LAB INTERFACE SYSTEM

Interface User Manual

for the Holy Family Hospitals, New Delhi.

Flat.No 14,No. 27, Venkataraman St,

Parthasarathi Puram, T. Nagar,
Chennai, Tamil Nadu 600017
LAB INTERFACE SYSTEM Mediinterface

Introduction

Lab Interface System provides connectivity between Hospital Information System and
Laboratory diagnostic analyzers.

Following is the list of analyzers available in the Lab Interface System.

Hematology Lab Analyzers

 Beckman Coulter DXH 800

 Beckman Coulter DXH 900
 Beckman Coulter LH 750
 Beckman Coulter LH 750
 IL ACL Elite Pro
 Siemens Clinitek Advantus
Biochemistry Lab Analyzers

 Biorad D10
 Siemens Advia Centaur XPT
 Beckman Coulter Access 2
 Beckman Coulter AU680
 Roche Cobas C311

Pin Configuration Diagram

DB9 Pin Female to DB9 Pin Female

Page | 1
LAB INTERFACE SYSTEM Mediinterface

DB9 Pin Female to DB9 Pin Female (Only for Monitor 100 (ESR))

DB9 Pin Female to DB25 Pin Male

Interface Troubleshooting
The interface will work smoothly only when the “exe’s - Medi Interface Software” is open.
Before starting the sample processing, once check and confirm whether the application is
opened or not and Com port is opened without any error.

For reference attached the screenshot.

Page | 2
LAB INTERFACE SYSTEM Mediinterface

 How to find the Medi-exe, when it is closed or minimized? , follow the below
references. Attached the screenshot for reference

Images 1 & 2:
Whenever the application is minimized, then we can find the Medi-exe in the Notification Bar,
available in the right side corner of the system, where the exe is configured and cable is connected.

 If you found “Access to ‘Com 3’ is denied” error, in Medi Application(exe) then

may be the exe opened multiple times or the same com port is assigned to other
active machine in the same system.

Note: The exe should not be open more than once.

Page | 3
LAB INTERFACE SYSTEM Mediinterface

 If you found “The port 'COM3' does not exist” error, then follow the below steps
to check whether the configured com port is available or not in the system.

Go to Control Panel
 Open Device Manager
 Check the Port Details

For example: If the current configured port is “com3” then the same should be available while viewing
in Device Manager.

This shows
available port

Image-1

 If the serial connection is enabled through “USB to serial Port convertor”, then it should be
connected properly. Otherwise, the ports won’t reflect in the system.
 So if the port is inaccessible then it shows error and machine wont communicate which results
in interface problems.
 Refer below screens for the reference.

Page | 4
LAB INTERFACE SYSTEM Mediinterface

None of the port

is available or
visible gehe

Image-2

Here the required port is unavailable, in this need to recover the old port or else need to reconfigure the
application with new available port.

Page | 5
