PLC DATA SHEET

Data sheet 6ES7241-1CH30-1XB0

SIMATIC S7-1200, Communication Board CB 1241, RS485, terminal block,

supports Freeport

General information
Product type designation CB 1241 RS 485
Input current
from backplane bus 5 V DC, typ. 50 mA
Power loss
Power loss, typ. 1.5 W
Interfaces
Point-to-point connection
● Cable length, max. 1 000 m
Integrated protocol driver
— Freeport Yes
— ASCII Yes; Available as library function
— Modbus RTU master Yes
— MODBUS RTU slave Yes
— USS Yes; Available as library function
Protocols
Integrated protocols
Freeport
— Telegram length, max. 1 kbyte
— Bits per character 7 or 8
— Number of stop bits 1 (Standard), 2
— Parity No parity (standard); even, uneven, mark (parity bit always 1); space (parity bit
always 0)
3964 (R)
— Telegram length, max. 1 kbyte
— Bits per character 7 or 8
— Number of stop bits 1 (Standard), 2
— Parity No parity (standard); even, uneven, mark (parity bit always 1); space (parity bit
always 0)
Modbus RTU master
— Address area 1 through 49 999 (Standard Modbus addressing)
— Number of slaves, max. 247; slave numbers 1 through 247, per MODBUS network segment maximum
32 devices, additional repeaters needed to expand the network to maximum
configuration
MODBUS RTU slave
— Address area 1 through 49 999 (Standard Modbus addressing)
Interrupts/diagnostics/status information
Diagnostics function Yes
Degree and class of protection
IP degree of protection IP20
Standards, approvals, certificates

6ES72411CH301XB0 Subject to change without notice

6/27/2023
Page 1/2 © Copyright Siemens
 CE mark Yes
CSA approval Yes
UL approval Yes
cULus Yes
FM approval Yes
RCM (formerly C-TICK) Yes
KC approval Yes
Marine approval Yes
Ambient conditions
Free fall
● Fall height, max. 0.3 m; five times, in product package
Ambient temperature during operation
● min. -20 °C
● max. 60 °C
● horizontal installation, min. -20 °C
● horizontal installation, max. 60 °C
● vertical installation, min. -20 °C
● vertical installation, max. 50 °C
● permissible temperature change 5°C to 55°C, 3°C / minute
Ambient temperature during storage/transportation
● min. -40 °C
● max. 70 °C
Air pressure acc. to IEC 60068-2-13
● Operation, min. 795 hPa
● Operation, max. 1 080 hPa
● Storage/transport, min. 660 hPa
● Storage/transport, max. 1 080 hPa
Relative humidity
● Operation at 25 ℃ without condensation, max. 95 %
Mechanics/material
Enclosure material (front)
● Plastic Yes
Dimensions
Width 38 mm
Height 62 mm
Depth 21 mm
Weights
Weight, approx. 40 g

last modified: 2/26/2021

6ES72411CH301XB0 Subject to change without notice

6/27/2023
Page 2/2 © Copyright Siemens
 Data sheet 6ES7134-6GF00-0AA1
SIMATIC ET 200SP, Analog input module, AI 8XI 2-/4-wire Basic,
suitable for BU type A0, A1, Color code CC01, Module diagnostics,
16 bit

General information
Product type designation AI 8xI 2-/4-wire BA
HW functional status from FS04
Firmware version
● FW update possible Yes
usable BaseUnits BU type A0, A1
Color code for module-specific color identification CC01
plate
Product function
● I&M data Yes; I&M0 to I&M3
● Isochronous mode No
● Measuring range scalable No
Engineering with
● STEP 7 TIA Portal configurable/integrated as of V13 SP1
version
● STEP 7 configurable/integrated as of version V5.5 SP3 / -
● PROFIBUS as of GSD version/GSD revision GSD Revision 5
● PROFINET as of GSD version/GSD revision GSDML V2.3
Operating mode

6ES7134-6GF00-0AA1 Subject to change without notice

Page 1/4 05/21/2020 © Copyright Siemens
 ● Oversampling No
● MSI No

CiR – Configuration in RUN

Reparameterization possible in RUN Yes
Calibration possible in RUN No

Supply voltage
Rated value (DC) 24 V
permissible range, lower limit (DC) 19.2 V
permissible range, upper limit (DC) 28.8 V
Reverse polarity protection Yes

Input current
Current consumption, max. 25 mA; without sensor supply

Encoder supply
24 V encoder supply
● 24 V Yes
● Short-circuit protection Yes
● Output current, max. 0.7 A; total current of all encoders/channels

Power loss
Power loss, typ. 0.7 W; Without encoder supply voltage

Address area
Address space per module
● Address space per module, max. 16 byte

Hardware configuration
Automatic encoding
● Mechanical coding element Yes
Selection of BaseUnit for connection variants
● 1-wire connection BU type A0, A1
● 2-wire connection BU type A0, A1
● 4-wire connection BU type A0, A1 + potential distributor module

Analog inputs
Number of analog inputs 8; Single-ended
● For current measurement 8
permissible input current for current input (destruction 50 mA
limit), max.
Cycle time (all channels), min. 1 ms; per channel
Input ranges (rated values), currents
● 0 to 20 mA Yes
— Input resistance (0 to 20 mA) 100 Ω; 15 bit
● -20 mA to +20 mA Yes

6ES7134-6GF00-0AA1 Subject to change without notice

Page 2/4 05/21/2020 © Copyright Siemens
 — Input resistance (-20 mA to +20 mA) 100 Ω; 16 bit incl. sign
● 4 mA to 20 mA Yes
— Input resistance (4 mA to 20 mA) 100 Ω; 15 bit
Cable length
● shielded, max. 200 m

Analog value generation for the inputs

Integration and conversion time/resolution per channel
● Resolution with overrange (bit including sign), 16 bit
max.
● Integration time, parameterizable Yes
● Interference voltage suppression for 16.67 / 50 / 60 / 4 800 (16.67 / 50 / 60)
interference frequency f1 in Hz
● Conversion time (per channel) 180 / 60 / 50 / 0.625 (67.5 / 22.5 / 18.75) ms
Smoothing of measured values
● Number of smoothing levels 4; None; 4/8/16 times
● parameterizable Yes

Encoder
Connection of signal encoders
● for voltage measurement No
● for current measurement as 2-wire transducer Yes
— Burden of 2-wire transmitter, max. 650 Ω
● for current measurement as 4-wire transducer Yes

Errors/accuracies
Linearity error (relative to input range), (+/-) 0.01 %
Temperature error (relative to input range), (+/-) 0.005 %/K
Crosstalk between the inputs, min. 50 dB
Repeat accuracy in steady state at 25 °C (relative to 0.05 %
input range), (+/-)
Operational error limit in overall temperature range
● Current, relative to input range, (+/-) 0.5 %
Basic error limit (operational limit at 25 °C)
● Current, relative to input range, (+/-) 0.3 %
Interference voltage suppression for f = n x (f1 +/- 1 %), f1 = interference frequency
● Series mode interference (peak value of 70 dB; With conversion time 67.5 / 22.5 / 18.75 ms: 40 dB
interference < rated value of input range), min.

Interrupts/diagnostics/status information
Diagnostics function Yes
Alarms
● Diagnostic alarm Yes
● Limit value alarm No
Diagnostic messages

6ES7134-6GF00-0AA1 Subject to change without notice

Page 3/4 05/21/2020 © Copyright Siemens
 ● Monitoring the supply voltage Yes
● Wire-break Yes; at 4 to 20 mA
● Short-circuit Yes; Sensor supply to M; module by module
● Group error Yes
● Overflow/underflow Yes
Diagnostics indication LED
● Monitoring of the supply voltage (PWR-LED) Yes; green LED
● Channel status display Yes; green LED
● for channel diagnostics No
● for module diagnostics Yes; green/red DIAG LED

Potential separation
Potential separation channels
● between the channels No
● between the channels and backplane bus Yes
● between the channels and the power supply of No
the electronics

Isolation
Isolation tested with 707 V DC (type test)

Ambient conditions
Ambient temperature during operation
● horizontal installation, min. -30 °C
● horizontal installation, max. 60 °C
● vertical installation, min. -30 °C
● vertical installation, max. 50 °C
Altitude during operation relating to sea level
● Installation altitude above sea level, max. 5 000 m; Restrictions for installation altitudes > 2 000 m, see
manual

Dimensions
Width 15 mm
Height 73 mm
Depth 58 mm

Weights
Weight, approx. 31 g

last modified: 05/09/2020

6ES7134-6GF00-0AA1 Subject to change without notice

Page 4/4 05/21/2020 © Copyright Siemens
SCALANCE XB-000 Introduction 1
___________________

___________________
Network topologies 2

SIMATIC NET
___________________
Description of the device 3

___________________
Mounting 4
Industrial Ethernet switches
SCALANCE XB-000
___________________
Connecting up 5

___________________
Maintenance and
troubleshooting 6
Operating Instructions

___________________
Technical specifications 7

___________________
Approvals 8

___________________
Dimension drawings 9

12/2015
A2B00077300-06
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.

DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.

WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.

CAUTION
indicates that minor personal injury can result if proper precautions are not taken.

NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by personnel qualified for the specific
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Qualified personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:

WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.

Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.

Siemens AG A2B00077300-06 Copyright © Siemens AG 2009 - 2015.

Division Process Industries and Drives Ⓟ 11/2015 Subject to change All rights reserved
Postfach 48 48
90026 NÜRNBERG
GERMANY
