Carrier

CARRIER
110D16028-1
TABLE OF CONTENTS Sandvik DD320-26X 101208
8. CARRIER
* 551 911 28 CARRIER MODULE........................................................................................................................................................ 2
** 550 274 36 SCREW SET, CONNECTION PARTS FOR CARRIER FRONT MODULE................................................................. 5
** 551 978 63 CONTROL SYSTEM.................................................................................................................................................... 8
*** 550 305 33 OPERATOR'S CONSOLE ASSEMBLY................................................................................................................... 10
**** 550 264 98 CONTROL BLOCK ASSEMBLY, FEED PRESSURE CONTROL BLOCK........................................................... 14
**** 550 015 57 ADAPTER ASSEMBLY........................................................................................................................................ 18
**** 550 016 71 DIRECTIONAL VALVE, ROTATION, PRESSURE, FEED................................................................................... 20
**** 550 010 16 DIRECTIONAL VALVE, FLUSHING AND RAPID MOVEMENT.......................................................................... 22
**** 550 276 53 CONTROL VALVE ASSEMBLY, BOOM.............................................................................................................. 24
***** 550 288 22 DIRECTIONAL VALVE..................................................................................................................................... 26
****** 882 591 69 LEVER.......................................................................................................................................................... 28
*** 550 519 67 VALVE ASSEMBLY, FIXED DISPLACEMENT PUMP............................................................................................. 30
**** 550 278 37 VALVE ASSEMBLY, CONTROL BLOCK OF DRILLING..................................................................................... 32
***** 868 479 39 PRESSURE RELIEF VALVE............................................................................................................................ 38
***** 887 360 09 VALVE ASSEMBLY.......................................................................................................................................... 40
****** 550 667 44 VALVE BODY, FEED DIRECTIONAL CONTROL VALVE........................................................................... 46
**** 550 064 91 CONTROL BLOCK ASSEMBLY, CONTROL BLOCK OF RETURN AUTOMATICS............................................ 48
***** 888 012 39 CONTROL BLOCK ASSEMBLY...................................................................................................................... 50
**** 550 278 43 CONTROL BLOCK ASSEMBLY.......................................................................................................................... 52
**** 550 486 01 CONTROL VALVE ASSEMBLY........................................................................................................................... 56
***** 550 485 56 DIRECTIONAL VALVE, ROTATION CONTROL VALVE................................................................................. 58
*** 550 429 85 CONTROL ASSEMBLY............................................................................................................................................ 66
**** 550 429 86 CONTROL ASSEMBLY, JB102........................................................................................................................... 68
***** 550 243 86 JUNCTION BOX ASSEMBLY.......................................................................................................................... 70
***** 550 260 59 CABLE ASSEMBLY......................................................................................................................................... 72
**** 550 429 87 ELECTRIC COMPONENT ASSEMBLY, JB93 AND JB94................................................................................... 74
***** 106 148 51 JUNCTION BOX, JB93.................................................................................................................................... 82
** 551 978 81 CONTROL SYSTEM, THC560 , INTEGRATED HYDRAULICS, FIXED PUMP, TTF, W............................................. 84
*** 550 275 55 OPERATOR'S CONSOLE ASSEMBLY, THC560.................................................................................................... 86
**** 550 275 54 CONTROL BLOCK ASSEMBLY, FEED PRESSURE CONTROL BLOCK, TTF.................................................. 90
**** 550 008 14 DIRECTIONAL VALVE, BOOM CONTROL VALVE............................................................................................. 94
*** 550 278 40 VALVE ASSEMBLY, SEP. PART LIST.................................................................................................................... 98
*** 550 269 55 HOSING, SEP. PART LIST..................................................................................................................................... 100
** 550 730 75 DRIVING PLATFORM ASSEMBLY............................................................................................................................. 102
*** 770 053 17 OPERATOR'S CONSOLE ASSEMBLY, CARRIER CONTROL PANEL.................................................................. 106
*** 550 268 23 OPERATOR'S CONSOLE ASSEMBLY................................................................................................................... 110
**** 777 506 60 STEERING SHAFT.............................................................................................................................................. 112
*** 550 852 23 ADAPTER ASSEMBLY, PRIORITY VALVE............................................................................................................ 114
*** 550 088 52 VALVE ASSEMBLY................................................................................................................................................. 116
**** 886 388 29 DIRECTIONAL VALVE......................................................................................................................................... 118
**** 887 417 79 DIRECTIONAL VALVE......................................................................................................................................... 120
*** 783 203 19 VALVE...................................................................................................................................................................... 122
*** 550 295 95 ADAPTER ASSEMBLY, PRESSURE RELIEF VALVE............................................................................................ 124
*** 550 949 94 ASSEMBLY, BRAKE VALVE ASSEMBLY............................................................................................................... 126
*** 777 607 10 ACCELERATOR PEDAL.......................................................................................................................................... 130
*** 550 294 78 ADAPTER ASSEMBLY, ACCELERATOR PEDAL.................................................................................................. 132
*** 777 607 14 PEDAL ASSEMBLY................................................................................................................................................. 134
*** 550 292 55 ADAPTER ASSEMBLY, BRAKE PEDAL................................................................................................................. 136
*** 550 836 49 CHECK VALVE ASSEMBLY.................................................................................................................................... 138
*** 550 595 28 SEAT ASSEMBLY.................................................................................................................................................... 140
*** 321 561 11 GAUGE ASSEMBLY................................................................................................................................................ 142
*** 321 561 16 GAUGE ASSEMBLY................................................................................................................................................ 144
** 550 233 05 SAFETY CANOPY ASSEMBLY................................................................................................................................... 146
*** 323 612 41 CYLINDER, D55 D32 LMIN1240 S850.................................................................................................................... 150
** 550 323 33 RETURN FILTER, TRANSMISSION OIL..................................................................................................................... 152
** 550 654 43 WATER SEPARATOR ASSEMBLY............................................................................................................................. 154
*** 550 378 36 WATER SEPARATOR............................................................................................................................................. 156
Sandvik Mining and Construction Oy, Drills Tampere © 2010

110D16028-1
** 763 156 01 CYLINDER, 56/100 S450............................................................................................................................................. 158

** 550 242 77 COLLECTING PIECE, RIGHT..................................................................................................................................... 160
** 550 242 79 COLLECTING PIECE, RIGHT..................................................................................................................................... 162
** 550 265 03 ADAPTER ASSEMBLY................................................................................................................................................ 164
** 550 312 43 DISTRIBUTOR, AIR..................................................................................................................................................... 166
** 550 290 42 COLLECTING PIECE................................................................................................................................................... 168
** 167 296 44 PRESSURE FILTER ASSEMBLY................................................................................................................................ 170
** 209 080 84 OILER........................................................................................................................................................................... 172
** 550 295 87 ADAPTER ASSEMBLY, ACCUMULATOR CHARGING VALVE.................................................................................. 178
** 550 288 12 PRESSURE SWITCH.................................................................................................................................................. 180
** 550 951 63 LUBRICATION FITTING BLOCK, MEASURING ADAPTERS..................................................................................... 182
** 550 941 17 PRESSURE SWITCH.................................................................................................................................................. 184
** 208 244 04 FLUSHING VALVE ASSEMBLY.................................................................................................................................. 185
*** 168 187 42 VALVE ASSEMBLY................................................................................................................................................. 188
*** 168 188 71 VALVE ASSEMBLY................................................................................................................................................. 190
*** 550 910 53 HOSING, DOUBLE FLUSHING VALVE................................................................................................................... 192
** 550 282 40 CABLE ENTRY PLATE................................................................................................................................................ 194
** 550 333 63 HOUSING ASSEMBLY, CONTROL LEVER................................................................................................................ 196
* 551 911 25 CARRIER FRAME PARTS.............................................................................................................................................. 198
** 550 266 86 CONNECTION PARTS................................................................................................................................................ 200
** 550 294 93 MOUNTING.................................................................................................................................................................. 202
*** 710 550 03 AXLE........................................................................................................................................................................ 204
**** 710 550 93 CYLINDER............................................................................................................................................................ 208
** 550 267 11 STEERING ASSEMBLY............................................................................................................................................... 210
*** 550 283 42 CYLINDER, ADAPTERS ASSEMBLY...................................................................................................................... 212
**** 763 180 69 CYLINDER, 80/45, S337...................................................................................................................................... 214
** 550 267 12 OSCILLATION BEAM ASSEMBLY.............................................................................................................................. 216
*** 795 200 74 EQUALIZER LEVER................................................................................................................................................ 218
** 550 267 13 DRIVING MOTOR AND GEARBOX ASSEMBLY........................................................................................................ 220
*** 550 288 17 HYDRAULIC MOTOR.............................................................................................................................................. 222
**** 777 900 50 HYDRAULIC MOTOR.......................................................................................................................................... 224
*** 710 810 93 TRANSFER GEAR BOX.......................................................................................................................................... 226
*** 550 267 49 DRIVE SHAFT.......................................................................................................................................................... 228
*** 550 267 50 DRIVE SHAFT.......................................................................................................................................................... 230
** 731 012 01 WHEEL......................................................................................................................................................................... 232

110D16028-1

551 911 28 dD
1 (233) CARRIER MODULE 101208

551 911 28 dD
101208 CARRIER MODULE 2 (233)
Ref. Part no. Description EN Standard designation Qty

e
1 551 978 63 CONTROL SYSTEM SECTION 8 PAGE 8 1
3 550 730 75 DRIVING PLATFORM ASSEMBLY SECTION 8 PAGE 102 1
7 550 233 05 SAFETY CANOPY ASSEMBLY SECTION 8 PAGE 146 1
9 550 323 33 RETURN FILTER SECTION 8 PAGE 152 1
. . . . .
10 550 654 43 WATER SEPARATOR ASSEMBLY SECTION 8 PAGE 154 1
17 763 156 01 CYLINDER SECTION 8 PAGE 158 2
18 550 268 10 MUD GUARD 1
19 550 268 11 MUD GUARD 1
20 550 242 77 COLLECTING PIECE SECTION 8 PAGE 160 1
. . . . .
22 550 265 03 ADAPTER ASSEMBLY SECTION 8 PAGE 164 1
24 550 312 43 DISTRIBUTOR SECTION 8 PAGE 166 1
26 206 161 98 ADAPTER L=68 4
. . . . .
27 801 802 69 BONDED SEAL U 13,7X22X1,5 D2=15,4 4
30 167 296 44 PRESSURE FILTER ASSEMBLY SECTION 8 PAGE 170 2
32 550 576 28 COVER RUBBER FRONT MODULE/CENTRAL OILER 1
33 550 576 58 MOUNTING PLATE FRONT MODULE/COVER RUBBER COVER 1
34 550 576 04 BRACKET LUBRICATION UNIT/ORIFICE PIECE 1
. . . . .
35 209 080 84 OILER SECTION 8 PAGE 172 1
45 550 288 12 PRESSURE SWITCH SECTION 8 PAGE 180 1
. . . . .
48 550 951 63 LUBRICATION FITTING BLOCK SECTION 8 PAGE 182 1
50 550 656 57 SUPPORTING BLOCK 1
51 550 267 95 BRACKET QN-PANEL 1
60 208 244 04 FLUSHING VALVE ASSEMBLY SECTION 8 PAGE 185 2
. . . . .
80 045 301 43 RUBBER PAD 17/391-60 4
81 314 840 58 PLATE 4
82 550 282 40 CABLE ENTRY PLATE SECTION 8 PAGE 194 1
90 550 273 68 BOTTOM PLATE 1
92 550 697 65 COVER PLATE PRESSURE FILTER 1
. . . . .
701 803 152 39 HOSE 12/15.8 5
740 550 333 63 HOUSING ASSEMBLY SECTION 8 PAGE 196 1
799 550 274 36 SCREW SET SECTION 8 PAGE 5 1
. . . . .

551 911 28 dD
3 (233) CARRIER MODULE 101208

551 911 28 dD
101208 CARRIER MODULE 4 (233)

e
3 550 730 75 DRIVING PLATFORM ASSEMBLY SECTION 8 PAGE 102 1
7 550 233 05 SAFETY CANOPY ASSEMBLY SECTION 8 PAGE 146 1
9 550 323 33 RETURN FILTER SECTION 8 PAGE 152 1
. . . . .
10 550 654 43 WATER SEPARATOR ASSEMBLY SECTION 8 PAGE 154 1
18 550 268 10 MUD GUARD 1
19 550 268 11 MUD GUARD 1
. . . . .
24 550 312 43 DISTRIBUTOR SECTION 8 PAGE 166 1
26 206 161 98 ADAPTER L=68 4
. . . . .
27 801 802 69 BONDED SEAL U 13,7X22X1,5 D2=15,4 4
30 167 296 44 PRESSURE FILTER ASSEMBLY SECTION 8 PAGE 170 2
32 550 576 28 COVER RUBBER FRONT MODULE/CENTRAL OILER 1
33 550 576 58 MOUNTING PLATE FRONT MODULE/COVER RUBBER COVER 1
34 550 576 04 BRACKET LUBRICATION UNIT/ORIFICE PIECE 1
. . . . .
35 209 080 84 OILER SECTION 8 PAGE 172 1
. . . . .
48 550 951 63 LUBRICATION FITTING BLOCK SECTION 8 PAGE 182 1
51 550 267 95 BRACKET QN-PANEL 1
60 208 244 04 FLUSHING VALVE ASSEMBLY SECTION 8 PAGE 185 2
. . . . .
80 045 301 43 RUBBER PAD 17/391-60 4
81 314 840 58 PLATE 4
82 550 282 40 CABLE ENTRY PLATE SECTION 8 PAGE 194 1
90 550 273 68 BOTTOM PLATE 1
. . . . .
701 803 152 39 HOSE 12/15.8 5
740 550 333 63 HOUSING ASSEMBLY SECTION 8 PAGE 196 1
799 550 274 36 SCREW SET SECTION 8 PAGE 5 1
. . . . .

550 274 36
5 (233) SCREW SET / CONNECTION PARTS FOR CARRIER FRONT MODULE 101208

e
118 445 765 80 HEXAGON SOCKET HEAD SCREW M5X40 m8.8 6
124 442 502 60 HEXAGON HEAD SCREW M6X25 - 8.8 3
142 808 803 59 HEXAGON HEAD SCREW M8x16m8.8 4
156 851 062 39 HEXAGON HEAD BOLT M8X65 SFS 2063 2
159 444 168 90 HEXAGON HEAD BOLT M8X75-8.8 DIN 931 2
. . . . .
162 442 751 30 HEXAGON HEAD BOLT M8X90 m8.8 SFS 2063 2
171 800 432 79 HEXAGON HEAD SCREW M10X16 4
172 800 823 09 HEXAGON HEAD SCREW M10x20 m8.8 6
173 800 460 49 HEXAGON HEAD SCREW M10X25-8.8 SFS-ISO 4017 8
. . . . .
175 800 461 79 HEXAGON HEAD SCREW M10x35 m8.8 SFS 2064 12
. . . . .
265 800 538 69 HEXAGON HEAD SCREW M16X45 m8.8 8
288 800 495 09 HEXAGON HEAD BOLT M16X140 m8.8 4
315 800 448 49 HEXAGON HEAD SCREW M20X50 m8.8 8
500 801 773 29 LOCK NUT M4 m8 DIN 985 4
. . . . .
506 801 779 99 LOCK NUT M8 m8 DIN 985 4
509 812 622 69 LOCK NUT M10 m8 DIN 980 12
512 811 260 29 LOCK NUT M12 m8 BH8 4
517 801 775 89 LOCK NUT M16 m8 DIN 985 4
518 811 259 69 LOCK NUT M16 m8 B-lock 8
. . . . .
521 817 807 89 LOCK NUT M20 m8 DIN 980 8
524 817 808 09 LOCK NUT VM24 m8 DIN 980 16
550 853 239 79 DOUBLE LOCK WASHER M6 9
. . . . .
. . . . .
575 421 189 50 WASHER M13 SFS 2041 4
592 884 292 29 WASHER M10 DIN 9021 8
601 800 915 79 SLOTTED PAN HEAD SCREW M4X16 m5.8 4
776 446 175 30 HEXAGON SOCKET HEAD SCREW M8X80 SFS 2219 2
. . . . .

551 978 63 A
7 (233) CONTROL SYSTEM 101208

551 978 63 A
101208 CONTROL SYSTEM 8 (233)

e
1 550 305 33 OPERATOR'S CONSOLE ASSEMBLY SECTION 8 PAGE 10 1
2 550 519 67 VALVE ASSEMBLY SECTION 8 PAGE 30 1
4 551 724 16 BRACKET Junction box mounting 1
5 550 429 85 CONTROL ASSEMBLY SECTION 8 PAGE 66 1
122 802 421 59 HEXAGON HEAD SCREW M6x18m8.8 SFS 2
. . . . .
123 802 559 29 HEXAGON HEAD SCREW M12X20-8.8 4
144 808 802 29 HEXAGON HEAD SCREW M8X20 m8.8 SFS 2064 8
505 802 558 09 HEXAGON NUT M6 m8 SFS 2067 4
512 811 260 29 LOCK NUT M12 m8 BH8 4
. . . . .
572 421 165 20 WASHER 6,4 2
700 550 274 71 STEEL PARTS KIT 1
700.1 550 242 67 FRAME ASSEMBLY 1
. . . . .
700.2 550 212 35 BODY 1
700.3 550 275 16 DECAL 1
754 446 066 20 HEXAGON SOCKET HEAD SCREW M6X30 m8.8 DIN 4
801 550 515 20 HOSING SECTION 5 PAGE 38 1
*10 550 242 67 FRAME ASSEMBLY 1
. . . . .
*11 550 212 35 BODY 1
*12 550 022 60 COVER PLATE 1

550 305 33
9 (233) OPERATOR'S CONSOLE ASSEMBLY 101208

550 305 33
101208 OPERATOR'S CONSOLE ASSEMBLY 10 (233)

e
2 550 264 98 CONTROL BLOCK ASSEMBLY SECTION 8 PAGE 14 1
4 550 016 71 DIRECTIONAL VALVE SECTION 8 PAGE 20 1
6 550 276 53 CONTROL VALVE ASSEMBLY SECTION 8 PAGE 24 1
. . . . .
7 818 163 49 PRESSURE GAUGE 0-250 BAR 3
8 853 251 79 PRESSURE GAUGE 25bar 1
9 816 886 19 ADAPTER (HYDRAULIC) 4
14 207 256 58 SIGN TYPE 1
15 455 332 90 SCREW 2X5 SMS 1549 4
. . . . .
145 800 916 09 HEXAGON HEAD SCREW M8x25 m8.8 SFS 4
. . . . .
572 421 165 20 WASHER 6,4 3
*11 550 270 56 INSTRUMENT PANEL 1
*11.1 550 270 36 DECAL 1
. . . . .

550 305 33

550 305 33

e
. . . . .
14 207 256 58 SIGN TYPE 1
15 455 332 90 SCREW 2X5 SMS 1549 4
. . . . .
. . . . .
572 421 165 20 WASHER 6,4 3
*11.1 550 270 36 DECAL 1
. . . . .

550 264 98 aB
13 (233) CONTROL BLOCK ASSEMBLY / FEED PRESSURE CONTROL BLOCK 101208

550 264 98 aB
101208 CONTROL BLOCK ASSEMBLY / FEED PRESSURE CONTROL BLOCK 14 (233)

e
1 550 264 99 CONTROL BLOCK ASSEMBLY 1
2 881 268 39 PRESSURE RELIEF VALVE 1
2.1 882 534 99 SEAL KIT 1
3 881 291 79 DIRECTIONAL VALVE 2
3.1 882 880 09 SEAL KIT 1
. . . . .
7 865 683 09 PLUG R1/8" 5
8 881 777 59 HAND WHEEL 1
20 817 179 09 STRAIGHT THREAD ADAPTER 7/16-20JIC 4
21 856 040 09 STRAIGHT THREAD ADAPTER JIC 9/16-18 1
22 851 975 79 STRAIGHT THREAD ELBOW 7/16-20 JIC 1
. . . . .
23 819 561 09 SWIVEL NUT ELBOW 90 7/16-20JIC 1

550 264 98 aB
15 (233) CONTROL BLOCK ASSEMBLY / FEED PRESSURE CONTROL BLOCK 101208

550 264 98 aB
101208 CONTROL BLOCK ASSEMBLY / FEED PRESSURE CONTROL BLOCK 16 (233)

e
2.1 882 534 99 SEAL KIT 1
3.1 882 880 09 SEAL KIT 1
. . . . .
7 865 683 09 PLUG R1/8" 5
8 881 777 59 HAND WHEEL 1
. . . . .

550 015 57
17 (233) ADAPTER ASSEMBLY 101208

550 015 57
101208 ADAPTER ASSEMBLY 18 (233)

e
1 325 499 78 SECTION BODY 1
2.1 882 534 99 SEAL KIT 1
3 881 105 79 CARTRIDGE 1
3.1 882 532 39 SEAL KIT 1
. . . . .
4 881 777 59 HAND WHEEL 1
7 816 711 99 STRAIGHT THREAD ELBOW 9/16-18 1
8 851 983 29 ADAPTER TEE R6X-S6 2
. . . . .
9 817 180 79 SWIVEL NUT ELBOW 90 9/16-18 JIC 1
10 816 719 09 ADAPTER TEE 9/16-18 JIC 1
11 887 823 89 LIMIT BUSHING 1

550 016 71 aA
19 (233) DIRECTIONAL VALVE / ROTATION, PRESSURE, FEED 101208

550 016 71 aA
101208 DIRECTIONAL VALVE / ROTATION, PRESSURE, FEED 20 (233)

e
1 881 780 79 STEERING VALVE 1
1.1 882 884 19 FILLING CAP 3
1.2 882 885 49 SOLENOID 6
1.3 882 886 79 COVER RUBBER 3
1.4 882 893 09 SEAL KIT 4
. . . . .
1.5 882 888 29 STEERING VALVE 1
3 816 701 89 STRAIGHT THREAD ADAPTER 40X-S10-1/4" (9/16-18JIC) 1
. . . . .
6 851 983 29 ADAPTER TEE R6X-S6 2
8 207 816 88 ADAPTER 2
8.1 207 818 38 ADAPTER 1
. . . . .

550 010 16 aB
21 (233) DIRECTIONAL VALVE / FLUSHING AND RAPID MOVEMENT 101208

550 010 16 aB
101208 DIRECTIONAL VALVE / FLUSHING AND RAPID MOVEMENT 22 (233)

e
1.1 874 828 69 COVER RUBBER 2
1.2 882 884 19 FILLING CAP 2
1.3 882 893 09 SEAL KIT 2
. . . . .
1.6 867 837 49 LEVER 2
2 812 553 99 SHUTTLE VALVE 22-1A-2 R1/4 IN 1
. . . . .
5 851 983 29 ADAPTER TEE R6X-S6 1
6 816 719 09 ADAPTER TEE 9/16-18 JIC 1
7 816 705 99 SWIVEL NUT MALE ADAPTER 1/4" 1
. . . . .

550 276 53 bC
23 (233) CONTROL VALVE ASSEMBLY / BOOM 101208

550 276 53 bC
101208 CONTROL VALVE ASSEMBLY / BOOM 24 (233)

e
5 816 770 19 STRAIGHT THREAD ADAPTER JIC 1 1/16"-12 1
6 864 095 09 STRAIGHT THREAD ELBOW C40X-S12-3/8" (3/4-16JIC) 1
. . . . .
9 853 813 59 SWIVEL NUT ELBOW 45 45, 9/16-18JIC 9
. . . . .
12 865 275 49 ADAPTER TEE 1,1/16-12JIC 1
13 853 385 39 NUT JIC 1,1/16-12 1
14 851 977 29 TUBE END REDUCER 1,1/16X7/16JIC 1
15 817 096 19 PLUG 7/16-20JIC 1

550 288 22 c
25 (233) DIRECTIONAL VALVE 101208

550 288 22 c
101208 DIRECTIONAL VALVE 26 (233)

e
*1 O-RING 33
*2 O-RING 9
*3 BALL 11
*4 O-RING 18
*5 WIPER RING 18
. . . . .
*7 VALVE SEAT 18
*13 882 612 49 ORIFICE SECTION PAGE 9
*14 882 611 19 CENTERING PIECE SECTION PAGE 9
*15 882 591 69 LEVER SECTION 8 PAGE 28 4
*16 817 806 59 CARTRIDGE 1
. . . . .
*16.1 819 951 09 SEAL KIT 1
*17 879 105 19 LIMITER 1
*17.1 819 951 09 SEAL KIT 1
*18 882 874 09 CHECK VALVE 1
*19 805 217 89 O-RING 1
. . . . .
*20 819 951 09 SEAL KIT 2
*21 550 301 78 DIRECTIONAL VALVE 1
*22 550 301 79 LEVER SM L10/M10x1,5x105,0 1
*23 887 626 09 VALVE SECTION 8
*900 880 489 29 SEAL KIT 11
. . . . .
*901 882 613 79 SEAL KIT 9
*902 879 231 69 SHUTTLE VALVE 9

882 591 69 d
27 (233) LEVER 101208

882 591 69 d
101208 LEVER 28 (233)

e
*1 882 823 39 RUBBER BELLOWS 1
*2 882 824 69 KNOB 1
*3 550 302 21 LEVER SPARE PART KIT OF SP08 CROSS LEVER 1
*4 550 409 96 MOUNTING PLATE 1

550 519 67
29 (233) VALVE ASSEMBLY / FIXED DISPLACEMENT PUMP 101208

550 519 67
101208 VALVE ASSEMBLY / FIXED DISPLACEMENT PUMP 30 (233)

e
10 870 254 89 PRESSURE SWITCH 1
. . . . .
16 209 600 78 SIGN 1
17 455 332 90 SCREW 2X5 SMS 1549 4
21 800 194 09 HEXAGON HEAD SCREW M12X20 m8.8 SFS-ISO 4017 4
. . . . .
24 801 779 99 LOCK NUT M8 m8 DIN 985 3
25 421 168 00 WASHER M8 3
. . . . .
29 881 895 49 CABLE GLAND PK13.5 (PK13.5, 6-9mm) 1
*1 550 212 35 BODY 1

550 278 37 eJ
31 (233) VALVE ASSEMBLY / CONTROL BLOCK OF DRILLING 101208

550 278 37 eJ
101208 VALVE ASSEMBLY / CONTROL BLOCK OF DRILLING 32 (233)

e
1 550 014 18 VALVE ASSEMBLY 1
1.1 865 683 09 PLUG R1/8" 46
1.2 871 692 89 PLUG R1/4", E336-1/4" 1
1.3 881 140 79 PLUG R1/2", E336-1/2" 1
1.4 881 141 09 PLUG R3/4" 1
. . . . .
2 887 706 19 OVERCENTER VALVE 1
2.1 871 694 39 SEAL KIT 1
3 887 703 39 SEQUENCE VALVE 1
3.1 871 694 39 SEAL KIT 1
. . . . .
4.1 882 534 99 SEAL KIT 1
5.1 882 534 99 SEAL KIT 1
6 134 469 48 HEXAGON SOCKET SET SCREW M8X8 DIN 913 1
7 868 479 39 PRESSURE RELIEF VALVE SECTION 8 PAGE 38 1
. . . . .
8.1 882 880 09 SEAL KIT 1
10.1 882 880 09 SEAL KIT 1
11 881 106 09 PRESSURE REDUCING VALVE 1
. . . . .
11.1 882 533 69 SEAL KIT 1
12 881 105 79 CARTRIDGE 1
12.1 882 532 39 SEAL KIT 1
13 881 105 79 CARTRIDGE 1
13.1 882 532 39 SEAL KIT 1
. . . . .
14 881 105 79 CARTRIDGE 1
14.1 882 532 39 SEAL KIT 1
17 881 109 89 PRESSURE COMPENSATOR 1
17.1 882 531 09 SEAL KIT 1
. . . . .
18 850 778 99 PRESSURE GAUGE CONNECTOR TT4XS10 1/4" 2
19 816 885 99 QUICK DISCONNECT FITTING 11
21 817 095 99 COUPLING 8-12F42EDMXS (3/4-16JIC) 1
22 816 778 39 STRAIGHT THREAD ADAPTER 1,5/16-12JIC 3
. . . . .

550 278 37 eJ

550 278 37 eJ

e
24 817 183 59 SWIVEL NUT ELBOW 90 , 3/4-16JIC 2
27 818 001 09 NUT JIC 3/4-16 2
28 817 165 99 TUBE END REDUCER 3/4X7/16JIC 2
29 871 692 89 PLUG R1/4", E336-1/4" 2
32 816 722 29 ADAPTER TEE 9/16-18JIC 1
. . . . .
33.1 882 534 99 SEAL KIT 1
34.1 882 880 09 SEAL KIT 1
35 881 105 79 CARTRIDGE 1
. . . . .
35.1 882 532 39 SEAL KIT 1
36 884 262 09 CHECK VALVE 1
36.1 882 878 19 SEAL KIT 1
37 817 183 59 SWIVEL NUT ELBOW 90 , 3/4-16JIC 1
38 816 718 89 ADAPTER TEE 1,5/16-12 JIC 1
. . . . .
39 816 725 09 PRESSURE GAUGE CONNECTOR 1,5/16-12JIC 1
45 550 032 57 PLUG 4-WAY CAVITY 1
46 886 830 09 PLUG 1
. . . . .
47 881 139 09 PLUG R3/8", E366-3/8" 1
48 871 692 89 PLUG R1/4", E336-1/4" 1
49 871 692 89 PLUG R1/4", E336-1/4" 1
51 816 739 29 NUT 9/16-18JIC 1
. . . . .
52 864 270 09 SWIVEL NUT ELBOW 45 V6X-S25 (1,5/16-12JIC) 2
53 816 708 79 SWIVEL NUT ELBOW 90 1,5/16-12 JIC 1
56 816 719 09 SWIVEL NUT RUN TEE 6R6MXS (9/16-18JIC) 1
. . . . .
58 816 739 29 NUT 9/16-18JIC 1

550 278 37 eJ

550 278 37 eJ

e
1.1 865 683 09 PLUG R1/8" 46
1.2 871 692 89 PLUG R1/4", E336-1/4" 1
1.3 881 140 79 PLUG R1/2", E336-1/2" 1
1.4 881 141 09 PLUG R3/4" 1
. . . . .
2 887 706 19 OVERCENTER VALVE 1
2.1 871 694 39 SEAL KIT 1
3 887 703 39 SEQUENCE VALVE 1
3.1 871 694 39 SEAL KIT 1
. . . . .
4.1 882 534 99 SEAL KIT 1
5.1 882 534 99 SEAL KIT 1
6 134 469 48 HEXAGON SOCKET SET SCREW M8X8 DIN 913 1
7 868 479 39 PRESSURE RELIEF VALVE SECTION 8 PAGE 38 1
. . . . .
8.1 882 880 09 SEAL KIT 1
10.1 882 880 09 SEAL KIT 1
11 881 106 09 PRESSURE REDUCING VALVE 1
. . . . .
11.1 882 533 69 SEAL KIT 1
12 881 105 79 CARTRIDGE 1
12.1 882 532 39 SEAL KIT 1
13 881 105 79 CARTRIDGE 1
13.1 882 532 39 SEAL KIT 1
. . . . .
14 881 105 79 CARTRIDGE 1
14.1 882 532 39 SEAL KIT 1
17 881 109 89 PRESSURE COMPENSATOR 1
17.1 882 531 09 SEAL KIT 1
. . . . .
23 817 094 69 ADAPTOR JIC 3/4-16 1
26 817 163 39 ADAPTER TEE 3/4-16 JIC 2
30 442 761 40 HEXAGON HEAD BOLT M8X80-8.8 SFS-ISO 4014 3
31 421 168 00 WASHER M8 3
. . . . .
33.1 882 534 99 SEAL KIT 1
34.1 882 880 09 SEAL KIT 1
35 881 105 79 CARTRIDGE 1
. . . . .
35.1 882 532 39 SEAL KIT 1
36 884 262 09 CHECK VALVE 1
36.1 882 878 19 SEAL KIT 1
45 550 032 57 PLUG 4-WAY CAVITY 1
46 886 830 09 PLUG 1
. . . . .

868 479 39
37 (233) PRESSURE RELIEF VALVE 101208

868 479 39
101208 PRESSURE RELIEF VALVE 38 (233)

e
* 818 930 59 SEAL KIT INCL. PARTS 1-6
*1 BACK-UP RING 16,7X21,1X0,6 2
*2 O-RING 15,55X2,62 1
*3 BACK-UP RING 1834X22,6X0,6 1
*4 O-RING 17312X2,62 1
. . . . .
*5 O-RING 23,47X2,62 1
*6 O-RING 15,2X2 1

887 360 09 a
39 (233) VALVE ASSEMBLY 101208

887 360 09 a
101208 VALVE ASSEMBLY 40 (233)

e
*1 550 667 44 VALVE BODY SECTION 8 PAGE 46 1
*2 882 200 79 END PLATE 1
*3 882 204 89 MECHANICAL ACTIVATING MODULE 1
*4 882 883 99 CONTROL BLOCK ASSEMBLY 1
*21 882 882 69 SPOOL INCL. PARTS 21-26 1
. . . . .

887 360 09 a

887 360 09 a

e
*2 882 200 79 END PLATE 1
*21 882 882 69 SPOOL INCL. PARTS 21-26 1
. . . . .

887 360 09 a

887 360 09 a

e
*2 882 200 79 END PLATE 1
*21 882 882 69 SPOOL INCL. PARTS 21-26 1
. . . . .

550 667 44
45 (233) VALVE BODY / FEED DIRECTIONAL CONTROL VALVE 101208

550 667 44
101208 VALVE BODY / FEED DIRECTIONAL CONTROL VALVE 46 (233)

e
*1 887 363 89 VALVE SECTION 157 B 6230 1
*4 887 365 39 SHOCK LOAD VALVE 157 B 2160 1
*5 882 191 59 O-RING 16,0X1,5 2
*6 887 366 69 SHOCK LOAD VALVE 157 B 2210 1

550 064 91 aB
47 (233) CONTROL BLOCK ASSEMBLY / CONTROL BLOCK OF RETURN AUTOMATICS 101208

550 064 91 aB
101208 CONTROL BLOCK ASSEMBLY / CONTROL BLOCK OF RETURN AUTOMATICS 48 (233)

e

888 012 39 b
49 (233) CONTROL BLOCK ASSEMBLY 101208

888 012 39 b
101208 CONTROL BLOCK ASSEMBLY 50 (233)

e
*12 888 014 99 PRESSURE REDUCING VALVE 1
*12.1 888 017 79 SEAL KIT 1
*13 888 015 19 CHECK VALVE 2
*14 888 011 09 PRESSURE RELIEF VALVE 2
*14.1 888 019 29 SEAL KIT SK10-2 1
. . . . .
*16 888 013 69 PRESSURE SWITCH 2
*16.1 814 036 39 O-RING 9,0x1,5 80SHORE A 2

550 278 43 cJ
51 (233) CONTROL BLOCK ASSEMBLY 101208

550 278 43 cJ
101208 CONTROL BLOCK ASSEMBLY 52 (233)

e
1 328 857 18 CONTROL BLOCK ASSEMBLY Antijamming/Return automation 1
3 881 105 79 CARTRIDGE 1
3.1 882 532 39 SEAL KIT 1
. . . . .
4.1 882 532 39 SEAL KIT 1
4.2 882 535 19 COIL 1
5 881 105 79 CARTRIDGE 1
5.1 882 532 39 SEAL KIT 1
6 881 105 79 CARTRIDGE 1
. . . . .
6.1 882 532 39 SEAL KIT 1
7 881 105 79 CARTRIDGE 1
7.1 882 532 39 SEAL KIT 1
. . . . .
13 816 719 09 ADAPTER TEE 9/16-18 JIC 1
. . . . .
17 804 318 29 STRAIGHT THREAD ADAPTER 7/16-20 JIC 2
20 816 739 29 NUT 9/16-18JIC 1
22 817 096 19 PLUG 7/16-20JIC 1
. . . . .
23 816 722 29 ADAPTER TEE 9/16-18JIC 1

864 257 79

864 257 79

e
*1 883 000 29 SEAL KIT 1
*1.1 O-RING 4
*1.2 O-RING 1
*1.3 O-RING 2

550 486 01 cC
55 (233) CONTROL VALVE ASSEMBLY 101208

550 486 01 cC
101208 CONTROL VALVE ASSEMBLY 56 (233)

e
3 853 385 39 NUT JIC 1,1/16-12 1
7 865 275 49 ADAPTER TEE 1,1/16-12JIC 1
. . . . .
10 816 768 29 STRAIGHT THREAD ADAPTER 1,1/16"-12 JIC 2
12 816 722 29 ADAPTER TEE 9/16-18JIC 1
. . . . .
17 164 146 48 ADAPTER R1/2" - 1 1/16"-12 UNF, L=85 1
. . . . .
19 800 347 99 BONDED SEAL U 21,5X28,7X2,5 D2=23,15 1

550 485 56 d
57 (233) DIRECTIONAL VALVE / ROTATION CONTROL VALVE 101208

550 485 56 d
101208 DIRECTIONAL VALVE / ROTATION CONTROL VALVE 58 (233)

e
*3 550 497 59 REPAIR KIT Regulating kit 1
*4 550 497 72 SEAL KIT 1
*6 550 497 61 SEAL KIT 1
*7 550 497 64 FLOW CONTROL VALVE Flow regulator 1
. . . . .
*8 550 497 65 SEAL KIT 2
*9 550 497 67 SEAL KIT 1
*12 550 497 70 CHECK VALVE ASSEMBLY Check valve kit 1
*13 550 497 71 PRESSURE COMPENSATOR Pressure compensator kit 1
*25 550 497 69 FILTER 1
. . . . .
*90 550 497 73 REPAIR KIT Hydraulic operation kit 1

550 485 56 d

550 485 56 d

e
*4 550 497 72 SEAL KIT 1
*6 550 497 61 SEAL KIT 1
. . . . .
*8 550 497 65 SEAL KIT 2
*9 550 497 67 SEAL KIT 1
*25 550 497 69 FILTER 1
. . . . .

550 485 56 d

550 485 56 d

e
*4 550 497 72 SEAL KIT 1
*6 550 497 61 SEAL KIT 1
. . . . .
*8 550 497 65 SEAL KIT 2
*9 550 497 67 SEAL KIT 1
*25 550 497 69 FILTER 1
. . . . .

550 485 56 d

550 485 56 d

e
*4 550 497 72 SEAL KIT 1
*6 550 497 61 SEAL KIT 1
. . . . .
*8 550 497 65 SEAL KIT 2
*9 550 497 67 SEAL KIT 1
*25 550 497 69 FILTER 1
. . . . .

550 429 85 aE
65 (233) CONTROL ASSEMBLY 101208

550 429 85 aE
101208 CONTROL ASSEMBLY 66 (233)

e
5 550 429 87 ELECTRIC COMPONENT ASSEMBLY SECTION 8 PAGE 74 1
7 551 664 24 SOLENOID VALVE SYMBOL SET 1

550 429 86 L
67 (233) CONTROL ASSEMBLY / JB102 101208

550 429 86 L
101208 CONTROL ASSEMBLY / JB102 68 (233)

e
1 550 243 86 JUNCTION BOX ASSEMBLY SECTION 8 PAGE 70 1
2 879 368 09 PRE-WIRED PLUG CABLE 24DC, 3.0m 1
3 887 291 29 PRE-WIRED PLUG CABLE Solenoid valve cable 1
4 887 291 29 PRE-WIRED PLUG CABLE Solenoid valve cable 1
. . . . .
6 867 108 59 CABLE 1,5M 1.5
7 818 826 89 SLEEVE COLLAR 1
8 885 564 49 SHIELDED CABLE GLAND 1
9 550 260 59 CABLE ASSEMBLY SECTION 8 PAGE 72 1
10 870 293 99 CABLE 3X1,5mm2 750V 1
. . . . .
30 888 152 09 RELAY C10-A10BX 24VDC 1
31 888 153 29 RELAY SOCKET S10 1
32 856 470 49 TERMINAL STRIP UK4-TG 1
33 856 471 79 TERMINAL STRIP ACCESSORY ST-BE 1
34 850 968 39 DIODE 1
. . . . .

550 243 86 kE
69 (233) JUNCTION BOX ASSEMBLY 101208

550 243 86 kE
101208 JUNCTION BOX ASSEMBLY 70 (233)

e
K70 888 154 59 OFF DELAY TIME RELAY MCR1 1
K71-K72 888 152 09 RELAY C10-A10BX 24VDC 2
K71-K72 888 153 29 RELAY SOCKET S10 2
X102 421 155 10 WASHER 4,3 4
X102 850 485 39 MULTI-POLE CONNECTOR CASE 16A 380V, bottom part 1
. . . . .
X102 819 476 29 MALE MULTIPOLE CONNECTOR 1
X102 800 915 79 SLOTTED PAN HEAD SCREW M4X16 m5.8 4
X102 801 772 09 HEXAGON NUT M4 m8 SFS 2067 4
1 550 484 31 STAINLESS STEEL ENCLOSURE JB 102-box, 160x260x90 1
2 550 860 37 WASHER d1=8.5, d2=21, s=3, Ms 4
. . . . .
2 550 860 31 WASHER d1=17 d2=30 s=3, Ms, M16 4
3 550 243 87 WIRING INSTRUCTION JB102 , Axera D06 drawing list 1
4 850 546 59 MOUNTING RAIL 0,1M 0.26
5 800 825 59 SLOTTED PAN HEAD SCREW m5.8 SFS 2176 2
6 421 155 10 WASHER 4,3 2
. . . . .
7 550 038 19 METALLIC CABLE GLAND M25x1.5, 13-18mm 1
8 550 076 08 CABLE ENTRY M25, 4x7mm 1
9 550 076 09 CABLE ENTRY M25, 2x9mm 1
10 550 024 04 METALLIC LOCKING PLUG M25x1.5, D=28mm, H=4mm, L=8mm 4
11 550 024 06 METALLIC LOCK-NUT M25x1.5, H=3.5mm 7
. . . . .
13 888 141 69 TERMINAL STRIP 18
14 888 143 19 END PLATE 870-518 1
15 550 102 43 JUMPER BAR FBS 20-5 (20 TERMINALS) 0.5
16 856 470 49 TERMINAL STRIP UK4-TG 5
17 856 471 79 TERMINAL STRIP ACCESSORY ST-BE 5
. . . . .
18 850 968 39 DIODE 5
19 816 239 99 TERMINAL STRIP ACCESSORY D-UK 4/10 1
20 816 241 89 END CLAMP 2
21 888 145 79 MARKING PLATE 793-502 (1-10) 0.2
22 888 146 09 MARKING PLATE 793-503 (11-20) 0.2
. . . . .
23 885 928 29 TERMINAL MARKING STRIP 1
23 550 425 62 TERMINAL STRIP ACCESSORY ZB6 1
24 550 059 92 METALLIC LOCKING PLUG M32x1.5, D=35, H=4. L=8, IP68 1
27 888 147 29 MARKING PLATE 793-504 (21-30) 0.2
. . . . .

550 260 59 A
71 (233) CABLE ASSEMBLY 101208

550 260 59 A
101208 CABLE ASSEMBLY 72 (233)

e
1 819 473 49 MULTI-POLE CONNECTOR CASE 16A AC 1
2 819 477 59 FEMALE MULTIPOLE CONNECTOR 1
5 885 568 59 SHIELDED CABLE GLAND 13-18 1
10 872 565 19 CABLE 18X1,5mm2 500V 1.5

550 429 87 bH
73 (233) ELECTRIC COMPONENT ASSEMBLY / JB93 AND JB94 101208

550 429 87 bH
101208 ELECTRIC COMPONENT ASSEMBLY / JB93 AND JB94 74 (233)

e
1 550 476 59 SELECTOR SWITCH 1
7 550 471 82 EMERGENCY STOP BUTTON 1
9 811 694 79 COVER PLUG 1
. . . . .
12 811 694 79 COVER PLUG 1
15 811 694 79 COVER PLUG 1
16 811 694 79 COVER PLUG 1
17 421 155 10 WASHER 4,3 4
. . . . .
20 880 731 49 MULTI-POLE CONNECTOR CASE 16E 380V 16A 1
21 819 476 29 MALE MULTIPOLE CONNECTOR 1
22 810 940 99 FILLING CAP Ms GL = 7 mm 1
23 421 155 10 WASHER 4,3 4
. . . . .
26 880 884 09 BLANKING PLATE 380V 16A 1
29 811 694 79 COVER PLUG 1
32 550 270 56 INSTRUMENT PANEL 1
. . . . .
32.1 550 270 36 DECAL 1
40 106 148 51 JUNCTION BOX SECTION 8 PAGE 82 1
550 270 35 WIRING INSTRUCTION JB94, Drawing list 1
*33 550 270 36 DECAL 1

550 429 87 bH

550 429 87 bH

e
9 811 694 79 COVER PLUG 1
. . . . .
12 811 694 79 COVER PLUG 1
15 811 694 79 COVER PLUG 1
16 811 694 79 COVER PLUG 1
17 421 155 10 WASHER 4,3 4
. . . . .
23 421 155 10 WASHER 4,3 4
. . . . .
29 811 694 79 COVER PLUG 1
. . . . .
32.1 550 270 36 DECAL 1
*33 550 270 36 DECAL 1

550 429 87 bH

550 429 87 bH

e
9 811 694 79 COVER PLUG 1
. . . . .
12 811 694 79 COVER PLUG 1
15 811 694 79 COVER PLUG 1
16 811 694 79 COVER PLUG 1
17 421 155 10 WASHER 4,3 4
. . . . .
23 421 155 10 WASHER 4,3 4
. . . . .
29 811 694 79 COVER PLUG 1
. . . . .
32.1 550 270 36 DECAL 1
*33 550 270 36 DECAL 1

550 429 87 bH

550 429 87 bH

e
9 811 694 79 COVER PLUG 1
. . . . .
12 811 694 79 COVER PLUG 1
15 811 694 79 COVER PLUG 1
16 811 694 79 COVER PLUG 1
17 421 155 10 WASHER 4,3 4
. . . . .
23 421 155 10 WASHER 4,3 4
. . . . .
29 811 694 79 COVER PLUG 1
. . . . .
32.1 550 270 36 DECAL 1
*33 550 270 36 DECAL 1

106 148 51 h
81 (233) JUNCTION BOX / JB93 101208

106 148 51 h
101208 JUNCTION BOX / JB93 82 (233)

e
1 550 365 81 PLASTIC ENCLOSURE 80x75x57 1
3 850 546 59 MOUNTING RAIL 0,1M 0.8
4 800 617 49 SLOTTED PAN HEAD SCREW M4X6 2
5 800 246 39 STAR WASHER 2
6 850 547 89 TERMINAL STRIP 6
. . . . .
7 850 595 79 TERMINAL STRIP ACCESSORY 1
8 850 549 39 END CLAMP 2
9 806 768 09 SWITCHING BRIDGE 0.5
10 852 885 69 TERMINAL MARKING STRIP ZB6.Lgs:1-10 1
. . . . .
17 550 059 90 METALLIC LOCKING PLUG M16x1.5, D=19, H=3, L=7 1

551 978 81 A
83 (233) CONTROL SYSTEM / THC560 , INTEGRATED HYDRAULICS, FIXED PUMP, TTF, W 101208

551 978 81 A
101208 CONTROL SYSTEM / THC560 , INTEGRATED HYDRAULICS, FIXED PUMP, TTF, W 84 (233)

e
4 551 724 16 BRACKET Junction box mounting 1
. . . . .
512 811 260 29 LOCK NUT M12 m8 BH8 4
. . . . .
572 421 165 20 WASHER 6,4 2
700.1 550 242 67 FRAME ASSEMBLY 1
. . . . .
700.2 550 212 35 BODY 1
700.3 550 275 16 DECAL 1
754 446 066 20 HEXAGON SOCKET HEAD SCREW M6X30 m8.8 DIN 4
*9 550 270 46 LOCK PIECE 1
. . . . .
*11 550 212 35 BODY 1
*12 550 022 60 COVER PLATE 1

550 275 55
85 (233) OPERATOR'S CONSOLE ASSEMBLY / THC560 101208

550 275 55
101208 OPERATOR'S CONSOLE ASSEMBLY / THC560 86 (233)

e
. . . . .
14 207 256 58 SIGN TYPE 1
15 455 332 90 SCREW 2X5 SMS 1549 4
. . . . .
. . . . .
572 421 165 20 WASHER 6,4 3
*11.1 550 270 36 DECAL 1
. . . . .

550 275 55
87 (233) OPERATOR'S CONSOLE ASSEMBLY / THC560 101208

550 275 55
101208 OPERATOR'S CONSOLE ASSEMBLY / THC560 88 (233)

e
. . . . .
14 207 256 58 SIGN TYPE 1
15 455 332 90 SCREW 2X5 SMS 1549 4
. . . . .
. . . . .
572 421 165 20 WASHER 6,4 3
*11.1 550 270 36 DECAL 1
. . . . .

550 275 54 aB
89 (233) CONTROL BLOCK ASSEMBLY / FEED PRESSURE CONTROL BLOCK, TTF 101208

550 275 54 aB
101208 CONTROL BLOCK ASSEMBLY / FEED PRESSURE CONTROL BLOCK, TTF 90 (233)

e
2.1 882 534 99 SEAL KIT 1
3.1 882 880 09 SEAL KIT 1
. . . . .
7 865 683 09 PLUG R1/8" 5
8 881 777 59 HAND WHEEL 1
. . . . .

550 275 54 aB
91 (233) CONTROL BLOCK ASSEMBLY / FEED PRESSURE CONTROL BLOCK, TTF 101208

550 275 54 aB
101208 CONTROL BLOCK ASSEMBLY / FEED PRESSURE CONTROL BLOCK, TTF 92 (233)

e
2.1 882 534 99 SEAL KIT 1
3.1 882 880 09 SEAL KIT 1
. . . . .
7 865 683 09 PLUG R1/8" 5
8 881 777 59 HAND WHEEL 1
. . . . .

550 008 14 eF
93 (233) DIRECTIONAL VALVE / BOOM CONTROL VALVE 101208

550 008 14 eF
101208 DIRECTIONAL VALVE / BOOM CONTROL VALVE 94 (233)

e
6 864 095 09 STRAIGHT THREAD ELBOW C40X-S12-3/8" (3/4-16JIC) 1
. . . . .
. . . . .
12 865 275 49 ADAPTER TEE 1,1/16-12JIC 1
13 853 385 39 NUT JIC 1,1/16-12 1
15 817 096 19 PLUG 7/16-20JIC 1

881 781 09 c

881 781 09 c

e
*1 O-RING 33
*2 O-RING 9
*3 BALL 9
*4 O-RING 18
*5 WIPER RING 18
. . . . .
*7 VALVE SEAT 18
*13 882 612 49 ORIFICE SECTION PAGE 8
*14 882 611 19 CENTERING PIECE SECTION PAGE 8
*15 882 591 69 LEVER SECTION 8 PAGE 28 4
*16 817 806 59 CARTRIDGE 1
. . . . .
*16.1 819 951 09 SEAL KIT 1
*17 879 105 19 LIMITER 1
*17.1 819 951 09 SEAL KIT 1
*18 882 874 09 CHECK VALVE 1
*19 805 217 89 O-RING 1
. . . . .
*20 819 951 09 SEAL KIT 2
*23 887 626 09 VALVE SECTION 8
*900 880 489 29 SEAL KIT 10
*901 882 613 79 SEAL KIT 8
*902 879 231 69 SHUTTLE VALVE 8
. . . . .

550 278 40 dB
97 (233) VALVE ASSEMBLY / SEP. PART LIST 101208

550 278 40 dB
101208 VALVE ASSEMBLY / SEP. PART LIST 98 (233)

e
. . . . .
16 209 600 78 SIGN 1
17 455 332 90 SCREW 2X5 SMS 1549 4
. . . . .
24 801 779 99 LOCK NUT M8 m8 DIN 985 3
25 421 168 00 WASHER M8 3
. . . . .
29 881 895 49 CABLE GLAND PK13.5 (PK13.5, 6-9mm) 1
*1 550 212 35 BODY 1

550 269 55 bC
99 (233) HOSING / SEP. PART LIST 101208

550 269 55 bC
101208 HOSING / SEP. PART LIST 100 (233)

e
20 858 463 39 ADAPTER (HYDRAULIC) 7/16-20 JIC 2
30 817 184 89 ADAPTER (HYDRAULIC) 9/16"-18 JIC 1
100 592 005 85 HYDRAULIC HOSE ASSEMBLY 2SC04MS AA-1200-JIC 1
. . . . .
. . . . .
. . . . .
. . . . .
. . . . .
240 592 024 59 HOSE ASSY 2SN08MS AA-700-JIC 1
250 816 890 69 HYDRAULIC HOSE ASSEMBLY 2120-04-01.50 1
. . . . .
. . . . .
. . . . .

550 730 75 bC
101 (233) DRIVING PLATFORM ASSEMBLY 101208

550 730 75 bC
101208 DRIVING PLATFORM ASSEMBLY 102 (233)

e
1 550 396 87 DRIVING PLATFORM ASSEMBLY 1
14 550 411 77 SUPPORTING BLOCK BRAKE VALVE 1
. . . . .
28 550 949 94 ASSEMBLY SECTION 8 PAGE 126 1
41 550 595 28 SEAT ASSEMBLY SECTION 8 PAGE 140 1
60 321 561 11 GAUGE ASSEMBLY SECTION 8 PAGE 142 1
61 321 561 16 GAUGE ASSEMBLY SECTION 8 PAGE 144 1
63 550 310 07 HOUSING 1
. . . . .
*27 783 203 19 VALVE SECTION 8 PAGE 122

550 730 75 bC
103 (233) DRIVING PLATFORM ASSEMBLY 101208

550 730 75 bC
101208 DRIVING PLATFORM ASSEMBLY 104 (233)

e
. . . . .
37 550 836 49 CHECK VALVE ASSEMBLY SECTION 8 PAGE 138 1
*35 777 607 10 ACCELERATOR PEDAL SECTION 8 PAGE 130
*36 777 607 14 PEDAL ASSEMBLY SECTION 8 PAGE 134

770 053 17 aI
105 (233) OPERATOR'S CONSOLE ASSEMBLY / CARRIER CONTROL PANEL 101208

770 053 17 aI
101208 OPERATOR'S CONSOLE ASSEMBLY / CARRIER CONTROL PANEL 106 (233)

e
9 851 529 29 SWITCH ZB2-BD2 3
10 885 343 49 SWITCH BODY (CONTACT BLOCK) ZB2-BZ103 (2S) 3
11 887 897 59 SWITCH 1
12 818 635 09 SWITCH BODY (CONTACT BLOCK) ZB2-BW065 1
13 888 108 19 PUSH BUTTON 1
. . . . .
14 852 032 19 PUSH BUTTON XB2-BP21NORMET 55128607 1
15 550 076 08 CABLE ENTRY M25, 4x7mm 5
16 550 260 31 SUPPORT TRAMMING PANEL 2

770 053 17 aI
107 (233) OPERATOR'S CONSOLE ASSEMBLY / CARRIER CONTROL PANEL 101208

770 053 17 aI
101208 OPERATOR'S CONSOLE ASSEMBLY / CARRIER CONTROL PANEL 108 (233)

e
9 851 529 29 SWITCH ZB2-BD2 3
10 885 343 49 SWITCH BODY (CONTACT BLOCK) ZB2-BZ103 (2S) 3
11 887 897 59 SWITCH 1
12 818 635 09 SWITCH BODY (CONTACT BLOCK) ZB2-BW065 1
13 888 108 19 PUSH BUTTON 1
. . . . .
14 852 032 19 PUSH BUTTON XB2-BP21NORMET 55128607 1
15 550 076 08 CABLE ENTRY M25, 4x7mm 5
16 550 260 31 SUPPORT TRAMMING PANEL 2

550 268 23 fD

550 268 23 fD

e
1 770 053 18 HOUSING DRIWING CONTROL BOX 1
2.1 615 095 23 SEAL KIT FOR STEERING VALVE 1
9 551 612 60 STEERING WHEEL D=250 1
10 551 612 61 CENTER Cover for steering wheel (D=250) 1
. . . . .
12 777 506 60 STEERING SHAFT SECTION 8 PAGE 112 1
21 868 731 69 PRESSURE GAUGE CONNECTOR 1/4" 1
30 817 094 69 STRAIGHT THREAD ADAPTER 1/2 x3/4-16 JIC 2063-8-8 4
31 817 183 59 SWIVEL NUT ELBOW 90 JIC 3/4-16 2
. . . . .
176 800 525 79 HEXAGON HEAD BOLT M10x40 m8.8 SFS2064 4

777 506 60 a
111 (233) STEERING SHAFT 101208

777 506 60 a
101208 STEERING SHAFT 112 (233)

e
*100010 851 281 89 DOUBLE LOCK WASHER M8 1
*100020 736 902 25 NUT HmZ 18/150 DEC. ZB 1
*100030 777 505 12 KEY -DIRECTION 1

550 852 23 a
113 (233) ADAPTER ASSEMBLY / PRIORITY VALVE 101208

550 852 23 a
101208 ADAPTER ASSEMBLY / PRIORITY VALVE 114 (233)

e
1 550 852 01 VALVE Priority valve 1
5 817 163 39 ADAPTER TEE 3/4-16 JIC 1
. . . . .
7 853 780 09 TUBE END REDUCER 9/16JIC, 3/4X 1
8 818 001 09 NUT JIC 3/4-16 1
. . . . .

550 088 52 aA

550 088 52 aA

e
1 817 935 89 BASE PLATE 1
4 263 976 98 CENTER SECTION 1
4.1 804 249 59 O-RING 9,25X1,78 4
. . . . .
4.2 134 469 48 HEXAGON SOCKET SET SCREW M8X8 DIN 913 1
5 819 257 89 HEXAGON SOCKET HEAD SCREW M5X50 m10,9 DIN 912 12
6 871 241 09 HEXAGON SOCKET HEAD SCREW M5X70 m12.9 SFS 2219 4
. . . . .
13 881 140 79 PLUG R1/2", E336-1/2" 2
14 881 139 09 PLUG R3/8", E366-3/8" 1

886 388 29 aA

886 388 29 aA

e
*1 886 391 49 SOLENOID 2
*2 851 651 69 SPRING 6,7/1,1X13,9/5 2
*3 886 390 19 SEAL KIT INCL. PARTS 4, 5 1
*4 O-RING 2
*5 O-RING 4
. . . . .
*6 887 500 09 NUT INCL. PARTS 7 2
*7 O-RING 2

887 417 79

887 417 79

e
4 O-RING
5 O-RING
7 O-RING
*1 886 391 49 SOLENOID 1
*2 851 651 69 SPRING 6,7/1,1X13,9/5 2
. . . . .
*3 886 390 19 SEAL KIT INCL. PARTS 4 1
*6 887 500 09 NUT INCL. PARTS 7 1

783 203 19 a
121 (233) VALVE 101208

783 203 19 a
101208 VALVE 122 (233)

e
*1 777 225 41 VALVE 1
*1.1 777 225 92 SEAL KIT FOR PRESSURE RELIEF VALVE 1
*2 777 227 00 VALVE BLOCK 1

550 295 95 cC
123 (233) ADAPTER ASSEMBLY / PRESSURE RELIEF VALVE 101208

550 295 95 cC
101208 ADAPTER ASSEMBLY / PRESSURE RELIEF VALVE 124 (233)

e
1 783 203 19 VALVE SECTION 8 PAGE 122 1
3 865 407 99 ADAPTER (HYDRAULIC) JIC 3/4-16 1
4 819 563 69 UNION CROSS 8KTXS (3/4-16JIC) 1
5 853 780 09 TUBE END REDUCER 9/16JIC, 3/4X 2
. . . . .
6 818 001 09 NUT JIC 3/4-16 2
7 817 163 39 ADAPTER TEE 3/4-16 JIC 1

550 949 94 aB
125 (233) ASSEMBLY / BRAKE VALVE ASSEMBLY 101208

550 949 94 aB
101208 ASSEMBLY / BRAKE VALVE ASSEMBLY 126 (233)

e
1 550 936 55 BODY 1
2.1 550 637 29 COIL 24 VDC, 42 W, 1.75 A 1
2.2 550 637 25 SEAL KIT 1
. . . . .
4 816 769 59 STRAIGHT THREAD ADAPTER 1,1/16-12 JIC 1
5 879 178 69 STRAIGHT THREAD ADAPTER JIC 3/4 -16 2
6 817 163 39 ADAPTER TEE 3/4-16 JIC 3
8 818 001 09 NUT JIC 3/4-16 1
. . . . .
9 819 560 89 SWIVEL NUT ELBOW 90 1 1/16"-12 JIC 1

550 949 94 aB
127 (233) ASSEMBLY / BRAKE VALVE ASSEMBLY 101208

550 949 94 aB
101208 ASSEMBLY / BRAKE VALVE ASSEMBLY 128 (233)

e
1 550 936 55 BODY 1
2.1 550 637 29 COIL 24 VDC, 42 W, 1.75 A 1
2.2 550 637 25 SEAL KIT 1
. . . . .
6 817 163 39 ADAPTER TEE 3/4-16 JIC 3
8 818 001 09 NUT JIC 3/4-16 1
. . . . .

777 607 10 b
129 (233) ACCELERATOR PEDAL 101208

777 607 10 b
101208 ACCELERATOR PEDAL 130 (233)

e
*1 770 125 31 RUBBER BOOT 1
*2 550 699 01 REPAIR KIT 1
*3 770 125 30 BOX 1
*5 550 698 90 COVER RUBBER 1
*6 770 140 47 VALVE 1
. . . . .

550 294 78 aB
131 (233) ADAPTER ASSEMBLY / ACCELERATOR PEDAL 101208

550 294 78 aB
101208 ADAPTER ASSEMBLY / ACCELERATOR PEDAL 132 (233)

e
1 777 607 10 ACCELERATOR PEDAL SECTION 8 PAGE 130 1
5 816 739 29 NUT 9/16-18JIC 1
. . . . .
6 816 719 09 ADAPTER TEE 9/16-18 JIC 1

777 607 14 bB
133 (233) PEDAL ASSEMBLY 101208

777 607 14 bB
101208 PEDAL ASSEMBLY 134 (233)

e
100010 777 607 04 CHARGING VALVE 1
100020 777 607 12 PEDAL ASSEMBLY 1
100020.1 550 698 90 COVER RUBBER 1

550 292 55 fE
135 (233) ADAPTER ASSEMBLY / BRAKE PEDAL 101208

550 292 55 fE
101208 ADAPTER ASSEMBLY / BRAKE PEDAL 136 (233)

e
1 777 607 12 PEDAL ASSEMBLY 1
1.1 550 698 90 COVER RUBBER 1
2 738 083 50 ADAPTER 9/16-18 JIC / M14x1,5 4
4 816 719 09 ADAPTER TEE 9/16-18 JIC 3
. . . . .
6 816 739 29 NUT 9/16-18JIC 3
9 801 802 69 BONDED SEAL U 13,7X22X1,5 D2=15,4 1
10 323 580 03 CONNECTOR 1
. . . . .

550 836 49
137 (233) CHECK VALVE ASSEMBLY 101208

550 836 49
101208 CHECK VALVE ASSEMBLY 138 (233)

e
1 812 744 69 CHECK VALVE R1/2" 1
3 816 904 19 STRAIGHT THREAD ADAPTER F40X-S10-1/2" (7/16-20JIC) 1
5 812 553 99 SHUTTLE VALVE 22-1A-2 R1/4 IN 1
. . . . .

550 595 28 cD
139 (233) SEAT ASSEMBLY 101208

550 595 28 cD
101208 SEAT ASSEMBLY 140 (233)

e
1 550 439 13 BRACKET 1
2 550 009 87 ROTARY DRILLING DEVICE 1
3 807 801 99 SEAT 1
4 800 040 19 SLIDE RAIL 1
6 550 434 81 FITTING PIECE 1
. . . . .
7 550 441 67 PLATE 2
8 551 661 10 SEAT BELT 70mm 1
10 550 680 21 PLATE SEAT 1
11 550 680 22 PLATE SEAT 1
50 445 783 40 HEXAGON SOCKET HEAD SCREW M8X20 m8.8 SFS 2219 4
. . . . .
174 800 192 49 HEXAGON HEAD SCREW M10X30 DIN933 8.8ZN 4
. . . . .

321 561 11 D
141 (233) GAUGE ASSEMBLY 101208

321 561 11 D
101208 GAUGE ASSEMBLY 142 (233)

e
1 883 656 09 GAUGE 1
2 208 429 78 PLATE 1
3 265 125 18 COVER 1
10 800 454 49 HEXAGON HEAD SCREW SFS-ISO 4017 M4X10-8.8 4

321 561 16 D
143 (233) GAUGE ASSEMBLY 101208

321 561 16 D
101208 GAUGE ASSEMBLY 144 (233)

e
1 883 656 09 GAUGE 1
2 208 429 78 PLATE 1
3 265 125 18 COVER 1
4 322 397 68 BRACKET 1
10 800 454 49 HEXAGON HEAD SCREW SFS-ISO 4017 M4X10-8.8 4
. . . . .
12 801 774 59 LOCK NUT M6 3

550 233 05 bA
145 (233) SAFETY CANOPY ASSEMBLY 101208

550 233 05 bA
101208 SAFETY CANOPY ASSEMBLY 146 (233)

e
1 550 233 06 SAFETY CANOPY MACHINING ASSEMBLY, 06/TC06 1
2 550 233 07 BEAM SAFETY CANOPY SC06/RIGHT SIDE 1
3 550 233 08 OUTER PIPE SAFETY CANOPY SC06/LEFT SIDE 1
4 550 233 09 BEAM SAFETY CANOPY SC06 2
. . . . .
8 599 432 78 PIN 2
8.1 572 102 40 GREASE NIPPLE AR 1/8 2
8.2 422 064 80 CIRCLIP 28X1,5 2
9 550 260 22 LOCKING PIN SAFETY CANOPY 2
10 550 060 75 ADAPTER 9/16-18 (FEMALE)-9/16-18 (MALE) L=84 8
. . . . .
13 550 065 05 COVER PLATE 4
14 550 260 25 SPACER 4
20 550 259 47 RAILING SAFETY CANOPY 2
61 455 332 90 SCREW N:O 2 X 5 SMS 1549 4
. . . . .
574 421 181 30 WASHER 10,5 2
. . . . .
*60 390 065 78 SIGN 80X45 1

550 233 05 bA
147 (233) SAFETY CANOPY ASSEMBLY 101208

550 233 05 bA
101208 SAFETY CANOPY ASSEMBLY 148 (233)

e
1 550 233 06 SAFETY CANOPY MACHINING ASSEMBLY, 06/TC06 1
4 550 233 09 BEAM SAFETY CANOPY SC06 2
6 550 261 03 PIN SAFETY CANOPY 2
7 422 064 80 CIRCLIP 28X1,5 4
11 550 060 81 PIPE CLAMP STAUFF 3 22-PP DP-AS 4
. . . . .
12 800 250 89 HOSE 3/4" 4M 4
13 550 065 05 COVER PLATE 4
14 550 260 25 SPACER 4
36 550 091 22 LAMP 1
37 815 113 79 BULB 24V, 21W 1
. . . . .
574 421 181 30 WASHER 10,5 2

323 612 41 bF
149 (233) CYLINDER / D55 D32 LMIN1240 S850 101208

323 612 41 bF
101208 CYLINDER / D55 D32 LMIN1240 S850 150 (233)

e
1 323 595 77 CYLINDER TUBE 1
2 332 751 07 PISTON ROD 1
3 166 082 68 COVER 1
4 155 169 28 PISTON 1
5 205 351 28 LIMIT BUSHING D54 d40 L106 1
. . . . .
6 817 742 59 PISTON SEAL 55x39x18,4 1
7 806 599 09 U-SEAL 32-42-10 1
8 806 119 19 WIPER 32-45-10/7 1
9 522 153 80 O-RING 44,2X5,7-1 SMS 1586 1
10 817 741 29 O-RING 23,3X2,4 1
. . . . .
11 599 431 48 BEARING BUSHING D36 d28 L39,5 2
12 802 333 99 LOCK NUT M20X1 1
13 817 743 89 LOCK WASHER 1
14 572 102 40 GREASE NIPPLE AR 1/8 2
15 870 515 59 CHECK VALVE 1
. . . . .
15.1 871 694 39 SEAL KIT 1
16 853 812 29 STRAIGHT THREAD ELBOW 9/16-18JIC 2
*888 852 235 59 SEAL KIT INCL. PARTS 6-10 1

550 323 33 bB
151 (233) RETURN FILTER / TRANSMISSION OIL 101208

550 323 33 bB
101208 RETURN FILTER / TRANSMISSION OIL 152 (233)

e
1 866 813 09 RETURN FILTER 20abs 1
1.1 817 230 59 FILTER ELEMENT 1
2 866 659 59 INDICATOR 1
4 817 299 59 STRAIGHT THREAD ELBOW C40X-S25-3/4" 1
5 816 761 39 SWIVEL NUT MALE ADAPTER 1,1/16-12JIC 1
. . . . .
8 817 163 39 ADAPTER TEE 3/4-16 JIC 1
9 813 158 29 CHECK VALVE R3/4 16/0,1BAR 1
. . . . .

550 654 43
153 (233) WATER SEPARATOR ASSEMBLY 101208

550 654 43
101208 WATER SEPARATOR ASSEMBLY 154 (233)

e
1 550 378 36 WATER SEPARATOR SECTION 8 PAGE 156 1
5 811 294 69 ADAPTER (HYDRAULIC) HD 1260-12 R3/4" 1
6 811 292 09 LOCK NUT HD 1270-12 R3/4" 1
. . . . .
7 156 998 58 MOUNTING PLATE 1
8 865 413 99 ADAPTER (HYDRAULIC) UK=JIC 3/4-16 SK=R3/4" 1
9 800 348 19 BONDED SEAL U 27,2X36X2 D2=28,9 1
100 886 782 79 HOSE ASSEMBLY RW-06X04 00 1.5
*2 550 378 35 VALVE ASSEMBLY 1
. . . . .

550 378 36 b
155 (233) WATER SEPARATOR 101208

550 378 36 b
101208 WATER SEPARATOR 156 (233)

e
1 550 378 33 FILTER ELEMENT 1
2 550 378 34 CLOGGING INDICATOR 1
4 550 864 68 BOWL 1
5 550 968 94 LEVEL SIGHT INDICATOR 1
. . . . .

763 156 01
157 (233) CYLINDER / 56/100 S450 101208

763 156 01
101208 CYLINDER / 56/100 S450 158 (233)

e
*1 777 225 40 FLOW DIRECTIONAL VALVE 2
*2 751 331 59 PISTON SPECIFICATION 1
*3 784 022 10 SEAL Kit 1
*4 737 302 46 SPRING-TYPE STRAIGHT PIN ELASTIQUE E 6X40 1
*5 751 421 39 BODY 1
. . . . .
*8 756 221 78 PISTON ROD 1
*9 754 632 38 GUIDE 1
*10 750 131 63 PIN 1
*11 714 074 30 ROD END GK 30 DO 1
*13 757 030 35 SCREW 1
. . . . .

550 242 77 bB
159 (233) COLLECTING PIECE / RIGHT 101208

550 242 77 bB
101208 COLLECTING PIECE / RIGHT 160 (233)

e
1 323 491 38 COLLECTING TUBE 1
10 208 379 98 ADAPTER R1 1/2"-1 5/16"-12 UNF 1
12 881 142 29 PLUG R1" 1
. . . . .
14 881 140 79 PLUG R1/2", E336-1/2" 2
15 881 140 79 PLUG R1/2", E336-1/2" 1
18 802 284 39 USIT-SEAL 48,7X59X3 D2=50,8 1
. . . . .

550 242 79 bB
161 (233) COLLECTING PIECE / RIGHT 101208

550 242 79 bB
101208 COLLECTING PIECE / RIGHT 162 (233)

e
1 323 491 38 COLLECTING TUBE 1
10 208 379 98 ADAPTER R1 1/2"-1 5/16"-12 UNF 1
12 881 142 29 PLUG R1" 1
. . . . .
14 881 140 79 PLUG R1/2", E336-1/2" 2
15 881 140 79 PLUG R1/2", E336-1/2" 1
18 802 284 39 USIT-SEAL 48,7X59X3 D2=50,8 1
. . . . .

550 265 03 aA
163 (233) ADAPTER ASSEMBLY 101208

550 265 03 aA
101208 ADAPTER ASSEMBLY 164 (233)

e
1 322 274 38 DISTRIBUTOR 1
2 816 778 39 STRAIGHT THREAD ADAPTER 1,5/16-12JIC 1
3 881 143 59 PLUG R1 1/4",E336-1 1/4" 1
. . . . .

550 312 43 aA
165 (233) DISTRIBUTOR / AIR 101208

550 312 43 aA
101208 DISTRIBUTOR / AIR 166 (233)

e
1 289 012 98 COLLECTING PIECE 1
5 881 142 29 PLUG R1" 1
. . . . .
7 881 141 09 PLUG R3/4" 1

550 290 42 aB
167 (233) COLLECTING PIECE 101208

550 290 42 aB
101208 COLLECTING PIECE 168 (233)

e
1 161 490 88 COLLECTING PIECE 1
2 881 140 79 PLUG R1/2", E336-1/2" 2
. . . . .
6 871 692 89 PLUG R1/4", E336-1/4" 1
8 887 353 79 ADAPTER 90° 6-8C4OMXS (R1/2 - 9/16-18 JIC) 1

167 296 44 aG
169 (233) PRESSURE FILTER ASSEMBLY 101208

167 296 44 aG
101208 PRESSURE FILTER ASSEMBLY 170 (233)

e
1 815 583 49 PRESSURE FILTER 1
1.1 815 584 79 FILTER ELEMENT 1
1.2 869 305 49 SEAL KIT 1
3 816 628 69 INDICATOR 1
. . . . .
*2 815 584 79 FILTER ELEMENT 1

209 080 84 aHc
171 (233) OILER 101208

209 080 84 aHc
101208 OILER 172 (233)

e
1 550 884 02 AIR RECEIVER 16bar,V=10L, PED 97/23/EY 1
2 321 550 88 TOP PART 1
3 265 048 98 FILLING CAP 1
4 265 002 98 FILTER Filling filter 1
5 208 352 88 DIPSTICK KIT 1
. . . . .
6 208 341 48 SEAL D96 d78 s1,5 1
7 801 595 49 O-RING 56,20X3 1
8 872 523 29 SAFETY VALVE R1/4" 12BAR 1
9 321 731 48 BAND 2
10 801 802 69 BONDED SEAL U 13,7X22X1,5 D2=15,4 1
. . . . .
12 085 432 68 ADAPTER R1/4"-R1/4" 1
13 813 186 09 ELBOW ADAPTER 2047R-4 1
15 807 135 39 ADAPTER (HYDRAULIC) R1/4"XR1/2" 1
. . . . .
21 800 156 19 BALL VALVE R1/2IN 1
22 817 094 69 ADAPTOR JIC 3/4-16 1
23 813 184 49 ADAPTER (HYDRAULIC) 04010-8-8 (R1/2-R1/2) 1
. . . . .
24 813 187 29 ELBOW ADAPTER 2047R-8 1
25 811 300 09 ADAPTER (HYDRAULIC) RK1/2XR1/2 1
26 816 208 39 FITTING Insert Jic female-08-08 1
27 280 672 20 CLAMP 20 SMS 2298 1
28 803 152 39 HOSE 12/15.8 1.5
. . . . .
51 159 736 18 NOZZLE Nozzle piece, orifice D=4 2
52 133 390 98 ADAPTER 2
. . . . .
56 817 094 69 ADAPTOR JIC 3/4-16 2
57 800 348 19 BONDED SEAL U 27,2X36X2 D2=28,9 6
59 800 336 59 ADAPTER (HYDRAULIC) RK1XR1 1
61 800 349 49 USIT-SEAL 1
. . . . .
62 265 007 28 ADAPTER 1
63 858 880 89 ADAPTER TEE 7/16-20JIC 1
111 800 347 99 BONDED SEAL U 21,5X28,7X2,5 D2=23,15 3
131 814 024 79 ADAPTER (HYDRAULIC) R1/4"XR1/4" 1
. . . . .

209 080 84 aHc
173 (233) OILER 101208

209 080 84 aHc
101208 OILER 174 (233)

e
51 159 736 18 NOZZLE Nozzle piece, orifice D=4 2
52 133 390 98 ADAPTER 2
56 817 094 69 ADAPTOR JIC 3/4-16 2
57 800 348 19 BONDED SEAL U 27,2X36X2 D2=28,9 6
. . . . .
70 801 802 69 BONDED SEAL U 13,7X22X1,5 D2=15,4 2
72 813 186 09 ELBOW ADAPTER 2047R-4 1
75 813 422 19 NEEDLE VALVE R1/8 2
76 804 318 29 STRAIGHT THREAD ADAPTER 7/16-20 JIC 2
. . . . .
111 800 347 99 BONDED SEAL U 21,5X28,7X2,5 D2=23,15 3
112 811 293 39 ADAPTER (HYDRAULIC) R1/2" 2
113 322 467 68 BRACKET 1
114 811 291 89 LOCK NUT HD 1270-8 R1/2" 2
116 865 401 29 ADAPTER (HYDRAULIC) JIC3/4-16-R1/2" 2
. . . . .

209 080 84 aHc
175 (233) OILER 101208

209 080 84 aHc
101208 OILER 176 (233)

e
21 800 156 19 BALL VALVE R1/2IN 1
22 817 094 69 ADAPTOR JIC 3/4-16 1
26 816 208 39 FITTING Insert Jic female-08-08 1
. . . . .
27 280 672 20 CLAMP 20 SMS 2298 1
28 803 152 39 HOSE 12/15.8 1.5
62 265 007 28 ADAPTER 1
63 858 880 89 ADAPTER TEE 7/16-20JIC 1
111 800 347 99 BONDED SEAL U 21,5X28,7X2,5 D2=23,15 3
. . . . .
112 811 293 39 ADAPTER (HYDRAULIC) R1/2" 2
113 322 467 68 BRACKET 1
114 811 291 89 LOCK NUT HD 1270-8 R1/2" 2
116 865 401 29 ADAPTER (HYDRAULIC) JIC3/4-16-R1/2" 2

550 295 87 aB
177 (233) ADAPTER ASSEMBLY / ACCUMULATOR CHARGING VALVE 101208

550 295 87 aB
101208 ADAPTER ASSEMBLY / ACCUMULATOR CHARGING VALVE 178 (233)

e
1 777 607 04 CHARGING VALVE 1
5 550 299 75 PLUG M14x1,5 1
. . . . .
6 041 811 03 CONNECTOR 1
7 816 719 09 ADAPTER TEE 9/16-18 JIC 2
. . . . .

550 288 12 A
179 (233) PRESSURE SWITCH 101208

550 288 12 A
101208 PRESSURE SWITCH 180 (233)

e
1 866 395 09 PRESSURE SWITCH 2-20bar 1
3 816 719 09 ADAPTER TEE 9/16-18 JIC 1
4 816 739 29 NUT 9/16-18JIC 1
. . . . .

550 951 63 C
181 (233) LUBRICATION FITTING BLOCK / MEASURING ADAPTERS 101208

550 951 63 C
101208 LUBRICATION FITTING BLOCK / MEASURING ADAPTERS 182 (233)

e
1 550 287 26 LUBRICATION FITTING BLOCK 1
3 871 692 89 PLUG R1/4", E336-1/4" 3
. . . . .
6 817 096 19 PLUG 7/16-20JIC 2
7 851 983 29 ADAPTER TEE R6X-S6 1

550 941 17
183 (233) PRESSURE SWITCH 101208

550 941 17
101208 PRESSURE SWITCH 184 (233)

e
1 866 395 09 PRESSURE SWITCH 2-20bar 1
3 816 719 09 ADAPTER TEE 9/16-18 JIC 2
. . . . .
8 807 609 59 CHECK VALVE 9C-400-S-10 1
9 816 739 29 NUT 9/16-18JIC 1
. . . . .

208 244 04 aC
185 (233) FLUSHING VALVE ASSEMBLY 101208

e
4 157 759 08 BUSHING 4
7 803 233 79 HEXAGON HEAD BOLT M8x110 - 8.8 2
9 801 779 99 LOCK NUT M8 m8 DIN 985 2
. . . . .

168 187 42 D

168 187 42 D

e
1 095 503 18 BODY 1
2 090 389 58 SPOOL 1
3 522 057 60 O-RING 15,3X2,4 1
4 522 077 80 O-RING 19,2X3 1
5 522 113 40 O-RING 29,2X3 2
. . . . .
6 085 399 88 END COVER 1
8 085 403 68 SEAL 1
9 085 407 78 BACKING PLATE 1
10 085 436 78 SPRING 1
. . . . .
11 155 495 28 ADAPTER "R1"" - R1/2""" 1
. . . . .
17 865 275 49 ADAPTER TEE 1,1/16-12JIC 1
18 817 166 19 TUBE END REDUCER 1 1/16"X3/4" JIC 1
19 851 983 29 ADAPTER TEE R6X-S6 1
21 853 385 39 NUT JIC 1,1/16-12 1
. . . . .

168 188 71 B

168 188 71 B

e
1 095 503 18 BODY 1
2 090 389 58 SPOOL 1
3 522 057 60 O-RING 15,3X2,4 1
4 522 077 80 O-RING 19,2X3 1
5 522 113 40 O-RING 29,2X3 2
. . . . .
6 085 399 88 END COVER 1
8 085 403 68 SEAL 1
9 085 407 78 BACKING PLATE 1
10 085 436 78 SPRING 1
. . . . .
11 155 495 28 ADAPTER "R1"" - R1/2""" 1
12 812 603 79 PLUG 1
13 812 605 29 PLUG 139-8 R1/2" 1
14 858 965 29 CHECK VALVE R3/4 1
. . . . .
20 801 802 69 BONDED SEAL U 13,7X22X1,5 D2=15,4 1
. . . . .
21 800 347 99 BONDED SEAL U 21,5X28,7X2,5 D2=23,15 1
22 800 348 19 BONDED SEAL U 27,2X36X2 D2=28,9 1

550 910 53 C
191 (233) HOSING / DOUBLE FLUSHING VALVE 101208

550 910 53 C
101208 HOSING / DOUBLE FLUSHING VALVE 192 (233)

e

550 282 40 cB
193 (233) CABLE ENTRY PLATE 101208

550 282 40 cB
101208 CABLE ENTRY PLATE 194 (233)

e
1 550 282 41 CABLE ENTRY PLATE 1
2 816 746 59 ADAPTER (HYDRAULIC) 1.1/16-12JIC 2
3 816 909 59 PLUG 1,1/16 12JIC 2
4 816 761 39 SWIVEL NUT MALE ADAPTER 1,1/16-12JIC 2
5 806 805 99 BALL VALVE R3/4IN 2
. . . . .
10 205 397 28 SIGN 1
11 205 396 08 SIGN 1

550 333 63 A
195 (233) HOUSING ASSEMBLY / CONTROL LEVER 101208

550 333 63 A
101208 HOUSING ASSEMBLY / CONTROL LEVER 196 (233)

e
1 550 140 73 GUARD 1
2 550 140 74 FASTENER 1
5 816 747 89 ADAPTER (HYDRAULIC) 7/8-14JIC 1
. . . . .
6 817 163 39 ADAPTER TEE 3/4-16 JIC 3
7 856 984 09 SWIVEL NUT MALE ADAPTER 3/4-16JIC 2
8 813 552 79 BALL VALVE 3/8 Pmax=350bar 2
10 816 709 09 SWIVEL NUT ELBOW 90 C6X-S14 1
. . . . .
11 550 199 32 INSTRUCTION PLATE 1
12 455 332 90 SCREW 2X5 SMS 1549 12
15 817 097 49 PLUG 3/4-16 JIC 1
. . . . .
17 550 199 33 INSTRUCTION PLATE 1
18 865 407 99 ADAPTER (HYDRAULIC) JIC 3/4-16 1
19.1 885 444 09 PRESSURE RELIEF VALVE 1
19.1.1 885 446 59 SEAL KIT 1
. . . . .
22 816 709 09 SWIVEL NUT ELBOW 90 C6X-S14 1

551 911 25
197 (233) CARRIER FRAME PARTS 101208

551 911 25
101208 CARRIER FRAME PARTS 198 (233)

e
1 550 249 89 CARRIER (REAR) 1
2 550 249 88 CARRIER (FRONT) 1
3 550 266 86 CONNECTION PARTS SECTION 8 PAGE 200 1
4 550 294 93 MOUNTING SECTION 8 PAGE 202 1
5 550 294 93 MOUNTING SECTION 8 PAGE 202 1
. . . . .
6 550 267 11 STEERING ASSEMBLY SECTION 8 PAGE 210 1
7 550 267 12 OSCILLATION BEAM ASSEMBLY SECTION 8 PAGE 216 1
10 550 267 13 DRIVING MOTOR AND GEARBOX ASSEMBLY SECTION 8 PAGE 220 1
20 731 012 01 WHEEL SECTION 8 PAGE 232 2
21 731 012 01 WHEEL SECTION 8 PAGE 232 2
. . . . .
31 705 344 50 PLATE 4
111 550 358 20 HEXAGON NUT M24 - 10.9 32

550 266 86 eD
199 (233) CONNECTION PARTS 101208

550 266 86 eD
101208 CONNECTION PARTS 200 (233)

e
1 550 239 81 PIN 1
2 550 239 82 PIN CARRIER 1
3 550 239 93 SPACER 2
4 550 239 94 BEARING PLATE 2
5 550 572 59 SPHERICAL PLAIN BEARING D130 d90 L60 2
. . . . .
7 550 251 62 HOSE SUPPORT ASSEMBLY 1
8 550 269 12 TRANSPORT SUPPORT 1
205 442 776 90 HEXAGON HEAD SCREW M12X35 8.8 SFS 2064 8

550 294 93 cA
201 (233) MOUNTING 101208

550 294 93 cA
101208 MOUNTING 202 (233)

e
1 710 550 03 AXLE SECTION 8 PAGE 204 1
3 550 424 33 STRAIGHT THREAD ADAPTER 9/16-18UNF, 3/4-16JIC 2
4 711 906 35 FLANGE 3-70-109 (EX3-7 2
5 711 906 36 SCREW 4
. . . . .

710 550 03 a
203 (233) AXLE 101208

710 550 03 a
101208 AXLE 204 (233)

e
1 770 076 05 AXLE HOUSING INNER RIGHT 1
2 770 076 06 AXLE HOUSING INNER LEFT 1
3 770 076 07 NUT 4
4 770 076 08 PIN 4
5 770 076 09 COATED WET DISC 8
. . . . .
8 770 076 13 PIN 4
9 770 076 14 REMOTE BRAKE CONTROLLER 4
10 770 076 15 HEXAGON NYLOC NUT 4
. . . . .
11 770 076 16 ROLLER 12
12 770 076 17 SPRING 8
13 770 076 18 AXLE HOUSING 2
14 770 076 19 PIN 2
15 770 076 20 AXLE HOUSING OUTER RIGHT 1
. . . . .
16 770 076 21 AXLE HOUSING OUTER LEFT 1
17 770 076 22 CROWN WHEEL 2
18 770 076 23 BEARING CUP 2
19 770 076 24 STUD 4
20 770 076 25 BEARING CUP 2
. . . . .
21 770 076 26 BOLT 2
22 770 076 27 SUPPORT SUN GEAR HOUSING 2
23 770 076 28 BEARING SEPARATION CONE 2
24 770 076 29 SHAFT 6
25 770 076 30 PIN 6
. . . . .
26 770 076 31 WASHER 12
27 770 076 32 SPACER 6
28 770 076 33 PLANET GEAR 6
29 770 076 34 BACKING RING 2
30 770 076 35 WASHER 2
. . . . .
31 770 076 38 SPACER 2
32 770 076 39 WASHER 2
33 770 076 40 SEAL 2
34 770 076 41 PISTON ROD BRAKE CONTROL 2
35 770 076 42 PIN 2
. . . . .
36 770 076 43 BOLT 22
37 770 076 44 DRIVE LINE 2
38 770 076 45 SCREW 24
39 770 076 46 SEAL 2
. . . . .
41 770 076 48 SEAL 2
42 770 076 49 BOLT 12
43 770 076 50 RECONDITIONING PART 2
44 770 076 51 WASHER 4
45 770 076 52 BOLT 4
. . . . .
710 550 93 CYLINDER SECTION 8 PAGE 208 2

710 550 03 a
205 (233) AXLE 101208

710 550 03 a
101208 AXLE 206 (233)

e
46 770 076 65 AXLE HOUSING 1
47 770 076 66 PLUG MAGNETIC 1
48 770 076 67 PLUG 2
49 770 076 68 PLUG 1
50 770 076 69 PLUG 1
. . . . .
51 770 076 71 BEARING CUP 1
54 770 076 75 DIFFERENTIAL CASE 1
55 770 076 76 BOLT 12
. . . . .
56 770 076 77 NUT 12
57 770 076 78 BOLT 8
58 770 076 79 CROWN WHEEL 1
59 770 076 80 GEAR 1
60 770 076 81 GEAR 1
. . . . .
61 770 076 82 WASHER 2
62 770 076 83 BACKING RING 2
63 770 076 84 GEAR 4
64 770 076 85 WASHER 4
65 770 076 86 DIFFERENTIAL CROSS 1
. . . . .
66 770 076 87 BALL BEARING 1
67 770 076 88 BACKING RING 1
69 770 076 90 HALF COUPLING SLEEVE 1
70 770 076 91 BEARING CUP 1
. . . . .
71 770 076 92 BEARING CUP 1
72 770 076 94 SPACER 1
73 770 076 95 O-RING 1
75 770 076 97 SEAL 1
. . . . .
76 770 077 01 HALF COUPLING SLEEVE 1
77 770 077 02 SEAL 1
78 770 077 03 FLANGE 1
79 770 077 04 SEAL 1
80 770 077 05 WASHER 1
. . . . .
81 770 077 06 NUT 1
82 770 077 07 BOLT 6
83 770 077 08 WASHER 6
84 770 077 09 ADAPTER DIFFERENTIAL 1
85 770 077 10 SPRING 1
. . . . .
86 770 077 11 BEVEL GEAR SET 1
87 770 077 12 WASHER 1
88 770 077 13 BACKING RING 1
90 770 077 14 COVER 1
91 770 077 15 NUT 1
. . . . .
92 770 077 16 SCREW 1
93 770 077 17 WASHER 1
94 770 077 18 SHAFT 1
95 770 077 19 SEAL 1
96 770 077 20 WASHER 1
. . . . .
98 770 077 21 BACKING RING 1
99 770 077 22 PIN 1
100 770 077 23 REMOTE BRAKE CONTROLLER 1
101 770 077 24 BEARING CUP 1
102 770 077 25 SHIM 1
. . . . .
710 550 93 CYLINDER SECTION 8 PAGE 208 2

710 550 93
207 (233) CYLINDER 101208

710 550 93
101208 CYLINDER 208 (233)

e
1 770 072 78 SPRING 1
2 770 072 90 BLEEDER PLUG 1
3 770 072 93 BLEEDER SCREW 1
4 770 073 00 NUT 1
5 770 073 01 NUT 1
. . . . .
6 770 073 02 SPRING 1
7 770 073 04 PLUG 1
8 770 073 05 FIXING STRAP 1
9 770 073 06 NUT 2
10 770 073 07 WASHER 2
. . . . .
11 770 073 08 NUT 2
12 770 073 09 CYLINDER ROD 1
13 770 073 18 STOP 1
14 770 073 21 PROTECTOR 1
15 770 073 22 BLEEDER SCREW 1
. . . . .
16 770 073 23 PLUG 1
17 770 077 28 SUPPORT 1
18 770 077 29 SUPPORT 1
19 770 077 30 REPAIR KIT 1

550 267 11 eD
209 (233) STEERING ASSEMBLY 101208

550 267 11 eD
101208 STEERING ASSEMBLY 210 (233)

e
21 700 123 30 AXLE LOCKATING PIN 4
23 702 126 53 BUSHING D40/50 Th:4 /Jacks Q 4
25 865 683 09 PLUG R1/8" 2
26 858 881 09 ADAPTER TEE JIC 3/4-16 2
. . . . .
*20 763 180 69 CYLINDER SECTION 8 PAGE 214

550 283 42 bA
211 (233) CYLINDER / ADAPTERS ASSEMBLY 101208

550 283 42 bA
101208 CYLINDER / ADAPTERS ASSEMBLY 212 (233)

e

763 180 69
213 (233) CYLINDER / 80/45, S337 101208

763 180 69
101208 CYLINDER / 80/45, S337 214 (233)

e
*1 714 074 40 BALL & SOCKET JOINT 2
*2 737 302 54 SPRING-TYPE STRAIGHT PIN 1
*3 751 331 58 PISTON 1
*5 754 632 35 GUIDE 1
*6 756 253 88 PISTON ROD 1
. . . . .
*7 784 019 23 SEAL 1

550 267 12 fA
215 (233) OSCILLATION BEAM ASSEMBLY 101208

550 267 12 fA
101208 OSCILLATION BEAM ASSEMBLY 216 (233)

e
1 795 200 74 EQUALIZER LEVER SECTION 8 PAGE 218 1
2 700 123 32 AXLE LOCKATING PIN D60 L=415 1
4 705 344 14 MOUNTING PLATE 1
5 550 509 21 SPACER RING OSCILLATION BEAM ASSEMBLY 2
7 811 239 49 GREASE NIPPLE AM6 DIN 71412 2
. . . . .
10 550 268 52 LIMITER REAR FRAME/REAR AXLE 2
174 800 192 49 HEXAGON HEAD SCREW M10X30 DIN933 8.8ZN 2
205 442 776 90 HEXAGON HEAD SCREW M12X35 8.8 SFS 2064 4
. . . . .
*3 702 126 88 SPACER D70 d60 L70 2

795 200 74
217 (233) EQUALIZER LEVER 101208

795 200 74
101208 EQUALIZER LEVER 218 (233)

e
100010 702 126 88 SPACER D70 d60 L70 2
100020 705 344 50 PLATE 2

550 267 13 dA
219 (233) DRIVING MOTOR AND GEARBOX ASSEMBLY 101208

550 267 13 dA
101208 DRIVING MOTOR AND GEARBOX ASSEMBLY 220 (233)

e
1 550 288 17 HYDRAULIC MOTOR SECTION 8 PAGE 222 1
2 710 810 93 TRANSFER GEAR BOX SECTION 8 PAGE 226 1
5 550 267 49 DRIVE SHAFT SECTION 8 PAGE 228 1
6 550 267 50 DRIVE SHAFT SECTION 8 PAGE 230 1
. . . . .
512 550 443 77 LOCK NUT M12 m8 BH8 8
576 800 923 29 WASHER 15 SFS 2041 8
577 421 199 60 WASHER M17 4
850 065 304 86 HEXAGON HEAD BOLT M16X50 - 8.8 , ISO 4014 4
. . . . .
860 866 117 29 HEXAGON SOCKET HEAD BOLT M12X35 - 12.9 8

550 288 17 bA
221 (233) HYDRAULIC MOTOR 101208

550 288 17 bA
101208 HYDRAULIC MOTOR 222 (233)

e
1 777 900 50 HYDRAULIC MOTOR SECTION 8 PAGE 224 1
2 855 488 69 CONNECTING PIECE AFS 403G R1" 2
2.1 550 212 53 O-RING 32,92x3,53 1
. . . . .
6 816 739 29 NUT 9/16-18JIC 1
9 738 083 50 ADAPTER 9/16-18 JIC / M14x1,5 1
. . . . .
13 550 317 75 STRAIGHT THREAD ADAPTER 4M12F82EDMXS 2
. . . . .
850 065 320 43 HEXAGON SOCKET HEAD SCREW M12X40 - 12.9 8

777 900 50 a
223 (233) HYDRAULIC MOTOR 101208

777 900 50 a
101208 HYDRAULIC MOTOR 224 (233)

e
*1 777 900 80 SEAL KIT 1
*2 777 900 81 VALVE ASSEMBLY 1
*3 777 900 82 SWIVEL HEAD 1

710 810 93 B
225 (233) TRANSFER GEAR BOX 101208

710 810 93 B
101208 TRANSFER GEAR BOX 226 (233)

e
1 770 081 35 SHIM KIT 1
2 770 081 36 COVER 1
3 770 081 37 WASHER 12
4 770 081 38 SCREW 12
5 770 081 39 WASHER 6
. . . . .
6 770 081 40 NUT 2
7 770 081 41 BALL BEARING ROULEMENT A BILLES 3
8 770 081 48 AXLE HOUSING 1
9 770 081 49 STUD 2
10 770 081 50 SPACER 2
. . . . .
11 770 081 51 DRIVE LINE 1
12 770 081 52 GEAR 1
13 770 081 53 COVER 1
14 770 081 54 BALL BEARING ROULEMENT A BILLES 1
15 770 081 55 BREATHER 1
. . . . .
16 770 081 56 SEAL 1
17 770 081 58 COVER 1
18 770 081 59 YOKE 2
19 770 081 60 O-RING 2
20 770 081 61 ROLLER BEARING 2
. . . . .
21 770 081 62 NUT 2
22 770 081 63 COVER 2
23 770 081 64 SEAL 2
24 770 081 65 PLUG 1
25 770 081 66 PLUG 1
. . . . .
26 770 081 67 SCREW 4
27 770 081 68 DRIVE LINE 1
28 770 081 69 DRIVE LINE 1
29 770 081 70 SPACER 1
30 770 081 71 EXTENSION SLEEVE 2
. . . . .
31 770 081 72 WASHER 10
32 770 081 73 SCREW 10
33 770 081 74 GEAR ENGRENAGE 1
. . . . .

550 267 49 a
227 (233) DRIVE SHAFT 101208

550 267 49 a
101208 DRIVE SHAFT 228 (233)

e
1 550 719 40 FLANGE 1
2 550 719 39 CROSS-LINK 2
3 550 719 42 MOUNTING PARTS Locking set 2

550 267 50 a
229 (233) DRIVE SHAFT 101208

550 267 50 a
101208 DRIVE SHAFT 230 (233)

e
1 550 719 41 FLANGE 1
2 550 719 39 CROSS-LINK 2
3 550 719 42 MOUNTING PARTS Locking set 2

731 012 01 a
231 (233) WHEEL 101208

731 012 01 a
101208 WHEEL 232 (233)

e
*1 731 015 69 AIR RUBBER TYRE TYRE+FLAP+TUBE 1
*2 731 015 58 RIM 1
*4 731 016 58 VALVE 1

Carrier

Uploaded by

Document Information

Original Description:

Original Title

Copyright

Available Formats

Share this document

Share or Embed Document

Sharing Options

Did you find this document useful?

Is this content inappropriate?

Copyright:

Available Formats

Carrier

Uploaded by

Copyright:

Available Formats

CARRIER

Sandvik Mining and Construction Oy, Drills Tampere © 2010

** 763 156 01 CYLINDER, 56/100 S450............................................................................................................................................. 158

Sandvik Mining and Construction Oy, Drills Tampere © 2010

Sandvik Mining and Construction Oy, Drills Tampere © 2010

Sandvik Mining and Construction Oy, Drills Tampere © 2010

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy, Drills Tampere © 2010

Sandvik Mining and Construction Oy, Drills Tampere © 2010

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy, Drills Tampere © 2010

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy, Drills Tampere © 2010

Sandvik Mining and Construction Oy, Drills Tampere © 2010

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy, Drills Tampere © 2010

Sandvik Mining and Construction Oy, Drills Tampere © 2010

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy, Drills Tampere © 2010

Sandvik Mining and Construction Oy, Drills Tampere © 2010

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy, Drills Tampere © 2010

Sandvik Mining and Construction Oy, Drills Tampere © 2010

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy, Drills Tampere © 2010

Sandvik Mining and Construction Oy, Drills Tampere © 2010

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy, Drills Tampere © 2010

Sandvik Mining and Construction Oy, Drills Tampere © 2010

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy, Drills Tampere © 2010

Sandvik Mining and Construction Oy, Drills Tampere © 2010

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy, Drills Tampere © 2010

Sandvik Mining and Construction Oy, Drills Tampere © 2010

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy, Drills Tampere © 2010

Sandvik Mining and Construction Oy, Drills Tampere © 2010

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy, Drills Tampere © 2010

Sandvik Mining and Construction Oy, Drills Tampere © 2010

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy, Drills Tampere © 2010

Sandvik Mining and Construction Oy, Drills Tampere © 2010

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy, Drills Tampere © 2010

Sandvik Mining and Construction Oy, Drills Tampere © 2010

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy, Drills Tampere © 2010

Sandvik Mining and Construction Oy, Drills Tampere © 2010

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy, Drills Tampere © 2010

Sandvik Mining and Construction Oy, Drills Tampere © 2010

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy, Drills Tampere © 2010

Sandvik Mining and Construction Oy, Drills Tampere © 2010

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy, Drills Tampere © 2010

Sandvik Mining and Construction Oy, Drills Tampere © 2010

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy, Drills Tampere © 2010

Sandvik Mining and Construction Oy, Drills Tampere © 2010
