Normalization

NORMALISATION
CHAPTER 3: NORMALISATION
Database Systems
Objective
At the end of this chapter, students should be able to :
 Define relation.
 Recognize problems in relational data model.
 Define normalization and the level of normalization.
 Identify the step in normalization.
2
Database Systems
3.1.3 Problems In Relational Data Model
 There are 2 problems in relational data model :

- Anomalies
- Information Redundancy
(a) Anomalies
Anomalies - Errors or inconsistencies that may result when a user attempts to update
a table that contains redundant data.
Types of anomalies:
(i) Modification Anomalies
(ii) Insert Anomalies
(iii) Delete Anomalies
(b) Information Redundancy

Duplication of data due to storing the same data multiple times.
a) Update Anomalies
i) Modification Anomalies
STUDENT_COURSE
Student_ID Student_Name Address Course_Code Course_Name
S0144 Hamizah Mohamed Jln. Kg. Gajah ASDIM Associate Diploma in

Redzwan Interactive
Multimedia
S0149 Amjadi Abd. Mubin Bandar Baru CGMP200 Computer Power
Bangi 200 (Graphic and
Multimedia)
S0157 Nurazean Bt. Md. Tmn. Koperasi CITP100 Computer power 100
Sobri Polis (IT)
S0159 Aidil Akmar Hj. Tmn. Melawati CGMP200 Computer Power
Ayob 200 (Graphic and
Multimedia)
S0035 Syed Ahmad Rizal B. Jalan Puchong DIPCGR Diploma in Computer
Syed Abdul Razak Graphic and Design.
The Problem :
3
Database Systems
If we want to update Course_Name Computer Power 200 (Graphic & Multimedia) to Computer Power
200 (Graphic) from STUDENT_COURSE table, we have to update all the rows of all students who
take that course. The problem is we have to update more than once.
The Solution :
Therefore, to avoid this problem, we have to separate the STUDENT_COURSE table as follows :
STUDENT
Student_ID Student_Name Address Course_Code
S0144 Hamizah Mohamed Jln. Kg. Gajah ASDIM

Redzwan
S0149 Amjadi Abd. Mubin Bandar Baru Bangi CGMP200
S0157 Nurazean Bt. Md. Sobri Tmn. Koperasi Polis CITP100
S0159 Aidil Akmar Hj. Ayob Tmn. Melawati CGMP200
S0035 Syed Ahmad Rizal B. Syed Jalan Puchong DIPCGR
Abdul Razak
COURSE
Course_Code Course_Name
ASDIM Associate Diploma in Interactive Multimedia
CGMP200 Computer Power 200 (Graphic )
CITP100 Computer power 100 (IT)
DIPCGR Diploma in Computer Graphic and Design
The process to update Course will occur once without affecting other records.
ii) Insert Anomalies
STUDENT_COURSE
Student_ID Student_name Address Course_Code Course_Name
S0144 Hamizah Mohamed Jln. Kg. Gajah ASDIM Associate Diploma in

Redzwan Interactive
Multimedia
S0149 Amjadi Abd. Mubin Bandar Baru CGMP200 Computer Power 200
Bangi (Graphic and
Multimedia)
S0157 Nurazean Bt. Md. Tmn. Koperasi CITP100 Computer power 100
Sobri Polis (IT)
S0159 Aidil Akmar Hj. Tmn. Melawati DIPCGR Diploma in Computer
Ayob Graphic and Design
S0035 Syed Ahmad Rizal B. Jalan Puchong CGMP200 Computer Power 200
Syed Abdul Razak (Graphic and
Multimedia)
(null) (null) (null) (null) Diploma in
4
Database Systems
Information
Technology
The Problem :
If we want to insert a new Course_Code and Course_Name to the STUDENT_COURSE table, it is
necessary to enter no data (null) into the attribute for student (Student_ID, Student_Name, Address).
The problem is the primary key (Student_ID) cannot be null.
The Solution :
STUDENT
Student_ID Student_Name Address Course_Cide
Redzwan
S0159 Aidil Akmar Hj. Ayob Tmn. Melawati CGMP200
S0035 Syed Ahmad Rizal B. Syed Jalan Puchong DIPCGR
Abdul Razak
COURSE
CGMP200 Computer Power 200 (Graphic)
CGMP200 Diploma in Information Technology
Any insertion to the COURSE table will not affect to the primary key in STUDENT table.
iii) Delete Anomalies
STUDENT_COURSE
Student_ID Student_Name Address Course_Code Course_Name
S0144 Hamizah Mohamed Jln. Kg. Gajah ASDIM Associate Diploma

Redzwan in Interactive
Multimedia
S0149 Amjadi Abd. Mubin Bandar Baru CGMP200 Computer Power
Bangi 200 (Graphic and
Multimedia)
S0157 Nurazean Bt. Md. Sobri Tmn. Koperasi CITP100 Computer power
Polis 100 (IT)
S0159 Aidil Akmar Hj. Ayob Tmn. Melawati DIPCGR Diploma in
Computer
Graphic and
5
Database Systems
Design
S0035 Syed Ahmad Rizal B. Jalan Puchong CGMP200 Computer Power
Syed Abdul Razak 200 (Graphic and
Multimedia)
The Problem :
When the Student_ID S0035 is deleted from STUDENT_COURSE table, information about any
Course_Code DIPCGR related to that student will also be deleted. That means no other Course_Code
DIPCGR remains in the database.
The Solution :
STUDENT
Student_ID Student_Name Address Course_Code

Redzwan
S0035 Syed Ahmad Rizal B. Syed Jalan Puchong CGMP200
Abdul Razak
COURSE

CGMP200 Computer Power 200 (Grafik)
CGMP200 Diploma in Information Technology
Any deletion from STUDENT table will not affect the data in COURSE table.
(b) Information Redundancy

- Duplication of data due to the storing of the same data multiple times.
STUDENT_SUBJECT
Student_ Student_Name Address Subject_Cod Subject_Name Credit_Hours
ID
e
S0144 Hamizah Mohamed Jln. Kg. Gajah ACT410 Computerised 4
Redzwan Accounting
S0149 Amjadi Abd. Mubin Bandar Baru ADM101 Internet 4
6
Database Systems
Bangi Publishing
S0157 Nurazean Bt. Md. Sobri Tmn. Koperasi ADM101 Internet 4
Polis Publishing
S0159 Aidil Akmar Hj. Ayob Tmn. Melawati ADM301 Project 4
S0035 Syed Ahmad Rizal B. Jalan Puchong ADM101 Internet 4
Syed Abdul Razak Publishing
The Problem :
In the STUDENT_SUBJECT table there is redundant information. It shows that the details of
subject ADM101 (Internet Publishing) are repeated for every member of Student_ID enrolled for
that subject.
The solution :
Therefore, to avoid this problem, we have to separate the STUDENT_SUBJECT table as follows:
It shows that the subject information appears only once for each
3.2 Penormalan (Normalisation) subject in SUBJECT relation & only the Subject_Code is
repeated in the STUDENT_SUBJECT relation.
3.2 Normalisation
Normalisation
7
Database Systems
A process for assigning attributes into table and reduces data redundancy and helps eliminate the data
anomalies that associated with poor database design (unnormalised).
Level of Normalisation
There are 3 level of normalisation :
First normal Form (1NF)

Second Normal Form (2NF)
Third Normal Form (3NF)
First Normal Form (1NF)

A relation where the intersection of each row and column contains no repeating values (only
one value).

A relation that is in 1NF and every non-primary key attribute is fully functionally dependent on
the primary key.

A relation in which based on the concept of transitive dependency.
8
Database Systems
3.2.1 Steps in Normalisation
Table with repeating groups

(Unnormalised Form (UNF)) Remove repeating groups
Identify Functional
Dependencies
Remove Transitive
Third Normal Form (3NF) Dependencies
Example 1:
Steps in Normalisation

(Unnormalised Form (UNF)) Remove repeating groups
(refer table 1.1) (refer Note 1.1)
(rujuk jadual 1.1)

(refer table 1.2) Identify Functional
Dependencies
(refer Note 1.2)
(Second Normal Form (2NF)) Remove Transitive

(refer table 1.3) Dependencies
(refer Note 1.3)
(Third Normal Form9(3NF))

(refer table 1.4)
Database Systems
Table 1.1
Unnormalised Form (UNF)
STUDENT
Student ID Student Subject Name Subject Credit Grade Address Course Coordinator
Name Code Hours
S0001 Azlina Computerised ACT410 4 A Sentul Diploma in Fazilah
Ahmad Accounting Information
Internet
Repetitive
ADM101
group 4 B Technology
Publishing 4
Graphic
Attributes that DesignmoreART210
contains than one value in eachC and every line.
Application
S0144 Amirul Graphic ART310 4 A Shah Alam Diploma in Ahmad
Hamdan Communication Computer
Introduction to ART230 2 B Graphic
graphic Design Design
Business BUS210 4 B
Organization
S0151 Mazlina Promotion ART410 4 C Shah Alam Associate Sahada

Yakub Design ART 210 4 Diploma in
Graphic Design A Interactive
Application BUS210 4 Multimedia
Business A
Organisation
STUDENT (Student_ID, Student_name, Subject_name , Subject_code, Credit_hour, Grade, Address, Course,

Coordinator)
The table above shows that Subject_name, Subject_code, Credit_hour and Grade fields which contains multiple
or more repeating values.
10
Database Systems
Note 1.1:
Problems that occur in tables with repeating groups :
 It’s hard to know exactly which Credit_Hour
belongs to which Subject_Name.
 To find a record in the table is very difficult.
How to handle Repeating Groups?

 The repeating group can be handled by separating
Table 1.2:
Unnormalised Form (UNF) into First Normal
Form (1NF) as shown later.
STUDENT
Student ID Student Subject Grade Address Course Coordinator
Name code
S0001 Azlina ACT410 A Sentul Diploma in Information Fazilah
Ahmad Technology
S0001 Azlina ADM101 B Sentul Diploma in Information Fazilah
Ahmad Technology
S0001 Azlina ART210 C Sentul Diploma in Information Fazilah
Ahmad Technology
S0144 Amirul ART310 A Shah Alam Diploma in Computer Ahmad
Hamdan Graphic Design
S0144 Amirul ART230 B Shah Alam Diploma in Computer Ahmad
S0144 Amirul BUS210 B Shah Alam Diploma in Computer Ahmad
S0151 Mazlina ART410 C Shah Alam Associate Diploma in Sahada
Yakub Interactive Multimedia
S0151 Mazlina ART 210 A Shah Alam Associate Diploma in Sahada
S0151 Mazlina BUS210 A Shah Alam Associate Diploma in Sahada
STUDENT (Student_ID, Student_name, Subject_code, Grade, Address, Course, Coordinator)
SUBJECT
Subject_Code Subject_Name Credit_hour
ACT410 Computerised Accounting 4
QDM101 Internet Publishing 4
ART210 Graphic Design Application 4
ART310 Graphic Communication 4
ART230 Introduction to graphic Design 2
BUS210 Business Organization. 4
ART410 Promotion Design 4
11
SUBJECT (Subject_code, Subject_name, Credit_hour)
Database Systems
Note 1.2 :
What is Functional Dependencies?
Functional Dependencies describe relationships between attributes in a relation.
A relationship between attributes in which one attribute or group of attribute determines the value of another in
the same table.
Example :
Consider microcomputers in a COSMOPOINT computer lab. Each has only one size of main memory. So
MemorySize is functionally dependent on ComputerSerialNumber.
How to write?
ComputerSerialNumber MemorySize
The attributes on the left side of the arrow are called determinants.
How to read?
“ComputerSerialNumber functionaly determines MemorySize”

or
“ComputerSerialNumber determines MemorySize”
or
“MemorySize is functionally dependent on ComputerSerialNumber”
12
Database Systems
Note 1.2 :
Identify Functional Dependencies
Student_ID Student_name Subject_code Grade Address Course Coordinator
Subject_code Subject_name Credit_hour
Student_ID Student_name, Address, Course, Coordinator

Subject_code Subject_name, Credit_hour
Student_ID, Subject_code Grade
Based on these 3 relations schema, there will be 3 tables (relations) in 2NF.
13
Database Systems
Table 1.3
STUDENT
Student_ID Student_name Address Course Coordinator
S0001 Azlina Ahmad Sentul Diploma in Information Technology Fazilah
S0144 Amirul Shah Diploma in Computer Graphic Design Ahmad
Hamdan Alam
S0151 Mazlina Yakub Shah Associate Diploma in Interactive Sahada
Alam Multimedia
STUDENT (Student_ID, Student_name, Address, Course, Coordinator)
SUBJECT
ACT410 Computerised Accounting 4
ART210 graphic Design Application 4
BUS210 Business Organization. 4
Subject (Subject_code, Subject_name, Credit_hour)
STUDENT_GRADE
Student_ID Subject_code Grade
S0001 ACT410 A
S0001 QDM101 B
S0001 ART210 C
S0144 ART310 A
S0144 ART230 B
S0144 BUS210 B
S0151 ART410 C
S0151 ART210 A
S0151 BUS210 A
STUDENT_GRADE (Student_ID, Subject14
_code, Grade)
Database Systems
Note1.3:
What is Transitive Dependencies?
 A functional dependency between 2 or more non-key attributes. A condition in which an attribute is

dependent on another attributes that is not part of the primary key.
 A relation is in Third Normal Form (3NF) if it is in 2NF and has no transitive dependency.
 Non-primary key attribute is functionally dependent on another non-primary key attribute.
Transitive Dependencies
Student_ID Student_name Subject_code Grade Address Course Coordinator

15
Database Systems
Note 1.3 :
Solution : In order to build 3NF table (relation), you have to remove the transitive dependencies.
Becomes
Student_ID Student_name, Address, Course

2 tables (relation) are created
Course Coordinator
So, there will be 4 tables in 3NF as shown below :
Student_ID Student_name, Address, Course

Course Coordinator
16
Database Systems
17
Database Systems
Table 1.4
STUDENT
Student_ID Student_name Address Course
S0001 Azlina Ahmad Sentul Diploma in Information Technology
S0144 Amirul Hamdan Shah Alam Diploma in Computer Graphic Design
S0151 Mazlina Yakub Shah Alam Associate Diploma in Interactive Multimedia
STUDENT (Student_ID, Student_name, Address,Course)
SUBJECT
ACT410 Computerised Accounting, 4
BUS210 Business Organization 4
ART210 Graphic Design Application 4
SUBJECT(Subject_code, Subject_name, Credit_hour)
COURSE
Course Coordinator
Diploma in Information Technology Fazilah
Diploma in Computer Graphic Design Ahmad
Associate Diploma in Interactive Multimedia Sahada
COURSE (Course, Coordinator)
STUDENT_GRADE
Student_ID Subject_code Grade
S0001 ACT410 A
S0001 ADM101 B
S0001 ART210 C
S0144 ART310 A
S0144 ART230 B
S0144 BUS210 B
S0151 ART410 C
S0151 ART 210 A
S0151 BUS210 A
18
Database Systems
Example 2 :
Table 2.1 :
Unnormalised Table (UNF)
Table with repeating groups /

INVOICE
Unnormalised Form (UNF). Remove repeating groups
(refer table 2.1) (refer Note 2.1) Supplier
Customers Customer Address Item Item Qty Price Supplier
no name code desc _Address
A100 Abu Sentul KB100 Keyboard 20 25 XYZ Ent Petaling Jaya
First normal form (1NF)
CP200 CPU 10 650 XYZ Ent Petaling Jaya
(refer table 2.2) Identify Functional Dependencies.
MS112 Mouse 2 15 Note 2.2)
(refer XYZ Ent. Petaling Jaya
A101 Salmah Ampang HD200 Hard Disk 10 100 Seagate Pulau Pinang
KB100 Keyboard 10 25 XYZ Ent Petaling Jaya
(refer table 2.3)
SP360 Speaker 5 45 XYZ Ent Petaling Jaya
Remove Transitive Dependencies
(refer note 2.3)
102 Rani Ampang MS112
Third Normal Mouse
Form (3NF) 4 15 XYZ Ent Petaling Jaya
(refer tableCP200
2.4) CPU 2 650 XYZ Ent Petaling Jaya
VG400 VGA Card 2 200 XYZ Ent Petaling Jaya
INVOICE (Customer_no, Customer_name, Address, Item_code, Item_desc, Qty, Price, Supplier, Supplier_address)
The table above shows that Item_code, Item_desc, Qty, Price, Supplier & Supplier_address fields contain
multiple or repeating values.
Assumption : One supplier supply many products.
19
Database Systems
Table 2.2
CUSTOMER
Customer_no Customer_name Address
A100 Abu Sentul
Note 2.1:A101 Salmah Ampang
ProblemsA102
that occur in table with repeating Rani
groups Ampang
:
CUSTOMER (Customer_No,Customer_name,Address)
 It’s hard to know exactly which Item_Code
belongs to which Item_Desc.
INVOICE
Customer_no Item_code Item_desc Qty Price Supplier Supplier_address
A100
How to handleKB100 Keyboard
Repeating Groups? 20 25 XYZ Ent. Petaling Jaya
A100
 CP200 group can
The repeating CPU be handled10 by 650 XYZ Ent. Petaling Jaya
A100 separatingMS112
UnnormalisedMouse
Form (UNF)2 into 15 XYZ Ent. Petaling Jaya
First Normal Form (1NF) as shown later.
A101 HD200 Hard Disc 10 100 Seagate Pulau Pinang
A101 KB100 Keyboard 10 25 XYZ Ent. Petaling Jaya
A101 SP360 Speaker 5 45 XYZ Ent. Petaling Jaya
A102 MS112 Mouse 4 15 XYZ Ent. Petaling Jaya
A102 CP200 CP 2 200 XYZ Ent. Petaling Jaya
A102 VG400 VGA Card 2 650 XYZ Ent. Petaling Jaya
INVOICE (Customer_no, Item_code, item_desc, Qty, Price, Supplier, Supplier_address)
The table above shows that each row contains a single value.
20
Database Systems
Note 2.2
Identify Functional Dependencies.

the same table.
Customer_no Item_code Item_desc Qty Price Supplier Supplier_address
Customer_no Customer_name, Address,

Item_code Item_desc, Price, Supplier,Supplier_Address
Customer_no, Item_code Qty
Based on these 3 functional dependencies, there will be 3 tables (relations) in 2NF.
21
Database Systems
Table 2.3
CUSTOMER
A100 Abu Sentul
A101 Salmah Ampang
A102 Rani Ampang
CUSTOMER (Customer_no, Customer_name, Address)
ITEM
Item_code Item_desc Price Supplier Supplier_Address
KB100 Keyboard 25 XYZ Ent. Petaling Jaya

HD200 Hard Disc 100 Seagate Pulau Pinang
MS112 Mouse 15 XYZ Ent. Petaling Jaya

SP360 Speaker 45 XYZ Ent. Petaling Jaya
CP200 CPU 650 XYZ Ent. Petaling Jaya
VG400 VGA Card 400 XYZ Ent. Petaling Jaya
ITEM (Item_code, Item_desc, Price, Supplier, Supplier_Address)
INVOICE
Customer_no Item_code Qty
A100 KB100 20
A100 CP200 10
A100 MS112 2
A101 HD200 10
A101 KB100 10
A101 SP360 5
A102 MS112 4
A102 CP200 22 2
A102 VG400 2
Database Systems
Nota 2.3:
Transitive Dependency
Identify Functional Dependencies.
Customer_no Item_code Item_desc Qty Price Supplier Supplier Address
Customer_no Cust_Name, Cust_Address

Customer_No, Item_Code Qty
Item_Code Item_Desc, Price, Supplier, Supplier_address
23
Database Systems
24
Database Systems
Solution: In order to build 3NF table (relation), you have to remove the transitive dependencies.
Item_code Item_desc, Price, Supplier,Supplier_address
Becomes
Item_code Item_desc, Price,Supplier

2 table (relation) are
Supplier Supplier_address created
So, there will be 4 tables in 3NF as shown below:
Customer_no Customer_name, Address

Customer_no, Item_code Qty
Item_code Item_desc,Price, Supplier
Supplier Supplier_address
25
Database Systems
Table 2.4
CUSTOMER
A100 Abu Sentul
A101 Salmah Ampang
A102 Rani Ampang
CUSTOMER (Customer_no, Customer_name, Address)
Example 3 :
INVOICE
The Steps in Normalisation
Customer_no Item_code Qty
A100 KB100 20
A100 CP200 10
A100 MS112 2
A101 HD200 10
A101 SP360 5
A101 KB100 10
A102 MS112 4
A102 CP200 2
A102 VG400 2
INVOICE (Customer_no, Item_code, Qty)
ITEM
Item_code Item_desc Price Supplier
KB100 Keyboard 25 XYZ Ent.

HD200 Hard Disc 100 Seagate
MS112 Mouse 15 XYZ Ent.

SP360 Speaker 45 XYZ Ent.
CP200 CPU 650 XYZ Ent.
VG400 VGA Card 200 XYZ Ent.
ITEM (Item_code, Item_desc,Price, Supplier)
SUPPLIER
Supplier Supplier_address
XYZ Ent. Petaling Jaya
26
Database Systems
Table with repeating groups (UNF)

(refer table 3.1)
Remove repeating groups
(refer note 3.1)
First normal form (1NF)

(refer table 3.2)
Table 3.1 Identify Functional Dependencies
(refer note 3.2)
Second
Unnormalised Form normal
(UNF) form (2NF)
(refer table 3.3)
PROJECT
Remove Transitive Dependencies
Project_no Third normal Staff_no
Project_name form (3NF) Staff_name Job_classification
(refer note 3.3) Charge_hour Hour
(refer table 3.4)
1 DADD 00689 Samat Elect.Engineer RM 20 20
00500 Ali Web Developer RM 22 18
00444 Azie Web Developer RM 22 15
2 Programming 00123 Kamal System Analyst RM 25 30

00999 Hazlim Technical Support RM 16 56
3 Multimedia 00689 Samat Elect.Engineer RM 20 40

00111 Anaz Programmer RM 18 35
PROJECT (Project_no, Staff_no, Project_name, Staff_name, Job_classification, Charge_hour, Hour)
The above table shows fields (Staff_no, Staff_name, Job_classification, Charge_hour & Hour) which have
Repeating Values.
27
Database Systems
Note 3.1:
Problems that occur in tables with repeating
groups :
Table 3.2
 It’s hard to know exactly which Staff_no
belongs to which Staff_name.
PROJECT
Project_noHow to handle
Project_
RepeatingStaff_no
Groups? Staff_name Job_ Charge_ hour
name classification hour
The repeating groups can be handled by
1 DADD 00689 Samat Elect.Engineer RM 20 20
separating Unnormalised Form (UNF) into First
1 DADD 00500 Ali Web Developer RM 22 18
Normal Form (1NF) as shown later.
1 DADD 00444 Azie Web Developer RM 22 15
2 Programming 00123 Kamal System Analyst RM 25 30
2 Programming 00999 Hazlim Technical RM 16 56
Support
3 Multimedia 00689 Samat Elect.Engineer RM 20 40
3 Multimedia 00111 Anaz Programmer RM 18 35
PROJECT (Project_no, Staff_no, Project_name, Staff_name, Job_classification, Charge_hour, Hour)
The above table shows that each row has its own value.
28
Database Systems
Note 3.2:
the same table.
Project_no Project_name Staff_no Staff_name Job_classification Charge_hour Hour
Project_no Project_name
Staff_no Staff_name, Job_classification, Charge_hour
Staff_no, Project_no Hour
29
Database Systems
Table 3.3 :
PROJECT
1 DADD
2 Programming
3 Multimedia
PROJECT (Project_no, Project_name)
STAFF
Staff_no Staff_name Job_classification Charge_hour
00689 Samat Elect.Engineer RM 20

00500 Ali Web Developer RM 22
00444 Azie Web Developer RM 22

00123 Kamal System Analyst RM 25
00999 Hazlim Technical Support RM 16
00111 Anaz Programmer RM 18
STAFF (Staff_no, Staff_name, Job_classification, Charge_hour)
HOUR
Staff_no Project_no Hour
00689 1 20
00500 1 18
00444 1 15
00123 2 30
00999 2 56
00689 3 40
00111 3 35
HOUR (Staff_no, Project_no, Hour)
30
Database Systems
Note 3.3:
dependent on another attribute that is not part of the primary key.
Identify Transitive Dependencies
Project_no Project_name Staff_no Staff_name Job_classification Charge_hour Hour
31
Database Systems
Solution: In order to build 3NF table (relation), you have to remove the transitive dependencies.
Becomes
Staff_no Staff_name, Job_classification 2 tables

(relation) are
Job_classification Charge_hour created
So, there will be 4 tables in 3NF as shown below:
Staff_no Staff_name, Job_classification
32
Database Systems
Table 3.4
PROJECT
1 DADD
2 Programming
3 Multimedia
PROJECT (Project_no, Project_name)
STAFF
Staff_no Staff_name Job_classification
00689 Samat Elect.Engineer

00500 Ali Web Developer
00444 Azie Web Developer

00123 Kamal System Analyst
00999 Hazlim Technical Support
00111 Anaz Programmer
STAFF (Staff_no, Staff_name, Charge_hour, Job_classification)
HOUR
Staff_no Project_no Hour
00689 1 20
00500 1 18
00444 1 15
00123 2 30
00999 2 56
00689 3 40
00111 3 35
HOUR (Staff_no, Project_no, Hour)
JOB
Job_classification Charge_hour
Elect.Engineer RM 20
Web Developer RM 22
System Analyst RM 25
Technical Support RM 16 33
Programmer RM 18
JOB (Job_classification, Charge_hour)
Database Systems
Example 4:
Normalised the table below from UNF to 3NF.
StaffID Name Dept Salary CourseID CourseTitle EndDate

100 Margaret Simpson Marketing 48000 101 SPSS 19 Jul 2003
102 Surveys 10 Aug 2003
140 Alan Beeton Accounting 52000 103 Tax Acc 8 Dec 2003
110 Chris Lucera Info Systems 43000 101 SPSS 1 Dec 2003
104 C++ 14 Nov 2003
190 Lorenzo Davis Finance 55000
150 Susan Martin Marketing 42000 101 SPSS 16 Jun 2003
105 Java 12 Aug 2003
UNF
COURSE (StaffID, Name, Dept, Salary, CourseID, CourseTitle, EndDate)
Table in UNF consist of redundant data and it must be transform to 1NF.
34
Database Systems
STAFF
StaffID Name Dept Salary
100 Margaret Simpson Marketing 48000
110 Chris Lucera Info Systems 43000
140 Alan Beeton Accounting 52000
150 Susan Martin Marketing 42000
STAFF ( StaffID, Name, Dept, Salary)
COURSE
StaffID CourseID CourseTitle EndDate
100 101 SPSS 19 Jul 2003
100 102 Surveys 10 Aug 2003
110 101 SPSS 1 Dec 2003
110 104 C++ 14 Nov 2003
140 103 Tax Acc 8 Dec 2003
190
150 101 SPSS 16 Jun 2003
150 105 Java 12 Aug 2003
COURSE (StaffID, CourseID, CourseTitle, EndDate)
Table in 1NF is the situation where the intersection of each row and column contains no repeating values (only
one value).
Table in 1NF must be transform to 2NF by identify the functional dependencies.
35
Database Systems

the same table.
StaffID CourseID CourseTitle EndDate
StaffID Name, Dept, Salary

StaffID, CourseID EndDate
CourseID CourseTitle
36
Database Systems
STAFF
100 Margaret Simpson Marketing 48000
110 Chris Lucera Info Systems 43000
140 Alan Beeton Accounting 52000
150 Susan Martin Marketing 42000
STAFFCOURSE
StaffID CourseID EndDate
100 101 19 Jul 2003
100 102 10 Aug 2003
110 101 1 Dec 2003
110 104 14 Nov 2003
140 103 8 Dec 2003
190
150 101 16 Jun 2003
150 105 12 Aug 2003
COURSE (StaffID, CourseID, EndDate)
COURSE
101 SPSS
102 Surveys
101 SPSS
104 C++
103 Tax Acc
101 SPSS
105 Java
COURSE (CourseID, CourseTitle)
Table in 1NF must be transform to 2NF by identify the transitive dependency.

37
Database Systems
StaffID CourseID EndDate
There is no transitive dependencies in the relation.
3NF are :

COURSECOURSE (StaffID, CourseID, EndDate)
COURSE (CourseID, CourseTitle)
38
Database Systems
Example 5:
Normalise the following form to Third Normal Form (3NF). You are required to show the normalisation steps
taken. Provide your answer in a relation scheme.
Solution:
The Steps in Normalisation:
 Name the appropriate relation name.
 List down all attributes involved.
Relation Scheme Format:
39
Database Systems
NZ SDN. BHD
RECEIPT OF HOUSE RENTAL PAYMENT
TENANT’S NAME : Nurul Atiqah TENANT’S CODE: 123

a) Unnormalised Form (UNF)
House_codeAddressStart_
Relation scheme in an Unnormalised Form :
dateEnd_dateRentalLandlord_code
Landlord
RENTAL (Tenant_code, Tenant_name, House_code, Address, Start_date, End_date, Rental, Landlord_code,
Landlord_name)
_namePG 3No. 6 Taman Tenaga, Kajang1/7/199531/7/1997RM 600T0069Intan bt.
JaafarPG 14No. 5 Taman Cahaya, Cheras1/8/19971/8/1999RM 650T8881Noor bt.
Nazri
b) First Normal Form (1NF)
 Make sure there is no redundant data in relation.
 Underline Primary Key.
Relation Scheme in 1NF:
CUSTOMER(Tenant_code, Tenant_name)
RENTAL (Tenant_code, House_code, Address, Start_date, End_date, Rental, Landlord_code, Landlord_name)
c) Second Normal Form (2NF)

Identify the Functional Dependencies (relationship among attributes in a relation).
Relation Name (Primary Key, Non-key Attributes)
RENTAL (Tenant_code, House_code, Address, Start_date, End_date, Rental, Landlord_code, Landlord_name)
RENTAL (Tenant_code, House_code, Start_date, End_date)
HOUSE (House_code, Address, Rental, Landlord_code,

40 Landlord_name)
Database Systems
d) Third Normal Form (3NF)
Functional dependencies
HOUSE (House_code, Address, Rental, Landlord_code, Landlord_name)
Transitive dependency
HOUSE (House_code, Address, Rental, Landlord_code)
LANDLORD (Landlord_code, Landlord_name)
41
Database Systems
Example 6 :
Normalise the following form to Third Normal Form (3NF).
Solution:
The Steps in Normalisation:
KOLEJ MILENNIUM
 List down all attributes involved. GRADE REPORT
SEMESTER MAY – AUGUST 2002
Relation Scheme Format:
Name : Emily Williams Major : MIS
Student No : 053-6929-24 Status : Senior
Address : 208 Brooks Hall
Subject Code Subject Name Professor ProfDept Grade

MIS 403 System Analysis Kendall, K DESC A
MIS 411 Conceptual Kendall, J DESC A
Foundations
MIS 420 Human Factors Kendall, J DESC B
in IS
CIS 412 Database Design Sibley, E CIS A
DESC 353 Management Kelly, D DESC A
Models
42
Database Systems
STUDENT (Name, StudentNo, Address, Major, Status, Subject Code, SubjectName, Professor, ProfDept, Grade,
Semester)

Make sure there is no redundant data in relation.
Underline Primary Key.
STUDENT (StudentNo, Name, Address, Major, Status)
STUDENTSUBJECT (StudentNo, Subject Code, SubjectName, Professor, ProfDept, Grade, Semester)

STUDENTSUBJECT (StudentNo, Subject Code, SubjectName, Professor, ProfDept, Grade, Semester)
GRADEREPORT (StudentNo, Subject Code, Grade, Semester)
SUBJECT (Subject Code, SubjectName, Professor, ProfDept)

43
Database Systems
SUBJECT (Subject Code, SubjectName, Professor, ProfDept)

Functional dependency
SUBJECT (Subject Code, SubjectName, Professor)
PROF (Professor, ProfDept)
44
Database Systems
Example 7 :
Normalise the following form to Third Normal Form (3NF).
AR SDN BHD
Solution: 32, JALAN KELANA,
The Steps in Normalisation: 50567 PETALING JAYA,
SELANGOR DARUL EHSAN
NO TEL : 03-7552525
 List down all attributes involved.
CustomerNo
Relation Scheme: Format:
PNOO65 Invoice No : KS2345
Name : Ferhad Ibrahim Date : 2/3/2003
Address : Jalan Klang Lama
Tel No : 03 -2235990
ProductCode ProductName PriceUnit Quantity Discount SubTotal
A2345 Book 2.00 100 10% 180.00

B1235 Pen 0.25 500 125.00
D4568 Eraser 0.1 200 20.00
45 Total 325.00
Database Systems
INVOICE (InvoiceNo, Date, CustomerNo, Name, Address, TelNo, ProductCode, ProductName, PriceUnit, Quantity,
Discount, Subtotal)
b) First Normal Form (1NF)

 Make sure there is no redundant data in relation.
 Underline Primary Key.
INVOICE (InvoiceNo, Date, CustomerNo, Name, Address, TelNo)
PRODUCT (InvoiceNo , ProductCode, ProductName, PriceUnit, Quantity, Discount, Subtotal)

PRODUCT (InvoiceNo ,ProductCode, ProductName, PriceUnit, Quantity, Discount, Subtotal )
PRODUCT (ProductCode, ProductName, PriceUnit )
46
ORDER (InvoiceNo, ProductCode, Quantity, Discount, Subtotal )
Database Systems
Functional dependency
INVOICE (InvoiceNo, Date, CustomerNo)
CUSTOMER (CustomerNo, Name, Address, TelNo)
47
Database Systems
SUMMARY FOR CHAPTER 3 : NORMALIZATION
A two dimensional table with columns and rows is called a RELATION.
A relation scheme is a list of attributes and their corresponding domains.
Format for relation scheme :

Format : Relation Name ( Primary Key, Non Key Attribute)
2 problems in relational data model :

Anomalies
Information Redundancy
Anomalies is an errors or inconsistencies that may result when a user attempts to update a table
that contains redundant data.
Normalization is a process for assigning attributes into table and reduces data redundancy and
helps eliminate the anomalies problems.
3 level of normalization :
1 NF
2 NF
3 NF
1 NF is a relation where the intersection of each row and column contains no repeating values.
2 NF is a relation that is in 1 NF and every non-primary key attribute is fully functionally

depending on the primary key.
3 NF is a relation that is in 2 NF and is based on the concept of transitive dependency.
48
Database Systems
SUMMARY FOR CHAPTER 3 : NORMALIZATION
Steps in normalization :
Functional dependency is a relationship between attributes in which one attributes or group of

attribute determines the value of another in the same table.
Transitive dependencies are a condition where an attribute is depend on another attribute that is
not part of the primary key.
49
Database Systems

(Unnormalised Form (UNF))
Remove repeating groups
Identify Functional
Dependencies
Remove Transitive
Third Normal Form (3NF) Dependencies
50

Normalization

Uploaded by

Document Information

Copyright

Available Formats

Share this document

Share or Embed Document

Sharing Options

Did you find this document useful?

Is this content inappropriate?

Copyright:

Available Formats

Normalization

Uploaded by

Copyright:

Available Formats

NORMALISATION

At the end of this chapter, students should be able to :

3.1.3 Problems In Relational Data Model

 There are 2 problems in relational data model :

(b) Information Redundancy

S0144 Hamizah Mohamed Jln. Kg. Gajah ASDIM Associate Diploma in

S0144 Hamizah Mohamed Jln. Kg. Gajah ASDIM

ii) Insert Anomalies

S0144 Hamizah Mohamed Jln. Kg. Gajah ASDIM Associate Diploma in

iii) Delete Anomalies

S0144 Hamizah Mohamed Jln. Kg. Gajah ASDIM Associate Diploma

S0144 Hamizah Mohamed Jln. Kg. Gajah ASDIM

ASDIM Associate Diploma in Interactive Multimedia

(b) Information Redundancy

There are 3 level of normalisation :

First normal Form (1NF)

Third Normal Form (3NF)

First Normal Form (1NF)

Second Normal Form (2NF)

Third Normal Form (3NF)

3.2.1 Steps in Normalisation

Table with repeating groups

First normal Form (1NF)

Table with repeating groups

First normal Form (1NF)

(Second Normal Form (2NF)) Remove Transitive

(Third Normal Form9(3NF))

S0151 Mazlina Promotion ART410 4 C Shah Alam Associate Sahada

STUDENT (Student_ID, Student_name, Subject_name , Subject_code, Credit_hour, Grade, Address, Course,

How to handle Repeating Groups?

STUDENT (Student_ID, Student_name, Subject_code, Grade, Address, Course, Coordinator)

“ComputerSerialNumber functionaly determines MemorySize”

Identify Functional Dependencies

Student_ID Student_name Subject_code Grade Address Course Coordinator

Subject_code Subject_name Credit_hour

Student_ID Student_name, Address, Course, Coordinator

Based on these 3 relations schema, there will be 3 tables (relations) in 2NF.

What is Transitive Dependencies?

 A functional dependency between 2 or more non-key attributes. A condition in which an attribute is

Student_ID Student_name Subject_code Grade Address Course Coordinator

Subject_code Subject_name Credit_hour

Student_ID Student_name, Address, Course, Coordinator

Student_ID, Subject_code Grade

Subject_code Subject_name, Credit_hour

Student_ID Student_name, Address, Course, Coordinator

Student_ID Student_name, Address, Course

So, there will be 4 tables in 3NF as shown below :

Student_ID Student_name, Address, Course

Third Normal Form (3NF)

Table with repeating groups /

What is Functional Dependencies?

Customer_no Customer_name Address

Customer_no Item_code Item_desc Qty Price Supplier Supplier_address

Customer_no Customer_name, Address,

Based on these 3 functional dependencies, there will be 3 tables (relations) in 2NF.

Second Normal Form (2NF)

KB100 Keyboard 25 XYZ Ent. Petaling Jaya

MS112 Mouse 15 XYZ Ent. Petaling Jaya

Identify Functional Dependencies.

Customer_no Customer_name Address

Customer_no Item_code Item_desc Qty Price Supplier Supplier Address

Customer_no Cust_Name, Cust_Address

Item_code Item_desc, Price, Supplier,Supplier_address

Item_code Item_desc, Price,Supplier
