Product Description: LTE CPE B5328-155

LTE CPE B5328-155
Product Description
Issue
Date 2016-01-05
HUAWEI TECHNOLOGIES CO., LTD.

Copyright © Huawei Technologies Co., Ltd. 2016. All rights reserved.
No part of this document may be reproduced or transmitted in any form or by any means without prior
written consent of Huawei Technologies Co., Ltd.
Trademarks and Permissions
and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd.
All other trademarks and trade names mentioned in this document are the property of their respective
holders.
Notice
The purchased products, services and features are stipulated by the contract made between Huawei and
the customer. All or part of the products, services and features described in this document may not be
within the purchase scope or the usage scope. Unless otherwise specified in the contract, all statements,
information, and recommendations in this document are provided "AS IS" without warranties, guarantees or
representations of any kind, either express or implied.
The information in this document is subject to change without notice. Every effort has been made in the
preparation of this document to ensure accuracy of the contents, but all statements, information, and
recommendations in this document do not constitute a warranty of any kind, express or implied.
Huawei Technologies Co., Ltd.

Address: Huawei Industrial Base
Bantian, Longgang
Shenzhen 518129
People's Republic of China
Website: http://www.huawei.com
Email: support@huawei.com
Issue 2016-01-05 Huawei Proprietary and Confidential i

Copyright © Huawei Technologies Co., Ltd.
LTE CPE B5328-155
Product Description About This Document
About This Document
Purpose
This document describes the product features, main functions, supported services, technical
specifications, and technical reference of the LTE CPE B5328-155 (B5328-155 for short)
This document is organized as follows:
Chapter Description
1 Overview Describes the appearance and supported services of the
B5328-155.
2 Product Features Describes the features of the B5328-155.
3 Technical Specifications Describes the hardware, software, and interface
specifications of the B5328-155.
4 Services and Applications Describes the functions and services provided by the
B5328-155.
5 System Architecture Describes the system architecture of the B5328-155.
6 Technical Reference Describes the standards and protocols that the B5328-155
complies with.
Change History
Version Change Description Date
01 Completed 2016-01-05
Issue 2016-01-05 Huawei Proprietary and Confidential ii

LTE CPE B5328-155
Product Description Contents
Contents
About This Document .................................................................................................................... ii

1 Overview......................................................................................................................................... 4
2 Product Features ............................................................................................................................ 5
3 Technical Specifications .............................................................................................................. 6
3.1 Hardware Specifications ............................................................................................................................................... 6
3.2 Antenna Specifications ................................................................................................................................................. 8
3.2.1 Built-in LTE Antenna ................................................................................................................................................. 8
3.2.2 Built-in WLAN Antenna ............................................................................................................................................ 9
3.3 Software Specifications ................................................................................................................................................ 9
4 Services and Applications ......................................................................................................... 12

4.1 Data Services .............................................................................................................................................................. 12
4.1.1 LAN Port ................................................................................................................................................................. 12
4.2 Security Services ........................................................................................................................................................ 12
4.2.1 Firewall .................................................................................................................................................................... 12
4.2.2 MAC Filtering ......................................................................................................................................................... 12
4.2.3 IP Address Filtering ................................................................................................................................................. 12
4.2.4 URL Filtering ........................................................................................................................................................... 12
4.2.5 Forwarding by Using the DMZ................................................................................................................................ 12
4.2.6 UPnP ........................................................................................................................................................................ 13
4.2.7 PIN Code Protection ................................................................................................................................................ 13
5 System Architecture .................................................................................................................... 14

6 Technical Reference .................................................................................................................... 15
6.1 Compliant Protocols ................................................................................................................................................... 15
6.1.1 B5328-155 Compliant Protocols.............................................................................................................................. 15
6.1.2 Radio Access Protocols............................................................................................................................................ 15
A Acronyms and Abbreviations .................................................................................................. 17
Issue 2016-01-05 Huawei Proprietary and Confidential iii

LTE CPE B5328-155
Product Description 1 Overview
1 Overview
Huawei LTE CPE B5328-155 is an LTE wireless gateway that allows multiple users to
connect to the Internet over wired or wireless connections.
It complies with 3GPP Release 10 and supports data services, Wi-Fi services, security
services, DHCP services, and management services.
Issue (2015-01-07) Huawei Proprietary and Confidential 4

LTE CPE B5328-155
Product Description 2 Product Features
2 Product Features
The B5328-155 has the following main features:

 LTE bands: 3, 7, 20
 Wireless access: IEEE 802.11b/g/n
 Flexible network performance
Supports high-speed routing and diverse network and IP protocols, such as bridge,
routing, DNS, DHCP, and network address translation (NAT)
 Flexible security services
Supports data packet filtering to enhance security functions against security threats and
intrusions
 Basic network configuration
Supports maintenance and management over network ports
 GE port
Supports wired connection through LAN ports, rate auto-negotiation, and automatic
MDIX detection
 Antenna
Provides high-gain LTE and Wi-Fi antennas.
 Others
− Supports friendly state display
− Supports Linux, Mac OS, Windows 7, Windows 8, and Windows 10
− Supports Internet Explorer, Firefox, Chrome, and Opera

LTE CPE B5328-155
Product Description 3 Technical Specifications
3 Technical Specifications
3.1 Hardware Specifications

Table 3-1 lists the B5328-155 hardware specifications.

LTE CPE B5328-155
Table 3-1 B5328-155 hardware specifications
Item Description
Access LTE: 3GPP Release 10 (Cat.5)

standards
LAN: IEEE 802.3/802.3u
WLAN: IEEE 802.11b/g/n
Working bands LTE FDD Band 3, Band 7, Band 20
WLAN 2.4 GHz: Channel 8,9,10
Bandwidth LTE 1.4 MHz, 3 MHz,5 MHz, 10 MHz, 15 MHz, 20 MHz
Ports/Button  One GE port

 One reset button
 One USIM card slot
 One power button
 One power supply port
LED indicators  One power indicator

 One three-bar signal strength indicator
 One LAN indicator
 One WLAN indicator
Maximum LTE 23 dBm

transmit power
WLAN IEEE 802.11n: 22 dBm ± 1 dBm

802.11g: 22 dBm ± 1dBm
802.11b: 23 dBm ± 1 dBm
Receiver LTE 5 MHz: -100 dBm

sensitivity 10 MHz: -97 dBm
15 MHz: -95.2 dBm
20 MHz: -94 dBm
WLAN 802.11n: -64 dBm@300Mbit/s
802.11g: -65 dBm@54Mbit/s
802.11b: -76 dBm@11Mbit/s
Power ≤ 10 W
consumption
Power supply AC: 100 V to 240 V, 50/60 Hz

DC: 5 V/2 A
Dimensions (H 192 mm x 152.5 mm x 96.4 mm

x W x D)

LTE CPE B5328-155
Item Description
Weight About 300 g
Temperature Working temperature: 0°C to 40°C

Storage temperature: –20°C to 70°C
Humidity 5%–95% RH
3.2 Antenna Specifications

3.2.1 Built-in LTE Antenna
Table 3-2 lists the internal LTE antenna specifications.

LTE CPE B5328-155
Table 3-2 Internal LTE antenna specifications
Item Description
Frequency Band 3
Band 7
Band 20
Efficiency Band 3: > 50%
Band 7: > 50%
Band 20: > 40%
Gain Band 3: 2.5 dBi
Band 7: 3 dBi
Band 20: 0.5 dBi
Antenna Omnidirectional
3.2.2 Built-in WLAN Antenna

Table 3-3 lists the internal WLAN antenna specifications.
Table 3-3 Internal WLAN antenna specifications
Item Description
Frequency 2.4 GHz: Channel 8,9,10
Input 50 Ω
impedance
SWR < 3.5
Efficiency > 50% (on all frequencies)
Gain -0.5 dBi to 2 dBi
Polarization Linear
3.3 Software Specifications

Table 3-4 lists the B5328-155 software specifications.

LTE CPE B5328-155
Table 3-4 Software specifications
Item Description
Gateway Supports routing functions:

 Eight static router entries
 Common routing and NAT
 Manual IP address configuration for LAN connections
Supports DNS.
Supports IPv4.
NAT:
Supports NAT and Network Address and Port Translation (NAPT).
Supports the DHCP functions:
 Assigns IP addresses to managed hosts.
 Serves as a LAN gateway for managed hosts.
 Supports DNS relay.
firewall  Filters LAN MAC addresses.

 Filters LAN IP addresses.
 Filters URLs.
 Supports ACL-based access.
 Supports SPI.
 Supports anti-DoS attack.
 Supports demilitarized zone (DMZ).
 Supports Universal Plug and Play (UPnP).
LAN 100 Mbit/s/1000 Mbit/s auto-negotiation

Auto MDI/MDIX
WLAN IEEE 802.11b/g/n

SSID Broadcast and hide/AP isolation
Encryption:
 WPA2-PSK(AES)
 WPA-PSK(TKIP)
 WPA-PSK/WPA2PSK(AES+TKIP)
 WEP(SHARE, OPEN)
WPS: PIN code based access
Allows access for a maximum of 12 users.
Supports simultaneous data transmission for 12 users.
Upgrade Supports Firmware Over-the-Air (FOTA) upgrade and local upgrade.
USIM Supports PIN management and USIM card authentication.

LTE CPE B5328-155
Item Description
NTP Allows users to set the system clock through the Web UI.
Maintenanc Supports local maintenance.

e

LTE CPE B5328-155
Product Description 4 Services and Applications
4 Services and Applications
4.1 Data Services

After the USIM card is inserted, the B5328-155 can automatically connect to the Internet
through an LTE network to provide high-speed data services.
4.1.1 LAN Port

The local computer can connect to the Ethernet through the LAN port. Alternatively, devices
(for example, a mobile phone) can connect to the Ethernet through the WLAN port on the
B5328-155.
4.2 Security Services

The B5328-155 provides security services such as firewalls and a PIN protection mechanism.
4.2.1 Firewall
The B5328-155 provides the firewall to prevent unauthorized access.
4.2.2 MAC Filtering

The B5328-155 supports network access restriction by MAC address.
4.2.3 IP Address Filtering

The B5328-155 supports network access restriction by IP address.
4.2.4 URL Filtering

The B5328-155 supports network access restriction by URL address.
4.2.5 Forwarding by Using the DMZ

The B5328-155 supports forwarding packets to the local end over the DMZ.

LTE CPE B5328-155
Product Description 4 Services and Applications
4.2.6 UPnP
The B5328-155 supports UPnP to forward encapsulated packets to the local end through a
fixed port.
4.2.7 PIN Code Protection

The B5328-155 provides PIN code protection. If PIN code protection is enabled, users must
enter the correct PIN code each time they log in to the web management page. PIN codes are
user configurable.

LTE CPE B5328-155
Product Description 5 System Architecture
5 System Architecture
Figure 5-1 shows the B5328-155 system architecture.
Figure 5-1 System architecture
The B5328-155, an indoor LTE CPE UE, accesses the Internet through the LTE base station.
It allows user access through the wired or wireless connection.
 Wired connection through the RJ45 port: Terminals can connect to the B5328-155
through the Ethernet port to access the LAN or LTE networks. The data service can reach
a high speed of 1000 Mbit/s.
 Wireless connection through the WLAN port: The B5328-155 provides a WLAN port
compliant with IEEE 802.11b/g/n for wireless access.

LTE CPE B5328-155
Product Description 6 Technical Reference
6 Technical Reference
6.1 Compliant Protocols

6.1.1 B5328-155 Compliant Protocols
Table 6-1 B5328-155 compliant protocols
Item Description
Physical layer RFC894

ARP RFC826
IP RFC791, RFC1122, RFC1071, RFC1141, RFC1624, RFC792, RFC950,
RFC1256
ICMP RFC792, RFC950, RFC1256
TCP RFC793
UDP RFC768
DHCP RFC1531, RFC1533
NAT RFC1631
6.1.2 Radio Access Protocols

Table 6-2 Radio access protocols
Item Protocol
User Equipment (UE) conformance specification 3GPP TS 36.521

User Equipment radio transmission and reception 3GPP TS 36.101
Physical Channels and Modulation 3GPP TS 36.211
Multiplexing and Channel Coding 3GPP TS 36.212

LTE CPE B5328-155
Product Description 6 Technical Reference
Item Protocol
Physical layer procedures 3GPP TS 36.213
Physical layer – Measurements 3GPP TS 36.214
Radio Resource Control 3GPP TS 36.331

LTE CPE B5328-155
Product Description A Acronyms and Abbreviations
A Acronyms and Abbreviations
A
AP Access point
ARP Address Resolution Protocol
C
CPE Customer premises equipment
D
DHCP Dynamic Host Configuration Protocol
DMZ Demilitarized zone
DNS Domain name service
I
ICMP Internet Control Message Protocol
L
LAN Local area network
LTE Long Term Evolution
M
MAC Media Access Control
N
NAT Network Address Translation
P
PIN Personal identification number
S
SSID Service set identification
T
TCP Transmission Control Protocol

LTE CPE B5328-155
Product Description A Acronyms and Abbreviations
U
URL Uniform resource locator
USIM Universal Subscriber Identity Module
UDP User Datagram Protocol
UPnP Universal Plug and Play
W
WEP Wired equivalent privacy
Wi-Fi Wireless Fidelity
WLAN Wireless LAN
WPA Wi-Fi Protected Access
WPS Wi-Fi protected setup


Product Description: LTE CPE B5328-155

Uploaded by

Document Information

Original Title

Copyright

Available Formats

Share this document

Share or Embed Document

Sharing Options

Did you find this document useful?

Is this content inappropriate?

Copyright:

Available Formats

Product Description: LTE CPE B5328-155

Uploaded by

Copyright:

Available Formats

LTE CPE B5328-155

HUAWEI TECHNOLOGIES CO., LTD.

Trademarks and Permissions

Huawei Technologies Co., Ltd.

Issue 2016-01-05 Huawei Proprietary and Confidential i

About This Document

Issue 2016-01-05 Huawei Proprietary and Confidential ii

About This Document .................................................................................................................... ii

4 Services and Applications ......................................................................................................... 12

5 System Architecture .................................................................................................................... 14

A Acronyms and Abbreviations .................................................................................................. 17

Issue 2016-01-05 Huawei Proprietary and Confidential iii

Issue (2015-01-07) Huawei Proprietary and Confidential 4

The B5328-155 has the following main features:

Issue (2015-01-07) Huawei Proprietary and Confidential 5

3.1 Hardware Specifications

Issue (2015-01-07) Huawei Proprietary and Confidential 6

Table 3-1 B5328-155 hardware specifications

Access LTE: 3GPP Release 10 (Cat.5)

Working bands LTE FDD Band 3, Band 7, Band 20

WLAN 2.4 GHz: Channel 8,9,10

Bandwidth LTE 1.4 MHz, 3 MHz,5 MHz, 10 MHz, 15 MHz, 20 MHz

Ports/Button  One GE port

LED indicators  One power indicator

Maximum LTE 23 dBm

WLAN IEEE 802.11n: 22 dBm ± 1 dBm

Receiver LTE 5 MHz: -100 dBm

Power supply AC: 100 V to 240 V, 50/60 Hz

Dimensions (H 192 mm x 152.5 mm x 96.4 mm

Issue (2015-01-07) Huawei Proprietary and Confidential 7

Weight About 300 g

Temperature Working temperature: 0°C to 40°C

3.2 Antenna Specifications

Issue (2015-01-07) Huawei Proprietary and Confidential 8

Table 3-2 Internal LTE antenna specifications

3.2.2 Built-in WLAN Antenna

Table 3-3 Internal WLAN antenna specifications

3.3 Software Specifications

Issue (2015-01-07) Huawei Proprietary and Confidential 9

Table 3-4 Software specifications

Gateway Supports routing functions:

firewall  Filters LAN MAC addresses.

LAN 100 Mbit/s/1000 Mbit/s auto-negotiation

WLAN IEEE 802.11b/g/n

Upgrade Supports Firmware Over-the-Air (FOTA) upgrade and local upgrade.

USIM Supports PIN management and USIM card authentication.

Issue (2015-01-07) Huawei Proprietary and Confidential 10

Maintenanc Supports local maintenance.

Issue (2015-01-07) Huawei Proprietary and Confidential 11

4 Services and Applications

4.1 Data Services

4.1.1 LAN Port

4.2 Security Services

4.2.2 MAC Filtering

4.2.3 IP Address Filtering

4.2.4 URL Filtering

4.2.5 Forwarding by Using the DMZ

Issue (2015-01-07) Huawei Proprietary and Confidential 12

4.2.7 PIN Code Protection

Issue (2015-01-07) Huawei Proprietary and Confidential 13

Figure 5-1 shows the B5328-155 system architecture.

Figure 5-1 System architecture

Issue (2015-01-07) Huawei Proprietary and Confidential 14
