Outside Micrometers

For information about outside micrometers, see page 2255.

Mitutoyo Outside Micrometers

Series 101 with
Ratchet-Stop
Thimble

Starrett Outside Micrometers

Series 436 with
Ratchet-Stop
Thimble

Series 103
with Friction
Thimble

Get precise outside measurements. Micrometers have a spindle

lock to secure spindle at the desired reading. Thimble and sleeve are
stainless steel with a satin finish; spindle and anvil faces are carbide.
Spindle and anvil are 0.2500 dia. Micrometers have a rotating spindle.
Include plastic case. Micrometers that measure 20 and higher also
include a measuring rod. Certificates of calibration are traceable to
NIST (National Institute of Standards and Technology).
Series 101Frames are steel with a satin chrome finish.
Series 103Frames are cast iron with an enamel finish.
Micrometer SetsInclude series 103 micrometers with ratchet-stop
thimble, except 0-20 range micrometers, which have a friction thimble.
Micrometers
Meas. Thimble Throat
Mitutoyo
Range Grads. Dp.
Accuracy No.
Each
With Ratchet-Stop Thimble
0-10 .......... 0.0010........ 1.100 ....... 0.00010....... 101-105 ........ 85185A51 $97.93
0-10 .......... 0.00010 ..... 1.100 ....... 0.00010....... 101-113 ........ 85185A52 129.38
0-10 .......... 0.0010........ 1.100 ....... 0.00010....... 103-259 ........ 85205A61 87.33
0-10 .......... 0.00010 ..... 1.100 ....... 0.00010....... 103-260-99.. 85205A62 68.64
1-20 .......... 0.0010........ 1.490 ....... 0.00010....... 101-106 ........ 85185A53 117.70
1-20 .......... 0.00010 ..... 1.490 ....... 0.00010....... 101-114 ........ 85185A56 129.98
1-20 .......... 0.0010........ 1.490 ....... 0.00010....... 103-178 ........ 85205A63 101.52
1-20 .......... 0.00010 ..... 1.490 ....... 0.00010....... 103-262 ........ 85205A64 110.51
2-30 .......... 0.00010 ..... 1.930 ....... 0.00010....... 101-119 ........ 85185A54 141.95
2-30 .......... 0.0010........ 1.930 ....... 0.00010....... 103-179 ........ 85205A65 116.80
2-30 .......... 0.00010 ..... 1.930 ....... 0.00010....... 103-217 ........ 85205A66 123.98
3-40 .......... 0.0010........ 2.360 ....... 0.000150 .... 103-180 ........ 85205A67 135.66
3-40 .......... 0.00010 ..... 2.360 ....... 0.000150 .... 103-218 ........ 85205A68 141.95
4-50 .......... 0.00010 ..... 3.110 ....... 0.000150 .... 103-219 ........ 85205A73 154.53
5-60 .......... 0.00010 ..... 3.700 ....... 0.000150 .... 103-220 ........ 85205A74 170.70
0-25 mm 0.01 mm ... 1.100 ....... 0.002 mm 103-137 ........ 85205A69 87.33
With Ratchet-Stop Thimble and Certificate of Calibration
0-10 .......... 0.00010 ..... 1.100 ....... 0.00010....... 101-113 ........ 85185A41 169.68
0-10 .......... 0.00010 ..... 1.100 ....... 0.00010....... 103-260-99.. 85205A78 108.94
With Friction Thimble
0-10 .......... 0.0010........ 1.100 ....... 0.00010....... 101-109 ........ 85185A57 97.93
0-10 .......... 0.00010 ..... 1.100 ....... 0.00010....... 101-117 ........ 85185A58 106.02
0-10 .......... 0.00010 ..... 1.100 ....... 0.00010....... 103-135 ........ 85205A75 96.13
Micrometer Sets
Meas. No. of
Thimble
Mitutoyo
Range Micrometers Graduations No.
Each
0-30 ......... 3 .......................... 0.00010 .............. 103-922 .......... 85205A71 $345.00
0-60 ......... 6 .......................... 0.00010 .............. 103-907-01.... 85205A72 820.27

Brown & Sharpe Outside Micrometers

Reversible thimble sleeves convert
these micrometers from plain thimble
to friction thimble (unless noted). All micrometers have a spindle lock to secure
2053A4
spindle at desired reading, a rotating
spindle, and a measuring rod. Frame,
thimble, and sleeve are cast metal with a satin chrome finish (unless
noted). Spindle is stainless steel; spindle and anvil faces are carbide.
The spindle and the anvil are 0.2500 dia. 2053A4 and A1 have decimal
equivalents printed on the frame. 2053A1 also has slanted graduations
that remain visible through a complete revolution of the thimble.
Meas. Thimble
Throat
Brown &
Range Graduations Dp.
Accuracy Sharpe No.
Each
0-10 ........ 0.00010 ............ 10.......... 0.00010.... 599-1-31 ..... 2053A1 .... $126.00
0-10 ........ 0.00010 ............ 10.......... 0.00010.... 599-1-32 ..... 2053A4 .... 126.00
0-10 ........ 0.00010 ............ 10.......... 0.00010.... 599-1-44 ..... 2053A8l 93.00
1-20 ........ 0.00010 ............ 1.20 ...... 0.00010.... 599-2-32 ..... 2053A6 .... 171.00
2-30 ........ 0.00010 ............ 1.750 .... 0.000120 599-3-32 ..... 2053A7 .... 194.00
l Has friction thimble only. Frame has enamel finish.

Series 230 and 232

with Ratchet-Stop
Thimble

Precise outside measurements couldnt be easier. All micrometers

have a spindle lock to secure spindle at desired reading and a rotating
spindle. Theyre steel with a chrome finish on the thimble and sleeve.
Spindle and anvil are 0.2500 dia. (unless noted) and have carbide faces.
Accuracy of micrometers graduated in 0.0010 increments is 0.00010;
in 0.00010 increments is 0.000050; in 0.01 mm and 0.001 mm increments is 0.002 mm. Furnished in a plastic case (unless noted). Other
cases are sold separately on page 2259.
Certificates of calibration are traceable to NIST (National Institute of
Standards and Technology).
Micrometers with RL in the Starrett No. have a ratchet-stop thimble; FLdesignates a friction thimble. To Order : When given a choice
for the Starrett No., please specify thimble type: ratchet stop (RL)
or friction (FL).
Series 436Frame has enamel finish and ribbed edges for strength.
10 ratchet-stop thimble micrometers have decimal equivalents printed
on thimble.
Also Available : Starrett No. T436XRL micrometers with ranges up to
120. All have a cast iron frame, a 0.3000 dia. carbide spindle and anvil,
and 0.00010 graduations. Do not include case. To Order : Please ask for
2044A8 and specify range: 6-70, 7-80, 8-90, 9-100, 10-110, or 11-120.
Series 230Frame has a satin chrome finish. The 0-10 micrometers
have decimal equivalents on frame.
Micrometer SetsInclude series 436 micrometers with ratchetstop thimble and graduated in 0.00010 increments. Include a measuring rod and a wood case.
Micrometers
Measuring Throat
Range
Dp.
Starrett No.
Each
0.0010 Thimble Graduations
0-10 ................. 1.00............ 436.1XRL-1 ........................ 2044A44 ........ $114.00
1-20 ................. 1.50............ 436.1XRL-2 ........................ 2044A45 ........ 132.00
2-30 ................. 2.00............ 436.1XRL-3 ........................ 2044A46 ........ 166.00
3-40 ................. 2.50............ 436.1XRL-4 ........................ 2044A47 ........ 183.00
4-50 ................. 3.00............ 436.1XRL-5 ........................ 2044A48 ........ 199.00
5-60 ................. 3.50............ 436.1XRL-6 ........................ 2044A49 ........ 216.00
0.0010 Thimble GraduationsWith Certificate of Calibration
0-10 ................. 1.00............ 436.1XRL-1 ........................ 2044A141 ...... 140.67
0.00010 Thimble Graduations
0- 1/20............. 0.60............ T232XRL ............................. 21075A263' 171.01
0-10 ................. 1.00............ T436.1(XRL-1 or XFL-1) ... 2044A133 ...... 117.00
0-10 ................. 1.00............ T230X(RL or FL) ................ 8601A4,........ 149.01
1-20 ................. 1.50............ T436.1(XRL-2 or XFL-2) ... 2044A134 ...... 138.00
2-30 ................. 2.00............ T436.1(XRL-3 or XFL-3) ... 2044A135 ...... 171.00
3-40 ................. 2.50............ T436.1(XRL-4 or XFL-4) ... 2044A136 ...... 187.00
4-50 ................. 3.00............ T436.1(XRL-5 or XFL-5) ... 2044A137 ...... 202.00
5-60 ................. 3.50............ T436.1(XRL-6 or XFL-6) ... 2044A138 ...... 220.00
0.00010 Thimble GraduationsWith Certificate of Calibration
0-10 ................. 1.00............ T436.1(XRL-1 or XFL-1) ... 2044A36 ........ 143.67
0-10 ................. 1.00............ T230X(RL or FL) ................ 8601A51, ..... 175.68
1-20 ................. 1.50............ T436.1(XRL-2 or XFL-2) ... 2044A37 ........ 143.67
2-30 ................. 2.00............ T436.1(XRL-3 or XFL-3) ... 2044A17 ........ 197.67
3-40 ................. 2.50............ T436.1(XRL-4 or XFL-4) ... 2044A143 ...... 213.67
0.01 mm Thimble Graduations
0-25 mm ...... 1.00............ 436.2MXRL-25 .................. 21075A899 .... 114.00
25-50 mm ...... 2.50............ 436.1MXRL-50 .................. 21075A399 .... 141.00
0.001 mm Thimble Graduations
0-25 mm ...... 1.00............ V230MXRL ......................... 8601A22, ..... 149.01
' Spindle and anvil are 0.2000 dia. Does not include a case.
, Spindle and anvil are 0.2350 dia.
Micrometer Sets
Measuring No. of
Range
Micrometers Starrett No.
Each
0- 30 . . . . . . . . . . . . . . 3 . . . . . . . . . . . . . . . . . . . . . . ST436.1AXRLZ . . . . 2044A424 . . . . $492.00
0- 60 . . . . . . . . . . . . . . 6 . . . . . . . . . . . . . . . . . . . . . . ST436.1CXRLZ . . . . 2044A425 . . . . 1,198.00
0-120 . . . . . . . . . . . . . . 12 . . . . . . . . . . . . . . . . . . . . . . ST436EXRLZ . . . . . . . . 2044A426 . . . . 3,305.00

Specialty Micrometers from Mitutoyo and Starrett

Measuring
Range

Mfr.
No.

Each

Mitutoyo
Disc ............................................. 0-10 ...................... 223-125 ... 8655A11.. $251.96
Disc ............................................. 0-10 (0-25 mm).. 323-350 ... 20485A88 446.00
Point (15) .................................. 0-10 ...................... 142-177 ... 8653A11.. 232.70
Point (15) .................................. 0-10 (0-25 mm).. 342-351 ... 19585A61 413.00
Point (30) .................................. 0-10 ...................... 112-225 ... 8653A32.. 135.88
Point (30) .................................. 0-10 ...................... 142-225 ... 8653A12.. 189.57
Point (30) .................................. 0-10 (0-25 mm).. 342-361 ... 19585A62 403.00
Rounded Anvil .......................... 0-10 ...................... 295-153 ... 8654A11.. 172.50
Rounded Anvil and Spindle... 0-10 ...................... 295-253 ... 8654A12.. 180.59
Rounded Anvil and Spindle... 0-10 (0-25 mm).. 395-371 ... 2339A4 .... 366.00

Measuring Mfr.
Range
No.

Each
Mitutoyo (Cont.)
Inside (w/Carbide Pin Faces) .. 0.2-1.200 ...... 145-193 .... 20555A67 $194.96
Repl. Battery for Electronic Micrometers ...................... 21105A167
2.26
Starrett
Mul-T-Anvil................................... 0-10 ................ 220XFL-1 8575A61..... 223.00
Screw Thread Comparator ...... 0- 7/80 ........... 210AP ....... 8594A46..... 142.00
Disc ............................................... 0-10 ................ 256RL-1 ... 8603A61..... 273.01
Rounded Anvil ............................ 0- 1/20 ........... 576XR ....... 8576A11..... 180.00
Rounded Anvil ............................ 0-10 ................ 577XP ....... 8576A12..... 173.01

2257
