MOP - configuration of MPR Link

Insert Flash Memory: Insert Memory Card in IDU as per photo given below

Open cap from IDU


and insert flash card
and then close the
cap

This side up of flash


memory at the time of
inserting in IDU

Note: Plz insert flash memory in IDU before powering on of IDU

Configure Laptop IP: Laptop IP: 10.0.1.100


Subnet Mask: 255.255.255.0
Open Web EML Version 7.1
For BSNL project software is available at MP WNMS server
IP: 10.136.130.30
File Name: R7.1.0-ETSI.rar
Size: 1.77Gb
Click on desktop Icon WebEML:

Default IP Address is
10.0.1.2 then click ok

Then Show icon will be Highlight,


and click on that Icon
User Name: initial

Password: adminadmin

User Name: initial


Password: adminadmin

Click on Accept
This is first login window of MSS-1

Click on MSS core and setting


then add MPT-HQAM in port
1 or 2 as per plan
Click on Port 1.1 and then
power source then enables
PFoE

Click on ODU and then setting :

Configure shifter value as per LB

Configure modulation, Tx freq and


Rx freq as per plan

Configure Tx power
as per LB
Click on Maintenance and off tx
mute
