701ClientSQL en PDF

Part 4 Software Operation
Chapter 2
701ClientSQL
V221110
Table of Contents
1. Installation and Execution

1.1 The Purpose of Networking 4-2-1
1.2 Installation and Execution 4-2-1
1.3 Main Menu 4-2-1
1.4 Tool Bar 4-2-2
1.5 Operator Management (Login Name / Password / Operation Level ) 4-2-2
1.6 Permission to Operate the Software 4-2-4
1.7 Change font 4-2-4
2. Access Control Setting
2.1 Location 4-2-5

2.2 Door Groups 4-2-7
2.3 Time Zone 4-2-9
2.4 Holiday 4-2-11
2.5 Attendance Shift Setting 4-2-13
2.6 User Card Edit 4-2-15
2.7 One Day Access 4-2-18
2.8 Multiple Day Access 4-2-19
2.9 Card ID Registration 4-2-22
2.10 User Card Copy 4-2-27
2.11 Set up user to access at specified door group and specified time zone 4-2-28
3. Backup
3.1 701ClientSQL Backup and Restore data under File Base System Mode 4-2-29
3.2 701ClientSQL Backup and Restore data under Data Base System Mode 4-2-30
3.3 Import and Export User Card Data 4-2-30

3.4 Download To Controller 4-2-32
3.5 Single User Card Download 4-2-33
3.6 User Card Data Download - Read/Write to 7xxH 4-2-33
4. Time Attendance
4.1 701ClientSQL Time Attendance Setting Introduction 4-2-35
4.2 701ClientSQL Attendance Setting 4-2-36
4.3 701ServerSQL Attendance Structure 4-2-37
4.4 Holiday 4-2-38
4.5 System Parameters Setting 4-2-39

4.6 Attendance Shift Setting 4-2-41
4.7 Employee Attendance Data Setting 4-2-43
4.8 View Option of Report 4-2-44
4.9 Daily Time and Attendance Report View & Procedure of arranging Leave 4-2-46
4.10 Monthly Report(Multi-day Time and Attendance report) 4-2-49
4.11 Multi-day time and attendance Summary Report:
Check attendance related statistics within the specified days of the staff 4-2-52
4.12 How to export daily transactions to the 3rd party system for integration
(for example ERP system, Payroll system) 4-2-54
4.13 Salary Edit 4-2-56
4.14 Labor / Health Issuance Setting 4-2-58
5. Reports
5.1 Various Reports & Application 4-2-59
5.2 Daily Transaction Report 4-2-59
5.3 Multi-day Transaction Report 4-2-62

5.4 Report Title Setting 4-2-64
5.5 Monitor Format 4-2-64
5.6 Check Anti-pass Map 4-2-66
6. Testing the Setting Result 4-2-71
7. Import / Export Data

7.1 Save to text file 4-2-72
7.2 Export text file 4-2-73
7.3 Export User data 4-2-73
7.4 Export text files of multiple messages 4-2-75
7.5 Time Attendance Export Format 4-2-75
The Setting when the number of designated exporting transaction’s controller readers
is more than 9
8. Project Files Management 4-2-79
9. DI/DO Number Name & Remote Control through Software

9.1 Edit IO Name 4-2-80
9.2 Reader Status Monitor 4-2-83
10. Graphic Animation Software
10.1 About 701Client Graphic Animation 4-2-84
10.2 Graphic Animation Control Introduction 4-2-86

Events / Symbol Introduction / Site Plan / Animated Symbol / Label / Devices /
I/O Mapping Table / 701ClientSQL Path
10.3 701ClientSQL Graphic Animation GUI 4-2-102

10.4 Example 4-2-120
Architecture Diagram / Configuration and I/O Mapping Table /
701ServerSQL Setting: Access Point Setting / Load Site Plan / Graphic Animation Setting /
Save Changes Setting / POP UP Messages
10.5 Reference 4-2-147

Sound File / External Link / Troubleshooting
11. Lift Floor Setting 4-2-150
12. Special Application

12.1 E-Mail Server Setting 4-2-154
Yahoo Setting
12.2 SOYAL QRCode Format Introduction 4-2-160
12.3 701ClientSQL Email Notification Application Sharing 4-2-161
12.3.1 Sending visitor QR CODE to E-mail via 701CllientSQL software

12.3.2 Fire Event notification
12.3.3 Alarming Event notification
12.3.4 Student’s absent from school notification to guardian
12.4 SOYAL Controller Reader is not only used in Access Control but also used
for various application 4-2-175
12.4.1 AR-837-E Support to Connect Up To 64 Sets of Mailbox

12.4.2 Sharable Parking Lots Solution- Multi-Card Multi-Parking space
12.4.3 SOYAL 721 APP / 727 APP
12.4.4 701ClientSQL Supports Dual IPCAM to Capture User Image
12.4.5 Monitoring the flow of people in Areas
12.4.6 Multi-door Interlock Solution
12.5 Special Application 4-2-205
13.Reference document
13.1 FAQ 4-2-207
13.2 Video 4-2-207
Annex
701ClientSQL Portable Version Installation & Difference Instruction 4-2-208
701ClientSQL Portable Version Installation Instruction

701ClientSQL Standard version & Portable version difference
ACCESS & INDUSTRIAL CONTROL
SOYAL TECHNOLOGY CO.,LTD. SOYAL Product Line Training Course
1 . Installation and Execution

1.1 The Purpose of Networking
　　In the convenience for access control and time attendance management, SOYAL provides powerful software
701ServerSQL & 701ClientSQL, which enhance efficiency significantly with user-friendly graphical interface while
operating.
701ServerSQL acts as a bridge to coordinate the communication between the Host PC and access controllers,
as well as allows users to set parameters of access controller in different locations just through the Host PC at
once. Furthermore, all the event logs can be analyzed through 701ClientSQL to automatically generate daily or
monthly time and attendance report of each individual. Besides, 701ClientSQL is also capable of payroll control,
and setting the door group, time zone, user access level, etc.
1.2 Installation and Execution
Software Installation
Double click 701ClientSQL.exe

icon to start the installation pro- Go to the direction of Start All Programs Soyal Software
cess. 701Client. Click 701Client and then login window will come out
1.3 Main Menu
4-2-1
Part 4 Software Operation / Chapter 2 701ClientSQL
1.4 ool Bar
1 Print 4 Daily Report 8 User Card Edit B Time Zone Edit E User Pictures
2 Re-Login 6 Month Report 9 Door Group Edit C Attendance Edit F Download Data
3 Daily Records 7 Summary Reports A Door Name Edit D Holidays Edit G Controller Status
I View option
1.5 Operator Management (Login Name / Password / Operation Level )
Login
When login 701Client for the first time, please enter the default Login Name and password as below:
Login Name: supervisor
Password: supervisor
To improve security, please change your password and access level immediately after login.
Access Level/Password
Help Password and then “Modify User Access Password” window will come out. Items can be modified as
follows:
1. User ID: 00-99 operators, 100 in total, for editing the user level, login name and password, etc.
2. User Level: 0-63 user level for editing. 63 is the highest authority.
3. Login Name: login name can be composed of 18 English letters or 9 Chinese characters at most.
4. Password: password can be composed of 18 English letters or 9 Chinese characters at most.
5. You can tick the desired options on the right field.
※Advanced is that when the operator with advanced level is allowed to edit user card data on
the window of Edit User Card; In the daily report, the operator is allowed to modify the data in daily report.
4-2-2
NOTE
When 701Client has be minimized and disappeared from the desktop temporarily, you will be demanded
to re-login as you make 701Client appear again. If you want to avoid this re-login window and improve
efficiency, you can change the setting as follows:
※ Next time you can login 701Client with Login Name: NoLogin (Password: NoLogin) to prevent re-login
window from appearing again.
Click Help Password and then “Modify User Access Password” window will come out. Setting can be
modified as follows:
1. User ID: 00
2. User Level: 63
3. Login Name: NoLogin
4. Password: NoLogin
5. Option at right of window can be changed based on demand.
More Details :
FAQ : How to Assign a Login Account on 701Client that been only Permitted to
Access Daily / Monthly/ Summary Report...?
FAQ : After login 701Client, all function buttons cannot be clicked. Why?
FAQ : After download card data for User Add 001~199, why these cards will be
expired the next day?
FAQ : How to login 701Client without password and what should I need to know?
Video : 【701 Client】 701 Software introduction
4-2-3
1.6 Permission to Operate the Software
　　Both the operator and the software itself will be given an access level index. Operator with higher level index
number is allowed to operate the functions with lower level index in 701ClientSQL.
1. 2. 3.
1. Query: those operators with lower access level index are not allowed to query the following items.
2. Modify: those operators with lower access level index are not allowed to modify the following
items.
3. Advanced: those operators with lower access level index are not allowed to use the following
advanced features (including edit user data and modify daily report).
1.7 Change font

　　If want to change the font, please go to the menu bar "Font" to change it.
More Details :
FAQ : Time Attendance Access Level on 701Client
FAQ : I want that security guard can read message and open the door from
computer, how do I set up authorization for…
4-2-4
2 . Access Control Setting
2.1 Location
　　Where the access controller is located should be set via 701ClientSQL, including door number and door name.
Select Setting --> System Parameter --> Tick ‘Enable Multi Area Mode(Area. Door)’
There are two ways to open “Door Name Editior” window: and
Step 1. Click “Add Door” button.

Step 2. Select Area Name
Step 3. Door Number of Reader: input door number of the access controller .
Step 4. Name: input the location name corresponding to the door number (door number 001:
front door, door number 002: back door, door number 003: warehouse).
Step 5. Click “EXIT” to close the window (or click “Rename” to modify data).
Step 1.
Step 2.
Step 3.
Step 4.
4-2-5
NOTE
Step 5.
NOTE
You can also click “Save As” button to save the settings for future use.
For small framework, you just need to input the door number and door name to add door data in “Door
Name Editor” window. For huge framework, you need to tick “Enable Huge-Door-Group Mode” option
in “System Parameters Setting” window (refer to Page 27 Step 7.) and input (1) Node of Controller (2)
Door Number of Reader (3) Name as below:
1.
2.
3.
1. Node of Controller:
1. For H series access controller (AR-721-H) connected to the Multi-Door Networking Controller
(AR-716-E): Node ID of AR-716-E.
2. For E series access controller (AR-837-E) : Node ID of this access controller.
3. For H series access controller (AR-721-H) connected to the host PC directly: door number H of this
access controller (i.e. Virtual AR-716-E Node ID).
2. Door Number of Reader:
1. For H series access controller (AR-721-H) connected to the Multi-Door Networking Controller
(AR-716-E): door number L of this access controller.
2. For E series access controller (AR-837-E): door number of this access controller.
3. For H series access controller (AR-721-H) connected to the host PC directly: door number L of this
access controller.
3. Name: the corresponding location of the door number.
More Details :
FAQ : How to show correct reader node ID under virtual 716E?
FAQ : How to set 701Client to show complete node id for 716E + controller?
FAQ : Why I had set the new Wiegand Door Number,but it is still same to the
Door Number?
4-2-6
2.2 Door Groups
　　How can you control different users' access levels of doors? Door group management provides a perfect
solution to that requirement by setting different doors as a door group and only particular users are allowed to
access designated door group, for example, Accounting door group for accounting dept. and RD door group for RD
dept.
For example:
Door Groups Location Level
001 Front Door 00
002 Back Door 00
003 Backe Door + Warehouse 00
004 All doors (link Front Door to door group 003) 00
NOTE
Each user can be assigned to specific access Time Zone, Door Group, and Access Level. After these setting
being set up, each user have to assigned which Time Zone, Door Group, and Access Level to equip. More de-
tail please refer to Chapter 2.6 User Card Edit (Step. 6-8).
There are two ways to open the “Door Group Edit” window: and
Step 1. Group: 1 ~ 255 sets of door groups for selection. For example: 001.
Step 2. Tick the permitted locations (door number + door name) of this door group, for example:
001 Front Door.And Door Group Name can be edited for needs.
Step 3. Link: each door group can link to another door group. If there is no need for link, please
select “END” in the “LINK” field.
Step 4. Level: 00 ~ 63 Access Levels for editing. User with higher-level index number is allowed
to access those Time Zones or Door Groups with lower level index numbers (63 is the
highest authority), details please refer to the Chapter 2.6 User Card Edit (Step. 6-8).
Step 5. Click “Save” to save all settings.
Step 6. Click “EXIT” to close the window.
Step 2.
Step 3.
Step 4.
Step 1.
Step 5.
Step 6.
4-2-7
NOTE
NOTE
Each door group can link to another door group to increase the permitted locations.
For example: the permitted locations of door group 004 are Front Door, Back Door, and
Warehouse.
More Details :
FAQ : Has 6*AR-829E controllers now.How to set all people access door 5 and 6 at
21:00 ~ 7:30 by swiping card and PIN?
FAQ : How to set access time zone by【SET】function under 701Client?
FAQ : 701Client connection has been set to door group 001-008, why the card still
only displays door number 001
FAQ : How to set one card can access front door only by card, but access back door
by card and pin?
FAQ : There are three controllers, how to set 10 cards can access all controllers?
FAQ : How to set different time zone and different access way by 701Client?
FAQ : How to set door group in the 701Client?

FAQ : There are three controllers AC1, AC2 and AC3. How to set all users could
enter AC1 at office hour, User2 could enter…
FAQ : How to let one user card access some door by card only and other door
by card+pin?
FAQ : While 721H connected with 716E, how to use Level Comparison function to
set up one user card accessing the door with…
FAQ : How to set up【Anti-pass back】function on AR-721HV3 4 pcs and 【User
Status 】function ?
FAQ : Can u advise how to set card & pin entry after office hours ?
Normal office hours use card only.
FAQ : How to automatically change user access mode for different reader?
4-2-8
2.3 Time Zone
　　After the door group setting is completed, we can proceed to set the time zones for user's access control.
There are 00 ~ 63 time zones for editing.
Application :
Auto Open Time Zone :

Auto Open Zone usually program during office hour in which worker does not required to present any access
identification to roam freely and conveniently in the office. Meanwhile, for area that still required access restriction
such as treasury room, computer room, and executive room can be set as an exception of Auto Open Zone.
Limited Access Zone (Temporary Pass) :
Designated Access Zone is a short-term access for visitor or one-time access management. Each visitor is given
a temporary pass that could be used during their visit and could not use the access anymore after visit hours
have expired.
Access Time Zone :
Access Time Zone is a set of time in which user can access only has access during particular time. This is to
limit employee to have access only during shift hour and denied access even though employee presenting valid
card during non-working hours.
Duty Shift :
Duty Shift is the time recorded for employee in Time Attendance system.
For example:
To manage the personnel in each Time Zone conveniently, manager could set up multiple Time Zones by different
requirement. Taking the table below for instance, one factory has the Normal Personnel Time Zones 001~003
(Morning Shift – Mon to Fri 08:15-17:00 / Night Shift - Mon to Fri 17:00~23:00 / Graveyard Shift - Mon to Fri
23:15~06:00) and the Security Time Zone 004 (Mon to Fri 06:30~07:30/08:15~17:00), personnel can also enter the
factory in weekends during specific Time Zone.
Time
End/Start Mon Tue Wed Thu Fri Sat Sun Link Holiday Level
Zone
Start 08:15 08:15 08:15 08:15 08:15 12:00 12:00
001 END NO 00
End 17:00 17:00 17:00 17:00 17:00 17:00 17:00
Start 17:00 17:00 17:00 17:00 17:00 08:00 08:00
002 END NO 00
End 23:00 23:00 23:00 23:00 23:00 17:00 17:00
Start 23:15 23:15 23:15 23:15 23:15 12:00 12:00
003 END NO 00
End 06:00 06:00 06:00 06:00 06:00 17:00 17:00
Start 06:30 06:30 06:30 06:30 06:30 12:00 12:00
004 001 YES 01
End 07:30 07:30 07:30 07:30 07:30 17:00 17:00
NOTE
Each user can be assigned to specific access Time Zone, Door Group, and Access Level. After these setting
being set up, each user have to assigned which Time Zone, Door Group, and Access Level to equip. More
detail please refer to Chapter 2.6 User Card Edit (Step. 6-8)
4-2-9
There are two ways to open the “Time Zone Edit” window: and
Step 1. ZONE: 00 ~ 63 time zones for editing. For example: 001.

Step 2. Enter the starting/ending time of this time zone during Monday to Sunday.
Step 3. Level: 00 ~ 63 access levels for editing. User with higher level index number is allowed to
access those time zones or door groups with lower level index numbers. (63 is the
highest authority)
Step 4. Link: each time zone can link to another time zone. If there is no need for link, please
select “END” in the “LINK” field. If “FREE” is selected in the “LINK” field, the access
control of this time zone would be inactive, which can be used in emergency conditions.
Step 5. If “Available in Holiday” is ticked, users with higher level index number can still get access
during this time zone on holidays. If not ticked, all users are not allowed to get access
during this time zone on holidays (please refer to Page 8 for holiday setting).
Step 6. Select Area name and the controller’ node ID to edit time zone, then directly
click to download time zone setting to the controller.
Step 7. After finish setting, click

Save: Save all the Time Zone setting to the current work file;
Save As: Save all the Time Zone setting to another file;
Save as Text: Save all the Time Zone setting to a .TXT text file.
Step 2.
Step 1. NOTE
Step 3. In case of emergency,
Step 4. you can select “FREE”
Step 5. in the “LINK” field, and
the access control of this
time zone will be inactive.
Step 6.
Step 7.
Step 8.
4-2-10
More Details :
FAQ : Why scanning the cards out of available time zone, the system doesn't take
the log as attendance record?
FAQ : How to fix the duty function key of 727H on the last key state?
FAQ : How to show duty type automatically on 727H?
FAQ : How to show fixed duty type on AR-727H?
FAQ : How to edit time zone? Monday to Thursday all day pass. Friday cannot pass
after 18:00 until Sunday 21:00
FAQ : How to set auto open time zone?
FAQ : How to use Level Comparison function to set up one user card accessing one
Time Zone with Card & Pin and another…
FAQ : How to set up Auto-open function(Zone: 63) on AR-716E+AR-727H?
FAQ : One Example of 716E [SET] Function
FAQ : How to set up “door auto open＂ function on AR-829E?
FAQ : The 【SET】 application under user data edit
2.4 Holiday
　　After the time zone setting is completed, we can proceed to set the holidays of the whole year (up to 120
holidays in total).
Holiday Setting Concept: The holiday setting in 701ClientSQL software will be only recorded the month/day
(exclude year) , so when editing holidays, please do not edit a date as holiday that exceeds 11 months from the
current month to avoid the holiday setting being overwritten.
As shown below: The current month is August 2022, then you can set holidays from August 2022 to June 2023 (11
months in total)
Current month
2022 Holiday Setting 1 2 3 4 5 6 7 8 9 10 11 12
2023 Holiday Setting 1 2 3 4 5 6 7 8 9 10 11 12
There are two ways to open the “Holiday Edit” window: and
Step 1. Select “Year” first.

Step 2. Select “Month” next.
Step 3. Select the days of holidays.
4-2-11
Step 1. Step 2.
Step 3.
Step 4.
Step 5.
NOTE
NOTE
Save Office Day:
Save this holiday setting as *.wth file.
Read Office Day:

Read the holiday setting from the existent *.wth file.
Save As :
Save this holiday setting as *.hol file.
※701ClientSQL support to display up to 10 years ( previous 2 years , this year, and next 7 years) , it can
set maximum 120 days of holidays.
※If overtime work in a special holiday is required for overtime pay , it must be saved as a specialholiday.
hol file, and then the system will calculate the day as a special overtime duty
More Details :
FAQ : Why The Holiday Setting Screen only shows up to Year 2020? What happen
after 2020?
FAQ : Setting up Auto-open time via 701 Client and Not allow access during holiday.
4-2-12
2.5 Attendance Shift Setting
　　Before generating attendance reports, you have to set attendance shifts first, and there are 49 sets of
attendance shifts for editing.
There are two ways to open the “Attendance Edit” window: and
Step 1. Select Group # (attendance shift) first (or you can type in the group name directly).
Step 2. Select flex time next.
Step 3. Input the time of each attendance shift.
Step 4. Click “Save” to save all settings or click “Text File” to save the setting as *.txt file
(this file can be used for setting in future).
Step 5. Click “Exit” to close the window.
Step 1. Step 2.
Step 3.
Step 4.
Step 5.
NOTE
Break Out and Break RTN: the period between the two shift will be automatically deducted from
working hours when generating the attendance reports.
※ If the time of "Over Time" is set as 00:00, the time of overtime working will start from the time of
"Off duty". If there is no overtime pay, please set the time of "Over Time" as the time when no more
staff is working so as to avoid salary calculation errors.
Flex Time: in Duty_01 shift (On Duty: 08:15/ Off Duty: 17:45/ total working hours = 9.5 - 1.5 = 8 hr): If
the flex time is set as 30 min, when one employee is on duty at 08:39 and off duty at 18: 39, although
he is 24 minutes late for work, his lateness is within the flex time range (24 min < 30 min) and his total
working hours = 8.5 hr (> 8.0 hr), so he won't be shown as late in the attendance report.
4-2-13 12-8
　　If you want to set atendance shifts in monthly table rather than in weekly table, please refer to the following
setting:
First, open the “System Parameters Setting” window by clicking .

Select "Monthly Table".
Next, open the “Attendance Edit” window by clicking or .
Select the designated year/month and edit the attendance shift as you want.
NOTE
NOTE
You can use "Copy to Buffer" button and "Paste from Buffer" button to set monthly shifts more
efficiently. The time shift will be copied and pasted by the corresponding date of each month.
More Details :
FAQ : How to Pop-up Reminder Window for Abnormal Message?
FAQ : How to set up the flexible time?
Video : 《701 Client》Reports-5_Duty time
12-9 4-2-14
2.6 User Card Edit
　　After the settings of door group, time zone, and so on are all completed, we can proceed to set the user data,
including the card ID, access mode, and other relevant settings.
There are two ways to open the “User Card Edit” window: and .
Step 1. User Num (User Number = User Address): each user is assigned a specific 5-digit user
address at which all the related user data is stored in the memory of access controller.
User Address starts from 00000, and the maximum capacity differs according to the type
of access controller. Here it is set as 00001.The Client can edit someone who showed in
transaction log without clicking User Cards Edit on Menu Bar and seeking for the data.
By edit user from the transaction log window, client can access just by Twice-click in
row of each user.
Step 2. Lock: when you are editing the user data, please tick “Lock” to avoid window switching (if
not ticked, when there is a valid card presented to the access controller, the “User Data
Edit” window will automatically switch to the corresponding user data window).
Step 3. Auto Save Card ID: this function is only available when the card is presented at the
access controller of door number 001. If this option is ticked, the card ID (site code and
card code) will be automatically shown in the window after it is presented at the access
controller of door number 001. If a batch of cards are presented continuously, these
cards will be shown at the corresponding user address in an accumulative order, which
allows you to add cards more efficiently.
Step 4. Card ID: 5-digit site code + 5-digit card code. You can directly type in the card ID or use
Auto Save Card ID described in step 3.
Step 5. Access Mode: invalid, Card Only, Card or PIN, Card & PIN for selection.
Step 6. Zone: you can select the permitted time zone (01 ~ 63) for this user or select “ALL” (= not
limited).
Step 7. Level: 00 ~ 63 access levels for editing (for V5 version or later, access level: 00 ~ 03).
User with higher level index number is allowed to access those time zones or door groups
with lower level index numbers. (63 is the highest authority)
Step 8. Door Group: you can select the permitted door group (001 ~ 253) for this user or select
“ALL” (= not limited) or “NO” (= not authorized for any door group).
※ Comparison with access level of user, time zone, or door group can be only
applied to advanced access controllers like AR-716E, AR-829E ,or AR-821EF, not
available for H series access controllers. If you want to apply the level comparison
function to H series access controllers, please connect them to Multi-Door Networking
Controller AR-716E.
Step 9. Name/Alias: the name/nickname of this user, which will be shown in the event log.
Step 10. P.I.N. Code: the private password of this user.
※ When you use a H series access controller in M8 mode, please note that the private
password of each user cannot be repeated, or it might cause errors when the access
mode is “Card or PIN”.
Step 11. Changeable: if this option is ticked, the user can change the private PIN directly at the
access controller after a valid access procedure when the access mode is “Card or PIN”
or “Card & PIN” as below:
4-2-15
After a valid access procedure -> input the new 4-digit PIN twice + #.
(if the access controller is connected to Multi-Door Networking Controller AR-716E, the
new PIN is used to change the PIN stored in the memory of AR-716E.)
Step 12. Employ ID: the employee ID of this user.
Step 13. Photo: you can upload a photo of this user (200*230 pixels, .bmp or .jpg) for better
recognition. The photo will be saved with the file name User00001.jpg in the path:
C:\Program Files (x86)\701Client\popGra
Step 14. Date Limits: the function is only available for E series access controllers. You can assign
the data limits to the specific user. After the expiry date, this user cannot get access
anymore.
Step 15. Depart.: the department of this user. You can type in two departments here.
Step 16. Duty#: there are 49 sets of attendance shift for editing.
Step 17. User Data: Car ID, Birthday, Visa ID (ID card number), Gender, E-mail, TEL, Address.
Step 18. Anti-Pass-back: if this option is ticked, the anti-pass-back function of this user will be
enabled.
Step 19. Guard: if this option is ticked, the user will be identified as patrol check-in only and the
lock won’t be released when this Guard Card is presented.
Step 20. Just card control: User can use only card for access.
( Only suitable for fingerprint controller )
Step 21. Just Fingerprint: User can use only fingerprint for access.
( only suitable for fingerprint controller )
Step 1. Step 2. Step 3. Step 13.
Step 4. Step 5.
Step 6. Step 7.
Step 8.
Step 10. Step 11.
Step 9.
Step 12. Step 19.

Step 18.
Step 14. Step 20.
Step 15. Step 16.
NOTE 2 Step 21.
Step 17. Step 22.
4-2-16
NOTE 1
1 If the user selects a valid access mode such as
“Card only” or “Card or PIN”, the field of Card ID
1 must be filled, otherwise a warning window will pop
up.
2
NOTE 2
Change Department name :
Change Department name by selecting unused
Department and directly rename it
Door Group
Door Group Location Level
001 Front Door 00
002 Back Door 00
003 Backe Door + Warehouse 00
004 Front Door link 003 (All doors) 00
Time Zone
Time
End/Start Mon Tue Wed Thu Fri Sat Sun Link Holiday Level
Zone
Start 08:15 08:15 08:15 08:15 08:15 12:00 12:00
001 END NO 00
End 17:00 17:00 17:00 17:00 17:00 17:00 17:00
Start 17:00 17:00 17:00 17:00 17:00 08:00 08:00
002 END NO 00
End 23:00 23:00 23:00 23:00 23:00 17:00 17:00
Start 23:15 23:15 23:15 23:15 23:15 12:00 12:00
003 END NO 00
End 06:00 06:00 06:00 06:00 06:00 17:00 17:00
Start 06:30 06:30 06:30 06:30 06:30 12:00 12:00
004 001 YES 01
End 07:30 07:30 07:30 07:30 07:30 17:00 17:00
1. In this example, User Num 00001 named SOYAL can access Door Group - Group_001 during Time Zone
001, meaning that SOYAL can get access from the Front Door during Monday to Friday 08:15-17:00 and
weekends 12:00-17:00.
2. How to know the function of Access Mode? Although the Access Mode of this user is "Card & PIN", this user
can get access by simply presenting a valid card or inputting PIN since his access level index (01) is higher
than both of the time zone (00) and the door group (00). In this situation, "Card & PIN" will actually degrade
to "Card or PIN". This function is set up for manager’s different requirement of Access Mode during each
Time Zone.
3. Every single User Num could only select one Time Zone, but we can achieve multiple requirements of
Time Zones by LINK function. In this example, the personnel select Time Zone 004 has requirement of two
Time Zones (Time Zone 004 06:30~07:30 that been set to link to Time Zone 001 08:15~17:00), and then the
Controller will judge whether the user has enough level index during these Time Zones.
4-2-17
Level Comparison Table: (only available for E series access controllers)
User
Access Mode Time Zone Level Door Group Level Actual Access Mode
Level
01 Card & PIN 00< User Level 01 00< User Level 01 Card Only / Private PIN
01 Card & PIN 01= User Level 01 00< User Level 01 Card + Private PIN+#
01 Card & PIN 00< User Level 01 01= User Level 01 Card + Private PIN+#
01 Card & PIN 01= User Level 01 01= User Level 01 Card + Private PIN+#
01 Card & PIN 02> User Level 01 00< User Level 01 No Access
01 Card & PIN 00< User Level 01 02> User Level 01 No Access
2.7 One Day Access
　　For one day access, you can directly set the same date between start date and end date and enter the time
limit.Below example is enabling date limit for access only at March 18 2021 between 8:00-12:00 (remember to save
and download the save changed to controller)
Step 1. Setting" Start date / End date"

Step 2. Setting” Start time / End time”
Step 4. Download to controller
Step 1.
Step 3. Step 4.
Step 2.
4-2-18
Start date / End date
Start date End date
Start time / End time
Start time End time
2.8 Multiple Day Access
　　For multiple day access, the time limit set is from start date time to end date time.
For example setting the date limit for user no. 2 from March 1 to March 31, time limit set is 09:00-17:00. Because
it is multiple day access, between the start date and end date there should be combined with timezone access.
Example, time zone 1 is a set of timezone for weekday Mon, Tue, Wed, Thu, Fri for 08:00-18:00.
That way, User 2 access is:
March 1 (start date) User 2 can access from 09:00 (start time, instead of 08:00 from timezone 1 setting)
March 2 until March 30 User 2 can access according to assigned timezone 1; which is from 08:00-18:00
March 31 (end date) User 2 can access until 17:00 (end time, instead of 18:00 from timezone 1 setting)
There are two ways to open the “Time Zone” window: and .
Step 1. Time zone 01

Step 2. Weekday Mon, Tue, Wed, Thu, Fri for 08:00-18:00.
Step 4. Download to controller
Step 5. Setting” Start date”
Step 6. Setting” End date”
Step 7. Setting” Start time / End time”
4-2-19
Step 1.
Step 2.
Step 5. Step 6.
Step 3. Step 7.
Step 4.
Start date / End date
Start date End date
Start time / End time
Start time End time
More Details :
FAQ : How to Quickly Backup User “SET＂ Data for 716E & E Series Controller
on 701Client?
FAQ : Why the system crash while downloading User Alias?
FAQ : How to add/delete special "leave except" type default "leave" type?
FAQ : How to Quickly Delete User Cards Data?
FAQ : About Date Limit on 701Client
FAQ : How to use more than 4-digit PIN code to access the door?
FAQ : How to Quickly Delete All User Cards Data?
FAQ : How to set guard card ?
FAQ : How to use “Auto Save Card ID＂ function in 701 Client?
4-2-20
FAQ : Why my card is invalid after using one day?
FAQ : How to know the available door Of each user?
FAQ : How to add several cards (sequential card number) at one time by 701client?
(Only for EM card)?
FAQ : How to set up【Anti-pass back】function on AR-721HV3 and AR-727HV3 ?
FAQ : When I try to save the user parameter, it shows error message. How can I
solve this problem?
FAQ : Which types of card format could be supported on 701Client?
FAQ : How to get User card data from E&V5 Series Controllers to Computer?
FAQ : Why there pops up a warning window "Same UID with XX" when Edit User
Card on 701 Client?
FAQ : How to automatically export user card data via 701Client?
FAQ : When Add one card number to one new employee, Why the user can access
all door , but can been see any records in daily..
FAQ : How to show alias on the LCD of 8xx series controllers while accessing?
FAQ : The factory has 10 reader, for 10 office doors. And there are 30 workers no
allow to enter office from the doors…
FAQ : Why message says Expired Date on 701Client when scanning FP on

AR-821EF?
FAQ : how to Solve the trouble when the User Press Duress Code For Access on V5
Series Controller to Cause Error Time Attendan
FAQ : Can I import/export format of card as excel format?
FAQ : The maximum user capacity is 15000, why can´t I set up user number more
than 199 ?
FAQ : How to let one user card access some door by card only and other door
by card+pin?
FAQ : How to set up【Anti-pass back】function on AR-721HV3 4 pcs and

【User Status 】function ?
FAQ : Can u advise how to set card & pin entry after office hours ? Normal office
hours use card only.
FAQ : How to automatically change user access mode for different reader?
4-2-21
2.9 Card ID Registration
Method 1: Log in manually- Input Card ID
Get card ID on daily transaction report
The card number is printed on the card
WG ID
04099 , 09157
Card UID (__:xx)WG32(5:5) / Card UID (xx:__)WG32(5:5) /

u64(7~10:8) : u64(7~10:8) :
Site code, first 5 digit UID WG5:5 or Card Code, last 5 digit UID WG5:5
HEX 4~7/64Bit or HEX 0~3/64Bit
Method 2: Auto Save Card ID -the function is only available for the controller reader with node ID 001
Step 1. Check " Auto Save Card ID "

Step 2. After you select user number, swipe the card on controller reader, the card ID will automatically be
loaded into the card ID field and the software will automatically jump to the next user number.
Step 1.
Step 2.
swipe the card
4-2-22
Method 3: Register via RFID Card Reader AR-725-R - Need to install one newer 701ClientSQL version
•USB HID: Driver free,just Plug and Play

•Support WIN XP,WIN 7, WIN10
•Quick Register User Card with SOYAL 701Client Softwar
STEP 1 Plug in USB Card Reader (AR-725-R) into the USB port of your PC
Soyal Software
Start
STEP 2 Run 701ClientSQL software and go to option [8 User Cards Edit]
Soyal Software
Start
Place the card into AR-725-R and it will automatically adding

STEP 3 card number into the Card UID field
NOTE
※“Lock” option must be untick
If placing the next card into AR-725-R, 701ClientSQL will jump into the next user, that way
adding card number for big batch is much more easier using AR-725-R(Moreover, card
format shows in 701ClientSQL will follow the original card format
(ABA/ WG 34/ WG 26/ HEX) no need to convert it.
4-2-23 12-14
Method 4: Upload user card info. from device to 701ClientSQL software after adding user cards on device –the
function is suitable for adding lots of user cards on device for initial usage
Step 1. Run 701ClientSQL software, select the "Read/Write to Cxx" function in Tools Box drop down menu
Step 2. First select Controller Type
Step 3. Select Node ID of Controller
Step 4. Select user range for read
Step 5. Click "Start" button to read user card data from selected controller reader
Step 3.
Step 5.
Step 4.
Step 1.
Step 2.
NOTE
Download User Data Method and Fallback Mode on Control Panel &
Access Controller
※Read/Write user data in range

This method is the only method to ensure Fallback Mode is actively in use for emergency user list. When
downloading user data it is required in 701ClientSQL to download user data not only to control panel but also
to access controller under control panel.
4-2-24
LAN = Area (range Area00-Area15)

Controller = Select controller node ID
Reader
Direct wiring; select 1
Wiring under control panel; reader ID means
sub-node ID.
Access Range
Write= to write data saved on the computer to access
controller
Read= to read data saved on the controller to show
on the software.
※Note: by selecting Read, your existing data will
be overwrite by data from the controller. Back-up
is required before taking this action to prevent lost
data.
Controller Type
1 829EV3/716EV3/881E/725Ev2/829Ev5/837E
E series controller
And multi door control panel AR-716-E18/AR-
716-E16 (download to master)
2 3xx/7xx/8xx/H/E serial under 7xxE (Door
Group)
E or H series under multi-door controller sorting
out door group (download to RS485 CH1/CH2, to
slave)
This option is only download to specified unit of
door group that has been assigned in the User
Card Edit.
Example User 11 has been assigned with Door
Group 3, selecting this option will only download
user data to controller listed on Door Group 3.
1
2
3
4
3 3xx/7xx/8xx/H/E serial under 7xxE

E or H Series under multi-door controller
(download to RS485 CH1/CH2, to slave)
4 3xx/7xx/8xx/H/E serial under P
H Series controller
4-2-25
Example when you have control panel AR-716-E16 + controller AR-721H wiring beneath it
No. 1 and 4 is downloading to the master controller. If you are downloading to control panel
AR-716-E16 (for example) then you select option 1.
No. 2 and 3is downloading to the slave in CH1 and CH2, in your case if you want to download
to AR-721H (for example) you select either option 2 or 3. The difference is: option 2 consider the
sorting out door group if any, meanwhile option 3 doesn’t.
When connection between AR-721-H + AR-716-E16 is connected, database check is

conducted on AR-716-E16 as master
When connection between AR-721-H + AR-716-E16 are NOT connected, database check is
conducted on AR-721-H as the connection being cut and it returns to its controller status. That
means if you download the user data to both AR-716-E16 and AR-721-H, the card can still be
in use during the disconnection (advantage of Fallback mode for emergency user list). But you
need to note that H series only limited to 1000 and 3000 user capacity (user capacity of AR-
721-H is 1000), meanwhile control panel has 16.000 users that way only the first 1000/3000
(depend on the controller) can be used as emergency user list to still have access during
disconnection.
More Details :
Download User Data Method and Fallback Mode on Control Panel & Access
Controller
4-2-26
2.10 User Card Copy
Within a specified card range, user can copy cards that same as the current shown User Card setting
based on the selected items.
Step 1. Tick “Auto Save Card ID”

Step 2. Select user number that is based on the card of desired copy.
Step 3. Input Card ID
Step 4. Select Access Mode
Step 5. Choose Card Copy under the Tools Box drop down menu.
Step 6. Input Start Address and End Address for User range
Step 7. Click the user items setting you would copy. Besides, Card Code will be increased by 1 for each
continuous address (only for sequential EM card or encrypted SOR Mifare Card). The others
settings are the same with current shown User Card setting.
Step 8. Click [ YES ] to exit.
Step 6.
Step 2. Step 1.
Step 3. Step 4.
Step 7.
Step 5.
Step 8.
4-2-27
2.11 Set up user to access at specified door group and specified time zone
The function is only compatible for Enterprise E Series controller (AR-716-E/AR-837-E/727-E/725-E/327-E)
Function Description: Each user can individually specify the door group and time zone. This function can
specify the individual time zone for each door.
Step 1. Click Drop-down list of Door Group and select “Set”

Step 2. Click the user that can access which door number
Step 3. Click “Modify Zone” and select the time zone for this door number
Step 4. Click “OK” to save
Step 1.
Step 2. Step 3.
Step 4.
4-2-28
3 . Backup
3.1 701ClientSQL Backup and Restore data under File Base System Mode
　　The procedure of Backup data:
Select “Backup Restore＂ under Setting menu
Step 1. Select the path of the Backup data

Step 2. Click＂ Backup＂ button to execute Backup.
Step 1.
Step 2.
　The procedure of Restore data :
Select “Backup Restore＂ under Setting menu
Step 1. Select the path of the Restore data

Step 2. Click＂ Restore＂ button to execute Restore.
Step 1.
Step 2.
4-2-29
3. Backup
More Details:
FAQ : How to copy attendance information from A to B computer?

FAQ : Backup and Restore 701 Server and Client from old PC to new PC
3.2 701ClientSQL Backup and Restore data under Data Base System Mode
　　For the procedure of Backup and Restore data, please refer to the link for detail steps:
　　SOYAL official website--Resource download Section
3.3 Import and Export User Card Data
Before import / export user card data, please firstly go to set up Import / Export Format of Card under the Tools
menu
The user card format setting window will pop-up by choosing Import / Export Format
of Card under the Tools menu
Step 1. There are 17 fields (A ~ Q) of Item List Sequence. If you don't need some fields, please select
"M" in the fields and these fields won't be shown in the exported file. You can give each field a
file title according to your needs.
Step 2. Item Space: select the separator symbol of exported data. Please select "Tab" as the
separator symbol to prevent mismatch especially when you export .csv file.
Step 3. Import/Export Range: select the range of user data to be imported/exported.
Step 1.
Step 2.
Step 3.
4-2-30
Before import / export user card data, please firstly go to set up Import / Export Format of Card under the Tools
menu
•After complete the setting of import / Export Format of Card, then go to Edit User Card to import / export
user card data
•Please note that the format of import and export must be same setting
•The import and export format is a text file format (.txt), which can be rename format to .csv file and edit
user card data in Excel. After edited, save the file format from .csv file back to .txt file (separated
by Tab characters) (*.txt)
More Details:
FAQ : How to use “import/export to text file＂ function to edit card efficiently through
text file or excel?
FAQ : How to import/export user database to/from text file in 701Client
FAQ : Our client wants to update the software and export card from user address 100
to 200. How to set the range for…
4-2-31
3. Backup
3.4 Download To Controller
　　The settings have to download to the access controller to synchronize all settings between the host PC and the
access controllers.
There are two ways to open the “Download To Controller” window: and .
Step 1. Select Area name

Step 2. Tick the Node ID of the access controllers or click “All On-line＂ button to select the
access controllers. Please make sure all access controllers are ticked (no more, no less)
or some errors may occur while downloading data.
Step 3. Function Download
•Clock: click “Clock＂ button to synchronize time first. This step is very critical for
time-related access control
•Time Zone: click “Time Zone＂ button to download time zone data
•Door Group: click “Door Group＂ button to download door group data
•User Card: click “User Card＂ button to download user data
•Holiday: click “Holiday＂ button to download holiday data
•All Items download: download item1~item 5 to selected controllers in sequence
•Alias/Start Date: click “Alias/Start Date＂ button to download alias and start date data
Step 4. Auto download: download all above items to selected controllers
Step 5. Check the download process through the status bar
Step 6. Click “Exit＂ to close the window.
Step 3.
Step 4.
Step 1.
Step 2.
Step 5. Step 6.
More Details:
FAQ : When Download User Card data to Reader, Why it always Stop Downloading
in the same User Address?
FAQ : How to download user data to the reader? How to solve download error?
FAQ : The connection with PC is normal. Why it will show “No Destination
Controller＂ when download card user to controller?
4-2-32
3.5 Single User Card Download
　　Function：Download the user card setting at the current User Num to the selected controller
Step 1. Download user card setting including card ID, Alias, Date Limits and so on
Step 1.
3.6 User Card Data Download - Read/Write to 7xxH
　　Function: Download the card ID , password and access mode of the specified user address range to the
specified controller
Step 1. Start 701ClientSQL software, select “Read/Write to Cxx” under Edit User Card Setting Window
Step 2. Select Controller Structure and Model
Step 3. Select Node ID of Controller
Step 4. Select “Write” that mean Write user data from software to controller
Step 5. Click “Start”
*It is suitable for pre-downloading [emergency card ] list to RS485 reader under multi-door controller , so the
user card can be used to access in case of situation that RS485 readers are disconnected from Multi-door
controller
4-2-33
3. Backup
Step 3.
Step 4.
Step 5.
NOTE Step 1.
Step 2.
NOTE
If the Card Data cannot be download correctly, it must caused by the range error in "Tools"-->"Import/Export
Format of Card" option. The default range is set up 1 ~ 200, please modify the Import/Export range if your
demand is excess. Setting details please refer to 7.3 Import/Export User Data
More Details:
FAQ : How to read card information from controller?
FAQ : How to read card information from one controller?
FAQ : How to recover reader to work on stand alone when it disconnecting with
AR-716E?
12-15 4-2-34
4 . Time Attendance
4.1 701ClientSQL Time Attendance Setting Introduction

　　Six Features of Attendance :
•Automatically take first and last transaction records as Duty record to calculate Attendance
•File base or SQL Data base structure, flexible selection as needs
•Manual or automatic modification of Attendance report
•The salary calculation function can meet the needs of small and medium enterprises that need to
provide labor and health insurance rate calculation.
•The summary function provides various types of attendance summary report according to the specified
period and condition
•Automatic or manual transaction export file that can be integrated with 3rd party salary system; the exported
items can be specified as needs.
　　Applicable models for Attendance :

•LCD Screen Controller :
AR-837-E AR-327-E AR-727-E
•Biometric Controller : AR-837-EF / AR-837-EA
　　
AR-837-EF9DO AR-837-EA
　　Flexible Enable / Disable Attendance Mode
　　Assigned as an attendance Controller: Keypad type : Enterprise E Series and Home H series; Setting
via Software: 701ServerSQL , Controller Parameter Setting ( Enterprise E Series)
4-2-35 12-16
4. Time Attendance
4.2 701ClientSQL Attendance Setting
Setting Menu: System Parameter, Salary Edit

Tools Menu: Time Attendance Export Format --> export to ERP, the 3rd party system
for integration
ERP, the 3rd party system
System Parameter
Salary Edit - Set salary conditions for each

employee according to personal needs
The related time attendance setting icon on Menu
1 Print 4 Daily Report 8 User Card Edit B Time Zone Edit E User Pictures
2 Re-Login 6 Month Report 9 Door Group Edit C Attendance Edit F Download Data
3 Daily Records 7 Summary Reports A Door Name Edit D Holidays Edit G Controller Status
I View option
4-2-36
4.3 701ServerSQL Attendance Structure
　　Attendance Setting on 701ServerSQL
Select Time Attendance under the Setting menu
Step 1. “Time attendance Base On＂: you can decide how the time and attendance is reported
from the two choices: Work Time [ First and Last Records ]: The first record
(first record after Duty Start time 3:59) and the last record (last record before Duty Start time 3:59
next day) will be attendance record to be integrated with ERP or the 3rd party system software.
Depend On [ Duty Function Key ]: The system will follow the shift type shown on the LCD screen
of access controller, for example: "Duty: 0,Duty: F; OVT: 0, OVT: F" as time attendance records.
Step 2. Duty Start Time [Day Shift]: designate the beginning time of day shift.
Step 3. Automatically Synchronize time clock on computer to controller at program start
Step 4. Backup message (*.msg ) file to second folder ( the second folder shall not be assigned at Disk C)
Step 5. When PC startup, actively execute Client.exe. The function is used when set up exporting daily
transaction at a assigned time on 701Client C:\Program Files (x86)\701Client\Client.exe
Step 6. Click Yes to exit after setting.
Step 1.
Step 2.
Step 3.
Step 4.
Step 5.
Step 6.
More Details:
FAQ : Why the detail information on 701Client will show A: On Duty?
FAQ : Why can´t I set up user number after 4999 at User card Edit of 701Client ?
4-2-37
4. Time Attendance
4.4 Holiday
There are two ways to open the “Holiday Edit” window: and .
Step 1. Click the date to set holiday. The date of holidays is highlighted green. Other dates are work day
without green highlight.
Step 2. •Save Text：Only use for Attendance
•Save Office Day : Save holiday settings to *.wth file
•Read Office Day : Read .wth file to holiday setting window
Step 1.
Step 2.
NOTE
Step 2.
NOTE
Save As : Save as holiday setting to specialholiday.hol file that is used for special holiday such
as national holiday or new year holiday's overtime pay.
※Before saving as specialholiday.hol file, the normal .wth file shall be deleted to avoid confusion
between two holiday files.
More Details:
FAQ : How to set user card can enter door from 8:00 to 17:00 but cannot enter door
on holiday?
4-2-38
4.5 System Parameters Setting
The way to show the “System Parameters Setting” window:
Step 1. Time Attendance Settings: you can choose to set shifts of attendance in monthly table
or weekly table here.
Step 2. Tick these items that will show in monthly report and decide whether the monthly report includes
Attendance data, Salary data and insurance data or not.
Step 3. Add/delete leave type on Report:
a. Leave item means if it will affect non-leave bonus when the staff ask for leave.
b. Deduction item means if it will deduct salary when the staff ask for leave.
(See Also: Salary Edit, Daily Time and Attendance Report)
c. Report item means once this item is chose, there will be to show this leave type in Multi-day
Time and Attendance Reports and Multi-day Time and Attendance Summary Reports.
Step 4. Duty Hours Depends On Office Time or Real Off Duty Time: For example, if 08:30 on duty, lunch
rest is 1.5 hours and 18:00 off duty. Tom works from 8: 03 to 18:30. If choose office Time, duty
hours will show 8 hours in the report. If choose real off duty time, duty time will show 8:57 hours in
the reports.
Step 5. Overtime Duty Base (Min): for example, we set the time is 30 minutes, the state time of overtime
is 18:00 and if the duty off time is 18:29 that is less than 30 minutes, then it will not be calculated
as overtime pay but only display overtime records in report.
Step 6. The function is suitable for factory attendance management; it will automatically deduct meal time
from overtime.
Step 7. Insurance setting is used for Taiwan.
Step 8. Insurance value is only used for Taiwan.
Step 9. Click "OK"
4-2-39
4. Time Attendance
Step 3.
Step 1.
Step 2.
Step 4.
Step 5.
Step 6.
Step 7.
Step 8. Step 9.
More Details:
FAQ : How to set the correct insurance rate for one year?
FAQ : How to add/delete special “leave＂ type except default "leave" type?
4-2-40
4.6 Attendance Shift Setting
There are two ways to open the “Attendance Edit” window: and .
Step 1. Based the time attendance setting of Monthly table or Weekly table
on System Parameter, there have two types of duty attendance.
Step 2. Select duty group: There are up to 50 sets of Office Hours settings. Operator can assign a group
name for each Office Hours setting. There are max. 20 characters for the group name.
Step 3. Enter respectively On Duty, Break Out, Break RTN, Off Duty, Over Time.
(Note: if Over Time set 00:00, the duty off time will be taken as the start time of overtime. If there
are no overtime pay, please set Over time at 23:59. )
Step 4. Select Flex Time: for example, if duty on time is late, duty off time and overtime will automatically
be prolonged.
Step 5. Click Save to exit.
Step 2. Step 4.
Step 3.
Step 1.
Step 5.
4-2-41
4. Time Attendance
Step 1.
Step 2. Step 4.
Step 3.
NOTE
Step 5.
NOTE
You can use "Copy to Buffer" button and "Paste from Buffer" button to set monthly shifts more
efficiently. The time shift will be copied and pasted by the corresponding date of each month.
※The system support multi- duty group but doesn´t support 2-shifts or 3-shifts.
More Details:
FAQ : How to edit "Work Zone" based on monthly date instead weekday?
4-2-42
4.7 Employee Attendance Data Setting
There are two ways to open the “ User Card Edit ” window:
Step 1. User Num: Enter User address and the first address is 00001 ; Be advised to set User num
is same as Employee ID
Step 2. Access Mode: Set access mode for user and employee; Invalid mode will be not counted
in Attendance.
Step 3. Name: It is necessary item to be fielded. If the name is empty, it will be not counted
in Attendance.
Step 4. Employee ID: the ID can be customized but could not be duplicated in the system.
It is used to export transaction data to EPR system or the 3rd party system integration.
Step 5. Date Limits: Date Limits: Set card expiry date, resigned employee required to setup expiry date
here, daily and monthly report will exclude resigned employee after modification.
Step 6. Depart. 1 and 2: The department name can be directly edited in the field.
Step 7. Duty#: Select duty group,directly modify the custom duty name in the drop down menu.
＊If the executive manager not required to be counted in time attendance report, select [FREE]
at the bottom of drop down menu can exclude specific personnel.
Step 8. Clear one user data: Click this icon, then user data of this page will be cleared.
Step 9. Save: Save all user card settings.
Step 10. Exit: Click exit after setting is finished.
Step 1.
Step 2.
Step 3.
Step 4.
Step 5.
Step 6. Step 7.
Step 8. Step 9. Step 10.
4-2-43
4. Time Attendance
4.8 View Option of Report
　　Before view various reports, please be sure to select the correct view conditions in the viewing parameter set-
ting to avoid data omissions
Click on the toolbar Edits the view options icon to open the setting window
Step 1. Specify Door: select the specific doors to view event logs on these locations
Step 2. Department.1 and Department.2: View transaction records for the users in the assigned
department
Step 3. Start Date/End Date: For Transaction Records and Time and Attendance Report(s). Indicate
that Transaction Records & Time and Attendance Reports are limited in these periods.
Step 4. Select Time Range.
Step 5. Show Range Card Only: For Transaction Records and Time and Attendance Reports. Only in
Range and Sorting are for Transaction Records. Ranges shown indicate that Time and Atten
dance Reports & Transaction Records are limited in these card address ranges.
Step 6. Show Similar String User: Click this item and enter keywords in blank column. Then, the
searching result will be displayed in the reports.
Step 7. Only Error Message: if this option is ticked, only the event logs of error will be shown.
Step 8. Time Sorting: when there are multiple controllers, the event logs can be sorted in ascending
order (by time). However, please note that Time Sorting is a rather time-consuming process,
and it will take a while before the sorted event logs are shown.
Step 9. Only 992E Message: if this option is ticked, when AR-401E is connected, only the event logs
of AR-401E will be shown.
Step 10. Abnormal Events Only: if this option is ticked, only the event logs of abnormal events
(refer to step 24) will be shown.
Step 11. Options of report: For Time and Attendance Report(s).
a.Skip while user name is empty: If there is no user name in User Card Edit, the report for
Daily Time and Attendance Report and Multi-day Time and Attendance Reports will not show
the data of this user number.
b.Skip invalid user: If the access mode of the user is invalid in User Card Edit, the report
for Daily Time and Attendance Report and Multi-day Time and Attendance Reports will
not show the data of this user number.
c.Skip empty record of MonRep: lf there are not transaction record someday, it will not
show this day in the Multi-day Time and Attendance Reports.
d.Skip empty record of MonRep: When user overtakes expired date, it will not show this day
in the Multi-day Time and Attendance Reports.
e.Delay On Duty: Once this item is chose, it will only show delay data in the Daily Time and
Attendance Report.
f.Early Off Duty: Once this item is chose, it will only show early data in the Daily Time and
Attendance Report.
g.NEGL Duty: Once this item is chose, it will only show absence data in the Daily Time and
Attendance Report.
Step 12. Search conditions:
a.Search Conditions: Antipass-back Error
b.Search Conditions: Time Zone Error
c.Search Conditions: Door Group Error
※ To prevent the search process from consuming too much time, please designate a range
of time/card/date when you tick the search conditions in step 19/20/21
4-2-44
Step 13. Only Leave User In Summary Report: For Multi-day Time and Attendance Summary
Reports. Tick the duty type and the result will be displayed on Summary report. For example,
I want to see the information whose are late and early, card range from 1-5 on Oct. 01-10,
2002. The steps is as follows:
Step 1: Set parameter as desired, for example, Start / End Date, Card Range.
Step 2: Click Late and Early item in Only Leave User In Summary Report.
Step 3: Click on the tool bar icon Multi-day Time and Attendance Summary Reports. Then,
the result will show
Step 14. Click OK to exit after setting.
Step 1.
Step 4.
Step 2. Step 13.
Step 3.
Step 5.
Step 6.
Step 8.
Step 7.
Step 10.
Step 9.
Step 11.
Step 12.
Step 14.
More Details:
FAQ : Without work overtime and late, but the time attendance report show “other＂
How to solve this problem?
FAQ : Why do I cannot check card A user´s attendance information after I make
card A user invalid?
Video : 《701 Client》Reports-2_Daily duty report
4-2-45
4. Time Attendance
4.9 Daily Time and Attendance Report View & Procedure of arranging Leave
Daily Time and Attendance Report View & Modification
•Daily Time and Attendance Report is generated to display all attendance records of all employees in each day.
•If controller reader set in Attendance mode, Daily .dut report will be automatically generated once there
are someone to access the device.
•if the controller is not set in Attendance mode, the daily transactions will not generate into duty attendance
report. If change the controller mode afterwards, they daily attendance report could not be generated.
•When only the controller is set in Attendance mode 701Client SQL will calculate Attendance and Salary.
Step 1. Enter User range for view.

Step 2. Click OK to exit.
Step 1.
Step 2.
4-2-46
Step 3. You can select the designated .dut file by clicking or .
Step 4. Click on the tool bar Daily Time and Attendance Report icon, select the duty file to open
(the file format is XXXXXX.dut)
※ Be suggested to click on the first attendance day to open (e.g. the first attendance in January
on January 3) that can improve the convenience of continuous opening other
attendance reports}
Step 5. Click row twice of user num, then enter the editing window of employee attendance for
manual modification.
Step 6. The first item show User number
Step 7. Modify working hours of the employee. All the Time & Attendance data can be modified.
The [ OVT On, OVT Off, Break and Return ] can be modified only when
Attendance type of 701 Server select Depend on Function type. Eva

(If attendance data is modified, there will show Red Mark on the row.) Ben
Step 8. Select Case through the drop down when the employee asks for leave. The system provides
2 leaves one day, for example, CASU in the morning, DUTY in the afternoon. And enter
Leave Hours, it will be related with leave deduction of salary table.
Step 9. [Fix Record] : Click this item; it will lock modification data of this user. Otherwise, once
execute Reflash function, all settings go to original status. Elle
Step 10. Auto Re-calculated: updated and exit. If selected, the field Late, Early, OVT and Case will be
re-calculated and updated automatically based on the change of the field On, Off, OVT On,
OVT Off, Break (Lunchtime TIME-OUT) and Return (Lunchtime TIME-IN).
Step 11. Ok: Updated and exit. If selected, the field On, Off, Late, Early, OVT and Case will be updated.
Step 12. Reflash Daily Time and Attendance Report: This function applies for after Daily Time and
Attendance Report had been run and Attendance Edit is only modified. We just open Daily
Time and Attendance Report and click the daily duty report file one by one, Attendance result
of new Daily Time and Attendance Report will be counted according new Attendance Edit.
Step 13. Click or is to continuously open the daily report of the previous day or the next day.
Step 4.
4-2-47
4. Time Attendance
Step 13.
Step 12.
Step 5.
Step 6.
Step 10.
Step 11.
Step 7.
Step 9.
Step 8.
More Details:
FAQ : When Using Controller without LCD Screen Type for Time Attendance, why
did the daily Report not shown [Duty Off ] Time?
FAQ : If the Duty report shows very strange duty on and duty off time, how can I
solve this problem?
FAQ : How to Set “Leave＂ Duty in advance?
FAQ : If I change the flex time, how to revise the former attendance report?
FAQ : How to save report as Text. ?
FAQ : After check time-attendance information, there is more than 25 hours in daily
report, how do I fix this problem?
FAQ : Why the daily transactions report received two same messages in 701Client?
FAQ : What are these abbreviations of “leaves＂ category in 701 Client?
FAQ : If I have employees who work cross midnight during 8:00pm to 3:00am (next
day), how do I set Attendance Edit?
Video : 《701 Client》Reports-2_Daily duty report
4-2-48
4.10 Monthly Report(Multi-day Time and Attendance report)
　　Before opening monthly report, it is necessary to confirm that all daily time and attendance reports have
been opened one by one in the period, because only after opened the daily duty report, the attendance data such
as absent, leave, late and early will be marked and finally these records will be used for monthly report
calculation.
Step 1. Before opening monthly report, it is necessary to confirm that all daily time and attendance
reports have been opened one by one in the period
Step 2. Before opening monthly report, please go to view options window to set the conditions of report.
Step 3. Set start date / end date, user range and other conditions such as department for report view.
Step 4. Click [OK] to exit
Step 1. Step 2.
Step 3.
Step 4.
More Details:
FAQ : How to save month report (include salary) as .EXL?
4-2-49
4. Time Attendance
First, you need to select the desired date range and user range.
Please open “View option of Report / History” window by clicking or .
Step 5. Select the path you want to save the monthly report(the default path is
C:\Program Files (x86)\701Client\)
Step 6. Click “Save”, the monthly report will be generated. The software only display the first 5 users
reports and the complete reports for all users have been generated and saved in the assigned
path with the file name MonRep210103_00002_00005.xlsx
( YYMMDD_Start User Addr._End User Addr.)
Step 7. View Monthly Report: Open the monthly report file on the default path of
C:\Program Files (x86)\701Client or the assigned path.
Step 8. EXCEL monthly report will display all employee attendance monthly reports in sequence.
If the viewing condition is enabled [No blank data displayed in monthly reports], the
no-attendance holidays will not be displayed in the report.
Otherwise, all days are displayed. Whether to display the leave type field in the report can be
set by [Setting/System Parameter/Leave Type Display Parameters].
Step 9. The calculation results of salary and insurance are displayed in the monthly report.
{Whether to display salary and insurance on report can be set by {settings/system parameters]
Step 10. Click on the sheet to view the monthly report of different personnel.
Step 5.
Step 6.
4-2-50
Step 7.
Step 8.
Step 9.
Step 10.
More Details:
FAQ : How to check personal month report?
FAQ : It does show overtime on monthly report, but why does the total hours of
overtime show "0"?
FAQ : What caused the failure to open the monthly reports.
FAQ : Why The User's Monthly Report in 701Client couldn't display "Duty Hour"
FAQ : Why did 701Client only show the monthly report for 30 users?
FAQ : Why the system doesn't calculate "Full Attendance Bonus" correctly?
Video : 《701 Client》Reports-3_Monthly report
4-2-51
4. Time Attendance
4.11 Multi-day time and attendance Summary Report:

Check attendance related statistics within the specified days of the staff
Before viewing the summary report, please be sure to confirm whether the date range you would check is
correct. Summary report: {Quickly count the personnel's periodic attendance records, for example check the
holiday hours }
Step 1. Go to Edits the view options to set parameter such as department, user card range, Start Date /
End Date, etc.
Step 2. [Only Leave User In Summary Report]: Select the leave type that would show in summary report.
Step 1. Step 2.
Step 3.
4-2-52
There are two ways to open the “ Sum Report ” window: or
Step 4. Generate summary report
Step 5. Click Tools / Save To Text to save the report.
Step 6. Select the path and the file format can be selected Excel or TXT.
Step 7. Click Save to exit
Step 5.
Step 4.
Step 6.
Step 7.
More Details:
FAQ : I need the information of this cards (invalid cards) especially the card numbers
for report generation
Video : 《701 Client》Reports-4_ Summary
4-2-53
4. Time Attendance
4.12 How to export daily transactions to the 3rd party system for integration
(for example ERP system, Payroll system)
Time Attendance Export Format: 701ClientSQL don’t support 3-shift attendance calculation. The function can
export daily transactions with flexibly designated text file for the 3rd system such as ERP system, Payroll system to
integrate.
Step 1. Click [ Tools ]

Step 2. Click [Time Attendance Export Format ]
Step 3. [Begin Date / Ending Date]: The system export data according to designated date range.
Step 4. Set Date format/ Time Format / Insert Character / Zone; there are total 6 zones and it is applied
for 3-shift attendance system or meal expenses calculation. If you select "Zone" for sorting, the
system will take the first record of each zone and sort the card numbers when exporting the
transaction file.
Step 5. Select Gregorian , Reader ID , Duty Name ( it can be flexible defined)

Step 6. ※Run Time Transfer and Daily Transfer At are limited to select one at the same time and could
not be selected together.
•Run Time Transfer : Once this item is chose, When someone swipe card, the system will
automatically and immediately export this transaction record into TXT text file for the 3rd
party system to use. (Note: 701ClientSQL.exe must be kept running during the periods of
transferring)
•Daily Transfer At : Once this item is chose, and enter XX o’clock. For example, we enter
4:00 am clock When it is 4:00 am, the system will automatically export the transaction record
after 4:00 am yesterday and before 4:00 am o’clock today into TXT text file.
(Note: 701ClientSQL.exe must be kept running during the periods of transferring)
•Repeat Transfer: Once this item is chose and enters the interval time
For the example, we enter “00:10” that mean the system will auto update the message report at
each interval 10 minutes
Step 7. •Fixed Output Pathname: Default path C:\Program Files\701 Client, if you want to change
save path, you can click this item and select the path as desired.
•Fixed Output Filename: Click this item, and enter file name as desired. Then every day
transaction will save in one file. We suggest to enter “YYYYMMDD.TXT”.
Step 8. Select Card ID Format as needs
Step 9. Transfer after Sorting: Once this item is chose, the system will automatically filter the first
transaction and the last transaction of each user while exporting the transaction file and sort
them according to the user number.
Step 10. Set Leading String and Ending String of each row as desired.
Step 11. Assign Door: Only transfer the transaction from the assigned controller reader.
{The function of exporting transaction support all controller readers, as long as there is a
transaction on controller reader, it will be transferred out, whether the controller reader is set
as attendance mode or not.
4-2-54
Step 12. Item Order: Select the transferring data items as needs. There are total 10 items.
Step 13. Save Parameter: After setting parameter, If we don’t need to transfer it immediately.
We can click Save Parameter to save
Step 14. Save File : Save above setting as another .att file.
Step 15. Transfer Now: Click the button, the transactions will be immediately transferred to the file at
the designated path.
Step 16. Click Exit after setting.
Step 1.
Step 2.
Step 3.
Step 5.
Step 4.
Step 8.
Step 9.
Step 10.
Step 6.
Step 11.
Step 7.
Step 12.
Step 15. Step 13. Step 14. Step 16.
4-2-55
4. Time Attendance
4.13 Salary Edit
　　The attendance reports can be used for salary calculation, and you can edit the parameters according to each
user first.
The way to open the “Salary Table” window:
Step 1. User: select the user (User Address + User Name) in this “User” drop-down menu.
Step 2. Salary Payment (Hour): hourly rate of the salary.
Step 3. Leave Deduction (Hour): hourly rate of the salary deduction for absence.
Step 4. •1st Overtime Sec. (Min): duration of the first overtime section (time unit: minute).
•1st Overtime Multiple: the scale factor of the first overtime section compared to hourly rate
of the salary.
•2nd Overtime Multiple: the scale factor of the second overtime section compared to hourly
rate of the salary.
•Sat/Sun OVT Multiple: the scale factor of the overtime section on Sat/Sun compared to
hourly rate of the salary.
•Special Holiday Overtime Pay Rate : Salary for overtime hours on special holidays
(rate x basic working hours pay per hour)
Step 5. •Delay Deduction (Min): the salary deduction for late attendance or early leaving.
(calculated in one-minute unit)
•Free Delay Time (Min): the grace period of late attendance or early leaving. If the total
minutes are within this period, no leave deduction will be deducted from the salary.
•Free Delay Times: If the total times of late attendance or early leaving are within this range,
no leave deduction will be deducted from the salary.
Step 6. Nonleave Bonus (full attendance bonus): the employee can only get the full attendance
bonus when the total duration and times of late attendance or early leaving are both within
the limits inputted in the following “Max Delay Min” & “Times” fields.
Step 7. •Lunch Allowance: only effective when this employee signs in before the time range as well as
signs out after the time range.
•Dinner Allowance: only effective when this employee signs in before the time range as well as
signs out after the time range.
Step 8. •Health Insured Val.
•Insured Family
•Labor Insured Val.
Step 9. •Health Ins. Deduct.
•Labor Ins. Deduct.
Step 10. Payment/Description: user basic salary, welfare etc. (in “Desprition” field, you can enter 9
English letters at most).
Step 11. •Birthday: user’s date of Birth.
•Take office: take office date.
•Leave office: leave office date.
•Bank Code: Enter the bank account number of employee
Step 12. Click “Yes” to save all settings.
4-2-56
Step 1.
Step10.
Step 2.
Step 3.
Step 4.
Step5.
Step 6.
Step 7.
Step 8.
Step 11.
Step 9.
NOTE Step 12.
NOTE
To quickly set up salary table for many users, you can use "Copy" button -> select another user ->use "Paste"
button to quickly copy the salary table setting from one user to another user
4-2-57
4. Time Attendance
More Details:
FAQ : How to set up Sat/Sun overtime salary?

Video : 《701 Client》Reports-6_Salary
4.14 Labor / Health Issuance Setting
　　The basic concept of the labor and health insurance report: After the monthly report is opened, it means that
the labor and health insurance has been settled, and the labor and health insurance report will show the amount;
the correct labor and health insurance report will be available after the monthly report is generated.
The way to open the “System Parameter ” window:
Step 1. Confirm or modified the current [Labor and Health Insurance Rate Table] for salary calculation.
Step 2. Click [Insurance Value] to open [Insurance Rate Table]
Step 3. Fill in or Modify the setting on Issuance Rate Table
Step 4. Click OK after Setting is finished.

Step 3.
Step 4.
Step 1.
Step 2. Step 5.
4-2-58
5 . Reports
5.1 Various Reports & Application
　　•Daily Transaction Report : Card ID /Time/Node ID /Name/Employee ID /Function Description / Details

　　•Multi-Day Transaction Report: Card ID /Time/Node ID /Name/Employee ID /Function Description / Details
　　•Daily Duty Report: When someone swipe a card on attendance controller reader, the system will
　　 automatically generate a Daily Time and Attendance Report file with file name format
　　 yyyymmdd.dut and the file will count the attendance data of duty on / duty off /
　　 leave type/late/ early/overtime.
　　•Monthly Report: Count one month attendance data of each user including duty on / duty off /leaves/late/
　　 early/overtime hours.
　　•Summary Report: Count on duty on / duty off /leaves/late/ early/overtime hours based on the
　　 designated conditions
　　•Labor and Health Insurance Report: Accumulate the labor and health insurance deduction based
　　 on the designated conditions.
　　•The Report Title：Set the title/date format/time format of the print form
5.2 Daily Transaction Report

　　•The daily transaction report cannot be modified. As long as someone swipe a card, there will generate
　　 a transaction record. The daily transaction report is real records and cannot be modified.
　　•File Base Mode : When someone swipe card, the system will automatically generate a Daily Transaction
　　 Record file with file name format YYYYMMDD.msg. Default path C:\Program Files \ 701 Server
　　 (for example 20220118.msg)
　　•Data Base Mode : The daily transaction will automatically save to "event log" list into database
　A. Report View – Daily Transaction Report
4-2-59
5. Reports
　B.Report View – Open a daily transaction report (for File Base System Mode)
You can select the designated .dut file by clicking or .
Step 1. Select the file name and click Open (for example we view 20220118.msg report)
Step 2. The transaction report for the date of 2022/01/18 will be displayed in the software.
Step 2.
Step 1.
　C.Report View – Open a daily transaction report (for Data Base System Mode)
You can select the designated .dut file by clicking or .
Step 1. Go to the setting window of View Options – Select the date and sorting conditions and click OK
(for example we view 20210220.msg report)
Step 2. The transaction report for the date of 2021/02/20 will be displayed in the software.
4-2-60
Step 1.
Step 2.
More Details:
Video : 《701 Client》Reports-1_Event Logs
4-2-61
5. Reports
5.3 Multi-day Transaction Report
　 A. Report View – View multi-day transaction report (Query specified door/door group/
department/user and specified range of event log)
Click on the toolbar Edits the view options icon to open the setting window or
Step 1. Select the sorting options. If select two options (EX: Designated Department 1 and
Designated Department 2), then the system will search and display the related
transaction that match both options.
Step 2. Select Start Date / End Date
Step 3. Select user card range
Step 1.
Step 2.
Step 3.
Step 4.
More Details:
FAQ : Transaction record for one user's entry and exit
4-2-62
Step 5. Go to File menu--- Click “ Multi-day View”
Step 6. The multi-day transaction report will be displayed in the software.
More Details:
FAQ : How to check multi-days anti-passback error record?

FAQ : The setting of creating the record of invalid card and multiple failure of card
reading by 701 Client Software
FAQ : How to check out multi-day report for an employee?
4-2-63
5. Reports
5.4 Report Title Setting
　　Before printing, you can set the title of the attendance report as follows.
The way to open the "Report Title Define" window:
Step 1. Input the content of Report Title in Line 1 & 2.

Step 2. Select the format of Append Printing Time.
Step 3. Click "Yes".
Step 1.
Step 3.
5.5 Monitor Format
　　If you want to check who has entered specific locations on a specific date, you can set the function as follows
(please assign the user range in "View option of Report / History" window first):
First, you need to select the locations. Please open "Door Monitor Report Format Define" window
by clicking .
Step 1. Input the desired title label.

Step 2. Enter the contents of "Enter Column String" & "Exit Column String".
Step 3. Select the designated locations of "Enter Door Group" and "Exit Door Group" respectively.
Step 4. Click "Yes".
4-2-64
Step 1.
Step 2.
Step 3.
Step 4.
Go to Setting menu--- Click “ Monitor Format ” .
Step 5. Select the designated msg file.

Step 6. The monitor report will be shown in the following window.
Step 5.
Step 6.
4-2-65
5. Reports
5.6 Check Anti-pass Map

　　When the anti-pass-back function of the system is enabled, you can check the user status as follows:
COM3
AR-716-E16
Server PC
Node ID: 002
RS-485 RS-485
Exit Entrance
AR-837-E AR-727-E
Node ID: 001 Node ID: 002

Door Num: 001 Door Num: 002
Step 1. Please make sure that the following are both enabled: (1) anti-pass-back function for specific
users (2) anti-pass-back door.
Step 2. Select the Node ID of the designated access controller. For example, 002.
Step 3. Select the range of users. For example, 0000 ~ 0049.
Step 4. Click "Read" to view the current status of the users within the selected range.
Step 5. Click the designated user address to modify the user status:
1. Inside 2. Outside 3. Unknown: that indicates this user is temporarily exempted from the
anti-pass-back rule for now. As long as his or her card is
presented to the access controller once, then, this user
has to obey the anti-pass-back rule afterwards.
Step 6. Click "Write".
Step 5.
Step 2.
Step 3. NOTE
Step 6.
Step 4.
NOTE
NOTE
● To modify the number in the fields of "Total Inside (Current Cars Inside)" & "Total Space (Total Parking
Space)", please refer to Page 11 in Chapter 11.
● Clicking "Reset" button will restore all user status within this range to "Unknown".
4-2-66
Application Example：How to reset Anti-passback on EV5 series controller?
Step 1. Execute 701ClientSQL, click “ 8 User Cards Edit” icon on Menu Bar
Step 2. Tick the option of Anti-passback for each user card.
Step 1.
Step 2.
Step 3. Execute 701ServerSQL, Click " 82xEv5 Parameter Setting” icon on Menu bar
Step 4. Tick the two options of Enable Antipassback and Reset Antipassback(TZ61)
Step 3.
Step 4.
4-2-67
5. Reports
Step 5. Tick “Time Zone Edit” icon on menu bar to enter the setting window of time zone.
Step 6. Set different access time zone as needs.
Step 7. After setting, click Save and Download To Controller.
Step 5.
NOTE
Step 6.
Step7.
Step 8. Go to Download Data, click Time Zone to download to controller.
Step8.
NOTE
● Control the entry and exit of turnstile through time zone, if there are repeated swipes or violation , the
controller will sounds 5 beeps) to remind the user anti-passback error.
4-2-68
● 701ClientSQL must keep running; If 701ClientSQL stop running caused by accident power off, we need
to reset the status of anti-passback
NOTE
NOTE
Twice click the row to view
the user card data.
The solution of reset(1) :
Step 1. Set up the controller with Node ID 001 as Entry Door
Step 2. If there occurs the warning of Anti-passback error, click “Read＂ to reset.
Step 1.
Step 2.
4-2-69
5. Reports

Step 1. Set up the controller with Node ID 002 as Exit Door
Step 2. If there occurs the warning of Anti-passback error, click “Write＂ to reset.
Step 1.
Step 2.
Step 1. Select all Node ID
Step 2. If there occurs the warning of Anti-passback error, click “Reset＂ button to reset.
Step 1.
Step 2.
4-2-70
6 . Testing the Setting Result

　　After all the settings are completed, now you can present the user's card to the access controller to see if the
event log is shown correctly in 701Client.
Step 1. Present the user´s card (card site code and card code: 00750 37883) to AR-721-H
(Front Door), AR-727-E (Back Door), and AR-837-E (Warehouse).
RS-485 can connect with 254 access controllers at most.
COM3
Start
AR-716-E
AR-837-E
Server PC
Node ID:002
Node ID:001
Server Door Num:003
RS-485 RS-485
(Warehouse)
AR-721-H AR-727-E
Start
Node ID:001 Node ID:002

Client PC Door Num:001 Door Num:002
(Front door) (Back door)
Step 2. Click " Daily Transaction Record " and select file with today's date, and click “Open＂ button.
Step 3. "TRANSACTION RECORDSxxxxxxxx.msg" tag will be opened and the event logs of today
will be shown in 701ClientSQL.
Index: each event log or message has an index number.

Time: access time (hh,mm,ss).
Station: Node ID of the access controller, for example: "002-01: Front Door"
002: the Node ID of AR-716-E18, 01: the Node ID of AR-721-H, Front Door: the location of AR-721-H
Num: User Address, Tom's User Address is 00001.
Name: user name.
Department: the first department. Tom's first department is RD.
Department:2: the second department. Tom's second department is DP2.
UserID: Employ ID, Tom's employ ID is 8217.
Status: access status.
Detail: access remark.
4-2-71
5. Testing the Setting Result / 7. Import / Export Data
7 . Import / Export Data
7.1 Save to text file

　　Save the current page into .TXT file or .CSV file.
Export various reports to text file or excel file. Step 1.

Step 2.
Step 1. Save to Text: Save daily transaction report, daily duty report, summary report as a new file.
The exported file includes the header and can be saved as a .txt or .xlsx file.
Step 2. File to Text: only support to export daily transaction report and daily duty report; the file
will be automatically saved in the path of C:\Program Files\701Client with the name:
MSGYYYYMMDD.TXT
DUT YYYYMMDD.TXT
Step 3. Select the path and file name
Step 4. Select the file format. (The default is a .TXT text file, if you want an EXCEL file, save it as a .xlsx file)
Step 3.
Step 4.
More Details:
FAQ : How to clear all messages which are saved in the controller?
Video : 《701 Client》Reports-7_Export to Text or Excel File
4-2-72
7.2 Export text file
　　You can export the text file to back up the user card data for file management or related report process.
7.3 Export User data
　　After add new cards, we can export the data to the new text file (. TXT ), which provides an easy way to
edit user data and also can be re-imported in future.
First, please open the “Text Format Define for Card Data Transfer＂ window by clicking
Step 1. There are 17 fields (A ~ Q) of Item List Sequence. If you don't need some fields, please select "M" in
the fields and these fields won't be shown in the exported file. You can giveeach field a file title
according to your needs.
Step 2. AUTO Import and Download: you can designate a time range and if this option is ticked, 701ClientSQL
will automatically download user data to the access controllers during this time period every day.
Step 3. Download to Controller while Import Data: if this option is ticked, when the user data is imported to the
host PC, 701Client will automatically download user data to the access controllers as well.
Step 4. Item Space: select the separator symbol of exported data. Please select "Tab" as the separator
symbol to prevent mismatch especially when you export .csv file.
Step 5. Select export file path.
Step 6. Import/Export Range: select the range of user data to be imported/exported.
(Note: Import/Export Card Data in 701ClientSQL will be restricted by the range limit here, therefore,
please remind that this range include the Card Data you want to Import/Export.)
Step 7. Auto Export to Text File: you can assign 6 time schedules for automatically exporting User Card
Data to text file. This function is very useful for HR to backup user data.
Step 8. Click "OK".
Step 1.
Step 2.
Step 4.
Step 3.
Step 5.
Step 6.
Step 7.
Step 8.
4-2-73
Next, open “User Card Edit＂ window by clicking
Step 9. Click , and select "Export to Text File".

Step 10. Select the path and input file name (the default file type is .TXT, if you want to open this file by EXCEL,
please change the file extension as .CSV).
Step 9.
Step 10.
More Details:
FAQ : I am now importing all the user data (as attached) into the system but
with error.
4-2-74
7.4 Export text files of multiple messages
　　　　You can designate a time range and export all the messages within this period in text files (.TXT).
Click Tools - Files To Text to open the window:
Step 1. Select Start Date & End Date

Step 2. Click "Start". These text files will be exported and stored in C:\Program Files (x86)\701Client.
Step 1.
Step 2.
7.5 Time Attendance Export Format

　　　If you have to calculate multi-shift attendance like three-shift attendance, you can export the event logs of
theaccess controllers of desired format in text files which can be further analyzed by multi-shift time & attendance
software according to your needs.
※Please remind the daily record of the day must be opened up while transfer each day's time attendance, or the
transffering will got failed.
The way to show the “Time Attendance Format Define＂ window:
Step 1. Select Begin Date & Ending Date

Step 2. Select Date Format.
Step 3. Select Time Format.
Step 4. Select Insert Character.
Step 5. Select time zone. There are 6 zones available for the calculation of three-shift attendance, or
meal allowances.
Step 6. Select Calendar type (Taiwan or Standard)
Step 7. Select Reader ID format.
Step 8. Select Duty Name.
Step 9. Select Card ID Format.
Step 10. Set weekday table format by enter the numbers of 1~ 7. For example: 1234567 represents
Mon-Tue-Wed-Thu-Fri-Sat-Sun.
Step 11. Transfer after Sorting: if this option is ticked, the first & last event logs of each user will be selected
and sorted in ascending order by the user address when exporting the data.
Step 12. No Day in File Name: the file name will be given according to the year & month of the event logs.
Step 13. Input Leading String and Ending String.
Step 14. Select specific access controllers to collect the event logs.
*Please setup a virtual door number while the specific controller is always lost after saving parameter.
4-2-75 12-18
Step 15. Present String of Filename: input the string that will be shown at the beginning of the filename.
Step 16. Enclose Symbol to Items: input a symbol that will be shown as a pair of opening and closing
marks of the item.
Step 17. Run Time Transfer: if this option is ticked, whenever there is a new event log, 701ClientSQL
will automatically transfer it (※ 701ClientSQL must be kept normally open).
Step 18. Daily Transfer at: if this option is ticked, 701ClientSQL will automatically transfer event logs at fixed
time every day (※ 701ClientSQL must be kept normally open).
Step 19. Repeat Transfer: if this option is ticked, 701Client will automatically transfer event logs during the
designated time interval every day (※ 701Client must be kept normally open).
※ You can only tick one option in step 17/18/19 since these conditions cannot co-exist at
the same time.
Step 20. Select a Fixed Output Path.
Step 21. Fixed Output File name: if not given, the exported file will be in the filename of yymmdd.TXT.
Step 22. User String (up to 5 strings can be set).
Step 23. Input the department.
Step 24. Item Order: 10 fields in total. You can arrange the order as you want.
Step 25. Click" Save Parameter" to save all settings.
Step 26. Click "Transfer Now" to export the file.
Step 1.

Step 2.
Step 3.
Step 4. Step 7.
Step 5.
Step 10.
Step 11.
Step 12.
Step 22.
Step 13.
Step 15.
Step 16.
Step 14.
Step 17.
Step 18.
Step 19. Step 23.
Step 20.
Step 23.
Step 21.
Step 24.
Step 26. Step 25.
4-2-76
The Setting when the number of designated exporting transaction’s controller

readers is more than 9
When the number of designated exporting transaction´s controller readers is more than 9, we need to set the
operation through Regedit Editor. Add or Modify Regedit parameter: ATT_SEL_READER9 ~ 30;
Designate the node ID of controller that would export transaction data. For example, to export transaction for
controller´s Node ID 77, The value of ATT_SEL_READER9 should be filled in 77 (Decimal) and When cancel
the exporting transaction action, change the value to 0
Please firstly find the setting path in Regedit Editor is :

HKEY_CURRENT_USER-->SOFTWARE-->SOYAL-->701Client-->Settings
Step 1. Add “ATT_SEL_READER＂, Select DWORD (32 Bits), Select Edit --> Add -->
Select DWOD(32 Bits)
Step 2. The Name can be entered the range of ATT_SEL_READER9 ~ ATT_SEL_READER30
Step 3. Select Decimal
Step 4. Enter Node ID in the value filed
Step 1.
Step 2.
Step 4.
Step 3.
4-2-77
More Details:
FAQ : When I transfer time attendance format file, it shows nothing. How to solve it
FAQ : How to export message file as attendance format?
FAQ : Why the report time is not in order when I transfer to Time Attendance Format?
FAQ : How to show one user data in one row in Time Attendance Report?
4-2-78
8 . Project Files Management

　　You can assign a specific path to default files of 701Client if there is a need. Please be careful NOT to change
the default value in the Server PC or some errors may occur.
Open "Project Files Management" window by clicking Setting - Project File:
Step 1. Click "Save As" button and enter the desired project name.
Step 2. Parameter Path: the path of files which are necessary for launch 701Client. The default
parameter path is C:\Program Files (x86)\701 Client\
Step 3. History Path: the path of files (for example: .msg, .dut) which are collected and generated
by 701Server. The default history path is C:\Program Files(x86)\701 Server\
Step 4. User Card: Default.usr
Step 5. Door Group: Default.grp
Step 6. Time Zone: Default.zon
Step 7. Holiday: Default.hol
Step 8. Attendance: Default.wrk
Step 9. Door Name: Default.dor
Step 10. Acces Level: Default.acc
Step 11. Salary: Default.sly
Step 1.
Step 2.
Step 3.
Step 4.
Step 5.
Step 6.
Step 7.
Step 8.
Step 9.
Step 10.
Step 11.
NOTE
The default project name is "Default". The default file names of user card (.usr), door group (.grp), time
zone(.zon), holiday (.hol), attendance (.wrk), door name (.dor), access level (.acc), and salary (.sly) are
"Default" plus each file name extension.
4-2-79
8. Import / Export Data / 9. DI/DO Number Name & Remote Control through Software
9 . DI/DO Number Name & Remote Control through Software

9.1 Edit IO Name
When DI/DO is triggered, 701ClientSQL event log not only shows station number
but also show the IO Number and can be rename to make it easier to differentiate (
example: rename into entrance, emergency door, barrier, etc).
Editing IO Name should follow certain rules:
Maximum IO Name character is 16 characters, should not include [space]

Correct example: 00_04.barrier
Wrong example:
1.00_04.open barrier (include space)
2.00_04.512.openbarrier (exceed 16 characters)
Edit IO Name Menu :
Editing IO Name Menu can be found in Setting menu
● A. Control Label
Select Setting 　　　 Control Label
Control label is editing menu for AR-716-E18 and its expansion IO board control AR-716-E-
8I8O
● B. IO Name
Select Setting 　　　 IO Name
IO Name is for DI/DO listed on Industry Series (AR-727-CM-IO, AR-403 Series, and AR-401
Series)
4-2-80
● A.Control Label – IO Name for AR-716-E18 & AR-716-E18-8I8O
Step 1. Area/Node ID of the AR-716-E18

Step 2. Give a name of AR-716-E18
Step 3. Rename DI onboard DI1-DI4
Step 4. Rename DO onboard DO1-DO4 (K1-K4)
Step 5. Current status of DI/DO onboard, will be displayed after selecting ｀Read´
Step 6. Expansion DI of AR-716-E18-8I8O
Step 7. Expansion DO of AR-716-E18-8I8O
Below is the expansion DI/DO of AR-716-E18-8I8O between onboard number and

701ClientSQL:
AR-716-E18-8I8O Nr. 701ClientSQL Nr. AR-716-E18-8I8O Nr. 701ClientSQL Nr.

CN4 – 1 DI-09 CN1 – 1 DO-09
CN4 – 2 DI-10 CN1 – 2 DO-10
CN4 – 3 DI-11 CN1 – 3 DO-11
CN4 – 4 DI-12 CN1 – 4 DO-12
CN4 – 5 DI-13 CN1 – 5 DO-13
CN3 – 6 DI-14 CN1 – 6 DO-14
CN3 – 7 DI-15 CN1 – 7 DO-15
CN3 – 8 DI-16 CN1 – 8 DO-16
Step 8. Control button menu

Read = to read the current saved setting and status of DI/DO onboard
Write = to save changes IO name after done editing
Exit = to exit editing menu
Step 1. Step 2.
Step 3.
Step 4.
Step 8.
4-2-81
9. DI/DO Number Name & Remote Control through Software
● B.IO Name – IO Name for AR-727-CM-IO, AR-403 Series, and AR-401 Series
Step 1. Area/Node ID
Step 2. Select DI/DO range. Each range shows 16 units of DI or DO.
Step 3. Renaming DI/DO, default value: XX_NN:DIPPPPP / XX_NN:DOPPPPP
XX=Area, NN=Node ID, PPPPP=Physical IO Number
(for DO setting unlike setting of Symbol in Graphic contents, DO starts from
0000 instead of 0512)
Step 4. Control button menu
Step 1. Step 2.
Step 3.
Step 4.
4-2-82
9.2 Reader Status Monitor

　　After downloading data to controllers, now you can use "Reader Status Monitor" function to check the
current controller status, and perform the actions such as open door directly via PC or arm/disarm the designated
controller.
There are two ways to open the “Reader Status Monitor＂ window:
Step 1. Tick the Node ID of the controller. For example, 002 (AR-716-E).
Step 2. Since there are two readers (Reader 001: AR-721-H, Reader 002: AR-727-E) connected
to AR-716-E, you can choose the desired one in “Reader＂ field.
Step 3. Read Status: click “Read Status＂ button, and the current status (door status & arming
status) of the designated reader will be shown.
Step 4. You can enable/disable the arming mode of this reader by clicking “Arming＂ or “Disarm＂
button.
Step 5. There are two open modes for choose: 1. Pulse: the lock will be released only for the
period of Door Open Time and will revert to being locked; 2. Latch: the lock will be kept
released all the time.
Step 6. Click “Open＂ or “Close＂ button to control the door status of the designated reader.
Step 7. Click “Open All＂ or “Close All＂ to control the door status of all readers connected to the
designated controller. For example, when you click “Open All,＂ the locks of all readers
(Reader 001: AR-721-H, Reader 002: AR-727-E) connected to AR-716-E will be all released.
Step 1. NOTE
Step 2. In "User Card Edit" window, when
"Set" in the "Door Group" field is
selected, the access control of time
zone for this user will be inactive.
Step 3. The "Available Door" window will
Step 4.
pop up and you can click "Modify
Step 5. Step 6. Zone" to edit the permitted time
zone of this very door, which would
also be the new permitted time
zone for this user who selected
Step 7.
"Set" in the "Door Group" field.
※ This function can be only
applied to the access controllers
connected to Multi-Door
Networking Controller (AR-716-E).
More Details:
FAQ : The new option of open/close doors online via 701Client
4-2-83
9. DI/DO Number Name & Remote Control through Software / 10. Graphic Animation Software

10.1 About 701Client Graphic Animation
SOYAL 701Client built-in Graphic Animation with Animated Symbol, perfectly combines access control and
various DI/DO status monitoring required by BMS system. The features provide monitoring and remote control
that presents in a graphical manner, allowing manager to intuitively manage and control the status on the site in
real time, and make corresponding feedbacks and actions.
What you can do with 701Client Graphic Animation?
Door Status Monitoring : Monitor door open / close status, alarm status, remote control door relay
on / off, remote arming setting / disarm setting
I/O Status Monitor : Centrally monitor the on/off status of IO devices that need to be monitored
throughout the building
Lift Control : Remote control elevator floor button On / Off
Mailbox Status Monitor : Remote monitor delivering mail, mailbox open / close status, alarm
display when the mailbox is not closed
Alarm Notification : When an event occurs, the graphic picture will pop-up at the forefront to notify
the management staff
Basic Element of Graphic Animation
There are three important elements that create a Graphic Animation feature. It consists of: PIC (Site Plan in
PIC format), Symbol, and POP UP. :
1. *.pic
2. *.bmp
3. Popup Table
4-2-84
*.pic *.bmp Popup Table
JPEG+Symbol BMP+Event PIC+Event
PIC :
PIC file is a format recognized by 701ClientSQL as a composition of Site Plan in JPG file and Animated
Symbol. Before entering Graphic contents editing dialog, you must first click on the existing Site Plan(.PIC).
If the Site Plan is not currently opened, you need to select File > Open Graphic. To create a new PIC select
File > New Graphic, software will open new blank Site Plan and load the JPG file and saved as PIC file format
afterward.
Symbol :
Symbol or Animated Symbol is a set of event in BMP format file that composed of 6 pictures. Each files must
have the same file name with sequential number from 0~5.
POP :
Pop Up is consists of PIC file and events. When a particular event occurs, 701ClientSQL screen will
automatically display and jump to the correspondent Site Plan (.PIC) to notify management in charge.
4-2-85
10.2 Graphic Animation Control Introduction
1. Events
Events are a set of outcome or status shows on 701Client Graphic Animation features. Basically it is a set
of event log in Animated Symbol for in which you could track and monitor per area events are occurring.
Type of Events:
Device
Symbol
I/O Type Events Status
Sequence E Series
H Series 716-E16 716-E18
WG0/WG1
Di 1~4:24~27
Xi 1~8: 0~7
DI
Open 0
Close 1~5
K1~4: 20~23
Support Force ON/OFF
Xo 1~8: 8~15
DO Open 0
Close 1~5
1~16 1~16
Support Force Release/Lock/Arm/Disarm 1 17/18
(Reader) (Reader)
Door Close 0
Door Status
Door Open 1~5
Reader
Disarm/
0
Standby
Arm/
Arming 1
Alarm
Alarming 2~5
Only for AR-837 with AR-403-0202-IR 1~64
Standby 0
Letter Arrival 1
Mailbox
Door Open 2~3
Door open
too long, 4~5
alarming
Support auto release lock 1~64
Elevator Standby 0
Enable Floor
1~5
Access
4-2-86
2. Symbol Introduction
1.Digital IO
1-1Digital Input Status (OPEN/CLOSE)
Digital Input Status could be a button or card holder like in room control system that control the output
Sequence 0 = OPEN
Sequence 1-5 = CLOSE
1-2 Digital Output Status (ON/OFF)
Sequence 0 = OFF
Sequence 1-5 = ON (animated)
2. Reader
Reader has two events reader status to indicate door open or close and arming & alarming status.
At the same time, 701ClientSQL allow remotely control over door and arming/disarming.
2-1 Reader Status (ON/OFF)
Sequence 0 = Door Close

Sequence 1-5 = Door Open (animated)
4-2-87
2-2 Arming, Disarming, and Alarming
Sequence 0 = Disarming / Standby Mode

Sequence 1 = Arming Mode (arming mode has been enabled)
Sequence 2-5 = Alarming Event (animated)
2-3 Remote Control Reader

Remotely control reader door status and arming status in Graphic Animation
Off Door Relay = Close door

Pulse ON = Open door in pulse mode (normal open)
Latch ON = Open door in latch mode (short period release)
ARMING = enable reader in arming mode
DISARM = enable reader from arming mode to disarming/
standby mode
3. Mailbox
SOYAL offer mailbox management system specifically made for AR-837-E Series paired with I/O
Module AR-403-0202-IR for each Mailbox, support up to 64 mailboxes and offer details of events,
such as to monitor each user´s mailbox status: letter arrival, mailbox door status open, mailbox open
too long alarming.
Sequence 0 = Standby Mode / Sequence 1-2= Letter Arrival Notification (animated)

Sequence 3 = Mailbox Door Open / Sequence 4-5 = Mailbox Door Open Too Long, Alarming (animated)
4. Elevator
Graphic Animation for Elevator function support force release elevator floor access remotely. That way
admin could directly and remotely enable specified floor access when required via Software.
Sequence 0 = Standby Mode

Sequence 1-5 = Enable Specified Floor Access
4-2-88
3. Site Plan
PIC is a base map that used to help locating Animated Symbol position and could be a real map of a place
or venue. Client can create their own Site Plan based on the venue and load it to 701Client. Site plan has
two different format; JPG for the first time reloading Site Plan to the software and PIC when Site Plan has
been set up for Graphic Animation and has been allocated with Animated Symbol and Pop Up Parameter.
3-1 Example of Site Plan:
Two-dimensional Picture :
Three-dimensional Picture :
Real On-Site Picture :
4-2-89
Table Format Picture :
Example Structure :
3-2 Creating a Floor Plan (PIC)

Design the desired graphic picture according to the site layout.
Picture Format shall be [.jpg].
Picture pixels should not be larger than the resolution of LCD Screen so it the Graphic
Animation will not affect the efficiency of the display due to the zoom adjustment.
Save Site Plan Picture to the path of C:\Program Files (x86)\701Client.
835px
1900px
4-2-90
Visit SOYAL website for new updates of Site Plan pictures

(available for download)。Here / Download Link QRCode :
4. Animated Symbol
Animated Symbol is a set of picture that changes according to the device´s status. Because of the
dynamic change in between Symbol following the Events, it is called Animated Symbol.
4-1 Example of a set of ‘Arming’ Animated Symbol:
Each Symbol consists of 6 different pictures that is made out of sequence that should conform to
the Events.
Sequence 0 = Disarming / Standby Mode
Sequence 1 = Arming Mode (arming mode has been enabled)
Sequence 2-5 = Alarming Event (animated)
Example when reader is under disarming/standby mode it shows Sequence 0 picture, when
enabling reader in arming mode, it will shows Sequence 1 picture, and shows Graphic Animation
from Sequence 2-5 in repeat when reader is Alarming.
SOYAL Software included Symbol selections that can be found on path C:\Program Files
(x86)\701Client\PopGra after insallation. Symbol type inclusive on 701 Client: Alarm, Arming,
Barrier, Button, CardHolder, DI, Deny, DO, Door, Duress, Elevator, Emergency, Fan, Fire, Lamp,
Mailbox, Motor, Symbol, Panic, Pass, Switch, Window, Zones.
Visit SOYAL website for new updates of Site Plan pictures

(available for download)。Here / Download Link QRCode:
4-2-91
4-2 Creating an Animated Symbol

Design a set of Symbol in maximum 6 different states in 6 different file
Each set of Animated Symbol should conform to Events in term of sequence.
Symbol pixels can be set differently according to requirement and Site Plan size.
SOYAL software created Symbol in five different pixels 48*48(XS) / 64*64(S) / 128*128(M) /
256*256(L) / 360*360(XL)
Symbol format shall be [.bmp] format with transparent background.
Symbol file name must be following the file name code below:
Symbol Name Type Size Sequence Number Extension
A XS
B S
Symbol C M 0~5 .bmp
..... L
Z XL
Maximum Symbol Name is 25 characters and minimum 3 characters; each naming code is separated
with underscores.
The complete file name includes the extension (.bmp) maximum 60 characters.
File name could not include special character such as '+-/*'
Example:
The Type A of Door symbol with XS~XL size is:
\PopGra\Door\Door_A_XS0.bmp ~ \PopGra\Door\Door _A_XS5.bmp ; Recommended Dimension 48*48
\PopGra\Door\Door _A_S0.bmp ~ \PopGra\Door\Door _A_S5.bmp ; Recommended Dimension 64*64
\PopGra\Door\Door _A_M0.bmp ~ \PopGra\Door\Door _A_M5.bmp ; Recommended Dimension 128*128
\PopGra\Door\Door _A_L0.bmp ~ \PopGra\Door\Door _A_L5.bmp ; Recommended Dimension 256*256
\PopGra\Door\Door _A_XL0.bmp ~ \PopGra\Door\Door _A_XL5.bmp ; Recommended Dimension 360*360
Notes: if you are creating new Symbol without Type or Size selection, you can choose any naming code
(either A/B/C/D/E and XS/S/M/L/XL). The naming code for Type and Size is for differentiation between one
type to another when you created multiple types of Symbol.
4-2-92
The examples of symbols are listed below :
Symbol Name Symbol Name
Alarm Fan
Arming Fire
Barrier Lamp
Button Mailbox
CardHolder Motor
DI Symbol
Deny Panic
DO Pass
Doors Switch
Duress Windows
Elevator Zones
Emergency
※The example name of site plan and the symbol are in English.
※If the user changes the items in Symbols.txt to other languages, please remember to modify
the corresponding symbol file name and path name.
※If the software could not find the corresponding symbol in Symbols.txt when editing, the
symbol picture NoSymbol.bmp (95x95) will be displayed in the setting window .
※The file name cannot use special symbols such as '+-/*', otherwise 701ClientSQL could not
be opened normally.
4-2-93
Step 1 Create up to 6 different set of Symbol, more Symbol created means the status will show
more animation and will be more visible.
For example: Create Lamp in Yellow color in six different pixels.
Step 2 Save Symbol to the path of C:\Program Files (x86)\701Client\PopGra by creating a Folder
name LampYellow (must be the same name with Symbol file name).
Please DO NOT REMOVE the existing symbol in 701Client folder, but instead add
Animated Symbol of yours to the folder.
Step 3 Add / Modify 701Symbols.txt

On the same path, open file 701Symbols.txt´ and add LampYellow (must be the same name
with Folder and Symbol file name)
Please DO NOT REMOVE the existing Symbol Name on this file
4-2-94
NOTE
● First code of filename, folder name, and name listed on701 Symbols.txt must be correspondent to one
another. From example above:
File name: LampYellow_X_XXX.bmp
Folder Name: LampYellow
Listed on 701 Symbols.txt: LampYellow
● If there is a mismatched between the three of it, and also the Type and Size code is
incorrect, it will not be able to load on software and will be showed as
Example: LampYellow_X_XS0.bmp is a wrong format; there is no Type X selection
on software.
5. Label
Label is a marking on Symbol to let user easily distinguish between one and another Symbol, moreover
when there are identical Symbol created on the same PIC.
Example here is two of the same Symbol but functions differently (one for elevator, the other one
for arming. The label helps user distinguish between two functions when operating the software.
Label position could be adjusted either up above or down below the Symbol.
4-2-95
6. Devices
Access Controller
Home Series Controller (H Series) Enterprise Series Controller (E Series)
AR-101-H / AR-723-H / AR-721-H / AR-725-H / AR-331-H / AR-331-E&EF / AR-327-E / AR-725-E / AR-727-E / AR-837-
AR-321-H / AR-888-H/ AR-757-H / AR-323-D / AR-888-W E&EE / AR-837-EA /AR-837-EL / AR-837-EF9DO
Control Panel
Multi-door Networking Control
AR-716-E02 / AR-716-E16 / AR-716-E18
Digital I/O Series
Digital I/O Series
AR-727-CM-IO-0804M /AR-401-IO-0808R-U2 / AR-401-IO-0016R

/ AR-401-IO-1709R/ AR-403-IO-0404M / AR-403-IO-0001M-IR
4-2-96
7. I/O Mapping Table

I/O Table Number is a table that contains specific value of DI, DO, and fire alarm on I/O series and
access controller.
Indicator:
1. Control Type :
Point of devices to be controlled to get the monitoring status such as DI, DO, reader
(for door status, arming/alarm).
2. I/O Type :
The type of I/O of the devices going to monitor
Range: Digital IO, Reader, Mailbox, Elevator
3. Physical IO Address / Symbol IO Nr. :

IO Number is a designated number for each of devices´ control type and I/O type. Setting correct
IO Number is crucial as it is differ between reader and I/O mapping. Physical IO Address is the
actual IO number of each Control Type, meanwhile Symbol IO Nr. is a designated number for set
when setting up Symbols, required to distinguish between DI and DO. That is why the difference
for both of it is only required when configuring I/O Series for DO; Physical IO Address start from
0~511, meanwhile Symbol IO Nr. Start from 512~1024.
AR-716-E18 -- DI/DO
Control Type IO Type Physical IO Address / Symbol IO Nr.
AR-716E-K1 Relay (DO) Digital IO 20
AR-716E-DI_1 (DI) Digital IO 24
AR-716-E-8I8O DI 1~8 Digital IO 0~7
AR-716-E-8I8O DO 1~8 Digital IO 8~15
4-2-97
AR-716-E18 and AR-716-E16 – RS485 & Fire Alarm

RS485 CH1 – Controller Node ID 1~8 Reader 1~8
RS485 CH2 – Controller Node ID 9~16 Reader 9~16
Fire Alarm Digital IO 511
Enterprise Series Access Controller (E Series)

Controller Reader 17
Reader under E Series Controller Reader 18
Home Series Access Controller (H Series)

Controller Reader Controller´s Door Number
Example: AR-721-H node ID 1 with door number 1, Symbol IO Nr. = 1.
Industry Series (Digital I/O)

Physical IO
Control Type IO Type IO Num
Address
Digital IO
DI Mailbox 0-510 0-510
Elevator
Fire Alarm Digital IO 511 511
DO Digital IO 0-511 512-1023
Standard Mode VS Cluster Control Mode

SOYAL Industry Series offer standard single layer wiring and cluster control over two layer wiring.
The different between two wiring required different configuration over Physical IO Address and
Symbol IO Nr.
Example Digital I/O controller DI/DO in Standard Mode and Cluster Control Mode in Area00:
Standard Mode (Single Layer)

Physical IO
Control Type Node ID IO Num
Address
DI 0~3 DI 0~3
AR-403-IO-0404M Node ID 1
DO 0~3 DO 512~515
DI 0~3 DI 0~3
AR-403-IO-0404M Node ID 2
DO 0~3 DO 512~515
4-2-98
Cluster Control Mode (Two Layer) – Transparent Transmission

Each device under AR-727CM-IO-0804M control its own DI/DO
Device Device Physical IO Address
Node ID Node ID Symbol IO Remark
(first layer) (second layer) Start Finish Nr.
AR-401-IO-0016R DI 0 15 0~15 Only 8

Node ID 1
DI 0 / DO 16
DO 0 15 512~527 Only 4
Not
DI 0 15 0~15
Supported
AR-727CM-
IO-0804M DO 0 15 512~527
1 (Virtual) AR-401-IO-1709R
MAX 16 units/ Node ID 2
DI 16 / DO 8 / Fire DI 0 15 0~15
CH
DO 0 15 512~527 Only 8
Fire 511 511
AR-403-IO-0404M DI 0 15 0~15 Only 4

Node ID 3
DI 4 / DO 4 DO 0 15 512~527 Only 4
Cluster Control Mode (Two Layer) – Programmable Logic Controller

Each device is reserved 16 units DI and 16 units DO either being used or not, each DI/DO is
programmed by AR-401-IO-0808R-U2
Device Device Physical IO Address
Node ID Node ID Symbol IO Remark
(first layer) (second layer) Start Finish Nr.
AR-401-IO-0016R DI 0 15 0~15 Only 8

Node ID 1
DI 0 / DO 16
DO 0 15 512~527 Only 4
Not
DI 16 31 16~31
Supported
AR-401-IO-
0808R-U2 DO 16 31 528~543
1 (Virtual) AR-401-IO-1709R
MAX 16 units/ Node ID 2
DI 16 / DO 8 / Fire DI 32 47 32~47
CH
DO 32 47 544~559 Only 8
Fire 511 511
AR-403-IO-0404M DI 48 63 48~63 Only 4

Node ID 3
DI 4 / DO 4 DO 48 63 560~575 Only 4
4-2-99
DI/DO Mapping Table under Cluster Mode – Programmable Logic Controller Setting
(AR-401-IO-0808R-U2)
DI/DO under CH1 (Node ID 1-8)
Node ID 1 2 3 4 5 6 7 8
DI 0~15 16~31 32~47 48~63 64~79 80~95 96~111 112~127

Physical
IO Addr
DO 0~15 16~31 32~47 48~63 64~79 80~95 96~111 112~127
DI 0~15 16~31 32~47 48~63 64~79 80~95 96~111 112~127

Symbol
IO Nr.
DO 512~527 528~543 544~559 560~576 577~592 593~608 609~624 625~640
Node ID 9 10 11 12 13 14 15 16
DI 128~143 144~59 160~175 176~191 192~207 208~223 224~239 240~255

Physical
IO Addr
DO 128~143 144~59 160~175 176~191 192~207 208~223 224~239 240~255
DI 128~143 144~59 160~175 176~191 192~207 208~223 224~239 240~255

Symbol
IO Nr.
DO 641~656 657~672 544~559 689~704 705~720 721~736 737~752 753~768
Node ID 1 2 3 4 5 6 7 8
DI 256~271 272~287 288~303 304~319 320~335 336~351 352~367 368~383

Physical
IO Addr
DO 256~271 272~287 288~303 304~319 320~335 336~351 352~367 368~383
DI 256~271 272~287 288~303 304~319 320~335 336~351 352~367 368~383

Symbol
IO Nr.
DO 512~527 785~800 801~816 817~832 833~848 849~864 865~880 881~896
Node ID 9 10 11 12 13 14 15 16
DI 384~399 400~415 416~431 432~447 448~463 464~479 480~495 496~511

Physical
IO Addr
DO 384~399 400~415 416~431 432~447 448~463 464~479 480~495 496~511
DI 384~399 400~415 416~431 432~447 448~463 464~479 480~495 496~511

Symbol
IO Nr.
DO 897~912 913~928 929~944 560~576 961~976 977~992 993~1008 1009~1024
4-2-100
8. 701ClientSQL Path
Files and data related to Graphic Animation feature is saved and available in
C:\Program Files (x86)\701Client
8-1 Site Plan in JPG file
Location: C:\Program Files (x86)\701Client
8-2 Site Plan in PIC file

Location: C:\Program Files (x86)\701Client
8-3 Symbol folder

Location: C:\Program Files (x86)\701Client\PopGra
8-4 701Symbols.txt
A file which contains I/O Name that will be able to show and choose
when configuring on 701ClientSQL
8-5 PopGraphic.tbl
A file which contains saved POP Up Parameters setting

4-2-101
10.3 701ClientSQL Graphic Animation GUI
1 2 3
1 File – Create and Load Site Plan
Part 1.1 New Graphic: Create New Site Plan

Part 1.2 Open Graphic: Open existing Site Plan
Part 1.3 Close
Part 1.1 New Graphic
Step 1. Select File > New Graphic

Step 2. 701ClientSQL will open new blank Floor Plan.
Floor Plan created will be renamed as 701ClientX (X is a sequential number, for example
the first Floor Plan file will be renamed 701Client1, the second one will be renamed as
701Client2, and so on)
Step 3. Select Edit > Graphic contents
Step 4. On the Panel File select Browse to load the Floor Plane image
Step 5. Select desired Site Plan image and select Open. The Site Plan will
Step 6. Load the image to the software and 701Client1.pic is loaded with new Site Plan.
Step 7. Select Save
Step 8. If you are selecting Save As, you can rename and save the file.
NOTE
All of the file saved will be under extension .pic
4-2-102
Step 1.
Step 2.
Step 3.
Step 4.
4-2-103
Step 5.
Step 6.
4-2-104
Step 7.
Step 8.
Step 6.
4-2-105
Part 1.2 Open Graphic to load existing Site Plan
Step 1. Select File > Open Graphic

Step 2. Select saved Site Plan with extension .pic, then select Open.
Step 3. Select Open
Step 1.
Step 2.
Step 3.
4-2-106
Part 1.3 Close Site Plan
Step 1. To Close Site Plan, select File> Close (The operation will change Default.Pic)
Step 2. Click on the right side of the window.
Step 1.
Step 2.
4-2-107
2 Edit – Graphic Animation Setting & POP UP Messages

Part 2.1 Graphic contents: Assigned Animated Symbols for Events and on Floor Plan
in .PIC format.
Part 2.2 Pop Up Parameters: Auto Pop-Up Site Plan when devices received event of
designated conditions.
Part 2.1 Graphic contents:
Step 1.
Step 10.
Step 3.
Step 4.
Step 6. Step 9.
Step 2. Step 5.
Step 7.
Step 8.
Step 1. Load Site Plan Step 6. Label
Step 2. Access Point & IO Num Step 7. Label Position
Step 3. I/O Type (Events) Step 8. Label Text Color
Step 4. Symbol Selection Step 9. Control Button Menu
Step 5. Symbol Position Step 10. Created Animated Symbol List
4-2-108
Step 1. Site Plan Edit (Refer to 1 For more detail on how to load the Site Plan file.)
Step 1.
Step 2. Access Point & IO Num Edit

Area/Node: Select Area and enter device's Node ID
IO Num: Enter IO Number, refer to " I/O Mapping Table" for reference
Step 2.
4-2-109
Step 3. I/O Type (Events) Edit

( I/O Type & Watch: Refer to the " Events " )
I/O Type Watch

Digital I/O DIO State
*Analog I/O AIO State
Door Status
Reader
Arm/Alarm
*Interphone
Door Status
Mailbox
Alarm
Elevator Enable
Step 3.
4-2-110
Symbol Edit
Step 4. Symbol Selection:
Options listed is based on the Symbol name listed on " 701Symbols.txt " and the
availability of Symbol file and the format file name must be correct
Step 5 Symbol Position:
Symbol position can be set by manually entering the X and Y axis position or by
dragging it after Symbol is established.
Step 4.
Step 5.
Example of selecting correct Symbol file in correct format, the Symbol preview will show:
(Preview will show Sequence 1 picture)
Example of selecting incorrect Symbol file or wrong format, the Symbol will not be seen:
4-2-111
Label Edit
Step 6. Label: If label is not required, please skip this step. Enter the Label name that
related to the Symbol.
Step 7. Label Position: Label position need to be set on the first time creating a Symbol.
After that, when editing the position, Label will follow Symbol so dragging Symbol
will also dragging the Label as well
Step 8. Label Text Color: Default color is black, you can manually type RGB code or
select it by dragging the options down to choose color that you want.
Step 6.
Step 7.
Step 8.
Tips on Setting Label Position:

● Label position is following where Symbol is being dragged and positioned on the Floor Plan,
but Label distance with Symbol must be determine in the first place
● Label position can only be changed through Label Position Setting only.
● It is better to enter first fix value in the beginning then do the dragging for positioning
Enter 100 Enter 100
Enter 100 Enter value based on the position

(on top, below, above)
4-2-112
● Label position to Symbol can be on top of Symbol, above the Symbol, or below the Symbol.
1. Label position on top Setting:

of Symbol Symbol and Label positon axis has same value
(Actual test on Symbol Size: XS )
2. Label position above the Setting:

Symbol Label position in Y axis has smaller value. The
smaller gaps value, the further position of Label
within Symbol.
(Actual test on Symbol Size: XS )
3. Label position below the Setting:

Symbol Label position in Y axis has larger value. For setting
up Label below Symbol position, it should consider
the Symbol size.
For example XS (48*48) you can set the Y axis
difference in 50. The bigger the Symbol the bigger
gap value it required to position the Label below the
Symbol.
Example: Symbol in 48*48(XS)
Example in 64*64(S)
4-2-113
Step 9. Control Button Menu

●
Add: to add new Symbol or to copy Symbol (when Symbol is selected)
●
Update: to save changes Symbol after editing
●
Delete: to delete selected Symbol
Step 9.
Created Animated Symbol List
Step 10. All of the Created Animated Symbol will be listed on the window.
Step 10.
4-2-114
Part 2.2 Pop Up Parameters:

Notes:
● Maximum 6 Site Plan opened at the same time, if POP Up open more than six Site
Plan, the seventh Site Plan opened will replace the first Site Plan.
● Saved Pop Up Parameters setting is saved on PopGraphic.tbl
● The event trigger and devices does not always needed to be included into the Site
Plan (PIC)
For example: entrance controller in Area00, Node ID 5 with IO number 17 will
be the event trigger with conditions reader > door status to auto open Plane File
Warehouse.PIC (entrance controller does not include in Warehouse.
PIC but will triggering Warehouse.PIC when door is opened).
Step 6.
Step 5.
Step 3. Step 1.
Step 2. Step 6.
Step 4.
Step 1. Select PIC file Step 4. Pop Up Conditions
Step 2. Access Point & IO Num Step 5. Created Pop Up List
Step 3. I/O Type (Events) Step 6. Control Button Menu
4-2-115
Step 1. Select PIC file

Select saved Site Plan in PIC format that has already included with Animated Symbol
and have been preprogrammed on Graphic contents setting
Step 1.
Step 2. Access Point & IO Num

Site Plane, I/O Type, Access Point, and IO Num should be the same between setting in Graphic
contents and Pop Up Parameters.
Graphic contents Pop Up Parameters
Step 2.
4-2-116
Step 3. I/O Type (Events)

Site Plane, I/O Type, Access Point, and IO Num should be the same between setting
in Graphic contents and Pop Up Parameters.
Graphic contents Pop Up Parameters
Step 2.
Step 4. Pop Up Conditions

Pop Up Conditions can be selected and differentiate between Event Type.
Enabling certain Pop Up Conditions could enable certain events to automatically
Pop Up Graphic Animation on screen.
Step 4.
4-2-117
Event Type Conditions to Enable Pop Up Description
DIO-ON DI Close / DO ON
Digital IO DIO_OFF DI Open / DO OFF
DI Break/DO Blank Do Blank = continuously blinking pulse signal ON
Door Status Door Open
Reader Access User access on selected reader

Reader
Reader Arming Reader entering arming mode
Reader Egress User exiting by pressing push button
New New letter arrival notification
Mailbox Open Mailbox door open
Alarm Mailbox door open too long, alarming
Step 5. Created Pop Up List

Every new event condition created and selected ｀Add New Event´, it will be showed
on Pop Up List window.
Step 5.
4-2-118
Step 6. Control Button Menu

Remove: to delete selected Pop Up Events
Update: to save changes Pop Up Parameter after editing
Exit: exiting Pop Up Parameter setting
Add New Event: to add new Pop Up Event or to copy Pop Up Events
(when Pop Up is selected)
Step 6.
Step 6.
4-2-119
10.4 Example
Example show a test using devices from controller, reader, IO module series starting from
the planning on wiring diagram, corresponding IO number, what point or IO to monitor until
the real test once the setting is ready.
This real test is single PC testing, without enabling TCP-LINK feature.

To enable TCP-LINK features
please refer to 701 Software Ver 10.2 Installation Guide

by scanning QRCODE-->
Or link --> here
This example also mentioned only required setting according to example of installation.
If required more coverage of Software quick guide manual, refer to:
●
701ServerSQL refer to C:\Program Files (x86)\701Server\701Server Quick Start.pdf
●
701ClientSQL refer to C:\Program Files (x86)\701Client\701Client Quick Start.pdf
(Both files are available after you download 701 Software. Or go to SOYAL website >
resources download for more info.)
This real test example will cover several parts as listed below:
Part 1. Architecture Diagram:

Part 2. Configuration and I/O Mapping Table
Part 3. 701ServerSQL Setting: Access Point Setting
Part 4. Load Site Plan
Part 5. Graphic Animation Setting
Part 6. Save Changes Setting
Part 7. POP UP Messages
4-2-120
Part 1. Architecture Diagram:

Download link--> here
4-2-121
Part 2. Configuration and I/O Mapping Table:
Device Node ID Subnode Device Type I/O Type I/O Num
AR-837-E
1 *Controller
(Elevator Controller)
AR-401-IO-0016R 1 Elevator Panel Elevator B2~6F:1~8
AR-837-EA-T
2 *Controller Reader 17
(Entrance)
LPR IP Camera WG Port Reader Reader 18
DI0 Fire: 511

DI1 Parking Entrance: 1
AR-727-CM-IO-0804M
3 *TCP_IO DIO State DI2 Parking Exit: 2
IP: 192.168.1.174
DO0 Remote Open Barrier: 512
DO1~DO2: WG signal
AR-403-IO-0404M
DI0~DI1 Front Recognition: 0~1
Setting as RF/FF Falling 4 *RS485_IO DIO State
DO0 Barrier Open: 512
Mode via Commview
*required connection setting to 701Server
Part 3. 701ServerSQL Setting: Access Point Setting
Step 1. Run 701ServerSQL software
Step 2. Select ---> Select Area: Area00
Step 3. Area Communication Port: COM:5

Step 4. Save Current Data
Step 5. Yes
Step 2.
Step 3.
Step 4. Step 5.
4-2-122
Step 6. Select --> Area00
Step 7. Setting based on Configuration and I/O Mapping Table on Part 2

727CM CH1: 1621
727CM CH2: 1623
Step 8. Yes
Step 6.
Step 7.
Step 8.
Part 4. Load Site Plan

Step 1. Run 701ClientSQL software
Step 2. Select File --> Open Graphic
Step 3. Select Edit --> Graphic contents
Step 4. Select Browser
Step 5. Select Structure-en.jpg then click ｀Open´. The jpg file will load into 701ClientSQL
Step 6. Select File --> Save
Step7. Rename it as Structure.pic
Step 2.
4-2-123
Step 3.
Step 4.
Step 5.
4-2-124
Step 6.
Step 7.
4-2-125
Part 5. Graphic Animation Setting
A. Setting Elevator Controller of Reader Node ID 1

Node
Device Subnode Device Type I/O Type I/O Num
ID
AR-837-E
1 *Controller
AR-401-IO-0016R 1 *Elevator Panel Elevator B2~6F:1~8
A-1 Create a new Symbol and Label:
Step 1. ●
I/O Type: Elevator
●
Watch: Enable
●
Label: B2 (Floor Button)
●
Area: Area00
●
Node ID: 1
●
I/O Num：1
●
Initial Position:
(The new Animated Symbol created will show on the list.)
Step 2. Click ｀Add

Step 3. The existed Animated Symbol will create a new copy and listed on the above.
Step 3.
Step 1.
Step 2.
4-2-126
A-2 Drag the position of the Symbol to the desired position.
B2
B2
A-3 Create the next Symbol for other Floor Button.
Step 1. Select the existed Animated Symbol that has been created
Step 2. Click ｀Add´
Step 3. The existed Animated Symbol will create a new copy and listed on the above.
Step 4. Select one of the Animated Symbol and change the setting, Label: B1; IO Num: 2
Step 5. Click ｀Update´ to save changes
Step 6. Select ｀Exit´
(Drag and Position the Symbol to the desired position like mentioned on ｀2. Drag the
position of the Symbol to the desired position.´ Repeat the same process for the rest of the
elevator Floor)
Step 6.
Step 3.
Step 1.
Step 2. Step 5.
Step 4.
4-2-127
A-4 The finished setting and positions
6F 5F 4F 3F 2F 1F B1 B2
4-2-128
B. Setting Entrance Reader (AR-837-EA-T) and LPR IP Camera

AR-837-EA-T
2 *Controller Reader 17
LPR IP Camera WG Port *Reader Reader 18
B-1 Entrance reader node ID 2 setting
● Reader Door Status:

Step 1. I/O Type: Reader
Step 2. Watch: Door Status
Step 3. Symbols: Door, Type D, Size M
Step 4. Label: Entrance
Step 5. Area: Area00, Node ID: 2, IO Num: 17
Step 1. Step 2.
Step 3.
Step 4.
Step 5.
● Reader Arm/Alarm Status:

Step 2. Watch: Arm/Alarm
Step 3. Symbols: Arming, Type A, Size M
Step 4. Label: Entrance
4-2-129
Step 1. Step 2.
Step 3.
Step 4.
Step 5.
B-2 LPR IP Camera Setting
● Parking Lot Barrier Status：

Step 2. Watch: Door Status
Step 3. Symbols: Barrier, Type A, Size S
Step 4. Label: Parking_WG
Step 1. Step 2.
Step 3.
Step 4.
Step 5.
4-2-130
B-3 Finished Setting and position:
1 Parking Lot Barrier status (Open/Close)
2 Reader control and monitoring

Entrance door open or close and remotely force open door or close door.
3 Monitoring status of reader entrance is arming, disarming, or alarming.

Remotely control arming/disarming status
1 Entrance 2
Parking_WG
Entrance 3
4-2-131
C. AR-727CM-IO Setting

DI0 Fire: 511
DI2 Parking Exit: 2
AR-727-CM-IO-0804M
3 *TCP_IO DIO State DO0 Remote Open Barrier:
IP: 192.168.1.174
512
DO1~DO2: WG signal
● DI0 Fire Alarm Setting:
Step 1. I/O Type: Digital IO

Step 2. Watch: DIO State
Step 3. Symbols: Fire, Type A, Size M
Step 4. Label: Fire Alarm
Step 1. Step 2.
Step 3.
Step 4.
Step 5.
4-2-132
● DI1 Parking Entrance monitoring:

Step 3. Symbols: Alarm, Type B, Size XS
Step 4. Label: Car at entrance
Step 1. Step 2.
Step 3.
Step 4.
Step 5.
● DI2 Parking Exit monitoring:

Step 3. Symbols: Alarm, Type B, Size S
Step 4. Label: Car at exit
4-2-133
Step 1. Step 2.
Step 3.
Step 4.
Step 5.
● DO0 Parking Lot barrier force open:

Step 3. Symbols: Barrier, Type B, Size M
Step 4. Label: Force Open
Step 1. Step 2.
Step 3.
Step 4.
Step 5.
4-2-134
The finished setting and positions
1 Monitoring Status when car is present at entrance and exit
2 Force Open parking lot barrier button

3 Monitoring status of fire alarm event
1 Car at entrance
Parking_WG
Entrance
Car at exit
Entrance
Force open
Fire Alarm
4-2-135
D. Parking Lot direction recognition (AR-403-IO-0404M):

DI0~DI1 Front Recognition:
AR-403-IO-0404M
0~1
Setting as RF/FF Falling 4 *RS485_IO DIO State
DO0 Barrier Open: 512
Mode via Commview
● Parking Lot direction recognition setting:

Step 3. Symbols: Lamp, Type E, Size S
Step 4. Label: Loop_0
Step 5. Area: Area00, Node ID 4, IO Num 1
Step 2.
Step 1.
Step 3.
Step 4.
Step 5.
4-2-136
● DI1 Second loop setting：

Step 3. Symbols: Lamp, Type E, Size S
Step 4. Label: Loop_1
Step 1. Step 2.
Step 3.
Step 4.
Step 5.
4-2-137
● DO0 Barrier Open Status:

Step 3. Symbols: DO, Type A, Size S
Step 4. Label: Open
Step 1. Step 2.
Step 3.
Step 4.
Step 5.
4-2-138
The finished setting and positions
1 Monitoring status of barrier loop signal

2 Barrier open status (can also be used for remote open)
1 Loop_0 Loop_1 Car at entrance

Parking_WG
Entrance
Car at exit
Open
Entrance
2
Force open
Fire Alarm
4-2-139
Part 6. Save Changes Setting
After load Site Plan and configuring Animated Symbol, save changes all of the setting.
Select File --> Save
Part 7. POP UP Message
POP UP messages is auto open Site Plan (PIC) in 701ClientSQL when a certain event
triggered. The event can be set based on the applied conditions.
For this example, select each events from each I/O Type:
Node
Device Subnode I/O Type I/O Num POP UP
ID
AR-837-E
1
AR-401-IO-0016R 1 Elevator B2~6F:1~8
AR-837-EA-T 1.Reader Access

2 Reader 17
(Entrance) & Reader Arming
WG
LPR IP Camera Reader 18
Port
DI0 Fire: 511
2.Fire Alarm (DI)
AR-727-CM-IO-0804M DI2 Parking Exit: 2
3 DIO State 3.Car at entrance (DO)
IP: 192.168.1.174 DO0 Remote Open
4.Car at exit (DO)
Barrier: 512
DO1~DO2: WG signal
AR-403-IO-0404M DI0~DI1 Front
Setting as RF/FF Falling 4 DIO State Recognition: 0~1 5.Barrier Open (DO)
Mode via Commview DO0 Barrier Open: 512
12-39 4-2-140
Events triggered POP UP Messages:
Loop_0 Loop_1 Car at entrance Entrance

3 Parking_WG
Car at exit 1
Open 4 Entrance
5
Force open
Fire Alarm
Step 1. Select Edit --> Pop Up Parameters

Step 2. Select Panel File which means select Site Plan that has been saved in PIC format
Step 3. Select Structure.pic --> Open
Step 1.
Step 2.
4-2-141
Step 3.
Step 4. Start setting up the conditions for POP UP Messages.
● Part 1. Entrance Reader AR-837-EA-T with POP UP Site Plan under Reader Access
and/or Reader Arming Status
Step 1. Event Type: Reader

Step 3. Conditions: Reader Access Reader Arming
Step 4. Select ｀Add New Event´. It will be added to the created POP UP list.
4-2-142
Step 1.
Step 2. Step 4.
Step 3.
● Part 2. Fire Alarm POP UP Message
Step 1. Event Type: Digital IO

Step 2. Area: Area00, Node 3, IO Num 511
Step 3. Conditions: DIO-ON
Step 3. Select ｀Add New Event´. It will be added to the created POP UP list
Step 1.
Step 2. Step 4.
Step 3.
4-2-143
● Part 3. Sensing a car at parking lot entrance POP UP Message:

Step 1.
Step 2. Step 4.
Step 3.
● Part 4. Sensing a car at parking lot exit POP UP Message:

Step 4. Select ｀Add New Event´. It will be added to the created POP UP list
4-2-144
Step 1.
Step 2. Step 4.
Step 3.
● Part 5. Sensing parking lot barrier gate is open POP UP Message:

Step 1.
Step 2. Step 4.
Step 3.
4-2-145
After finishing the setting, you can directly operate and monitor the Site Plan.
To return to the editing mode select Edit > Graphic contents or Pop Up Parameters
After done editing, select POPIO Scan to continue monitoring and remotely control
4-2-146
10.5 Reference
1. Sound File
When DI/DO is triggered can be set to follow with specific sound. The sound file can
be assigned to specific IO number.
Sound file will be heard when DI/DO is triggered and only for DI/DO (not for reader)
The sound file is under WAV format
Save the sound file into path C:\Program Files (x86)\701Client\sound
file name should be as followed:
CtlPpxxNNNppppSSSSS.wav
CtlPp = fixed value, every sound file name should begin with ｀CtlPp´
Xx = Area (two digit, range 00~15)
NNN = Node ID of the device (three digit, range 001~254)
Pppp = IO Number (four digit, range 0000~1023)
SSSSS = IO Status, can be set up as the following:
Close, Open, Break（blinking） ON, OFF, Blank (continuously blinking pulse signal ON)
CtlPpxxNNNppppOpen.wav CtlPpxxNNNppppON.wav
DI DO
CtlPpxxNNNppppClose.wav CtlPpxxNNNppppOFF.wav
CtlPpxxNNNppppBreak.wav CtlPpxxNNNppppBlank.wav
.wav = extension WAV format

Example:
CtlPp000040512ON.wav
Area 00, Node ID 4, IO Number 512, Sound triggered when DO is ON
CtlPp000040512OFF.wav
Area 00, Node ID 4, IO Number 512, Sound triggered when DO is OFF
When event log recorded DO events, at the same time DO recorded will also trigger
designated sound file
4-2-147
2. External Link
Download Symbols -->here
Download Site Plan Package (application example, annually posted on SOYAL monthly
E-paper)-->here
3.Troubleshooting
Q1 : Could not open saved PIC file and shows error message
A1 : This error message is occurred because of JPG file renaming after reloading
to the parameter setting of Graphic contents in 701ClientSQL.
BEFORE
Original JPG file that has been renamed Setting of Graphic contents > Panel File
Both of the file name is mismatched, please
change the JPG file into the correct name
Office(1900x835).jpg to match the panel
file setting selection.
AFTER
4-2-148
Q2 : Symbol shows in editing page (File > Graphic contents) but does not show
on Site Plan Setting on Graphic contents, Animated Symbols show:
Finished editing, Animated Symbol does not show on Site Plan (only label appear)
Entrance
A2 : Try to check the BMP format, the format that is recognizes is BMP Windows
Bitmap. If the setting is OS/2 Bitmap, please change into Windows Bitmap.
More Details :
FAQ : RS-485 I/O status monitoring through 701Client Scada For Restroom
Emergency Assist Alarm
Video : 《701 Client》701ClientSQL Graphic Animation Cofiguration Single
Controller
4-2-149
10. Graphic Animation Software / 11. Lift Floor Setting
11. Lift Floor Setting
　　Use 701ClientSQL to set user floor for lift control, manage different floors by assigning access permissions
for each user.
Step 1. Select “8 User Cards Edit＂
Step 2. Select “Tools Box＂-->“ User Access Floor Edit ＂
Step 1.
Step 2.
Step 3. Select [Direct download] or [Bypass through]

Method 1 : [Direct download] means directly download user floors setting to controller reader
DIRECT BYPASS
RS-485 OR TCP/IP RS-485 OR TCP/IP
Start
Server PC Access Control Server PC Multi-Door Access Control

Networking Controller
Step 3.
4-2-150
Method 2 : [Bypass through] means download user floors setting to reader via Multi-door controller.
BYPASS
RS-485 OR TCP/IP
Access Control Server PC Multi-Door Access Control

Networking Controller
　　If the lift controller reader is connected under Multi-door controller, please select [Download through]
and select the Node ID of Multi-door Controller
NOTE
Controller Model Selection
630(701H)
1024(AR-721-H)
3072(725-H/888-H/ Home
H Series Controller Reader)
15000(Enterprise E
NOTE Series Controller Reader)
Step 4. Select Node ID

Step 5. Select User Number
Step 6. Select the floor number that the user is allowed to access
Step 7. Floor Number is up to 64
Step 8. Click [Write One] to write one user floor setting to the lift controller
Click [Read One From 1st Node] to read one user floor setting from the lift controller
Step 9. Save to Text File: Save all the user floor settings to a .TXT text file. The file can be used for Read
from File: Load the user floor setting from .TXT text file
Step 5.
Step 6.
Step 8.
Step 7.
Step 4. Step 9.
NOTE
4-2-151
11. Lift Floor Setting
NOTE
1. Floor Number: Home H series controller support up to 32 floors; Enterprise E series controller
support up to 64 floors
2. Select the Controller Node ID in step 4, it is irrelevent to the Door Number.
3. If each lift's user settings are identical, then we can select all 36 Controllers to download the
settings simultaneously.
4. If each lift's user settings are non-identical, then we need to download the settings one by one, and
must select the 1st option in top left corner.
5. The maximum Node ID supports up to 36, therefore, the Node ID of the controller installed must
between 001~036.
Step 9-1. Click “ Save to Text＂

Step 9-2. The file format can be selected .txt or .csv
Step 9-1.
Step 9-2.
4-2-152
Step 10. Enter the user number range

Step 11. The setting can be saved as a Floor file. It can be used for quick floor setting
Step 12. Click Exit after setting
Step 11.
Step 12.
Step 10.
More Details :
FAQ : Why I set lift control for one new card and then the other cards which have lift
control function become invalid?
FAQ : Why the option" Write All" can not click on User Floor Edit after install the new
701client 8.03 Version?
FAQ : How to edit parameter for lift control?
FAQ : How to assign a user for specific floor & lift and how to read floor assignment
in 701Client?
4-2-153
11. Lift Floor Setting / 12. Special Application
12.1 E-Mail Server Setting
　　Email Server Setting :
SERVER SMTP MAIL SERVER

MAIL SERVER : SMTP.GMAIL.COM
NOTE GMAIL
PORT: 465 or 587
MAIL SERVER : SMTP.MAIL.YAHOO.COM
YAHOO
PORT : 465 or 587
Local Provider MAIL SERVER : WWW.HIBOX.HINET.NET
(Example: ChungHwa Telecom in Taiwan,
Server for Business Email is Hibox)
PORT : 25
※ If you use a Yahoo account as your email server outgoing email notification, please opt “less
secure app access＂. This setting required to grant access for TaskBot to send emails using Yahoo
accounts on your behalf.
NOTE
From May 30, 2022, Google account will no longer support the "Allow access to low-security
applications" function. Please use YAHOO or HIBOX if need the function of send email notifications
via 701Server/701Client software.
4-2-154
　 Yahoo Setting :
(1) Apply a Yahoo account and set “Allow less secure apps: ON”
Step 1. After logged in to your Yahoo Account, on the top right side, select your account
and select “Account info”
Step 2. Select "Account Security"
Step 3. Select "Generate app password"
Step 4. Select Get started
Step 5. Enter 701ClientSQL on Enter your app’s name section --> enter Generate password
Step 6. You will get app password for 701ClientSQL, select Copy.
Step 1.
Step 2.
Step 3.
4-2-155
Step 4.
Step 5.
Step 6.
4-2-156
(2) Yahoo Server Setting on 701ClientSQL
Step 1. Go to 701ClientSQL --> Select "Setting"

Step 2. Select "Access Level and enter "
Step 3. Enter Account password for Mail Server
Mail Server : smtp.mail.yahoo.com
SMTP Port : 465 or 587
User Name : enter Yahoo email address
Password : paste the app password from step 5
Mail From : enter Yahoo email address
Step 4. Click "Save"
Step 1.
Step 2.
NOTE Step 3.
Step 4.
NOTE
● User Name : enter Yahoo email address(含@yahoo.com.tw)
● Password : paste the app password from step 5( abcc ddff gghh jjkk)
4-2-157
12.2 SOYAL QRCode Format Introduction

The standard firmware SOYAL supports QR Code format is as below:
( Other QR Code format can be supported by customized firmware)
QRCo08A12345678
QRCo10A1234567890
QRCo14A12345678901234
QRCo55W1234556789
QRCo08H33CDAB88
QRCo16H001122334455667788
The visitor application need to be set the number of times and the time limit for access, and also lift floor control:
Guest application QRCode format: (only supports Hex format)
QRCo16L11223344556677889999202010211735202101311730FFFFFFFFFFFFFFFF8AF1.
(Modbus CRC16:0x8AF1)
QRCo16L11223344556677889999202010211735202101311730FFFFFFFFFFFFFFFF8AF1
QRCo16L is fixed Head code for SOYAL QRCode Format
11223344556677889999202010211735202101311730FFFFFFFFFFFFFFFF is access data including card ID,
access times, allowed start and expiry date and available Floor Numbers
QRCo16L11223344556677889999202010211735202101311730FFFFFFFFFFFFFFFF8AF1
1 2
1 QRCo16L11223344556677889999202010211735
SiteCode / Card ID
The numbers of access times Start Date

0000 = Invalid 2020 = Year
0001~9998 = The numbers of access times 1021 = Month/Date
9999 = Unlimited times 1735 = Hour/Minutes
2 202101311730FFFFFFFFFFFFFFFF8AF1
Expiry Date Available Floor Numbers Modbus CRC16

2021= Year
1031= Month/Date
1730= Hour/Minutes
Modbus CRC16 use LSB rule conversion range:

11223344556677889999202010211735202101311730FFFFFFFFFFFFFFFF converted to 0x8AF1
4-2-158
12.3 701ClientSQL Email Notification Application Sharing

12.3.1 Application 1: Sending visitor QR CODE to E-mail via 701CllientSQL software
701ClientSQL can convert card ID into a QR code image and also send the image to a designated email, and
the software system can set the access right for the QR code through a specific door group, time period and
valid period (requires with Enterprise E series controller), the QR code will be invalided after the expiry date
0 1 2 3 4 5 6 7 8 9 1 0 3
3
ID CARD
QR Code Proximity Reader LCD QR Code Controller

AR-888-UL AR-837-EL
0 1 2 3 4 5 6 7 8 9 1 0 3
The 3rd
software Plat
SOYAL
SOYAL
Card ID :1562356566
Number of Times : 9999
Start Date : 2020/10/21 17:30
SOYAL
Expiry Date : 2020/10/22 17:35
Available Floors : 6F
TCP/IP
SOYAL
Food
16-Floors Lift Controller

AR-401-IO-0016R
RS485(SSC)
B-
A+
WG
IN AR-321L485-5V
OUT
TCP/IP
TTL 7 8
Touch Keypad IP 5 6
Access Controller 3
1
4
2 1
4
2
5
3
6
9
8
7
AR-725-E
#
0
*
Food CN9
CN11
AR-321L485-5V
B-
A+
QR Code Proximity Reader

AR-888-UL
TCP/IP
DI
DO
WG
IN
OUT
Touchless Infrared
Sensor With Push Button
AR-101-PBI
4-2-159
Sending QRcode to E-mail via 701CllientSQL software
(1) Execute 701ClientSQL software
Step 1. Install 701ServerSQL & 701ClientSQL software

Step 2. Execute 701SQL software and set up Mail Server
Access Control
Mail Server Setting
(2) Gmail Server Setting on 701ClientSQL
Step 1. Go to 701ClientSQL --> Setting

Step 2. Access Level and enter
Step 3. Enter Account password for Mail Server
Mail Server : smtp.gmail.com
SMTP Port : 465 or 587
User Name : enter Gmail email address
Password : enter Gmail password
Mail From : enter Gmail email address
4-2-160
Step 1.
Step 2.
NOTE Step 3.
Step 4.
NOTE
● User Name : Enter Gmail email address (include @gmail.com)
● Password : Enter Gmail password
(3) Enter to “Registry Editor” to configure Email Value

Add "SEND_QRCODE_EMAIL" under Settings/701Client/SOYAL,and Set its value to 1
Step 1.
Step 5.
Step 3.
Step 4.
Step 6.
Step 2. Step 7.
4-2-161
(4) Click "8 User Card Edits" , and enter window to set
Step 1. Select the “User Num＂ to be set

Step 2. Select " Door Group"
Step 3. If the hardware is enterprise version (E series) controller, you can set the date
and time
Step 4. Fill in the email address that would receive QRcode
Step 5. Click Save
Step 6. Click download to write the user card data to controller
Step 7. After clicking QRcode button, the QRcode image will be sent to the designated
email address
Step 7.
Step 1.
Step 2.
Step 3.
Step 4.
Step 5. Step 6.
4-2-162
NOTE
:
Save QR Code Image to the folder

When clicking the button whether or not you configure Email, QR code image will be saved
to the path of C:\Program Files (x86)\701Client\PopGra with the filed name QRCodeXXXX.jpg
(XXXX mean User Address)
(5) QRcode File in Email account

Open Mailbox to check the QRcode image file sent from 701ClientSQL software and then can scan QRcode
image on SOYAL QRcode device AR-837-EL to unlock the door lock for access
More Details :
FAQ : How to use 701Client to send QR Code to assigned Email?
4-2-163
12.3.2 Application 2: Fire Event notification

Access controller under AR-727-CM-IO-0804M that connected to the Fire Detector Control Unit, built-in
fire alarm interlinkage function that could trigger "Fire Alarm (DI0) Open Doors" under fire event, and then
release all door lock of access controllers under AR-727-CM-IO-0804M, at the same time could send email to
designated email address for real time notification of fire event.
RS485 CH1 & CH2 Ethernet/UDP Broadcast
Setting:
NOTE
● Update software & devices firmware version to the latest version.
● Upgrade AR-727-CM-IO-0804M into Firmware version: APX727i3___V0500 8I8O 190930 UDP
FireMessage.STM (If you have functional firmware requirements, please contact SOYAL sales
team)
● There are two ways of wiring to auto release all doors under fire alarm event, through RS485
CH1/CH2 OR Ethernet/UDP Broadcast
1. Update AR-727-CM-IO-0804M firmware
(Upgrade firmware using UDPUpdater software. )
Step 1. Select Firmware file

Step 2. Enter IP address of AR-727CM-V3-IO, Port 1604 , Node ID 001
Step 3. Select Device type “ 727iv3＂
Step 4. Click “Update FW＂to upgrade the customized firmware to device.
4-2-164
Step 1. Step 2.
Step 3.
Step 4.
Step 5.
From 2-5 below, choose one step based on your wiring and release door method.
2. Choosing RS485 wiring method – Open Specified Doors

Step 1. Select "Channel 1 Setting"
Step 2. Fire Alarm (DI0) Open Doors: "Enable"
Step 3. Door Open Mode Select "Keep Latch"
Step 4. Input Selected Node ID maximum 8 different node ID on field "Selected Node ID".
The specified station number range between Node ID 1-254.
Step 5. Select "Update" to save setting.
Repeat the same procedure for "Channel 2 Setting".
4-2-165
Step 2.
Step 3.
Step 4.
Step 5.
3. Choosing RS485 wiring method – Release All Doors

Step 1. Select "Channel 1 Setting"
Step 2. Fire Alarm (DI0) Open Doors: "Enable"
Step 3. Door Open Mode Select "Keep Latch"
Step 4. Input 255 on the first field of Selected Node ID.
Step 5. Select "Update" to save setting.
Repeat the same procedure for "Channel 2 Setting".
Step 2.
Step 3.
Step 4. 255
Step 5.
4-2-166
4. Choosing Ethernet/UDP Broadcast – Open One Specific Door
Step 1. Select "Network Setting"

Step 2. On Secondary DNS Server enter controller's IP Address.
Step 2. 192.168.1.171
5. Choosing Ethernet/UDP Broadcast – Release All Doors
Step 1. Select "Network Setting"

Step 2. On Secondary DNS Server enter 0.0.0.0 to release all doors.
Step 2. 0.0.0.0
4-2-167
6. Create Fire Alarm Event on Registry Editor
Create “Fire Station＂ name on Computer / Registry Editor window by following below steps:
Step 1. Open the Start menu and type “regedit＂ and hit Enter
Step 2. When the Registry Editor open, navitate to HKEY_CURRENT_USER\Software\
SOYAL\701Client, then create a new key file and name it “Fire Station＂.
Step 3. Under＂ Fire Station＂, create a new String Value and name “Fire Event＂
Step 1.
Step 2.
Step 3.
4-2-168
Step 3.
TEST: When fire occurs, 701Client software will receive the message from AR-727CM-V3 (the
message include fire station name, IP address ; At the same time, 701Client software will send the
message to the assigned E-mail address.
More Details :
Video :《Peripheral expansion application》Release door locks Solution
in Fire Alarm Event(2018) | Serial Network Server & Converter AR-727CM-
IO (Needs Customized Firmware)
Video : 《Product Application》TCP/IP Remote IO Control Setting | Two Serial
Network Server & Converter AR-727CM-IO |
4-2-169
12.3.3 Application 3: Alarming Event notification

After the 701ClientSQL receives alarm message in event log forms, at the same time it could forward alarming
event messages to up to 10 groups of management personnel Emails. All of the messages will display the date
and time, location (controller), alarming type of events such as:
Controller's offline Force open
Key-in wrong PIN or

Door open too long invalid card after
maximum error reached.
Setting:
NOTE
● You can set up to 10 different email address to receive the notification
Step 1. Add email address of recipient of the abnormal event

Step 2. Go to Computer\HKEY_CURRENT_USER\SOFTWARE\SOYAL\701Client\Email
Step 3. Right click and select New > String Value
Step 4. New Value is created then right click > Modify > enter email address of the recipient
Step 5. New Value has been set with email address, then right click > Rename > CcExt01
(CcExt01 means the first recipient email, if you create more than one recipient repeat the same
process but rename it differently to distinguish one another; example export@soyal.com is set as
CcExt01, sales@soyal.com is set as CcExt02)
Step 1.
4-2-170
Step 4.
Step 3.
Step 5.
Step 2.
Step 3.
4-2-171
12.3.4 Application 4: Student's absent from school notification to guardian

When a student does not arrive at school during class, the teacher can check the student's attendance status
by using the daily record in the software, and send an email notification to parents that students is not attending
school, so it is parents could get notified real time and know their children attendance status.
NOTE
● Required custom software to support this feature (please contact SOYAL for custom software)
● Messages on the email can also be customize
Sending QRcode to E-mail via 701CllientSQL software
(1) Execute 701ClientSQL software
Step 1. Install 701ServerSQL & 701ClientSQL software

Step 2. Execute 701SQL software and set up Mail Server
Access Control
Mail Server Setting
4-2-172
(2) Click "8 User Card Edits", and enter window to set
Step 1. Enter parents or guardian email address on student's user data's email field.
Step 1.
4-2-173
(3) The operation steps for accessing the list of students who are absent and
E-mail Notification:
Step 1. Go to View > Guest Status

Step 2. 701Client will list the status of student's arrival.
If students have arrived they will clocked in their access to access controller, then
software will show green dot, if students have not arrived to school yet, it will show
red cross.
Step 3. Click the option “Send Email＂, 701Client will automatically send email only
to student´s parents or guardian that has not yet arrived and clocked in.
Step 1.
Step 2.
Step 3.
(4) The mailbox receives a notification of the absent student from school
Step 1. Open the mailbox and you will receive the message. The content shows the name of
the student who did not yet arrive at the school during the school time
4-2-174
12.4 SOYAL Controller Reader is not only used in Access Control but also used for various application
12.4.1 Application 1: AR-837-E Support to Connect Up To 64 Sets of Mailbox
Function Description: When the letter is delivered to the household’s mailbox, the infrared I/O module
installed in the mailbox detects the letter and immediately sends the message to the management computer.
The manager knows which household has the letter through the graphic animation software. The software can
also actively send the message to the third-party system such as property management system for further
integrated applications. The resident can open their mailbox to take out letters by swiping their card on mailbox
reader. The smart mailbox system can instantly display the open/close status of each household's mailbox; If
the resident forgets to close, the manager can assist to remote close the mailbox on the software.
Setting Procedure:
1. Upgrade customized firmware
• 837E Firmware version: APS837E____V0403_191016 USERNAME3_MAILBOX_64_MONI.STM

• AR-403-IO Series Firmware Version: 401_MBox_V0300_191005.ISP
• 701ServerSQL/ ClientSQL Software Version: Upgrade to the latest 10V2 version
(If you need the customized firmware, please contact SOYAL sales)
4-2-175
2. The user address {00000} is used to enter the corresponding 1-64 points on AR-403-IO
Step 1. It is fixed setting to use User Address {00000} for mailbox application.
Step 2. Select the corresponding controller and node ID for download
Step 3. Tick the corresponding Mailbox number ;
For example: Number 01 Mailbox01 = Node ID 001 of AR-403-DI2MO2-IR;
Number 02 Mailbox02 = Node ID 002 of AR-403-DI2MO2-IR;
Number 03 Mailbox03 = Node ID 003 of AR-403-DI2MO2-IR;
One controller can connect up to 64 Mailbox module for 64 mailbox management
Step 4. Click “Write One＂ to write User 00000 setting to Controller.
Step 1.
Step 3.
Step 4.
Step 2.
3. Fill the corresponding Mailbox Number at User Alias field
For example ：User 200 would open Mailbox01 , please fill out 001 at its Alias field.
Step 1.
Step 2.
Step 3.
Step 4. Step 5.
4-2-176
FILL THE CORRESPONDING

MAILBOX AR-403-IO-0202M-IR MAILBOX NUMBER AT ALIAS
FIELD
1 001 001
2 002 002
3 003 003
4 004 004
5 005 005
6 006 006
7 007 007
8 008 008
9 009 009
-- -- --
-- -- --
-- -- --
64 064 064
701Client report will receive the message for Mailbox-New Letter and Mailbox open too long ;
these messages can be actively push to the 3rd party server for integration.
More Details :
FAQ: Smart Mailbox Management Application - One Controller Control 64 mailbox
4-2-177
12.4.2 Application 2: Sharable Parking Lots Solution- Multi-Card Multi-Parking space

Function Description: We will use multi-door controller AR-716-E-16, controller reader, UHF long range
reader and a LCD display board to manage parking lots.
Functional Requirements: The vehicle enters the parking lane, the UHF label is detected by UHF long range
reader.
Structure
Firmware Version: APS721Ev2__V0400_170913 Multi-Card Multi-Parking space CH2
MsgNode3Node4UserName WINLED_CRI1201
IP-Based Multi-Door
Control Panel (16 Doors)
AR-716-E16
Parking Entry
Classic Graphic Display UHF LED Display Board

Multi-Function Controller Long Range Reader
AR-727-E AR-661UG
Parking Exit
Classic Graphic Display UHF LED Display Board

Multi-Function Controller Long Range Reader
AR-727-E AR-661UG
4-2-178
Setting Procedure
1. 701ClientSQL Software Setting
Step 1. Modified to Multi-Card Multi-Parking space (5 cards & 5 parking spaces) (maximum 1000 groups),
Multi-Card Multi-Parking space control function is limited to User Address 10000~14999.
Group1 10000~10004
Group
10005~10009 Group2 14995~14999
1000
1000
groups
Group
10010~10014 Group3 4.5~999
Password: 1 Password: 2
Password: 1 (Means 5 cards in the group of Password: 2 (Means 5 cards in the group of
10000~10004 sharing 1 parking space) 10000~10004 sharing 2 parking spaces)
Password: 3 Password: 4
Password: 3 (Means 5 cards in the group of Password: 4 (Means 5 cards in the group of
10000~10004 sharing 3 parking spaces) 10000~10004 sharing 4 parking spaces)
4-2-179
Step 2. Select 8 User Cards Edit Icon

Step 3. Select User Num: 10000
Step 4. Card ID: Enter the card number
Step 5. Alias: Enter the vehicle number
Step 6. Tick the option [ Anti-passback ]
Step 7. P.I.N: Enter 5 in Password filed (the PIN number means User 10000~ User 10004, the 5 user
cards share 5 parking spaces)
Step 8. Click Save and download to controller
Step 3.
Step 4.
Step 7.
Step 6.
Step 5.
Step 8.
USER
INDEX TIME STATION NUM NAME DEPARMENT DEPARMENT2 STATUS DETAIL
ID
NOTE
(M11) NORMAL
1068 17:06:36 DOOR-4 10004 10004 SALES SALES-1 IN (07721:15248)
ACCESS
(M11) NORMAL
1069 17:06:38 DOOR-4 10000 10000 SALES SALES-1 IN (07710:13808)
ACCESS
(M30) ANTI-
1070 17:06:39 DOOR-4 10003 10003 SALES SALES-1 15240:17106
PASSBACK ERROR
(M30) ANTI-
1071 17:06:41 DOOR-4 10001 10001 SALES SALES-1 07869:53355
PASSBACK ERROR
(M30) ANTI-
1072 17:06:43 DOOR-4 10002 10002 SALES SALES-1 56014:51683
PASSBACK ERROR
NOTE
● Items 1068 and 1069 indicate the valid card is normal access
● Items 1070, 1071 and 1072 indicate the message for Anti-passback error or Occupied;
Abnormal Message, for example, "Occupied" will be displayed on the connected LCD display
board; 701Client report will only display “Anti-passback error＂ transaction.
4-2-180
2. The Message displayed on LCD Display Board
Normal standby Parking Lane at Entrance
Display: [Time] It is the factory clock from LCD display board Correct: Display Alias [Vehicle number]
18:31:44 ABC-1234
Invalid card: display【Invalid user】
Invalid user
Anti-passback error: display [Anti-passback error]
Anti-passback error
When the parking spaces are full : Display [Occupied]
Occupied
4-2-181
12.4.3 Application 3：SOYAL 721 APP / 727 APP

SOYAL 721 APP Function : The user can use mobile phone to control SOYAL controller reader via Ethernet,
721 APP support to remote open the door lock, monitor and display the controller status of arming, disarm,
alarm on mobile phone.
Now the APP can be downloaded on Google store for Android system.
721 APP Setting Procedures
Step 1. Install 721 APP and then open it

Step 2. Enter Account and Password (Both default account and default password is admin)
• Account：admin (default account)
• Password：admin (default password)
Step 1.
Step 2.
4-2-182
Step 3. Click "Add" to set up controller connection

Step 4. Enter name / IP Address /communication/ Port Number /Node ID, click “Add” button
4-1 Controller connection directly to 721APP (without installation and connection to
701ServerSQL)
E Series controller wired directly to 721APP through RJ45, LAN Base Setting of Port
is equivalent to Node ID + 6000.
Node ID Model No. IP Address Port
001 192.168.1.101 6001
327E/3xxE/7xxE/
002 192.168.1.102 6002
8xxE/716v5.
003 192.168.1.103 6003
H/E Series controller controller connected to 721APP through TCP to RS485
converter AR-727-CM / AR-401-IO-0808U2-R
Converter IP Address.
Channel Port
CH1 7001
First unit of AR-727-CM 192.168.1.200
CH2 7002
CH1 7003
Second unit of AR-727-CM 192.168.1.201
CH2 7004
4-2 Controller connected to 721APP and also 701ServerSQL
If controller is connected to both 721APP and 701ServerSQL, in 721APP network
setting IP Address enter with 701ServerSQL's [Local TCP-LINK Address](Default IP
Address setting is 127.0.0.1, please change to your PC's IP address. Refer to NOTE)
and Port enter with 701ServerSQL's [Port]
NOTE
˙This features required connection to the internet. Step below is how to know your PC's IP Address:
Step 1.
Step 2. Step 3.
Step 1. Search for [Command Prompt]

Step 2. Enter [ipconfig] and press [Enter]
Step 3. IPv4 Address is your PC's IP address. In this example, 192.168.1.82 is the IP Address.
Step 5. Click the blue button to connect the controller
Step 4.
Step 5.
Step 3.
4-2-183
Step 6. Enter 721 APP function page

6-1 Display Door open/ close status
6-2 Display Door Relay output status
6-3 Touch Arming button, the device will enter Arming Mode.
Touch Disarm button, exit arming mode.
6-4 Slide the first button to right, the function is to open the door lock based on
the setting of Door Relay time and the door lock will be automatically closed after the
setting door time is end.
6-5 Slide the middle button to right, the door lock will keep unlock
6-6 Till to Slide the bottom button to right, the door lock will be lock again
Step 6-1. Step 6-2.
Step 6-3.
Step 6-4.
Step 6-5.
Step 6-6.
Step 7. Change login account and password

7-1 Click the symbol in the upper right corner
7-2 Click Settings in the upper right corner
7-3 Select [Change Account]/[Change Password] to enter new Account and new Password
Step 7-1. Step 7-2.

Step 7-3.
More Details :
Video : 《SOYAL APP & WEB》SOYAL 721 APP
4-2-184
SOYAL 727 APP Function: SOYAL network Digital I/O Module support to monitor DI/DO status and remote
control DO output; AR-727-CM-IO is built-in 8 DI and 4 DO (built-in one Relay on the first DO0 point) that can be
used in monitoring door sensor status, high/low water level detection, push button and other status detection,
as well as switch, flashing buzzer, electric lock and other equipment on / off control.
Now the APP can be downloaded on Google store for Android system or download from SOYAL official website.
727 APP Setting Procedures
Step 1. Install 721 APP and then open it

Step 2. Click Settings in the upper right corner
Step 3. Set the following information: account (User) / Password /IP Address / Port Number/
Change Device Name / DI_0~DI7 / DO_0~DO_3
Step 2.
Step 3.
4-2-185
Step 4. Enter 727 APP function operation page

4-1 Real-time DI status display
4-2 Real-time DO output control; enter output seconds and slide the button to right
(the range of seconds is 0.1~600 seconds)
Step 4-1.
Step 4-2.
More Details :
Video : 《SOYAL APP & WEB》SOYAL 727 APP Introduction
4-2-186
12.4.4 Application 4: 701ClientSQL Supports Dual IPCAM to Capture User Image

Function: Access controller and time attendance controllers mostly use RFID technology to read card, which
can cause the problem of using the card from another person to access the area. In order to solve the security
problem, 701ClientSQL integrate the function of access controller, time attendance controller and IP camera.
When a user swipe a card, press a password or scan a fingerprint on controller reader, the camera can be
active to take a picture for the user action, the picture can be saved to the system for tracking and records,
in which effectively improve the safety of product use and prevent the problem of swiping cards from another
person.
Setting Description
Part A. The 701ClientSQL supports 2 units of IPCAM Setting (Enter Registry Editor on the
computer to edit IP cameras parameter to connect to 701ClientSQL)
4-2-187
Part B. Set up ACCESS (Part 1), DOOR (Part 2), NODE(Part 3), and TITLE(Part4)
Part C. Capture user image using IP Camera (Part 5) and upload the image as the user's
picture in 701Client (Part 6)
Setting Procedures
(1) Create ACCESS (String Value)
Step 1. Go to HKEY-CURRENT_USER > SOFTWARE > 701 Client

Step 2. Right click on 701Client and select "Add"> "Key".
Step 3. After successfully creating the "key code", rename it into IPCAM0 and right click
to select "New"> "String Value"
Step 4. Rename the string value into "Access" and twice click to edit the string settings.
Step 5. Insert the URL to connect it to 701ClientSQL; if each setting is different, you can
change its USERNAME, PASSWORD and IP ADDRESS.
Step 6. Click "OK" after the setting is completed.
Step 2.
Step 1.
4-2-188
Step 3.
Step 4.
Step 5.
NOTE
Step 6.
NOTE
rtsp://admin: admin@192.168.1.200:554/live/video/profile4
● admin : username
● admin : password
● 192.168.1.200:554 : IP Address
4-2-189
(2) Create DOOR (DWORD Value)
Step 1. Right click and select "New"> "DWORD (32-bit) Value"

Step 2. Rename the value into DOOR and edit the setting; set the value data to 1 (for DOOR NO 1)
and click "OK" after the setting is completed
Step 1.
Step 2.
4-2-190
(3) Create NODE (DWORD Value)
Step 1. Right click and select "New"> "DWORD (32-bit) Value"

Step 2. Rename the value into NODE and edit the setting; set the value data to 1 (for Node NO 1)
and click "OK"
Step 1.
Step 2.
4-2-191
(4) Create TITLE (String value)
Step 1. Right click and select "Add"> "String Value".

Step 2. Rename the string value into TITLE and edit the setting; set the value data to [CAMARA1]
and click "OK"
Step 1.
Step 2.
4-2-192
(5) Capture the picture by IP Camera and save it
Step 1. Execute 701ClientSQL and select [E Photo Display]

Step 2. Select the camera you want to use to capture the image
Step 3. Press "Capture "button
Step 4. Select the path to save the pictures
Step 5. It can be renamed as needs.
Step 6. Select "Save"
Step 1.
Step 2.
Step 3.
Step 4.
Step 5.
Step 6.
4-2-193
(6) Upload the picture captured by the IP camera to [User Card Edit]
Step 1. Click "8 User Card Edit" on Menu Bar

Step 2. Twice click the picture area.
Step 3. Select the picture you want to set it as the user image
Step 4. Click "Open"
Step 6. Click "Download" to write the user card to the controller
Step 1.
Step 2.
Step 5. Step 6.
Step 3.
Step 4.
4-2-194
Step 7. The captured pictures will be automatically saved to the installation path of
701ClientSQL software C:\Program Files (x86)\701Client\PopGra with the file name
defined by captured date and time for convenient tracking and review in future.
Step 7.
More Details :
FAQ : Setting and Manual for 701 Client Supports Multiple IP Cameras
4-2-195
12.4.5 Application 5：Monitoring the flow of people in Areas

Function：The application is recommended for construction site management. The people need to use the
valid card to get access at entrance and exit; the system can automatically count the total numbers of people
inside and also timely report the name list of user inside.
4-2-196
Hardware Structure:
Preparing Multi-door Controller AR-716-E16 (old name AR-721E-V2), connect more than 2 units of RS485
readers to 485 port; we use 721H in this case as example.
Setting Procedure
(1)Upgrade customized software and firmware
Step 1. Upgrade customized software

701ClientSetup902 200112 ShowInside_Member for each Node Change.exe
Step 2. Upgrade customized firmware
APS721Ev2__V0403_190829 SEND_INSIDE_NUM_WINLED4.STM
Access Control
Software Installation Firmware Installation
APS721Ev2__V0403_190829
SEND_INSIDE_NUM_WINLED4.STM
4-2-197
(2) Anti-pass back Settings: Enable Anti-pass back function for two RS485 readers,
one reader set as Entry by command 20*192# and another reader set as Entry by
command 20*128#
Step 1. Enter program mode → 20 DDD

【Anti-pass-back(0=Disable; 1=Enable) / 064=Entrance / Exit(0=Exit; 1=Entrance)】
[e.g.] Enable Anti-pass-back, and set to Exit door= (128 x 1) + (064 x 0) = 128
Enter program mode → 20 128 (Please refer to function default value for details.)
Step 2. If RS485 reader is LCD screen type, please use menu to set up 4. Parameters(2)
→ 6. Anti-pass back .
Step 1.
NOTE
NOTE
Anti-pass back function is only suitable for M4 Mode or M8 Mode and is not suitable for M6 Mode
Step 2.
1. Add/ Delete 5. Close & Stop

2. User Setting 6. Anti-pass-back
3. Parameters[1] 7. Duress Code
4. Parameters[2] 8. Password Mode
(3) Set up AR-716-E18 connection on 701Server ( Node ID 002 as exmple)
4-2-198
(4) Select Node ID of RS485 readers connected to AR-716-E18 by following picture , the
default node ID of 003 and 009 is selected.
Step 1. Select Controller Node ID 002

Step 2. Click “Read＂ button to read parematers from AR-716-E18
Step 3. Click “ 721EV2＂ button
Step 4. Select Node ID for connected RS485 reader
Step 5. Click “OK＂ to exit
Step 6. Click “Write＂ button to write parematers from AR-716-E18
Step 1.
Step 3.
Step 4.
Step 5.
Step 2.
Step 6.
4-2-199
(5) Download user card data to Multi-door controller.
Step 1. Select "User Card Edit"

Step 2. Select user address
Step 3. Edit user data
Step 4. Enable "Anti-passbck" option
Step 5. Click "Save" after setting
Step 6. Click "Download" button to download user setting to controller
Step 1.
Step 2.
Step 3.
Step 4.
Step 5. Step 6.
4-2-200
(6) Set up how to check in and out status for each user
Step 1. Setting ----> Anti-pass Map to open the setting window

Step 2. Select “Controller＂ Node ID
Step 3. The current total user numbers inside will be displayed in “ Total Space＂ filed
Step 4. The software will pop-up the user list in txt format , the file will also be automatically saved
to the path of C:\Program Files (x86)\701Client with the name " Inside User List
YYYYMMDD_Node ID number.txt
Step 5. Click "Read" button
Step 6. The software will display the current user names list.
Step 1.
Step 2.
Step 4.
Step 3.
Step 6.
Step 5.
4-2-201
12.4.6 Application6：Multi-door Interlock Solution

Function: Clean room one-way multi-door interlock controller uses I/O module AR-401-IO-1709R for clean
room one-way multi-door interlock application, not only construction, wiring is simple, but also convenient for
future maintenance, up to 8 doors Control, only need to install door lock, access card reader, door magnetic
spring and horn in each door (this case requires special firmware)
(1) Multi-door interlock ( 4 Doors / 8 Doors)

Upgrade customized firmware:
4 Doors Interlock—401RO8DI16_V0206_190320 DOOR_INTERLOCK_4.ISP
8 Doors Interlock—401RO8DI16_V0206_190320 DOOR_INTERLOCK_8.ISP
DIP Switch Setting

ON
Power
Node ID
L1 2 3 4 5 6 7 8H
3 seconds 6 seconds
ON ON
L1 2 3 4 5 6 7 8H L1 2 3 4 5 6 7 8H
Door lock output 4 doors : K7
relay time
9 seconds 15 seconds 電鎖 8 doors : K8
ON ON 4 doors : K3
電鎖 8 doors : K2
4 doors : K1
L1 2 3 4 5 6 7 8H L1 2 3 4 5 6 7 8H Lock 8 doors : K1
alarm
3 seconds 6 seconds alarm
ON ON
alarm
Alarm output L1 2 3 4 5 6 7 8H L1 2 3 4 5 6 7 8H
relay time 4 doors : K8
9 seconds 15 seconds 警報 8 doors : K30
ON ON
4 doors : K4
警報 When DO is enabled,
8 doors : K30
4 doors : K2
L1 2 3 4 5 6 7 8H L1 2 3 4 5 6 7 8H Alarm
When DODIis
8 doors (door sensor)
enabled,
: K30 trigger alarm
DI (door sensor) trigger alarm
GND
When DO is enabled, Door H
DI (door sensor) trigger alarm
Door B
Door A x8
K30
Note 1: 4 doors interlocking K2/K4/K6/K8

connect to alarm for each door
AB CD E F GH Note 2: 8 doors interlocking share one public
alarm (K30)
12V
Power
GND
COM
17-CH Optical Coupling DI /
NO
9-CH Relay Output Module
NC
AR-401-IO-1709R
Open circuit during standby mode,
open circuit all relays when the
Fire alarm signal contact is short-circuited
COM NC NO NO NC COM
1 2 3
4 5 6
7 8 9
* 0 #
1 2 3
Relay Sensor
4 5 6
1 2 3
1 2 3
7 8 9
4 5 6
4 5 6
7 8 9 * 0 # 7 8 9
* 0 # * 0 #
Relay
1
7 門位磁簧
2
8
3
9
Relay Sensor 1
7
2
8
3
9
Relay Sensor
* 0 #
* 0 #
Relay 門位磁簧
1
4
2
5
3
6
Relay Sensor
7 8 9
* 0 #
Relay Sensor Relay Sensor
Door E
Door H Door D
Door G Door A Door C
Door F Door B
4-2-202
12.5 Special Application
Customized Firmware & Function

Brief Function Introduction of Recommended
Item
The Customized Firmware Applicable Places
Multi-Card Multi-Parking Space Management (5 cards
1 share 1 space, 5 cards share 5 spaces, 10 cards share 10 Parking Lots
spaces);Display space status on external display Board
When the controller reader read an invalid card, trigger the Apply to external alert light or BA
2
second relay output system,IP CAM capture image
LCD Screen Controller reader with Function Key; after
swipe card or scan fingerprint and then press arming code, Apply to control up, stop, and down of
3
press function key F1 F2 F3 within 30 seconds that can the electric iron rolling shutter door
trigger three corresponding outputs
Apply to changing controller reader
4 Card Number conversion modification
from other brands.
Apply to the line printer's to print time
Enterprise E Series controller support to connect with line
5 attendance records, remaining value
printer, the output content can be modified as requirements
or remaining points stored in card
Enterprise E Series controller connected with Relay output Scheduled DO output and Remote
module AR-401-IO-0016R support to automatically release control function that can be applied
6
lift button for free access during the assigned time zone on to Area light control, Sprinkler system
the software of Lift Control and etc.
When the controller reader read an valid card, trigger two Apply to door lock, alert light or output
7
relay outputs contact backup
8 Parking lot floor partition management Car Parking
Responding to the management
Energy Saver AR-888-W DI/DO Modification as different
9 requirements to modify from different
requirements
hotels and hostels
Calculate the stay time in parking and write the available
10 Car Parking
time to the designated block in card
Applied to Parking lots of community
11 Access Controller integrate with Power Charging Application center, commercial building, shopping
mall or other private or public spaces.
E series controller integrate with PLC or HMI equipment; Be
12 Public Car Parking
able to integrate via interface or commands
E series controller can display Alias or duty function on LCD
13 Office or Factory Time Attendance
Screen
Clean room, Parking Lots or Interlock
14 RFID function enable while Door Sensor is closed to GND
door
Access card controller or fingerprint controller dual
Bank , Office or the places that need
15 Identification – need any 2 personnel and employees to one
high security access management
manager + one personnel to open the door
Enable Anti-passback function on Multi-door controller, only
Parking Lots, bank or the places
swipe an valid card and also the door is opened by door
16 that need high security access
sensor detection, the action of swiping the valid card is
management
counted in the record of Anti-passback
4-2-203

Item
Enable Anti-passback function on Multi-door controller –
Bank or the places that need high
17 Access via many doors but Only one personnel can stay
security access management
inside the space at the same time
Enable Anti-passback function on Multi-door controller -
-each room in Bank could not be allowed to stay only one
person. If only one person stays for more than one minute, Bank or the places that need high
18
an alarm output needs to be triggered. The second person security access management
must enter the room within one minute after the first person
enters.
Enterprise E series controller support UART port that can
connect one external voice module; the voice module will Time Attendance Management in
19
sound Alias while the employee swipe their card or scan Office or Factor
fingerprint for work on the controller
Swipe an valid card on Controller reader to open the
20 assigned mailbox- be able to control 64 sets ,128 sets or Smart Mailbox , Smart Locker
256 sets mailboxes
LCD screen controller for staff meal consumption
application: Press 2~4 digits value to and swipe a valid
Staff Restaurant Meal Consumption in
21 card, LCD screen will display the info. of Alias + Meal Fees;
Company
the transfer text file on 701 CLIENT software add the item
of values.
Multi-door controller assign specified user address range
to trigger the corresponding relay output: User range These places management that need
22
8001~9999 trigger Relay01 and User range 10000~16383 different relay outputs
trigger Relay02
Two 727CM-IO under same LAN network- DI0~4 on first
23 Remote Control in building
727CM-IO trigger DO0~4 on another 727CM-IO
AR-837-WD can deduct the stored value from Mifare card Renting offices, Renting machines,
24
block and display the balance and time on LCD Screen and Air-conditioning billing
Specified user address range trigger the corresponding
25 relay output, for example User1~200 trigger main door The places that need specified output
relay, User201~400 trigger second WG output door relay
Anti-pasback management and display the number of Monitoring the flow of peoples in Areas
26
person inside the area via external LED display board such as construction site
Opening door process: Enter password one time and then
27 the password will be invalid, and then the door can be open Door Access Control
by swiping valid card
Set two password: one password trigger door relay on and Applied to warehouse materials in and
28
another password trigger door relay off out management
LCD Screen controller can display the balance and points
29 Renting offices, Renting machines
on LCD Screen and deduct points by function key
30 Trigger Alarm output when Anti-pasback error Door Access Control
4-2-204

Item
Enterprise E Series Controller connected with WG reader Dual Door Interlock in Clean room,
31
support dual door interlock ward area in hospital
716E-E16 car parking management – be able to connect
32 UHF long range reader and also integrate with LRP Camera Car Parking lots
to trigger barrier gate
Multi-door controller management-
(1) After only the manager card is swiped on controller
33 reader, other user cards can be active to use. Bank , Office door
(2)After swiping one first card on one specified controller
reader, other controller reader will be active to use
Restroom Emergency Assist Application with universal I/O Restroom or the places that need
34
module monitoring status and emergency help
Multi-door interlock application via I/O module AR-401-IO- Clean room or the places that need
35
1709R interlock access control
AR-101H can remember the card ID once one card is
swiped. During this period, other cards could not open the
36 Membership locker
locker. When the same card is swiped again, the locker will
be unlocked and the reader will restore standby status.
13. Reference document

13.1 FAQ
How to View “Daily None Access User＂ Report?

Why could not see Event Log while 701Server Setting is correct?
Why does the message show "invalid card" but "Door group error" while Set Up
"Door Group " function on 721H?
How to turn off the music of 701Client?
How to remote control the 721H to open door through 701Client?
Why message says Global Access on 701Client when flashing card on AR-721H?
Why does 701Client disappear when I let it to leave unused?
Setting"Project Files", after set up"Parameter path" to

"C:\Program Files\701Client", not be executed successfully…
13.2 Video
《Software Upgrade FAQ》Move To Another Computer
4-2-205
12. Special Application / 13. Reference document / Annex
701ClientSQL Portable Version Installation Instruction
1. Install Standard 701ServerSQL and 701ClientSQL
Step 1. Obtain SOYAL 10.3 software by downloading it from SOYAL website

(required authorization from SOYAL or distributor to logged in)
Step 2. Install both 701ServerSQL and 701ClientSQL
(further detail please refer to 701ServerSQL & 701ClientSQL Installation Guide)
Step 1.
Step 2.
2. Install Portable Version Software
Step 1. Obtain the portable version software installation file by downloading if from SOYAL official
website. Currently, There are two versions of ABA64 and WG64_HEX, which can be downloaded
according to your needs. (required authorization from SOYAL or distributor to logged in)
Step 1.
4-2-206
Step 2. After the file is downloaded, put the portable version file
in the path \Program Files(x86)\701Client\...
Step 3. After running the program by creating a shortcut, you can use the portable version.
Step 3.
Step 2.
701 ClientSQL Standard version & Portable version difference
Version : Standard Version

Card Format : WG32
Card ID field description :
A Range : 1~65535
B Range: 1~65536
A B
4-2-207
Annex 701ClientSQL Portable Version Installation & Difference Instruction
Version : Portable WG64_HEX

Card Format : WG64_HEX
A Hex / UID64 high 32bits

B Hex / UID64 low 32bits
A B
Version : Portable ABA64

Card Format : ABA64
A No need to fill in
B Decimal / 64Bits / 17 Bits
A B
4-2-208

701ClientSQL en PDF

Uploaded by

Document Information

Original Title

Copyright

Available Formats

Share this document

Share or Embed Document

Sharing Options

Did you find this document useful?

Is this content inappropriate?

Copyright:

Available Formats

701ClientSQL en PDF

Uploaded by

Copyright:

Available Formats

Part 4 Software Operation

1. Installation and Execution

2. Access Control Setting

2.1 Location 4-2-5

3.3 Import and Export User Card Data 4-2-30

3.5 Single User Card Download 4-2-33

3.6 User Card Data Download - Read/Write to 7xxH 4-2-33

4.4 Holiday 4-2-38

4.5 System Parameters Setting 4-2-39

4.7 Employee Attendance Data Setting 4-2-43

4.8 View Option of Report 4-2-44

5.2 Daily Transaction Report 4-2-59

5.3 Multi-day Transaction Report 4-2-62

5.5 Monitor Format 4-2-64

5.6 Check Anti-pass Map 4-2-66

6. Testing the Setting Result 4-2-71

7. Import / Export Data

9. DI/DO Number Name & Remote Control through Software

10.2 Graphic Animation Control Introduction 4-2-86

10.3 701ClientSQL Graphic Animation GUI 4-2-102

10.5 Reference 4-2-147

11. Lift Floor Setting 4-2-150

12. Special Application

12.2 SOYAL QRCode Format Introduction 4-2-160

12.3 701ClientSQL Email Notification Application Sharing 4-2-161

12.3.1 Sending visitor QR CODE to E-mail via 701CllientSQL software

12.4.1 AR-837-E Support to Connect Up To 64 Sets of Mailbox

12.5 Special Application 4-2-205

13.1 FAQ 4-2-207

13.2 Video 4-2-207

701ClientSQL Portable Version Installation Instruction

1 . Installation and Execution

1.2 Installation and Execution

Double click 701ClientSQL.exe

1.3 Main Menu

1.4 ool Bar

1.5 Operator Management (Login Name / Password / Operation Level )

Video : 【701 Client】 701 Software introduction

1.6 Permission to Operate the Software

1.7 Change font

2 . Access Control Setting

Step 1. Click “Add Door” button.

2.2 Door Groups

FAQ : How to set door group in the 701Client?

2.3 Time Zone

Auto Open Time Zone :

Step 1. ZONE: 00 ~ 63 time zones for editing. For example: 001.

Step 7. After finish setting, click

FAQ : How to show duty type automatically on 727H?

FAQ : How to show fixed duty type on AR-727H?

FAQ : How to set auto open time zone?

FAQ : How to set up Auto-open function(Zone: 63) on AR-716E+AR-727H?

FAQ : One Example of 716E [SET] Function

FAQ : How to set up “door auto open＂ function on AR-829E?

FAQ : The 【SET】 application under user data edit

2022 Holiday Setting 1 2 3 4 5 6 7 8 9 10 11 12

2023 Holiday Setting 1 2 3 4 5 6 7 8 9 10 11 12

Step 1. Select “Year” first.

Read Office Day:

2.5 Attendance Shift Setting

First, open the “System Parameters Setting” window by clicking .

Next, open the “Attendance Edit” window by clicking or .

FAQ : How to Pop-up Reminder Window for Abnormal Message?

Card UID (:xx)WG32(5:5) / Card UID (xx:)WG32(5:5) /

　The procedure of Restore data :

　　Applicable models for Attendance :

　　Flexible Enable / Disable Attendance Mode
