"""'" -­ Pr imary standard liquid column Manometer are used for precision

-
measurement of Pressure, Vacuum & Differential Pressure
Where certain accuracy is required

U-Tube Manometers
!Manometers have 'U' shaped tube, half filled with Liquid (Water or Mercury). When both the tubes are open, the liquid is at
the same height in each leg. When positive pressure is applied to one leg the liquid is forced down in that leg and up in the

S
other.The difference in the height, which is the sum of the reading above and below zero, tells you the pressure. When
Vacuum is applied to one Leg, the liquid rises in that leg and falls in the other. The difference in the height indicates the

SE
amount of Vacuum.

Model : UTM/MG/110 Model : UTM/WB/109

10 TA RI
Consisting of two Glass limbs. Stainless Steel !General purpose U Tube Manometer,
Connecting fitting mounted on a metallic frame, mounted on best quality PINE wood, with
provided with White Acrylic Scale with zero at 'U' bend Glass Tube fitted with clamps.
83 KA RP
the centre. Manometers are protected with
transparent front cover and fixed with an Range in mm
50-0-50

1
Aluminium frame. An external 'O' adjustment
knob is provided. 100-0-100

02
1 9 OL TE
150-0-150
SPECIALITY: 200-0-200
No Moving Parts, 250-0-250
Calibration Accuracy, 300-0-300
Zero Adjustments. 500-0-500
37
+9 K N

Range : VAC to 20000 mmWc. 600-0-600

MOUNTING: Wall Mounting, Table (Stand) Mounting and Panel Mounting.
IE

STAND MOUNTED MODEL: Manometer will be provided with C.I.

3 legged Stand, having 3 Nos leveling screw and attached Round Type Bull Eye Spirit Level.

Inclined Tube Manometers

RT

!Inclined Tube Manometer utilize expanded scales for unusual sensitivity for fast and easy reading of Low
pressure,draft of small differential pressure. They are available in simple Standard Models as well as extreme precision inclined
Manometer.
SU

Measuring Range available CUSTOM DESIGNED MANOMETERS

From O to 1000 mmWc,
Inclined cum U Tube
Lease Count: Manometer
0.1,0.2,0.25 and 0.5
depending upon ranges. We design Manometer
as per customers'
requirements and
Any in-between Ranges
will be manufactured on drawings in all standard
Request. /INC/202 measuring units such as
mmWc, mmHg, inWc,
inHg, PSI, BAR
Single Limb Manometers
Single limb well type direct reading manometers are used for precision measurement of pressure, vacuum, differential
pressure, flow and liquid level measurement device used in different process applications. These manometers are
general purpose, direct reading and relatively simple instruments. The well type Single limb manometers are accurate &
dependable as well as highly versatile for many applications. All scales are graduated to correct for the drop in the well level.

Model : SLM/MG/11 5 Model : SLM/WB/116

In general consisting of Stainless Steel fittings, Wooden Board type Single limb Manometers are
Glass limbs mounted on a metallic frame, avalaible for commercial use. Straight Glass limb

S
provide with white acrylic Scale of 1 mm Least is end fitted with Aluminium Blocks. An acrylic

SE
Count, with zero at bottom. Manometer will be direct reading scale and Stainless Steel Reserve
protected with transparent acrylic front cover. Pot is Provided.
MOUNTING : Wall Mounting, Table (Stand) Available in Wall/Table Mounting.
Mounting and Panel Mounting.

10 TA RI
STAND MOUNTED MODEL : Manometer will be Range : From Oto 10000 mmWc
VAC Oto -760 mmHg
provided with C.I. 3 legged Stand, having 3 Nos
Type : Wall / Table Mounting
83 KA RP
leveling screw and attached Round Type Bull Eye
Spirit Level.

1
Arrangements : Fill Plug, Drain Plug, Levelling Screw, Spirit Level, Scale 'O' Adjustment Knob.

02
1 9 OL TE
Acrylic Body Manometers
Acrylic Body Manometers are fabricated from 1" thick solid Acrylic Block.unbreakable, stable & free from distortion.
Acrylic/Aluminium scale, Zero adjustment knob, Drain plug & Panel Mounting holes are provided with the
37
+9 K N

Manometers.

Range in mm INCLINED LIMB

SINGLE LIMB U TUBE
IE

-50 to 100 mmWc

Range in mm Range in mm
Any intermediate
0 -100 50-0-50
range can be
0 - 150 100-0-100
manufactured
0 - 200 150-0-150
RT

with the least

0 - 250 200-0-200
count
0 - 300 250-0-250
of 0.1, 0.2,
0 - 500 300-0-300
0.25, 0.5 mm
SU

Absolute Pressure Manometers Digital Manometers

DIGITAL PRESSURE CUM
VACUUM GAUGE
Anschutz Mc-Lead Gauge
Manometer Model : VCT-525 Range : 0 to 150 PSI
Model : ACZ-530 Battery Operated: 9V
Speciality
Ranges in mm Ranges DATA HOLD, MEMORY BACK UP
100-0-100 10 mm x 0.01 BACK LIGHT.
200-0-200 1 mm x 0.001 UNITS : bar,mbar,psi,inHg,
mmHg,Kg/cm2 ,inH 20

Manufactured By :
SURTI ENTERPRISES
23 CANNING STREET
KOLKATA 700 001
( M ) +91 98310 37021
