Scamec 2000 S 100101660 #FB170

Electrics

Assembly:5 Page:5
 Scamec 2000 S 100101660 #FB170
Electrics

Item Part No. Description Standard designation Qty Units

47026590 Instrument panel
47028270 Warning light unit
47026610 Seat switch panel
100043963_1 Carrier electric schema, Page 1/7
100043963_2 Carrier electric schema, Page 2/7
100043963_3 Carrier electric schema, Page 3/7
100043963_4 Carrier electric schema, Page 4/7
100043963_5 Carrier electric schema, Page 5/7
100043963_6 Carrier electric schema, Page 6/7
100043963_7 Carrier electric schema, Page 7/7
47026910 Terminal box TB1
100043952 Main fuse box
100022876 Electric schema, Start blocking relay
45920280 Terminal box TB6
47026620 Terminal box TB20
45747350 Terminal box TB39
47026580_1 Cabin electric schema, Page 1/2
47026580_2 Cabin electric schema, Page 2/2
47026840_1 Electric schema, Scaler, Page 1/4
47026840_2 Electric schema, Scaler, Page 2/4
47026840_3 Electric schema, Scaler, Page 3/4
47026840_4 Electric schema, Scaler, Page 4/4
100008484 Hammer hour meter kit
100083664 Powerpack kit
100083667 High voltage box
100083688_1 Electric schema, 400V/50Hz, Page 1/2
100083688_2 Electric schema, 400V/50Hz, Page 2/2
100034927 Reverse camera kit
100071381 Reverse alarm / reversing sensors
100103582_1 Electric scheme, Brake activation kit, Page 1/2
100103582_2 Electric scheme, Brake activation kit, Page 2/2

Assembly:5 Page:5
 Scamec 2000 S 100101660 #FB170
Instrument panel

S50,51

TB7 H25 S83

P9 S50 S51
P1 S144 S200
W(P1-P9)
P5 P3

S168 S54 H38

W(P3-P5) S302 S175
H7 W(P1-P3)

S2 S379
S136 S4 S5 SH22 S108 S125 S75
LA1 LA1

K16B
X7

X7 DIODE

K19

Assembly:47026590 Page:5_1
 Scamec 2000 S 100101660 #FB170
Instrument panel

Item Part No. Description Standard designation Qty Units

H7 55156380 SIGNAL LIGHT 1
47028390 SYMBOL-PARKING BRAKE 1
H25 47028270 WARNING LIGHT UNIT 1
55131395 BULB 24V 1
55140735 MULTIPOLE CONNECTOR 2
H38 100016401 INDICATOR LIGHT FRAME 1
100016414 LENS PART 1
47027430 SYMBOL 1
K16B 55119747 RELAY 24V 1
55119788 RELAY BASE 1
K19 55114292 BLINK RELAY 24V 1
LA1 47026890 SYMBOL SERIE 1
P1 100007785 TEMPERATURE GAUGE 1
P3 100007788 TEMPERATURE GAUGE 1
P5 100007790 FUEL LEVEL GAUGE 1
P9 100007778 TACHOMETER / DOT MATRIX DISPLAY MACHINE DETAILS NEEDED 1
55155500 WIRING HARNESS 1
S2 55137608 IGNITION SWITCH 1
57700692 KEY 1
55137574 CONNECTING PLUG 1
55137582 CONNECTING PLUG 1
47026900 SYMBOL-KEYSWITCH 1
100033380 SYMBOL-WAIT 10S BEFORE RESTART 1
S4 100012154 ROTATING SWITCH 1
100009027 CONTACT FRAME 1
S5 100012154 ROTATING SWITCH 1
100009027 CONTACT FRAME 1
S50,51 47026770 SYMBOL-REAR SUPPORTLEGS 1
S50 100016485 PUSH BUTTON 1
100016011 CONTACT FRAME 1
100016416 SILICONE COVER 1
S51 100016485 PUSH BUTTON 1
100016011 CONTACT FRAME 1
100016416 SILICONE COVER 1
S54 100016485 PUSH BUTTON 1
100016011 CONTACT FRAME 1
100016416 SILICONE COVER 1
47022660 SYMBOL-SUPPORT LEG 1
S75 100004994 ROTATING SWITCH 1
100016011 CONTACT FRAME 1
S83 100016325 MUSHROOM SHAPED PUSH BUTTON 1
100016405 CONTACT FRAME 1
55156900 SYMBOL-EMERGENCY STOP 1
S108 100012154 ROTATING SWITCH 1
100009027 CONTACT FRAME 1
S125 100004994 ROTATING SWITCH 1
100016011 CONTACT FRAME 1
S136 100016326 SWITCH BUTTON 1
100009027 CONTACT FRAME 1
47020580 SYMBOL-DIAGNOSIS 1
S144 100004994 ROTATING SWITCH 1
100016011 CONTACT FRAME 1
47016450 SYMBOL-HAND THROTTLE +/- 1
S168 100016485 SWITCH BUTTON 1
100016011 CONTACT FRAME 1
100016416 SILICONE COVER 1
47011610 SYMBOL-PUSH PLATE 1
S175 100004994 ROTATING SWITCH 1
100016011 CONTACT FRAME 1
47018620 SYMBOL-CABIN TILTING 1
S200 100004994 ROTATING SWITCH 1
100016011 CONTACT FRAME 1
47026880 SYMBOL-CABIN LIFTING 1
S302 100012154 ROTATING SWITCH 1
100009027 CONTACT FRAME 1
47016440 SYMBOL-HAND THROTTLE ON/OFF 1
S379 100016326 SWITCH BUTTON 1
100009027 CONTACT FRAME 1
47024600 SYMBOL-OVERRIDE BUTTON 1
Assembly:47026590 Page:5_1
 Scamec 2000 S 100101660 #FB170
Instrument panel

S50,51

TB7 H25 S83

P9 S50 S51
P1 S144 S200
W(P1-P9)
P5 P3

S168 S54 H38

W(P3-P5) S302 S175
H7 W(P1-P3)

S2 S379
S136 S4 S5 SH22 S108 S125 S75
LA1 LA1

K16B
X7

X7 DIODE

K19

Assembly:47026590 Page:5_1
 Scamec 2000 S 100101660 #FB170
Instrument panel

Item Part No. Description Standard designation Qty Units

SH22 100016409 ROTATING SWITCH 1
SH22 100016320 CONTACT FRAME 1
SH22 55123244 BULB 24V 3W 1
TB7 47011670 ELECTRIC BOX 1
W(P1-P3) 100007802 WIRING HARNESS 1
W(P1-P9) 100007801 WIRING HARNESS 1
W(P3-P5) 100007802 WIRING HARNESS 1
X7 55150924 END CLIP 2
X7 55150817 TERMINAL BLOCK 50
X7 55150775 TERMINAL BLOCK 5
X7 55150809 END PLATE 4
X7 DIODE 55117055 DIODE 3A 20
X7 DIODE 55150866 TERMINAL BLOCK 20
X7 DIODE 55150668 END PLATE 1

Assembly:47026590 Page:5_1
 Scamec 2000 S 100101660 #FB170
Warning light unit

H25

H71 H46

H19 H39

H72 H23

H28 H8

H6 H27

Assembly:47028270 Page:5_2
 Scamec 2000 S 100101660 #FB170
Warning light unit

Item Part No. Description Standard designation Qty Units

H25 55142079 SIGNAL LIGHT UNIT 1
55123236 BULB 10
H6 55142137 SYMBOL 1
H8 55142152 SYMBOL 1
H19 55142434 SYMBOL 1
H23 55142129 SYMBOL 1
H27 55142848 SYMBOL 1
H28 55134381 SYMBOL 1
H39 55151690 SYMBOL 1
H46 55155430 SYMBOL 1
H71 55151290 SYMBOL 1
H72 55134340 SYMBOL 1

Assembly:47028270 Page:5_2
 Scamec 2000 S 100101660 #FB170
Seat switch panel

Assembly:47026610 Page:5_3
 Scamec 2000 S 100101660 #FB170
Seat switch panel

Item Part No. Description Standard designation Qty Units

H44 100016438 INDICATOR LIGHT 1
55123244 BULB 24V 3W 1
S8 100016326 PUSH BUTTON 1
100009027 CONTACT FRAME 1
S21 100016325 EMERGENCY STOP SWITCH 1
100016405 CONTACT FRAME 1
100013720 CONTACT BLOCK 1
SH1 100016324 PUSH BUTTON WITH SIGNAL LIGHT 1
100016320 CONTACT FRAME 1
55123244 BULB 24V 3W 1

Assembly:47026610 Page:5_3
 Scamec 2000 S 100101660 #FB170
Carrier electric schema, Page 1/7

F5
F12 F4
F3
F2
F1
F13
S2

F14

K5
K16

K11
F10

F11

G2 G1

F15 K2
G3

S1 M1

Assembly:100043963_1 Page:5_4
 Scamec 2000 S 100101660 #FB170
Carrier electric schema, Page 1/7

Item Part No. Description Standard designation Qty Units

F1 55138077 CIRCUIT BREAKER 1
F2 55138077 CIRCUIT BREAKER 1
F3 55138077 CIRCUIT BREAKER 1
F4 55138077 CIRCUIT BREAKER 1
F5 55138077 CIRCUIT BREAKER 1
F10 100043952 MAIN FUSE BOX 1
F11 55125868 FUSE 600A 1
F12 55125801 FUSE 10A 1
55150932 FUSE TERMINAL 1
F13 55125801 FUSE 10A 1
55150932 FUSE TERMINAL 1
F14 55125819 FUSE 7,5A 1
55150932 FUSE TERMINAL 1
F15 55125819 FUSE 7,5A 1
55150932 FUSE TERMINAL 1
G1 55124168 BATTERY 12V/140AH 1
G2 55124168 BATTERY 12V/140AH 1
G3 100004872 ALTERNATOR 1
K2 55153090 RELAY KIT 1
K5 55119317 RELAY 1
K11 55119317 RELAY 24V 1
K16 55119317 RELAY 24V 1
M1 100064989 START MOTOR 1
S1 55128078 MAIN SWITCH 1
S2 55137608 IGNITION SWITCH 1
55137574 CENTRAL PLUG CONNECTOR 1
55137582 CENTRAL PLUG CONNECTOR 1
55147151 RECEPTACLE 1

Assembly:100043963_1 Page:5_4
 Scamec 2000 S 100101660 #FB170
Carrier electric schema, Page 2/7

F8
F7
F6

S83

S21

K3 SH1
S27

K2

K5

Y2 Y75
K22 K17 K21
SH1 PC5
PC10

Assembly:100043963_2 Page:5_5
 Scamec 2000 S 100101660 #FB170
Carrier electric schema, Page 2/7

Item Part No. Description Standard designation Qty Units

F6 55138077 FUSE 10A 1
F7 55138077 FUSE 10A 1
F8 55138077 FUSE 10A 1
K2 55153090 RELAY KIT 1
K3 55119747 RELAY 24V 1
55119788 RELAY BASE 1
K5 55119747 RELAY 24V 1
55119788 RELAY BASE 1
K17 55119747 RELAY 24V 1
55119788 RELAY BASE 1
K21 55119747 RELAY 24V 1
55119788 RELAY BASE 1
K22 55119747 RELAY 24V 1
55119788 RELAY BASE 1
S27 55137806 SELECTOR SWITCH 1
S21 100016325 EMERGENCY STOP SWITCH 1
100016405 CONTACT FRAME 1
100013720 CONTACT BLOCK 1
S83 100016325 MUSHROOM SHAPED PUSH BUTTON 1
100016405 CONTACT FRAME 1
SH1 100016324 SWITCH BUTTON 1
100016320 CONTACT FRAME 1
55123244 BULB 24V 3W 1
Y2 57701880 SOLENOID COIL 1
Y75 57701880 SOLENOID COIL 1

OPTIONAL EQUIPMENT FOR SOLENOID COILS

PC5 55138663 PLUG CABLE L=5M 1
PC10 55148720 PLUG CABLE L=10M 1

Assembly:100043963_2 Page:5_5
 Scamec 2000 S 100101660 #FB170
Carrier electric schema, Page 3/7

F11
F10
F9

F6

P5 P1 P3
P9

B5 B2 B1

Assembly:100043963_3 Page:5_6
 Scamec 2000 S 100101660 #FB170
Carrier electric schema, Page 3/7

Item Part No. Description Standard designationQty Units

B1 55115828 SENSOR 1
B2 55115604 SENSOR 1
B5 100071757 FUEL LEVEL SENSOR 1
F6 55150932 FUSE TERMINAL 1
55125827 FUSE 1
F9 55138077 FUSE 10A 1
F10 55131635 FUSE 15A 1
F11 55138077 FUSE 10A 1
P1 100007785 TRANSMISSION TEMPERATURE GAUGE 1
P3 100007788 COOLANT TEMPERATURE GAUGE 1
P5 100007790 FUEL GAUGE 1
P9 100007778 TACHOMETER / DOT MATRIX DISPLAY MACHINE DETAILS NEEDED 1

Assembly:100043963_3 Page:5_6
 Scamec 2000 S 100101660 #FB170
Carrier electric schema, Page 4/7

K2 S8

H25 FY68
H7 K29

K68

Y68

S311A S10 S35 S35 S13 S15

S118
H9
S34
PC5
PC10

Assembly:100043963_4 Page:5_7
 Scamec 2000 S 100101660 #FB170
Carrier electric schema, Page 4/7

Item Part No. Description Standard designation Qty Units

H7 55156380 SIGNAL LIGHT 1
47028390 SYMBOL-PARKING BRAKE 1
H9 55116198 HORN 1
H25 47028270 WARNING LIGHT UNIT 1
K2 55153090 RELAY KIT 1
K29 55119747 RELAY 24V 1
55119788 RELAY BASE 1
K68 100006874 TIMER DELAY RELAY 1
S8 100016326 SWITCH BUTTON 1
100009027 CONTACT FRAME 1
S10 55121701 SENSOR 1
S13 55121636 SENSOR 1
S15 55121701 SENSOR 1
S34 55121172 SENSOR 1
S35 55115562 SENSOR 2
S118 100079530 SENSOR 1
S311A 57702310 SENSOR 1
FY68 55150932 FUSE TERMINAL 1
55125892 FUSE PLATE 1
Y68 57829040 SOLENOID COIL 1

OPTIONAL EQUIPMENT FOR SOLENOID COILS

PC5 55138663 PLUG CABLE L=5M 1
PC10 55148720 PLUG CABLE L=10M 1

Assembly:100043963_4 Page:5_7
 Scamec 2000 S 100101660 #FB170
Carrier electric schema, Page 5/7

K19 S5 S4

SH22 S19

K24 K7

K23

E7 E8
E21 E20 E5 H11 E6
H13 H17 E1 E2 E3 E4

Assembly:100043963_5 Page:5_8
 Scamec 2000 S 100101660 #FB170
Carrier electric schema, Page 5/7

Item Part No. Description Standard designation Qty Units

E1 55120463 HEAD LIGHT 24V 1
55123384 BULB H3 24V / 70W 1
55140990 COUPLING 1
E2 55120463 HEAD LIGHT 24V 1
55123384 BULB H3 24V / 70W 1
55140990 COUPLING 1
E3 55120463 HEAD LIGHT 24V 1
55123384 BULB H3 24V / 70W 1
55140990 COUPLING 1
E4 55120463 HEAD LIGHT 24V 1
55123384 BULB H3 24V / 70W 1
55140990 COUPLING 1
E5 55154340 PARKING LIGHT 1
E6 55154340 PARKING LIGHT 1
E7 46010690 BRAKE LIGHT KIT 1
E8 46010700 BRAKE LIGHT KIT 1
E20 55154340 SIDE LIGHT 1
E21 55154340 SIDE LIGHT 1
H11 55155760 BLINKER LIGHT 1
H13 55155760 BLINKER LIGHT 1
H17 55118955 BACK UP ALARM 1
K7 55119747 RELAY 1
55119788 RELAY BASE 1
K19 55114292 BLINKER RELAY 24V 1
K23 100022876 START BLOCKING RELAY SCHEMA 1
K24 55119747 RELAY 1
55119788 RELAY BASE 1
S4 100012154 SWITCH 1
100009027 CONTACT FRAME 1
S5 100012154 SWITCH 1
100009027 CONTACT FRAME 1
S19 55121727 SENSOR 1
SH22 100016409 SWITCH 1
100016320 CONTACT FRAME 1
55123244 BULB 24V 3W 1

Assembly:100043963_5 Page:5_8
 Scamec 2000 S 100101660 #FB170
Carrier electric schema, Page 6/7

XJ60

S40

K15 R24
K17 S307
S18

S136

Assembly:100043963_6 Page:5_9
 Scamec 2000 S 100101660 #FB170
Carrier electric schema, Page 6/7

Item Part No. Description Standard designation Qty Units

K15 55119747 RELAY 1
55119788 RELAY BASE 1
K17 55119747 RELAY 1
55119788 RELAY BASE 1
R24 55142772 RESISTOR 1
S18 55115133 SENSOR 1
S40 55153490 SENSOR 1
S136 100016326 PUSH BUTTON 1
100009027 CONTACT FRAME 1
S307 100028022 SENSOR 1
XJ60 55152740 DIAGNOSTIC PLUG 1

Assembly:100043963_6 Page:5_9
 Scamec 2000 S 100101660 #FB170
Carrier electric schema, Page 7/7

A8A A8B

S144 S302 S379

Assembly:100043963_7 Page:5_10
 Scamec 2000 S 100101660 #FB170
Carrier electric schema, Page 7/7

Item Part No. Description Standard designation Qty Units

A8A 54825590 ELECTRIC THROTTLE PEDAL 1
55154270 CONNECTOR KIT 1
A8B 54825590 ELECTRIC THROTTLE PEDAL 1
55154270 CONNECTOR KIT 1
S144 55121353 SWITCH 1
55151586 CONTACT FRAME 1
S302 100012154 SWITCH 1
100009027 CONTACT FRAME 1
S379 100016326 PUSH BUTTON 1
100009027 CONTACT FRAME 1

Assembly:100043963_7 Page:5_10
 Scamec 2000 S 100101660 #FB170
Terminal box TB1

K49 V16

X1 X1

R5

K23
K22 K17 K21 K5 K29 K68 K24 K7 K15 K3 K65

K5
F1 F2 F3 K2
F4 F5 F6 F7 F8 F9 F10 F11
X22

K16 K11

Assembly:47026910 Page:5_11
 Scamec 2000 S 100101660 #FB170
Terminal box TB1

Item Part No. Description Standard designation Qty Units

F1 55138077 CIRCUIT BREAKER 10A 1
F2 55138077 CIRCUIT BREAKER 10A 1
F3 55138077 CIRCUIT BREAKER 10A 1
F4 55138077 CIRCUIT BREAKER 10A 1
F5 55138077 CIRCUIT BREAKER 10A 1
F6 55138077 CIRCUIT BREAKER 10A 1
F7 55138077 CIRCUIT BREAKER 10A 1
F8 55138077 CIRCUIT BREAKER 10A 1
F9 55138077 CIRCUIT BREAKER 10A 1
F10 55131635 CIRCUIT BREAKER 15A 1
F11 55138077 CIRCUIT BREAKER 10A 1
K2 55153090 RELAY KIT 1
K3 55119747 RELAY 24V 1
55119788 RELAY BASE 1
K5 55119317 RELAY 24V 1
55119788 RELAY BASE 1
K7 55119747 RELAY 24V 1
55119788 RELAY BASE 1
K11 55150387 RELAY 1
K15 55119747 RELAY 24V 1
55119788 RELAY BASE 1
K16 55119317 RELAY 1
K17 55119747 RELAY 24V 1
55119788 RELAY BASE 1
K21 55119747 RELAY 24V 1
55119788 RELAY BASE 1
K22 55119747 RELAY 24V 1
55119788 RELAY BASE 1
K23 100022876 START BLOCKING RELAY SCHEMA 1
K24 55119747 RELAY 24V 1
55119788 RELAY BASE 1
K29 55119747 RELAY 24V 1
55119788 RELAY BASE 1
K49 55137038 SAFETY RELAY 1
K65 55119747 RELAY 24V 1
55119788 RELAY BASE 1
K68 100006874 TIMER DELAY RELAY 1
R5 100027830 WIRE RESISTOR 3A 1
55147235 PLUG-IN CONNECTOR 3A 1
55117055 DIODE 3A 1
V16 55117055 DIODE 3A 1
X1 55150817 DOUBLE DECK TERMINAL BLOCK 75
55150825 END PLATE 2
55150924 END CLIP 2
55150726 TERMINAL BLOCK 3
55150759 END PLATE 1
X22 55152740 DIAGNOSTIC PLUG 1

Assembly:47026910 Page:5_11
 Scamec 2000 S 100101660 #FB170
Main fuse box

MFB

F10.1 F10.2 F10.3 F10.4 F10.5 F10.6

X4

LA

Assembly:100043952 Page:5_12
 Scamec 2000 S 100101660 #FB170
Main fuse box

Item Part No. Description Standard designation Qty Units

F10.1 55154390 CIRCUIT BREAKER 100A 1
F10.2 55154400 CIRCUIT BREAKER 80A 1
F10.3 55154410 CIRCUIT BREAKER 50A 1
F10.4 55154390 CIRCUIT BREAKER 100A 1
F10.5 55154410 CIRCUIT BREAKER 50A 1
F10.6 55154410 CIRCUIT BREAKER 50A 1
LA 47023960 SYMBOL-FUSE 1
MFB 55154890 ELECTRIC BOX 1
X4 55150775 TERMINAL BLOCK 3
55150676 TERMINAL BLOCK 2
55150726 TERMINAL BLOCK 4
55152280 TERMINAL BLOCK 2
55150809 END PLATE 1
55150700 END PLATE 1
55150759 END PLATE 1

Assembly:100043952 Page:5_12
 Scamec 2000 S 100101660 #FB170
Electric schema, Start blocking relay

12 3 4 5 6 78

-XNOT _ Conn ect e d

A
A

1/4- XS1 :50

+30

- XS1 :15

1
PRO J ECT I D : 100022876

2/4
+15
15 50a 19 17

-S1
RE LA TE TO :

B 0 1 2 3
B
0,1

1.50 YE

1.50 YE

1.50 YE

1.50 YE
30
H2 1

1/4
-XS1 :3 0
2

-XK 23

-XK 23

-XK 23

-XK 23
3/7

2/7

6/7
1/7
3 1 2 6
+30
K233
50 15 W
7-POLE
C
100021357 C
100021357 50f 31 D+
100021357
57 4 55143101
100021357 100012735

5/7

7/7

4/7
-XK23

-XK23

-XK23
55143101
100021357 100012735
55143101
/1.F5 100021357 100012735
55143101
30 100012735
100012686

1.50 LBU
1.50 YE

1.50 YE
-K5 55147508
87 87a 100012686
100012686

87/5
- XK5 :86
R eprod uctio n, use or discl osure to t hird parti es wit hout expre ss au thori ty is strictly forbi dden.

100012686
D D
W e res erve a ll rig hts in this doc ume nt and in th e informa tion c ont ain ed the rein.

+ En gine mo dule

1/1 -XM1A 1

55140313 55140313
1/1 -X1

55140362 55140321

1/1 -XG :B+

1/1 -XG :W
E 5 5140081 55140602 E
30 A1
5 5140081 55140602

-XK5 :86
100012735 55140354 1.50 YE
B+ - W
-M1 -G1

86/5
100012735 55140354
55147235 55140289 G
M
55140602 R5 -K5
86
D+

-XG :D +
1/1
55117055
- 10001273 6R8 /100W /1.D4
-XM 1-
1/1

100012735 85
1.50 LBU

85/5
- XK5 :86
100012686

F 100012686 F
100012686
100012686
55140289 -G RO UND - G ROUND
5 5140321

3 W I R ES FOR K5 AD DED 2 011- 0 1-0 5 KU DA TE 0 5 .08. 2010 #NA M E#

2 R5 ADDED 2 010- 1 2-1 3 KU D ES IGN . JE
100022876
SCH E MA
APP. SHEET 1
VER. CHANG E DA TE NAM E ST AND. CONN E C TION FOR STAR T B LOC KING RE LAY 1 Sh.
12 3 4 5 6 78

Assembly:100022876 Page:5_13
 Scamec 2000 S 100101660 #FB170
Electric schema, Start blocking relay

Item Part No. Description Standard designation Qty Units

H2 55155760 INDICATOR LIGHT 1
K23 100021315 RELAY 1
55147508 PLUG 1
100021357 FEMALE PIN CONTACT 7
100021355 FEMALE CONNECTOR BODY 1
R5 100027830 WIRE RESISTOR 6,8OHM 100W 1
55147235 PLUG-IN CONNECTOR 1
55117055 DIODE 3A 1

Assembly:100022876 Page:5_13
 Scamec 2000 S 100101660 #FB170
Terminal box TB6

TB6

X6
K37 K38

Assembly:45920280 Page:5_14
 Scamec 2000 S 100101660 #FB170
Terminal box TB6

Item Part No. Description Standard designation Qty Units

K37 55119747 RELAY 24V 1
55119788 RELAY BASE 1
K38 55119747 RELAY 24V 1
55119788 RELAY BASE 1
TB6 45920290 BOX 1
X6 55119804 TERMINAL BLOCK 80
55119051 END PLATE 1
55119077 END CLIP 2

Assembly:45920280 Page:5_14
 Scamec 2000 S 100101660 #FB170
Terminal box TB20

LA1

TB20

S51B S54B S168B

Assembly:47026620 Page:5_15
 Scamec 2000 S 100101660 #FB170
Terminal box TB20

Item Part No. Description Standard designation Qty Units

LA1 100002867 SYMBOL 1
S51B 100004994 SELECTOR KEY 1
100016011 CONTACT FRAME 1
S54B 100004994 SELECTOR KEY 1
100016011 CONTACT FRAME 1
S168B 100004994 SELECTOR KEY 1
100016011 CONTACT FRAME 1
TB20 55131064 BOX 1

Assembly:47026620 Page:5_15
 Scamec 2000 S 100101660 #FB170
Terminal box TB39

TB39

K39

Assembly:45747350 Page:5_16
 Scamec 2000 S 100101660 #FB170
Terminal box TB39

Item Part No. Description Standard designation Qty Units

TB39 55136238 ELECTRIC BOX 1
K39 55119747 RELAY 24V 1
55119788 RELAY BASE 1

Assembly:45747350 Page:5_16
 Scamec 2000 S 100101660 #FB170
Cabin electric schema, Page 1/2

F7.5 F7.1 F7.2 F7.3 F7.4 F7.6

S60
S24 S23A S23B
K16A

M5A
M4A M4B M2 M3
E21

Assembly:47026580_1 Page:5_17
 Scamec 2000 S 100101660 #FB170
Cabin electric schema, Page 1/2

Item Part No. Description Standard designation Qty Units

E21 55123517 INTERIOR LIGHT 1
55123210 INTERIOR LIGHT BULB 24V 21W 1
55123442 INTERIOR LIGHT BULB 24V 10W 1
F7.1 55125827 FUSE 5A 1
F7.2 55125819 FUSE 7,5A 7
F7.3 55125827 FUSE 5A 1
F7.4 55125827 FUSE 5A 1
F7.5 55125827 FUSE 5A 1
F7.6 55125801 FUSE 10A 1
K16A 55119317 RELAY 1
M2 57986432 WINDSHIELD WIPER MOTOR 1
M3 55133052 REAR WINDOW WIPER MOTOR 1
M4A 57986390 WASHING DEVICE, WINDSHIELD 1
M4B 57941759 WASHING DEVICE, REAR GLASS 1
M5A 57957714 FAN MOTOR 1
S23A 100008659 WINDOW WIPER SWITCH 1
S23B 100008659 WINDOW WIPER SWITCH 1
S24 55142715 WINDOW WASHER SWITCH 1
S60 57969586 BLOWER SWITCH 1

Assembly:47026580_1 Page:5_17
 Scamec 2000 S 100101660 #FB170
Cabin electric schema, Page 2/2

F8.1 F8.2 F8.3 F8.4 F8.5 F8.6

K16B S25 S6 S7 S387

H18 E15 E16 E13 E14 E11 E12 E33A E33B E34A E34B
E29 E30

Assembly:47026580_2 Page:5_18
 Scamec 2000 S 100101660 #FB170
Cabin electric schema, Page 2/2

Item Part No. Description Standard designation Qty Units

E11 100029094 WORK LIGHT 1
E12 100029094 WORK LIGHT 1
E13 100029094 WORK LIGHT 1
E14 100029094 WORK LIGHT 1
E15 100029094 WORK LIGHT 1
E16 100029094 WORK LIGHT 1
E29 100050553 SIDE LIGHT 1
E30 100050553 SIDE LIGHT 1
E33A 100029092 WORK LIGHT 1
E33B 100029092 WORK LIGHT 1
E34A 100029092 WORK LIGHT 1
E34B 100029092 WORK LIGHT 1
F8.1 55125819 FUSE 7,5A 1
F8.2 55125819 FUSE 7,5A 1
F8.3 55125819 FUSE 7,5A 1
F8.4 55125819 FUSE 7,5A 1
F8.5 55125819 FUSE 7,5A 1
F8.6 55125819 FUSE 7,5A 1
H18 55122568 WARNING BEACON 1
K16B 55119317 RELAY 1
55140800 MULTIPOLE CONNECTOR 1
S6 100013546 SWITCH 1
S7 100013545 SWITCH 1
S25 100013546 SWITCH 1
S387 100013545 SWITCH 1

Assembly:47026580_2 Page:5_18
 Scamec 2000 S 100101660 #FB170
Electric schema, Scaler, Page 1/4

S125A S200 S175

Y16 Y17 Y106A Y106B

Y25A Y25B
PC5
PC10

Assembly:47026840_1 Page:5_20
 Scamec 2000 S 100101660 #FB170
Electric schema, Scaler, Page 1/4

Item Part No. Description Standard designation Qty Units

S125A 100004994 SWITCH 1
100016011 CONTACT FRAME 1
S175 100004994 SWITCH 1
100016011 CONTACT FRAME 1
S200 100004994 SWITCH 1
100016011 CONTACT FRAME 1
Y16 57620411 SOLENOID COIL 1
Y17 57620411 SOLENOID COIL 1
Y25A 57620411 SOLENOID COIL 1
Y25B 57620411 SOLENOID COIL 1
Y106A 57620411 SOLENOID COIL 1
Y106B 57620411 SOLENOID COIL 1

OPTIONAL EQUIPMENT FOR SOLENOID COILS

PC5 55138663 PLUG CABLE L=5M 1
PC10 55148720 PLUG CABLE L=10M 1

Assembly:47026840_1 Page:5_20
 Scamec 2000 S 100101660 #FB170
Electric schema, Scaler, Page 2/4

S51B S54B S168B

S50 S51A S54A S168A

Y37 Y38 Y39 Y40 Y45 Y46 Y72 Y73 Y19

PC5
PC10

Assembly:47026840_2 Page:5_21
 Scamec 2000 S 100101660 #FB170
Electric schema, Scaler, Page 2/4

Item Part No. Description Standard designation Qty Units

S50 55136204 DOUBLE-HEADED PUSH BUTTON 1
100016011 CONTACT BLOCK 1
55136196 SEALING BOOT 1
S51A 55136204 DOUBLE-HEADED PUSH BUTTON 1
100016011 CONTACT BLOCK 1
55136196 SEALING BOOT 1
S51B 100004994 SWITCH 1
100016011 CONTACT FRAME 1
S54A 55136204 DOUBLE-HEADED PUSH BUTTON 1
100016011 CONTACT BLOCK 1
55136196 SEALING BOOT 1
S54B 100004994 SWITCH 1
100016011 CONTACT FRAME 1
S168A 55136204 DOUBLE-HEADED PUSH BUTTON 1
100016011 CONTACT BLOCK 1
55136196 SEALING BOOT 1
S168B 100004994 SWITCH 1
100016011 CONTACT FRAME 1
Y19 57701880 SOLENOID COIL 1
Y37 57620411 SOLENOID COIL 1
Y38 57620411 SOLENOID COIL 1
Y39 57620411 SOLENOID COIL 1
Y40 57620411 SOLENOID COIL 1
Y45 57620411 SOLENOID COIL 1
Y46 57620411 SOLENOID COIL 1
Y72 57620411 SOLENOID COIL 1
Y73 57620411 SOLENOID COIL 1

OPTIONAL EQUIPMENT FOR SOLENOID COILS

PC5 55138663 PLUG CABLE L=5M 1
PC10 55148720 PLUG CABLE L=10M 1

Assembly:47026840_2 Page:5_21
 Scamec 2000 S 100101660 #FB170
Electric schema, Scaler , Page 3/4

S108
S83

S222

WS222
K37 K65

K38

Y49 Y24A Y24B Y113

M6
S126

PC5 PC10

Assembly:47026840_3 Page:5_22
 Scamec 2000 S 100101660 #FB170
Electric schema, Scaler , Page 3/4

Item Part No. Description Standard designation Qty Units

K37 55119747 RELAY 24V 1
55119788 RELAY BASE 1
K38 55119747 RELAY 24V 1
55119788 RELAY BASE 1
K65 55119747 RELAY 24V 1
55119788 RELAY BASE 1
M6 57944548 FAN COMPLETE 1
S83 100016325 PUSH BUTTON 1
100016405 CONTACT FRAME 1
S108 100012154 SWITCH 1
100009027 CONTACT FRAME 1
S126 54848056 TEMPERATURE SWITCH 1
S222 55150536 INDUCTIVE SENSOR 1
WS222 55155700 CONNECTOR 1
Y24A 57987695 SOLENOID COIL 1
Y24B 57620411 SOLENOID COIL 1
Y49 57991130 SOLENOID COIL 1
Y113 57701880 SOLENOID COIL 1

OPTIONAL EQUIPMENT FOR SOLENOID COILS

PC5 55138663 PLUG CABLE L=5M 1
PC10 55148720 PLUG CABLE L=10M 1

Assembly:47026840_3 Page:5_22
 Scamec 2000 S 100101660 #FB170
Electric schema, Scaler, Page 4/4

X7

X8

X9
X14 X13

Y29A
Y29B
X15

X3

Y25A
Y24A

Y25A
Y24B

Y25B
Y49
PC5

PC10

Assembly:47026840_4 Page:5_23
 Scamec 2000 S 100101660 #FB170
Electric schema, Scaler, Page 4/4

Item Part No. Description Standard designation Qty Units

Y24A 57987695 SOLENOID COIL 1
Y24B 57620411 SOLENOID COIL 1
Y25A 57620411 SOLENOID COIL 1
Y25B 57620411 SOLENOID COIL 1
Y29A 57816050 SOLENOID COIL 1
Y29B 57816050 SOLENOID COIL 1
Y49 57620411 SOLENOID COIL 1
X3 55136329 CONNECTOR BODY 1
55124226 PLUG SOCKET 1
55124200 CONNECTING PLUG 1
55136311 PLUG BOX 1
X7 55136329 CONNECTOR BODY 1
55124226 PLUG SOCKET 1
55124200 CONNECTING PLUG 1
55136311 PLUG BOX 1
X8 55136329 CONNECTOR BODY 1
55124226 PLUG SOCKET 1
55124200 CONNECTING PLUG 1
55136311 PLUG BOX 1
X9 55136329 CONNECTOR BODY 1
55124226 PLUG SOCKET 1
55124200 CONNECTING PLUG 1
55136311 PLUG BOX 1
X13 55136329 CONNECTOR BODY 1
55124226 PLUG SOCKET 1
55124200 CONNECTING PLUG 1
55136311 PLUG BOX 1
X14 55136329 CONNECTOR BODY 1
55124226 PLUG SOCKET 1
55124200 CONNECTING PLUG 1
55136311 PLUG BOX 1
X15 55136329 CONNECTOR BODY 1
55124226 PLUG SOCKET 1
55124200 CONNECTING PLUG 1
55136311 PLUG BOX 1

OPTIONAL EQUIPMENT FOR SOLENOID COILS

PC5 55138663 PLUG CABLE L=5M 1
PC10 55148720 PLUG CABLE L=10M 1

Assembly:47026840_4 Page:5_23
 Scamec 2000 S 100101660 #FB170
Hammer hour meter kit

P1

BOX

F21

Assembly:100008484 Page:5_26
 Scamec 2000 S 100101660 #FB170
Hammer hour meter kit

Item Part No. Description Standard designation Qty Units

BOX 100015588 ELECTRIC BOX 1
F21 55125827 BLADE FUSE 5A 1
55150221 FUSE HOLDER 1
P1 55113039 HOUR METER 1

Assembly:100008484 Page:5_26
 Scamec 2000 S 100101660 #FB170
Powerpack kit

E20 E23

E21 E22

Assembly:100083664 Page:5_27
 Scamec 2000 S 100101660 #FB170
Powerpack kit

Item Part No. Description Standard designation Qty Units

2 100083667 HIGH VOLTAGE BOX 1
E20 47023440 SPOTLIGHT 1
E21 47023440 SPOTLIGHT 1
E22 47023440 SPOTLIGHT 1
E23 47023440 SPOTLIGHT 1

Assembly:100083664 Page:5_27
 Scamec 2000 S 100101660 #FB170
High voltage box

Assembly:100083667 Page:5_28
 Scamec 2000 S 100101660 #FB170
High voltage box

Item Part No. Description Standard designation Qty Units

F1 55114979 MINIATURE CIRCUIT-BREAKER 1
F2 55138333 SAFETY SWITCH 1
F3 55114979 MINIATURE CIRCUIT-BREAKER 1
F6 55114979 MINIATURE CIRCUIT-BREAKER 1
H1 100018411 SIGNAL LIGHT 1
H77A 100018411 SIGNAL LIGHT 1
K1M 100014639 CONTACTOR 1
100014666 AUXILIARY CONTACT 2
100014677 TIMER DELAY BLOCK 1
K2M 100014648 CONTACTOR 1
100014665 AUXILIARY CONTACT 1
K3 100014828 PHASE ORDER RELAY 1
K3M 100048337 CONTACTOR 1
100045532 AUXILIARY CONTACT 1
100045533 AUXILIARY CONTACT 1
P1 55113039 HOUR METER 1
P8 55151380 VOLTAGE GAUGE 1
Q5 100076522 MOTOR CIRCUIT-BREAKER 1
Q50 100014562 PROTECTION SWITCH 1
100014559 ATTACHING PART 3
Q55 100045493 MOTOR CIRCUIT-BREAKER 1
S1 100007815 LOAD SWITCH 1
100013815 SHAFT 1
100013819 FINGER COVER 1
47011550 SYMBOL-MAIN SWITCH 1
S3 100018413 PUSH BUTTON 1
100017534 HOLDER 1
100019815 COVER RUBBER 1
100017703 CONTACT BLOCK 1
S6 100018523 SELECTOR SWITCH 1
100017535 CONTACT BLOCK 3
SH1 100017535 CONTACT BLOCK 3
100018556 SELECTOR SWITCH 1
T1 55133433 TRANSFORMER 1
T2 55155180 BATTERY CHARGER 1
PE 55150742 TERMINAL BLOCK 1
X1 55150775 TERMINAL BLOCK 30
55150809 END PLATE 6
55150924 END CLIP 7
X1/N 55150783 TERMINAL BLOCK 9
X1/PE 55150791 TERMINAL BLOCK 10
X5 55150817 TERMINAL BLOCK 10
55150825 END PLATE 1
X32 100014881 SOCKET 1
LA1 51970770 WARNING SIGN 2
LA2 41010940 SYMBOL-HIGH VOLTAGE 1

Assembly:100083667 Page:5_28
 Scamec 2000 S 100101660 #FB170
Electric schema, 400V/50Hz, Page 1/2

S1 Q55 Q5
Q50

P8

T1

K1M K2M K3M

K3

F50

K119A
W1

M50

Assembly:100083688_1 Page:5_30
 Scamec 2000 S 100101660 #FB170
Electric schema, 400V/50Hz, Page 1/2

Item Part No. Description Standard designation Qty Units

F50 100014596 THERMAL OVERLOAD RELAY 1
K119A 55154850 THERMISTOR RELAY 1
K1M 100014639 CONTACTOR 55KW, 1000VVAC, 1
100014666 AUXILIARY CONTACT 2
100014677 TIMER DELAY BLOCK 1
K2M 100014648 CONTACTOR 45KW, 690VAC, 125A, 1
100014665 AUXILIARY CONTACT 1
K3 100014828 PHASE ORDER RELAY 10VA, 400VAC, 8A 1
K3M 100048337 CONTACTOR 1
100045532 AUXILIARY CONTACT 1
100045533 AUXILIARY CONTACT 1
M50 100044465 ELECTRIC MOTOR 1
P8 55151380 VOLTAGE GAUGE IP54 1
Q5 100076522 MOTOR CIRCUIT-BREAKER 1
Q50 100014562 PROTECTION SWITCH 690/500ACDC, 160A 1
100014559 ATTACHING PART CU, 14MM 3
Q55 100045493 MOTOR CIRCUIT-BREAKER DIN RAIL, 690VAC/50/60HZ 1
S1 100007815 LOAD SWITCH 380-690VAC, 250A, 3-POLE, IP65 1
100013815 SHAFT 6X6X290MM 1
100013819 FINGER COVER IP 30 1
47011550 SYMBOL-MAIN SWITCH 1
T1 55133433 TRANSFORMER 6.3KVA, 50/60HZ, IP00 1
W1 55126221 CABLE 3x35+3G6 L=110M
54944731 CABLE STOPPER 2

Assembly:100083688_1 Page:5_30
 Scamec 2000 S 100101660 #FB170
Electric schema, 400V/50Hz, Page 2/2

F1 F2
F3

SH1
K3
T2
S3 M1

K119A F6
S6
SH2

SH2 H1

X2

E4
H77A E20 E21 E22 E23
P1
SH1
K1MB
K1M K2M K3M

Assembly:100083688_2 Page:5_31
 Scamec 2000 S 100101660 #FB170
Electric schema, 400V/50Hz, Page 2/2

Item Part No. Description Standard designation Qty Units

E4 55123335 INTERIOR LIGHT 1
55123095 BULB 2
E20 47023440 SPOTLIGHT 1
55123038 HALOGEN BULB 1
E21 47023440 SPOTLIGHT 1
55123038 HALOGEN BULB 1
E22 47023440 SPOTLIGHT 1
55123038 HALOGEN BULB 1
E23 47023440 SPOTLIGHT 1
55123038 HALOGEN BULB 1
F1 55114979 MINIATURE CIRCUIT-BREAKER 1
F2 55138333 SAFETY SWITCH 1
F3 55114979 MINIATURE CIRCUIT-BREAKER 1
F6 55114979 MINIATURE CIRCUIT-BREAKER 1
H1 100018411 SIGNAL LIGHT 1
H77A 100018411 SIGNAL LIGHT 1
K119A 55154850 THERMISTOR RELAY 1
K1M 100014639 CONTACTOR 1
100014666 AUXILIARY CONTACT 2
100014677 TIMER DELAY BLOCK 1
K1MB 100020057 RELAY 1
100014747 RELAY BASE 1
K2M 100014648 CONTACTOR 1
100014665 AUXILIARY CONTACT 1
K3 100014828 PHASE ORDER RELAY 1
K3M 100048337 CONTACTOR 1
100045532 AUXILIARY CONTACT 1
100045533 AUXILIARY CONTACT 1
M1 100012991 FAN&FILTER UNIT 1
100012992 AIR GRID 1
P1 55113039 HOUR METER 1
S3 100018413 PUSH BUTTON 1
100017534 HOLDER 1
100019815 COVER RUBBER 1
100017703 CONTACT BLOCK 1
S6 100018523 SELECTOR SWITCH 1
100017535 CONTACT BLOCK 3
SH1 100017535 CONTACT BLOCK 3
100018556 SELECTOR SWITCH 1
SH2 100018553 SWITCH BUTTON 1
T2 55155180 BATTERY CHARGER 1
X2 55150924 END CLIP 7
55150759 END PLATE 1

Assembly:100083688_2 Page:5_31
 Scamec 2000 S 100101660 #FB170
Reverse camera kit

Assembly:100034927 Page:5_32
 Scamec 2000 S 100101660 #FB170
Reverse camera kit

Item Part No. Description Standard designation Qty Units

1 100034927 REVERSE CAMERA COMPLETE INCLUDE ITEMS 2-5 1
2 100032426 MONITOR 1
3 100034995 PLUG CABLE BE-L115, 15M 1
4 57702880 CAMERA 1
5 100082646 PLUG CABLE 1

Assembly:100034927 Page:5_32
 Scamec 2000 S 100101660 #FB170
Reverse alarm / reversing sensors

3
1 4

7 8

Assembly:100071381 Page:5_33
 Scamec 2000 S 100101660 #FB170
Reverse alarm / reversing sensors

Item Part No. Description Standard designation Qty Units

1 100071381 REVERSE ALARM SYSTEM COMPLETE INCLUDE ITEMS 2-8 1
2 100052401 BOTTOM SENSOR CABLE L=6M 1
3 100052403 REVERSE CAMERA, IN-CAB DISPLAY 1
4 100052406 SENSOR CABLE, DISPLAY IN-CAB L=8M 1
5 100052405 POWER CABLE L=7M 1
6 100052404 CONTROL UNIT 1
7 100052400 BOTTOM SENSOR 1
8 46109410 BRACKET FOR VALVE 1

Assembly:100071381 Page:5_33
 Scamec 2000 S 100101660 #FB170
Electric scheme, Brake activation kit, Page 1/2

H22

K22B

Assembly:100103582_1 Page:5_34
 Scamec 2000 S 100101660 #FB170
Electric scheme, Brake activation kit, Page 1/2

Item Part No. Description Standard designation Qty Units

H22 55134365 ALARM 1
K22B 55119747 RELAY 1
55119788 RELAY BASE 1
L 47027420 SYMBOL 1

Assembly:100103582_1 Page:5_34
 Scamec 2000 S 100101660 #FB170
Electric scheme, Brake activation kit, Page 2/2

K22 K17

Assembly:100103582_2 Page:5_35
 Scamec 2000 S 100101660 #FB170
Electric scheme, Brake activation kit, Page 2/2

Item Part No. Description Standard designation Qty Units

K17 55119747 RELAY 1
55119788 RELAY BASE 1
K22 55119747 RELAY 1
55119788 RELAY BASE 1

Assembly:100103582_2 Page:5_35
