10/7/21, 5:39 AM LED Light Kit (FLK LED Series) - Hammond Mfg.

Quality Products. Service Excellence.

LED Light Kit FLK LED Series

Features

Available in 9", 17.5", 26", 34.5", and 38.5" lengths

Operating voltage 120V AC5 (50/60Hz). Operating temperature -20C to +50C (-4F to
+122F)
Provides 175 lumens per LED module
Long lamp life of 60,000 hours in warm white color temperature
No remote power supplies as unit comes with its own integral LED drivers
Hardwired via multiple knockouts in lightweight extruded aluminum frame, finished white
with manual operated switch
Hinged glass diffuser allows easy access to replaceable LED module
Certified by ETL to UL and CSA Luminaires standards

Accessories
Remote Door Switches

Part Number Description Number LED Modules Lumens Energy Use

FLK5LED 9" LED Light Kit 1 175 4.4 w
FLK7LED 17.5" LED Light Kit 2 350 7.2 w
FLK10LED 26" LED Light Kit 3 525 9.8 w
FLK15LED 34.5" LED Light Kit 4 700 15.0 w
FLK17LED 38.5 LED Light Kit 5 875 17.0 w

Data subject to change without notice

© 2021. Hammond Manufacturing Ltd. All rights reserved.

[Link] 1/1
10/7/21, 5:39 AM Fold Down Shelf - Hammond Mfg.

Quality Products. Service Excellence.

Fold Down Shelf

Features

Supports various equipment used temporarily to service/program switchgear inside

enclosures.
Mounts with bolts through doors or sides.
Supports up to 100 lbs weight capacity.

Work Surface
Part No. Finish W D
FDS1212GY ANSI 61 Gray 12.00 12.00
FDS1818GY ANSI 61 Gray 18.00 18.00
FDS2424GY ANSI 61 Gray 24.00 24.00
FDS1212LG RAL 7035 Light Gray 12.00 12.00
FDS1818LG RAL 7035 Light Gray 18.00 18.00
FDS2424LG RAL 7035 Light Gray 24.00 24.00
FDS1212S16 316 Stainless Steel 12.00 12.00
FDS1818S16 316 Stainless Steel 18.00 18.00
FDS2424S16 316 Stainless Steel 24.00 24.00

Data subject to change without notice

© 2021. Hammond Manufacturing Ltd. All rights reserved.

[Link] 1/1
10/8/21, 11:15 PM Literature Pocket (PKT Series) - Hammond Mfg.

Quality Products. Service Excellence.

Literature Pocket PKT Series

Features

For use as additional or replacement literature pockets.

Kit includes pocket, high strength two-sided adhesive tape and surface preparation swab.
Plastic pocket is black.
Packaged individually.

Gallery






Part No. H W D
PKT66 6.00 6.00 0.75
PKT99 6.00 9.00 0.75
PKT1212S 12.00 12.00 1.25
PKT1212 12.00 12.00 2.50

Data subject to change without notice

© 2021. Hammond Manufacturing Ltd. All rights reserved.

[Link] 1/1
 NEMA 12-13 Mtrx SHELVING & STORAGE 886 KBS
External screen console
The 886 KBS screen compart- DIMENSIONS (mm)
CATALOG
ment is designed to accommo- NUMBER H W D
date at most a 21 inch flat screen. 886 KBS06 400 550 120
The compartment is accessible
via a locking window door made
of 16GA steel and polycarbonate
NOTE: Supplied with mounting
window. Finish is light gray hardware, however may require
RAL7035 heat fused powder drilling holes for installation
paint.

Fold down keyboard tray

The 886 KBF Fold down key- CATALOG DIMENSIONS (mm)
board trays are made of 16GA NUMBER H W D
steel and can be installed on any 886 KBF06 300 550 120
outside enclosure surface. The
fold down tray is designed to
accommodate standard keyboard NOTE: Supplied with mounting
and mouse sizes. Finish is light hardware, however may require
gray RAL7035 heat fused powder drilling holes for installation
paint.

886 KBS 886 KBF

CABLE ENTRY 100

120.00
25.00
300.00

KEY LOCK

407.92 581.76

550.00 120 401.76

362.50
480.00

25.00

KEY LOCK
CABLE ENTRY 100

550.00

NOTE :The combination of the 886 KBF and the 886 KBS offers a solution for housing a keyboard
and a flat screen. These two items are made of 16GA steel and can be installed on any enclosure
surface. The two items 886 KBF and 886 KBS need to be selected in order to complete this kit

Data subject to
change without
notice.

115

[Link]  1-800-363-2423 Fax : 450-979-4626 info@[Link]

Wireless productivity
for the busiest offices

Wireless Combo MK270

The Logitech Wireless Combo MK270 delivers fast and reliable keyboard and mouse connectivity of up to
10 meters with Logitech Advanced 2.4 GHz wireless, even in the busiest environments. The mouse features
the Logitech Unifying receiver for plug-and-play productivity anywhere and the long battery life reduces
support requirements and costs.

Features:
• Logitech Advanced 2.4 GHz wireless connectivity • Keyboard shortcuts
with 10-meter/32-feet range1 • Feel-good typing
• Logitech Unifying receiver and internal storage • Contoured mouse design with laser tracking
compartment in mouse
• Plug-and-play simplicity
• 24-month keyboard and 12-month mouse battery
life2 plus auto-sleep

Tools Designed for the Anywhere Workplace

 DATA SHEET

Logitech Wireless Combo MK270

Product Specifications System Requirements

Price: $29.99 Mouse Windows® XP, Windows Vista®, Windows® 7,
Part #: 920-004536 Width: 4.2 in (106.9 mm) Windows® 8, USB port
Height: 1.6 in (39.6 mm)
Keyboard Inside the box
Depth: 2.4 in (60.2 mm)
Width: 17.6 in (441.5 mm) Keyboard, Mouse, USB receiver, USB range
Weight: 2.4 ounces (68.9 g)
Height: 0.9 in (22.9 mm) extender, 2 AAA (keyboard) and 2 AA (mouse)
Depth: 5.9 in (149.1 mm) batteries, User documentation
Weight: 17.2 ounces (487.6 g)
Warranty
3-year limited hardware

FEATURE SPOTLIGHT

Logitech Advanced 2.4 GHz wireless connectivity Keyboard shortcuts

with 10-meter/32-feet range1 Save time with eight keyboard hot keys, which
Delivers a fast, reliable, and secure connection using provide instant access to most-used applications
128-bit AES keyboard encryption with virtually no like email, Internet and volume up/down.
delays or dropouts—even in the busiest wireless
environments—for convenient use anywhere in the
Feel-good typing
office, including a conference room environment.
A full-size, spill-resistant3 keyboard with low-
profile, whisper-quiet keys, F-keys and a number
Logitech Unifying receiver and internal storage pad is comfortable, convenient, and built to last
compartment in mouse for easy use.
The small receiver stays plugged into the laptop’s
USB port for easy, convenient, and clutter-free
Contoured mouse design with laser tracking
connectivity and can be stored in your mouse to
Provides all-day comfort and smooth and
reduce the risk of damage or loss. Users can add
accurate tracking.
up to six devices to one USB port.

Plug-and-play simplicity
24-month keyboard and 12-month mouse battery
Works right out of the box for maximum plug-
life2 plus auto-sleep
and-play efficiency. No software installation
Offers long-lasting battery life to minimize
is required, saving tech support time.
downtime and the cost and hassle of changing
batteries. Auto-sleep and on/off switches reduce
power consumption to further extend battery life.

Learn more at [Link]/business

To order contact your reseller, or call us at 800-308-8666.
1
Wireless range may vary due to environmental and computing conditions.
2
Keyboard battery life calculation based on an estimated two million keystrokes/year in an office environment.
User experience may vary. Mouse battery life may vary based on user and computing conditions.
3
Tested under limited conditions (maximum 60 ml liquid spillage). Do not immerse in liquid.

Logitech Inc. 7600 Gateway Blvd. Newark, CA 94560

© 2013 Logitech. Logitech, the Logitech logo and other Logitech marks are owned by Logitech and may be registered. All other trademarks are the property of their respective owners.
Logitech assumes no responsibility for any errors that may appear in this publication. Product, pricing and feature information contained herein is subject to change without notice.
 DCB Group
+353 (0) 1 276 9000
[Link]

Product information

Information

Manufacturer Ergotron
Part number 99-033-085

Ergotron - Mouse holder - black

Specifications

General
Product Type Mouse holder
Color Black
Manufacturer Warranty
Service & Support Limited warranty - 5 years

DCB Group | Unit 5, The Mill | The Maltings | Bray | Co Wicklow | A98 RH29 | [Link] | sales@[Link]
DisplayPac-i5-WN
Competitively Priced, High Performance Flat Panel Computer Solution based on Intel®
Core™ i5 Processors
The DisplayPac-i5-WN series of Panel PCs are an excellent performance solution for Industrial Computing
needs. The platform offers flat panels ranging from 15" to 21.5" and come with a touchscreen. The systems
can be configured either with a panel-mount plate or with a stand-alone chassis. Additionally, the displays can be
made sunlight readable.

Display Specifications
Display Brightness Viewing Angle
• 10.4" 800x600 (SVGA) • 10.4" SVGA 400 nit • 10.4" SVGA +/-70° (H); -55° to +65° (V)
• 10.4" 1024x768 (XGA) • 10.4" XGA 350 nit • 10.4" XGA +/-88° (H); +/-88° (V)
• 12.1" 800x600 (SVGA) • 12.1" SVGA 400 nit • 12.1" SVGA +/-70° (H); -50° to +60° (V)
• 12.1" 1024x768 (XGA) • 12.1" XGA 500 nit • 12.1" XGA +/-80° (H); +/-70° (V)
• 15" 1024x768 • 15" 250 nit • 15" +/-70° (H); +/-60° (V)
• 17" 1280x1024 • 17" 300 nit • 17" +/-85° (H); +/-80° (V)
• 19" 1280x1024 • 19" 400 nit • 19" +/-85° (H); +/-80° (V)
• 21.5" 1920x1080 • 21.5" 250 nit • 21.5" +/-85° (H); +/-80° (V)
• 24" 1920x1080 • 24" 250 nit • 24" +/-89° (H); +/-89° (V)

Colors Contrast Ratio

Touchscreen Specification
• 10.4" SVGA 16.2M (8 bits/color) • 10.4" SVGA 500:1
• 10.4" XGA 16.2M (8 bits/color) • 10.4" XGA 1200:1 Touchscreen
• 12.1" SVGA 16.2M (6 bits/color) • 12.1" SVGA 500:1 • 5-wire Resistive
• 12.1" XGA 16.2M (8 bits/color) • 12.1" XGA 700:1
• 15" 16.2M (6 bits/color + FRC) • 15" 500:1
• 17" 16.7M (6 bits/color + FRC) • 17" 800:1
• 19" 16.7M (8 bits/color) • 19" 1000:1
• 21.5" 16.7M (8 bits/color) • 21.5" 1000:1
• 24" 16.7M (8 bits/color) • 24" 5000:1
DisplayPac-i5-WN Competitively Priced, High Performance Flat Panel Computer Solution
System Specifications
CPU Serial Environmental
• 3rd Generation Core i5 Processor • 2x RS-232 • 0° to 50°C operating temperature
• 1333/1600 MHz Front Side Bus • 1x RS-232/422/485 • 30% to 90%, operating humidity non-
condensing
BIOS Power Input
• AMI BIOS • Shock: 15G, 11ms
• DC in (12V) • Vibration: 5 Hz ~ 500 Hz / 1 Grms
Chipset Power Consumption (@ 12V) maximum
• Intel® HM76 brightness and 100% CPU load
Memory Slot • 10.4" 87W Options
• 2x DDR3 (16GB Max) • 12.1" 87W Touchscreen
• 15" 87W • Projected Capacitive (Supports MultiTouch)
SATA • 17" 95W
• 1x SATA II • 19" 96W Mechanical
• 1x SATA III • 21.5" 98W • Chassis
Media • 24" 100W Bezel
• 160 GB 2.5" HDD
• IP65
• Larger capacities available Power Supply
Display
Keyboard/Mouse • Universal AC (external brick)
• -HB (Hi-Brite)
• 2x PS/2 Construction
Expansion Slot
VGA • Panel Mount • 2x Mini PCIe
• 1x VGA Connector
Certifications • 1x PCI
Audio
• CE, FCC, RoHS Media
• 1 x Audio
• Solid State Drive
USB • CompactFlash
• 4x USB 3.0
O/S
Ethernet
• Windows ® XP Pro for Embedded Systems
• Dual Broadcom BCM57780 PCIe GbE LAN
• Windows ® 7 Pro
• Windows ® 10 IoT Enterprise

About Computer Dynamics

Computer Dynamics (A CIMTEC Automation Company) is a leading global provider of flat panel
display solutions for a wide range of industries and applications. Our comprehensive product
offering includes open-frame, enclosed, and environmentally sealed flat panel display systems in
both computer and monitor configurations. Whether you’re looking for one of our standard products
or a fully custom solution, Computer Dynamics has the breadth, experience and support to deliver
what you need. For more than 25 years, CIMTEC Automation has been providing automation
solutions throughout the world that deliver value, performance, and innovation.

Computer Dynamics Contact Information

Americas: 1 864 627 8800
Additional contact information available on our web site at [Link]/[Link]

[Link]
CompactLogix™ 5370 L3 Programmable
Automation Controllers
1769-L30ER, -L30ERM, -L30ER-NSE, -L33ER, -L33ERM, -L36ERM

Features and Benefits

The CompactLogix 5370 L3 controllers
deliver scalable, affordable control
ideal for applications from small stand-
alone equipment to high performance
indexing tables, process skids, case
packers and erectors, and packaging.
Machine builders and end users can
take advantage of the cost-saving
features of these controllers:
• Support for Integrated Motion
on EtherNet/IP
• Support for Device Level Ring (DLR)
network topologies
Expanding on the scalability of the Logix family of controllers, the
• Built-in energy storage eliminates CompactLogix 5370 L3 programmable automation controllers (PAC) are
the need for lithium batteries designed to meet the growing need for a higher performance controller
• Support reuse of existing 1769 I/O in a compact and affordable package.
• Removable 1GB secure digital (SD)
card improves data integrity
As part of the Integrated Architecture system, the CompactLogix 5370
L3 controllers use the same programming software, network protocol,
• Flexible memory options up to 3MB and information capabilities as all Logix controllers, providing a common
• Added features for hazardous development environment for all control disciplines.
environments (NSE version)
• Support for Kinematics eliminates Integrated Motion on EtherNet/IP
the need for additional robot The CompactLogix 5370 L3 controller provides a strong motion solution
controllers and software for customers looking for performance and cost competitiveness.
• Open socket capability allows • Supports up to 16 axes of integrated motion
support for Modbus TCP as well as • Together with the Kinetix 350, offers cost-effective, scalable
devices such as printers, barcode motion solution
readers and servers
Network Capabilities
With dual Ethernet ports and an integrated Ethernet switch, these controllers
now support Device Level Ring (DLR) network topologies, simplifying
integration of components in your control system and reducing system cost:
• Provides resiliency from loss of one network connection
• Allows replacement of devices one at a time without stopping production
• Reduces the number of Ethernet switches in the control system
Reduce cost and time to
Features for Hazardous Environments
market with CompactLogix The No Stored Energy (NSE) version of the CompactLogix 5370 L3 offers
5370 L3 Programmable additional features for hazardous environments found in industries such
as mining and oil and gas.
Automation Controllers. • Allows safe transport of controller in and out of mining areas
• Powered down controller has less than 200uJ of residual energy
stored in each component
• No consequences of arc or spark to cause an explosion in
gaseous environment
CompactLogix 5370 L3 Controller Product Specifications
1769-L30ER 1769-L30ERM 1769-L30ER-NSE 1769-L33ER 1769-L33ERM 1769-L36ERM
User memory 1 MB 1 MB 1 MB 2 MB 2 MB 3 MB
Controller tasks 32 tasks 32 tasks 32 tasks 32 tasks 32 tasks 32 tasks
Programs per task 100 tasks 100 tasks 100 tasks 100 tasks 100 tasks 100 tasks
Integrated Motion -- 4 axis CIP motion -- -- 8 axis CIP motion 16 axis CIP motion
position loop axis position loop axis position loop axis
Package Size 55mm wide x 118mm high x 105mm deep
Certifications cULH (Class I Division 2), KCC / UL (UL 508), ULH (Class I & II, Division 2 and Class III, Divisions 1 & 2) /
ATEX, CE, C-Tick / Marine and GOST certifications in 2012
Local Expansion Modules 8 8 8 16 16 30
Local Expansion I/O Points 128 128 128 256 256 480
Communication Module Additions DeviceNet with 1769-SDN or 3rd party
Flash Memory Card Industrially rated and certified Secure Digital (SD) memory card (1 and 2 GB options); all controllers shipped with 1 GB card
Servo Drives (Position Loop CIP) -- 4 -- -- 8 16
Ethernet I/O IP nodes 16 16 16 32 32 64
Virtual axes 100 100 100 100 100 100
Feedback only, torque, velocity, Vhz
-- 16 -- -- 32 64
(max CIP motion drives)
Axes/ms -- 2 -- -- 2 2
Kinematics support -- yes -- -- yes yes
Software / Firmware RSLogix 5000 V20 and RSLinx Classic V2.58 Firmware v20.1x or later

CompactLogix, Integrated Architecture, Kinetix, RSLogix, Integrated Motion on EtherNet/IP are trademarks of Rockwell Automation, inc.
Trademarks not belonging to Rockwell Automation are property of their respective companies.

Publication 1769-PP010A-EN-E – November 2011 Copyright © 2011 Rockwell Automation, Inc. All Rights Reserved. Printed in USA.
Compact™ 24V dc Sink/Source Input
Module

(Catalog Number 1769-IQ16)

Installation Instructions

Inside
Module Description ......................................................................................... 2
Module Installation .......................................................................................... 3
System Assembly ........................................................................................... 4
Mounting Expansion I/O.................................................................................. 5
Replacing a Single Module within a System ................................................... 7
Field Wiring Connections................................................................................ 8
I/O Memory Mapping .................................................................................... 10
Spare/Replacement Parts............................................................................. 10
Specifications................................................................................................ 11
Hazardous Location Considerations ............................................................. 13
Environnements dangereux .......................................................................... 13
For More Information .................................................................................... 14

Publication 1769-IN007B-EN-P
2

Module Description

Item Description

1 bus lever
1 2a (with locking function)

2a upper panel mounting tab

3 2b lower panel mounting tab
DANGER
Do Not Remove RTB Under Power
Unless Area is Non-Hazardous
3 I/O diagnostic LEDs
10a IN 1
IN 0

IN 2
IN 3

IN 5
IN 4

4 module door with terminal

IN 7
IN 6

DC
COM1
identification label
10 IN 9
IN 8

movable bus connector

IN 11
IN 10
IN 13

IN 15
IN 12
5a with female pins
10b DC
COM 2
IN 14

Ensure Adjacent
Bus Lever is Unlatched/Latched
4
5b stationary bus connector
Before/After
Removing/Inserting Module
1769-IQ16
with male pins
8a

2b 6 nameplate label
7a 7a
7a upper
tongue-and-groove slots
lower
5a 7b tongue-and-groove slots

5b 8a upper DIN rail latch

9
8b lower DIN rail latch

9 write-on label (user ID tag)

6 removable terminal block

10 (RTB) with finger-safe cover

7b 7b 10a RTB upper retaining screw

8b
10b RTB lower retaining screw

Publication 1769-IN007B-EN-P
 3

Module Installation
Compact I/O is suitable for use in an industrial environment when installed in
accordance with these instructions. Specifically, this equipment is intended for
use in clean, dry environments (Pollution degree 21) and to circuits not exceeding
Over Voltage Category II2 (IEC 60664-1).3

Prevent Electrostatic Discharge

ATTENTION: Electrostatic discharge can damage integrated

circuits or semiconductors if you touch bus connector pins.
! Follow these guidelines when you handle the module:
• Touch a grounded object to discharge static potential.
• Wear an approved wrist-strap grounding device.
• Do not touch the bus connector or connector pins.
• Do not touch circuit components inside the module.
• If available, use a static-safe work station.
• When not in use, keep the module in its static-shield box.

Remove Power

ATTENTION: Remove power before removing or inserting

this module. When you remove or insert a module with power
! applied, an electrical arc may occur. An electrical arc can cause
personal injury or property damage by:
• sending an erroneous signal to your system’s field devices,
causing unintended machine motion
• causing an explosion in a hazardous environment
Electrical arcing causes excessive wear to contacts on both the
module and its mating connector. Worn contacts may create
electrical resistance.

1. Pollution Degree 2 is an environment where, normally, only non-conductive pollution occurs except that
occasionally a temporary conductivity caused by condensation shall be expected.
2. Over Voltage Category II is the load level section of the electrical distribution system. At this level transient
voltages are controlled and do not exceed the impulse voltage capability of the product’s insulation.
3. Pollution Degree 2 and Over Voltage Category II are International Electrotechnical Commission (IEC)
designations.

Publication 1769-IN007B-EN-P
4

System Assembly
The module can be attached to the controller or an adjacent I/O module before or
after mounting. For mounting instructions, see “Panel Mounting” on page 5, or
“DIN Rail Mounting” on page 6. To work with a system that is already mounted,
see “Replacing a Single Module within a System” on page 7.
The following procedure shows you how to assemble the Compact I/O system.

4
2
1

6
1
5

1. Disconnect power.
2. Check that the bus lever of the module to be installed is in the unlocked
(fully right) position.
3. Use the upper and lower tongue-and-groove slots (1) to secure the modules
together (or to a controller).
4. Move the module back along the tongue-and-groove slots until the bus
connectors (2) line up with each other.
5. Push the bus lever back slightly to clear the positioning tab (3). Use your
fingers or a small screw driver.
6. To allow communication between the controller and module, move the bus
lever fully to the left (4) until it clicks. Ensure it is locked firmly in place.

ATTENTION: When attaching I/O modules, it is very

important that the bus connectors are securely locked
! together to ensure proper electrical connection.

7. Attach an end cap terminator (5) to the last module in the system by using
the tongue-and-groove slots as before.
8. Lock the end cap bus terminator (6).
IMPORTANT: A 1769-ECR or 1769-ECL right or left end cap must be used to
terminate the end of the serial communication bus.
Publication 1769-IN007B-EN-P
 5

Mounting Expansion I/O

ATTENTION: During panel or DIN rail mounting of all
devices, be sure that all debris (metal chips, wire strands, etc.) is
! kept from falling into the module. Debris that falls into the
module could cause damage on power up.

Minimum Spacing

Top
Maintain spacing from
enclosure walls,

Compact I/O

Compact I/O

Compact I/O

Compact I/O

Compact I/O
wireways, adjacent

End Cap
Controller
equipment, etc. Allow 50 Side Side
mm (2 in.) of space on all
sides for adequate
ventilation, as shown: Bottom

Panel Mounting
Mount the module to a panel using two screws per module. Use M4 or #8
panhead screws. Mounting screws are required on every module.

Panel Mounting Using the Dimensional Template

For more than 2 modules: (number of modules - 1) X 35 mm (1.38 in.)

Refer to host controller documentation for this dimension. 35 28.5
(1.38) (1.12)
Host Controller

Right End Cap

Compact I/O

Compact I/O

Compact I/O

132
(5.197)
122.6±0.2 NOTE: All dimensions
(4.826±0.008) are in mm (inches). Hole
spacing tolerance:
±0.4 mm (0.016 in.)

Publication 1769-IN007B-EN-P
6

Panel Mounting Procedure Using Modules as a Template

The following procedure allows you to use the assembled modules as a template
for drilling holes in the panel. If you have sophisticated panel mounting
equipment, you can use the dimensional template provided on page 5. Due to
module mounting hole tolerance, it is important to follow these procedures:
1. On a clean work surface, assemble no more than three modules.
2. Using the assembled modules as a template, carefully mark the center of all
module-mounting holes on the panel.
3. Return the assembled modules to the clean work surface, including any
previously mounted modules.
4. Drill and tap the mounting holes for the recommended M4 or #8 screw.
5. Place the modules back on the panel, and check for proper hole alignment.
6. Attach the modules to the panel using the mounting screws.
Note: If mounting more modules, mount only the last one of this group
and put the others aside. This reduces remounting time during
drilling and tapping of the next group.
7. Repeat steps 1 to 6 for any remaining modules.

DIN Rail Mounting

The module can be mounted using the following DIN rails: 35 x 7.5 mm (EN 50
022 - 35 x 7.5) or 35 x 15 mm (EN 50 022 - 35 x 15).
Before mounting the module on a DIN rail, close the DIN rail latches. Press the
DIN rail mounting area of the module against the DIN rail. The latches will
momentarily open and lock into place.

Publication 1769-IN007B-EN-P
 7

Replacing a Single Module within a System

The module can be replaced while the system is mounted to a panel (or DIN rail).
1. Remove power. See important note on page 3.
2. On the module to be removed, remove the upper and lower mounting
screws from the module (or open the DIN latches using a flat-blade or
phillips style screw driver).
3. Move the bus lever to the right to disconnect (unlock) the bus.
4. On the right-side adjacent module, move its bus lever to the right (unlock)
to disconnect it from the module to be removed.
5. Gently slide the disconnected module forward. If you feel excessive
resistance, check that the module has been disconnected from the bus, and
that both mounting screws have been removed (or DIN latches opened).
Note: It may be necessary to rock the module slightly from front to back
to remove it, or, in a panel-mounted system, to loosen the screws of
adjacent modules.
6. Before installing the replacement module, be sure that the bus lever on the
module to be installed, and on the right-side adjacent module are in the
unlocked (fully right) position.
7. Slide the replacement module into the open slot.
8. Connect the modules together by locking (fully left) the bus levers on the
replacement module and the right-side adjacent module.
9. Replace the mounting screws (or snap the module onto the DIN rail).

Publication 1769-IN007B-EN-P
8

Field Wiring Connections

Grounding the Module

This product is intended to be mounted to a well-grounded mounting surface
such as a metal panel. Additional grounding connections from the module’s
mounting tabs or DIN rail (if used), are not required unless the mounting surface
cannot be grounded. Refer to Industrial Automation Wiring and Grounding
Guidelines, Allen-Bradley publication 1770-4.1, for additional information.

Input Wiring
Basic wiring of input devices1 to the 1769-IQ16 is shown below.

ATTENTION:
• Miswiring of the module to an AC power source will damage
! the module.
• Be careful when stripping wires. Wire fragments that fall into a
module could cause damage at power up. Once wiring is
complete, ensure the module is free of all metal fragments.
+DC (sinking)
-DC (sourcing)

IN 0
IN 1
IN 2
IN 3 24V dc
IN 4
IN 5
IN 6
IN 7
DC
+DC (sinking) COM 1 -DC (sinking)
-DC (sourcing) +DC (sourcing)

IN 9
IN 8
IN 11
24V dc IN 10
IN 13
IN 12
IN 15
IN 14
DC
-DC (sinking) COM 2
+DC (sourcing)

1. Sinking/Sourcing Inputs - Sourcing/sinking describes the current flow between the I/O module and the field
device. Sourcing I/O circuits supply (source) current to sinking field devices. Sinking I/O circuits are driven
by a current sourcing field device. Field devices connected to the negative side (DC Common) of the field
power supply are sinking field devices. Field devices connected to the positive side (+V) of the field supply
are sourcing field devices. Europe: DC sinking input and sourcing output module circuits are the commonly
used options.

Publication 1769-IN007B-EN-P
 9

A removable, write-on label is provided with the module. Remove the label from
the door, mark the identification of each terminal with permanent ink, and slide
the label back into the door. Your markings (ID tag) will be visible when the
module door is closed.

upper retaining screw

wiring the
finger-safe
terminal block

lower retaining screw

Removing the Finger-Safe Terminal Block

To remove the terminal block, loosen the upper and lower retaining screws. The
terminal block will back away from the module as you remove the screws. When
replacing the terminal block, torque the retaining screws to 0.46 Nm (4.1 in-lbs).

Wiring the Finger-Safe Terminal Block

When wiring the terminal block, keep the finger-safe cover in place.
1. Loosen the terminal screws to be wired.
2. Route the wire under the terminal pressure plate. You can use the bare wire
or a spade lug. The terminals will accept a 6.35 mm (0.25 in.) spade lug.

Note: The terminal screws are non-captive. Therefore, it is possible to use a ring
lug [max. 1/4” o.d. with a 0.139” minimum i.d. (M3.5)] with the module.
3. Tighten the terminal screw making sure the pressure plate secures the wire.
Recommended torque when tightening terminal screws is 0.68 Nm (6 in-
lbs).

Note: If you need to remove the finger-safe cover, insert a screw driver into one
of the square, wiring holes and gently pry the cover off. If you wire the
terminal block with the finger-safe cover removed, you will not be able to
put it back on the terminal block because the wires will be in the way.

Publication 1769-IN007B-EN-P
10

Wire Size and Terminal Screw Torque

Each terminal accepts up to two wires with the following restrictions:

Terminal Screw Retaining Screw

Wire Type Wire Size Torque Torque
Solid Cu-90°C (194°F) #14 to #22 AWG 0.68 Nm (6 in-lbs) 0.46 Nm (4.1 in-lbs)
Stranded Cu-90°C (194°F) #16 to #22 AWG 0.68 Nm (6 in-lbs) 0.46 Nm (4.1 in-lbs)

I/O Memory Mapping

Input Data File

For each input module, slot x, word 0 in the input data file contains the current
state of the field input points.

Bit Position
Word

15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
0 r r r r r r r r r r r r r r r r

r= read
Spare/Replacement Module Parts
• Terminal Block: 1769-RTBN18 (1 per kit)
• Door Label: 1769-RL1 (2 per kit)
• Door: 1769-RD (2 per kit)

Publication 1769-IN007B-EN-P
 11

Specifications

General Specifications

Specification Value
118 mm (height) x 87 mm (depth) x 35 mm (width)
height including mounting tabs is 138 mm
Dimensions
4.65 in. (height) x 3.43 in (depth) x 1.38 in (width)
height including mounting tabs is 5.43 in.
Approximate Shipping Weight 270g (0.6 lbs.)
(with carton)
Storage Temperature -40°C to +85°C (-40°F to +185°F)
Operating Temperature 0°C to +60°C (32°F to +140°F)
Operating Humidity 5% to 95% non-condensing
Operating Altitude 2000 meters (6561 feet)
Operating: 10 to 500 Hz, 5G, 0.030 inches maximum
Vibration peak-to-peak
Relay Operation: 2G
Operating: 30G panel mounted (20G DIN rail mounted)
Relay Operation: 7.5G panel mounted (5G DIN rail
Shock mounted)
Non-Operating: 40G panel mounted (30G DIN rail
mounted)
• C-UL certified (under CSA C22.2 No. 142)
Agency Certification • UL 508 listed
• CE compliant for all applicable directives
Class I, Division 2, Hazardous Location, Groups A, B, C,
Hazardous Environment Class D (UL 1604, C-UL under CSA C22.2 No. 213)
Radiated and Conducted Emissions EN50081-2 Class A
Electrical /EMC: The module has passed testing at the following levels:
• ESD Immunity (IEC1000-4-2) • 4kV contact, 8 kV air, 4 kV indirect
• 10 V/m, 80 to 1000 MHz, 80% amplitude modulation,
• Radiated Immunity (IEC1000-4-3) +900 MHz keyed carrier
• Fast Transient Burst (IEC1000-4-4) • 2 kV, 5 kHz
• Surge Immunity (IEC1000-4-5) • 2 kV common mode, 1 kV differential mode
• Conducted Immunity (IEC1000-4-6) • 10V, 0.15 to 80 MHz1
1. Conducted Immunity frequency range may be 150 kHz to 30 MHz if the Radiated Immunity frequency range
is 30 MHz to 1000 MHz.

Publication 1769-IN007B-EN-P
12

Input Specifications
Specification 1769-IQ16
Voltage Category 24V dc (sink/source1)
10 to 30V dc at 30°C (86°F)
Operating Voltage Range
10 to 26.4V dc at 60°C (140°F)
Number of Inputs 16
Bus Current Draw (max.) 115 mA at 5V dc (0.575W)
Heat Dissipation 3.55 Total Watts (The Watts per point, plus the minimum Watts,
with all points energized.)
On Delay: 8.0 ms
Signal Delay (max.)
Off Delay: 8.0 ms
Off-State Voltage (max.) 5V dc
Off-State Current (max.) 1.5 mA
On-State Voltage (min.) 10V dc
On-State Current (min.) 2.0 mA
Inrush Current (max.) 250 mA
Nominal Impedance 3K Ω
IEC Input Compatibility Type 1+
Power Supply Distance Rating 8 (The module may not be more than 8 modules away from the
power supply or controller.)
Verified by one of the following dielectric tests: 1200V ac for 1
Input Point to Bus (Compact Bus) sec. or 1697V dc for 1 sec.
Isolation
75V dc working voltage (IEC Class 2 reinforced insulation)
Group 1: inputs 0 to 7
Isolated Groups Group 2: inputs 8 to 15
Isolated groups operate in either sink or source configurations.
Verified by one of the following dielectric tests: 1200V ac for 1
Input Group to Input Group sec. or 1697V dc for 1 sec.
Isolation
75V dc working voltage (IEC Class 2 reinforced insulation)
Vendor I.D. Code 1
Product Type Code 7
Product Code 67
1. Sinking/Sourcing Inputs - Sourcing/sinking describes the current flow between the I/O module and the field
device. Sourcing I/O circuits supply (source) current to sinking field devices. Sinking I/O circuits are driven
by a current sourcing field device. Field devices connected to the negative side (DC Common) of the field
power supply are sinking field devices. Field devices connected to the positive side (+V) of the field supply
are sourcing field devices. Europe: DC sinking input and sourcing output module circuits are the commonly
used options.

Publication 1769-IN007B-EN-P
 13

Hazardous Location Considerations

This equipment is suitable for use in Class I, Division 2, Groups A, B, C, D or
non-hazardous locations only. The following ATTENTION statement applies to
use in hazardous locations.

ATTENTION: EXPLOSION HAZARD

• Substitution of components may impair suitability for Class I,
! Division 2.
• Do not replace components or disconnect equipment unless
power has been switched off or the area is known to be non-
hazardous.
• Do not connect or disconnect components unless power has
been switched off or the area is known to be non-hazardous.
• This product must be installed in an enclosure.
• All wiring must comply with N.E.C. article 501-4(b).

Environnements dangereux
Cet équipement est conçu pour être utilisé dans des environnements de Classe 1,
Division 2, Groupes A, B, C, D ou non dangereux. La mise en garde suivante
s’applique à une utilisation dans des environnements dangereux.

ATTENTION: DANGER D’EXPLOSION

• La substitution de composants peut rendre cet équipement
! impropre à une utilisation en environnement de Classe 1,
Division 2.
• Ne pas remplacer de composants ou déconnecter l'équipement
sans s'être assuré que l'alimentation est coupée et que
l'environnement est classé non dangereux.
• Ne pas connecter ou déconnecter des composants sans s'être
assuré que l'alimentation est coupée ou que l'environnement est
classé non dangereux.
• Ce produit doit être installé dans une armoire.

Publication 1769-IN007B-EN-P
14

For More Information

For Refer to this Document Pub. No.

A more detailed description of how to MicroLogix 1200 and MicroLogix
install and use your Compact I/O with 1500 Programmable Controllers 1764-RM001B-US-P
MicroLogix 1200 & 1500 programmable User Manual
controller.
A more detailed description of how to 1769-ADN DeviceNet Adapter
install and use your Compact I/O with User Manual 1769-UM001A-US-P
the 1769-ADN DeviceNet Adapter.
More information on proper wiring and Industrial Automation Wiring and
grounding techniques. Grounding Guidelines 1770-4.1

If you would like a manual, you can:

• download a free electronic version from the internet:
[Link]/micrologix or [Link]
• purchase a printed manual by:
– contacting your local distributor or Rockwell Automation representative
– visiting [Link] and placing your order
– calling 1.800.9NEWLIT(800.963.9548) (USA/Canada)
or 001.330.725.1574 (Outside USA/Canada)

Publication 1769-IN007B-EN-P
 15

Compact and MicroLogix are trademarks of Rockwell Automation.

Publication 1769-IN007B-EN-P
Publication 1769-IN007B-EN-P - June 2000 PN 40071-097-01(B)
Supercedes 1769-IN007A-EN-P - April 2000
& 1769-5.3 - January 1999 © 2000 Rockwell International Corporation. All rights reserved. Printed in the U.S.A.

´H'*£!¶Bq¨
 1769 Compact I/O Modules Specifications

1769-OB16
Compact solid-state 24V DC source output module
1769-OB16
Simplified Output Circuit Diagram +VDC +DC
CR OUT 0
OUT 1 CR
+VDC CR OUT 2
OUT 3 CR
S OUT 4
10K OUT 5
G CR OUT 6
VCC OUT OUT 7 CR
15K CR OUT 8 24V DC (Source)
0.1 μF D OUT 9 CR
OUT 10
100pF OUT 11 CR
OUT 12
20K OUT 13 CR
DC COM OUT 14
OUT 15
DC COM
-DC
Technical Specifications - 1769-OB16
Attribute 1769-OB16
Outputs 16 (16 points/group)
Voltage category 24V DC source
Operating voltage range 20.4…26.4V DC
Output delay, on 0.1 ms
Output delay, off 1.0 ms
Current draw @ 5.1V 200 mA
Heat dissipation, max 2.11 W
(1)
Off-state leakage current, max 1.0 mA @ 26.4V DC
On-state current, min 1.0 mA
On-state voltage drop, max 1.0V DC @ 1 A

Current per point, max 0.5 A @ 60 °C (140 °F)

1.0 A @ 30 °C (86 °F)
4.0 A @ 60 °C (140 °F)
Current per module, max 8.0 A @ 30 °C (86 °F)
Surge current(2) 2.0 A for 10 ms, repeatable every 2 s
Verified by one of these dielectric tests: 1200V AC for 1 s or 1697V DC for 1 s, output point to bus
Isolation voltage
75V DC working voltage (IEC Class II reinforced insulation)
Weight, approx 280 g (0.61 lb)
118 x 35 x 87 mm (4.65 x 1.38 x 3.43 in.)
Dimensions (HxWxD), approx
Height with mounting tabs 138 mm (5.43 in.)
Slot width 1
Module location DIN rail or panel mount
Power supply 1769-PA2, 1769-PB2, 1769-PA4, 1769-PB4
Power supply distance rating 8 modules
Terminal screw torque 0.68 Nm (6 lbin)
Retaining screw torque 0.46 Nm (4.1 lbin)
(22…14 AWG) solid
Wire size
(22…16 AWG) stranded
Wire type Cu-90 °C (194 °F)
Replacement terminal block 1769-RTBN18 (1 per kit)

Rockwell Automation Publication 1769-TD006G-EN-P - March 2020 69

1769 Compact I/O Modules Specifications

Technical Specifications - 1769-OB16

Attribute 1769-OB16
Replacement door label 1769-RL1 (2 per kit)
Replacement door 1769-RD (2 per kit)
Vendor ID code 1
Product type code 7
Product code 71
Enclosure type rating None (open style)

(1) To limit the effects of leakage current through solid-state outputs, a loading resistor can be connected in parallel with your load. Use a 5.6 k, 1/2 W resistor for transistor outputs, 24V DC operation.
(2) Use a 1N4004 diode reverse-wired across the load for transistor outputs switching 24V DC inductive loads.

See Environmental Specifications - 1769 Compact I/O Modules on page 3.

70 Rockwell Automation Publication 1769-TD006G-EN-P - March 2020

 1769 Compact I/O Modules Specifications

Temperature Derating - 1769-OB16

1769-OB16 Maximum Amperes per Point Versus Temperature
1.00
0.95
0.90
0.85
Maximum Amperes per Point

0.80
0.75
0.70
0.65
0.60
0.55
0.50
30˚C (86˚F) 40˚C (104˚F) 50˚C (122˚F) 60˚C (140˚F)
Ambient Temperature

1769-OB16 Maximum Amperes per Module Versus Temperature

8.00

7.50
Maximum Amperes per Module

7.00

6.50

6.00

5.50

5.00

4.50

4.00
30˚C (86˚F) 40˚C (104˚F) 50˚C (122˚F) 60˚C (140˚F)
Ambient Temperature

Certifications - 1769-OB16
Certification(1) 1769-OB16
UL Listed Industrial Control Equipment, certified for US and Canada. See UL File E10314.
c-UL-us
UL Listed for Class I, Division 2 Group A,B,C,D Hazardous Locations, certified for U.S. and Canada. See UL File E10314.
European Union 2014/30/EU EMC Directive, compliant with:
CE • EN 61000-6-2; Industrial Immunity
• EN 61000-6-4; Industrial Emissions

RCM Australian Radiocommunications Act, compliant with:

• AS/NZS CISPR 11; Industrial Enclosure
EAC Russian Customs Union TR CU 020/2011 EMC Technical Regulation
(1) When marked. See the Product Certification link at [Link] for Declarations of Conformity, Certificates, and other certification details.

Rockwell Automation Publication 1769-TD006G-EN-P - March 2020 71

1769 Compact I/O Modules Specifications

1769-IF4I
Compact voltage/current analog, individually isolated input module

1769-IF4I Differential Inputs 1769-IF4I Single-ended Sensor/Transmitter Inputs

Belden 8761 Cable (or equivalent) Sensor/ +

Transmitter -
Current
Analog Source Supply
+ Signal

Voltage

Ground Signal
+

Voltage
Ground Signal
+

1769-IF4I Mixed Transmitter Inputs

Ch0+
Sensor/ + N/C
Transmitter Current Ch0_iRtn
-
Supply N/C

+ Signal Ch0-
Ch1+
N/C
Ch1_iRtn
Voltage N/C
Ch1-
Ground Signal
+
Ch2+
N/C
Voltage Ch2_iRtn
N/C
+ Ground Signal
Ch2-
Ch3+
N/C
Ch3_iRtn
N/C
+ Ch3-
Differential
Voltage
_
+ Signal

14 Rockwell Automation Publication 1769-TD006G-EN-P - March 2020

 1769 Compact I/O Modules Specifications

Technical Specifications - 1769-IF4I

Attribute 1769-IF4I
Inputs 4 isolated differential
±10V
0…10V
0…5V
Input range 1…5V
0…20 mA
4…20 mA
±10.5V
-0.5…10.5V
Full scale range(1) -0.5…5.25V
0.5…5.25V
0…21 mA
3.2…21 mA
5V DC, 140 mA
Bus current draw
24V DC, 110 mA
Heat dissipation, max 3.0 W
Converter type Delta Sigma

Resolution (2) 16 bits (unipolar)

15 bits plus sign (bipolar)
Rated working voltage(3) 30V AC/30V DC
Common mode voltage range(4) ±10V DC max per channel
Common mode rejection > 60 dB @ 50 and 60 Hz with the 10 Hz filter selected
Normal mode rejection ratio -50 dB @ 50 and 60 Hz with the 10 Hz filter selected
Voltage: 1 M
Input impedance
Current: 249 

Accuracy(5) Voltage: ±0.2% full scale @ 25 °C (77 °F)

Current: ±0.35% full scale @ 25 °C (77 °F)
Voltage: ±0.003% per °C
Accuracy drift with temperature Current: ±0.0045% per °C
Nonlinearity ±0.03%
Repeatability(6) ±0.03%
Voltage: ±0.3%
Module error
Current: ±0.5%

Overload at input terminals, max(7) Voltage: ±24V DC continuous, 0.1 mA

Current: ±28 mA continuous, ±7.6V DC
500V AC or 710V DC for 1 minute (qualification test), group to bus
30V AC/30V DC working voltage (IEC Class II reinforced insulation)
Isolation voltage
500V AC or 710V DC for 1 minute or 250V continuous (optical and magnetic), channel to rack and
channel to channel
Weight, approx 300 g (0.65 lb)
118 x 35 x 87 mm (4.65 x 1.38 x 3.43 in.)
Dimensions (HxWxD), approx
Height with mounting tabs 138 mm (5.43 in.)
Slot width 1
Module location DIN rail or panel mount
Power supply 1769-PA2, 1769-PB2, 1769-PA4, 1769-PB4
Power supply distance rating 8 modules
Terminal screw torque 0.68 Nm (6 lbin)
Retaining screw torque 0.46 Nm (4.1 lbin)
(22…14 AWG) solid
Wire size
(22…16 AWG) stranded
Wire type Cu-90 °C (194 °F)
Replacement terminal block 1769-RTBN18 (1 per kit)

Rockwell Automation Publication 1769-TD006G-EN-P - March 2020 15

1769 Compact I/O Modules Specifications

Technical Specifications - 1769-IF4I

Attribute 1769-IF4I
Replacement door label 1769-RL2 series B (2 per kit)
Replacement door 1769-RD (2 per kit)
Vendor ID code 1
Product type code 10
Product code 44
Enclosure type rating None (open-style)

(1) The over- or under-range flag comes on when the normal operating range (over/under) is exceeded. The module continues to convert the analog input up to the maximum full scale range. The flag
automatically resets when within the normal operating range.
(2) Resolution is dependent upon your filter selection. The maximum resolution is achieved with either the 50 or 60 Hz filter selected.
(3) Rated working voltage is the maximum continuous voltage that can be applied at the input terminal, including the input signal and the value that floats above ground potential. For example, a 10V DC
input signal and 20V DC potential above ground at the input terminal.
(4) For proper operation, both the plus and minus input terminals must be within ±10V DC of analog common.
(5) Includes offset, gain, nonlinearity, and repeatability error terms.
(6) Repeatability is the ability of the input module to register the same reading in successive measurements for the same input signal.
(7) Damage can occur to the input circuit if this value is exceeded.

See Environmental Specifications - 1769 Compact I/O Modules on page 3.

Response Speed - 1769-IF4I

Filter Frequency Channel Update
28.5 Hz 108 ms
50 Hz 62 ms
60 Hz 52 ms
300 Hz 12 ms
360 Hz 10 ms

Certifications - 1769-IF4I
Certification(1) 1769-IF4I
UL Listed Industrial Control Equipment, certified for US and Canada. See UL File E194810.
c-UL-us
UL Listed for Class I, Division 2 Group A,B,C,D Hazardous Locations, certified for U.S. and Canada. See UL File E194810.
European Union 2014/30/EU EMC Directive, compliant with:
CE • EN 61000-6-2; Industrial Immunity
• EN 61000-6-4; Industrial Emissions
Australian Radiocommunications Act, compliant with:
RCM • AS/NZS CISPR 11; Industrial Enclosure
EAC Russian Customs Union TR CU 020/2011 EMC Technical Regulation
(1) When marked. See the Product Certification link at [Link] for Declarations of Conformity, Certificates, and other certification details.

16 Rockwell Automation Publication 1769-TD006G-EN-P - March 2020

 1769 Compact I/O Modules Specifications

1769-OF4
Compact voltage/current output analog module

Simplified Schematic
Indicator
Isolation
1769-OF4
16-pin Backplane Connector

Voltage

18-pin Terminal Block

Output V out 3+
Optocouplers

I out 3+
D to A V out 2+
ASIC CPU Converter Voltage Load I out 2+
ANLG Com
Current ANLG Com
Output Earth Ground V out 0+
I out 0+
+15V V out 1+
Isolated Current Load
+5V I out 1 +
DC to DC GND
Earth Ground
-15V

Technical Specifications - 1769-OF4

Attribute 1769-OF4
Outputs 4 single-ended
±10V
0…10V
0…5V
Output range
1…5V
0…20 mA
4…20 mA
±10.5V
-0.5…10.5V
-0.5…5.25V
Full scale range(1) 0.5…5.25V
0…21 mA
3.2…21 mA
Resolution 15 bits plus sign unipolar and bipolar
Current draw @ 5.1V 120 mA
Current draw @ 24V 170 mA
Heat dissipation, max 2.86 W
Interrupts not enabled: 2.5 ms
Conversion rate (all channels), max Interrupts enabled: 3.8 ms
Step response to 63%(2) 2.9 ms
Current: 0…600  (includes wire resistance)
Resistive load
Voltage: 1 K or greater

Inductive load, max 0.1 mH (current load)

1.0 μF (voltage load)
Field calibration None required
(3)
Accuracy 0.5% full scale at 25 °C (77 °F)
Accuracy drift with temperature ±0.0086% of full scale per °C
Output ripple(4) ±0.05% @ 0…50 kHz
Nonlinearity ±0.05%

Rockwell Automation Publication 1769-TD006G-EN-P - March 2020 83

1769 Compact I/O Modules Specifications

Technical Specifications - 1769-OF4

Attribute 1769-OF4
Repeatability(5) ±0.05%
Module error
0…60 °C (32…140 °F) +/-0.8% of full scale

Voltage output: < 1 

Output impedance
Current output: > 1 M
Open and short-circuit protection Yes
Short-circuit protection, max 40 mA
Output overvoltage protection Yes
Output response at system power up and power down 2.5…-1.0V DC spike for < 15 ms
(6)
Rated working voltage 30V AC/30V DC
510V AC or 720V DC for 1 minute (qualification test), output group to bus
Isolation voltage
30V AC/30V DC working voltage (IEC Class II reinforced insulation)
Weight, approx 280 g (0.61 lb)
118 x 35 x 87 mm (4.65 x 1.38 x 3.43 in.)
Dimensions (HxWxD), approx
Height with mounting tabs 138 mm (5.43 in.)
Slot width 1
Module location DIN rail or panel mount
Power supply 1769-PA2, 1769-PB2, 1769-PA4, 1769-PB4
Power supply distance rating 8 modules
Terminal screw torque 0.68 Nm (6 lbin)
Retaining screw torque 0.46 Nm (4.1 lbin)
(22…14 AWG) solid
Wire size (22…16 AWG) stranded
Wire type Cu-90 °C (194 °F)
Replacement terminal block 1769-RTBN18 (1 per kit)
Replacement door label 1769-RL2 (2 per kit)
Replacement door 1769-RD (2 per kit)
Vendor ID code 1
Product type code 10
Product code 48
Input words 5
Output words 5
Configuration words 32
Enclosure type rating None (open style)

(1) The over- or under-range flag comes on when the normal operating range (over/under) is exceeded. The module continues to convert the analog input up to the maximum full scale range. The flag
automatically resets when within the normal operating range.
(2) Step response is the time between when the D/A converter was instructed to go from minimum to full range until the device is at 63% of full range.
(3) Includes offset, gain, drift, nonlinearity, and repeatability error terms.
(4) Output ripple is the amount that a fixed output varies with time, which assumes a constant load and temperature.
(5) Repeatability is the ability of the output module to reproduce output readings when the same controller value is applied to it consecutively, under the same conditions and in the same direction.
(6) Rated working voltage is the maximum continuous voltage that can be applied at the input terminal, including the input signal and the value that floats above ground potential. For example, a10V DC
input signal and 20V DC potential above ground at the input terminal.

See Environmental Specifications - 1769 Compact I/O Modules on page 3.

84 Rockwell Automation Publication 1769-TD006G-EN-P - March 2020

 1769 Compact I/O Modules Specifications

Certifications - 1769-OF4
Certification(1) 1769-OF4
UL Listed Industrial Control Equipment, certified for US and Canada. See UL File E65584
c-UL-us
UL Listed for Class I, Division 2 Group A,B,C,D Hazardous Locations, certified for U.S. and Canada. See UL File E194810.
European Union 2014/30/EU EMC Directive, compliant with:
CE • EN 61000-6-2; Industrial Immunity
• EN 61000-6-4; Industrial Emissions

RCM Australian Radiocommunications Act, compliant with:

• AS/NZS CISPR 11; Industrial Enclosure
EAC Russian Customs Union TR CU 020/2011 EMC Technical Regulation
(1) When marked. See the Product Certification link at [Link] for Declarations of Conformity, Certificates, and other certification details.

Rockwell Automation Publication 1769-TD006G-EN-P - March 2020 85

Compact I/O Expansion Power Supplies

Connect Field Wires

The following instructions explain how to wire your power supply.

Ground the Power Supply

ATTENTION: This product is intended to be mounted to a well-grounded mounting surface such

as a metal panel. Additional grounding connections from the power supply's mounting tabs or DIN
rail (if used) are not required unless the mounting surface cannot be grounded. Refer to Industrial
Automation Wiring and Grounding Guidelines, Allen-Bradley publication 1770-4.1, for additional
information.

Wire the Power Supply

Connect the ground screw of the power supply to the nearest ground or ground bus.
Use a 2.5 mm2 (14 AWG) wire and keep the leads as short as possible.

ATTENTION: This symbol denotes protective earth ground and earth ground terminals that
provide a low impedance path between electrical circuits and earth for safety purposes and
provides noise immunity improvements. You must make these connections for safety purposes.

20 Rockwell Automation Publication 1769-IN028I-EN-P - July 2020

 Compact I/O Expansion Power Supplies

1. Connect incoming power to the power supply terminals as indicated in this graphic.

Catalog Number 1769-PB2, 1769-PB2K Catalog Number 1769-PB4, 1769-PB4K

NOT USED NOT USED

NOT USED NOT USED

+24V DC +24V DC

DC NEUTRAL DC NEUTRAL

CHASSIS GROUND CHASSIS GROUND

Catalog Number 1769-PA2, 1769-PA2K Catalog Number 1769-PA4, 1769-PA4K

*PWR OUT +24V DC NOT USED

*PWR OUT COM NOT USED
120/240V AC (L1) 120/240V AC (L1)
V AC COM (L2) V AC COM (L2)

CHASSIS GROUND CHASSIS GROUND

*24V DC user power for sensors or other special 24V DC I/O devices

ATTENTION: Turn off incoming power before connecting or disconnecting wires. Failure to do so
could cause injury to personnel and/or damage to equipment.

Rockwell Automation Publication 1769-IN028I-EN-P - July 2020 21

 Compact I/O Expansion Power Supplies

Specifications

Technical Specifications
Attribute 1769-PA2, 1769-PA2K(3) 1769-PB2, 1769-PB2K 1769-PA4, 1769-PA4K 1769-PB4, 1769-PB4K

Input voltage range 85…265V AC 19.2…31.2V DC 85…265V AC 19.2…32V DC

Input frequency range 47…63 Hz N/A 47…63 Hz N/A

Power supply distance 8

rating(1) 8 I/O modules can be connected on either side of the power supply for a maximum of 16 modules

Operating altitude 2000 m (6562 ft)

265V (continuous), 265V (continuous), 75V (continuous),

Reinforced Insulation Type 75V (continuous), Reinforced Insulation Type Reinforced Insulation Type
Routine tested at Reinforced Insulation Type (IEC Class 1 grounding (IEC Class 1 grounding
Isolation voltage 2596V DC for 1s, AC Power Routine tested at required) required)
Input to System and AC 1697V DC for 1s, DC Power Routine tested at Routine tested at
Power Input to 24V DC Input to System 2596V DC for 1s, AC Power 1697V DC for 1s, DC Power
User Power Input to System Input to System

100VA @ 120V AC 200VA @ 120V AC

Power consumption 50VA @ 24V DC 100VA @ 24V DC
130VA @ 240V AC 240VA @ 240V AC

Power dissipation 8 W @ 60 °C (140 °F) 7.5 W @ 60 °C (140 °F) 18 W @ 60 °C (140 °F) 14.5 W @ 60 °C (140 °F)

Current capacity @ 5V DC 2.0 A 2.0 A 4.0 A 4.0 A

Current capacity @ 24V DC 0.8 A 0.8 A 2.0 A 2.0 A

Inrush current, max 25 A @ 132V AC 30 A @ 31.2V DC 25 A @ 132V AC 30 A @ 31.2V DC

Fuse type Littelfuse 02153.15MXP Littelfuse 021706.3MXP Littelfuse 02183.15MXP Littelfuse [Link]

Dimensions (HxWxD), 118 x 70 x 87 mm (4.65 x 2.76 x 3.43 in.)

approx height including mounting tabs is 138 mm (5.43 in.)

Weight, approx 485 g (1.07 lb) 500 g (1.10 lb)

Wiring category(2) 1 on power ports 2 on power ports 1 on power ports 2 on power ports
2
Wire size 2.5 mm (14 AWG) solid copper wire rated at 90 °C (194 °F), or greater, 1.2 mm (3/64 in.) insulation max

North American temp

T3C
code

ATEX/IEC temp code N/A T4 N/A T4

Enclosure type rating None (open-style)

(1) You can use a maximum of two banks of I/O modules. This condition occurs when configuring your system with a MicroLogix 1500 controller, one
expansion cable, one expansion power supply, and a total of eight I/O modules. The expansion power supply cannot be directly connected to the
MicroLogix 1500 controller.
(2) Use this Conductor Category information for to plan conductor routing. See the Industrial Automation Wiring and Grounding Guidelines,
publication 1770-4.1.
(3) Catalog numbers followed by a “K” indicate a conformal coating option.

Rockwell Automation Publication 1769-IN028I-EN-P - July 2020 29

Compact I/O Expansion Power Supplies

Environmental Specifications
1769-PA2, 1769-PB2, 1769-PA4, 1769-PB4,
Attribute
1769-PA2K(1) 1769-PB2K 1769-PA4K 1769-PB4K

Temperature, operating
IEC 60068-2-1 (Test Ad, Operating Cold
IEC 60068-2-2 (Test Bd, Operating Dry 0 °C < Ta < 60 °C (32 °F < Ta < 140 °F)
Heat)
IEC 60068-2-14 (Test Nb, Operating
Thermal Shock)

Temperature,
non-operating
IEC 60068-2-1 (Test Ab, Unpackaged
Non-operating Cold)
-40 < Ta < +85 °C (-40 < Ta < +185 °F)
IEC 60068-2-2 (Test Bb, Unpackaged
Non-operating Dry Heat)
IEC 60068-2-14 (Test Na, Unpackaged
Thermal Shock)

Relative humidity
IEC 60068-2-30 (Test Db, Unpackaged 5…95% noncondensing
Damp Heat)

Vibration
5 g @ 10…500 Hz
IEC 60068-2-6 (Test Fc, Operating)

Shock, operating
DIN rail mount: 20 g
IEC 60068-2-27 (Test Ea, Unpackaged
Panel mount: 30 g
Shock)

Shock, nonoperating
DIN rail mount: 30 g
IEC 60068-2-27 (Test Ea, Unpackaged
Shock) Panel mount: 40 g

Emissions
Group 1, Class A
CISPR 11

ESD immunity 6 kV contact

IEC61000-4-2 8 kV air discharges

10V/m with 1 kHz 10V/m with 1 kHz 10V/m with 1 kHz

sine-wave 80% AM sine-wave 80% AM sine-wave 80% AM 10V/m with 1 kHz sine-
from 80…2000 MHz from 80…2000 MHz from 80…2000 MHz wave 80%AM from
10V/m with 200 Hz 10V/m with 200 Hz 10V/m with 200 Hz 80…2000 MHz
50% Pulse 100% AM 50% Pulse 100% AM 50% Pulse 100% AM 10V/m with 200 Hz 50%
Radiated RF immunity at 900 MHz at 900 MHz at 900 MHz Pulse 100% AM at 900 MHz
10V/m with 200 Hz 10V/m with 200 Hz 10V/m with 200 Hz 10V/m with 200 Hz 50%
IEC61000-4-3
50% Pulse 100% AM 50% Pulse 100% AM 50% Pulse 100% AM Pulse 100% AM at 1890
at 1890 MHz at 1890 MHz at 1890 MHz MHz
10V/m with 1 kHz 10V/m with 1 kHz 10V/m with 1 kHz 10V/m with 1 kHz sine-
sine-wave 80% AM sine-wave 80% AM sine-wave 80% AM wave 80% AM from
from 2000…2700 from 2000…2700 from 2000…2700 2000…2700 MHz
MHz MHz MHz

±2 kV at 5 kHz on AC
power ports
EFT/B immunity ±2 kV at 5 kHz on DC ±2 kV at 5 kHz on AC ±2 kV at 5 kHz on DC power
±2 kV at 5 kHz on power ports power ports ports
IEC 61000-4-4
24V DC PWR OUT
ports

30 Rockwell Automation Publication 1769-IN028I-EN-P - July 2020

 Compact I/O Expansion Power Supplies

Environmental Specifications (Continued)

1769-PA2, 1769-PB2, 1769-PA4, 1769-PB4,
Attribute
1769-PA2K(1) 1769-PB2K 1769-PA4K 1769-PB4K

±2 kV line-line (DM)
and ±4 kV line-earth
(CM) on AC power
ports ±500 V line-line ±2 kV line-line (DM)
±500 V line-line (DM) and
Surge transient immunity IEC61000-4-5 (DM) and ±1 kV line- and ±4 kV line-earth
±500V line-line earth (CM) on DC (CM) on AC power ±1 kV line-earth (CM) on
(DM) and ±500V power ports ports DC power ports
line-earth (CM) on
24V DC PWR OUT
ports

Conducted RF Immunity IEC61000-4-6 10V rms with 1 kHz sine-wave 80% AM from 150 kHz...80 MHz

30% dips for 1 period 30% dips for 1 period

at 0° and 180° on AC at 0° and 180° on AC
supply ports supply ports
60% dips for 5 and 50 60% dips for 5 and 50
periods on AC supply periods on AC supply
Voltage variation ports ports
N/A N/A
IEC 61000-4-11 ±10% fluctuations ±10% fluctuations
for 15 min on AC for 15 min on AC
supply ports supply ports
>95% interruptions >95% interruptions
for 250 periods on AC for 250 periods on AC
supply ports supply ports

Voltage variation 10 ms interruption 10 ms interruption on DC

N/A on DC supply ports N/A supply ports
IEC 61000-4-29

(1) Catalog numbers followed by a “K” indicate a conformal coating option.

Rockwell Automation Publication 1769-IN028I-EN-P - July 2020 31

 Product brochure

Eaton FlexPDU and Maintenance Bypass PDU

Eaton provides five different functions for rack power Features
distribution solutions. Two of these functions, FlexPDU
and Maintenances Bypass PDU, were created as • H otSwap MBP provides service continuity during
accessories specific to some of our UPSs. Both of UPS maintenance or upgrade
these units offer the flexibility of connections to • Both units offer connections to all types of equipment
meet the demanding requirements of today’s data • Eases installation with flexible mounting options
center architects.
• Minimal depth accommodates most space
The HotSwap Maintenance Bypass (MBP) unit enables constraints
easy UPS replacement without interruption of the load.
The HotSwap MBP is ideal when exchanging a unit or
servicing a UPS. For added convenience, the HotSwap
MBP offers two types of receptacles: 5-15R or 5-20R.
The FlexPDU is a basic function power distribution
unit with a short power cord for easy, close mounting.
FlexPDUs are available with 5-15R, 5-20R or L5-20R
output receptacles, for connection to a wide range
of equipment.
Both of these options allow for easy deployment, even
in space-constrained environments. You have a variety
of mounting options, including top and side mounting. Side mounting Flex PDU Top mounting horizontal
with Tower UPS FlexPDU with 2U UPS

HotSwap MBPs rackmounted Top mounting vertical

horizontally in rack FlexPDU
FLEXPDU MODELS
Dimensions
Catalog number Style Number Input Plug Breaker Max kW Function Cord (ft) Orientation Receptacles (H x W x D, in)
EFLXL1500R-PDU1U 58015 5-15P None 1.44 BA 3 1U (12) 5-15R 1.7 x 19.0 x 2.4
EFLXL2000R-PDU1U 58020 5-20P None 1.92 BA 3 1U (12) 5-20R 1.7 x 19.0 x 2.4
EFLXL2000R-PDU1UL 58021 5-20P None 1.92 BA 3 1U (5) L5-20R 1.7 x 19.0 x 3.0
EFLXI3000R-PDU1UIEC 68438 C20 Inlet (2) 20A 3.33 BA 3 1U (12) C13, (1) C19 1.7 x 19.0 x 2.4

HOTSWAP MODELS
Dimensions
Catalog number Style Number Input Plug Breaker Max kW Function Cord (ft) Orientation Receptacles (H x W x D, in)
EHBPL1500R-PDU1U 58115 5-15P None 1.44 BA 8 2U (6) 5-15R 2.1 x 17.3 x 3.8
EHBPL2000R-PDU1U 58120 5-20P None 1.92 BA 8 2U (6) 5-20R 2.1 x 17.3 x 3.8
EHBPL3000R-PDU1U 58130 L5-30P (2) 20A 2.88 BA 3.3 2U (5) 5-20R 2.1 x 17.3 x 3.8

COMPATIBILITY MATRIX FOR RACKMOUNT UPSs*

FlexPDU UPS model
plug/amp rating (North American only) Rack mounting
Eaton 5P 1U UPS, 550, 750, 1000 and 1500 VA 3
Eaton 5P 2U UPS, 1500, 2200 and 3000 VA 3
15A Eaton 5) 2U Compact UPS, 750, 1000 and 1500 VA 3
Eaton 5PX UPS, 1000 and 1500 VA 3
Eaton 9PX UPS, 700, 1000 and 1500 VA 3
Eaton 5PX UPS, 2200 VA 3
20A
Eaton 9PX UPS, 2000 VA 3
*For tower models, all FlexPDUs can be wall-mounted. ** Rear mounting available on 3U models only.

HotSwap MBP UPS model

plug/amp rating (North American only) Rack mounting
Eaton 5P UPS, 550, 750, 1000 and 1500 VA 3
Eaton 5P 2U UPS, 1500, 2200 and 3000 VA 3
15A Eaton 5P 2U Compact UPS, 750, 1000 and 1500 VA 3
Eaton 5PX UPS, 1000 and 1500 VA 3
Eaton 9PX UPS, 700, 1000 and 1500 VA 3
Eaton 5PX UPS, 2200 VA 3
20A
Eaton 9PX UPS, 2000 VA 3
Eaton 5PX UPS, 3000 VA 3
30A
Eaton 9PX UPS, 3000 VA 3
*For tower models, all HotSwap MBPs can be wall-mounted. **Rear mounting available on 3U models only.

To interact with the FlexPDU and Maintenance

Bypass PDF, please visit: [Link]/epdu
Eaton
1000 Eaton Boulevard
Cleveland, OH 44122
United States
[Link]

©2017 Eaton Follow us on social media to get the

All Rights Reserved Eaton is a registered trademark. latest product and support information.
Printed in USA
Publication No. PDU17FXA / GG All other trademarks are property
August 2017 of their respective owners.
[Link]

Power supply unit - QUINT-PS/1AC/24DC/10 - 2866763

Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
([Link]

Primary-switched power supply unit, QUINT POWER, Screw connection, DIN rail mounting, SFB Technology
(Selective Fuse Breaking), input: 1-phase, output: 24 V DC / 10 A

Product Description
QUINT POWER power supplies with maximum functionality
QUINT POWER circuit breakers magnetically and therefore quickly trip at six times the nominal current, for selective and therefore cost-effective
system protection. The high level of system availability is additionally ensured, thanks to preventive function monitoring, as it reports critical
operating states before errors occur.
Reliable starting of heavy loads takes place via the static power reserve POWER BOOST. Thanks to the adjustable voltage, all ranges between 5
V DC ... 56 V DC are covered.

Your advantages
 Fast tripping of standard circuit breakers with dynamic power reserve SFB (selective fuse breaking) technology with up to 6 times the nominal
current for 12 ms
 For superior system availability
 Reliable starting of difficult loads with the static POWER BOOST power reserve with up to 1.5 times the nominal current permanently
 Preventive function monitoring

Key Commercial Data

Packing unit 1 pc

GTIN

GTIN 4046356113793
Weight per Piece (excluding packing) 1,100.000 g
Custom tariff number 85044070
Country of origin Thailand

Technical data
Dimensions
Width 60 mm
Height 130 mm
Depth 125 mm

06/24/2021   Page 1 / 5
[Link]

Power supply unit - QUINT-PS/1AC/24DC/10 - 2866763

Technical data
Dimensions
Width with alternative assembly 122 mm
Height with alternative assembly 130 mm
Depth with alternative assembly 63 mm
Installation distance right/left 5 mm / 5 mm
Installation distance top/bottom 50 mm / 50 mm

Ambient conditions
Degree of protection IP20
Ambient temperature (operation) -25 °C ... 70 °C (> 60 °C Derating: 2.5 %/K)
Ambient temperature (start-up type tested) -40 °C
Ambient temperature (storage/transport) -40 °C ... 85 °C
Max. permissible relative humidity (operation) ≤ 95 % (at 25 °C, non-condensing)
Climatic class 3K3 (in acc. with EN 60721)
Degree of pollution 2
Installation height 5000 m

Input data
Nominal input voltage range 100 V AC ... 240 V AC
110 V DC ... 250 V DC
Input voltage range 85 V AC ... 264 V AC
90 V DC ... 350 V DC (UL 508: ≤ 300 V DC)
Dielectric strength maximum 300 V AC
AC frequency range 45 Hz ... 65 Hz
Frequency range DC 0 Hz
Discharge current to PE < 3.5 mA
Current consumption 2.2 A (120 V AC)
1.3 A (230 V AC)
2.5 A (110 V DC)
1.2 A (220 V DC)
Nominal power consumption 302 VA
Inrush current < 15 A
Mains buffering time > 36 ms (120 V AC)
> 36 ms (230 V AC)
Input fuse 10 A (slow-blow, internal)
Recommended breaker for input protection 10 A ... 20 A (AC: Characteristics B, C, D, K)
Power factor (cos phi) 0.85
Type of protection Transient surge protection
Protective circuit/component Varistor, gas-filled surge arrester

Output data
Nominal output voltage 24 V DC ±1 %
Setting range of the output voltage (USet) 18 V DC ... 29.5 V DC (> 24 V DC, constant capacity restricted)

06/24/2021   Page 2 / 5
[Link]

Power supply unit - QUINT-PS/1AC/24DC/10 - 2866763

Technical data
Output data
Nominal output current (IN) 10 A (-25 °C ... 60 °C, UOUT = 24 V DC)
POWER BOOST (IBoost) 15 A (-25 °C ... 40 °C permanent, UOUT = 24 V DC )
Selective Fuse Breaking (ISFB) 60 A (12 ms)
Derating 60 °C ... 70 °C (2.5%/K)
Connection in parallel Yes, for redundancy and increased capacity
Connection in series yes
Feedback voltage resistance max. 35 V DC
Protection against overvoltage at the output (OVP) < 35 V DC
Control deviation < 1 % (change in load, static 10 % ... 90 %)
< 2 % (change in load, dynamic 10 % ... 90 %)
< 0.1 % (change in input voltage ±10 %)
Residual ripple < 50 mVPP (with nominal values)
Output power 240 W
Typical response time < 0.15 s
Maximum power dissipation in no-load condition 9.1 W
Power loss nominal load max. 22 W

General
Net weight 1.1 kg
Efficiency > 92.5 % (for 230 V AC and nominal values)
MTBF (IEC 61709, SN 29500) > 940000 h (25 °C)
> 530000 h (40 °C)
> 230000 h (60 °C)
Insulation voltage input/output 4 kV AC (type test)
2 kV AC (routine test)
Insulation voltage input / PE 3.5 kV AC (type test)
2 kV AC (routine test)
Insulation voltage output / PE 500 V DC (routine test)
Degree of protection IP20
Protection class I
Mounting position horizontal DIN rail NS 35, EN 60715
alignable: PN ≥50%, 5 mm horizontally, 15 mm next to active
components, 50 mm vertically
Assembly instructions
alignable: PN <50%, 0 mm horizontally, 40 mm vertically top, 20 mm
vertically bottom

Connection data, input

Connection method Screw connection
Conductor cross section solid min. 0.2 mm²
Conductor cross section solid max. 2.5 mm²
Conductor cross section flexible min. 0.2 mm²
Conductor cross section flexible max. 2.5 mm²

06/24/2021   Page 3 / 5
[Link]

Power supply unit - QUINT-PS/1AC/24DC/10 - 2866763

Technical data
Connection data, input
Conductor cross section AWG min. 16
Conductor cross section AWG max. 12
Stripping length 7 mm
Screw thread M3

Connection data, output

Connection method Screw connection
Conductor cross section solid min. 0.2 mm²
Conductor cross section solid max. 2.5 mm²
Conductor cross section flexible min. 0.2 mm²
Conductor cross section flexible max. 2.5 mm²
Conductor cross section AWG min. 16
Conductor cross section AWG max. 12
Stripping length 7 mm
Screw thread M3

Connection data for signaling

Connection method Screw connection
Conductor cross section solid min. 0.2 mm²
Conductor cross section solid max. 2.5 mm²
Conductor cross section flexible min. 0.2 mm²
Conductor cross section flexible max. 2.5 mm²
Conductor cross section AWG min. 16
Conductor cross section AWG max. 12
Screw thread M3

Standards and Regulations

Electromagnetic compatibility Conformance with EMC Directive 2014/30/EU
Noise immunity EN 61000-6-2
Connection in acc. with standard CSA
Standards/regulations EN 61000-4-2
Contact discharge 4 kV (Test Level 2)
Standards/regulations EN 61000-4-3
Frequency range 80 MHz ... 1 GHz
Test field strength 10 V/m (Test Level 3)
Frequency range 1.4 GHz ... 2 GHz
Test field strength 3 V/m (Test Level 2)
Standards/regulations EN 61000-4-4
Comments Criterion B
Standards/regulations EN 61000-6-3
EN 61000-4-6
Frequency range 0.15 MHz ... 80 MHz

06/24/2021   Page 4 / 5
[Link]

Power supply unit - QUINT-PS/1AC/24DC/10 - 2866763

Technical data
Standards and Regulations
Voltage 10 V (Test Level 3)
Low Voltage Directive Conformance with Low Voltage Directive 2014/35/EC
Standard - Electrical safety IEC 61010-2-201 (SELV)
Standard – Safety extra-low voltage IEC 61010-1 (SELV)
IEC 61010-2-201 (PELV)
Standard - Safe isolation IEC 61010-2-201
Standard – Limitation of mains harmonic currents EN 61000-3-2
Standard - Equipment safety BG (design tested)
Standard - Approval for medical use IEC 60601-1, 2 x MOOP
Shipbuilding approval DNV GL (EMC B), ABS, LR, RINA, NK, BV
UL approvals UL Listed UL 508
UL/C-UL Recognized UL 60950-1
UL ANSI/ISA-12.12.01 Class I, Division 2, Groups A, B, C, D
(Hazardous Location)
DeviceNet approval DeviceNet™ Power Supply Conformance Tested
Shock 18 ms, 30g, in each space direction (according to IEC 60068-2-27)
Vibration (operation) < 15 Hz, amplitude ±2.5 mm (according to IEC 60068-2-6)
15 Hz ... 150 Hz, 2.3g, 90 min.
Approval - requirement of the semiconductor industry with regard to
SEMI F47-0706 Compliance Certificate
mains voltage dips
Certificate nd
IEC 60950-1 (2  Edition)
Rail applications EN 50121-4
Overvoltage category (EN 62477-1) III

Environmental Product Compliance

REACh SVHC Lead 7439-92-1
China RoHS Environmentally Friendly Use Period = 25;
For details about hazardous substances go to tab “Downloads”,
Category “Manufacturer's declaration”

Phoenix Contact 2021 © - all rights reserved

[Link]

06/24/2021   Page 5 / 5
[Link]

Diode - QUINT-DIODE/12-24DC/2X20/1X40 - 2320157
Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
([Link]

DIN rail diode module 12-24 V DC/2x20 A or 1x40 A. Uniform redundancy up to the consumer.

Product Description
A safe redundant system is the result of the parallel connection of two power supply units which are decoupled from one another. To further
increase system availability, QUINT DIODE provides the solution: decoupling with diode.

Your advantages
 Flexible
 Rugged design
 Consistent redundancy up to the load

Key Commercial Data

Packing unit 1 pc
Weight per Piece (excluding packing) 750.000 g
Custom tariff number 85049091
Country of origin China

Technical data
Dimensions
Width 50 mm
Height 130 mm
Depth 125 mm
Installation distance right/left 5 mm / 5 mm
Installation distance top/bottom 50 mm / 50 mm

Ambient conditions
Degree of protection IP20
Ambient temperature (operation) -40 °C ... 70 °C (> 60 °C Derating: 2.5 %/K)
Ambient temperature (storage/transport) -40 °C ... 85 °C
Max. permissible relative humidity (operation) ≤ 95 % (at 25 °C, non-condensing)

06/24/2021   Page 1 / 4
[Link]

Diode - QUINT-DIODE/12-24DC/2X20/1X40 - 2320157
Technical data
Ambient conditions
Climatic class 3K3 (in acc. with EN 60721)
Degree of pollution 2
Installation height 2000 m

Input data
Nominal input voltage range 12 V DC ... 24 V DC
12 V DC ... 24 V DC
Input voltage range 10 V DC ... 30 V DC
10 V DC ... 30 V DC
Nominal input current 2x 20 A (-25 °C ... 60 °C)
1x 40 A (-25 °C ... 60 °C)
Maximum input current 2x 30 A (-25°C ... 40°C)
1x 60 A (-25°C ... 40°C)
Nominal input current 2x 20 A (-25 °C ... 60 °C)
1x 40 A (-25 °C ... 60 °C)
Maximum input current 2x 30 A (-25°C ... 40°C)
1x 60 A (-25°C ... 40°C)

Output data
Setting range of the output voltage (USet) 12 V DC ... 24 V DC
Nominal output current (IN) 40 A (Increasing power)
20 A (Redundancy)
Derating 60 °C ... 70 °C (2.5%/K)
Connection in series No
Power loss nominal load max. 10 W (IOUT = 20 A)

General
Net weight 0.75 kg
Efficiency > 97 %
> 97 %
MTBF (IEC 61709, SN 29500) 40000000 h
Degree of protection IP20
Protection class III
Housing material Steel sheet, zinc-plated
Mounting position horizontal DIN rail NS 35, EN 60715
alignable: PN ≥50%, 5 mm horizontally, 15 mm next to active
components, 50 mm vertically
Assembly instructions
alignable: PN <50%, 0 mm horizontally, 40 mm vertically top, 20 mm
vertically bottom

Connection data, input

Connection method Screw connection
Conductor cross section solid min. 0.2 mm²
Conductor cross section solid max. 6 mm²
06/24/2021   Page 2 / 4
[Link]

Diode - QUINT-DIODE/12-24DC/2X20/1X40 - 2320157
Technical data
Connection data, input
Conductor cross section flexible min. 0.2 mm²
Conductor cross section flexible max. 4 mm²
Conductor cross section AWG min. 12
Conductor cross section AWG max. 10
Stripping length 7 mm
Screw thread M3

Connection data, output

Connection method Screw connection
Conductor cross section solid min. 0.5 mm²
Conductor cross section solid max. 16 mm²
Conductor cross section flexible min. 0.5 mm²
Conductor cross section flexible max. 16 mm²
Conductor cross section AWG min. 10
Conductor cross section AWG max. 6
Stripping length 10 mm
Screw thread M4

Insulation electric strength

Insulation voltage input, output / housing 1000 V

Standards
EMC requirements for noise immunity EN 61000-6-1
EN 61000-6-2
EMC requirements for noise emission EN 61000-6-3
EN 61000-6-4
Standard - Electrical safety EN 60950-1/VDE 0805 (SELV)
Standard – Electronic equipment for use in electrical power installations
EN 50178/VDE 0160 (PELV)
and their assembly into electrical power installations
Standard – Safety extra-low voltage IEC 60950-1 (SELV) and EN 60204-1 (PELV)
Standard - Safe isolation DIN VDE 0100-410
Standard – Protection against shock currents, basic requirements for
EN 50178
protective separation in electrical equipment

Conformance/approvals
UL approvals UL/C-UL listed UL 508
UL/C-UL Recognized UL 60950-1
UL ANSI/ISA-12.12.01 Class I, Division 2, Groups A, B, C, D
(Hazardous Location)

EMC data
Electromagnetic compatibility Conformance with EMC Directive 2014/30/EU
Low Voltage Directive Conformance with Low Voltage Directive 2014/35/EC
Electrostatic discharge EN 61000-4-2

06/24/2021   Page 3 / 4
[Link]

Diode - QUINT-DIODE/12-24DC/2X20/1X40 - 2320157
Technical data
EMC data
Electromagnetic HF field EN 61000-4-3
Fast transients (burst) EN 61000-4-4
Surge voltage load (surge) EN 61000-4-5
Conducted interference EN 61000-4-6

Environmental Product Compliance

REACh SVHC Lead 7439-92-1
China RoHS Environmentally Friendly Use Period = 25;
For details about hazardous substances go to tab “Downloads”,
Category “Manufacturer's declaration”

Phoenix Contact 2021 © - all rights reserved

[Link]

06/24/2021   Page 4 / 4
[Link]

Industrial Ethernet Switch - FL SWITCH 2116 - 2702908

Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
([Link]

Managed Switch 2000, 16 RJ45 ports 10/100/1000 Mbps, degree of protection: IP20, PROFINET Conformance-
Class A

The figure shows a version of the

product

Your advantages
 Suitable for PROFINET and EtherNet/IP™ networks
 Unmanaged Mode
 Easy and fast startup and commissioning with the FL NETWORK MANAGER software
 Configuration memory
 RSTP
 MRP client
 DHCP client, DHCP server (port-based)
 VLANs
 Web-based management, SNMP

Key Commercial Data

Packing unit 1 pc

GTIN

GTIN 4055626398716
Weight per Piece (excluding packing) 560.000 g
Custom tariff number 85176200
Country of origin Germany

06/24/2021   Page 1 / 5
[Link]

Industrial Ethernet Switch - FL SWITCH 2116 - 2702908

Technical data
Dimensions
Width 85 mm
Height 130 mm
Depth 115 mm

Ambient conditions
Degree of protection IP20
Ambient temperature (operation) 0 °C ... 60 °C
Ambient temperature (storage/transport) -40 °C ... 85 °C
Permissible humidity (operation) 10 % ... 95 % (non-condensing)
Permissible humidity (storage/transport) 10 % ... 95 % (non-condensing)
Air pressure (operation) 86 kPa ... 108 kPa (1500 m above sea level)
Air pressure (storage/transport) 86 kPa ... 108 kPa (1500 m above sea level)
Degree of pollution 2

Interfaces
Interface Ethernet (RJ45)
No. of ports 16 (RJ45 ports)
Note on the connection method Auto negotiation and autocrossing
Transmission physics Copper
Transmission speed 10/100/1000 Mbps
Transmission length 100 m (per segment)
Signal LEDs Data receive, link status

Function
Basic functions Store-and-forward switch, complies with IEEE 802.3
Configuration memory max. 8 GByte (SD card)
Management Web-based management (HTTP/HTTPS)
Role-based user management
SNMPv1/v2/v3
Command-line interface (Telnet, SSH)
Diagnostic functions RMON History
LLDP (Link Layer Discovery Protocol)
SNMP-Traps
N:1-Portmirroring
ACD (Address Conflict Detection)
SysLog
CRC-Surveillance
Filter functions Quality of Service (8 priority classes)

06/24/2021   Page 2 / 5
[Link]

Industrial Ethernet Switch - FL SWITCH 2116 - 2702908

Technical data
Function
Class of Service
DiffServ/DSCP
Port-Priorisierung
VLAN (up to 8 VLANs)
IGMP Snooping/Querier (v1/v2)
Auto-Query-Port
Extended Multicast Filtering
Redundancy MRP (Media Redundancy Protocol)
RSTP (Rapid Spanning Tree Protocol)
Additional functions Jumbo frames (max. 9,600 bytes)
Transmission of MMS and GOOSE (IEC 61850-8-1)
Transmission of Modbus TCP
MAC address table 8k
≥ 1.9 µs (Store-and-Forward mode, 10/100/1000 Mbps, depending on the
Latency
frame size)
IP parameterization DHCP-Client
DHCP server (port based)
BootP
PROFINET conformance class Conformance-Class A
Time synchronization SNTP (Simple Network Time Protocol)
LEDs: US (power supply), 2 LEDs per Ethernet port (Link/Activity and
Status and diagnostic indicators
Speed)

Network expansion parameters

Cascading depth Network, linear, and star structure: any
Maximum conductor length (twisted pair) 100 m

Supply voltage
Supply voltage 24 V DC (single)
Residual ripple 3.6 VPP (within the permitted voltage range)
Supply voltage range 18 V DC ... 32 V DC
Typical current consumption 315 mA (at US = 24 V DC and 25 °C ambient temperature)
Max. current consumption 0.7 A (At US = 18 V DC and 60°C ambient temperature)
Current consumption 455 mA

General
Mounting type DIN rail
Type AX Book type
Net weight 445 g

06/24/2021   Page 3 / 5
[Link]

Industrial Ethernet Switch - FL SWITCH 2116 - 2702908

Technical data
General
Housing material Polycarbonate fiber reinforced
Note Support by phone or on-site (fee is charged)
≥ 1.9 µs (Store-and-Forward mode, 10/100/1000 Mbps, depending on the
Latency
frame size)
379.84 Years (SN 29500 standard, temperature 25°C, operating
MTTF
cycle 21%)
199.41 Years (SN 29500 standard, temperature 40°C, operating
cycle 34.25%)
40.42 Years (SN 29500 standard, temperature 55°C, operating
cycle 100%)

Connection data
Connection method Push-in spring connection
Conductor cross section solid min. 0.25 mm²
Conductor cross section solid max. 1.5 mm²
Conductor cross section flexible min. 0.25 mm²
Conductor cross section flexible max. 1.5 mm²
Conductor cross section AWG min. 24
Conductor cross section AWG max. 16
Stripping length 9 mm

Standards and Regulations

Electromagnetic compatibility Conformance with EMC Directive 2014/30/EU
Interference emission EN 61000-6-2 EN 61000-6-3 (noise emission) Class B
Conducted noise emission EN 61000-6-2 EN 61000-6-3 (conducted emissions) Class B
Immunity to surge EN 61000-6-2 EN 61000-4-5 (surge) Criterion B
Immunity to burst EN 61000-6-2 EN 61000-4-4 (EFT burst) Criterion A
Immunity to EF EN 61000-6-2 EN 61000-4-3 (electromagnetic fields) Criterion A
Immunity to ESD EN 61000-6-2 EN 61000-4-2 (ESD) Criterion B
Immunity to conducted interference EN 61000-6-2 EN 61000-4-6 (line noise immunity) Criterion A
Type of test Free fall in accordance with EN 61131-2
Noise emission EN 61000-6-4
Noise immunity EN 61000-6-2
Vibration (storage/transport) 2g, criterion 1 according to IEC 60068-2-6
Free from substances that could impair the application of coating Yes
Vibration (operation) 2g, according to IEC 60068-2-6
Shock (operation) 30g (EN 60068-2-27)
UL, USA UL 61010-1, Ed.3 / UL 61010-2-201, Ed.1
UL, Canada CSA C22.2 NO.61010-2-201:14, Ed.1 / CSA C22.2 NO.61010-1-12, Ed.3

06/24/2021   Page 4 / 5
[Link]

Industrial Ethernet Switch - FL SWITCH 2116 - 2702908

Technical data
Environmental Product Compliance
REACh SVHC Lead 7439-92-1
China RoHS Environmentally Friendly Use Period = 50 years
For details about hazardous substances go to tab “Downloads”, Category
“Manufacturer's declaration”

Phoenix Contact 2021 © - all rights reserved

[Link]

06/24/2021   Page 5 / 5
FREQUENTLY ASKED QUESTIONS
Q: Do you have CAD drawings for GracePort® Housings? Q: What is the GFCI rated for and does the GFCI protect all
A: Absolutely! We have 2D PDF, 2D DWG, and 3D STP files three outlets?
available. Visit your configuration at [Link] to A: The exterior duplex outlet is rated for 20A and the inside is
download or email: sales@[Link]. rated for 15A. The unit is UL Recognized up to 15A. All three
outlets are protected by GFCI.
Q: What is the SCCR rating for the accessory power outlets/
receptacles used with GracePorts®?
A: Since GracePorts® are offered with variety of power outlet
options, the default SCCR ratings as defined in the UL 508A
Q: Do you sell components separately?
A: Unfortunately no, we do not sell components separately. GRACEPORT ®

Table SB4.1 apply to the power outlet offerings. OEMs are Q: What’s the difference between Shielded and Unshielded Enhance Safety and Productivity
required to use current limiting fuses of Class CC type in Ethernet Ports? Do I need a Shielded Port?
the upstream to increase the SCCR rating for the accessory A: Shielded Ethernet cables and ports are typically used when in Industrial Control Panels
power outlets used in the GracePorts to match with their®
there is high electromagnetic power presence that will
panel SCCR ratings. Below is the Short Circuit Current Rating interfere with communication. This is oftentimes found in
of the various receptacle outlets offered with GracePorts . ®
welding applications. Typically if you are not aware that you
• Any outlet with a Circuit Breaker: 0.2kA have a high EMI (Electro-Magnetic Interference) environment,
• Standard GFCI (RF): 2kA you will not need the shielded port or cable.
• Simplex (R): 10kA
• Duplex (RD): 10kA Q: Do Grace Permanent Electrical Safety Devices (PESDs)
• High Interrupt GFCI (RX-K10): 10kA work with these housings as well?
A: The Voltage Test Station, which contain a Voltage Indicator
Q: I work for a UL 508 panel shop, do I need to match the and the Safe-Test Point, will fit within the “M” size housings.
housing rating to my enclosure? Individual PESD Products can be placed in smaller size
A: For UL 508 panel shops, the UL rating of the housing must housing depending on the application. For more information
match the rating of the enclosure. It cannot exceed in order on PESDs, please go to [Link] or contact your local
to pass (i.e.: use UL 4X GracePort on UL 4 rated enclosure). sales representative to customize your GracePort®.
If UL 508 is not needed or desired, a housing can exceed the
rating of the enclosure with no problems. Q: I have an urgent order, can it ship today?
A: We have many GracePort® components readily in stock. If
GRACEPORT® FEATURES
Q: What is the difference between a GFCI and Circuit your GracePort® uses common components and the order is ▶▶ GracePorts® are panel interface connectors that provide safe access to PLC control panels
Breaker? recieved by 11:00am CST many times your GracePort can ® through closed doors.
A: A GFCI is designed with the goal of keeping the operator safe, ship that day. Expedite fees apply.
▶▶ Our GracePorts® can be fully customized with a variety of components housing, domestic
if a current leak is detected the current will be interrupted.
and international power options to match your specific application. We can also add your
This trip can be caused by any imbalance between hot and Q: Can I get my company logo printed on the faceplate? logo or custom text to make your configuration unique to you.
neutral lines, even something as small as 4 to 5 milliamps or A: Absolutely! Custom logo and text options are available on
if any power is flowing through anything other than the circuit the GracePort® faceplate. The recommended file resolution ▶▶ We offer quick assembly and delivery and ship each GracePort® within 2-3 business days.

(such as a human). A circuit breaker is designed to protect is 600dpi .jpg for submitted text and logos. Contact your local
▶▶ Thru-door access enabled by GracePorts® enhances compliance to OSHA, NEC &
your equipment by not allowing your circuit to overheat. For sales representative for more details. NFPA 70E/CSA Z462.
example, a 5A circuit breaker will not allow over 5A of current
through the circuit.

FOR MORE INFORMATION VISIT [Link] OR CALL 1.800.280.9517 Actual product certification will vary
© Grace Technologies, Inc. All rights reserved. Specifications are subject to change with/without notice. GP-GP-DS-EN 2007 FOR MORE INFORMATION VISIT [Link] OR CALL 1.800.280.9517 with component selection.
 HOUSING OPTIONS
BUILD YOUR CUSTOMIZABLE GRACEPORT®
This is what sets a GracePort® apart from other communication ports. We can create
UL Type 1
a custom-built GracePort®, including special text, cut-outs, cable lengths, and even Indoor use primarily to provide protection against contact with the enclosed equipment and against a limited
adding your company logo, all in just a few days. Assembled in the USA and created amount of falling dirt. Choose from our standard sizes and interfaces or a custom interface to fit your exact
requirements. Units can be built with gasketing to offer an extra measure of protection against dust and other
just the way you want it.
contaminates.

UL Type 4
Either indoor or outdoor use to provide a degree of protection against falling rain, splashing water and
hose-directed water; undamaged by the formation of ice on the enclosure.
Grace Port® Interface P-P11R2-K3RF3

Components 120VAC, 5A(MAX)

FOR COMPUTER USE ONLY
Housing Size & UL Rating
There are various connectors available UL Type 4X
and are represented by a two to three digit
E207344
Several housing types are available to
Either indoor or outdoor use to provide a degree of protection against falling rain, splashing water and
code found in between the first two dashes meet your needs. The size of your housing
LR110845 hose-directed water; undamaged by the formation of ice on the enclosure; resists corrosion.
of our GracePort® part number layout. depends on several variables including the
Multiple connectors in a GracePort® are kinds of components you choose, the power
listed alpha-numerically and multiples of the option you want and, in some cases, the UL
USB ETHERNET UL Type 3R
same component are followed by # and the rating you need. UL ratings offered include
In-use extra-duty housings allow items to be plugged in while the cover is closed, which offers added protection
quantity. See the next page for some of our UL Type 1, 3R, 4, 4X, and 12.
against moisture. Outdoor use to provide a degree of protection against falling rain; undamaged by the
common components. formation of ice on the enclosure. Designed for wet or damp locations.

Circuit Breaker / Power Option UL Type 12

Many power options for international and domestic use are available and are represented by a one to two or three letter Indoor use to provide a degree of protection against dust, dirt, fiber flyings, dripping water and external
code. Because circuit breakers offer the ability to limit what devices can be run through the GracePort®, we offer different condensation of noncorrosive liquids.
amperages as well.

Over 15,000 unique GracePorts® created Stainless Steel

Keep stainless steel enclosures closed with the #304 or #316 stainless steel GracePort® interface. The 100%
and shipped in 2-3 business days! stainless steel GracePort® is designed to meet rigorous environments. Also available in a low-profile design.

NEW TECHNOLOGY Surface Mount Heavy Duty

We recently developed a new GracePort® component with USB-C charging functionality that Surface Mount Housings are made from a cast alloy base and are IP65 Rated when installed. These housings
provide excellent protection for GracePort® components and power options from contaminants such as dust
allows service technicians and PLC programmers to safely charge their laptops and other
and debris as well as protection from water entry. This makes these types of housings suitable for corrosive
handheld devices from outside the door with a USB-C cable. environments and/or areas that require frequent wash downs.

In addition to the USB-C option, we also now feature an SD Card component. The P46
GracePort® is a great addition to any programmers who routinely access PLCs that Hazardous Location
The Hazardous Location GracePort® (M7) is intended for environments where the user must do a “sniff test” and
use SD Card components. Extending the SD Card connection to the outside of the
typically obtain a “Hazardous Work Permit” before opening the enclosure. The housing is especially well suited
cabinet provides a safer and more efficient means of access and programming. for use with the GracePort Low Profile Circuit Board for ease of field wiring.

Need to cover an existing HMI or UL Type 1 GracePort®? GracePort®+ has you covered -
refer to the GracePort+ Datasheet for more information.

FOR MORE INFORMATION VISIT [Link] OR CALL 1.800.280.9517 Actual product certification will vary
FOR MORE INFORMATION VISIT [Link] OR CALL 1.800.280.9517 Actual product certification will vary
© Grace Technologies, Inc. All rights reserved. Specifications are subject to change with/without notice. with component selection. © Grace Technologies, Inc. All rights reserved. Specifications are subject to change with/without notice. with component selection.
BUILDING YOUR CUSTOM GRACEPORT® Housing Options
Varieties of components are available and can be paired together in your fully customized GracePort®. Whether you need something
Circuit Breaker HOUSING CODE UL RATING
as common as an RJ45 or as unique as a DVI female-to-female feed-thru bulkhead, Grace Technologies can design and create Codes A

a GracePort® for you. No Breaker 0 B 1, 3R, 4, 4X, and 12

F Not all housings are available
The code in this area depends on weather you need a custom logo or 1 AMP 1
Housing Size Circuit G
in all UL Ratings

and UL Rating Breaker

text added. The GracePort® logo is the default. 2 AMP 2 Sample Housing Code:
H
Component Power Customize 3 AMP 3 B2
JB7
5 AMP 5 First letter Numeral refers to the
K depicts environmental ratings

P-P11R2-K3RF3-UXXX GENDER
6 AMP 6 L
size only below
1 = UL TYPE 1
2 = UL TYPE 4X (IP-65)
DESCRIPTION TYPE GENDER BACK CODE 8 AMP 8 M
FRONT 3 = UL TYPE 4 (IP-65)
4 = UL TYPE 12
M5
Data Switch 10 AMP 10 8 = UL TYPE 3R
M6
DB9F 2:1 Custom Female Female R38 15 AMP 15

DB9F 4:1 Custom Female Female R39

Power Options
Components Crossover – Generic DB9F Custom Qty (2) DB9 – R49
POWER
DESCRIPTION VAC AMPS
CODE
DESCRIPTION TYPE
GENDER
GENDER BACK CODE DESCRIPTION TYPE
GENDER
GENDER BACK CODE Generic Bulkhead Interfaces
FRONT FRONT Simplex 120 15 R
4MDIN F/F Bulkhead Female Female Q26
Ethernet & Network Interfaces Universal Serial Bus 50 ohm BNC Bulkhead Female Female Q42
Duplex Outlet 125 20 RD

Category 5e Ethernet Bulkhead RJ45Female RJ45Female R2 USB 4 to 1 Hub Bulkhead USB-BFemale USB-BFemale P44 GFCI Inside-Outlet Rear Outlet 15 AMP, (UL
6MDIN F/F Bulkhead Female Female Q28 125 20 RF
recognized for 15 AMPs)
Category 5 with M/M patch USB Memory Stick Cable USB-AFemale USB-AMale P50
Bulk head RJ45Female RJ45Female R13 75 ohm Bulkhd, Feed-Thru, IEC 320 Male Power Entry Module 250 15 RM
cable Bulkhead Female Female Q40
Coaxial F/F (non BNC)
USB Mini Type B 5 POS Cable USB-BFemale USB-BMale P42
Category 5e Shielded Bulkhead RJ45Female RJ45Female R33 IEC 320 Female Power Entry Module 250 10 RP
8MDIN F/F Bulkhead Female Female Q29
USB Type A/B F/F Bulkhead USB-AFemale USB-BFemale Q50
Category 6 Ethernet Bulkhead RJ45Female RJ45Female R62 TWIST LOCK Receptacle 125 15 RN
DB-15 F/F Bulkhead Female Female Q35
USB Type A-A Cable Cable USB-AFemale USB-AMale P11
Category 6 Shielded Bulkhead RJ45Female RJ45Female R31 Power AC Inlet with On/Off Switch, 2 Pole 250 10 RS
DB-15 F/M Bulkhead Female Male Q37
USB Type A-A F/F Bulkhead USB-AFemale USB-AFemale P22
Ethernet Switch (5 ports) Unmanaged RJ45Female (1) RJ45Female (4) E5 12-24V Vehicle Style Accessory Socket 12 5 RC
DB-15 M/F Bulkhead Male Female Q38
USB Type B/A F/F Bulkhead USB-BFemale USB-AFemale Q51
Antenna with Coaxial Coupler Cable SMA F/F SMA F/F Q43 USB Charger Receptacle: 2 Port, 3 amp,
DB-15 M/M Bulkhead Male Male Q36 125 15 RDC
USB Type B/B F/F Bulkhead USB-BFemale USB-BFemale P27 5 VDC USB
DB-15HD F/F Bulkhead Female Female Q18
Keyboard, Mouse & Monitor USB Type B/B M/M Bulkhead USB-BMale USB-BMale P31
Type I: Australia, New Zealand & People’s
250 10 RA
DB-15HD F/M Bulkhead Female Male Q11 Republic of China
Keyboard (PS/2) Cable 6MDINFemale 6MDINMale P3 USB Type B/F to USB Type
Cable USB-BFemale USB-BMale P15 Type G: United Kingdom, Hong Kong, Ireland,
B/M (6' integrated cable) DB-15HD M/F Bulkhead Male Female Q12 250 13 RB
Keyboard (USB) Cable USBAFemale USBAMale P28 Singapore & Malaysia
USB-A (3.0) DB-15HD M/M Bulkhead Male Male Q19
Cable USB-AFemale USB-BMale P13
Modem Bulkhead RJ12Female RJ12Female P7 with 1.5’ cable Type G: United Kingdom with GFCI 250 16 RBF
Type A to B Bulkhead USB-AFemale USB-BFemale P19 DB-15HDVGA F/F Bulkhead Female Female Q22
Mouse (PS/2) Cable 6MDINFemale 6MDINMale P5 Type F: Continental Europe “Schuko” (Germany,
DB-15HDVGA F/M Bulkhead Female Male Q24 Finland, Netherlands, Norway, Sweden, Portugal, 250 16 RE
Mouse (USB) Cable USBAFemale USBAMale P29 USB-A (3.0) USB-AFemale USB-AFemale P33
Spain, Greece, Soviet Republic & Eastern Bloc)
USB-C & A DB-15HDVGA M/F Bulkhead Male Female Q23
VGA Monitor Cable HDDB15Female HDDB15Male P6 USB-C Charging Adapter Cable 24V Terminal C1 Type E: France & Belgium 250 16 RH
Female
DB-15HDVGA M/M Bulkhead Male Male Q25
HDMI Bulkhead HDMIFemale HDMIFemale P38 SD Card Adapter Cable SD Card Female SD Card Male P46 250 15 RU
DB-25 F/F Bulkhead Female Female Q4 Type M: India
DisplayPort DisplayPort
DisplayPort Bulkhead P39 250 6/16 RIN
Female Female DB-25 F/M Bulkhead Female Male Q8
Banana Jacks
Type O: Thailand 250 15 RW
DB-25 M/F Bulkhead Male Female Q10
Parallel Pin-to-Pin Extension Cables Black Banana Jack
Bulkhead Female Solder Terminal Q85
(sheathed) DB-25 M/M Bulkhead Male Male Q16 Type N: Brazil 250 15 RQB
8 Pin MiniDIN Cable 8MDINFemale 8MDINMale R8
Black Banana Jack
Bulkhead Female Solder Terminal Q75 DB-9 F/F Bulkhead Female Female Q3 Type H: Israel 250 16 RZ
8 Pin MiniDIN Locking Cable 8MDINFemale 8MDINMale R28 (unsheathed)
Green Banana Jack DB-9 F/M Bulkhead Female Male Q7 Type I: Argentina 250 10 RAG
DB15 F/M Cable DB15Female DB15Male R11 Bulkhead Female Solder Terminal Q86
(sheathed)
DB-9 M/F Bulkhead Male Female Q9 Type F: Continental Europe with GFCI 230 16 REF
DB15 M/F Cable DB15Male DB15Female R10 Green Banana Jack
Bulkhead Female Solder Terminal Q76
(unsheathed) DB-9 M/M Bulkhead Male Male Q15
DB15HDM F/M (Not for VGA) Cable Female Male R45 Type L: Italy 250 16 RI
Red Banana Jack (sheathed) Bulkhead Female Solder Terminal Q84 RJ-11/12 F/F Bulkhead Female Female Q6
DB15HDM M/F (Not for VGA) Cable Male Female R44 Type J: Switzerland 250 10 RSW
Red Banana Jack
Bulkhead Female Solder Terminal Q74 RJ-45 F/F Bulkhead Female Female Q17
(unsheathed)
DB25 F/M Cable DB25Female DB25Male P2 Universal International 250 20 RUV

DB9 F/M Cable DB9Female DB9Male R3 Connector to Terminal Block PCB

DB9 M/F Cable DB9Male DB9Female P1 DB9F (PCB Pins 1-9 to
Term DB9Female Terminal Block R1 Need manufacturer specific components?
Terminal Block)
See our complete listing of components at:
DB9M (PCB Pins 1-9 to
Serial, Parallel Terminal Block)
Term D9Male Terminal Block R12 [Link]
DB25 Parallel Cable DB25Female DB25Male P2 RJ-45 (PCB Pins 1-8 to
Term RJ45Female Terminal Block R15
Terminal Block)
DB9 Serial Cable DB9Male DB9Female P1 FOR MORE INFORMATION VISIT [Link] OR CALL 1.800.280.9517
© Grace Technologies, Inc. All rights reserved. Specifications are subject to change with/without notice.
 D, CSA, AND CE MAY APPLY CONSULT FACTORY.

E DATA SHEETS THAT APPLY.

AL CODES.
Subpart S; the current edition of NFPA 70E; and the current edition of CSA Z462.
● Davenport, IA ● [Link] ● 1.800.280.9517

PE 4 OTHER ENVIRONMENTAL RATINGS MAY APPLY.

ATIONS ARE APPROXIMATE.
of Grace Engineered Products, Inc. Property of Grace Engineered Products, Inc. (Drawings are subject to change without notification)

IONS FOR PROPER INSTALLATION.

ed using an adequately rated test equipment before working on it. Follow appropriate
H-X-M6

3.15±.010
[80.0±0.2]
Ø0.45 x 0.20
[Ø11.5 x 5.2]
Ø0.26±.004

Ø0.26+.010
[Ø6.5±0.1]

[6.5+0.2]
OVERALL HOUSING SPECIFICATIONS INCHES (MM) Surface Mount UL Type 4

2.76±.004
[70.0±0.1]
[96.0]
3.78
C PANEL CUTOUT
Thru-View Housings (Type 4, 4X, 3R, and 12)

5.02 [127.6]

PANEL CUTOUT

H-X-M6
H M8 HOUSING DETAIL ONLY

5.83±.004 [148.0±0.1]
4.80±.010 [122.0±0.2]
B D
3.25±.004
[82.6±0.1]
F

6.50 [165.0]

P-XX-M3RX
3.14±.010
B [79.8±0.2]

[40.7]
1.60
I Cable Opening

H-X-M6

(TYP. X 4)
8-32 x .75
(Isometric) 9.29

PANEL CUTOUT
D J [236.1]
E
A G 5.00±.010 [127.0±0.2]

5.00±.010 [127.0±0.2]
5.25±.004 [133.4±0.1]
Ø0.18+.010
5.25±.004 [133.4±0.1]
0.39

GracePort(R) and SafeSide(R) are Registered Trademarks of Grace Engineered Products, Inc. Property of Grace Engineered Products, Inc. (Drawings are subject to change without notification)
A 0.24 [Ø4.6+0.2]

[11.0]
0.43

6.33 [160.8]
E 0.39 [10.00]
[6.4]

1515 East Kimberly Road ● Davenport, IA ● [Link] ● 1.800.280.9517

C [10.00] HOUSING
K WEIGHT (OZ) A B C D E F G
0.75 [19.00]
CODE PANEL CUTOUT

[55.8]
2.20
A3 7.5 2.76[70] 1.57[40] 3.22[82] 2.05[52] .22[5.5] 6.33 [160.8]
2.64[67] 1/2" NPT
M F
G3 11.9 5.20[132] 1.77[45] 5.67[144] 2.24[57] .22[5.5] 2.80[71] 3/4" NPT
N

[125.5]
I L3 45.2 4.37[111] 4.17[106] 0.35 5.55[141] 4.72[120] .25[6.4] 4.65[118] 1" NPT

4.94
3.25±.004
K

[79.8±0.2]
3.14±.010
[9.0]
[82.6±0.1]

Warning: Verify an electrical conductor has been de-energized using an adequately rated test equipment before working on it. Follow appropriate
5) HOUSINGS ARE UL RECOGNIZED TYPE 4X OTHER ENVIRONMENTAL RATINGS MAY APPLY.
3.14±.010

Energy Control (Lockout/Tagout) procedures as per OSHA Subpart S; the current edition of NFPA 70E; and the current edition of CSA Z462.
4.34

[110.2]
L

4.34
[79.8±0.2] [110.2]

Ø0.18+.010
[Ø4.6+0.2]
VOLTAGE TEST STATION P-S10S21-M3RX

6) FINAL ASSEMBLIES: UL RECOGNIZED, CSA, AND CE MAY APPLY CONSULT FACTORY.

G
VOLTAGE VOLTAGE
9.29

[82.6±0.1]
3.25±.004
IF ILLUMINATED TEST POINTS
WARNING
ALWAYS
FOLLOW SAFETY
Cable Opening [236.1]
(Isometric) Stainless Steel Housing Type 4X
PROCEDURES
WHEN USING

H
THIS DEVICE

5.00±.010 [127.0±0.2]
Ø0.18+.010
5.25±.004 [133.4±0.1]

1) REFER TO INSTALLATION INSTRUCTIONS FOR PROPER INSTALLATION.

102 kΩ
102 kΩ
L1
NOTE:
TEST POINT ASSEMBLY
L2 WITH 102kΩ IMPEDANCE
[Ø4.6+0.2]
102 kΩ
L3 ON L1, L2, & L3
AFFECTS VOLTAGE

3) FOR DETAILED SPECIFICATIONS SEE DATA SHEETS THAT APPLY.

READINGS ± 2%

4) HOUSING INSERT COMPONENT LOCATIONS ARE APPROXIMATE.

L
Cable Opening
0.39 6.33D
H-X-JB7
8-32 x .75

0.39 (Isometric) [160.8] (TYP. X 4)

[10.00] 13.60 0.26

HOUSING
[10.00] [345.5] [6.6]

NOTE:
1515 East Kimberly Road ● Davenport, IA ● [Link] ● 1.800.280.9517

2) ALWAYS FOLLOW LOCAL ELECTRICAL CODES.

Energy Control (Lockout/Tagout) procedures as per OSHA Subpart S; the current edition of NFPA 70E; and the current edition of CSA Z462.
GracePort(R) and SafeSide(R) are Registered Trademarks of Grace Engineered Products, Inc. Property of Grace Engineered Products, Inc. (Drawings are subject to change without notification)

Warning: Verify an electrical conductor has been de-energized using an adequately rated test equipment before working on it. Follow appropriate

1) REFER TO INSTALLATION INSTRUCTIONS FOR PROPER INSTALLATION.

5) HOUSING: 16 GA. 304 STAINLESS STEEL.

3) FOR DETAILED SPECIFICATIONS SEE DATA SHEETS THAT APPLY.

2) ALWAYS FOLLOW LOCAL ELECTRICAL CODES.
4) HOUSING INSERT COMPONENT LOCATIONS ARE APPROXIMATE.
F G H I J K L MØ NØ
CODE 0.75 [19.00] 0.35 4.94

7) HOUSING: 16 GA. 316 STAINLESS STEEL.

[9.0] [125.5]

B2, B3, B4
3.15 1.72 102 kΩ NOTE:
3.20 1.60 .20 4.33 .96 0.39
N/A
.18 ± .004 4.34
C
[110.2]
(80.0) (43.6) (81.2) (40.7) (5.0) (110.1)0.39 (24.4) (4.6 ± .1)
L1

[10.00]
102 kΩ TEST POINT ASSEMBLY
L2 WITH 102kΩ IMPEDANCE
102 kΩ ON L1, L2, & L3
L3
AFFECTS VOLTAGE
READINGS ± 2%

4.45 1.72 3.20 1.60 ..20 4.87[10.00] .57 .18 ± .004

F2, F3, F4 N/A
(113.0) (43.6) (81.2) (40.7) (5.0) (123.7) (14.4) (4.6 ± .1)

[9.0]
0.35
0.75 [19.00] B
NOTE: 2.20
E
1) REFER TO INSTALLATION INSTRUCTIONS FOR PROPER INSTALLATION. [55.8]

[236.1]
5.51 1.72 3.20 1.60 .20 4.87 .57 .18 ± .004 A 2) ALWAYS FOLLOW LOCAL ELECTRICAL CODES.

9.29
H2, H3, H4 N/A 3) FOR DETAILED SPECIFICATIONS SEE DATA SHEETS THAT APPLY.
(140.0) (43.6) (81.2) (40.7) (5.0) (123.7) (14.4) (4.6 ± .1) PANEL CUTOUT

[180.4]
4) HOUSING INSERT COMPONENT LOCATIONS ARE APPROXIMATE.

7.10
5) HOUSINGS ARE UL RECOGNIZED TYPE 4X OTHER4.20ENVIRONMENTAL
[106.7] RATINGS MAY APPLY.
-0.01 [139.7-0.2 ]
5.50+0.01 +0.2

5.08 3.54 4.79 1.60 0.43 8.28 .45 .45 .22 .26 ± .004 HOUSING CODE A B
6) FINAL ASSEMBLIES: UL RECOGNIZED, CSA, AND CE MAY APPLY
C
8-32 x .75 FACTORY.
CONSULT
D (TYP. X 4) E STAINLESS STEEL USED

NOTE:
K2, K3, K4 7) HOUSING: 16 GA. 316 STAINLESS STEEL.
(129.0) (90.0) (121.6) (40.7) (11.0) (210.2) (11.4) (11.5 .5.5) (6.5 ± .1) Warning: Verify an electrical conductor has been de-energized using an adequately rated test equipment before working on it. Follow appropriate
edition of NFPA 70E; and the current edition of CSA Z462. 2.38+0.00
Energy Control (Lockout/Tagout) procedures as per OSHA Subpart S; the current5.50
M5 9.29 (236.1) 0.35 (9.0) 4.34 (110.2) 6.33 (160.8) 2.20 (55.8) -0.005
#304
6.50 3.78 5.02 1.60 0.43 8.52 .57 .45 .20 .26 ± .004 GracePort(R) and SafeSide(R) are Registered Trademarks of Grace Engineered[139.7] [60.3 are
] subject to change without notification) +0.0
Products, Inc. Property of Grace Engineered Products, Inc. (Drawings -0.1

M2, M3, M4
(165.0) (96.0) (127.6) (40.7) (11.0) (216.4) (14.4) (11.5 5.2) (6.5 ± .1) M6 9.29 (236.1) 0.35 (9.0) 4.34 (110.2)
4.94 6.33 (160.8) (55.8) 4.25 2.95 4.75+0.00
2.20
-0.01
#316
4.25+0.01
-0.01

[108.0] [74.9] [120.7+0.0

-0.2 ]

6.50 3.78 5.02 4.59 0.43 9.03 0.57 .45 .20 .26 ± .004 1515 East Kimberly[125.5]
Road ● Davenport, IA ● [Link] ● 1.800.280.9517 [108.0+0.2
-0.2 ]

M8
(165.0) (96.0) (127.6) (116.7) (11.0) (229.4) (14.4) (11.5 5.2) (6.5 ± .1)

[142.9]
5.63
H-X-JB7

(TYP. x 6)
Ø0.14-0.01
Low-Profile Stainless Steel Housing NEMA Type 4

[Ø3.5+0.2
(TYP. x 6) 3.00+0.005
-0.01 [76.2-0.1 ]
+0.0

+0.01
-0.2 ]
UL Type 1
Ø0.14+0.01
GracePort Hazardous Location Housing
® 2.20
-0.01
NOTE: 6.00+0.00
-0.01 [152.4-0.2 ]
+0.0
-0.2 ]
[Ø3.5+0.2
1) REFER TO INSTALLATION INSTRUCTIONS FOR PROPER INSTALLATION. [55.8]
13.60
2) ALWAYS FOLLOW LOCAL ELECTRICAL CODES. A 0.26
B 7.10 1.38
[345.5] [6.6] D [34.9]

Ø0.30
HOUSING 3) FOR DETAILED SPECIFICATIONS SEE DATA SHEETS THAT APPLY.

[Ø7.6]
5.26 [180.4]
SIZE: (H x W, INCHES) 4) HOUSING INSERT COMPONENT LOCATIONS ARE APPROXIMATE.

ENVIRONMENT 5) HOUSINGS ARE UL RECOGNIZED TYPE 4X OTHER ENVIRONMENTAL RATINGS MAY APPLY.
6) FINAL ASSEMBLIES: UL RECOGNIZED, CSA, AND CE MAY APPLY CONSULT FACTORY.

3.00+0.005
7) HOUSING: 16 GA. 316 STAINLESS STEEL.
B1 1.72 x 3.15

-0.01 [76.2-0.1 ]
Warning: Verify an electrical conductor has been de-energized using an adequately rated test equipment before working on it. Follow appropriate
Energy Control (Lockout/Tagout) procedures as per OSHA Subpart S; the current edition of NFPA 70E; and the current edition of CSA Z462.

[34.9]
3.93

1.38
F1 1.72 x 4.45

6.00+0.00
GracePort(R) and SafeSide(R) are Registered Trademarks of Grace Engineered Products, Inc. Property of Grace Engineered Products, Inc. (Drawings are subject to change without notification)
5.63
C
[142.9] E

+0.0
-0.01 [152.4-0.2 ]
6.14
H1 1.72 x 5.51 1515 East Kimberly Road ● Davenport, IA ● [Link] ● 1.800.280.9517
Ø0.30
[Ø7.6]
5.51
K1 3.54 x 5.08

+0.0
M1 3.79 x 6.50
Class I, Div. 1 & 2, Groups A,B,C,D PANEL CUTOUT NOTE:
Class I, Zones 1 & 2, Groups IIB +H2, IIA 4.20 [106.7]
Class II, Div. 1 & 2, Groups E,F,G
S1 Custom panel 5.50+0.01
-0.01 [139.7-0.2 ]
+0.2 1) REFER TO INSTALLATION INSTRUCTIONS FOR PROPER INSTALLATION.
2) ALWAYS FOLLOW LOCAL ELECTRICAL CODES.
HOUSING CODE A B C
3) FOR DETAILED SPECIFICATIONS SEE DATA SHEETS THAT APPLY. D E STAINLESS STEEL USED
Class III

[108.0+0.2
4) HOUSING INSERT COMPONENT LOCATIONS ARE APPROXIMATE.
5) HOUSING: 16 GA. 304 STAINLESS STEEL.
.25" DIA.
NEMA 3,4,7 (B,C,D), 9 (E,F,G) JB7
5.50
13.60 (345.5)
2.38 +0.00

[60.3 0.26 (6.6) 5.63 (142.9) 7.10 (180.4) 1.38 (34.9) #304
-0.005 Warning: Verify an electrical conductor has been de-energized using an adequately rated test equipment before working on it. Follow appropriate

-0.2 ]
[139.7] ] +0.0 Energy Control (Lockout/Tagout) procedures as per OSHA Subpart S; the current edition of NFPA 70E; and the current edition of CSA Z462.

CENELEC - EEx D IIB IP66 -0.1

GracePort(R) and SafeSide(R) are Registered Trademarks of Grace Engineered Products, Inc. Property of Grace Engineered Products, Inc. (Drawings are subject to change without notification)

4.25+0.01
4.25 2.95 4.75
+0.00
-0.01
-0.01

[108.0] [74.9] [120.7 ]

+0.0

FOR MORE INFORMATION VISIT [Link] OR CALL 1.800.280.9517 FOR MORE INFORMATION VISIT [Link] OR CALL 1.800.280.9517
1515 East Kimberly
[108.0 ]
-0.2
Road ● Davenport, IA ● [Link] ● 1.800.280.9517
+0.2
-0.2

© Grace Technologies, Inc. All rights reserved. Specifications are subject to change with/without notice. © Grace Technologies, Inc. All rights reserved. Specifications are subject to change with/without notice.

(TYP. x 6) 3.00+0.005
-0.01 [76.2-0.1 ]
+0.0

Ø0.14+0.01
-0.01

[Ø3.5+0.2] 6.00+0.00
-0.01 [152.4-0.2 ]
+0.0
[Link]

Patch cable - VS-04-2X2X26C7/7-SDA/SDB/2,0 - 1653935
Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
([Link]

Assembled USB cable, shielded, color: RAL 5021 (water blue), PUR outer sheath, USB type A/standard on USB
type B/standard, length: 2 m

Key Commercial Data

Packing unit 1 pc

GTIN

GTIN 4017918970260
Weight per Piece (excluding packing) 151.400 g
Custom tariff number 85444290
Country of origin Germany

Technical data
Dimensions
Length of cable 2.00 m

Ambient conditions
Degree of protection IP20
Ambient temperature (operation) -20 °C ... 60 °C (cable, fixed installation)
0 °C ... 50 °C (Cable, flexible installation)
Plug / socket

General data
Number of positions 4
Flammability rating according to UL 94 HB
Degree of pollution 2

11/15/2021   Page 1 / 4
[Link]

Patch cable - VS-04-2X2X26C7/7-SDA/SDB/2,0 - 1653935
Technical data
General data
Alternative short product description USB cable
Rated voltage (III/3) 125 V
Insertion/withdrawal cycles ≥ 500
Contact material CuSn
Contact carrier material PA 6.6
Contact surface material Ni/Au
Housing material PA
Rated current 1A

Performance data
Fixed cable length 2.00 m
Outer sheath, material PUR
External sheath, color water blue RAL 5021
Cable structure 2x2xAWG26/7 + 2xAWG20/19; S/FTP
AWG signal line 26
Cable cross section 0.14 mm²
Smallest bending radius, movable installation ≥ 35 mm
Smallest bending radius, fixed installation ≥ 35 mm
Shielded yes
Conductor structure signal line 7x 0.15 mm

Environmental Product Compliance

China RoHS Environmentally friendly use period: unlimited = EFUP-e
No hazardous substances above threshold values

Drawings

Schematic diagram Schematic diagram

D– +
2 1
3 4
+ D- D+ -
1 2 3 4 D+ –

Pin assignment plug USB, type A Plug pin assignment plug USB, type B

11/15/2021   Page 2 / 4
[Link]

Patch cable - VS-04-2X2X26C7/7-SDA/SDB/2,0 - 1653935
Circuit diagram Dimensional drawing

USB-A USB-B

1 1

2 2

3 3

4 4

58
12
16 10,5

USB connector, type A, Standard

Dimensional drawing
46
12

16 10,5

USB connector, type B, standard

Classifications
eCl@ss

eCl@ss 10.0.1 27060390

eCl@ss 11.0 27060390
eCl@ss 4.0 24010400
eCl@ss 4.1 24010400
eCl@ss 5.0 19030300
eCl@ss 5.1 19030300
eCl@ss 6.0 27060300
eCl@ss 7.0 27060390
eCl@ss 9.0 27060390

11/15/2021   Page 3 / 4
[Link]

Patch cable - VS-04-2X2X26C7/7-SDA/SDB/2,0 - 1653935
Classifications
ETIM

ETIM 2.0 EC000830

ETIM 3.0 EC001855
ETIM 4.0 EC001855
ETIM 6.0 EC000748
ETIM 7.0 EC000748

UNSPSC

UNSPSC 6.01 31261501

UNSPSC 7.0901 31261501
UNSPSC 11 31261501
UNSPSC 12.01 31261501
UNSPSC 13.2 26121604
UNSPSC 18.0 26121604
UNSPSC 19.0 26121604
UNSPSC 20.0 26121604
UNSPSC 21.0 26121604

Approvals
Approvals

Approvals

EAC

Ex Approvals

Approval details

EAC
    19060508

Phoenix Contact 2021 © - all rights reserved

[Link]

11/15/2021   Page 4 / 4
 Tags: OM_LT_2104_LI, OM_LT_2105_LI
Level Measurement
Continuous level measurement — Ultrasonic controllers
SITRANS LUT400 series

■ Overview ■ Application
The SITRANS LUT400 comes in three different models,
depending on the application, level of performance and
functionality required:
• SITRANS LUT420 Level Controller: Level or volume
measurement of liquids, slurries, and solids, as well as basic
pump control functions, and basic data logging capability
• SITRANS LUT430 Level, Pump and Flow Controller: Includes
all features of the LUT420 plus a full suite of advanced pump
control and alarm functionality, open channel flow monitoring,
and basic flow data logging capability
• SITRANS LUT440 High Accuracy OCM: Our most featured,
highest accuracy model. Includes all features of the LUT430,
plus the industry’s best accuracy (± 1 mm within 3 m), full suite
of advanced control functionality, and enhanced flow logging
capability
• Key Applications: wet wells, reservoirs, flumes/weirs, chemi-
4 cal storage, liquid storage, hoppers, crusher bins, dry solids
storage
The Siemens SITRANS LUT400 series controllers are compact,
single point, long-range ultrasonic controllers for continuous
level or volume measurement of liquids, slurries, and solids,
and high accuracy monitoring of open channel flow.

■ Benefits
• Small 1/2 DIN enclosure [144 h x 144 d x 146 w mm
(5.7 x 5.7 x 5.75 inch)] with standard universal mounting
bracket for wall, pipe, and DIN rail, plus an optional panel
mount
• Easy to use LUI display with local four-button programming,
menu-driven parameters, and Wizard support for key
applications
• Level, Volume, OCM Flow monitoring
• Three relays combined with a suite of pump, alarm, and relay
control features
• HART Communications
• EDDs for SIMATIC PDM, AMS Device Manager,
and Field Communicator 375/475, plus DTMs for FDTs
(Field Device Tools)
• Web browser for local programming from an intuitive
web-based interface
• Two discrete inputs for backup level override and pump
interlock functions
• Echo profile and trend views from the local display
• Patented digital receiver for improved performance in
electrically noisy applications (close proximity to VSDs)
• Real time clock with daylight savings time, supporting an
integrated datalogger and energy saving algorithms for
minimizing pump operation during high cost energy periods
• Removable terminal blocks for ease of wiring
• MCERTS Certified for Open Channel Flow

4/146 Siemens FI 01 · 2014

 Level Measurement
Continuous level measurement — Ultrasonic controllers
Tags: OM_LT_2104_LI, OM_LT_2105_LI
SITRANS LUT400 series

■ Technical specifications
Mode of operation Ultrasonic level, volume, pump, Design
and open channel flow
Weight
Measuring range 0.3 … 60 m (1 … 196 ft), • Enclosure with display lid 1.3 kg (2.87 lb)
transducer dependent • Enclosure with blank lid: 1.2 kg (2.65 lb)
Input Material (enclosure) Polycarbonate
Discrete 0 ... 50 V DC switching level Degree of protection
Logical 0 d 10 V DC • Enclosure with display or blank lid: IP65/Type 4X/NEMA 4X
Logical 1 = 10 ... 50 V DC • Enclosure with blank lid and IP20
Max. 3 mA knock-out removed:
Output Remote display lid: IP65/Type 3/NEMA 3
Transducer frequency 10 ... 52 kHz Cable
Ultrasonic transducer Compatible transducers: Transducer and mA output signal • Transducer, mA output:
All EchoMax and ST-H series 2 copper conductors, twisted,
transducers with foil shield/drain wire, 300 V
Relays • 1 SPDT Form C, NO or NC relay, 0.5 … 0.75 mm² (22 … 18 AWG)
rated 1A at 250 V AC,
non-inductive and 3A at
• Relay/power to be copper
conductors per local 4
30 V DC requirements to meet 250 V
• 2 SPST Form A, NO relays, 5 A contact rating
rated 5A at 250 V AC, Max. separation between 365 m (1 200 ft)
non-inductive and 3 A at transducer and transceiver
30 V DC
Displays and controls 60 x 40 mm (2.36 x 1.57 inch)
mA output 4 … 20 mA, isolated removeable
• Max. load 600 : max. in ACTIVE mode, LCD, 240 x 160 pixels resolution,
750 : max. in PASSIVE mode operational up to 5 m from
• Resolution 0.1 % of range enclosure base
Accuracy Programming
Error in measurement • Standard operation: ± 1 mm • Primary 4 Local push buttons
(0.04 inch) plus 0.17 % of • Secondary • PC running SIMATIC PDM
measured distance • PC running Emerson AMS
• High accuracy OCM: ± 1 mm Device Manager
(0.04 inch), within 3 m (9.84 ft) • PC running a web browser
range • PC running a Field Device Tool
(FDT)
Resolution • Standard operation: 0.1 % of • Field Communicator 375/475
range or 2 mm (0.08 inch), (FC375/FC475)
whichever is greater
• High accuracy OCM: 0.6 mm Memory • 512 kB flash EPROM
(0.02 inch), within 3 m (9.84 ft) • 1.5 MByte flash for data logging
range Power supply
Temperature compensation • -40 ... +150 °C (-40 ... +300 °F) AC version 100 ... 230 V AC ± 15 %,
• Integral temperature sensor in 50/60 Hz, 36 VA
transducer Fuse: 5 x 20 mm, Slow Blow,
• External TS-3 temperature 0.25 A, 250 V
sensor (optional)
• Programmable fixed DC version 10 … 32 V DC, 10 W
temperature values Fuse: 5 x 20 mm, Slow Blow,
1.6 A, 125 V
Rated operating conditions
Certificates and approvals
Installation conditions
• Location Indoor/outdoor General CSAUS/C, CE, FM, UL listed,
• Installation category II C-TICK, MCERTS certified for
Open Channel Flow
• Pollution degree 4
Hazardous
Ambient conditions
• Non-incendive CSA Class I, Div. 2,
• Ambient temperature (enclosure) -20 … +50 °C (-4 … +122 °F) (Canada) Groups A, B, C, D;
Class II, Div. 2, Groups F, G;
Class III
• Shipping Lloyd's Register, ABS
Communication HART 7.0, USB

4/147
Tags: OM_LT_2104_LI, OM_LT_2105_LI Level Measurement
Continuous level measurement — Ultrasonic controllers
SITRANS LUT400 series
Selection and Ordering data Article No. Selection and Ordering data Order code
SITRANS LUT420 and LUT430 7ML5050- Further designs
Compact ultrasonic level controllers for continuous
short to long-range level or volume measurement of 00 7 7 7 7 0- 7 77 00 Please add "-Z" to Article No. and specify Order
liquids, slurries, and solids. Both units include code(s).
basic relay functions for pumps, alarms, and other Manufacturer's test certificate M to DIN 55350, ¢ C11
controls, plus onboard data logging. LUT430 offers Part 18 and to ISO 9000
additional advanced pump control and alarm
functionality, open channel flow monitoring, Stainless steel tag [69 x 50 mm (2.71 x 1.97 inch)]: ¢ Y15
and basic flow data logging capability. Measuring-point number/identification
Functionality varies by model. (max. 27 characters) specify in plain text
Model Namur NE43 failsafe setting - device preset to ¢ N07
SITRANS LUT420 - Level controller ¢ A failsafe < 3.6 mA
SITRANS LUT430 - Level, Pump & Flow controller ¢ B Operating Instructions Article No.
Enclosure display options English 7ML1998-5MV01
With display ¢ A French 7ML1998-5MV11
With remote panel mount display ¢ B
[Includes panel mount cable extension, 2.5 m Spanish 7ML1998-5MV21
(8.2 ft)]
4
German 7ML1998-5MV31
No display (blank lid provided) ¢ C
Italian 7ML1998-5MV51
Note: Enclosure includes back-plate for wall
and pipe mounting, and an integrated clip for Multi-language compact operating instructions 7ML1998-5XU81
DIN-rail mounting. DIN-rail mounting for standard Note: The operating instructions should be
TS35 x 7.5 and TS35 x 15 mm DIN-rail to ordered as a separate line item on the order.
IEC 60715, EN 60715
Communications Manual
Input voltage
100 ... 230 V AC ± 15 % ¢ 1 English 7ML1998-5NE01
10 ... 32 V DC ¢ 2 French 7ML1998-5NE11
Cable inlet Spanish 7ML1998-5NE21
3 cable inlets, cable glands not supplied ¢ 1 German 7ML1998-5NE31
3 cable inlets, 3 M20 plastic cable glands supplied¢ 2
Italian 7ML1998-5NE51
Number of measurement points Note: The communications manual should be
Single point system (includes one transducer input, ¢ 1 ordered as a separate line item on the order.
one mA output, and one external temperature
sensor input) Accessories

Communications and I/O Tag, stainless steel, 12 x 45 mm (0.47 x 1.77 inch), 7ML1930-1AC
one text line, suitable for enclosure
HART, 2 discrete inputs, 3 relays ¢ D
TS-3 Temperature Sensor - see TS-3 in catalog 7ML1813
Approvals
General purpose CE, FM, CSAUS/C, UL, C-TICK ¢ A Panel mount cable extension, 2.5 m (8.2 ft) 7ML1930-1GF
Hazardous locations CSA Class I, II, III, Div. 2 C Qty 3 cable glands and retaining nuts 7ML1930-1GB
(Groups A, B, C, D, F, G)
USB cable, 2 m (6.56 ft) - Standard USB-A to 7ML1930-1GD
¢ We can offer shorter delivery times for configurations designated with the USB-mini B
Quick Ship Symbol ¢. For details see page 9/5 in the appendix.
HART modem/RS-232 7MF4997-1DA
(for use with a PC and SIMATIC PDM)
Hart modem/USB 7MF4997-1DB
(for use with a PC and SIMATIC PDM)
Sunshield, 304 stainless steel 7ML1930-1GE
SITRANS RD100 Remote display - see Chapter 7
SITRANS RD200 Remote display - see Chapter 7
SITRANS RD500 web, datalogging, alarming, 7ML5750-
ethernet, and modem support for instrumentation - 1AA00-0
see Chapter 7
Spare parts
Panel mount retrofit kit (convert standard unit with 7ML1830-1PA
display to panel mount version)
Terminal block replacement kit 7ML1830-1PB
(5 piece kit with one of each removable terminal)
Wall/Pipe mount plate 7ML1830-1PC
Enclosure (include blank label) 7ML1830-1PD
SITRANS LUT400 Lid (with Display) 7ML1830-1PE
SITRANS LUT400 Lid (blank) 7ML1830-1PF
Fuse - AC (0.25 A, 250 V, Slow Blow) 7ML1830-1PG
Fuse - DC (1.6 A, 125 V, Slow Blow) 7ML1830-1PH
Battery BR2032 7ML1830-1PJ
Panel mount gasket and fastener kit 7ML1830-1PK
DIN-rail clip 7ML1830-1PL

4/149
 Level Measurement
Continuous level measurement — Ultrasonic controllers
Tags: OM_LT_2104_LI, OM_LT_2105_LI
SITRANS LUT400 series

■ Dimensional drawings

Back Enclosure
mount
bracket

SITRANS LUT400

198
(7.8)
4

190
(7.5)

144
(5.7)

34
(1.34)
22
(0.87)  98°


Cable entry 259

(3 places) (10.2)

155
(6.10)

146
(5.75)




SITRANS LUT400, dimensions in mm (inch)

4/151
 Level Measurement
Continuous level measurement — Ultrasonic controllers
Tags: OM_LT_2104_LI, OM_LT_2105_LI
SITRANS LUT400 series

■ Schematics

INPUT
POWER

12 13 14
1.6 A,125 V
SLOW BLOW 10 - 32 V

INPUT
TS-3 TRANSDUCER DISCRETE INPUTS POWER

4
1 2 3 4 5 6 7 8 9 10 1 12 13 14
1 2 DC SYNC L1 L2/N
0.25 A, 250 V
SHLD

SLOW BLOW
WHT
WHT

XWWGTGYZWG}
BLK

BLK

RELAYS mA OUT/HART BATTERY

BR2032

DISPLAY
15 16 17 18 19 20 21 22 23 24

RLY 1 RLY 2 RLY 3

PAS
ACT
SERVICE

SITRANS LUT400 connections

4/153
 © Siemens AG 2018

Tags: OM_LT_2104_LI, OM_LT_2105_LI Level Measurement

Continuous level measurement
Ultrasonic transducers
EchoMax XPS

■ Overview ■ Benefits
• Integral temperature compensation
• Low ringing effect reduces blanking distance
• Optional foam facing for dusty applications
• Self-cleaning and low-maintenance
• Chemically resistant
• Hermetically sealed

■ Application
XPS transducers can be fully immersed, are resistant to steam
and corrosive chemicals, and can be installed without flanges.
The XPS series offers versions for various measuring ranges up
to 30 m (100 ft) and up to a max. temperature of 95 °C (203 °F).

4
During operation, the EchoMax transducers emit acoustic
pulses in a narrow beam. The level monitor measures the prop-
agation time between pulse emission and its reflection (echo) to
EchoMax XPS transducers use ultrasonic technology to mea-
calculate the distance.
sure level in a wide range of liquids and solids.

Siemens FI 01 · 2018 4/177

 © Siemens AG 2018

Level Measurement
Continuous level measurement Tags: OM_LT_2104_LI, OM_LT_2105_LI
Ultrasonic transducers
EchoMax XPS

■ Technical specifications
Input XPS-10 XPS-15 (standard and F models) XPS-30
Measuring range 0.3 ... 10 m (1 ... 33 ft) Standard: 0.6 ... 30 m (2 ... 100 ft)
0.3 ... 15 m (1 ... 50 ft)
XPS-15F:
0.45 ... 15 m (1.5 ... 50 ft)
Output
Frequency 44 kHz 44 kHz 30 kHz
Beam angle 12° 6° 6°
Environmental
Location Indoors/outdoors
Ambient temperature -40 ... +95 °C (-40 ... +203 °F) Standard: -40 ... +95 °C (-40 ... +203 °F)
-40 ... +95 °C (-40 ... +203 °F)
XPS-15F:

4 Pollution degree 4
-20 ... +95 °C (-4 ... +203 °F)

Pressure 8 bar g (120 psi g) 8 bar g (120 psi g) 0.5 bar g (7.25 psi g)
Flanged: Flanged: Flanged:
0.5 bar g (7.25 psi g) 0.5 bar g (7.25 psi g) 0.5 bar g (7.25 psi g)
Design
Weight 0.8 kg 1.3 kg (2.8 lb) 4.3 kg
(1.8 lb) Flanged: (9.5 lb)
2 kg (4.4 lb)
Power supply Operation of transducer only with approved Siemens controllers
Material Standard: PVDF Standard: PVDF Standard: PVDF
Flanged: PVDF with CPVC flange Flanged: PVDF with CPVC flange Flanged: PVDF with CPVC flange
Option: PTFE face with CPVC flange Option: PTFE face with CPVC flange Option: PTFE face with CPVC flange
Color Blue Standard: Blue Blue
XPS-15F: Gray
Process 1" NPT or 1" BSPT Standard: 1" NPT or 1" BSPT 1.5" universal thread (NPT or BSPT)
connection XPS-15F: 1" NPT
Degree of IP66/68 IP66/68 IP66/68
protection
Cable 2-wire twisted pair/braided and foil shielded 0.5 mm² (20 AWG) PVC jacket
Separation Max. 365 m (1 200 ft)
Certificates and approvals Standard: Standard: CE, CSA, FM, ATEX, IECEx
CE, CSA, FM, ATEX, IECEx CE, CSA, FM, ATEX, IECEx
XPS-15F:
FM Class I, Div. 1, Groups A, B, C, and
D, Class II Div. 1, Groups E, F, and G,
Class III
1)
EMC certificate available on request.

4/178 Siemens FI 01 · 2018

 © Siemens AG 2018

Level Measurement Tags: OM_LT_2104_LI, OM_LT_2105_LI

Continuous level measurement
Ultrasonic transducers
EchoMax XPS
Selection and Ordering data Article No. Selection and Ordering data Order code
EchoMax XPS-15 ultrasonic transducer 7ML1118- Further designs
High-frequency ultrasonic transducer designed 777 7 0 Please add "-Z" to Article No. and specify Order
for a wide variety of liquid and solid applications, code(s).
for use with approved controllers. Includes integral
temperature sensor. Stainless steel tag [69 x 50 mm (2.71 x 1.97 inch)]: Y15
Measuring range: min. 0.3 m, max. 15 m Measuring point number/ identification
(max. 27 characters) specify in plain text
Click on the Article No. for the online configura-
tion in the PIA Life Cycle Portal. Operating Instructions Article No.
Mounting thread and facing Multi-language A5E43390688
1" NPT [(Taper), ANSI/ASME B1.20.1] 0
Note: The Operating Instructions should be
1" NPT [(Taper), ANSI/ASME B1.20.1] 1
ordered as a separate line item on the order.
with foam facing1)
1" NPT [(Taper), ANSI/ASME B1.20.1] 2 All literature is available to download for free, in a
with PTFE facing2) range of languages, at [Link]
processinstrumentation/documentation
R 1" [(BSPT), EN 10226] 3
R 1" [(BSPT), EN 10226] with foam facing1) 4 Accessories
R 1" [(BSPT), EN 10226] with PTFE facing2) 5 Tag, stainless steel with hole, 12 x 45 mm 7ML1930-1BJ
4 Cable length
5 m (16.40 ft) B
(0.47 x 1.77 inch), one text line for fastening on
sensors
10 m (32.81 ft) C Submergence shield kit 7ML1830-1BJ
30 m (98.43 ft) E
Universal box bracket, mounting kit 7ML1830-1BK
50 m (164.04 ft) F
100 m (328.08 ft) K Channel bracket, wall mount 7ML1830-1BL
Mounting flange Extended channel bracket, wall mount 7ML1830-1BM
None A
Channel bracket, floor mount 7ML1830-1BN
6" ASME, 150 lb, flat faced D
8" ASME, 150 lb, flat faced E Extended channel bracket, floor mount 7ML1830-1BP
DN 150, PN 10/16, Type A, flat faced J Bridge channel bracket, floor mount 7ML1830-1BQ
DN 200, PN 10, Type A, flat faced K (see Mounting Brackets on page 4/186 for
more information)
JIS10K 6B N
JIS10K 8B P 1" NPT locknut, plastic 7ML1830-1DS
(Note: Flange bolting patterns and facings
1" BSPT locknut, plastic 7ML1830-1DR
dimensionally correspond to the applicable
ASME B16.5 or EN 1092-1, or JIS B 2220 standard.) Easy Aimer 2, aluminum, NPT with ¾" x 1" PVC 7ML1830-1AQ
Approvals coupling
ATEX 2GD Ex mb IIC T4 Gb, Ex tb IIIC T135 °C Db; 3 Easy Aimer 2, aluminum with M20 adapter and 7ML1830-1AX
IECEx SIR 13.0009X Ex mb IIC T4 Gb, Ex tb IIIC 1" and 1½" BSPT aluminum couplings
T135 °C Db; FM Class I, Div. 2, Groups A, B, C, D;
Class II, Div. 1, Groups E, F, G; Class III Easy Aimer 304, NPT with 1" stainless steel 7ML1830-1AU
CSA Class I, Div. 1, Groups A, B, C, D, Class II, 4 coupling
Div. 1, Groups E, F, G, Class III 3) Easy Aimer 304, with M20 adapter and 1" and 1½" 7ML1830-1GN
1)
Not available with flanged versions
BSPT 304 stainless steel couplings
2)
Available with flanged versions only Plastic adapter 1" BSP - 20 mm 7ML1830-1EA
3)
Available with mounting options 0 ... 2 only Plastic adapter 1" NPT 7ML1930-1FX
Plastic adapter 1" NPT/M20 7ML1830-1EF

4/180 Siemens FI 01 · 2018

 © Siemens AG 2018

Level Measurement
Tags: OM_LT_2104_LI, OM_LT_2105_LI Continuous level measurement
Ultrasonic transducers
EchoMax XPS

■ Dimensional drawings ■ Circuit diagrams

Standard Submergence shield Direct connection

J
Black
B White

Shield

F
Coaxial connection
A Radiating face

Bonded flange White

Shield

4
B

3 terminal direct*
C
Black

XPS ultrasonic transducer Shield

Version White

Dimension XPS-10 XPS-15 XPS-30

A 88 mm 121 mm 175 mm
(3.464 inch) (4.764 inch) (6.890 inch)
B 122 mm 132 mm 198 mm 3 terminal extension*
(4.803 inch) (5.197 inch) (7.795 inch) Black
C According to ASME, DIN, and JIS White
E 124 mm 158 mm n/a
(4.882 inch) (6.220 inch) Shield

F 152 mm 198 mm n/a

(5.984 inch) (7.795 inch)
* For SITRANS LUT400, MultiRanger 100/200, HydroRanger 200
J 28 mm (1.1 inch) 28 mm (1.1 inch) 28 mm (1.1 inch)

Mounting
Make particularly sure that the radiating face of the transducer is
protected from damage. Mount the transducer so that it is above the
maximum material level by at least the blanking value. On liquid
applications, the transducer must be mounted so that the axis of
transmission is perpendicular to the liquid surface. On solids applications,
an Easy Aimer should be used to facilitate aiming the
transducer. Consider the optional temperature sensor when mounting
the transducer.

Interconnection
Do not route cable openly or near high voltage or current runs, contactors
and SCR control drives. For optimum isolation against electrical noise,
run cable separately in a grounded metal conduit. Seal all thread
connections to prevent ingress of moisture.

XPS ultrasonic transducer connections

Siemens FI 01 · 2018 4/183

 Product brochure 700 VA – 3 kVA

Eaton 9SX UPS

Reliable power protection for the edge and beyond
Combining reliable double-conversion topology, internal Gain efficiencies in your operations
static bypass and an easy-to-read LCD menu display, the Eaton
9SX UPS provides the highly efficient and reliable power you Integrate and standardize communications
expect from a 9-series UPS in a convenient tower form factor. Maximize uptime with remote monitoring and management of your
Network, Modbus, Relay and signal input functionality enables 9SX via an Eaton connectivity card and software. SNMP, serial,
integration into a variety of IoT and IIoT applications. USB, Modbus, and relay options enable integration regardless of
the system architecture. Remote Power Off/Remote On Off signal
Protect the business you’ve worked hard to grow: input also manages UPS On/Off state preserving battery life during
process shutdown.
Reliable power for critical systems
The 9SX offers the robust double-conversion, online power Advanced LCD interface
protection needed for medical, light industrial, automation and Simplify UPS monitoring with Eaton’s advanced LCD display.
mission critical IT applications. With zero transfer time to battery, Easy access to UPS alarm history, energy logs, unit serial numbers
continuous filtering of power, and an internal, automatic static and firmware versions enable first time issue resolution right at
bypass, the 9SX ensures performance and compatibility. the source. Eight, user-selectable languages ensure success for
Increased battery life global deployments.
Eaton offers ABM technology that increases battery service life by
50 percent. ABM uses advanced charging techniques to extend Services and support:
battery life and provides advanced notice before batteries fail.
Eaton provides product support
24 hours a day, 7 days a week.
Get more so you can do more From battery replacement to full
More power UPS service plans, Eaton has
By providing up to 28 percent more wattage compared to traditional one of the top service models
UPSs, the 9SX allows you to connect more devices and leave room in the industry.
for expanding IT systems.
More control
Automate power delivery by utilizing switchable, programmable
outlets, without the need of a third party device or PDU.
Programmable signal input through the RPO port also enables the
UPS to change operating modes in reaction to external events.
9SX front panel 1 9SX back panel 6 7

1 LED indicators 2 6 EBM connector

3
2 LCD panel 7 Network Card-M2 slot
8 10
3 Hot swappable batteries 8 RS-232 port
11
4 Sleek tower design 9 USB port 13
4
5 High efficiency mode 10 Standard relay output 9 12
connector
11 Battery detection port

5
12 Remote Power Off 14 15
(RPO)/Signal Input
Connector
13 Fan
14 Switchable load groups Model 9SX1500 shown here

15 5-15P input plug

9SX MODEL SELECTION GUIDE*
Catalog number Rating (VA/watts) Input connection Output receptacles Dimensions (H x W x D), in Net weight, lb
120V output, 50/60 Hz models
9SX700 700/630 5-15P** (6) 5-15R 9.9 x 6.3 x 13.9 26.5
9SX1000 1000/900 5-15P** (6) 5-15R 9.9 x 6.3 x 15.1 30.9
9SX1500 1500/1350 5-15P** (6) 5-15R 9.9 x 6.3 x 17.1 41.9
9SX2000 1960/1770 5-20P** (6) 5-20R, (1) L5-20R 13.6 x 8.4 x 16.2 77.2
9SX3000 3000/2700 L5-30P** (4) 5-20R, (1) L5-30R 13.6 x 8.4 x 16.2 77.2
9SX3000HW 3000/2700 Hardwired Hardwired 13.6 x 8.4 x 16.2 77.2
208V output, 50/60 Hz models
9SX1000G 1000/900 C14 (6) C13 9.9 x 6.3 x 15.1 30.9
9SX1500G 1500/1350 C14 (8) C13 9.9 x 6.3 x 17.1 41.9
9SX2000G 2000/1800 C20/L6-20P*** (8) C13 13.6 x 8.4 x 16.2 77.2
9SX3000G 3000/2700 C20/L6-20P*** (8) C13, (1) C19 13.6 x 8.4 x 16.2 77.2
9SX3000GL 3000/2700 C20/L6-20P*** (1) L6-30R, (2) L6-20R, (2) 6-20R 13.6 x 8.4 x 16.2 77.2
*D ue to continuous product improvement programs, all specifications are subject to change without notice.
** Input line cord is 8 feet long.
*** C19 to L6-20P input connector is 8 feet long.

Optional extended battery module (EBM) Options

Internal runtime (min) +4 EBM Catalog Connectivity Catalog number Slot type
UPS model Full / half load Full / half load number Gigabit network card NETWORK-M2 Mini slot
9SX700 5.8 / 16.6 — — Industrial relay INDRELAY-MS Mini slot
9SX1000 6.7 / 18.5 113 / 269 9SXEBM36 Industrial Gateway card INDGW-M2 Mini slot
9SX1000G 5.9 / 16.2 108 / 232 Relay card RELAY-MS Mini slot
9SX1500 5.9 / 16.5 105 / 239 9SXEBM48
9SX1500G 5.3 / 16.2 104 / 234
9SX2000 10.3 / 26.2 162 / 363 9SXEBM96
9SX2000G 10.4 / 27.5 164 / 396
9SX3000 5.7 / 16.7 104 / 231
9SX3000G 5.8 / 15.7 104 / 231

For complete battery runtime information

and to interact with the 9SX UPS, please visit:
[Link]/9SX

Eaton
1000 Eaton Boulevard
Cleveland, OH 44122
United States
[Link]

© 2021 Eaton Eaton, Intelligent Power Manger and ABM Follow us on social media to get the
All Rights Reserved are registered trademarks. latest product and support information.
Printed in USA
BR153093EN / GG All other trademarks are property of their
March 2021 respective owners.
[Link]

Management
Card Contact &
RS232 / Serial

Installation manual

34003907EN/AE

[Link]
 INTRODUCTION UNPACKING AND CHECKS
The Management Card Contact & RS232/Serial offers two types of ● One Management Card Contact & RS232/Serial
interfaces via a DB9 connector: ● One installation manual (34003907)
Dry contacts (contact mode)
RS232 serial interface (RS232 mode)
All UPSs from EATON equipped with a Minislot can be connected to a
number of electrical-management applications.
Jumpers are used to select the interface (contacts or RS232).

APPLICATIONS
Contact mode (factory setting)
● In this mode, the card provides a simple way to remote UPS
information to an alarm system, PLC or computer system via dry
contacts (relay).
The transmitted information is load powered, load on bypass, load on
battery , load on utility, battery fault and low battery.

● A UPS power off function activated by an external contact or voltage

level is also proposed. It is available only in contact mode.
OVERVIEW
● Equipped with an IBM iSeries (66033) or Windows (66047) cable
available from EATON, the card offers direct communication with the
power-management system of the servers supplied by the UPS and
can thus provide protection (shutdown) on reception of one of the DB9
connector
information signals. Configuration of the various systems is presented
in the documents supplied with the cable. For this application, use the UPS data Relay
Config2 setting on the card. Contacts
or RS232
UPS Windows cable (66047)
Windows
server
RS232 / Relay Contacts

Jumpers for mode selection

66104

CONTACT MODE CONFIGURATION

● In this mode, the contact (relay) is closed between the common (pin
5) and the pin transmitting the signal (pin 2, 4, 6, 7, 8, 9) when UPS
information is active or true.
● When the card is not supplied, all the contacts between pin 5 and the
RS232 mode other pins are open, except the contact between pin 4 and pin 5, which
● In this mode, the card offers an RS232 interface for connection to a remains closed.
PC or to a UPS Control display unit. ● Three configurations are available in this mode, for three types of
Connection to a PC requires the RS232 UPS Communication Cable UPS power off. The diagram below shows, for each configuration, the
(66049). The cable is not supplied with the card. Once connected the jumper settings, the various contacts (card not supplied) and the
protection software can be installed and used immediately. external wiring for the power off function. The UPS shuts off if the
● The WindowsTM Plug&Play function is managed by the card. contact position is the opposite of that shown.
● The cable and the display are available from EATON.
Config1: Config2: Config3:
Cable 66049
UPS power off if UPS power off UPS power off if
contact opens depending on contact closes
voltage level
(factory setting)

(66049)
5 4 3 2 1 5 4 3 2 1 5 4 3 2 1
Protection 9 8 7 6 9 8 7 6 9 8 7 6
software
NC NO NO NO NO NC NO NO NO NO NO NC NO NO NO NO

common common common

5 4 3 2 1 5 4 3 2 1 5 4 3 2 1
9 8 7 6 9 8 7 6 9 8 7 6

34003907EN/AE
DB9 CONNECTOR PINOUTS
No. Function Description TECHNICAL CHARACTERISTICS
1 Not used
2* Battery fault (Config 2) Config 2: a battery fault occurred. Physical characteristics
UPS power off (Config 1 Config 1 or 3: UPS power off by contact. Dimensions (W x H x D) 66 x 42 x 132 mm
or 3)
Weight 70 g
3 UPS power off (Config 2) Config 2: UPS power off by voltage level.
RoHS 100% compatible
Not used (Config 1 or 3)
Storage
4 Load on utility** The load is protected. The UPS supplies
the load using utility power (not from the Storage temperature range -10°C to 70°C
battery). Ambient conditions
5 Common Config 2: volt-free pin. Operating temperature range 0°C to 40°C
Config 1 or 3: pin connected to GND.
Relative humidity 90% RH max. without condensation
6 Load on automatic The load is not protected. The UPS
bypass*** supplies the load using utility power. If utility
Performance
power fails, the load will not be supplied. Card
7 Low battery The battery has dropped below the preset Supply voltage 5 V +/- 5%
warning level (depending on UPS setup). If Supply current (all relays activated) 150 mA max.
the voltage level continues to drop, the UPS
Supply current (all relays deactivated) 15 mA max.
will no longer be capable of supplying
power to the load. Relay contacts (output)
8 UPS ON, load powered The UPS is operational and can supply Double insulation (optocoupler) > 4000V DC
power to the load, whether utility power is Max. contact resistance 75 mOhm
available or not, whether the UPS is on the
Max. switching voltage <40 V AC or <50 V DC
bypass or not.
Max. switching current 1 A max (e.g. for five contacts,
9 Load on battery ** The load is protected. The UPS supplies
200 mA max for each contact.)
the load from the battery (not using utility
power). Max. switching power 40 W
Min. switching capacity 10 µA 10 mV DC
* The function of this pin varies, depending on the configuration. The Battery fault
information is available only in Config 2. Service life (min. number of operating 105
** Load on utility and Load on battery are complementary signals. They cannot be cycles)
activated simultaneously.
*** Not available on line-interactive UPS. No manual bypass. Max. recommended distance 20 meters
UPS power off (input)

RS232 MODE CONFIGURATION Single insulation (optocoupler) > 4000V DC

Max. acceptable external contact 20 Ohm
resistance
● In this mode, only one configuration is possible.
(including cable, Config 1 or 3)
Min. & max. voltage (Config 2) +3 V DC to +50 V DC
Min. input current (Config 2) 500 µA
Max. input current (Config 2) 60 mA
Min. impulse duration >100 ms
Reverse voltage Diode protection
Max. recommended distance 20 meters
DB9 CONNECTOR PINOUTS
Note. The UPS does not take into account the shutdown time required by any
No. Function Description protected applications once the shutoff order has been requested. Power at the
2 TD Transmit data (output) UPS outputs is interrupted immediately (<100 ms).

3 RD Receive data (input) Serial interface Compliant with EIA-232E

specifications
5 GND Ground

SAFETY INSTRUCTIONS
6 RTS Plug-&-Play (input)
1, 4, 7, 8, 9 Not used
The relay contacts and the card inputs are galvanically
isolated from the UPS. It is strictly forbidden to apply a
INSTALLATION voltage greater than 40 V AC or 50 V DC to the contacts.
Disregard for this restriction may endanger human life,
The Contact & RS232/Serial Management Card can be installed on damage equipment and cancel the manufacturer warranty.
a running UPS from EATON compatible with this card. It is not

ELECTROMAGNETIC COMPATIBILITY
necessary to shutoff the UPS, disconnect the load or restart the UPS.
● Remove the plastic cover of the Minislot.
● Insert and secure the card with the screws. When correctly installed and used in accordance with manufacturer
instructions, the card complies with the following standards:
● ITE (Information Technology Equipment) safety: IEC/EN 60950-1
2002
● EMC: EN 61000-6-2 (2002), EN 61000-6-3 (2002), IEC/EN 62040-2
(2002)
In compliance with European directives:
● Low voltage: 73/23/EEC and 93/68/EEC.
● EMC: 89/336/EEC and 93/68/EEC.

Federal Communication Commission (FCC) statement

This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to part 15 of the FCC rules. These
limits are designad to provide reasonable protection against harmful
interference when the equipment is operated in a commercial
environment.
34003907EN/AE
 WEB SITE
The information presented in this manual is also available in other
languages at [Link]/powerquality.

34003907EN/AE
Safety Barriers
Single-channel safety barriers

9001/51-280-110-141  Art. No. 158530
• For the intrinsically safe operation of a wide range of devices, such as
HART transmitters, solenoid valves, sensors, zero-​potential contacts
and many more
• Compact, space-​saving devices that are easy to install on a DIN rail
• Quick to install as barriers can be simultaneously snapped onto rail
and connected to PE

WebCode  9001A

The 9001 series INTRINSPAK single-​channel safety barriers enable the intrinsically safe operation of
virtually all field devices. The comprehensive portfolio and the combination of safety barriers cover a
wide variety of signals. The devices are incredibly robust and require little space. The back-​up fuse
is a convenient feature as it is standardised for all variants.

Technical Data
Explosion Protection
Application range (zones) 2
22
Ex interface zone 0
1
2
20
21
22
Certificate IECEX Gas IECEx PTB 09.0001X
Certificate ATEX Gas PTB 01 ATEX 2088 X
Certificate IECEX Dust IECEx PTB 09.0001X
Certificate ATEX Dust PTB 01 ATEX 2088 X
Gas explosion protection IECEx Ex nA [ia Ga] IIC/​IIB T4 Gc
Gas explosion protection ATEX E II 3 (1) G Ex nA [ia Ga] IIC/​IIB T4 Gc
Dust explosion protection IECEx [Ex ia Da] IIIC
Dust explosion protection ATEX E II (1) D [Ex ia Da] IIIC
Certificates ATEX (PTB), Brazil (ULB), Canada (CSA), EAC (STV), IECEx (PTB), Korea (KGS), USA
(FM), USA (UL)
EAC certificate TS RU S-​DE.GB04.B.00132
Installation in Zone 2, Division 2 and in safe area
Safety Data
Max. voltage Uo 28 V
Max. current Io 110 mA
Max. power Po 770 mW
Max. permissible external capacitance Co 0.083 μF
for IIC
Max. permissible external capacitance Co 0.65 μF
for IIB

2018-04-26 R. STAHL Schaltgeräte GmbH | Am Bahnhof 30 | D 74638 Waldenburg | [Link]1/5

V 0.41 EN Tel. +49 (7942) 943-0 | +49 (7942) 943-4333 | Email: [Link]@[Link]
Safety Barriers
Single-channel safety barriers

9001/51-280-110-141  Art. No. 158530

Safety Data
Max. permissible external inductance Lo 1.2 mH
for IIC
Max. permissible external inductance Lo 9 mH
for IIB
Further information see respective certificate and operating instructions
Electrical Data
Number of channels 1
Power supply Uncontrolled, 20 – 35 V DC
Nominal voltage 20 – 35 V
Potential For transmitter
[Link].>= 50mA ≤ 100 kHz
[Link]<= 50 mA ≤ 50 kHz
Ileak leakage current for Un ≤ 2  µA
Ileak leakage current for Un 2 (Unless specified otherwise)
Ambient Conditions
Min. ambient temperature -​20  °C
Max. ambient temperature +60 °C
Ambient temperature -​20 °C ... +60 °C
Min. storage temperature -​20  °C
Max. storage temperature +75 °C
Storage temperature -​20 °C ... +75 °C
Maximum relative humidity 95% on av., no condensation
Temperature influence ≤ 0,25 %/10K
Mechanical Data
Degree of protection (IP) IP40
Type of protection note according to IEC 60529
Degree of protection (IP) Terminals IP20
Enclosure material Polyamide 6GF
Number of connection terminals 4
Max. clamping range 1.5 mm²
Connection cross-​section 4 mm²
Type of connection cable Solid
Finely stranded
Width 103 mm
Length 12 mm
Mounting depth 72 mm
Weight 0.11 kg
Mounting / Installation
Connection type 2 PA

2018-04-26 R. STAHL Schaltgeräte GmbH | Am Bahnhof 30 | D 74638 Waldenburg | [Link]2/5

V 0.41 EN Tel. +49 (7942) 943-0 | +49 (7942) 943-4333 | Email: [Link]@[Link]
Safety Barriers
Single-channel safety barriers

9001/51-280-110-141  Art. No. 158530
Technical Drawings
Hazardous area Safe area

Is Power supply
+Ue +20 V ... 35 V + UN
0V
Intrinsically safe UN
eld device Control room
+Ue equipment
-Ue / 0V
RL
Picture K
0V

/ PA

Single-Channel Safety Barriers for Transmitters

Hazardous area Safe area

+20 ... 35 V DC
4 ... 20 mA
00 5 2 0 0 4

Application: Analog input with standard transmitter Field circuit earthed

Dimensional Drawings (All Dimensions in mm [inches]) – Subject to Alterations

80 [3,15]
103 [4,06]

Mounting on DIN rail NS 35/15

12 [0,47] 72 [2,83]
76 [3,00]
95 [3,74]

66 [2,60] 38 [1,50]

66 [2,60] 38 [1,50] Mounting on mounting plate by means of adaptor

Mounting on DIN rail NS 32 by means of adaptor and mounting

attachment, moulded plastic

Accessories and Spare Parts

2018-04-26 R. STAHL Schaltgeräte GmbH | Am Bahnhof 30 | D 74638 Waldenburg | [Link]3/5

V 0.41 EN Tel. +49 (7942) 943-0 | +49 (7942) 943-4333 | Email: [Link]@[Link]
Safety Barriers
Single-channel safety barriers

9001/51-280-110-141  Art. No. 158530

Back-​up fuse Art. No.

For all safety barriers Series 9001, 9002 and 9004 158964
unit: 5 pcs.

Holder for label Art. No.

Transparent cover for labelling 158977

Labelling paper Art. No.

Perforated, for typing 158973
Format: DIN A4
Packaging unit: 80 pieces

Adaptor Art. No.

Adaptor allows installation of a safety barrier Series 900x on a mounting plate of a previous 158826
series.

Mounting attachment moulded plastic Art. No.

Enables mounting of safety barrier on a G-​rail. 165283

DIN rail Art. No.

NS35/​15  (meter length) 103714

Earth terminal Art. No.

USLKG 5 (wire range 4 mm ) 2
112760
Terminal enables connection of protective conductors to DIN rail. Colour green-​yellow.
USLKG 6 N (wire range 6 mm2) 112599
Terminal enables connection of protective / earthing conductors to DIN rail. Colour green-​yel-
low.

Fuse holder Art. No.

Fuse holder is snapped onto the side of the safety barrier and can be equipped with up to 158834
5 back-​up fuses (replacement).

Insulating stand off Art. No.

Suitable for DIN rail NS35/​15, allows electrically insulated mounting of DIN rail from mounting 158828
plate.

2018-04-26 R. STAHL Schaltgeräte GmbH | Am Bahnhof 30 | D 74638 Waldenburg | [Link]4/5

V 0.41 EN Tel. +49 (7942) 943-0 | +49 (7942) 943-4333 | Email: [Link]@[Link]
Safety Barriers
Single-channel safety barriers

9001/51-280-110-141  Art. No. 158530
We reserve the right to make alterations to the technical data, dimensions, weights, designs and products available with-
out notice. The illustrations cannot be considered binding.

2018-04-26 R. STAHL Schaltgeräte GmbH | Am Bahnhof 30 | D 74638 Waldenburg | [Link]5/5

V 0.41 EN Tel. +49 (7942) 943-0 | +49 (7942) 943-4333 | Email: [Link]@[Link]
Straight Blade Devices
20A, 125V, 2 Pole, 3 Wire Grounding
®
HBL Extra Heavy Duty MAX Specification Grade
Duplex Receptacle

Features
Back wired ground terminal allows faster, easier installation
One-piece brass integral ground strap
Finder Groove Face
Deep body design with circuit ID face

Ordering Information
Description Device Color UPC Number Catalog Number
Deep body design with circuit Ivory 783585435282 HBL5362I
ID face. Back and side wired.

Listings
UL Listed to UL498 File No. E2186
Certified to CSA 22.2, No. 42 File 285
Fed. Spec. W-C-596
NEMA® WD-6 Compliant

Specifications
Face Nylon
Base PBT
By-Pass Power Contacts .036". (.9) Brass
Ground Contacts .031 in. (.8) Brass
Clamping Plate Nickel plated brass
Terminal Screws Plated brass
Mounting Strap .050 in. (1.3) Brass
Automatic Self-grounding Clip Stainless steel
Mounting Screws Zinc plated steel

Performance
Complementary Products
Electrical
Current Interrupting Certified for current interrupting at full rated Wallplate or Weatherproof Cover Duplex Opening
current
Dielectric Voltage Withstands 2,000V minimum

Mechanical
Product Identification Ratings are a permanent part of the device
Terminal Accommodation #14-#10 AWG copper stranded or solid
conductor only
Terminal Identification Terminals identified in accordance with UL 498 Online Resources
and CSA Customer Sales Drawings
eCatalog
Environmental
Installation Instructions
Flammability Top: UL 94V-2, Base: UL 94V-0
Operating Temperatures Maximum continuous 75°C; minimum -40°C (w/o
impact)

Dimensions in Inches (mm)

Hubbell Wiring Device-Kellems • Hubbell Incorporated (Delaware) • 40 Waterview Drive • Shelton, CT 06484
Phone (800) 288-6000 • Fax (800) 255-1031 • Specifications subject to change without notice.
Straight Blade Devices
15A, 125V, 2 Pole, 3 Wire Grounding
®
HBL Extra Heavy Duty MAX Specification Grade
Single Receptacle

Features
One-piece brass integral ground strap
Unique bypass contact design

Ordering Information
Description Device Color UPC Number Catalog Number
Back and side wired Brown 783585013855 HBL5261

Listings
UL Listed to UL498 File No. E2186
Certified to CSA 22.2, No. 42 File 285
Fed. Spec. W-C-596
NEMA® WD-6 Compliant

Specifications
Face Nylon
Base PBT
Power Contacts .037 in. (.9) Brass
Ground Contact Brass
Mounting Strap .050" (1.3) Brass
Auto Self-grounding Clip Stainless steel
Mounting Screws Zinc plated steel

Performance
Electrical
Current Interrupting Certified for current interrupting at full rated
current
Dielectric Voltage Withstands 2,000V minimum

Mechanical
Product Identification Ratings are a permanent part of the device
Terminal Accommodation #14-#10 AWG copper stranded or solid Complementary Products
conductor only Wallplate or Weatherproof Cover 1.40" Opening
Terminal Identification Terminals identified in accordance with UL 498
and CSA

Environmental
Flammability Top: UL 94V-2, Base: UL 94V-0
Operating Temperatures Maximum continuous 75°C; minimum -40°C (w/o
impact)
Online Resources
Customer Sales Drawings
eCatalog
Installation Instructions

Dimensions in Inches (mm)

Hubbell Wiring Device-Kellems • Hubbell Incorporated (Delaware) • 40 Waterview Drive • Shelton, CT 06484
Phone (800) 288-6000 • Fax (800) 255-1031 • Specifications subject to change without notice.
Straight Blade Devices
15A, 125V, 2 Pole, 3 Wire Grounding
Flanged Receptacles

Features
Impact resistant thermoplastic construction
Backwired terminations for ease of installation
#8-32 Multiple drive terminal screws
Mounting screws included

Ordering Information
Description Device Color UPC Catalog Number
Nylon casing, back White 783585173603 HBL5279C
wired

Listings
UL Listed, File E2186
Certified to CSA, C22.2, No. 42
NEMA® WD-6 Compliant

Specifications
Housing Nylon
Terminal Retainer Clear polycarbonate
Contacts Brass
Terminal Screws #8-32 Brass, Multiple Drive
Terminal Clamp Cold rolled steel – nickel plated
Assembly Screws Steel - nickel plated
Mounting Screws Nickel plated brass

Performance
Electrical
Current Interrupting Certified for current interrupting at full rated current
Dielectric Voltage Withstands 2,000V minimum

Mechanical
Product Identification Ratings are a permanent part of the device
Terminal Accommodation #18-#10 AWG copper stranded or solid conductor only Accessories
Terminal Identification Terminals identified in accordance with UL 498 and CSA Weatherproof Lift Cover WP1

Environmental
Flammability UL 94 V-2 Resources
Operating Temperatures Maximum continuous 75°C; minimum -40°C (w/o impact) Customer Use Drawing
eCatalog

Dimensions in Inches (mm)

Hubbell Wiring Device-Kellems • Hubbell Incorporated (Delaware) • 40 Waterview Drive • Shelton, CT 06484
Phone (800) 288-6000 • Fax (800) 255-1031 • Specifications subject to change without notice.
Straight Blade Devices
15A, 125V, 2 Pole, 3 Wire Grounding
Flanged Inlets

Features
Impact resistant thermoplastic construction
Backwired terminations for ease of installation
#8-32 Multiple drive terminal screws
Mounting screws included

Ordering Information
Description Device Color UPC Catalog Number
Nylon casing, back White 783585173504 HBL5278C
wired

Listings
UL Listed, File E2186
Certified to CSA, C22.2, No. 42
NEMA® WD-6 Compliant

Specifications
Housing Nylon
Terminal Retainer Clear polycarbonate
Blades Brass
Terminal Screws #8-32 Brass, Multiple Drive
Terminal Clamp Cold rolled steel – nickel plated
Assembly Screws Steel - nickel plated
Mounting Screws Nickel plated brass

Performance
Electrical
Current Interrupting Certified for current interrupting at full rated current
Dielectric Voltage Withstands 2,000V minimum

Mechanical
Product Identification Ratings are a permanent part of the device
Terminal Accommodation #18-#10 AWG copper stranded or solid conductor only Accessories
Terminal Identification Terminals identified in accordance with UL 498 and CSA Weatherproof Lift Cover WP1

Environmental
Flammability UL 94 V-2 Resources
Operating Temperatures Maximum continuous 75°C; minimum -40°C (w/o impact) Customer Use Drawing
eCatalog

Dimensions in Inches (mm)

Hubbell Wiring Device-Kellems • Hubbell Incorporated (Delaware) • 40 Waterview Drive • Shelton, CT 06484
Phone (800) 288-6000 • Fax (800) 255-1031 • Specifications subject to change without notice.
 Boxes and Covers

Utility Boxes and Covers

CI2018 CI2018-SB BC2020 BC2020-R

BC20-C-1 BC20-C-3 BC20-C-4 BC20-C-5

Volume Features Knockouts

Cat. No.
(Cu. in.) Bracket Raised Ground Screw 1/2 in. ends 1/2 in. bottom 1/2 in. sides
1-1/2 in. Deep — 4 in. x 2-1/4 in.
CI2018 13.0 - no 2 2 6
CI2018-SB 13.0 “SB” no 2 2 3
1-7/8 in. Deep — 4 in. x 2-1/8 in.
BC2020 14.0 - yes 2 2 6
BC2020-R 14.0 - - 2 - 6

Cat. No. Description

Covers — 20 Series
BC20-C-1 For duplex receptacle
BC20-C-3 For 1-13/32 in. diameter 15 A single receptacle
BC20-C-4 Blank
BC20-C-5 For toggle switch
Note: BC2020-R can be installed on CI2018 / BC2020 Series
Covers: Device mounting screws included

w w w. t n b. c a
A42
 Boxes and Covers

Utility Boxes and Covers

CI1141 BC1110 CI1110-SB BC1110-LSKO

BC1110-SSX BC1110-R 1151 (For toggle switch) 1198 (For Decora or GFCI) 1199 (For duplex receptacle)

BC11-C-1 BC11-C-2 BC11-C-3 BC11-C-4 BC11-C-5 BC11-C-10 CI11-C-10-HV BC11-C-4-HV BC11-C-5-HV

Volume Features Knockouts

Cat. No.
(Cu. in.) Bracket Raised Ground Screw 1/2 in. ends 1/2 in. bottom 1/2 in. sides
1-1/2 in. Deep – 4 in. x 2-1/4 in.
CI1141 13.0 mounting ears no 2 2 6
1-7/8 in. Deep – 4 in. x 2-3/8 in.
BC1110 16.5 - yes 2 2 6
CI1110-SB 16.5 “SB” yes 2 2 3
BC1110-R 16.5 - - 2 - 6
2-1/8 in. Deep – 4 in. x 2-1/2 in.
1151 18.5 - yes 2 2 -
1198 18.5 - yes 2 2 -
1199 18.5 - yes 2 2 -
1-7/8 in. Deep – 4 in. x 2-3/8 in.
BC1110-LSKO 16.5 - yes 2 2 -
BC1110-SSX 16.5 “SSX” yes 2 2 -

Cat. No. Description Cat. No. Description

Covers – 11 Series
BC11-C-1 For duplex receptacle BC11-C-10 Decora/GFCI
BC11-C-2 For 1-19/32 in. diameter 20 A single locking receptacle CI11-C-10-HV Decora 347 V
BC11-C-3 For 1-13/32 in. diameter 15 A single receptacle BC11-C-4-HV Blank 347 V
BC11-C-4 Blank BC11-C-5-HV For toggle switch
BC11-C-5 For toggle switch
Note: Covers: Device mounting screws included

w w w. t nb. c a
A43
Relay and Timer Specifications

700-HF Square Base Relay

• 12 A contact rating
• DPDT, 4PDT
• Plug-in quick connect/solder terminals
• Options: LED, push-to-test manual override operator

Contact Wiring Diagrams

Photo Description Coil Voltage Cat. No.(1)
Rating U.S./Canada International
6V AC 700-HF32A06
12V AC 700-HF32A12
24V AC 700-HF32A24
DPDT 120V AC 700-HF32A1
2-pole
2 Form C 240V AC 700-HF32A2
AgCdO 12 A
Contacts 6V DC 700-HF32Z06
12V DC 700-HF32Z12
24V DC 700-HF32Z24
48V DC 700-HF32Z48
700-HN116 700-HN116
Socket 110V DC 700-HF32Z1
700-HN262 700-HN262
6V AC 700-HF34A06
12V AC 700-HF34A12
24V AC 700-HF34A24

4PDT 120V AC 700-HF34A1

4-pole 240V AC 700-HF34A2
4 Form C
AgCdO Contact 12 A 6V DC 700-HF34Z06
12V DC 700-HF34Z12
24V DC 700-HF34Z24
48V DC 700-HF34Z48
700-HN139 700-HN139
Socket 110V DC 700-HF34Z1
700-HN264 700-HN264
(1) Pilot Light Option: Add suffix (-4) to the selected 700-HF Relay Cat. No. except for the 240V AC units, add (-4L).
Manual Operator and LED Option: Add suffix (-3-4) to the selected 700-HF Relay Cat. No., except for the 240V AC units, add (-3-4L).

32 Rockwell Automation Publication 700-TD552C-EN-P - October 2018

 Relay and Timer Specifications

Accessories - 700-HF Relays

Photo Description Pkg. Qty. Cat. No.
Pre-Printed Identification Tags — contains 10 sheets of pre-printed and blank tags. Each sheet contains 13
sets of the markings CR…9CR, TR…9TR, M…9M, F, R, 1S, and 117 blank tags. Tags are peel-off with sticky 10 700-N40
backing for easy placement on relays.
Blank Identification Tags — contains 10 sheets of blank identification tags for customer specialized printing. 10 700-N41
Each sheet contains 546 blank tags. Tags are peel-off with sticky backing for easy placement on relays.

Screw Terminal Socket — Panel or DIN Rail Mounting 8-blade miniature socket for use with DPDT HF 10 700-HN116
relays.

Screw Terminal Socket — Panel or DIN Rail Mounting, Guarded Terminal Construction
8-blade socket for use with DPDT 700-HF relays. The socket has the ability to use optional plug-in modules (Cat. 10 700-HN262
No. 700-A_ _ accessories, LED, surge suppression, timing modules).

Screw Terminal Socket — Panel or DIN Rail Mounting, Guarded Terminal Construction 10 700-HN139
14-blade socket for use with 4PDT 700-HF relays.

Screw Terminal Socket — Panel or DIN Rail Mounting, Guarded Terminal Construction
14-blade socket for use with 4PDT 700-HF relays. The socket has coil and contact separation and the ability to use 10 700-HN264
optional plug-in modules (Cat. No. 700-A_ _ accessories, LED, surge suppression, timing modules).

DIN (#3) symmetrical hat rail 10 199-DR1

35 x 7.5 x 1 m

Retainer Clip for Cat. Nos. 700-HN103, -HN104 and -HN128 Sockets with 700-HC Relays and Cat. Nos.
700-HN116, 700-HN262 Sockets with 700-HF DPDT Relays§ 10 700-HN114
Secures relay in socket. Order must be for 10 clips or multiples of 10.

Retainer Clip for Cat. Nos. 700-HN139 and -HN264 Sockets with 700-HF 4PDT Relays§ 10 700-HN266
Secures relay in socket. Order must be for 10 clips or multiples of 10.

Rockwell Automation Publication 700-TD552C-EN-P - October 2018 33

Relay and Timer Specifications

Accessories - 700-HF Relays

Photo Description Pkg. Qty. Cat. No.
Diode with LED Surge Suppressor 10 700-ADL1
Voltage Range: 6…24V DC used with sockets that accept plug-in accessory modules.
Diode with LED Surge Suppressor 10 700-ADL2
Voltage Range: 28…60V DC used with sockets that accept plug-in accessory modules.
Diode with LED Surge Suppressor 10 700-ADL3
Voltage Range: 110…220V DC used with sockets that accept plug-in accessory modules.
Varistor with LED Surge Suppressor 10 700-AV1R
Voltage Range: 6…24V AC used with sockets that accept plug-in accessory modules.
Varistor with LED Surge Suppressor
Voltage Range: 110…240V AC used 10 700-AV3R
with sockets that accept plug-in accessory modules.
RC Surge Suppressor
Voltage Range: 6…24V AC/DC used 10 700-AR1
with sockets that accept plug-in accessory modules.
RC Surge Suppressor
Voltage Range: 110…240V AC/DC used 10 700-AR2
with sockets that accept plug-in accessory modules.
Timing Module
On-Delay or One-Shot selectable voltage range: 12…24V AC/DC 700-AT3
used with sockets that accept plug-in accessory modules.
Timing Module
On-Delay or One-Shot selectable voltage range: 110…125V AC 700-AT3A1
used with sockets that accept plug-in accessory modules.
1

Timing Module
On-Delay or One-Shot selectable voltage range: 230…240V AC 700-AT3A2
used with sockets that accept plug-in accessory modules.

Socket, and Retainer Clip Reference

Relay Type Cat. No. Socket Cat. No. Retainer Clip

700-HN116
700-HF32 700-HN114
700-HN262
700-HN139
700-HF34 700-HN266
700-HN264

34 Rockwell Automation Publication 700-TD552C-EN-P - October 2018

 Relay and Timer Specifications

Specifications- 700-HF Relays

Electrical Ratings 700-HF 2 Pole 700-HF 4 Pole
AC 15 @ 700 VA
230V AC AC-1 @ 3000 VA
Inductive V AC
1 Hp @ 240V AC
120V AC 1/2 Hp @ 120V AC
Contacts 12 A @ 30V DC
VDC DC-1 0.5 A @ 110V DC
0.25 A @ 220V DC
AC 12 A @ 250 V AC (per pole)
Resistive
DC 12 A @ 30 V DC (per pole)
AC 80...110% nom voltage
Operating Range
DC 80...110% nom voltage 85...110% nom voltage
AC (50 Hz) 1.5 VA 2 VA
Rated Power
DC 1W 1.3 W
AC 80% nom voltage
Holding Voltage
DC 60% nom voltage
AC 20% nom voltage
Must Drop Out Voltage
DC 10% nom voltage
Insulation Voltage 250V AC
Design Specification/Test Requirements
Pole-to-Pole 2500V AC
Dielectric Withstand Voltage
Contact to Pole 2500V AC
Mechanical
Degree of Protection Open Type (Sockets)
Mechanical Life Operations 20 x 106
Switching Frequency Operations 3600/hr
Coil Voltages See Product Selection
Operating Time at nom voltage at 20 Pickup 8 ms 10 ms
°C Dropout 3 ms 4 ms
Maximum Operating Rate 4 Ops/s
Vibration 15 G
Shock 15 G
Environmental
Operating –40…+70 °C (–40…+268 °F)
Temperature
Storage –50…+80 °C (–89…+176 °F)
Altitude 2000 m (6560 ft)
Construction
Insulating Material Molded High-Dielectric Material
Enclosure Transparent Dust Cover
Contact Material Silver Cad. Oxide
Terminal Markings on Socket In accordance with EN50 0005
Sockets 8-Blade Socket (DPDT) Cat. No. 700-HN116 & 700-HN262, 14-Blade Socket (4PDT) Cat. No. 700-HN139 & 700-HN264
CSA Certified (File No. 229473), UL Recognized (File No. E3125, Guide NLDX2/NLDX8), CE Marked,
Certifications
UL Listed when used with sockets shown above, (File No. E3125, Guide NLDX/NLDX 7), LR Certified, RINA Certified, IMQ Certified
Standards UL 508, CSA 22.2 No. 14, EN-61810-1

Rockwell Automation Publication 700-TD552C-EN-P - October 2018 35

 Relay and Timer Specifications

Dimensions -700-HF Relays

Approximate Dimensions are shown in millimeters (inches). Approximate Dimensions are not intended to be used for manufacturing purposes.

700-HF Relay (DPDT)

700-HF (4PDT)

Cat. No. 199-DR1 DIN Mounting Rail Series B

Cat. No. 199-DR4 DIN Mounting Rail Series B Has No Mounting Holes

Approx.
Cat. No. A B C D
Shipping Wt.
35 27 7.5 1.02 1.85 kg
199-DR1 (1-3/8) (1-1/16) (19/64) (1/64) (4.07 lb) (10/pkg)
35 27 15 2.3 3.68 kg
199-DR4 (1-3/8) (1-1/16) (19/32) (3/32) (8 lb) (5/pkg)

36 Rockwell Automation Publication 700-TD552C-EN-P - October 2018

 Relay and Timer Specifications

Dimensions - 700-HF Relays

Approximate Dimensions are shown in millimeters (inches). Approximate Dimensions are not intended to be used for manufacturing purposes.

Cat. No. 700-HN116

Wire Size: 2 x 2.5 mm2
Single Wire – Up to #12 AWG
Double Wire – 2.5 mm2 (14 … 20 AWG), Qty. 2 wires
(Either Solid or Stranded)
Strip Length: 9 mm (3/8 in.) – Torque: 0.8 N•m (7 lb·in)

Cat. No. 700-HN262

Wire Size: Solid - 1x6/ 2 x 2.5 mm2
1x10 / 2 x 14 AWG
Stranded - 1x4 / 2x2.5 mm2
1x12 / 2x14 AWG
Length: 9 mm (3/8 in.) - Torque: 0.8 N∙m (7 lb. ∙ in.)
300V AC, 12 A, 50 °C

Rockwell Automation Publication 700-TD552C-EN-P - October 2018 37

Relay and Timer Specifications

Cat. No. 700-HN139

Wire Size: 2 x 2.5 mm2
Single Wire – Up to #12 AWG
Double Wire – 2.5 mm2 (14 … 20 AWG), Qty. 2 wires
(Either Solid or Stranded)
Strip Length: 9 mm (3/8 in.) – Torque: 0.8 N•m (7 lb·in)

Cat. No. 700-HN264

Wire Size: Solid - 1x6/ 2 x 2.5 mm2
1x10 / 2x14 AWG
Stranded - 1x4 / 2x2.5 mm2
1x12 / 2x14 AWG
Length: 9 mm (3/8 in.) - Torque: 0.8 N∙m (7 lb. ∙ in.)
300V AC, 10 A, 70 °C

38 Rockwell Automation Publication 700-TD552C-EN-P - October 2018

 100-C/104-C, 100S-C/104S-C, 100Q-C Contactors
Product Selection—100-C/104-C Contactors
• Compact sizes from 4…55 kW/5…75 Hp (9…97 A)
• Common ac5cessories for all contactor sizes
• Front and side mounting of auxiliary contacts
• Electronic and pneumatic timing modules
• Space-saving coil-mounted control modules
• Reversible coil terminations (line or load side) 100-C Contactor 104-C Reversing Contactor
• All devices can be attached to 35 mm DIN mounting Rail
• Environmentally friendly materials
The Bulletin 100-C/104-C IEC contactor family, along with a wide range of common accessories and Bulletin 193 solid-state
overload relays, provides the most compact and flexible starter component system available.
3-Pole AC- and DC-operated Contactors
Ratings for switching AC motors - AC-2, AC-3, AC-4 Auxiliary Contacts
Rated Operational Current Ie [A]
3-phase kW (50 Hz) Hp (60 Hz)
Cat. No.(1)
40 °C 1-Phase 3-Phase
230V 400/415V 500V 690V
AC-3 AC-1 115V 230V 200V 230V 460V 575V N.O. N.C.
1 0 100-C0910
9 32 3 4 4 4 1/2 1-1/12 2 2 5 7-1/12
0 1 100-C0901
1 0 100-C1210
12 32 4 5.5 5.5 5.5 1/2 2 3 3 7-1/2 10
0 1 100-C1201
1 0 100-C1610
16 32 5.5 7.5 7.5 7.5 1 3 5 5 10 15
0 1 100-C1601
1 0 100-C2310
23 32 7.5 11 13 10 2 3 5 7-1/2 15 15
0 1 100-C2301
0 0 100-C3000
30 65 10 15 15 15 2 5 7-1/2 10 20 25 1 0 100-C3010
0 1 100-C3001
0 0 100-C3700
37 65 11 18.5/20 20 18.5 3 5 10 10 25 30 1 0 100-C3710
0 1 100-C3701
0 0 100-C4300
43 85 13 22 25 22 3 7-1/2 10 15 30 30 1 0 100-C4310
0 1 100-C4301
0 0 100-C5500
55 85 15 30 30 30 5 10 15 20 40 40 1 0 100-C5510
0 1 100-C5501
0 0 100-C6000
60 100 18.5 32 37 32 5 10 15 20 40 50 1 0 100-C6010
0 1 100-C6001
0 0 100-C7200
72 100 22 40 45 40 5 15 20 25 50 60 1 0 100-C7210
0 1 100-C7201
0 0 100-C8500
85 100 25 45 55 45 7-1/2 15 25 30 60 60 1 0 100-C8510
0 1 100-C8501
0 0 100-C9700
97 130 30 55 55 55 10 20 30 30 75 75 1 0 100-C9710
0 1 100-C9701
(1) For screwlesss terminals on 100-C09…C16, add an “R” after the letter “C” in the catalog number. Example: Cat. No. 100-C0910 becomes 100-CR0910. The AC-1 rating for the 100-CR is limited to 25 A.
Coil voltage code and terminal position—see page 24

Rockwell Automation Publication 100-TD013G-EN-P - August 2018 21

100-C/104-C, 100S-C/104S-C, 100Q-C Contactors

4-Pole AC- and DC-Operated Contactors

Contact Configuration, Main
Rated Operational Ratings for switching AC motors - AC-2, AC-3
Poles
Current Ie [A]
3-phase kW (50 Hz)(2) Hp (60 Hz) Cat. No.(1)
40 °C 1-Phase 3-Phase*
230V 400/415V 500V 690V
AC-3 AC-1 115V 230V 200V 230V 460V 575V N.O. N.C.
4 0 100-C09400
9 32 3 4 4 4 1/2 1-1/2 2 2 5 7-1/2 3 1 100-C09300
2 2 100-C09200
4 0 100-C12400
12 32 4 5.5 5.5 5.5 1/2 2 3 3 7-1/2 10 3 1 100-C12300
2 2 100-C12200
4 0 100-C16400
16 32 5.5 7.5 7.5 7.5 1 3 5 5 10 10 3 1 100-C16300
2 2 100-C16200
4 0 100-C23400
23 32 7.5 11 13 10 2 3 5 7-1/2 15 15 3 1 100-C23300
2 2 100-C23200
4 0 100-C40400
37 75 11 18.5/20 20 18.5 3 5 10 10 25 30
2 2 100-C40200
4 0 100-C90400
85 130 25 45 55 45 7-1/2 15 25 30 60 50
2 2 100-C90200
(1) For screwlesss terminals on 100-C09…C16, add an “R” after the letter “C” in the catalog number. Example: Cat. No. 100-C0910 becomes 100-CR0910. The AC-1 rating for the 100-CR is limited to 25 A.
(2) Three-phase ratings apply only to contactors with at least three N.O. power poles.

Coil voltage code and terminal position— see page 24.

22 Rockwell Automation Publication 100-TD013G-EN-P - August 2018

 100-C/104-C, 100S-C/104S-C, 100Q-C Contactors

Reversing AC- and DC-Operated Contactors

Auxiliary Contacts per

Ratings for switching AC motors - AC-2, AC-3, AC-4
Rated Operational Current Ie [A] Contactor
3-phase kW (50 Hz) Hp (60 Hz) Cat. No.
40 °C 1-Phase 3-Phase
230V 400/415V 500V 690V
AC-3 AC-1 115V 230V 200V 230V 460V 575V N.O. N.C. (1)
9 32 3 4 4 4 1/2 1-1/2 2 2 5 7-1/2 1 1 104-C0922
12 32 4 5.5 5.5 5.5 1 2 3 3 7-1/2 10 1 1 104-C1222
16 32 5.5 7.5 7.5 7.5 1 3 5 5 10 15 1 1 104-C1622
23 32 7.5 11 13 10 2 3 5 7-1/2 15 20 1 1 104-C2322
0 1 104-C3002
30 65 10 15 15 15 2 5 7-1/2 10 20 25
1 1 104-C3022
0 1 104-C3702
37 65 11 18.5/20 20 18.5 3 5 10 10 25 30
1 1 104-C3722
0 1 104-C4302
43 85 13 22 25 22 3 7.5 10 15 30 30
1 1 104-C4322
0 1 104-C5502
55 85 15 30 30 30 5 10 15 20 40 40
1 1 104-C5522
0 1 104-C6002
60 100 18.5 32 37 32 5 10 15 20 40 50
1 1 104-C6022
0 1 104-C7202
72 100 22 40 45 40 5 15 20 25 50 60
1 1 104-C7222
0 1 104-C8502
85 100 25 45 55 45 7-1/2 15 25 30 60 60
1 1 104-C8522
0 1 104-C9702
97 130 30 55 55 55 10 15 30 30 75 75
1 1 104-C9722
(1) The N.C. auxiliary contact is supplied as part of the mechanical/electrical interlock.
Coil voltage code and terminal position— see page 24.

Rockwell Automation Publication 100-TD013G-EN-P - August 2018 23

100-C/104-C, 100S-C/104S-C, 100Q-C Contactors

Coil Voltage Codes

The Cat. No. as listed is incomplete. Select a coil voltage code from the table below to complete the Cat. No. Example: 120V,
60 Hz: Cat. No. 100-C0910 becomes Cat. No.100-C09D10.

100… 200… 208…

AC Voltages [V] 12 24 32 36 42 48 100 110 120 127 200 208
110 220 240
50 Hz R K V W X Y KP — D P S KG L — —
60 Hz Q J — V — X — KP — D — — KG H L
50/60 Hz — KJ — — — KY KP — KD — — KG KL(1) — —
(1) Not available on 100/104-C90 or -C97 contactors.

220… 230… 380… 400…

AC Voltages [V] 230 240 277 347 380 400 440 480 500 550 600
230 240 400 415
50 Hz F — VA T — — — N — G B — M C —
60 Hz — — — A T I E — — — N B — — C
50/60 Hz KL(1) KF — KA — — — — KN — KB — — — —
(1) Not available on 100/104-C90 or -C97 contactors.

DC Voltages [V] 9 12 24 24 36 36…48 48 48…72 60 64

Electronic with
100-C09…C55 — EQ EJ QJ(1) — EW — EY — —
Integrated Diode
100-C60…C97 with Integrated Diode DR DQ DJ — DW — DY — DZ DB
(1) “QJ” coil has faster dropout time (16…21 ms).

DC Voltages [V] 72 80 110 110…125 115 125 220 220…250 230 250
Electronic with
100-C09…C55 — — — ED — — — EA — —
Integrated Diode
100-C60…C97 with Integrated Diode DG DE DD — DP DS DA — DF DT

Coil Terminal Position

All contactors are delivered with the coil terminals located on the line side.

For load side coil terminations, insert a “U” prior to the coil voltage code. Ordering example: Cat. No. 100-C09UD10.

Cat. No.100-C0910 Line Side Cat. No.100-C09U10 Load Side

24 Rockwell Automation Publication 100-TD013G-EN-P - August 2018

 100-C/104-C, 100S-C/104S-C, 100Q-C Contactors

Assignment of Contacts
Table valid for: AC / DC = 0.85…1.1 x Us, Tamb = -25 °C…+60 °C, normal position (horizontal rail mounting)

Device Combinations in Accordance with IEC 60947-1 / -4-1

Auxiliary Contact Blocks 100-C Contactors (AC and DC Control)
100-C30_00
100-C37_00
100-C43_00 100-C09_400 100-C09_200
100-C55_00 100-C12_400 100-C12_200
100-C09_10 100-C09_01 100-C60_00 100-C16_400 100-C09_300 100-C16_200
100-C12_10 100-C12_01 100-C72_00 100-C23_400 100-C12_300 100-C23_200
Circuit Diagram Control
100-C16_10 100-C16_01 100-C85_00 100-C40_400 100-C16_300 100-C40_200
100-C23_10 100-C23_01 100-C97_00 100-C90_400 100-C23_300 100-C90_200
A1 1 3 5 13 A1 1 3 5 21 A1 1 3 5 A1 1 3 5 7 A1 1 3 5 R7 A1 1 R3 R5 7
K1 K1 K1 K1 K1 K1
A2 2 4 6 14 A2 2 4 6 22 A2 2 4 6 A2 2 4 6 8 A2 2 4 6 R8 A2 2 R4 R6 8
(1)
Side Mounting
21

01 + 01 = 02 (3)
32
100-SB01 AC/DC 10 + 01 = 11 00 + 01 = 01 00 + 01 = 01 00 + 01 = 01 00 + 01 = 01
22
31

13

10 + 10 = 20 (3)
44
100-SB10 AC/DC 01 + 10 = 11 00 + 10 = 10 00 + 10 = 10 00 + 10 = 10 00 + 10 = 10
14
43

11 21

10 + 02 = 12 (3)
32 42
100-SB02 AC/DC — 00 + 02 = 02 00 + 02 = 02 00 + 02 = 02 00 + 02 = 02
12 22
31 41

13 21

10 + 11 = 21 (3) 01 + 11 = 12 (3)
32 44

100-SB11 AC/DC 00 + 11 = 11 00 + 11 = 11 00 + 11 = 11 00 + 11 = 11
14 22
31 43

13 23

10 + 20 = 30 (3) 01 + 20 = 21 (3)
34 44
100-SB20 AC/DC 00 + 20 = 20 00 + 20 = 20 00 + 20 = 20 00 + 20 = 20
14 24
33 43

17 25
36 48

100-SBL11 (2) AC/DC 10 + L11 = L21 (3) 01 + L11 = L12 (3) 00 + L11 = L11 00 + L11 = L11 00 + L11 = L11 00 + L11 = L11
18 26
35 47

(1) Up to 8 auxiliary contacts possible: contactor + front mounted (AC max. 4 N.C. / DC max. 4 N.C.), side mounted (AC max. 2 N.O. / DC max. 2 N.O. and max. 2 N.C.).
(2) Early make and/or late break.
(3) Double numbering: because of double numbering only left-side mounting is recommended.

Rockwell Automation Publication 100-TD013G-EN-P - August 2018 25

100-C/104-C, 100S-C/104S-C, 100Q-C Contactors

Device Combinations in Accordance with IEC 60947-1 / -4-1

Auxiliary Contact Blocks 100-C Contactors (AC and DC Control)

100-C30_00
100-C37_00
100-C43_00 100-C09_400 100-C09_200
100-C55_00 100-C12_400 100-C12_200
100-C09_10 100-C09_01 100-C60_00 100-C16_400 100-C09_300 100-C16_200
100-C12_10 100-C12_01 100-C72_00 100-C23_400 100-C12_300 100-C23_200
Circuit Diagram Control
100-C16_10 100-C16_01 100-C85_00 100-C40_400 100-C16_300 100-C40_200
100-C23_10 100-C23_01 100-C97_00 100-C90_400 100-C23_300 100-C90_200
A1 1 3 5 13 A1 1 3 5 21 A1 1 3 5 A1 1 3 5 7 A1 1 3 5 R7 A1 1 R3 R5 7
K1 K1 K1 K1 K1 K1
A2 2 4 6 14 A2 2 4 6 22 A2 2 4 6 A2 2 4 6 8 A2 2 4 6 R8 A2 2 R4 R6 8

Front Mounting (1)

51 61
100-FA02,
AC/DC 10 + 02 = 12 01 + 02 = 03 00 + 02 = 02 00 + 02 = 02 00 + 02 = 02 00 + 02 = 02
100-FAB02
52 62

53 61
100-FA11,
AC/DC 10 + 11 = 21 01 + 11 = 12 00 + 11 = 11 00 + 11 = 11 00 + 11 = 11 00 + 11 = 11
100-FAB11
54 62

13 21
100-FB11,
AC/DC — — 00 + 11 = 11 00 + 11 = 11 00 + 11 = 11 00 + 11 = 11
100-FBB11
14 22

23 31
100-FC11,
AC/DC 10 + 11 = 21 — — — — —
100-FCB11
24 32

100-FA20, 53 63
AC/DC 10 + 20 = 30 01 + 20 = 21 00 + 20 = 20 00 + 20 = 20 00 + 20 = 20 00 + 20 = 20
100-FAB20
54 64

17 25
100-FBL11 (2) AC/DC — — 00 + L11 = L11 00 + L11 = L11 00 + L11 = L11 00 + L11 = L11
18 26

53 61 71 83
100-FA22,
AC/DC 10 + 22 = 32 01 + 22 = 23 00 + 22 = 22 00 + 22 = 22 00 + 22 = 22 00 + 22 = 22
100-FAB22
54 62 72 84

13 21 31 43
100-FB22,
AC/DC — — 00 + 22 = 22 00 + 22 = 22 00 + 22 = 22 00 + 22 = 22
100-FBB22
14 22 32 44

21 31 43 53
100-FC22,
AC/DC 10 + 22 = 32 — — — — —
100-FCB22
22 32 44 54

53 61 73 83
100-FA31,
AC/DC 10 + 31 = 41 01 + 31 = 32 00 + 31 = 31 00 + 31 = 31 00 + 31 = 31 00 + 31 = 31
100-FAB31
54 62 74 84

100-FA40, 53 63 73 83
AC/DC 10 + 40 = 50 01 + 40 = 41 00 + 40 = 40 00 + 40 = 40 00 + 40 = 40 00 + 40 = 40
100-FAB40
54 64 74 84

53 61 75 87
100-FAL22 (2) AC/DC 10 + L22 = L32 01 + L22 = L23 00 + L22 = L22 00 + L22 = L22 00 + L22 = L22 00 + L22 = L22
54 62 76 88

51 61 71 81
100-FA04,
AC/DC 10 + 04 = 14 01 + 04 = 05 00 + 04 = 04 00 + 04 = 04 00 + 04 = 04 00 + 04 = 04
100-FAB04
52 62 72 82

26 Rockwell Automation Publication 100-TD013G-EN-P - August 2018

 1489-M Circuit Breakers

Dual terminals provide

wiring/bus bar flexibility Terminal design helps
and clamp from both sides to prevent wiring misses
improve connection reliability

Scratch and solvent

resistant printing
Suitable for DIN
Rail mounting

Accepts right-mounted
shunt trips, auxiliary
Indicator window and signal contacts
reflects contact state
red: closed, green: open
IP20 finger-safe design
(all sides)

Bulletin 1489-M thermal magnetic Circuit Breakers are approved for branch circuit
protection in the United States and Canada, and are certified as Miniature Circuit Breakers
for IEC applications.

These branch protectors are compatible with many accessories to meet diverse 1489-M Circuit Breakers
application needs, including UL 508 Listed bus bars for convenience in panel assembly, Rated Voltage UL/CSA: Max. 480Y/277V AC
auxiliary contacts, signal contacts and shunt trips for versatility, and lock out attachments IEC: Ue 230/400V AC
for safety during maintenance.
Interrupting UL/CSA: 10 kA
Capacity IEC: 15 kA
Features Current Ratings 0.5...63 A
 Current limiting Poles 1, 2, 3
 Fast breaking time Trip Curves C, D
 High rated voltage
UL 489
 Superior shock and vibration resistance to help prevent nuisance tripping
Standards CSA C22.2 No. 5.1
 Dual terminals allow the connection of two wires, or both a wire and bus bar (self
Compliance EN 60947-2
declared)
 Terminal design helps prevent wiring misses by directing wires into the terminal GB 14048.2
openings, even while tightening UL Listed, File No. E197878
 Reversible line and load connections CSA Certified
 Single and multi-pole toggle mount lock out attachments available for Lock Out Tag CE Marked
Certifications
Out (LOTO) VDE Certified
 RoHS compliant and fully-recyclable device CCC Certified
 Suitable for extreme ambient conditions RoHS Compliant

Rockwell Automation Publication 1492-SG122B-EN-P — January 2014 5

1489-M Circuit Breakers

Catalog Number Explanation

Note: Examples given in this section are for reference purposes. This basic explanation should not be used for product selection; some combinations may not produce a valid catalog number.

1489 - M 1 C 005
a b c d

a b d
Voltage Type Poles Rated Current (In)
Code Description Code Description Code Current [A]
M AC Circuit Breaker 1 1-Pole 005 0.5
2 2-Pole 010 1
3 3-Pole 016 1.6
020 2
030 3

c 040 4
050 5
Trip Curve
060 6
Code Trip Curve
070 7
C Trip Curve C
080 8
D Trip Curve D
100 10
130 13
150 15
160 16
200 20
250 25
300 30
320 32
350 35
400 40
500 50
600 60
630 63

6 Rockwell Automation Publication 1492-SG122B-EN-P — January 2014

[Link]

Fuse modular terminal block - UK 10,3-HESI N - 3048386

Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
([Link]

Fuse modular terminal block, fuse type: Ceramic, fuse type: 10:3 x 38 mm, nom. voltage: 690 V, nominal current:
32 A, connection method: Screw connection, Rated cross section: 16 mm², cross section:  1.5 mm²- 25 mm²,
mounting type: NS 35/7,5, NS 35/15, color: black

Your advantages
 Fuse holder for fuses up to 690 V AC
 For 10 x 38 fuse-links in accordance with IEC 60269-2
 Easy to bridge

Key Commercial Data

Packing unit 1 pc
Minimum order quantity 10 pc

GTIN

GTIN 4017918976293
Weight per Piece (excluding packing) 52.000 g
Custom tariff number 85369095
Country of origin Germany

Technical data
General
Number of rows 1
Number of connections 2
Nominal cross section 16 mm²
Color black
Flammability rating according to UL 94 V2

11/16/2021   Page 1 / 4
[Link]

Fuse modular terminal block - UK 10,3-HESI N - 3048386

Technical data
General
Maximum power dissipation for nominal condition 2.43 W
Rated surge voltage 6 kV
Degree of pollution 3
Overvoltage category III
Insulating material group III a
Connection in acc. with standard IEC 60947-1 / -3
Maximum load current 32 A (the current and voltage are determined by the fuse)
Nominal current IN 32 A (the current and voltage are determined by the fuse)
Nominal voltage UN 690 V AC (the current and voltage are determined by the fuse)
Fuse 10:3 x 38 mm
Fuse type Ceramic
Open side panel No
Shock protection test specification DIN EN 50274 (VDE 0660-514):2002-11
Back of the hand protection guaranteed
Finger protection guaranteed
Note Swing the locking lever to its final position before replacing the fuse.
Result of surge voltage test Test passed
Result of power-frequency withstand voltage test Test passed
Result of tight fit on support Test passed
Contact resistance Test passed
Result of the test for mechanical stability of terminal points (5 x conductor
Test passed
connection)
Result of flexion and pull-out test Test passed
Bending test rotation speed 10 rpm
Bending test turns 135
Bending test conductor cross section/weight 1.5 mm² / 0.4 kg
16 mm² / 2.9 kg
25 mm² / 4.5 kg
Result of thermal test Test passed
Relative insulation material temperature index (Elec., UL 746 B) 125 °C

Dimensions
Width 18 mm
Length 81 mm
Height NS 35/7,5 65.5 mm
Height NS 35/15 73 mm

Connection data
Conductor cross section solid min. 1.5 mm²
11/16/2021   Page 2 / 4
[Link]

Fuse modular terminal block - UK 10,3-HESI N - 3048386

Technical data
Connection data
Conductor cross section solid max. 25 mm²
Conductor cross section flexible min. 1.5 mm²
Conductor cross section flexible max. 16 mm²
Conductor cross section AWG min. 16
Conductor cross section AWG max. 4
Conductor cross section flexible, with ferrule without plastic sleeve min. 1.5 mm²
Conductor cross section flexible, with ferrule without plastic sleeve max. 16 mm²
Conductor cross section flexible, with ferrule with plastic sleeve min. 1.5 mm²
Conductor cross section flexible, with ferrule with plastic sleeve max. 16 mm²
Cross section with insertion bridge, solid max. 10 mm²
Cross section with insertion bridge, stranded max. 10 mm²
2 conductors with same cross section, solid min. 1.5 mm²
2 conductors with same cross section, solid max. 4 mm²
2 conductors with same cross section, stranded min. 1.5 mm²
2 conductors with same cross section, stranded max. 4 mm²
Two conductors with the same cross section stranded, with ferrule and
1.5 mm²
without plastic sleeve, minimum
Two conductors with the same cross section stranded, with ferrule and
4 mm²
without plastic sleeve, maximum
Two conductors with the same cross section, flexible, with TWIN ferrules,
1.5 mm²
with plastic sleeve, minimum
Two conductors with the same cross section, flexible, with TWIN ferrules,
10 mm²
with plastic sleeve, maximum
Cross section with insertion bridge, solid max. 10 mm²
Cross section with insertion bridge, stranded max. 10 mm²
Connection method Screw connection
Stripping length 11 mm
Internal cylindrical gage A7
Screw thread M5
Tightening torque, min 2 Nm
Tightening torque max 2.5 Nm

Ambient conditions
Operating temperature -60 °C ... 85 °C
Ambient temperature (storage/transport) -25 °C ... 55 °C (for a short time, not exceeding 24 h, -60 °C to +70 °C)
Permissible humidity (storage/transport) 30 % ... 70 %
Ambient temperature (assembly) -5 °C ... 70 °C
Ambient temperature (actuation) -5 °C ... 70 °C

Standards and Regulations

11/16/2021   Page 3 / 4
[Link]

Fuse modular terminal block - UK 10,3-HESI N - 3048386

Technical data
Standards and Regulations
Connection in acc. with standard CSA
IEC 60947-1 / -3

Environmental Product Compliance

China RoHS Environmentally friendly use period: unlimited = EFUP-e
No hazardous substances above threshold values

Phoenix Contact 2021 © - all rights reserved

[Link]

11/16/2021   Page 4 / 4
[Link]

Fuse modular terminal block - UT 4-HESILED 24 (5X20) - 3046090

Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
([Link]

Lever-type fuse terminal block, black, for 5 x 20 mm G fuse inserts, with LED for 24 V AC/DC

Your advantages
 An extremely compact design
 Test connection on both sides in safety lever
 Tested for railway applications

Key Commercial Data

Packing unit 1 pc
Minimum order quantity 50 pc

GTIN

GTIN 4017918956585
Weight per Piece (excluding packing) 18.420 g
Custom tariff number 85369095
Country of origin Germany

Technical data
General
The current is determined by the fuse used, the voltage by the selected
Note LED.
If the fuse is faulty, the downstream circuit will not be disconnected.
Number of rows 1
Number of connections 2
Nominal cross section 4 mm²

11/06/2021   Page 1 / 7
[Link]

Fuse modular terminal block - UT 4-HESILED 24 (5X20) - 3046090

Technical data
General
Color black
Insulating material PA
Flammability rating according to UL 94 V0
Area of application Railway industry
Machine building
Plant engineering
Maximum power dissipation for nominal condition 1.02 W
Rated surge voltage 6 kV
Degree of pollution 3
Overvoltage category III
Insulating material group I
max. 1.6 W (with single arrangement of the fuse terminal block in the event
Maximum power dissipation
of overload)
max. 1.6 W (With interconnected arrangement of several fuse terminal
blocks in the event of overload)
max. 4 W (with single arrangement of the fuse terminal block in the event
of a short-circuit)
max. 2.5 W (With interconnected arrangement of several fuse terminal
blocks in the event of a short-circuit)
LED voltage range 12 V AC/DC ... 30 V AC/DC
LED current range 0.31 mA ... 0.95 mA
Connection in acc. with standard IEC 60947-7-3
Maximum load current 6.3 A (the current is determined by the fuse used)
Nominal current IN 6.3 A
Nominal voltage UN 24 V
Fuse G / 5 x 20
Fuse type Glass / ceramics / ...
Open side panel No
Relative insulation material temperature index (Elec., UL 746 B) 130 °C
Temperature index of insulation material (DIN EN 60216-1 (VDE 0304-21)) 125 °C
Static insulating material application in cold -60 °C
Surface flammability NFPA 130 (ASTM E 162) passed
Specific optical density of smoke NFPA 130 (ASTM E 662) passed
Smoke gas toxicity NFPA 130 (SMP 800C) passed
Calorimetric heat release NFPA 130 (ASTM E 1354) 27,5 MJ/kg
Fire protection for rail vehicles (DIN EN 45545-2) R22 HL 1 - HL 3
Fire protection for rail vehicles (DIN EN 45545-2) R23 HL 1 - HL 3
Fire protection for rail vehicles (DIN EN 45545-2) R24 HL 1 - HL 3

11/06/2021   Page 2 / 7
[Link]

Fuse modular terminal block - UT 4-HESILED 24 (5X20) - 3046090

Technical data
General
Fire protection for rail vehicles (DIN EN 45545-2) R26 HL 1 - HL 3

Dimensions
Width 6.2 mm
Length 57.8 mm
Height NS 35/7,5 75.6 mm
Height NS 35/15 83.1 mm

Connection data
Conductor cross section solid min. 0.14 mm²
Conductor cross section solid max. 6 mm²
Conductor cross section flexible min. 0.14 mm²
Conductor cross section flexible max. 6 mm²
Conductor cross section AWG min. 26
Conductor cross section AWG max. 10
Conductor cross section flexible, with ferrule without plastic sleeve min. 0.14 mm²
Conductor cross section flexible, with ferrule without plastic sleeve max. 4 mm²
Conductor cross section flexible, with ferrule with plastic sleeve min. 0.14 mm²
Conductor cross section flexible, with ferrule with plastic sleeve max. 4 mm²
2 conductors with same cross section, solid min. 0.14 mm²
2 conductors with same cross section, solid max. 1.5 mm²
2 conductors with same cross section, stranded min. 0.14 mm²
2 conductors with same cross section, stranded max. 1.5 mm²
Two conductors with the same cross section stranded, with ferrule and
0.14 mm²
without plastic sleeve, minimum
Two conductors with the same cross section stranded, with ferrule and
1.5 mm²
without plastic sleeve, maximum
Two conductors with the same cross section, flexible, with TWIN ferrules,
0.5 mm²
with plastic sleeve, minimum
Two conductors with the same cross section, flexible, with TWIN ferrules,
2.5 mm²
with plastic sleeve, maximum
Connection method Screw connection
Stripping length 9 mm
Internal cylindrical gage A4
Screw thread M3
Tightening torque, min 0.6 Nm
Tightening torque max 0.8 Nm

Ambient conditions
Operating temperature -60 °C ... 105 °C (max. short-term operating temperature RTI Elec.)

11/06/2021   Page 3 / 7
[Link]

Fuse modular terminal block - UT 4-HESILED 24 (5X20) - 3046090

Technical data
Ambient conditions
Ambient temperature (storage/transport) -25 °C ... 60 °C (for a short time, not exceeding 24 h, -60 °C to +70 °C)
Permissible humidity (storage/transport) 30 % ... 70 %
Ambient temperature (assembly) -5 °C ... 70 °C
Ambient temperature (actuation) -5 °C ... 70 °C

Standards and Regulations

Connection in acc. with standard CSA
IEC 60947-7-3

Environmental Product Compliance

REACh SVHC Lead 7439-92-1
China RoHS Environmentally Friendly Use Period = 50 years
For details about hazardous substances go to tab “Downloads”, Category
“Manufacturer's declaration”

Drawings

Circuit diagram

Classifications
eCl@ss

eCl@ss 10.0.1 27141116

eCl@ss 11.0 27141116
eCl@ss 4.0 27141100
eCl@ss 4.1 27141100
eCl@ss 5.0 27141100
eCl@ss 5.1 27141100
eCl@ss 6.0 27141100
eCl@ss 7.0 27141116
eCl@ss 9.0 27141116

ETIM

ETIM 2.0 EC000897

ETIM 3.0 EC000899
ETIM 4.0 EC000899
ETIM 6.0 EC000899
ETIM 7.0 EC000899
11/06/2021   Page 4 / 7
[Link]

Fuse modular terminal block - UT 4-HESILED 24 (5X20) - 3046090

Classifications
UNSPSC

UNSPSC 6.01 30211811

UNSPSC 7.0901 39121410
UNSPSC 11 39121410
UNSPSC 12.01 39121410
UNSPSC 13.2 39121410
UNSPSC 18.0 39121410
UNSPSC 19.0 39121410
UNSPSC 20.0 39121410
UNSPSC 21.0 39121410

Approvals
Approvals

Approvals

CSA / PRS / KEMA-KEUR / EAC / RS / CSA / DNV GL / IECEE CB Scheme / LR / cULus Recognized

Ex Approvals

Approval details

CSA
  [Link]  13631

PRS
  [Link]  TE/2156/880590/17

KEMA-KEUR
  [Link]  71-113330


Nominal voltage UN 500 V
Nominal current IN 6.3 A
mm²/AWG/kcmil 0.14-4

11/06/2021   Page 5 / 7
[Link]

Fuse modular terminal block - UT 4-HESILED 24 (5X20) - 3046090

Approvals


 RU C-
EAC
DE.BL08.B.00534

RS
  [Link]  17.00013.272

CSA
  [Link]  13631

  B C
Nominal voltage UN 24 V 24 V
Nominal current IN 6.3 A 6.3 A
mm²/AWG/kcmil 26-10 26-10

DNV GL
  [Link]  TAE00001S9

IECEE CB Scheme
  [Link]  NL-65056


Nominal voltage UN 500 V
Nominal current IN 6.3 A
mm²/AWG/kcmil 0.14-4

LR
  [Link]  LR2003762TA

cULus Recognized
  [Link]  E60425

  B C
Nominal voltage UN 600 V 600 V
Nominal current IN 10 A 10 A

11/06/2021   Page 6 / 7
[Link]

Fuse modular terminal block - UT 4-HESILED 24 (5X20) - 3046090

Approvals
  B C
mm²/AWG/kcmil 26-10 26-10

Phoenix Contact 2021 © - all rights reserved

[Link]

11/06/2021   Page 7 / 7
[Link]

Feed-through terminal block - UT 4 - 3044102

Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
([Link]

Feed-through terminal block, nom. voltage: 1000 V, nominal current: 32 A, connection method: Screw connection,
Rated cross section: 4 mm², cross section: 0.14 mm² - 6 mm², mounting type: NS 35/7,5, NS 35/15, color: gray

Your advantages
 The large wiring space enables the connection of solid and stranded conductors without ferrules, even above the nominal cross section
 As well as saving space, the compact design enables user-friendly wiring in a small amount of space
 Optimum screwdriver guidance through closed screw shafts
 The cable entry funnel enables the use of conductors with ferrules and plastic collars within the nominal cross section
 Tested for railway applications

Key Commercial Data

Packing unit 1 pc
Minimum order quantity 50 pc

GTIN

GTIN 4017918960391
Weight per Piece (excluding packing) 9.600 g
Custom tariff number 85369010
Country of origin Germany

Technical data
General
Number of rows 1
Number of connections 2
Potentials 1
Nominal cross section 4 mm²
11/06/2021   Page 1 / 8
[Link]

Feed-through terminal block - UT 4 - 3044102

Technical data
General
Color gray
Insulating material PA
Flammability rating according to UL 94 V0
Area of application Railway industry
Machine building
Plant engineering
Process industry
Mounting type NS 35/7,5
Rated surge voltage 8 kV
Degree of pollution 3
Overvoltage category III
Insulating material group I
Maximum power dissipation for nominal condition 1.02 W
Maximum load current 41 A (with 6 mm² conductor cross section)
Nominal current IN 32 A (with 4 mm² conductor cross section)
Nominal voltage UN 1000 V
Open side panel Yes
Shock protection test specification DIN EN 50274 (VDE 0660-514):2002-11
Back of the hand protection guaranteed
Finger protection guaranteed
Result of surge voltage test Test passed
Result of power-frequency withstand voltage test Test passed
Power frequency withstand voltage setpoint 2.2 kV
Result of the test for mechanical stability of terminal points (5 x conductor
Test passed
connection)
Result of flexion and pull-out test Test passed
Bending test rotation speed 10 rpm
Bending test turns 135
Bending test conductor cross section/weight 0.14 mm² / 0.2 kg
4 mm² / 0.9 kg
6 mm² / 1.4 kg
Tensile test result Test passed
Result of tight fit on support Test passed
Tight fit on carrier NS 35
Setpoint 1N
Result of voltage-drop test Test passed
Result of temperature-rise test Test passed

11/06/2021   Page 2 / 8
[Link]

Feed-through terminal block - UT 4 - 3044102

Technical data
General
Requirement temperature-rise test Increase in temperature ≤ 45 K
Short circuit stability result Test passed
Conductor cross section short circuit testing 4 mm²
Short-time current 0.48 kA
Conductor cross section short circuit testing 6 mm²
Short-time current 0.72 kA
Result of thermal test Test passed
Proof of thermal characteristics (needle flame) effective duration 30 s
Oscillation, broadband noise test result Test passed
Test specification, oscillation, broadband noise DIN EN 50155 (VDE 0115-200):2008-03
Test spectrum Service life test category 1, class B, body mounted
Test frequency f1 = 5 Hz to f2 = 150 Hz
ASD level 1.857 (m/s²)²/Hz
Acceleration 0.8g
Test duration per axis 5h
Test directions X-, Y- and Z-axis
Shock test result Test passed
Test specification, shock test DIN EN 50155 (VDE 0115-200):2008-03
Shock form Half-sine
Acceleration 5g
Shock duration 30 ms
Number of shocks per direction 3
Test directions X-, Y- and Z-axis (pos. and neg.)
Relative insulation material temperature index (Elec., UL 746 B) 130 °C
Temperature index of insulation material (DIN EN 60216-1 (VDE 0304-21)) 125 °C
Static insulating material application in cold -60 °C
Surface flammability NFPA 130 (ASTM E 162) passed
Specific optical density of smoke NFPA 130 (ASTM E 662) passed
Calorimetric heat release NFPA 130 (ASTM E 1354) 27,5 MJ/kg
Smoke gas toxicity NFPA 130 (SMP 800C) passed
Fire protection for rail vehicles (DIN EN 45545-2) R22 HL 1 - HL 3
Fire protection for rail vehicles (DIN EN 45545-2) R23 HL 1 - HL 3
Fire protection for rail vehicles (DIN EN 45545-2) R24 HL 1 - HL 3
Fire protection for rail vehicles (DIN EN 45545-2) R26 HL 1 - HL 3

Dimensions
Width 6.2 mm
End cover width 2.2 mm
11/06/2021   Page 3 / 8
[Link]

Feed-through terminal block - UT 4 - 3044102

Technical data
Dimensions
Length 47.7 mm
Height 46.9 mm
Height NS 35/7,5 47.5 mm
Height NS 35/15 55 mm

Connection data
Connection method Screw connection
Screw thread M3
Stripping length 9 mm
Tightening torque, min 0.6 Nm
Tightening torque max 0.8 Nm
Connection in acc. with standard IEC 60947-7-1
Note: Product releases, connection cross sections and notes on
Note
connecting aluminum cables can be found in the download area.
Conductor cross section solid min. 0.14 mm²
Conductor cross section solid max. 6 mm²
Conductor cross section AWG min. 26
Conductor cross section AWG max. 10
Conductor cross section flexible min. 0.14 mm²
Conductor cross section flexible max. 6 mm²
Min. AWG conductor cross section, flexible 26
Max. AWG conductor cross section, flexible 10
Conductor cross section flexible, with ferrule without plastic sleeve min. 0.14 mm²
Conductor cross section flexible, with ferrule without plastic sleeve max. 4 mm²
Conductor cross section flexible, with ferrule with plastic sleeve min. 0.14 mm²
Conductor cross section flexible, with ferrule with plastic sleeve max. 4 mm²
2 conductors with same cross section, solid min. 0.14 mm²
2 conductors with same cross section, solid max. 1.5 mm²
2 conductors with same cross section, stranded min. 0.14 mm²
2 conductors with same cross section, stranded max. 1.5 mm²
Two conductors with the same cross section, flexible, with TWIN ferrules,
0.5 mm²
with plastic sleeve, minimum
Two conductors with the same cross section, flexible, with TWIN ferrules,
2.5 mm²
with plastic sleeve, maximum
Two conductors with the same cross section stranded, with ferrule and
0.14 mm²
without plastic sleeve, minimum
Two conductors with the same cross section stranded, with ferrule and
1.5 mm²
without plastic sleeve, maximum
Internal cylindrical gage A4

11/06/2021   Page 4 / 8
[Link]

Feed-through terminal block - UT 4 - 3044102

Technical data
Ambient conditions
Operating temperature -60 °C ... 105 °C (max. short-term operating temperature RTI Elec.)
Ambient temperature (storage/transport) -25 °C ... 60 °C (for a short time, not exceeding 24 h, -60 °C to +70 °C)
Permissible humidity (storage/transport) 30 % ... 70 %
Ambient temperature (assembly) -5 °C ... 70 °C
Ambient temperature (actuation) -5 °C ... 70 °C

Standards and Regulations

Connection in acc. with standard CSA
IEC 60947-7-1

Environmental Product Compliance

REACh SVHC Lead 7439-92-1
China RoHS Environmentally Friendly Use Period = 50 years
For details about hazardous substances go to tab “Downloads”, Category
“Manufacturer's declaration”

Drawings

Circuit diagram

Classifications
eCl@ss

eCl@ss 10.0.1 27141120

eCl@ss 11.0 27141120
eCl@ss 4.0 27141100
eCl@ss 4.1 27141100
eCl@ss 5.0 27141100
eCl@ss 5.1 27141100
eCl@ss 6.0 27141100
eCl@ss 7.0 27141120
eCl@ss 9.0 27141120

ETIM

ETIM 2.0 EC000897

ETIM 3.0 EC000897
ETIM 4.0 EC000897

11/06/2021   Page 5 / 8
[Link]

Feed-through terminal block - UT 4 - 3044102

Classifications
ETIM
ETIM 6.0 EC000897
ETIM 7.0 EC000897

UNSPSC

UNSPSC 6.01 30211811

UNSPSC 7.0901 39121410
UNSPSC 11 39121410
UNSPSC 12.01 39121410
UNSPSC 13.2 39121410
UNSPSC 18.0 39121410
UNSPSC 19.0 39121410
UNSPSC 20.0 39121410
UNSPSC 21.0 39121410

Approvals
Approvals

Approvals

DNV GL / CSA / PRS / IECEE CB Scheme / EAC / RS / LR / VDE Zeichengenehmigung / cULus Recognized

Ex Approvals

IECEx / UL Recognized / cUL Recognized / EAC Ex / NEPSI / ATEX / CCC / cULus Recognized

Approval details

DNV GL
  [Link]  TAE00001S9

CSA
  [Link]  13631

  B C
Nominal voltage UN 600 V 600 V
Nominal current IN 30 A 30 A
mm²/AWG/kcmil 26-10 26-10

11/06/2021   Page 6 / 8
[Link]

Feed-through terminal block - UT 4 - 3044102

Approvals

PRS
  [Link]  TE/2156/880590/17

IECEE CB Scheme
  [Link]  DE1-63061


Nominal voltage UN 1000 V
Nominal current IN 32 A
mm²/AWG/kcmil 4


 RU C-
EAC
DE.A*30.B.01742

RS
  [Link]  17.00013.272

LR
  [Link]  LR2003762TA


 [Link]
VDE Zeichengenehmigung   40013658
VDE-gepruefteProdukte/Seiten/[Link]


Nominal voltage UN 1000 V
Nominal current IN 32 A
mm²/AWG/kcmil 0.2-4

cULus Recognized
  [Link]  E60425

  B C
Nominal voltage UN 600 V 600 V
Nominal current IN 30 A 30 A

11/06/2021   Page 7 / 8
[Link]

Feed-through terminal block - UT 4 - 3044102

Approvals
  B C
mm²/AWG/kcmil 26-10 26-10

Phoenix Contact 2021 © - all rights reserved

[Link]

11/06/2021   Page 8 / 8
[Link]

Ground modular terminal block - UT 4-PE - 3044128

Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
([Link]

Ground modular terminal block, number of connections: 2, connection method: Screw connection, cross section:
0.14 mm² - 6 mm², mounting type: NS 35/7,5, NS 35/15, color: green-yellow

Your advantages
 Tested for railway applications

Key Commercial Data

Packing unit 1 pc

GTIN

GTIN 4017918960407
Weight per Piece (excluding packing) 13.250 g
Custom tariff number 85369010
Country of origin Germany

Technical data
General
Number of rows 1
Number of connections 2
Nominal cross section 4 mm²
Color green-yellow
Insulating material PA
Flammability rating according to UL 94 V0
Area of application Railway industry
Machine building

11/06/2021   Page 1 / 6
[Link]

Ground modular terminal block - UT 4-PE - 3044128

Technical data
General
Plant engineering
Process industry
Mounting type NS 35/7,5
Rated surge voltage 8 kV
Degree of pollution 3
Overvoltage category III
Insulating material group I
Maximum power dissipation for nominal condition 1.02 W
Open side panel Yes
Shock protection test specification DIN EN 50274 (VDE 0660-514):2002-11
Relative insulation material temperature index (Elec., UL 746 B) 130 °C
Temperature index of insulation material (DIN EN 60216-1 (VDE 0304-21)) 125 °C
Static insulating material application in cold -60 °C
Surface flammability NFPA 130 (ASTM E 162) passed
Specific optical density of smoke NFPA 130 (ASTM E 662) passed
Calorimetric heat release NFPA 130 (ASTM E 1354) 27,5 MJ/kg
Smoke gas toxicity NFPA 130 (SMP 800C) passed
Fire protection for rail vehicles (DIN EN 45545-2) R22 HL 1 - HL 3
Fire protection for rail vehicles (DIN EN 45545-2) R23 HL 1 - HL 3
Fire protection for rail vehicles (DIN EN 45545-2) R24 HL 1 - HL 3
Fire protection for rail vehicles (DIN EN 45545-2) R26 HL 1 - HL 3

Dimensions
Width 6.2 mm
End cover width 2.2 mm
Length 47.7 mm
Height 46.9 mm
Height NS 35/7,5 47.5 mm
Height NS 35/15 55 mm

Connection data
Note Please observe the current carrying capacity of the DIN rails.
Connection method Screw connection
Screw thread M3
Stripping length 9 mm
Tightening torque, min 0.6 Nm
Tightening torque max 0.8 Nm
Connection in acc. with standard IEC 60947-7-2

11/06/2021   Page 2 / 6
[Link]

Ground modular terminal block - UT 4-PE - 3044128

Technical data
Connection data
Note: Product releases, connection cross sections and notes on
Note
connecting aluminum cables can be found in the download area.
Conductor cross section solid min. 0.14 mm²
Conductor cross section solid max. 6 mm²
Conductor cross section AWG min. 26
Conductor cross section AWG max. 10
Conductor cross section flexible min. 0.14 mm²
Conductor cross section flexible max. 6 mm²
Min. AWG conductor cross section, flexible 26
Max. AWG conductor cross section, flexible 10
Conductor cross section flexible, with ferrule without plastic sleeve min. 0.25 mm²
Conductor cross section flexible, with ferrule without plastic sleeve max. 4 mm²
Conductor cross section flexible, with ferrule with plastic sleeve min. 0.25 mm²
Conductor cross section flexible, with ferrule with plastic sleeve max. 4 mm²
2 conductors with same cross section, solid min. 0.14 mm²
2 conductors with same cross section, solid max. 1.5 mm²
2 conductors with same cross section, stranded min. 0.14 mm²
2 conductors with same cross section, stranded max. 1.5 mm²
Two conductors with the same cross section, flexible, with TWIN ferrules,
0.5 mm²
with plastic sleeve, minimum
Two conductors with the same cross section, flexible, with TWIN ferrules,
2.5 mm²
with plastic sleeve, maximum
Two conductors with the same cross section stranded, with ferrule and
0.14 mm²
without plastic sleeve, minimum
Two conductors with the same cross section stranded, with ferrule and
1.5 mm²
without plastic sleeve, maximum
Internal cylindrical gage A4

Ambient conditions
Operating temperature -60 °C ... 105 °C (max. short-term operating temperature RTI Elec.)
Ambient temperature (storage/transport) -25 °C ... 60 °C (for a short time, not exceeding 24 h, -60 °C to +70 °C)
Permissible humidity (storage/transport) 30 % ... 70 %
Ambient temperature (assembly) -5 °C ... 70 °C
Ambient temperature (actuation) -5 °C ... 70 °C

Standards and Regulations

Connection in acc. with standard CSA
IEC 60947-7-2

Environmental Product Compliance

REACh SVHC Lead 7439-92-1
11/06/2021   Page 3 / 6
[Link]

Ground modular terminal block - UT 4-PE - 3044128

Technical data
Environmental Product Compliance
China RoHS Environmentally Friendly Use Period = 50 years
For details about hazardous substances go to tab “Downloads”, Category
“Manufacturer's declaration”

Drawings

Circuit diagram

Classifications
eCl@ss

eCl@ss 10.0.1 27141141

eCl@ss 11.0 27141141
eCl@ss 4.0 27141100
eCl@ss 4.1 27141100
eCl@ss 5.0 27141100
eCl@ss 5.1 27141100
eCl@ss 6.0 27141100
eCl@ss 7.0 27141141
eCl@ss 9.0 27141141

ETIM

ETIM 2.0 EC000901

ETIM 3.0 EC000901
ETIM 4.0 EC000901
ETIM 6.0 EC000901
ETIM 7.0 EC000901

UNSPSC

UNSPSC 6.01 30211811

UNSPSC 7.0901 39121410
UNSPSC 11 39121410
UNSPSC 12.01 39121410
UNSPSC 13.2 39121410
UNSPSC 18.0 39121410
UNSPSC 19.0 39121410
UNSPSC 20.0 39121410
11/06/2021   Page 4 / 6
[Link]

Ground modular terminal block - UT 4-PE - 3044128

Classifications
UNSPSC
UNSPSC 21.0 39121410

Approvals
Approvals

Approvals

DNV GL / CSA / PRS / IECEE CB Scheme / EAC / RS / VDE Gutachten mit Fertigungsüberwachung / cULus Recognized

Ex Approvals

IECEx / EAC Ex / NEPSI / ATEX / CCC

Approval details

DNV GL
  [Link]  TAE00001S9

CSA
  [Link]  13631

  B C
mm²/AWG/kcmil 26-10 26-10

PRS
  [Link]  TE/2156/880590/17

IECEE CB Scheme
  [Link]  DE1-63045


 RU C-
EAC
DE.A*30.B.01742

11/06/2021   Page 5 / 6
[Link]

Ground modular terminal block - UT 4-PE - 3044128

Approvals

RS
  [Link]  17.00013.272


VDE Gutachten mit  [Link]
 40013715
Fertigungsüberwachung  VDE-gepruefteProdukte/Seiten/[Link]


mm²/AWG/kcmil 0.2-4

cULus Recognized
  [Link]  E60425

  B C D
mm²/AWG/kcmil 26-10 26-10 26-10

Phoenix Contact 2021 © - all rights reserved

[Link]

11/06/2021   Page 6 / 6
[Link]

Knife disconnect terminal block - UT 4-MT-P/P - 3046171

Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
([Link]

Knife disconnect terminal block, With test socket screws for insertion of test plugs, nom. voltage: 500 V, nominal
current: 20 A, connection method: Screw connection, Rated cross section: 2.5 mm², cross section: 0.14 mm² - 6
mm², mounting: NS 35/7,5, NS 35/15, color: gray

Your advantages
 Double bridge shaft enables individual potential distribution and supply
 Tested for railway applications

Key Commercial Data

Packing unit 1 pc
Minimum order quantity 50 pc

GTIN

GTIN 4017918975593
Weight per Piece (excluding packing) 13.200 g
Custom tariff number 85369010
Country of origin Germany

Technical data
General
Number of rows 1
Number of connections 2
Potentials 1
Nominal cross section 4 mm²
Color gray
Insulating material PA

11/06/2021   Page 1 / 7
[Link]

Knife disconnect terminal block - UT 4-MT-P/P - 3046171

Technical data
General
Flammability rating according to UL 94 V0
Area of application Railway industry
Machine building
Plant engineering
Mounting type NS 35/7,5
Rated surge voltage 6 kV
Degree of pollution 3
Overvoltage category III
Insulating material group I
Maximum power dissipation for nominal condition 1.02 W
Maximum load current 20 A (with 6 mm² conductor cross section)
Nominal current IN 20 A (with 4 mm² conductor cross section)
Nominal voltage UN 500 V
Open side panel No
Shock protection test specification IEC 60529:2001-02
Back of the hand protection guaranteed
Finger protection guaranteed
Result of surge voltage test Test passed
Result of power-frequency withstand voltage test Test passed
Power frequency withstand voltage setpoint 1.89 kV
Result of the test for mechanical stability of terminal points (5 x conductor
Test passed
connection)
Result of flexion and pull-out test Test passed
Bending test rotation speed 10 rpm
Bending test turns 135
Bending test conductor cross section/weight 0.14 mm² / 0.2 kg
4 mm² / 0.9 kg
6 mm² / 1.4 kg
Tensile test result Test passed
Result of tight fit on support Test passed
Tight fit on carrier NS 35
Setpoint 1N
Result of voltage-drop test Test passed
Result of temperature-rise test Test passed
Requirement temperature-rise test Increase in temperature ≤ 45 K
Short circuit stability result Test passed
Conductor cross section short circuit testing 2.5 mm²

11/06/2021   Page 2 / 7
[Link]

Knife disconnect terminal block - UT 4-MT-P/P - 3046171

Technical data
General
Short-time current 0.3 kA
Result of thermal test Test passed
Proof of thermal characteristics (needle flame) effective duration 30 s
Oscillation, broadband noise test result Test passed
Test specification, oscillation, broadband noise DIN EN 50155 (VDE 0115-200):2008-03
Test spectrum Service life test category 1, class B, body mounted
Test frequency f1 = 5 Hz to f2 = 150 Hz
ASD level 1.857 (m/s²)²/Hz
Acceleration 0.8g
Test duration per axis 5h
Test directions X-, Y- and Z-axis
Shock test result Test passed
Test specification, shock test DIN EN 50155 (VDE 0115-200):2008-03
Shock form Half-sine
Acceleration 5g
Shock duration 30 ms
Number of shocks per direction 3
Test directions X-, Y- and Z-axis (pos. and neg.)
Relative insulation material temperature index (Elec., UL 746 B) 130 °C
Temperature index of insulation material (DIN EN 60216-1 (VDE 0304-21)) 125 °C
Static insulating material application in cold -60 °C
Surface flammability NFPA 130 (ASTM E 162) passed
Specific optical density of smoke NFPA 130 (ASTM E 662) passed
Calorimetric heat release NFPA 130 (ASTM E 1354) 27,5 MJ/kg
Smoke gas toxicity NFPA 130 (SMP 800C) passed
Fire protection for rail vehicles (DIN EN 45545-2) R22 HL 1 - HL 3
Fire protection for rail vehicles (DIN EN 45545-2) R23 HL 1 - HL 3
Fire protection for rail vehicles (DIN EN 45545-2) R24 HL 1 - HL 3
Fire protection for rail vehicles (DIN EN 45545-2) R26 HL 1 - HL 3

Dimensions
Width 6.2 mm
Length 57.8 mm
Height NS 35/7,5 49.1 mm
Height NS 35/15 56.6 mm

Connection data
Connection method Screw connection

11/06/2021   Page 3 / 7
[Link]

Knife disconnect terminal block - UT 4-MT-P/P - 3046171

Technical data
Connection data
Screw thread M3
Stripping length 9 mm
Tightening torque, min 0.6 Nm
Tightening torque max 0.8 Nm
Connection in acc. with standard IEC 60947-7-1
Conductor cross section solid min. 0.14 mm²
Conductor cross section solid max. 6 mm²
Conductor cross section AWG min. 26
Conductor cross section AWG max. 10
Conductor cross section flexible min. 0.14 mm²
Conductor cross section flexible max. 6 mm²
Min. AWG conductor cross section, flexible 26
Max. AWG conductor cross section, flexible 10
Conductor cross section flexible, with ferrule without plastic sleeve min. 0.14 mm²
Conductor cross section flexible, with ferrule without plastic sleeve max. 4 mm²
Conductor cross section flexible, with ferrule with plastic sleeve min. 0.14 mm²
Conductor cross section flexible, with ferrule with plastic sleeve max. 4 mm²
2 conductors with same cross section, solid min. 0.14 mm²
2 conductors with same cross section, solid max. 1.5 mm²
2 conductors with same cross section, stranded min. 0.14 mm²
2 conductors with same cross section, stranded max. 1.5 mm²
Two conductors with the same cross section, flexible, with TWIN ferrules,
0.5 mm²
with plastic sleeve, minimum
Two conductors with the same cross section, flexible, with TWIN ferrules,
2.5 mm²
with plastic sleeve, maximum
Two conductors with the same cross section stranded, with ferrule and
0.14 mm²
without plastic sleeve, minimum
Two conductors with the same cross section stranded, with ferrule and
1.5 mm²
without plastic sleeve, maximum
Internal cylindrical gage A4

Ambient conditions
Operating temperature -60 °C ... 105 °C (max. short-term operating temperature RTI Elec.)
Ambient temperature (storage/transport) -25 °C ... 60 °C (for a short time, not exceeding 24 h, -60 °C to +70 °C)
Permissible humidity (storage/transport) 30 % ... 70 %
Ambient temperature (assembly) -5 °C ... 70 °C
Ambient temperature (actuation) -5 °C ... 70 °C

Standards and Regulations

Connection in acc. with standard CSA
11/06/2021   Page 4 / 7
[Link]

Knife disconnect terminal block - UT 4-MT-P/P - 3046171

Technical data
Standards and Regulations
IEC 60947-7-1

Environmental Product Compliance

REACh SVHC Lead 7439-92-1
China RoHS Environmentally Friendly Use Period = 50 years
For details about hazardous substances go to tab “Downloads”, Category
“Manufacturer's declaration”

Drawings

Circuit diagram

Classifications
eCl@ss

eCl@ss 10.0.1 27141126

eCl@ss 11.0 27141126
eCl@ss 4.0 27141100
eCl@ss 4.1 27141100
eCl@ss 5.0 27141100
eCl@ss 5.1 27141100
eCl@ss 6.0 27141100
eCl@ss 7.0 27141126
eCl@ss 9.0 27141126

ETIM

ETIM 2.0 EC000902

ETIM 3.0 EC000902
ETIM 4.0 EC000902
ETIM 6.0 EC000902
ETIM 7.0 EC000902

UNSPSC

UNSPSC 6.01 30211811

UNSPSC 7.0901 39121410
UNSPSC 11 39121410
UNSPSC 12.01 39121410

11/06/2021   Page 5 / 7
[Link]

Knife disconnect terminal block - UT 4-MT-P/P - 3046171

Classifications
UNSPSC
UNSPSC 13.2 39121410
UNSPSC 18.0 39121410
UNSPSC 19.0 39121410
UNSPSC 20.0 39121410
UNSPSC 21.0 39121410

Approvals
Approvals

Approvals

CSA / EAC / cULus Recognized

Ex Approvals

Approval details

CSA
  [Link]  13631

  B C
Nominal voltage UN 300 V 300 V
Nominal current IN 16 A 16 A
mm²/AWG/kcmil 26-10 26-10


 RU C-
EAC
DE.BL08.B.00534

cULus Recognized
  [Link]  E60425

  B C
Nominal voltage UN 300 V 300 V
Nominal current IN 16 A 16 A
mm²/AWG/kcmil 26-10 26-10

11/06/2021   Page 6 / 7
[Link]

Phoenix Contact 2021 © - all rights reserved

[Link]

11/06/2021   Page 7 / 7
[Link]

End cover - D-UT 2,5/10 - 3047028

Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
([Link]

End cover, length: 47 mm, width: 2.2 mm, height: 39.8 mm, color: gray

Key Commercial Data

Packing unit 1 pc
Minimum order quantity 50 pc

GTIN

GTIN 4017918960346
Weight per Piece (excluding packing) 2.600 g
Custom tariff number 85389099
Country of origin Germany

Technical data
General
Color gray
Material PA
Flammability rating according to UL 94 V0

Dimensions
Width 2.2 mm
Length 47 mm
Height 39.8 mm

General
Relative insulation material temperature index (Elec., UL 746 B) 130 °C

11/15/2021   Page 1 / 3
[Link]

End cover - D-UT 2,5/10 - 3047028

Technical data
General
Temperature index of insulation material (DIN EN 60216-1 (VDE 0304-21)) 125 °C
Static insulating material application in cold -60 °C
Surface flammability NFPA 130 (ASTM E 162) passed
Specific optical density of smoke NFPA 130 (ASTM E 662) passed
Calorimetric heat release NFPA 130 (ASTM E 1354) 27,5 MJ/kg
Smoke gas toxicity NFPA 130 (SMP 800C) passed
Fire protection for rail vehicles (DIN EN 45545-2) R22 HL 1 - HL 3
Fire protection for rail vehicles (DIN EN 45545-2) R23 HL 1 - HL 3
Fire protection for rail vehicles (DIN EN 45545-2) R24 HL 1 - HL 3
Fire protection for rail vehicles (DIN EN 45545-2) R26 HL 1 - HL 3

Ambient conditions
Operating temperature -60 °C ... 105 °C (max. short-term operating temperature RTI Elec.)
Ambient temperature (storage/transport) -25 °C ... 60 °C (for a short time, not exceeding 24 h, -60 °C to +70 °C)
Permissible humidity (storage/transport) 30 % ... 70 %
Ambient temperature (assembly) -5 °C ... 70 °C
Ambient temperature (actuation) -5 °C ... 70 °C

Environmental Product Compliance

China RoHS Environmentally friendly use period: unlimited = EFUP-e
No hazardous substances above threshold values

Classifications
eCl@ss

eCl@ss 10.0.1 27141133

eCl@ss 11.0 27141133
eCl@ss 4.0 21011300
eCl@ss 4.1 21011300
eCl@ss 5.0 27141100
eCl@ss 5.1 27141100
eCl@ss 6.0 27141100
eCl@ss 7.0 27141133
eCl@ss 9.0 27141133

ETIM

ETIM 2.0 EC000886

ETIM 3.0 EC000886

11/15/2021   Page 2 / 3
[Link]

End cover - D-UT 2,5/10 - 3047028

Classifications
ETIM
ETIM 4.0 EC000886
ETIM 6.0 EC000886
ETIM 7.0 EC000886

UNSPSC

UNSPSC 6.01 30211827

UNSPSC 7.0901 39121424
UNSPSC 11 39121424
UNSPSC 12.01 39121424
UNSPSC 13.2 39121425
UNSPSC 18.0 39121425
UNSPSC 19.0 39121425
UNSPSC 20.0 39121425
UNSPSC 21.0 39121425

Phoenix Contact 2021 © - all rights reserved

[Link]

11/15/2021   Page 3 / 3
[Link]

End clamp - CLIPFIX 35 - 3022218

Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
([Link]

Quick mounting end clamp for NS 35/7,5 DIN rail or NS 35/15 DIN rail, with marking option, width: 9.5 mm, color:
gray

Your advantages
 Phoenix Contact has engineered its CLIPFIX end brackets to maintain a secure grip on the various DIN rail systems
 Design width of just 9.5 mm
 Large-surface labeling

Key Commercial Data

Packing unit 1 pc
Minimum order quantity 50 pc

GTIN

GTIN 4017918156541
Weight per Piece (excluding packing) 5.200 g
Custom tariff number 39269097
Country of origin Poland

Technical data
Dimensions
Length (b) 55.6 mm
Width (a) 9.5 mm

Ambient conditions
Ambient temperature (operation) -60 °C ... 105 °C (max. short-term operating temperature RTI Elec.)
Ambient temperature (assembly) -5 °C ... 70 °C

11/15/2021   Page 1 / 3
[Link]

End clamp - CLIPFIX 35 - 3022218

Technical data
General
Color gray
Material PA
Flammability rating according to UL 94 V2
Fire protection for rail vehicles (DIN EN 45545-2) R22 HL 1 - HL 2
Fire protection for rail vehicles (DIN EN 45545-2) R23 HL 1 - HL 2
Fire protection for rail vehicles (DIN EN 45545-2) R24 HL 1 - HL 2

Environmental Product Compliance

China RoHS Environmentally friendly use period: unlimited = EFUP-e
No hazardous substances above threshold values

Classifications
eCl@ss

eCl@ss 10.0.1 27141135

eCl@ss 11.0 27141135
eCl@ss 4.0 27141100
eCl@ss 4.1 27141100
eCl@ss 5.0 27141100
eCl@ss 5.1 27141100
eCl@ss 6.0 27141100
eCl@ss 7.0 27141135
eCl@ss 9.0 27141135

ETIM

ETIM 2.0 EC000761

ETIM 3.0 EC001041
ETIM 4.0 EC001041
ETIM 6.0 EC001041
ETIM 7.0 EC001041

UNSPSC

UNSPSC 6.01 30212109

UNSPSC 7.0901 39121708
UNSPSC 11 39121708
UNSPSC 12.01 39121708
UNSPSC 13.2 39121425
UNSPSC 18.0 39121425

11/15/2021   Page 2 / 3
[Link]

End clamp - CLIPFIX 35 - 3022218

Classifications
UNSPSC
UNSPSC 19.0 39121425
UNSPSC 20.0 39121425
UNSPSC 21.0 39121425

Phoenix Contact 2021 © - all rights reserved

[Link]

11/15/2021   Page 3 / 3
ATM
Fast-Acting Midget Fuses

M I D G E T, P C M O U N T & M I N I AT U R E F U S E S
M
F

R AT I N G S :
• Volts: 600VAC / DC
• Amps: 1/10 to 30A
(35 to 50A AC only)
• I.R.: 100kA I.R.; 10kA I.R. AC
(35 to 50A)

HIGHLIGHTS:
• Fast-acting
Amp-Trap® midget fast-acting ATM fuses are rated 600 volts AC and • Special Ratings (Above 30A)
DC, with a 100kA interrupting rating. These ratings give the ATM a
wide range of applications not covered by other midget fuses. In A P P L I C AT I O N S :
addition, ratings of 30/35, 30/40 and 30/50 amperes are offered for • Supplemental protection of
of circuits up to 600VAC and
specific applications such as capacitor protection. These ATM fuses 600VDC with 100kA I.R.
must still be considered 30A fuses because of their dimensions, but
are able to withstand much higher inrush currents and tougher duty C ATA L O G N U M B E R S
cycles. (Not for Branch Circuit Protection). (AMPS)
ATM1/10 ATM2 ATM12
F E AT U R E S / B E N E F I T S : ATM1/8 ATM3 ATM15
• For supplemental protection of small motors and transformers ATM2/10 ATM4 ATM20
ATM1/4 ATM5 ATM25
• Extended ratings for special protection of capacitors and circuits ATM1/2 ATM6 ATM30
with high inrush currents ATM3/4 ATM7 ATM30/35*
• 600VDC ratings for a wide variety of applications including ATM1 ATM8 ATM30/40*
ATM1-1/2 ATM10 ATM30/50*
photovoltaic and solar applications.
* are not continuous current rated devices
• Can be used with UltraSafe™ fuse holders
• 1 1/2" x 13/32" (10mm x 38mm) dimensions A P P R O VA L S :
• UL listed to standard 248-14
R E CO M M E N D E D F U S E B LO C KS for Midget (10x38mm) Fuses
(1/10 to 30A) File E33925
• DC Listed to UL Standard
Catalog Number 248-14 (1/10 to 30A)
UltraSafeTM Indicating Screw Pressure Plate Copper Box
Number of Poles • CSA Certified to Standard
Fuse Holder Connector Connector Connector
Adder 30310 30320 30350 C22.2 No. 248.14 (1/10 to
1 USM1I 30311 30321 30351 30A)
2 USM2I 30312 30322 30352
3 USM3I 30313 30323 30353
3 USFM10I

© 2018 Mersen. All rights reserved. Mersen reserves the right to change, update,
E P. M E R S E N . C O M or correct, without notice, any information contained in this datasheet. MF 3
M I D G E T, P C M O U N T
ELECTRONIC/
& M I N I AT U R E F U S E S GLASS FUSES

GGC/GGC-V GGM/GGM-V
• Glass body • Glass body
• Fast-acting • Fast-acting
• 1/4" x 1-1/4" • 5 mm x 20 mm
• 1-1/2"Axial leads • 1-1/2" Axial leads
optional optional
1/10A through 10A, 1/16A through 3A, M
250VAC, UL Listed
and CSA Certified
250VAC, UL Listed and
CSA Certified F
12A and 15A, 125VAC, 4A through 8A,
UL Listed and CSA 125VAC, UL Listed and CSA Certified
Certified
10A and 15A, 250VAC,
20A through 30A, 32VAC UL Recognized

S TA N D A R D F U S E S TA N D A R D F U S E
A M P E R E R AT I N G S A M P E R E R AT I N G S
Catalog Number Axial Lead Cat. No Ampere Rating Volts I.R. Catalog Number Axial Lead Cat. No Ampere Rating Volts I.R.
GGC1/10 GGC-V1/10 1/10A 250V 2 GGM1/16 GGM-V1/16 1/16A 250V 2
GGC1/8 GGC-V1/8 1/8A 250V 2 GGM1/10 GGM-V1/10 1/10A 250V 3
GGC15/100 GGC-V15/100 15/100A 250V 2 GGM1/8 GGM-V1/8 1/8A 250V 3
GGC175/1000 GGC-V175/1000 175/1000A 250V 2 GGM2/10 GGM-V2/10 2/10A 250V 3
GGC3/16 GGC-V3/16 3/16A 250V 2 GGM1/4 GGM-V1/4 1/4A 250V 3
GGC2/10 GGC-V2/10 2/10A 250V 2 GGM3/10 GGM-V3/10 3/10A 250V 3
GGC1/4 GGC-V1/4 1/4A 250V 2 GGM4/10 GGM-V4/10 4/10A 250V 1
GGC3/10 N/A 3/10A 250V 2 GGM1/2 GGM-V1/2 1/2A 250V 3
GGC3/8 GGC-V3/8 3/8A 250V 2 GGM6/10 GGM-V6/10 6/10A 250V 1
GGC4/10 GGC-V4/10 4/10A 250V 2 GGM7/10 GGM-V7/10 7/10A 250V 3
GGC1/2 GGC-V1/2 1/2A 250V 2 GGM3/4 GGM-V3/4 3/4A 250V 3
GGC6/10 GGC-V6/10 6/10A 250V 2 GGM8/10 GGM-V8/10 8/10A 250V 1
GGC3/4 GGC-V3/4 3/4A 250V 2 GGM1 GGM-V1 1A 250V 3
GGC8/10 GGC-V8/10 8/10A 250V 2 GGM1-2/10 N/A 1-2/10A 250V 2
GGC1 GGC-V1 1A 250V 2 GGM1-1/4 GGM-V1-1/4 1-1/4A 250V 3
GGC1-1/4 GGC-V1-1/4 1-1/4A 250V 2 GGM1-1/2 GGM-V1-1/2 1-1/2A 250V 3
GGC1-1/2 GGC-V1-1/2 1-1/2A 250V 2 GGM2 GGM-V2 2A 250V 3
GGC1-3/4 N/A 1-3/4A 250V 2 GGM2-1/2 GGM-V2-1/2 2-1/2A 250V 3
GGC1-6/10 GGC-V1-6/10 1-6/10A 250V 2 GGM3 GGM-V3 3A 250V 3
GGC2 GGC-V2 2A 250V 2 GGM4 GGM-V4 4A 125V 4
GGC2-1/4 GGC-V2-1/4 2-1/4A 250V 2 GGM5 GGM-V5 5A 125V 4
GGC2-1/2 GGC-V2-1/2 2-1/2A 250V 2 GGM6 GGM-V6 6A 125V 4
GGC3 GGC-V3 3A 250V 2 GGM7 GGM-V7 7A 125V 4
GGC3-2/10 GGC-V3-2/10 3-2/10A 250V 3 GGM8 GGM-V8 8A 125V 4
GGC4 GGC-V4 4A 250V 2 GGM15 GGM-V15 15A 250V 5
GGC5 GGC-V5 5A 250V 2 1. 250VAC @ 35A I.R./125VAC @ 10kA I.R.
GGC6 GGC-V6 6A 250V 2 2. 250VAC @ 100A I.R./125VAC @ 10kA I.R.
GGC6-3/10 GGC-V6-3/10 6-3/10A 250V 2 3. 250VAC @ 200A I.R./125VAC @ 10kA I.R.
GGC7 GGC-V7 7A 250V 2 4. 125VAC @ 10kA I.R.
GGC7-1/2 N/A 7-1/2A 250V 2
5. 250VAC @ 100A I.R.
GGC8 GGC-V8 8A 250V 2
GGC10 GGC-V10 10A 250V 2
GGC12 GGC-V12 12A 125V 4
GGC15 GGC-V15 15A 125V 4
GGC20 GGC-V20 20A 32V 5
GGC25 GGC-V25 25A 32V 5
GGC30 GGC-V30 30A 32V 5
2. 250VAC @ 200A I.R./125VAC @ 10kA I.R.
3. 250VAC @ 10kA I.R.
4. 125VAC @ 10kA I.R.
5. 32VAC @ 1000A I.R.

E P. M E R S E N .C O M MF 17
800T/H 30 mm Push Buttons 30 mm Push Button Specifications

Pilot Light Devices

Transformer Type Pilot Light Push-to-Test Pilot Light

Cat. No. 800T-P16R Cat. No. 800T-PT16R

(Push-to-Test)

800 T – P T 16 G AR
a b c d e f g h

a d f g
Protection Rating Lamp Test Options Voltage Lens Color
Code Description Code Description Transformer Glass
T Metal, Type 4/13 Code Description Code Color Code
Blank No test option∇
#
H Plastic, Type 4/4X/13 T Push-to-test 16 120V AC 50/60 Hz
Blank No lens Blank
D Dual input — diode∆♠ 26 240V AC 50/60 Hz
b A Amber D
Dual input — transformer 46 480V AC 50/60 Hz
Finger-Safe Guards DT B Blue E
relay♠ 56 600V AC 50/60 Hz
Code Description C Clear F
Note: Push-to-test supplied with Full Voltage — Incandescent
Blank No guards factory jumpered contact block. G Green H
12 12V AC/DC
C Guards on terminals R Red J
e 24 24V AC/DC
W White K
c Illumination Options 48 48V AC/DC
Power Module Type Code Description 10 120V AC/DC h
800T 800H Blank Incandescent 20 240V AC/DC Contact Blocks
Type Type (Push-to-test units only)
H LED♣ Universal — LED
4/13 Description 4/4X/13 Code Description
2 12…130V AC/DC
Code Code Standard
Dual Input
Transformer Blank 1 N.O. - 1 N.C.
P PR 16 120V AC
(or dual input)
PenTUFF (Low Voltage)
24V AC/DC
Full voltage/ 24
Q QR (Dual input diode only) AV 1 N.O. - 1 N.C.
Universal
Class 1, Div. 2
Logic Reed
∇ Non-push-to-test pilot lights using the universal LED option cannot be ordered as Bul. 800HC or 800TC. The AR 1 N.O. - 1 N.C.
terminals are finger-safe as standard.
∆ Diode type dual input provides circuit isolation via opposing diodes. Not recommended for use with solid-state Sealed Switch
outputs. AP 1 N.O. - 1 N.C.
♠ Dual input devices (diode or transformer type) cannot be ordered as Bul. 800HC or 800TC. Finger-safe terminal
Stackable Sealed Switch
guards are not available.
♣ LED illumination option is not available with diode type dual input. AY 1 N.O. - 1 N.C.
# Glass lens available on 800T pilot lights only. Not available on push-to-test units.

18 Rockwell Automation Publication 800-TD009B-EN-P

Bulletin 855P — Panel-mount Signaling Alarms
This product line includes sounders, status indicator beacons, xenon strobes, and sounders with status indicator
combination and dual-circuit alarms. These alarms significantly reduce panel space requirements and installation time.
Our panel-mount alarms are rear-securing and fingersafe, which adds a high level of environmental integrity to your
panel.

Bulletin 855P — Panel-mount Sounder

855P – B 10 ME 22
a b c d

30 mm Panel-mount Sounder 45 mm Panel-mount Sounder 65 mm Panel-mount Sounder

a b c d
Housing Color Voltage Size Mounting Hole
Code Description Code Description Code Description Code Description
B Black 30 12…24V AC/DC SE 30 mm, fully enclosed, smooth front, 72 dB 22 22.5 mm
10 120V AC SH 30 mm, high output, 80 dB
20 240V AC ME 45 mm
LE 65 mm

Bulletin 855PC — Panel-mount Combined Sounder with LED Beacon

855PC – B 10 ME 3 22
a b c d e

45 mm Panel-mount Combined Sounder with LED (Light-emitting Diode) Beacon 65 mm Panel-mount Combined Sounder with LED Beacon

a b c d e
Housing Color Voltage Size Lens Color Mounting Hole
Code Description Code Description Code Description Code Description Code Description
B Black 12 12V AC/DC ME 45 mm 3 Green 22 22.5 mm
24 24V AC/DC LE 65 mm 4 Red
10 120V AC 5 Amber
20 240V AC 6 Blue
7 Clear
8 Yellow

Rockwell Automation Publication 855-TD001G-EN-P - October 2018 3

N174 CU GROUND BARS Page 1 of 1

Search... Login
Advanced Search

Home Help

Customer Self Service N174 CU GROUND BARS

About Us
Home > ILSCO Product Catalog > Grounding > Neutral/Ground Bars > N174 CU GROUND BARS
Products
Reference
ILSCO Product Catalog

• Supplied in 5'9'' lengths.

• UL Recognized and CSA Certified for 600 Volts.
• For Copper Conductor only.
• UL File E6207

Items Per Page 20 Compare

Compare Item ID Conductor Number of Product Details Standard NAED/UPC

Range Taps Package Number
Tap Quantity
N-174 6-14 AWG Approx. 174 Bar Only - Screws Sold Separately - (E-153) 1 0783669695144

Contact Us Privacy Policy Terms And Conditions ©1991-2013 CDI Technology All Rights Reserved

ILSCO
4730 MADISON ROAD
CINCINNATI, OH 45227
513-533-6200
800-776-9775

[Link] 8/6/2013
 
  Parts List

 F4X3LG6

Panduit F4X3LG6 Narrow Slot Wiring Duct,No

cover
F4X3LG6

Share

The F4X3LG6 Panduct Lead-Free PVC Narrow Slot Wiring Duct features a narrow slot/finger
design that closely matches the spacing of high-density components. Upper and lower
scorelines allow for easy finger/sidewall section removal. UL 94 flame class of V-0 with a UL
recognized continuous-use temperature up to 122°F (50°C). Mounting holes provided.
Lead-free PVC. 3.12" x 4.25" (79.2 mm x 108 mm) and 6' (1.83 m) long. Cover sold separately.
Color Light Gray. 6 per package.


Find A Distributor

FEATURED
 
  Parts List

 C4LG6

Panduit C4LG6 PVC Wiring Duct Cover Gray, 4"

C4LG6

Share

The C4LG6 PVC Flush Wiring Duct Cover features a non-slip, liner to prevent cover slide.
Designed with the user in mind, the cover is easy to install and remove. The general-
purpose lead-free PVC material is suitable for use in indoor applications. UL 94 flame class
of V-0 with a UL recognized continuous-use temperature up to 122°F (50°C). Lead-free
PVC. 0.37" x 4.25" (9.4 mm x 108 mm) and 6' (1.83 m) long. Color Light Gray. 6 per package.


Find A Distributor

BEST SELLER
 
  Parts List

 F4X3IB6

Panduct® Base Wiring Duct

F4X3IB6

Share

Panduct® type F narrow slot wiring duct, 4 W x 3 H, 6' length, PVC, intrinsic blue.


Find A Distributor

Qty Add to Part List

 
  Parts List

 C4IB6

Panduct Type C Cover for Flush Cover Wiring

Duct
C4IB6

Share

Duct cover, 4 W x 6' length, PVC, intrinsic blue.


Find A Distributor
