Cabin Module

CABIN MODULE
112A22211-1
TABLE OF CONTENTS Sandvik DL421 -7C 170410
13. CABIN MODULE

* 552 178 70 CABIN MODULE............................................................................................................................................................. 2
** 551 653 62 NSS SCREW KIT......................................................................................................................................................... 7
** 551 803 78 CABIN........................................................................................................................................................................... 8
*** 550 520 17 NSS WINDOW KIT.................................................................................................................................................. 9
*** 552 012 29 DOOR ASSEMBLY.................................................................................................................................................. 12
*** 552 012 30 DOOR ASSEMBLY.................................................................................................................................................. 14
*** 550 608 32 WASHING EQUIPMENT KIT................................................................................................................................... 15
**** 550 524 00 WIPER.................................................................................................................................................................. 16
**** 550 524 01 WIPER.................................................................................................................................................................. 17
**** 550 524 02 WIPER.................................................................................................................................................................. 18
**** 550 523 99 WIPER.................................................................................................................................................................. 19
**** 550 608 43 NSS WASHING EQUIPMENT KIT....................................................................................................................... 22
*** 551 712 60 NSS AIR CONDITIONING, CABIN.......................................................................................................................... 23
**** 550 517 38 FILTER UNIT........................................................................................................................................................ 24
*** 552 012 17 INSULATION AND LINING...................................................................................................................................... 26
*** 552 012 36 UPHOLSTERY KIT.................................................................................................................................................. 27
*** 552 012 37 NSS ELECTRICS KIT.............................................................................................................................................. 28
**** 551 514 60 PANEL, INSTRUMENT........................................................................................................................................ 29
**** 551 514 61 WIRING KIT......................................................................................................................................................... 32
**** 551 514 65 ENCLOSURE....................................................................................................................................................... 34
**** 551 514 66 TERMINAL BOX................................................................................................................................................... 35
** 551 668 98 HEATER, CABIN.......................................................................................................................................................... 38
** 550 394 34 PEDAL, THROTTLE..................................................................................................................................................... 39
** 551 996 57 NSS BRAKE PEDAL.................................................................................................................................................... 42
*** 551 972 08 VALVE, BRAKE........................................................................................................................................................ 43
** 551 609 97 NSS GAUGE ASSEMBLY........................................................................................................................................... 44
** 551 644 01 NSS STEERING UNIT................................................................................................................................................. 46
*** 550 515 63 NSS ASSEMBLY...................................................................................................................................................... 47
*** 551 644 14 ASSEMBLY.............................................................................................................................................................. 48
** 550 099 25 NSS SUPPORTING BLOCK ASSEMBLY................................................................................................................... 49
** 321 561 11 NSS GAUGE ASSEMBLY........................................................................................................................................... 50
** 550 150 58 MESH, SAFETY........................................................................................................................................................... 52
** 551 567 63 BRACKET, LAMP......................................................................................................................................................... 53
** 550 767 15 NSS PEDESTAL.......................................................................................................................................................... 56
** 551 537 43 LIGHT........................................................................................................................................................................... 57
** 551 735 33 NSS MOUNTING......................................................................................................................................................... 58
** 552 127 75 NSS MOUNTING......................................................................................................................................................... 59
** 551 726 10 NSS ALARM LIGHT, MOUNTING............................................................................................................................... 61
*** 551 794 35 BEACON ASSEMBLY.............................................................................................................................................. 62
** 551 801 74 MOUNTING, LAMP...................................................................................................................................................... 63
** 552 127 05 MOUNTING.................................................................................................................................................................. 66
** 552 127 06 MOUNTING, LAMP...................................................................................................................................................... 70
** 551 510 25 NSS MOUNTING......................................................................................................................................................... 72
** 550 854 49 MOUNTING.................................................................................................................................................................. 74
Sandvik Mining and Construction Oy Drills Tampere © 2017

552 178 70 dC
1 (75) CABIN MODULE 170410
29
701
703 73 74 21 122 26
111
552 173 18
553 205 72
71 205 553
174 510 552
60 50 66 204 553
552 561 708

553 204 65
60 77 145
174 506 510
572 123 5 6 123 572 62

552 178 70 dC
170410 CABIN MODULE 2 (75)
Ref. Part no. Description EN Standard designation Qty

e
1 551 803 78 CABIN SECTION 13 PAGE 8 1
7 550 394 34 PEDAL, THROTTLE SECTION 13 PAGE 39 1
8 551 996 57 NSS BRAKE PEDAL SECTION 13 PAGE 42 1
14 550 128 97 HANDLE 2
20 551 672 20 BRACKET Emergency stop 2
. . . . .
24 550 150 58 MESH, SAFETY SECTION 13 PAGE 52 1
30 551 720 49 BRACKET Alarm light 1
60 551 537 43 LIGHT SECTION 13 PAGE 57 6

552 178 70 dC
552 173 30
205 82 24 60
553 518 264 144
555 507
561
710
553 205 87 20 555 260 88 14 171 552 75 124 572
709
144 7 144 8 20
551 507 551 507

552 178 70 dC

e
2 551 668 98 HEATER, CABIN SECTION 13 PAGE 38 1
10 550 128 48 PLATE 1
11 551 860 76 CABLE ENTRY PLATE Cabin front 1
12 551 736 12 CABLE ENTRY PLATE Cabin front 1
15 550 429 80 NSS BRACKET Driving panel 1
. . . . .
16 551 609 97 NSS GAUGE ASSEMBLY SECTION 13 PAGE 44 1
17 551 669 97 HOUSING, INSTRUMENT Left, Cabin 1
19 550 099 25 NSS SUPPORTING BLOCK ASSEMBLY SECTION 13 PAGE 49 1
34 550 149 19 HOUSING 1
52 550 060 77 SEAT 1
. . . . .
53 550 767 15 NSS PEDESTAL SECTION 13 PAGE 56 1
54 550 128 45 ARMREST Left 1
57 550 131 34 ARMREST Right 1
61 550 532 27 NSS PLATE, BULKHEAD 1
63 819 174 99 SOCKET 1
. . . . .
80 550 456 39 NSS PROTECTOR, CABLE ENTRY 1
85 550 546 01 PROTECTIVE HOSE 1
86 550 556 31 BRACKET Glass holder 1
89 550 757 28 PLATE, LINING Cabin 1
*55 550 128 42 PAD Left 1
. . . . .
*56 550 128 43 PAD Right 1

552 178 70 dC
507 145 2
551 610
709
61
122
550 82 174 552 17 11 12 89
86
19 263
555
64 110 112 571
99 10
63 110 571
34
562 172 85 80
52 16
552 173 31 15

552 178 70 dC

e
5 550 120 50 PLATE, MOUNTING Right, Control panel 1
6 550 120 49 PLATE, MOUNTING Left, Control panel 1
18 551 644 01 NSS STEERING UNIT SECTION 13 PAGE 46 1
21 321 561 11 NSS GAUGE ASSEMBLY SECTION 13 PAGE 50 2
50 551 567 63 BRACKET, LAMP SECTION 13 PAGE 53 4
. . . . .
62 550 595 30 PLATE 1
71 551 650 27 BRACKET, LAMP Left 1
72 551 650 26 BRACKET, LAMP Right 1
76 551 612 06 BRACKET, LAMP 2
. . . . .

551 653 62 a NSS
7 (75) SCREW KIT / CABIN ASSEMBLY 170410

e
81 801 450 49 HEXAGON HEAD TAPPING SCREW M4,8x19 4
110 284 330 90 HEXAGON HEAD SCREW M5X10 2
112 800 954 89 HEXAGON HEAD SCREW M5x16-8.8 2
. . . . .
145 800 916 09 HEXAGON HEAD SCREW M8x25 10
. . . . .
264 442 218 50 HEXAGON HEAD SCREW M16X40 - 8.8 4
507 800 917 29 NUT, HEXAGON M8 10
. . . . .
510 800 820 19 NUT, HEXAGON M10 16
518 811 259 69 NUT, LOCK M16 - 8 4
551 851 281 89 WASHER, LOCK, DOUBLE M8 24
552 851 282 09 WASHER, LOCK, DOUBLEC M10 44
. . . . .
561 550 160 42 WASHER, LOCK, DOUBLE M8 sp 4
571 421 156 40 WASHER 5,3 2
572 421 165 20 WASHER 6,4 4
. . . . .
610 852 243 09 STUD M8X25 - 8.8 1
850 446 805 60 SLOTTED PAN HEAD SCREW M4x10 - 5.8 3

551 803 78
170410 CABIN / WITHOUT A/C-UNIT 8 (75)

e
*1 552 012 28 FRAME, CABIN 1
*2 550 520 17 NSS WINDOW KIT SECTION 13 PAGE 9 1
*3 552 012 29 DOOR ASSEMBLY SECTION 13 PAGE 12 1
*4 552 012 30 DOOR ASSEMBLY SECTION 13 PAGE 14 1
*5 550 608 32 WASHING EQUIPMENT KIT SECTION 13 PAGE 15 1
. . . . .
*6 551 712 60 NSS AIR CONDITIONING, CABIN SECTION 13 PAGE 23 1
*7 552 012 17 INSULATION AND LINING SECTION 13 PAGE 26 1
*8 552 012 36 UPHOLSTERY KIT SECTION 13 PAGE 27 1
*9 552 012 37 NSS ELECTRICS KIT SECTION 13 PAGE 28 1
*10 551 888 93 SCREW KIT Rivet nut kit 1
. . . . .

550 520 17 c NSS
9 (75) WINDOW KIT 170410
17
12 3 17
5 10
16
17
13 2 8
4
14
15
18
11
13
1 6
2
9 16
16
7
5
17

e
*1 550 148 84 WINDOW, FRONT 1
*2 550 148 85 WINDOW, FRONT 2
*3 550 520 26 WINDOW 1
*4 550 520 30 WINDOW 1
*5 550 520 45 WINDOW 2
. . . . .
*6 550 520 46 FRAME, WINDOW 1
*7 550 148 87 FRAME, WINDOW Outer frame, right 1
*8 550 148 88 FRAME, WINDOW Outer frame, left 1
*9 550 520 47 FRAME, WINDOW 1
*10 550 520 48 FRAME, WINDOW Outer frame door left 1
. . . . .
*11 550 520 49 FRAME, WINDOW 1
*12 550 520 50 FRAME, WINDOW 1
*13 886 218 39 SCREW M5x20 132
*14 550 520 69 SEAL BAND 4x8 L=20400 21
*15 550 520 71 SEAL MATERIAL 1
. . . . .
*16 551 540 18 FITTING PIECE for front and front side windows 6
*17 551 540 20 FITTING PIECE for door, side and rear windows 11
*18 550 520 69 SEAL BAND 4x8 L=20400 21

552 012 29
11 (75) DOOR ASSEMBLY / RIGHT, CABIN 170410
24 15 15 24
13 11
12
14 24
16 15
14 24
27 25
9 8
30
10
29
21 4
28 3
19
22 26
1 2 25
17 7
20
18
6
15
23 5
31

552 012 29
170410 DOOR ASSEMBLY / RIGHT, CABIN 12 (75)

e
1 550 522 04 LOCK door lock right 1
2 550 982 29 SCREW, CR, C-SUNK, FLAT HEAD M6x25, A4 2
3 550 981 23 NUT, LOCK M6 2
4 550 522 15 HANDLE Door handle 1
5 550 982 10 SCREW, CR, PAN HEAD M6x20, A4 9
. . . . .
6 550 522 21 LEVER Right 1
7 550 522 24 BAR 1
8 550 522 28 PIN Lock pin 1
9 550 522 50 GUARD Pin guard 1
10 550 522 52 BOSS, THREADED 1
. . . . .
11 551 588 88 SPRING, GAS 300N, L=650mm, S=250mm 1
12 886 528 29 JOINT, BALL M8 1
13 550 977 25 BRACKET For gas spring 1
14 550 982 18 HEXAGON HEAD SCREW M8X20, A4 3
15 550 980 99 NUT, LOCK M8 A4 4
. . . . .
16 550 522 63 BUFFER, RUBBER 1
17 552 012 31 PLATE, COVER Door, right - Cabin DL 1
18 552 012 32 HANDLE Door, right - Cabin DL 1
19 551 512 81 SEAL DL, L=3670 1
20 550 522 71 SEAL L=550 1
. . . . .
21 550 996 34 PLATE, COVER cover for lock of door 1
22 886 218 39 SCREW M5x20 2
23 551 769 24 WASHER M6 (A4) 9
24 551 825 10 WASHER M8, A4, black 5
25 551 825 11 WASHER M10, A4, black 3
. . . . .
26 551 825 21 HEXAGON HEAD SCREW M10X20, A4, black 2
27 551 825 16 HEXAGON SOCKET HEAD SCREW M10X25, A4, black 1
28 551 888 99 HANDLE 1
30 551 825 12 WASHER M12, A4 2
. . . . .

552 012 30
13 (75) DOOR ASSEMBLY / LEFT, CABIN 170410
24 15 11 15 24
13
12
24 14
24 14 30
15 16
25 27 29
8 9
28
10
4 21
23 5 3
26
22 19
25
2
1
17
20
7
18
15 5 23
31

552 012 30
170410 DOOR ASSEMBLY / LEFT, CABIN 14 (75)

e
1 550 522 03 LOCK door lock left 1
2 550 982 29 SCREW, CR, C-SUNK, FLAT HEAD M6x25, A4 2
3 550 981 23 NUT, LOCK M6 2
4 550 522 14 HANDLE Door handle left 1
5 550 982 10 SCREW, CR, PAN HEAD M6x20, A4 9
. . . . .
6 550 522 20 LEVER Left 1
7 550 522 24 BAR 1
8 550 522 28 PIN Lock pin 1
9 550 522 50 GUARD Pin guard 1
10 550 522 52 BOSS, THREADED 1
. . . . .
11 551 588 88 SPRING, GAS 300N, L=650mm, S=250mm 1
12 886 528 29 JOINT, BALL M8 1
13 550 977 25 BRACKET For gas spring 1
15 550 980 99 NUT, LOCK M8 A4 4
. . . . .
16 550 522 63 BUFFER, RUBBER 1
17 552 012 33 PLATE, COVER Door, left 1
18 552 012 34 HANDLE Door, left 1
19 551 512 81 SEAL DL, L=3670 1
20 550 522 71 SEAL L=550 1
. . . . .
21 550 608 45 PLATE, COVER For lock of door 1
22 886 218 39 SCREW M5x20 2
23 551 769 24 WASHER M6 (A4) 12
24 551 825 10 WASHER M8, A4, black 5
25 551 825 11 WASHER M10, A4, black 3
. . . . .
26 551 825 21 HEXAGON HEAD SCREW M10X20, A4, black 2
27 551 825 16 HEXAGON SOCKET HEAD SCREW M10X25, A4, black 1
28 552 012 35 HANDLE 1
30 551 825 12 WASHER M12, A4 2
. . . . .

550 608 32
15 (75) WASHING EQUIPMENT KIT 170410
10
11
9
3
11
10
5
7
8
11
11 6
10
10 1

e
*1 550 524 00 WIPER SECTION 13 PAGE 16 1
*5 550 608 43 NSS WASHING EQUIPMENT KIT SECTION 13 PAGE 22 1
. . . . .
*6 550 524 05 HOSE L=6500, Washing liquid hose windscreen 1
*7 550 524 06 HOSE Washing liquid hose, front side right, 1
L=7200
*8 550 524 07 HOSE Washing liquid hose, front side left, L=4700 1
*9 550 524 08 HOSE Washing liquid hose, rear window, L=5000 1
*10 550 524 13 SEAL, RUBBER Hose entry rubber 4
. . . . .
*11 550 524 15 VALVE, DIRECTIONAL 4

550 524 00 a
170410 WIPER / WINDSCREEN WIPER 16 (75)
1
4
1 3

e
*1 551 739 14 MOTOR, WIPER 1
*2 551 769 06 BUSHING 30/20-15 1
*3 551 769 07 BUSHING 24/16-15 1
*4 550 148 30 ARM Double arm L=700 1
*5 550 148 29 BLADE, WIPER L=700 1
. . . . .
*6 881 639 49 NOZZLE 1

550 524 01 a
17 (75) WIPER / FRONT SIDE WINDOW RIGHT 170410
1 7
1
6
1
3
4
5

e
*1 551 741 96 MOTOR, WIPER 1
*2 551 769 10 BUSHING 28/17-25 1
*3 551 769 11 BUSHING 12/9-25 2
*4 551 769 24 WASHER M6 (A4) 2
*5 443 074 50 HEX.BOLT M6X40 , A4 2
. . . . .
*6 550 524 64 ARM, WIPER Front side right 1
*7 550 148 33 BLADE, WIPER Headlight 1
*8 881 645 49 NOZZLE 1

550 524 02 a
170410 WIPER / FRONT SIDE WINDOW LEFT 18 (75)
5
8 1

e
*1 551 739 12 MOTOR, WIPER 1
*2 551 769 10 BUSHING 28/17-25 1
*3 551 769 11 BUSHING 12/9-25 2
*4 551 769 24 WASHER M6 (A4) 2
*5 443 074 50 HEX.BOLT M6X40 , A4 2
. . . . .
*6 550 524 65 ARM, WIPER Front side left 1
*7 550 148 33 BLADE, WIPER Headlight 1
*8 881 645 49 NOZZLE 1

550 523 99 a
19 (75) WIPER / REAR WINDOW 170410
2
1

e
*1 551 739 14 MOTOR, WIPER 1
*2 551 769 06 BUSHING 30/20-15 1
*3 551 769 07 BUSHING 24/16-15 1
*4 852 791 39 DOUBLE ARM 600mm 1
*5 550 148 29 BLADE, WIPER L=700 1
. . . . .
*6 881 639 49 NOZZLE 1

550 608 43 a NSS
21 (75) WASHING EQUIPMENT KIT 170410
13
8 10 12
12 11
12 10
4
3
14
15 17 16
1
1
18 1
2 10 12

550 608 43 a NSS
170410 WASHING EQUIPMENT KIT 22 (75)

e
*2 550 608 55 FIXING CLIP 1
*6 550 608 51 PUMP UNIT 2
*8 550 608 52 CAP, FILLING 1
*9 550 608 60 CLAMP 58-75 1
*10 443 203 10 HEXAGON HEAD SCREW M10X20 , A4 1
. . . . .
*11 411 763 00 NUT, HEXAGON M10, A4 1
*12 551 825 93 WASHER M10, A4 8
*13 447 094 00 SLOTTED SCREW M5X10 - 5.8 6
*14 550 608 61 CLAMP 44-56 1
*15 551 825 84 PLATE, COVER Pump unit 1
. . . . .
*16 551 825 91 HEXAGON HEAD SCREW M6X12, A4 3
*17 551 825 92 WASHER M6, A4 3
*18 551 825 85 SEAL L=260 1

551 712 60 NSS
23 (75) AIR CONDITIONING, CABIN / CABIN - STEEL, WITHOUT A/C-UNIT 170410
8
4 17 2 3
10
15
10
16
5 1
7
13 12
14
19
18
16 6 11

e
*1 550 517 38 FILTER UNIT SECTION 13 PAGE 24 1
*2 421 253 90 WASHER 8,4 4
*3 443 089 00 HEXAGON HEAD SCREW M8X20, A4 8
*5 550 523 48 SEAL L=1200 1
*7 550 523 75 CLAMP, HOSE 15-24 1
. . . . .
*8 550 523 78 HOSE Front, Ø65 L=2000 1
*9 550 523 79 HOSE Back, Ø65 L=800 1
*10 550 134 68 CLAMP D=58-75 4
*11 550 148 65 PIPE, LUBRICANT Air channel 1
*12 881 616 49 AIRNOZZLE 5
. . . . .
*14 550 523 50 NOZZLE Heating nozzle 1
*15 550 523 52 PLATE, COVER Cabin heater cover 1
*16 550 523 55 SCREW, CR, PAN HEAD M8x20-8.8, Black 8

550 517 38
170410 FILTER UNIT 24 (75)
2
3
4
5

e
*1 550 519 72 FRAME 1
*2 550 519 73 ELEMENT, FILTER 2
*3 550 519 74 PLATE, MOUNTING 1
*4 550 519 75 SEPARATOR, COARSE 1
*5 550 519 76 COVER 1
. . . . .

552 012 17
25 (75) INSULATION AND LINING 170410
13
12 10
20
11
7 9
8 4 18
15
16
16
14
17 2 5 19

552 012 17
170410 INSULATION AND LINING 26 (75)

e
1 551 657 68 CARPET Heavy Carpet, rear floor 1
2 552 012 18 CARPET Heavy carpet, middle floor 1
3 552 012 19 CARPET Heavy carpet, front floor 1
4 551 647 43 CARPET Carpet, rear floor 1
5 552 012 20 CARPET Middle floor 1
. . . . .
6 552 012 21 CARPET Front floor 1
7 551 657 80 UPHOLSTERY MATERIAL Upholstery plate, back wall, cabin 1
8 551 657 82 UPHOLSTERY MATERIAL Upholstery plate, side wall R 1
9 551 657 83 UPHOLSTERY MATERIAL Upholstery plate, side wall L 1
10 551 657 86 UPHOLSTERY MATERIAL Upholstery material, back wall 1
. . . . .
11 551 657 88 CARPET Heavy carpet, conditioning, lower 1
12 551 657 90 UPHOLSTERY MATERIAL Upholstery plate, roof, front 1
13 551 824 97 UPHOLSTERY MATERIAL Upholstery plate, roof, back 1
14 551 824 98 CARPET Heavy carpet, fore 1
15 551 824 99 UPHOLSTERY MATERIAL Upholstery plate, fore 1
. . . . .
16 551 659 99 UPHOLSTERY MATERIAL Upholstery plate, frontside 2
17 552 012 22 UPHOLSTERY MATERIAL Upholstery plate, door R 1
18 552 012 23 UPHOLSTERY MATERIAL Upholstery plate, door L 1
19 551 658 19 UPHOLSTERY MATERIAL Upholstery plate, trap door 1
20 551 658 24 CARPET Heavy carpet, conditioning channel 1
. . . . .
21 552 012 24 CARPET Heavy carpet, rear 1
22 552 012 25 CARPET Rear 1

552 012 36
27 (75) UPHOLSTERY KIT 170410
28
27
13
23
1
14
18
12
22
22
25 15
24
16
18 26
19
18 5 17
7
3 21
11
10 20
4
18
6 9
19 20
8 20

e
*1 550 608 62 PANEL, CEILING REAR 1
*2 550 608 63 PANEL, CEILING FRONT 1
*12 550 608 66 COVER, REAR 1
*14 550 608 65 CUP, BASE PLATE 2
*17 550 608 64 HOUSING 1
. . . . .

552 012 37 NSS
170410 ELECTRICS KIT 28 (75)
24
18 13
17 12
15 11
15
14
29
19
27 26 4
20 3
23
16
22
17
9
18
6 19 7 19
8 10
21 24
25
2 19
28 1
30 19

e
1 551 888 95 CABLE ENTRY PLATE Front part 1
2 550 104 98 CABLE ENTRY PLATE Front part 1
6 330 075 18 COVER Instrument panel 1
7 550 608 67 PANEL, INSTRUMENT 1
11 856 273 79 LIGHT 1
. . . . .
12 551 749 25 BULB 10 W Cabin S, Ceiling light 2
13 551 749 26 BULB 5W Cabin S, Ceiling light 1
14 551 749 30 LIGHT max 10W 'Spotlight', Cabin S 2
15 551 749 09 BULB 'Spotlight' Cabin S 2
26 551 514 60 PANEL, INSTRUMENT SECTION 13 PAGE 29 1
. . . . .
27 551 514 61 WIRING KIT SECTION 13 PAGE 32 1
28 551 514 63 CABLE SET 1
29 551 514 65 ENCLOSURE SECTION 13 PAGE 34 1
30 551 514 66 TERMINAL BOX SECTION 13 PAGE 35 1

551 514 60
29 (75) PANEL, INSTRUMENT / SW-PANEL 170410
15 1
8 7 13 14 9 10 8
SW -
X1
K 500
128A
210
209
208
207
206
204
203
127
126
125
124
123
122
121
120
119
118
117
116
115
114
113
112
111
107
106
106
106
106
106
105
104
103
103
103
103
102
101
101
19
18
17
16
15
14
13
12
11
10
24
23
22
21
20
1
9
8
7
6
5
4
3
2
128K
4 5 3 11 2
12

e
2 551 514 04 RELAY 0 335 320 019 24V 1
3 803 123 39 CONTACT RAIL 1
5 855 016 39 TERMINAL STRIP 64
6 816 240 59 SEPARATION PLATE 2
. . . . .
8 816 241 89 CLAMP, END E/NS 35N 2
9 806 768 09 BRIDGE, SWITCHING 3
14 856 471 79 ACCESSORIES, TERMINAL 1

551 514 61
31 (75) WIRING KIT 170410

551 514 61
170410 WIRING KIT 32 (75)

e
WIRE KIT 551 514 61 INCL. WIRE KIT 1-5 AND CABLES 1

551 514 65
33 (75) ENCLOSURE 170410
8
7
1 6 2 3 4
8
7
S500 S501 S502 S510
6
8
OP T I O N
7
S505 S503 S504 S5 11
6
8 5
7
15
OP T I O N OP T I O N OP T I O N
6 S507 SH506 S508 S512

14
OP T I O N OP T I O N OP T I O N OP T I O N
12
8
7 S524 S525 S520 S521 S522 S523
6 16
9 14
12
17 OP T I O N
12
10
13
12
11

551 514 65
170410 ENCLOSURE 34 (75)

e
1 550 056 91 LABEL, PANEL SW-panel 1
2 550 476 59 SWITCH, SELECTOR Stay/Stay/Return, NC + NO 2
3 550 475 53 SWITCH, SELECTOR Complete 1
4 550 614 50 HOUSING 1
5 550 476 62 PUSH BUTTON, ILLUMINATED with blue indicator light (complete) 1
. . . . .
6 888 111 39 PLUG 8
9 868 964 29 MOUNTING FRAME 1
11 856 750 09 SWITCH, ROCKER 1
12 867 078 99 BODY, SWITCH 6
13 880 672 89 LABEL, PANEL 1
. . . . .
14 872 670 19 SWITCH, ROCKER 4
15 855 967 59 LABEL, PANEL 1
16 882 383 59 LABEL, PANEL 3

551 514 66
35 (75) TERMINAL BOX 170410
8
13
JB26 5
JB23--X1 JB424--X1
X1 12
2 10
101
101
10
106
205
205
206
207
205
201
201
202
202
203
204
205
205
205
205
1
1
2
2
3
1 2 3
4
5
13
3 4 6 5 11 12
6
9
7
13

e
2 803 123 39 CONTACT RAIL 0.14
3 803 123 39 CONTACT RAIL 0.18
4 816 241 89 CLAMP, END E/NS 35N 3
5 806 768 09 BRIDGE, SWITCHING 2
. . . . .
7 885 567 29 GLAND, CABLE, SHIELDED 3
8 813 587 39 CAP, FILLING PK16 IP65 MsGL = 6,5 mm 4
9 817 862 09 TERMINAL, EARTHING 5
13 806 282 19 NUT, LOCKING, METALLIC PK16 , SSTL 17 405 16 7
. . . . .

551 668 98 a
37 (75) HEATER, CABIN / A/C + 230V ELECTRIC HEATING 170410
21 20 13 15 14 21 20
22
22
8 15 9 15 10 15 12 15
1
1.1
13
18
16
19
24
7 23

551 668 98 a
170410 HEATER, CABIN / A/C + 230V ELECTRIC HEATING 38 (75)

e
1 550 131 38 FAN 24 V 1
1.1 080 000 52 RESISTOR 1
2 550 131 42 CELL 1
3 550 131 45 RESISTOR Electric heat resistor 220V 3
4 550 131 51 CELL Vaporizer cell 1
. . . . .
5 550 131 53 FILTER 1
6 885 919 49 VALVE 1
7 551 597 56 VALVE 24 V 1
8 857 030 09 THERMOSTAT 1
9 550 131 59 ADJUSTER 1
. . . . .
10 551 713 32 ADJUSTER 1
12 883 379 19 SWITCH 1
13 550 131 97 SWITCH, CONTROL AND LOAD 2
14 882 386 39 SWITCH 2 1
15 550 131 89 KNOB 5
. . . . .
16 551 597 58 TERMINAL BOX 1
18 550 184 93 HOUSING 1
19 550 184 90 COVER 1
20 550 131 70 NOZZLE 4
21 881 724 29 AIR HOSE FITTING D=63mm 2
. . . . .
22 551 668 96 HOUSING 1
23 551 768 96 BRACKET Water valve 1
24 551 768 97 CONNECTOR Water valve 20/16 1

550 394 34 aA
39 (75) PEDAL, THROTTLE 170410
29
19
21 13 7 18
1 REPAIR KIT (INCL. PARTS 19, 21)
2 AXLES SET (INCL. PART 18)
3 SENSOR ASSEMBLY (INCL. PARTS 6, 7 ,13, 29)

e
1 550 613 74 WHEEL Repair kit (incl. parts 19,21) 1
2 550 613 86 AXLES SET Treadle pin kit (incl. parts 18) 1
3 550 613 87 SENSOR ASSEMBLY Sensor kit (incl. parts 6,7,13,29) 1

551 996 57 F NSS
41 (75) BRAKE PEDAL / BRAKE PEDAL VALVE 170410
2 5
6
2 5 6
6 6
6
2
16 9
15
3 11
6
18
2
17
9
6 2 16 10
18
11 10 15
17
MF2
F2
F1
T MF1
A1
LS
A2
P
B3
8
S MS MA

551 996 57 F NSS
170410 BRAKE PEDAL / BRAKE PEDAL VALVE 42 (75)

e
1 551 972 08 VALVE, BRAKE SECTION 13 PAGE 43 1
2 550 404 93 STRAIGHT THREAD ADAPTER M14x1,5 / JIC 3/4-16 5
3 866 769 99 STRAIGHT THREAD ADAPTER JIC 9/16-18 1
4 817 180 79 ELBOW, SWIVEL NUT 9/16-18JIC 1
. . . . .
6 817 183 59 SWIVEL NUT ELBOW 90 JIC 3/4-16 7
9 817 163 39 ADAPTER, TEE 3/4-16 JIC 2
10 817 165 99 REDUCER, TUBE END 3/4X7/16JIC 2
11 818 001 09 NUT JIC 3/4-16 2
. . . . .
15 817 163 39 ADAPTER, TEE 3/4-16 JIC 2
17 853 780 09 REDUCER, TUBE END JIC 3/4-16 x JIC 9/16-18 2
18 818 001 09 NUT JIC 3/4-16 2

551 972 08 aA
43 (75) VALVE, BRAKE 170410
7430
7400
7575

e
7400 550 698 92 REPAIR KIT Mechanical repair kit 1
7430 550 698 90 COVER, RUBBER 1
7575 551 974 18 COVER, RUBBER Cover rubber for brake valve 1

551 609 97 a NSS
170410 GAUGE ASSEMBLY / RIGHT, PRESSURE GAUGES 44 (75)
12 17 16
600 600
10 4 1 23 13 21 11
WATER PRESSURE
SEARCH LIGHT CONTROLS
3 9 AIR PRESSURE

e
1 551 669 52 HOUSING, INSTRUMENT Cabin, Right 1
11 853 251 79 GAUGE, PRESSURE 25bar 1
12 868 731 69 CONNECTOR, PRESSURE GAUGE 1/4 1
13 850 719 69 GAUGE, PRESSURE 16 bar 1
16 133 435 08 ADAPTER, DAMPING R1/4-JIC 7/16-20UNF 1
. . . . .
21 390 051 58 SIGN Water pressure 1
23 550 873 19 SIGN Air pressure 1
600 455 332 90 SCREW 2X5 4

551 644 01 a NSS
45 (75) STEERING UNIT / ASSEMBLY 170410
5 6
11
744 572
224 512
8 3 574
572 744
10
7
172 552

551 644 01 a NSS
170410 STEERING UNIT / ASSEMBLY 46 (75)

e
1 550 461 26 SHIFTER, GEAR F-N-R Shifter 1
2 550 515 63 NSS ASSEMBLY SECTION 13 PAGE 47 1
3 550 579 28 HANDLE 1
4 550 727 31 PLATE, COVER 1
5 551 612 60 WHEEL, STEERING D=250 1
. . . . .
6 551 612 61 CENTER 1
7 551 644 14 ASSEMBLY SECTION 13 PAGE 48 1
8 551 645 68 FRAME Welding 1
9 551 647 24 HOUSING Welding 1
10 551 647 79 PLATE 1
. . . . .
11 551 647 80 PLATE 1
224 804 380 79 HEXAGON HEAD BOLT M12X130 m8.8 1
512 811 260 29 NUT, LOCK M12 1
. . . . .
572 421 165 20 WASHER 6,4 6
574 421 181 30 WASHER 10,5 1
744 445 768 60 HEX.SOCKET HEAD CAP SCR. M6X12 6

550 515 63 dD NSS
47 (75) ASSEMBLY / CONTROL ARM+ORBITROL 170410
8 5
4 6 9 552 510 615 1

e
1 550 433 81 ARM, CONTROL 1
2 614 814 69 VALVE, STEERING 1
2.1 615 095 23 SEAL KIT FOR STEERING VALVE 1
4 817 094 69 STRAIGHT THREAD ADAPTER G 1/2 x JIC 3/4-16 2
5 263 331 58 ADAPTER R1/2 in - 3/4 in -16 JIC, L=80 2
. . . . .
6 851 975 79 STRAIGHT THREAD ELBOW 7/16-20 JIC 1
9 807 180 49 USIT-SEAL 22,7X30X2 D2=24,4 2
510 AF0 140 0006 NUT, HEXAGON M10 4
552 AF0 300 0031 WASHER, LOCK, PAIR NL10 4
. . . . .
615 AF0 310 0170 STUD, DOUBLE END M10x25-8.8 Zn 4

551 644 14 bB
170410 ASSEMBLY / STEERING DEVICE, HORIZONTAL ADJUSTMENT 48 (75)
2
144 551
1
4
6 121 504
5 574
504 550 755

e
1 551 644 03 BRACKET, MOUNTING Welding assembly 1
2 551 644 10 BRACKET, MOUNTING Welding assembly 1
3 551 643 73 RAIL BEAM L=220 1
4 551 643 74 CARRIAGE 1
5 552 086 66 HANDLE 1
. . . . .
6 551 644 16 PLATE 1
121 AF0 010 0131 SCREW, HEXAGON HEAD, FULL THREAD M6x12 2
144 AF0 010 0322 SCREW, HEXAGON HEAD, FULL THREAD M8x20 4
504 AF0 190 0003 NUT, HEXAGON, PREVAILING TORQUE M6 4
. . . . .
574 AF0 230 0006 WASHER, PLAIN, NORMAL M10 1
755 AF0 050 0227 SCREW, SOCKET HEAD, HEXAGON M6x30-8.8 Zn 4

550 099 25 cF NSS
49 (75) SUPPORTING BLOCK ASSEMBLY / CONTROL PANEL 170410
7 6
155
507
551
4 2

e
1 550 904 99 BRACKET For control panel 1
2 550 104 32 GUIDE Control panel support 1
3 550 063 89 SCREW M12 1
4 880 671 59 STAR GRIPS R600xM12x50 plastic/steel screw 1
5 550 127 50 ADJUSTER Control panel support 1
. . . . .
6 850 557 99 WASHER D35/13x5 1
7 552 046 08 HANDLE 1
155 808 743 69 HEXAGON HEAD BOLT M8X60-8.8 2
507 800 917 29 NUT, HEXAGON M8 2
. . . . .

321 561 11 D NSS
170410 GAUGE ASSEMBLY / INCLINATION GAUGE 50 (75)

e
1 883 656 09 GAUGE Tilt gauge 1
2 208 429 78 PLATE 1
3 265 125 18 COVER 1

550 150 58 aC
51 (75) MESH, SAFETY 170410
10
25
15 20
SECTION A-A

550 150 58 aC
170410 MESH, SAFETY 52 (75)

e
1 550 150 59 MESH, SAFETY 1
2 265 556 88 WATER NOZZLE 1
3 550 107 92 CYLINDER, SPRING Gas spring 500N L=205/330mm 2
4 885 790 19 BUFFER, RUBBER M10, D=40, L=20 2
. . . . .
15 812 622 69 NUT, LOCK M10 m8 2
25 572 102 40 NIPPLE, GREASE AR 1/8 2

551 567 63
53 (75) BRACKET, LAMP / ADJUSTABLE BRACKET FOR HID LIGHT 170410
4 574 575 5 3 575 574 510
574

e
1 550 984 83 PLATE, MOUNTING 1
2 551 567 64 PLATE Light bracket 1
3 551 567 65 HOUSING HID light 1
4 550 433 67 HANDLE 2
5 551 567 61 SCREW M10X30 - 8.8 2
. . . . .
510 800 820 19 NUT, HEXAGON M10 2
574 421 181 30 WASHER 10,5 3
575 421 189 50 WASHER M13 2

550 767 15 eD NSS
55 (75) PEDESTAL / ROTATION SEAT 170410
6 15 22
26
24
9 5 1 14 4
745
23 10 8 19 30 31 25
11 3 17
21
20
12
32
16 SECTION A - A 2 13 18 7

550 767 15 eD NSS
170410 PEDESTAL / ROTATION SEAT 56 (75)

e
1 421 165 20 WASHER 6,4 6
2 421 168 00 WASHER 8,4 11
3 422 066 30 CIRCLIP 30X1,5 1
4 550 841 14 ARM 1
5 550 767 17 SHAFT ASSEMBLY 1
. . . . .
6 550 498 47 SHAFT ASSEMBLY 1
7 550 498 53 PLATE 1
8 550 498 54 HOUSING, BEARING 1
9 550 686 12 COVER, REAR Swing pedestal 1
10 550 498 56 HOUSING, BEARING 1
. . . . .
11 550 794 49 PULLEY, CHAIN 1
12 550 500 55 PULLEY, CHAIN 1
14 802 421 59 HEXAGON HEAD SCREW M6x16m8.8 6
15 812 622 69 NUT, LOCK M10 m8 1
. . . . .
16 872 415 49 ANGULAR BALL BEARING 1
17 818 959 19 BEARING, BALL, DEEP GROOVE D55 d30 L13 1
18 550 687 06 ANGULAR BALL BEARING D52 d25 B15 1
19 815 743 69 BEARING, BALL, DEEP GROOVE D62 d35 L14 1
20 550 687 05 SLEEVE, CLAMPING d=35, D42 1
. . . . .
21 065 681 07 SPRING-TYPE STRAIGHT PIN 8X40 1
22 550 827 08 LEVER 1
24 801 444 49 HEXAGON HEAD BOLT M10x75 - 8.8 1
25 550 543 76 PLATE 1
. . . . .
26 550 544 96 SPRING 1
30 422 072 30 CIRCLIP 35X1,5 1
31 422 272 90 CIRCLIP 62X2 1
32 801 491 09 CHAIN 08B-1 72
745 445 709 30 SCREW M6X12 - 12.9 2
. . . . .

551 537 43 e
57 (75) LIGHT / 24V, 35W, 120X120X120 170410

e
*1 551 787 63 LAMP ACCESSORY Cover lens 1
*2 550 409 63 BULB D1S 35W 1

551 735 33 a NSS
170410 MOUNTING / CD-PLAYER 58 (75)
26 27 850
26
26

e
26 550 071 77 RADIO Radio-CD Player 1
27 885 298 09 DC/DC CONVERTER 20-32V DC/12VDC 12A 1

552 127 75 f NSS
59 (75) MOUNTING / POWER OUTLET 12V AND 24V 170410
850
105 41 107 108
106 42 108

e
41 885 298 09 DC/DC CONVERTER 20-32V DC/12VDC 12A 1
42 888 121 49 SOCKET 1
105 552 114 06 DECAL Decal for 24V outlet cabin 1
106 552 061 79 DECAL Decal for 12V outlet cabin 1
107 551 678 47 SOCKET Socket 24V 16A 1
. . . . .
108 888 122 79 CONNECTOR, PLUG Plug 6-50V, 16A 2

551 726 10 dA NSS
61 (75) ALARM LIGHT, MOUNTING 170410
90
91
92
93

e
90 551 794 35 BEACON ASSEMBLY SECTION 13 PAGE 62 1
92 560 148 97 ACCESSORIES, CONNECTOR Stainless steel mounting clip 1
93 560 148 97 ACCESSORIES, CONNECTOR Stainless steel mounting clip 1
*91 807 525 39 BULB H1 24V 70W 1

551 794 35
170410 BEACON ASSEMBLY / HALOGEN BEACON AND CONNECTOR ASSY 62 (75)
2, 3, 4, 5

e
1 819 501 59 ALARM LIGHT ASSEMBLY 24V, 70W H1 1
2 855 484 59 SHRINK WRAP d=20, 0.7 m 0.5
3 886 820 99 CONNECTOR CONTACT Pin, Nickel 2
4 550 148 91 CONNECTOR 2-pole male 1
5 550 148 92 CONNECTOR ACCESSORIES Locking part 1
. . . . .

551 801 74
63 (75) MOUNTING, LAMP / EXTRA LIGHTS 170410
63 177
50 53 60
174 510 562
DETAIL A

e
50 551 567 63 BRACKET, LAMP SECTION 13 PAGE 53 2
53 550 150 01 CABLE ASSEMBLY SECTION 6 PAGE 30 2
63 551 801 75 BRACKET Extra lights 2
. . . . .
510 800 820 19 NUT, HEXAGON M10 8

552 127 05 A
65 (75) MOUNTING / 2X DATA LIGHTS 170410
552 173 30
60
205 82 24
144
553 518 264
507
555
561
20 14 171 552 75 124 572
144 7 144 8 20
551 507 551 507

552 127 05 A
170410 MOUNTING / 2X DATA LIGHTS 66 (75)

e
75 550 020 54 LAMP Stop/Tail/Park, 9/2/2W, 9-33V 2
572 421 165 20 WASHER 6,4 4

552 127 05 A
67 (75) MOUNTING / 2X DATA LIGHTS 170410
29
26 26
42
66 145 67 65 21 122
74 73
850 41 40 850 27 850
OPTION:
RELAY CONTROL BOX
552 173 18
553
205
72
553
205
71
552 60 50
510 174
ONLY DL420
76 552 561
204 60 77 145
62
553 174 506 510
572 123 5 6 123 572

552 127 05 A
170410 MOUNTING / 2X DATA LIGHTS 68 (75)

e
73 800 915 79 SLOTTED PAN HEAD SCREW M4X16 - 5.8 4
74 550 372 39 JUNCTION BOX ASSEMBLY SECTION 6 PAGE 72 1
572 421 165 20 WASHER 6,4 4

552 127 06 A
69 (75) MOUNTING, LAMP / DRIVING LIGHTS 170410
552 173 30
60
205 82 24
144
553 518 264
507
555
561
20 14 171 552 75 124 572
144 7 144 8 20
551 507 551 507

552 127 06 A
170410 MOUNTING, LAMP / DRIVING LIGHTS 70 (75)

e
77 551 607 24 BRACKET, LAMP N45 HID 2
506 801 779 99 NUT, LOCK M8 - 8 2
. . . . .
510 800 820 19 NUT, HEXAGON M10 8
561 550 160 42 WASHER, LOCK, DOUBLE M8 sp 4

551 510 25 aA NSS
71 (75) MOUNTING / DOCUMENT BOX ASSEMBLY A4 170410
144 3
A3-BOX MOUNTING
A4-BOX MOUNTING
205 511 553

551 510 25 aA NSS
170410 MOUNTING / DOCUMENT BOX ASSEMBLY A4 72 (75)

e
3 551 001 61 ENCLOSURE, DOCUMENTS 1

550 854 49 dA
73 (75) MOUNTING / DOCUMENT BOX ASSEMBLY 170410
144 3
A3-BOX MOUNTING
A4-BOX MOUNTING
205 511 553

550 854 49 dA
170410 MOUNTING / DOCUMENT BOX ASSEMBLY 74 (75)

e
1 550 852 38 ENCLOSURE, DOCUMENTS 1
2 550 854 52 BRACKET, MOUNTING 1
511 412 113 00 NUT, LOCK M12 - 8, Zn 2
. . . . .

Cabin Module

Uploaded by

Document Information

Original Title

Copyright

Available Formats

Share this document

Share or Embed Document

Sharing Options

Did you find this document useful?

Is this content inappropriate?

Copyright:

Available Formats

Cabin Module

Uploaded by

Copyright:

Available Formats

CABIN MODULE

13. CABIN MODULE

Sandvik Mining and Construction Oy Drills Tampere © 2017

552 561 708

Sandvik Mining and Construction Oy Drills Tampere © 2017

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2017

553 205 87 20 555 260 88 14 171 552 75 124 572

Sandvik Mining and Construction Oy Drills Tampere © 2017

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2017

64 110 112 571

Sandvik Mining and Construction Oy Drills Tampere © 2017

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2017

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2017

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2017

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2017

Sandvik Mining and Construction Oy Drills Tampere © 2017

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2017

Sandvik Mining and Construction Oy Drills Tampere © 2017

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2017

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2017

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2017

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2017

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2017

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2017

Sandvik Mining and Construction Oy Drills Tampere © 2017

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2017

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2017

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2017

Sandvik Mining and Construction Oy Drills Tampere © 2017

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2017

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2017

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2017

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2017

Sandvik Mining and Construction Oy Drills Tampere © 2017

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2017

6 S507 SH506 S508 S512

Sandvik Mining and Construction Oy Drills Tampere © 2017

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2017

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy Drills Tampere © 2017

Sandvik Mining and Construction Oy Drills Tampere © 2017
