REAR END MODULE

121D73057-1
TABLE OF CONTENTS Sandvik DD321-40C 211001

11. REAR END MODULE

* BG 015 996 72 NSS MODULE, REAR.............................................................................................................................................. 2
** 551 710 29 NSS SCREW KIT, REAR MODULE............................................................................................................................ 5
** BG 011 120 54 NSS CABLE REEL ASSEMBLY, WITH SPOOLING DEVICE............................................................................... 8
*** BG 011 035 78 CABLE REEL, CABLE REEL............................................................................................................................ 12
**** 550 535 54 SLIP RING UNIT.................................................................................................................................................. 14
**** 551 976 20 GEARBOX, INCLUDES HYDRAULIC MOTOR ADAPTER.................................................................................. 17
***** 551 971 27 GEARBOX, GEARBOX T4 1:15 WITH CHAIN ADAPTER-DOWN.................................................................. 20
****** 550 910 32 GEARBOX.................................................................................................................................................... 22
***** 550 525 65 ADAPTER......................................................................................................................................................... 25
*** BG 004 508 82 NSS CABLE GUIDING BRACKET.................................................................................................................... 26
*** 551 875 81 CABLE GUIDE ASSEMBLY..................................................................................................................................... 28
*** 551 562 84 SHAFT ASSEMBLY, SPOOLING SHAFT KIT......................................................................................................... 29
*** BG 001 732 17 CONTROL BLOCK ASSEMBLY........................................................................................................................ 30
**** 552 160 27 DRILLING MODULE............................................................................................................................................. 32
** BG 007 924 87 NSS REEL, WATER HOSE, WATER HOSE REEL ASSEMBLY.......................................................................... 34
*** 551 705 53 BRACKET, ASSEMBLY - WATER HOSE REEL..................................................................................................... 37
**** 551 646 50 BRACKET............................................................................................................................................................. 40
**** 551 653 53 ASSEMBLY, PIN+CHAIN..................................................................................................................................... 42
*** 550 412 43 REEL, WATER HOSE, GR1-1½ IN......................................................................................................................... 43
**** 550 530 12 SHAFT.................................................................................................................................................................. 44
*** BG 007 924 69 NSS VALVE, SHOCK LOAD, ASSEMBLY........................................................................................................ 46
*** 551 000 64 NSS VALVE ASSEMBLY......................................................................................................................................... 47
*** 551 979 71 HOSING SET, REAR ASSEMBLY........................................................................................................................... 48
** BG 009 616 88 NSS POWER PACK ASSEMBLY, NC7, PUMPS 112+33, RIGHT........................................................................ 50
*** BG 009 705 18 HYDRAULIC PUMP, AXIAL PISTON................................................................................................................ 51
*** BG 009 635 21 PRESSURE FILTER ASSEMBLY..................................................................................................................... 52
*** 551 794 52 CHECK VALVE ASSEMBLY, FOR 112CC PUMP.................................................................................................. 54
** BG 009 611 22 NSS POWER PACK ASSEMBLY......................................................................................................................... 56
** BG 010 520 70 COMPRESSOR ASSEMBLY, 2.8 M3/MIN, 440-480 V......................................................................................... 57
*** BG 006 325 56 FRAME ASSEMBLY, CT28, FRAME ASSEMBLY............................................................................................ 58
*** 552 125 35 NSS ASSEMBLY, BELT DRIVE ASSEMBLY, CT28, 60HZ.................................................................................... 59
*** BG 010 793 28 NSS COOLER ASSEMBLY, COOLER ASSEMBLY.......................................................................................... 62
*** BG 006 337 27 HOSE ASSEMBLY, CT28, DRAIN HOSE ASSEMBLY..................................................................................... 63
*** BG 006 337 25 NSS VALVE ASSEMBLY, CT28, INLET VALVE ASSEMBLY........................................................................... 66
**** 036 167 18 INTAKE VALVE.................................................................................................................................................... 68
*** BG 006 338 15 NSS PIPING, CONTROL AIR, CT28, CONTROL AIR PIPING......................................................................... 70
*** BG 006 339 70 NSS COMPRESSOR COMPONENTS, CT28, TEMPEST 6............................................................................. 72
**** 036 030 78 VALVE, DISCHARGE........................................................................................................................................... 74
*** BG 006 340 20 AIR END, CT28................................................................................................................................................. 75
**** 552 125 43 COMPRESSOR UNIT, AIR END......................................................................................................................... 76
** BG 011 055 76 COMPRESSOR ASSEMBLY, CT28 LEFT, NC7................................................................................................... 78
*** BG 011 183 47 NSS ELECTRICAL ASSEMBLY, COMPRESSOR OVERHEAT SENSORING.................................................. 86
** BG 011 055 90 COMPRESSOR ASSEMBLY, CT28, NC7............................................................................................................. 88
** BG 007 821 18 NSS SEPARATOR, MUD, R3 IN AND PRESSURE REDUCING VALVE............................................................. 90
*** BG 002 346 43 VALVE, PRESSURE REDUCING, 1 7/8 JIC IN, 1-7BAR (MAX 25BAR).......................................................... 92
** 550 004 39 HYDRAULIC CYLINDER, DOUBLE-ACTING.............................................................................................................. 94
** BG 010 795 91 NSS PUMP ASSEMBLY, WATER, WATER.......................................................................................................... 95
*** BG 010 795 96 DISTRIBUTOR................................................................................................................................................... 98
** 551 596 27 NSS TANK, FUEL, ASSEMBLY, FILLING CAP (0,5BAR)........................................................................................... 100
** BG 015 394 69 NSS FUEL SYSTEM, MB OM 904 LA, NC7......................................................................................................... 102
*** BG 003 241 69 NSS FILTER, FUEL........................................................................................................................................... 103
** BG 007 768 31 NSS TANK, HYDRAULIC, 2X OW30 STD............................................................................................................ 106
*** BG 007 690 69 TANK, HYDRAULIC, BASIC ASSEMBLY PARTS FOR NC7............................................................................ 108
**** 551 990 66 FILTER, AIR BREATHER.................................................................................................................................... 111
**** 550 463 70 NSS JUNCTION BOX ASSEMBLY, JB5, JB20, X336, X337.............................................................................. 114
**** BG 006 309 40 FILTER, RETURN.......................................................................................................................................... 115
*** 551 798 38 NSS ASSEMBLY, WATER AND OIL HOSES......................................................................................................... 116
**** 853 502 39 HEAT EXCHANGER, OIL-WATER, Q 160 L/MIN, P_MAX 20 BAR.................................................................... 117
** 551 897 84 NSS MOUNTING, OF FILLING BUMP........................................................................................................................ 120

Sandvik Mining and Construction Oy Drills Tampere © 2021

 121D73057-1
TABLE OF CONTENTS Sandvik DD321-40C 211001

*** 551 730 63 NSS PUMP, FILLING, ASSEMBLY......................................................................................................................... 122

**** 560 385 10 NSS PUMP, FILLING, 24VDC............................................................................................................................. 123
**** 560 385 11 NSS SUCTION HOSE ASSEMBLY, FOR FILLING PUMP.................................................................................. 126
** BG 001 744 51 VALVE ASSEMBLY, REAR JACKS...................................................................................................................... 128
** BG 004 133 22 NSS AIR FILTER ASSEMBLY.............................................................................................................................. 132
** 552 269 54 NSS BRACKET, ASSEMBLY - ELECTRICAL SWITCHGEAR, STANDARD VERSION.............................................. 133
** BG 014 552 36 NSS SUPPORT, REAR, ASSEMBLY, WITHOUT WATER HOSE GUIDE............................................................ 134
*** BG 014 563 75 BRACKET, REELS REMOTE CONTROL......................................................................................................... 135
*** 550 333 52 NSS BAR, INDICATOR ROD ASSEMBLY.............................................................................................................. 136
*** BG 013 980 83 NSS LIGHT........................................................................................................................................................ 138
** BG 004 145 29 NSS BRACKET, COMPRESSOR.......................................................................................................................... 140
** 551 741 92 BRACKET, COMPRESSOR......................................................................................................................................... 141
** 551 683 28 NSS TAP, SUBASSEMBLY......................................................................................................................................... 144
** 551 705 59 NSS COCK, ASSEMBLY, ADAPTERS & BRACKET, 2 X COCK............................................................................... 145
** 550 449 07 LAMP ASSEMBLY, STEP LIGHT, 24V (LED), DT04-2P CONNECTOR..................................................................... 146
** 550 723 46 CABLE ASSEMBLY, DT06 2S / 4.0M - PUR 2X1.5.................................................................................................... 147
** 551 818 39 STEPS, REAR MODULE............................................................................................................................................. 148
** BG 015 962 04 NSS MOUNTING, WATER HOSE QUIDE, REAR PANEL................................................................................... 150
** BG 009 675 89 NSS ASSEMBLY, HYDRAULIC TANK CONNECTORS FOR KAWASAKI PUMPS.............................................. 152
** BG 008 641 72 PUMP, WATER, WBP-1008.................................................................................................................................. 153
*** BG 010 477 97 SEAL KIT, SEAL KIT......................................................................................................................................... 156
*** BG 010 708 13 HARDWARE KIT, HARDWARE KIT.................................................................................................................. 158
*** BG 010 708 22 HYDRAULIC KIT, HYDRAULIC KIT.................................................................................................................. 159
** BG 009 584 55 CABLE ASSEMBLY............................................................................................................................................... 162
** BG 009 584 57 CABLE ASSEMBLY, CABLE ASSEMBLY (SLIP RING UNIT - MP)..................................................................... 164
** BG 015 583 11 NSS HOSING SET, WATER HOSE, 65M, 1 1/2"................................................................................................. 165
** 552 181 53 NSS MOUNTING, CABLE RACK MOUNTING............................................................................................................ 168
** BG 002 350 61 NSS RAILING, ASSEMBLY................................................................................................................................... 169
** BG 007 896 00 NSS FRAME, BACKING, ASSEMBLY.................................................................................................................. 172
*** BG 007 900 14 NSS FRAME, BACKING, ASSEMBLY.............................................................................................................. 176
**** 552 189 72 NSS LIMITER, ASSEMBLY, COVERS NC7........................................................................................................ 177
**** 552 190 67 NSS WIRE ROPE, ASSEMBLY........................................................................................................................... 178
*** 552 178 37 NSS THRUST, FOR FRONT COVERPLATE LATCH............................................................................................. 179
*** 552 176 30 NSS LATCH, ASSEMBLY........................................................................................................................................ 180
** BG 007 788 06 NSS COVERS ASSEMBLY, SEMI+ARCT............................................................................................................ 182
*** BG 007 787 87 NSS COVERS ASSEMBLY, UPPER AND SIDE COVERS.............................................................................. 186
**** 551 729 04 PLATE, COVER, HYDRAULIC OIL RECEIVER.................................................................................................. 191
**** 551 767 79 PLATE, COVER, ENGINE................................................................................................................................... 192
**** BG 002 924 46 PLATE, COVER, FRONT COVERPLATE, RIGHT........................................................................................ 194
***** 551 853 87 NSS MOUNTING, ROPE, COVERS................................................................................................................ 195
**** 552 199 69 NSS PLATE, COVER, REAR COVERPLATE ASSEMBLY, RIGHT.................................................................... 196
**** BG 004 485 08 PLATE, COVER, REAR COVERPLATE ASSEMBLY, LEFT......................................................................... 197
**** 551 769 12 DOOR, REAR DOOR, RIGHT............................................................................................................................. 200
**** 551 769 16 DOOR ASSEMBLY, REAR DOOR ASSEMBLY, RIGHT..................................................................................... 201
**** 552 215 21 DOOR ASSEMBLY, REAR DOOR, LEFT........................................................................................................... 204
**** 551 769 26 DOOR ASSEMBLY, REAR DOOR ASSEMBLY, LEFT....................................................................................... 205
**** 552 076 92 DOOR, POWER PACK, RIGHT........................................................................................................................... 206
**** 552 076 96 DOOR, POWER PACK, LEFT............................................................................................................................. 207
**** 552 076 94 NSS PLATE, COVER, POWER PACK COVER + THRUST, RIGHT................................................................... 208
**** 552 076 98 NSS PLATE, COVER, POWER PACK COVER + THRUST, LEFT..................................................................... 209

Sandvik Mining and Construction Oy Drills Tampere © 2021

 121D73057-1
TABLE OF CONTENTS Sandvik DD321-40C 211001

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 015 996 72 fI NSS
1 (209) MODULE, REAR 211001

563 563
511 205
204 15
16
563
566 204
349 2
348
563
320
511
52
207
45 18
172
91
552

555 90 206 512 553 765 801 555 8 19 17 563 201 7 AR60 / IP5
517 14
272 Water pump
bleed valve
10
551 145 40 551 450 145 41 33 172 552
802
712 20
43
202
12
563 MP
265
594 562 508 178
564
13
570
JB80

564 264 21
721
SH330
721 570 63
S35
51
721 570
320
553 204 30
348
349
566

31 204 553 551 144 556 311 11 8 555 801 28 262 266 517 555
JB43

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 015 996 72 fI NSS
211001 MODULE, REAR 2 (209)

Ref. Part no. Description EN Standard designation Qty

e
2 BG 007 924 87 NSS REEL, WATER HOSE SECTION 11 PAGE 34 1
7 BG 007 821 18 NSS SEPARATOR, MUD SECTION 11 PAGE 90 1
8 550 004 39 HYDRAULIC CYLINDER, DOUBLE-ACTING SECTION 11 PAGE 94 2
10 BG 010 795 91 NSS PUMP ASSEMBLY, WATER SECTION 11 PAGE 95 1
11 551 596 27 NSS TANK, FUEL SECTION 11 PAGE 100 1
. . . . .
12 BG 007 768 31 NSS TANK, HYDRAULIC SECTION 11 PAGE 106 1
13 551 897 84 NSS MOUNTING SECTION 11 PAGE 120 1
14 BG 001 744 51 VALVE ASSEMBLY SECTION 11 PAGE 128 1
16 BG 004 133 22 NSS AIR FILTER ASSEMBLY SECTION 11 PAGE 132 1
17 552 269 54 NSS BRACKET SECTION 11 PAGE 133 1
. . . . .
18 551 666 22 SUPPORT Main switchgear bracket 1
19 813 768 09 BATTERY, STARTER 12V 142Ah 344x172x281 2
20 550 100 36 NSS ADAPTER ASSEMBLY SECTION 10 PAGE 13 4
21 BG 014 552 36 NSS SUPPORT, REAR SECTION 11 PAGE 134 1
28 551 741 92 BRACKET SECTION 11 PAGE 141 1
. . . . .
30 550 496 14 NSS HOLDER, CABLE also THR Water hose 1
33 552 121 82 HANDLE Rear frame 1
40 550 169 75 BUZZER 12-24 VDC 1
41 BG 013 862 78 HORN 24 VDC 1
43 BG 011 897 20 BRACKET Fuel filter 1
. . . . .
45 551 683 28 NSS TAP SECTION 11 PAGE 144 1
51 551 739 02 NSS BRACKET Powerpack, Right 1
52 551 739 00 NSS BRACKET Powerpack, Left 1
63 551 927 88 PROTECTIVE HOSE Safesleeve 109mm 1.2
348 551 866 46 SCREW Hexagon head bolt, power pack turning slot 2
. . . . .
348.1 857 935 99 HEXAGON HEAD SCREW M20X110 m8.8 1
349 806 668 79 SPRING-TYPE STRAIGHT PIN 4355/8A 2
712 BG 002 350 61 NSS RAILING SECTION 11 PAGE 169 1
802 BG 015 394 69 NSS FUEL SYSTEM SECTION 11 PAGE 102 1

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 015 996 72 fI NSS
3 (209) MODULE, REAR 211001

53 54 55 123 172 550 572

587

213
553

46 172 552

708 564 265 2 563 202 56 553 207 6 682 555 517 271 4

700 556 314 1 710 553 511 205 5 682 555 517 271 3

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 015 996 72 fI NSS
211001 MODULE, REAR 4 (209)

Ref. Part no. Description EN Standard designation Qty

e
1 BG 011 120 54 NSS CABLE REEL ASSEMBLY SECTION 11 PAGE 8 1
2 BG 007 924 87 NSS REEL, WATER HOSE SECTION 11 PAGE 34 1
3 BG 009 616 88 NSS POWER PACK ASSEMBLY SECTION 11 PAGE 50 1
4 BG 009 611 22 NSS POWER PACK ASSEMBLY SECTION 11 PAGE 56 1
5 BG 010 520 70 COMPRESSOR ASSEMBLY SECTION 11 PAGE 57 2
. . . . .
6.1 BG 008 641 72 PUMP, WATER SECTION 11 PAGE 153 1
6.2 BG 002 020 72 ELECTRIC MOTOR, THREE PHASE 5.5 kW 1
27 BG 004 145 29 NSS BRACKET SECTION 11 PAGE 140 1
46 551 705 59 NSS COCK SECTION 11 PAGE 145 1
53 551 727 20 BRACKET, LAMP Light (LED) for mud separator 1
. . . . .
54 550 449 07 LAMP ASSEMBLY SECTION 11 PAGE 146 1
55 550 723 46 CABLE ASSEMBLY SECTION 11 PAGE 147 1
56 551 818 39 STEPS SECTION 11 PAGE 148 1
68 BG 015 962 04 NSS MOUNTING SECTION 11 PAGE 150 1
115 BG 009 675 89 NSS ASSEMBLY SECTION 11 PAGE 152 1
. . . . .
699 BG 009 584 55 CABLE ASSEMBLY SECTION 11 PAGE 162 1
700 BG 009 584 57 CABLE ASSEMBLY SECTION 11 PAGE 164 1
701 BG 002 808 56 CABLE, POWER PUR 3x150 + 3x25 + 2x1x1,5mm2, D=52 100
704 551 000 87 SUPPORT, CABLE L600 D50-65, braided 2
708 BG 015 583 11 NSS HOSING SET SECTION 11 PAGE 165 1
. . . . .
710 BG 011 055 90 COMPRESSOR ASSEMBLY SECTION 11 PAGE 88 1
711 552 181 53 NSS MOUNTING SECTION 11 PAGE 168 1
713 BG 011 055 76 COMPRESSOR ASSEMBLY SECTION 11 PAGE 78 1
799 551 710 29 NSS SCREW KIT SECTION 11 PAGE 5 1
888 BG 007 896 00 NSS FRAME, BACKING SECTION 11 PAGE 172 1
. . . . .
889 BG 007 788 06 NSS COVERS ASSEMBLY SECTION 11 PAGE 182 1

Sandvik Mining and Construction Oy Drills Tampere © 2021

 551 710 29 j NSS
5 (209) SCREW KIT / REAR MODULE 211001

Ref. Part no. Description EN Standard designation Qty

e
122 AF0 010 0133 SCREW, HEXAGON HEAD, FULL THREAD M6x16 5
144 AF0 010 0322 SCREW, HEXAGON HEAD, FULL THREAD M8x20 4
145 AF0 010 0324 SCREW, HEXAGON HEAD, FULL THREAD M8x25 3
146 AF0 010 0326 SCREW, HEXAGON HEAD, FULL THREAD M8x30 1
172 AF0 010 0524 SCREW, HEXAGON HEAD, FULL THREAD M10x20 12
. . . . .
173 AF0 010 0526 SCREW, HEXAGON HEAD, FULL THREAD M10x25 5
178 800 526 09 HEXAGON HEAD BOLT M10x45 4
201 AF0 010 0734 SCREW, HEXAGON HEAD, FULL THREAD M12x20 8
202 AF0 010 0735 SCREW, HEXAGON HEAD, FULL THREAD M12x25 6
204 AF0 010 0736 SCREW, HEXAGON HEAD, FULL THREAD M12x30 14
. . . . .
205 AF0 010 0737 SCREW, HEXAGON HEAD, FULL THREAD M12x35 18
207 AF0 010 0739 SCREW, HEXAGON HEAD, FULL THREAD M12x45 4
213 AF0 010 0843 SCREW, HEXAGON HEAD, PARTIAL M12x70-8.8 Zn 1
THREAD
262 AF0 010 1123 SCREW, HEXAGON HEAD, FULL THREAD M16x30 1
264 AF0 010 1125 SCREW, HEXAGON HEAD, FULL THREAD M16x40 8
. . . . .
265 AF0 010 1126 SCREW, HEXAGON HEAD, FULL THREAD M16x45 6
266 AF0 010 1127 SCREW, HEXAGON HEAD, FULL THREAD M16x50 5
271 AF0 010 1223 SCREW, HEXAGON HEAD, PARTIAL M16x60-8.8 Zn 4
THREAD
311 AF0 010 1338 SCREW, HEXAGON HEAD, FULL THREAD M20x30 4
314 AF0 010 1341 SCREW, HEXAGON HEAD, FULL THREAD M20x45 4
. . . . .
320 AF0 010 1438 SCREW, HEXAGON HEAD, PARTIAL M20x65-8.8 Zn 6
THREAD
450 157 759 08 BUSHING D12 L10 1
505 AF0 140 0004 NUT, HEXAGON M6 5
506 AF0 190 0004 NUT, HEXAGON, PREVAILING TORQUE M8 1
508 AF0 190 0005 NUT, HEXAGON, PREVAILING TORQUE M10 4
. . . . .
511 AF0 190 0006 NUT, HEXAGON, PREVAILING TORQUE M12 12
517 AF0 190 0008 NUT, HEXAGON, PREVAILING TORQUE M16 17
520 AF0 190 0009 NUT, HEXAGON, PREVAILING TORQUE M20 2
550 AF0 300 0029 WASHER, LOCK, PAIR NL6 9
551 AF0 300 0030 WASHER, LOCK, PAIR NL8 9
. . . . .
552 AF0 300 0031 WASHER, LOCK, PAIR NL10 17
553 AF0 300 0032 WASHER, LOCK, PAIR NL12 25
555 AF0 300 0034 WASHER, LOCK, PAIR NL16 35
556 AF0 300 0036 WASHER, LOCK, PAIR NL20 6
562 AF0 300 0121 WASHER, LOCK, PAIR NL10-sp 8
. . . . .
563 AF0 300 0122 WASHER, LOCK, PAIR NL12-sp 31
564 AF0 300 0124 WASHER, LOCK, PAIR NL16-sp 14
566 AF0 300 0126 WASHER, LOCK, PAIR NL20-sp 16
570 AF0 230 0002 WASHER, PLAIN, NORMAL M4 12
587 868 505 99 WASHER R14 1
. . . . .
594 AF0 250 0006 WASHER, PLAIN, LARGE M10 4
682 AF0 310 0207 STUD, DOUBLE END M16x60-8.8 Zn 12
721 AF0 050 0063 SCREW, SOCKET HEAD, HEXAGON M4x16 12
765 AF0 050 0236 SCREW, SOCKET HEAD, HEXAGON M6X75 5
801 801 471 99 HEXAGON SOCKET HEAD SCREW M16X45 m8.8 8
. . . . .

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 011 120 54 aA NSS
7 (209) CABLE REEL ASSEMBLY / WITH SPOOLING DEVICE 211001

2 205 553

563 173 23

564 205 35
564 207 36
37 207 564
552 173 26
29 30 31
3 314 566 28 207 513 564

564 205 27 50 189 552

202 564

562 142 24 34
704.4 704.3 704.2 704.1

900

32 33

6 7
188 552

9 14 8 563 510 174 22 21 264 565

10 705.1
15 16 17 20
705.2

275 519 555

18 19 51 52

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 011 120 54 aA NSS
211001 CABLE REEL ASSEMBLY / WITH SPOOLING DEVICE 8 (209)

Ref. Part no. Description EN Standard designation Qty

e
1 BG 011 035 78 CABLE REEL SECTION 11 PAGE 12 1
2 BG 006 191 45 HYDRAULIC MOTOR, AXIAL PISTON 1
3 551 609 12 BRACKET Cable reel 1
6 806 659 99 CLAMP, HOSE D 48-60 mm, Cast iron 1
8 102 125 18 BUFFER, RUBBER D60, AK 70/150 1
. . . . .
9 261 980 18 BUSHING D60 d50 L190 1
10 261 981 48 BUSHING D50 d40 L200 1
14 806 658 69 CLAMP, HOSE D 60-76 mm, Cast Iron 2
15 AF1 112 0031 ADAPTER, MALE STUD CONNECTOR JIC 1 1/16 - UNF 1 1/16 2
16 AF1 150 0011 ADAPTER, TUBE END REDUCER FORM B JIC 9/16 - JIC 1 1/16 2
. . . . .
17 AF1 040 0006 ADAPTER, NUT JIC 1 1/16 2
18 AF1 112 0018 ADAPTER, MALE STUD CONNECTOR JIC 9/16 - UNF 7/8 1
19 AF1 146 0002 ADAPTER, SWIVEL NUT ELBOW JIC 7/16 1
20 AF1 146 0004 ADAPTER, SWIVEL NUT ELBOW JIC 9/16 2
21 BG 004 508 82 NSS CABLE GUIDING BRACKET SECTION 11 PAGE 26 1
. . . . .
22 551 708 86 SUPPORTING BLOCK Chain cover, spooling system 1
23 551 896 40 PLATE, COVER Cable reel chain cover 1
24 551 896 43 PLATE, COVER Cable reel chain cover 1
26 551 875 81 CABLE GUIDE ASSEMBLY SECTION 11 PAGE 28 1
27 551 875 83 SUPPORTING BLOCK Cable guide 1
. . . . .
28 551 562 84 SHAFT ASSEMBLY SECTION 11 PAGE 29 1
29 814 948 49 CHAIN, ROLLER 2.3
30 811 600 89 LINK, CHAIN 1
31 813 296 39 LINK, CHAIN 1
32 AF0 410 0017 BOLT, LIFTING EYE M10 Zn 1
. . . . .
33 550 957 92 SHACKLE M12, 0,63t 1
34 551 895 16 BRACKET Spooling shaft 1
35 551 894 79 SUPPORT Spooling shaft 1
36 551 843 92 SUPPORTING BLOCK Left, spooling shaft 1
37 551 843 93 SUPPORTING BLOCK Right, spooling shaft 1
. . . . .
50 BG 001 732 17 CONTROL BLOCK ASSEMBLY SECTION 11 PAGE 30 1
51 AF1 150 0002 ADAPTER, TUBE END REDUCER FORM B JIC 7/16 - JIC 9/16 1
52 AF1 040 0003 ADAPTER, NUT JIC 9/16 1
142 AF0 010 0320 SCREW, HEXAGON HEAD, FULL THREAD M8x16 3
173 AF0 010 0526 SCREW, HEXAGON HEAD, FULL THREAD M10x25 3
. . . . .
174 AF0 010 0528 SCREW, HEXAGON HEAD, FULL THREAD M10x30 1
188 AF0 010 0648 SCREW, HEXAGON HEAD, PARTIAL M10x100 2
THREAD
189 802 472 29 HEXAGON HEAD BOLT M10X110 m8.8 2
202 AF0 010 0735 SCREW, HEXAGON HEAD, FULL THREAD M12x25 4
205 AF0 010 0737 SCREW, HEXAGON HEAD, FULL THREAD M12x35 8
. . . . .
206 AF0 010 0738 SCREW, HEXAGON HEAD, FULL THREAD M12x40 4
207 AF0 010 0739 SCREW, HEXAGON HEAD, FULL THREAD M12x45 4
264 AF0 010 1125 SCREW, HEXAGON HEAD, FULL THREAD M16x40 3
275 AF0 010 1226 SCREW, HEXAGON HEAD, PARTIAL M16X75 - 8.8 Zn 4
THREAD
314 AF0 010 1341 SCREW, HEXAGON HEAD, FULL THREAD M20x45 4
. . . . .
510 AF0 140 0006 NUT, HEXAGON M10 1
513 AF0 140 0007 NUT, HEXAGON M12 8
519 AF0 140 0009 NUT, HEXAGON M16 4
552 AF0 300 0031 WASHER, LOCK, PAIR NL10 6
553 AF0 300 0032 WASHER, LOCK, PAIR NL12 2
. . . . .
555 AF0 300 0034 WASHER, LOCK, PAIR NL16 4
562 AF0 300 0120 WASHER, LOCK, PAIR NL8-sp 3
563 AF0 300 0121 WASHER, LOCK, PAIR NL10-sp 3
564 AF0 300 0122 WASHER, LOCK, PAIR NL12-sp 22
565 AF0 300 0124 WASHER, LOCK, PAIR NL16-sp 3
. . . . .

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 011 120 54 aA NSS
9 (209) CABLE REEL ASSEMBLY / WITH SPOOLING DEVICE 211001

2 205 553

563 173 23

564 205 35
564 207 36
37 207 564
552 173 26
29 30 31
3 314 566 28 207 513 564

564 205 27 50 189 552

202 564

562 142 24 34
704.4 704.3 704.2 704.1

900

32 33

6 7
188 552

9 14 8 563 510 174 22 21 264 565

10 705.1
15 16 17 20
705.2

275 519 555

18 19 51 52

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 011 120 54 aA NSS
211001 CABLE REEL ASSEMBLY / WITH SPOOLING DEVICE 10 (209)

Ref. Part no. Description EN Standard designation Qty

e
566 AF0 300 0126 WASHER, LOCK, PAIR NL20-sp 4
900 551 512 36 SHRINK WRAP 92/25, black 0.15
*704.1 551 000 84 SUPPORT, CABLE L600 D25-38, braided 1
*704.2 551 000 86 SUPPORT, CABLE L600 D40-50, braided 1
*704.3 551 000 87 SUPPORT, CABLE L600 D50-65, braided 1
. . . . .
*704.4 551 000 90 SUPPORT, CABLE L600 D65-80, braided 1
*705.1 813 105 09 SUPPORT, CABLE L600 D40-50 1
*705.2 814 853 99 SUPPORT, CABLE L600 D65-80 1

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 011 035 78 aA
11 (209) CABLE REEL / CABLE REEL 211001

9 8 7 2 34 35

37 36 26

19 28

C 21 27
1 6

29 19
4
33
22 23 24 25
32 29

10 11 5

8 15 16 17 18
4
19 20

7 8 12 13

30 31

15 14 8

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 011 035 78 aA
211001 CABLE REEL / CABLE REEL 12 (209)

Ref. Part no. Description EN Standard designation Qty

e
1 551 721 42 DRUM 1
2 550 526 72 ENTRY, CABLE Ø920 1
3 550 686 14 WHEEL 2
4 550 535 54 SLIP RING UNIT SECTION 11 PAGE 14 1
5 551 737 06 CABLE Earth cable 2
. . . . .
6 551 976 20 GEARBOX SECTION 11 PAGE 17 1
12 550 532 16 NUT M6 1
13 550 535 64 TERMINAL, WIRE 3
14 550 532 15 NUT M10 3
15 550 535 67 TIE ROD M10 x 45 3
. . . . .
16 550 532 07 WASHER M10 26
17 551 976 32 TIE ROD Tierod M10 x 400 11
18 550 532 24 NUT Selflocking hex. nut M 10 23
19 550 526 61 TIE ROD Tierod M10 x 190 galvanized 1
20 550 530 47 PIPE, SLEEVE M10x40 1
. . . . .
21 550 531 77 BOLT Cup square bolt M10 x 60 1
23 551 737 28 PLATE Closing plate 2
24 551 737 26 SEAL Gasket for closing cover RAC PR 1
25 551 737 27 COVER RAC drum closing cover 1
26 550 532 09 WASHER M8 8
. . . . .
27 550 532 02 SCREW M8x20 8
29 551 976 35 BOLT, EYE male 1
30 551 737 05 COVER Kit closing flange 1
31 551 737 28 PLATE Closing plate 1
35 550 531 31 BUSHING Through terminal MK 3/2 1
. . . . .
37 551 976 37 ENTRY, CABLE Cable gland kit 1
38 551 976 39 COVER Closing plate 1

Sandvik Mining and Construction Oy Drills Tampere © 2021

 550 535 54 a
13 (209) SLIP RING UNIT 211001

67 73 10 54 66 60 9 32 6 14 15 18 22 20 24 36
59 19 23
13
47 48
29
45 46
8 7

58 57 49 50

5 77
3
38 39
1
40

42 43
44

37

75

2 33 68 69

34 25
35
27 28

21
56
31

74 55 30 16 17 72

Sandvik Mining and Construction Oy Drills Tampere © 2021

 550 535 54 a
211001 SLIP RING UNIT 14 (209)

Ref. Part no. Description EN Standard designation Qty

e
1 867 756 09 SLIP RING ACCESSORY 1
2 550 526 76 BUSHING Reduction bushing 1
3 550 531 81 SCREW M10X35 3
5 550 526 77 FLANGE Base ring flange 1
6 550 526 80 TIE ROD M14 x 217 galvanized 3
. . . . .
7 550 532 12 NUT M14 3
8 550 532 28 WASHER M14 6
9 550 528 01 PIPE Fibre glass tube L = 178 mm 3
10 867 758 69 RING, SLIP 600A 4
13 550 395 51 TERMINAL, WIRE 34mm 3
. . . . .
14 550 528 15 PIPE Fibre glass tube L = 42 mm 9
15 550 535 74 CROSS 1
16 550 531 31 BUSHING Through terminal MK 3/2 1
17 550 531 94 SCREW M3X20 1
18 550 532 13 NUT Thin hexagon nut M14 3
. . . . .
19 550 166 34 TIE ROD M8x65 3
20 550 166 35 PIPE, INSULATING Glass-fibre isolating tube, L=24mm 3
21 550 166 37 PIPE, INSULATING PVC isolating tube L=15 3
22 550 532 14 NUT M8 9
23 883 931 29 RING, SLIP d130/30A 2
. . . . .
24 885 645 89 RING 3
25 550 166 38 BUSHING, RUBBER Rubber bushing 6,4 6
27 550 532 09 WASHER M8 5
28 550 532 17 NUT Selflocking hex. nut M 8 3
29 550 528 31 PLATE, BASE 1
. . . . .
30 550 526 82 TIE ROD M10 x 322 galvanized 6
31 550 532 15 NUT M10 10
32 550 528 24 PIPE PVC insulating tube L = 281 mm 4
33 550 532 07 WASHER M10 2
34 550 528 25 PIPE PVC insulating tube L = 286 mm 2
. . . . .
35 886 685 29 BUSHING 2
36 550 528 32 FLANGE Upper bearing flange 1
37 550 394 31 BEARING, SUPPORT 1
38 550 531 85 SCREW [Link] M6x16 3
39 550 535 75 WASHER M6 3
. . . . .
40 550 532 16 NUT M6 3
42 550 532 29 WASHER Lock washer M12 1
43 550 531 86 SCREW Hexag. screw M12x11 0 1
44 550 532 20 NUT Selflocking hex. nut M 12 1
45 550 535 76 TIE ROD M8 x 58 2
. . . . .
46 550 528 26 PIPE PVC insulating tube L = 17 mm 2
47 550 531 32 SLEEVE, INSULATING Brushgear insulator for Collector 2
48 550 531 34 ISOLATOR End insulator for Collector 2
49 550 532 32 WASHER Lock washer M8 2
50 550 532 21 NUT Thin hexagon nut M 8 2
. . . . .
54 550 535 82 CABLE, PREWIRED, IO Earth connection 16 mmq 2
55 550 535 83 HOUSING 1
56 550 531 88 SCREW M10x30 4
57 550 531 89 SCREW M6x16 4
58 550 532 34 WASHER plain washer M 6 4
. . . . .
59 550 532 35 WASHER lock washer M 6 2
60 550 532 22 NUT M6 2
66 550 535 85 SEAL Gasket L = 2150 1
69 550 528 27 WIRE Wiring cable 1x2,5 for Collector 2
72 550 535 89 SPACER L = 45 mm 1
. . . . .
73 550 535 90 BAR 3
74 550 530 49 PLATE 1
75 550 535 91 SEAL Sealing plug 2" 2
77 550 535 93 NUT 2" 2

Sandvik Mining and Construction Oy Drills Tampere © 2021

 550 535 54 a
15 (209) SLIP RING UNIT 211001

65

51

52

26 12

41 11

76

81
82
83
84

59 54 53 61 64 78 79 80

60 62

Sandvik Mining and Construction Oy Drills Tampere © 2021

 550 535 54 a
211001 SLIP RING UNIT 16 (209)

Ref. Part no. Description EN Standard designation Qty

e
11 550 531 83 SCREW M12X25 7
12 550 166 39 FASTENING ACCESORY, CABLE Phase clamp 1
26 550 166 39 FASTENING ACCESORY, CABLE Phase clamp 6
41 550 532 33 WASHER M12 4
51 883 930 09 BRUSH, CARBON 2
. . . . .
52 550 531 35 TERMINAL, WIRE Push-on terminal 2
53 883 929 39 BRUSH, CARBON 7
54 550 535 82 CABLE, PREWIRED, IO Earth connection 16 mmq 2
59 550 532 35 WASHER lock washer M 6 2
60 550 532 22 NUT M6 2
. . . . .
61 550 528 21 GLAND, CABLE 2
62 550 532 23 NUT Ring nut PG 11 2
64 867 777 59 SWITCH, LIMIT 1
65 550 535 84 HOUSING 1
76 550 535 92 O-RING 4200 2
. . . . .
78 550 531 79 SCREW [Link] M 12x30 3
79 550 166 39 FASTENING ACCESORY, CABLE Phase clamp 3
80 550 532 33 WASHER M12 3
81 550 532 11 NUT M12 3
4 550 532 24 NUT Selflocking hex. nut M 10 9
. . . . .
63 867 776 29 MICROSWITCH 1
70 550 531 97 SCREW Cap screw M 6x16 6
71 550 528 33 PLATE, GASKET Housing gasket for Collector 1

Sandvik Mining and Construction Oy Drills Tampere © 2021

 551 976 20
17 (209) GEARBOX / INCLUDES HYDRAULIC MOTOR ADAPTER 211001

Ref. Part no. Description EN Standard designation Qty

e
1 551 971 27 GEARBOX SECTION 11 PAGE 20 1
2 550 525 65 ADAPTER SECTION 11 PAGE 25 1

Sandvik Mining and Construction Oy Drills Tampere © 2021

 551 971 27 bB
19 (209) GEARBOX / GEARBOX T4 1:15 WITH CHAIN ADAPTER-DOWN 211001

VIEW C - C

50 49 48 27

Sandvik Mining and Construction Oy Drills Tampere © 2021

 551 971 27 bB
211001 GEARBOX / GEARBOX T4 1:15 WITH CHAIN ADAPTER-DOWN 20 (209)

Ref. Part no. Description EN Standard designation Qty

e
27 551 976 19 FLANGE Intermediate support flange for Spooling 1
device
48 551 563 19 SHAFT + GEAR Dog hub and sprocket shaft 1
49 551 563 20 ARM, ROTATION Torque key 2
50 551 563 21 HEXAGON SOCKET HEAD SCREW M6x12 4
900 550 910 32 GEARBOX SECTION 11 PAGE 22 1
. . . . .

Sandvik Mining and Construction Oy Drills Tampere © 2021

 550 910 32 dD
21 (209) GEARBOX 211001

22

28 42 2 26 51 19 20 18 17 16 21 41 6 5

B A

29 27 25 24 11 14 10 9 8 15 1 4 23 7

47
32 33 34

VIEW B - B VIEW A - A

Sandvik Mining and Construction Oy Drills Tampere © 2021

 550 910 32 dD
211001 GEARBOX 22 (209)

Ref. Part no. Description EN Standard designation Qty

e
1 550 529 20 HOUSING - 1
2 550 529 21 HOUSING - 1
3 550 529 24 SHAFT Main shaft 1
4 550 529 51 SEAL Oil seal 1
5 550 529 63 BEARING 1
. . . . .
6 550 529 53 CIRCLIP - 1
7 550 529 57 WEDGE KEY 12x8x35 1
8 550 529 54 CIRCLIP E 80 1
9 550 529 56 PIN Cylindrical pin 6x22 2
10 550 529 58 WHEEL Sun wheel 1
. . . . .
11 550 529 59 WHEEL Conic wheel 1
14 550 531 90 SCREW M 10x20 6
15 550 529 60 SUPPORT - 1
16 550 529 62 SUPPORT - 3
17 550 529 69 BEARING - 3
. . . . .
18 550 529 67 GEAR WHEEL Satellite pinion 3
19 550 529 84 RING Joint ring T3/T4 3
20 550 531 91 SCREW M4X12 6
21 551 994 65 WASHER M18 3
22 551 994 66 NUT Ring nut 17x1 3
. . . . .
23 550 529 70 RING V-Ring 1
24 550 529 76 BEARING - 1
25 550 529 77 SPACER - 1
26 550 529 78 BEARING - 1
27 550 529 79 FLANGE 1
. . . . .
28 550 529 52 SEAL Oil seal 1
29 550 531 92 SCREW M8x20 6
32 550 529 85 PIN Screw dowl pin for T4/T5 M12x45 4
33 550 532 08 WASHER M12 4
34 550 532 25 NUT M12 4
. . . . .
41 550 529 94 PIN Spring pin 3x18 3
42 550 532 26 NUT Crown nut 75x2 1
47 550 530 00 WASHER 1

Sandvik Mining and Construction Oy Drills Tampere © 2021

 550 910 32 dD
23 (209) GEARBOX 211001

40 39

36

37

38

30

43

VIEW C - C

Sandvik Mining and Construction Oy Drills Tampere © 2021

 550 910 32 dD
211001 GEARBOX 24 (209)

Ref. Part no. Description EN Standard designation Qty

e
30 550 531 93 SCREW M10X120 4
36 550 529 88 PLUG G1/2 1
37 550 529 89 PLUG TM 1/2 1
38 550 529 90 PLUG LMA 1/2 1
43 550 529 98 SEAL Bond seal 1/8 4
. . . . .

Sandvik Mining and Construction Oy Drills Tampere © 2021

 550 525 65 a
25 (209) ADAPTER 211001

7 8

1
3

5 6

2 4

Ref. Part no. Description EN Standard designation Qty

e
1 550 525 71 HOUSING 1
2 550 530 02 BEARING 2
3 550 525 82 SHAFT 1
4 550 525 84 WEDGE KEY 8x7x35 1
5 550 525 87 CIRCLIP E 40 1
. . . . .
6 550 525 89 RING, SEAL Oil seal 1
7 550 531 79 SCREW [Link] M 12x30 2
8 550 532 08 WASHER M12 2

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 004 508 82 bB NSS
211001 CABLE GUIDING BRACKET 26 (209)

5 7

4 2 5 6

Ref. Part no. Description EN Standard designation Qty

e
2 551 923 65 ROLLER GST Roller D76.1mm, d20, L=400 Zn 2
3 551 687 80 ROLLER GST Roller D76.1mm, d20, L=200 2
4 551 897 31 SPACER Cable guide 4
5 550 130 59 WASHER, LOCK, DOUBLE M12 8
6 801 211 89 HEXAGON HEAD BOLT M12X65 4
. . . . .
7 800 470 59 HEXAGON HEAD SCREW M12x30 4

Sandvik Mining and Construction Oy Drills Tampere © 2021

 551 875 81
27 (209) CABLE GUIDE ASSEMBLY 211001

12

10

11
2

13 3

Sandvik Mining and Construction Oy Drills Tampere © 2021

 551 875 81
211001 CABLE GUIDE ASSEMBLY 28 (209)

Ref. Part no. Description EN Standard designation Qty

e
1 551 875 82 BRACKET Cable guide 1
2 551 687 80 ROLLER GST Roller D76.1mm, d20, L=200 4
3 550 905 16 SLIPPER PAD 1
10 550 130 59 WASHER, LOCK, DOUBLE M12 8
11 800 470 59 HEXAGON HEAD SCREW M12x30 4
. . . . .
12 800 531 79 HEXAGON HEAD SCREW M12x40 4
13 445 801 40 HEXAGON SOCKET HEAD SCREW M10x40 - 8.8 2

Sandvik Mining and Construction Oy Drills Tampere © 2021

 551 562 84 aA
29 (209) SHAFT ASSEMBLY / SPOOLING SHAFT KIT 211001

10 9 8 11 5

6 7
1 4

Ref. Part no. Description EN Standard designation Qty

e
1 551 562 80 SHAFT Spooling shaft, d=50 / p=6,0 1
2 551 562 14 KEY BAR Key A 12x8x35 1
3 551 562 15 PULLEY, CHAIN Z=25 1
4 551 562 16 SUPPORT FOR ADJUSTABLE FLANGE 2
5 551 562 81 SLIDE D=50 1
. . . . .
6 551 562 82 PIN, GUIDE For cursor, d=50 1
7 551 562 83 CIRCLIP J 30 1
8 551 562 20 PLATE, COVER 1
9 551 562 21 HEXAGON HEAD SCREW M10x20 2
10 551 562 22 WASHER M10 2
. . . . .
11 551 562 23 NIPPLE, GREASE, STRAIGHT M8x1 1

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 001 732 17 aA
211001 CONTROL BLOCK ASSEMBLY 30 (209)

Ref. Part no. Description EN Standard designation Qty

e
1 552 160 27 DRILLING MODULE SECTION 11 PAGE 32 1
2 817 180 79 ELBOW, SWIVEL NUT 9/16-18JIC 2
3 816 702 09 STRAIGHT THREAD ADAPTER 9/16-18 JIC 4

Sandvik Mining and Construction Oy Drills Tampere © 2021

 552 160 27 b
31 (209) DRILLING MODULE 211001

4 5

6
9

15

16
13

11
8
12

3
16

14
2

10

Sandvik Mining and Construction Oy Drills Tampere © 2021

 552 160 27 b
211001 DRILLING MODULE 32 (209)

Ref. Part no. Description EN Standard designation Qty

e
2 552 244 75 DAMPER Delay unit 1
2.1 552 260 00 PISTON Delay unit piston 1
2.2 552 259 98 SPRING 5x16x100 1
2.3 550 759 34 O-RING 31.42x2.62-90 1
2.4 046 021 54 O-RING 40,94 x 2,62 1
. . . . .
2.5 550 836 62 ORIFICE 0,4mm M6 1
3 881 107 29 VALVE, SPOOL, DIRECTIONAL Q 23 l/min, p_max 207 bar 1
3.1 882 532 39 SEAL KIT
3.2 882 535 19 COIL 1
4 552 244 31 VALVE, SPOOL, DIRECTIONAL 4,1 bar 1
. . . . .
4.1 882 880 09 SEAL KIT 1
5 881 108 59 VALVE, PRESSURE RELIEF 1
5.1 882 534 99 SEAL KIT 1
6 881 108 59 VALVE, PRESSURE RELIEF 1
6.1 882 534 99 SEAL KIT 1
. . . . .
7 881 788 99 VALVE, CHECK 1
7.1 882 878 19 SEAL KIT 1
8 552 244 73 VALVE, CHECK 1
9 550 673 91 STRAINER, OIL 100 MICRON 1
10 551 736 24 ORIFICE M6x6 D0,3 1
. . . . .
11 552 246 79 ORIFICE M6x6 D2,0 1
12 552 246 79 ORIFICE M6x6 D2,0 1
16 816 885 99 FITTING, QUICK CONNECT 4

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 007 924 87 aA NSS
33 (209) REEL, WATER HOSE / WATER HOSE REEL ASSEMBLY 211001

265 555 1 51

7 4 2 553 202

11
8

152 561
205

10 553

9 206

563
5

50

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 007 924 87 aA NSS
211001 REEL, WATER HOSE / WATER HOSE REEL ASSEMBLY 34 (209)

Ref. Part no. Description EN Standard designation Qty

e
1 551 705 53 BRACKET SECTION 11 PAGE 37 1
2 551 799 81 BRACKET Water hose reel 1
4 550 412 43 REEL, WATER HOSE SECTION 11 PAGE 43 1
5 AF1 014 0012 ADAPTER, MALE STUD CONNECTOR JIC 9/16 - BSPP 1/2 2
7 872 683 09 ADAPTER, HYDRAULIC R2x1,7/8-12UNF-JIC 2
. . . . .
8 813 078 19 HYDRAULIC MOTOR, GEROTOR Vg_max 80 ccm/rev, p_max 230 bar 1
9 332 312 88 SPROCKET WHEEL 1
10 207 065 88 FLANGE 1
11 263 439 08 SPACER 1
50 BG 007 924 69 NSS VALVE, SHOCK LOAD SECTION 11 PAGE 46 1
. . . . .
51 551 000 64 NSS VALVE ASSEMBLY SECTION 11 PAGE 47 1
152 AF0 010 0330 SCREW, HEXAGON HEAD, FULL THREAD M8x50-8.8 Zn 1
202 AF0 010 0735 SCREW, HEXAGON HEAD, FULL THREAD M12x25 1
205 AF0 010 0737 SCREW, HEXAGON HEAD, FULL THREAD M12x35 4
206 AF0 010 0738 SCREW, HEXAGON HEAD, FULL THREAD M12x40 4
. . . . .
265 AF0 010 1126 SCREW, HEXAGON HEAD, FULL THREAD M16x45 6
553 AF0 300 0032 WASHER, LOCK, PAIR NL12 5
555 AF0 300 0034 WASHER, LOCK, PAIR NL16 6
561 AF0 300 0120 WASHER, LOCK, PAIR NL8-sp 1
563 AF0 300 0122 WASHER, LOCK, PAIR NL12-sp 4
. . . . .

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 007 924 87 aA NSS
35 (209) REEL, WATER HOSE / WATER HOSE REEL ASSEMBLY 211001

7 17 18 12 13

100

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 007 924 87 aA NSS
211001 REEL, WATER HOSE / WATER HOSE REEL ASSEMBLY 36 (209)

Ref. Part no. Description EN Standard designation Qty

e
7 872 683 09 ADAPTER, HYDRAULIC R2x1,7/8-12UNF-JIC 2
12 AF1 007 0025 ADAPTER, UNION JIC 1 7/8 1
13 550 550 81 PIPE ASSEMBLY 38x3 1
17 802 285 69 USIT-SEAL U 60,7X73X3 D2=62,8 1
18 AF1 146 0011 ADAPTER, SWIVEL NUT ELBOW JIC 1 7/8 1
. . . . .
100 551 979 71 HOSING SET SECTION 11 PAGE 48 1

Sandvik Mining and Construction Oy Drills Tampere © 2021

 551 705 53 cC
37 (209) BRACKET / ASSEMBLY - WATER HOSE REEL 211001

3 172 552

562 174

174 552

23

174 509 2 1 6

Ref. Part no. Description EN Standard designation Qty

e
1 551 648 17 BRACKET Bracket 1
2 551 643 26 PLATE, COVER Water hose reel 1
3 551 649 97 GUARD Chain guard 1
6 551 646 50 BRACKET SECTION 11 PAGE 40 1
7 572 102 40 NIPPLE, GREASE AR 1/8 1
. . . . .
8 550 339 58 BUSH, PLAIN, DRY da = 65 mm, d_i = 60 mm 2
23 551 653 53 ASSEMBLY SECTION 11 PAGE 42 1
172 AF0 010 0524 SCREW, HEXAGON HEAD, FULL THREAD M10x20 3
174 AF0 010 0528 SCREW, HEXAGON HEAD, FULL THREAD M10x30 8
509 AF0 200 0005 NUT, HEXAGON, PREVAILING TORQUE, ALL M10 1
METAL
. . . . .
552 AF0 300 0031 WASHER, LOCK, PAIR NL10 4
562 AF0 300 0121 WASHER, LOCK, PAIR NL10-sp 6

Sandvik Mining and Construction Oy Drills Tampere © 2021

 551 646 50 cC
39 (209) BRACKET 211001

555

Sandvik Mining and Construction Oy Drills Tampere © 2021

 551 646 50 cC
211001 BRACKET 40 (209)

Ref. Part no. Description EN Standard designation Qty

e
2 551 645 72 SHAFT 1
3 AF0 050 0779 SCREW, SOCKET HEAD, HEXAGON M16x40 4
555 AF0 300 0034 WASHER, LOCK, PAIR NL16 4

Sandvik Mining and Construction Oy Drills Tampere © 2021

 551 653 53
41 (209) ASSEMBLY / PIN+CHAIN 211001

172 552 4

552 171 5 5

Sandvik Mining and Construction Oy Drills Tampere © 2021

 551 653 53
211001 ASSEMBLY / PIN+CHAIN 42 (209)

Ref. Part no. Description EN Standard designation Qty

e
1 551 653 50 PIN 1
2 551 510 44 LINCH PIN D=4,5mm, L=40mm 1
3 550 074 52 WIRE ROPE 2mm, 7X19, A4 0.27
4 550 074 52 WIRE ROPE 2mm, 7X19, A4 0.28
5 550 192 99 CRIMP For 2 mm Wire Rope 8
. . . . .
171 800 432 79 HEXAGON HEAD SCREW M10X16 1
172 800 823 09 HEXAGON HEAD SCREW M10X20 1
552 851 282 09 WASHER, LOCK, DOUBLE M10 4

Sandvik Mining and Construction Oy Drills Tampere © 2021

 550 412 43 a
43 (209) REEL, WATER HOSE / GR1-1½ IN 211001

A 2

5
A 6

3
SECTION A - A

Ref. Part no. Description EN Standard designation Qty

e
*1 550 531 37 DRUM 1
*2 550 530 12 SHAFT SECTION 11 PAGE 44 1
*3 550 531 43 CHAIN 1
*3.1 550 531 44 CHAIN Roller chain 5/8" 1
*3.2 550 531 45 CHAIN LINK Chain joint 5/8 1
. . . . .
*3.3 550 531 41 CHAIN PULLEY Chain wheel Z=110 , 5/8" 1
*3.4 550 532 05 SCREW [Link] M 8x25 6
*4 550 531 56 CONNECTING PIECE Kit GR1 2" su CR 25 Bar 1
*5 550 531 62 PIPE Kit R515-270 GR 1 2" 1
*6 550 531 64 PIPE Kit R515-270 GR 1 2" 1
. . . . .

Sandvik Mining and Construction Oy Drills Tampere © 2021

 550 530 12
211001 SHAFT 44 (209)

10
2

2v”
G

3
4 A --A
1
6
5 7

Ref. Part no. Description EN Standard designation Qty

e
1 550 530 18 SHAFT 1
2 550 530 14 BEARING Bearing 2
3 550 529 55 CIRCLIP 1
4 550 528 29 BUSHING, BEARING Bushing for bearing 1
5 550 532 06 SCREW Hexag. screw M 10x5 5 12
. . . . .
6 550 532 30 WASHER M10 12
7 550 532 07 WASHER M10 12
10 550 530 21 O-RING O-ring 4225 for Swivel 2"-25 Bar 2

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 007 924 69 bB NSS
45 (209) VALVE, SHOCK LOAD / ASSEMBLY 211001

10

8 4 5 6 7

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 007 924 69 bB NSS
211001 VALVE, SHOCK LOAD / ASSEMBLY 46 (209)

Ref. Part no. Description EN Standard designation Qty

e
1 BG 007 719 79 VALVE, PRESSURE RELIEF Q 256 l/min, p_max 50 bar 1
2 AF1 014 0033 ADAPTER, MALE STUD CONNECTOR JIC 1 5/16 - BSPP 1 1/4 1
3 AF1 035 0012 ADAPTER, SWIVEL MALE STUD JIC 1 1/16 - BSPP 3/4 1
4 AF1 147 0006 ADAPTER, SWIVEL NUT RUN TEE JIC 1 1/16 1
5 550 716 42 REDUCER, TUBE END 1,7/8X1,1/16JIC 1
. . . . .
6 AF1 040 0009 ADAPTER, NUT JIC 1 7/8 1
7 AF1 147 0010 ADAPTER, SWIVEL NUT RUN TEE JIC 1 7/8 1
8 AF1 175 0001 ADAPTER, TEST POINT CONNECTOR JIC 1 1/16 - BSPP 1/4 1
10 AF1 143 0005 ADAPTER, TEST POINT WITH THREADED G 1/4 1
CONNECTION M 16X

Sandvik Mining and Construction Oy Drills Tampere © 2021

 551 000 64 cA NSS
47 (209) VALVE ASSEMBLY 211001

4 6

Ref. Part no. Description EN Standard designation Qty

e
1 885 443 79 VALVE ASSEMBLY Q 150 l/min, p_max 400 bar 1
1.1 885 444 09 VALVE, PRESSURE RELIEF Q 150 l/min, p_max 400 bar 1
1.1.1 885 446 59 SEAL KIT 1
1.2 885 445 29 BODY 1
2 816 702 09 STRAIGHT THREAD ADAPTER 9/16-18 JIC 2
. . . . .
3 817 180 79 ELBOW, SWIVEL NUT 9/16-18JIC 1
4 816 885 99 FITTING, QUICK CONNECT 1
5 850 778 99 CONNECTOR, PRESSURE GAUGE 9/16-18 JIC 1
6 816 719 09 ADAPTER, TEE 9/16-18 JIC 1

Sandvik Mining and Construction Oy Drills Tampere © 2021

 551 979 71 hH
211001 HOSING SET / REAR ASSEMBLY 48 (209)

12 11 10 13 14 800 5 4 3 2 1

7 6

Ref. Part no. Description EN Standard designation Qty

e
1 552 091 52 ADAPTER, HYDRAULIC Claw coupling 2" - 1 1/2" Hose 1
2 550 004 22 CONNECTOR Claw coupling R2 in out thread 1
3 803 324 19 REDUCER R2XR1 1/2 1
4 AF1 014 0038 ADAPTER, MALE STUD CONNECTOR JIC 1 7/8 - BSPP 1 1/2 1
6 AF1 007 0025 ADAPTER, UNION JIC 1 7/8 1
. . . . .
12 102 125 18 BUFFER, RUBBER D60, AK 70/150 1
13 806 658 69 CLAMP, HOSE D 60-76 mm, Cast Iron 2
14 551 000 87 SUPPORT, CABLE L600 D50-65, braided 1
800 BG 002 866 69 HOSE ASSEMBLY, HYDRAULIC 1SN BC-24-01400-J24A-J24A-0-0 1

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 009 616 88 cC NSS
49 (209) POWER PACK ASSEMBLY / NC7, PUMPS 112+33, RIGHT 211001

32

553

172

552 264

25
555
7

142 3

551
4

8
14
13
1
12

24 16

11
15
10
2
17

20

31

30

18

553

794

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 009 616 88 cC NSS
211001 POWER PACK ASSEMBLY / NC7, PUMPS 112+33, RIGHT 50 (209)

Ref. Part no. Description EN Standard designation Qty

e
1 BG 009 705 18 HYDRAULIC PUMP, AXIAL PISTON SECTION 11 PAGE 51 1
2 550 394 59 HYDRAULIC PUMP, EXTERNAL GEAR 33cc 1
2.1 550 394 60 SEAL KIT 1
3 550 404 30 FLANGE For oil cooler, left 1
4 550 241 93 CLUTCH, HALF Flexible clutch, 55/70-98 1
. . . . .
5 550 241 92 CLUTCH, HALF Flexible clutch, 55/70-98 1
6 550 265 54 SPACER RING 1
8 BG 009 635 21 PRESSURE FILTER ASSEMBLY SECTION 11 PAGE 52 1
10 551 794 52 CHECK VALVE ASSEMBLY SECTION 11 PAGE 54 1
11 800 385 79 O-RING 38x3,5 1
. . . . .
12 AF1 146 0009 ADAPTER, SWIVEL NUT ELBOW JIC 1 5/16 1
13 AF1 112 0042 ADAPTER, MALE STUD CONNECTOR JIC 1 5/16 - UNF 1 1/16 1
14 AF1 112 0015 ADAPTER, MALE STUD CONNECTOR JIC 9/16 - UNF 7/16 1
15 AF1 178 0011 FLANGE CLAMP, HALF, SPLIT SAE 2 1/2 2
16 451 335 30 HEXAGON HEAD SCREW 1/2 UNCX32 M8.8 4
. . . . .
17 857 012 49 HEXAGON SOCKET HEAD SCREW 1/2 in UNC X 2 1/4 in 4
18 AF1 015 0021 ADAPTER, MALE STUD ELBOW JIC 1 5/16 - BSPP 1 1
20 AF1 014 0034 ADAPTER, MALE STUD CONNECTOR JIC 1 5/8 - BSPP 1 1/4 1
24 AF1 145 0009 ADAPTER, MALE STUD ELBOW JIC 9/16 - UNF 7/16 1
30 AF0 010 1126 SCREW, HEXAGON HEAD, FULL THREAD M16x45 2
. . . . .
31 AF0 300 0124 WASHER, LOCK, PAIR NL16-sp 2
32 AF0 010 0737 SCREW, HEXAGON HEAD, FULL THREAD M12x35 2
142 AF0 010 0320 SCREW, HEXAGON HEAD, FULL THREAD M8x16 4
172 AF0 010 0524 SCREW, HEXAGON HEAD, FULL THREAD M10x20 4
264 AF0 010 1125 SCREW, HEXAGON HEAD, FULL THREAD M16x40 2
. . . . .
551 AF0 300 0030 WASHER, LOCK, PAIR NL8 4
552 AF0 300 0031 WASHER, LOCK, PAIR NL10 4
553 AF0 300 0032 WASHER, LOCK, PAIR NL12 4
555 AF0 300 0034 WASHER, LOCK, PAIR NL16 2
794 AF0 050 0565 SCREW, SOCKET HEAD, HEXAGON M12x30 2
. . . . .

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 009 705 18 cA
51 (209) HYDRAULIC PUMP, AXIAL PISTON 211001

2 3

116 742

Ref. Part no. Description EN Standard designation Qty

e
*1 BG 009 705 54 SEAL KIT For Pump 1
*2 BG 009 705 66 SEAL KIT For Regulator 1
*3 BG 009 705 70 REGULATOR For Pump 1
*742 BG 009 705 40 O-RING For Through Drive SAE B 1
*800 BG 011 696 75 SPARE PARTS KIT - 1
. . . . .

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 009 635 21 aA
211001 PRESSURE FILTER ASSEMBLY 52 (209)

Ref. Part no. Description EN Standard designation Qty

e
1 815 583 49 FILTER, PRESSURE 20 abs, R1 1
1.1 815 584 79 FILTER ELEMENT, PRESSURE Q 300 l/min, 20 micron 1
1.2 869 305 49 SEAL KIT 1
2 816 628 69 INDICATOR In filter 1
3 AF1 015 0021 ADAPTER, MALE STUD ELBOW JIC 1 5/16 - BSPP 1 2
. . . . .

Sandvik Mining and Construction Oy Drills Tampere © 2021

 551 794 52
53 (209) CHECK VALVE ASSEMBLY / FOR 112CC PUMP 211001

5 2

Sandvik Mining and Construction Oy Drills Tampere © 2021

 551 794 52
211001 CHECK VALVE ASSEMBLY / FOR 112CC PUMP 54 (209)

Ref. Part no. Description EN Standard designation Qty

e
1 323 503 38 VALVE SECTION 1
2 888 036 69 VALVE, CHECK RKVE-25 R1" 1
2.1 550 348 38 SPECIAL TOOLS 1
3 888 037 99 VALVE, CHECK RB3 1/2 1
4 816 700 59 STRAIGHT THREAD ADAPTER G 1 x JIC 1 5/16-12 1
. . . . .
5 881 142 29 PLUG G1 1
6 817 098 79 STRAIGHT THREAD ELBOW G 1/2 x JIC 3/4-16 1

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 009 611 22 bB NSS
55 (209) POWER PACK ASSEMBLY 211001

264

555

172

552

3 142

551

6 8

14
12

22
13

1 23

15 10

16 17

24 11

2 31

20 30

21
18

19

553

794

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 009 611 22 bB NSS
211001 POWER PACK ASSEMBLY 56 (209)

Ref. Part no. Description EN Standard designation Qty

e
1 BG 009 705 18 HYDRAULIC PUMP, AXIAL PISTON SECTION 11 PAGE 51 1
2 550 394 69 HYDRAULIC PUMP, EXTERNAL GEAR, 33cc+26cc, [Link]. 250 1
DOUBLE
2.1 550 394 60 SEAL KIT 2
3 550 404 30 FLANGE For oil cooler, left 1
4 550 241 93 CLUTCH, HALF Flexible clutch, 55/70-98 1
. . . . .
5 550 241 92 CLUTCH, HALF Flexible clutch, 55/70-98 1
6 550 265 54 SPACER RING 1
7 550 404 12 PLATE, COVER 1
8 BG 009 635 21 PRESSURE FILTER ASSEMBLY SECTION 11 PAGE 52 1
10 551 794 52 CHECK VALVE ASSEMBLY SECTION 11 PAGE 54 1
. . . . .
11 800 385 79 O-RING 38x3,5 1
12 AF1 146 0009 ADAPTER, SWIVEL NUT ELBOW JIC 1 5/16 1
13 AF1 112 0042 ADAPTER, MALE STUD CONNECTOR JIC 1 5/16 - UNF 1 1/16 1
14 AF1 112 0015 ADAPTER, MALE STUD CONNECTOR JIC 9/16 - UNF 7/16 1
15 AF1 178 0011 FLANGE CLAMP, HALF, SPLIT SAE 2 1/2 2
. . . . .
16 AF0 010 0737 SCREW, HEXAGON HEAD, FULL THREAD M12x35 4
17 737 025 16 SCREW M14X55 - 12.9 4
18 AF1 015 0021 ADAPTER, MALE STUD ELBOW JIC 1 5/16 - BSPP 1 1
19 AF1 015 0018 ADAPTER, MALE STUD ELBOW JIC 1 1/16 - BSPP 3/4 1
20 AF1 014 0034 ADAPTER, MALE STUD CONNECTOR JIC 1 5/8 - BSPP 1 1/4 1
. . . . .
21 AF1 014 0030 ADAPTER, MALE STUD CONNECTOR JIC 1 5/16 - BSPP 1 1
22 AF1 147 0004 ADAPTER, SWIVEL NUT RUN TEE JIC 3/4 1
23 AF1 146 0005 ADAPTER, SWIVEL NUT ELBOW JIC 3/4 1
24 AF1 145 0009 ADAPTER, MALE STUD ELBOW JIC 9/16 - UNF 7/16 1
30 AF0 010 1126 SCREW, HEXAGON HEAD, FULL THREAD M16x45 2
. . . . .
31 AF0 300 0124 WASHER, LOCK, PAIR NL16-sp 2
142 AF0 010 0320 SCREW, HEXAGON HEAD, FULL THREAD M8x16 4
172 AF0 010 0524 SCREW, HEXAGON HEAD, FULL THREAD M10x20 4
264 AF0 010 1125 SCREW, HEXAGON HEAD, FULL THREAD M16x40 2
551 AF0 300 0030 WASHER, LOCK, PAIR NL8 4
. . . . .
552 AF0 300 0031 WASHER, LOCK, PAIR NL10 4
553 AF0 300 0032 WASHER, LOCK, PAIR NL12 2
555 AF0 300 0034 WASHER, LOCK, PAIR NL16 2
794 AF0 050 0565 SCREW, SOCKET HEAD, HEXAGON M12x30 2

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 010 520 70 aA
57 (209) COMPRESSOR ASSEMBLY / 2.8 M3/MIN, 440-480 V 211001

3 6 7

4
1

Ref. Part no. Description EN Standard designation Qty

e
1 BG 005 175 54 ELECTRIC MOTOR, THREE PHASE 18.5 kW, 380-440-660-690V/50Hz 1
440-480V/60Hz
2 BG 006 325 56 FRAME ASSEMBLY SECTION 11 PAGE 58 1
3 552 125 35 NSS ASSEMBLY SECTION 11 PAGE 59 1
4 BG 010 793 28 NSS COOLER ASSEMBLY SECTION 11 PAGE 62 1
5 BG 006 337 27 HOSE ASSEMBLY SECTION 11 PAGE 63 1
. . . . .
6 BG 006 337 25 NSS VALVE ASSEMBLY SECTION 11 PAGE 66 1
7 BG 006 338 15 NSS PIPING, CONTROL AIR SECTION 11 PAGE 70 1
8 BG 006 339 70 NSS COMPRESSOR COMPONENTS SECTION 11 PAGE 72 1
9 BG 006 340 20 AIR END SECTION 11 PAGE 75 1
103 BG 005 169 30 SERVICE KIT Oil and Air Filter Kit (every 500h) 1
. . . . .
104 BG 005 169 33 SERVICE KIT Oil Separator Kit (every 1000h) 1
105 BG 005 169 35 SERVICE KIT Inlet and Discharge Valve Kit (once a year) 1
106 BG 005 169 36 SERVICE KIT Control Kit (once a year) 1
107 BG 005 169 37 SERVICE KIT Thermostat Kit (once a year) 1

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 006 325 56 aA
211001 FRAME ASSEMBLY / CT28, FRAME ASSEMBLY 58 (209)

2 5

Ref. Part no. Description EN Standard designation Qty

e
1 BG 006 325 86 FRAME CT28 1
2 551 626 23 FRAME 1
3 552 022 92 PLATE Support 1
4 AF0 010 0526 SCREW, HEXAGON HEAD, FULL THREAD M10x25 2
5 550 130 58 WASHER, LOCK, DOUBLE M10 3
. . . . .
6 AF0 010 0533 SCREW, HEXAGON HEAD, FULL THREAD M10x55 2
7 AF0 200 0005 NUT, HEXAGON, PREVAILING TORQUE, ALL M10 1
METAL

Sandvik Mining and Construction Oy Drills Tampere © 2021

 552 125 35 NSS
59 (209) ASSEMBLY / BELT DRIVE ASSEMBLY, CT28, 60HZ 211001

6 3 4 5 9 7 10

1 2 8

Ref. Part no. Description EN Standard designation Qty

e
1 550 747 81 PULLEY, V BELT 1
2 858 418 29 SLEEVE, CONICAL 1
3 552 125 36 PULLEY, V BELT 1
4 815 885 89 SLEEVE, CONICAL 1
5 002 357 48 KEY, PARALLEL 1
. . . . .
6 550 717 65 BELT, V 2
7 550 717 66 FAN 1
8 551 549 82 HUB Fan hub 1
9 448 593 20 HEXAGON SOCKET SET SCREW M8X20 m12.9 1
10 802 421 59 HEXAGON HEAD SCREW M6x16m8.8 5
. . . . .

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 010 793 28 aA NSS
61 (209) COOLER ASSEMBLY / COOLER ASSEMBLY 211001

14

14
3

17

18
9 10

9 8
2

15

16

14 12 11

19

21 13

22 20

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 010 793 28 aA NSS
211001 COOLER ASSEMBLY / COOLER ASSEMBLY 62 (209)

Ref. Part no. Description EN Standard designation Qty

e
1 BG 010 707 48 HOUSING Belt housing 1
2 BG 009 235 84 PLATE 1
3 550 717 94 COOLER, OIL 1
4 BG 010 791 23 SUPPORT Support for cooler 1
5 552 141 11 HOSE 1
. . . . .
6 552 141 12 HOSE 1
7 552 141 13 ADAPTER, ELBOW 2
8 800 331 19 ADAPTER, HYDRAULIC R3/4xR3/4 1
9 800 348 19 BONDED SEAL U d27, 2xD36xs2 SC 2
10 552 141 15 FITTING 1
. . . . .
11 852 847 89 CLAMP, P 39 mm, Steel (Plastic-coated) 1
12 551 554 47 LARGE PLAIN WASHER 2
13 802 421 59 HEXAGON HEAD SCREW M6x16m8.8 4
14 BG 002 137 71 SCREW 14
15 810 468 99 HEXAGON HEAD SCREW M8x40 3
. . . . .
16 851 281 89 WASHER, LOCK, DOUBLE M8 3
17 801 779 99 NUT, LOCK M8 4
18 421 168 00 WASHER 8,4 4
19 BG 006 337 19 SUPPORT CT28 1
20 552 140 85 SUPPORT 1
. . . . .
21 445 854 70 HEXAGON SOCKET HEAD SCREW M16X30 2
22 850 687 49 WASHER, LOCK, DOUBLE M16 4

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 006 337 27 aA
63 (209) HOSE ASSEMBLY / CT28, DRAIN HOSE ASSEMBLY 211001

4 5 2 6 1
2

Ref. Part no. Description EN Standard designation Qty

e
1 551 892 74 HOSE ASSEMBLY, HYDRAULIC L=490 1
2 800 347 99 BONDED SEAL U 21,5x28,7x2,5 3
3 813 184 49 ADAPTER, HYDRAULIC R1/2xR1/2 1
4 800 345 39 ADAPTER, ELBOW R1/2XRK1/2 1
5 855 291 29 VALVE, BALL R1/2 in 1
. . . . .
6 800 330 99 ADAPTER, HYDRAULIC R1/2xR1/2 1
7 804 683 39 PLUG 1

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 006 337 25 aA NSS
65 (209) VALVE ASSEMBLY / CT28, INLET VALVE ASSEMBLY 211001

6 1 3 5 2 4

10

12
13

11

11.2 11.1

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 006 337 25 aA NSS
211001 VALVE ASSEMBLY / CT28, INLET VALVE ASSEMBLY 66 (209)

Ref. Part no. Description EN Standard designation Qty

e
1 036 167 18 INTAKE VALVE SECTION 11 PAGE 68 1
2 551 550 35 FLANGE 1
3 445 804 20 HEXAGON SOCKET HEAD SCREW M10X50 m8.8 4
4 551 550 33 O-RING 1
5 871 807 99 O-RING 129x3,0 1
. . . . .
6 376 920 48 SUCTION CASE Inlet Valve Housing 1
7 801 779 99 NUT, LOCK M8 1
8 897 268 19 PIPE Pipe bend 1
9 280 680 80 CLAMP 50-65 2
10 550 557 82 INDICATOR, SERVICE 1
. . . . .
11 551 550 44 FILTER ELEMENT, AIR 1
11.1 550 717 73 FILTER Air filter element 1
11.2 550 717 91 FILTER Secondary filter element 1
12 551 550 37 SUPPORT 1
13 360 732 70 CLAMP, HOSE 165 1
. . . . .

Sandvik Mining and Construction Oy Drills Tampere © 2021

 036 167 18 a
67 (209) INTAKE VALVE 211001

9 11

21

17

16

18

22

7
8

12
10
15
20
13

19

Sandvik Mining and Construction Oy Drills Tampere © 2021

 036 167 18 a
211001 INTAKE VALVE 68 (209)

Ref. Part no. Description EN Standard designation Qty

e
2 COVER 1
5 SPRING 1
8 GASKET PLATE 1
10 BEARING BUSHING 1
12 SPRING 1
. . . . .
14 PISTON GASKET 1
15 SW-RING 1
17 O-RING 1
18 O-RING 1
20 O-RING 1
. . . . .
21 O-RING 1
22 BEARING 1
881 033 875 38 SEAL KIT INCL. PARTS 8, 14-21 1
882 895 763 09 REPAIR KIT Incl. parts 2,5,8,10,12,14,15,17,18,20-22 1

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 006 338 15 bB NSS
69 (209) PIPING, CONTROL AIR / CT28, CONTROL AIR PIPING 211001

11 9
9 13

11

10 16 17

5 4

12

11

11

15 14 1

8
3 2

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 006 338 15 bB NSS
211001 PIPING, CONTROL AIR / CT28, CONTROL AIR PIPING 70 (209)

Ref. Part no. Description EN Standard designation Qty

e
1 552 125 40 GAUGE, PRESSURE 1
2 551 813 17 SEAL, COPPER Copper gasket 1
3 856 473 29 SWIVEL NUT MALE ADAPTER 6/4-R1/4 in 1
4 033 403 08 BUSHING Sensor housing 1
5 283 352 50 SEAL, COPPER 21X26X1,5 1
. . . . .
6 BG 011 292 07 VALVE, CONTROL Valve, Control 1
7 550 557 81 BLOW DOWN VALVE 1
8 812 882 79 ADAPTER, HYDRAULIC R1/8 in 2
9 817 443 09 FITTING 6/4xR1/8 in male thread 2
10 034 808 68 ADAPTER, ELBOW 1
. . . . .
11 817 442 79 ADAPTER, ELBOW 6/4-R1/8 in 4
12 817 804 09 ADAPTER, TEE 6/4-R1/8K 1
13 308 954 08 BUSHING D4,0 L15,0 1
14 BG 003 121 33 PIPE, PLASTIC 6/4mm 2
15 800 711 09 CABLE TIE PLT 2S BLACK 10
. . . . .
16 550 254 66 CONNECTOR 1
17 803 141 09 SEAL, COPPER 10x13,5x1 1

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 006 339 70 bB NSS
71 (209) COMPRESSOR COMPONENTS / CT28, TEMPEST 6 211001

23 34

27

38

24
22
2
47
20

18 19

43 15

16 17

39 41

5 3

36 7

30 29

10 8

46
25
21

26 11

31 12

44
32
1
6

40 33 37 35 40

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 006 339 70 bB NSS
211001 COMPRESSOR COMPONENTS / CT28, TEMPEST 6 72 (209)

Ref. Part no. Description EN Standard designation Qty

e
1 552 125 45 FRAME 1
2 551 550 50 CYCLONE 1
3 551 550 52 HOUSING, FILTER 1
4 034 983 28 OIL SEPARATOR 1
5 551 550 58 PIPE Cyclone 1
. . . . .
6 551 550 64 PIPE, INTAKE 1
7 551 550 67 CYLINDER Thermostat cylinder 1
8 BG 006 339 86 GLASS, SIGHT CT28, Oil Checking Glass 1
10 551 550 68 CONNECTOR 1
11 033 811 78 PLUG 3
. . . . .
12 BG 005 170 07 GASKET Gasket 3
15 813 449 29 ADAPTER R1/4XR1/8 1
16 550 254 66 CONNECTOR 1
17 BG 002 456 14 ADAPTER - 90 DEG 6/4-1/8 2
18 308 954 08 BUSHING D4,0 L15,0 1
. . . . .
19 852 002 99 PIPE, PLASTIC 6/4 1
20 552 154 11 VALVE, CHECK 1
21 550 557 78 THERMOSTAT Incl. Spring 1
22 551 550 72 VALVE, SHOCK LOAD 1
23 036 030 78 VALVE, DISCHARGE SECTION 11 PAGE 74 1
. . . . .
24 853 280 79 PLUG R1,1/2 in 1
25 550 755 04 O-RING 1
26 550 755 06 O-RING 1
27 BG 005 172 39 O-RING O-Ring for Oil Separator 1
29 BG 005 174 33 O-RING O-Ring for Thermostat 1
. . . . .
30 551 550 74 O-RING 1
31 550 755 07 O-RING 1
32 550 806 43 HEXAGON SOCKET HEAD SCREW m16x140 8.8 6
33 551 550 75 HEXAGON SOCKET HEAD SCREW 2
34 AF0 050 0500 SCREW, SOCKET HEAD, HEXAGON M10x30 7
. . . . .
35 551 546 19 HEXAGON SOCKET HEAD SCREW 2
36 AF0 050 0224 SCREW, SOCKET HEAD, HEXAGON M6X16 6
37 807 047 79 PLUG RK1/8 8
38 BG 013 659 44 HOLDER Oil separator holder 1
39 551 550 77 SEAL 1
. . . . .
40 551 550 78 HEXACON SOCKET HEAD PLUG 3
41 550 717 61 FILTER, OIL 1
43 895 564 79 SUPPORTING BUSHING 3
44 551 550 79 SPRING 1
46 550 855 94 GASKET 1
. . . . .
47 807 424 89 ADAPTER, ELBOW 1/2 IN 1
801 550 855 96 SIGHT GLASS, OIL Repair kit, Incl. Oil checking glass + Seal 1

Sandvik Mining and Construction Oy Drills Tampere © 2021

 036 030 78 aC
73 (209) VALVE, DISCHARGE 211001

16 15

12

10

14
2

11

13

Sandvik Mining and Construction Oy Drills Tampere © 2021

 036 030 78 aC
211001 VALVE, DISCHARGE 74 (209)

Ref. Part no. Description EN Standard designation Qty

e
1 FRAME 1
2 PISTON 1
3 THRUSTING 1
4 PLATE 1
6 SPRING 1
. . . . .
7 BEARING 1
8 RETAINING RING 1
9 NUT 1
10 SCREW 1
11 SEAL 1
. . . . .
12 O-RING 1
13 SEAL 1
14 SLIDE RING 1
15 855 886 19 FILTER M10X0,75 outer thread 1
16 033 985 78 COUPLING 1
. . . . .
801 033 892 70 SEAL KIT INCL. PARTS 11-14 1
802 895 555 99 REPAIR KIT INCL. PARTS 6-7, 11-14 1

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 006 340 20 aA
75 (209) AIR END / CT28 211001

Ref. Part no. Description EN Standard designation Qty

e
1 552 125 43 COMPRESSOR UNIT SECTION 11 PAGE 76 1

Sandvik Mining and Construction Oy Drills Tampere © 2021

 552 125 43
211001 COMPRESSOR UNIT / AIR END 76 (209)

6 2 4 1 3 7

Ref. Part no. Description EN Standard designation Qty

e
1 INNER RING 1
2 551 550 81 COVER Seal cover 1
3 SEAL 1
4 SHAFT SEAL 1
5 DUST SEAL 1
. . . . .
6 445 774 60 HEXAGON SOCKET HEAD SCREW M6X20 - 8.8 6
6 SCREW 6
7 AIR END 1
801 551 550 80 SEAL KIT INCL. PARTS 1, 3-5 1

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 011 055 76 cC
77 (209) COMPRESSOR ASSEMBLY / CT28 LEFT, NC7 211001

25 21 10 11 12 13 14 20 25 27 28

26

36

41

44

42 37

24 3

8 7 19 22 23

37

41
31 16 15 32 1 33 30 29

35 34 39 38 38

40 40 42 42

43 43
47 18 46 17

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 011 055 76 cC
211001 COMPRESSOR ASSEMBLY / CT28 LEFT, NC7 78 (209)

Ref. Part no. Description EN Standard designation Qty

e
1 BG 011 168 04 BRACKET Compressor Assembly 1
3 550 217 41 VALVE, AIR 24V, 16bar, G 3/8 in 1
4 879 179 99 SWIVEL NUT MALE ADAPTER 3/8 in JIC 1
5 AF1 014 0003 ADAPTER, MALE STUD CONNECTOR JIC 7/16 - BSPP 3/8 1
6 AF1 146 0002 ADAPTER, SWIVEL NUT ELBOW JIC 7/16 1
. . . . .
7 505252 ADAPTER 1
8 552 103 17 REDUCER, NOISE Plastic, D=17, L=36,5 1
9 AF1 135 0001 ADAPTER, BULKHEAD UNION WITH JIC 7/16 1
BULKHEAD LOCKNUT
10 550 156 61 PLUG R 1,1/2 in 1
11 812 877 09 REDUCING PIECE R1,1/2 in x 1 in 1
. . . . .
12 800 324 99 ADAPTER, HYDRAULIC R1/2xR1 2
13 807 180 49 USIT-SEAL 22,7X30X2 D2=24,4 1
14 550 441 63 UNION, BULKHEAD L=200 mm 1
15 BG 011 169 37 PLATE Compressor Assembly 1
16 BG 011 183 47 NSS ELECTRICAL ASSEMBLY SECTION 11 PAGE 86 1
. . . . .
17 550 801 34 SENSOR Temperature sensor 1
18 BG 003 692 83 ADAPTER, REDUCER R1/2 to M10 1
19 801 543 49 CLAMP, P 31 mm, Steel (Plastic-coated) 1
20 AF1 014 0030 ADAPTER, MALE STUD CONNECTOR JIC 1 5/16 - BSPP 1 1
21 AF1 144 0007 ADAPTER, SWIVEL NUT BRANCH TEE JIC 1 5/16 1
. . . . .
22 AF1 175 0002 ADAPTER, TEST POINT CONNECTOR JIC 1 5/16 - BSPP 1/4 1
23 AF1 014 0002 ADAPTER, MALE STUD CONNECTOR JIC 7/16 - BSPP 1/4 1
24 550 485 38 CABLE, PREWIRED PLUG 24DC, 10m 1
25 280 679 10 CLAMP, HOSE D 44-56 mm, Stainless Steel 2
26 550 415 58 SUPPORTING BLOCK Air cleaner 1
. . . . .
27 550 449 63 CONNECTOR 1
28 550 481 03 HOSE, AIR 0.6
29 BG 006 562 94 LIFTING EQUIPMENT 1
30 BG 006 830 24 LIFTING EQUIPMENT Compressor 1
31 390 009 28 SIGN Compressors temperature 1
. . . . .
32 390 075 88 SIGN Air pressure 1
33 390 098 88 SIGN Air filter 1
34 AF0 010 0137 SCREW, HEXAGON HEAD, FULL THREAD M6x25 4
35 AF0 050 0229 SCREW, SOCKET HEAD, HEXAGON M6x40 4
36 AF0 010 0430 SCREW, HEXAGON HEAD, PARTIAL M8x40 2
THREAD
. . . . .
37 AF0 010 0524 SCREW, HEXAGON HEAD, FULL THREAD M10x20 2
38 AF0 010 0526 SCREW, HEXAGON HEAD, FULL THREAD M10x25 4
39 AF0 010 0529 SCREW, HEXAGON HEAD, FULL THREAD M10x35 2
40 AF0 300 0029 WASHER, LOCK, PAIR NL6 16
41 AF0 300 0030 WASHER, LOCK, PAIR NL8 4
. . . . .
42 AF0 300 0121 WASHER, LOCK, PAIR NL10-sp 10
43 AF0 190 0003 NUT, HEXAGON, PREVAILING TORQUE M6 8
44 AF0 190 0004 NUT, HEXAGON, PREVAILING TORQUE M8 2
45 AF0 190 0005 NUT, HEXAGON, PREVAILING TORQUE M10 2
46 813 563 09 SEAL, COPPER A10X13,5X3 Cu 1
. . . . .
47 800 347 99 BONDED SEAL U 21,5x28,7x2,5 1

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 011 183 47 eD NSS
79 (209) ELECTRICAL ASSEMBLY / COMPRESSOR OVERHEAT SENSORING 211001

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 011 183 47 eD NSS
211001 ELECTRICAL ASSEMBLY / COMPRESSOR OVERHEAT SENSORING 80 (209)

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 011 183 47 eD NSS
81 (209) ELECTRICAL ASSEMBLY / COMPRESSOR OVERHEAT SENSORING 211001

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 011 183 47 eD NSS
211001 ELECTRICAL ASSEMBLY / COMPRESSOR OVERHEAT SENSORING 82 (209)

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 011 183 47 eD NSS
83 (209) ELECTRICAL ASSEMBLY / COMPRESSOR OVERHEAT SENSORING 211001

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 011 183 47 eD NSS
211001 ELECTRICAL ASSEMBLY / COMPRESSOR OVERHEAT SENSORING 84 (209)

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 011 183 47 eD NSS
85 (209) ELECTRICAL ASSEMBLY / COMPRESSOR OVERHEAT SENSORING 211001

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 011 183 47 eD NSS
211001 ELECTRICAL ASSEMBLY / COMPRESSOR OVERHEAT SENSORING 86 (209)

Ref. Part no. Description EN Standard designation Qty

e
WR1 560 255 64 CABLE, PREWIRED, IO 0,75mm2, D2,2mm, black 0.2
1 BG 010 975 51 MEASURING EQUIPMENT Temperature measuring unit 1
2 BG 004 149 07 CABLE, PREWIRED, IO M12, Female, 8-pin, L=10m, shield 1
3 BG 011 061 91 CABLE, PREWIRED PLUG LMU Sensor cable 1
5 800 397 39 TERMINAL, WIRE 10-M8-O 1
. . . . .
6 885 698 09 TERMINAL, WIRE 0,5mm2, L8 0.06
7 BG 010 927 12 TUBE, SHRINK Clear, shrink 4.5mm/1.5mm, with glue, 0.1
1,2m
8 806 249 79 CABLE TIE 1m 32

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 011 055 90 dD
87 (209) COMPRESSOR ASSEMBLY / CT28, NC7 211001

21

10 9 20 19 18

12 11

13

2 17 16 1

27 26 27

29 28 29

30

25

23

24

32 14 31 15

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 011 055 90 dD
211001 COMPRESSOR ASSEMBLY / CT28, NC7 88 (209)

Ref. Part no. Description EN Standard designation Qty

e
1 BG 011 114 91 BRACKET, LIFTING Compressor Assembly 1
2 BG 006 828 68 LIFTING EQUIPMENT 1
3 550 217 41 VALVE, AIR 24V, 16bar, G 3/8 in 1
4 879 179 99 SWIVEL NUT MALE ADAPTER 3/8 in JIC 1
5 AF1 014 0003 ADAPTER, MALE STUD CONNECTOR JIC 7/16 - BSPP 3/8 1
. . . . .
6 505252 ADAPTER 1
7 552 103 17 REDUCER, NOISE Plastic, D=17, L=36,5 1
8 AF1 135 0001 ADAPTER, BULKHEAD UNION WITH JIC 7/16 1
BULKHEAD LOCKNUT
9 550 156 61 PLUG R 1,1/2 in 1
10 812 877 09 REDUCING PIECE R1,1/2 in x 1 in 1
. . . . .
11 800 324 99 ADAPTER, HYDRAULIC R1/2xR1 1
12 807 180 49 USIT-SEAL 22,7X30X2 D2=24,4 1
13 550 441 63 UNION, BULKHEAD L=200 mm 1
14 BG 003 692 83 ADAPTER, REDUCER R1/2 to M10 1
15 550 801 34 SENSOR Temperature sensor 1
. . . . .
16 BG 011 183 47 NSS ELECTRICAL ASSEMBLY SECTION 11 PAGE 86 1
17 801 543 49 CLAMP, P 31 mm, Steel (Plastic-coated) 1
18 AF1 014 0030 ADAPTER, MALE STUD CONNECTOR JIC 1 5/16 - BSPP 1 1
19 AF1 144 0007 ADAPTER, SWIVEL NUT BRANCH TEE JIC 1 5/16 1
20 AF1 175 0002 ADAPTER, TEST POINT CONNECTOR JIC 1 5/16 - BSPP 1/4 1
. . . . .
21 AF1 014 0002 ADAPTER, MALE STUD CONNECTOR JIC 7/16 - BSPP 1/4 1
22 550 485 38 CABLE, PREWIRED PLUG 24DC, 10m 1
23 390 009 28 SIGN Compressors temperature 1
24 390 075 88 SIGN Air pressure 1
25 390 098 88 SIGN Air filter 1
. . . . .
26 AF0 050 0228 SCREW, SOCKET HEAD, HEXAGON M6x35-8.8 Zn 4
27 AF0 010 0735 SCREW, HEXAGON HEAD, FULL THREAD M12x25 4
28 AF0 300 0029 WASHER, LOCK, PAIR NL6 8
29 AF0 300 0032 WASHER, LOCK, PAIR NL12 4
30 AF0 190 0003 NUT, HEXAGON, PREVAILING TORQUE M6 4
. . . . .
31 813 563 09 SEAL, COPPER A10X13,5X3 Cu 1
32 800 347 99 BONDED SEAL U 21,5x28,7x2,5 1

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 007 821 18 bB NSS
89 (209) SEPARATOR, MUD / R3 IN AND PRESSURE REDUCING VALVE 211001

23

22

21

20

19

23

18

3
11
12
11
13
1 30 29 31 2
13
11
12

10

15

16 15 17 5
33
14 6

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 007 821 18 bB NSS
211001 SEPARATOR, MUD / R3 IN AND PRESSURE REDUCING VALVE 90 (209)

Ref. Part no. Description EN Standard designation Qty

e
1 BG 002 346 43 VALVE, PRESSURE REDUCING SECTION 11 PAGE 92 1
2 551 708 24 STRAINER, WATER Q 20 l/min, p_max 16 bar 1
2.1 551 709 52 STRAINER 800 microns, stainless steel 1
2.2 551 709 53 REDUCER G1, Mudseparator 3 in 1
2.3 551 709 54 SEAL, O-RING 3 in 1
. . . . .
3 806 798 29 VALVE, BALL 2/2, p_max 25 bar 1
4 806 801 89 VALVE, BALL 2/2, p_max 16 bar 1
5 AF1 015 0021 ADAPTER, MALE STUD ELBOW JIC 1 5/16 - BSPP 1 1
6 551 693 70 PLATE, MOUNTING 1
10 AF1 014 0038 ADAPTER, MALE STUD CONNECTOR JIC 1 7/8 - BSPP 1 1/2 1
. . . . .
11 AF1 035 0018 ADAPTER, SWIVEL MALE STUD JIC 1 7/8 - BSPP 1 1/2 3
12 AF1 135 0010 ADAPTER, BULKHEAD UNION WITH JIC 1 7/8 2
BULKHEAD LOCKNUT
13 290 592 40 ADAPTER, HYDRAULIC R3 in X R1,1/2 in 2
14 AF1 146 0011 ADAPTER, SWIVEL NUT ELBOW JIC 1 7/8 1
15 AF1 015 0021 ADAPTER, MALE STUD ELBOW JIC 1 5/16 - BSPP 1 2
. . . . .
16 AF1 144 0009 ADAPTER, SWIVEL NUT BRANCH TEE JIC 1 7/8 1
17 AF1 135 0008 ADAPTER, BULKHEAD UNION WITH JIC 1 5/16 1
BULKHEAD LOCKNUT
18 AF1 035 0014 ADAPTER, SWIVEL MALE STUD JIC 1 5/16 - BSPP 1 1
19 AF1 135 0001 ADAPTER, BULKHEAD UNION WITH JIC 7/16 1
BULKHEAD LOCKNUT
20 AF1 035 0002 ADAPTER, SWIVEL MALE STUD JIC 7/16 - BSPP 1/4 1
. . . . .
21 813 448 09 VALVE, BALL 2/2, p_max 25 bar 1
22 AF1 014 0002 ADAPTER, MALE STUD CONNECTOR JIC 7/16 - BSPP 1/4 1
23 AF1 146 0002 ADAPTER, SWIVEL NUT ELBOW JIC 7/16 2
29 550 716 42 REDUCER, TUBE END 1,7/8X1,1/16JIC 1
30 AF1 040 0009 ADAPTER, NUT JIC 1 7/8 1
. . . . .
31 AF1 038 0008 ADAPTER, CAP JIC 1 1/16 1

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 002 346 43 bB
91 (209) VALVE, PRESSURE REDUCING / 1 7/8 JIC IN, 1-7BAR (MAX 25BAR) 211001

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 002 346 43 bB
211001 VALVE, PRESSURE REDUCING / 1 7/8 JIC IN, 1-7BAR (MAX 25BAR) 92 (209)

Ref. Part no. Description EN Standard designation Qty

e
1 BG 003 945 54 REPAIR KIT Incl. Valve insert with seal and diaphgram 1
2 BG 003 945 75 ADAPTER KIT Include both adapters and seals. 1
3 BG 003 945 69 SEAL valve (pressure reducing) 1

Sandvik Mining and Construction Oy Drills Tampere © 2021

 550 004 39 cD
93 (209) HYDRAULIC CYLINDER, DOUBLE-ACTING 211001

6 35 26 7 22 23 24 25 1 2 8 17 21 20 5 21

33 34

29

31

28

27

30

32

Sandvik Mining and Construction Oy Drills Tampere © 2021

 550 004 39 cD
211001 HYDRAULIC CYLINDER, DOUBLE-ACTING 94 (209)

Ref. Part no. Description EN Standard designation Qty

e
1 550 130 94 CYLINDER TUBE ASSEMBLY 1
2 550 130 95 PISTON ROD MACHINING 1
5 550 130 76 PISTON 99,4-119 1
6 550 130 87 PAD 200-56 1
7 550 130 78 GUIDE 1
. . . . .
8 550 130 79 BUSHING, LIMIT 1
11 550 129 08 SEAL, PISTON 100/75x22,4 1
12 550 129 10 RING, PISTON 100/94X13 5
13 550 129 09 SEAL, ROD S 80/90X12,5 G 1
14 550 129 07 SEAL, ROD NI 300 80/90X12 1
. . . . .
16 550 129 06 O-RING 94,5x3-1 1
17 AF0 130 0177 SCREW, SET, SOCKET, HEXAGON, DOG M8x12 1
POINT
17 866 432 99 RING, BACK-UP 95-100-1,3 1
18 801 993 09 O-RING 11,3X2,4 1
19 801 994 29 O-RING 17,3X2,4 2
. . . . .
20 550 129 08 SEAL, PISTON 100/75x22,4 1
20 550 128 05 O-RING 22,2X3-1 2
21 550 129 10 RING, PISTON 100/94X13 5
22 550 129 07 SEAL, ROD NI 300 80/90X12 1
23 550 129 09 SEAL, ROD S 80/90X12,5 G 1
. . . . .
24 866 432 99 RING, BACK-UP 95-100-1,3 1
25 550 129 06 O-RING 94,5x3-1 1
26 880 344 29 WIPER 80x90x7x10, VITON 1
27 453 787 68 SPOOL L=51,5 1
28 801 993 09 O-RING 11,3X2,4 1
. . . . .
29 049 735 58 PIN, TAPER D12 L21.5 2
30 049 734 28 CHUCK 2
31 801 994 29 O-RING 17,3X2,4 2
32 550 129 88 SPRING 8x1,25-43 2
33 048 286 88 PLUG R3/4 in 2
. . . . .
34 550 128 05 O-RING 22,2X3-1 2
35 AF0 130 0315 SCREW, SET, SOCKET, HEXAGON, DOG M16x30 4
POINT
*100 550 129 11 SEAL KIT INCL. PARTS 11-14, 16-20, 26 1

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 010 795 91 bB NSS
95 (209) PUMP ASSEMBLY, WATER / WATER 211001

7 7
8 8
9 9

5 2 6 7 2 1

Ref. Part no. Description EN Standard designation Qty

e
1 BG 010 795 96 DISTRIBUTOR SECTION 11 PAGE 98 1
2 AF1 014 0038 ADAPTER, MALE STUD CONNECTOR JIC 1 7/8 - BSPP 1 1/2 2
3 AF1 013 0004 ADAPTER, MALE STUD CONNECTOR JIC 7/16 - BSPP 1/2 1
4 AF1 146 0002 ADAPTER, SWIVEL NUT ELBOW JIC 7/16 1
5 AF1 146 0011 ADAPTER, SWIVEL NUT ELBOW JIC 1 7/8 1
. . . . .
6 AF0 010 0740 SCREW, HEXAGON HEAD, FULL THREAD M12x50 4
7 AF0 300 0122 WASHER, LOCK, PAIR NL12-sp 12
8 AF0 010 0739 SCREW, HEXAGON HEAD, FULL THREAD M12x45 4
9 AF0 200 0006 NUT, HEXAGON, PREVAILING TORQUE, ALL M12 4
METAL

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 010 795 96 aA
97 (209) DISTRIBUTOR 211001

12 11 16

17

9 8
15

9 8 14

13
6
5 10

4 7

1
3

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 010 795 96 aA
211001 DISTRIBUTOR 98 (209)

Ref. Part no. Description EN Standard designation Qty

e
1 320 350 18 DISTRIBUTOR 1 1/2 in 1
2 AF1 035 0018 ADAPTER, SWIVEL MALE STUD JIC 1 7/8 - BSPP 1 1/2 1
3 AF1 146 0011 ADAPTER, SWIVEL NUT ELBOW JIC 1 7/8 1
4 AF1 146 0007 ADAPTER, SWIVEL NUT ELBOW JIC 1 1/16 1
5 801 802 69 BONDED SEAL d13,7xD22xs1,5 1
. . . . .
6 AF1 014 0027 ADAPTER, MALE STUD CONNECTOR JIC 1 1/16 - BSPP 1 1
7 AF1 014 0024 ADAPTER, MALE STUD CONNECTOR JIC 1 1/16 - BSPP 3/4 1
8 AF1 128 0007 ADAPTER, PLUG BSPP 1 2
9 800 349 49 USIT-SEAL d34,3 D43 s2 2
10 812 603 79 PLUG R 1/4 1
. . . . .
11 AF1 128 0008 ADAPTER, PLUG BSPP 1 1/4 1
12 800 350 09 BONDED SEAL 42.7x53x3 1
13 AF1 014 0017 ADAPTER, MALE STUD CONNECTOR JIC 3/4 - BSPP 3/4 1
14 AF1 146 0005 ADAPTER, SWIVEL NUT ELBOW JIC 3/4 1
15 AF1 036 0009 ADAPTER, SWIVEL MALE STUD JIC 3/4 - BSPP 1/2 1
. . . . .
16 AF1 014 0018 ADAPTER, MALE STUD CONNECTOR JIC 3/4 - BSPP 1 1
17 BG 007 719 80 VALVE, PRESSURE RELIEF Q 210 l/min, p_max 50 bar 1

Sandvik Mining and Construction Oy Drills Tampere © 2021

 551 596 27 gGa NSS
99 (209) TANK, FUEL / ASSEMBLY, FILLING CAP (0,5BAR) 211001

551

571 144

13 18 5 41 20 20
704 12 8 6 40 9 9
17

16 2 4 204 553
15

11

553 205

551 141 10 551 144 22 21

Sandvik Mining and Construction Oy Drills Tampere © 2021

 551 596 27 gGa NSS
211001 TANK, FUEL / ASSEMBLY, FILLING CAP (0,5BAR) 100 (209)

Ref. Part no. Description EN Standard designation Qty

e
1 551 596 26 TANK, FUEL Assembly 1
2 330 422 08 FLANGE 1
4 330 312 68 SEAL D250 d200 s2 1
5 812 608 09 PLUG R1 1
6 800 349 49 USIT-SEAL d34,3 D43 s2 1
. . . . .
8 551 974 27 SENSOR Bolt circle diam 54mm, L=750mm 1
9 817 094 69 STRAIGHT THREAD ADAPTER G 1/2 x JIC 3/4-16 2
15 BG 015 481 36 FILTER, AIR BREATHER p_check 0.5 bar 1
16 551 652 01 FLANGE 1
17 560 335 60 SEAL 110x80x3 1
. . . . .
18 446 820 40 SLOTTED PAN HEAD SCREW M5x16 - 5.8 5
20 817 183 59 SWIVEL NUT ELBOW 90 JIC 3/4-16 2
21 550 466 37 FLANGE D156 1
22 550 466 47 SEAL D156 1
40 550 466 61 FLANGE D140 1
. . . . .
41 550 466 60 RING, SEAL D140, d55 1
144 AF0 010 0322 SCREW, HEXAGON HEAD, FULL THREAD M8x20 10
204 AF0 010 0736 SCREW, HEXAGON HEAD, FULL THREAD M12x30 6
205 AF0 010 0737 SCREW, HEXAGON HEAD, FULL THREAD M12x35 2
551 AF0 300 0030 WASHER, LOCK, PAIR NL8 10
. . . . .
553 AF0 300 0032 WASHER, LOCK, PAIR NL12 2
553 AF0 300 0032 WASHER, LOCK, PAIR NL12 6
571 AF0 230 0003 WASHER, PLAIN, NORMAL M5 5
704 AF0 050 0131 SCREW, SOCKET HEAD, HEXAGON M5x16 6

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 015 394 69 aBc NSS
101 (209) FUEL SYSTEM / MB OM 904 LA, NC7 211001

103

102
101
5
6 7 10 11 12
3
3
4
4

1
2
8
9

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 015 394 69 aBc NSS
211001 FUEL SYSTEM / MB OM 904 LA, NC7 102 (209)

Ref. Part no. Description EN Standard designation Qty

e
1 BG 003 241 69 NSS FILTER, FUEL SECTION 11 PAGE 103 1
3 AF1 027 0011 ADAPTER, MALE STUD CONNECTOR JIC 3/4 - M 14x1.5 2
4 AF1 146 0005 ADAPTER, SWIVEL NUT ELBOW JIC 3/4 2
8 BG 013 272 87 SENSOR Sensor 1
9 BG 013 275 27 CABLE, PREWIRED Cable, Prewired 1
. . . . .
10 AF0 010 0739 SCREW, HEXAGON HEAD, FULL THREAD M12x45 2
11 AF0 300 0032 WASHER, LOCK, PAIR NL12 4
12 AF0 190 0006 NUT, HEXAGON, PREVAILING TORQUE M12 2
101 BG 009 310 25 HOSE ASSEMBLY, FUEL 1W10B A8A8 JIC L=1000 1
102 BG 009 310 33 HOSE ASSEMBLY, FUEL 1W10B A8A8 JIC L=2000 1
. . . . .
103 BG 009 310 33 HOSE ASSEMBLY, FUEL 1W10B A8A8 JIC L=2000 1

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 003 241 69 cB NSS
103 (209) FILTER, FUEL 211001

Ref. Part no. Description EN Standard designation Qty

e
1 BG 003 594 90 FILTER, FUEL Fuel filter with WIF sensor 1

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 007 768 31 bB NSS
105 (209) TANK, HYDRAULIC / 2X OW30 STD 211001

26
27
25 24 4
3 4 5 6

22
21

15
16
17
10

14

23 22 4
20
19
18 9
11
12

13

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 007 768 31 bB NSS
211001 TANK, HYDRAULIC / 2X OW30 STD 106 (209)

Ref. Part no. Description EN Standard designation Qty

e
1 BG 007 690 69 TANK, HYDRAULIC SECTION 11 PAGE 108 1
3 AF1 178 0011 FLANGE CLAMP, HALF, SPLIT SAE 2 1/2 2
4 AF0 300 0032 WASHER, LOCK, PAIR NL12 10
5 AF0 010 0737 SCREW, HEXAGON HEAD, FULL THREAD M12x35 4
6 806 957 19 O-RING 69,44X3,53 1
. . . . .
9 AF0 300 0121 WASHER, LOCK, PAIR NL10-sp 8
10 BG 005 764 17 FIREWALL Oil receiver 1
11 551 671 55 FIREWALL Hydraulic oil receiver 1
12 AF0 010 0524 SCREW, HEXAGON HEAD, FULL THREAD M10x20 8
13 AF0 190 0005 NUT, HEXAGON, PREVAILING TORQUE M10 1
. . . . .
14 551 671 56 FIREWALL Hydraulic oil receiver 1
15 551 605 25 CLIP Hydraulic oil receiver 2
16 AF0 010 0853 SCREW, HEXAGON HEAD, PARTIAL M12x150 2
THREAD
17 AF0 300 0122 WASHER, LOCK, PAIR NL12-sp 2
18 AF0 010 0734 SCREW, HEXAGON HEAD, FULL THREAD M12x20 2
. . . . .
19 551 888 88 SUPPORT, HOSE Hydraulic reciever hoses 1
20 551 798 38 NSS ASSEMBLY SECTION 11 PAGE 116 2
21 551 712 45 PIPE, RETURN 1
21.1 816 737 79 NUT 1,7/8-12JIC 2
22 AF1 146 0011 ADAPTER, SWIVEL NUT ELBOW JIC 1 7/8 2
. . . . .
23 551 712 44 PIPE, RETURN 1
23.1 816 737 79 NUT 1,7/8-12JIC 2
24 AF0 050 0566 SCREW, SOCKET HEAD, HEXAGON M12x35 4
25 AF1 179 0012 FLANGE CLAMP, STRAIGHT 4 BOLT, BSPP SAE 2 - BSPP 1 1/2 1
26 AF1 038 0008 ADAPTER, CAP JIC 1 1/16 1
. . . . .
27 AF1 014 0037 ADAPTER, MALE STUD CONNECTOR JIC 1 5/8 - BSPP 1 1/2 1

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 007 690 69 fF
107 (209) TANK, HYDRAULIC / BASIC ASSEMBLY PARTS FOR NC7 211001

41 54

8 30 17
15
16 7
4 F
13 6
32 M1
14
34 T2 12 40
11

48 46 2 3 4

18

38 10
51 39

53 1

T1 34
52
T3
BR 5
99 4
9
28

19 35

36

45

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 007 690 69 fF
211001 TANK, HYDRAULIC / BASIC ASSEMBLY PARTS FOR NC7 108 (209)

Ref. Part no. Description EN Standard designation Qty

e
1 BG 007 671 56 TANK, HYDRAULIC WELDING ASSEMBLY NC 7 1
2 AF0 190 0006 NUT, HEXAGON, PREVAILING TORQUE M12 24
3 850 604 99 STUD M12x30 - 8.8 22
4 AF0 300 0032 WASHER, LOCK, PAIR NL12 36
5 551 990 66 FILTER, AIR BREATHER SECTION 11 PAGE 111 1
. . . . .
6 BG 012 405 12 PLATE, MOUNTING Level switch, Machining 1
7 AF0 310 0155 STUD, DOUBLE END M8x25-8.8 Zn 2
8 AF0 010 0735 SCREW, HEXAGON HEAD, FULL THREAD M12x25 4
9 AF1 115 0005 ADAPTER, BULKHEAD UNION BSPP 3/4 1
10 551 605 45 SEAL 1
. . . . .
11 552 158 88 SWITCH, LEVEL 3/8 L1=85 L2=310 1
12 550 463 70 NSS JUNCTION BOX ASSEMBLY SECTION 11 PAGE 114 1
14 AF2 502 0421 O-RING 61.5x2.65 1
15 138 030 08 COVER Tank 1
16 870 902 79 O-RING 174,3X5,7 1
. . . . .
17 AF0 300 0030 WASHER, LOCK, PAIR NL8 2
18 551 595 74 COVER Hydraulic oil receiver NC 7 1
19 800 348 19 BONDED SEAL U d27, 2xD36xs2 SC 3
28 AF0 010 0736 SCREW, HEXAGON HEAD, FULL THREAD M12x30 4
30 AF1 014 0027 ADAPTER, MALE STUD CONNECTOR JIC 1 1/16 - BSPP 1 2
. . . . .
32 806 870 19 SWITCH, PRESSURE 4A 24VDC. Default setting 30psi 1
34 AF1 014 0038 ADAPTER, MALE STUD CONNECTOR JIC 1 7/8 - BSPP 1 1/2 2
35 AF1 178 0010 FLANGE CLAMP, HALF, SPLIT SAE 2 2
36 811 038 69 O-RING 57x3,5 1
38 BG 007 182 83 INDICATOR, LEVEL Aluminium frame, plastic pipe and end caps 1
. . . . .
39 550 370 60 STUD M12X40 - 8.8 2
40 802 323 89 SLOTTED PAN HEAD SCREW M4X20 m5.8 4
41 AF0 410 0018 BOLT, LIFTING EYE M12 2
45 092 362 68 PLUG 1
46 447 765 00 SLOTTED COUNTERSUNK FLAT HEAD M5X12 m5.8 3
SCREW
. . . . .
48 550 898 53 LATCH 1
51 BG 009 539 42 SCALE Hydraulic oil receiver NC 7 1
52 AF0 010 0317 SCREW, HEXAGON HEAD, FULL THREAD M8x10 4
53 AF0 300 0120 WASHER, LOCK, PAIR NL8-sp 4
54 AF0 190 0004 NUT, HEXAGON, PREVAILING TORQUE M8 2
. . . . .
*13 BG 006 309 40 FILTER, RETURN SECTION 11 PAGE 115 1

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 007 690 69 fF
109 (209) TANK, HYDRAULIC / BASIC ASSEMBLY PARTS FOR NC7 211001

42 23 22 4 A2 E 24 25 30 S2 26

33 L5 L4 27 31

43 29 L6 S1 26

L1 27

R2 19 44

R1 19 44
31 26 S3

27 L2

26 R3

TR 20 21
47 37 P

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 007 690 69 fF
211001 TANK, HYDRAULIC / BASIC ASSEMBLY PARTS FOR NC7 110 (209)

Ref. Part no. Description EN Standard designation Qty

e
4 AF0 300 0032 WASHER, LOCK, PAIR NL12 36
19 800 348 19 BONDED SEAL U d27, 2xD36xs2 SC 3
20 871 769 79 PLUG G2 1/2 1
21 808 616 99 USIT-SEAL U 76,08x90,3x3,38 D2=79 1
22 AF1 178 0011 FLANGE CLAMP, HALF, SPLIT SAE 2 1/2 2
. . . . .
23 AF0 010 0737 SCREW, HEXAGON HEAD, FULL THREAD M12x35 4
24 AF1 038 0008 ADAPTER, CAP JIC 1 1/16 1
25 AF1 144 0006 ADAPTER, SWIVEL NUT BRANCH TEE JIC 1 1/16 1
26 AF1 014 0033 ADAPTER, MALE STUD CONNECTOR JIC 1 5/16 - BSPP 1 1/4 4
27 AF1 014 0030 ADAPTER, MALE STUD CONNECTOR JIC 1 5/16 - BSPP 1 3
. . . . .
29 AF1 014 0005 ADAPTER, MALE STUD CONNECTOR JIC 7/16 - BSPP 3/4 1
30 AF1 014 0027 ADAPTER, MALE STUD CONNECTOR JIC 1 1/16 - BSPP 1 2
31 AF1 038 0010 ADAPTER, CAP JIC 1 5/16 2
33 AF1 014 0024 ADAPTER, MALE STUD CONNECTOR JIC 1 1/16 - BSPP 3/4 1
37 804 161 29 PLUG Magnet plug R1 1
. . . . .
42 AF2 501 0645 O-RING 69.44x3.53 1
43 AF1 038 0003 ADAPTER, CAP JIC 7/16 1
44 AF1 128 0006 ADAPTER, PLUG BSPP 3/4 2
47 800 349 49 USIT-SEAL d34,3 D43 s2 1

Sandvik Mining and Construction Oy Drills Tampere © 2021

 551 990 66 bB
111 (209) FILTER, AIR BREATHER 211001

Ref. Part no. Description EN Standard designation Qty

e
1 551 990 68 FILTER ELEMENT, BREATHER Change element for breather 1

Sandvik Mining and Construction Oy Drills Tampere © 2021

 550 463 70 jK NSS
113 (209) JUNCTION BOX ASSEMBLY / JB5, JB20, X336, X337 211001

35 34

37 36

37 36
23 24
1
15 16
19

20

17 18
21

22
10 11 12 13 14

3 4 5

31 32

Sandvik Mining and Construction Oy Drills Tampere © 2021

 550 463 70 jK NSS
211001 JUNCTION BOX ASSEMBLY / JB5, JB20, X336, X337 114 (209)

Ref. Part no. Description EN Standard designation Qty

e
1 550 365 81 ENCLOSURE, PLASTIC Perforated 80x75x57, Polycarbonate 1
3 850 546 59 RAIL, MOUNTING DIN rail NS15 0.07
4 800 617 49 SLOTTED PAN HEAD SCREW M4X6 2
5 800 246 39 WASHER, STAR 4 IZ 2
10 850 547 89 TERMINAL BLOCK, FEED-THROUGH 2 Connections, 4 mm2 8
. . . . .
11 850 595 79 TERMINAL BLOCK, END PLATE Gray 1
12 850 548 09 TERMINAL, GROUND 2
13 850 550 09 MARKER STRIP, TERMINAL 0.2
15 550 038 16 GLAND, CABLE M16 1
17 550 367 68 GLAND, CABLE M20, 2 Cables 1
. . . . .
19 550 038 00 NUT, LOCKING, METALLIC M16x1.5, H=2.8mm 1
20 550 038 02 NUT, LOCKING, METALLIC M20x1.5, H=3.0mm 1
21 550 059 90 PLUG, BLANKING, METALLIC M16x1,5 with NBR O-ring, Thread=6,0mm 1
22 550 038 00 NUT, LOCKING, METALLIC M16x1.5, H=2.8mm 1

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 006 309 40 aA
115 (209) FILTER, RETURN 211001

1
3

Ref. Part no. Description EN Standard designation Qty

e
*1 BG 006 309 46 FILTER ELEMENT, RETURN Q 850 l/min, 10 micron 1
*2 552 008 90 SPRING 1
*3 552 008 91 SEAL KIT 1

Sandvik Mining and Construction Oy Drills Tampere © 2021

 551 798 38 cC NSS
211001 ASSEMBLY / WATER AND OIL HOSES 116 (209)

12
11 10

9
7

5 6

Ref. Part no. Description EN Standard designation Qty

e
1 853 502 39 HEAT EXCHANGER, OIL-WATER SECTION 11 PAGE 117 1
2 816 699 59 STRAIGHT THREAD ADAPTER 1,7/8-12JIC 1
3 550 777 31 STRAIGHT THREAD ELBOW JIC 1,5/8-12 1
4 882 155 29 STRAIGHT THREAD ADAPTER M/M 1"1/16JIC-1"1/ 4BSPP 1
5 817 179 09 STRAIGHT THREAD ADAPTER JIC 7/16-20 1
. . . . .
6 819 561 09 SWIVEL NUT ELBOW 90 JIC 7/16-20 1
7 819 560 89 LIITINRUNKO90 1 1/16 in -12 JIC 1
9 818 018 09 ADAPTER, ELBOW G 1 1/4 x JIC 1 5/8-12 1
10 819 562 39 REDUCER, TUBE END 1,5/8X1,1/16JIC 1
11 816 913 09 NUT JIC 1,5/8-12 1
. . . . .
12 816 707 49 SWIVEL NUT ELBOW 90 JIC 1,7/8-12, 90 deg 1

Sandvik Mining and Construction Oy Drills Tampere © 2021

 853 502 39 fF
117 (209) HEAT EXCHANGER, OIL-WATER / Q 160 L/MIN, P_MAX 20 BAR 211001

1 2

6 3 7

Ref. Part no. Description EN Standard designation Qty

e
1 856 025 29 FRAME Buy Cooler 1
2 856 766 89 CELL 1
3 800 592 59 HEXAGON SOCKET HEAD SCREW M8X35 - 8.8 8
6 816 021 09 COVER with drain plug and hole, 4 holes 2
7 813 198 69 O-RING 2
. . . . .

Sandvik Mining and Construction Oy Drills Tampere © 2021

 551 897 84 aA NSS
119 (209) MOUNTING / OF FILLING BUMP 211001

2 173 562

3 174 508 552

550 504 123 1

ELECTRIC FILLING PUMP

2 4 173 562

146 506 551

3 174 508 552

553 207 1

OPTION

Sandvik Mining and Construction Oy Drills Tampere © 2021

 551 897 84 aA NSS
211001 MOUNTING / OF FILLING BUMP 120 (209)

Ref. Part no. Description EN Standard designation Qty

e
1 551 730 63 NSS PUMP, FILLING SECTION 11 PAGE 122 1
123 802 559 29 HEXAGON HEAD SCREW M6x20 4
173 800 460 49 HEXAGON HEAD SCREW M10x25 - 8.8 2
174 800 192 49 HEXAGON HEAD SCREW M10x30 2
504 801 774 59 NUT, LOCK M6 4
. . . . .
508 284 773 10 NUT, LOCK M10 - 8, Zn 2
550 853 239 79 WASHER, LOCK, DOUBLE M6 8
552 851 282 09 WASHER, LOCK, DOUBLE M10 4
562 550 130 58 WASHER, LOCK, DOUBLE M10 2
*3 551 730 89 BRACKET 1
. . . . .

Sandvik Mining and Construction Oy Drills Tampere © 2021

 551 730 63 bB NSS
121 (209) PUMP, FILLING / ASSEMBLY 211001

2
3

4 5 6 7

Sandvik Mining and Construction Oy Drills Tampere © 2021

 551 730 63 bB NSS
211001 PUMP, FILLING / ASSEMBLY 122 (209)

Ref. Part no. Description EN Standard designation Qty

e
3:REF 551 730 89 BRACKET 1
1 560 385 10 NSS PUMP, FILLING SECTION 11 PAGE 123 1
2 560 385 11 NSS SUCTION HOSE ASSEMBLY SECTION 11 PAGE 126 1
4 AF1 014 0026 ADAPTER, MALE STUD CONNECTOR JIC 1 1/16 - BSPP 1/2 1
5 AF1 035 0013 ADAPTER, SWIVEL MALE STUD JIC 1 1/16 - BSPP 1/2 1
. . . . .
6 047 905 83 VALVE, CHECK Q 160 l/min, p_max 350 bar 1
7 AF1 014 0026 ADAPTER, MALE STUD CONNECTOR JIC 1 1/16 - BSPP 1/2 1
8 283 358 10 SEAL, COPPER Cu A33X39X2 1

Sandvik Mining and Construction Oy Drills Tampere © 2021

 560 385 10 a NSS
123 (209) PUMP, FILLING / 24VDC 211001

4 3

Ref. Part no. Description EN Standard designation Qty

e
1 047 605 39 HYDRAULIC POWER UNIT, ELECTRIC 1
2 560 365 31 SCREEN Strainer 1
3 560 421 01 CONNECTOR, MALE 1
4 560 421 02 RING, SEAL USIT 12- 3/4, self centering 1

Sandvik Mining and Construction Oy Drills Tampere © 2021

 560 385 11 aA NSS
125 (209) SUCTION HOSE ASSEMBLY / FOR FILLING PUMP 211001

1 2

3 4

Sandvik Mining and Construction Oy Drills Tampere © 2021

 560 385 11 aA NSS
211001 SUCTION HOSE ASSEMBLY / FOR FILLING PUMP 126 (209)

Ref. Part no. Description EN Standard designation Qty

e
1 560 365 30 HOSE Thread G1 , length 3m 1
2 560 385 09 VALVE, INLET Suction valve for filling pump. Thread G1 1
3 560 356 21 CONNECTOR Suction head 1
4 560 356 20 GUARD Plastic cover for suction head 1

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 001 744 51 dD
127 (209) VALVE ASSEMBLY / REAR JACKS 211001

15
16

25
14
13

12
22 18

21 20 19

21 5 6 21 35 4

11 10 7 9 8

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 001 744 51 dD
211001 VALVE ASSEMBLY / REAR JACKS 128 (209)

Ref. Part no. Description EN Standard designation Qty

e
4 853 163 09 VALVE, RESTRICTOR, ONE WAY 1
4.1 882 772 29 SEAL KIT 1
5 853 163 09 VALVE, RESTRICTOR, ONE WAY 1
5.1 882 772 29 SEAL KIT 1
6 550 432 71 VALVE, PRESSURE REDUCING Q 60 l/min, p_max 315 bar 1
. . . . .
6.1 550 432 75 SEAL KIT 1
7 550 432 71 VALVE, PRESSURE REDUCING Q 60 l/min, p_max 315 bar 1
7.1 550 432 75 SEAL KIT 1
8 886 388 29 VALVE, SPOOL, DIRECTIONAL SECTION 10 PAGE 49 1
9 886 388 29 VALVE, SPOOL, DIRECTIONAL SECTION 10 PAGE 49 1
. . . . .
10 886 388 29 VALVE, SPOOL, DIRECTIONAL SECTION 10 PAGE 49 1
11 886 388 29 VALVE, SPOOL, DIRECTIONAL SECTION 10 PAGE 49 1
12 801 031 49 BONDED SEAL U 17.4x24x1.5 7
13 AF1 014 0026 ADAPTER, MALE STUD CONNECTOR JIC 1 1/16 - BSPP 1/2 1
14 AF1 144 0006 ADAPTER, SWIVEL NUT BRANCH TEE JIC 1 1/16 1
. . . . .
15 852 264 59 HEXAGON SOCKET HEAD SCREW M5X130m10.9 8
16 AF0 050 0181 SCREW, SOCKET HEAD, HEXAGON M5x50 8
18 049 429 78 ADAPTER R3/8 - 9/16-18 UNF, L=65 7
19 AF1 014 0010 ADAPTER, MALE STUD CONNECTOR JIC 9/16 - BSPP 1/8 2
20 AF1 174 0003 ADAPTER, TEST POINT CONNECTOR JIC 9/16 - BSPP 1/4 2
. . . . .
21 AF1 143 0005 ADAPTER, TEST POINT WITH THREADED G 1/4 2
CONNECTION M 16X
22 AF1 015 0013 ADAPTER, MALE STUD ELBOW JIC 3/4 - BSPP 1/2 1
25 AF1 038 0008 ADAPTER, CAP JIC 1 1/16 1
35 806 982 09 VALVE, CHECK Q 110 l/min, p_max 350 bar 1

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 001 744 51 dD
129 (209) VALVE ASSEMBLY / REAR JACKS 211001

28 24 23 17 23 24
8 9

7 5 10 11
6

1
33

35

33

34

28

27

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 001 744 51 dD
211001 VALVE ASSEMBLY / REAR JACKS 130 (209)

Ref. Part no. Description EN Standard designation Qty

e
1 817 935 89 MANIFOLD BODY, VALVE p_max 315 bar 1
4 853 163 09 VALVE, RESTRICTOR, ONE WAY 1
4.1 882 772 29 SEAL KIT 1
5 853 163 09 VALVE, RESTRICTOR, ONE WAY 1
5.1 882 772 29 SEAL KIT 1
. . . . .
6 550 432 71 VALVE, PRESSURE REDUCING Q 60 l/min, p_max 315 bar 1
6.1 550 432 75 SEAL KIT 1
7 550 432 71 VALVE, PRESSURE REDUCING Q 60 l/min, p_max 315 bar 1
7.1 550 432 75 SEAL KIT 1
8 886 388 29 VALVE, SPOOL, DIRECTIONAL SECTION 10 PAGE 49 1
. . . . .
9 886 388 29 VALVE, SPOOL, DIRECTIONAL SECTION 10 PAGE 49 1
10 886 388 29 VALVE, SPOOL, DIRECTIONAL SECTION 10 PAGE 49 1
11 886 388 29 VALVE, SPOOL, DIRECTIONAL SECTION 10 PAGE 49 1
17 AF1 144 0003 ADAPTER, SWIVEL NUT BRANCH TEE JIC 9/16 1
23 AF1 014 0012 ADAPTER, MALE STUD CONNECTOR JIC 9/16 - BSPP 1/2 2
. . . . .
24 AF1 038 0005 ADAPTER, CAP JIC 9/16 2
27 AF1 147 0003 ADAPTER, SWIVEL NUT RUN TEE JIC 9/16 1
28 AF1 146 0004 ADAPTER, SWIVEL NUT ELBOW JIC 9/16 2
33 AF1 014 0011 ADAPTER, MALE STUD CONNECTOR JIC 9/16 - BSPP 3/8 2
34 AF1 035 0006 ADAPTER, SWIVEL MALE STUD JIC 9/16 - BSPP 3/8 1
. . . . .
35 806 982 09 VALVE, CHECK Q 110 l/min, p_max 350 bar 1

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 004 133 22 cC NSS
131 (209) AIR FILTER ASSEMBLY 211001

12 178 147 2 1 6 185 9 10

508 562 508
563

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 004 133 22 cC NSS
211001 AIR FILTER ASSEMBLY 132 (209)

Ref. Part no. Description EN Standard designation Qty

e
1 550 446 11 FILTER ELEMENT, AIR 1
1.1 886 012 19 AIR FILTER CARTRIDGE 1
1.2 886 013 49 SAFETY CARTRIDGE 1
2 550 446 12 CLAMP 1
5 550 446 18 COVER, RAIN 1
. . . . .
6 BG 004 155 97 ELBOW, AIR HOSE Cobra head elbow 4 1
8 853 313 19 CLAMP, HOSE D 120-122 mm, Steel 5
9 550 204 54 CLAMP, HOSE D 68-85 mm, Stainless Steel 1
10 550 440 53 SWITCH, PRESSURE 1
12 280 679 10 CLAMP, HOSE D 44-56 mm, Stainless Steel 1
. . . . .
147 442 577 60 HEXAGON HEAD SCREW M8X35 2
178 800 526 09 HEXAGON HEAD BOLT M10x45 2
185 801 444 49 HEXAGON HEAD BOLT M10x75 - 8.8 1
508 284 773 10 NUT, LOCK M10 - 8, Zn 3
562 550 160 42 WASHER, LOCK, DOUBLE M8 sp 2
. . . . .
563 550 130 58 WASHER, LOCK, DOUBLE M10 4

Sandvik Mining and Construction Oy Drills Tampere © 2021

 552 269 54 cC NSS
133 (209) BRACKET / ASSEMBLY - ELECTRICAL SWITCHGEAR, STANDARD VERSION 211001

121 561 9

4 1

144 551 6

506 551 8

510 7

512 564 3

2 564 206

Ref. Part no. Description EN Standard designation Qty

e
1 552 269 55 BRACKET 1
2 551 660 87 PLATE, MOUNTING 1
2.1 551 641 21 LATCH 1
3 551 660 91 BAR 3
4 550 339 58 BUSH, PLAIN, DRY da = 65 mm, d_i = 60 mm 2
. . . . .
5 572 102 40 NIPPLE, GREASE AR 1/8 2
6 552 264 70 LATCH 1
6.1 550 124 27 KNOB PL.30 B-M8 1
6.2 551 642 70 SPRING, COMPRESSIVE Break spring 1
6.3 800 066 09 SPRING-TYPE STRAIGHT PIN 4X24 1
. . . . .
7 851 620 09 DAMPER 40x20 1
8 551 804 70 HOLDER Electric cable 1
9 140 467 88 FASTENER, RING 2
121 866 024 29 HEXAGON HEAD SCREW M6X12-8.8 2
144 AF0 010 0322 SCREW, HEXAGON HEAD, FULL THREAD M8x20 4
. . . . .
206 AF0 010 0738 SCREW, HEXAGON HEAD, FULL THREAD M12x40 2
506 801 779 99 NUT, LOCK M8 2
510 AF0 140 0006 NUT, HEXAGON M10 1
512 AF0 200 0006 NUT, HEXAGON, PREVAILING TORQUE, ALL M12 6
METAL
551 AF0 300 0030 WASHER, LOCK, PAIR NL8 6
. . . . .
561 AF0 300 0119 WASHER, LOCK, PAIR NL6-sp 2
564 AF0 300 0122 WASHER, LOCK, PAIR NL12-sp 8

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 014 552 36 aA NSS
211001 SUPPORT, REAR / ASSEMBLY, WITHOUT WATER HOSE GUIDE 134 (209)

17
21
4 172 563 17
3 172 563 21

174 508 563

18 19

20
563 172 2
10
20

Ref. Part no. Description EN Standard designation Qty

e
1 551 886 14 SUPPORT, REAR 1
10 BG 014 563 75 BRACKET SECTION 11 PAGE 135 1
17 550 333 52 NSS BAR SECTION 11 PAGE 136 2
18 551 689 34 GLAND, CABLE M25 9-16mm, flexible 1
19 550 024 06 NUT, LOCKING, METALLIC M25x1.5 1
. . . . .
20 552 182 06 LIGHT, LED SECTION 10 PAGE 14 2
21 BG 013 980 83 NSS LIGHT SECTION 11 PAGE 138 2
172 AF0 010 0524 SCREW, HEXAGON HEAD, FULL THREAD M10x20 8
174 AF0 010 0528 SCREW, HEXAGON HEAD, FULL THREAD M10x30 2
508 AF0 190 0005 NUT, HEXAGON, PREVAILING TORQUE M10 2
. . . . .
563 AF0 300 0121 WASHER, LOCK, PAIR NL10-sp 12

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 014 563 75 aA
135 (209) BRACKET / REELS REMOTE CONTROL 211001

Ref. Part no. Description EN Standard designation Qty

e
1 BG 014 563 76 BRACKET Reels remote control 1
2 550 096 92 BAND RUBBER BAND 5X20 0.64

Sandvik Mining and Construction Oy Drills Tampere © 2021

 550 333 52 cC NSS
211001 BAR / INDICATOR ROD ASSEMBLY 136 (209)

3 2

4 3

Ref. Part no. Description EN Standard designation Qty

e
2 046 681 38 KNOB for indicator rod 1
3 AF0 140 0149 NUT, HEXAGON M16 3
4 AF0 300 0034 WASHER, LOCK, PAIR NL16 2

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 013 980 83 aA NSS
137 (209) LIGHT 211001

504

572

124

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 013 980 83 aA NSS
211001 LIGHT 138 (209)

Ref. Part no. Description EN Standard designation Qty

e
2 BG 012 253 55 LIGHT 8-33Vdc, IP69k 1
124 AF0 010 0137 SCREW, HEXAGON HEAD, FULL THREAD M6x25 2
504 AF0 190 0003 NUT, HEXAGON, PREVAILING TORQUE M6 2
572 AF0 230 0004 WASHER, PLAIN, NORMAL M6 4

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 004 145 29 hH NSS
139 (209) BRACKET / COMPRESSOR 211001

2
9 510 552

4 557

555
552 508 185 6
5
8
6
6
3
5
8
9
555
558 6

557 10

552 510 4

11 1 185 508 552

9 510 552

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 004 145 29 hH NSS
211001 BRACKET / COMPRESSOR 140 (209)

Ref. Part no. Description EN Standard designation Qty

e
1 BG 004 158 35 BRACKET bottom 1
2 BG 004 158 39 BRACKET Top 1
3 BG 008 216 65 SUPPORT compressor bracket 1
4 BG 008 146 86 LATCH - 2
5 551 644 62 PLATE 2
. . . . .
6 815 366 59 BUSH, PLAIN, LUBRICATED 60x35 4
8 572 102 40 NIPPLE, GREASE AR 1/8 2
9 851 620 09 DAMPER 40x20 2
11 BG 008 162 38 PLATE, SHIM Plate, Shim 4
185 AF0 010 0644 SCREW, HEXAGON HEAD, PARTIAL M10x75 4
THREAD
. . . . .
508 AF0 190 0005 NUT, HEXAGON, PREVAILING TORQUE M10 4
510 AF0 140 0006 NUT, HEXAGON M10 2
552 AF0 300 0031 WASHER, LOCK, PAIR NL10 10
555 AF0 300 0034 WASHER, LOCK, PAIR NL16 2
557 AF0 010 1122 SCREW, HEXAGON HEAD, FULL THREAD M16x25 2
. . . . .
558 AF0 070 0143 SCREW, SOCKET HEAD, COUNTERSUNK, M8x25 2
HEXAGON

Sandvik Mining and Construction Oy Drills Tampere © 2021

 551 741 92 eE
141 (209) BRACKET / COMPRESSOR 211001

7
8 9

10

11

13 12
12

Ref. Part no. Description EN Standard designation Qty

e
1 551 741 95 BRACKET Bottom part 1
2 551 741 94 BRACKET Top part 1
3 550 339 58 BUSH, PLAIN, DRY da = 65 mm, d_i = 60 mm 2
4 551 644 62 PLATE 1
5 AF0 300 0034 WASHER, LOCK, PAIR NL16 1
. . . . .
6 AF0 010 1122 SCREW, HEXAGON HEAD, FULL THREAD M16x25 1
7 572 102 40 NIPPLE, GREASE AR 1/8 2
8 551 742 52 SUPPORT Bracket, compressor 1
9 AF0 300 0122 WASHER, LOCK, PAIR NL12-sp 4
10 AF0 010 0738 SCREW, HEXAGON HEAD, FULL THREAD M12x40 2
. . . . .
11 AF0 140 0007 NUT, HEXAGON M12 2
12 851 620 09 DAMPER 40x20 2
13 AF0 140 0006 NUT, HEXAGON M10 1

Sandvik Mining and Construction Oy Drills Tampere © 2021

 551 683 28 cC NSS
143 (209) TAP / SUBASSEMBLY 211001

1
4

Sandvik Mining and Construction Oy Drills Tampere © 2021

 551 683 28 cC NSS
211001 TAP / SUBASSEMBLY 144 (209)

Ref. Part no. Description EN Standard designation Qty

e
2 806 805 99 VALVE, BALL 2/2, p_max 16 bar 1
3 AF1 014 0024 ADAPTER, MALE STUD CONNECTOR JIC 1 1/16 - BSPP 3/4 1
4 AF1 035 0012 ADAPTER, SWIVEL MALE STUD JIC 1 1/16 - BSPP 3/4 1
5 AF1 135 0006 ADAPTER, BULKHEAD UNION WITH JIC 1 1/16 1
BULKHEAD LOCKNUT
6 AF1 038 0008 ADAPTER, CAP JIC 1 1/16 1
. . . . .

Sandvik Mining and Construction Oy Drills Tampere © 2021

 551 705 59 a NSS
145 (209) COCK / ASSEMBLY, ADAPTERS & BRACKET, 2 X COCK 211001

2
1

Ref. Part no. Description EN Standard designation Qty

e
1 551 705 63 PLATE, MOUNTING Cock assembly, adapters & bracket 1
2 813 448 09 VALVE, BALL 2/2, p_max 25 bar 2
3 817 179 09 STRAIGHT THREAD ADAPTER JIC 7/16-20 2
4 865 405 39 ADAPTER, HYDRAULIC JIC 7/16-20 2
5 817 100 09 ADAPTER, HYDRAULIC JIC 7/16-20 2
. . . . .

Sandvik Mining and Construction Oy Drills Tampere © 2021

 550 449 07 a
211001 LAMP ASSEMBLY / STEP LIGHT, 24V (LED), DT04-2P CONNECTOR 146 (209)

Step light 24V (LED)

5

1, 2, 3, 4

DT04-2P connector

Ref. Part no. Description EN Standard designation Qty

e
1 550 148 91 SHELL, CONNECTOR 2-pole male 1
2 550 148 92 LOCKING PART, CONTACT Wedge lock, 2 cavities, Plastic, Green 1
3 886 820 99 CONTACT, CONNECTOR Pin, Nickel 2
4 855 484 59 SHRINK WRAP 18.0 mm, 6.0 mm 1
5 550 441 60 LIGHT, LED 24V, 100x45x10 (oval) 1
. . . . .

Sandvik Mining and Construction Oy Drills Tampere © 2021

 550 723 46
147 (209) CABLE ASSEMBLY / DT06 2S / 4.0M - PUR 2X1.5 211001

1,2,3 4 5

Ref. Part no. Description EN Standard designation Qty

e
1 550 148 83 CONTACT, CONNECTOR Socket, Nickel 2
2 550 149 20 SHELL, CONNECTOR Plug for sockets, 2-pole female, shrink boot 1
3 550 149 21 LOCKING PART, CONTACT Locking part 1
4 855 484 59 SHRINK WRAP 18.0 mm, 6.0 mm 0.05
5 867 108 59 CABLE 2x1,5mm2 4
. . . . .

Sandvik Mining and Construction Oy Drills Tampere © 2021

 551 818 39 aA
211001 STEPS / REAR MODULE 148 (209)

552 508 174 182 508 552

Ref. Part no. Description EN Standard designation Qty

e
1 551 818 40 NSS FRAME ASSEMBLY Rear module steps 1
2 551 818 41 STEP Folding step 1
174 800 192 49 HEXAGON HEAD SCREW M10x30 2
182 442 567 50 HEXAGON HEAD BOLT M10X60 2
508 851 282 09 WASHER, LOCK, DOUBLE M10 8
. . . . .
552 812 622 69 NUT, LOCK M10 m8 4

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 015 962 04 aA NSS
149 (209) MOUNTING / WATER HOSE QUIDE, REAR PANEL 211001

3 1

2 4

564 201 205 512 553 564

564 553 512 205 201 564

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 015 962 04 aA NSS
211001 MOUNTING / WATER HOSE QUIDE, REAR PANEL 150 (209)

Ref. Part no. Description EN Standard designation Qty

e
1 551 687 84 GUIDE Water hose guide 1
1.1 551 687 78 ROLLER GST Roller D76.1mm, d20, L=300 2
1.2 551 687 80 ROLLER GST Roller D76.1mm, d20, L=200 2
2 552 241 88 GUIDE Cable Guide 1
3 BG 015 964 15 BRACKET Water hose guide, uppe 1
. . . . .
4 BG 015 966 47 BRACKET Water hose guide, lower 1
201 AF0 010 0734 SCREW, HEXAGON HEAD, FULL THREAD M12x20 4
205 AF0 010 0737 SCREW, HEXAGON HEAD, FULL THREAD M12x35 4
512 AF0 200 0006 NUT, HEXAGON, PREVAILING TORQUE, ALL M12 4
METAL
553 AF0 300 0032 WASHER, LOCK, PAIR NL12 4
. . . . .
564 AF0 300 0122 WASHER, LOCK, PAIR NL12-sp 8

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 009 675 89 aA NSS
151 (209) ASSEMBLY / HYDRAULIC TANK CONNECTORS FOR KAWASAKI PUMPS 211001

1 2

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 009 675 89 aA NSS
211001 ASSEMBLY / HYDRAULIC TANK CONNECTORS FOR KAWASAKI PUMPS 152 (209)

Ref. Part no. Description EN Standard designation Qty

e
1 AF1 150 0011 ADAPTER, TUBE END REDUCER FORM B JIC 9/16 - JIC 1 1/16 1
2 AF1 040 0006 ADAPTER, NUT JIC 1 1/16 1
3 AF1 144 0003 ADAPTER, SWIVEL NUT BRANCH TEE JIC 9/16 1

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 008 641 72 aA
153 (209) PUMP, WATER / WBP-1008 211001

Ref. Part no. Description EN Standard designation Qty

e
1 BG 010 477 97 SEAL KIT SECTION 11 PAGE 156 1
2 BG 010 708 13 HARDWARE KIT SECTION 11 PAGE 158 1
3 BG 010 708 22 HYDRAULIC KIT SECTION 11 PAGE 159 1

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 010 477 97 aA
155 (209) SEAL KIT / SEAL KIT 211001

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 010 477 97 aA
211001 SEAL KIT / SEAL KIT 156 (209)

Ref. Part no. Description EN Standard designation Qty

e
1 MECHANICAL SEAL WITH CARTRIDGE 1
2 O-RING FOR OUTER CASING 2
3 FLANGE GASKET 2

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 010 708 13 aA
157 (209) HARDWARE KIT / HARDWARE KIT 211001

13

9 11

7 8

12

14

4
10
19
17
2
16

5
3

15

18

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 010 708 13 aA
211001 HARDWARE KIT / HARDWARE KIT 158 (209)

Ref. Part no. Description EN Standard designation Qty

e
1 ADJUSTER KEY 1
2 O-RING OR 3050 1
3 GASKET 4
4 O-RING OR 3068 1
5 TIE ROD 4
. . . . .
6 SCREW FOR COUPLING 4
7 SCREW FOR MOTOR 4
8 NUT FOR TIE ROD 4
9 NUT (SCREW FOR MOTOR) 4
10 SCREW FOR COUPLING GUARD 4
. . . . .
11 PIN FOR SHAFT 1
12 WASHER 4
13 COUPLING 2
14 PLUG (FILLING) G 1/2 1
15 PLUG (DISCHARGE) G 3/8 4
. . . . .
16 VENTING PLUG 1
17 COUPLING GUARD 2
18 PLUG WASHER 4
19 ADAPTER G 3/8 - G 1/2 1

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 010 708 22 aA
159 (209) HYDRAULIC KIT / HYDRAULIC KIT 211001

Ref. Part no. Description EN Standard designation Qty

e
1 HYDRAULIC STACK 1

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 009 584 55 cR
161 (209) CABLE ASSEMBLY 211001

10 11 12 13 14 15

4 2 3 5

1 3 5

1
2 3 4 5 6 7

1 2 3 4 5 6 7

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 009 584 55 cR
211001 CABLE ASSEMBLY 162 (209)

Ref. Part no. Description EN Standard designation Qty

e
1 080 015 65 TERMINAL, WIRE 50 mm2, Tubular Lug 7
1 BG 007 130 40 WASHER, LOCK, PAIR NLX10-sp 7
2 BG 007 155 77 CABLE, PREWIRED, IO 50mm2,D=14.1,Betatherm® 145 UL/cUL 2
3820
3 BG 007 155 77 CABLE, PREWIRED, IO 50mm2,D=14.1,Betatherm® 145 UL/cUL 2
3820
4 BG 007 155 77 CABLE, PREWIRED, IO 50mm2,D=14.1,Betatherm® 145 UL/cUL 2
3820
. . . . .
5 813 110 79 WIRE 50mm2 YELLOW/GREEN 1
6 560 255 67 WIRE 2,5mm2, D3,7mm, black 2
7 080 015 66 TERMINAL, WIRE 50 mm2, Tubular Lug 7
7 BG 007 130 42 WASHER, LOCK, PAIR NLX12-sp 7
8 551 523 33 SHRINK WRAP Clear, 18/6mm 1.5
. . . . .

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 009 584 57 bR
163 (209) CABLE ASSEMBLY / CABLE ASSEMBLY (SLIP RING UNIT - MP) 211001

10 11 12 13 14 15

4 2 3 5

1 3 5

1
2 3 4 5 6 7

1 2 3 4 5 6 7

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 009 584 57 bR
211001 CABLE ASSEMBLY / CABLE ASSEMBLY (SLIP RING UNIT - MP) 164 (209)

Ref. Part no. Description EN Standard designation Qty

e
1 851 173 09 FITTING 45 deg 1
2 816 252 19 FITTING 90 deg 1
3 049 454 68 NUT, BACK 2
4 816 401 09 PROTECTIVE HOSE 2 in, 1,9m 3.7
5 802 285 69 USIT-SEAL U 60,7X73X3 D2=62,8 4
. . . . .
10 BG 007 155 77 CABLE, PREWIRED, IO 50mm2,D=14.1,Betatherm® 145 UL/cUL 26
3820
11 BG 007 155 77 CABLE, PREWIRED, IO 50mm2,D=14.1,Betatherm® 145 UL/cUL 26
3820
12 BG 007 155 77 CABLE, PREWIRED, IO 50mm2,D=14.1,Betatherm® 145 UL/cUL 26
3820
13 813 110 79 WIRE 50mm2 YELLOW/GREEN 6.5
14 560 255 67 WIRE 2,5mm2, D3,7mm, black 13
. . . . .
15 080 015 65 TERMINAL, WIRE 50 mm2, Tubular Lug 7
15 BG 007 130 40 WASHER, LOCK, PAIR NLX10-sp 7

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 015 583 11 a NSS
165 (209) HOSING SET / WATER HOSE, 65M, 1 1/2" 211001

NO ILLUSTRATION AVAILABLE

Ref. Part no. Description EN Standard designation Qty

e
1 BG 003 759 88 HOSE ASSEMBLY, HYDRAULIC 1SN BC-24-65000-J24A-J24A-0-0 1

Sandvik Mining and Construction Oy Drills Tampere © 2021

 552 181 53 bB NSS
167 (209) MOUNTING / CABLE RACK MOUNTING 211001

7
7 6
6 5
12
5 4
11
7 2
10
6

1 5 6 8 9

10 11 12 13

Sandvik Mining and Construction Oy Drills Tampere © 2021

 552 181 53 bB NSS
211001 MOUNTING / CABLE RACK MOUNTING 168 (209)

Ref. Part no. Description EN Standard designation Qty

e
1 552 183 06 RACK, CABLE 75x5/55, L= 505 1
2 552 183 06 RACK, CABLE 75x5/55, L= 505 1
3 552 183 08 RACK, CABLE 75x5/55, zinc plated, L= 305 1
4 552 183 08 RACK, CABLE 75x5/55, zinc plated, L= 305 1
5 550 531 21 CONNECTING PIECE 8
. . . . .
6 550 204 51 WASHER, LOCK, DOUBLE M6 10
7 802 421 59 HEXAGON HEAD SCREW M6x16m8.8 6
8 867 706 69 HEXAGON HEAD SCREW M6X50 - 8.8 2
9 801 774 59 NUT, LOCK M6 2
11 800 470 59 HEXAGON HEAD SCREW M12x30 2
. . . . .
12 851 068 09 WASHER, LOCK, DOUBLE M12 2
13 807 695 29 STRAP L=400 Black 1

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 002 350 61 aA NSS
169 (209) RAILING / ASSEMBLY 211001

206 553

206 553 513

Ref. Part no. Description EN Standard designation Qty

e
1 BG 002 333 16 RAILING 1
206 800 531 79 HEXAGON HEAD SCREW M12x40 3
513 800 821 49 NUT, HEXAGON M12 - 8 1
553 851 068 09 WASHER, LOCK, DOUBLE M12 4

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 007 896 00 bB NSS
171 (209) FRAME, BACKING / ASSEMBLY 211001

42 173 563 563

171 21
510 262
28
563
43 562
173
510
31 34
43
SECTION F-F 173

37 171 563 563

SECTION E-E
SECTION T-T

564
510 564
563 202 24 563 171 30 201
43 201
F F 23
E
35
E
T

510 43

26
T
176

510

510 43 206

511
563 171 29 26 32
24 43 32 564
30 22
43 175 43 142
202 510 142
171 201 510
510 508 562
563 562
563 564
563

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 007 896 00 bB NSS
211001 FRAME, BACKING / ASSEMBLY 172 (209)

Ref. Part no. Description EN Standard designation Qty

e
21 551 721 62 BRACKET Cover assembly 1
22 551 812 52 BRACKET right, Cover assembly 1
23 551 812 50 BRACKET left, Cover assembly 1
24 552 070 88 SUPPORTING BLOCK Rear cover plate 2
26 552 178 37 NSS THRUST SECTION 11 PAGE 179 1
. . . . .
28 551 735 22 THRUST for Latch 1
29 551 728 39 THRUST for Rear door latch 1
30 551 728 72 BRACKET for Gas spring 2
31 552 070 85 HOLDER for Lifting bar 2
32 551 728 06 BRACKET for Damper 2
. . . . .
34 551 817 88 SUPPORT Front cover, right 1
35 BG 004 244 87 BRACKET Cover assembly 1
37 551 888 17 THRUST for Rear door latch 1
42 552 176 30 NSS LATCH SECTION 11 PAGE 180 2
43 851 620 09 DAMPER 40x20 11
. . . . .
142 808 803 59 HEXAGON HEAD SCREW M8X16 - 8.8 4
171 800 432 79 HEXAGON HEAD SCREW M10X16 14
173 800 460 49 HEXAGON HEAD SCREW M10x25 - 8.8 6
175 800 461 79 HEXAGON HEAD SCREW M10x35 m8.8 2
201 800 194 09 HEXAGON HEAD SCREW M12X20 - 8.8 8
. . . . .
202 800 824 29 HEXAGON HEAD SCREW M12x25 4
206 800 531 79 HEXAGON HEAD SCREW M12x40 2
262 800 196 59 HEXAGON HEAD SCREW M16X30 - 8.8 3
508 284 773 10 NUT, LOCK M10 - 8, Zn 2
510 800 820 19 NUT, HEXAGON M10 m8 12
. . . . .
511 412 113 00 NUT, LOCK M12 - 8, Zn 15
562 550 160 42 WASHER, LOCK, DOUBLE M8 sp 4
563 550 130 58 WASHER, LOCK, DOUBLE M10 28
564 550 130 59 WASHER, LOCK, DOUBLE M12 42

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 007 896 00 bB NSS
173 (209) FRAME, BACKING / ASSEMBLY 211001

563 171 36

20 205 511 564

39 201 564

563 173 42

563 171 27

43 510

34 173 563
563 173 31

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 007 896 00 bB NSS
211001 FRAME, BACKING / ASSEMBLY 174 (209)

Ref. Part no. Description EN Standard designation Qty

e
20 BG 007 900 14 NSS FRAME, BACKING SECTION 11 PAGE 176 1
27 552 179 05 THRUST for Latch 1
31 552 070 85 HOLDER for Lifting bar 2
34 551 817 88 SUPPORT Front cover, right 1
36 551 794 18 BRACKET Cover plate, water pump 1
. . . . .
39 552 181 83 BRACKET Cover assembly 1
42 552 176 30 NSS LATCH SECTION 11 PAGE 180 2
43 851 620 09 DAMPER 40x20 11
171 800 432 79 HEXAGON HEAD SCREW M10X16 14
173 800 460 49 HEXAGON HEAD SCREW M10x25 - 8.8 6
. . . . .
201 800 194 09 HEXAGON HEAD SCREW M12X20 - 8.8 8
205 442 776 90 HEXAGON HEAD SCREW M12x35 13
510 800 820 19 NUT, HEXAGON M10 m8 12
511 412 113 00 NUT, LOCK M12 - 8, Zn 15
563 550 130 58 WASHER, LOCK, DOUBLE M10 28
. . . . .
564 550 130 59 WASHER, LOCK, DOUBLE M12 42
25 551 726 85 SUPPORT Cover, hydraulic oil receiver 1
172 800 823 09 HEXAGON HEAD SCREW M10X20 2
177 800 525 79 HEXAGON HEAD BOLT M10X40 1
565 550 130 61 WASHER, LOCK, DOUBLE M16 sp 3
. . . . .

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 007 900 14 cC NSS
175 (209) FRAME, BACKING / ASSEMBLY 211001

564 214

43 510

33 70 43 510

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 007 900 14 cC NSS
211001 FRAME, BACKING / ASSEMBLY 176 (209)

Ref. Part no. Description EN Standard designation Qty

e
2 552 200 99 HINGE 1
33 552 189 72 NSS LIMITER SECTION 11 PAGE 177 1
43 851 620 09 DAMPER 40x20 3
70 552 190 67 NSS WIRE ROPE SECTION 11 PAGE 178 1
214 AF0 010 0844 SCREW, HEXAGON HEAD, PARTIAL M12x75 4
THREAD
. . . . .
510 AF0 140 0006 NUT, HEXAGON M10 3
564 AF0 300 0122 WASHER, LOCK, PAIR NL12-sp 4

Sandvik Mining and Construction Oy Drills Tampere © 2021

 552 189 72 a NSS
177 (209) LIMITER / ASSEMBLY, COVERS NC7 211001

94 93 92 91

Ref. Part no. Description EN Standard designation Qty

e
91 552 189 93 PIN Limiter, cover plate 1
92 551 743 50 SPRING, COMPRESSIVE Dt=2.0, Di=16, Lo=50, Ln=24.7, c=3.5 1
93 551 641 60 LOCK Lock piece 1
94 800 076 09 SPRING-TYPE STRAIGHT PIN 6X30 1

Sandvik Mining and Construction Oy Drills Tampere © 2021

 552 190 67 NSS
211001 WIRE ROPE / ASSEMBLY 178 (209)

73 74

575 511
71

73

575 215 72

Ref. Part no. Description EN Standard designation Qty

e
71 550 074 52 WIRE ROPE 2mm, 7X19, A4 1.25
72 800 248 99 HOSE 5/8,2 0.37
73 550 192 99 CRIMP For 2 mm Wire Rope 4
74 552 180 61 BUSHING nylon 2
215 800 535 89 HEXAGON HEAD BOLT M12x80 - 8.8 2
. . . . .
511 412 113 00 NUT, LOCK M12 - 8, Zn 2
575 421 189 50 WASHER M13 4

Sandvik Mining and Construction Oy Drills Tampere © 2021

 552 178 37 NSS
179 (209) THRUST / FOR FRONT COVERPLATE LATCH 211001

201 564

Ref. Part no. Description EN Standard designation Qty

e
1 552 178 39 PLATE 1
2 552 178 40 PLATE 1
201 800 194 09 HEXAGON HEAD SCREW M12X20 - 8.8 1
564 550 130 59 WASHER, LOCK, DOUBLE M12 1

Sandvik Mining and Construction Oy Drills Tampere © 2021

 552 176 30 NSS
211001 LATCH / ASSEMBLY 180 (209)

Ref. Part no. Description EN Standard designation Qty

e
1 550 898 53 LATCH 1
2 552 176 21 PLATE, MOUNTING Attachment Plate 1
3 552 192 50 SLOTTED COUNTERSUNK FLAT HEAD M5x8 3
SCREW

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 007 788 06 bB NSS
181 (209) COVERS ASSEMBLY / SEMI+ARCT 211001

12 205 511 564

17 46 158 506 573

14 172 563

564 511 205 8

7 207 511 564

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 007 788 06 bB NSS
211001 COVERS ASSEMBLY / SEMI+ARCT 182 (209)

Ref. Part no. Description EN Standard designation Qty

e
46 552 066 47 SPRING, COMPRESSIVE Dt=2 Dm=12,5 Lo=49,5 2
158 AF0 010 0334 SCREW, HEXAGON HEAD, FULL THREAD M8x70 2
172 AF0 010 0524 SCREW, HEXAGON HEAD, FULL THREAD M10x20 6
205 AF0 010 0737 SCREW, HEXAGON HEAD, FULL THREAD M12x35 21
207 AF0 010 0739 SCREW, HEXAGON HEAD, FULL THREAD M12x45 8
. . . . .
506 AF0 190 0004 NUT, HEXAGON, PREVAILING TORQUE M8 10
511 AF0 190 0006 NUT, HEXAGON, PREVAILING TORQUE M12 20
563 AF0 300 0121 WASHER, LOCK, PAIR NL10-sp 12
564 AF0 300 0122 WASHER, LOCK, PAIR NL12-sp 64
573 AF0 230 0005 WASHER, PLAIN, NORMAL M8 4
. . . . .
573 AF0 300 0030 WASHER, LOCK, PAIR NL8 2

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 007 788 06 bB NSS
183 (209) COVERS ASSEMBLY / SEMI+ARCT 211001

564 511 205 13 17 46 158 506 573

563 172 15

564 511 207 9 10 205 511 564

551 506 156

47 45

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 007 788 06 bB NSS
211001 COVERS ASSEMBLY / SEMI+ARCT 184 (209)

Ref. Part no. Description EN Standard designation Qty

e
45 551 820 03 BUSHING Gas spring attachment 8
46 552 066 47 SPRING, COMPRESSIVE Dt=2 Dm=12,5 Lo=49,5 2
47 551 740 43 SPRING, GAS 505/200mm 1200N 4
156 AF0 010 0435 SCREW, HEXAGON HEAD, PARTIAL M8x65 4
THREAD
158 AF0 010 0334 SCREW, HEXAGON HEAD, FULL THREAD M8x70 2
. . . . .
172 AF0 010 0524 SCREW, HEXAGON HEAD, FULL THREAD M10x20 6
205 AF0 010 0737 SCREW, HEXAGON HEAD, FULL THREAD M12x35 21
207 AF0 010 0739 SCREW, HEXAGON HEAD, FULL THREAD M12x45 8
506 AF0 190 0004 NUT, HEXAGON, PREVAILING TORQUE M8 10
511 AF0 190 0006 NUT, HEXAGON, PREVAILING TORQUE M12 20
. . . . .
551 AF0 300 0030 WASHER, LOCK, PAIR NL8 10
563 AF0 300 0121 WASHER, LOCK, PAIR NL10-sp 12
564 AF0 300 0122 WASHER, LOCK, PAIR NL12-sp 64
573 AF0 230 0005 WASHER, PLAIN, NORMAL M8 4
573 AF0 300 0030 WASHER, LOCK, PAIR NL8 2
. . . . .
40 BG 007 787 87 NSS COVERS ASSEMBLY SECTION 11 PAGE 186 1
173 AF0 010 0526 SCREW, HEXAGON HEAD, FULL THREAD M10x25 6
202 AF0 010 0735 SCREW, HEXAGON HEAD, FULL THREAD M12x25 14

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 007 787 87 bB NSS
185 (209) COVERS ASSEMBLY / UPPER AND SIDE COVERS 211001

12 205 511 564

17 46 158 506 573

14 172 563

564 511 205 8

7 207 511 564

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 007 787 87 bB NSS
211001 COVERS ASSEMBLY / UPPER AND SIDE COVERS 186 (209)

Ref. Part no. Description EN Standard designation Qty

e
7 551 769 12 DOOR SECTION 11 PAGE 200 1
8 551 769 16 DOOR ASSEMBLY SECTION 11 PAGE 201 1
12 552 076 92 DOOR SECTION 11 PAGE 206 1
14 552 076 94 NSS PLATE, COVER SECTION 11 PAGE 208 1
17 552 070 86 BAR Lifting bar for Rear coverplate 2
. . . . .

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 007 787 87 bB NSS
187 (209) COVERS ASSEMBLY / UPPER AND SIDE COVERS 211001

564 511 205 13 17 46 158 506 573

563 172 15

564 511 207 9 10 205 511 564

551 506 156

47 45

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 007 787 87 bB NSS
211001 COVERS ASSEMBLY / UPPER AND SIDE COVERS 188 (209)

Ref. Part no. Description EN Standard designation Qty

e
9 552 215 21 DOOR ASSEMBLY SECTION 11 PAGE 204 1
10 551 769 26 DOOR ASSEMBLY SECTION 11 PAGE 205 1
13 552 076 96 DOOR SECTION 11 PAGE 207 1
15 552 076 98 NSS PLATE, COVER SECTION 11 PAGE 209 1
17 552 070 86 BAR Lifting bar for Rear coverplate 2
. . . . .

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 007 787 87 bB NSS
189 (209) COVERS ASSEMBLY / UPPER AND SIDE COVERS 211001

551 506 156 47 45 563 551 506 173 564 563 202 171 4

564 202 6

C C

5 205 45 16 45
2 3 1
202 511 47 202 47
202 202 202
564 564 156 564 156
564 205 564
506 506 564
551 551

158

573

46

573

506

SECTION C-C
17

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 007 787 87 bB NSS
211001 COVERS ASSEMBLY / UPPER AND SIDE COVERS 190 (209)

Ref. Part no. Description EN Standard designation Qty

e
1 551 729 04 PLATE, COVER SECTION 11 PAGE 191 1
2 551 767 79 PLATE, COVER SECTION 11 PAGE 192 1
3 BG 002 924 46 PLATE, COVER SECTION 11 PAGE 194 1
5 552 199 69 NSS PLATE, COVER SECTION 11 PAGE 196 1
6 BG 004 485 08 PLATE, COVER SECTION 11 PAGE 197 1
. . . . .
16 551 794 17 PLATE, COVER Water pump 1
17 552 070 86 BAR Lifting bar for Rear coverplate 2

Sandvik Mining and Construction Oy Drills Tampere © 2021

 551 729 04 cC
191 (209) PLATE, COVER / HYDRAULIC OIL RECEIVER 211001

3 10 11

12 4

15 5
14 13

2 6 4 6 1

Ref. Part no. Description EN Standard designation Qty

e
3 552 019 17 LATCH Covers assembly 1
4 851 620 09 DAMPER 40x20 4
5 550 898 55 THRUST For door latch 1
6 550 450 23 HINGE 2
10 800 192 49 HEXAGON HEAD SCREW M10x30 1
. . . . .
11 812 622 69 NUT, LOCK M10 m8 1
12 800 820 19 NUT, HEXAGON M10 m8 4
13 800 824 29 HEXAGON HEAD SCREW M12x25 2
14 550 130 59 WASHER, LOCK, DOUBLE M12 2
15 447 765 00 SLOTTED COUNTERSUNK FLAT HEAD M5X12 m5.8 2
SCREW
. . . . .

Sandvik Mining and Construction Oy Drills Tampere © 2021

 551 767 79 aA
211001 PLATE, COVER / ENGINE 192 (209)

11 10 2

Ref. Part no. Description EN Standard designation Qty

e
1 551 767 78 PLATE Engine coverplate 1
2 551 706 95 HINGE Incl. Perforated hinge and grease nipple 2
10 AF0 010 0735 SCREW, HEXAGON HEAD, FULL THREAD M12x25 2
11 AF0 300 0122 WASHER, LOCK, PAIR NL12-sp 2

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 002 924 46 bB
193 (209) PLATE, COVER / FRONT COVERPLATE, RIGHT 211001

9 144 506 562

4 4 144 506 562 5 144 506 562 4 144 506 562

8 144 506 562

10

3 144 506 562

144 506 562 2 7 173 509 563 6 60 504 572

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 002 924 46 bB
211001 PLATE, COVER / FRONT COVERPLATE, RIGHT 194 (209)

Ref. Part no. Description EN Standard designation Qty

e
1 BG 012 417 03 PLATE, COVER Front coverplate welding, right 1
2 BG 012 417 05 PLATE, COVER Front coverplate welding, right 1
3 551 846 67 STIFFENER Front coverplate 1
4 552 201 27 STIFFENER Front coverplate 2
5 BG 002 924 51 STIFFENER Front coverplate 2
. . . . .
6 551 725 04 LATCH 1
7 551 819 74 HANDLE 1
8 551 828 43 SUPPORT Front cover 1
9 BG 012 229 04 GRID, SAFETY Grid, Safety 1
10 551 853 87 NSS MOUNTING SECTION 11 PAGE 195 1
. . . . .
60 551 814 28 SCREW M6x20, Socket head 4
144 AF0 010 0322 SCREW, HEXAGON HEAD, FULL THREAD M8x20 30
173 AF0 010 0526 SCREW, HEXAGON HEAD, FULL THREAD M10x25 2
504 AF0 190 0055 NUT, HEXAGON, PREVAILING TORQUE M6 4
506 AF0 190 0004 NUT, HEXAGON, PREVAILING TORQUE M8 30
. . . . .
509 AF0 200 0005 NUT, HEXAGON, PREVAILING TORQUE, ALL M10 2
METAL
562 AF0 300 0120 WASHER, LOCK, PAIR NL8-sp 60
563 AF0 300 0121 WASHER, LOCK, PAIR NL10-sp 4
572 AF0 230 0029 WASHER, PLAIN, NORMAL M6 4

Sandvik Mining and Construction Oy Drills Tampere © 2021

 551 853 87 bB NSS
195 (209) MOUNTING / ROPE, COVERS 211001

62 130 572

61

Ref. Part no. Description EN Standard designation Qty

e
61 550 739 76 ROPE 1.7
62 811 696 29 CLAMP, BLOCK, COMPLETE Single, D 16 mm 1
130 800 681 49 HEXAGON HEAD BOLT M6X45 - 8.8 2
572 421 165 20 WASHER 6,4 2

Sandvik Mining and Construction Oy Drills Tampere © 2021

 552 199 69 bB NSS
211001 PLATE, COVER / REAR COVERPLATE ASSEMBLY, RIGHT 196 (209)

506 551 144 3 202 553

7 510

Ref. Part no. Description EN Standard designation Qty

e
2 551 818 75 SUPPORT Cover plate, rear 1
3 551 792 29 HINGE L=100 with grease nipple 2
3.1 572 106 50 NIPPLE, GREASE CR 1/8 1
7 851 620 09 DAMPER 40x20 4
144 808 802 29 HEXAGON HEAD SCREW M8X20 m8.8 3
. . . . .
202 800 824 29 HEXAGON HEAD SCREW M12x25 4
506 801 779 99 NUT, LOCK M8 3
510 800 820 19 NUT, HEXAGON M10 m8 4
551 AF0 300 0030 WASHER, LOCK, PAIR NL8 6
553 AF0 300 0032 WASHER, LOCK, PAIR NL12 4
. . . . .

Sandvik Mining and Construction Oy Drills Tampere © 2021

 BG 004 485 08 bB
197 (209) PLATE, COVER / REAR COVERPLATE ASSEMBLY, LEFT 211001

3 202 564 144 506 562 1

Ref. Part no. Description EN Standard designation Qty

e
1 BG 004 485 10 PLATE, COVER Rear coverplate welding, left 1
2 BG 004 485 13 SUPPORT Cover plate, rear 1
3 551 792 29 HINGE L=100 with grease nipple 2
3.1 572 106 50 NIPPLE, GREASE CR 1/8 1
144 AF0 010 0322 SCREW, HEXAGON HEAD, FULL THREAD M8x20 3
. . . . .
202 AF0 010 0735 SCREW, HEXAGON HEAD, FULL THREAD M12x25 4
506 AF0 190 0004 NUT, HEXAGON, PREVAILING TORQUE M8 3
562 AF0 300 0120 WASHER, LOCK, PAIR NL8-sp 6
564 AF0 300 0122 WASHER, LOCK, PAIR NL12-sp 4

Sandvik Mining and Construction Oy Drills Tampere © 2021

 551 769 12 bB
199 (209) DOOR / REAR DOOR, RIGHT 211001

10

11
4
12
16

17

18

7 19

13 1

14
15

Sandvik Mining and Construction Oy Drills Tampere © 2021

 551 769 12 bB
211001 DOOR / REAR DOOR, RIGHT 200 (209)

Ref. Part no. Description EN Standard designation Qty

e
1 551 769 13 DOOR Rear door welding, right 1
2 551 769 15 HOLEPLATE Rear door, right 1
3 551 814 89 STIFFENER Rear door 1
4 551 725 04 LATCH 1
5 551 727 82 HINGE L=100 with grease nipple 2
. . . . .
6 551 814 87 STIFFENER Rear door, left 1
7 851 620 09 DAMPER 40x20 2
10 802 309 29 HEXAGON HEAD SCREW M8X18 3
11 421 168 00 WASHER 8,4 6
12 801 779 99 NUT, LOCK M8 3
. . . . .
13 442 776 90 HEXAGON HEAD SCREW M12x35 10
14 550 130 59 WASHER, LOCK, DOUBLE M12 20
15 412 113 00 NUT, LOCK M12 - 8, Zn 10
16 551 814 28 SCREW M6x20, Socket head 4
17 551 825 92 WASHER M6, A4 4
. . . . .
18 550 981 23 NUT, LOCK M6 4
19 800 820 19 NUT, HEXAGON M10 m8 2

Sandvik Mining and Construction Oy Drills Tampere © 2021

 551 769 16 bB
201 (209) DOOR ASSEMBLY / REAR DOOR ASSEMBLY, RIGHT 211001

4 7 19 20 21

8 9 20 21 22

13 14 15
12 11 10

18 17 16 5

3 2 1

Ref. Part no. Description EN Standard designation Qty

e
3 551 814 87 STIFFENER Rear door, left 1
5 551 725 04 LATCH 1
6 551 727 82 HINGE L=100 with grease nipple 2
7 550 898 55 THRUST For door latch 1
8 857 450 39 FASTENING LOOP 1
. . . . .
9 550 131 26 PIN HD Polythene/Black 1
10 802 309 29 HEXAGON HEAD SCREW M8X18 5
11 421 168 00 WASHER 8,4 10
12 801 779 99 NUT, LOCK M8 5
13 551 814 28 SCREW M6x20, Socket head 4
. . . . .
14 551 825 92 WASHER M6, A4 4
15 550 981 23 NUT, LOCK M6 4
16 442 776 90 HEXAGON HEAD SCREW M12x35 6
17 550 130 59 WASHER, LOCK, DOUBLE M12 12
18 412 113 00 NUT, LOCK M12 - 8, Zn 6
. . . . .
19 447 765 00 SLOTTED COUNTERSUNK FLAT HEAD M5X12 m5.8 2
SCREW
20 421 156 40 WASHER 5,3 4
21 806 221 39 NUT, LOCK M5 m8 3
22 800 456 09 HEXAGON HEAD SCREW M5X30 - 8.8 1

Sandvik Mining and Construction Oy Drills Tampere © 2021

 552 215 21 aA
203 (209) DOOR ASSEMBLY / REAR DOOR, LEFT 211001

8 9 145 573 506

10 9 145 573 506

18 143 573 506

6 2
7

143
3
573
205
506
564
510
511

205

564 143

511 573 5
506

PART 18 GLUED TO PART 2

WITH SIKAFLEX 3131 OR 3141 1

Sandvik Mining and Construction Oy Drills Tampere © 2021

 552 215 21 aA
211001 DOOR ASSEMBLY / REAR DOOR, LEFT 204 (209)

Ref. Part no. Description EN Standard designation Qty

e
2 552 215 23 HOLEPLATE Rear door, left 1
3 551 814 89 STIFFENER Rear door 1
4 552 215 25 STIFFENER with latch mounting, Rear door, left 1
5 551 727 82 HINGE L=100 with grease nipple 2
6 851 620 09 DAMPER 40x20 1
. . . . .
7 BG 002 387 24 BRACKET Damper 1
8 552 215 26 PLATE Rear door 1
9 552 215 27 COVER, PLASTIC Rear door 2
10 552 215 38 PLATE Stiffener 1
18 552 215 37 PLATE Stiffener 1
. . . . .
143 802 309 29 HEXAGON HEAD SCREW M8X18 8
145 800 916 09 HEXAGON HEAD SCREW M8x25 6
205 442 776 90 HEXAGON HEAD SCREW M12x35 10
506 801 779 99 NUT, LOCK M8 14
510 800 820 19 NUT, HEXAGON M10 m8 1
. . . . .
511 412 113 00 NUT, LOCK M12 - 8, Zn 10
564 550 130 59 WASHER, LOCK, DOUBLE M12 20
573 421 168 00 WASHER 8,4 28

Sandvik Mining and Construction Oy Drills Tampere © 2021

 551 769 26 cC
205 (209) DOOR ASSEMBLY / REAR DOOR ASSEMBLY, LEFT 211001

22

28 21
6 9 10 11 12 19 23 24 27 11 12
26 20

25 7

22 12
21 11
10
13

14 16

15 17
18
4
5
10

11
12

Ref. Part no. Description EN Standard designation Qty

e
4 551 725 04 LATCH 1
5 551 727 82 HINGE L=100 with grease nipple 2
6 851 620 09 DAMPER 40x20 1
7 550 898 55 THRUST For door latch 1
9 BG 002 387 24 BRACKET Damper 1
. . . . .
10 802 309 29 HEXAGON HEAD SCREW M8X18 9
11 AF0 230 0005 WASHER, PLAIN, NORMAL M8 22
12 801 779 99 NUT, LOCK M8 11
13 551 814 28 SCREW M6x20, Socket head 4
14 AF0 230 0029 WASHER, PLAIN, NORMAL M6 4
. . . . .
15 550 981 23 NUT, LOCK M6 4
16 AF0 010 0737 SCREW, HEXAGON HEAD, FULL THREAD M12x35 6
17 AF0 300 0122 WASHER, LOCK, PAIR NL12-sp 12
18 412 113 00 NUT, LOCK M12 - 8, Zn 6
19 AF0 140 0006 NUT, HEXAGON M10 1
. . . . .
20 447 765 00 SLOTTED COUNTERSUNK FLAT HEAD M5X12 m5.8 2
SCREW
21 AF0 230 0003 WASHER, PLAIN, NORMAL M5 4
22 806 221 39 NUT, LOCK M5 m8 3
23 551 907 11 PLATE Rear door 1
24 551 907 13 COVER, PLASTIC Rear door 1
. . . . .
25 857 450 39 FASTENING LOOP 1
26 550 131 26 PIN HD Polythene/Black 1
27 AF0 010 0324 SCREW, HEXAGON HEAD, FULL THREAD M8x25 2
28 AF0 010 0069 SCREW, HEXAGON HEAD, FULL THREAD M5x30 1

Sandvik Mining and Construction Oy Drills Tampere © 2021

 552 076 92
211001 DOOR / POWER PACK, RIGHT 206 (209)

3
2
10
13
11
14
12
15

Ref. Part no. Description EN Standard designation Qty

e
1 552 076 93 PLATE Door, power pack, right 1
2 551 706 95 HINGE Incl. Perforated hinge and grease nipple 2
3 551 725 04 LATCH 1
10 551 814 28 SCREW M6x20, Socket head 4
11 551 825 92 WASHER M6, A4 4
. . . . .
12 550 981 23 NUT, LOCK M6 4
13 442 776 90 HEXAGON HEAD SCREW M12x35 2
14 550 130 59 WASHER, LOCK, DOUBLE M12 4
15 412 113 00 NUT, LOCK M12 - 8, Zn 2

Sandvik Mining and Construction Oy Drills Tampere © 2021

 552 076 96
207 (209) DOOR / POWER PACK, LEFT 211001

2 3

13 10

14 11

15 12

Ref. Part no. Description EN Standard designation Qty

e
1 552 076 97 PLATE Door, power pack, left 1
2 551 706 95 HINGE Incl. Perforated hinge and grease nipple 2
3 551 725 04 LATCH 1
10 551 814 28 SCREW M6x20, Socket head 4
11 551 825 92 WASHER M6, A4 4
. . . . .
12 550 981 23 NUT, LOCK M6 4
13 442 776 90 HEXAGON HEAD SCREW M12x35 2
14 550 130 59 WASHER, LOCK, DOUBLE M12 4
15 412 113 00 NUT, LOCK M12 - 8, Zn 2

Sandvik Mining and Construction Oy Drills Tampere © 2021

 552 076 94 cC NSS
211001 PLATE, COVER / POWER PACK COVER + THRUST, RIGHT 208 (209)

10
3 14
11
12

Ref. Part no. Description EN Standard designation Qty

e
1 552 076 95 PLATE, COVER Power pack, right 1
2 551 706 80 THRUST Lock, door 1
3 851 620 09 DAMPER 40x20 3
10 AF0 010 0324 SCREW, HEXAGON HEAD, FULL THREAD M8x25 2
11 AF0 230 0005 WASHER, PLAIN, NORMAL M8 4
. . . . .
12 AF0 190 0004 NUT, HEXAGON, PREVAILING TORQUE M8 2
14 AF0 140 0006 NUT, HEXAGON M10 3

Sandvik Mining and Construction Oy Drills Tampere © 2021

 552 076 98 bB NSS
209 (209) PLATE, COVER / POWER PACK COVER + THRUST, LEFT 211001

12

11

1 10

14 3

Ref. Part no. Description EN Standard designation Qty

e
1 552 076 99 PLATE, COVER Power pack, left 1
2 551 706 80 THRUST Lock, door 1
3 851 620 09 DAMPER 40x20 3
10 800 916 09 HEXAGON HEAD SCREW M8x25 2
11 421 168 00 WASHER 8,4 4
. . . . .
12 801 779 99 NUT, LOCK M8 2
14 800 820 19 NUT, HEXAGON M10 m8 3

Sandvik Mining and Construction Oy Drills Tampere © 2021
