Roller Guide System
V700
Roller Guide System
HIGH SPEED
MACHINING
CENTER
LONG CHANG MACHINERY CO., LTD.
01 FIRST V700
SPEED
& AC C U R AC Y
HIGH SPEED MACHINING CENTER
• 3-axes high rigidity & precision roller
guide ways.
• Direct driven spindle makes excellent
finishing surface with low noise and low
vibration.
• Rapid traverse speed X.Y.Z 48 m/min.
(FANUC Z 32m/min)
• High accuracy.
• Full enclosed splashguard for elegant
outlook.
• Wide door open design, easy access to
working-piece.
V700 FIRST 02
• MEEHANITE cast iron for all major machine parts.
• Box type headstock construction provides outstanding cutting capability.
OUTSTANDING • Heavy duty roller guide ways with wide spacing.
STRUCTURE • Direct driven on 3-axes ball screw.
• Working surface 800x400mm
03 FIRST V700
PRECISION BALL SCREW
• Ball screws directly driven with servo motors.
• All axes are with high precision C3 grade ball screws.
• Ball screws diameter X .Y. Z : 32mm
PRECISION HAND SCRAPING
• Hand scraping and precision grinding ensure stability
and accuracy.
SPIRAL TYPE
CHIP CONVEYOR
• Standard spiral type chip conveyor
in the middle removes chips out
easily.
V700 FIRST 04
• Direct drive rigid 10,000 rpm spindle unit
• Easy for after service
• Low noise and low vibration make
excellent finishing surface
• High accuracy Spindle cooling system for accuracy
and long life.
STANDARD
DIRECT
DRIVE
SPINDLE
Spindle
CHILLER
COOLANT THROUGH SPINDLE (OP) AIR THROUGH SPINDLE (OP)
05 FIRST V700
Heavy duty
linear guide
ways
• Linear guide ways are in roller type.
(X/Y/Z: 35mm)
• TWO INDEPENDENT PUMPS ENSURE EFFICIENT
COOLING ON WORK PIECE AND STRONG CHIP
FLUSHING DURING MACHINING.
AUTOMATIC
LUBRICATION SYSTEM
• Automatic central lubricator provides
excellent lubrication to all guide way blocks
and ball screws.
V700 FIRST 06
AUTOMATIC TOOL CHANGE
• 24 Tools Magazine
TOOL CHANG TIME
• TOOL TO TOOL : 2.0 SEC
• CHIP TO CHIP : 4.6 SEC
OIL SKIMMER (OP)
• Steel wiper Oil skimmer can
easily separate the oil from
coolant water.
Steel material wiper
FLAT TYPE CHIP
CONVEYOR (OP)
• Flat type chip conveyor can
be installed at right side or
left, easy to arrange layout.
07 FIRST V700
IN-HOUSE MODERN
MANUFACTURING FACILITIES
We have OKUMA 5-face machining center TOYODA
,TOSHIBA ,MITSUI SEIKI Horizontal machining
centers with pallet changers,OKUMA CNC
lathes,Warner ,OKUMA and TOYODA CNC grinders
for building the best machines ,whole critical and
precision parts are done in house.
MACHINE DIMENSION 330
1070
0002Bi22b
V 7 00
(A)
+
1986
2080 1900
2284 Z-AXIS TRAVEL 550 (A)=2720mm
Z-AXIS TRAVEL 650 (A)=2770mm
V700 FIRST 08
Standard accessories
• Fully enclosed splash guard
• 40 Taper arm type 24 tools
• Surround chip flushing system
• Automatic lubrication system
• Telescopic covers
• Spiral type chip conveyor
• Working light
• Alarm light
• Tool box
• Leveling bolts, pads and nuts
OPTIONAL ACCESSORIES
• 4th or 4+5th axis rotary table
• Coolant through spindle system
• Air through spindle system
• Door lock
• Spindle air blow
• Water gun
• Air gun
• Mist collection system
• Oil skimmer
• Flat type chip conveyor
• Power transformer
• Z axis travel 650mm
09 FIRST V700
Machine Specification V700
Travel
X-Axis 700 mm (27.5")
Y-Axis 400 mm (15.7")
Z-Axis 550 mm (21.6") / 650 mm (25.5") (Option)
Spindle nose to table 150 ~700 mm (5.9 ~ 27.5") / 150 ~800 mm (5.9 ~ 31.4") (Option)
Table
Table size 800 mm x 400 mm (31.5 ~15.7")
Floor to table 858 mm (33.77")
Max. table loading capacity 250 kg (551 lbs)
T-slot (number x width x pitch) 3x18 mm x 100 mm (3x0.7" x 3.93")
Spindle center to column 500 mm (19.68")
Feed system
Rapid traverse speed X / Y / Z ︰48 / 48 / 32 M/min
Feed motor (FANUC) X/Y: 1.8kW , Z: 3.0kW
X ︰32 mm / 16 mm (1.26/0.63") Y ︰32 mm / 16 mm (1.26/0.63")
Ball screw diameter & pitch
Z ︰32 mm / 16 mm (1.26/0.63")
Cutting feed rate 1~10000 mm/min
Type of transmission Direct Drive
Spindle
Type of tool shank BT 40 / CAT 40 / DIN 69871A
Max. spindle speed 10000 rpm / 12000 or 15000 rpm (Option)
Spindle motor 5.5/7.5kW
Type of transmission Direct Drive
ATC
Tool storage capacity 24 T
ATC type Arm type
Max. tool diameter 80 mm (3.14")
Without adjacent tool 150 mm (5.9")
Max. tool length 250 (9.84")
Max. tool weight 7kg (14.14 lbs)
Tool changing time (Tool to Tool) 2.0 sec
Tool changing time (Chip to Chip) 4.6 sec
Method of tool selection Random selection
bi-directional magazine rotation
Tool display Yes
Special tool management Yes
Coolant system
Coolant tank size 200 L
Coolant capacity 150 L/min
Chip Flush capacity 150 L/min
Machine size
Machine height 2770 mm
Floor space 1900 x 2284 mm (74.8" x 89.92")
weight 3690 kg (8133 lbs)
Power source
Electrical power supply 20 KVA / 3PH，220V 50/60HZ
Compressed air supply 6.0 kgf/c㎡ (85psi) (0.6MPa)
Controller
FANUC / HEIDENHAIN / MITSUBISHI / SIEMENS
Edition / A00
* Specifications may different according to option accessories and are subject to change without notice.
* Remark: Rapid traverse speed on Z axis will be 48M/min while in Heidenhain or Mitsubishi.
