Information Theory and Coding

Report

Submitted to: Submitted by:

Neelam Ma’am Name: Gaurav Deepak Nair
Roll no: 01815002817
Branch: ECE-2
Hamming code
Hamming code is a liner code that is useful for error detection up to two
immediate bit errors. It is capable of single-bit errors.

In Hamming code, the source encodes the message by adding redundant

bits in the message. These redundant bits are mostly inserted and
generated at certain positions in the message to accomplish error detection
and correction process.

History of Hamming code

• Hamming code is a technique build by R.W.Hamming to detect
errors.
• Hamming code should be applied to data units of any length and
uses the relationship between data and redundancy bits.
• He worked on the problem of the error-correction method and
developed an increasingly powerful array of algorithms called
Hamming code.
• In 1950, he published the Hamming Code, which widely used today
in applications like ECC memory.

Application of Hamming code

Here are some common applications of using Hemming code:

• Satellites
• Computer Memory
• Modems
• PlasmaCAM
• Open connectors
• Shielding wire
• Embedded Processor

Advantages of Hamming code

• Hamming code method is effective on networks where the data
streams are given for the single-bit errors.
• Hamming code not only provides the detection of a bit error but also
helps you to indent bit containing error so that it can be corrected.
• The ease of use of hamming codes makes it best them suitable for
use in computer memory and single-error correction.
Disadvantages of Hamming code
• Single-bit error detection and correction code. However, if multiple
bits are founded error, then the outcome may result in another bit
which should be correct to be changed. This can cause the data to
be further errored.
• Hamming code algorithm can solve only single bits issues.

Process of Encoding a message using Hamming

Code
The process used by the sender to encode the message includes the
following three steps:

• Calculation of total numbers of redundant bits.

• Checking the position of the redundant bits.
• Lastly, calculating the values of these redundant bits.

When the above redundant bits are embedded within the message, it is
sent to the user.

Step 1) Calculation of the total number of redundant bits.

Let assume that the message contains:

• n- number of data bits

• p - number of redundant bits which are added to it so that np can
indicate at least (n + p + 1) different states.

Here, (n + p) depicts the location of an error in each of (n + p) bit positions

and one extra state indicates no error. As p bits can indicate 2p states,
2p has to at least equal to (n + p + 1).

Step 2) Placing the redundant bits in their correct position.

The p redundant bits should be placed at bit positions of powers of 2. For

example, 1, 2, 4, 8, 16, etc. They are referred to as p1 (at position 1), p2 (at
position 2), p3 (at position 4), etc.

Step 3) Calculation of the values of the redundant bit.

The redundant bits should be parity bits makes the number of 1s either
even or odd.
The two types of parity are ?

• Total numbers of bits in the message is made even is called even

parity.
• The total number of bits in the message is made odd is called odd
parity.

Here, all the redundant bit, p1, is must calculated as the parity. It should
cover all the bit positions whose binary representation should include a 1 in
the 1st position excluding the position of p1.

P1 is the parity bit for every data bits in positions whose binary
representation includes a 1 in the less important position not including 1
Like (3, 5, 7, 9, …. )

P2 is the parity bit for every data bits in positions whose binary
representation include 1 in the position 2 from right, not including 2 Like (3,
6, 7, 10, 11,…)

P3 is the parity bit for every bit in positions whose binary representation
includes a 1 in the position 3 from right not include 4 Like (5-7, 12-15,… )

Process of Decrypting a Message in Hamming

code
Receiver gets incoming messages which require to performs recalculations
to find and correct errors.

The recalculation process done in the following steps:

• Counting the number of redundant bits.

• Correctly positioning of all the redundant bits.
• Parity check

Step 1) Counting the number of redundant bits

You can use the same formula for encoding, the number of redundant bits

2p ? n + p + 1

Here, the number of data bits and p is the number of redundant bits.

Step 2) Correctly positing all the redundant bits

Here, p is a redundant bit which is located at bit positions of powers of 2,
For example, 1, 2, 4, 8, etc.

Step 3) Parity check

Parity bits need to calculated based on data bits and the redundant bits.

p1 = parity(1, 3, 5, 7, 9, 11…)

p2 = parity(2, 3, 6, 7, 10, 11… )

p3 = parity(4-7, 12-15, 20-23… )

Summary
• Transmitted data can be corrupted during communication
• Three types of Bit error are 1) Single Bit Errors 2) Multiple Bit Error 3)
Burst Bit errors
• The change made in one bit in the entire data sequence is known as
"Single bit error."
• In data sequence, if there is a change in two or more bits of a data
sequence of a transmitter to receiver, it is known as "Multiple bit
errors."
• The change of the set of bits in data sequence is known as "Burst
error".
• Error detection is a method of detecting the errors which are present
in the data transmitted from a transmitter to receiver in a data
communication system
• Three types of error detection codes are 1) Parity Checking 2) Cyclic
Redundancy Check (CRC) 3) Longitudinal Redundancy Check (LRC)
• Hamming code is a liner code that is useful for error detection up to
two immediate bit errors. It is capable of single-bit errors.
• Hamming code is a technique build by R.W.Hamming to detect
errors.
• Common applications of using Hemming code are Satellites
Computer Memory, Modems, Embedded Processor, etc.
• The biggest benefit of the hamming code method is effective on
networks where the data streams are given for the single-bit errors.
• The biggest drawback of the hamming code method is that it can
solve only single bits issues.
• We can perform the process of encrypting and decoding the
message with the help of hamming code.
Numerical

Q) Find the parity-check matrix, the generator matrix, and all the 16
codewords for a (7, 4) Hamming code. Determine the syndrome, if the
received codeword is a) 0001111 and b) 0111111.

Solution
The parity-check matrix H matrix consists of all binary columns except the
all zero sequence, we thus have it in the following form:
H=110110110111|100|010|001
and the corresponding generator matrix G is as follows:
G=1000010000100001||||110110110111
The resulting codewords are all listed in the following table:
Message (M) Codeword (C)
0000 0000000
0001 0001111
0010 0010011
0011 0011100
0100 0100101
0101 0101010
0110 0110110
0111 0111001
1000 1000110
1001 1001001
1010 1010101
1011 1011010
1100 1100011
1101 1101100
1110 1110000
 Message (M) Codeword (C)
1111 1111111

(a) S=RHT=000. Since the syndrome is a zero vector, there are no

errors in the codeword.

(b) S=RHT=110. Since the syndrome corresponds to the first row of

column of H, the first bit of the received codeword is in error (i.e., the
transmitted codeword was 1111111).

Q) Consider (7,4) hamming code, with d min=3, show that it is a perfect

code.

Solution
To find it is a perfect code we have
2𝑛−𝑘 ≥ ∑𝑡𝑖=0 𝑛 𝐶𝑖
𝑑𝑚𝑖𝑛 −1 3−1
Where 𝑡 = = =1
2 2

27−4 ≥ ∑1𝑖=0 7𝐶0

23 ≥ 7𝐶0 + 7𝐶1

23 ≥ 1 + 7

8≥ 8

8=8

Therefore, (7,4) is a perfect code
