Carrier

CARRIER
45377
TABLE OF CONTENTS PANTERA DP1500i 160113
11. CARRIER
* 551 962 47 OSCILLATION ASSEMBLY............................................................................................................................................ 1
** 551 970 41 CYLINDER ASSEMBLY, 140/90-190........................................................................................................................... 2
*** 551 546 58 CYLINDER ASSEMBLY, 140/90-190, LMIN=680MM.............................................................................................. 4
* 551 941 52 NSS IDLER WHEEL ASSEMBLY, TRACK.................................................................................................................... 6
** 814 675 09 WHEEL ASSEMBLY.................................................................................................................................................... 7
* 551 964 57 NSS TRACK ROLLER SET............................................................................................................................................ 8
** 887 939 89 ROLLER, TRACK......................................................................................................................................................... 10
* 551 722 98 BEAM, CRAWLER, TRACK BEAMS.............................................................................................................................. 12
* 551 964 24 NSS TRACKS, TRIPLE GROUSER 400MM................................................................................................................... 13
** 550 580 92 TRACK CHAIN, TRIPLE GROUSER 400MM.............................................................................................................. 14
* 552 034 84 NSS GEARBOX, LOHMANN.......................................................................................................................................... 16
** 552 034 85 FINAL DRIVE ASSEMBLY, LEFT................................................................................................................................ 18
** 552 034 86 FINAL DRIVE ASSEMBLY, RIGHT............................................................................................................................. 20
*** 887 912 79 FINAL DRIVE........................................................................................................................................................... 21
**** 550 005 00 GEAR, DRIVE...................................................................................................................................................... 24
**** 550 005 01 HYDRAULIC MOTOR.......................................................................................................................................... 27
* 551 806 16 GEARBOX, TRASMITAL................................................................................................................................................ 30
** 551 969 75 FINAL DRIVE ASSEMBLY, TRASMITAL, WITH BRAKE RELEASE, LEFT................................................................ 32
*** 550 469 89 FINAL DRIVE........................................................................................................................................................... 34
**** 551 922 16 MOTOR, HYDRAULIC, MAG 85VP-19................................................................................................................ 36
** 551 970 14 FINAL DRIVE ASSEMBLY, TRASMITAL, WITH BRAKE RELEASE, RIGHT.............................................................. 38
* BG 003 401 32 COOLER, MOUNTING.............................................................................................................................................. 40
** BG 003 401 34 COOLER ASSEMBLY, ENGINE............................................................................................................................ 44
*** 551 878 41 COOLER, ENGINE COOLER.................................................................................................................................. 48
*** BG 003 401 38 TANK, EXPANSION, SURGE TANK................................................................................................................. 49
*** 551 885 32 NSS MOTOR ASSEMBLY, HYDRAULIC................................................................................................................ 50
**** 551 828 04 MOTOR, HYDRAULIC......................................................................................................................................... 51
*** 551 887 00 VALVE ASSEMBLY................................................................................................................................................. 52
**** 550 830 87 BLOCK, VALVE, PROPORTIONAL PRESSURE RELIEF VALVE...................................................................... 53
*** BG 006 507 06 MOTOR ASSEMBLY, HYDRAULIC, -............................................................................................................... 56
**** BG 006 425 76 MOTOR, HYDRAULIC, 19CM3/REV GEAR MOTOR.................................................................................... 57
* BG 003 502 08 COOLER, OIL, MOUNTING...................................................................................................................................... 60
** BG 003 622 25 COOLER ASSEMBLY, -........................................................................................................................................ 64
*** 550 746 35 COOLER, OIL, HYDRAULIC / COMPRESSOR OIL................................................................................................ 67
*** 550 856 34 ASSEMBLY, HYDRAULIC OIL THERMOSTAT....................................................................................................... 68
*** 550 856 33 ASSEMBLY, COMPRESSOR OIL THERMOSTAT.................................................................................................. 69
*** 550 925 28 VALVE ASSEMBLY................................................................................................................................................. 70
** 550 860 70 HOSE FITTINGS KIT, AIR........................................................................................................................................... 71
** 550 976 57 MOUNTING, BIT BRACKET........................................................................................................................................ 74
* BG 002 456 12 CARRIER ASSEMBLY, -.......................................................................................................................................... 76
** BG 005 020 98 NSS SIDE MASK ASSEMBLY.............................................................................................................................. 80
*** 552 272 42 COVER, SIDE, MOUNTING, LEFT SIDE................................................................................................................ 84
*** 550 909 87 PUMP, HAND........................................................................................................................................................... 85
** BG 002 252 64 MOUNTING, BATTERY MOUNTING.................................................................................................................... 86
** BG 002 059 77 VALVE ASSEMBLY, COMPRESSOR CONTROL VALVE.................................................................................... 87
*** BG 002 058 19 VALVE, PRESSURE REDUCING, PROPORTIONAL....................................................................................... 88
** BG 002 537 97 MODULE, ELECTRIC, IO-BOARD MOUNTING.................................................................................................... 89
** 552 257 44 MOUNTING.................................................................................................................................................................. 92
* BG 003 742 52 BUSHING, FRAME, FRAME.................................................................................................................................... 94
* BG 002 544 90 NSS COVERS ASSEMBLY...................................................................................................................................... 98
** BG 002 354 04 NSS COVER ASSEMBLY, DPI............................................................................................................................. 100
*** 551 891 06 DOOR, SIDE, RIGHT FRONT DOOR..................................................................................................................... 103
*** 551 891 04 DOOR, REAR DOOR ASSEMBLY.......................................................................................................................... 106
*** BG 004 198 00 NSS FRAME ASSEMBLY, PANTERA DPI....................................................................................................... 108
**** 551 891 73 NSS CORNER, CORNER PIECE........................................................................................................................ 110
***** BG 004 197 81 NSS LATCH, LATCH ASSEMBLY............................................................................................................. 111
**** BG 004 198 14 NSS BEAM.................................................................................................................................................... 112
**** BG 004 198 21 NSS FRAME ASSEMBLY, LEFT REAR CORNER....................................................................................... 114
**** BG 004 198 31 NSS FRAME ASSEMBLY, RIGHT REAR CORNER..................................................................................... 116
Sandvik Mining and Construction Oy, Drills Tampere © 2016

45377
**** BG 004 198 48 NSS BODY.................................................................................................................................................... 118

**** 550 566 88 NSS FRAME ASSEMBLY.................................................................................................................................... 120
*** BG 004 198 01 NSS HATCH, PANTERA DPI............................................................................................................................ 122
*** BG 004 198 02 NSS HATCH, PANTERA DPI............................................................................................................................ 124
*** BG 004 198 03 NSS COVER ASSEMBLY, PANTERA DPI ROOF BOX................................................................................... 126
**** BG 004 197 61 NSS FRAME ASSEMBLY.............................................................................................................................. 128
**** BG 004 197 85 HATCH, HATCH ASSEMBLY........................................................................................................................ 130
*** BG 004 198 04 NSS DOOR, SIDE, LEFT FRONT DOOR ASSEMBLY..................................................................................... 131
*** BG 004 198 05 DOOR, SIDE, LEFT REAR DOOR.................................................................................................................... 132
*** BG 004 198 06 DOOR, SIDE, RIGHT REAR DOOR................................................................................................................. 134
*** BG 004 198 09 PLATE, COVER, ROOF PLATE, RIGHT REAR................................................................................................ 136
*** BG 004 198 10 HATCH, ROOF HATCH ASSEMBLY, RIGHT FRONT...................................................................................... 138
**** BG 004 199 20 LATCH, SAFETY, WIND LATCH ASSEMBLY.............................................................................................. 139
* 551 982 44 NSS MOUNTING, HYDRAULIC JACK OUTER PIPE.................................................................................................... 140
* BG 004 615 02 SIGNS AND DECALS ASSEMBLY, PANTERA DPI............................................................................................... 142
* BG 004 337 50 NSS SIGNS AND DECALS ASSEMBLY, BASIC DECALS.................................................................................... 154
** BG 004 338 44 NSS DECAL SET.................................................................................................................................................. 155
*** BG 004 338 82 NSS DECAL SET, PANTERA DP1500I............................................................................................................ 156
** BG 004 359 64 NSS SIGN SET..................................................................................................................................................... 158
** BG 004 368 53 NSS INSTRUCTION, YELLOW TAPE INSTALLATION........................................................................................ 172
* OPTIONAL EQUIPMENT.................................................................................................................................................................... 179
** 550 746 42 GUIDE, TRACK, 1 PAIR.............................................................................................................................................. 179
* BG 006 235 54 NSS COVER ASSEMBLY, COVER PLATE MOUNTING........................................................................................ 182

45377

551 962 47 aA
1 (183) OSCILLATION ASSEMBLY 160113
5
2
3
10
Ref. Part no. Description EN Standard designation Qty

e
1 550 781 96 FLANGE 2
2 851 068 09 WASHER, LOCK, DOUBLE M12 16
3 442 776 90 HEXAGON HEAD SCREW M12X35 - 8.8 16
4 551 970 41 CYLINDER ASSEMBLY SECTION 11 PAGE 2 2
5 551 693 28 PIN, TAPER D70 / L171 4
. . . . .
6 551 675 77 SHIM 1mm 2

551 970 41 a
160113 CYLINDER ASSEMBLY / 140/90-190 2 (183)

e
1 551 546 58 CYLINDER ASSEMBLY SECTION 11 PAGE 4 1
2 856 040 09 STRAIGHT THREAD ADAPTER G 3/8 in x JIC 9/16-18 1
3 817 180 79 ELBOW, SWIVEL NUT 9/16-18 JIC 1
5 817 183 59 SWIVEL NUT ELBOW 90 JIC 3/4-16 2
. . . . .
6 816 713 49 STRAIGHT THREAD ELBOW G3/8 x JIC 9/16-18 1

551 546 58 bB
3 (183) CYLINDER ASSEMBLY / 140/90-190, LMIN=680MM 160113
1 10 15 40
VIEW X VIEW Y
47 39
17 5
35
22
39
21
20
23
21
22
18
VIEW X VIEW Y
26
28
25 A
24
30 A
6
27
2 10 15 40
A-A

551 546 58 bB
160113 CYLINDER ASSEMBLY / 140/90-190, LMIN=680MM 4 (183)

e
1 551 546 60 CYLINDER TUBE ASSEMBLY 140/90-190, Lcta=546 1
2 551 546 59 PISTON ROD ASSEMBLY 140/90-190, Lpra=520mm 1
5 550 946 20 PISTON D140, Medium Duty 1
6 551 546 34 COVER, FRONT Ø140 / Ø90 1
10 815 589 09 BEARING, PLAIN 2
. . . . .
15 802 353 09 CIRCLIP 105X4 4
17 448 160 00 HEXAGON SOCKET SET SCREW M10X20 - 12.9, dog point 1
18 448 473 80 HEXAGON SOCKET SET SCREW M10X10 1
20 885 047 79 SEAL, PISTON 140x119x8 1
21 550 952 82 PISTON GUIDE RING D140 d135 L15 2
. . . . .
22 551 534 26 PISTON DIRT RING 9,7x4 2
23 550 954 84 O-RING 53.34X5.33 1
24 550 990 60 SEAL, ROD D=105, d=90, L=12.5 1
25 550 990 58 GUIDE RING, PISTON ROD D=95, d=90, L=25 1
26 551 534 57 RING, WIPER 9,7x4 1
. . . . .
27 560 289 49 SEAL 90/100x10 1
28 550 955 01 SEAL 140X12.3 1
30 550 955 42 O-RING 155x2,5 1
35 551 506 66 VALVE, PRESSURE RELIEF 2
35.1 551 506 76 SEAL KIT 1
. . . . .
39 885 093 09 VALVE, DIRECTIONAL 2/2 2
40 572 102 40 NIPPLE, GREASE AR 1/8 1
47 881 139 09 PLUG G3/8 4
*200 551 808 70 SEAL KIT 140/90 1

551 941 52 bB NSS
5 (183) IDLER WHEEL ASSEMBLY, TRACK 160113
5 4 3 2 1
1
3 2
3 2
4 5
A A
SECTION A - A

551 941 52 bB NSS
160113 IDLER WHEEL ASSEMBLY, TRACK 6 (183)

e
1 814 675 09 WHEEL ASSEMBLY SECTION 11 PAGE 7 2
2 866 631 19 NIPPLE, GREASE 2
3 866 632 49 GASKET 2
4 AF0 010 0739 SCREW, HEXAGON HEAD, FULL THREAD M12X45 - 8.8 Zn 4
5 AF0 300 0122 WASHER, LOCK, PAIR NL12-sp-350-HV Zn 4
. . . . .

814 675 09 bA
7 (183) WHEEL ASSEMBLY 160113
21 22
1
2
5 8
7 10
9
6
3 4
23
24
20

e
1 814 676 39 CYLINDER 1
1.1 815 011 99 WIPER LH 237 1
1.2 815 012 19 SEAL RING LH 238 1
2 814 995 09 SHOCK ABSORBER 1
3 853 064 09 WHEEL, IDLER 1
. . . . .
4 815 006 19 SHAFT 1
5 815 010 69 SLIDE 2
6 815 007 49 BUSHING 2
7 815 009 09 O-RING 2
8 853 065 39 CLEVIS 1
. . . . .
9 815 008 79 SEAL KIT 2
10 870 295 49 PIN, LOCKING 2
20 886 671 09 WHEEL, IDLER INCL. PARTS 3-10 1
*21 866 631 19 NIPPLE, GREASE 1
*22 866 632 49 GASKET 1
. . . . .
*23 800 635 09 CONNECTOR PART 1
*24 800 634 89 HOSE 1

551 964 57 bB NSS
160113 TRACK ROLLER SET 8 (183)
1 2 3

e
1 887 939 89 ROLLER, TRACK SECTION 11 PAGE 10 16
2 442 926 00 HEXAGON HEAD SCREW M16X1,5X70 - 8.8 64
3 AF0 300 0034 WASHER, LOCK, PAIR NL16 64

887 939 89 eA
9 (183) ROLLER, TRACK 160113
1 3 4
1

887 939 89 eA
160113 ROLLER, TRACK 10 (183)

e
1 550 005 86 BUSHING 2
2 550 005 87 O-RING 2
3 550 005 88 SEAL KIT 2
4 551 965 13 PIN, LOCKING 2
5 551 965 14 PLUG 1
. . . . .

551 722 98 cA
11 (183) BEAM, CRAWLER / TRACK BEAMS 160113
9 8
7 4
3
4
3
8 7
2 9
1
26
5
C D
SECTION D-D
C D
27
SECTION C-C

551 722 98 cA
160113 BEAM, CRAWLER / TRACK BEAMS 12 (183)

e
1 551 794 12 BEAM, CRAWLER machining, left 1
2 551 734 08 BEAM, CRAWLER machining, right 1
3 550 576 16 BEARING, PLAIN WB 802 220660, D=195, d=190, L=60 8
4 572 102 40 NIPPLE, GREASE AR 1/8 2
5 804 318 29 STRAIGHT THREAD ADAPTER 7/16-20 JIC 4
. . . . .
7 551 574 14 PLATE 2
8 800 470 59 HEXAGON HEAD SCREW M12x30 - 8.8 10
26 592 012 47 HOSE ASSY 2SC04MS AB-540-JIC 1
27 592 012 47 HOSE ASSY 2SC04MS AB-540-JIC 1
. . . . .

551 964 24 NSS
13 (183) TRACKS / TRIPLE GROUSER 400MM 160113

e
1 550 580 92 TRACK CHAIN SECTION 11 PAGE 14 4

550 580 92 a
160113 TRACK CHAIN / TRIPLE GROUSER 400MM 14 (183)
9
8 10
2 3 6
5 4
1 7

e
1 814 996 39 TRACK LINK 43
2 814 997 69 TRACK LINK 43
3 814 998 99 PIN 42
4 814 999 19 BUSHING 42
5 815 000 59 BUSHING Master 1
. . . . .
6 815 001 89 PIN Master 1
7 815 002 09 THRUST 2
8 815 003 39 HEXAGON HEAD BOLT 172
9 815 004 69 NUT, HEXAGON 172
10 551 679 03 PLATE, GROUND Triple grouser 400mm 43
. . . . .

552 034 84 bA NSS
15 (183) GEARBOX / LOHMANN 160113
3 4
3 4

552 034 84 bA NSS
160113 GEARBOX / LOHMANN 16 (183)

e
1 552 034 85 FINAL DRIVE ASSEMBLY SECTION 11 PAGE 18 1
5 390 503 08 SIGN 1
. . . . .

552 034 85 aA
17 (183) FINAL DRIVE ASSEMBLY / LEFT 160113
2
3
9 8
9 10
7
5

552 034 85 aA
160113 FINAL DRIVE ASSEMBLY / LEFT 18 (183)

e
1 887 912 79 FINAL DRIVE SECTION 11 PAGE 21 1
2 258 796 78 DRIVING GEAR 1
3 550 485 41 FLANGE 1
4 872 292 89 STRAIGHT THREAD ADAPTER 1,1/16-12JIC 2
5 867 503 29 STRAIGHT THREAD ADAPTER JIC 3/4-16 1
. . . . .
7 850 638 29 PLUG M18X1,5 1
10 800 541 89 HEXAGON HEAD BOLT M16X85 - 8.8 16
. . . . .

552 034 86
19 (183) FINAL DRIVE ASSEMBLY / RIGHT 160113
1 2 3
9 8
4
9 10

552 034 86
160113 FINAL DRIVE ASSEMBLY / RIGHT 20 (183)

e
2 258 796 78 DRIVING GEAR 1
3 550 485 41 FLANGE 1
4 872 292 89 STRAIGHT THREAD ADAPTER 1,1/16-12JIC 2
. . . . .
7 850 638 29 PLUG M18X1,5 1
. . . . .

887 912 79 bB
21 (183) FINAL DRIVE 160113
2 1

e
1 550 005 00 GEAR, DRIVE SECTION 11 PAGE 24 1
2 550 005 01 HYDRAULIC MOTOR SECTION 11 PAGE 27 1

550 005 00 b
23 (183) GEAR, DRIVE 160113
6 23 26 19
12 12 1 11 15 2 7 14 41 40
60
13
87
46
69 50
45
10
48
16
43
52
51
9
54
53
44
42
55
22
21
85 8
33
63 61 73 72 64 68 62 66 3
67 65 74 20
19
75 76 75
4 24 27
77 78 77

550 005 00 b
160113 GEAR, DRIVE 24 (183)

e
1 550 383 56 PLANET GEAR ASSEMBLY 5
2 550 383 24 GEAR WHEEL 3
3 550 124 32 GEAR WHEEL 1
4 550 121 28 NUT, LOCK 1
6 551 687 21 RING 1
. . . . .
7 550 790 70 PLANET CARRIER 1
8 550 414 24 COVER 1
9 888 228 69 ROLLER - 1
10 888 223 29 BEARING, ROLLER - 3
11 888 221 79 BEARING, ROLLER - 5
. . . . .
12 888 222 09 BEARING, ROLLER, TAPERED - 2
14 422 072 30 CIRCLIP 35X1,5 3
15 422 080 90 CIRCLIP 40X1,75 5
16 422 106 00 CIRCLIP 65X2,5 2
. . . . .
19 857 536 09 O-RING 250,00-3,00 1
20 551 685 79 SEAL, FACE 1
21 882 434 69 PLUG M18X1,5 DIN 908 2
22 882 435 99 RING, SEAL A18X22X1,5 2
. . . . .
24 813 627 09 BALL 2
26 550 794 05 WASHER 8
33 551 685 96 O-RING 235x3 1
40 550 125 56 GEAR WHEEL 3
. . . . .
41 550 790 71 PLANET CARRIER 1
42 550 299 02 GEAR WHEEL 1
43 550 115 32 GEAR WHEEL 1
44 888 220 49 SHAFT, INPUT - 1
45 550 081 93 SHAFT 3
. . . . .
46 888 230 59 BEARING, ROLLER 3
48 422 056 20 CIRCLIP 25X1,2 3

550 005 00 b
25 (183) GEAR, DRIVE 160113
6 23 26 19
12 12 1 11 15 2 7 14 41 40
60
13
87
46
69 50
45
10
48
16
43
52
51
9
54
53
44
42
55
22
21
85 8
33
63 61 73 72 64 68 62 66 3
67 65 74 20
19
75 76 75
4 24 27
77 78 77

550 005 00 b
160113 GEAR, DRIVE 26 (183)

e
50 888 229 99 PLATE, BACKING 3
51 883 294 79 COVER - 1
54 812 660 49 O-RING 16,3X2,4-1 SMS 1586 1
55 550 239 17 SPRING 1
. . . . .
60 550 697 00 SHAFT 1
61 551 828 77 PISTON - 1
62 550 041 11 COUPLING 1
63 550 710 19 SPACER RING 1
64 551 712 29 PLATE 1
. . . . .
65 551 828 78 DISC - 1
66 422 213 60 CIRCLIP 22X1 1
67 422 312 60 CIRCLIP 160X4 1
68 800 203 19 CIRCLIP 102X4 1
. . . . .
72 INNERDISK 5
73 OUTERDISK 17
74 888 216 09 SPRING 16
75 SUPPORTRING 126X135,4X1,4 1
76 PISTONSEAL 2
. . . . .
77 SUPPORTINGRING 150,6X160X1,4 1
78 PISTONSEAL 1
85 O-RING 150X4 1
87 O-RING 9,3X2,4 1
100 886 652 19 LAMELLA SET INCL. PARTS 72-78 1
. . . . .
200 886 653 49 SEAL KIT INCL. PARTS 19-20, 33, 54, 85-87 1

550 005 01 a
27 (183) HYDRAULIC MOTOR 160113
22
38 24 18
20
40 23

e
18 O-RING 120X2,5 1
20 886 656 29 SEAL KIT 28X40X6 1
22 O-RING 23,7X2,8 2
23 O-RING 10,82X1,78 2
24 SEAL 7,65X1,68 2
. . . . .
38 O-RING 150X4 1
40 USITRING 7,3X10,2X1 1
100 550 005 02 SEAL KIT INCL. PARTS 20-40 1

551 806 16 b
29 (183) GEARBOX / TRASMITAL 160113
3 4
2
3 4

551 806 16 b
160113 GEARBOX / TRASMITAL 30 (183)

e
5 551 884 33 SIGN towing trasmital 2
. . . . .

551 969 75 aA
31 (183) FINAL DRIVE ASSEMBLY / TRASMITAL, WITH BRAKE RELEASE, LEFT 160113
3 2
5 4
10 7
T2 P2 P1 T1
Ps
11

551 969 75 aA
160113 FINAL DRIVE ASSEMBLY / TRASMITAL, WITH BRAKE RELEASE, LEFT 32 (183)

e
2 550 485 42 FLANGE 1
3 550 485 43 WHEEL, DRIVE 1
. . . . .
7 810 491 29 PLUG R1/2 in 1
9 550 510 99 STRAIGHT THREAD ADAPTER R3/4-JIC 1,1/16-12 2
10 550 510 98 STRAIGHT THREAD ADAPTER R1/2-JIC 3/4-16 1
. . . . .

550 469 89 f
33 (183) FINAL DRIVE 160113
15
16
17
18
8
9
10
11
12
13
14
2
3
4
5
7
6

550 469 89 f
160113 FINAL DRIVE 34 (183)

e
1 551 900 40 SCREW M10x25 - 12.9 10
2 550 516 09 O-RING 3,53x278,99 1
3 551 915 31 PAD - 1
4 550 606 50 COVER Incl.parts: 2,3,5,6 1
5 550 516 20 WASHER, SEAL WASHER SEAL 2
. . . . .
6 550 516 15 BREATHER BREATHER PLUG 2
7 551 915 06 GEAR, SUN - 1
8 550 606 45 GEAR SHAFT 1
9 551 915 07 GEAR, REDUCTION Reduction assembly 1
10 551 915 09 GEAR, SUN - 1
. . . . .
11 551 915 11 GEAR, REDUCTION Reduction assembly 1
12 551 915 04 SCREW M20x100 - 10.9 4
13 551 914 84 GEAR, REDUCTION Incl.parts: 12 and 14 1
14 551 915 05 BUSHING - 4
15 551 915 34 HOUSING - 1
. . . . .
16 550 516 10 RING, SEAL 1
17 551 915 33 SPACER - 1
18 551 922 16 MOTOR, HYDRAULIC SECTION 11 PAGE 36 1

551 922 16
35 (183) MOTOR, HYDRAULIC / MAG 85VP-19 160113
19
18
17
16
200 15
14
13
12 600 20
11
10
9
300 8
7
6 300
400
5 600
26 700
500
4 800 100
3 120
2 800
1
25
24
23 800
22
21 700
46
45
130 44
800 43
42 130
150 52 140
53 120
100
54 120
52 140
51 800
55 50 800
45
52 49 800
56 140 48 800 130

57 800
43 800
58 47
28 100
100
700 36
29 37 800
36
150
38
59 120 39 800
52 38
60 800 140 100 40
100 27 61 41
30 800
111
100 31
110 32
800 33
34
35

551 922 16
160113 MOTOR, HYDRAULIC / MAG 85VP-19 36 (183)

e
58 551 924 29 SCREW M14x40 - 12.9 9
100 550 516 40 MOTOR, HYDRAULIC Incl.parts:27,56,110,120,130,140,150 1
110 551 924 30 VALVE ASSEMBLY Incl.parts: 31-35,111 1
111 551 924 31 PISTON ASSEMBLY - 1
120 551 924 33 ORIFICE Incl.parts: 3,54,55,59 1
. . . . .
130 551 924 36 SPOOL ASSEMBLY Incl.parts: 42-47 1
140 550 516 41 PLUG Incl.parts:52,56,57,60,61 1
150 551 924 46 RELIEF VALVE ASSEMBLY - 1
200 550 516 54 BLOCK, CYLINDER Incl.parts: 10-19 1
300 551 924 43 PLATE, GUIDE Incl.parts: 6-9 1
. . . . .
400 551 924 45 SHAFT - 1
500 550 516 43 SEAL, SHAFT SHAFT SEAL 1
600 550 516 46 BEARING ASSEMBLY Incl.parts: 5 and 20 1
700 551 924 47 BRAKE ASSEMBLY Incl.parts: 21,26,28,29 1
800 550 516 49 SEAL KIT Incl.parts:2,4,22-25,30,33,36-41,43,48-51,57,601
. . . . .

551 970 14 aA
37 (183) FINAL DRIVE ASSEMBLY / TRASMITAL, WITH BRAKE RELEASE, RIGHT 160113
7 10
T2 P2 P1 T1
Ps
11
3
2
6
8
4 5

551 970 14 aA
160113 FINAL DRIVE ASSEMBLY / TRASMITAL, WITH BRAKE RELEASE, RIGHT 38 (183)

e
2 550 485 42 FLANGE 1
3 550 485 43 WHEEL, DRIVE 1
. . . . .
7 810 491 29 PLUG R1/2 in 1
9 550 510 99 STRAIGHT THREAD ADAPTER R3/4-JIC 1,1/16-12 2
. . . . .

BG 003 401 32 bB
39 (183) COOLER / MOUNTING 160113
DP1500i
CAT C13
8
2
A DETAIL A
DP1100i / 900i
CAT C9.3 9
2
DETAIL B

BG 003 401 32 bB
160113 COOLER / MOUNTING 40 (183)

e
1 BG 003 401 34 COOLER ASSEMBLY SECTION 11 PAGE 44 1
2 BG 003 401 33 GUARD Left side 1

BG 003 401 32 bB
41 (183) COOLER / MOUNTING 160113
C
4
D DETAIL C
10 L= 300m m 12 11
DETAIL D 7
10 L= 50 mm 10 L= 300m m

BG 003 401 32 bB
160113 COOLER / MOUNTING 42 (183)

e
4 550 160 42 WASHER, LOCK, DOUBLE M8 sp 2
6 851 282 09 WASHER, LOCK, DOUBLEC M10 6
7 812 622 69 NUT, LOCK M10 m8 3
. . . . .
10 550 576 13 SEAL, RUBBER EPDM self adhesive seal 5x30mm 1
11 800 001 09 HEXAGON HEAD TAPPING SCREW 6,3X19 DIN 7976 7
12 884 293 59 WASHER M8 1

BG 003 401 34 dD
43 (183) COOLER ASSEMBLY / ENGINE 160113
14
15
1
19 18
18 19
901 902 903
16
17
28
11 30 29 10 12

BG 003 401 34 dD
160113 COOLER ASSEMBLY / ENGINE 44 (183)

e
1 551 878 41 COOLER SECTION 11 PAGE 48 1
2 551 848 47 BRACKET Cooler bracket right 1
3 551 848 60 BRACKET Cooler bracket left 1
4 BG 003 401 38 TANK, EXPANSION SECTION 11 PAGE 49 1
9 550 531 21 CONNECTING PIECE 2
. . . . .
10 BG 006 507 06 MOTOR ASSEMBLY, HYDRAULIC SECTION 11 PAGE 56 1
11 819 560 89 ELBOW, SWIVEL NUT 1 1/16 in -12 JIC 1
12 551 887 00 VALVE ASSEMBLY SECTION 11 PAGE 52 1
14 AF0 010 0524 SCREW, HEXAGON HEAD, FULL THREAD M10x20 - 8.8 Zn 4
. . . . .
17 AF0 300 0029 WASHER, LOCK, PAIR NL6-350-HV Zn 14
28 550 836 38 RACK, CABLE 120/60, zinc plated 1
. . . . .

BG 003 401 34 dD
45 (183) COOLER ASSEMBLY / ENGINE 160113
16
17
17
23
17 22
23
17
17 22
17
7 8
16
HOSE SET
900
ENGINE COOLER HOSES
27

BG 003 401 34 dD
160113 COOLER ASSEMBLY / ENGINE 46 (183)

e
7 552 036 94 BRACKET 2
8 552 019 99 PLATE 2
22 AF0 010 0133 SCREW, HEXAGON HEAD, FULL THREAD M6x16-8.8 Zn 8
. . . . .
23 801 774 59 NUT, LOCK M6 - 8 4
900 BG 003 704 61 NSS HOSE SET SECTION 4 PAGE 56 1

551 878 41 bB
47 (183) COOLER / ENGINE COOLER 160113
16
1 17
20
15
12
13 4
101 103
A
DETAIL A DETAIL C
102 101
B
102
DETAIL B DETAIL D

551 878 41 bB
160113 COOLER / ENGINE COOLER 48 (183)

e
*1 552 247 27 AIR COOLER Element 1
*4 552 247 34 HOUSING 1
*8 552 247 49 HOUSING, BEARING 1
*9 552 247 51 FAN D=1000 mm 1
*12 552 248 31 RADIATOR Element 1
. . . . .
*13 552 248 33 COOLER, FUEL Element 1
*15 552 248 36 PLATE, COVER Left 1
*16 552 248 37 PLATE, COVER Right 1
*17 552 248 39 BRACKET, BEARING 1
*20 552 248 40 GUARD, FAN Right 1
. . . . .
*101 816 702 09 STRAIGHCT THREAD ADAPTER 9/16-18 JIC 2
*102 817 094 69 STRAIGHT THREAD ADAPTER G 1/2 x JIC 3/4-16 2
*103 881 140 79 PLUG R1/2" 1

BG 003 401 38 bB
49 (183) TANK, EXPANSION / SURGE TANK 160113
1
13
12 2
14
18
14
12 13
20
16
5 4 5 3

e
1 BG 003 401 40 TANK, EXPANSION - 1
2 550 216 75 FILLING CAP 100 kPa o.drk 1
3 550 599 90 BOLT, BANJO R 1/4 2
4 550 599 88 ADAPTER, BANJO 22-RSN-08 2
5 550 421 99 SEAL, COPPER 13x17x1.5 4
. . . . .
6 550 758 72 HOSE D17mm 0.28
7 550 759 10 CLAMP, HOSE 16mm 2
12 550 591 25 ADAPTER, HYDRAULIC R1/4 / 9/16-18 JIC 2
13 550 421 99 SEAL, COPPER 13x17x1.5 2
. . . . .
16 816 700 59 STRAIGHT THREAD ADAPTER G 1 x JIC 1,5/16-12 1
18 851 975 79 STRAIGHT THREAD ELBOW 7/16-20 JIC 1
20 552 053 80 PLUG 3/4-16 UNF 1

551 885 32 aA NSS
160113 MOTOR ASSEMBLY, HYDRAULIC 50 (183)
1
2 3 4 5

e
1 551 828 04 MOTOR, HYDRAULIC SECTION 11 PAGE 51 1
2 234 570 48 FITTING 1,1/6-12JIC 1
3 522 077 80 O-RING 19.2x3.00 1
4 522 077 80 O-RING 19.2x3.00 1
5 234 570 48 FITTING 1,1/6-12JIC 1
. . . . .
7 445 774 60 HEXAGON SOCKET HEAD SCREW M6X20 - 8.8 1
. . . . .
. . . . .
. . . . .
23 816 711 99 ADAPTER, ELBOW G 1/4 x JIC 9/16-18 1

551 828 04
51 (183) MOTOR, HYDRAULIC 160113
NO ILLUSTRATION AVAILABLE

e
1 551 828 20 SEAL KIT For hydr.motor 1

551 887 00 bB
160113 VALVE ASSEMBLY 52 (183)
5
4 6

e
1 550 830 87 BLOCK, VALVE SECTION 11 PAGE 53 1
2 887 851 59 ADAPTER, ELBOW 1/2-14 x 1.1/6-12 2
3 879 235 79 SWIVEL NUT MALE ADAPTER 1/2 - 1,1/16-12 JIC 1
4 164 146 48 ADAPTER R1/2 in - 1 1/16 in -12 UNF, L=85 1
. . . . .
6 800 347 99 BONDED SEAL U 21,5x28,7x2,5 1

550 830 87 b
53 (183) BLOCK, VALVE / PROPORTIONAL PRESSURE RELIEF VALVE 160113
3
3.1
B A
R1 / 2 " 2 R1 / 2 "
1
2
2 1
y1
2.1 3
2.2 2 1
R1 / 2 " R1 / 2 "
V1 V2

e
2 551 523 90 VALVE Proportional, 207-6.9 bar, 24V, inverse 1
curve
2.1 551 527 06 SEAL KIT for 10-2 industrial valve 1
2.2 882 535 19 COIL 1
3 881 789 19 VALVE, CHECK 1
3.1 551 527 13 SEAL KIT 1
. . . . .

BG 006 507 06 aA
55 (183) MOTOR ASSEMBLY, HYDRAULIC / - 160113
A
6
3 2 1
5 4
SECTION A - A

BG 006 507 06 aA
160113 MOTOR ASSEMBLY, HYDRAULIC / - 56 (183)

e
1 BG 006 425 76 MOTOR, HYDRAULIC SECTION 11 PAGE 57 1
2 522 077 80 O-RING 19.2x3.00 2
3 234 570 48 FITTING 1,1/6-12JIC 2
5 AF0 050 0225 SCREW, SOCKET HEAD, HEXAGON M6X20 - 8.8 Zn 8
. . . . .
6 816 701 89 STRAIGHT THREAD ADAPTER G 1/4 x JIC 9/16-18 1

BG 006 425 76 a
57 (183) MOTOR, HYDRAULIC / 19CM3/REV GEAR MOTOR 160113
NO ILLUSTRATION AVAILABLE

e
1 551 828 20 SEAL KIT For hydr.motor 1

BG 003 502 08 bB
59 (183) COOLER, OIL / MOUNTING 160113
12 13 14 15
23
22
16
1 21
36 21 50
27 23
28
29
2
D
19 18 15 14 13 17 20 21 22
42
10 41 42
9 11 28 30
DETAIL D

BG 003 502 08 bB
160113 COOLER, OIL / MOUNTING 60 (183)

e
1 BG 003 622 25 COOLER ASSEMBLY SECTION 11 PAGE 64 1
2 552 125 55 MUDGUARD left side 1
6 550 784 89 SUPPORT, MOUNTING 1
9 817 099 09 ADAPTER, HYDRAULIC JIC 3/4-16 1
10 817 238 79 ADAPTER, HYDRAULIC 9/16-18 JIC 1
. . . . .
11 816 746 59 ADAPTER, HYDRAULIC 1,1/16-12 JIC 2
12 550 836 40 RACK, CABLE 120/60, zinc plated 2
. . . . .
16 550 836 48 SEAL BAND D-profile, 21x17 1
17 550 922 80 RACK, CABLE 1
18 801 774 59 NUT, LOCK M6 - 8 2
19 421 168 00 WASHER 8,4 2
. . . . .
22 800 820 19 NUT, HEXAGON M10 - 8 5
. . . . .
29 801 779 99 NUT, LOCK M8 - 8 9
36 BG 004 840 13 BRACKET Oil cooler side plate 1
41 BG 004 360 07 PLATE Oil cooler guide plate 1
42 560 327 25 SEAL, RUBBER 1.5
. . . . .
50 BG 003 504 76 PLATE - 1

BG 003 502 08 bB
61 (183) COOLER, OIL / MOUNTING 160113
8 29 28 27 4
35
31 32 24 25 26 E
DETAIL E
34 33 32 7 28 30

BG 003 502 08 bB
160113 COOLER, OIL / MOUNTING 62 (183)

e
3 550 860 70 HOSE FITTINGS KIT, AIR SECTION 11 PAGE 71 1
4 BG 003 510 61 PLATE, GUIDE - 1
5 552 125 69 PLATE, GUIDE Guide plate 1
7 551 958 23 PLATE 1
. . . . .
26 800 821 49 NUT, HEXAGON M12 - 8 8
29 801 779 99 NUT, LOCK M8 - 8 9
. . . . .
33 801 775 89 NUT, LOCK M16 - 8 2
. . . . .
35 550 976 57 MOUNTING SECTION 11 PAGE 74 1

BG 003 622 25 aA
63 (183) COOLER ASSEMBLY / - 160113
4
18
DETAIL A
23 21 20 30 31
2 3 1
A
402 152
151
408
401
409
405
403
C
406 153
899 HOSES 151 - 153
16
DETAIL C 17

BG 003 622 25 aA
160113 COOLER ASSEMBLY / - 64 (183)

e
1 550 746 35 COOLER, OIL SECTION 11 PAGE 67 1
2 550 856 34 ASSEMBLY SECTION 11 PAGE 68 1
3 550 856 33 ASSEMBLY SECTION 11 PAGE 69 1
4 550 925 28 VALVE ASSEMBLY SECTION 11 PAGE 70 1
16 817 226 09 STRAIGHT THREAD ADAPTER JIC 1,5/8-12 1
. . . . .
17 817 824 19 ADAPTER, TEE JIC 1,5/8-12 1
20 234 570 48 FITTING 1,1/6-12JIC 2
21 522 077 80 O-RING 19.2x3.00 2
23 816 711 99 ADAPTER, ELBOW G 1/4 x JIC 9/16-18 1
. . . . .
899 BG 003 622 26 HOSE SET SECTION 4 PAGE 52 1

BG 003 622 25 aA
65 (183) COOLER ASSEMBLY / - 160113
31 30 DETAIL D 20 21
11 10 11 12 13 18
DETAIL B

BG 003 622 25 aA
160113 COOLER ASSEMBLY / - 66 (183)

e
11 885 311 69 ADAPTER, TEE 1,7/8-12JIC 2
12 816 737 79 NUT 1,7/8-12JIC 1
13 550 716 42 REDUCER, TUBE END 1,7/8X1,1/16JIC 1
. . . . .
20 234 570 48 FITTING 1,1/6-12JIC 2
21 522 077 80 O-RING 19.2x3.00 2

550 746 35
67 (183) COOLER, OIL / HYDRAULIC / COMPRESSOR OIL 160113
2 1 3 5 6 7 4

e
*1 550 746 36 CORE, RADIATOR HYDRAULIC OIL 1
*2 550 746 37 CORE, RADIATOR COMPRESSOR OIL 1
*3 550 750 89 SHROUD, FAN 1
*4 550 750 87 GUARD, FAN 1
*5 550 746 38 FAN 1
. . . . .
*6 550 750 90 BRACKET 1
*7 550 264 85 MOTOR, HYDRAULIC 1
*7.1 886 816 49 SEAL KIT 1

550 856 34
160113 ASSEMBLY / HYDRAULIC OIL THERMOSTAT 68 (183)
5 3 1 6
4 2

e
1 550 746 45 THERMOSTAT 450 L/min, close 52 Celsius, 1 1/2" 1
2 858 324 09 SWIVEL NUT MALE ADAPTER 1,7/8-12JIC 1
3 885 311 69 ADAPTER, TEE 1,7/8-12JIC 1
4 816 707 49 SWIVEL NUT ELBOW 90 JIC 1,7/8-12, 90 deg 1
. . . . .
6 869 606 59 STRAIGHT THREAD ELBOW JIC 1,7/8-12 1

550 856 33 cC
69 (183) ASSEMBLY / COMPRESSOR OIL THERMOSTAT 160113
6 5 4 3 2 1

e
1 551 602 28 VALVE, THERMOSTAT Thermo by-pass valve G1-80C 1
2 816 703 39 SWIVEL NUT MALE ADAPTER 1,5/16-12 JIC 1
3 817 825 49 REDUCER, TUBE END 1,5/8X1,5/16JIC 1
4 816 913 09 NUT JIC 1,5/8-12 1
5 817 824 19 ADAPTER, TEE JIC 1,5/8-12 1
. . . . .
7 808 758 09 ADAPTER, HYDRAULIC R1X1,5/8-12JIC 1

550 925 28 cC
160113 VALVE ASSEMBLY 70 (183)
1
6
4
2
3
2

e
1 550 830 87 BLOCK, VALVE SECTION 11 PAGE 53 1
2 887 851 59 ADAPTER, ELBOW 1/2-14 x 1.1/6-12 2
3 879 235 79 SWIVEL NUT MALE ADAPTER 1/2 - 1,1/16-12 JIC 1
4 164 146 48 ADAPTER R1/2 in - 1 1/16 in -12 UNF, L=85 1
. . . . .
6 800 347 99 BONDED SEAL U 21,5x28,7x2,5 1

550 860 70 dD
71 (183) HOSE FITTINGS KIT, AIR 160113
13
12
18
17 16 15 14 18 10 11 1 2 19 20

e
1 550 781 16 SUPPORTING BLOCK 1
2 806 801 89 VALVE, BALL 1 in 1
10 812 007 19 ADAPTER, HYDRAULIC R1 in 1
11 812 006 99 NUT, LOCK R1 in 1
12 813 019 99 ADAPTER, HYDRAULIC R1xR1 1
. . . . .
13 811 583 09 ADAPTER, ELBOW R1-R1 1
14 816 910 19 CONNECTOR, FEMALE 1,5/16-12 JIC 1
15 816 708 79 SWIVEL NUT ELBOW 90 JIC 1,5/16-12, 90 deg 1
17 802 106 99 COUPLER R1 female thread 1
. . . . .
18 800 349 49 USIT-SEAL d34,3 D43 s2 2
20 853 815 09 SWIVEL NUT ELBOW 45 45deg ,1,1/16-12JIC 1

550 976 57 aA
73 (183) MOUNTING / BIT BRACKET 160113
5 4 3 1 6
2
3

550 976 57 aA
160113 MOUNTING / BIT BRACKET 74 (183)

e
1 550 908 72 BRACKET 3
2 550 576 13 SEAL, RUBBER EPDM self adhesive seal 5x30mm 1.8
4 801 779 99 NUT, LOCK M8 - 8 9
. . . . .
6 807 695 29 STRAP L=400 Black 3
7 850 953 99 EDGING PLATE MP 1000V 1.6

BG 002 456 12 fF
75 (183) CARRIER ASSEMBLY / - 160113
37 36
12
DETAIL B
20
30
E
A
11
40 35
24 9
8 41
28 25 21
DETAIL E
DETAIL A

BG 002 456 12 fF
160113 CARRIER ASSEMBLY / - 76 (183)

e
2 552 257 44 MOUNTING SECTION 11 PAGE 92 1
5 560 246 20 HORN 24-48VDC, 0,8A, 107dB(A) Constant tone 1
8 550 523 36 RACK, CABLE l=800 1
11 550 594 13 SUPPORT, TRANSPORT SHORT MODEL 1
. . . . .
12 BG 002 059 77 VALVE ASSEMBLY SECTION 11 PAGE 87 1
21 AF0 010 1444 SCREW, HEXAGON HEAD, PARTIAL M20x100-8.8 Zn 4
THREAD
25 AF0 190 0009 NUT, HEXAGON, PREVAILING TORQUE M20-8 Zn 6
. . . . .
THREAD
. . . . .
41 BG 005 165 01 PLATE 1

BG 002 456 12 fF
77 (183) CARRIER ASSEMBLY / - 160113
10
16
25
15 28
1
4
40 42 43
D 7
3 32 33
DETAIL D
100 HYDRAULIC DIAGRAM

BG 002 456 12 fF
160113 CARRIER ASSEMBLY / - 78 (183)

e
1 BG 005 020 98 NSS SIDE MASK ASSEMBLY SECTION 11 PAGE 80 1
3 562 064 19 SWITCH, MAIN Manual disconnect switch with red handle 1
4 BG 002 252 64 MOUNTING SECTION 11 PAGE 86 1
7 BG 002 456 21 BRACKET Bracket 1
10 550 724 61 BLOCK, SUPPORTING 1
. . . . .
15 BG 002 537 97 MODULE, ELECTRIC SECTION 11 PAGE 89 1
THREAD
25 AF0 190 0009 NUT, HEXAGON, PREVAILING TORQUE M20-8 Zn 6
. . . . .
42 AF0 140 0004 NUT, HEXAGON M6 - 8 Zn 1
43 AF0 250 0004 WASHER, PLAIN, LARGE M6-200 HV Zn 1
100 BG 003 685 65 HOSE SET SECTION 4 PAGE 16 1
. . . . .

BG 005 020 98 aA NSS
79 (183) SIDE MASK ASSEMBLY 160113
12
16 34
15 26
26 22 19 10
9 17 27
8
17 23 27
5 24 29 32
4 16 22 26

BG 005 020 98 aA NSS
160113 SIDE MASK ASSEMBLY 80 (183)

e
2 BG 005 021 02 PLATE, SIDE Rear right 1
3 550 581 84 COVER, SIDE 1
4 550 777 66 PLATE 1
5 550 777 65 PLATE 1
. . . . .
10 550 307 23 HOLDER 1
12 550 909 87 PUMP, HAND SECTION 11 PAGE 85 1
. . . . .
THREAD
22 AF0 200 0006 NUT, HEXAGON, PREVAILING TORQUE, ALL M12 - 8 Zn 6
METAL
. . . . .
. . . . .

BG 005 020 98 aA NSS
81 (183) SIDE MASK ASSEMBLY 160113
32 29 20 25
18 27
17 23 27
11
33
17 23 27
35 7
26 22 14
26 15 22 26 31
20
29 24 21 26 30

BG 005 020 98 aA NSS
160113 SIDE MASK ASSEMBLY 82 (183)

e
1 552 272 42 COVER, SIDE SECTION 11 PAGE 84 1
11 885 790 19 BUFFER, RUBBER M10, D=40, L=20 1
. . . . .
. . . . .
METAL
25 550 081 32 LATCH 1
. . . . .
. . . . .
METAL

552 272 42 bB
83 (183) COVER, SIDE / MOUNTING, LEFT SIDE 160113
3 1 2 5
7 L= 170 7 L= 1120
16
15
17 16 6 16 14 12 16
10 13 16 14
11 14
16
9
17 16

552 272 42 bB
160113 COVER, SIDE / MOUNTING, LEFT SIDE 84 (183)

e
1 552 132 04 COVER, SIDE Left side 1
2 552 171 39 PLATE Lock plate 1
3 552 171 40 PLATE - 1
4 552 132 78 PLATE, MOUNTING 1
. . . . .
. . . . .
. . . . .
17 800 820 19 NUT, HEXAGON M10 - 8 3

550 909 87 bAa
85 (183) PUMP, HAND 160113
1 7
8
3
10 5 6

e
1 550 909 72 BRACKET 1
2 810 197 09 PUMP, HAND 1
2.1 810 961 39 SEAL KIT 1
3 813 129 29 VALVE, BALL R3/4 1
5 816 746 59 ADAPTER, HYDRAULIC 1,1/16-12 JIC 1
. . . . .
7 816 768 29 STRAIGHT THREAD ADAPTER G 3/4 x JIC 1,1/16-12 2
10 592 010 41 HOSE ASSEMBLY, HYDRAULIC 1SN12MS AA-700-JIC 1
. . . . .

BG 002 252 64 aA
160113 MOUNTING / BATTERY MOUNTING 86 (183)
9 8 2
9 8
8
15
10 4 1 3 4 6 7 4 6 11

e
1 550 575 77 BRACKET 1
2 BG 002 252 74 COVER Cover assembly 1
3 551 707 32 RAIL, MOUNTING 1
4 551 705 48 CLIP Threaded rod 3
6 800 917 29 NUT, HEXAGON M8 - 8 3
. . . . .
7 814 951 69 BATTERY 12V, 185Ah, 1150 CCA (EN), 513x223x216 2
8 411 621 90 NUT, WING M8 3
11 442 761 40 HEXAGON HEAD BOLT M8X80-8.8 6
. . . . .
15 811 260 29 NUT, LOCK M12 4

BG 002 059 77 cC
87 (183) VALVE ASSEMBLY / COMPRESSOR CONTROL VALVE 160113
2
6
2
2

e
1 BG 002 058 19 VALVE, PRESSURE REDUCING SECTION 11 PAGE 88 1
6 816 722 29 ADAPTER, TEE JIC 9/16-18 1

BG 002 058 19 bB
160113 VALVE, PRESSURE REDUCING / PROPORTIONAL 88 (183)

e
*1 BG 002 058 27 VALVE SECTION G3/8" 1
*2 BG 002 058 26 CARTRIDGE, VALVE - 1
*3 BG 002 058 31 COIL 24 V, 2 pole, axial 1

BG 002 537 97 bB
89 (183) MODULE, ELECTRIC / IO-BOARD MOUNTING 160113
5 6

e
1 BG 002 915 71 BRACKET 1
4 446 860 80 SLOTTED PAN HEAD SCREW M6x20 - 5.8 4
*2 552 260 94 MODULE, INTERFACE S/n needed when ordering! 1
. . . . .

552 257 44 aA
91 (183) MOUNTING 160113
11
12
13
9
10
7
8

552 257 44 aA
160113 MOUNTING 92 (183)

e
9 507159 HOSE M26,500mm 1
10 280 675 00 CLAMP 32 1
11 801 543 49 CLAMP, PIPE 2
. . . . .

BG 003 742 52 fF
93 (183) BUSHING, FRAME / FRAME 160113
B
173 563
6
4
A
DETAIL A
4
2
564
213
2
7 5
DETAIL B
7 3
2
DETAIL C

BG 003 742 52 fF
160113 BUSHING, FRAME / FRAME 94 (183)

e
2 265 164 28 BUSHING, BEARING D125 d110 L54 4
3 133 948 28 BUSHING, BEARING 2
5 550 752 40 COVER 1
6 BG 003 524 24 HATCH Frame assembly 1
7 572 102 40 NIPPLE, GREASE AR 1/8 2
. . . . .
THREAD
*4 550 593 89 BUSHING D189.8 d170 L150 4
. . . . .

BG 003 742 52 fF
95 (183) BUSHING, FRAME / FRAME 160113
565
566

BG 003 742 52 fF
160113 BUSHING, FRAME / FRAME 96 (183)

e
8 BG 005 781 92 COVER Cover 1

BG 002 544 90 bB NSS
97 (183) COVERS ASSEMBLY 160113
26 25 21 9 21 25 26
44
43
21 22
31 30
31
8
32 21
33 25
13 12 11
26 31 30 3 50
31 30
30 31
7 30 31
50 2
30
31
24 32
21
20 40
41
42
30 31
5 21 23 6

BG 002 544 90 bB NSS
160113 COVERS ASSEMBLY 98 (183)

e
1 BG 002 354 04 NSS COVER ASSEMBLY SECTION 11 PAGE 100 1
2 550 908 24 CORNER (PIECE) BOX LEFT 1
3 550 908 23 CORNER (PIECE) BOX RIGHT 1
5 550 800 31 FASTENER, PIPING 1
6 550 565 35 PLATE, COVER 1
. . . . .
7 BG 004 690 36 COVER Roof cover 1
8 550 855 25 PLATE 2
9 550 855 26 PLATE 6
11 800 535 89 HEXAGON HEAD BOLT M12x80 - 8.8 1
. . . . .
13 800 821 49 NUT, HEXAGON M12 - 8 1
. . . . .
24 800 820 19 NUT, HEXAGON M10 - 8 1
25 850 602 39 STUD M10X40 - 8.8 12
26 812 622 69 NUT, LOCK M10 m8 12
. . . . .
32 801 779 99 NUT, LOCK M8 - 8 7
33 446 166 50 HEX.SOCKET HEAD CAP SCR. M8X30 4
40 446 703 80 HEXAGON SOCKET HEAD SCREW .A4-80 4
42 802 558 09 NUT, HEXAGON M6 - 8 4
. . . . .
43 551 982 85 WASHER C 25 2
44 551 982 84 WASHER G 25 2
50 550 149 49 LIGHT 24V/70W 4
50.1 806 693 69 BULB 24V/70W H3 1

BG 002 354 04 eF NSS
99 (183) COVER ASSEMBLY / DPI 160113
14 7 12
5 6 13
4
15 10
11
3
9
2
1

BG 002 354 04 eF NSS
160113 COVER ASSEMBLY / DPI 100 (183)

e
1 551 891 06 DOOR, SIDE SECTION 11 PAGE 103 1
2 550 677 94 CORNER BOX, WELDING 1
3 550 678 01 CORNER BOX, WELDING 1
4 551 891 04 DOOR SECTION 11 PAGE 106 1
. . . . .
. . . . .
11 BG 004 198 00 NSS FRAME ASSEMBLY SECTION 11 PAGE 108 1
12 BG 004 198 01 NSS HATCH SECTION 11 PAGE 122 1
13 BG 004 198 02 NSS HATCH SECTION 11 PAGE 124 1
14 BG 004 198 03 NSS COVER ASSEMBLY SECTION 11 PAGE 126 1
15 BG 004 198 04 NSS DOOR, SIDE SECTION 11 PAGE 131 1
. . . . .

BG 002 354 04 eF NSS
101 (183) COVER ASSEMBLY / DPI 160113
25 21
25 23
19 24
24 19
17 24 19
16
24
27
24 20
25 27
17 16
19 24 26
26
29
25 17 19 24 24 27
19 24 16
28 25
22 25

BG 002 354 04 eF NSS
160113 COVER ASSEMBLY / DPI 102 (183)

e
16 BG 004 198 05 DOOR, SIDE SECTION 11 PAGE 132 1
17 BG 004 198 06 DOOR, SIDE SECTION 11 PAGE 134 1
18 BG 004 198 07 PLATE, COVER Left front roof 1
19 BG 004 198 08 PLATE, COVER Roof plate 1
20 BG 004 198 09 PLATE, COVER SECTION 11 PAGE 136 1
. . . . .
21 BG 004 198 10 HATCH SECTION 11 PAGE 138 1
23 AF0 230 0005 WASHER, PLAIN, NORMAL M8-200 HV Zn 2
24 AF0 190 0004 NUT, HEXAGON, PREVAILING TORQUE M8 - 8 Zn 1
. . . . .
28 BG 002 036 55 SPRING, GAS 1300 N 3
29 BG 004 199 33 SPRING, GAS Gas spring assembly 3

551 891 06 A
103 (183) DOOR, SIDE / RIGHT FRONT DOOR 160113
7 8
5 4
3
2

e
1 550 706 17 DOOR 1
2 550 706 00 HINGE 2
3 550 567 48 HANDLE WBH Drop T-handle 1
. . . . .
6 550 741 05 SCREW 4

551 891 04 B
105 (183) DOOR / REAR DOOR ASSEMBLY 160113
9 16
9 11
19
17 18 14 15 5
12
13 9 10
2
8
1

551 891 04 B
160113 DOOR / REAR DOOR ASSEMBLY 106 (183)

e
1 550 677 73 DOOR 1
2 550 677 74 PLATE, SIDE 1
3 550 678 66 PLATE, SIDE 1
4 550 741 35 SUPPORT 2
5 550 741 20 SUPPORT 2
. . . . .
6 550 740 91 BUSHING 2
8 550 741 28 HINGE 3
. . . . .
12 AF0 050 0329 SCREW, SOCKET HEAD, HEXAGON M8x16-8.8 Zn 2
13 550 741 05 SCREW 8
. . . . .
17 550 845 07 STRIP 1

BG 004 198 00 cC NSS
107 (183) FRAME ASSEMBLY / PANTERA DPI 160113
19
7
9
19 5
11
6
10
17 13 13 18
12 8
19
4
2
3
1 13 18
SECTION M-M
13 18 13 18
13 13
15 13
15 15 4 21
13 18
SECTION N-N 13 16
SECTION D-D 18 13
SECTION K-K SECTION L-L
SECTION J-J SECTION I-I
M M K K
B B
J J
A D A
D I I
N N
14 13 13 14
15 13 14 13 13 14 13 15
SECTION A-A SECTION B-B

BG 004 198 00 cC NSS
160113 FRAME ASSEMBLY / PANTERA DPI 108 (183)

e
1 551 891 73 NSS CORNER SECTION 11 PAGE 110 1
2 551 891 76 FRAME ASSEMBLY Supporting block assembly 1
3 BG 004 198 14 NSS BEAM SECTION 11 PAGE 112 1
4 BG 004 197 92 SIDE, FRAME Side frame beam 1
. . . . .
6 551 891 78 FRAME ASSEMBLY Supporting block assembly 1
8 BG 004 198 37 PLATE, BACK 1
9 BG 004 198 41 SIDE, FRAME Side frame, right beam 1
10 BG 004 198 48 NSS BODY SECTION 11 PAGE 118 1
. . . . .
11 BG 004 198 51 FRAME Corner piece 1
12 550 566 88 NSS FRAME ASSEMBLY SECTION 11 PAGE 120 1
. . . . .
19 BG 004 198 52 SUPPORT Support for hinge 6
. . . . .

551 891 73 aA NSS
109 (183) CORNER / CORNER PIECE 160113
9 8
3
2
13
5 6 7
15
A
14
10 A
11 12
SECTION A-A

551 891 73 aA NSS
160113 CORNER / CORNER PIECE 110 (183)

e
1 551 891 74 BODY 1
2 550 705 91 HINGE 2
3 550 567 11 BUFFER, RUBBER 1
4 550 740 90 LATCH 1
. . . . .
10 AF0 070 0189 SCREW, SOCKET HEAD, COUNTERSUNK, M10x20-10.9 Plain 2
HEXAGON
. . . . .
13 BG 004 197 96 DOOR 1
14 BG 004 197 98 STOPPER Stopper for latch 1
15 BG 004 197 81 NSS LATCH SECTION 11 PAGE 111 1
. . . . .

BG 004 197 81 aA NSS
111 (183) LATCH / LATCH ASSEMBLY 160113
2 3 4

e
1 BG 004 197 79 LATCH 1
2 BG 004 197 80 KNOB 1

BG 004 198 14 aA NSS
160113 BEAM 112 (183)
2
4
3

e
1 BG 004 198 11 SUPPORT 1
2 BG 004 198 12 SUPPORT, WELDING Support for stopper 1
. . . . .

BG 004 198 21 aA NSS
113 (183) FRAME ASSEMBLY / LEFT REAR CORNER 160113
12 11
2
11 12 7 6 13
6
10 13
7 3
13 14

BG 004 198 21 aA NSS
160113 FRAME ASSEMBLY / LEFT REAR CORNER 114 (183)

e
1 BG 004 198 17 BODY 1
2 550 705 87 HOLDER 1
4 550 845 00 SUPPORT 1
5 550 845 01 SUPPORT 1
. . . . .
6 550 567 41 PAD, RUBBER 1
7 BG 004 198 20 PLATE, SUPPORT 1
METAL
. . . . .

BG 004 198 31 aA NSS
115 (183) FRAME ASSEMBLY / RIGHT REAR CORNER 160113
8 10
3
2
13 9
9 13
7
8 10 6
12
9 11
5
4

BG 004 198 31 aA NSS
160113 FRAME ASSEMBLY / RIGHT REAR CORNER 116 (183)

e
1 BG 004 198 30 BODY Right rear corner 1
2 550 705 88 HOLDER 1
3 550 844 92 HOLDER 1
4 550 845 00 SUPPORT 1
5 550 845 01 SUPPORT 1
. . . . .
6 550 740 91 BUSHING 1
7 550 567 41 PAD, RUBBER 1
. . . . .

BG 004 198 48 aA NSS
117 (183) BODY 160113
11 9 3 6
11 9
4
8 10
7
5
11 9
6
10 8
2 3

BG 004 198 48 aA NSS
160113 BODY 118 (183)

e
1 BG 004 198 47 BODY 1
2 550 678 53 HOLDER, PLUG-IN 1
4 550 678 69 HOLDER 1
5 550 740 91 BUSHING 1
. . . . .
6 551 532 41 GUIDE, ROD 2
. . . . .

550 566 88 bB NSS
119 (183) FRAME ASSEMBLY 160113
2
3
H
E
F
5
H E E-E
6 9
10 8
14
4
9
10 8 DETAIL F
1
11
12 13
10 8 H-H
13 7
DETAIL D

550 566 88 bB NSS
160113 FRAME ASSEMBLY 120 (183)

e
1 550 741 37 BODY 1
3 550 706 26 PLATE 1
4 550 740 90 LATCH 1
5 550 678 13 PLATE 1
. . . . .
. . . . .
11 AF0 070 0140 SCREW, SOCKET HEAD, COUNTERSUNK, M8x12-10.9 Plain 8
HEXAGON
14 551 532 23 PIN, LOCKING 1

BG 004 198 01 aA NSS
121 (183) HATCH / PANTERA DPI 160113
4 1
9
5 7
6
10
11
12
8
15
9 14
9 13

BG 004 198 01 aA NSS
160113 HATCH / PANTERA DPI 122 (183)

e
1 551 891 88 PLATE, SIDE 1
2 551 891 85 PLATE, SIDE 1
3 BG 004 198 66 COVER 1
4 550 706 22 CUP, BASE PLATE 1
5 BG 004 198 69 PIN, LOCKING 1
. . . . .
6 BG 004 198 67 SUPPORT Support for rubber 1
7 BG 004 198 68 SUPPORT Support for stopper 1
. . . . .
. . . . .

BG 004 198 02 aA NSS
123 (183) HATCH / PANTERA DPI 160113
12 13 13 14
5
13 14
A
16 9
6
15 9
4 7
12 10 DETAIL A
8 1
11 9
18 17
C C
SECTION C-C
2 9 11 2

BG 004 198 02 aA NSS
160113 HATCH / PANTERA DPI 124 (183)

e
1 BG 004 198 78 COVER ASSEMBLY 1
2 550 741 28 HINGE 2
3 551 532 25 HANDLE 1
4 550 844 90 BRACKET 1
5 550 678 67 LATCH Rotarylatch Eberhard 1-400-L 1
. . . . .
6 550 567 15 OPENER 1
7 551 532 24 LEVER 1
8 BG 004 199 24 LATCH, SAFETY Wind lock 1
. . . . .
. . . . .

BG 004 198 03 bB NSS
125 (183) COVER ASSEMBLY / PANTERA DPI ROOF BOX 160113
1
B
SECTION A - A
16 11
10
17 13
13 18
12 11
DETAIL B DETAIL D
C
2
6
5
14 13
23
A 8 A
21
4
9
22
D
6
7 SECTION C - C
C

BG 004 198 03 bB NSS
160113 COVER ASSEMBLY / PANTERA DPI ROOF BOX 126 (183)

e
2 BG 004 197 74 COVER ASSEMBLY Roof plate 1
3 BG 004 197 78 HOOK 1
4 BG 004 197 85 HATCH SECTION 11 PAGE 130 1
5 BG 004 197 76 CORNER Corner piece for roof box 1
. . . . .
8 BG 004 197 57 PLATE, COVER Roof piece 1
9 BG 004 197 87 PLATE, SIDE 1
10 550 741 28 HINGE 2
. . . . .
. . . . .
METAL
. . . . .
21 BG 004 199 26 CLIP 1
22 BG 004 197 66 SUPPORT Support for wind rod 1
23 551 532 23 PIN, LOCKING 2

BG 004 197 61 aA NSS
127 (183) FRAME ASSEMBLY 160113
8 7 8 10 10 8 7 8
8 10 10 8
9 8
7 8 8 7 8 9
A B
9 8 B 8 9
A
7 8
10 8
SECTION A-A SECTION B-B
1
3
2
1 6

BG 004 197 61 aA NSS
160113 FRAME ASSEMBLY 128 (183)

e
1 BG 004 197 70 SUPPORT, WELDING Transverse support assembly 2
2 BG 004 197 71 SUPPORT, WELDING Longitudinal support left assembly 1
3 BG 004 197 86 SUPPORT, WELDING Longitudinal support right assembly 1
4 BG 004 197 72 FRAME Body piece right assembly 1
5 BG 004 197 60 FRAME, REAR, WELDING Back body piece assembly 1
. . . . .
6 BG 004 197 65 FRAME Left body piece assembly 1
. . . . .

BG 004 197 85 bB
129 (183) HATCH / HATCH ASSEMBLY 160113
B
A
1
3 SECTION B - B
6 7
8 6
5 4 DETAIL A 5 4
2
DETAIL
DETAIL C C

BG 004 197 85 bB
160113 HATCH / HATCH ASSEMBLY 130 (183)

e
1 BG 004 197 82 HATCH Hatch assembly 1
2 BG 004 197 81 NSS LATCH SECTION 11 PAGE 111 1
3 551 532 25 HANDLE 1
. . . . .

BG 004 198 04 aA NSS
131 (183) DOOR, SIDE / LEFT FRONT DOOR ASSEMBLY 160113
8 7 6
4 5

e
1 BG 004 198 82 DOOR, SIDE Left front door 1
2 BG 004 198 89 HINGE 2
. . . . .
6 550 741 05 SCREW 4

BG 004 198 05 aA
160113 DOOR, SIDE / LEFT REAR DOOR 132 (183)
16 1
15
2
13 12 12 14 9
11 10 10 11
3
7 8

e
2 550 845 07 STRIP 1
6 550 741 28 HINGE 3
. . . . .
9 550 741 05 SCREW 8
. . . . .
15 550 678 68 SCREW 23

BG 004 198 06 aB
133 (183) DOOR, SIDE / RIGHT REAR DOOR 160113
3
15
SECTION A-A
14 11 14 13
A 8 12
A
10 7
13 10
B B
11 14
5
3 SECTION B-B

BG 004 198 06 aB
160113 DOOR, SIDE / RIGHT REAR DOOR 134 (183)

e
2 550 845 07 STRIP 1
3 550 567 41 PAD, RUBBER 2
6 550 741 28 HINGE 3
. . . . .
9 550 741 05 SCREW 8
. . . . .
15 550 678 68 SCREW 12

BG 004 198 09 aA
135 (183) PLATE, COVER / ROOF PLATE, RIGHT REAR 160113
5 4
DETAIL A
3

BG 004 198 09 aA
160113 PLATE, COVER / ROOF PLATE, RIGHT REAR 136 (183)

e
1 BG 004 198 60 PLATE, COVER Roof panel 1
2 BG 004 198 61 GUARD 1
3 BG 004 198 63 COLLAR - 1
. . . . .

BG 004 198 10 aA
137 (183) HATCH / ROOF HATCH ASSEMBLY, RIGHT FRONT 160113
6
B
5 3
14
16
4 DETAIL B 15 10 9 9 11
8
7
8 12 12 13
SECTION A-A
14 9
1

BG 004 198 10 aA
160113 HATCH / ROOF HATCH ASSEMBLY, RIGHT FRONT 138 (183)

e
1 550 741 28 HINGE 1
2 BG 004 199 11 HATCH Hatch assembly 1
3 550 844 90 BRACKET 1
4 550 678 67 LATCH Rotarylatch Eberhard 1-400-L 1
5 551 532 34 STRIP 1
. . . . .
6 BG 004 199 20 LATCH, SAFETY SECTION 11 PAGE 139 1
. . . . .
. . . . .

BG 004 199 20 aA
139 (183) LATCH, SAFETY / WIND LATCH ASSEMBLY 160113
4 5

e
1 BG 004 199 18 LATCH, SAFETY Wind latch 1
2 BG 004 199 19 LATCH, SAFETY Wind latch 1
. . . . .

551 982 44 a NSS
160113 MOUNTING / HYDRAULIC JACK OUTER PIPE 140 (183)
2 3

e
1 551 966 31 OUTER PIPE machining 1
2 802 280 29 HEXAGON HEAD BOLT M20X80 m8.8 6

BG 004 615 02 c
141 (183) SIGNS AND DECALS ASSEMBLY / PANTERA DPI 160113
101
403
202
219 209 201
252*
210

BG 004 615 02 c
160113 SIGNS AND DECALS ASSEMBLY / PANTERA DPI 142 (183)

e
460 BG 003 731 73 DECAL Warning: Operation distance. Turkey 1

BG 004 615 02 c
102
214
401
215
210 217
206
218/50* 250* 216 207 2 3 452 404
458
153
454
204
213 457

BG 004 615 02 c

e
401 BG 003 731 32 SIGN Check compressor oil level. Turkey 1
452 BG 003 731 47 SIGN Warning: Hot surfaces. Turkey 1
454 BG 004 232 71 SIGN Warning: Dust hazard 2
457 BG 004 202 33 SIGN General Warning 3
461 BG 004 202 46 SIGN High pressure fluidinjection hazard 2
. . . . .

BG 004 615 02 c
456
451
455
404 205 258*
428*

BG 004 615 02 c

e
454 BG 004 232 71 SIGN Warning: Dust hazard 2
458 552 273 27 SIGN Safety label Air receiver, Turkish 2
459 BG 003 731 83 SIGN Warning: Splashing hazard of hot fluids. 1
Turkey

BG 004 615 02 c
405
203
453
429
428*
402

BG 004 615 02 c

e
451 BG 003 731 45 SIGN Warning: Rotating rod danger. Turkey 2
455 BG 003 731 63 SIGN Warning: Hazardous boom motion. Turkey 2
456 BG 003 731 67 SIGN Warning: Danger area when operating. 2
Turkey

BG 004 615 02 c
251*
255*
256*

BG 004 615 02 c

e
451 BG 003 731 45 SIGN Warning: Rotating rod danger. Turkey 2
455 BG 003 731 63 SIGN Warning: Hazardous boom motion. Turkey 2
456 BG 003 731 67 SIGN Warning: Danger area when operating. 2
Turkey

BG 004 615 02 c
456
451
213
208 404 455 205
213 102

BG 004 615 02 c

e
402 550 955 76 DECAL 1
453 BG 003 731 53 SIGN Warning: Dust hazard. Turkey 1
462 BG 003 731 61 SIGN Warning: Hazardous voltage near 1
powerlines. Turkey
463 BG 005 515 51 SIGN Roll-over hazard, TR 1
. . . . .

BG 004 337 50 cC NSS
153 (183) SIGNS AND DECALS ASSEMBLY / BASIC DECALS 160113
102
214
401
206
215
210
217
218/50* 250* 216 207 2 3 257* 452 461 206
461
153
454
204
213 457

BG 004 337 50 cC NSS
160113 SIGNS AND DECALS ASSEMBLY / BASIC DECALS 154 (183)

e
1 550 169 96 SIGN Sound power level 1
2 550 076 68 DECAL 1
10 455 332 90 SCREW 2X5 24
11 806 263 29 POP-RIVET 3,2x8 Al 74
100 BG 004 338 44 NSS DECAL SET SECTION 11 PAGE 155 1
. . . . .
200 BG 004 359 64 NSS SIGN SET SECTION 11 PAGE 158 1
300 BG 004 368 53 NSS INSTRUCTION SECTION 11 PAGE 172 1
*50 BG 005 071 52 DECAL CSL oil filling 1

BG 004 338 44 aA NSS
155 (183) DECAL SET 160113
right
left
Sandvik-lens sticker
Sandvik-lens sticker
Front bumber
cab and back

220 mm wide
260 mm wide

e
101 BG 004 105 64 DECAL Sandvik-logo 220 mm 1
102 BG 004 105 65 DECAL Sandvik-logo 260 mm 3
150 BG 004 338 82 NSS DECAL SET SECTION 11 PAGE 156 1

BG 004 338 82 aA NSS
160113 DECAL SET / PANTERA DP1500I 156 (183)
151
152
LEFT
RIGHT
153

e
151 BG 004 339 42 DECAL DP1500i 1
152 BG 004 339 47 DECAL Pantera 1
153 BG 004 339 48 DECAL Pantera DP1500i 1

BG 004 359 64 cC NSS
157 (183) SIGN SET 160113
102
460
202
259* 219 209 201
252*
210 254*

BG 004 359 64 cC NSS
160113 SIGN SET 158 (183)

e
201 157 452 28 SYMBOL ''FUSE'' FUSE 1
202 550 213 17 SIGN Elect. controlled engines 1
209 BG 004 116 28 DECAL Battery disconnect 1
210 552 167 27 DECAL Hot surface, do not touch, 30x50 mm 4
219 BG 005 275 63 DECAL Engine shut down 1
. . . . .
*252 551 925 51 LABEL, INSTRUCTION 1
*254 551 706 67 DECAL Decal for Lincoln switch 1
*259 551 947 08 SIGN 1

BG 004 359 64 cC NSS
159 (183) SIGN SET 160113
102
214
401
206
215
210
217
218/50* 250* 216 207 2 3 257* 452 461 206
461
153
454
204
213 457

BG 004 359 64 cC NSS
160113 SIGN SET 160 (183)

e
204 136 219 68 SIGN Noise warning in 85dB in 1
206 232 184 38 DECAL Sticker "min-max", oil receiver 2
207 132 727 18 SIGN Oiler drainage 1
213 BG 004 330 30 DECAL Tie down point 6
. . . . .
214 BG 004 363 07 DECAL SECTION 3 PAGE 1 1
215 BG 004 100 96 DECAL First Filling Fluids list, Pantera DPi 1
216 551 940 64 LABEL, INSTRUCTION 1
217 552 023 88 DECAL Fuel tank seal --- Ultra low sulfur fuel only 1
218 390 099 08 SYMBOL ''OIL FILLING'' 1
. . . . .
*250 390 503 08 SIGN 2
*250 551 884 33 SIGN towing trasmital 2
*257 550 862 25 DECAL Decal 1

BG 004 359 64 cC NSS
161 (183) SIGN SET 160113
251*
255*
256*

BG 004 359 64 cC NSS
160113 SIGN SET 162 (183)

e
211 550 539 47 DECAL Engine coolant type (ELC) 1
*250 390 503 08 SIGN 2
*250 551 884 33 SIGN towing trasmital 2
. . . . .

BG 004 359 64 cC NSS
163 (183) SIGN SET 160113
102
151
152
458 454 250* 457 213 210 211 459 210

BG 004 359 64 cC NSS
160113 SIGN SET 164 (183)

e
205 390 100 08 SIGN Lifting 3
*258 BG 002 494 17 DECAL Decal 1
*258 BG 002 494 22 DECAL Decal 1

BG 004 359 64 cC NSS
165 (183) SIGN SET 160113
456
451
213
208 461 455 205
213 101

BG 004 359 64 cC NSS
160113 SIGN SET 166 (183)

e
203 551 810 50 SIGN STOPPING ENGINE 1

BG 004 359 64 cC NSS
167 (183) SIGN SET 160113
456
451
455
461 205 258*
428*

BG 004 359 64 cC NSS
160113 SIGN SET 168 (183)

e
*251 390 108 28 SIGN "FILLING PUMP" 1
*255 550 862 22 DECAL Decal 1
*256 550 862 26 DECAL Decal 1

BG 004 359 64 cC NSS
169 (183) SIGN SET 160113
453
203
457
463
462
429*
428*
402

BG 004 359 64 cC NSS
160113 SIGN SET 170 (183)

e
205 390 100 08 SIGN Lifting 3
208 552 197 28 SIGN Safety wire action: stop. feed and rot. 1
*253 BG 002 260 87 DECAL Dragonfly sampler control box decal 1

BG 004 368 53 b NSS
171 (183) INSTRUCTION / YELLOW TAPE INSTALLATION 160113
301

BG 004 368 53 b NSS
160113 INSTRUCTION / YELLOW TAPE INSTALLATION 172 (183)

e
301 552 069 07 TAPE Yellow tape, width 50 mm (Tape roll 0.42
55206739)

BG 004 368 53 b NSS
302
303

BG 004 368 53 b NSS

e
55206740)
55206740)

BG 004 368 53 b NSS
304

BG 004 368 53 b NSS

e
55206740)

BG 004 368 53 b NSS
305 305
306
306

BG 004 368 53 b NSS

e
55206740)
55206739)

550 746 42
179 (183) GUIDE, TRACK / 1 PAIR 160113
1
2

e
1 550 589 70 GUIDE, TRACK 2
2 801 592 69 HEXAGON HEAD SCREW M16X1,5X55 m8.8 SFS 2065 16

BG 006 235 54 aA NSS
181 (183) COVER ASSEMBLY / COVER PLATE MOUNTING 160113
24
13 15

BG 006 235 54 aA NSS
160113 COVER ASSEMBLY / COVER PLATE MOUNTING 182 (183)

e
3 550 692 52 PLATE 1
24 552 219 39 RUBBER SHEET 1

Carrier

Uploaded by

Document Information

Original Title

Copyright

Available Formats

Share this document

Share or Embed Document

Sharing Options

Did you find this document useful?

Is this content inappropriate?

Copyright:

Available Formats

Carrier

Uploaded by

Copyright:

Available Formats

CARRIER

Sandvik Mining and Construction Oy, Drills Tampere © 2016

**** BG 004 198 48 NSS BODY.................................................................................................................................................... 118

Sandvik Mining and Construction Oy, Drills Tampere © 2016

Sandvik Mining and Construction Oy, Drills Tampere © 2016

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy, Drills Tampere © 2016

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy, Drills Tampere © 2016

Sandvik Mining and Construction Oy, Drills Tampere © 2016

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy, Drills Tampere © 2016

Sandvik Mining and Construction Oy, Drills Tampere © 2016

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy, Drills Tampere © 2016

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy, Drills Tampere © 2016

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy, Drills Tampere © 2016

Sandvik Mining and Construction Oy, Drills Tampere © 2016

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy, Drills Tampere © 2016

Sandvik Mining and Construction Oy, Drills Tampere © 2016

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy, Drills Tampere © 2016

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy, Drills Tampere © 2016

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy, Drills Tampere © 2016

Sandvik Mining and Construction Oy, Drills Tampere © 2016

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy, Drills Tampere © 2016

Sandvik Mining and Construction Oy, Drills Tampere © 2016

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy, Drills Tampere © 2016

Sandvik Mining and Construction Oy, Drills Tampere © 2016

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy, Drills Tampere © 2016

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy, Drills Tampere © 2016

Sandvik Mining and Construction Oy, Drills Tampere © 2016

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy, Drills Tampere © 2016

Sandvik Mining and Construction Oy, Drills Tampere © 2016

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy, Drills Tampere © 2016

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy, Drills Tampere © 2016

Sandvik Mining and Construction Oy, Drills Tampere © 2016

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy, Drills Tampere © 2016

Sandvik Mining and Construction Oy, Drills Tampere © 2016

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy, Drills Tampere © 2016

Sandvik Mining and Construction Oy, Drills Tampere © 2016

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy, Drills Tampere © 2016

56 140 48 800 130

Sandvik Mining and Construction Oy, Drills Tampere © 2016

Ref. Part no. Description EN Standard designation Qty

Sandvik Mining and Construction Oy, Drills Tampere © 2016

Sandvik Mining and Construction Oy, Drills Tampere © 2016

Ref. Part no. Description EN Standard designation Qty
