Wiring

2013
EMGRAND X7
Wiring Diagram Manual
This Wiring Diagram Manual Provides 2013 EMGRAND X7 Model
(These models included EX720 and EX725) wiring info rmation.
2013 Geely Automotive Co., Ltd.

All Rights Reserved
Information as of the date of September 2013
Without Written Permission from Geely Automotive Co., Ltd., Any Form or Means (Including, but not Limited to
Electronic Duplicating, Photocopying, Scanning and Recording) of Copying, Storing or Distribution of Any Part or
the Whole Manual Is not Allowed. The Above Statement Is Applicable to All Texts, Diagrams and Tables.
Contents 1
13.1 Wiring Diagram Description ...................................................................................................... ....................... 2
13.2 Mark Symbols .................................................................................................................................................. 6
13.3 Diagnosis and Maintenance Methods and Specification .................................................................................. 8
13.4 Fuse and Relay ............................................................................................................................................... 15
13.5 Layout of Harness and the Connector ............................................................................................................ 26
13.6 Layout of Grounding Points ........................................................................................................................... 69
13.7 Power Configurations..................................................................................................................................... 81
13.8 Wiring Diagram .............................................................................................................................................. 89
13.10 Abbreviation ............................................................................................................................................... 229
EX 7 2013
2 13.1 Wiring Diagram Description
Front wiper
Indoor fuse,
relay box
To windshield
washer
motor
Front wiper motor
Intermittent
control
Washer switch
Front wiper switch
Wiper switch
2013 EX 7
3
Indoor fuse, Indoor fuse,

relay box relay box
Rear washer motor
Rear wiper switch
Rear wiper motor
EX 7 2013
4
1 System name If the guide wire is of two color wire, the first letter
indicates the base color of guide wire and the second
2 Harness connector number; letter indicates the stripe color, and they are separated
The numbering rule of harness connectors in this circuit with “/”.
diagram manual is based on the harness, for example, the For example, the guide wire marked as G/B refers to
number of water temperature sensor harness in engine green base and black strip.
harness is EN23, in which EN refers to harness code and
23 refers to connector serial number. 7. Display the terminal numbers of socket connectors.
Note that the terminal sequences of harness
Codes indicating harness are shown in the following connectors which are connected with each other are
table: of mirror image as shown in the following figure:
Definition Harness name
CA Engine compartment harness
EN Engine harness (3G10A + UMC-US System)
Engine harness (479 Engine + Delphi
ED
System)
Engine harness (479 Engine + UMC-US
EL
System )
IP Instrument panel harness
SO Base plate harness
DR Door harness
RF Inside lamp (ceiling) harness
Notes:
1. The definition of door harness includes four
door harnesses.
2. Base plate harness includes back door and
reversing radar harness.
3. The details of harness connector number refer 8 Number of grounding point. All the grounding
to harness layout diagram. points are indicated with the letter of G. The
3. Component name. details of grounding point positions refer to
grounding point layout.
4. Display the system information related to the circuit
connection. 9 Power type supplying on the fuse
5. The connection between plugs shall be indicated 10 Guide wire contact point:
with fine solid line and covered with grey shade so
as to differ from the physical harness. The physical
harness shall be indicated with heavy solid line, of
which the color is the same with that of actual wire.
Disconnecting cross
6. Display the guide wire color. The color codes are circuit
shown in the following table：
Color code Guide wire color Illustration

B Black
Gr Grey Connecting cross
circuit
Br Brown
L Blue
G Green
R Red
Y Yellow 11 The fuse number consists of fuse code and serial
W White number. The fuse code in engine compartment is EF,
V Violet SF and PF, and indoor fuse code is IF. The fuse
O Orange number details refer to fuse list.
P Pink 12 The relay number is indicated with a single
Lg Grass green English letter. The details refer to relay list.
2013 EX 7
5
13 If the circuit diagram designs differ due to different
vehicle model, engine type or configurations,
indicate with dashed line in the circuit diagram and
describe besides the line.
Left rear Right

reverse rear
lamp reverse
lamp
Sedan Hatch
14 If “8” shape mark is used between circuit lines and

lines, it indicates that this circuit is twisted pair wire
which is mainly used for signal circuit of sensor or
data communication circuit.
15 If the content of a system is so much that its circuit

needs to be indicated in many pages. The start point
of circuit is indicated with and the arrival point
with . If more than one circuits continue in next
page, they will be indicated with letters B, C and so
on. And the rest can be done in the same manner.
EX 7 2013
6 13.2 Mark Symbols
Normally
Ground Battery
closed relay
Temperature Normally
Electric capacity
sensor opened relay
Short splicing SPDT relays Cigarette lighter
Solenoid Resistance Antenna

valve
Common opened
Small load fuse Potentiometer
switch
Middle load Variable Common closed

fuse resistance switch
Big load fuse Ignition coil Double SPDT relays
Heater Knock sensor Ignition switch
2013 EX 7
7
Diode Bulb Twisted pair
Circuit
Photodiode Starter
direction
LED Horn Fan assembly
Motor Clock spring Oxygen sensor
Low speed fan

Limiting switch Airbag
relay B
Safety belt Disconnecting Connecting cross

preloader cross circuit circuit
Electromagnetic
valve
EX 7 2013
13.3 Diagnosis and Maintenance Methods and Specification
8
Fault Diagnosis Process Resumed normal operation. If the fuse is blown, check
all the circuits that jointly use the fuse.
For the electrical circuit fault, check it by following
steps: Voltage Inspection
1 Confirm the faults complained by the customer 1 Create measurement conditions at individual voltage
measurement points.
In order to correctly repair the problem, confirm the fault
phenomenon described by the customer. Carefully For example:
check the relevant components to confirm the fault 1 The ignition switch is on.
phenomenon and then make a record. Disassembling of 2 The ignition switch is on, and the switch SW1 is
the parts is not allowed prior to non-confirmation of the closed.
fault scope or cause. 3 The igniting switch is on, and the switch SW1
is closed and the relay is switched on.
2 Identification of the electrical circuit and cause (Namely the switch SW2 is disconnected.)
analysis 2 Connect the cathode of voltmeter to a grounding
Analyze and judge the whole circuit from the power point with good condition or the cathode terminal of
supply to grounding of the faulty part based on the battery, and then connect the anode of voltmeter to the
electrical circuit of subsystem, and confirm the scheme connector terminal at the point to be measured.
of maintenance and operation. If impossible to confirm The voltage can be detected by a test lamp instead of
the scheme of maintenance and operation, refer to the voltmeter.
description and operation set forth in the maintenance
manual, and understands the operating principle of the
same system. Meanwhile, it is necessary to inspect
other common electrical circuit together with the faulty Connect to ignition switch SW
circuit, such as the common electrical circuit for fuse, IG Terminal
grounding and switch systems. Inspect the common
electrical circuit that is not checked in step 1. If other Fuse
parts in the common circuit operate normally, it indicates
that the fault is in its own circuit; if the parts in the
common circuit fail, it is possible that the fuse or
grounding is faulty.
3 Checkup of the electrical circuit and parts
The circuit diagram should be used together with the Voltmeter
maintenance manual at any time, and making a reference Relay
to the checkup process of electrical circuit and parts
described in the maintenance manual. For the
module-controlled circuit, the parts should be tested by a
diagnosis tester, and an effective fault diagnosis should
be carried out by following a logic and reasonable Electromagn
operating process. By fully making a reference to the etic valve
fault diagnosis process described in the maintenance
manual, begin to check the parts from the most possible
causes and the easiest- to-check parts.
4 Fault maintenance
In case of any fault, refer to the circuit diagram and
description of troubleshooting methods in the Connectivity and Resistance Detection of the
maintenance manual, for example: troubleshooting Electrical Circuit
process in case of poor grounding and 1 Disconnect the battery or electrical connection of
troubleshooting method for harness connector. the measurement point, ensuring no voltage in the
5 Confirmation of operating condition of the electrical circuit to be measured.
circuit 2 Connect the two probes of ohmmeter to both ends of
After the maintenance is finished, confirm that the fault the electrical circuit to be measured.
is eliminated, and check whether all functions have been
2013 EX 7
9
Connect to ignition switch SW

IG Terminal
Resistance
meter Fuse box
Testing lamp
Short circuit to
ground (A)
Short circuit to
ground (B)
Off Off
Testing Relay
lamp
If a diode is contained in the electrical circuit, exchange Short circuit to

the two probes and measure the resistance again. If the ground (C)
cathode probe of ohmmeter is connected to the anode of
diode, and the anode probe is connected to the cathode of Off
diode, the reading of ohmmeter should be close to 0. Electromagn
etic valve
After exchanging the two probes to measure the
resistance again, the reading of ohmmeter should be
close to infinity. In case of meeting the two conditions
above, it indicates that the diode can be operated
normally.
Disconnect Connector
When disconnecting, please press connector, do not pull
out harness.
Resistance Resistance
meter meter Tip: when disconnecting connector, please confirm to
select connector.
Diode Diode Up Up
3 during electrical circuit inspection, it is necessary to

use a voltmeter and ohmmeter with high internal
resistance (above 10KΩ).
Digital meters Press down

Press down
Analog meter
EX 7 2013
10
Short Circuit Inspection
1 Remove the blown fuse, and disconnect all loads of the
fuse.
2 Connect a test lamp to both ends of the blown fuse
box.
3 After setting up the following testing conditions, the
test lamp should be lit.
For example:
1． The ignition switch is on.
2． The ignition switch is on, and the switch SW1
is closed.
3． The igniting switch is on, and the switch SW1
is closed and the relay is switched on.
(Namely the switch SW2 is disconnected.)
4 Disconnect and connect both connectors of the test
lamp, and observe whether the test lamp is lit. The
short circuit point is located between the
measurement point where the test lamp is lit and the
measurement point where the test lamp is not lit.
5 Slightly rock the faulty circuit, and find the short
circuit point.
Warning:
1. Unless necessary, do not open the ECU housing (in
case of contacting with the integrated circuit pins on
the ECU electrical circuit board, it is possible to
damage the integrated electrical circuit due to static
electricity. )
2. When changing the internal mechanism of digital
instrument, ensure that any parts of your body or
clothes do not contact with the pins of spare
integrated electrical circuit.
2013 EX 7
11
Change the Terminal (with Terminal Retainer or Example 1
Secondary Lock Device)
Pull upward the terminal retainer to temporary locking
1 Prepare a special tool for repairing the harness position
terminal.
Tip: use a special tool for terminal repairing or similar
object as shown in the left picture to remove harness Terminal holder
terminal.
2 Disconnect the connector.
Reference：
Holder is in the safety locking position
Chock Terminal holder
Holder is in the temporary locking position

3 Release the secondary lock device of the terminal or
terminal retainer.
1. Release the lock device before releasing the
terminal locking plate and removing the terminal Example 2
from the connector.
Open the secondary lock device.
2. Use a special tool to release the secondary lock
device or terminal retainer.
Example 2 Secondary lock
Note: do not dismantle the terminal retainer from the
device
connector.
Example 1
Tools
Up
Terminal holder
A. Non-water proof connector

Tip: the position where the tool is inserted varies with the
shape of connector, such as the number of the terminals.
Check the position before inserting the tool.
EX 7 2013
12
Clip tab
Tools
Holder is in the safety locking position
Clip tab
B. Water proof connector

Tip: the color of terminal retainer varies with different
connectors.
Holder is in the temporary locking position
For example: (Metric) (Female)
Terminal holder Connector

Black or white Grey
Black or white Dark grey
Grey or white Black Example 2
The terminal retainer cannot be pulled upward.
Example 1
Terminal holder
Tools Example 2
Terminal holder
Tools Tools
Tools
Inserting hole
(Metric) (△mark) (Female)
Press down Press down

(Metric) (Female)
Example 1
The terminal retainer can be pulled upward to Press down the terminal retainer to temporary locking
temporary locking position (upward pull type). position.
Insert the special tool into insertion hole (Y mark) of

the terminal retainer, and pull upward the terminal
retainer to temporary locking position.
Tip: the position where the tool is inserted varies with
the shape of connector, such as the number of the
terminals. Check the position before inserting the tool.
2013 EX 7
13
Holder is in the temporary locking

position
B. Push the secondary lock device to full locking

position.
5 Connect the harness connector.
Holder is in the temporary locking

position
(Metric) (Female)
C. Release the terminal locking plate and pull out the

terminal at backward direction.
Lock plate
Tools Handling Process of Poor Grounding

1. Dismantle the bolt at grounding point.
4 Install the terminal.

A. Insert the terminal.
Tips:
1. Ensure the terminal is correctly aligned with the
socket.
2. Insert the terminal into terminal retainer until the
locking plate locks the terminal.
2. Clean both contact surfaces of grounding copper
3. Insert the terminal retainer into temporary locking ring at harness side (including body side and bolt
position of the connector. side) with a coarse abrasive cloth until the oxide is
fully cleared.
EX 7 2013
14
3.Clean body side grounding point by roving cloth, until

clean out the surface.
4. Installed grounding point harness and fixing bolt, and

tighten by specified torque
Torque: M6 bolt: 8 Nm
Bolt: 20Nm
2013 EX 7
15
13.4 Fuse & Relay
13.4.1. Engine C om p artm ent Fuse & Relay
Engine Compartment Fuse and Relay Box
M ain fuse EF40
NL13-04006
2013 GX7
16
Internal Wiring Diagram of Engine Compartment Fuse, Relay Box
EX7 2013
17
Internal Wiring Diagram of Engine Compartment Fuse, Relay Box (Continued 1)
2013 EX7
18
Internal Wiring Diagram of Engine Compartment Fuse, Relay Box (Continued 2)
EX7 2013
19
Fuse List of Engine Compartment
NO. Description Rated current(A) Descriptions

EF40 Main fuse of battery 100A
EF01 Fuse of power seat 30A
EF02 Fuse of alternator 60A
EF03 ABS fuse 25A
EF04 ABS fuse 40A
EF06 Fuse of front fog lamp 15A
EF07 Fuse of FL high beam lamp 10A
EF08 Fuse of FR high beam lamp 10A
EF09 Fuse of A/C 10A
EF10 Fuse of cooling fan-high 30A
EF11 Fuse of cooling fan-low 30A
EF14 Ignition switch of AM2 fuse 30A DSI model
EF15 Fuse of vacuum pump 10A
EF16 ECM fuse 10A
EF17 Fuse of horn 15A
EF18 Ignition switch of AM1 fuse 30A
EF21 Fuse of ignition coil 15A
EF22 Fuse of engine injecting nozzle 15A
EF25 Fuse of oil pump 15A
EF26 FR low beam lamp 10A
EF27 FL low beam lamp 10A
EF29 Fuse of starter 30A
EF35 Main fuse 110A
2013 EX7
20
Relay List of Engine Compartment
NO. Description Descriptions

ER01 Front fog lamp relay /
ER02 High beam lamp relay /
ER03 Start relay /
ER04 A/C relay /
ER05 Cooling fan relay-high speed Cooling fan relay-high speed
ER06 Cooling fan relay-low speed Cooling fan relay-low speed
ER07 Cooling fan relay-low speed 2 Cooling fan relay-low speed
ER08 Horn relay /
ER09 Engine main relay /
ER10 Fuel pump relay /
ER11 Low beam lamp relay /
ER13 Vacuum pump relay DSI model
ER14 Rear wiper relay It is under the interior panel of back door
EX7 2013
21 13.4.2 Ind oor Fuse & Relay Box
Ind oor fuse & relay box
NL13-04012
2013 GX7
22
Internal Wiring Diagram of Indoor Fuse, Relay Box
EX7 2013
23
Internal Wiring Diagram of Indoor Fuse, Relay Box (Continued)
2013 EX7
24
List of Indoor Fuse
NO. Description Rated current(A) Descriptions

IF01 Fuse of door lock 20 /
IF02 Diagnosis fuse 10 /
IF03 Fuse of brake lamp 10 /
IF04 Fuse of turning / hazard warning lamp 10 /
Tail lamp, instrument and switch
IF05 Fuse of position lamp 10
backlight
IF06 Fuse of A/C and instrument 15 /
IF11 Fuse of rear fog lamp 10 /
IF12 Fuse of power window 30 /
IF13 Fuse of sunroof 20 /
IF14 Fuse of radio/CD player 15 /
IF16 Fuse of rear defrost 30 /
IF17 Fuse of blower 40 /
IF18 Rear view mirror heating fuse 10 /
IF20 Fuse of radio/CD player 10 /
IF21 Fuse of spare power supply 15 /
IF22 Fuse of cigarette lighter 15 /
IF23 Fuse of rear wiper 15 /
IF25 Fuse of combination instrument 10 /
IF26 Empty Empty /
IF27 Fuse of reverse lamp 10 /
IF28 Fuse of brake lamp 10 /
IF29 Fuse of seat heater 15 /
IF30 Fuse of front wiper 30 /
IF32 Fuse of airbag 10
IF33 ECM fuse 10 /
IF34 ABS fuse 10
IF35 Fuse of immobilizer 10 /
IF36 Fuse of DSI transmission 10
EX7 2013
25
List of Indoor Relay
NO. Description Descriptions

IR01 Rear fog lamp relay /
IR02 Rear defrost relay /
IR03 Blower relay /
IR05 IG1 relay /
IR06 Right position lamp relay /
IR08 Left position lamp relay /
IR09 License lamp relay /
2013 EX7
13.5 Layout of Harness and the Connector
13.5.1 Battery Negative Harness 26
Battery Negative Harness
EX7 2013
27
Harness connector Description Harness connector Description

BE01 To battery negative G18 Battery grounding
G17 Battery grounding
2013 EX7
28
Battery Negative Connector Terminal Diagram
BE01 connect to battery negative G17 battery grounding G18 battery grounding
EX7 2013
29 13.5.2 Engine Compartment Harness
Engine Compartment Harness Layout Drawing
CA16 CA26 CA18 CA11 CA20 CA28 CA22

CA13 CA14 CA27
CA23 CA25 CA17 CA32 CA10 CA05 CA29 CA06 CA19

CA24 CA30 CA21 CA15 CA09 CA12 CA07
NL13-05019
2013 EX7
30
Engine Compartment Harness Layout Drawing (Continued)
EX7 2013
31
Harness Harness
Description Description
connector connector
CA01 To instrument harness connector 1 CA17 Harness connector of FR horn
Harness connector of FR combination
CA02 To instrument harness connector 2 CA18
headlamp
Harness connector of FL optical axis
CA03 To instrument harness connector 3 CA19
regulating motor
CA04 To instrument harness connector 4 CA20 Harness connector of brake fluid level sensor
Harness connector of environment
CA05 CA21 Harness connector of FR collision sensor
temperature sensor
Harness connector of FL fog
CA06 CA22 To engine harness connector
lamp
Harness connector of FL
CA07 CA23 Harness connector of FR fog lamp
speed sensor
CA08 To base plate harness connector CA24 Harness connector of front washer
Harness connector of cooling fan
CA09 CA25 Harness connector of rear washer
motor 1
Harness connector of cooling fan Harness connector of FR optical axis
CA10 CA26
motor 2 regulating motor
Harness connector of FL To engine harness connector (connecting wire
CA11 CA27
collision sensor plate 1)
Harness connector of FL To engine harness connector (connecting wire
CA12 CA28
combination headlamp plate 2)
Harness connector of ABS control
CA13 CA29 Harness connector of FL radar sensor
module
Harness connector of front wiper
CA14 CA30 Harness connector of FR radar sensor
motor
CA15 Harness connector of FL horn CA31 To base plate harness connector 2
Harness connector of FR
CA16 CA32 Harness connector of vacuum pump
speed sensor
2013 EX7
32
Terminal Diagram of Engine Compartment Harness Connector
CA01 connect to instrument CA02 connect to instrument CA03 connect to instrument

harness connector 1 harness connector 2 harness connector 3
7 6 5 4 3 2 1
B A
14 13 12 11 10 9 8
CA04 connect to instrument CA05 Environment temperature sensor CA06 FL fog lamp harness
harness connector 4 harness connector connector
CA07 FL speed sensor CA08 connect to base plate harness CA09 cooling fan motor 1 harness
harness connector connector connector
CA10 cooling fan motor 2 harness CA11 FL collision sensor CA12 FL combination lamp
connector harness connector harness connector
CA14 front wiper motor harness

CA13 ABS control module harness connector connector
EX7 2013
33
Terminal Diagram of Engine Compartment Harness Connector (Continued 1)
CA15 FL horn harness CA16 FR speed sensor CA17 FR horn harness

connector harness connector connector
CA18 FR combination CA19 FL optical axis CA20 brake fluid level sensor
headlamp harness connector adjusting motor harness connector harness connector
CA21 right front collision sensor CA22 connect to engine harness CA23 FR fog lamp harness
CA24 front washer harness CA25 Rear washer harness CA26 FR optical axis
connector connector adjusting motor harness connector
CA27 connect to engine harness CA28connect to engine harness CA29 connect to reverse radar
connector (splicing1) connector (splicing2) sensor 4 harness connector
2013 EX7
34
Terminal Diagram of Engine Compartment Harness Connector (Continued 2)
CA30 connect to reverse radar CA31 connect to body harness CA32 vacuum pump harness
sensor 5 harness connector connector 2 connector
EX7 2013
35
Engine Harness Layout Drawing
2013 EX7
36
Engine Harness Layout Drawing (Continued)
EX7 2013
37
Harness Harness
connector connector
Harness connector of engine control
EM01 EM22 Harness connector of reverse lamp switch
module
To harness connector of instrument Harness connector of water temperature
EM02 EM23
harness (1) sensor
Harness connector of carbon canister
EM03 Harness connector of rear oxygen sensor EM25
solenoid valve
Harness connector of front oxygen Harness connector of cylinder No.3ignition
EM04 EM26
sensor coil
Harness connector of power steering Harness connector of cylinder No.4ignition
EM05 EM27
switch coil
EM06 Harness connector of knock sensor EM28 Harness connector of electric throttle
Harness connector of air intake pressure
EM07 Harness connector of speed sensor EM30
temperature sensor
EM09 Harness connector of A/C compressor EM31 Harness connector of starter motor
EM10 Harness connector of oil pressure switch EM32 Harness connector of starter clutch
EM11 Alternator harness connector EM33 Harness connector of battery (1)
EM12 Harness connector of alternator (2) EM34 Harness connector of battery (2)
Harness connector of VVT To harness connector of engine compartment
EM13 EM35
solenoid valve fuse box (1)
Harness connector of cylinder To harness connector of engine compartment
EM14 EM36
No.1injecting nozzle fuse box (2)
Harness connector of cylinder To harness connector of engine compartment
EM15 EM37
No.2injecting nozzle fuse box (3)
Harness connector of cylinder
EM16 EM38 Harness connector of battery fuse box
No.3injecting nozzle
EM17 EM40 Harness connector of A/C pressure switch
No.4injecting nozzle
Harness connector of camshaft position Harness connector of transmission gear
EM18 EM41
sensor status
EM19 EM42 Harness connector of transmission actuator
No.1ignition coil
Harness connector of cylinder To harness connector of instrument harness
EM20 EM43
No.2ignition coil (2)
EM21 Harness connector of speed sensor EM44 Harness connector of vacuum sensor
2013 EX7
38
Terminal Diagram of Engine Harness Connector
EM03 rear oxygen sensor harness

EM01 engine control module harness connector
connector
EM02 connect to instrument EM04 front oxygen sensor harness EM05 power steering switch
harness connector connector harness connector
EM06 knock sensor harness EM07 engine speed sensor harness EM09 A/C compressor harness
connector connector connector
EM10 oil pressure sensor harness EM11 Alternator harness connector EM12 Alternator (2) harness
connector connector
EM13 VVT solenoid valve EM14 1Cylinder injector harness EM15 2 cylinders injector harness
EX7 2013
39
Terminal Diagram of Engine Harness Connector (Continued 1)
EM16 3cylinders injector harness EM17 4 cylinders injector harness EM18 camshaft position sensor
connector connector harness connector
EM19 1cylinder ignition coil EM20 2cylinders ignition coil EM21 speed sensor harness
harness connector harness connector connector
EM22 reverse switch harness EM23 engine coolant sensor EM25 canister solenoid
connector harness connector valve harness connector
EM26 3 cylinders ignition coil EM27 4 cylinders ignition coil EM28 electric throttle valve
harness connector harness connector harness connector
EM30 air intake pressure

EM31 start harness EM32 starter solenoid switch harness
temperature sensor harness connector connector connector
2013 EX7
40
Terminal Diagram of Engine Harness Connector (Continued 2)
EM35 connect to compartment fuse

EM33 battery (splicing1) EM34 battery (splicing2)
box(1)
EM36 connect to compartment EM37 connect compartment fuse

EM38 battery fuse box
fuse box(2) box(3)
EM40 A/C pressure switch EM41 transmission gears status EM42 transmission actuator harness
EM43 connect to instrument harness (2)connector EM44 vacuum sensor harness

connector
EX7 2013
41 13.5.4 Instrument Harness
Instrument Harness Layout Drawing
IP03
IP59 IP54 IP56 IP20 IP26 IP11 IP05 IP13

IP55 IP63 IP19 IP17
IP39 IP58
IP12
IP25
IP53
IP72
IP44 IP30
IP29
IP71
IP36 IP37 IP46 IP28
IP35 IP57 IP51 IP45 IP15 IP34

IP38 IP33 IP32
NL13-05022
GX7 2013
42
Instrument Harness Layout Drawing (Continued)
EX7 2013
43
Harness connector Name Harness connector Name
IP01 Instrument panel harness connector IP42 Heambeam combination switch
harness connector
Multi-functional instrument harness Immobilizer antenna
IP03 IP43
connector harness connector
IP04 Sunlight sensor harness connector IP44 Knee airbag harness connector
IP05 Environment light sensor IP45 Ignition switch harness connector
harness connector
Rear defroster switch harness Key removal prompt switch
IP06 IP46
Hazard warning lamp switch Electronic accelerator pedal
IP07 IP51
harness connector harness connector
Combination switch Wiper washer combination switch
IP08 IP52
Reversing radar indicator lamp Backup power source harness
IP10 IP53
harness connector connector
IP11 Blower harness connector IP54 To headlining harness connector 1
IP12 DLC harness connector IP55 To headlining harness connector 2
To right front door harness Brake lamp switch harness
IP13 IP56
connector connector
Headlamp beam axis regulating To engine compartment harness
IP14 switch & immobilizer warning lamp IP57
IP15 Airbag module harness connector IP58 Camera harness connector
A/C control panel harness
IP16 IP59 Antenna wire 1 harness connector
connector (automatic)
IP17 To engine harness connector IP60 Clutch switch harness connector
Passenger side airbag harness Body control module harness
IP19 IP61
connector connector 1
Body control module harness
IP20 Antenna wire 2 harness connector IP62
connector 2
Radio & CD player harness Body control module harness
IP21 IP63
connector 1 connector 3
IP22 IP64
IP23 IP65
Body control module harness
IP24 Immobilizer connector 1 IP66
connector 6
IP25 Immobilizer connector 2 IP67 To engine (2) harness connector
Manual A/C control panel connector
IP26 IP68 Shift controller 1 harness connector
C
Manual A/C control panel
connector A
Parking brake switch harness
connector
Central lock switch Gear selector harness connector
IP29 IP71
connector (AT)
Gear selector protection module
IP30 Cigarette lighter harness connector IP72
harness connector (AT)
IP32 To floor harness connector 1 IP74 To body harness connector 3
Driver side seat-heating switch
IP33 To body harness connector 5 IP75
harness connector
Passenger side seat-heating
IP34 To floor harness connector 2 IP76
switch harness connector
To engine compartment harness
IP35 connector 1 IP77 To body harness connector 6
To engine compartment harness
IP36 connector 2 IP78 To body harness connector 4
To engine compartment harness Hazard flasher relay
IP37 connector 3 IP79 harness connector
Radio & CD player harness
IP38 To FL door harness connector IP80
connector 4
IP40 Clock spring coil harness connector IP81 To USB harness connector
IP41 Driver seat airbag harness IP82 Back door unlock switch harness
connector connector
2013 GX7
44
Terminal Diagram of Instrument Harness Connector
IP03 multi-function instrument

IP01 combination instrument harness connector
harness connector
1 2 3 4 5 6
7 8 9 10 11 12
IP04 solar sensor harness IP05 Sunlight sensor harness IP06 rear defrost switch harness
connector1 connector 2 connector
IP07 hazard switch connector IP08 combination adjusting switch IP10 reverse radar indicator
IP11 blower connector IP12 diagnostics interface IP13 FR door harness

connector
IP14 headlamp optical axis adjusting

IP15 airbag module harness connector
Anti-theft alarm lamp harness connector
EX7 2013
45
Terminal Diagram of Instrument Harness Connector (Continued 1)
IP17 Connect to engine harness IP19 passenger side airbag harness IP20 antenna wire 2 harness
IP21 Radio/CD player harness IP22 Radio/CD player harness IP23 Radio/CD player harness
connector 1 connector 2 connector 3
IP24 Immobilizer connecter1 IP25 Immobilizer connecter2 IP26 manual A/C control panel
connector C
IP27 manual A/C control panel IP28 parking brake switch harness IP29 Central lock switch connector
connector A
IP30 cigarette lighter harness IP32 connect to body harness IP33 connect to body harness
connector connector 1 connector 5
2013 EX7
46
Terminal Diagram of Instrument Harness Connector (Continued 2)
IP34 connect to body harness IP35 connect to engine IP36 connect to engine
connector 3 compartment harness connector compartment harness connector 2
1 1 2 3 4 5 6 7 8 9 10
1 2 3 4 5 6 7 8 9 10 11
11 12 13 14 15 16 17 18 19 20
12 13 14 15 16 17 18 19 20 21 22 2
IP37 connect to engine IP38 connect to FL door IP40 clock spring harness
compartment harness connector 3 harness connector connector
1 2 3
4 5 6 7 8
9 10 11 12 13
1 2 3 4 5 6 7 8 9 10 11 12 13 1 2 3 4 5 6
13 14 15 16 17 18 19 20 21 22 23 24 26 14 15 16 17 18 19 20 21
22 23 24 25 26 27 28 29 7 8 9 10 11 12
30 31 32 33 34
IP41 driver safety airbag harness IP42 Headbeam combination switch IP43 Anti-theft coil
connector harness connector harness connector
2 1 1 2 3 4 5 6 7 8
1 2 3 4 5 6
9 10 11 12 13 14 15 16 17
IP44 knee airbag harness connector IP45 Ignition switch harness IP46 key forget reminding switch
2 1
1 2 3
4 5 6
1 2
IP51 electric acceleration pedal IP52 Wiper switch IP53 Spare power harness
1
6 5 4 3 2 1 1 2 3 4 5 6 7 8 9
2
10 11 12 13 14 15 16 17 18
3
NL13-10021
2013 GX7
47
Terminal diagram of instrument harness connector (Continued 3)
IP54 connect to roof harness IP55 connect to body harness IP56 brake lamp switch harness
connector 1 connector 2 connector
1
1 2 3 4 5
1 2 3 4 3 4
6 7 8 9 10 11 12
IP57 connect to engine IP60 clutch switch harness IP61 Body control module 1
compartment harness connector connector harness connector
B 1 2 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
IP62 body control module 2 IP63 body control module3 harness IP64 body control module4 harness
19 16 13 10 7 4 1 13 10 7 4 1
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 14 11 8 5 2
20 17 14 11 8 5 2
21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 21 18 15 12 9 6 3 15 12 9 6 3
IP65 body control module 5 IP66 body control module 6 IP67 connect to engine(2)
10 7 4 1 11 10 9 8 7 6 5 4 3 2 1
11 8 5 2 22 21 20 19 18 17 16 15 14 13 12
1 2 3 4
12 9 6 3
IP68 TCU1 harness connector IP69 TCU2 harness connector IP70 TCU3 harness connector
1 2 3 4 5 6 7 8 1 2 3 4 5 6 1 2 3 4 5 6 7 8 9 10
11 12 13 14 15 16 17 18 19 20
9 10 11 12 13 14 15 16 7 8 9 10 11 12
2013 EX7
48
Terminal diagram of instrument harness connector (cont. 4)
IP71 Gear shift harness IP72 G ear shift protection IP16 A/C control panel
connector (AT) module harness connector (AT) (Auto) harness connector
1 2 3 4 1 2 3 4 5 6
1 2 3 4 5 6 7 8 9 10 11 12
5 6 7 8 9 10 11 7 8 9 10 11 12 13 13 14 15 16 17 18 19 20 21 22 23 24
IP58 Camera harness connector IP74 connect to body harness IP75 Driver side seat-heating
connector switch harness connector
IP76 Passenger side IP77 To right b ody harness IP78 To b ody harness
seat-heating switch harness connector 6 connector 4
connector
2 1 1 2 3
1 2 3 4
4 5 6 7 8
6 5 4 3 5 6 7 8 9 10
IP79 Hazard relay IP80 Radio & CD player harness IP81 To USB harness connector
86
3 4
30 87 5 4 3 2 1
85 10 9 8 7 6 1 2
IP82 Backdoor switch

harness connector
2 1
6 5 4 3
NL13-04012
2013 GX7
49 13.5.5 Roof harness
Roof Harness Layout Drawing
EX7 2013
50
Harness connector Description Harness connector Description

Harness connector of sunroof
RF01 To instrument harness connector 1 RF07
module
RF02 To instrument harness connector 3 RF12 Harness connector of front reading

lamp harness
Harness connector of driver curtain Harness connector of sunroof
RF04 RF13
airbag switch
RF05 Harness connector of rear reading lamp RF14 Antenna connector
Harness connector of passenger air
RF06
curtain
2013 EX7
51
Terminal Diagram of Ceiling Harness Connector
RF01 connect to instrument RF02 connect to instrument RFO4 driver curtain airbag
harness connector 1 harness connector 2 harness connector
1 2 3 4 5 1 2
4 3 2 1
6 7 8 9 10 11 12
RF05 Rear reading lamp harness RF06 passenger side curtain airbag PF07 sunroof switch harness
connector harness connector connector
1 2 4 3 2 1
1 2 3
14 13 12 11 10 9 8 7 6 5
RF12 front reading lamp harness PF13 sunroof module harness RF14 Antenna connector
connector connector
1 2 3 4
1
1 2 3 4 5 6 5 6 7 8 9 10
NL13-10011
EX7 2013
52
Body Harness Layout Drawing
2013 EX7
53
Body Harness Layout Drawing (Continued 1)
SO42 SO59 SO40 SO41 SO46 SO44 SO47 SO45
SO43 SO48
NL13-05013
GX7 2013
54
Body Harness Layout Drawing (Continued 2)
2013 EX7
55
Harness Description Harness Description

connector connector
SO01 To RR door harness connector SO30 To back door harness connector
SO02 Harness connector of FR door SO31 Harness connector of RL combination
control switch lamp
SO04 Harness connector of passenger seat heating SO32 Harness connector of Parking
control module
SO05 Harness connector of passenger side power SO34 Harness connector of RL collision
window sensor
SO06 Harness connector of passenger seat airbag SO35 Harness connector of left collision sensor
SO07 Harness connector of passenger seat belt SO36 Harness connector of RR door control
switch
SO08 To instrument panel harness connector 1 SO37 Harness connector of passenger safety belt
pretensioner
SO09 To instrument panel harness connector 2 SO40 Harness connector of rear wiper motor
SO10 To instrument panel harness connector 3 SO41 Harness connector of right license lamp
SO11 Harness connector of driver power seat SO42 Rear defrost negative harness connector
SO12 Harness connector of driver seat heating SO43 Harness connector of back door lcok motor
SO13 Driver safety belt switch SO44 Harness connector of left license lamp
SO14 To engine compartment harness connector SO45 To body harness connector
SO15 Harness connector of driver side seat SO46 Harness connector of high brake
airbag lamp
SO16 To left rear door harness connector SO47 Rear defrost positive harness connector
SO17
Harness connector of luggage compartment SO48 Harness connector of camera
lamp
SO18 Harness connector of RL door control SO49 Harness connector of parking
switch sensor 1
SO19 Harness connector of driver safety belt SO50 Harness connector of parking
pretensioner sensor 2
SO20 Harness connector of FL door SO51 Harness connector of parking
control switch sensor 3
SO21 Harness connector of right collision sensor SO52 Harness connector of RR fog lamp
SO22 Harness connector of RR collision SO53 To bodyt harness connector
sensor
Harness connector of right rear Harness connector of RL fog lamp
SO24 combination lamp SO54
SO25 Harness connector of RR wheel SO55 To engine compartment harness connector 2

speed sensor
SO26 Harness connector of fuel pump SO56 To instrument panel harness connector
SO27 Harness connector of fuel level sensor SO57 To instrument panel harness connector
SO28 Harness connector of RL speed sensor SO58 To instrument panel harness connector
SO29 To rear bumper harness connector SO59 Harness connector of rear wiper
EX7 2013
56
Terminal Diagram of Body Harness Connector
SO01 connect to RR door SO02 FR door control SO04 passenger seat-heating harness
harness connector switch harness connector connector
1 2 3 4 5 6 7 1
8 9 10 11 12 13 14 1 2
SO05 passenger power window SO06 passenger seat airbag harness SO07 passenger safety belt harness
1 1
1 2 3 4
2 2
SO08 connect to instrument panel SO09 connect to instrument panel SO10 connect instrument panel
harness connector 1 harness connector 2 harness connector 3
11 10 9 8 7 6 5 4 3 2 1 13 12 11 10 9 8 7 6 5 4 3 2 1 11 10 9 8 7 6 5 4 3 2 1
22 21 20 19 18 17 16 15 14 13 12 26 25 24 23 22 21 20 19 18 17 16 15 14 22 21 20 19 18 17 16 15 14 13 12
SO11 driver power seat harness SO12 passenger seat-heating harness SO13 driver safety belt switch
connector connector
1 1 1
2 2 2
SO14 connect to engine SO15 driver seat side airbag SO16 connect to RL door
compartment harness connector harness connector harness connector
3 2 1
1 2 3 4 5 6 7
8 7 6 5 4 1 2 3 4 8 9 10 11 12 13 14
NL13-10012
2013 EX7
57
Terminal Diagram of Base Plate Harness Connector (Continued 1)
SO17 luggage compartment lamp SO18 RL door control switch SO19 driver safety belt pretensioner
2 1 1 1 2
SO20 FL door control switch SO21 right side collision sensor SO22 RR side collision
harness connector harness connector sensor harness connector
1 2 1 2 1
SO24 RR combination lamp SO25 RR wheel speed harness SO26 fuel pump harness connector
1 2 1 2
2 1
3 4 5 6
3 4
SO27 Fuel level sensor harness SO28 RL wheel speed sensor SO29 connect to bumper harness
connector harness sensor connector
4 3 2 1
2 1
A B 10 9 8 7 6 5
SO30 connector back door SO31 RL combination lamp SO32 Parking controller
harness connector harness connector module harness connector
5 4 3 2 1 1 2
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
12 11 10 9 8 7 6 3 4 5 6
17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32
NL13-10013
EX7 2013
58
Terminal Diagram of Base Plate Harness Connector (Continued 2)
SO34 RL side collision sensor SO35Left side collision sensor SO RR door control switch
SO37 passenger safety belt with SO54 RL fog lamp harness SO53 connect to body harness
pretensioner harness connector connector connector
SO40 rear wiping motor harness SO41 right license lamp harness SO42 rear defrost negative harness
connector connector
SO43 Back door lock motor SO44 left license lamp harness SO45 connect to body harness
harness connector connector connector harness connector
SO46 high mount brake lamp SO47 Rear defrost positive harness SO48 camera harness connector
2013 EX7
59
Terminal diagram of floor harness connector (cont. 3)
S049 To parking radar 1 S050 To parking radar 2 S051 To parking radar 3

2 2 2
1 3 1 3 1 3
S052 RR fog lamp S055 To engine compartment S056 To instrument panel

harness connector harness connector 2 harness connector
4 3 2 1
4 3 2 1
1 2 10 9 8 7 6 5
S057 To instrument panel S058 To instrument panel S059 Rear wiper relay harness
3 2 1 86
4 3 2 1
30 87
8 7 6 5 4 10 9 8 7 6 5
85
NL13-10015
2013 GX7
60
Front Left (FL) Door Harness Layout Drawing
2013 EX7
61
Harness Harness
connector connector
To instrument panel harness Harness connector of FL door front
DR01 DR06
connector speaker
FL door power window motor
DR02 DR07 FL door tweeter harness
connector
FL door power window motor Harness connector of left exterior
DR02 DR08
connector rearview mirror
Harness connector of FL door Harness connector of power rearview mirror
DR04 DR09
lock motor switch
Harness connector of FL door power window
DR05 FL door step lamp connector DR10
switch
EX7 2013
62
Right Front (FR) Door Harness Layout Drawing
2013 EX7
FR door power window motor
63
Harness Harness
connector connector
Harness connector of FR power window
DR11 DR16 FR door speaker connector
motor
Harness connector of FR door power window
DR13 DR17 FR door tweeter speaker
switch
Harness connector of FR door lock Right exterior rearview
DR14 DR18
motor mirror connector
FR door connecting to
DR15 FR door step light connector DR19
instrument panel harness connector
EX7 2013
64
Rear Door Harness Layout Drawing
2013 EX7
65
Harness Harness
connector connector
RL door connec ting to body RR door connecting to body
DR21 DR31
DR22 Harness connector of RL speaker DR32 Harness connector of RR speaker
Harness connector of RL power window Harness connector of RR power window
DR23 DR33
motor motor
Harness connector of RL door lock Harness connector of RR door lock
DR25 DR35
motor motor
Harness connector of RL door power Harness connector of RR door power
DR26 DR36
window switch window switch
EX7 2013
66
Terminal Diagram of Door Harness
DR02 FL door power window DR02 FL power window

DR01 connect to instrument panel
motor connector (without motor connector (with anti-clamp)
harness connector
anti-clamp)
DR04 FL door lock motor DR05 FL door step lmap

DR06 FL door front speaker DR07 FL door tweeter DR08 left exterior rearview
harness connector harness mirror connector
DR09 power rearview mirror DR10 FL door power window switch DR11 FR door power window motor
switch harness connector harness connector harness connector (without
anti-clamp)
DR11 FR door power window

DR13 FR door power window DR14 FR door lock motor
motor harness connector (without
switch harness connector harness connector
anti-clamp)
2013 EX7
67
Terminal Diagram of Door Harness (Continued 1)
DR15 FR door step light DR16 FR door speaker DR17 FR door tweeter
DR18 Right side door rearview DR19 FR door connect to DR21 RL door connect to body
mirror connector instrument panel harness connector harness connector
DR22 RL speaker harness DR23 RL power window motor

connector harness connector (anti-clamp)
DR23 RL door power window motor DR25 RL door lock motor harness DR26 RL door power window
harness connector (without connector switch harness connector
anti-clamp)
DR31 RR door to body DR32 RR speaker harness DR33 RR door power window motor
harness connector connector harness connector (without
anti-clamp)
EX7 2013
68
Terminal Diagram of Door Harness (Continued 2)
DR33 RR power window DR35 RR door lock DR36 RR power window

motor harness connector motor harness connector switch harness connector
(with anti-clamp
2013 EX7
69
Front Compartment Harness Grounding Layout Drawing
EX7 2013
70
Engine Harness Grounding Layout Drawing
2013 EX7
71
Battery Negative Harness Grounding Layout Drawing
EX7 2013
72
Instrument Harness Grounding Layout Drawing
2013 EX7
73
Body harness Grounding Point Layout Drawing
EX7 2013
74
Back Door Harness Gr ounding Layout Drawing
2013 EX7
75
Grounding Circuit Drawing 1 (G6)
Headbeam axis
adjusting switch
Instrument panel
background lamp
adjustment switch
Anti-theft alarm lamp
Rear defrost switch

BCM body control
module
Diagnosis connector
Left exterior
rearview mirror
Combination
instrument
FL door lock
motor
Multi-function
instrument Power rearview mirror
switch
Combination switch
FL power window
motor
Wiper
combination switch
FL power window
switch
IR04 relay
Front reading lamp
Combination
instrument
Sunroof control module
Multi-function
instrument
Sunroof switch
DR01
EX7 2013
76
Grounding Circuit Drawing 2 (G5, G6A, G7, G10 and P)
ABS module
Airbag
FR power window Cigarette Lighter

switch
FR power window Spare power

supply
motor
Right exterior
rearview mirror
Speed sensor
(shield wire) Speed sensor
Engine control
module
2013 EX7
77
Grounding Circuit Drawing 3 (G11, G12)
B
Auto gear shift
自动换挡器
㞾ࡼᤶᣵ఼
B
TCU
Auto gear shift protection B

自动换挡保护器模块
module
B
Driver side power seat
驾驶员侧电动座椅
偒偊ਬջ⬉ࡼᑻộ
B B
12 SO16 2 SO16
12 DR21 2 DR21
RL power window
左后玻璃升降电机
Ꮊৢ⦏⩗छ䰡⬉ᴎ
motor
RL power window B B
左后门玻璃升降器开关
Ꮊৢ䮼⦏⩗छ䰡఼ᓔ݇
switch
B
G11
Passenger side power B

乘客侧电动座椅
Ьᅶջ⬉ࡼᑻộ
seat
Passenger side Safety B B

乘客侧安全带开关
Ьᅶջᅝܼᏺᓔ݇
belt switch
B B
1 DR31
1 SO59
RR power window
右后门玻璃升降电机
েৢ䮼⦏⩗छ䰡⬉ᴎ
motor
B B
5 DR37
2 SO01
RR power window
右后门玻璃升降器开关
েৢ䮼⦏⩗छ䰡఼ᓔ݇
switch
G12
NL13-06016
EX7 2013
78
Grounding Circuit Drawing 4 (G2, G4)
FR combination FR optical axis

headbeam adjustment motor
FR fog lamp Front right horn
Front washing lamp Rear washer
Power vacuum pump
Braking fluid level sensor
FL combination ER07 relay

headlamp
FL optical axis
Cooling fan motor 2
adjustment motor
Front left horn
ER03 relay
Front washer motor
FL fog lamp
2013 EX7
79
Grounding Circuit Drawing 5 (G9, G13, G14)
Environment light sensor
Fuel level sensor
Fuel pump
Parking control
module
RL combination
lamp
RL fog lamp
RR fog lamp
RR combination
lamp
EX7 2013
80
Grounding Wiring Diagram 6 (G8, G15, G16)
B
Rear wiper relay
B
Rear defrost negative
Back door lock B

motor
B B
Left license lamp
B
Right license lamp
High mount brake B

lamp
B
Rear wiper motor
2 SO30
2 SO45
G16 G15
B
Central lock switch
Key forget reminding B B

Immobilizer 1
switch
B
Hazard switch
B
A/C control panel B
Immobilizer 2
(manual)
G8
NL13-06005
2013 GX7
81
Power Configuration Circuit Diagram 1
Engine compartment fuse, relay box
Ignition switch
Vacuum
relay
Horn
Relay
Fuel pump
Relay
Start
Relay
Engine main relay

Engine compartment fuse, relay box Ignition coil
Engine compartment fuse, relay

b Vacuum pump relay
Low beam lamp Right front combination

headlamp
relay
Right front
Engine compartment fuse, relay box Engine compartment fuse,
optical axis
relay box
regulator motor
Left front combination

Battery positive terminal fuse box headlamp
Battery Left front optical

Engine compartment fuse, axis regulator
relay box motor
EX7 2013
82
Driver power seat
Passenger power seat

Cooling fan High

speed relay
Cooling fan low

speed relay 1
Front fog lamp relay
A/C relay
High beam lamp relay Left front combination

headlamp
Right front combination

headlamp
airbag
Inner fuse relay box
2013 EX7
83
Reverse gear switch
Speed sensor

Generator
Combination
instrument
Ambient light sensor
Sunroof control module
Auxiliary instrument
Left rearview mirror
Rear defrost relay

Right rearview mirror
IG1 relay
Brake lamp switch
License lamp relay Left license lamp

Right license lamp
Power rearview mirror

switch
Standby power supply
Cigarette Lighter
Wiper washing
15A IF23 combination switch
Rear wiper motor
A/C relay
EX7 2013
84
Diagnosis connector
Immobilizer
Brake switch

Clutch switch
Hazard alarm switch
Left position lamp

relay
Left rear position lamp
Left front position lamp
Right position lamp

relay
Right rear position lamp
Right front position lamp
Rear reading lamp

Front ceiling lamp
Left front door guest lamp
Passenger side door guest

lamp
Headlamp lighting
shaft adjusting switch
Auxiliary instrument
Combination instrument
Trunk lamp
2013 EX7
85
A/C relay
Cooling fan low

speed relay 2
Cooling fan Low

speed relay
Cooling fan high

speed relay
Fuel pump relay
Injector 4
Injector 3
Injector 2
Injector 1
Front Oxygen Sensor
Rear Oxygen Sensor
Canister solenoid
valve
VVT solenoid
valve
EX7 2013
86
FL power window motor
FR power window motor
RR power window motor
RL power window motor
Rear defrost relay
Blower relay
Radio/CD player
Rear fog lamp relay
2013 EX7
87
Power Configurations List
NO. Description Rated current(A) System

EF40 Main fuse of battery 100A All systems
EF01 Fuse of power seat 30A Power seat
Power window
ECM
EF02 Fuse of alternator 60A Horn
Radio/CD player
Fog lamp
EF03 ABS fuse 25A ABS
EF04 ABS fuse 40A ABS
EF06 Fuse of front fog lamp 15A Fog lamp
EF07 Fuse of left front high beam lamp 10A Headlamp
EF08 Fuse of right front high beam lamp 10A Headlamp
EF09 Fuse of A/C 10A A/C system
EF10 Fuse of cooling fan 30A Cooling fan
EF11 Fuse of cooling fan 30A Cooling fan
Airbag
Cooling ECM
fan-low Ignition switchAM2Fuse 30A
speed ABS
Engine anti-theft
EF15 Vacuum fuse 10A Charging system
EF16 ECM fuse 10A ECM
EF17 Fuse of horn 15A Horn
Radio /CD player
Spare power supply
Cigarette lighter
Rear wiper
EF18 Ignition switchAM1fuse 30A
Combination instrument
Reverse lamp
Front wiper
Rear view mirror heating
EF21 Fuse of ignition coil 15A ECM
EF22 Fuse of engine injecting nozzle 15A ECM
Door lock
Diagnosis
Brake lamp
Steering / hazard warning lamp
Position lamp
A/C and instrument
EX7 2013
88
NO. Description Rated current(A) System

EF25 Fuse of oil pump 15A ECM
EF26 Fuse of right front low beam lamp 10A Headlamp
EF27 Fuse of left front low beam lamp 10A Headlamp
EF29 Fuse of starter 30A Start system
Charging system
Power seat
Cooling fan
ABS
Fog lamp
A/C
EF35 Main fuse 110A
Headlamp
Power window
ECM
Horn
Radio /CD player
Rear fog lamp
IF01 Fuse of door lock 20 Door lock
IF02 Diagnosis fuse 10 Diagnosis
IF03 Fuse of brake lamp 10 Brake lamp
IF04 Fuse of steering / hazard warning lamp 10 Turn signal/hazard lamp

IF05 Fuse of position lamp 10 Position lamp
IF06 Fuse of A/C and instrument 15 A/C / instrument
IF11 Fuse of rear fog lamp 10 Fog lamp
IF12 Fuse of power window 30 Power window
IF14 Fuse of radio/CD player 15 Radio
IF16 Fuse of rear defrost 30 Rear defrost
IF17 Fuse of blower 40 Blower
IF18 Rear view mirror heating fuse 10 Rear view mirror heating
IF20 Fuse of radio/CD player 10 Radio/CD player
IF21 Fuse of standby power supply 15 Spare power supply
IF22 Fuse of cigarette lighter 15 Cigarette lighter
IF23 Fuse of rear wiper 15 Rear wiper
IF25 Fuse of combination instrument 10 Combination instrument
IF26 Fuse of license lamp 10 License lamp
IF27 Fuse of reverse lamp 10 Reversing lamp
IF28 Fuse of brake lamp 10 Brake lamp
IF30 Fuse of front wiper 30 Front wiper
IF32 Fuse of airbag 10 Airbag
IF33 ECM fuse 10 ECM
IF34 ABS fuse 10 ABS
IF35 Fuse of immobilizer 10 Immobilizer
2013 EX7
89 13.8 Circuit Diagram
Circuit Diagram Index
Power Distribution Diagram1 ..................................... 91 Power Supply, Grounding and Data Line 1 Of Body
Power Distribution Diagram2 ..................................... 92 Control Module (BCM) .......................................... 158
Power Distribution Diagram3 ..................................... 93 Power Supply, Grounding and Data Line 2 Of Body
Power Distribution Diagram4 ..................................... 94 Control Module (BCM) ........................................... 159
Charging System ........................................................ 96 Power Supply, Grounding and Data Line 3 Of Body
Control Module (BCM) ........................................... 160
Start System ............................................................... 98
Start System (DSI). .................................................... 99 Power Supply, Grounding and Data Line 4 Of Body
Control Module (BCM) ........................................... 161
ECM power Supply, Data, Grounding Wire1 ............ 101 Power Supply, Grounding and Data Line 5 Of Body
ECM power Supply, Data, Grounding Wire2 ........... 102 Control Module (BCM) ........................................... 162
ECM ignition System..................................... ........... 104 Body Anti-Theft Control System ......................... 164
ECM ignition System (DSI) ..................................... 105 Center Control Lock 1 ........................................... 166
Fuel Pump, Fuel Injector .......................................... 107 Center Control Lock 2 ........................................... 167
ECM equipment Control............................................ 109 Power Rear View Mirror Control ........................ 169
ECM sensor............................................................... 111 Defrost Control .................................................... 171
ECM sensor (DSI) ......................................... ....... 112 Power Seat Control .............................................. 173
Speed Sensor ............................................................. 114
Power Seat Heating .............................................. 175
Cooling Fan Control .................................................. 116
Front Wiper And Washer ..................................... 177
Cooling Fan Control (DSI) ........................................ 117
Rear Wiper And Washer ...................................... 179
TCU power Supply, Grounding, Data Line (DSI). .... 119
Headlamp Lighting Shaft Adjusting .................... 181
TCU transmission Control (DSI). .............................. 120
A/C System Power Supply, Grounding (Auto).... 183
Engine Anti-Theft System ......................................... 122
A/C Compressor Clutch Control (Auto)............... 185
Combination Instrument Power Supply, Grounding.. 124
Blower (Auto)....................................................... 187
Combination Instrument Lighting, Indicator ............. 126 Wind Direction Regulating Motor (Auto)............ 189
Combination Instrument Sound Warning, Alarm..... 128 A/C System, GD (Auto)....................................... 190
Multi-Function Instrument ....................................... 130
A/C Power Supply, Grounding, Signal (Manual) 192
ABS Power Supply, Grounding, Data Line. ............ 132
A/C Compressor Clutch Control (Manual) .......... 194
ABS Sensor. ............................................................. 134
Blower Control..................................................... 196
Headlamp System1 .................................................... 136
Wind Direction Regulation Motor ....................... 198
Headlamp System2 .................................................... 137
Sound Main Engine Power Supply, Signal Grounding
Position Lamp .......................................................... 139 ............................................................................. 199
Fog Lamp ................................................................. 141 Sound Main Engine Speaker Control ................... 201
Steering Lamp, Hazard Warning Lamp1 .................. 143 Airbag (SRS) Power Supply, Grounding, Data Line 203
Steering Lamp, Hazard Warning Lamp2 .................. 144 Airbag (SRS) Sensor1 .......................................... 205
Brake Lamp .............................................................. 146 Airbag (SRS) Sensor2 .......................................... 206
Reverse Lamp ........................................................... 148 Seat Belt Pretensioner And Airbag ...................... 208
Reverse Lamp (DSI). ............................................... 149 Reverse Radar ...................................................... 210
Reading Lamp. .. . ...................................................... 151 Reverse Radar 2 ................................................... 212
Guest Lamp ............................................................... 153 Horn ..................................................................... 214
Background light 1 ..................................................... 155 Cigarette Lighter, Power Supply Socket .............. 216
Background light 2 ..................................... ....... .......... 156 Sunroof System .................................................... 218
EX7 2013
90
Power Window (Only Driver Side Door With

Anti-Clamp Function)1 .......................................... 220
Power window (Only driver side door with anti-clamp
function)4............................................................... 223
Diagnosis connector ............................................. 225
CANdata communications network. ..................... 227
2013 EX7
91
Power Distribution Diagram 1
To Alternator
To starter
EX7 2013
92
2013 EX7
93
EX7 2013
94
2013 EX7
95
Harness connector Description Pages

BE01 To battery negative 27
CA01 To instrument harness connector 1 31
CA27 To engine harness connector (connecting wire plate2) 31
EM35 To engine compartment fuse, relay box (connecting wire plate1) 37
EM37 To engine compartment fuse, relay box (connecting wire plate2) 37
EM38 Battery fuse box (connecting wire plate) 37
EM33 Harness connector of battery (1) 37
IP35 To engine compartment harness connector 1 43
IP57 To engine compartment harness connector 43
G17 Battery grounding 71
EX7 2013
96
Charging system
Engine compartment
fuse, relay box
6MT model
Instrument panel
Alternator
NL13-08094
2013 GX7
97

EM02 To instrument harness connector 37
EM11 Alternator harness connector 37
EM12 To alternator (connecting wire plate) harness connector 37
EM35 To engine compartment distribution box (connecting wire plate2) 37
EM38 Battery fuse box 37
EM33 Battery (connecting wire plate1)harness connector 37
IP01 Harness connector 1 of combination instrument 43
IP17 To engine harness connector 43
G6 Instrument panel grounding 72
EX7 2013
98
Start System
Ignition switch
Engine
compartment,
Fuse, relay
box
Start relay
Starter
Battery
2013 EX7
99
Staring system (DSI)
Ignition switch
Engine compartment
fuse relay
box
Starting
relay
Battery
T ransm ission
S tarter switch
NL13-08094
2013 GX7
100

CA22 To engine harness connector 31
EM32 Harness connector of starter solenoid switch 37
EM31 Harness connector of starter 37
EM36 To harness connector of engine compartment distribution box 37
EM34 Battery fuse box (connecting wire plate2) 37
EM38 Battery fuse box 37
IP45 Harness connector of ignition switch 43
P Engine grounding 70
2013 EX7
101
ECM Power Supply, Data, Grounding Wire 1
Engine
compartment,
Fuse, relay box
Engine
main relay
ER09 To A/C control panel
Inner fuse
relay box
Vacuum
pump
relay
A/C
pressure
switch
Power
vacuum
pump
EX7 2013
102
ECM power, data and ground wire 2
To clutch To cooling fan To cooling fan To brake lamp To brake lamp

To A/C switch low speed relay high speed switch switch
To CAN-H To CAN-L relay relay
1
To EF07 To To left front To electric A/C To sensor To To immobilizer

instrument
panel combination system IP27-15/ EM21-3 immobilizer module
headlamp To automatic A/C module IP24-5
system IP16-21 IP24-8
NL13-08096
GX7 2013
103
EM01 Harness connector of engine control module 35
EM40 Harness connector of A/C pressure switch 34
CA32 Harness connector of power vacuum pump 28
G2 Engine compartment harness grounding 67
P Engine harness grounding 68
Connection point Descriptions Pages

EM01-9 To A/C relay 178
To EF07 131
EM01-35 To front left combination headlamp 131
To combination instrument IP01-26 121
EM01-34 To clutch switch IP60-2 106
EM01-65 To cooling fan low speed relay 1 112
EM01-17 To cooling fan high speed relay 112
EM01-80 To A/C system IP27-15 176
EM01-75 To immobilizer module IP24-5
117
EM01-46 To immobilizer module IP24-8
EM01-69 To brake lamp switch IP56-2 141
EM01-33 To brake lamp switch IP56-4 141
EM40-1
To A/C control panel IP27-3 176
EM40-2
EM01-51 To speed sensor EM21-3 110
EX7 2013
104
ECM ignition system
Ignition coil 1 Ignition coil 2 Ignition coil 3 Ignition coil 4
Knock sensor E ngine revolution speed

sensor
NL13-08097
GX7 2013
105
ECM ignition system (DSI)
Ignition coil 1 Ignition coil 2 Ignition coil 3 Ignition coil 4
Knock sensor E ngine revolution speed

sensor
NL13-08164
2013 GX7
106

EM19 Harness connector of cylinder No.1ignition coil 34
EM06 Harness connector of knock sensor 34
EM07 Harness connector of speed sensor 34
P Engine harness grounding 68
EX7 2013
107
Fuel pump & fuel injector
Injector 1 Injector 2 Injector 4 Injector 2

Engine compartment
M ain fuse, relay box
Fuel pump
relay
Fuel pump
NL13-08098
GX7 2013
108

EM14 Harness connector of 1st cylinder No.1injector 34
EM15 Harness connector of 2nd cylinder No.2injector 34
EM16 Harness connector of 3rd cylinder No.3injector 34
EM17 Harness connector of 4th cylinder No.4injector 34
EM36 To harness connector of engine compartment fuse box (2) 34
CA08 To body harness connector 29
SO04 To engine compartment harness connector 50
SO26 Harness connector of fuel pump 50
EX7 2013
109
ECM equipment control
Front oxygen sensor Rear oxygen sensor
Clutch
switch
Power steering
switch
Canister VVT solenoid
solenoid valve valve
NL13-08099
2013 GX7
110

EM03 Harness connector of rear oxygen sensor 34
EM04 Harness connector of front oxygen sensor 34
EM13 Harness connector of VVT solenoid valve 34
EM25 Harness connector of carbon canister solenoid valve 34
EM05 Harness connector of power steering switch 34
EM02 To harness connector of instrument harness (1) 35
IP60 Harness connector of clutch switch 41
EX7 2013
111
ECM Sensor
CMP(Camshaft Position) Engine coolant temperature sensor Electric throttle
Electric accelerator pedal Air intake temperature pressure Vacuum pump sensor
sensor
2013 EX7
112
ECM sensor (DSI)
Engine coolant temperature

Camshaft position sensor sensor Electronic throttle valve
Electronic Intake temperature & Vacuum pump

accelerator pedal pressure sensor sensor
NL13-08168
2013 GX7
113

EM18 Harness connector of front oxygen sensor 34
EM23 Harness connector of rear oxygen sensor 34
IP51 Harness connector of electric accelerator pedal 40
EM30 Harness connector of air intake pressure temperature sensor 34
EM44 Harness connector of vacuum pump sensor 34
EX7 2013
114
Speed Sensor
2 EM21 1 EM21
3 EM21 3 EM21
G
G
L
Br
6 EM02 6 EM02 14 EM02
6 IP17 6 IP17 14 IP17

EM01-51
EM01-51
To ECM
To ECM
Br
W
P
8 IP01 12 IP01
SPEED IN 8V POWER
OUT
IPC
NL13-08148
2013 GX7
115

EM02 To harness connector of instrument harness 35
IP17 To harness connector of engine harness 40
IP01 Harness connector of combination instrument 41
IP33 To body harness connector 2 40
SO10 To instrument harness connector 3 50

EM21-3 To parking control module SO32-3 194
EM21-3 To engine control module EM01-51 100
EX7 2013
116
Cooling Fan Control
Engine
ccompartment,
Fuse, relay
box
Engine Cooling fan Cooling fan Cooling fan

main high low speed high speed high low
relay relay 1 relay speeds relay
2
Cooling
Cooling fan
fan motor 2
motor 1
2013 EX7
117
Cooling fan control (DSI)
Engine
ccompartment,
Fuse, relay
box
Cooling
Cooling fan
Engine Cooling fan fan high high/low
main high/low speed speed
relay speed relay 1 relay relay 2
Cooling
fan Cooling
motor 1 fan
motor
2
NL13-08169
GX7 2013
118

CA09 Harness connector of cooling fan motor (1) 28
CA10 Harness connector of cooling fan motor (2) 28
EX7 2013
119
TCU power source, ground point and data cable (DSI)
Indoor fuse Indoor fuse

relay box relay box
To BCM
Gear
selector, AT
Gear selector
protection
module
Transmission gear position

connector
NL13-08152
GX7 2013
120
TCU Transmission Control
Transmission actuator
Transmission actuator
EX7 2013
121

IP67 To engine harness connector (2) 41
IP68 TCU harness connector 1 41
IP71 Harness connector of auto gear shift 41
IP72 Harness connector of self gear shifting protection module 41
EM41 Harness connector of transmission gear position 34

EM42 Harness connector of transmission actuator 34

IP71-5 To brake lamp switch IP56-4 188
IP71-2 To BCM IP63-16 98
2013 EX7
122
Engine a nti- th ef t system
Indoor fuse
relay box
A nti-theft
coil
immobilizer module
Instrument
panel DLC
NL13-08112
2013 GX7
123

EM01 To harness connector of engine control module 35
IP12 Harness connector of diagnosis connector 40
IP24 Immobilizer connector 1 40
IP25 Immobilizer module connector 2 40
IP43 Harness connector of electronic anti-theft coil 41
2013 EX7
124
Instrument panel power source & ground
Indoor fuse
relay box
NL13-08113
2013 GX7
125

2013 EX7
EX7
To left front
optical axis
regulator
To left front
combination
headlamp
To front fog
Combination Instrument Lighting, Indicator
lamp relay
To left front
combination
headlamp
To ECM
To rear fog
lamp relay
To high beam
lamp relay
To lighting
combination
switch
2013
126
127

EM36 To engine compartment harness connector 2 35
CA22 To engine harness connector 2 28
Connection point Pages

To left front optical axis regulator motor CA19-3 131
IP01 -14
To FL combination headlamp CA16-6 131
To FL combinatio n headlamp CA12-7 131
IP01-26
To engine control module EM01-35 100
To high beam lamp relay ER02-2 131
IP01-25
To lighting combination switch IP42-7 132
IP01-27 To rear fog lamp relay IR01-5 136
IP01-28 To front fog lamp relay ER01-5 136
2013 EX7
128
Sound warning & alarm of instrument panel
To PDC control module

Headlamp beam axis
To A/C control panel
To parking switch
regulating switch
To immobilizer
To alternator
(automatic)
module
Radio & CD Reversing radar

indicator lamp
Vehicle speed sensor
Fuel Brake Oil Parking

level fluid pressure brake
sensor level sensor switch
sensor
To parking
sensor
I nstrument panel
background
regulating switch
NL13-08115
2013 GX7
129

IP23 Radio / CD player harness connector 3 41
SO10 To instrument panel harness connector 3 50
EM10 Oil pressure switch 34
IP28 Harness connector of parking brake switch 40
CA20 Harness connector of brake fluid level sensor 28
IP08 Harness connector of combination adjusting switch 41
SO27 Harness connector of fuel fluid sensor 50
G6 Instrument grounding 70
G4 Engine compartment grounding 67

IP01-16 To immobilizer module IP24-3 117
IP01-30 To alternatorEM11-1 94
IP01-7 To parking radar indication lamp IP10-2 194
IP01-29 To headlamp lighting shaft adjusting switch IP14-4 132
2013 EX7
130
Multi-function Instrument
Fuse relay box

of engine
compartment
Indoor fuse
relay box
IPC
Combination
instrument
EX7 2013
131

IP03 Harness connector of multi-function instrument 40
2013 EX7
132
ABS Power Supply, Grounding, Data Line
Engine Indoor fuse

compartment relay box
fuse, relay box
To To
EX7 2013
133

CA13 Harness connector of ABS control module 28
EM01 Engine control module 35
G6A Engine compartment grounding 67
2013 EX7
134
ABS Sensor
RR speed sensor RL speed sensor
FR speed sensor FL speed sensor

Brake lamp switch
EX7 2013
135
CA07 Harness connector of FL wheel speed sensor 28
CA16 Harness connector of FR wheel speed sensor 28
SO25 Harness connector of RRwheel speed 50
SO28 Harness sensor of RL wheel speed sensor 50
2013 EX7
136
Headbeam System 1
Combination
instrument
Fuse relay box of engine

compartment
High Low beam

beam relay
lamp ER11
relay
ER02
FL FL optical axis
combi nation regulator motor
headbeam
High beam Low beam
EX7 2013
137
Headb eam system 2
Indoor fuse
relay box
Engine
compartment
fuse relay
box
Environment light sensor
Indoor fuse
relay box
Light combination
switch
Position lamp
Low-beam
High-beam
Overtaking
lamp
Automatic
To background light
t
t Headbeam
High beam axis
regulating
- switch
Low beam FR optical axis
FR
combi nation regulator motor
headbeam
NL13-08119
GX7 2013
138
CA12 Harness connector of FLcombination headlamp 28
CA18 Harness connector of FR combination headlamp 28
CA19 Harness connector of FL optical axis regulating motor 28
CA26 Harness connector of FR optical axis regulating motor 28
IP05 Harness connector of ambient light sensor 40
IP14 Harness connector of headlamp lighting shaft adjusting switch 41
IP42 Harness connector of lighting combination switch 41
IP61 Body control module harness connector 1 41
IP14-4 To background light IP63-16 150
EX7 2013
139
Position Lamp

compartment
Indoor fuse relay box
license lamp
Left position Right position relay IR09
lamp relay lamp relay
IR08 IR06
Light
combination
switch
Position
Right license lamp

Left license lamp
Left rear combination lamp
(position lamp)
RL F L RR F R
position position position position
lamp lamp lamp lamp
2013 EX7
140
CA12 Harness connector of FL combination headlamp 28
CA18 Harness connector of FR combination headlamp 28
IP45 Harness connector of ignition switch 40
SO24 Harness connector of RR combination lamp 50
SO31 Harness connector of RL combination lamp 50
SO41 Harness connector of right license lamp 51
SO44 Harness connector of left license lamp 51
G13 Body harness grounding 71
G15 Back door grounding 72
EX7 2013
141
Fog lamp
Engine compartment fuse
relay box
Front fog
lamp
relay
Indoor
fuse
relay Rear fog lamp
box Front fog lamp
Rear
fog
lamp
relay
FL FR
fog fog
lamp lamp
Instrument panel
RL RR
fog fog
lamp lamp
NL13-08120
GX7 2013
142
CA06 Harness connector of FL fog lamp 28
CA23 Harness connector of FR fog lamp 28
IP32 To base plate harness connector 1 40
IP63 Harness connector of body control module3 41
SO29 To rear bumper harness connector 50
SO52 Harness connector of RR fog lamp 52
SO53 To body harness connector 52
SO54 Harness connector of RL fog lamp 52
G13 Body grounding 71
EX7 2013
143
T u rn s ingnals & hazard warning lamp 1

relay box
Indoor fuse
relay box
Hazard
warning
switch
Left side RL FL
turn turn turn
singnal singnal singnal
To hazard flasher
NL13-08121
GX7 2013
144
T u rn s ingnals & hazard warning lamp 2
Light
combination
switch
Left turn singnal
Right turn singnal
To BCM
FR RR Right side
turn turn turn Hazard
singnal singnal singnal flasher relay
NL13-08122
2013 GX7
145
Harness
Name Page
connector
CA12 FL combination headlamp harness connector 28
CA18 FR combination headlamp harness connector 28
DR01 To instrument panel harness connector 1 60
DR08 Left exterior rearview mirror connector 60
DR18 Right exterior rearview mirror connector 62
DR19 FR door to Instrument panel harness connector1 62
IP07 Hazard warning switch connector 42
IP13 To FR door harness connector 41
IP32 Body harness connector 1 41
IP38 To FL door harness connector 41
IP42 Light combination switch harness connector 42
IP62 BCM harness connector 2 42
IP79 Hazard flasher relay harness connector
SO24 RR combination lamp harness connector 52
SO31 RL combination lamp harness connector 52
GX7 2013
146
Brake lamp

relay box
Indoor fuse
relay box
Brake lamp
switch
Central high
RR braking RL braking mount break
lamp lamp lamp
NL13-08123
2013 GX7
147
IP56 Harness connector of brake lamp switch 40
SO46 Harness connector of high mount brake lamp 51
G13 Body grounding 71
2013 EX7
148
Reversi n g lamp
Indoor fuse
relay box
Reverse
lamp switch
RL reversing RR reversing
lamp lamp
PDC
Instrument
module
panel
Radio & CD
player
NL13-08124
2013 GX7
149
Reverse lamp (DSI)
Indoor use
relay box
Reverse
lamp
switch
RL reversing RR reversing
lamp lamp
Instrument
PDC panel
Radio & CD
player
NL13-08154
GX7 2013
150

EM22 Harness connector of reverse gear switch 34
EM41 Harness connector of transmission gear position 34
SO30 To back door harness connector 50
SO31 Harness connector of RL combination lamp 50
SO32 Harness connector of PDC module 50
EX7 2013
151
Reading Lamp
F ront reading lamp Rear reading lamp
2013 EX7
152
IP54 To roof harness connector 1 40
RF01 To instrument harness connector 1 47
RF05 Harness connector of rear reading lamp 47
RF12 Harness connector of front reading lamp 47
G6 Instrument harness grounding 70
EX7 2013
153
Door Step Lamp
F L door switch F R door switch
F L door F R door F ront

step lamp reading
step lamp
lamp
FRL door switch FRR door switch
2013 EX7
154
IP32 To body harne ss connector 1 40
DR01 FL door connecting to in strument panel harness connector 58
DR05 FL door step lamp connector 58
DR15 FR door step lamp connector 60
DR19 FR door connecting to instrument panel harness connector 60
RF12 Harness connector of front reading lamp 47
SO02 Harness connector of right front door control switch 50
SO16 To RL door harness connector 1 50
SO18 Harness connector of RL door switch 50
SO20 Harness connector of FL door switch 50
SO36 RR door contact switch 50
EX7 2013
155
Background lighting 1
+B ݀‫ۯ‬ऐ֝
ԍ၃ີी‫ۉ‬ഗ࢈
relay box
30A EF24

compartment
R
B CA03
B IP57 ๪ాԍ၃ີ
IG2 Indoor use
ी‫ۉ‬ഗ࢈
relay box
10A IF35
15A IF06
10A IF05
R/G
G/R
R/Y
3 IP65 15 IP64 20 IP62

BATT BATT IG2
SAVER PWR
BCM
POSITION LAMP SW LICENSE LAMP

34 IP61 16 IP63
B/W
14 IP42
A
14 16
L
OFF
2 IP08 Combination
2 IP06 Rear
4 IP14 Headlamp
12 IP16
Position࿋ዃ‫ڨ‬ ፇࢇ
adjusting ࢫ‫أ‬ຠ
defrost മቷ
lighting shaft ੣ۙ
switch
A/ / C control
lamp ࿋ዃ‫ڨ‬
Lighting ۙবਸ࠲ switch
ਸ࠲ adjusting
‫࠼ڨ‬ዡ ੦዆
switch panel (A uto)
‫࠼ڨ‬ፇࢇcombination
16 IP42
switch
Light ۙবਸ࠲ ௬ӱ
ਸ࠲
combination )ጲ‫*ۯ‬
switch 6 IP08 6 IP06 Rear 1 IP14 1 IP16
Adjustment defroster Headbeam axis
combination switch
B
switch adjustment switch

B
G6
NL13-08127
2013 EX7
156
Background lighting 2
L L L L L L
A B
L
25 IP38 25 IP13 10 IP32
L
L 25 DR01 25 DR19 10 SO09
L
1 IP29 3 IP30 1 DR13
L
Cigarette
L
FR power
L
iocking Cigarette Right front
door glass
L
mechanis Lighter
lighter window lifter
m switch
L switch switch
L
L
4 IP29 1 IP30 5 DR13
L
10 SO16 10 SO01
Central
lock 1 DR09 4 DR10
switch 10 DR21 10 DR31
Power Left front
Power rearviewdoor glass
L
rearviewmirror lifter
switch switch
B
mirror 1 DR26 1 DR36

switch Left back Right rear
B
8 DR09 15 DR10 door glass
lifter
RR power
door glass
lifter
window
B/W
FL power switch switch

B
window switch
switch
5 DR26 5 DR36
B/W
G8 G10 RL power
window
B
9 DR01 9 DR19 switch
2 DR21 2 DR31
9 IP38 9 IP13
2 SO16 2 SO01
B
B
B
B
G6 G11 G12
L L L L
B
L
2 IP82 2 IP07 Hazard Radio tape A/C Auto-

warning
lamp 6 IP21 player 9 IP27 control 2 IP71 shifter
panel lighting
switch
A uto gear
shifting
illumination
6 IP82 6 IP07 8 IP21 16 IP27 1 IP71

Back door Hazard Radio / CD A/ / C control
unlock switch player panel (E lectric)
B
switch
DSI
B
G6 G8
G6 G11
NL13-08151
EX7 2013
157

DR01 To instrument panel harness connector 58
DR09 Harness connector of power rear view mirror switch 58
DR10 Harness connector of FL power window switch 58
DR13 Harness connector of FR power window switch 60
DR19 Right front door connecting to instrument panel harness connector 60
DR21 Left rear door connecting to body harness connector 62
DR26 Harness connector of RL power window switch 62
DR31 Right rear door connecting to body harness connector 62
DR36 Harness connector of RR power window switch 62
IP06 Harness connector of rear defrost switch 41
IP07 Hazard warning lamp switch connector 41
IP08 Combination adjusting switch connector 41
IP27 Manual A/C control panel connector A 41
IP29 Central lock switch connector 40
IP30 Harness connector of cigarette lighter 40
IP42 Harness connector of light combination switch 41
IP71 Harness connector of auto-shifter 41
RF13 Harness connector of sunroof switch 47
SO01 To RR door harness connector 50
SO16 To RL door harness connector 50
2013 EX7
158
Power Supply, Grounding And Data Line 1 of Body Control Module (BCM)
IG1 relay
FL power
window
motor DR02-4 DLC
EX7 2013
159
Power Supply, Grounding and Data Line 2 of Body Control Module (BCM)
To ambient To To light To light To light To FL To FL To FL

light sensor background light combination combination combination power window power window power window
IP05-2 switch switch switch switch switch switch
IP42-8 IP42-6 IP42-14 DR10-11 DR10-12 DR10-13
To ignition To To FR To FR To central To central To central

power window power window
switch immobilizer lock lock lock
IP45-2 antenna switch switch switch switch switch
IP43-4 DR11-B DR11-A IP29-1 IP29-5 IP29-3
2013 EX7
160
To FL To FL To FL To FL To FL
To FL
power window power window power window power window
power window power window
switch switch switch switch switch
switch
DR10-8 DR10-9 DR10-10 DR10-1 DR10-2 DR10-3
To driver door To FR To RL To RR To driver door To FR To back To RL To RR

lock motor door lock lock motor door lock lock motor door lock door lock door lock door lock
DR04-9 motor DR14-1 DR25-1 motor DR35-9 DR04-3 motor DR14-7 motor SO43-1 motor DR25-7 motor DR35-3
EX7 2013
161
To wiper To wiper To wiper To wiper To hazard To lighting To lighting To lighting

combination combination combination combination warning switch combination combination combination
switch IP52-7 switch IP52-8 switch IP52-11 switch IP52-15 IP07-4 switch IP42-13 switch IP42-1 switch IP42-3
To left position To right To RL To RL To front To rear reading

lamp relay position lamp power window power window reading lamp lamp RF05-2
IR08-2 relay IR06-85 motor DR23-B motor DR23-A RF12-2
2013 EX7
162
To driver door To driver door To back To back To backdoor lamp

lock motor lock motor door lock motor door lock motor SO17-2
DR04-8 DR04-6 SO43-2 SO43-3
To RL To RR To RR To front wiper To front wiper To front wiper

power window power window power window motor CA14-3 motor CA14-2 motor CA14-1
motor R23-B motor DR33-B motor DR33-A
EX7 2013
163
DR21 RL door connecting to body harness connector 62
DR31 RR door connecting to body harness connector 62
SO01 To RR door harness connector 1 50
2013 EX7
164
Body Anti-theft Control System
FR
FL
door control door control
switch switch
Anti-theft alarm
lamp
RL RR
door control door control
switch switch
EX7 2013
165
IP39 Harness connector of anti-theft alarm lamp 40
SO02 Harness connector of FR door control switch 50
SO18 Harness connector of RL door control switch 50
SO20 Harness connector of FL door control switch 50
SO23 Harness connector of anti-theft horn 50
SO36 Harness connector of RR door control switch 50
2013 EX7
166
Center Control Lock 1
switch
door control
IP+B IP+B IG2

10A IF04
15A IF06
10A IF35
FL
FL FR RL RR
doorcontrol
control FR RLcontrol
door RR
door control
door
switch door control door control
switch switchdoor control
switch
switch switch switch
1 SO20 1 SO02 1 SO18 1 SO36
B/G
V/Y
V/G
V/B
R/Y
7 SO09 8 SO09 20 SO09 21 SO09

R/Y
A
7 IP32 8 IP32 20 IP32 21 IP32
W/B
G/R
R/Y
V/G
V/B
B/G
V/Y
1 IP63 3 IP65 20 IP62 14 IP62 15 IP62 36 IP62 35 IP62
P-DOOR BATT IG2 FLDR AJAR RLDR AJAR RLDR AJAR RRDR AJAR
BCM
POS- DOL DOL CENTRAL
LAMP LOCK UNLOCK UNLOCK
16 IP63 34 IP62 33 IP62 31 IP62 7 IP65
W/P
1 DR19
1 IP13 B
Gr/W
W/B
V/W
W/P
8 SO08
G
8 IP33
V/W
14 SO10
5 IP29 3 IP29
14 IP33
4 IP82 Backdoor
unlock C
switch
L
W/P
W/P
V/W
V/W
V/W
1 IP82 2 IP13 8 SO01 9 SO01 9 SO16 8 SO16

iocking
1 IP29 4
4 IP29
mechanism
switch
2 DR19 8 DR31 9 DR31 9 DR21 8 DR21
Central
lock
switch
W/P
W/P
W/P
V/W
V/W
V/W
B
B
RR RL
FR door lock door lock
1 DR14
door motor 3 DR35 motor 1 DR25
lock
motor FR RR
M door M door lock M RL
door lock
lock
motor motor
motor
7 DR14 9 DR35 7 DR25
G8 G6
NL13-08134
EX7 2013
167
Center Control Lock 2
Back door
lock motor
Trunk lamp
Driver door lock
motor
2013 EX7
168

DR04 Harness connector of FL door lock motor 58
DR14 Harness connector of FR door lock motor 60
DR21 Left rear door connecting to body harness connector 62
DR25 Harness connector of RL door lock motor 62
DR31 Right rear door connecting to body harness connector 62
DR35 Harness connector of RR door lock motor 62
IP29 Central door locking switch connector 40
SO02 Harness connector of FR door control switch 50
SO17 Harness connector of trunk lamp 50
SO18 Harness connector of RL door control switch 50
SO20 Harness connector of FL door control switch 50
SO36 Harness connector of RR door control switch 50
SO43 Harness connector of back door lock motor 51
G15 Back door harness grounding 72
EX7 2013
169
Power Rear View Mirror Control
Rearview mirror
adjustment switch
Left side turn signal Right side turn signal
2013 EX7
170
DR08 Left side exterior rearview mirror connector 58
DR09 Harness connector of power rearview mirror switch 58
DR18 Right side exterior rear view mirror connector 60
EX7 2013
171
Defroster control
Rear
defrosterlay
Rear
defroster
switch
Left
Rear Right
A/C ( Auto) exterior
windshield rearview exterior
defroster mirror rearview
mirror
A/C ( Manual)
NL13-08136
GX7 2013
172
DR08 Left side vehicle outer rear view mirror connector 58
DR18 Right side rearview mirror connector 60
IP06 Harness connector of rear defrost switch 41
IP27 Manual A/C control panel A 41
SO47 Rear defrost positive harness connector 51
EX7 2013
173
2013
Backrest
Power Seat Control
regulation motor
compartment
Front height
adjusting motor
D river power seat adjustment switch

Rear height
adjusting motor
Level regulation motor
Backrest
regulation motor
Height regulation
motor
P assenger power seat adjustment switch

Level regulation motor
EX7
174
SO05 Harness connector of passenger seat power window 50
SO11 Harness connector of driver power seat 50
EX7 2013
175
P o w er seat heating

Relay
D river seat Passenger seat

heating switch heating switch
D river Passenger
seat heater seat
heater
NL13-08039
GX7 2013
176
Harness
Name Page
connector
IP75 Harness connector of driver side seat-heating switch
IP76 Harness connector of passenger side seat-heating switch
IP33 To body harness connector 5
IP34 B ody harness connector 2
S004 Harness connector of passenger seat heater
S008 To instrument panel harness connector 1
S010 To instrument panel harness connector 3
S012 Harness connector of driver seat heat er
G8 Instrument panel grounding
G11 B ody harness ground
G12 B ody harness ground
2013 GX7
177
Front Wiper and Washer

IG1 relay
Interval
Front washer
Auto
Front
washer
Front wiper
motor
2013 EX7
178
CA14 Harness connector of front wiper motor 28
CA24 Harness connector of front washer 28
IP52 Harness connector of wiper washer combination switch 41
EX7 2013
179
Rear wiper washer
Wiper
combination
Rear wiper
switch
Rear washer
Rear
wiper
relay
Rear washer motor

Rear wiper motor
NL13-08040
GX7 2013
180
CA25 Harness connector of rear washer 28
IP52 Harness connector of wiper washer combination switch 41
SO40 Harness connector of rear wiper motor 51
EX7 2013
181
Headlamp Lighting Shaft Adjusting
T o F R head beam
axis ad justment motor
CA26-2
T o F L head beam
axis ad justment motor
CA19-2
H eadbeam axis
ad justment switch
2013 EX7
182
IP14 Headbeam axis adjusting switch 41
To FR axis regulator motor CA26-2 132

IP14-3
To FL axis regulator motor CA19-2 131
EX7 2013
183
A/C System Power Supply, Grounding, Signal (Auto)
Indoor fuse
relay box
Environment
temperature Sunlight sensor
A/C
pressure
switch
A / C (AUTO)
To background light To rear defrost To rear defrost To instrument

switch relay panel IP02 -11
2013 EC8
184
Harness connector Name Page
IP04
IP16
IP17
IP37
EM02
EM40
CA02
CA05
Connection point Description Page
IP16-12 To background light BCM IP49 -8
IP16-22 To rear defrost switch IP06-4
IP16-7 To rear defrost relay
IP16-6 To instrument panel IP02 -11
GX7 2013
185
Air-conditioner compressor clutch control (AUTO)
Engine Indoor fuse

Compartment relay box
Fuse and Relay
Box
Air-conditioner
relay
ER04
A/C pressure
switch
Compressor clutch
Compressor clutch
A / C (AUTO)
2013 EC8
186
Harness connector
CA22
EM01
EM40
EM36
EM02
EM09
IP16
IP17
GX7 2013
187
Blower (Auto)

IG1 relay
Blower
relay
IR03
Blower
A / C (AUTO)
2013 EC8
188
IP11
GX7 2013
189
Wind direction regulating motor (Auto)
A / C (AUTO)
Actuator for internal and Actuator for moistu Actuator for mode Evaporator sensor
external cycles re adjustment regulation
Evaporator assembly
2013 EC8
190
Air-conditioner system, GD (Electric)
Indoor fuse
relay box
A/C pressure
switch
A / C (Electric)
To background light
To rear defrost To rear defrost relay

switch
GX7 2013
191
EM01 ECM harness connector 35
EM40 Air-conditioner pressure switch harness connector 36
IP26 Air-conditioner control panel harness connector C (MANUAL） 41
IP27 Air-conditioner control panel harness connector A (MANUAL） 42
Connection point Description Page
IP27-9 To background light BCM IP63-16 153
IP27-14 To rear defrost switch IP06-4 168
IP27-13 To rear defrost relay 168
2013 EC8
192
A/C Power Supply, Grounding, Signal (manual)
A/C pressure
switch
A / C Manual
To background light
IP63-16
To rear defrost To rear defrost

switch IP06-4 relay
2013 EX7
193
IP26 A/C control panel harness connector C(Manual) 40
IP27 A/C control panel harness connector A (Manual) 41
IP27-14 To rear defrost switch IP06-4 166
IP27-13 To rear defrost relay 166
EX7 2013
194
A/C Compressor Clutch Control (Manual)

compartment
Engine main
relay ER09
A/C relay
ER04
A/C pressure
switch
A/C
compressor
clutch
A / C Manual
2013 EX7
195
EM09 Harness connector of A/C compressor relay 34
EX7 2013
196
Blower Control
Blower relay
IR03
Blower
A / C Electric
2013 EX7
197
IP11 Blower connector (Manual) 40
IP26 A/C control panel harness connector C(Manual) 40
EX7 2013
198
Wind Direction Regulation Motor
A / C Manual
Internal and external cycle actuator Water temperature regulation actuator Mode regulation actuator Evaporator sensor
Evaporator assembly
2013 EX7
199
Sound Main Engine Power Supply, Signal Grounding

ACC IP ALT
10A IF20
15A IF14
R/Y
R/L
4 IP21 7 IP21
ACC +B
Radio / CD plaYyer
GND
8 IP21 5 IP21 16 IP23 6 IP23
O
O
3 IP74
G/O
B/R
3 IP54
B
3 RF01 3 SO56
G/O
O
10 SO30
10 SO45
G9
G/O
1 RF14 1 SO48 11 IP01 32 IP01
Antenna Camera IPC
NL13-08047
2013 GX7
200

IP21 Ra dio/ C D player harness con1nector 1 41
IP23 Radio/ C D player harness con3nector 3 41
IP54 To inside lamp harness connector 1 40

IP74 To body harness connector
RF01 To instrument harness conn1ector 1 47
RF14 Antenna wire connector 47

SO56 To instrument connector harness connector
SO30 To back door harness connector
SO45 To body harness connector
SO48 To camera harness connector
GX7 2013
201
Main Speaker Control
Radio / CD plaYyer
Rig h t tw eeter F R speak er RR speak er RL speak er F L speak er L eft tw eeter
EX7 2013
202
DR06 Harness connector of FL door front speaker 58
DR07 FL door twteer harness 58
DR16 FR door speaker connector 60
DR17 FR door twteer speaker 60
DR21 To body harness connector 62
DR31 To body harness connector 62
IP22 Radio/CD player harness connector 2 41
SO01 To RR door harness connector 50
2013 EX7
203
20
Airbag (SRS) Power Supply, Grounding, Data Line
Passenger Driver safety

inspection belt switch
detection
sensor
Passenger
safety belt
switch
To CAN_H To CAN_L
EX7 2013
204
IP15 Harness connector of airbag module 40
IP33 To \body harness connector 2 40
SO07 Harness connector of passenger seat belt 50
SO13 Driver safety belt switch 50
2013 EX7
205
Airbag (SRS) Sensor 1
RR side RL side Rig h t side

c ollision sensor c ollision sensor c ollision sensor
EX7 2013
206
Airbag (SRS) Sensor 2
L eft side F R side F L side

c ollision c ollision sensor c ollision sensor
sensor
2013 EX7
207
CA11 Harness connector of FL collision sensor 28
CA21 Harness connector of right front collision sensor 28
SO21 Harness connector of right collision sensor 50
SO22 Harness connector of RR collision sensor 50
SO34 Harness connector of RL collision sensor 50
SO35 Harness connector of left collision sensor 50
EX7 2013
208
Safety Belt Pretensioner and Airbag
Cloc k spring
K
D riv er seat P asseng er seat D riv er seat D riv er seat
side airbag side airbag airbag Kk nee airbag airbag
P asseng er D riv er P asseng er side D riv er side

safety belt safety belt c urtain airbag c urtain airbag
pretensiner pretensiner
2013 EX7
209
20
IP19 Harness connector of passenger seat side airbag 40
IP41 Harness connector of driver airbag 41
IP44 Harness connector of knee airbag 40
RF04 Harness connector of driver air curtain 47
RF06 Harness connector of passenger air curtain 47
SO06 Passenger seat side airbag 50
SO15 Driver seat side airbag 50
SO19 Harness connector of driver safety belt pretensioner 50
SO37 Harness connector of passenger safety belt pretensioner 50
EX7 2013
210
Parking D ist anc e C ont rol 1
To instrument pack
To instrument pack
Instrument panel
brake switch
To parking
To left reverse
reverse lamp
To right
lamp
Parking sensor
indicator lamp
PD C
Rear central parking F L parking

sensor sensor
RL parking sensor RR parking sensor F R parking sensor
2013 GX7
211
21
CA29 Harness connector of FL radar sensor 28
CA30 Harness connector of FR radar sensor 28
CA31 To body harness connector 2 28
SO29 To rear bumper harness connector 50
SO32 PDC module harness connector 1 50
SO49 To harness connector of reverse radar probe1 52
SO53 To base plate harness connector 52
SO55 To engine compartment harness connector 2 50
To right reverse lamp SO24-4 143/144

SO32-4
To left reverse lamp SO31-4 143/144
SO32-3 To speed sensor EM21-3 110
To combination instrument IP01-9 123

SO32-5 To parking brake switch IP28-1 123
EX7 2013
212
Parking D ist anc e C ont rol 1
Camera Screen
1 IP58 2 IP58 3 IP58
B
3 IP74 1 IP74 2 IP74
B
3 SO56 1 SO56 2 SO56
G/O
G8
10 SO30 8 SO30 9 SO30
10 SO45 8 SO45 9 SO45

G/O
O
5 IP21 1 SO48 3 SO48 4 SO48 2 SO48
Radio
Camera
NL13-08082
2013 GX7
213
Harness Connector Description Pages

IP21 Radio / CD and player harness connector 1
IP74 To b ody harness connector

IP58 Camera harness connector
SO56 To instrument panel harness connector
SO45 To b ody harness connector
SO30 To b ack door harness connector
GX7 2013
214
Horn
Fuse relay box of

engine compartment
Horn relay
ERO8
F L h orn F R h orn
Clock spring
Horn switch
2013 EX7
215
21
CA15 Harness connector of FL horn 28
CA17 Harness connector of FR horn 28
IP40 Harness connector of clock spring 41
EX7 2013
216
Cigarette Lighter, Power Supply Socket
To back-lighting BCM
IP63-16
Spare power
Cigarette
Lighter supply
2013 EX7
217
IP30 Harness connector of cigarette lighter 40
IP53 Harness connector of spare power supply 40
EX7 2013
218
Sunroof System
Sunroof
module
Sunroof
switch
2013 EX7
219
RF07 Harness connector of sunroof module 47
EX7 2013
220
Front Left Power Window (Only Driver Side Door with Anti-Clamp Function) 1
F L door p ow er
w indow sw it ch
F L w indow
l if t ing mot or
2013 EX7
221
Frong Right Power Window (Only Driv er Side Door with Anti-Clamp Function) 2
To FL power window switch
F R door p ow er
w indow sw it ch
F R p ow er
w indow mot or
EX7 2013
222
Rear Left Power window (Only Driver Side Door with Anti-clamp Function) 3
F L power window switch
FRL door
p ow er
w indow
sw it ch
RL p ow er
w indow mot or
2013 EX7
223
Rear Right Power Window (Only Driv er Side Door with Anti-clamp Function) 4
To FL power window switch
To background light
IP63-16
FRR door p ow er
w indow sw it ch
RR p ow er
w indow mot or
EX7 2013
224
DR02 FL power window motor connector 58
DR10 Harness connector of FL power window switch 58
DR11 FR power window\ motor harness connector 1 60
DR13 Harness connector of FR power window switch 60
DR21 RL door connecting to body harness connector 62
DR23 Harness connector of RL power window motor 62
DR26 Harness connector of RL power window switch 62
DR31 RR door connecting to body harness connector 62
DR33 Harness connector of RR power window motor 62
SO16 To RL door harness connector 1 51
2013 EX7
225
Diagnosis Connector
To immobilizer
module IP24-7
To BCM IP62-13
EX7 2013
226
IP12-7 To immobilizer module IP24-7 117
IP12-13 To BCM IP62-13 153
2013 EX7
227
CAN Data Communications Network
DSI model
EX7 2013
228
IP15 Harness connector of airbag control module 40
IP70 TCU3harness connector 41
2013 EX7
229 13.10 Abbreviation
English Abbreviation Specification
ABS Anti-lock Braking System
A/C Air Conditioner
ACU Airbag control module
ALT Alternator
BCM Body control module
CAN Controller area network
CKP Crankshaft position sensor
CMP Camshaft position sensor
DLC Data Link Control
ECM Engine control module
ECT EngineCoolant temperature sensor
EVAP Charcoal carbon canister solenoid valve
FL Front Left
FR Front Right
HO2S Oxygen sensor
IAC Idling speed control valve
IAT Air intake temperature sensor
IMMO Immobilizer
IPC Combination instrument
KS Knock sensor
MAP Air intake manifold absolute pressure sensor
PDC Parking Distance Control
RL Rear Left
RR Rear Right
TPS Throttle position sensor
VSS Vehicle Speed Sensor
2013 EX7

Wiring

Uploaded by

Document Information

Copyright

Available Formats

Share this document

Share or Embed Document

Sharing Options

Did you find this document useful?

Is this content inappropriate?

Copyright:

Available Formats

Wiring

Uploaded by

Copyright:

Available Formats

2013

2013 Geely Automotive Co., Ltd.

13.1 Wiring Diagram Description ...................................................................................................... ....................... 2

13.2 Mark Symbols .................................................................................................................................................. 6

13.3 Diagnosis and Maintenance Methods and Specification .................................................................................. 8

13.4 Fuse and Relay ............................................................................................................................................... 15

13.5 Layout of Harness and the Connector ............................................................................................................ 26

13.6 Layout of Grounding Points ........................................................................................................................... 69

13.7 Power Configurations..................................................................................................................................... 81

13.8 Wiring Diagram .............................................................................................................................................. 89

13.10 Abbreviation ............................................................................................................................................... 229

Front wiper motor

Front wiper switch

Indoor fuse, Indoor fuse,

Rear washer motor

Rear wiper switch

Rear wiper motor

Color code Guide wire color Illustration

Left rear Right

14 If “8” shape mark is used between circuit lines and

15 If the content of a system is so much that its circuit

Short splicing SPDT relays Cigarette lighter

Solenoid Resistance Antenna

Middle load Variable Common closed

Big load fuse Ignition coil Double SPDT relays

Heater Knock sensor Ignition switch

Diode Bulb Twisted pair

LED Horn Fan assembly

Motor Clock spring Oxygen sensor

Low speed fan

Safety belt Disconnecting Connecting cross

Connect to ignition switch SW

If a diode is contained in the electrical circuit, exchange Short circuit to

3 during electrical circuit inspection, it is necessary to

Digital meters Press down

Chock Terminal holder

Holder is in the temporary locking position

A. Non-water proof connector

Holder is in the safety locking position

B. Water proof connector

Terminal holder Connector

Press down Press down

Insert the special tool into insertion hole (Y mark) of

Holder is in the temporary locking

B. Push the secondary lock device to full locking

Holder is in the temporary locking

C. Release the terminal locking plate and pull out the

Tools Handling Process of Poor Grounding

4 Install the terminal.

3.Clean body side grounding point by roving cloth, until

4. Installed grounding point harness and fixing bolt, and

Engine Compartment Fuse and Relay Box

M ain fuse EF40

Internal Wiring Diagram of Engine Compartment Fuse, Relay Box

Internal Wiring Diagram of Engine Compartment Fuse, Relay Box (Continued 1)

Internal Wiring Diagram of Engine Compartment Fuse, Relay Box (Continued 2)

Fuse List of Engine Compartment

NO. Description Rated current(A) Descriptions

Relay List of Engine Compartment

NO. Description Descriptions

Ind oor fuse & relay box

Internal Wiring Diagram of Indoor Fuse, Relay Box

Internal Wiring Diagram of Indoor Fuse, Relay Box (Continued)

List of Indoor Fuse
