AcumaticaERP CustomizationFormReference

Customization Tool Reference
2022 R2
Contents | 2
Contents
Copyright...............................................................................................................................................4
Access Rights......................................................................................................................................... 5
Analytical Reports.................................................................................................................................. 7
Actions.................................................................................................................................................. 9
ASPX Editor.......................................................................................................................................... 19
Business Events.................................................................................................................................... 20
Code.................................................................................................................................................... 22
Code Editor.......................................................................................................................................... 24
Conditions............................................................................................................................................27
Connected Applications.........................................................................................................................31
Custom Files.........................................................................................................................................33
Customization Menu............................................................................................................................. 36
Customization Project Editor................................................................................................................. 39
Customization Projects......................................................................................................................... 44
Customized Data Classes....................................................................................................................... 49
Customized Screens.............................................................................................................................. 51
Data Class............................................................................................................................................ 53
Database Scripts...................................................................................................................................59
Dashboards.......................................................................................................................................... 63
Dialog Boxes.........................................................................................................................................65
Edit Project Items................................................................................................................................. 68
Element Inspector................................................................................................................................ 69
Event Handlers..................................................................................................................................... 72
Fields...................................................................................................................................................75
Generic Inquiries.................................................................................................................................. 79
Import and Export Scenarios................................................................................................................. 81
Mobile Application................................................................................................................................ 83
Mobile Workspaces............................................................................................................................... 86
Project XML Editor................................................................................................................................ 88
Push Notifications................................................................................................................................ 89
Reports................................................................................................................................................ 91
Screen Editor........................................................................................................................................93
Shared Filters.......................................................................................................................................99
Site Map............................................................................................................................................. 101
Contents | 3
Source Code....................................................................................................................................... 103

System Locales................................................................................................................................... 105
User-Defined Fields............................................................................................................................. 107
Webhooks...........................................................................................................................................109
Web Service Endpoints........................................................................................................................ 111
Wikis.................................................................................................................................................. 113
Workflow (Diagram View).................................................................................................................... 115
Workflow (Tree View).......................................................................................................................... 127
Workflows.......................................................................................................................................... 138
Copyright | 4
Copyright
© 2022 Acumatica, Inc.
ALL RIGHTS RESERVED.
No part of this document may be reproduced, copied, or transmitted without the express prior consent of
Acumatica, Inc.
3933 Lake Washington Blvd NE, # 350, Kirkland, WA 98033
Restricted Rights
The product is provided with restricted rights. Use, duplication, or disclosure by the United States Government is
subject to restrictions as set forth in the applicable License and Services Agreement and in subparagraph (c)(1)(ii)
of the Rights in Technical Data and Computer Soware clause at DFARS 252.227-7013 or subparagraphs (c)(1) and
(c)(2) of the Commercial Computer Soware-Restricted Rights at 48 CFR 52.227-19, as applicable.
Disclaimer
Acumatica, Inc. makes no representations or warranties with respect to the contents or use of this document, and
specifically disclaims any express or implied warranties of merchantability or fitness for any particular purpose.
Further, Acumatica, Inc. reserves the right to revise this document and make changes in its content at any time,
without obligation to notify any person or entity of such revisions or changes.
Trademarks
Acumatica is a registered trademark of Acumatica, Inc. HubSpot is a registered trademark of HubSpot, Inc.
Microso Exchange and Microso Exchange Server are registered trademarks of Microso Corporation. All other
product names and services herein are trademarks or service marks of their respective companies.
Soware Version: 2022 R2

Last Updated: 01/29/2023
Access Rights | 5
Access Rights
Page ID: (AU205200)
On this page, you manage the ScreenWithRights items in the customization project. A ScreenWithRights item
contains the dataset of the custom access rights of roles to a form, down to the control of form elements.
You open the Access Rights page by clicking Access Rights in the navigation pane of the
Customization Project Editor.
Page Toolbar and More Menu

The page toolbar includes standard buttons and page-specific buttons and commands. For the list of standard
buttons, see Page Toolbar. The page-specific commands can be shown as buttons on the page toolbar, as
commands on the More menu, or in both places. These commands are listed in the following table in alphabetical
order.
Command Description
Manage Access Opens the Access Rights by Screen (SM201020) form in a new browser tab, so that you
Rights can specify the access rights of the screen that was selected in the table.
Reload from Data- Updates the ScreenWithRights items in the customization project if these items have
base been modified on the forms related to user access configuration, such as Access Rights
by Screen (SM201020), Access Rights by Role (SM201025), and Access Rights by User
(SM201055).
Table: Add Access Rights for Screen Dialog Box

This dialog box opens when you click Add New Record on the page toolbar. The table contains the following
elements.
Element Description
The table in the dialog box has the following columns.
Selected A check box that you select to indicate that the access rights of the form (screen) in this
row will be added to the customization project.
Screen ID The ID of the form for which the access rights will be added.
Title The name of the form for which the access rights will be added.
This dialog box has the following buttons.
OK Adds the selected access rights to the table on the page and closes the dialog box.
Cancel Closes the dialog box without making any changes.
Table
This table lists the ScreenWithRights items in the customization project. The columns of the table are described
below.
Access Rights | 6
Column Description
Object Name The ID of the form for which the access rights will be added.
Description The description of the access rights.
Last Modified By The name of the user who last modified the access rights in the customization project.
Last Modified On The date when the access rights were last modified in the customization project.
Analytical Reports | 7
Analytical Reports
Page ID: (AU206003)
On this page, you manage the ReportDefinition items in the customization project. A ReportDefinition item contains
the dataset of a custom analytical report, including the data of a predefined set of rows, columns, and units.
You open the Analytical Reports page by clicking Analytical Reports in the navigation pane of the

order.
Command Description
Manage Report De- Opens the Report Definitions (CS206000) form in a new browser tab.
finitions
Reload from Data- Updates the ReportDefinition items in the customization project if the analytical reports
base that correspond to these items have been modified on the Report Definitions form.
Table: Add Report Definition Dialog Box

This dialog box opens when you click Add New Record on the page toolbar. The dialog box contains a table with
the following elements.
Element Description
The table toolbar includes only standard buttons. For the list of standard buttons, see Table Toolbar.
Included A check box that indicates (if selected) that the current report will be added to the
customization project if you click Save.
Code The internal name of the report.
Description The description of the report.
Last Modified By The name of the user who last modified the report in the customization project.
Last Modified On The date when the report was last modified in the customization project.
Save Adds the selected report to the table on the page and closes the dialog box.
Cancel Closes the dialog box without making or saving any changes.
Analytical Reports | 8
Table
This table contains a list of the analytical reports that have been modified in the customization project. The
columns of the table are described below.
Column Description
Object Name The name of the report in the customization project.
Actions | 9
Actions
Page ID: (AU201050)
For a particular screen (that is, a form in Acumatica ERP), you use this page to add a new action, modify an action in
a predefined workflow, or modify an action defined in a graph.
The table on the page displays actions added in the predefined workflow and actions added in previous versions of
Acumatica ERP.
You open the Actions page by clicking Actions under the screen ID (of the form for which you are
adding or modifying actions) in the navigation pane of the Customization Project Editor. In the
name that appears on the page, Actions is preceded by the screen ID and then the screen name in
parentheses.

order.
Command Description
Add Existing Action Opens the Action Properties dialog box, in which you can select an existing action, mod-
ify its properties (if needed), and then add this action to the workflow.
Create New Action Opens the Action Properties dialog box, where you can specify the settings of a new ac-
tion.
Delete Row Deletes the action selected in the table. You click the row with the action before you click
this button.
Manage Categories Opens the Manage Categories dialog box. In this dialog box, you can reorder the cate-
gories on the More menu of the Acumatica ERP form (that is, the screen) whose actions
you are viewing, change the names of existing categories, and add new categories.
Reorder Actions Opens the Reorder Actions dialog box, where you can reorder the actions located on the
form toolbar of the Acumatica ERP form (that is, the screen for which you have opened
the Actions page), or in a selected category of the More menu of this form.
Revert Changes Opens the Revert Changes dialog box, in which you can click OK to return all actions to
their predefined state.
View Changes Opens the Changes dialog box, where you can view the description of an action in JSON
format. If any changes have been applied to a predefined action, they are highlighted
in the dialog box. You can return the action to its predefined state by clicking Revert
Changes in the Changes dialog box.
The View Changes command is available only if the action is inherited—that is, based on
a predefined action.
Actions | 10
Action Properties Dialog Box

This dialog box opens when you click Create New Action on the page toolbar or Add Existing Action on the More
menu, or when you click the link with the action name in the table on the page.
Table: Action Properties Dialog Box: Summary Area

The Summary area of this dialog box has the following elements.
Element Description
Action Name The internal name of the action.

This box is read-only if you have opened the dialog box by clicking the link with the action
name in the table on the page.
Display Name The name of the action that will be displayed on the Acumatica ERP form that corre-
sponds to the screen.
Disabled An indicator of when the action is disabled.

By default, the box is empty, indicating that the action is always enabled. If the box is not
empty, it contain one of the following:
• True: The action is always disabled.
• Condition: The condition that, if it is met, causes the action to be disabled. If any con-
ditions are specified on the Conditions page for the screen of this action, they are avail-
able for selection in this box.
If the action is used in a workflow and its availability depends on the state of the applica-
ble entity, you need to specify this property in this state.
This box does not appear in the dialog box if the action has the Navigation: Side Panel
type.
Hidden An indicator of when the action is hidden.

By default, the box is empty, indicating that the action is always visible. If the box is not
empty, it can contain one of the following:
• True: The action is always hidden.
• Condition: The condition that, if it is met, causes the action to be hidden. If any condi-
tions are specified on the Conditions page for the screen of this action, they are avail-
able for selection in this box.
If the action is used in a workflow and its visibility depends on the state of the applicable
entity, you need to specify this property in this state.
type.
Dialog Box The dialog box that will be displayed when the action is clicked on the form, if applicable.
For details, see Dialog Boxes.
type.
Icon The icon that will be displayed for the action on the side panel.
This box appears only if the action has the Navigation: Side Panel type.
Actions | 11
Element Description
Processing Screen The screen ID of the processing form of Acumatica ERP on which the action will be an op-
tion in the Action box, in addition to being available on the form for which the action is
defined.
type.
On a mass-processing form, if you add to a schedule a workflow action that

invokes a dialog box in which a user should enter some additional informa-
tion, then for automated processing, the system uses the default values of
this dialog box.
For details on how to schedule mass processing, see Scheduling Automated
Processing.
Batch Mode A check box that (if selected) indicates that the records will be mass-processed on the
Acumatica ERP form specified in the Processing Screen box.
This check box does not appear in the dialog box if the action has the Navigation: Side
Panel type.
Action Type The type of the action.

You can select one of the following options:
• Run Report: The action runs the report whose ID is specified in the Destination Screen
box.
• Navigation: Search Records: The action redirects the user to the form whose ID is spec-
ified in the Destination Screen box and on which the user can search for records
(such as an inquiry or a generic inquiry).
• Navigation: Create Record: The action redirects the user to the data entry form whose
ID is specified in the Destination Screen box and on which the user can create a
record.
• Navigation: Side Panel: The action opens as a side panel the form whose ID is speci-
fied in the Destination Screen box. With this option selected, you can specify a form
of any of the following types as the destination: dashboard, report, or generic inquiry.
• Workflow: The action changes the state of an entity as a part of a workflow.
• Graph Action: Read-only. The action that is defined in a graph. This option is not avail-
able for selection when you are creating an action.
This box is read-only if you have opened the dialog box by clicking the link with the action
name in the table on the page.
Category The category of the More menu in which the menu command associated with the action
will be displayed on the form. The list of categories available for selection depends on the
form. To manage the categories, you click Manage Categories on the page toolbar.
type.
Destination Screen Required. The screen or report that will be opened when the action redirects a user to a
different screen.
This box does not appear in the dialog box if the action has the Workflow or Graph Action
type.
Actions | 12
Element Description
Window Mode An option that indicates whether the results of the action will be displayed on the same
tab, on a new tab, or in a pop-up window.
This box does not appear in the dialog box if the action has the Navigation: Side Panel,
Workflow, or Graph Action type.
Rights to Enable The minimum level of access rights that a user must have for the action to be enabled
Action on the form. The access rights of user roles are specified on the Access Rights by Screen
(SM201020) form.
If the action has the Workflow type, this option is set to Update by default. This means
that for the action to be available on the form, a user must have the Edit access rights for
the form. If the action has the Navigation: Search Records, Navigation: Create Record, or
Run Report type, this option is set to Select by default. This means that a user must have
View Only access rights (or a more permissible level) for the action to be available on the
form.
type.
Rights to View Ac- The minimum level of access rights that a user must have for the action to be visible on
tion the form.
type.
Expose to Mobile A check box that (if selected) indicates that the action will be available on the corre-
sponding mobile screen. The check box is cleared by default. To expose this action on the
mobile screen, you need to select this check box.
type.
Display on Toolbar The way the action is displayed on the form toolbar and under a category on the More
menu. One of the following options can be selected:
• Hide: The action will not be displayed on the form toolbar but will be displayed under
a category on the More menu if a category is specified for it. However, if you select the
Duplicate on Toolbar check box for this action in a workflow state, the action will be
displayed on the form toolbar when the record is in this state.
• If Available: The action will be displayed as a button on the form toolbar and under a
category on the More menu if the action is available for a record based on its state and
if a category is specified for it. If the action is available but no category is specified, the
action will be displayed on the form toolbar and under the Other category. If the ac-
tion is not available or a record based on its state, it will not be displayed on the form
toolbar and the More menu.
• Always: The action will be displayed as a button on the form toolbar and under a cat-
egory on the More menu even if the action is unavailable for the record based on its
state.
• As Configured in Graph: The action will be displayed according to the properties of the
PXButton attribute.
This box does not appear in the dialog box if the action has the Navigation:
Side Panel type.
Actions | 13
Element Description
Connotation A color notation that gives users additional information. For example, you can use con-
notations to indicate to users which action in the entity processing workflow is the one
most likely to be taken (given the state of the entity), which actions require special con-
sideration, and which actions provide links to additional information, such as reports.
On the More menu, the connotation is displayed as a dot of the selected color (see the list
below) after the associated menu command. If the action is also displayed on the form
toolbar, it is highlighted in the selected color.
The possible values and corresponding colors are as follows:
• Primary: The primary color of the site theme
• Secondary: The secondary color of the site theme
• Success: Green
• Danger: Red
• Warning: Yellow
• Info: Blue
• Light: Light gray
• Dark: Dark gray
type.
Table: Action Properties Dialog Box: Navigation Parameters Tab

On this tab, you specify the navigation parameters for the action. These parameters depend on the type of action
and are the following:
• For an action of the Run Report type: The parameters of the report
• For an action of the Navigation: Search Records type: The parameters by which the records are filtered
• For an action of the Navigation: Create Records type: The values for the fields of the new record
• For an action of the Navigation: Side Panel type: The parameters that will be passed to the side panel
The tab is not shown in the dialog box if the action has the Graph Action type.
The columns of the table are described below.
Column Description
Active A check box that indicates (if selected) that the parameter in this row is active.
Parameter Name The name of the parameter.
Value The value of the parameter.
From Schema A check box that indicates (if selected) that the parameter value from the database
should be used.
Table: Action Properties Dialog Box: Field Update Tab

This tab contains a table with the fields whose properties should be modified when the action is performed.
The tab is not available if the action has the Navigation: Side Panel type.
Actions | 14
Column Description
Active A check box that indicates (if selected) that the field should be updated.
Field The name of the field that should be updated.
From Schema A check box that indicates (if selected) that field value from the database should be used.
New Value The new value for the field.
Status The status of the field update.
Table: Action Properties Dialog Box: Action Parameters Tab

On this tab, you specify the action parameters that should be applied to the action method.
The tab is available only if the action has the Graph Action type.
Column Description
Active A check box that indicates (if selected) that the parameter in this row is active.
Parameter Name The name of the action parameter.
From Schema A check box that indicates (if selected) that parameter value from the database should be
used.
Value The value of the action parameter.
Status The status of the parameter.
Table: Action Properties Dialog Box: Buttons

The dialog box includes the following buttons.
Button Description
OK Closes the dialog box and applies the changes.
Manage Categories Dialog Box

This dialog box opens when you click Manage Categories on the page toolbar. In this dialog box, you can change
the order of the existing categories on the More menu of the form you are modifying. If needed, you can also add
new categories.
Actions | 15
Element Description
The table toolbar includes standard buttons and buttons that are specific to this table. For the list of standard
buttons, see Table Toolbar. The table-specific buttons are listed below.
Add Category Opens the New Category dialog box, where you can add a new category.
Move Up Moves the selected row up, which causes the selected category to be moved up on the
More menu. You click the row you want to move before clicking this button.
Move Down Moves the row down, which causes the selected category to be moved down on the More
menu. You click the row you want to move before clicking this button.
The table contains the following columns.
Category Name The internal name of the category.
Display Name The name of the category that will be displayed on the More menu of the form.
Cancel Closes the dialog box without saving any changes.
New Category Dialog Box

This dialog box opens when you click Add Category on the table toolbar of the Manage Categories dialog box. In
the dialog box, you can add a new category to the More menu of the form whose actions you are modifying.
Element Description
The dialog box has the following elements.
Category Name The internal name of the category.
Display Name The name of the category that will be displayed on the More menu of the form.
Reorder Actions Dialog Box

This dialog box opens when you click Reorder Actions on the More menu. In the dialog box, you can change the
position of the action in the category of the More menu where it is listed.
Element Description
The Summary area contains the following element.

Actions | 16
Element Description
Category The list of categories on the More menu in which the menu command associated with the
action is displayed.
Move Up Moves up the row, which causes the selected action to be moved up in the category of the
More menu.
Move Down Moves down the row, which causes the selected action to be moved down in the category
of the More menu.
The table contains the following elements.
Action Name The internal name of the action.
Display Name The name of the action that will be displayed on the applicable Acumatica ERP form.
Action Type The type of the action, which is one of the following:
box.
record.
• Navigation: Side Panel: The action opens as a side panel the form whose ID is speci-
fied in the Destination Screen box You can specify the following types of forms: dash-
boards, reports, and generic inquiries.
able for selection when you are creating an action.
Cancel Closes the dialog box without applying any changes.
Changes Dialog Box

You use this dialog box to view the source code of the action; the changes are highlighted in red. The dialog box
also contains the following buttons.
Button Description
Revert Changes Returns the action to its predefined state.

Actions | 17
Button Description
Close Closes the dialog box.
Table
This table contains the list of actions and the basic settings of each of them. When you click the link in the Action
Name column, the Action Properties dialog box is opened. The columns of the table are described below.
Table: Table Columns
Column Description
Action Name The internal name of the action. When you click the name, the Action Properties dialog
box is opened, which shows the properties of the selected action.
Action Type The type of the action.

This column can contain one of the following options:
box.
record.
• Navigation: Side Panel: The action opens as a side panel the form whose ID is specified
in the Destination Screen box. If this option is selected, you can specify a form of any
of the following types as the destination: dashboard, report, or generic inquiry.
able for selection when you create an action.
Disabled An indicator of when the action is disabled.

By default, the column is empty, indicating that the action is always enabled. If the col-
umn is not empty, it can contain one of the following:
• True: The action is always disabled.
• Condition: The condition that, if it is met, causes the action to be disabled. If any con-
ditions are specified on the Conditions page for the screen that contains this action,
they are available for selection in this column.
Hidden An indicator of when the action is hidden.

By default, the column is empty, indicating that the action is always visible. If the column
is not empty, it can contain one of the following:
• True: The action is always hidden.
• Condition: The condition that, if it is met, causes the action to be hidden. If any condi-
tions are specified on the Conditions page for the screen that contains this action, they
are available for selection in this column.
Actions | 18
Column Description
Dialog Box The dialog box that will be displayed when the action is clicked on the form, if applicable.
For details, see Dialog Boxes.
Processing Screen The processing form of Acumatica ERP on which the action will be an option in the Ac-
tion box, in addition to being available on the form for which the action is defined.
On a mass-processing form, if you add to a schedule a workflow action that

invokes a dialog box in which a user should enter some additional informa-
tion, then for automated processing, the system uses the default values of
this dialog box.
Category The category of the More menu in which the menu command associated with the action
will be displayed on the form.
This column is not populated if the action has the Navigation: Side Panel type.
Status The status of the action.

The status of the action can be one of the following:
• Inherited: The system action.
• New: The action that you have created.
• Modified: The system action that you have modified.
ASPX Editor | 19
ASPX Editor
Page ID: (SM204590)
You use the ASPX Editor page to edit the ASPX code of the particular screen (that is, the form in Acumatica ERP) that
you are customizing by using the Screen Editor page.
The ASPX Editor page contains the Source Code pane and a toolbar with only the Generate Customization Script
button, which is described below.
You open the ASPX Editor page by clicking Edit ASPX on the page toolbar of the Screen Editor page of
the Customization Project Editor. The name that appears on the page is ASPX Editor: followed by the
screen ID and then the screen name in parentheses.
Page Toolbar
The page toolbar includes only the following page-specific button.
Button Description
Generate Cus- Generates a customization script and saves it to the customization project. You use the
tomization Script Generate Customization Script button instead of a Save button because this action
saves to the customization project not the modified ASPX code but the difference be-
tween the modified code and the original code of the page.
Source Code Pane

You use the Source Code pane of the ASPX editor (shown in the following screenshot) instead of the Screen Editor
page if you want to use a text editor rather than a visual tool.
Figure: The Source Code pane of the ASPX editor

Business Events | 20
Business Events
Page ID: (AU210010)
On this page, you manage the BpEvent items in the customization project. A BpEvent item contains all the data
required to recreate the corresponding business event on any instance of Acumatica ERP.
You open the Business Events page by clicking Business Events in the navigation pane of the

order.
Command Description
Manage Business Opens the Business Events (SM302050) form in a new browser tab.
Events
Reload from Data- Updates the BpEvent items in the customization project if the business events that corre-
base spond to these items have been modified on the Business Events (SM302050) form.
If you have changed the generic inquiry used in the business event or the
import scenario of the business event, you need to update each changed
item separately on the corresponding page of the Customization Project Ed-
itor. If you have changed the notification template of the business event,
the system updates the notification template in the customization project
automatically when you update the business event.
Table: Add Business Events Dialog Box

This dialog box opens when you click Add New Record on the page toolbar. The dialog box contains the following
elements.
Element Description
Included An unlabeled check box that you select to add the business event in this row to the
customization project.
Event ID The internal name of the business event.

Business Events | 21
Element Description
Type The type of the business event, which can be one of the following:
• Trigger by Record Change: The system processes the subscribers specified on the
Subscribers tab when the inquiry results have changed in the ways specified
on the Trigger Conditions tab. The option is available if an inquiry or data en-
try form is specified in the Screen Name box. For details on this type of business
event, see Business Events: Data Change Processing.
• Trigger by Schedule: At the times and frequencies specified on the Schedules
tab, the system checks the results of the inquiry and processes the subscribers
specified on the Subscribers tab if the inquiry results satisfy the conditions
specified on the Trigger Conditions tab. The option is available if an inquiry
form is specified in the Screen Name box. For more information about this type
of business event, see Business Events: Scheduled Event Processing.
• Trigger by Action: The system processes the subscribers specified on the Sub-
scribers tab when a user clicks the action specified in the Action Name box
for this business event. The option is available if an inquiry form is specified in
the Screen Name box. For details on this type of business event, see Business
Events: User-Triggered Processing of Subscribers.
Save Adds the selected business events to the table on the page and closes the dialog
box.
Table
This table contains the list of business events in the customization project and the basic settings of each of them.
Column Description
Object Name The name of the business event in the customization project.
Description The description of the business event.
Last Modified By The name of the user who last modified the business event in the customization project.
Last Modified On The date when the business event was last modified in the customization project.
Code | 22
Code
Page ID: (AU204000)
On this page, you manage the Code items in the customization project. You can add the following Code items:
• New Graph: A new business logic controller that is derived from the PXGraph<> class
• New DAC: A data access class that is derived from the IBqlTable class
• Graph Extension: A graph extension that is derived from the PXGraphExtension<> class
• DAC Extension: A DAC extension (which is also referred to as a cache extension) that is derived from the
PXCacheExtension<> class
• Code File: Custom C# code
• Customization Plug-in: A class that is derived from the CustomizationPlugin class
You open the Code page by clicking Code in the navigation pane of the Customization Project Editor.

order.
Button Description
Edit Opens the Code Editor page for the Code item selected in the table. You click the row with
the item and then click this button. (You can also open the Code Editor page by clicking
the link in the Object Name column.)
Table: Create Code File Dialog Box

This dialog box opens when you click Add New Record on the page toolbar.
Element Description
File Template The type of the Code item that will be created.
You select one of the following options:
• New Graph (default): To create a business logic controller
• New DAC: To create a data access class
• Graph Extension: To create a graph extension
• DAC Extension: To create a DAC extension
• Code File: To create custom C# code
• Customization Plug-In: To create a class
Code | 23
Element Description
Class Name The name of the entity, which is one of the following, depending on the option se-
lected in the File Template box:
• If New Graph is selected in the File Template box, the class name of the business
logic controller
• If New DAC item is selected in the File Template box, the class name that corre-
sponds to the name of the table created in the database
• If Code File is selected in the File Template box, the name of the new class
• If Customization Plug-in is selected in the File Template box, the name of the
plug-in
Base Graph The class name of the business logic controller.

This box is available only if Graph Extension is selected in the File Template box.
Base DAC The DAC on which the DAC extension is based.

This box is available only if DAC Extension is selected in the File Template box.
Generate Members A check box that you select to indicate that a data access class will be generated with
from Database members that correspond to the table columns.
This check box is available only if New DAC is selected in the File Template box.
OK Adds the Code item to the table on the page and closes the dialog box.
Cancel Closes the dialog box without any changes.
Table
This table lists the Code items in the customization project. The table contains the following columns.
Column Description
Object Name The name of the Code item in the customization project.
Description The description of the Code item.
Last Modified By The name of the user who last modified the Code item in the customization project.
Last Modified On The date when the Code item was last modified in the customization project.
Code Editor | 24
Code Editor
Page ID: (AU204000)
On this page, you can develop, view, and edit the customization code that has been added to the project. The name
that appears on the page is Code Editor: followed by the object name of the Code item whose code you are viewing.
You open the Code Editor for any Code item by clicking the link in the table on the Code page or by
clicking its name under Code in the navigation pane. You can also open the Code Editor from an
Acumatica ERP form by clicking Customization > Inspect Element to open the Element Properties
dialog box, and then clicking Actions > Customize Business Logic.
Page Toolbar
The page toolbar includes standard and page-specific buttons and commands. For the list of standard buttons, see
Page Toolbar. The page-specific commands are listed in the following table.
Button Description
Move to Extension Launches the operation that converts the current Code item into a file of customiza-
Lib. tion code, adds the file to the extension library project in Microsoft Visual Studio, and re-
moves the item from the customization project. See the Move to Extension Lib. Button sec-
tion of this topic for details.
The customization project must be bound to an existing extension library

project in Visual Studio before you click the Move to Extension Lib. button.
See Customization Project Editor for details.
New Action Opens the Create Action dialog box, which you can use to create a code template for a
new action.
Open Screen Opens the form bound to the business logic controller if you are editing the customiza-
tion code of the business logic executed for a form.
Override Method Opens the Select Methods to Override dialog box, which you can use to select multiple
virtual methods of the business logic controller (BLC) to override.
View Source Opens the Source Code Browser (see Source Code) with the original source code of the
BLC if you are editing the customization code of the business logic executed for a form.
Table: Create Action Dialog Box

This dialog box opens when you click New Action on the page toolbar. By using the dialog box, you can create an
action in the business logic controller whose extension you are viewing in the Code Editor. The dialog box contains
the following elements.
Element Description
Action Name The name of the action delegate method.

Code Editor | 25
Element Description
OK Adds the template of the action declaration to the graph extension and closes the dia-
log box.
Table: Select Methods to Override Dialog Box

This dialog box opens when you click Override Method on the page toolbar. The dialog box contains the list of the
virtual methods of the current BLC and its parent classes.
When you override a virtual method, the system generates an overridden method template that includes the
delegate declaration of the base method, the PXOverride attribute, and the method declaration that invokes the
base method delegate.
Column Description
The table in the dialog box contains the following columns.
Selected A check box that you select to indicate that the virtual method will be overridden in
the BLC extension.
Type The identifier of the class type that contains the declaration of the virtual method.
Method The signature of the virtual method.
Save Adds to the graph extension a template of an overridden method for each method
selected in the table.
Move to Extension Lib. Button

You can develop customization code either as Code items in a customization project or as source code included in
an extension library project to be developed in Microso Visual Studio. Some part of a customization may exist in
the Code items of a customization project, while another part can be included in an extension library that is added
to the customization project as a dynamic link library (DLL) file.
If you have a Code item in a customization project that you want to move to an extension library to compile it into a
DLL file, you can use the Move to Extension Lib. button on the page toolbar of the Code Editor.
Before you click this button, make sure that the customization project is bound to an existing extension library. (See
Customization Project Editor for details.)
Aer the operation is complete, the Code item that is currently displayed in the work area of the Code Editor is
removed from the customization project, and a file with the same source code is appended to the extension library
that is bound to the customization project. The system assigns a similar name to the file: For example, if the Code
item name was CodeItemName, the name of the created file will be CodeItemName.cs.
The operation of moving code to an extension library is irreversible. If you need to move source code from an
extension library to a Code item of a customization project, use the following approach:
• In Visual Studio (or any text editor), open the file, select the needed source code, and copy it to the
clipboard.
• Create a new Code item in the customization project.
Code Editor | 26
• Delete the code template from the created item.

• Paste the code from the clipboard, and save the Code item to the customization project.
• Delete the source code file from the extension library.
Source Code Pane

You use the Source Code pane of the Code Editor page to view and edit the code for the Code item that you opened
from the navigation pane or the Code page.
Conditions | 27
Conditions
Page ID: (AU201000)
You use the Conditions page to construct a condition that can later be specified as a property value for the
following items on a particular screen (that is, a form in Acumatica ERP):
• A UI control
• An action, including an auto-run action
• Transition
You open the Conditions page by clicking Conditions under the screen ID (of the form for which you
are constructing the condition) in the navigation pane of the Customization Project Editor. In the
name that appears on the page, Conditions: is followed by the screen ID and then the screen name in
parentheses.
Page Toolbar
Condition Properties Dialog Box

This dialog box opens when you click Add New Record on the page toolbar of the Conditions page, or when you
click a link of an existing condition in the Condition Name column of the table on the page.
This dialog box shows the rows that make up the condition. You can add new rows and modify existing rows of the
conditions that you have created previously.
Table: Condition Properties Dialog Box: Summary Area
Element Description
Condition Name The name of the condition.
Append System A check box that indicates (if selected) that a predefined condition will be used along
Condition with the condition specified in the table.
System Condition The predefined condition that will be used along with the condition specified in the ta-
ble.
This box is available only if you select the Append System Condition check box.
Operator The logical operator to join the system condition specified in the System Condition box
and the condition specified in the table in a logical expression. Possible values are And or
Or.
This box is available only if you select the Append System Condition check box.
Table: Condition Properties Dialog Box: Table

Column Description
Active A check box that indicates (if selected) that the row is an active condition.
Conditions | 28
Column Description
Brackets The opening bracket or brackets for composing a logical expression with multiple condi-
tions.
Field Name The field to whose value the condition should be applied.
Condition The logical condition that will be applied to the value of the field specified in the Field
Name box and the values in the Value and Value 2 fields, if applicable.
One of the following logical conditions should be selected:
• Equals: Returns TRUE if the field value is equal to the value specified as Value.
• Does Not Equal: Returns TRUE if the field value is not equal to the Value value.
• Is Greater Than: Returns TRUE if the field value is greater than the Value value.
• Is Greater Than or Equal To: Returns TRUE if the field value is greater than or equal to
the Value value.
• Is Less Than: Returns TRUE if the field value is less than the Value value.
• Is Less Than or Equal To: Returns TRUE if the field value is less than or equal to the Value
value.
• Is Between: Returns TRUE if the field value is between the Value and Value 2 values.
(For this option, you must specify both Value and Value 2.)
• Contains: Returns TRUE if the field value (string) contains the Value value.
• Does Not Contain: Returns TRUE if the field value (string) does not contain the Value
value.
• Starts With: Returns TRUE if the field value begins with the Value value.
• Ends With: Returns TRUE if the field value ends with the Value value.
• Is Empty: Returns TRUE if the field value is empty (null).
• Is Not Empty: Returns TRUE if the field value is not empty (not null).
From Schema A check box that indicates (if selected) that in the Value and Value 2 columns, you can se-
lect one of the predefined values of the field selected in the Field Name column (for ex-
ample, a document type or a document status).
Value The value to be used in the selected condition. You can select a field, or you can click the
Edit button to open the Formula Editor dialog box and create a formula.
For the date-related data fields, you can use the date-relative parameters either by select-
ing the parameter in the Calendar dialog box (if the field is based on a schema field and
the From Schema check box is selected) or by using the date-relative parameter in a for-
mula (if the field is not based on a schema field and you use the formula editor). The fol-
lowing date-relative parameters are available:
• @Today: The current day.
• @WeekStart and @WeekEnd: The start and end, respectively, of the current week. The
start and end of the week are determined according to the default system locale or the
locale the user has selected when signing in to Acumatica ERP. The system locales are
specified and configured on the System Locales (SM200550) form.
• @MonthStart and @MonthEnd: The start and end, respectively, of the current month.
• @QuarterStart and @QuarterEnd: The start and end, respectively, of the current quar-
ter.
• @PeriodStart and @PeriodEnd: The start and end, respectively, of the current financial
period. The financial periods are defined on the Financial Year (GL101000) form.
Conditions | 29
Column Description
For more information on financial periods in Acumatica ERP, see Managing Financial
Periods.
• @YearStart and @YearEnd: The start and end, respectively, of the current calendar year.
All the date-relative parameters use the date (in UTC) of the server used to
run the Acumatica ERP instance as the current date.
Additionally, you can modify the date-relative parameters by adding or subtracting inte-
gers. The unit of measure of the parameter is determined automatically and the reference
point is moved according to the measurement of the parameter—for example, @WeekS-
tart+1 relate to the start of the next week.
You can use the following company-related parameters to filter records or show values
that depend on a branch or a company selected by a user in the Company and Branch
Selection menu:
• @branch: The branch specified for a entity
• @company: The company specified for a entity
You can also use the following user-relative parameters for the workgroup-related data
fields with the Is In or Is Not In condition:
• @MyGroups: The workgroups in which the current user is a member, excluding the
workgroups that are the subordinates of these workgroups
• MyWorktree: The workgroups in which the current user is a member, including the
groups that are subordinates of these groups according to the tenant tree structure
Value 2 The second value to be used, if the selected condition requires another value. You select
a field, or you click the Edit button to open the Formula Editor dialog box and create a
formula.
For the date-related data fields that are not based on a schema field (that is, the From
Schema check box is cleared), you can use one of the date-relative parameters, as de-
scribed in the previous description.
Brackets The closing bracket or brackets for composing a logical expression with multiple condi-
tions
.
Operator The logical operator to join conditions in a logical expression, which can be And or Or.
Table: Condition Properties Dialog Box: Buttons

The dialog box includes the following buttons.
Button Description
OK Adds the condition to the list of conditions on the page or updates the existing condition;
closes the dialog box.

Conditions | 30
Table
The table on the page displays the conditions added in the predefined workflow and the conditions that have been
added in previous versions of Acumatica ERP.
Column Description
Condition Name The internal name of the condition. When you click the name of the user-defined condi-
tion, the Condition Properties dialog box is opened, which shows the properties.
Expression The short version of the condition that you have constructed in the table of the Condi-
tion Properties dialog box.
Status The status of the condition, which can be one of the following: System Read-Only, Inherit-
ed, or New.
Table: Shortcut Menu

If you right-click within the rows of a table, the system opens a shortcut menu. The commands you see in the menu
are duplicates of actions on the table toolbar and are listed below.
Command Description
Refresh Refreshes the data in the table.
Delete Deletes the selected row.

Connected Applications | 31
Connected Applications
Page ID: (AU210030)
On this page, you can manage the connected applications in the customization project.
You open the Connected Applications page by clicking Connected Applications in the navigation
pane of the Customization Project Editor.

order.
Command Description
Manage Connected Opens the Connected Applications (SM303010) form in a new browser tab.
Application
Reload from Data- Updates the connected application properties in the customization project if these prop-
base erties have been modified on the Connected Applications (SM303010) form.
Table: Add Connected Application Dialog Box

This dialog box opens when you click Add New Record on the page toolbar.
Element Description
The dialog box contains the following columns.
Included A check box that indicates (if selected) that the client application will be added to the
Client Name The name of the client application.
OAuth 2.0 Flow The OAuth 2.0 flow that is used by the client application for authentication in Acumati-
ca ERP.
Save Adds the selected connected application to the table on the page and closes the dia-
log box.
Table
This table lists the connected applications included in the customization project. The table contains the following
columns.
Connected Applications | 32
Column Description
Object Name The name of the connected application in the customization project.
Description The description of the connected application.
Last Modified By The name of the user who last modified the connected application in the customization
project.
Last Modified On The date when the connected application was last modified in the customization project.
Custom Files | 33
Custom Files
Page ID: (AU202500)
On this page, you manage the File items in the customization project. A File item contains the path to the custom
file and the GUID of the file content in the file storage of the database. The path is relative to the website folder.
You open the Files page by clicking Files in the navigation pane of the Customization Project Editor.

order.
Command Description
Detect Modified Runs the check for modified files and opens the Modified Files Detected dialog box if any
Files files have been modified.
This process compares each file in the project (in the database) with the original file and de-
tects the files modified in the file system. If any files have been modified, it opens the Modi-
fied Files Detected dialog box.
Table: Modified Files Detected Dialog Box

This dialog box is displayed when you click Detect Modified Files on the More menu if you have modified any files
of the customization project in the file system. The dialog box lists all custom and customized files in the website
folder. The dialog box contains the following elements.
Element Description
Selected A check box that you select to update the current file in the customization project.
Conflict A check box that indicates (if selected) that the file version in the file system differs
from the file version in the customization project.
Path The path to the modified file.
Update Customiza- Updates the customization project with the file version from the file system.
tion Project
Discard All Changes Keeps the file version that exists in the customization project and discards the changes
in the file system.
Table: Add Files Dialog Box

This dialog box opens when you click Add New Record on the page toolbar. The dialog box contains a table that
lists the files that you can add to the customization project.
Custom Files | 34
Element Description
The table in this dialog box contains the following columns.
Selected A check box that indicates (if selected) that the current file will be added to the customiza-
tion project.
Path The path to the file.
Modified The date when the file was modified.
Size The size of the file.
Save Adds the selected files to the table on the page and closes the dialog box.
Cancel Closes the dialog box without adding any files to the page.
Table: Edit File Dialog Box

This dialog box opens when you click the name of the file in the table on the page. The dialog box contains the
following elements. In the dialog box, you can review and edit a text file, or review the content of a binary DLL file.
If you have modified a custom file and saved the changes in the database, the changes are not saved in the original
file in the file system. If you then click Detect Modified Files on the More menu, the system does not detect a
conflict because the file in the database is newer. The system automatically updates the original file in the file
system during the publication of the customization project.
The dialog box contains the following elements.
Element Description
Work Area The area where you review and edit the file.
Save Saves the changes you have made to the file and closes the dialog box.
You cannot save changes to DLL files.
Table
This table contains the list of custom files and the basic settings of each of them. The columns of the table are
described below.
Element Description
Object Name The name of the custom file in the customization project.
Third-Party Assembly A check box that indicates (if selected) that the current file is a third-party assembly.
Custom Files | 35
Element Description
Description The description of the custom file.
Last Modified By The name of the user who last modified the file in the customization project.
Last Modified On The date when the file was last modified in the customization project.
Customization Menu | 36
Customization Menu
You can access the Customization menu on the form title bar of an opened Acumatica ERP form if your user
account is assigned the Customizer role. (For details, see To Assign the Customizer Role to a User Account.)
You click Customization on the form title bar to access the customization-related menu commands
associated with the form, as shown in the following screenshot.
Figure: Customization menu commands
Menu Commands
You can use the following customization-related menu commands.
Command Description
Select Project Opens the Select Customization Project dialog box, which you use to select an existing
customization project or to specify the name of a new project for all modifications that you
are going to perform.
Inspect Element Launches the Element Inspector, so that you can select a UI control on the current form and
open the Element Properties dialog box for the selected control. You use this dialog box
to inspect and customize the control.
You can use the keyboard shortcut Ctrl+Alt+Click to inspect elements on pop-
up windows and dialog boxes.
If you have selected a customization project, all the modifications that you initiate in the
inspector will be added to this current project. Otherwise, the Element Inspector opens
the Select Customization Project dialog box.
Command Description
Manage User-De- Opens the Edit User Defined Fields (CS205020) form, where you can select user-defined
fined Fields fields for the current form from the previously defined list of attributes and user-defined
fields (for details, see Managing Attributes and User-Defined Fields).
This command appears only on data entry forms and reports.
For details on how to add user-defined user fields, see To Add User-Defined Fields to a
Form.
Edit Project Opens the Customization Project Editor for the currently selected customization project.
Manage Cus- Opens the Customization Projects (SM204505) form.

tomizations
Show State Dia- Opens the State Diagram dialog box, which contains the workflow diagram for the select-
gram ed form and the Customize Workflow button.
If you click the Customize Workflow button, the system opens the Select Customiza-
tion Project dialog box. In this dialog box, you select an existing customization project (or
click New and then specify the name of the customization project to be created in the New
Project dialog box) and click OK. This opens the Customization Project Editor, so that you
can modify the workflow for the current form. For details, see Workflow Creation: General
Information and Diagram View: General Information.
If you have only one customization project, the system opens the Customization Project
Editor for this project after you click Customize Workflow, without displaying the Select
Customization Project dialog box.
This command is displayed for forms with workflows without composite

states.
Table: Select Customization Project Dialog Box

You use the Select Customization Project dialog box to select an existing customization project or to create a new
You open the dialog box in the following ways:
• From the Customization menu of a form by clicking Select Project
• From the Customization menu of a form by clicking Edit Project if there is no currently selected
customization project
• From the Element Properties dialog box if you click Customize in the dialog box and there is no currently
selected customization project
Element Description
The dialog box has the following element.
Project Name Provides the ability to select an existing customization project.
The dialog box has the following buttons.
OK Confirms your selection and closes the dialog box.
Cancel Cancels the operation and closes the dialog box.

Element Description
New Opens the New Project dialog box, where you can create a new project.
Table: New Project Dialog Box

You use the New Project dialog box to create a customization project. The dialog box contains the following
elements.
Element Description
The dialog box has the following element.
Project Name The name of the customization project you are creating.
The customization project name is used as the namespace if you create an ex-
tension library from the project. The first character of the name must be a let-
ter or the underscore symbol.
OK Creates an empty customization project with the specified name and closes the dialog box.
As soon as you click OK, the system creates a customization project in the
database.
Cancel Closes the dialog box without creating a customization project.

Customization Project Editor | 39
Customization Project Editor

Form ID: SM204510
You can use the Customization Project Editor to develop and manage the content of a customization project.
The editor contains separate pages to add and manage items of the following types in the currently selected
customization project. (See Managing Items in a Project for instructions.)
• Screen (form)
• Data access class
• Code (C#)
• File
• Generic inquiry
• Acumatica Report Designer report
• Site map
• Database script (custom column or script)
• Translation (language locale)
• Integration scenario
• Shared reusable filter
• Access rights of roles to forms
• Wiki changes
• Analytical report
• Push notification
• Mobile app screen
You can launch the Customization Project Editor only if you have selected a customization project and your user
account is assigned the Customizer role.
You can launch the editor from any Acumatica ERP form by using the Customization Menu or from the
Customization Projects (SM204505) form.
Pages of the Customization Project Editor

The Customization Project Editor is a set of pages with a common interface, and the interface consists of the
following parts:
• The main menu for working with the customization project (see Item 1 in the following screenshot)
• The navigation pane, which displays the list of pages used to manage the corresponding project items (Item
2)
• The main area, which displays the selected page (Item 3, which shows the Custom Files page)
Figure: The Customization Project Editor
In the navigation pane, a node with a capitalized name can be expanded to give you direct access to items of the
appropriate type.
Main Menu of the Project Editor

The main menu contains the following items and commands.
Command Description
The File menu contains the following commands.
Manage Customiza- Opens the Customization Projects (SM204505) form in a new window.
tion Projects
Edit Project XML Opens the Project XML Editor, which you can use to edit the XML source code of the cur-
rent customization project, save it to the database, download the project package, and
upload a deployment package to replace the project content.
Edit Project Items Opens the Edit Project Items page, which you can use to edit the XML source code of a
project item.
Export Project Exports the deployment package of the project—that is, the ZIP file that contains the
Package project. The file has the same name as the exported customization project has.
Command Description
Replace from Pack- Initiates the import of a previously exported deployment package from a ZIP file. This
age menu command opens the Open Package dialog box with the Choose File button and
the Upload button, which you can use to replace the current project content.
Validate Project Opens the Customization Project Prefix dialog box, in which you can make sure that all
Prefix project items contain the needed prefix.
Export Project Generates a workbook with the project items in Excel format. The workbook contains a
Items Workbook list of solution objects and integration scenarios grouped by the following types:
• Site map nodes
• Mobile site map nodes
• BLСs and BLC extensions
• DACs and DAC extensions
• Push notifications
• Import or export scenarios
The Publish menu contains the following commands.
Publish Current Initiates the process of publishing the current customization project. The system launch-
Project es a publication process that opens the Compilation window, where you can view a log
with information about the process.
Validate Current Initiates the process of validating the current project. The system launches the valida-
Project tion process and opens the Compilation window, where you can view a log with infor-
mation about the process.
If both the validation and the compilation of the project are successful, the system
makes the Publish button available. You can click this button to finalize the publishing
and to update the website.
Multiple Projects Opens the Customization Projects form.
Publish with Initiates the process of publishing the current customization project, as the Publish Cur-
Cleanup rent Project command does, but with the following difference: When the Acumatica
Customization Platform publishes a project that contains a database script, the plat-
form executes the script and tries to avoid executing the script at every publication of
the project for optimization purposes. Therefore, the platform keeps information about
each script that has been executed at least once and has not since been changed in the
database, and omits the repeated execution of such scripts.
If you run the Publish with Cleanup operation, the platform cleans all the information
about previously executed scripts of the customization project and executes this scripts
once more while publishing the project.
The Extension Library menu contains the following commands.

Command Description
Create New Creates a solution for Microsoft Visual Studio in which you can develop an extension li-
brary for the customization project. The solution contains the website and extension li-
brary projects. This action also downloads the OpenSolution.bat file. The file con-
tains the absolute path to the .sln file in the file system; you can use this file to open
the solution in Visual Studio.
By default, the system uses the App_Data\Projects folder of the web-

site as the parent folder for the solution project. If the website folder is out-
side of the C:\Program Files (x86) and C:\Program Files
folders, such as C:\AcumaticaSites\MySite, we recommend that
you not change it. Otherwise, we recommend that you specify a parent
folder outside these folders to avoid an issue with permission to access
files.
Bind to Existing Opens the Bind to Extension Library dialog box with the Containing Folder box and
the OK and Cancel buttons. In this dialog box, you specify the extension library project
in the file system to which the customization code will be moved if you click Move to Ex-
tension Lib. on the page toolbar of the Code Editor page.
Open in Visual Stu- Downloads the OpenSolution.bat file, which is used to open the existing solution in
dio Visual Studio.
Show Active Exten- Starts the verification of extensions for data access classes and business logic con-
sions trollers, and opens the Validate Extensions pop-up window to display the validation
log. In the log, every error is highlighted in red. We recommend that you verify exten-
sions if you have upgraded legacy DAC customization.
Analyze Referenced Runs the validation of custom files in the customization project and downloads the CSV
Assemblies file with the report.
The Source Control menu contains the following commands.
Save Project to Saves the customization project as a set of files to a local folder that is used for integra-
Folder tion with source control systems. Opens the Saves Project to Folder dialog box (see To
Save a Project to a Local Folder for instructions), in which you can select the name and
location of the folder inside a repository.
Open Project from Opens the Open Project from Folder dialog box. In this dialog box, you specify the
Folder repository (in the Containing Folder box) from which the system should load the cus-
tomization project.
Table: Customization Project Prefix Dialog Box

In this dialog box, you can make sure that the names of the project items contain the needed prefix.
Element Description
Project Prefix The prefix that the project items should have.
Validation Result The area that displays the results of the validation.
Element Description
Validate Project Runs the validation process. This button becomes available when you enter the prefix in the
Items Project Prefix box and click Save.
Save Saves the project prefix to the customization project.
Save & Close Saves the project prefix and closes the dialog box.
Cancel Closes the dialog box without saving your changes.
Table: Save Project to Folder dialog box

In this dialog box, you specify the folder to which the items of the customization project will be saved.
Element Description
Parent Folder The path to the folder to save the project items.
Project Name The name of the folder.
OK Closes the dialog box and saves the project items to the specified folder.
Cancel Closes the dialog box without saving your changes.

Customization Projects | 44
Customization Projects
Form ID: (SM204505)
You use this form to do any of the following:
• Add a new customization project, which is a set of changes and additional files that are used to modify the
Acumatica ERP application
• Open a customization project for editing in the Customization Project Editor
• Validate a customization project or multiple projects (see Validation of a Customization Project for details)
• Publish a customization project (or multiple projects) for a tenant or multiple tenants
• Cancel the publication of customization projects
• View the XML of the published customization project
• Export a customization project as the deployment package
• Import a customization project from an existing deployment package
• Delete a customization project
Form Toolbar
The form toolbar includes standard buttons and form-specific buttons and commands. For the list of standard
buttons, see Form Toolbar. The form-specific commands can be shown as buttons on the form toolbar, as
order.
Command Description
DAC Attributes Determines whether there are any PXAttributeFamilyAttribute violations on a

(Runtime Valida- DAC field.
tion)
DAC Field Types Verifies that the data type of a DAC field matches with the field states generated at run-
(Runtime Valida- time.
tion)
Export Exports the deployment package of the customization project—that is, the ZIP file with
the project. The file has the same name as the exported customization project.
Import Initiates the import of a previously exported deployment package from a ZIP file. When
you click this button or command, the system opens the Open Package dialog box,
which has the Choose File button and the Upload button to execute the operation.
Lookup Definitions Verifies that the DAC fields with lookup boxes defined for a segmented key properly han-
(Runtime Valida- dle foreign key segments by means of PXDimensionAttribute.
tion)
Command Description
Publish Initiates the process of publishing the selected customization projects (that is, those
for which you have selected the check box in the Included column). When you click this
command, the Compilation dialog box opens to display a log of information about the
process.
If both the project validation and the compilation of the modified website are successful,
the system displays the Publish button in the dialog box; you click this button to finalize
the publishing and to update the website.
Publish to Multiple Opens the Publish to Multiple Tenants dialog box, which is used to select the tenants to
Tenants which the selected customization projects are published and to configure the publishing
options. (You select the check box in the Included column for all projects to be published
before clicking this command.) After publication is complete, the selected tenants share
the customization data that is specific to the opened tenant and stored exclusively in the
database.
See Customization Projects: Publication to a Multitenant Website or Customization of a Multi-
tenant Site for details.
Replace Highlight- Initiates the import of a previously exported deployment package from a ZIP file to re-
ed Project Content place the content of the customization project that is currently selected in the table. This
command opens the Open Package dialog box, which has the Choose File button and
the Upload button.
Unpublish All Removes the publication of all listed customization projects from the website. This com-
mand does not delete the projects themselves.
Validate Certifica- Checks the certification status of all customization projects.

tion Status
Validate Highlight- Initiates the process of validating the selected customization projects (that is, those for
ed Project which you have selected the Included check box). This command opens the Validation
Results dialog box, which displays a log of information about the process.
Validate Multiple Opens the Choose Projects dialog box, which is used to select the customization projects
Projects for validation.
View Published Displays the Published Customization page, which displays the merged content of the
customization projects that are currently published.
See Published Customization Page for details.
Publish to Multiple Tenants Dialog Box

By using this dialog box, you can publish customization projects to multiple tenants at once.
Element Description
This dialog box includes a table with the following columns.
Selected A check box that indicates (if selected) that the system will publish the selected cus-
tomization projects on the tenant.
Element Description
Tenant Name The tenant name that is used on the site map.
ID The tenant identifier, which was generated automatically by the system when the tenant
was created.
Parent ID The identifier of the parent tenant that was used to create the tenant in the Acumatica
ERP Configuration Wizard.
This dialog box has the following elements below the table.
Apply Changes A check box that indicates (if selected) that the system applies to the selected tenants on-
Only to Database ly the database changes introduced by the selected customization packages.
(Skip Website Up-
If you have published all the selected customization projects in the website for a tenant,
date)
you do not need to update website files while publishing to the other tenants. You can
apply only the database changes.
For details, see Customization Projects: Publication to a Multitenant Website.
Execute All Data- A check box that indicates (if selected) that the system cleans all the information about
base Scripts (In- previously executed scripts of the customization project and executes them once more
cluding Previously while publishing the selected projects.
Executed)
If you have published all the selected customization projects in the website for a tenant,
you do not need to run the executed scripts once again while publishing the projects to
the other tenants. The system will run only any scripts that were not executed earlier.
For details, see Customization Projects: General Information.
OK Closes the dialog box and initiates the process of publishing the selected projects to each
tenant selected in the table of the dialog box. As a result, the published customization
content is saved in the database for each selected tenant.
Table
This table lists all the customization projects that have been created for the instance of Acumatica ERP. The
Column Description
Included An unlabeled check box that indicates (if selected) that the system will execute the se-
lected command for the project in this row.
Published A check box that indicates (if selected) that the project is published.
Project Name The unique name of the project. The project name is also a link you can click to open
the project in the Customization Project Editor, which is used to configure the project
changeset for the website.
Column Description
Level A number representing the level that is used to resolve any conflicts that arise if multiple
modifications of the same items of the website are merged.
If you leave this box empty, the default value is 0.
Use higher values for projects that contain more important changes.
Screen Names A system-generated list of the identifiers of the screens that have been modified in the
project.
Description The description of the customization project, which may be a short explanation of the
changes.
Certification Sta- The certification status of each uploaded customization project. A customization project
tus can have one of the following statuses:
• Certified: The project has been imported into the Acumatica ERP instance and is avail-
able in the database with the certified customization projects.
• Not Certified: The project has been imported into the Acumatica ERP instance and is
not available in the database with the certified customization projects.
• Not Verified: The project has been manually modified or created in the current
Acumatica ERP instance.
• Not Certified for Current Version: The project has been imported into the Acumati-
ca ERP instance and is available in the database with the certified customization
projects, but the major version it has been certified for is not the same as the major
version of the current Acumatica ERP instance.
Initials The project prefixes assigned to the customization project provided by Acumatica or ISV
partners.
Created By The name of the user who created the project.
Last Modified On The date when the project was modified most recently.
Published Customization Page

The Published Customization page of the form shows the merged XML code of the customization projects that are
currently published. You open this page by clicking View Published on the More menu.
On the Published Customization page, you can do the following:
• View the code
• Download the deployment package that contains the code
• Upload the deployment package as a ZIP file
The Published Customization page includes a toolbar and a text area for viewing XML code. The text area displays
the XML content of a merged customization project. This area is not used for editing the XML code.
The toolbar buttons are listed below.
Button Description
Save to Database Is not available at this time.
Download Package Downloads the Customization.zip file, which has the full content of the merged
customization project. You can use this file as a joint deployment package to work with
the customization project or to publish the final customization on the target website.
Upload Package Initiates the upload of a deployment package to Acumatica ERP and makes XML code
available in the text area for viewing.
Choose File Opens the Open dialog box, in which you select the deployment package file to be up-
loaded.
Customized Data Classes | 49
Customized Data Classes

Page ID: (AU203001)
On the Customized Data Classes page, you manage the DAC items in the customization project. A DAC item contains
data in XML format used by the platform to create an appropriate extension for the original data access class (DAC).
You open the Customized Data Classes page by clicking Data Access in the navigation pane of the
You cannot create a custom data access class on this page. Instead, you have to use the Code page of the editor.
Custom DACs are added to the project as Code items. See To Create a Custom Data Access Class for details.
Page Toolbar
order.
Button Description
Add New Record Opens the Select Existing Data Access Class dialog box, in which you select the data
class and then click OK.
Convert to Exten- Converts the class changes into the class extension code used to complete the extension
sion development in either the Code Editor or Microsoft Visual Studio.
Edit Opens the Data Class page for the DAC you have selected in the table (by clicking it be-
fore clicking this button).
Upgrade All Launches the upgrade wizard, which processes all the project items of the DAC and Code
types to discover and update the following cases of DAC customization based on the Mi-
crosoft Intermediate Language (MSIL) injection technology:
• A field of a data access class does not contain the StorageName attribute, which
specifies the storage type of the field.
In the Acumatica Customization Platform, you must select the way a

custom field will be stored in the database when you add the field to a
data access class.
• The code contains a direct reference to a custom field of a row.

• The code contains a direct reference to an abstract class of a DAC field.
Table
This table contains the list of customized data classes and the basic settings of each of them. When you click the
link in the Name column, the Data Class Editor page for the class is opened. The table contains the following
columns.
Customized Data Classes | 50
Column Description
Name The name of the customized data class.
Class Name The full class name.
DB Table The name of the database table that contains the class.
Customized Screens | 51
Customized Screens
Page ID: (AU201000)
You use the Customized Screens page to manage the screens (that is, Acumatica ERP forms) in the customization
project. You can add existing screens to the customization project or create new ones.
You open the Customized Screens page by clicking Screens in the navigation pane of the

order.
Command Description
Create New Screen Opens the Create New Screen dialog box, in which you specify the settings of the new
screen.
Customize Existing Opens the Customize Existing Screen dialog box. In this dialog box, you select the
Screen screen you want to customize, and click OK.
Edit Opens the Screen Editor page for the screen selected in the table.
Table: Create New Screen Dialog Box

This dialog box opens when you click Create New Screen on the page toolbar. The dialog box contains the
following elements.
Element Description
Screen ID The ID to be used for the custom Acumatica ERPform, as well as for the screen in the
Customization Project Editor. This ID has the XX.**.**.** format, which consists of the
following parts:
• The two-letter code of the functional area in Acumatica ERP
• The two-digit code indicating the form type as follows:
• 10: Setup form
• 20: Maintenance form
• 30: Data entry form
• 40: Inquiry form
• 50: Processing form
• 60: Report form
• The two-digit codes (separated by a period) indicating the form's sequential num-
ber
Graph Name The unique name of the new graph.

Customized Screens | 52
Element Description
Graph Namespace The ID of the existing or new namespace for the new graph. By default, the system
specifies the customization project name as the namespace ID.
Page Title The title to be used as the form title in Acumatica ERP.
Template The ASPX page template to be used for the custom form, which can be one of the fol-
lowing:
• Form (FormView): A record-editing page with one PXFormView container
• Grid (GridView): A record-editing page with one PXGrid container
• Tab (TabView): A record-editing page with one PXTab container
• FormTab: A record-editing page with PXFormView and PXTab containers
• FormGrid (FormDetail): A master-detail editing page with PXFormView and PX-
Grid containers
• TabGrid (TabDetail): A master-detail page with PXTab and PXGrid containers
Table
This table contains the list of customized screens and basic settings of each of them. When you click the link in the
Screen ID column, the Screen Editor page is opened for the selected screen. The columns of the table are described
below.
Column Description
Screen ID The ID of the form, which is a link that you click to open the Screen Editor page for the
form.
Title The name of the form as it is displayed in Acumatica ERP.
Is New A check box that indicates (if selected) that the screen has been created by a customizer.
This check box is selected automatically for new screens and is read-only.
Last Modified By The name of the user who last modified the screen in the Customization project.
Last Modified On The date when the screen was last modified in the customization project.
Data Class | 53
Data Class
Page ID: (AU203001)
You use the Data Class page to develop the content of the extension for a data access class (DAC). The full name of
the page is Data Class:, followed by the name of the customized DAC. By using this page, you can do the following:
• Customize the attributes of the existing fields of a DAC
• Add custom fields to a DAC
• For a selector field, add, delete, and sort the columns of the associated lookup table
• Review the modifications made to an original class
• View the source code of an original data access class
• Navigate to the form on which a field of a class is used
While performing customization, you can open this page in the following ways:
• From the Element Properties dialog box, which you access by clicking Customization Menu >
Inspect Element, if you click Actions > Customize Data Fields
• From the Customized Data Classes page of the Customization Project Editor, by clicking the
link in the Name column of a DAC
• From the navigation pane of the Customization Project Editor, by clicking an item listed under
Data Access
The platform gives you advanced possibilities to control the field customization by using additional attributes in
the DAC extension. See Customization of Field Attributes in DAC Extensions of Customization Framework for details.

order.
Button Description
Change Attributes Opens the Change Existing Field dialog box, which you can use to add an existing field of
of Base Field the DAC to the customization project.
Create New Field Opens the Create New Field dialog box, which you can use to add a new custom field to
the DAC.
Edit Attributes Opens the Customize Attributes dialog box, which you can use to customize the attrib-
utes of the selected field. Before clicking the command, in the table of the Customized
Fields pane, you click the row with the field. This command is unavailable if you are cre-
ating a new custom field.
This command is unavailable if you click a row with a new field before clicking the but-
ton.
Data Class | 54
Button Description
Edit Selector Opens theCustomize Selector Columns dialog box, in which you can modify the
Columns columns in the lookup table that corresponds to the selector field you have selected in
the Customized Fields pane.
This command is available only if you have selected a selector field before clicking Edit
Selector Columns on the More menu.
Open Screen Opens the primary form of Acumatica ERP for the DAC.
If there is a primary business logic controller (BLC) for the class, then the
primary form is the form bound to this container. Otherwise, the primary
form is the form bound to the BLC in which the class is the main DAC of the
primary view.
View Source Opens the Data Access tab of the Source Code (SM204570) form, which displays the DAC
source code.
Create New Field Dialog Box

This dialog box opens when you click Create New Field on the More menu. You can also open the dialog box by
clicking New Field on the Add Data Fields tab of the Screen Editor page.
Element Description
Field Name The name of the field in the DAC. Because this is a custom field, the Usr prefix must begin its
name. If you do not add the prefix, the system adds it automatically when the box loses fo-
cus.
Display Name The name of the field to be displayed on the form. The specified string is inserted as the
DisplayName parameter of the PXUIField attribute of the field.
Storage Type The storage type for the field.

The storage type can be one of the following:
• NonPersistedField: An unbound field of the DAC. The unbound field is added only to the
data access class and is not mapped to the database.
• DBTableColumn (default): An ordinary bound field. The platform adds the database col-
umn to the base table by altering the base table schema.
• NameValuePair: A "name-value" bound field. The platform stores the field value in a
dedicated table of the database without altering the schema of the base table.
Data Type The data type to be used for a custom field. The type can be one of the following: string, int
(default), bool, decimal, datetime, and guid.
Length The maximum field length. For the string type, you enter the maximum number of symbols
in the field value; for the decimal type, you enter the precision of the value (the maximum
total number of decimal digits that will be stored, both to the le of the decimal point and
to the right of it).
This box appears if you have selected the string or decimal data type.
Data Class | 55
Element Description
Decimal The scale of the value (that is, the number of decimal digits that will be stored to the right of
the decimal point).
This box appears if you have selected the decimal data type.
OK Adds the new field with the specified properties to the data access class and closes the dia-
log box. The field appears in the list of customized fields of the class on the page.
Change Existing Field Dialog Box

This dialog box opens when you click Change Attributes of Base Field on the More menu. You use the dialog box
to change the attributes of a field of the current DAC.
Element Description
The dialog box contains the following box.
Field Name The existing field (of the DAC) whose attributes you want to change.
OK Adds the selected field to the list of the customized fields of the data access class, and closes
the dialog box. You then customize the attributes of this field in the Source Code pane.
Cancel Closes the dialog box without adding any fields to the list of customized fields.
Customize Selector Columns Dialog Box

This dialog box opens when you click Edit Selector Columns on the More menu. In the dialog box, you can add,
delete, and sort columns to customize the lookup table that is opened on the form when the user clicks the
magnifier button.
Table: Customize Selector Columns Dialog Box: Table Toolbar

Button Description
Add Columns Opens the Add Columns to Selector dialog box, which you use to add columns to the
lookup table that corresponds to the selector field.
Up Moves up the selected field, so that the column moves le in the lookup table.
Down Moves down the selected field, so that the column moves right in the lookup table.
Table: Customize Selector Columns Dialog Box: Table Columns

The table has the following columns.
Data Class | 56
Column Description
Column Name The value of the DisplayName parameter of the PXUIField attribute of the field.
Data Field The name of the public virtual property of the field in the DAC.
Table: Customize Selector Columns Dialog Box: Buttons

The dialog box contains the following buttons.
Button Description
OK Applies the modifications to the lookup table associated with the selector field.
As a result, the PXCustomizeSelectorColumns attribute is added to the selector
field, and you can view the attribute in the Customize Attributes area of the Data Class
page. This attribute defines the new set and order of the columns in the lookup table.
Add Columns to Selector Dialog Box

This dialog box opens when you click Add Columns in the Customize Selector Columns dialog box. You use the
dialog box to add one column to the lookup table that corresponds to the selector field or to add multiple columns
to the lookup table at once.
Table: Add Columns to Selector Dialog Box: Tabs

The tabs in the dialog box display the filtered lists of fields, as described in the following table.
Tab Description
All Displays all fields.
Selector Displays only selector fields.
Custom Displays new custom fields.
Table: Add Columns to Selector Dialog Box: Table

Element Description
Selected A check box that you use to select the fields for which columns will be added to the
lookup table that corresponds to the selector field.
Column Name The value of the DisplayName parameter of the PXUIField attribute of the field.
Data Field The name of the public virtual property of the field in the DAC.
Table: Add Columns to Selector Dialog Box: Buttons

Data Class | 57
Button Description
OK Applies the modifications and adds the selected columns to the table of the Customize
Selector Columns dialog box.
Customize Attributes Dialog Box

This dialog box opens when you click a field on the Data Class page and then click Edit Attributes on the More
menu. In the dialog box, you edit the attributes of the selected field.
Table: Customize Attributes Dialog Box: Table Toolbar

Button Description
Delete Deletes the attribute selected in the Attributes column.

As a result, the [PXRemoveBaseAttribute(typeof(AttrNameAttribute))] at-
tribute is added to the field, and you can view the attribute in the Customize Attributes
area of the Data Class page.
Table: Customize Attributes Dialog Box: Table Columns

Element Description
Attributes The list of field attributes.
Property The name of the parameter of the attribute selected in the Attributes column.
Value The original value of the parameter selected in the Attributes column.
You can enter any string as the parameter value without the system performing type vali-
dation. If the value of the customized parameter has an incorrect type, it causes a valida-
tion error during the publication of the customization project.
Table: Customize Attributes Dialog Box: Buttons

Button Description
OK Applies the modifications to the field.

As a result, the [PXCustomizeBaseAttribute(typeof(AttrNameAttribut-
e), "ParameterName", NewValue)] attribute is added to the field for the mod-
ified parameter. You can view the source code of the attribute in the Customize Attrib-
utes area of the Data Class page.

Data Class | 58
Customized Fields Pane

The Customized Fields pane (the le pane of the Data Class page) contains a table that lists all of the currently
customized fields of the DAC. In the table, you select a field, and then you view or edit its attributes in the Source
Code pane (the right pane of this page). The table has a single column: Field Name.
Source Code Pane

You use the Source Code pane (the right pane of the page) to customize the attributes of the field that is currently
selected in the table of the Customized Fields pane.
The title of the pane contains the name and type of the selected field. The type of the field is specified in
parentheses and can be one of the following: New Field or Customized Existing Field.
The work area contains the following elements.
Element Description
Customize Attributes The area in which you can edit the source code of the attributes of the selected field.
Drop-down list The way in which the system applies the changes to the field attributes.
The following options are available:
• Keep Original: The original attributes remain on the field until you select another
option in this box.
• Replace Original: The original attributes are replaced on the field with the custom
attributes specified in the Customize Attributes area.
• Append to Original (default): The custom attributes are added to the end of the list
of the original attributes of the data field. If you use this option, make sure that
you do not duplicate attributes on the field.
This element is available for only an existing customized field.
If you want to change the original attributes in the Customize Attributes area, be-
fore typing any text in the area, select the Replace Original option. The original attrib-
utes will be copied to the Customize Attributes area.
Original Attributes The area in which you view the source code of the original attributes of the selected
field.
Database Scripts | 59
Database Scripts
Page ID: (AU209000)
On this page, you can manage the Sql and Table items of the customization project.
An Sql item contains a custom database table definition or a custom SQL script that has to be
executed while the customization project is published. A Table item contains a description of the
custom columns added to a table for bound custom fields created in the appropriate data access
class.
When you create a custom table in the database, we recommend that you add the table schema to the
customization project, as described in To Add a Custom Table to a Project. To create other database objects or insert
data into the tables, you have to compose the corresponding SQL script and add the script to the customization
project, as described in To Add a Custom SQL Script to a Project.
You open the Database Scripts page by clicking Database Scripts in the navigation pane of the

order.
Command Description
Add Custom Col- Opens the Add Custom Column to Table dialog box, in which you select a column of an
umn to the Table existing table to be added to the customization project.
Add Custom Table Opens the Add Custom Table Schema dialog box, in which you select the table to be
Schema added to the customization project, and then click OK.
Add Script Opens the Edit SQL Script dialog box, which you use to add and edit a custom SQL
script.
Increase Column Opens the Column Length Increase dialog box, in which you can specify the new length
Length for the column.
Reload from Data- Updates the Table items in the customization project if the business events that corre-
base spond to these items have been modified by using a database administration tool, such
as SQL Server Management Studio.
Add Custom Column to Table Dialog Box

This dialog box opens when you click Add Custom Column to Table on the More menu. In the dialog box, you can
add custom columns of an existing table of Acumatica ERP to the customization project.
Element Description
Table The name of the table to which the column will be added.
Field Name The name of the column to be added.
Data Type The type of the column to be added.
OK Adds the Table item to the customization project and closes the dialog box.
Edit SQL Script Dialog Box

This dialog box opens when you click Add Script on the page toolbar or More menu. You can also open it by clicking
the name of the script in the Object Name column of the table on the page, or by selecting the row with the script
and clicking Edit on the page toolbar. The dialog box contains the following elements.
Element Description
Script Name The name of the SQL script.
Priority The priority of the script. The priority can have a value that ranges from 0 to 100. By de-
fault, the priority is 0.
Unlabeled text A text area that you can use to view and edit a custom SQL script.
area
Specify Database Opens the Specify Database Engine dialog box. In this dialog box, you select the attribute
Engine of the script that indicates on which database servers the script can be executed (Microsoft
SQL Server, MySQL Server, or both), and then click OK.
• Skip Batch on MySQL Server: Adds the --[mysql: Skip] attribute to the end of the
text in the text area of the script editor.
• Skip Batch on Microsoft SQL Server: Adds the --[mssql: Skip] attribute to the end
of the text in the text area of the script editor.
• Use Interpreter: Adds the --[VmSql] attribute to the end of the text in the text area of
the script editor.
For more information about the database script attributes, see Using the SQL Script Attrib-
utes.
OK Saves the custom SQL script to the customization project and closes the dialog box.
Element Description
Column Length Increase Dialog Box

This dialog box opens when you click Increase Column Length on the More menu. You use the dialog box to
increase the size of a text column of an existing table of Acumatica ERP.
Element Description
Table The table in which the column should be modified.
Field Name The name of the column that should be modified.
Only text fields are available in the list because only their length can be
changed.
Data Type Read-only. The current type and size of the specified column.
New Length The new length of the text field.
OK Creates a script to alter the column in the application database, adds the script to the
table on page, and closes the dialog box.
Edit Table Columns Dialog Box

This dialog box opens when you click the name of a database table in the Object Name column in the table on the
page, or when you select the row with the name of the database table and click Edit on the page toolbar. You use
the dialog box to edit the custom table.
Table: Edit Table Columns Dialog Box: Table Toolbar

Button Description
Add Provides the following menu commands:

• Add New Column: Opens the Add Custom Column to Table dialog box, in which you
can add custom columns of the selected table.
• Column Length Increase: Opens the Column Length Increase dialog box, in which
you can increase the size of a text column of the selected table.
Table: Edit Table Columns Dialog Box: Table Columns

Element Description
Field Name The name of the field of the database table.
Script Type The type of the database script applied to the table.
Data Type The type of the field of the database table.
Table: Edit Table Columns Dialog Box: Button

The dialog box contains the following button.
Button Description
Done Saves the custom columns of the table to the customization project and closes the dia-
log box.
Table
The table on the page contains the following columns.
Column Description
Object Name The name of the item added to the customization project.
Type The type of the item added to the customization project.
Priority The priority of the SQL script.

Dashboards | 63
Dashboards
Page ID: (AU206004)
On this page, you manage the Dashboard items in the customization project. A Dashboard item contains the
dataset of a custom or customized dashboard.
You open the Dashboards page by clicking Dashboards in the navigation pane of the Customization
Project Editor.

order.
Command Description
Manage Dash- Opens the Dashboards (SM208680) form in a new browser tab.
boards
Reload from Data- Updates the Dashboard items in the customization project if the dashboards that corre-
base spond to these items have been modified on the Dashboards (SM208680) form.
Table: Add Dashboards Dialog Box

This dialog box opens when you click Add New Record on the page toolbar. The dialog box displays all the custom
and customized dashboards that exist in your Acumatica ERP instance. You can select multiple dashboards to add
them to the project simultaneously. The dialog box contains the following elements.
Element Description
The table the following columns.
Included A check box that indicates (if selected) that the current dashboard will be added to the
Name The name of the dashboard.
Site Map Location The ID of the dashboard.

Dashboards | 64
Element Description
Save Adds the selected dashboard to the table on the page and closes the dialog box.
The system also adds to the customization project the needed Generic Inquiry, Site Map,
and Wiki items for generic inquiries, site map nodes, and wiki pages, respectively, associ-
ated with the dashboard.
The system automatically includes in the customization project informa-

tion about the workspace to which the dashboard has been added on the
UI, along with other information about the dashboard.
Table
The table on the page lists the dashboards in the customization project. The columns of the table are described
below.
Column Description
Object Name The name of the dashboard in the customization project.
Description The description of the dashboard.
Last Modified By The name of the user who last modified the dashboard in the customization project.
Last Modified On The date when the dashboard was last modified in the customization project.
Dialog Boxes | 65
Dialog Boxes
Page ID: (AU201040)
On this page, you configure the dialog boxes that are displayed when a user performs particular actions on the
form. In a dialog box, the user enters settings and clicks buttons to perform the applicable action and change the
state of the entity associated with the form.
You open the Dialog Boxes page by clicking Dialog Boxes under the screen ID (of the form for which
you are adding or modifying dialog boxes) in the navigation pane of the Customization Project Editor.
In the name that appears on the page, Dialog Boxes is preceded by the screen ID and then the screen
name in parentheses.

order.
Command Description
Preview Dialog Box Previews the selected dialog box.
View Changes Opens the Changes dialog box, which you use to view the changes in the dialog box.
This command is available only if the selected dialog box is inherited—that is, based on a
predefined dialog box.
Table: Changes Dialog Box

You use this dialog box, which opens when you click View Changes, to view the source code of the dialog box;
the changes to the currently selected element are highlighted in red. The dialog box also contains the following
buttons.
Button Description
Revert Changes Returns the dialog box to the predefined state.

This button is available if you have made changes to the dialog box.
Dialog Boxes Pane

The Dialog Boxes pane (the le pane of the page) contains the list of dialog boxes. In the table, you select a dialog
box, and then you view its settings in the Settings pane (the right pane of the page). The table has a single column:
Dialog Box Name.
You add a new dialog box by clicking Add Row on the table toolbar. In the dialog box that is opened, you specify the
name of the dialog box and click OK.
Dialog Boxes | 66
Summary Area
The Summary area, located in the right pane, contains the summary settings of the dialog box.
Element Description
Title The name of the dialog box as it is displayed in Acumatica ERP.
Dialog Box Name Read-only. The internal name of the dialog box.
Status Read-only. The status of the dialog box, which can be one of the following: Inherited,
Modified, or New.
Number of Columns The number of columns in which fields are arranged in the dialog box.
Actions The action or actions that cause the system to display the dialog box.
Dialog Box Fields Table

The Dialog Box Fields table displays the list of fields of the dialog box selected in the Dialog Boxes pane.
Table: Table Toolbar

Button Description
Combo Box Values Opens the Combo Box Values dialog box, in which you can configure the values dis-
played for the field selected in the Dialog Box Fields table.

This table lists the fields in the dialog box that is selected in the Dialog Boxes pane. The columns are described
below.
Column Description
Active A check box that indicates (if selected) that the selected field is displayed in the dialog
box.
Schema Field The database field selected as the schema for the field.
Field Name The internal name of the field.
Title The name of the field that is displayed in the dialog box.
From Schema A check box that indicates (if selected) that field value from the database should be
used.
Default Value The value that is displayed for the field by default.
Required A check box that indicates (if selected) that the current field is marked as required in
the dialog box.
Dialog Boxes | 67
Column Description
Hidden The condition under which the field is not displayed in the dialog box. The default val-
ue is False.
Column Span The number of columns the field will span.
Control Size The width of the grid column.
Status The status of the field, which can be one of the following: Inherited, Modified, or New.
Table: Combo Box Values Dialog Box

This dialog box opens if you click a field in the Dialog Box Fields table and then click Combo Box Values on the
table toolbar. You can then specify the source of values for the field you have selected, or specify these values
explicitly.
Element Description
The Summary area of the dialog box contains the following element.
Source of Values The source of the values for the field.

• Take From Source State: The values from the source state of the transition are used.
This is the default option for a drop-down list in a new dialog box.
• Take From Target State: The values from the target state of the transition are used.
• Specify Explicitly: The values are selected in the table in the dialog box.
The table with the values of the combo box has the following columns.
Active A check box that indicates (if selected) that the current value is available for the field that
was selected in the Dialog Box Fields table.
Value The internal name of the field value.
Description The display name that will be shown in the drop-down box for the selected field.
Cancel Closes the dialog box without applying any changes to the combo box values of the field.
Edit Project Items | 68
Edit Project Items

You use the Edit Project Items page to edit and review the items of a customization project.
You open the page by clicking File > Edit Project Items on the main menu of the Customization
Project Editor.
Page Toolbar
The page toolbar includes standard and page-specific buttons. For the list of standard buttons, see Page Toolbar.
The page-specific buttons are listed below.
Button Description
Get Package Imports the contents of the customization project as a ZIP file.
Table
This table contains the list of all items added to the customization project and the basic settings of each item. The
Column Description
Object Name The ID of the item.
Type The type of the item.
Description The description of the item.
Created By The name of the user who added the item to the customization project.
Creation Date The date when the item has been added to the customization project.
Last Modified By The name of the user who last modified the item in the customization project.
Last Modified On The date when the item was last modified in the customization project.
Source Pane
You use the Source pane of this page to view and edit the contents of the item selected in the table.
Element Inspector | 69
Element Inspector
For any visual element on a form, you can use the Element Inspector to do the following:
• View such information about the element as its control type, data access class, data field, data view,
business logic controller, actions (if applicable), and drop-down control values
• View the source code of the ASPX page that contains the UI control for the inspected element
• View the source code of the data access class that provides data for the inspected element
• View the source code of the business logic executed for the inspected element
• Start the customization of the inspected element
While you are viewing a form, you can activate the Element Inspector from the Customization Menu.
If you need to activate the Element Inspector for a pop-up panel, dialog box, or other UI element that
opens in modal mode and makes the Customization menu unavailable for selection, you can press
Control+Alt.
Aer the Element Inspector is activated, the cursor indicates that you can select a UI element to inspect it. If
you click an element, the Element Inspector opens the Element Properties Dialog Box for the element.
Element Properties Dialog Box

The Element Inspector opens the Element Properties dialog box (see the following screenshot) when you have
selected a UI element to inspect.
Figure: The Element Properties dialog box
Element Description
Control Type The type of the inspected UI element.
Data Class The name of the DAC to which the field for the inspected element belongs.
Data Field The string value of the DataField property of the inspected UI element. (It corre-
sponds to the name of the field in the DAC.)
View Name The name of the data view that provides data for the inspected UI element.
Element Description
Business Logic The name of the BLC bound to the form.
Description The description of the inspected UI element. When you click More, the system opens a
pane that partially overlaps the working area of the screen and contains the complete
element's description.
Action Name The name of the action of the inspected toolbar button or menu command.
Drop-Down Values Opens the Drop-Down Values dialog box, which lists all possible values of the control
and the corresponding values that are saved to the database.
The button is displayed only if you have selected a drop-down control.
Customize Launches the Customization Project Editor, which opens on the Screen Editorpage for
the form that contains the inspected element.
Actions Opens the Actions menu with the following commands:

• Customize Business Logic: Creates a graph extension template for the BLC that is
bound to the form, adds the template code to the customization project, and opens
the Customization Project Editor on the Code Editor page, which loads the BLC exten-
sion template so that you can edit it.
• Customize Data Fields:
Opens the Customization Project Editor on the Data Class page so that you can cus-
tomize the inspected element attributes in the Edit Attributes area.
• View ASPX Source: Opens the Screen ASPX tab of the Source Code browser with the
source code of the current form.
• View Business Logic Source: Opens the Business Logic tab of the Source Code
browser with the source code of the BLC that is bound to the form.
• View Data Class Source: Opens the Data Access tab of the Source Code browser
with the source code of the DAC to which the field for the inspected element belongs.
Cancel Cancels the inspection of the element and closes the dialog box.
If you open the Customization Project Editor or the Source Code browser, you can access any source
code of the website—not only the source code of the inspected element and the current form, DAC,
and BLC.
Drop-Down Values Dialog Box

In the dialog box, you can view all possible values of the selected drop-down control and the corresponding values
that are saved to the database. For details on the internal names of drop-down control values, see Configuration of
Drop-Down Lists.
You open this dialog box by clicking Drop-Down Values in the Element Properties dialog box. The dialog box
contains the following elements.
Element Description
Value The internal value of the drop-down control that is saved to the database.
Description The display name that will be shown in the drop-down box for the selected field.
The dialog box has the following button.

Event Handlers | 72
Event Handlers
Page ID: (AU201070)
You use this page to create and modify event handlers for a particular screen (that is, a form in Acumatica ERP).
The page automatically displays the event handlers added in the predefined workflow.
You open the Event Handlers page by clicking Event Handlers under the screen ID (of the form for
which you are adding or modifying event handlers) in the navigation pane of the Customization
Project Editor. In the name that appears on the page, Event Handlers is preceded by the screen ID and
then the screen name in parentheses.

order.
Command Description
Revert Changes Returns the selected event handler to its predefined state.
View Changes Opens the Changes dialog box, in which you can view the description of the selected
event handler in JSON format. If any changes were applied to a predefined event handler,
they are highlighted in the dialog box. You can return the event handler to the predefined
state by clicking Revert Changes in the Changes dialog box.
The command is available only if the event handler is inherited—that is,

based on a predefined event handlers.
Event Handler Properties Dialog Box

This dialog box opens when you click Add New Record on the page toolbar, or when you click the link in the
Handler Name column in the table on the page. The list of properties may diﬀer depending on the event handler.
Table: Event Handler Properties Dialog Box: Summary Area

The Summary area of this dialog box has the following elements.
Element Description
Handler Name The system name of the event handler.
Display Name The name of the event handler that is displayed in the diagram view of the workflow (see
Workflow (Diagram View) for details).
Event Source The source object for the event handler. This is the DAC for which the event is raised.
Event Name The name of the event that needs to be handled.

Event Handlers | 73
Element Description
Entity to Apply Workflow section

In this section, you specify how to get the object for which the workflow should be used.
Object from Event A check box that indicates (if selected) that the system should use the primary data view
of the graph where the event has been raised.
This check box is available only if the DAC on which the event is raised is the same as the
primary DAC of the current graph.
Parameter from A check box that indicates (if selected) that the system should use the view that has been
Event transferred as the event parameter.
This check box is available only if the type of the parameter returned by the event coin-
cides with the primary DAC of the current graph.
View from Graph This check box is available only if the event handler is predefined and if the code for the
event handler contains the BQL for obtaining the entity for which the workflow should be
used.
Allow Multiple En- A check box that indicates (if selected) that the workflow can be used for multiple entities
tities if the BQL has returned multiple entities. If the check box is cleared, the workflow is used
for only the first entity.
This check box is available only if the event handler is predefined and if the code for the
event handler contains the BQL for obtaining the entity for which the workflow should be
used.
Table: Event Handler Properties Dialog Box: Field Update Tab

In the table on the Field Update tab, you add the fields that should be updated aer the event is processed. The
fields are updated in the order in which you add them to the table. You can change the order of the listed rows (and
thus the corresponding fields) by clicking the row you want to move and then clicking Move Up or Move Down on
the table toolbar.
Column Description
Active A check box that indicates (if selected) that the field should be updated after the event
is processed.
Field The name of the field that should be updated.
From Schema A check box that indicates (if selected) that field value from the database should be
used.
New Value The new value to be used for the field.
Table: Event Handler Properties Dialog Box: Buttons

Event Handlers | 74
Button Description
Cancel Closes the dialog box without applying any changes.

Fields | 75
Fields
Page ID: (AU201060)
For a particular screen (that is, a form in Acumatica ERP), you use the Fields page to add existing fields to the
customization project and modify the properties of these fields.
You open the Fields page by clicking Fields under the screen ID (of the form for which you are
modifying the field’s properties) in the navigation pane of the Customization Project Editor. In the
name that appears on the page, Fields is preceded by the screen ID and then the screen name in
parentheses.

order.
Command Description
Combo Box Val- Opens the Combo Box Values dialog box. In this dialog box, you can configure the list of
ues values for fields that are displayed as combo boxes. The command is available only if you
have selected this type of field.
View Changes Opens the Changes dialog box, where you can view the description of the selected field
in JSON format. If any changes have been applied to the predefined field, they are high-
lighted in the dialog box. You can return the field to the predefined state by clicking Revert
Changes in the Changes dialog box.
The View Changes command is available only if the field has the Inherited
status.
Table: Add Field Dialog Box

This dialog box opens when you click Add New Row on the page toolbar. In this dialog box, you can use the
elements of the Selection area to narrow the range of the fields listed in the table. You then select the Included
check box for each field you want to add and click the appropriate button to add the fields to the page.
Element Description
The dialog box has a Selection area with the following elements.
Container The form container where the box for the field is located. If you select a container in this
box, the table lists only the rows of the fields in the container, and the DAC box is filled in
automatically with the corresponding DAC.
DAC The DAC that contains the field. If you select a DAC in this box, the table narrows the range
of listed rows to display the fields of the DAC.
Field Name The internal name of the field to be added to the customization project. The system lists
the available values of the DAC selected in the DAC box.
Fields | 76
Element Description
Display Name The name of the field that is selected in the Field Name box. This name will be displayed
on the applicable Acumatica ERP form.
The dialog box contains a table with the following columns. The table lists the fields that meet any selection cri-
teria you have specified in this dialog box.
Included A check box that you can select to add the field to the table on the page.
The check box is also selected if the field has already been added to the table.
Container The form container where the box for the field is located.
DAC The data access class from the container that is selected in the Container box. The system
inserts this value automatically if you are manually adding the row.
Field Name The internal name of the field that can be added to the customization project.
Display Name The name of the field that will be displayed on the applicable Acumatica ERP form.
Add Adds the selected field or fields to the table on the page without closing the dialog box.
Add & Close Adds the selected field or fields to the table on the page and closes the dialog box.
Close Closes the dialog box without adding any fields to the table on the Fields page.
Table: Combo Box Values Dialog Box

This dialog box opens if on the Fields page, you click a field that is displayed as a combo box on the applicable
Acumatica ERP form and then you click Combo Box Values on the page toolbar. In the dialog box, you can specify
or modify the values for the field you have selected.
Element Description
Active A check box that indicates (if selected) that the current value is active, meaning that it will
be available for selection in the combo box on the applicable Acumatica ERP form.
Custom A check box that indicates (if selected) that the current value is a user-defined value.
The system automatically selects this check box for the values that you add in the dialog
box. The check box is read-only for the default system values.
Value The internal name of the value.
Description The name of the value that will be displayed in the combo box on the applicable Acumatica
ERP form.

Fields | 77
Element Description
Cancel Closes the dialog box without applying any changes to the combo box values of the field.

You use this dialog box to view the source code of the field; the changes are highlighted in red. The dialog box also
contains the following buttons.
Element Description
Revert Changes Returns the field to its predefined state.
Table
This table contains the list of fields and the basic settings of each of them. The columns of the table are described
below.
Column Description
Object Name The data access class that contains the field.
Field Name The internal name of the field.
Disabled An indicator of when the field is disabled on the applicable Acumatica ERP form.
By default, the column is empty, indicating that the field is always enabled. If the column
• True: The field is always disabled.
• Condition: The condition that, if it is met, causes the field to be disabled. If any condi-
tions are specified on the Conditions page for the screen of this field, they are available
for selection in this column.
Hidden An indicator of when the field is hidden on the applicable Acumatica ERP form.
By default, the column is empty, indicating that the field is always visible. If the column is
not empty, it can contain one of the following:
• True: The field is always hidden.
• Condition: The condition that, if it is met, causes the field to be hidden. If any condi-
tions are specified on the Conditions page for the screen of this field, they are available
for selection in this column.
Required An indicator of when the field is marked as required on the applicable Acumatica ERP
form.
By default, the column is empty, indicating that the field is never required. If the column
• True: The field is always marked as required.
• Condition: The condition that, if it is met, causes the field to be required. If any con-
ditions are specified on the Conditions page for the screen of this field, they became
available for selection in the box.
Fields | 78
Column Description
Display Name The name of the field that will be displayed on the applicable Acumatica ERP form.
From Schema A check box that indicates (if selected) that field value from the database should be used.
Default Value The value that is displayed for the field by default.
Status The status of field.

The status of the field can be one of the following:
• Inherited: A system field
• New: A field that you have added
• Modified: A system field that you have modified
Generic Inquiries | 79
Generic Inquiries
Page ID: (AU206000)
On this page, you manage the GenericInquiryScreen items in the customization project. A GenericInquiryScreen item
contains the dataset of a custom or customized generic inquiry form.
You open the Generic Inquiries page by clicking Generic Inquiries in the navigation pane of the

order.
Command Description
Manage Inquiries Opens the Generic Inquiry (SM208000) form in a new browser tab.
Reload from Data- Updates the GenericInquiryScreen items in the customization project if the generic
base inquiries that correspond to these items have been modified on the Generic Inquiry
(SM208000) form.
Table: Add Generic Inquiries Dialog Box

This dialog box opens when you click Add New Record on the page toolbar. The dialog box displays a table listing
all the custom and customized generic inquiries that exist in your instance of Acumatica ERP.
Element Description
The dialog box has a table with the following columns.
Included A check box that you select to add the current generic inquiry to the customization
project.
Inquiry Title The name of the generic inquiry as it is displayed on the Generic Inquiry (SM208000) form.
Last Modified By The name of the user who last modified the generic inquiry in the customization project.
Last Modified On The date when the generic inquiry was last modified in the customization project.
Save Adds the selected generic inquiries to the table on the page and closes the dialog box.
Cancel Closes the dialog box without adding any generic inquiries to the page.
Generic Inquiries | 80
The system automatically includes in the customization project information about the workspace
or workspaces to which the generic inquiry has been added on the UI, along with other information
about the generic inquiry.
Table
This table contains the list of generic inquiries and the basic settings of each of them. The columns of the table are
described below.
Column Description
Object Name The name of the generic inquiry in the customization project.
Description The description of the generic inquiry.
Last Modified By The name of the user who last modified the generic inquiry in the customization project.
Last Modified On The date when the generic inquiry was last modified in the customization project.
If you delete a GenericInquiryScreen item from the project, the generic inquiry remains in the system
unless you delete the inquiry by using the Generic Inquiry (SM208000) form.
Import and Export Scenarios | 81
Import and Export Scenarios

Page ID: (AU205500)
On this page, you manage the XportScenario items in the customization project. An XportScenario item contains the
dataset of a custom export or import scenario that is used to perform data migration between a legacy application
and Acumatica ERP.
You open the Import and Export Scenarios page by clicking Import/Export Scenarios in the
navigation pane of the Customization Project Editor.
Page Toolbar
The page toolbar includes standard and page-specific buttons. For the list of standard buttons, see Page Toolbar.
The page-specific buttons are listed below.
Command Description
Manage Scenarios Opens the Import Scenarios (SM206025) form in a new browser tab.
Reload from Data- Updates the XportScenario items in the customization project if the integration scenarios
base that correspond to these items have been modified on the Import Scenarios (SM206025)
form.
Table: Add Import or Export Scenario Dialog Box

integration scenarios that exist in your Acumatica ERP instance. You can select multiple integration scenarios to
add them to the project simultaneously.
Element Description
Selected A check box that you select to add the current integration scenario to the customization
project.
Name The name of the integration scenario.
OK Adds the selected integration scenarios to the table on the page and closes the dialog
box.
Cancel Closes the dialog box without adding any scenarios to the page.
An XportScenario item contains all the data required for the integration scenario. Therefore, the item
includes the data of the data provider.
Import and Export Scenarios | 82
Table
This table contains the list of integration scenarios and the basic settings of each of them. The columns of the table
are described below.
Column Description
Object Name The name of the integration scenario in the customization project.
Description The description of the integration scenario.
Last Modified By The name of the user who last modified the integration scenario in the customization
project.
Last Modified On The date when the integration scenario was last modified in the customization project.
Mobile Application | 83
Mobile Application
Page ID: (AU220000)
You use this page to manage the screens of the Acumatica mobile app.
You open the Mobile Applications page by clicking Mobile Application in the navigation pane of the

order.
Command Description
Add New Screen Opens the Add New Screen dialog box, in which you specify the screen ID and then
click OK.
The system adds the selected screen to the mobile app, adds the add item to the ta-
ble on the page, and opens the Add page (see the Pages section of this topic). The
system also adds a node for the Add page beneath the Mobile Application node of
the navigation pane.
Clear All Tenants Reverses the changes to all tenants.
Clear Current Tenant Reverses the changes to the current tenant.
Manage Workspaces Opens the Mobile Workspaces page.
Remove Existing Opens the Remove Existing Screen dialog box, in which you specify the screen ID,
Screen and then click OK.
When you click OK, the system removes the selected screen from the mobile app and
adds the remove item to the table on the page (see the Pages section of this topic).
The system also adds a node for the Remove page beneath the Mobile Application
node of the navigation pane. You click the node to open the Remove page.
Update Existing Opens the Update Existing Screen dialog box, in which you specify the screen ID and
Screen then click OK.
The system adds the update item to the table on the page and opens the Update
page (see the Pages section of this topic). The system also adds a node for the Up-
date page beneath the Mobile Application node of the navigation pane.
Update Main Menu Opens the Update Menu page (see the Pages section of this topic), where you can up-
date the main menu of the mobile app.
The system adds the update item to the table on the page and opens the Update
Menu page (see the Pages section of this topic). The system also adds a node for the
Update Menu page beneath the Mobile Application node of the navigation pane.
Table
This table contains the list of modified screens and the basic settings of each of them. The columns of the table are
described below.
Element Description
Operation The type of the operation performed with the screen.

The column can contain the following values:
• add
• update (with the screen ID specified in theScreen ID column)
• update (with the Menu specified in the Screen ID column
• remove
Screen ID The ID of the added, modified, or removed screen.
Title The name of the screen.
Last Modified By The name of the user who last performed the operation in the customization project.
Last Modified On The date when the operation was last performed in the customization project.
Pages
From the Mobile Application page, you can open any of the following pages related to the Acumatica mobile app:
• Add: By using the Add page, which you open by clicking Add New Screen on the Mobile Application page,
you can add a new screen to the Acumatica mobile app. In the name that appears on the page, Add is
followed by a colon, the screen ID, and then the screen name.
• Remove: You use the Remove page to remove a screen from the Acumatica mobile app. This page is opened
when you click Remove Existing Screen on the Mobile Application page. In the name that appears on the
page, Remove is followed by a colon, the screen ID, and then the screen name.
• Update: You update an existing screen of the Acumatica mobile app by using the Update page. To open this
page, you click Update Existing Screen on the Mobile Application page. In the name that appears on the
page, Update is followed by a colon, the screen ID, and then the screen name.
• Update Menu: You use the Update Menu page, which opens when you click Update Main Menu on the
Mobile Application page, to update the main menu of the Acumatica mobile app. The name that appears on
the page is Update: MENU.
The pages have the same structure, as described below.
order.
Button Description
Export Preview as XML Exports the settings of the page as an XML file.
Table: Source Code Pane

The Source Code pane consists of the following areas.
Area Description
Commands The area where you add the instructions to modify the screen.
Errors The area that displays any errors that are generated.
Result Preview The area that displays the code of the updated screen configuration.
Mobile Workspaces | 86
Mobile Workspaces
Form ID: (AU220012)
On this page, you manage the workspaces of the Acumatica mobile app by using the following type of items.
• MobileSitemapWorkspace: An item of this type contains general data, such as the name of a workspace, its
sequential number, and its icon.
• MobileSitemapWorkspaceItems: An item of this type contains the screens included in the workspace.
• MobileSitemapWorkspaceWidgets: An item of this type contains the KPI widgets included in the workspace
and its screens.
You open the Mobile Workspaces page by clicking Manage Workspaces on the page toolbar of the
Mobile Application page.

order.
Command Description
Manage Work- Opens the Mobile Workspaces (AU220012) form in a new browser tab. You can use this
spaces form to manage workspaces for the Acumatica mobile app.
Reload from Data- Updates the MobileSitemapWorkspace, MobileSitemapWorkspaceItems, and Mo-

base bileSitemapWorkspaceWidgets items in the customization project if the data that corre-
sponds to these items has been modified on the Mobile Workspaces (AU220012) form.
Table: Add Workspace Dialog Box

This dialog box, which opens when you click Add New Record on the page toolbar, has a table that lists the
workspaces that have been created on the Mobile Workspaces (AU220012) form. The dialog box contains the
following elements.
Element Description
The dialog box has the following columns.
Included A check box that indicates (if selected) that the workspace in this row will be added to the
customization project if you click Save in the dialog box.
Workspace ID The internal name of the workspace.
Display Name The name of the workspace as it is displayed in the mobile app.
Icon The icon that is displayed for this workspace in the mobile app.
Active A check box that indicates (if selected) that the current workspace is active—that is, it will
be displayed in the mobile app.
Mobile Workspaces | 87
Element Description
Save Adds the selected workspaces to the table on the page and closes the dialog box.
Table
This table contains the list of workspaces in the customization project and the basic settings of each of them. The
Column Description
Object Name The name of the workspace in the customization project.
Description The description of the workspace.
Last Modified By The name of the user who last modified the workspace in the customization project.
Last Modified On The date when the workspace was last modified in the customization project.
Project XML Editor | 88
Project XML Editor

You use the Project XML Editor to edit and review the content of a customization project in XML format.
You open the editor by clicking File > Edit Project XML on the main menu of the Customization
Project Editor. The actual name shown on the page is the name of the customization project.
Page Toolbar
The page toolbar contains the name of the customization project and the following buttons.
Button Description
Choose File Opens the standard dialog box, in which you select a deployment package file. The de-
ployment package is a ZIP file that has the same name as the customization project.
Download Package Saves the project locally as a deployment package.
Save to Database Saves the XML code of the project to the database.
Upload Package Opens the deployment package file that has been selected; the name of the file is dis-
played on the page toolbar.
You click this button after you select the deployment package file by clicking Choose
File.
Source Code Pane

You use this pane of the page to view and edit the contents of the customization project.
Push Notifications | 89
Push Notifications
Page ID: (AU210000)
On this page, you manage the PushNotification items in the customization project. A PushNotification item
contains the dataset of a push notification definition. A push notification definition includes the push notification
destination and the data query, which defines the data changes for which Acumatica ERP sends notifications.
You open the Push Notifications page by clicking Push Notifications in the navigation pane of the

order.
Command Description
Manage Notifica- Opens the Push Notifications (SM302000) form in a new browser tab.
tions
Reload from Data- Updates the PushNotification items in the customization project if the push notifications
base that correspond to these items have been modified on the Business Events (SM302050)
form.
Table: Add Push Notifications Dialog Box

This dialog box opens when you click Add New Record on the page toolbar. The dialog box displays all the push
notification definitions that are configured in your instance of Acumatica ERP.The dialog box contains the following
elements.
Element Description
Included A check box that indicates (if selected) that the current push notification will be added
to the customization project.
Destination Name The name of the notification destination.
Destination Type The type of the notification destination.
Save Adds the selected business events to the table on the page and closes the dialog box.

Push Notifications | 90
Table
This table contains the list of push notifications and the basic settings of each of them. The columns of the table are
described below.
Column Description
Object Name The name of the push notification in the customization project.
Description The description of the push notification.
Last Modified By The name of the user who last modified the push notification in the customization
project.
Last Modified On The date when the push notification was last modified in the customization project.
If you delete a PushNotification item from the project, the push notification definition remains in the
system unless it is deleted on the Push Notifications (SM302000) form.
Reports | 91
Reports
Page ID: (AU207000)
On this page, you manage the Report items in the customization project. A Report item contains the dataset of a
custom report created with Acumatica Report Designer.
You open the Reports page by clicking Reports in the navigation pane of the Customization Project
Editor.

order.
Command Description
Reload from Data- Updates the Report items in the customization project if the reports that correspond to
base these items have been modified in the Report Designer.
Table: Select Report from Database Dialog Box

This dialog box opens when you click Add New Record on the page toolbar. Before adding a report to a project,
you have to construct the report in the Report Designer and save the report to the database. (For more information
about reports, see Acumatica Report Designer Guide.)
Element Description
Name The name of the report.
If a custom report is created in the Report Designer and saved as a file in the
file system, you cannot add the report to a customization project as a Report
item.
Save Adds the selected report to the table on the page and closes the dialog box.
Table
This table contains the list of custom reports and the basic settings of each of them. The columns of the table are
described below.
Reports | 92
Column Description
Object Name The name of the report in the customization project.
Screen Editor | 93
Screen Editor
Page ID: (AU204520)
The Screen Editor page is the visual editor for the source code of an ASPX page and the business logic of a screen.
You use this page to configure ASP.NET containers (such as forms and grids), and to specify the properties of UI
controls and grids.
You can open the Screen Editor page in a variety of ways, including by clicking the screen ID (of the
form you want to customize in the navigation pane of the Customization Project Editor. You can also
open it from other pages, such as Customized Screens page. In the actual name that appears on the
page, Screen Editor: is followed by the screen ID of the form being customized and then the screen
name in parentheses.

order.
Command Description
Customize Busi- Opens the Code Editor page with the extension class template of the business logic con-
ness Logic tainer (BLC) that is bound to the form.
Customize Data Opens the Data Class page for customization of the DAC that contains the field selected
Class in the control tree.
Edit Aspx Opens the ASPX Editor page with the webpage source code.
Open Screen Opens the original form of Acumatica ERP.
Preview Changes Opens the customized form in a new browser window.
Control Tree
The control tree of the Screen Editor contains a list of the elements that are displayed on the form and the layout
rules that organize the elements into rows and columns. (You can see the list of controls that can be added to a
form on the Add Controls tab of the Screen Editor.) In the tree, you can do the following:
• Select a container, a control, or an action, and then review or customize its settings by using the tabs of the
page.
• Change the order of controls in a container. To do this, you drag controls on the control tree within their
containers.
• Remove any selected item from the webpage or reset the properties of the item to the out-of-the-box state.
The toolbar of the control tree includes the following buttons.
Button Description
Refresh Refreshes the control tree.

Screen Editor | 94
Button Description
Remove Removes the item selected in the control tree from the form.
Reset Properties Resets all controls and actions to the out-of-the-box state.
The following screenshot shows the actions of the Customers (AR303000) form, as displayed in the control tree. The
first element of the control tree is the DataSource node (see Item 1 in the screenshot), which contains all actions
defined for the form. The actions displayed on the form toolbar and on the More menu are located in the Toolbar
node. This node contains standard actions (the Standard node) and form-specific buttons (the Form-Specific
node). Form-specific actions are listed under their category on the More menu. All other actions of the form are
located in the Other node (Item 2).
Figure: Actions of the Customers form
The remaining top-level elements are containers:

• Form: BAccount: This node (see Item 3 in the screenshot above) represents the form's Summary area.
• Tab: CurrentCustomer: This node (Item 4) represents the tab area of the form and contains tab items.
• Dialogs: This node (Item 5) contains definitions for all dialog boxes that are defined in the ASPX code of the
page.
The top element of each container is an element of the Column or Row type that specifies the layout rule for the
elements located inside it.
Layout Properties Tab

On the Layout Properties tab, you review and modify the layout properties of the form controls or actions that are
defined on the ASPX page.
The tab contains a table toolbar and a table. The table toolbar includes the Hide Advanced Properties button ( ),
which you can use to hide or show the advanced properties of the selected control. The tab table consists of the
following columns.
Screen Editor | 95
Column Description
Override A check box that indicates whether the property value has been changed. This check box
is selected automatically when you change the property value.
Property The name of the property or the property group.
Value The value of the property.
Attributes Tab
You use the Attributes tab to review and customize the attributes of the DAC field that is bound to the control
currently selected in the control tree. The tab consists of elements that hold the DAC field information and buttons
to customize the field attributes.
Table: Attributes Elements

The tab contains the following elements.
Element Description
Data Class The name of the DAC to which the field belongs.
Field Name The name of the field in the DAC. The field name is the name of the public virtual property
in the public abstract class of the field.
Original Attributes The original attributes of the field in Acumatica ERP.
Table: Attributes Buttons

The tab has the following buttons.
Button Description
Customize Attrib- Opens the Data Class page so you can customize the field attributes in the DAC.
utes
View Source Opens the Data Access tab of the Source Code (SM204570) form so that you can browse
the DAC source code.
Override on Screen Opens the Code Editor page with the BLC extension class template. The template in-
Level cludes the field attributes and the template of the DACName_FieldProperty-
Name_CacheAttached() method, which you can use to replace the attributes within
the BLC.
Events Tab
On the Events tab, you view and add event handlers for the selected control.
The tab consists of summary elements and a table (which has a toolbar).
Table: Events Elements

Screen Editor | 96
Element Description
Data Class The name of the DAC to which the field belongs.
Field Name The name of the field in the DAC.
Business Logic The name of the BLC bound to the form.

The table toolbar includes the following table-specific buttons.
Button Description
Add Handler For the selected event (that is, the event that you have clicked in the table), opens the
Code Editor page with the BLC extension class template. The class template includes a
code template for the event handler, so you should implement only the body of the han-
dler.
The button provides the following menu commands:
• Keep Base Method: Creates the event handler with two parameters, as it is defined in
the base BLC. As a result, the event handler is added to the appropriate event handler
collection.
• Override Base Method: Creates the event handler with an additional parameter to re-
place the base BLC event handler collection.
View Source Opens the Source Code browser with the source code of the BLC bound to the form.

The table holds information about the event handlers used for the selected control. It contains the following
columns.
Column Description
Event The event name.
Handled in Source A check box that indicates whether the event handler is implemented within Acumatica
ERP.
Customized A check box that indicates whether the event handler is customized. This check box is se-
lected automatically when you add the event handler.
Add Control Tab

You can use the Add Control tab to easily add new containers, controls, and layout rules to the form you are
modifying. The tab has the Main Containers, Layout Rules, and Other Controls sections with rectangles for the
types of controls in the sections.
The Main Containers section has rectangles for each of the following controls, which you can add: Form, Tab, Tab
Item, Grid, and Pop-Up Panel.
The Layout Rules section has rectangles for each of the following controls, which you can add: Row, Column,
Group, Merge, and Empty Rule.
Screen Editor | 97
The Other Controls section has rectangles for each of the following controls, which you can add: Panel, Group
Box, Radio Button, Label, Button, and Java Script.
To add a control, you drag its box from this tab to the needed position in the control tree. Aer you have added the
control, you specify its properties on the Layout Properties tab.
Add Data Fields Tab

You use the Add Data Fields tab to manage the controls in the form container that is currently selected in the
control tree. On this tab, you can create a control for a DAC field and add it to the selected container. You can also
create a new custom field in a DAC, create a control for the field, and add it to the selected container.
The tab contains the Data View drop-down list and a table with a table toolbar and three filters you can use to view
the needed fields.
Table: Add Data Fields Element

The tab contains the following element.
Element Description
Data View The DAC whose fields you want to view in the table. The drop-down list includes all DAC-
Name(DataViewName) pairs of the BLC that are bound to the form.

The table toolbar has the following buttons.
Button Description
Create Controls Adds the selected fields (that is, those for which you have selected the unlabeled Includ-
ed check boxes in the table) to the container selected in the control tree.
New Field Opens the Create New Field Dialog Box, which you can use to add a new custom field to
the DAC that is referenced in the data view selected in the Data View box.
Once you have created a field or multiple fields, you need to publish the
customization project before you can create a control for the new fields.

This table displays the fields that belong to the selected DAC. The table includes the following columns.
Column Description
Included An unlabeled check box that you use to include this field in processing when you click
Create Controls on the table toolbar. This processing will create a control for the field in
the container that is currently selected in the control tree.
Used Read-only. A check box that indicates whether a control for the field exists in the object
that is currently selected in the control tree. The system selects this check box automati-
cally when you create a control for the field.
Field Name The name and DisplayName (in parentheses) of the field in the DAC.
Control The type of the UI control.

Screen Editor | 98
Table: Filter Tabs

You can use the following filter tabs to select which DAC fields you want to display in the table.
Filter Description
All All fields of the selected DAC that are not represented by controls on the form.
Visible The fields that are visible because of the Visibility field attribute in the selected
DAC.
Custom The new custom fields of the selected DAC.
View ASPX Tab

The View ASPX tab displays the ASPX code of the control selected in the control tree.
Shared Filters | 99
Shared Filters
Page ID: (AU205100)
On this page, you manage the SharedFilter items in the customization project. A SharedFilter item contains the
dataset of a custom reusable shared filter created on a processing or inquiry form of Acumatica ERP.
You open the Shared Filters page by clicking Shared Filters in the navigation pane of the

order.
Command Description
Manage Filters Opens the Filters (CS209010) form in a new browser tab.
Reload from Data- Updates the SharedFilter items in the customization project if the shared filters that cor-
base respond to these items have been modified on the Filters (CS209010) form or on the form
to which the filter is applied.
Table: Add Shared Filter Dialog Box

This dialog box opens when you click Add New Record on the page toolbar. The dialog box lists all the custom
shared filters that exist in your instance of Acumatica ERP. You can select multiple shared filters to add them to the
customization project simultaneously.
Element Description
The table in this dialog box has the following columns.
Selected A check box that you select to add the current filter to the customization project.
Name The name of the shared filter.
User Name The user who created the shared filter.
Screen ID The ID of the form on which the shared filter has been created.
OK Adds the selected shared filters to the table on the page and closes the dialog box.
Cancel Closes the dialog box without making any changes on the page.
Shared Filters | 100
Table
This table contains the list of shared filters and the basic settings of each of them. The columns of the table are
described below.
Column Description
Object Name The name of the shared filter in the customization project.
Description The description of the shared filter.
Last Modified By The name of the user who last modified the shared filter in the customization project.
Last Modified On The date when the shared filter was last modified in the customization project.
Site Map | 101
Site Map
Page ID: (AU208000)
On this page, you manage the SiteMapNode items in the customization project. A SiteMapNode item contains the
dataset of a custom site map node for a custom form or report included in the customization project. The item also
includes information about the location of the form or report on the UI (such as the workspace or workspaces in
which the form or report is included).
You open the Site Map page by clicking Site Map in the navigation pane of the Customization Project
Editor.

order.
Command Description
Manage Site Map Opens the Site Map (SM200520) form in a new browser tab.
Reload from Data- Updates the SiteMapNode items in the customization project if the site map nodes that
base correspond to these items have been modified on the Site Map (SM200520) form.
Table: Add Site Map Items Dialog Box

site map nodes that have been created in the site map of Acumatica ERP, and the nodes that have been modified in
the site map. You can select multiple custom site map nodes to add them to the project simultaneously.
Element Description
The table in this dialog box has the following columns.
Included A check box that you select to add the current site map node to the customization
project.
Screen ID The screen ID associated with the site map node.
Title The screen name as it is displayed on the form in Acumatica ERP.
Last Modified On The date when the site map node was last modified in the customization project.
Save Adds the selected site map nodes to the table on the page and closes the dialog box.
Site Map | 102
Table
This table contains the list of site map nodes and the basic settings of each of them. The columns of the table are
described below.
Column Description
Object Name The name of the site map node in the customization project.
Description The description of the site map node.
Last Modified By The name of the user who last modified the site map node in the customization project.
Last Modified On The date when the site map node was last modified in the customization project.
Source Code | 103
Source Code
Form ID: (SM204570)
You use this form, which functions as a source code browser, to explore the source code of Acumatica ERP.
The source code browser displays the code in various views on each of the tabs, which are described in the
following sections.
Screen ASPX Tab

You use this tab to view the ASPX code for the selected page. The tab contains the following element.
Element Description
Screen ID The ID of the form for which you want to view the source code.
In this box, you can find a screen either by the screen ID or by the screen title. You can
search by any part of an ID or title.
The tab also contains the Source Code pane, which displays the source code of the selected screen. The source
code is displayed with the changes that were made in all the published customization projects of the website. The
changes related to the UI elements of the page are highlighted in yellow.
Business Logic Tab

This tab displays the source code of the BLC. If you selected a form on the Screen ASPX tab, this tab opens with the
source code of the graph associated with the form; you can select another graph. If you did not select a form, this
tab is empty.
The tab contains the following element.
Element Description
Graph Name The name of the graph for which you want to view the source code.
In this box, you can select the graph by its name. You can also type any part of the name
and select the name from the list of names that match your search string.
The tab contains a navigation pane. The pane has the Methods and Event Handler headers, which are followed
by the methods and event handlers (respectively) for the selected graph. You click a particular method or event
handler name to view its code in the Source Code pane of the tab.
The Source Code pane displays the whole source code of the selected graph. When you click a particular method or
event handler in the navigation pane, the system scrolls to the code for this method or event handler.
Data Access Tab

You use the Data Access tab to review the source code of a DAC. The tab contains the following element.
Source Code | 104
Element Description
Table Name The name of the DAC.

In this box, you can type any part of the class name and select the name from the list of
names that match your search string.
The tab also contains the Source Code pane, which displays the source code of the DAC selected in the Table Name
box.
Find in Files Tab

You use this tab to search for Acumatica ERP application code fragments that contain the specified text. The search
is case-sensitive.
Element or Pane Description
The Summary area contains the following elements.
Find Text A box where you enter a fragment of the source code you need to find.
Find A button that you click to start the search.

The table on the tab contains the results of the search.
Column Description
Name The name of the source code file that has been found.
Line The number of the code line (in the source code file) that contains the code fragment.
Content The contents of the line in the source code file.
The tab also contains the Source Code pane that displays the code of the item selected in the table. You click a row
in the table to view the corresponding source code.
System Locales | 105
System Locales
Page ID: (AU205000)
On this page, you manage the Locale items in the customization project. A Locale item contains the dataset of a
system locale, which is a set of parameters that defines the language and other local preferences—such as how to
display numbers, dates, and times in the user interface—for a group of users.
You open the System Locales page by clicking System Locales in the navigation pane of the

order.
Command Description
Manage Locales Opens the System Locales (SM200550) form in a new browser tab.
Reload from Data- Updates the Locale items in the customization project if the system locales that corre-
base spond to these items have been modified on the System Locales (SM200550) form.
Table: Add Locale Dialog Box

This dialog box opens when you click Add New Record on the page toolbar. The dialog box contains a table that
displays all the system locales that exist in your instance of Acumatica ERP. You can select multiple system locales
to add them to the project simultaneously. The dialog box contains the following elements.
Element Description
The dialog box has the following columns.
Selected A check box that you select to add the current system locale to the customization
project when you click OK.
Locale Name The internal name of the system locale.
Locale Name in Lo- The name of the system locale as it is displayed on the Acumatica ERP forms.
cale Language
OK Adds the selected system locales to the table on the page and closes the dialog box.
System Locales | 106
Table
This table contains the list of system locale and the basic settings of each of them. The columns of the table are
described below.
Column Description
Object Name The name of the system locale in the customization project.
Description The description of the system locale.
Last Modified By The name of the user who last modified the system locale in the customization project.
Last Modified On The date when the system locale was last modified in the customization project.
User-Defined Fields | 107
User-Defined Fields
Page ID: (AU230000)
On this page, you manage the user-defined fields in the customization project.
Any user-defined fields you add on this page are added to the current customization project with all other items.
You open the User-Defined Fields page by clicking User-Defined Fields in the navigation pane of the

order.
Command Description
Manage User-De- Opens the Attributes (CS205000) form in a new browser tab so that you can view and
fined Fields change, if needed, the settings of the attributes used for user-defined fields.
Reload from Data- Updates the properties of user-defined fields in the customization project if these fields
base have been modified on the Attributes (CS205000) form.
Table: Add User-Defined Fields Dialog Box

This dialog box opens when you click Add New Record on the page toolbar. The dialog box contains the following
elements.
Element Description
Included A check box that indicates (if selected) that the user-defined field in this row will be
added to the customization project.
Attribute ID The attribute that corresponds to the user-defined field.
Description The description of the user-defined field.
Save Adds the selected user-defined fields to the table on the page and closes the dialog
box.
Cancel Closes the dialog box without adding any fields.
Table: Edit Attribute Dialog Box

This dialog box opens when you click Edit on the page toolbar, or when you click the link with the ID of a user-
defined field in the Attribute ID column on the page. In the dialog box, you select the IDs of the forms on which the
field will appear. You can see only the IDs of the screens for which the user-defined field was added in Acumatica
User-Defined Fields | 108
ERP. To add a user-defined field to a form, click Customization > Manage User-Defined Fields on the title bar of
the Acumatica ERP form, and add the field.
Element Description
Included A check box that indicates (if selected) that the user-defined field will be available
on the form with the ID specified in the Screen ID column after you publish the cus-
tomization project.
Screen ID The ID of the form on which the user-defined field has been added.
Save Adds the selected user-defined fields to the table on the page and closes the dialog
box.
Table
This table contains the list of user-defined fields that you have added to the customization project and the basic
settings of each of them. When you click the link in the Attribute ID column, the Edit Attribute dialog box is
opened. The columns of the table are described below.
Column Description
Attribute ID The name of the business event in the customization project.
Description The description of the business event.
Screen ID The ID of the form on which the user-defined field will be available after you publish the
Last Modified By The name of the user who last modified the business event in the customization project.
Last Modified On The date when the business event was last modified in the customization project.
Webhooks | 109
Webhooks
Page ID: (AU210020)
On this page, you manage the webhooks in the customization project.
You open the Webhooks page by clicking Webhooks in the navigation pane of the Customization
Project Editor.

order.
Command Description
Manage Webhooks Opens the Webhooks (SM304000) form in a new browser tab so that you can open and
modify any webhook.
Reload from Data- Updates the properties of the webhooks in the customization project if these webhooks
base have been modified on the Webhooks (SM304000) form.
Table: Add Webhooks Dialog Box

This dialog box opens when you click Add New Record on the page toolbar. In the dialog box, you can see the
names of the webhooks that have been added on the Webhooks (SM304000) form.
Element Description
Included A check box that indicates (if selected) that the current webhook will be added to the
Webhook Name The name of the webhook.
Implementation The implementation class of the webhook.

Class
OK Adds the selected webhooks to the table on the page and closes the dialog box.
Table
This table contains the list of webhooks and the basic settings of each of them. The columns of the table are
described below.
Webhooks | 110
Column Description
Predefined A check box that indicates (if selected) that the implementation class of the webhook will
not be available for editing in the instance where the customization project is published.
Object Name The name of the webhook in the customization project.
Implementation The implementation class of the webhook.

Class
Description The description of the webhook.
Last Modified By The name of the user who last modified the webhook in the customization project.
Last Modified On The date when the webhook was last modified in the customization project.
Web Service Endpoints | 111
Web Service Endpoints

Page ID: (AU206002)
On this page, you manage the EntityEndpoint items in the customization project. An EntityEndpoint item contains
the dataset of a custom contract-based web service endpoint.
You open the Web Service Endpoints page by clicking Web Service Endpoints in the navigation pane
of the Customization Project Editor.

order.
Command Description
Manage Endpoints Opens the Web Service Endpoints (SM207060) form in a new browser tab.
Reload from Data- Updates the EntityEndpoint items in the customization project if the web service end-
base points that correspond to these items have been modified on the Web Service Endpoints
(SM207060) form.
Table: Add Entity Endpoint Dialog Box

This dialog box opens when you click Add New Record on the page toolbar. The Add Entity Endpoint dialog box
displays all the custom contract-based web service endpoints that exist in your Acumatica ERP instance. You can
select multiple endpoints to add them to the project simultaneously.
Element Description
Included A check box that indicates (if selected) that the web service endpoint in this row will be
added to the customization project if you click Save in the dialog box.
Endpoint Version The endpoint version.
Endpoint Name The name of the web service endpoint.
Save Adds the selected web service endpoints to the table on the page and closes the dialog
box.
Cancel Closes the dialog box without adding any new endpoints.
Web Service Endpoints | 112
Table
This table contains the list of custom contract-based web service endpoints and the basic settings of each of them.
Column Description
Object Name The name and version of the web service endpoint in the customization project.
Description The description of the web service endpoint.
Last Modified By The name of the user who last modified the web service endpoint in the customization
project.
Last Modified On The date when the web service endpoint was last modified in the customization project.
Wikis | 113
Wikis
Page ID: (AU206001)
On this page, you manage the WikiArticle items in the customization project. A WikiArticle item contains the dataset
of a custom wiki and all the articles created within this wiki.
You open the Wikis page by clicking Wikis in the navigation pane of the Customization Project Editor.

order.
Command Description
Manage Wikis Opens the Wiki (SM202005) form in a new browser tab, so that you can specify the wikis
that should be added to the customization project.
Reload from Data- Updates the WikiArticle items in the customization project if the wikis that correspond to
base these items have been modified on the Wiki (SM202005) form.
Table: Add Wiki Page Dialog Box

This dialog box opens when you click Add New Record on the page toolbar. The dialog box displays all the
custom wikis that exist in your Acumatica ERP instance. You can select multiple wikis to add them to the project
simultaneously.
Element Description
The table in the dialog box includes the following columns.
Included A check box that you select to add the current wiki to the customization project if you
click Save.
Name The unique identifier of the wiki.
Title The name of the wiki as it is displayed in your Acumatica ERP instance.
Last Modified By The name of the user who last modified the wiki.
Last Modified On The date when the wiki was last modified.
Save Adds the selected wikis to the table on the page and closes the dialog box.
Wikis | 114
Element Description
Table
This table contains the list of wikis that have been added to the customization project, and the basic settings of
each of them. The columns of the table are described below.
Column Description
Object Name The name of the wiki in the customization project.
Description The description of the wiki.
Last Modified By The name of the user who last modified the wiki in the customization project.
Last Modified On The date when the wiki was last modified in the customization project.
Workflow (Diagram View) | 115
Workflow (Diagram View)

Page ID: (AU201030)
For a customized or custom workflow of a particular screen (that is, a form in Acumatica ERP), you can use the
diagram view of the Workflow page (also referred to as the Workflow Visual Editor) to define the states, transitions,
and actions of a workflow. (In addition to the diagram view of the workflow, you can use the tree view of the
workflow, which is described in Workflow (Tree View).) The diagram view provides visual representations of the
states and the transitions between them.
To access the diagram view, you click Diagram View on the page toolbar of the Workflow (Tree View)
page for the particular customized, custom, or predefined workflow. For a workflow with composite
states, the Workflow Visual Editor is not available, and the Diagram View button is not displayed on
the More menu of the Workflow (Tree View) page. The name that appears on the page consists of the
screen ID, the screen name in parentheses, and State Diagram: <Workflow Name> Workflow. (This
name is also used for the tree view of the workflow.)
Page Toolbar and the More Menu

order.
Command Description
Add Predefined State Opens the Add Predefined State Dialog Box dialog box, which you use to add a prede-
fined state to the workflow.
Add State Opens the Add State Dialog Box dialog box, which you use to add a new state to the
workflow.
Add Transition Opens the Add Transition Dialog Box dialog box, which you use to add a transition to
the workflow.
This command is available only if you select a state in the States and Transitions
pane.
Change Parent State Opens the Change Parent State Dialog Box dialog box, which you use to select the par-
ent state for the current state.
This command is available only if you select a state in the States and Transitions
pane.
Tree View Changes the view of the workflow from the diagram view to the tree view. (In the tree
view, you can click the Diagram View button to return to this view.)
View Changes Opens the Changes Dialog Box dialog box, which you use to view the changes in the
workflow. This button is available only if the workflow is inherited (that is, based on a
predefined workflow).
Table: New Action Dialog Box

The New Action dialog box opens when you click Create in the Add Transition dialog box, as well as when you
click Create Action on the table toolbar of the Actions tab of the State dialog box.
Element Description
Action Type Read-only. The type of the action, which indicates that the action changes the
state of an entity as a part of a workflow.
Action Name Required. The internal name of the action, which will be displayed on the Actions
page and in the Workflow Editor.
Display Name Required. The name of the action that will be displayed on the applicable Acumat-
ica ERP form.
Dialog Box The dialog box that will be displayed when the action is clicked. For details, see
Workflow Elements: General Information.
Category The category of the More menu in which the menu command associated with the
action will be displayed. The default list of categories depends on the form. To
manage the categories, you click the Manage Categories button on the page tool-
bar.
Add to Toolbar A check box that indicates (if selected) that the action will be displayed as a but-
ton on the form toolbar as well as under the selected category of the More menu if
the action is available for a record based on its state. If the action is available but
no category is specified, the action will be displayed on the form toolbar and un-
der the Other category.
If the check box is cleared, the action will not be displayed on the form toolbar but
will be displayed on the More menu.
The dialog box also contains the following buttons.
OK Closes the dialog box and creates the action.
Cancel Closes the dialog box without creating the action.
Add State Dialog Box

You use the Add State dialog box, which opens when you click Add State, to add a new state to the workflow.
Element Description
Identifier A single-letter identifier of the state (for example, H for On Hold).
Description The display name of the state (for example, On Hold).

Element Description
Parent State The parent state of the current state.

If you select a parent state, the state you are creating becomes a nested one for this par-
ent state. If this parent state is not a composite state yet (that is, if it does not contain any
nested states), the parent state becomes a composite state.
If you leave this box empty, the created state is added to the bottom of the list of states
on the States and Transitions pane.
OK Closes the dialog box and adds the state to the workflow.
Cancel Closes the dialog box without adding the state.
Change Parent State Dialog Box

You use the Change Parent State dialog box, which opens when you click Change Parent State, to select the
parent state for the current state.
Element Description
State Read-only. The name of the current state.

If this box is empty and you select a value in it, the current state becomes a nested one.
If the box contains a value and you remove it, the current state becomes an ordinary
state (that is, neither composite nor nested). If you modify the value in this box, the cur-
rent nested state moves to another composite state.
OK Closes the dialog box and changes the parent state.
Cancel Closes the dialog box without saving your changes to the parent state.
Add Predefined State Dialog Box

You use the Add Predefined State dialog box to add a predefined state to the workflow. This dialog box opens
when you click Add Predefined State on the form.
Element Description
State The name of the predefined state.

Element Description
Parent State The parent state for the predefined state.

If you leave this box empty, the state is added to the bottom of the list of states on the
States and Transitions pane.
OK Closes the dialog box and adds the predefined state to the workflow.
Cancel Closes the dialog box without adding the predefined state.
Add Transition Dialog Box

You use the Add Transition dialog box, which opens when you click Add Transition, to add a transition to the
workflow.
Element Description
Original State Read-only. The name of the state from which the transition is being created.
Triggered by Action An option button that indicates that the transition is triggered by an action.
Triggered by Event An option button that indicates that the transition is triggered by an event handler.
Handler
Trigger Name The name of the action or event handler that triggers the transition. You can select a
name from the drop-down list. Alternatively, you can click Create (right of the box)
and add a new action.
Create A button that you click to open the New Action dialog box, so that you can specify the
settings of the new action.
This button is available if you select the Triggered by Action option button.
Condition Optional. The condition that must be fulfilled for the transition to take place.
Target State The target state of the transition.

In the box, you can select a nested state, a composite state, @Next (the next state in
the composite state), or @ParentNext (the next state of the parent state).
This box is filled in when you create a transition by clicking the plus but-
ton and manually drawing a transition line.
OK Closes the dialog box and adds the transition to the workflow.
Cancel Closes the dialog box without adding the transition.

Changes Dialog Box

You use this dialog box to view the source code of the workflow; the changes to the currently selected element
(state or transition) are highlighted in red. The dialog box also contains the following buttons.
Button Description
Revert Changes Returns the workflow to its predefined state.
Elements of the Diagram View

The diagram view of the Workflow page (that is, the Workflow Visual Editor) contains the following parts:
• The page toolbar and More menu with various buttons and commands.
• The main area, which displays the workflow of the selected form as a diagram and has the following
elements:
• Boxes that contain the names of the states of the entity created by using the form and labels with the
names of the actions or event handlers that trigger the transitions. The labels appear aer you create a
transition and specify the source and target states. For example, in the screenshot below, the New box
reflects this state for a case, and the Open and Pending Customer labels within this box reflect the actions
a user can perform while the case has the New state (which is the status on the form).
Actions and event handlers for the current state are not displayed if they do not trigger any
transitions.
• Arrows that show the transitions between the states. For example, Item 1 in the following screenshot
shows an arrow that represents a transition from the Open state to the Pending Customer state of a case
that has been created on the Cases (CR306000) form.
• Buttons that are shown to the right of the diagram: Zoom In or Zoom Out (see Item 2 in the following
screenshot), Reset Scale to 100% (Item 3), Fit Screen (Item 4), and Collapse All/Expand All (Item 5).
Figure: The diagram view of the Workflow page
Table: State Elements

In the Workflow Visual Editor, a box with a state contains the following elements.
Element Description
Arrow You click an arrow (see Item 6 in the screenshot above) to expand or collapse the list of
actions or event handlers that trigger transitions for this state.
More button You click the More button (Item 7) to invoke a More menu with the following com-
mands:
• Edit State: Opens the State Dialog Box dialog box, which you can use to modify the
state.
• Add Transition: Opens the Add Transition Dialog Box dialog box, which you can use
to add a transition from the current state to another state. In the dialog box, you
specify the action or event handler that causes the transition, and the target state.
• Delete State: Deletes the state. When you select this command, you need to con-
firm the deletion in the dialog box that is opened.
Plus button You click a plus button (Item 8) to manually draw a transition line for an action or an
event handler that does not yet have any outgoing transitions from the current state.
This opens the Add Transition Dialog Box dialog box with the Target State box filled in.
When the transition is created, the action or event handler that triggers it is added to
the box with the current state with the name you have specified in the Trigger Name
box of the dialog box.
State Dialog Box

This dialog box opens when you click the More button for a state and then click Edit State. The dialog box contains
a Summary area and the following tabs: Fields, Actions, Handlers, Fields to Update on Entry, and Fields to
Update on Exit.
Table: State Dialog Box: Summary Area

The Summary area of the dialog box contains the following elements.
Element Description
Active A check box that indicates (if selected) that the selected state is active.
Initial State of the Work- A check box that indicates (if selected) that this state is the initial state of the work-
flow flow.
Table: State Dialog Box: Fields Tab

The Fields tab of State dialog box contains a table with the fields that have properties that should be modified for
the current state. (For details, see Getting Started with Workflows: Transitions.) Also, for fields of the Combo type,
specific combo box values can be specified. The tab has the following elements.
Element Description
The table toolbar includes standard buttons and the following table-specific button.
Combo Box Values Opens the Combo Box Values dialog box, where you can specify the list of values
that are displayed as combo boxes.
The table on the tab has the following columns.
Active A check box that indicates (if selected) that the field is active for the selected
state.
Object Name The name of the DAC from which the field is selected.
Field Name The name of the field.
Disabled A check box that indicates (if selected) that the field is unavailable for the select-
ed state.
Hidden A check box that indicates (if selected) that the field is hidden for the selected
state.
Required A check box that indicates (if selected) that the field is required for the selected
state.
Element Description
Default Value The default value of the field.
You can specify default values of fields only for the initial state of a
workflow.
Status Read-only. The status of the field.

The column can have one of the following values: Inherited or New.
Table: State Dialog Box: Fields to Update on Entry and Fields to Update on Exit Tabs
On the Fields to Update on Entry and Fields to Update on Exit tabs of the State dialog box, you specify which
fields should be updated when an entity on the form enters the current state and when the entity leaves this state,
respectively.
Before a transition is performed, the system checks the following:
• For the target state, the fields that should be updated when the entity enters the state
• For the original state, the fields that should be updated when the entity leaves the state
The tab has the following elements.
Element Description
The tables on the tabs contain the same columns, which are listed in the following table.
Active A check box that indicates (if selected) that the field should be updated after the
transition.
Field Name The name of the field that should be updated.
From Schema A check box that indicates (if selected) that the field value from the database
should be used.

Table: State Dialog Box: Actions Tab

The Actions tab of the State dialog box contains the list of actions specified for the state (for details, see Action
Configuration: General Information).The tab has the following elements.
Element Description
Create Action Opens the New Action dialog box, where you can create an action for the current
state.
The table of the tab has the following columns.

Element Description
Active A check box that indicates (if selected) that the action is active for the selected
state.
Action An action that is available for the selected state.
Duplicate on Toolbar A check box that indicates (if selected) that the action should be available on the
page toolbar (as a button) as well as on the More menu.
Auto-Run Action An indicator of whether (and when, if applicable) the action is triggered automati-
cally when the selected condition is fulfilled. You can select False or a condition. If
a condition is selected, the action is triggered automatically on fulfillment of the
condition.
Connotation An optional color notation that you can assign to the action to give users addi-
tional information about it. For example, you can use connotations to indicate to
users which action in the entity processing workflow is the one most likely to be
taken, given the state of the entity, which actions require special consideration,
and which actions provide links to additional information, such as reports.
On the More menu, a connotation is displayed as a dot of the selected color (see
the list below) right of the associated menu command. If the action is also dis-
played on the form toolbar, it is highlighted in the selected color.
You can select one of the following options (with the corresponding colors noted):
• Success: Green
• Danger: Red
• Warning: Yellow
• Info: Blue
• Dark: Dark gray
For an action on a form with a workflow, you can also specify a connotation in
the Action Properties dialog box of the Actions page. In this case, this connota-
tion is used for this action in all states of an entity in the workflow. If in a specific
state, another connotation is specified for the action, the state-specific connota-
tion takes precedence.
Connotations are also supported for forms without workflows, but

the connotations for these forms can be modified only through
code. For details, see To Add a Connotation.
Status A read-only box that indicates the status of the action.

• Modified: The system action that you have modified.
Element Description
Dialog Box The name of the dialog box that is displayed when a user clicks the action, if ap-
plicable; in this dialog box, the user should enter the needed values.

Table: State Dialog Box: Handlers Tab

The Handlers tab of the State dialog box displays the event handlers that are available for the current state (for
details, see Getting Started with Workflows: Transitions). The tab has the following elements.
Element Description
Active A check box that indicates (if selected) that the event handler is active for the
selected state.
Handler An event handler that is available for the selected state.
Status A read-only box that indicates the status of the event handler.
Transition Elements
In the Workflow Visual Editor, if a transition has a condition (that is, if the transition is performed only when a
particular condition is met for the entity), a diamond icon is displayed above the transition (see Item 1 in the
following screenshot).
If an action with a transition contains an auto-run condition (that is, a condition for which the action is triggered
automatically if the condition is met), a lightning rod icon is displayed above the transition (Item 2).
The transition lines are of the same color as the states they originate from, which makes it easier to distinguish
between transitions. Also, each transition has a dot that indicates the direction of the transition and that is of the
same color as the target state (Item 3).
Figure: Elements of the transitions
Table: Transition Context Menu

The context menu of a transition, which is displayed when you click the transition, contains the following
commands.
Command Description
Edit Transition Opens the Transition Dialog Box dialog box.
Delete Transition Deletes the selected transition. When you select this command, you need to
confirm the deletion in the dialog box that is opened.
Transition Dialog Box

This dialog box opens when you click the transition and then click the Edit button in the context menu.
Element Description
Original State Read-only. The name of the state from which the transition is being creat-
ed.
Active A check box that indicates (if selected) that the transition is active for the
selected action.
Triggered by Action An option button that indicates that the transition is triggered by an ac-
tion.
Element Description
Triggered by Event Handler An option button that indicates that the transition is triggered by an
event handler.
Trigger Name The name of the action or event handler that triggers the transition.
Condition Optional. The condition that must be fulfilled for the transition to take
place.
Target State The target state of the transition. This box is filled in when you create a
transition by clicking the plus button and manually drawing a transition
line.
The dialog box also contains the Fields to Update After Transition table, which lists the fields that the system
should update after the transition is performed. The table has the following columns.
Active A check box that indicates (if selected) that the field should be updated
after the transition.
From Schema A check box that indicates (if selected) that the field value from the data-
base should be used.
The dialog box also contains the following button.
OK Closes the dialog box and applies the selected options.

Workflow (Tree View) | 127
Workflow (Tree View)

Page ID: (AU201030)
For a customized or custom workflow for a particular screen (that is, a form in Acumatica ERP), you use the
Workflow page to define states, transitions, and actions. The page has a tree view, described in this topic, and a
diagram view (also referred to as the Workflow Visual Editor), which is described in Workflow (Diagram View).
You open the Workflow page by clicking Default Workflow or the name of the customized or custom workflow
under the screen ID (of the form for which you are adding or modifying workflows) in the navigation pane of the
Customization Project Editor. You can also open the page by clicking the link in the Workflow Name column of the
Workflows page. The name that appears on the page consists of the screen ID, the screen name in parentheses, and
State Diagram: <Workflow Name> Workflow. (This name is also used for the tree view of the workflow.)
If a particular form has only one predefined workflow, the workflow name of the predefined workflow
is Default workflow. If the form has multiple predefined workflows, diﬀerent workflow names are
assigned to each predefined workflow.

order.
Command Description
Add Predefined Opens the Add Predefined State dialog box, which you use to add a predefined state to
State the workflow.
This command is not available for a predefined workflow
Add State Opens the Add State dialog box, which you use to add a new state to the workflow.
Add Transition Opens the Add Transition dialog box, which you use to add a transition to the workflow.
This command is available only if you select a state or one of the nodes under Transi-
tions in the States and Transitions pane.
Change Parent Opens the Change Parent State dialog box, which you use to select the parent state for
State the current state.
This command is available only if you select a state in the States and Transitions pane.
Diagram View Changes the view of the workflow from the tree view to the diagram view. (In the diagram
view, you can click the Tree View button to return to this view.)
This command is unavailable if the selected workflow has composite states.

Command Description
View Changes Opens the Changes dialog box, which you use to view the changes in the workflow. This
command is available only if the workflow is inherited (that is, based on a predefined
workflow).
Table: Add State Dialog Box

You use the Add State dialog box, which opens when you click Add State, to add a new state to the workflow.
Element Description

If you select a parent state, the state you are creating becomes a nested one for this par-
ent state. If this parent state is not a composite state yet (that is, if it does not contain any
nested states), the parent state becomes a composite state.
If you leave this box empty, the created state is added to the bottom of the list of states
on the States and Transitions pane.
OK Closes the dialog box and adds the state to the workflow.
Cancel Closes the dialog box without adding the state.
Table: Change Parent State Dialog Box

You use the Change Parent State dialog box, which opens when you click Change Parent State, to select the
parent state for the current state.
Element Description
State Read-only. The name of the current state.

If this box is empty and you select a value in it, the current state becomes a nested one.
If the box contains a value and you remove it, the current state becomes an ordinary
state (that is, neither composite nor nested). If you modify the value in this box, the cur-
rent nested state moves to another composite state.
OK Closes the dialog box and changes the parent state.

Element Description
Cancel Closes the dialog box without saving your changes to the parent state.
Table: Add Predefined State Dialog Box

You use the Add Predefined State dialog box to add a predefined state to the workflow. This dialog box opens
when you click Add Predefined State on the form.
Element Description
State The name of the predefined state.
Parent State The parent state for the predefined state.

If you leave this box empty, the state is added to the bottom of the list of states on the
States and Transitions pane.
OK Closes the dialog box and adds the predefined state to the workflow.
Cancel Closes the dialog box without adding the predefined state.
Table: Add Transition Dialog Box

You use the Add Transition dialog box, which opens when you click Add Transition, to add a transition to the
workflow.
Element Description
Original State Read-only. The name of the state from which the transition is being created.
Handler
Trigger Name The name of the action or event handler that triggers the transition. You can select a
name from the drop-down list or click Create (right of the box) and add the action.
Create A button that you click to open the New Action dialog box, so that you can specify the
settings of the new action.
This button is available if you select the Triggered by Action option button.
Condition Optional. The condition that must be fulfilled for the transition to take place.

In the box, you can select a nested state, a composite state, @Next (the next state in
the composite state), or @ParentNext (the next state of the parent state).
Element Description
OK Closes the dialog box and adds the transition to the workflow.
Cancel Closes the dialog box without adding the transition.
Table: New Action Dialog Box

The New Action dialog box opens when you click Create in the Add Transition dialog box, as well as when you
click Create Action on the table toolbar of the Actions tab.
Property Description
Action Type Read-only. An option that indicates that the action changes the state of an entity as a
part of a workflow.
Action Name Required. The internal name of the action, which will be displayed on the Actions
page and in the Workflow Editor.
Display Name Required. The name of the action that will be displayed on the applicable Acumatica
ERP form.
Dialog Box The dialog box that will be displayed when the action is clicked.
Category The category of the More menu in which the menu command associated with the ac-
tion will be displayed. The default list of categories depends on the form. To manage
the categories, you click the Manage Categories button on the page toolbar of the
Actions page.
Add to Toolbar A check box that indicates (if selected) that the action will be displayed as a button on
the form toolbar as well as under the selected category of the More menu if the action
is available for a record based on its state. If the action is available but no category is
specified, the action will be displayed on the form toolbar and under the Other cate-
gory.
If the check box is cleared, the action will not be displayed on the form toolbar but
will be displayed on the More menu.
The dialog box also contains the following buttons
OK Closes the dialog box and creates the action.
Cancel Closes the dialog box without creating the action.

You use this dialog box to view the source code of the workflow; the changes to the currently selected element
(state or transition) are highlighted in red. The dialog box also contains the following buttons.
Button Description
Revert Changes Returns the workflow to the predefined state.

Button Description
States and Transitions Pane

The States and Transitions pane contains the tree view of states and transitions defined for the workflow. On the
pane, the transitions that lead from a state to another state are displayed in the Transitions node under the node
with the name of this state. The pane contains the following buttons.
These buttons are not available for a predefined workflow.
Button Description
Delete Deletes the selected state or transition (the one you clicked before clicking this but-
ton).
Move Up Moves up the selected state or transition (the one you clicked before clicking this
button).
Move Down Moves down the selected state or transition (the one you clicked before clicking this
button).
State Properties Tab: Summary Area

The State Properties tab is displayed when you click a state on the States and Transitions pane. It consists of a
Summary area and three tabs in the lower part of the State Properties tab: Fields, Fields to Update on Entry, and
Fields to Update on Exit.
The Summary area of the tab contains the following elements.
Element Description

Element Description
Skip Condition The condition that the system checks when an entity enters any nested state in a
composite state. If the condition is fulfilled, the nested state is skipped. The box is dis-
played only if you have selected a nested state in a composite state.
If this condition is fulfilled, the system does the following for the selected nested
state:
1. Assigns the default values for the fields as specified on the Fields tab if the select-
ed state is the initial state of the workflow
2. Does not check the fields that should be updated when the entity enters the state
and leaves it
3. Does not check any of the workflow settings
4. Moves the entity to the next state in the composite state
If the box is empty, the system uses the typical workflow for this state. That is, the
transitions are triggered only by actions or event handlers, and the system does not
check the skip condition again while the entity remains in this state.
Next State Read-only. The state to which an entity will move if the skip condition is fulfilled and
the entity skips the current state. The box is displayed only if you have selected a
nested state.
Active A check box that indicates (if selected) that the selected state is active.
Initial State of the A check box that indicates (if selected) that this state is the initial state of the work-
Workflow flow.
State Properties Tab: Fields Tab

The Fields tab, located in the lower part of the State Properties tab, contains a table with the fields whose
properties should be modified for the current state. (For details, see Workflow Elements: General Information.) Also,
for fields of the Combo type, specific combo box values can be specified.

Button Description
Combo Box Values Opens the Combo Box Values dialog box, where you can specify the list of values that
are displayed as combo boxes.

The tab includes the following columns.
Column Description
Active A check box that indicates (if selected) that the field is active for the selected state.
Object Name The name of the DAC from which the field is selected.
Field Name The name of the field.

Column Description
Disabled A check box that indicates (if selected) that the field is unavailable for the selected
state.
Hidden A check box that indicates (if selected) that the field is hidden for the selected state.
Required A check box that indicates (if selected) that the field is required for the selected state.
Default Value The default value of the field.
You can specify default values of fields only for the initial state of a work-
flow.
Status Read-only. The status of the field.

State Properties Tab: Fields to Update on Entry and Fields to Update on Exit Tabs
On the Fields to Update on Entry and Fields to Update on Exit tabs, you specify which fields should be updated
when an entity on the form enters the current state and when the entity leaves this state, respectively. These tabs
are located in the lower part of the State Properties tab.
Before a transition is performed, the system checks the following:
• For the target state, the fields that should be updated when the entity enters the state
• For the original state, the fields that should be updated when the entity leaves the state

The tables on the tabs contain the same columns, which are described below.
Column Description
Active A check box that indicates (if selected) that the field should be updated after the
transition.
From Schema A check box that indicates (if selected) that the field value from the database should
be used.

Actions Tab
The Actions tab is displayed when you click a state on the States and Transitions pane. The Actions tab contains
the list of actions specified for the state (for details, see Action Configuration: General Information).

Button Description
Create Action Opens the New Action dialog box, where you can create an action for the current
state.

Column Description
Active A check box that indicates (if selected) that the action is active for the selected state.
Action An action that is available for the selected state.
Duplicate on Toolbar A check box that indicates (if selected) that the action should be available on the
page toolbar (as a button) as well as on the More menu.
Auto-Run Action An indicator of whether (and when, if applicable) the action is triggered automati-
cally when the selected condition is fulfilled. You can select a condition or False. If a
condition is selected, the action is triggered automatically on fulfillment of the con-
dition.
Column Description
Connotation An optional color notation that you can assign to the action to give users addition-
al information about it. For example, you can use connotations to indicate to users
which action in the entity processing workflow is the one most likely to be taken,
given the state of the entity, which actions require special consideration, and which
actions provide links to additional information, such as reports.
On the More menu, a connotation is displayed as a dot of the selected color (see the
list below) right of the associated menu command. If the action is also displayed on
the form toolbar, it is highlighted in the selected color.
You can select one of the following options (with the corresponding colors noted):
• Success: Green
• Danger: Red
• Warning: Yellow
• Info: Blue
• Dark: Dark gray
For an action on a form with a workflow, you can also specify a connotation in the
Action Properties dialog box of the Actions page. In this case, this connotation is
used for this action in all states of an entity in the workflow. If in a specific state, an-
other connotation is specified for the action, the state-specific connotation takes
precedence.
Connotations are also supported for forms without workflows, but the
connotations for these forms can be modified only through code. For
details, see To Add a Connotation.
Status A read-only box that indicates the status of the action.

Dialog Box The name of the dialog box that is displayed when a user clicks the action, if applic-
able; in this dialog box, the user should enter the needed values.
Handlers Tab
The Handlers tab is displayed when you click a state on the States and Transitions pane. The Handlers tab
displays the event handlers that are available for the current state (for details, see Getting Started with Workflows:
Transitions). The columns of the table are described below.
Column Description
Active A check box that indicates (if selected) that the event handler is active for the selected
state.
Handler An event handler that is available for the selected state.
Status A read-only box that indicates the status of the event handler.
Transition Properties Tab

The Transition Properties tab is displayed when you click a transition on the States and Transitions pane.
The tab includes the following elements and the Fields to Update Aer Transition table.
Table: Transition Properties Elements

You can use the following elements to define the transition.
Element Description
Original State Read-only. The name of the state from which the transition is performed.
Active A check box that indicates (if selected) that the transition is active.
Handler
Trigger Name The name of the action or event handler that triggers the transition.
Condition Optional. The condition that should be fulfilled for the transition to take place.
Table: Fields to Update Aer Transition Table

The Fields to Update Aer Transition table lists the fields that the system should update aer the transition is
performed, and contains the following columns.
Column Description
Active A check box that indicates (if selected) that the field should be updated after the tran-
sition.
From Schema A check box that indicates (if selected) that the field value from the database should
be used.

Column Description

Workflows | 138
Workflows
Page ID: (AU201020)
This page contains the list of all workflows defined for a particular screen (that is, a form in Acumatica ERP) as well
as the general settings of each workflow. The page lists predefined workflows, as well as customized and custom
workflows. You can use the page to add customized and custom workflows for the form.
You open the Workflows page by clicking Workflows under the screen ID (of the form for which you
are adding or modifying workflows) in the navigation pane of the Customization Project Editor. In the
name that appears on the page, Workflows is preceded by the screen ID and then the screen name in
parentheses.

order.
Command Description
Add Workflow Opens the Add Workflow dialog box, which you use to add a new workflow or modify an
existing one.
Disinherit Breaks the relationship between the predefined workflow and the selected customized
workflow that was based on it. (You first click the row with the customized workflow in
the table and then click this command.) The selected workflow will no longer get updates
from the system, and the Upgrade Predefined Workflow command will not be available
for it.
You cannot reverse the changes induced by the Disinherit command. That
is, you cannot link the selected workflow to a predefined workflow once
you have selected the workflow and clicked Disinherit.
Upgrade Prede- Starts the process of upgrading the selected customized workflow (which is based on a
fined Workflow predefined workflow) with the latest changes from the system. (You first click the row
with the customized workflow in the table and then click this command.)
View Changes Opens the Changes dialog box, which you use to view the description of a workflow in in-
ternal format. If you have made changes to this workflow, they are highlighted in the dia-
log box. You can return the workflow to the predefined state by clicking Revert Changes
in the dialog box.
The View Changes button and command are available only if the workflow
is inherited—that is, based on a predefined workflow.
Table: Add Workflow Dialog Box

This dialog box opens when you click Add Workflow on the page toolbar. The dialog box contains the following
elements.
Workflows | 139
Element Description
Operation The operation that the system will perform when you specify all the needed val-
ues and click OK. You can select one of the following options: Create New Work-
flow, Extend System Workflow, and Copy Workflow.
Base Workflow The name of the predefined workflow on which the current workflow is based.
Workflow Type The type of the entities to which the workflow is applied. The applicable entities
depends on the particular form for which the workflow is defined.
Workflow Name The name of the workflow you are adding.
OK Adds the workflow to the table on the page and closes the dialog box.
Cancel Closes the dialog box without adding a workflow to the page.
Summary Area
In this area, you can specify the basic settings for the new workflow.
Element Description
State Identifier The name of the field on this form that indicates the state.
Workflow-Identifying Field The field whose value determines which workflow is used if multiple workflows
are defined for the form.
If you do not select any value in the this box, an entity that has been created on
the form can have only one workflow. If you want the entity to have multiple
workflows, select the field that defines the change of the workflow in this box.
Allow Users to Modify Value A check box that you select if you want users to be able to change the workflow
type for an existing entity.
Table
This table lists all workflows defined for the form. If you click the name of a workflow in the table, you open the
Workflow page with the workflow. This page has the name <Form Number (Form Name)> State Diagram: <Workflow
Name> for the customized, custom, or predefined workflow. The columns of the table are described below.
Column Description
Active A check box that indicates (if selected) that the current workflow is active.
Workflow Type The type of the entities to which the workflow is applied. The applicable entities depends
on the particular form for which the workflow is defined.
Workflow Name The name of the workflow, which is also a link that you can click to switch to the Work-
flow page for the selected workflow.
Workflows | 140
Column Description
Base System Work- The name of the predefined workflow on which the current workflow is based.
flow
Status The status of the workflow, which can be one of the following: System Read-Only, Inherit-
ed, or New.

AcumaticaERP CustomizationFormReference

Uploaded by

Document Information

Original Title

Copyright

Available Formats

Share this document

Share or Embed Document

Sharing Options

Did you find this document useful?

Is this content inappropriate?

Copyright:

Available Formats

AcumaticaERP CustomizationFormReference

Uploaded by

Copyright:

Available Formats

Customization Tool Reference

Source Code....................................................................................................................................... 103

© 2022 Acumatica, Inc.

ALL RIGHTS RESERVED.

Soware Version: 2022 R2

Page Toolbar and More Menu

Table: Add Access Rights for Screen Dialog Box

The table in the dialog box has the following columns.

This dialog box has the following buttons.

Cancel Closes the dialog box without making any changes.

Description The description of the access rights.

Page Toolbar and More Menu

Table: Add Report Definition Dialog Box

Code The internal name of the report.

Description The description of the report.

This dialog box has the following buttons.

Object Name The name of the report in the customization project.

Description The description of the report.

Page Toolbar and More Menu

Action Properties Dialog Box

Table: Action Properties Dialog Box: Summary Area

Action Name The internal name of the action.

Disabled An indicator of when the action is disabled.

Hidden An indicator of when the action is hidden.

On a mass-processing form, if you add to a schedule a workflow action that

Action Type The type of the action.

Table: Action Properties Dialog Box: Navigation Parameters Tab

Parameter Name The name of the parameter.

Value The value of the parameter.

Table: Action Properties Dialog Box: Field Update Tab

Field The name of the field that should be updated.

New Value The new value for the field.

Status The status of the field update.

Table: Action Properties Dialog Box: Action Parameters Tab

Parameter Name The name of the action parameter.

Value The value of the action parameter.

Status The status of the parameter.

Table: Action Properties Dialog Box: Buttons

OK Closes the dialog box and applies the changes.

Cancel Closes the dialog box without making any changes.

Manage Categories Dialog Box

The table contains the following columns.

Category Name The internal name of the category.

This dialog box has the following buttons.

OK Closes the dialog box and applies the changes.

Cancel Closes the dialog box without saving any changes.

New Category Dialog Box

The dialog box has the following elements.

Category Name The internal name of the category.

This dialog box has the following buttons.

OK Closes the dialog box and applies the changes.

Cancel Closes the dialog box without making any changes.

Reorder Actions Dialog Box

The Summary area contains the following element.

The table contains the following elements.

Action Name The internal name of the action.

This dialog box has the following buttons.

OK Closes the dialog box and applies the changes.

Cancel Closes the dialog box without applying any changes.

Changes Dialog Box

Revert Changes Returns the action to its predefined state.

Close Closes the dialog box.

Table: Table Columns
