N.

: DT23807007

TECHNICAL DESCRIPTIONS
MP720E42HT
( EURO 2 )

The information in this literature is intended to be of a general nature only. Iveco reserve
the right to modify or change specification at any time.

1
MP720E42HT N. : DT23807007

Gearbox TS-13612

Wheelbase Cab Drive Vcb

3200-1380 MPC LEFT HAND DRIVE K3FC22A1

MPL LEFT HAND DRIVE K3FC22F1

3500-1380 MPC LEFT HAND DRIVE K3FC23A1

MPL LEFT HAND DRIVE K3FC23F1

Gearbox ZF 16S-221

Wheelbase Cab Drive Vcb

3200-1380 MPC LEFT HAND DRIVE K3FC22D1

MPL LEFT HAND DRIVE K3FC22J1

3500-1380 MPC LEFT HAND DRIVE K3FC23D1

MPL LEFT HAND DRIVE K3FC23J1

2 11/01/2000
MP720E42HT N. : DT23807007

DIMENSIONS (mm) (AU 0296-D MPC)

A Wheelbase 3200-1380 3500-1380

B Total length 6844 7159

C Front overhang 1440 1440

D Rear overhang 785 785

E Max width 2500 2500

F Front axle to back of cab 500 500

K Overall height to top of cab, unladen 3056 3057

L Height of frame at frame end, unladen 1130 1130

M Front track 2040 2040

N Rear track 1827 1827

P Minimum ground clearance ( Axle2 ) 310 310

5th wheel position max 430 450

Approach angle 26° 26°

Departure angle 30° 31°

Ramp angle 22° 21°

Back of cab to end of frame 5084 5399

Steering radius wall to wall 7975 8325

Steering radius kerb to kerb 7400 7750

Frame top flange to ground (front axle unladen) 1110 1110

Frame top flange to ground (rear axle unladen) 1125 1125

3 11/01/2000
MP720E42HT N. : DT23807007

DIMENSIONS (mm) (AU 0297-D MPL)

A Wheelbase 3200-1380 3500-1380

B Total length 6844 7159

C Front overhang 1440 1440

D Rear overhang 785 785

E Max width 2500 2500

F Front axle to back of cab 940 940

K Overall height to top of cab, unladen 3056 3057

L Height of frame at frame end, unladen 1130 1130

M Front track 2040 2040

N Rear track 1827 1827

P Minimum ground clearance ( Axle2 ) 310 310

5th wheel position max 430 450

Approach angle 26° 26°

Departure angle 31° 31°

Ramp angle 22° 21°

Back of cab to end of frame 4644 4959

Steering radius wall to wall 7975 8325

Steering radius kerb to kerb 7400 7750

Frame top flange to ground (front axle unladen) 1110 1110

Frame top flange to ground (rear axle unladen) 1125 1125

4 11/01/2000
MP720E42HT N. : DT23807007

Weights (kg) (BU 0215-D MPC)

Wheelbase 3200-1380 3500-1380

GVW EEC 26000 26000

GCW EEC 85000 85000

GCW Series

Permitted weight on axle 1 EEC 7500 7500

Permitted weight on axle 2 EEC 9500 9500

Permitted weight on axle 3 EEC 9500 9500

Body payload EEC 16530 16440

Semitrailer weight 75530 75440

Vehicle kerbweight 1 EEC 4820 4855

Vehicle kerbweight 2 EEC 2325 2352

Vehicle kerbweight 3 EEC 2325 2353

Tractor kerbweight 9470 9560

Weights (kg) (BU 5215-D MPL)

Wheelbase 3200-1380 3500-1380

GVW EEC 26000 26000

GCW EEC 85000 85000

GCW Series

Permitted weight on axle 1 EEC 7500 7500

Permitted weight on axle 2 EEC 9500 9500

Permitted weight on axle 3 EEC 9500 9500

Body payload EEC 16420 16330

Semitrailer weight 75420 75330

Vehicle kerbweight 1 EEC 4875 4910

Vehicle kerbweight 2 EEC 2352 2380

Vehicle kerbweight 3 EEC 2353 2380

Tractor kerbweight 9580 9670

5 11/01/2000
MP720E42HT N. : DT23807007

Engine 8210.42L ( EU 0016-D)

Position FRONT

Disposition VERTICAL
Cycle DIESEL

Aspiration type TCA

Injection type DIRECT

No. of cylinders 6 IN-LINE

Fuel type DIESEL OIL

4 Stroke / 2 Stroke cycle 4

Total displacement cm³ 13798

Bore / Stroke mm 137 / 156

Max power kW/Hp (1) 309kW 420 Hp 198.87 Rad / sec 1900 r.p.m.

Specific fuel consumption-max power 225 g/kWh

Max torque rpm Nm (2) 194 Kgm 1900 Nm 115.13 Rad / sec 1100 r.p.m.

Specific fuel consumption-max torque 195 g/kWh g/Hph

Power loss 4% every 1000 m

Dry weight Kg 1100

Oil capacity kg 28

Crankshaft supported by 7 Bearings

Injection pump type ON LINE

Cooling system WATER

Hydraulic steering pump

Cold starting type TERMOSTARTER + CHOKE

Emissions according regulations

6 11/01/2000
MP720E42HT N. : DT23807007

Fuelling (ABU 0007-D)

No. of tanks 1

Total tank capacity l. 300

Fuel pump

Prefilter

Filter

Fuel separator

Air intake (AC 0001-D)

Filter type DRY

Snorkel position BEHIND THE CAB ON THE LEFT

Air intake WITH SNORKEL

Cooling (AD 0001-D)

Cooling system WATER

Fan type VISCOSTATIC

Clutch 17'' (FU 0002-D)

Type SINGLE DRY PLATE

GearboxEATON - TS-13612 (GU 0001-D)

Type NOT SYNCRONIZED

Installation ENGINE FLANGED

Control MANUAL H

No. of gears (forward) 12+3

Casing material CAST IRON

Dry weight Kg 338

Total ratio speed 14.88

Max. torque 185 Kgm

Possible P.T.O. installation

Gear ratios

1st 14.88

2nd 11.59

3rd 9.10

4th 6.98

5th 5.44

6th 4.27

7th 3.40

8th 2.65

9th 2.08

10th 1.63

11th 1.27

7 11/01/2000
MP720E42HT N. : DT23807007

Gear ratios

12th 1.0

Rev. 1st 13.82

Rev. 2nd 10.76

3rd R 8.45

GearboxZF - ZF 16S-221 (GU 0033-D)

Type SYNCRONIZED

Installation ENGINE FLANGED

Control MANUAL DOUBLE H

No. of gears (forward) 16+2 No. of synchro gears 16

Casing material ALUMINIUM

Dry weight Kg 295

Total ratio speed 16.47

Max. torque 224 Kgm/ 224 Nm

Possible P.T.O. installation

Gear ratios

1st 16.47

2nd 13.79

3rd 11.32

4th 9.48

5th 7.79

6th 6.52

7th 5.48

8th 4.58

9th 3.59

10th 3.01

11th 2.47

12th 2.07

13th 1.70

14th 1.42

15th 1.20

16th 1.0

Rev. 1st 15.42

Rev. 2nd 12.91

Front steering axle (LU 0002-D )

Identification 5886

Type RIGID

Steering angle (int.) 52°

Axle material STEEL

8 11/01/2000
MP720E42HT N. : DT23807007

Rear drive axle (MU 0019-D )

Identification 453291

Type BANJO

Axle TANDEM

Wheel arrangement TWIN

Axle box material CAST IRON

Reduction type HUBS REDUCTION

Rear drive axle (MU 5019-D )

Identification 453291

Type BANJO

Axle TANDEM

Wheel arrangement TWIN

Axle box material CAST IRON

Reduction type HUBS REDUCTION

Suspensions (NU 0004-D)

Front steering axle SINGLE RATE PARABOLIC SPRING

Rear drive axle CANTILEVER TYPE

Rear drive axle IN COMMON WITH THE SECOND AXLE

Main features

Axle no. 1 2

Leaf width mm 90 100

Auxiliary leaf spring length (mm) 1090

Master leaf spring length (mm) 1900 1460

No. of auxiliary leaf springs 1

No. of master leaf springs 3 3

Shock absorbers (PU 0003-D)

Shock absorbers no. (front) 2

Shock absorbers type HYDRAULIC TELESCOPIC

Anti-roll bars (OU 0001-D)

Position FRONT AXLE

Wheels (QU 0001-D)

Wheel type DISC

Rim dimensions 22,5" x 9.00"

9 11/01/2000
MP720E42HT N. : DT23807007

Tyres (RU 0009-D)

Tyre dimensions 13 R 22.5

Load-index 154/149

Speed index K = 110 Km/h

Rolling radius mm 543

Rolling circumference mm 3410,04

Axle Mounting

1 SINGLE

2 TWIN

Steering 8098 (KU 0002-D)

Type HYDRAULIC

Adjustment type HEIGHT + STEERING WHEEL ANGLE

Max. steering wheel diameter (mm) 500

No. of parts steering column 2

Chassis (mm) (JU 0029-D)

Frame section DOUBLE BOTTLE NECK

Front crossmember fixing BOLTED

Middle crossmember fixing RIVETED

Rear crossmember fixing BOLTED

Wheelbase 3200-1380 3500-1380

Side member material STEEL STEEL

Side member section "C" "C"

Edge thickness 10 10

Web thickness 10 10

Upper edge width 80 80

Lower edge width 80 80

Side member max. height 309 309

Frame width at rear 776 776

10 11/01/2000
MP720E42HT N. : DT23807007

Brakes (SU 0035-D)

Rear braking control

Air dryer

Trailer auxiliary brake

Air dryer

Auxiliary brake DECOMPRESSION TYPE BRAKE

Emergency brake SERVICE BRAKE

Parking brake SPRING BRAKE

Service brake AIR

Parking brake axles AXLE 2 AND 3

Total tank capacity l. 85

Air compressor displacement cm³ 221

Air compressor ONE CYLINDRE

Air tank material STEEL

Pipings material PLASTIC

Brake standards EEC

No. of circuits 2

Number of air tanks 5

Axle no. Axle 1 Axle 2 Axle 3

Brake type DRUM DRUM DRUM

No. of cylinders 2 2 2

Brake cylinder diameter (inches) 22 22 22

Drum diameter (mm) 410 410 410

Friction area cm² 2750 3085 3085

Linings width (mm) 180 200 200

Electrics (VU 0004-D)

Voltage V 24

Alternator power V/A 28/55

No. of batteries 2

Battery voltage V 12

Battery capacity Ah 143

Starter motor power kW 6.5

Lighting (WU 0002-D)

No. of headlights 2

Type of lamps HALOGEN

Front parking lights

Tail lights

Front side marker lights

11 11/01/2000
MP720E42HT N. : DT23807007

Lighting (WU 0002-D)

Backup lights

Hazard lights

Number plate lights

Rear fog lights

Side lights

Rear marker lights

Stop lights

Front direction indicators

Side direction indicators

Rear direction indicators

Rear cab lighting

Provision for front fog lights

Cab MPC (YU 0003-D)

Cab type FORWARD CONTROL

Version SHORT CAB

Material STEEL

Steps no. 3

Overall length mm 1675

External width mm 2285

Internal height in front of the seat (mm) 1560

Tilting device HYDRAULIC

Tilt angle 67°

Roof hatch control system MANUAL

Front doors type WINDOW SASH

Front doors height (mm) 1323

Front doors width (mm) 788

Front doors opening angle 90°

Wind-up-window type (front) LEFT ELECTRICAL

Sun visors no. 2

Ceiling no. 1

Roof type LOW

Windscreen type STRENGTHENED - LAMINATED

Windscreen ONE PIECE FLAT

Windscreen post type EEC

No. of windscreen wipers 2

No. of windscreen wiper speeds 2

Rear windows

Front suspension points 2 MC PHERSON UNITS

Rear suspension points 1 MC PHERSON UNITS

Rear view mirrors no. 2

12 11/01/2000
MP720E42HT N. : DT23807007

Cab MPC (YU 0003-D)

No. of places 2

No. of seats 2

Driver seat type AIR

Driver seat adjustment IN HEIGHT LENGTH AND BACK INCLINATION

Passenger seat type SINGLE - FIXED

Passenger seat adjustment IN HEIGHT LENGTH AND BACK INCLINATION

Fan speed no. 4

Provision for safety belts

Lighter

CB wiring

Radio wiring

Cab MPL (YU 5003-D)

Cab type FORWARD CONTROL

Version SLEEPER CAB

Material STEEL

Steps no. 3

Overall length mm 2092

External width mm 2285

Internal height in front of the seat (mm) 1560

Tilting device HYDRAULIC

Tilt angle 67°

Roof hatch control system MANUAL

Front doors type WINDOW SASH

Front doors height (mm) 1323

Front doors width (mm) 788

Front doors opening angle 90°

Wind-up-window type (front) FULL ELECTRICAL

Sun visors no. 2

Ceiling no. 1

Roof type LOW

Windscreen type STRENGTHENED - LAMINATED

Windscreen ONE PIECE FLAT

Windscreen post type EEC

No. of windscreen wipers 2

No. of windscreen wiper speeds 2

Side windows

Front suspension points 2 MC PHERSON UNITS

Rear suspension points 1 MC PHERSON UNITS

Rear view mirrors no. 2

No. of places 2

13 11/01/2000
MP720E42HT N. : DT23807007

Cab MPL (YU 5003-D)

No. of seats 2

Driver seat type AIR

Driver seat adjustment IN HEIGHT LENGTH AND BACK INCLINATION

Passenger seat type AIR

Passenger seat adjustment IN HEIGHT LENGTH AND BACK INCLINATION

Fan speed no. 4

No. of bunks 1

Bunk position LOWER OVERTURNABLE

Provision for safety belts

Lighter

CB wiring

Radio wiring

In cab equipment (TU 0002-D)

Warning lights

High beam

Direction indicators (tractor)

Direction indicators (trailer)

Hazard lights

Low ranges

Speed limiter

Longitudinal differential

Rear transversal differential

Hand brake on

Front brake wear

Rear brake wear

Engine preheating

Low engine oil pressure

Clogged air filter

Air pressure for air suspensions

Unhooked cab

Battery charge

Warning lights prearrangement

Speed limiter

Trailer coupling w/o ABS signaling

Power take off

ABS failure (tractor)

ABS failure (trailer)

14 11/01/2000
MP720E42HT N. : DT23807007

Equipment prearrangement

IVECO Control

Switches

External lights

Hazard lights

Rear fog lights + warning light

Loading platform light

Right handside internal spot light

Left handside internal spot light

Rear cab light

Switches prearrangement

Fog lights

Additional headlights

Heated windscreen

Instruments

Rpm counter

Air brakes pressure gauge

Engine oil pressure gauge + warning light

Tachograph (2 drivers)

Water temperature indicator

Fuel level gauge

Multifunction stalk

Horn

High beam

Blinker

Indicator lights

Windscreen wiper

Windscreen wiper with interval

Miscellaneous (XU 0013-D)

Chocks no. 2

Engine guards SOUND PROUF

Jack

Front towing hitch

Tools kit

Drawings (DU 0155-D)

Wheelbase 3200-1380 3500-1380

Left hand drive vehicle 4180 3290 4180 4182

drawing

Sleeper cab frame drawing 4180 3913 4180 4517

Day cab frame drawing 4180 3913 4180 4517

15 11/01/2000
MP720E42HT N. : DT23807007

Gearbox TS-13612
Tyres 12 R 22.5
Max. gradient %
Rear axle ratio Gearbox ratio Max. speed GVW GCW
Km/h
33 37 38 40 44 56 72 85

3.792 1 - 14.88 6.721 56 50 48 46 42 33 25 21

12 - 1 100 3.7 3.3 3.2 3.1 2.8 2.2 1.7 1.4
4.227 1 - 14.88 6.03 62 56 54 51 47 37 28 24
12 - 1 89.72 4.2 3.7 3.6 3.4 3.1 2.4 1.9 1.6
5.008 1 - 14.88 5.089 74 66 64 61 55 43 34 28
12 - 1 75.73 5 4.4 4.3 4.1 3.7 2.9 2.2 1.9
5.558 1 - 14.88 4.586 82 73 71 68 61 48 37 32
12 - 1 68.24 5.5 4.9 4.8 4.5 4.1 3.2 2.5 2.1
6.589 1 - 14.88 3.868 97 87 85 80 73 57 44 38
12 - 1 57.56 6.5 5.8 5.7 5.4 4.9 3.8 3 2.5

Gearbox TS-13612
Tyres 12.00 R 20 20PR
Max. gradient %

Rear axle ratio Gearbox ratio Max. speed GVW GCW

Km/h
33 37 38 40 44 56 72 85

3.792 1 - 14.88 6.925 54 48 47 45 41 32 25 21

12 - 1 103 3.6 3.2 3.1 3 2.7 2.1 1.6 1.4
4.227 1 - 14.88 6.212 60 54 52 50 45 35 27 23
12 - 1 92.44 4 3.6 3.5 3.3 3 2.4 1.8 1.5
5.008 1 - 14.88 5.243 72 64 62 59 54 42 33 28
12 - 1 78.02 4.8 4.3 4.2 4 3.6 2.8 2.2 1.8
5.558 1 - 14.88 4.724 80 71 69 66 60 47 36 31
12 - 1 70.3 5.3 4.8 4.6 4.4 4 3.1 2.4 2
6.589 1 - 14.88 3.985 95 84 82 78 71 55 43 36
12 - 1 59.3 6.3 5.6 5.5 5.2 4.7 3.7 2.9 2.4

Gearbox TS-13612
Tyres 13 R 22.5
Max. gradient %
Rear axle ratio Gearbox ratio Max. speed GVW GCW
Km/h
33 37 38 40 44 56 72 85

3.792 1 - 14.88 6.925 54 48 47 45 41 32 25 21

12 - 1 103 3.6 3.2 3.1 3 2.7 2.1 1.6 1.4
4.227 1 - 14.88 6.212 60 54 52 50 45 35 27 23
12 - 1 92.44 4 3.6 3.5 3.3 3 2.4 1.8 1.5
5.008 1 - 14.88 5.243 72 64 62 59 54 42 33 28
12 - 1 78.02 4.8 4.3 4.2 4 3.6 2.8 2.2 1.8
5.558 1 - 14.88 4.724 80 71 69 66 60 47 36 31
12 - 1 70.3 5.3 4.8 4.6 4.4 4 3.1 2.4 2
6.589 1 - 14.88 3.985 95 84 82 78 71 55 43 36
12 - 1 59.3 6.3 5.6 5.5 5.2 4.7 3.7 2.9 2.4

16 11/01/2000
MP720E42HT N. : DT23807007

Gearbox TS-13612
Tyres 315/80 R 22.5
Max. gradient %
Rear axle ratio Gearbox ratio Max. speed GVW GCW
Km/h
33 37 38 40 44 56 72 85

3.792 1 - 14.88 6.632 57 50 49 47 42 33 26 22

12 - 1 98.69 3.8 3.4 3.3 3.1 2.8 2.2 1.7 1.4
4.227 1 - 14.88 5.95 63 56 55 52 47 37 29 24
12 - 1 88.54 4.2 3.8 3.7 3.5 3.2 2.5 1.9 1.6
5.008 1 - 14.88 5.022 75 67 65 62 56 44 34 29
12 - 1 74.73 5 4.5 4.4 4.1 3.7 2.9 2.3 1.9
5.558 1 - 14.88 4.525 83 74 72 69 62 49 38 32
12 - 1 67.33 5.6 5 4.8 4.6 4.2 3.3 2.5 2.1
6.589 1 - 14.88 3.817 99 88 86 81 74 58 45 38
12 - 1 56.8 6.6 5.9 5.7 5.5 5 3.9 3 2.5

Gearbox ZF 16S-221
Tyres 12 R 22.5
Max. gradient %

Rear axle ratio Gearbox ratio Max. speed GVW GCW

Km/h
33 37 38 40 44 56 72 85

3.792 1 - 16.47 6.072 62 55 54 51 46 36 28 24

16 - 1 100 3.7 3.3 3.2 3.1 2.8 2.2 1.7 1.4
4.227 1 - 16.47 5.448 69 62 60 57 52 40 31 26
16 - 1 89.72 4.2 3.7 3.6 3.4 3.1 2.4 1.9 1.6
5.008 1 - 16.47 4.598 82 73 71 67 61 48 37 31
16 - 1 75.73 5 4.4 4.3 4.1 3.7 2.9 2.2 1.9
5.558 1 - 16.47 4.143 91 81 79 75 68 53 41 35
16 - 1 68.24 5.5 4.9 4.8 4.5 4.1 3.2 2.5 2.1
6.589 1 - 16.47 3.495 100 96 94 89 81 63 49 42
16 - 1 57.56 6.5 5.8 5.7 5.4 4.9 3.8 3 2.5

Gearbox ZF 16S-221
Tyres 12.00 R 20 20PR
Max. gradient %
Rear axle ratio Gearbox ratio Max. speed GVW GCW
Km/h
33 37 38 40 44 56 72 85

3.792 1 - 16.47 6.256 60 53 52 49 45 35 27 23

16 - 1 103 3.6 3.2 3.1 3 2.7 2.1 1.6 1.4
4.227 1 - 16.47 5.612 67 60 58 55 50 39 30 26
16 - 1 92.44 4 3.6 3.5 3.3 3 2.4 1.8 1.5
5.008 1 - 16.47 4.737 79 71 69 65 59 47 36 31
16 - 1 78.02 4.8 4.3 4.2 4 3.6 2.8 2.2 1.8
5.558 1 - 16.47 4.268 88 79 77 73 66 52 40 34
16 - 1 70.3 5.3 4.8 4.6 4.4 4 3.1 2.4 2
6.589 1 - 16.47 3.6 100 93 91 86 78 61 48 40
16 - 1 59.3 6.3 5.6 5.5 5.2 4.7 3.7 2.9 2.4

17 11/01/2000
MP720E42HT N. : DT23807007

Gearbox ZF 16S-221
Tyres 13 R 22.5
Max. gradient %
Rear axle ratio Gearbox ratio Max. speed GVW GCW
Km/h
33 37 38 40 44 56 72 85

3.792 1 - 16.47 6.256 60 53 52 49 45 35 27 23

16 - 1 103 3.6 3.2 3.1 3 2.7 2.1 1.6 1.4
4.227 1 - 16.47 5.612 67 60 58 55 50 39 30 26
16 - 1 92.44 4 3.6 3.5 3.3 3 2.4 1.8 1.5
5.008 1 - 16.47 4.737 79 71 69 65 59 47 36 31
16 - 1 78.02 4.8 4.3 4.2 4 3.6 2.8 2.2 1.8
5.558 1 - 16.47 4.268 88 79 77 73 66 52 40 34
16 - 1 70.3 5.3 4.8 4.6 4.4 4 3.1 2.4 2
6.589 1 - 16.47 3.6 100 93 91 86 78 61 48 40
16 - 1 59.3 6.3 5.6 5.5 5.2 4.7 3.7 2.9 2.4

Gearbox ZF 16S-221
Tyres 315/80 R 22.5
Max. gradient %

Rear axle ratio Gearbox ratio Max. speed GVW GCW

Km/h
33 37 38 40 44 56 72 85

3.792 1 - 16.47 5.992 63 56 54 52 47 37 28 24

16 - 1 98.69 3.8 3.4 3.3 3.1 2.8 2.2 1.7 1.4
4.227 1 - 16.47 5.375 70 62 61 58 52 41 32 27
16 - 1 88.54 4.2 3.8 3.7 3.5 3.2 2.5 1.9 1.6
5.008 1 - 16.47 4.537 83 74 72 68 62 49 38 32
16 - 1 74.73 5 4.5 4.4 4.1 3.7 2.9 2.3 1.9
5.558 1 - 16.47 4.088 92 82 80 76 69 54 42 35
16 - 1 67.33 5.6 5 4.8 4.6 4.2 3.3 2.5 2.1
6.589 1 - 16.47 3.448 100 97 95 90 82 64 50 42
16 - 1 56.8 6.6 5.9 5.7 5.5 5 3.9 3 2.5

18 11/01/2000
