2023 Quick Reference Guide

For detailed operating and safety information, please refer to

your Owner’s Manual.

BASIC OPERATION
Lock/Unlock doors
Remote keyless entry system
1 All doors, fuel filler lid, and the rear gate
1 will be locked.
2 2 The driver’s door and fuel filler lid will be
1
3 unlocked. (To unlock all doors and the rear
2 3 4 gate, briefly press the button again within
PANIC
4 5 seconds.)
3 Press the button to unlock the rear gate.
Remote Access key fob 4 The horn will sound and the hazard warning
transmitter key (if equipped) flashers will flash.
(if equipped)

Keyless access function (if equipped)

All doors, fuel filler lid and the rear gate will be locked/unlocked by the following procedures
carrying the access key fob on your person. Also, an electronic chirp will sound and the
hazard warning flashers will flash. (The driver should always carry the access key fob.)

Side door (front door handles only):

Unlock*

Grip

Lock *Grip the driver’s door handle to unlock the

Touch driver’s door and fuel filler lid. Grip the front
passenger’s door handle to unlock all doors,
Door lock sensor fuel filler lid and the rear gate.

◆ Some functions are available on certain models. ◆ For detailed operating and safety information, please refer to your Owner’s Manual.
Opening rear gate:
Lock

Press

Open

Press

Power rear gate (if equipped):

Carry the access key fob, and press the
power rear gate lock button. It will close
automatically, and the rear gate, all doors
and the fuel filler lid will be locked. Also, the
hazard warning flashers will flash once, and
an electronic chirp will sound once.

Lock

Hands free access function (if equipped)

Hands-free Power Rear Gate function
The Hands-free Power Rear Gate function enables the rear gate to be opened automatically
by holding a hand over the rear emblem.

Carry the access key fob, and move your hand

slowly toward the rear emblem and hold it there until
an electronic chirp sounds.
This function can be deactivated using the Hands-
free Power Rear Gate off switch.

3
 Adjust each component
Driver’s seat
Power seat
1 Forward and backward adjustment
3 2 Seat cushion angle adjustment

5 3 Seat height adjustment

6
4 Seatback reclining adjustment
4
5 2-way lumbar support adjustment (if equipped)

2 3 6 4-way lumbar support adjustment (if equipped)

1
7 Thigh extension (if equipped)

Memory function (if equipped)

Some seat positions and angle of the outside mirrors

SET
can be registered. Register the seat and outside mirror
position with button 1 or 2 or each of the access key
1
fobs and retrieve the outside mirror position and the seat
2
position.

◆ Some functions are available on certain models. ◆ For detailed operating and safety information, please refer to your Owner’s Manual.
 Tilt/telescopic steering wheel

2 1 Adjust the seat position and pull the tilt/

telescopic lock lever down.
2 Move the steering wheel to the desired level.
2 3 Pull the lever up to lock the steering wheel in
3 place.
Make sure that the steering wheel is securely
locked by moving it up and down, and forward and
1 backward.

Remote control mirror switch/Power folding mirror switch (if equipped)

Ignition switch must be in ACC or ON position.
1

1 Select side to adjust.

2 To adjust the mirror, move the switch in the
direction you want to move the mirror.
2
3 To fold the outside mirrors, press the switch.

5
 Start/Stop engine
Push-button ignition switch (if equipped)
To start engine:
STEP1: Carry the access key fob, and sit in the driver’s seat.
STEP2: Apply the parking brake.
Operation STEP3: Shift the select lever in the P position.
indicator
STEP4: Depress the brake pedal until the indicator on
the push-button ignition switch turns green.
STEP5: While depressing the brake pedal, press the
push-button ignition switch.

To stop engine:
STEP1: Stop the vehicle completely.
STEP2: Move the select lever to the P position.
STEP3: Press the push-button ignition switch.

Change of the power supply (Without starting engine)

Every time the button is pressed without depressing the brake pedal, the power is switched
in the sequence of OFF➞ACC➞ON➞OFF.
OFF (Turned off) ACC (Orange) ON (Orange)

Ignition switch (if equipped) Electronic parking brake switch

Release

Apply

The key can be turned from ACC to LOCK

only when the key is pushed in while turning
it and the select lever is in the P position.
6

◆ Some functions are available on certain models. ◆ For detailed operating and safety information, please refer to your Owner’s Manual.
Operate Select lever
Continuously variable transmission
Select lever button

With the brake pedal depressed, shift while

pressing the button in

Shift while pressing the button in

Shift without pressing the button

M = Manual mode:
With the vehicle either moving or stationary, move the
Downshift Upshift select lever from the D position to the M position to
select the manual mode.
Shift paddle:
Gearshifts can be performed using the shift paddle
behind the steering wheel.

Fuel
Fuel filler lid

1 Stop the vehicle and turn the ignition switch to the

OFF position and turn off all the other electrical
components. The fuel filler lid will be unlocked
3 when the ignition switch is turned to the OFF
position.
2 Push the rear side of the fuel filler lid.
3 The fuel filler lid opens automatically.
2 Open it further by hand.

7
 MAIN PARTS AND OPERATION
A B C M

H G D E F J

A
Headlight switch/Turn signal lever/Front fog light switch
3 1 Headlights
2 Headlight flasher, High/Low beam change (dimmer)

High Beam Assist Function

1
2 The high beam assist function automatically changes
the headlight from high beam to low beam (or vice versa).
The high beam assist function is activated when:
3
1. The light control switch is in the AUTO position and
the low beam headlights are on automatically.
2. The turn signal lever is pushed forward.
When the high beam assist
function is activated, the indicator
on the combination meter will High beam assist
illuminate. indicator

3 Turn signal
4 Front fog lights
To turn on the front fog lights, rotate dial to .
4
Front fog lights operate only when headlight switch is in...
- position.
- AUTO position and the headlights are on.
8

◆ Some functions are available on certain models. ◆ For detailed operating and safety information, please refer to your Owner’s Manual.
B
Wiper and washer switch
1 1 Windshield wiper
To operate the wiper, rotate knob to;
2 : Mist (for a single wipe)
: Off
: Intermittent
: Low speed
: High speed
3 2 Wiper intermittent time control
3 Windshield washer
To wash the windshield, pull the wiper control lever
4 toward you.

4 Rear window wiper and washer

To operate the wiper, rotate knob to;
: Continuous
: Intermittent
: Off
: Washer
Rotate knob to . The washer fluid sprays and the
wiper operates.

C
Hazard warning flasher switch
To turn on the hazard warning flasher, press the switch.
Use the hazard warning flasher when you have to park
in emergency conditions.

D
Power rear gate button (if equipped)

Press and hold

the button.

9
 E
Illumination brightness control dial
Turn the dial to adjust the illumination brightness of the
instrument panel.
When the control dial is turned fully upward, the
illumination brightness becomes the maximum and the
automatic dimming function does not work at all.

*The design may be slightly different from the

illustration depending on the models.

F
Hands - free Power Rear Gate G
Hood release knob
off switch (if equipped)

Pull

H
Power window switches
1 For front left window
1 2 For front right window

3
3 For rear left window
5 4 For rear right window
5 Lock switch
2

I Power door locking switch

1 To lock all doors, the rear gate and

fuel filler lid
2 To unlock all doors, the rear gate
1 2 and fuel filler lid
10

◆ Some functions are available on certain models. ◆ For detailed operating and safety information, please refer to your Owner’s Manual.
 J Front view monitor switch (if equipped)
Press the front view monitor switch to change over to
the camera screen.

Front View Monitor

The image from the camera mounted inside the front
grill is displayed on the center information display.

K
Heated Steering Wheel system (if equipped)
The Heated Steering Wheel system warms the steering
wheel at a constant temperature.

Pull

L
Cruise Control buttons
EyeSight is a driving support system that uses a range of functions to assist the driver in
making decisions in order to provide for more safe and comfortable driving and to reduce
driver fatigue.

1 (Following distance setting) switch

1 2 (CRUISE) switch
2
3 RES/+ switch
3 4
4 SET/- switch
1 5
5 (Lane Centering) switch

11
 M
Climate Control/Defroster/Defogger and deicer
Touch the climate control screen to display the detailed settings of temperature and air flow
adjustment on the screen.

▼Dual 7.0-Inch Display Models

1 Defrosting:
3 Press the defroster button to defrost or
dehumidify the windshield and front door
windows.

2 Defogger and deicer:

1 4 Press the button to turn on rear window
defogger, outside mirror defogger and wiper
2
deicer (if equipped). The function will
automatically shut off after approximately
▼11.6-Inch Display Models 15 minutes.

3 Climate control screen

3
4 Temperature control
5 Passenger’s side temperature control

1 2 6 Driver’s side temperature control

6 5

*The display maybe slightly different from the

illustration depending on the models.

Child safety locks

Located on the edge of each rear door.
When the lever is in the LOCK position, the rear
door cannot be opened from the inside.

12

◆ Some functions are available on certain models. ◆ For detailed operating and safety information, please refer to your Owner’s Manual.
 Front seat shoulder belt anchor height
1 To lower:
Push and hold the upper part of the anchor and
1 2 slide it down.
2 To raise:
Push and hold the upper part of the anchor and
slide it up.

Moonroof switch (if equipped)

Tilting lay down (Slide) Sliding Close

tilt up (Press)
Open

Front Seat Heater and Ventilation (if equipped)

Front Seat Heater

Dual 7.0-Inch Display Models
HIGH:
3 indicator lights are
illuminated.
Touch MID:
11.6-Inch Display Models 2 indicator lights are
or illuminated.
LOW:
1 indicator light is
Front Seat Ventilation (if equipped) illuminated.
OFF:
All indicator lights turn off.

*The display maybe slightly different from the

illustration depending on the models.
13
 FUNCTION FOR MORE COMFORTABLE DRIVE
A A B

A
Combination meter display (color LCD)

Activating Deactivating 1 Meter information screen

the EyeSight the EyeSight 2 Warning screen/Basic screen
system system
3 EyeSight screen
1
4 Digital speed screen
2
5 Telltale screen
3
6 Select lever/gear position indicator
4
5 7 X-MODE indicator/SI-DRIVE indicator
8 Odometer/Double trip meter
6 7 8 6 7 8
Control switch: By operating or of the control
switch, the screens can be switched.
When the switch is pulled toward
you, the message marked with on
Control the display will be recalled.
switch

14

◆ Some functions are available on certain models. ◆ For detailed operating and safety information, please refer to your Owner’s Manual.
B
Center Information Display (CID)
All information is displayed on the center information display, including vehicle settings,
vehicle status, navigation system (if equipped) operation, audio operation, and air
conditioning operation.
The settings of the on-board systems can be changed by operating the center information
display.
Useful messages, such as reminders, weather information (if equipped) and traffic
information (if equipped) may interrupt the current screen and appear on the display
accompanied by a beep. Take the proper action according to the message.

Basic screens
▼11.6-Inch Display Models
2 1 HOME icon
3 2 Status bar
3 Information bar
4 Main screen
5 Manage device icon
4
6 Driver profiles icon
7 Climate control screen
1 5 8 Car settings icon
8 6 9 Auto Start Stop ON/OFF icon
9 7

▼Dual 7.0-Inch Display Models

2 A) Upper display
B) Lower display
A
3 1 HOME button
2 Status bar
1 3 Upper main screen
RADIO MEDIA PHONE APPS

4 Lower main screen

5 Climate control screen
4
B

5
*The display maybe slightly different from the
illustration depending on the models.

15
 Various driving support systems
The following item can also be turned ON/OFF by operating the center information display.

1 (HOME) 2 (Settings) 3 Car Touch the preferred icon.

2
2

RADIO
1
MEDIA PHONE APPS

11.6-Inch Display Dual 7.0-Inch Display

*The display maybe slightly different from the illustration depending on the models.

Auto Start Stop

The Auto Start Stop system is designed to automatically stop and restart the engine when the
vehicle is stationary for a short period of time (while waiting for a traffic light or in a traffic jam)
after the engine has warmed up.

BSD/ RCTA (if equipped)

The BSD/ RCTA consists of rear corner radars with Blind
Spot Detection and Rear Cross Traffic Alert.
These functions are the systems that detect objects
and vehicles to the rear and draw attention to the driver
when changing a lane or when driving in reverse.

16

◆ Some functions are available on certain models. ◆ For detailed operating and safety information, please refer to your Owner’s Manual.
 Steering Responsive Headlight (SRH) system
SRH is a function that automatically moves the
headlight beam to the left or right in accordance with
the steering angle and vehicle speed. This function
helps to improve the visibility at night by illuminating the
road ahead at corners and intersections.

Not activated Activated

X-MODE
X-MODE is the integrated control system of the engine, AWD and Vehicle Dynamics Control
system, etc. for driving with bad road conditions.
Using X-MODE, you can drive more comfortably even in slippery road conditions including
uphill and downhill.

Vehicle Dynamics Control

It may be useful to temporarily deactivate the Vehicle Dynamics Control system to escape
from the following situations.
- A standing start on a steeply sloping road with a snowy, gravel-covered, or
otherwise slippery surface
- Extrication of the vehicle when its wheels are stuck in mud or deep snow
Do not deactivate the system except when absolutely necessary.

Driver Monitoring System (if equipped)

The Driver Monitoring System monitors possible cases when the driver is not paying attention
to the forward direction, and also recognizes individual users.
This system warns the driver of inattentive/drowsy driving, and can support safe and
comfortable driving.

EyeSight
EyeSight is a driving support system that uses a range of functions to assist the driver in
making decisions in order to provide for more safe and comfortable driving and to reduce
driver fatigue.

17
 Reverse Automatic Braking (RAB) system (if equipped)
Reverse Automatic Braking (RAB) is a system
designed to help avoid collisions or reduce collision
damage when reversing the vehicle.
If a wall or an obstacle is detected in the reversing
direction, the system will notify the driver with a
warning sound and may activate the vehicle’s brakes
automatically.

The system detects objects

using sonar sensors installed in
the rear bumper.

SUBARU STARLINK (if equipped)

The SUBARU STARLINK system features using
just two buttons to provide 24/7/365 access to
STARLINK advisors who can provide help in an
emergency or summon roadside assistance.

18

◆ Some functions are available on certain models. ◆ For detailed operating and safety information, please refer to your Owner’s Manual.
 MAIN WARNING AND INDICATOR LIGHTS
Some warning/indicator lights illuminate for a few seconds in order to check themselves
when the ignition switch is turned ON.

Warning lights
Refer to your Owner’s Manual for countermeasures when each warning light comes on.
If necessary, consult your authorized SUBARU dealer.
Seatbelt warning/Front passenger’s seatbelt warning Rear seatbelt warning
Remind the driver and front Remind the rear passenger to
passenger to fasten seatbelt. fasten seatbelt.

Malfunction indicator (Check Engine) Charge warning

Engine/Emission control system Charging system malfunction.
malfunction.

Oil pressure warning Engine low oil level warning

The engine oil pressure is too The engine oil level decreases to
low. the lower limit.

All-Wheel Drive warning SRS airbag system warning

Tires of different diameter fitted/ SRS airbag system and/
air pressure excessively low. or seatbelt pretensioners
malfunction.

Power steering warning AT OIL TEMP warning

The electric power steering Transmission fluid temperature
system malfunction. is too hot./Transmission control
system malfunction.

Low fuel warning RAB warning

Fuel tank is nearly empty. Refill Reverse Automatic Braking
fuel immediately. (RAB) system malfunctions.

Access key warning EyeSight warning

The access key fob is not inside The EyeSight systems
the vehicle. For other situations, malfunction.
refer to your Owner’s Manual.

19
 Brake system warning
Electronic parking brake system malfunction/Electronic brake booster
malfunction/Brake fluid level/EBD System malfunction (ABS warning light
illuminates simultaneously).

ABS warning
Anti-lock Brake System malfunction/EBD System malfunction.
(Brake System warning light illuminates simultaneously).

Vehicle Dynamics Control warning/Vehicle Dynamics Control operation indicator

Warning : Vehicle Dynamics Control system malfunction.
Indicator : Flashes during activation of the skid suppression function and the
traction control function.

Icy road surface warning

When the outside temperature becomes 3°C (37°F) or less, the icy road surface
warning will illuminate to inform the driver that the road surface may be frozen.

Auto Start Stop warning

Auto Start Stop system malfunction or the Auto Start Stop system is not operating
under some vehicle condition. For details, refer to your Owner’s Manual.

Windshield washer fluid warning BSD/RCTA warning

The fluid level in the windshield Blind Spot Detection/Rear
washer fluid tank decreases to Cross Traffic Alert (BSD/RCTA)
the lower limit. malfunction.

Engine hood open warning Driver Monitoring System warning

Illuminates if the engine hood is The Driver Monitoring System
not fully closed. malfunction.

LED headlight warning Steering Responsive Headlight warning

The LED headlights malfunction. The Steering Responsive
Headlight system malfunction.

Automatic headlight beam leveler warning Wide angle mono camera warning
Automatic headlight beam leveler The wide angle mono camera
malfunction. malfunction.

20

◆ Some functions are available on certain models. ◆ For detailed operating and safety information, please refer to your Owner’s Manual.
 Indicator lights
The following indicators show the current status of your car. Refer to your Owner’s Manual
for more information.

Turn signal indicator Headlight indicator

High beam indicator Front fog light indicator

Security indicator Door open indicator

BSD/RCTA OFF indicator Auto Vehicle Hold indicator

Hill descent control indicator X-MODE indicator

High beam assist indicator RAB OFF indicator

Electronic parking brake

Auto Start Stop indicator
indicator

Automatic Emergency
Auto Start Stop OFF indicator
Steering OFF indicator

Vehicle Dynamics Control OFF OFF

Front passenger’s frontal
indicator ON
airbag ON/OFF indicator

Pre-Collision Braking System Lane Departure Warning OFF

OFF indicator indicator

Steering Responsive Headlight Auto Start Stop No Activity

OFF indicator Detected Indicator

21
 Driver Monitoring System Driver Monitoring System
operation indicator OFF indicator

Driver Monitoring System Adaptive Cruise Control

Temporary Stop indicator indicator

EyeSight temporary stop

Lane Centering indicator
indicator

Sonar audible alarm OFF Wide angle mono camera OFF

indicator indicator

22

◆ Some functions are available on certain models. ◆ For detailed operating and safety information, please refer to your Owner’s Manual.
 Notes

23
 subaru.ca

All illustrations, specifications, features and photographs contained in this brochure are based on product information available at the time of
its printing, and may not be completely accurate following its publication. Colours shown may vary due to reproduction variations in the printing
process, and some vehicle parts cannot be shown in certain photographs. Subaru Canada, Inc. reserves the right to discontinue or make changes
at any time, without notice or incurring obligations, to colours, materials, equipment, accessories, features, specifications and models, or to change
their prices. Please visit our Web site for the latest information and specifications. For detailed operating and safety information, please consult
your Owner’s Manual. For complete details on product updates, warranties or the Subaru C.A.R.E. program, please contact your Subaru dealer.
Outback and Subaru are registered trademarks. Printed in Canada. © 2022 Subaru Canada, Inc. 2023 model year.

Environmental Management System (EMS)

ISO 14001:2015 certified by SGS
www.subaru-earth.com

SUBARU CANADA, INC./SUBARU CORPORATION

07.22 SBQRGOUT23E
