Drilling Module

DRILLING MODULE
120D61492-1
TABLE OF CONTENTS Sandvik DD321-40 200824
7. DRILLING MODULE
* BG 014 698 08 NSS MODULE, DRILLING........................................................................................................................................ 1
** BG 011 002 61 ROCK DRILL......................................................................................................................................................... 4
*** BG 010 965 98 NSS GEARBOX................................................................................................................................................. 6
**** BG 006 571 32 GEARBOX..................................................................................................................................................... 8
***** 551 552 03 BEARING ASSEMBLY..................................................................................................................................... 9
**** 551 552 04 BEARING ASSEMBLY......................................................................................................................................... 10
**** BG 005 702 40 NSS STABILIZER.......................................................................................................................................... 11
***** BG 005 702 41 BEARING ASSEMBLY............................................................................................................................... 12
***** BG 006 302 06 PISTON, STABILIZER............................................................................................................................... 13
***** BG 005 702 47 BEARING ASSEMBLY............................................................................................................................... 14
**** BG 003 773 12 BEARING ASSEMBLY................................................................................................................................... 15
**** 551 529 97 BUSHING, ROTATION......................................................................................................................................... 16
**** BG 008 389 53 BEARING ASSEMBLY................................................................................................................................... 17
**** 550 117 63 ACCUMULATOR, DIAPHRAGM.......................................................................................................................... 18
*** BG 010 946 68 NSS BODY, ROCK DRILL................................................................................................................................ 19
**** BG 010 946 69 BODY, ROCK DRILL..................................................................................................................................... 22
*** BG 007 313 93 NSS MECHANISM, PERCUSSION................................................................................................................... 25
*** BG 005 702 64 NSS MOTOR ASSEMBLY, HYDRAULIC.......................................................................................................... 26
**** 551 587 43 MOTOR ASSEMBLY, HYDRAULIC..................................................................................................................... 27
*** BG 005 702 59 NSS FLUSHING DEVICE ASSEMBLY.............................................................................................................. 28
**** 551 551 63 FLUSHING DEVICE ASSEMBLY......................................................................................................................... 30
***** 152 745 38 COVER, FRONT.............................................................................................................................................. 31
***** 152 747 98 BUSHING, SHANK........................................................................................................................................... 32
***** 550 056 76 ADAPTER ASSEMBLY.................................................................................................................................... 33
*** 551 617 36 TOOL, SPECIAL...................................................................................................................................................... 36
*** 552 023 89 TOOL KIT................................................................................................................................................................. 40
*** 550 479 73 TOOL, SPECIAL...................................................................................................................................................... 42
**** 550 067 39 TOOL, SPECIAL.................................................................................................................................................. 43
*** BG 009 349 92 SERVICE KIT.................................................................................................................................................... 46
*** BG 008 108 27 SERVICE KIT.................................................................................................................................................... 47
*** BG 005 799 29 KIT..................................................................................................................................................................... 48
*** BG 005 793 64 SERVICE KIT.................................................................................................................................................... 49
*** BG 011 014 60 SERVICE KIT.................................................................................................................................................... 50
*** BG 006 402 21 SERVICE KIT.................................................................................................................................................... 51
*** BG 009 498 75 SERVICE KIT.................................................................................................................................................... 52
** BG 011 219 82 BOOM ASSEMBLY................................................................................................................................................ 54
*** BG 003 539 08 BOOM ASSEMBLY, REAR............................................................................................................................... 58
**** BG 004 510 75 PLATE, MOUNTING...................................................................................................................................... 61
**** BG 004 393 86 CROSS JOINT............................................................................................................................................... 62
*** BG 011 223 97 BOOM, ZOOM................................................................................................................................................... 64
**** 551 609 93 HYDRAULIC CYLINDER, DOUBLE-ACTING...................................................................................................... 66
*** 550 031 38 HEAD, BOOM.......................................................................................................................................................... 68
**** BG 004 583 07 FRAME........................................................................................................................................................... 70
**** BG 004 569 84 SWING PIECE............................................................................................................................................... 71
**** BG 004 571 38 CROSS JOINT............................................................................................................................................... 72
*** BG 009 123 60 NSS HOSE SUPPORT ASSEMBLY................................................................................................................. 73
*** BG 010 356 13 ACTUATOR, ROTARY...................................................................................................................................... 76
**** BG 010 353 87 HYDRAULIC ROTARY ACTUATOR, DOUBLE............................................................................................. 77
**** BG 003 343 38 VALVE ASSEMBLY....................................................................................................................................... 78
*** BG 003 429 55 NSS VALVE ASSEMBLY.................................................................................................................................. 80
*** BG 003 877 39 VALVE ASSEMBLY........................................................................................................................................... 84
*** 550 997 48 HYDRAULIC CYLINDER, DOUBLE-ACTING, 3-CHAMBER................................................................................... 88
*** 551 560 82 HYDRAULIC CYLINDER, DOUBLE-ACTING, 3-CHAMBER................................................................................... 90
*** 550 041 20 HYDRAULIC CYLINDER, DOUBLE-ACTING.......................................................................................................... 92
Sandvik Mining and Construction Oy Drills Tampere © 2020

120D61492-1

*** 321 845 92 NSS ASSEMBLY...................................................................................................................................................... 95
*** 550 968 79 SUPPORT, HOSE.................................................................................................................................................... 96
** 551 592 93 FEED ASSEMBLY....................................................................................................................................................... 98
*** 344 495 04 FEED BEAM ASSEMBLY........................................................................................................................................ 101
*** 550 829 49 CYLINDER............................................................................................................................................................... 104
**** 550 540 65 HYDRAULIC CYLINDER, DOUBLE-ACTING...................................................................................................... 106
**** 323 610 98 WHEEL, IDLER.................................................................................................................................................... 107
*** 550 385 04 WIRE ROPE............................................................................................................................................................. 108
*** 551 591 56 WIRE ROPE............................................................................................................................................................. 110
*** 332 767 78 CYLINDER, IMPULSE.............................................................................................................................................. 112
*** 325 321 68 CENTRALIZER, FRONT.......................................................................................................................................... 113
*** 551 861 40 ASSEMBLY.............................................................................................................................................................. 116
*** 263 685 98 CENTRALIZER, TRAVELLING................................................................................................................................ 117
*** BG 008 674 65 HOSE SUPPORT ASSEMBLY.......................................................................................................................... 118
** BG 002 350 30 NSS CONNECTION PARTS................................................................................................................................. 120
**** BG 002 238 11 TUBE, CYLINDER......................................................................................................................................... 122
*** BG 005 259 90 VALVE ASSEMBLY........................................................................................................................................... 123
**** BG 003 425 45 MANIFOLD, VALVE ASSEMBLY................................................................................................................... 124
*** 550 372 39 JUNCTION BOX ASSEMBLY.................................................................................................................................. 126
** 551 637 30 CARRIAGE ASSEMBLY.............................................................................................................................................. 128
** 327 899 01 MOUNTING, CENTRAL LUBRICATION SYSTEM...................................................................................................... 130
** BG 012 346 40 HOSE KIT.............................................................................................................................................................. 131
** BG 012 245 21 HOSE KIT.............................................................................................................................................................. 132
** BG 013 789 58 HOSE KIT.............................................................................................................................................................. 133
* BG 014 698 10 NSS MODULE, DRILLING........................................................................................................................................ 134
** BG 011 218 31 BOOM ASSEMBLY................................................................................................................................................ 136
*** BG 003 538 77 BOOM ASSEMBLY, REAR............................................................................................................................... 140
**** BG 004 494 25 PLATE, MOUNTING...................................................................................................................................... 143
*** BG 011 223 16 BOOM, ZOOM................................................................................................................................................... 146
*** 550 031 37 HEAD, BOOM.......................................................................................................................................................... 148
**** BG 004 571 43 FRAME........................................................................................................................................................... 149
** 551 599 73 FEED ASSEMBLY....................................................................................................................................................... 152
** BG 012 346 41 HOSE KIT.............................................................................................................................................................. 155
** BG 012 351 55 HOSE KIT.............................................................................................................................................................. 156
** BG 013 789 63 HOSE KIT.............................................................................................................................................................. 157

120D61492-1

BG 014 698 08 aG NSS
1 (157) MODULE, DRILLING / LEFT 200824
LEFT
TFX500
900
9
6 11 1
4 21 15 12 8 3 5
TF500
2 7 40 41 42 43 50
33
Ref. Part no. Description EN Standard designation Qty

e
1 BG 011 002 61 ROCK DRILL SECTION 7 PAGE 4 1
2 BG 011 219 82 BOOM ASSEMBLY SECTION 7 PAGE 54 1
3 551 592 93 FEED ASSEMBLY SECTION 7 PAGE 98 1
4 BG 002 350 30 NSS CONNECTION PARTS SECTION 7 PAGE 120 1
6 551 637 30 CARRIAGE ASSEMBLY SECTION 7 PAGE 128 1
. . . . .
7 327 899 01 MOUNTING, CENTRAL LUBRICATION SECTION 7 PAGE 130 1
SYSTEM
33 550 968 79 SUPPORT, HOSE SECTION 7 PAGE 96 1
40 155 750 38 COVER, HOSE D=50 L=2000 18
50 807 695 29 STRAP L=400 Black 40
805 BG 012 346 40 HOSE KIT SECTION 7 PAGE 131 1
. . . . .
811 BG 009 036 02 NSS HOSING SET SECTION 5 PAGE 72 1
. . . . .

BG 011 002 61 bB
200824 ROCK DRILL / RD520, OMS80, WATER FLUSHING 2 (157)
HYDRAULIC ROCK DRILL RD520

HYDRAULIC MOTOR OMS80
WATER FLUSHING

BG 011 002 61 bB
3 (157) ROCK DRILL / RD520, OMS80, WATER FLUSHING 200824

BG 011 002 61 bB
200824 ROCK DRILL / RD520, OMS80, WATER FLUSHING 4 (157)

e
1 BG 010 965 98 NSS GEARBOX SECTION 7 PAGE 6 1
2 BG 010 946 68 NSS BODY, ROCK DRILL SECTION 7 PAGE 19 1
3 BG 007 313 93 NSS MECHANISM, PERCUSSION SECTION 7 PAGE 25 1
4 BG 005 702 64 NSS MOTOR ASSEMBLY, HYDRAULIC SECTION 7 PAGE 26 1
5 BG 005 702 59 NSS FLUSHING DEVICE ASSEMBLY SECTION 7 PAGE 28 1
. . . . .
____________________________________
PARTS TO BE ORDERED SEPARATELY
____________________________________
*90 BG 005 702 67 SEAL KIT Complete kit for rock drill 1
*91 551 617 36 TOOL, SPECIAL SECTION 7 PAGE 36 1
. . . . .
*92 552 023 89 TOOL KIT SECTION 7 PAGE 40 1
*93 550 479 73 TOOL, SPECIAL SECTION 7 PAGE 42 1
*202 BG 009 349 92 SERVICE KIT SECTION 7 PAGE 46 1
*204 BG 005 799 29 KIT SECTION 7 PAGE 48 1
. . . . .

BG 010 965 98 cC NSS
5 (157) GEARBOX / MAIN ASSEMBLY 200824
21
18
7
27
10
22
28
11
12
13
18
8
9
8
17
16
15
14
20 1 4
5
3
23
25 24

BG 010 965 98 cC NSS
200824 GEARBOX / MAIN ASSEMBLY 6 (157)

e
1 BG 006 571 32 GEARBOX SECTION 7 PAGE 8 1
3 551 552 04 BEARING ASSEMBLY SECTION 7 PAGE 10 1
4 551 528 68 TIE BOLT M27x2 4
5 511 049 70 BEARING, BALL, DEEP GROOVE D68 d40 L15 1
6 BG 005 702 40 NSS STABILIZER SECTION 7 PAGE 11 1
. . . . .
7 BG 003 773 12 BEARING ASSEMBLY SECTION 7 PAGE 15 1
8 551 529 98 PLATE, SIDE 2
9 551 530 23 GEAR WHEEL 1
10 551 529 97 BUSHING, ROTATION SECTION 7 PAGE 16 1
. . . . .
12 AF0 300 0082 WASHER, LOCK, PAIR NL12-A4-19H 3
13 AF0 050 0564 SCREW, SOCKET HEAD, HEXAGON M12x25-8.8 Zn 3
14 152 539 88 PLATE, GASKET s0.5 1
15 550 117 63 ACCUMULATOR, DIAPHRAGM SECTION 7 PAGE 18 1
16 AF0 300 0034 WASHER, LOCK, PAIR NL16 3
. . . . .
17 AF0 010 1127 SCREW, HEXAGON HEAD, FULL THREAD M16x50 3
18 BG 002 289 19 SEAL d105 2
20 818 735 39 O-RING 32.2x3.00 1
21 800 816 79 O-RING 124.5X3.00 1
22 522 135 10 O-RING 134.5X3.00 1
. . . . .
23 808 788 39 O-RING 22.3x2.40, 90 SHORE A 4
24 800 658 09 O-RING 74.5x3.00 2
25 801 368 49 O-RING 59,3X3 2
27 BG 003 781 14 RING 1
28 551 537 71 O-RING 143.0x2.00 1
. . . . .

BG 006 571 32 bB
7 (157) GEARBOX / ASSEMBLY 200824
8
7
4 3
5 4

BG 006 571 32 bB
200824 GEARBOX / ASSEMBLY 8 (157)

e
2 871 692 89 PLUG G1/4 5
3 881 139 09 PLUG G3/8 2
4 881 140 79 PLUG G1/2 2
5 806 448 09 PLUG G1/4 1
6 801 811 49 PLUG G1/8 1
. . . . .
7 551 552 03 BEARING ASSEMBLY SECTION 7 PAGE 9 1
8 522 131 00 O-RING 34.2x3.00 1

551 552 03 a
9 (157) BEARING ASSEMBLY 200824

e
3 551 587 58 BEARING, NEEDLE D32 d25 L20 1

551 552 04 cC
200824 BEARING ASSEMBLY 10 (157)

e

BG 005 702 40 bB NSS
11 (157) STABILIZER / ASSEMBLY 200824
7
5

e
2 BG 006 302 06 PISTON, STABILIZER SECTION 7 PAGE 13 1
3 BG 005 357 35 PISTON, STABILIZER 1
5 BG 005 357 36 CHUCK 1
. . . . .
6 550 457 27 SEAL, ROD d 67 1
7 550 457 24 SEAL, ROD d 71 1
8 801 517 29 O-RING 104.5x3.00 5

BG 005 702 41 aA

e
2 BG 005 232 15 BUSHING, BEARING D77 d67 L21 1
3 551 529 90 BUSHING, BEARING D98 d92 L33 1

BG 006 302 06 bB
13 (157) PISTON, STABILIZER 200824

e

BG 005 702 47 aA

e

BG 003 773 12 aA

e

551 529 97 A
200824 BUSHING, ROTATION 16 (157)

e
2 551 529 95 BUSHING, BEARING D79 d73 1

BG 008 389 53 aA

e

550 117 63 dD
200824 ACCUMULATOR, DIAPHRAGM / 0,1DM³, 30BAR 18 (157)
5.1 5.2
*7

e
3 152 254 88 DIAPHRAGM Stem-type, D88 1
5 807 590 69 VALVE Thread 1/2-20 UNJF-3A 1
5.1 869 733 29 O-RING 14.0x2.00 1
5.2 851 682 19 CAP, PROTECTING Vg8 Av3/8 1
6 151 548 58 SIGN NOT PRESSURIZED 1
. . . . .
____________________________________
____________________________________
*7 085 370 18 CAP, PROTECTING D28, L34, RUBBER 1

BG 010 946 68 aA NSS
19 (157) BODY, ROCK DRILL 200824
6
5
1
8
7
10
12
13
2
5
9 6
3
11 10

e
1 BG 010 946 69 BODY, ROCK DRILL SECTION 7 PAGE 22 1
2 550 042 26 PLATE, GASKET s0.5 2
5 850 687 49 WASHER, LOCK, DOUBLE M16 8
. . . . .
6 802 198 29 HEXAGON HEAD BOLT M16X70 8
7 815 174 59 BONDED SEAL U 16.7x24x1.5 1
8 816 818 09 HEXAGON HEAD SCREW M16X20 1
9 551 528 76 NUT, CAP M27x2 4
10 BG 005 794 21 O-RING 17.3x2.40, NBR, 90 Shore A 2
. . . . .
11 808 788 39 O-RING 22.3x2.40, 90 SHORE A 1
12 BG 005 502 33 O-RING 25.3x2.40, NBR, 90 Shore A 1
13 551 743 98 O-RING 270x3 1
400 BG 004 114 06 DECAL Accumulators, 50x30 mm 1

BG 010 946 69 aA
21 (157) BODY, ROCK DRILL / ASSEMBLY 200824
7
6
3
12
6
6
7 5
7
6 4
5
3 11 18
14
13
15
4
16
2
3
4 10 17
9
16 5 19 8 16 9 16

BG 010 946 69 aA
200824 BODY, ROCK DRILL / ASSEMBLY 22 (157)

e
2 551 745 42 PLUG G1 1/4 1
3 881 142 29 PLUG G1 4
4 881 141 09 PLUG G3/4 in 4
5 881 140 79 PLUG G1/2 5
6 881 139 09 PLUG G3/8 5
. . . . .
7 871 692 89 PLUG G1/4 3
8 816 769 59 STRAIGHT THREAD ADAPTER G 1 x JIC 1,1/16-12 2
9 816 768 29 STRAIGHT THREAD ADAPTER G 3/4 x JIC 1,1/16-12 2
10 817 094 69 STRAIGHT THREAD ADAPTER G 1/2 x JIC 3/4-16 1
11 856 040 09 STRAIGHT THREAD ADAPTER G 3/8 in x JIC 9/16-18 1
. . . . .
12 882 322 79 PIN, SPRING 5x12 1
13 800 347 99 BONDED SEAL U 21,5x28,7x2,5 1
14 812 605 29 PLUG G1/2 in 1
15 800 350 09 BONDED SEAL 42.7x53x3 1
16 816 909 59 PLUG JIC 1 1/16-12 4
. . . . .
17 817 097 49 PLUG JIC 3/4-16 1
18 857 302 19 PLUG 9/16-18 JIC 1
19 BG 006 123 06 ORIFICE d8 1

550 036 25 dD
23 (157) ACCUMULATOR, DIAPHRAGM / 4BAR, 0,3DM³ 200824
5
6
4.1
4
4.2

e
3 092 602 98 DIAPHRAGM Stemless type, D120 1
4.1 869 733 29 O-RING 14.0x2.00 1
5 522 134 90 O-RING 129.5X3.00 1
. . . . .
6 819 532 09 O-RING 64.5x3.00 1

550 036 27 dD
200824 ACCUMULATOR, DIAPHRAGM / 50BAR, 0,3DM³ 24 (157)
5
6
4.1
4
4.2

e
4.1 869 733 29 O-RING 14.0x2.00 1
5 522 134 90 O-RING 129.5X3.00 1
. . . . .
6 819 532 09 O-RING 64.5x3.00 1

BG 007 313 93 aA NSS
25 (157) MECHANISM, PERCUSSION / RD520 200824
6
8
4
9
2
8
1
8
3
5
8
7

e
1 BG 004 344 05 CYLINDER, PILOT 1
2 551 552 22 DISTRIBUTOR 1
3 BG 004 884 03 PISTON 1
4 551 552 25 BEARING ASSEMBLY d38 1
. . . . .
6 818 200 39 SEAL, ROD d 38 2
7 551 587 66 SEAL, ROD d 47 2
8 801 518 59 O-RING 84.5x3.00 6
9 818 454 49 O-RING 74,5X3 2

BG 005 702 64 aA NSS
200824 MOTOR ASSEMBLY, HYDRAULIC / OMS80 26 (157)

e
1 551 587 43 MOTOR ASSEMBLY, HYDRAULIC SECTION 7 PAGE 27 1
2 551 530 24 SHAFT, ROTATING OMS80, OMS100, OMS125 1

551 587 43 ab
27 (157) MOTOR ASSEMBLY, HYDRAULIC / OMS80 200824
3 7 6 5 4 2
8 *9 *10 *12
*11

e
2 551 587 20 COVER L84.5 1
3 150 800 78 THRUST L42.5 1
4 801 368 49 O-RING 59,3X3 1
5 551 587 14 STUD M12, L125 4
. . . . .
7 AF0 140 0007 NUT, HEXAGON M12 4
8 855 207 09 O-RING 70X2 1
____________________________________
*9 855 206 89 O-RING 45.0x2.00 90 ShA 1
. . . . .
*10 814 872 89 O-RING 24.0x2.00 1
*11 550 091 04 O-RING 82x2 2
*12 550 351 48 WASHER, SPRING 1

BG 005 702 59 bB NSS
200824 FLUSHING DEVICE ASSEMBLY / WATER FLUSHING, D45 28 (157)
4
5

e
1 551 551 63 FLUSHING DEVICE ASSEMBLY SECTION 7 PAGE 30 1
2 550 034 00 SCREW M24x57 4
3 551 530 28 DRIVER (BRONZE) 10 splines 1
4 047 689 68 GUARD 1 1/2 1
5 280 678 90 CLAMP, HOSE d50 1
. . . . .
____________________________________
____________________________________
*20 BG 005 702 68 SEAL KIT Complete kit for flushing device assembly 1

551 551 63 aAa
29 (157) FLUSHING DEVICE ASSEMBLY / WATER FLUSHING, D45 200824
4
7
2
7
9
8
12
6
1 3
5
1.3 7
1.2
1.4
7
10
10.2 10.2
7
11

551 551 63 aAa
200824 FLUSHING DEVICE ASSEMBLY / WATER FLUSHING, D45 30 (157)

e
1 551 590 74 FRAME - INCL. PARTS 1.2-1.4 1
1.2 881 140 79 PLUG G1/2 1
1.3 881 139 09 PLUG G3/8 1
1.4 865 683 09 PLUG G1/8 1
2 152 745 38 COVER, FRONT SECTION 7 PAGE 31 1
. . . . .
3 152 747 98 BUSHING, SHANK SECTION 7 PAGE 32 1
4 150 809 18 PLATE, GASKET s1.0 1
5 300 637 10 O-RING 62,2X3 1
6 BG 004 822 17 PLATE, GASKET s1.0 1
7 872 189 39 SEAL, U d45 5
. . . . .
10 550 695 68 HOUSING, SEAL - INCL. PARTS 10.2 1
10.2 550 668 36 GUIDE RING, PISTON ROD 9.7x45/50 2
11 550 056 76 ADAPTER ASSEMBLY SECTION 7 PAGE 33 1
. . . . .
12 522 135 10 O-RING 134.5X3.00 1

152 745 38 aA
31 (157) COVER, FRONT 200824

e

152 747 98 aA
200824 BUSHING, SHANK 32 (157)

e
2 152 697 08 BUSHING D68 d45 L56 1

550 056 76 dD
33 (157) ADAPTER ASSEMBLY / G 3/4'' X JIC 3/4-16 200824

e
2 812 949 59 NUT, LOCK G 3/4 1
3 093 718 24 USIT-SEAL 27,4X36X2 1

551 617 36 dD
35 (157) TOOL, SPECIAL / RD500-SERIES 200824
11
1
12
13
14
4
5 15
6
16
7
17
8
18
9
19
10
20

551 617 36 dD
200824 TOOL, SPECIAL / RD500-SERIES 36 (157)

e
1 152 248 88 PUNCH D47, L125 1
2 150 546 98 THRUST D95, d72, L129 1
3 150 545 68 PUNCH D68, L95, M22 1
4 151 866 08 ARM D41, L165, M22 1
5 550 632 78 PUNCH D72, L15, M22 1
. . . . .
6 BG 002 591 37 PUNCH D106,5, L15, M22 1
7 551 616 43 PUNCH D37, L45, M22 1
8 551 617 69 PUNCH D83, L15, M22 1
9 551 618 22 PUNCH D76, L48, M22 1
10 551 618 40 THRUST D138, d123, L45 1
. . . . .
11 551 618 41 THRUST D122, d110, L60 1
12 BG 009 647 44 KEY D110 1
14 551 619 07 PUNCH D71, L20 1
15 551 619 08 PUNCH D94, L20 1
16 551 619 14 THRUST D100, d78, L35 1
. . . . .
17 551 619 34 PUNCH D39, L36, M22 1
18 551 619 83 PUNCH D50, L35, M22 1
19 551 619 27 ARM D40, L470, M22 1
20 551 818 55 PUNCH D89, L250, Aluminium 1

551 617 36 dD
37 (157) TOOL, SPECIAL / RD500-SERIES 200824
21 31
22 32
33
23
34
24
25
35
26
36
27
28
37
38
29
39
30
40

551 617 36 dD
200824 TOOL, SPECIAL / RD500-SERIES 38 (157)

e
21 551 818 05 GAGE D32, for seal groove 4.2 1
22 551 621 24 PUNCH D118, L26, M22 1
23 551 620 05 HAMMER slide hammer, M12, 1.1 kg 1
24 551 618 27 PUNCH D115, L15, M22 1
25 551 620 30 PUNCH D48, L40 1
. . . . .
26 551 620 60 ARM D25, L290 1
27 551 620 82 PUNCH D54, L33 1
28 551 620 99 PUNCH D78, L16, M22 1
29 550 855 13 PUNCH D22, L200 1
30 551 805 01 PLATE, MOUNTING for rock drill 1
. . . . .
31 552 005 90 PUNCH D140, d92, L115 1
32 552 005 92 PUNCH D54, L330 1
33 152 501 38 TOOL D120, L32 1
34 550 058 64 PLATE, MOUNTING 200x85x40 1
35 152 098 78 TOOL D95 L46 1
. . . . .
37 BG 000 855 99 THRUST D40 L240 1
38 BG 000 856 01 PUNCH D90 1
39 814 044 99 HEXAGON HEAD BOLT M20x220 m8.8 1
40 BG 009 641 38 PUNCH D75 1
. . . . .

552 023 89 a
39 (157) TOOL KIT / COMMERCIAL SPECIAL TOOLS 200824
1 2.1 4
2 3
9
7
10
6
5
4
3
1
2
2.2
80
90
70
100
60
50
40
30
10
20
5
6
9
8
7
203
200
204
201
202
205 206
210
209 211
207 208
212
213
214
215

552 023 89 a
200824 TOOL KIT / COMMERCIAL SPECIAL TOOLS 40 (157)

e
1 833 710 99 HOOK SET 1
2 153 936 18 FILLING DEVICE Inlet thread W24,32X1/14 1
2.1 810 791 09 PRESSURE REDUCING VALVE 200/100 bar N2 1
2.2 152 280 08 HOSE ASSEMBLY 1
3 090 300 38 GAUGE, PRESSURE (0-100 bar) 1
. . . . .
5 869 598 69 SEAL 2
6 870 492 19 TORQUE WRENCH 80 - 400 Nm, 3/4 1
7 870 513 09 RING INSERT TOOL 19 1
. . . . .
*200 550 500 13 TORQUE WRENCH 160-800 Nm 1
*201 552 027 70 RING INSERT TOOL 36 1
*202 552 027 71 RING INSERT TOOL 30 1
*203 870 504 19 RECOILLESS HAMMER Plastic, 50 mm 1
. . . . .
*204 550 855 22 HAMMER copper, 2.7 kg 1
*205 551 884 93 LUG, LIFTING M16x24 1
*206 551 897 48 LUG, LIFTING M16 1
*207 551 898 48 LUG, LIFTING M12x18 1
*208 551 953 43 LUG, LIFTING M20x30 1
. . . . .
*209 551 953 44 LUG, LIFTING M24x36 1
*210 552 061 33 SPANNER, RING 38 1
*211 870 503 99 SPANNER, RING 41 1
*212 552 061 34 SPANNER, RING 46 1
*213 552 061 36 SPANNER, RING 50 1
. . . . .
*214 552 027 23 SPANNER, RING Set, 6-32 & 36 1
*215 552 027 73 WRENCH, SOCKET Set 1

550 479 73 c
41 (157) TOOL, SPECIAL / FIELD SERVICE 200824
1.1 1 2 3 4
1.2
5 6 7
8 9 10 11
100
10
12

550 479 73 c
200824 TOOL, SPECIAL / FIELD SERVICE 42 (157)

e
1 153 936 18 FILLING DEVICE Inlet thread W24,32X1/14 1
1.1 810 791 09 PRESSURE REDUCING VALVE 200/100 bar N2 1
1.2 152 280 08 HOSE ASSEMBLY 1
2 152 501 38 TOOL D120, L32 1
. . . . .
4 152 098 78 TOOL D95 L46 1
7 550 067 39 TOOL, SPECIAL SECTION 7 PAGE 43 1
8 833 710 99 HOOK SET 1
. . . . .
11 152 248 88 PUNCH D47, L125 1
12 869 598 69 SEAL 2

550 067 39 c
43 (157) TOOL, SPECIAL / TORQUE WRENCH SET 200824
NO ILLUSTRATION AVAILABLE

e
1 870 492 19 TORQUE WRENCH 80 - 400 Nm, 3/4 1
2 870 495 09 WRENCH, SOCKET 24 3/4 1
3 870 493 49 WRENCH, SOCKET 19, 3/4 1
5 870 504 19 RECOILLESS HAMMER Plastic, 50 mm 1
. . . . .
6 870 498 89 SPANNER, RING 19 1
7 870 499 09 SPANNER, RING 24 1
8 870 510 19 EXTENSION BAR 3/4" l=100 1
9 836 747 39 HEXAGON HOLLOW SOCKET 8mm, 1/2" 1
10 836 746 09 HEXAGON HOLLOW SOCKET 7mm, 1/2" 1
. . . . .
11 870 511 49 CONVERTER 3/4", 1/2" 1
13 550 835 49 WRENCH, SOCKET 19, L83 1
14 550 855 22 HAMMER copper, 2.7 kg 1

BG 009 349 92 bB
45 (157) SERVICE KIT / ENDURANCE KIT 200824
7
4
22
7
26
21
20
17
2
8
15 3
16
6
5
11
14
13
14
12
19
17
1
25
8
15
16 24
23 18
27

BG 009 349 92 bB
200824 SERVICE KIT / ENDURANCE KIT 46 (157)

e
2 152 254 88 DIAPHRAGM Stem-type, D88 1
3 AF2 101 0090 BEARING, DEEP GROOVE BALL D68-d40-B15 1
5 551 529 98 PLATE, SIDE 2
. . . . .
8.1 869 733 29 O-RING 14.0x2.00 1
. . . . .
9 BG 009 633 50 SEAL KIT 1
10 720 851 50 GREASE CARTRIDGE SPECIFICATION JOINTE 3
. . . . .
16 085 370 18 CAP, PROTECTING D28, L34, RUBBER 3
. . . . .
19 AF0 010 1225 SCREW, HEXAGON HEAD, PARTIAL M16x70 8
THREAD
21 AF0 050 0564 SCREW, SOCKET HEAD, HEXAGON M12x25-8.8 Zn 3
22 BG 005 357 36 CHUCK 1
23 AF0 140 0007 NUT, HEXAGON M12 4
. . . . .
24 551 587 14 STUD M12, L125 4
25 AF0 010 1121 SCREW, HEXAGON HEAD, FULL THREAD M16x20-8.8 Zn 1
26 AF0 300 0082 WASHER, LOCK, PAIR NL12-A4-19H 3
27 550 351 48 WASHER, SPRING 1

BG 008 108 27 bB
47 (157) SERVICE KIT / FLUSHING KIT 200824
4
3
2

e
1 BG 005 702 68 SEAL KIT Complete kit for flushing device assembly 1
5 550 034 00 SCREW M24x57 4
. . . . .
6 550 056 76 ADAPTER ASSEMBLY SECTION 7 PAGE 33 1
7 152 747 98 BUSHING, SHANK SECTION 7 PAGE 32 1

BG 005 799 29 bB
200824 KIT / PERCUSSION KIT 48 (157)
4
3

e
2 BG 004 884 03 PISTON 1
3 551 552 22 DISTRIBUTOR 1

BG 005 793 64 cC
49 (157) SERVICE KIT / ROTATION KIT 200824
3
2

e
1 551 530 24 SHAFT, ROTATING OMS80, OMS100, OMS125 1
2 551 530 28 DRIVER (BRONZE) 10 splines 1
3 551 529 97 BUSHING, ROTATION SECTION 7 PAGE 16 1
4 551 530 23 GEAR WHEEL 1

BG 011 014 60 aA
200824 SERVICE KIT / RD520/ RD525 BODY KIT 50 (157)

e
1 BG 006 571 32 GEARBOX SECTION 7 PAGE 8 1
2 BG 010 946 69 BODY, ROCK DRILL SECTION 7 PAGE 22 1

BG 006 402 21 bB
51 (157) SERVICE KIT / BOLT KIT 200824

e
1 551 528 68 TIE BOLT M27x2 4
2 551 528 76 NUT, CAP M27x2 4

BG 009 498 75 aA
200824 SERVICE KIT / STABILIZER KIT 52 (157)
2
1

e
2 BG 005 357 35 PISTON, STABILIZER 1
3 BG 006 302 06 PISTON, STABILIZER SECTION 7 PAGE 13 1

BG 011 219 82 aA
53 (157) BOOM ASSEMBLY / SB40NV LEFT 200824
25
748 748 34
9 550 13 13 552
12 12
18
19 18 29
85
31
10
792 82
553 553
18
202 202
18 19
33 42
6
12
12
550 11
550
748 13 13
748
29

BG 011 219 82 aA
200824 BOOM ASSEMBLY / SB40NV LEFT 54 (157)

e
6 323 060 78 SHAFT L=366 1
7 323 057 58 SHAFT L=306 1
9 264 387 71 PIN, TAPER D50 L156 3
9.1 851 283 39 WASHER, LOCK, DOUBLE M20 1
9.2 883 130 89 HEXAGON HEAD SCREW M20x1.5x160-8.8 1
. . . . .
10 264 388 02 PIN, TAPER D70 L182 1
11 264 388 01 PIN, TAPER D70 L166 3
11.1 AF0 300 0036 WASHER, LOCK, PAIR NL20 1
11.2 883 131 09 HEXAGON HEAD SCREW M20x1,5x170 - 8.8 1
12 264 383 68 COVER 4
. . . . .
13 873 457 49 SEAL, V 115-125 4
18 AF2 501 0518 O-RING 119.5x3 4
19 AF2 501 0510 O-RING 79.5x3 2
25 BG 010 356 13 ACTUATOR, ROTARY SECTION 7 PAGE 76 1
29 885 635 79 SPRING-TYPE STRAIGHT PIN S-20x40 3
. . . . .
31 208 061 88 RING D=70 2
34 330 463 68 SUPPORTING BLOCK 1
42 BG 003 429 55 NSS VALVE ASSEMBLY SECTION 7 PAGE 80 1
82 551 560 82 HYDRAULIC CYLINDER, DOUBLE-ACTING, SECTION 7 PAGE 90 1
3-CHAMBER
. . . . .
85 550 041 24 HYDRAULIC CYLINDER, DOUBLE-ACTING SECTION 7 PAGE 94 1
. . . . .
748 442 500 00 HEXAGON HEAD SCREW M6X20 - 8.8 16
792 AF0 070 0233 SCREW, SOCKET HEAD, COUNTERSUNK, M12x25-10.9 Plain 2
HEXAGON

BG 011 219 82 aA
55 (157) BOOM ASSEMBLY / SB40NV LEFT 200824
54
300
519
555
861 556
4
52
51
3
9 50
84
8 30
9
22 16
21 15
17 14
2 100
11
81
45
552
785
32
11
1

BG 011 219 82 aA
200824 BOOM ASSEMBLY / SB40NV LEFT 56 (157)

e
1 BG 003 539 08 BOOM ASSEMBLY, REAR SECTION 7 PAGE 58 1
2 BG 011 223 97 BOOM, ZOOM SECTION 7 PAGE 64 1
3 550 031 38 HEAD, BOOM SECTION 7 PAGE 68 1
4 BG 002 454 23 CRADLE Cradle machining, SB20NV, SB40NV 1
8 264 387 72 PIN, TAPER D50 L172 1
. . . . .
8.2 883 132 39 HEXAGON HEAD SCREW M20x1.5x180-m8.8 1
9 264 387 71 PIN, TAPER D50 L156 3
. . . . .
11 264 388 01 PIN, TAPER D70 L166 3
14 550 968 55 STRAP, METAL 1
15 550 968 57 STRAP, METAL 1
. . . . .
16 AF0 010 0841 SCREW, HEXAGON HEAD, PARTIAL M12x60-8.8 Zn 2
THREAD
17 AF0 140 0007 NUT, HEXAGON M12 2
21 AF0 200 0006 NUT, HEXAGON, PREVAILING TORQUE, ALL M12 2
METAL
22 AF0 300 0122 WASHER, LOCK, PAIR NL12-sp 2
30 208 060 58 RING D=50 2
. . . . .
32 321 845 92 NSS ASSEMBLY SECTION 7 PAGE 95 1
45 BG 003 877 39 VALVE ASSEMBLY SECTION 7 PAGE 84 1
50 AF1 035 0005 ADAPTER, SWIVEL MALE STUD JIC 9/16 - BSPP 1/4 2
51 808 226 99 VALVE, THROTTLE CHECK R1/4-R1/4 2
52 AF1 014 0009 ADAPTER, MALE STUD CONNECTOR JIC 9/16 - BSPP 1/4 2
. . . . .
54 330 970 28 GUIDE 1
3-CHAMBER
100 AF0 110 0224 SCREW, SET, SOCKET, HEXAGON, FLAT M10x20 2
POINT
. . . . .
519 AF0 140 0009 NUT, HEXAGON M16 2
. . . . .
785 AF0 050 0450 SCREW, SOCKET HEAD, HEXAGON M10x60 - 8.8 Zn 2
THREAD
THREAD
862 BG 003 585 57 BOLT M20X60 m8.8 9

BG 003 539 08 cC
57 (157) BOOM ASSEMBLY, REAR / SB40 LEFT 200824
47 44
43 41 45 40 46 1

BG 003 539 08 cC
200824 BOOM ASSEMBLY, REAR / SB40 LEFT 58 (157)

e
1 328 967 58 SWING ARM 1
2 BG 004 510 75 PLATE, MOUNTING SECTION 7 PAGE 61 1
3 BG 004 393 86 CROSS JOINT SECTION 7 PAGE 62 1
40 887 192 29 VALVE, THROTTLE CHECK 2
41 816 719 09 ADAPTER, TEE 9/16-18 JIC 2
. . . . .
43 858 385 89 SWIVEL NUT MALE ADAPTER 3/8 in 9/16-18 JIC 2
45 868 401 59 STRAIGHT THREAD ADAPTER 9/16-18 JIC 2
46 882 087 89 STRAIGHT THREAD ELBOW 2
47 816 722 29 ADAPTER, TEE JIC 9/16-18 2
. . . . .

BG 003 539 08 cC
59 (157) BOOM ASSEMBLY, REAR / SB40 LEFT 200824
9 12 13
12 5 748 550 16
10
11
20
16
11
11
13
8
4
799 555 18 19
SECTION A - A 11
20
16
11
8
13
799 555 24
SECTION B - B 18 19
A 31 23 A
550 749 43 41 45 40 46
16
B B
C
22 30
553 202 42 44
C SECTION C - C

BG 003 539 08 cC
200824 BOOM ASSEMBLY, REAR / SB40 LEFT 60 (157)

e
4 321 379 98 SHAFT L=679 1
5 207 881 08 SHAFT 1
8 207 883 68 COVER for swing arm 2
9 264 383 68 COVER 1
10 207 951 08 CONNECTING PIECE 1
. . . . .
11 873 457 49 SEAL, V 115-125 5
12 800 118 39 O-RING 79.5x3.00 2
13 522 450 80 O-RING 119.5x3.00 4
16 572 102 40 NIPPLE, GREASE AR 1/8 4
18 207 958 08 SHIM 0,1 4
. . . . .
19 207 959 28 SHIM 0,3 4
20 801 811 49 PLUG G1/8 2
22 BG 003 426 35 VALVE, SPOOL, DIRECTIONAL Plunger valve, 13 l/min 1
24 344 738 12 KEY, PARALLEL C-12x8x115 1
. . . . .
30 331 785 21 BRACKET Left 1
31 331 785 22 BRACKET Right 1
41 816 719 09 ADAPTER, TEE 9/16-18 JIC 2
42 817 180 79 ELBOW, SWIVEL NUT 9/16-18JIC 2
. . . . .
43 858 385 89 SWIVEL NUT MALE ADAPTER 3/8 in 9/16-18 JIC 2
45 868 401 59 STRAIGHT THREAD ADAPTER 9/16-18 JIC 2
. . . . .
749 AF0 050 0225 SCREW, SOCKET HEAD, HEXAGON M6X20 8
. . . . .
799 AF0 050 0777 SCREW, SOCKET HEAD, HEXAGON M16x30 12

BG 004 510 75 aA
61 (157) PLATE, MOUNTING / SB40 LEFT 200824
2 1 2

e
1 326 696 58 PLATE, MOUNTING 1

BG 004 393 86 aA
200824 CROSS JOINT / TBR60 62 (157)

e
1 320 990 18 CROSS JOINT SB40-90 1

BG 011 223 97 aA
63 (157) BOOM, ZOOM 200824
9 10 11 16 17
27
552
7 13 175
17 14
16
11
552
10 172
9
28
27
7
20
3
555
264 573 506 21
27 5

BG 011 223 97 aA
200824 BOOM, ZOOM 64 (157)

e
1 BG 011 225 75 TUBE, OUTER - 1
4 265 117 61 PIN, TAPER D40 L132 1
4.1 808 738 99 HEXAGON HEAD SCREW M16X1,5X140 m8.8 1
. . . . .
7 265 096 88 SLIPPER PAD 2
9 208 410 18 SHIM 14
10 207 825 68 SCREW, ADJUSTING M70X2 14
. . . . .
11 207 824 38 LOCKING SCREW M 70 X 2 14
13 321 482 38 FLANGE 2
14 550 003 85 WIPER 1
16 522 166 70 O-RING 36,2X3 14
17 AF2 502 0508 O-RING 69.5x3 14
. . . . .
20 BG 002 492 93 COVER 1
21 BG 002 587 79 STUD M8x20 - 8.8 2
27 572 102 40 NIPPLE, GREASE AR 1/8 10
28 572 104 00 NIPPLE, GREASE Pipe thread ISO 7/1-R 1/8 2
. . . . .
506 AF0 190 0004 NUT, HEXAGON, PREVAILING TORQUE M8 2
. . . . .
573 AF0 230 0005 WASHER, PLAIN, NORMAL M8 2

551 609 93 eE
65 (157) HYDRAULIC CYLINDER, DOUBLE-ACTING / ZOOM 200824
17
22
21
20
21
22
23
26
28
25
24
30
18
27
42
47
10
15

551 609 93 eE
200824 HYDRAULIC CYLINDER, DOUBLE-ACTING / ZOOM 66 (157)

e
1 551 609 94 ASSEMBLY, CYLINDER TUBE Machining, Lcta=1478mm 1
2 551 609 96 PISTON ROD ASSEMBLY Ø80 / Ø50, Lpra=1582mm 1
5 550 937 81 PISTON Ø80 1
6 550 938 08 COVER, FRONT Ø80 / Ø50 1
7 551 610 81 BUSHING Ø80 / Ø65, L=270mm 1
. . . . .
10 814 749 19 BEARING, PLAIN 1
15 422 272 90 CIRCLIP 62X2 2
17 814 851 39 HEXAGON SOCKET SET SCREW M8X10 m8.8 1
18 284 318 90 HEXAGON SOCKET SET SCREW M8X20 - 12.9, dog point 1
20 550 952 44 SEAL, PISTON D80 d59 L8 1
. . . . .
21 550 952 79 PISTON GUIDE RING D80 d75 L9,7 2
22 551 534 47 PISTON DIRT RING 5,6x2,5 2
23 550 954 82 O-RING 37.69X3.53 1
24 550 954 15 SEAL, ROD D65 d50 L12.5 1
25 550 955 45 GUIDE RING, PISTON ROD D55 d50 L15 2
. . . . .
26 551 534 28 ROD DIRT RING 9,7x4 1
27 551 510 43 WIPER d50 D58 L5 1
28 550 954 98 SEAL 80X6.4 1
30 551 506 18 O-RING 90x2 1
. . . . .
47 857 302 19 PLUG 9/16-18 JIC 2

550 031 38 dD
67 (157) HEAD, BOOM / ASSEMBLY, LEFT 200824
16 17 23 4 22 12 13
11
35
23
35
21
22
35
20
10
14 15
26
555
553 794
2
3
550 748
1
550 749
34

550 031 38 dD
200824 HEAD, BOOM / ASSEMBLY, LEFT 68 (157)

e
1 BG 004 583 07 FRAME SECTION 7 PAGE 70 1
2 BG 004 569 84 SWING PIECE SECTION 7 PAGE 71 1
4 323 058 88 SHAFT L=350 1
5 207 906 08 SHAFT L=242 1
. . . . .
10 207 939 08 COVER 1
11 207 908 58 COVER 1
12 264 383 68 COVER 1
14 207 959 28 SHIM 0,3 2
. . . . .
15 207 968 08 SHIM S=0,1 2
16 207 969 38 SHIM S=0,3 2
17 207 958 08 SHIM 0,1 2
20 873 457 49 SEAL, V 115-125 3
21 879 026 39 SEAL, V 93-98 W6 2
. . . . .
22 800 118 39 O-RING 79.5x3.00 2
23 522 450 80 O-RING 119.5x3.00 3
26 807 219 59 HEXAGON SOCKET HEAD SCREW M16X35 - 8.8 6
35 572 102 40 NIPPLE, GREASE AR 1/8 3
. . . . .
. . . . .
794 445 821 60 HEXAGON SOCKET HEAD SCREW M12X30 6

BG 004 583 07 bB
69 (157) FRAME / ASSEMBLY, LEFT 200824
3 1 2 3

BG 004 583 07 bB
200824 FRAME / ASSEMBLY, LEFT 70 (157)

e
1 550 023 83 FRAME Left 1
2 264 334 48 BUSHING D100 d85 L50 2

BG 004 569 84 aA
71 (157) SWING PIECE / RIGHT, TB40 200824
1 2 3

e
1 550 020 13 SWING PIECE 1
2 264 334 48 BUSHING D100 d85 L50 2
3 264 397 88 BUSHING D80 d70 L52 2

BG 004 571 38 aA
200824 CROSS JOINT / RIGHT, TB40 72 (157)

e
1 321 069 08 CROSS JOINT 1

BG 009 123 60 aA NSS
73 (157) HOSE SUPPORT ASSEMBLY / SB40 LEFT 200824
7 5 4 6 5 4

e
6 550 967 81 SUPPORTING BLOCK D=90 1
7 550 968 06 SUPPORT, HOSE D=90/90 1

BG 010 356 13 aA
75 (157) ACTUATOR, ROTARY / DOUBLE HYDRAULIC ROTARY ACTUATOR 170 200824
20
20
155
551
3
155
551
157 157
551 551
11
791 553 11
553 791

BG 010 356 13 aA
200824 ACTUATOR, ROTARY / DOUBLE HYDRAULIC ROTARY ACTUATOR 170 76 (157)

e
1 BG 010 353 87 HYDRAULIC ROTARY ACTUATOR, DOUBLE SECTION 7 PAGE 77 1
11 BG 010 609 77 PLATE, COVER Plate, Cover 2
20 522 041 90 O-RING 19,3X2,4 4
. . . . .
155 808 743 69 HEXAGON HEAD BOLT M8X60-8.8 8
157 442 140 30 HEXAGON HEAD BOLT M8x70 8
791 445 816 90 HEXAGON SOCKET HEAD SCREW M12x20 4
. . . . .

BG 010 353 87 aA
77 (157) HYDRAULIC ROTARY ACTUATOR, DOUBLE / P_MAX 250 BAR, M 11000 NM 200824

e
*1 884 084 19 BEARING INCL. PARTS 10, 18, 20, 30 2
*2 550 417 35 SEAL KIT INCL. PARTS 21-28 2

BG 003 343 38 aA
200824 VALVE ASSEMBLY / 200BAR 78 (157)
4 3
7 6 5
1 2

e
1 BG 003 402 98 NSS BODY 1
2 552 129 40 VALVE, COUNTERBALANCE Counterbalance, poppet type, 200bar 2
2.1 552 164 17 SEAL KIT Oil Control Counterbalance Cartridge 1
3 816 711 99 ADAPTER, ELBOW G1/4 x JIC 9/16-18 2
4 884 380 99 PLUG UNF 9/16 in inside thread 2
. . . . .
5 801 802 69 BONDED SEAL d13,7xD22xs1,5 2
6 858 643 79 PLUG R1/4 in 2
7 865 683 09 PLUG G1/8 4

BG 003 344 90 aA
79 (157) VALVE ASSEMBLY / 200BAR 200824
6 5
2 1
4 7

e
2 552 129 40 VALVE, COUNTERBALANCE Counterbalance, poppet type, 200bar 2
2.1 552 164 17 SEAL KIT Oil Control Counterbalance Cartridge 1
3 816 711 99 ADAPTER, ELBOW G1/4 x JIC 9/16-18 2
6 858 643 79 PLUG R1/4 in 2
. . . . .
7 865 683 09 PLUG G1/8 4

BG 003 429 55 aA NSS
200824 VALVE ASSEMBLY / PARALLELISM, SB40-150 80 (157)

e

BG 003 426 04 aA
81 (157) VALVE ASSEMBLY / PARALLELISM VALVE 200824

BG 003 426 04 aA
200824 VALVE ASSEMBLY / PARALLELISM VALVE 82 (157)

e
AA BG 003 427 19 VALVE, CHECK Q 80 l/min, p_max 350 bar 1
AB BG 003 427 19 VALVE, CHECK Q 80 l/min, p_max 350 bar 1
S1 BG 003 427 26 VALVE, COUNTERBALANCE 1
. . . . .
S5 BG 003 425 08 VALVE, CHECK, PILOT TO OPEN VSON-08H-G-00 1
S6 BG 003 425 08 VALVE, CHECK, PILOT TO OPEN VSON-08H-G-00 1
X1 BG 003 427 24 VALVE, COUNTERBALANCE 1
. . . . .
X2 552 129 39 VALVE, COUNTERBALANCE Counterbalance,standard guided poppet 1
type,160bar
X2.1 871 694 39 SEAL KIT 1
Y1 884 358 89 VALVE, PRESSURE SEQUENCE 3/2 1
Y2 884 358 89 VALVE, PRESSURE SEQUENCE 3/2 1

BG 003 877 39 bB
83 (157) VALVE ASSEMBLY / OPTION VALVE BLOCK ASSEMBLY, SB BOOMS 200824
1
3 4

BG 003 877 39 bB
200824 VALVE ASSEMBLY / OPTION VALVE BLOCK ASSEMBLY, SB BOOMS 84 (157)

e

BG 003 877 43 bB
85 (157) VALVE ASSEMBLY 200824

e
S1 BG 002 364 25 VALVE, SHUTTLE - 1
S4 BG 002 366 93 VALVE, SPOOL, DIRECTIONAL - 1
S5 BG 002 366 93 VALVE, SPOOL, DIRECTIONAL - 1
. . . . .
S6 BG 002 364 24 VALVE, PRESSURE REDUCING - 1
S7 BG 002 376 99 VALVE, PRESSURE REDUCING - 1

550 997 48 eE
87 (157) HYDRAULIC CYLINDER, DOUBLE-ACTING, 3-CHAMBER 200824
15 32 31 32
10
40
40
33
5
43
22
42
21
20
65
17
21
22
23
1
56 47 46 60 45 44
2
55 51
3
56
55
26
28
25
18
24
30
6
37
27
40
38 65
57
12
58

550 997 48 eE
200824 HYDRAULIC CYLINDER, DOUBLE-ACTING, 3-CHAMBER 88 (157)

e
1 551 528 16 CYLINDER TUBE ASSEMBLY Ø165 / Ø140 1
2 551 555 57 ROD, PISTON Ø110, Lpra=897mm 1
3 551 528 20 PISTON ASSEMBLY Ø80 1
5 551 529 74 PISTON Ø140 / Ø110 1
6 551 528 27 COVER, FRONT Ø140 / Ø110 1
. . . . .
15 802 353 09 CIRCLIP 105X4 2
18 448 473 80 HEXAGON SOCKET SET SCREW M10X10 1
. . . . .
20 885 047 79 SEAL, PISTON 140x119x8 1
21 550 952 82 PISTON GUIDE RING D140 d135 L15 2
22 551 534 26 PISTON DIRT RING 9,7x4 2
23 551 559 90 O-RING 110,49x5.33 1
24 551 533 45 SEAL, ROD D130 d110 L16 1
. . . . .
26 551 534 59 ROD DIRT RING 9,7x4 1
27 551 533 42 WIPER d110 D125 L9,5 1
28 550 955 01 SEAL 140X12.3 1
30 550 955 42 O-RING 155x2,5 1
. . . . .
31 550 970 13 SEAL, ROD D95 d80 L12.5 2
33 551 559 91 O-RING 72,39x5.33 1
37 BG 003 263 56 VALVE, COUNTERBALANCE Q 120 l/min, p_max 350 bar 1
38 BG 003 263 56 VALVE, COUNTERBALANCE Q 120 l/min, p_max 350 bar 1
. . . . .
40 572 102 40 NIPPLE, GREASE AR 1/8 3
44 807 604 19 ADAPTER, HYDRAULIC RK1/8xR1/4 1
45 887 628 69 VALVE, THROTTLE, ADJUSTABLE Q 11 l/min, p_max 345 bar 1
. . . . .
47 817 096 19 PLUG 7/16-20 JIC 1
55 421 434 50 WASHER, SPRING M8 2
. . . . .
57 804 309 49 NUT, LOCK VM 16x1,5 1
60 551 531 14 PLATE, COVER - 1
65 390 140 48 SIGN DON'T PLUG THIS NIPPLE 2
*200 551 559 89 SEAL KIT 140/110/80 INCL. PARTS 20-33 1
. . . . .

551 560 82 fE
89 (157) HYDRAULIC CYLINDER, DOUBLE-ACTING, 3-CHAMBER 200824
15 32 31 32
10
40
40
33
5
43
22
42
21
20
65
17
21
22
23
1
56 47 46 60 45 44
2
55 51
3
56
55
26
28
25
18
24
30
6
37
27
40
38 65
57
12
58

551 560 82 fE
200824 HYDRAULIC CYLINDER, DOUBLE-ACTING, 3-CHAMBER 90 (157)

e
1 551 528 16 CYLINDER TUBE ASSEMBLY Ø165 / Ø140 1
2 551 555 57 ROD, PISTON Ø110, Lpra=897mm 1
3 551 528 20 PISTON ASSEMBLY Ø80 1
5 551 529 74 PISTON Ø140 / Ø110 1
6 551 528 27 COVER, FRONT Ø140 / Ø110 1
. . . . .
7 207 952 38 LIMIT BUSHING L=19 D=137/80 1
8 551 560 75 LIMIT BUSHING Ø137 / Ø110, L=55mm 1
15 802 353 09 CIRCLIP 105X4 2
. . . . .
18 448 473 80 HEXAGON SOCKET SET SCREW M10X10 1
20 885 047 79 SEAL, PISTON 140x119x8 1
21 550 952 82 PISTON GUIDE RING D140 d135 L15 2
22 551 534 26 PISTON DIRT RING 9,7x4 2
. . . . .
23 551 559 90 O-RING 110,49x5.33 1
24 551 533 45 SEAL, ROD D130 d110 L16 1
26 551 534 59 ROD DIRT RING 9,7x4 1
27 551 533 42 WIPER d110 D125 L9,5 1
. . . . .
28 550 955 01 SEAL 140X12.3 1
30 550 955 42 O-RING 155x2,5 1
32 550 970 13 SEAL, ROD D95 d80 L12.5 2
33 551 559 91 O-RING 72,39x5.33 1
. . . . .
37 BG 003 263 53 VALVE, COUNTERBALANCE 290 bar 1
40 572 102 40 NIPPLE, GREASE AR 1/8 3
. . . . .
44 807 604 19 ADAPTER, HYDRAULIC RK1/8xR1/4 1
45 887 628 69 VALVE, THROTTLE, ADJUSTABLE Q 11 l/min, p_max 345 bar 1
47 817 096 19 PLUG 7/16-20 JIC 1
. . . . .
56 421 434 50 WASHER, SPRING M8 2
57 804 309 49 NUT, LOCK VM 16x1,5 1
60 551 531 14 PLATE, COVER - 1
. . . . .
65 390 140 48 SIGN DON'T PLUG THIS NIPPLE 2
*200 551 559 89 SEAL KIT 140/110/80 INCL. PARTS 20-33 1

550 041 20 bB
91 (157) HYDRAULIC CYLINDER, DOUBLE-ACTING / TILT, D125 D50 LMIN643 S289 200824
1 2
5 10 15 4 11 14 13 3 12
16 17
7 8

550 041 20 bB
200824 HYDRAULIC CYLINDER, DOUBLE-ACTING / TILT, D125 D50 LMIN643 S289 92 (157)

e
1 322 848 88 CYLINDER TUBE ASSEMBLY 1
1.1 800 733 89 BEARING, PLAIN 1
1.2 207 974 08 BUSHING, BEARING D60 d50 L59 1
1.3 422 292 00 CIRCLIP 90x3 2
1.4 572 102 40 NIPPLE, GREASE AR 1/8 2
. . . . .
2 321 408 28 PISTON ROD ASSEMBLY Incl. parts 18, 21 1
2.2 572 102 40 NIPPLE, GREASE AR 1/8 1
3 161 412 68 COVER, FRONT D125/50 1
4 155 004 08 PISTON D125 1
. . . . .
5 869 128 99 NUT, LOCK M40X1,5 1
8 871 830 29 VALVE, PRESSURE RELIEF 1
9 817 566 29 CARTRIDGE 1
. . . . .
10 816 819 39 SEAL, PISTON 125x100x25,4 1
11 803 135 09 SEAL, U 50x60x10, NI300 1
12 807 823 69 WIPER 50-60-7-10 1
13 814 797 09 GUIDE RING, PISTON ROD 50/56X13 3
14 522 300 00 O-RING 114,3x5,7-1 1
. . . . .
15 428 702 10 O-RING 49.5x3.00 1

550 041 24 bB
93 (157) HYDRAULIC CYLINDER, DOUBLE-ACTING / SWING, D125 D70 LMIN640 S289 200824
5 1
10 4 15 3 11 14 13 12 2
8
6
16 17
7 9

550 041 24 bB
200824 HYDRAULIC CYLINDER, DOUBLE-ACTING / SWING, D125 D70 LMIN640 S289 94 (157)

e
1 322 848 88 CYLINDER TUBE ASSEMBLY 1
1.1 800 733 89 BEARING, PLAIN 1
1.3 422 292 00 CIRCLIP 90x3 2
1.4 572 102 40 NIPPLE, GREASE AR 1/8 2
. . . . .
2 321 409 58 PISTON ROD ASSEMBLY Incl. parts 18, 21 1
2.2 572 102 40 NIPPLE, GREASE AR 1/8 1
3 264 191 68 COVER, FRONT 125/70 1
4 155 004 08 PISTON D125 1
. . . . .
5 869 128 99 NUT, LOCK M40X1,5 1
8 817 566 29 CARTRIDGE 1
9 855 878 69 CARTRIDGE 1
. . . . .
9.1 819 592 69 SEAL KIT 1
10 816 819 39 SEAL, PISTON 125x100x25,4 1
11 874 560 09 SEAL, U 70-80-12 1
12 801 010 09 WIPER 70x80x7x10 1
13 817 054 29 GUIDE RING, PISTON ROD 70/76X13 3
. . . . .
14 522 300 00 O-RING 114,3x5,7-1 1
15 428 702 10 O-RING 49.5x3.00 1
16 816 713 49 STRAIGHT THREAD ELBOW G3/8 x JIC 9/16-18 3
17 803 264 29 PLUG 9/16-18 JIC 3
. . . . .

321 845 92 aA NSS
95 (157) ASSEMBLY / POINTER ASSEMBLY WITHOUT ANGLE SENSOR 200824
3 4

e
1 208 048 58 SIGN Boom hinge angle 1
2 265 541 32 POINTER 1

550 968 79 bB
200824 SUPPORT, HOSE / DOUBLE D=90/90 + PERC. 96 (157)

e
1 158 066 48 CHAIN L=71 1
2 164 527 68 CLIP D90 2
3 345 532 08 PLATE Hose Support 1
4 550 967 90 STRAP, METAL 1
. . . . .
6 AF0 140 0007 NUT, HEXAGON M12 2
METAL

551 592 93 aAa
97 (157) FEED ASSEMBLY / 16', IMP.SYL, TF500, RD5XX. LEFT 200824
328 556
553 201
21
35 518
1 590 555
24 262
285 553
45
205
42 26
555 41
218
601 518
512
590
43 553
555
281
518
44 38
2
4
41
38
518
590
3
31
518
590 29
27 281 45
205
518 553
22
590
281 553
299
202
590
601 555 42
518 553 37

551 592 93 aAa
200824 FEED ASSEMBLY / 16', IMP.SYL, TF500, RD5XX. LEFT 98 (157)

e
1 344 495 04 FEED BEAM ASSEMBLY SECTION 7 PAGE 101 1
2 550 829 49 CYLINDER SECTION 7 PAGE 104 1
3 550 385 04 WIRE ROPE SECTION 7 PAGE 108 1
21 325 321 68 CENTRALIZER, FRONT SECTION 7 PAGE 113 1
. . . . .
22 551 861 40 ASSEMBLY SECTION 7 PAGE 116 1
24 263 685 98 CENTRALIZER, TRAVELLING SECTION 7 PAGE 117 1
26 325 124 98 PLATE Travelling centralizer 1
27 551 000 70 PLATE 1
29 330 016 98 SLIPPER PAD TF and TFX slide piece 4
. . . . .
31 331 341 78 BRACKET 1
35 551 592 41 BRACKET 1
37 207 752 88 HEXAGON HEAD BOLT M12 1
38 209 027 18 SCREW, RETAINER 7
41 550 123 95 FRAME 2
. . . . .
42 331 435 08 BRACKET 2
43 332 767 78 CYLINDER, IMPULSE SECTION 7 PAGE 112 2
44 BG 008 674 65 HOSE SUPPORT ASSEMBLY SECTION 7 PAGE 118 1
45 331 436 28 FRAME, SLIDE 2
. . . . .
THREAD
THREAD
. . . . .
THREAD
THREAD
THREAD
METAL
METAL
. . . . .
. . . . .

551 592 93 aAa
99 (157) FEED ASSEMBLY / 16', IMP.SYL, TF500, RD5XX. LEFT 200824
205
553
A
36
328 556
23
30 560
104 556
100
33 600 552 173 39
28 29 101 173 552

SECTION A - A

551 592 93 aAa
200824 FEED ASSEMBLY / 16', IMP.SYL, TF500, RD5XX. LEFT 100 (157)

e
23 325 116 38 FRAME, REAR 1
28 263 375 08 FRAME, SLIDE L=250 2
30 289 221 28 NUT Sleeve nut 1
33 209 600 78 SIGN Type explanation, components 1
. . . . .
36 207 568 08 PLATE 1
39 208 353 08 PLATE For 90 degrees slide pieces 8
101 551 501 27 DAMPER, HOLE MOUNT 1
. . . . .
THREAD
. . . . .
600 455 332 90 SCREW 2X5 4

344 495 04 cB
101 (157) FEED BEAM ASSEMBLY / TF500-16' 200824
6 1 5
201
553

e
1 064 815 76 NSS BEAM 1
5 208 919 08 STRIP, GUIDE L=6363 4
. . . . .

550 829 49 bBg
103 (157) CYLINDER / FEED CYLINDER ASSY OF TF-16' 200824
14
14
12
11
13 15
11
14

550 829 49 bBg
200824 CYLINDER / FEED CYLINDER ASSY OF TF-16' 104 (157)

e
2 323 610 98 WHEEL, IDLER SECTION 7 PAGE 107 1
3 262 511 88 BUSHING L=305 1
4 263 487 98 BRACKET 2-TOOL BOX 1
11 801 031 49 BONDED SEAL U 17.4x24x1.5 2
. . . . .
12 207 144 68 ADAPTER R6-JIC8 L=70 1
13 208 039 78 ADAPTER R 3/8 X JIC 3/4 1
15 817 183 59 SWIVEL NUT ELBOW 90 JIC 3/4-16 2

550 540 65 a
105 (157) HYDRAULIC CYLINDER, DOUBLE-ACTING 200824
A A
6
12 1
8 13
11 19
SECTION A - A
10
9 18
10
4
15
20
16 1
16
17

550 540 65 a
200824 HYDRAULIC CYLINDER, DOUBLE-ACTING 106 (157)

e
1 550 542 64 PISTON AND PISTON ROD 1
2 550 540 68 TUBE, CYLINDER 1
3 550 540 70 COVER, CYLINDER 1
4 550 272 33 BUSHING D60/d50 L=305 1
5 550 546 02 WIPER D58.8 d50 L9.5 1
. . . . .
6 872 634 99 SEAL, ROD 2
7 872 630 89 SEAL, PISTON 1
9 872 632 39 RING 2
10 872 631 09 GUIDE RING, PISTON ROD 2
. . . . .
11 550 546 03 SEAL D70 d65 L5 1
12 812 604 09 PLUG G3/8 2
13 801 031 49 BONDED SEAL U 17.4x24x1.5 2
15 812 604 09 PLUG G3/8 1
16 801 031 49 BONDED SEAL U 17.4x24x1.5 1
. . . . .
18 428 702 10 O-RING 49.5x3.00 2
*888 550 550 45 SEAL KIT INCL. PARTS 5-11, 13 1

323 610 98 aA
107 (157) WHEEL, IDLER 200824
4
7
4
7
10 9 8 2

e
1 320 417 08 BRACKET 1
2 332 779 38 WHEEL, IDLER 1
3 206 116 88 SHAFT 1
5 AF2 002 0070 CIRCLIP, INTERNAL 90.0x3.0 1
6 800 083 39 SPRING-TYPE STRAIGHT PIN 8X36 1
. . . . .
7 AF2 104 0465 BEARING, DEEP GROOVE BALL D90-d40-B23 2
8 572 102 40 NIPPLE, GREASE AR 1/8 1
9 888 172 19 VALVE 1/8'' 1

550 385 04 lL
200824 WIRE ROPE / L=6600 108 (157)

e
4 800 485 09 NUT, HEXAGON M16 2
5 811 259 69 NUT, LOCK M16 - 8 2
6 421 199 60 WASHER M17 1

551 591 56 bB
109 (157) WIRE ROPE / TF500 - 16' L=3348 200824
5
6

551 591 56 bB
200824 WIRE ROPE / TF500 - 16' L=3348 110 (157)

e
4 AF0 140 0009 NUT, HEXAGON M16 1
METAL

332 767 78 cC
111 (157) CYLINDER, IMPULSE / IMPULSE CYLINDER 200824
10 8 1 2
9 3 7 4 11 6 5

332 767 78 cC
200824 CYLINDER, IMPULSE / IMPULSE CYLINDER 112 (157)

e
2 345 702 38 PISTON 1
3 041 443 58 REDUCER, TUBE END R1 1/4 in -R1 1/4 in 1
4 041 444 88 SPRING 16,5/2,5 1
5 BG 013 149 78 WIPER 30x40x5x8 1
6 810 119 99 SEAL, U 30x38x6, S8-30 1
. . . . .
7 522 151 20 O-RING 44.2x3.00 1
8 804 160 09 USIT-SEAL U d12,4xD16xs1,5 SC 1
10 887 328 89 PLUG R 1/8 in in 1
11 550 018 27 GUIDE guide ring 35/31/9.6 1
. . . . .

325 321 68 gG
113 (157) CENTRALIZER, FRONT / ASSEMBLY 200824
6 8 15 20 25 30 35
7
3
10
1

e
1 325 322 98 CENTRALIZER, FRONT 1
3 263 634 18 BUFFER TF500 1
4 263 934 08 JAW 1
6 442 831 40 HEXAGON HEAD BOLT M20X150 m8.8 1
. . . . .
METAL
15 331 912 31 SLIPPER PAD D41 1
*20 331 912 32 SLIPPER PAD D=48 1
. . . . .
*25 331 912 33 SLIPPER PAD D57 1
*30 331 912 34 SLIPPER PAD D=66 1
*35 332 110 78 SLIPPER PAD D41, special long L=118, only TF feed 1

551 861 40 fF
115 (157) ASSEMBLY / TF/TFX HOSE REEL 200824
14
15 9 1 11 13 10 12 5
8 16 17 2

551 861 40 fF
200824 ASSEMBLY / TF/TFX HOSE REEL 116 (157)

e
1 551 563 69 COVER 1
2 552 250 41 SHAFT ASSEMBLY 1
3 551 563 70 BUSHING 70/58,2 L=177 1
4 BG 006 724 77 BEARING, BALL, DEEP GROOVE D95 d60 L18 1
. . . . .
7 323 405 68 WHEEL, IDLER 1
8 551 854 18 PLATE, BASE 1
9 551 853 95 REEL, HOSE 1
10 514 014 30 NUT, LOCK M50X1,5 1
. . . . .
11 514 410 30 WASHER, LOCK 1
12 801 811 49 PLUG G1/8 1
15 884 868 29 HEXAGON SOCKET COUNTERSUNK HEAD M12X25 m10.9 6
SCREW (FULL THREAD
. . . . .
16 551 853 93 SEAL 160 2
17 551 853 89 SEAL, SHAFT 70x85x8 1

263 685 98 fC
117 (157) CENTRALIZER, TRAVELLING / ASSEMBLY 200824
5 6
15 20 21 25 30
1 3 7

e
1 263 684 68 FRAME 1
3 263 934 08 JAW 1
7 817 807 89 NUT, LOCK M20 - 8 1
. . . . .
15 331 912 31 SLIPPER PAD D41 1
*20 331 912 32 SLIPPER PAD D=48 1
*21 551 744 01 SLIPPER PAD D51 1
*25 331 912 33 SLIPPER PAD D57 1
*30 331 912 34 SLIPPER PAD D=66 1
. . . . .

BG 008 674 65 cC
200824 HOSE SUPPORT ASSEMBLY / HOSE BRACKET. HLX5, RD5XX 118 (157)
6
5
8
555 266
4
2 525 557

e
2 330 105 88 HOSE SUPPORT ASSEMBLY 1
3 209 567 98 CLIP 1
4 BG 008 675 85 PIECE, CLAMPING Hose Clamp 1
5 BG 008 675 64 PIECE, CLAMPING Hose Clamp 1
6 BG 008 675 88 ADAPTER 1
. . . . .
7 BG 008 675 95 PIECE, CLAMPING D=17/19 1
525 AF0 140 0013 NUT, HEXAGON M24 1
. . . . .

BG 002 350 30 fF NSS
119 (157) CONNECTION PARTS / SB40, SB20 TCAD 200824
4 555 264
LT1
147
599
3
173 1
552
279 555 6 5 22 7 552 785
285 518
8 173 565
552
5
10
279 6 14
2
3
11
285 555 173 552 10 13 565 518

BG 002 350 30 fF NSS
200824 CONNECTION PARTS / SB40, SB20 TCAD 120 (157)

e
2 208 907 38 PIN D28 2
2.1 572 102 40 NIPPLE, GREASE AR 1/8 1
2.2 800 460 49 HEXAGON HEAD SCREW M10x25 - 8.8 1
2.3 851 282 09 WASHER, LOCK, DOUBLEC M10 1
. . . . .
4 321 041 68 BRACKET, BEARING Height 72 1
6 263 375 08 FRAME, SLIDE L=250 4
. . . . .
9 552 158 36 RUBBER SHEET 1
10 AF0 130 0314 SCREW, SET, SOCKET, HEXAGON, DOG M16x25-45H Plain 4
POINT
11 550 372 39 JUNCTION BOX ASSEMBLY SECTION 7 PAGE 126 1
POINT
. . . . .
22 BG 003 695 61 PLATE Valve mounting 1
. . . . .
THREAD
THREAD
METAL
. . . . .
599 AF0 250 0005 WASHER, PLAIN, LARGE M8 3

552 162 27 a
121 (157) HYDRAULIC CYLINDER, DOUBLE-ACTING / Ø63 / 200824
Ø40, LMIN=1660MM, S=1350MM (ACID PROOF)
18 15 17 19
13 12 11 10 3 1 2 4 9 7 6 7 8 14 16

e
1 BG 002 238 11 TUBE, CYLINDER SECTION 7 PAGE 122 1
2 552 186 10 PISTON ROD ASSEMBLY Ø40, Acid Proof 1
3 551 748 83 PISTON D63 1
4 551 748 80 COVER, FRONT D63 d40 s1650 1
5 868 929 29 SEAL, PISTON 63/47X19 1
. . . . .
6 807 645 89 SEAL, U 40-112 1
7 868 930 99 GUIDE, ROD 40/46X9,6 3
8 806 120 89 WIPER 40-50-7-10 1
9 868 932 49 O-RING 57X3 1
10 551 751 35 O-RING 26.2X3 1
. . . . .
11 551 751 60 PLATE, BASE Ø17,4 / Ø14, L=7 1
12 551 751 31 MAGNET Ø17.4 / Ø13.5, s=8mm 1
13 551 751 56 NUT Ø41, L=15 1
. . . . .
16 572 102 40 NIPPLE, GREASE AR 1/8 1
18 857 302 19 PLUG 9/16-18 JIC 2
19 812 603 79 PLUG R 1/4 2

BG 002 238 11 aV
200824 TUBE, CYLINDER / INCLUDES MA SENSOR 122 (157)
A A
B A-A
8
B
7 6 9 4

e
4 737 031 08 SCREW M5x12 1
5 551 751 14 HEXAGON SOCKET HEAD SCREW M4x10 -8.8/Zn 4
7 572 102 40 NIPPLE, GREASE AR 1/8 1
8 BG 002 221 36 GLAND, CABLE 1
. . . . .
9 093 701 91 O-RING 14X1,78, NBR, 70 SHORE A 1

BG 005 259 90 aA
123 (157) VALVE ASSEMBLY / CONTROL VALVE,CONTROL PRESSURE 120BAR 200824
1 2
2 3

e
1 BG 003 425 45 MANIFOLD, VALVE ASSEMBLY SECTION 7 PAGE 124 1

BG 003 425 45 aA
200824 MANIFOLD, VALVE ASSEMBLY / FEED EXTENSION CONTROL VALVE 124 (157)

e
1 BG 005 095 05 VALVE, PRESSURE RELIEF max P=350 bar, max Q=50 l/min 1

550 372 39 gK
125 (157) JUNCTION BOX ASSEMBLY / 2XM16 200824
35 34
37 36
37 36
23 24
1
15 16
19
20
17 18
21
22
10 11 12 13 14
3 4 5
31 32

550 372 39 gK
200824 JUNCTION BOX ASSEMBLY / 2XM16 126 (157)

e
3 850 546 59 RAIL, MOUNTING DIN rail NS15 0.07
4 800 617 49 SLOTTED PAN HEAD SCREW M4X6 2
5 800 246 39 WASHER, STAR 4 IZ 2
10 850 547 89 TERMINAL BLOCK, FEED-THROUGH 2 Connections, 4 mm2 8
11 850 595 79 TERMINAL BLOCK, END PLATE Gray 1
. . . . .
12 850 548 09 TERMINAL BLOCK, GROUND 2
13 852 885 69 MARKER STRIP, TERMINAL White 1
15 550 038 16 GLAND, CABLE M16 1
17 550 038 16 GLAND, CABLE M16 1
18 550 082 89 REDUCER M20x1.5 / M16x1.5 1
. . . . .
19 550 038 00 NUT, LOCKING, METALLIC M16x1.5, H=2.8mm 1
21 550 059 90 PLUG, BLANKING, METALLIC M16x1,5 with NBR O-ring, Thread=6,0mm 1

551 637 30 eE
127 (157) CARRIAGE ASSEMBLY / FOR RD500 -SERIES, TF FEEDS (ALUMINIUM) 200824
8 10 16
18 17
6 7
21
5
20
8 10 19
11
A A
14 13
23 11
3
8 9
12
15 13
SECTION A-A
14 13
8 10 22 4
6 7
12
3

551 637 30 eE
200824 CARRIAGE ASSEMBLY / FOR RD500 -SERIES, TF FEEDS (ALUMINIUM) 128 (157)

e
1 551 728 41 CARRIAGE for RD500, TF feeds 1
2 551 718 08 MOUNTING PIECE for rear wire rope, RD500 1
3 551 796 00 FRAME, SLIDE 2
. . . . .
METAL
. . . . .
12 551 637 74 SUPPORT for slide piece, RD5, TF feeds 2
THREAD
. . . . .
17 421 205 00 WASHER M21 1
18 550 837 77 NUT, HEXAGON M20 - 8.8 1
THREAD
20 816 746 59 ADAPTER, HYDRAULIC 1,1/16-12 JIC 1
. . . . .
21 817 238 79 ADAPTER, HYDRAULIC 9/16-18 JIC 1
22 800 543 39 HEXAGON HEAD BOLT M16x130 - 8.8 2
23 551 796 07 BOSS, THREADED for RD5 carriage TF feed, M16 2

327 899 01 gG
129 (157) MOUNTING, CENTRAL LUBRICATION SYSTEM 200824
10 550
10 550
550 10
ONLY WITH
TB150
550 10 12 11
5
(TB60)
2
550 10
550 10
550 10

327 899 01 gG
200824 MOUNTING, CENTRAL LUBRICATION SYSTEM 130 (157)

e
1 851 786 59 DISTRIBUTOR SSV6 1
5 550 216 58 PLATE, COVER 2
. . . . .
10 810 461 09 HEXAGON HEAD SCREW M6X40-8.8 10

BG 012 346 40 a
131 (157) HOSE KIT / HOSE BUNDLE, SB40NV BOOM HOSES, CENTRAL GREASING 200824

e
40 552 158 20 COVER, HOSE Flame resistant safe-spiral 3
51 550 968 06 SUPPORT, HOSE D=90/90 1
. . . . .
54 804 532 39 RUBBER SHEET S3mm 1
55 807 695 29 STRAP L=400 Black 10

BG 012 245 21 a
200824 HOSE KIT / HOSE BUNDLE, SB40 PERCUSSION HOSES, LEFT 132 (157)

e
59 807 695 29 STRAP L=400 Black 10

BG 013 789 58 a
133 (157) HOSE KIT / HOSE BUNDLE, SB40 DRILLING HOSES, TF, SLU, IMP, ST 200824

e
23 BG 011 661 64 HOSING SET SECTION 5 PAGE 68 1
. . . . .
55 807 695 29 STRAP L=400 Black 10
. . . . .

BG 014 698 10 aG NSS
200824 MODULE, DRILLING / RIGHT 134 (157)
RIGHT
TFX500
900
9
1 11 6
5 3 8 12 15 21 4
TF500
50 43 42 41 40 7 2
33

e
1 BG 011 002 61 ROCK DRILL SECTION 7 PAGE 4 1
2 BG 011 218 31 BOOM ASSEMBLY SECTION 7 PAGE 136 1
3 551 599 73 FEED ASSEMBLY SECTION 7 PAGE 152 1
4 BG 002 350 30 NSS CONNECTION PARTS SECTION 7 PAGE 120 1
6 551 637 30 CARRIAGE ASSEMBLY SECTION 7 PAGE 128 1
. . . . .
7 327 899 01 MOUNTING, CENTRAL LUBRICATION SECTION 7 PAGE 130 1
SYSTEM
40 155 750 38 COVER, HOSE D=50 L=2000 18
50 807 695 29 STRAP L=400 Black 40
. . . . .
. . . . .

BG 011 218 31 aA
135 (157) BOOM ASSEMBLY / SB40NV RIGHT 200824
25
34
748 748
550 550
12 13 12
556
861
7
19
9
18
18 85
29
31
10
792
82
553
202 553
42 202
18 33
18
6
12 11
19
550
748 13 12 550 748
29

BG 011 218 31 aA
200824 BOOM ASSEMBLY / SB40NV RIGHT 136 (157)

e
6 323 060 78 SHAFT L=366 1
7 323 057 58 SHAFT L=306 1
9 264 387 71 PIN, TAPER D50 L156 3
. . . . .
10 264 388 02 PIN, TAPER D70 L182 1
11 264 388 01 PIN, TAPER D70 L166 3
12 264 383 68 COVER 4
. . . . .
13 873 457 49 SEAL, V 115-125 4
18 AF2 501 0518 O-RING 119.5x3 4
19 AF2 501 0510 O-RING 79.5x3 2
25 BG 010 356 13 ACTUATOR, ROTARY SECTION 7 PAGE 76 1
. . . . .
31 208 061 88 RING D=70 2
34 330 463 68 SUPPORTING BLOCK 1
42 BG 003 429 55 NSS VALVE ASSEMBLY SECTION 7 PAGE 80 1
3-CHAMBER
. . . . .
. . . . .
792 AF0 070 0233 SCREW, SOCKET HEAD, COUNTERSUNK, M12x25-10.9 Plain 2
HEXAGON
THREAD
THREAD
. . . . .

BG 011 218 31 aA
137 (157) BOOM ASSEMBLY / SB40NV RIGHT 200824
54
300
519
555
556
52
861
51
50
3
9
84 30
100 16 22 9 8
15 21
14 17
11
81
45
552
785
32
11
1

BG 011 218 31 aA
200824 BOOM ASSEMBLY / SB40NV RIGHT 138 (157)

e
1 BG 003 538 77 BOOM ASSEMBLY, REAR SECTION 7 PAGE 140 1
2 BG 011 223 16 BOOM, ZOOM SECTION 7 PAGE 146 1
3 550 031 37 HEAD, BOOM SECTION 7 PAGE 148 1
4 BG 002 454 23 CRADLE Cradle machining, SB20NV, SB40NV 1
8 264 387 72 PIN, TAPER D50 L172 1
. . . . .
8.2 883 132 39 HEXAGON HEAD SCREW M20x1.5x180-m8.8 1
9 264 387 71 PIN, TAPER D50 L156 3
. . . . .
11 264 388 01 PIN, TAPER D70 L166 3
14 550 968 55 STRAP, METAL 1
15 550 968 57 STRAP, METAL 1
. . . . .
16 AF0 010 0841 SCREW, HEXAGON HEAD, PARTIAL M12x60-8.8 Zn 2
THREAD
17 AF0 140 0007 NUT, HEXAGON M12 2
METAL
30 208 060 58 RING D=50 2
. . . . .
32 321 845 92 NSS ASSEMBLY SECTION 7 PAGE 95 1
51 808 226 99 VALVE, THROTTLE CHECK R1/4-R1/4 2
. . . . .
54 330 970 28 GUIDE 1
3-CHAMBER
POINT
. . . . .
519 AF0 140 0009 NUT, HEXAGON M16 2
. . . . .
785 AF0 050 0450 SCREW, SOCKET HEAD, HEXAGON M10x60 - 8.8 Zn 2
THREAD
THREAD
862 BG 003 585 57 BOLT M20X60 m8.8 9

BG 003 538 77 dC
139 (157) BOOM ASSEMBLY, REAR / SB40, RIGHT 200824
16
44 47
43 41 45 40 46
1

BG 003 538 77 dC
200824 BOOM ASSEMBLY, REAR / SB40, RIGHT 140 (157)

e
1 328 967 58 SWING ARM 1
2 BG 004 494 25 PLATE, MOUNTING SECTION 7 PAGE 143 1
16 572 102 40 NIPPLE, GREASE AR 1/8 4
41 AF1 147 0003 ADAPTER, SWIVEL NUT RUN TEE JIC 9/16 2
. . . . .
47 AF1 144 0003 ADAPTER, SWIVEL NUT BRANCH TEE JIC 9/16 2
. . . . .

BG 003 538 77 dC
141 (157) BOOM ASSEMBLY, REAR / SB40, RIGHT 200824
9
748 550 12
13
5 16 10
16 12 11
11 20
11
4
8
13 555 799 18 19 11
SECTION B - B
20
11
16
13
799 555 18 19 24 8
B 23 30 B SECTION A - A
16 550 749
43 41 45 40 46
A A
C
202 553 22 31 42 44
C
SECTION C - C

BG 003 538 77 dC
200824 BOOM ASSEMBLY, REAR / SB40, RIGHT 142 (157)

e
4 321 379 98 SHAFT L=679 1
5 207 881 08 SHAFT 1
8 207 883 68 COVER for swing arm 2
9 264 383 68 COVER 1
. . . . .
11 873 457 49 SEAL, V 115-125 5
12 800 118 39 O-RING 79.5x3.00 2
13 522 450 80 O-RING 119.5x3.00 4
16 572 102 40 NIPPLE, GREASE AR 1/8 4
. . . . .
18 207 958 08 SHIM 0,1 4
19 207 959 28 SHIM 0,3 4
20 801 811 49 PLUG G1/8 2
. . . . .
24 344 738 12 KEY, PARALLEL C-12x8x115 1
30 331 785 21 BRACKET Left 1
31 331 785 22 BRACKET Right 1
41 AF1 147 0003 ADAPTER, SWIVEL NUT RUN TEE JIC 9/16 2
. . . . .
42 AF1 146 0004 ADAPTER, SWIVEL NUT ELBOW JIC 9/16 4
. . . . .
. . . . .

BG 004 494 25 aA
143 (157) PLATE, MOUNTING / SB40 RIGHT 200824
2 1 2

e
1 326 211 38 PLATE, MOUNTING Incl. plate and bushing 1

BG 011 223 16 aA
145 (157) BOOM, ZOOM 200824
6
27
7
14
10 11 16
175
9 17
552
2
13
17
16
11 172 552
10
28
9
7
27
573 506 21
3
555 264 20
4 5
27

BG 011 223 16 aA
200824 BOOM, ZOOM 146 (157)

e
1 BG 011 224 77 TUBE, OUTER - 1
4 265 117 61 PIN, TAPER D40 L132 1
4.1 808 738 99 HEXAGON HEAD SCREW M16X1,5X140 m8.8 1
. . . . .
7 265 096 88 SLIPPER PAD 2
9 208 410 18 SHIM 14
10 207 825 68 SCREW, ADJUSTING M70X2 14
. . . . .
11 207 824 38 LOCKING SCREW M 70 X 2 14
13 321 482 38 FLANGE 2
14 550 003 85 WIPER 1
16 522 166 70 O-RING 36,2X3 14
17 AF2 502 0508 O-RING 69.5x3 14
. . . . .
20 BG 002 492 93 COVER 1
21 BG 002 587 79 STUD M8x20 - 8.8 2
27 572 102 40 NIPPLE, GREASE AR 1/8 10
28 572 104 00 NIPPLE, GREASE Pipe thread ISO 7/1-R 1/8 2
. . . . .
506 AF0 190 0004 NUT, HEXAGON, PREVAILING TORQUE M8 2
. . . . .
573 AF0 230 0005 WASHER, PLAIN, NORMAL M8 2

550 031 37 eD
147 (157) HEAD, BOOM / RIGHT, SB40 200824
23 22 12 4 5 22 35
35 13
35
20
10
14 15 17 16 21 23 11
794 553
1 550 748 550 749 2
3
26
555
34

550 031 37 eD
200824 HEAD, BOOM / RIGHT, SB40 148 (157)

e
1 BG 004 571 43 FRAME SECTION 7 PAGE 149 1
2 BG 004 569 84 SWING PIECE SECTION 7 PAGE 71 1
4 323 058 88 SHAFT L=350 1
5 207 906 08 SHAFT L=242 1
. . . . .
10 207 939 08 COVER 1
11 207 908 58 COVER 1
12 264 383 68 COVER 1
14 207 959 28 SHIM 0,3 2
. . . . .
15 207 958 08 SHIM 0,1 2
16 207 969 38 SHIM S=0,3 2
17 207 968 08 SHIM S=0,1 2
20 873 457 49 SEAL, V 115-125 3
21 879 026 39 SEAL, V 93-98 W6 2
. . . . .
22 800 118 39 O-RING 79.5x3.00 2
23 522 450 80 O-RING 119.5x3.00 3
35 572 102 40 NIPPLE, GREASE AR 1/8 3
. . . . .
. . . . .

BG 004 571 43 bB
149 (157) FRAME / RIGHT, TB40 200824
3 2 3

e
1 550 023 81 FRAME 1
2 264 334 48 BUSHING D100 d85 L50 2

551 599 73 aAa
151 (157) FEED ASSEMBLY / 16', IMP.SYL, TF500, RD5XX. RIGHT 200824
328 556
553 201
21
518
35 555
590
262
1 555 285
24 601 26 553
45
42 205
41
518
38 590
555
555 281
518
518
38
2
44
218
512
553 41 43
3
600
33
205
27 29 553
553
28
22 202
39
173
552 553 37 299 518 590

551 599 73 aAa
200824 FEED ASSEMBLY / 16', IMP.SYL, TF500, RD5XX. RIGHT 152 (157)

e
1 344 495 04 FEED BEAM ASSEMBLY SECTION 7 PAGE 101 1
2 550 829 49 CYLINDER SECTION 7 PAGE 104 1
21 325 321 68 CENTRALIZER, FRONT SECTION 7 PAGE 113 1
. . . . .
22 551 861 40 ASSEMBLY SECTION 7 PAGE 116 1
24 263 685 98 CENTRALIZER, TRAVELLING SECTION 7 PAGE 117 1
26 325 124 98 PLATE Travelling centralizer 1
27 551 000 70 PLATE 1
28 263 375 08 FRAME, SLIDE L=250 2
. . . . .
33 209 600 78 SIGN Type explanation, components 1
35 551 592 41 BRACKET 1
37 207 752 88 HEXAGON HEAD BOLT M12 1
38 209 027 18 SCREW, RETAINER 7
. . . . .
41 550 123 95 FRAME 2
42 331 435 08 BRACKET 2
43 332 767 78 CYLINDER, IMPULSE SECTION 7 PAGE 112 2
44 BG 008 674 65 HOSE SUPPORT ASSEMBLY SECTION 7 PAGE 118 1
. . . . .
45 331 436 28 FRAME, SLIDE 2
. . . . .
THREAD
THREAD
THREAD
THREAD
. . . . .
THREAD
METAL
METAL
. . . . .
600 455 332 90 SCREW 2X5 4
. . . . .

551 599 73 aAa
153 (157) FEED ASSEMBLY / 16', IMP.SYL, TF500, RD5XX. RIGHT 200824
A
ADAPTER PLACE
WHEN USING HLX5 DRILL
ADAPTER PLACE
WHEN USING RD5XX DRILL
205 553
36 A
518 590 299
328 556
23
30 560
104 556
100
31 29 45 590 518 281 101 173 552
555 601 42 39 552 173

SECTION A - A

551 599 73 aAa
200824 FEED ASSEMBLY / 16', IMP.SYL, TF500, RD5XX. RIGHT 154 (157)

e
23 325 116 38 FRAME, REAR 1
30 289 221 28 NUT Sleeve nut 1
31 331 341 78 BRACKET 1
36 207 568 08 PLATE 1
. . . . .
42 331 435 08 BRACKET 2
45 331 436 28 FRAME, SLIDE 2
101 551 501 27 DAMPER, HOLE MOUNT 1
. . . . .
THREAD
THREAD
THREAD
. . . . .
METAL
. . . . .

BG 012 346 41 a
155 (157) HOSE KIT / HOSE BUNDLE, SB40NV BOOM HOSES, CENTRAL GREASING 200824

e
51 550 968 06 SUPPORT, HOSE D=90/90 1
. . . . .
55 807 695 29 STRAP L=400 Black 10

BG 012 351 55 a
200824 HOSE KIT / HOSE BUNDLE, SB40 PERCUSSION HOSES, RIGHT 156 (157)

e
59 807 695 29 STRAP L=400 Black 10

BG 013 789 63 a
157 (157) HOSE KIT / HOSE BUNDLE, SB40 DRILLING HOSES, TF, SLU, IMP 200824

e
23 BG 011 661 64 HOSING SET SECTION 5 PAGE 68 1
. . . . .
55 807 695 29 STRAP L=400 Black 10
. . . . .

Drilling Module

Uploaded by

Document Information

Original Title

Copyright

Available Formats

Share this document

Share or Embed Document

Sharing Options

Did you find this document useful?

Is this content inappropriate?

Copyright:

Available Formats

Drilling Module

Uploaded by

Copyright:

Available Formats

DRILLING MODULE

Sandvik Mining and Construction Oy Drills Tampere © 2020

*** 550 041 24 HYDRAULIC CYLINDER, DOUBLE-ACTING.......................................................................................................... 94

Sandvik Mining and Construction Oy Drills Tampere © 2020

Sandvik Mining and Construction Oy Drills Tampere © 2020

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2020

HYDRAULIC ROCK DRILL RD520

Sandvik Mining and Construction Oy Drills Tampere © 2020

Sandvik Mining and Construction Oy Drills Tampere © 2020

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2020

Sandvik Mining and Construction Oy Drills Tampere © 2020

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2020

Sandvik Mining and Construction Oy Drills Tampere © 2020

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2020

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2020

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2020

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2020

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2020

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2020

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2020

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2020

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2020

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2020

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2020

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2020

Sandvik Mining and Construction Oy Drills Tampere © 2020

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2020

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2020

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2020

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2020

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2020

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2020

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2020

Sandvik Mining and Construction Oy Drills Tampere © 2020

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2020

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2020

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2020

Ref. Part no. Description EN Standard designation Qty
