Machine Drawing Assignments in AutoCAD

Machine Drawing
(PC-ME 592)
3rd Year 5th Semester
AutoCAD Assignments
Hooghly Engineering and Technology College

Vivekananda Road, Pipulpati, Hooghly – 712103
Department of Mechanical Engineering

Mechanical Engineering Department
Machine Drawing (PC-ME 592)
AutoCAD
COMPUTERAIDED DRAWING (AutoCAD 2011)
With the help of special software drawing or drafting can be done using computers.
The process of constructing the drawings on the computer screen is called computer
aided drafting(CAD). The drawings in CAD are clearer and more exact than manual
drawings. AutoCAD is a particular CAD software where the user enters the data in
command form which is then converted into graphics.
The window of AutoCAD contains the following:

1. Pull down Menu bar. 2. Standard tool bar. 3. Draw tool bar
4. Modify tool bar 5. Layer tool bar 6. Properties toolbar
7. Drawing Area 8. Crosshair cursor 9. Command line
10. Command window 11. UCS Icon 12. Status bar
AutoCAD window with drawing area (Model Space) background white
1
AutoCAD
COMMANDS:
DRAW TOOLBAR OR DRAW MENU ON MENU BAR:
LINE
A line is drawn by joining two points. The point input can be given by entering the
Cartesian coordinates or the polar coordinates in absolute (points specified by
position with respect to origin) or relative (next point specified with respect to the
previous point) mode.
Click on the Line icon in the draw toolbar
or Menu → Draw → Line,
or Command: line or l
Specify first point: Click on any point
Specify next point or [Undo]: Click on another point
Specify next point or [Undo]: Click on another point
…………………………………………….
Specify next point or [Undo]: Press ESC or Space or  to leave command.
 To draw a line from a specified point to another specified point
Cartesian Coordinates in Absolute Mode (X,Y coordinates)
Specify first point: specify X,Y (for e.g. 50,100)
Specify next point or [Undo]: specify X,Y (for e.g. 100,100)
…………………………………………
Polar Coordinates in Absolute Mode (angle  is measured from +ve X axis in
anticlockwise direction, L is the distance from origin)
Specify first point: specify L< (for e.g. 50<60)
Specify next point or [Undo]: specify L< (for e.g. 100<45)
…………………………………………
Cartesian Coordinates in Relative Mode (X,Y coordinates)
Specify first point: Click on any point or specify X,Y or X<
Specify next point or [Undo]: @X,Y (for e.g. @100,50) i.e. a point 100 mm to
the left and 50 mm above of the first point
…………………………………………
Specify next point or (Undo):Press ESC or Space or  to leave command.
 To draw a line with a given length and a given angle
Polar Coordinates in Relative Mode (angle  is measured from +ve X axis in
anticlockwise direction)
Specify first point: Click on any point or specify L< or X,Y
Specify next point or [Undo]: @L< (for e.g. @100<45) i.e. a line emanating
from the first point with a length of 100 mm and inclined at 45˚ with +ve X
axis.
…………………………………………
2
AutoCAD
RECTANGLE
Click on the Rectangle icon in the draw toolbar
or Menu → Draw → Rectangle
or Command : Rectang
Specify first corner point or [Chamfer/Elevation/Fillet/Thickness/Width]:
Click on any point or specify X,Y
Specify other corner point or [Area/Dimensions/Rotation]: Click on another
point or specify X,Y
To draw a rectangle with given length and width
Click on any point
Specify other corner point or [Area/Dimensions/Rotation]: d
Specify length for rectangles: length value (for e.g. 80 for 80 mm length)
Specify width for rectangles: width value
Specify other corner point or [Area/Dimensions/Rotation]: Click on the
particular side where you want the rectangle
To draw a rectangle with chamfered (beveled) corners
Specify first corner point or [Chamfer/Elevation/Fillet/Thickness/Width]: c
Specify first chamfer distance for rectangles: value(for e.g. 10for 10 mm)
Specify second chamfer distance for rectangles: value
Proceed as above
Similarly type ‘f’ for fillet, ‘w’ for line width etc and follow the prompt.
POLYGON
Click on the Polygon icon in the draw toolbar
or Menu → Draw → Polygon
or Command : Polygon or pol
To draw a polygon with given no. of sides and given length of a side
No. of sides: value(for e.g. 5 for a pentagon)
Specify centre of polygon or [Edge]: e
Specify first end point of edge: Click on any point or specify X,Y
Specify second end point of edge: You can either click on another point or
give coordinates or use line command to draw an edge with a given length and
given inclination (for e.g.@30<0).
To draw a polygon with given no. of sides which is inscribed in or circumscribed about a
circle with a specific centre and given radius
No. of sides: value
Specify centre of polygon or [edge]: click on any point or specify X,Y
Enter an option [Inscribed in circle/Circumscribed about circle]: i or c
Specify radius of circle: value (for e.g. 40 for 40 mm radius)
3
AutoCAD
CIRCLE
Click on the Circle icon in the draw toolbar
or Menu → Draw → Circle
or Command: circle or c
To draw a circle with a given centre and a given radius or diameter
Specify centre point for circle or [3P/2P/Ttr (tan tan radius)]: Click at
any point or give X,Y coordinates
Specify radius of circle or [Diameter]: value
or Specify radius of circle or [Diameter]: d (for diameter)
Specify diameter of circle: value
To draw a circle passing through 3 given points
Specify centre point for circle or [3P/2P/Ttr (tan tan radius)]: 3p
Specify first point on circle: Click at any point or specify X,Y
Specify second point on circle: Click at any point or specify X,Y
Specify third point on circle: Click at any point or specify X,Y
Similarly use the 2P option and specify the ends of a diameter.
To draw a circle with two given lines as tangents and a given radius
First draw two lines inclined to each other using line command.
Specify centre point for circle or [3P/2P/Ttr (tan tan radius)]: ttr
Specify point on object for first tangent of circle: Click on any of the two
lines
Specify point on object for second tangent of circle: Click on the other
line
Specify radius of circle: value
ARC (part of a circle)

Click on the arc icon in the draw toolbar
or Menu → Draw → Arc
or Command: arc or a
To draw an arc with given start point, second point and end point
Specify start point of arc or [center]: click at any point or specify X,Y
Specify second point of arc or [center/end]: click at another point or
specify X,Y
Specify end point of arc: click at another point or specify X,Y
To draw an arc with given start point, centre and end point
Specify second point of arc or [center/end]: c
Specify centre point of arc: click at any point or specify X,Y
Specify end point of arc or [Angle/chord Length]: click at any point or
specify X,Y
To draw an arc with given start point, centre and included angle or alternatively centre, start
point and included angle
Specify second point of arc or [center/end]: c
4
AutoCAD
Specify end point of arc or [Angle/chord Length]: a

Specify included angle: value (for e.g. 120)
To draw an arc with given start point, centre and chord length or alternatively centre, start
point and chord length
Specify start point of arc or [center]: c
Specify start point of arc: click at any point or specify X,Y
Specify end point of arc or [Angle/chord Length]: l
Specify length of chord: value
To draw an arc with given start point, end point and included angle/ direction of tangent at
start point/ radius
Specify second point of arc or [center/end]: e
Specify end point of arc: click at any point or specify X,Y
Specify center point of arc or [Angle/Direction/Radius]: a
Similarly the radius can be given by typing ‘r‘or direction of tangent (angle)
at start point can be given by typing ‘d’.
Specify included angle: value
ELLIPSE
Click on the arc icon in the draw toolbar
or Menu → Draw → Ellipse
or Command : ellipse or el
To draw an ellipse with given endpoints or length of an axis and given end or half length of
the other axis
Specify axis endpoint of ellipse or [Arc/Center]: click at any point or
specify X,Y
Specify other endpoint of axis: click at any point or specify X,Y or specify
axis length and direction (for e.g. @80<0)
Specify distance to other axis or [Rotation]: click at any point or specify
X,Y or specify axis half length and direction (for e.g. @30<90)
To draw an ellipse with given centre, given end or half length of major axis and rotation
Specify axis endpoint of ellipse or [Arc/Center]:
c
Specify center of ellipse: click at any point or
specify X,Y
Specify endpoint of axis: click at any point or
specify X,Y or specify axis half length and
direction (for e.g. @25<0)
Specify distance to other axis or [Rotation]: r
Specify rotation around major axis: value (for
e.g. 60)
To draw an elliptical arc with given endpoints or length of an axis, given end or half length of
the other axis, given starting angle of arc and given end angle of arc/ included angle
Specify axis endpoint of ellipse or [Arc/Center]: a
Specify axis endpoint of elliptical arc or [Center]: click at any point or
specify X,Y
5
AutoCAD
Specify other endpoint of axis: click at any point or specify X,Y or specify
axis length and direction (for e.g. @80<0)
Specify distance to other axis or [Rotation]: click at any point or specify
X,Y or specify axis half length and direction (for e.g. @30<90)
Specify start angle or [Parameter]: value (for e.g. 30)
Specify end angle or [Parameter/Included angle]: value (for e.g. 210)
Included angle may also be given by typing ‘i’.
POLY LINE (PLINE)

Polyline (or pline) is a curve consisting of line segments and/or arcs of same or
variable line thickness. This command operates like the line command but has more
options and unlike the line command, where different line segments are taken as
different objects, the whole curve is counted as one object.
Click on the Polyline icon in the draw toolbar
or Menu → Draw → polyline
or Command : pline or pl
To draw a polyline curve of variable width consisting of lines and arc
Specify start point: click at any point or specify X,Y
Current line-width is 0.0000
Specify next point or [Arc/Halfwidth/Length/Undo/Width]: w
Specify starting width <0.0000>: value (for e.g. 0)
Specify ending width <0.0000>: value (for e.g. 0.1)
Specify next point or [Arc/Halfwidth/Length/Undo/Width]: click at any point
or specify X,Y or specify length and direction (for e.g. @100<0)
Specify next point or [Arc/Close/Halfwidth/Length/Undo/Width]: h
Specify starting half-width <0.0500>: value (for e.g. 0.05)
Specify ending half-width <0.0500>: value (for e.g. 0.1)
Specify next point or [Arc/Close/Halfwidth/Length/Undo/Width]: click at any
point or specify X,Y or specify length and direction (for e.g. @50<90)
Specify next point or [Arc/Close/Halfwidth/Length/Undo/Width]: a
Specify end point of arc or
[Angle/Center/Close/Dirction/Halfwidth/Line/Radius/Second pt/Undo/Width]: w
Specify starting width <0.2000>: value (for e.g. 0.2)
[Angle/Center/Close/Dirction/Halfwidth/Line/Radius/Second pt/Undo/Width]:
click at any point or specify X,Y or specify length and direction (for e.g.
@50<180)
[Angle/Center/Close/Dirction/Halfwidth/Line/Radius/Second pt/Undo/Width]: l
Specify next point or [Arc/Close/Halfwidth/Length/Undo/Width]: h
Specify starting half-width <0.2000>: value (for e.g. 0.2)
Specify ending half-width <0.2000>: value (for e.g. 0.1)
Specify next point or [Arc/Close/Halfwidth/Length/Undo/Width]: w
6
AutoCAD

Specify next point or [Arc/Close/Halfwidth/Length/Undo/Width]: w
Specify ending width <0.1000>: value (for e.g. 0)
Specify next point or [Arc/Close/Halfwidth/Length/Undo/Width]: c
SPLINE
A spline is a smooth curve that passes through or near a given set of points. This command
creates a smooth curve that passes through fit points or near control vertices.
Click on the Spline icon in the draw toolbar
or Menu → Draw → spline
or Command : spline
TEXT
To write text on the drawing text or mtext command is used. Text command creates
single line text object. Mtext command creates multiline text paragraph, using Text
Formatting dialog box and in place text editor, where font typeface, font style, font size
etc. can be edited.
Menu → Draw → Text→ Single Line Text
or Command: text
Click on the MultilineText Icon in the draw toolbar

Menu → Draw → Text→ Single Line Text
or Command: mtext or mt or t
In Text Formatting dialog box that appears after the last command one can choose
from the various options given. You can also change the size of the text area by
moving the ruler head. Click the OK button when finished.
MODIFY TOOLBAR OR MODIFY MENU ON MENU BAR:
Object Selection: Objects need to be selected to modify them. When any modify
command is applied the crosshair cursor changes to a square cursor and one have to
click on an object or use selection window to select it.
In general AutoCAD selection windows are of two types – crossing window and
box. While selecting objects if the cursor is moved from right to left you get a
crossing window (highlighted by green colour) which selects the objects that it
crosses. If the cursor is moved from left to right you get a box (highlighted by blue
colour) which selects the objects that it encloses. The selected objects show blue
coloured square boxes (called grips) on them.
7
AutoCAD
ERASE
Click on the Erase icon on the modify toolbar
or Menu → Modify → Erase
or Command : erase or e
Select objects: Select any of the objects to be erased by clicking on that
object or select all of them using selection window
Select objects: 
MOVE
By move command an object is shifted permanently from one position to another.
Click on the Move icon on the modify toolbar
or Menu → Modify → Move
or Command : move or m
Select objects: Select any of the objects to be moved by clicking on that
object or select all of them using selection window
Select objects: 
Specify Base point or [Displacement] <Displacement>: Click at any point on
the selected object/objects
Specify second point or <use first point as displacement>: click at another
point or specify X,Y or specify distance and direction (@X<)
COPY
Click on the Copy icon on the modify toolbar
or Menu → Modify → Copy
or Command: copy or co
Select objects: Select the objects to be copied one by one by clicking on
those objects or select all of them using selection window
Select objects: 
Specify Base point or [Displacement] <Displacement>: Click at any point on
the selected object/objects
Specify second point or <use first point as displacement>: click at another
point or specify X,Y or specify distance and direction (@L<)
Specify second point or [Exit/Undo] <Exit>: Proceed as above
……………………………………………make as many copies as you want
Specify second point or [Exit/Undo] <Exit>: 
OFFSET
Offset command creates a new object parallel to the original object. The distance
between the original object and new object is called offset distance.
Click on the Move icon on the modify toolbar
or Menu → Modify → Offset
or Command : offset or o
8
AutoCAD
Specify Offset distance or [Through/Erase/Layer] <through>: value

Select object to offset or [Exit/Undo] <Exit>: click on the object
Specify point on side to offset or [Exit/Multiple/Undo] <Exit>: click on the
left/right or above/below or inside/outside of the selected object
Select object to offset or [Exit/Undo] <Exit>:  to exit or click on the
object and proceed as above
TRIM
If an object is divided into many parts by other intersecting objects then trim
command is used to delete selected intersected parts of that object.
Click on the Trim icon on the modify toolbar
or Menu → Modify → Trim
or Command : trim or tr
Select objects or <select all>:  to select all or choose objects that
define the cutting edges at which you want to trim other objects
Select object to trim or shift-select to extend or
[Fence/Crossing/Project/Edge/eRase/Undo]: click on that portion of the
object which you want to trim
Select object to trim or shift-select to extend or
[Fence/Crossing/Project/Edge/eRase/Undo]: repeat above procedure
……………………………………until all parts are trimmed and then type ‘’ to exit
EXTEND
The extend command extends an object to meet a particular reference object called
boundary edge.
Click on the Extend icon on the modify toolbar
or Menu → Modify → Extend
or Command : extend or ex
Select objects or <select all>:  to select all or choose objects that
define the extents up to which you want to extend other objects
Select object to extend or shift-select to trim or
[Fence/Crossing/Project/Edge/Undo]: click on an object to be extended
Select object to extend or shift-select to trim or
[Fence/Crossing/Project/Edge/Undo]: repeat above procedure
……………….until all intended objects are extended and then type ‘’ to exit
MIRROR
Mirror command creates a mirror image of an object with respect to a mirror line.
Click on the Mirror icon on the modify toolbar
or Menu → Modify → Mirror
or Command: mirror or mi
Selects objects: Select the objects to be copied one by one by clicking on
those objects or select all of them using selection window
Select objects: 
9
AutoCAD
Specify first point of mirror line: click on any point or specify X,Y
Specify second point of mirror line: click on another point or specify X,Y
or specify length and direction (@L<)
Erase source objects? [Yes/No] <No>: 
CHAMFER
Chamfer command is used to bevel the corners of an object thereby removing sharp
corners with angled lines.
Click on the Chamfer icon on the modify toolbar
or Menu → Modify → Chamfer
or Command : chamfer or cham
Select first line or [Undo/Polyline/Distance/Angle/Trim/mEthod/Multiple]: d
Specify first chamfer distance <0.0000>: value (for e.g. 15 for 15 mm)
Specify second chamfer distance <15.0000>: value
Select first line or [Undo/Polyline/Distance/Angle/Trim/mEthod/Multiple]:
click on a line
Select second line or shift-select to apply corner: click on the other line
that forms a corner with first line
FILLET
Fillet command is used to join two objects by a tangential arc. Radius option helps to
set the radius of fillet arc.
Click on the Fillet icon on the modify toolbar
or Menu → Modify → Fillet
or Command : fillet or f
Select first object or [Undo/Polyline/Radius/Trim/Multiple]: r
Specify fillet radius <0.0000>: value (for e.g. 15 for 15 mm radius)
Select first object or [Undo/Polyline/Radius/Trim/Multiple]: click on a line
Select second object or shift-select to apply corner: click on the other
line that forms a corner with first line
CHANGING THE PROPERTIES:

The properties (Colour, Linetype, Lineweight) of the object can be changed using the
Properties toolbar. Select the object, open the color control or linetype control or
lineweight control combo box and select the required option.
Alternatively you can use: Menu → Format → Color (to open Select Color dialog
box) or Menu → Format → Linetype (to open Linetype Manager dialog box) or
Menu → Format → Lineweight (to open Lineweight Settings dialog box).
Select Color dialog box, linetype Manager dialog box and Lineweight Settings
dialog box may also be opened by using commands: color, ltype and lweight
respectively.
10
AutoCAD
To see the chosen lineweight, turn on LWT button on Status bar. You may need to
change Linetype scale to see the chosen linetype properly by using the command:
ltscale (it enables you to set a new linetype scale factor).
The properties of the object can also be changed using Properties palette. The palette
may be made visible by any of the following ways:
Click on the Properties icon in the Standard toolbar
or Menu → Tools → Properties
or double click on the object
or select the object then right click and select Properties from shortcut menu
or Command: properties or props or mo or ch
The Properties palette lists the current settings for properties of the selected object or
set of objects. When more than one object is selected, the Properties palette displays
only those properties common to all objects in the selection set. You can modify any
property that can be changed by specifying a new value.
DIMENSIONING:
Dimensioning is very easy in AutoCAD. Length of a line, radius/diameter of an arc
or a circle and angle between lines are automatically calculated.
DIMSCALE
It is a system variable that sets the overall scale factor applied to dimensioning
variables that specify sizes, distances, or offsets.
Command: dimscale
Enter new value for DIMSCALE <1.0000>: value (for e.g. 20)
DISPLAY COMMANDS:
ZOOM
Menu → View → Zoom→Preset options
or Command : zoom or z
Specify corner of window, enter a scale factor (nX or nXP), or
[All/Center/Dynamic/Extents/Previous/Scale/Window/Object] <real time>:click
at any point
Specify opposite corner:click at second point
or Specify corner of window, enter a scale factor (nX or nXP), or
[All/Center/Dynamic/Extents/Previous/Scale/Window/Object] <real time>:value
Or Specify corner of window, enter a scale factor (nX or nXP), or
[All/Center/Dynamic/Extents/Previous/Scale/Window/Object] <real time>: give
the required option (for e.g. a for zoom all)
ZOOM Realtime increases or decreases the apparent size of objects in the
current viewport. If the cursor is dragged upwards magnification increases
and if it is dragged downward magnification decreases.
ZOOM All displays either the user-defined grid limits or the drawing extents,
whichever view is larger.
11
AutoCAD
ZOOM Previous returns you quickly to the prior view.

ZOOM Window zooms to display an area specified by two opposite corners of
a rectangular window.
Specify first corner: Specify a point (1)
Specify opposite corner: Specify a point (2)
PAN
Menu → View → Pan → Preset options
Command: Pan or P
The cursor changes to a hand cursor. Left click the mouse, hold and drag the cursor.
The cursor is locked in its current location relative to the view port co-ordinate
system and the display screen moves in the same direction as the cursor.
REDRAW
Command: redraw or r
During the drawing and editing process, an operation may cause an object to
partially disappear. Redraw refreshes the display in the current viewport and
restore such obscured objects.
REGENERATE
Command: regen (regenauto to turn on or off automatic regeneration of drawing)
Regen command is used to regenerate the entire drawing and recomputed screen
coordinates for all objects in the current viewport. It corrects the geometry of the
zoomed circles/arcs, removes marker blips (point marks) and restores the point
sizes. Regen command may be used after zoom command.
STATUS BAR BUTTONS:
The status bar displays the coordinate values of the cursor and drawing tools in the
form of buttons. Tools can be turned on or off by clicking on the buttons on the
status bar.
Grid display button: Grid creates a rectangular pattern of dots or lines that
covers the drawing area. The grid serves as a reference to align objects and to
visualize the distances.
Object snap button : Object snap is used to specify precise locations on objects
such as end points of lines or centre of circle etc. During a draw command,
when the curser moves over an existing object snap markers are displayed.
Ortho mode button: Ortho mode compels the cursor to draw only horizontal
or vertical lines. If isometric snap is on then the cursor draws lines only along
isometric axes.
Dynamic input button: Dynamic input provides a command interface near
the cursor to help in keeping the focus on drafting area. Tooltips display
information which is dynamically updated as cursor moves.
12
AutoCAD
AutoCAD 2011
SHORTCUT KEYS
F1 Displays Help
F2 Toggles Text Window
F3 Toggles OSNAP
F4 Toggles TABMODE
F5 Toggles ISOPLANE
F6 Toggles UCSDETECT
F7 Toggles GRIDMODE
F8 Toggles ORTHOMODE
F9 Toggles SNAPMODE
F10 Toggles Polar Tracking
F11 Toggles Object Snap Tracking
F12 Toggles Dynamic Input
Esc To cancel any command
COMMAND SHORTCUTS
A *ARC OP *OPTIONS
AR *ARRAY ORBIT *3DORBIT
B *BLOCK OS *OSNAP
-B *-BLOCK P *PAN
BH *HATCH PE *PEDIT
BR *BREAK PL *PLINE
C *CIRCLE PO *POINT
CH *PROPERTIES POL *POLYGON
-CH *CHANGE PR *PROPERTIES
CHA *CHAMFER PROPS *PROPERTIES
COL *COLOR PRINT *PLOT
CO *COPY PYR *PYRAMID
CP *COPY QC *QUICKCALC
CYL *CYLINDER QCUI *QUICKCUI
D *DIMSTYLE R *REDRAW
DAL *DIMALIGNED RA *REDRAWALL
DAN *DIMANGULAR RE *REGEN
DAR *DIMARC REA *REGENALL
JOG *DIMJOGGED REC *RECTANGLE
DBA *DIMBASELINE REG *REGION
DBC *DBCONNECT REV *REVOLVE
DC *ADCENTER RO *ROTATE
DCE *DIMCENTER RR *RENDER
DCENTER *ADCENTER RW *RENDERWIN
DCO *DIMCONTINUE S *STRETCH
DCON *DIMCONSTRAINT SC *SCALE
DDA *DIMDISASSOCIATE SEC *SECTION
13
AutoCAD
DDI *DIMDIAMETER SL *SLICE

DED *DIMEDIT SN *SNAP
DJL *DIMJOGLINE SO *SOLID
DJO *DIMJOGGED SPL *SPLINE
DLI *DIMLINEAR SPLANE *SECTIONPLANE
DO *DONUT SU *SUBTRACT
DOR *DIMORDINATE T *MTEXT
DOV *DIMOVERRIDE TEDIT *TEXTEDIT
DR *DRAWORDER TH *THICKNESS
DRA *DIMRADIUS TOR *TORUS
DS *DSETTINGS TR *TRIM
DST *DIMSTYLE UC *UCSMAN
DT *TEXT UN *UNITS
E *ERASE UNI *UNION
EL *ELLIPSE V *VIEW
EX *EXTEND WE *WEDGE
EXIT *QUIT X *EXPLODE
EXT *EXTRUDE Z *ZOOM
F *FILLET
G *GROUP
GD *GRADIENT
H *HATCH
HE *HATCHEDIT
HB *HATCHTOBACK
HI *HIDE
I *INSERT
IN *INTERSECT
J *JOIN
L *LINE
LA *LAYER
LINEWEIGHT *LWEIGHT
LO *LAYOUT
LS *LIST
LT *LINETYPE
LTYPE *LINETYPE
LTS *LTSCALE
LW *LWEIGHT
M *MOVE
ME *MEASURE
MEA *MEASUREGEOM
MI *MIRROR
MO *PROPERTIES
MT *MTEXT
O *OFFSET
14
AutoCAD
Assignments
2 D Drawings
Simple 2D Figures
Problem 1 Problem 2
Problem 3 Problem 4
Problem 5 Problem 6
15
AutoCAD
Development
Problem 1: A cylinder of base 40 mm diameter and 55 mm long axis is resting on its
base on H.P. It is cut by a section plane perpendicular to the V.P. and inclined at an
angle of 45 to the H.P. intersecting the axis at a distance 35 mm above base. Draw
the development of surfaces of the cut solid.
Problem 2: Develop the lateral surfaces of a pentagonal pyramid of base edges 30

mm and height 60 mm, resting on its base on H.P.
16
AutoCAD
Problem 3: Develop the surface of a truncated cone of 40 mm diameter base and

height 60 mm, resting on its base on H.P. It is cut by a cutting plane perpendicular to
the V.P. and inclined at an angle of 45 to the H.P., intersecting the axis 35 mm above
the base.
Section
Problem 1: A hexagonal pyramid of base 30 mm side, axis 70 mm long is resting on
its base on H.P. with two edges parallel to the V.P. It is cut by a cutting plane
perpendicular to the V.P. and inclined at an angle of 45 to the H.P. intersecting the
axis at a distance 25 mm above the base. Draw front view, sectional top view,
sectional side view and true shape of the section.
17
AutoCAD
Problem 2: A cone, base 50 mm Problem 3: A cone, base 50 mm

diameter and axis 60 mm long is diameter and axis 65 mm long, rests
resting on its base on H.P. It is cut by with its base on H.P. It is cut by a section
a vertical section plane inclined at an plane perpendicular to V.P. inclined at
angle of 60° to the V.P. The plane is 45⁰ to H.P. and passing through a point
passing through a point 8 mm away on the axis 35 mm above the base. Draw
from the axis of the cone in the top the sectional top view and the true
view. Draw top view, sectional front shape of the section.
view and true shape of the section.
Machine parts:
Problem1 Problem 2
Knuckle Joint Hook
18
AutoCAD
Problem 3
3 D Drawings
Simple Solids
Problem 1 Problem 2
Problem 3 Problem 4
19
AutoCAD
Machine Parts
Problem 1: Problem 2:
20
AutoCAD
21
AutoCAD
Problem 9:
Problem 10:
22

Machine Drawing Assignments in AutoCAD

Uploaded by

Document Information

Original Title

Copyright

Available Formats

Share this document

Share or Embed Document

Sharing Options

Did you find this document useful?

Is this content inappropriate?

Copyright:

Available Formats

Machine Drawing Assignments in AutoCAD

Uploaded by

Copyright:

Available Formats

Machine Drawing

Hooghly Engineering and Technology College

Department of Mechanical Engineering

COMPUTERAIDED DRAWING (AutoCAD 2011)

The window of AutoCAD contains the following:

AutoCAD window with drawing area (Model Space) background white

ARC (part of a circle)

Specify end point of arc or [Angle/chord Length]: a

POLY LINE (PLINE)

Specify next point or [Arc/Close/Halfwidth/Length/Undo/Width]: click at any

Click on the MultilineText Icon in the draw toolbar

MODIFY TOOLBAR OR MODIFY MENU ON MENU BAR:

Specify Offset distance or [Through/Erase/Layer] <through>: value

CHANGING THE PROPERTIES:

ZOOM Previous returns you quickly to the prior view.

DDI DIMDIAMETER SL SLICE

Problem 2: Develop the lateral surfaces of a pentagonal pyramid of base edges 30

Problem 3: Develop the surface of a truncated cone of 40 mm diameter base and

Problem 2: A cone, base 50 mm Problem 3: A cone, base 50 mm

Knuckle Joint Hook

You might also like
