Teaming up with Wow creative thinking, chromatic choice and an easy installation
method, the essence of this collection is revealed.
Raster es una retícula de datos conformada por pequeños píxeles que generan
estructuras y dan lugar a infinitas composiciones.
01.
SIZES, COLOURS AND FINISHES / pag. 6
FORMATOS, COLORES Y ACABADOS
02.
GET INSPIRED / pag. 8
INSPÍRATE
03.
RECOMMENDATIONS / pag. 36
RECOMENDACIONES
04.
TECHNICAL FEATURES / pag. 37
CARACTERÍSTICAS TÉCNICAS
05.
TECHNICAL DRAWINGS / pag. 38
DIBUJOS TÉCNICOS
06.
PACKING pag. 39
07.
PRICE CODE / pag. 39
CÓDIGO DE TARIFA
4| |5
01. SIZES, COLOURS AND FINISHES / FORMATOS, COLORES Y ACABADOS RASTER
W20 W20
LINES S 15x15 cm / 6”x6” LINES M 15x15 cm / 6”x6”
Deep Blue Basalt Clay Off White Deep Blue Basalt Clay Off White
W20 W20
GRID S 15x15 cm / 6”x6” GRID M 15x15 cm / 6”x6”
Deep Blue Basalt Clay Off White Deep Blue Basalt Clay Off White
6| |7
02. GET INSPIRED / INSPÍRATE RASTER
Lines M Chalk
Grid M Mud
Lines S Mud
Lines S Chalk
8| |9
02. GET INSPIRED / INSPÍRATE RASTER
Lines M Moss
Grid M Moss
Grid S Moss
10 | | 11
02. GET INSPIRED / INSPÍRATE RASTER
Grid M Chalk & Mud - Lines M Mud -Grid S Chalk Lines M Chalk - Lines S Chalk - Grid M Chalk
12 | | 13
02. GET INSPIRED / INSPÍRATE RASTER
14 | | 15
02. GET INSPIRED / INSPÍRATE RASTER
16 | | 17
02. GET INSPIRED / INSPÍRATE RASTER
18 | | 19
02. GET INSPIRED / INSPÍRATE RASTER
Lines M Basalt 50% - Grid M Basalt 25% - Grid S Basalt 25% Wall: Lines M Basalt Lines M Moss - Lines S Moss
20 | | 21
02. GET INSPIRED / INSPÍRATE RASTER
22 | | 23
02. GET INSPIRED / INSPÍRATE RASTER
24 | | 25
02. GET INSPIRED / INSPÍRATE RASTER
Lines M Moss
Grid S Basalt & Moss
26 | | 27
02. GET INSPIRED / INSPÍRATE RASTER
Grid M Clay 25% - Grid S Clay 25% - Lines M Clay 25% - Lines S Clay 25% Grid S Off White 20% - Lines S Off White 40% - Lines M Off White 40%
28 | | 29
02. GET INSPIRED / INSPÍRATE RASTER
30 | | 31
02. GET INSPIRED / INSPÍRATE RASTER
Grid M Chalk
Grid S Mud
Lines M Chalk
Lines S Mud
32 | | 33
02. GET INSPIRED / INSPÍRATE RASTER
34 | | 35
03. RECOMMENDATIONS / RECOMENDACIONES 04. TECHNICAL FEATURES / INFORMACIÓN TÉCNICA
Porcelain tiles whith water absorption B Ia ≤ 0,5% for interior and exterior floors and walls.
Baldosas cerámicas prensadas en seco con absorción de agua B Ia ≤ 0,5% para suelos y paredes interiores y exteriores.
FEATURES /
SPECIFICATION / ESPECIFICACIÓN NORMA
CARACTERÍSTICAS
UNE-EN ISO
ALMACENAMIENTO Dimensional Features 148 mm +/- 0,6% x 148 mm +/- 0,6% x 8,5 mm+/- 5 %
10545-2:1998
WAREHOUSING Para garantizar las características de su acabado, el
In order to guarantee the characteristics of the finish the producto debe mantenerse en su embalaje original hasta el
product must be kept in its original packaging until the time momento de la colocación. Si el producto va a permanecer UNE-EN ISO
Water absorption Eb ≤ 0,5%
of fixing. If the product is likely to be stored for a long period almacenado durante un largo periodo es conveniente 10545-3:1997
of time it should be suitably covered. hacerlo bajo cubierta.
Minimum 35 N/mm2 UNE-EN ISO
TILE FIXING COLOCACIÓN Modulus of rupture
Individual Minimum 32 N/mm2 10545-4:2012
To ensure the products adhere correctly to the surface, it is Para garantizar una buena adhesión al soporte es necesaria
essential to use specific adhesive and grouting material. This la utilización de materiales de agarre y de rejuntado
PEI 4 : Chalk & Off White
must also be suitable for the environment they will have to adecuados al ambiente al que vayan a estar sometidos. UNE-EN ISO
withstand. Fitting with traditional mortars does not ensure La colocación con morteros tradicionales no garantiza una PEI Abrasive resistance PEI 3: Clay, Ash & Mud
10545-7:1999
PEI 2: Moss, Deep Blue & Basalt
good adhesion. buena adhesión.
Due to the nature of the material there may be dimensional Debido a la naturaleza del material pueden existir diferencias UNE-EN ISO
Crazing resistance Pass
variations between pieces. Therefore , all types of joints must dimensionales entre piezas. Por ello deberán planificarse y 10545-11:1997
be planned and carried out correctly: structural, perimeter, ejecutarse correctamente todo tipo de juntas: estructurales,
expansion and installation joints. Fitting tiles without joints perimetrales, de dilatación y de colocación. La colocación UNE-EN ISO
is not advisable from any technical point of view as this may sin juntas es desaconsejable desde cualquier punto de vista Frost resistance Pass
10545-11:1997
lead to various problems. For an optimal result we advise to técnico, pudiendo ser el origen de diversas patologías. Para
use 1,5 mm (0.06”) spacers. un resultado óptimo es necesario usar 1,5 mm de junta.
Household products UNE-EN ISO
GA
GROUTING REJUNTADO resistance 10545-13:1998
The choice of quality grouting mortar is crucial. Es importante la elección de un material de rejunte de
We recommend: calidad. WOW recomienda utilizar: UNE-EN ISO
Chemical resistance GHA
- Kerakoll Fugabella® (www.kerakoll.com) - Kerakoll Fugabella® (www.kerakoll.com) 10545-13:1998
- Litokol StyleGrout (www.litokol.it) - Litokol StyleGrout (www.litokol.it)
- Mapei Ultracolor (www.mapei.com) - Mapei Ultracolor Plus (www.mapei.com) UNE-EN ISO
Stain resistance 5
10545-14:1998
MAINTENANCE AND CLEANING MANTENIMIENTO Y LIMPIEZA
Once the materials have been fitted, it is advisable to remove Finalizada la puesta en obra se recomienda eliminar
any remaining adhesive and grouting material by using a los restos de materiales de agarre y rejuntado con un R10 / CLASS 2 DIN 51130:2014
Non-slip value
commercial descaling product designed especially, diluted desincrustante comercial diseñado expresamente para DCOF >0,42 ANSI A137.1:2012
with water . The descaling product must not remain in contact baldosas cerámicas, rebajado con agua, permaneciendo
with the surface to be cleaned for more than 5 minutes. en contacto con la superficie a limpiar no más de 5 minutos.
Tone variation V2 -
As a general guideline, powder dertergents should not be Como norma general no deben utilizarse detergentes en
used, not wire wool or abrasive materials. Generally a sponge polvo ni estropajos metálicos o abrasivos. Generalmente
will be sufficient with warm water and liquid neutral soap. será suficiente con una esponja, agua tibia y un jabón líquido Porcelain body - -
Then rinse with plenty of clean water. neutro. Posteriormente aclarar con abundante agua limpia.
36 | | 37
05. TECHNICAL DRAWINGS / DIBUJOS TÉCNICOS 06. PACKING
RASTER
LB FT2
FT2
8,5 mm 148 mm 8,5 mm 148 mm Modelo Tamaño (cm) Piezas/caja Kg/caja m2/caja Cajas/palet m2/palet
0.33 in 5.83 in 0.33 in 5.83 in Model Size (cm) Pieces/box kg/box m2/box Box/pallet m2/pallet
W20
