GETINGE ED-FLOW AER RANGE

SPARE PARTS
ED-FLOW - TOUTES / ALL OPTIONS - 2016-09 2 / 27
 DOUBLE DOOR BODYWORK
Label Reference Designation Length Drawing Number
1 04050004 HORIZONTAL TRIM FOR ED-FLOW
2 04050005 VERTICAL LEFT TRIM FOR ED-FLOW
3 04050006 VERTICAL RIGHT TRIM FOR ED-FLOW
4 05010081 SCREW TRHC 5X10 ISO 7380
5 05020021 SCREW TFZ 5x25
6 05020022 SELF-DRILLING TAPPING SCREW TFZ 4.8x16
7 05030031 SCREW TC 4x12
8 05030047 SCREW STF M5x30 FLAT END
9 06010006 WING NUT DIAM.5
10 11060008 KNURLED SCREW M5 X 15
11 13010017 EMERGENCY BUTTON LABEL
12 13010064 EMERGENCY STOP LABEL
13 14050014 SEAL FOR CHAMBER CHANNEL
14 14050014 SEAL FOR CHAMBER CHANNEL
15 22050035 COUPLER F/F RJ45
16 31040012 ERTACETAL WASHER ØEXT. 10 ØINT. 1,6 TH.
17 46010132 SWITCH FOR FOOTPEDAL 46010072
18 46020021 FRONT PANEL LOCKING
19 46020028 DOOR HANDLE
20 46030064 STOPGAP 5/8´´
21 46030171 PLUG FOR CRUCIFORM SCREW M5
22 48010009 FRONT BUMPER F5
23 60107520 CENTRAL PLINTH F5 RAL 5002
24 60107521 LATERAL PLINTH F5
25 60107530 REMOVABLE TOP PANEL F5
26 60107582 F5 WATER AND POWER SUPPLY PLINTH
27 60107632 ASSEMBLY BOTTOM DOOR RHS LOADING
28 60107633 ASSEMBLY BOTTOM DOOR LHS LOADING
29 60107634 ASSEMBLY BOTTOM DOOR RHS UNLOADING
30 60107635 ASSEMBLY BOTTOM DOOR LHS UNLOADING
31 70010824 PLATE PROFILE EXTREMITY CLIP
32 70010836 EMERGENCY STOP
33 70010837 FOOT PEDAL SYSTEM
34 70010837 FOOT PEDAL SYSTEM
35 70020576 MODULABLE BRACKET
36 80011622 CONNECTION ELEC. DOOR PROTECTION SHEET
37 80011673 PLATE 304 UNLOADING LEFT DOOR LOCK
38 80011681 SEALING 2843 EQ260 CNS S 2000-N - L160
39 80011685 BLACK PVC LIP SEAL TYPE V 10X7 - L510

ED-FLOW - TOUTES / ALL OPTIONS - 2016-09 3 / 27

ED-FLOW - TOUTES / ALL OPTIONS - 2016-09 4 / 27
 SINGLE DOOR BODYWORK
Label Reference Designation Length Drawing Number
1 04090018 EDGE PROTECTION
2 05010081 SCREW TRHC 5X10 ISO 7380
3 05020021 SCREW TFZ 5x25
4 05030031 SCREW TC 4x12
5 05030047 SCREW STF M5x30 FLAT END
6 06010006 WING NUT DIAM.5
7 11060008 KNURLED SCREW M5 X 15
8 13010017 EMERGENCY BUTTON LABEL
9 13010064 EMERGENCY STOP LABEL
10 14050014 SEAL FOR CHAMBER CHANNEL
11 31040012 ERTACETAL WASHER ØEXT. 10 ØINT. 1,6 TH.
12 46010132 SWITCH FOR FOOTPEDAL 46010072
13 46020021 FRONT PANEL LOCKING
14 46020028 DOOR HANDLE
15 46030171 PLUG FOR CRUCIFORM SCREW M5
16 46030448 DECORATIVE PLUG Ø5.1
17 48010009 FRONT BUMPER F5
18 60107520 CENTRAL PLINTH F5 RAL 5002
19 60107521 LATERAL PLINTH F5
20 60107530 REMOVABLE TOP PANEL F5
21 60107632 ASSEMBLY BOTTOM DOOR RHS LOADING
22 60107633 ASSEMBLY BOTTOM DOOR LHS LOADING
23 60107634 ASSEMBLY BOTTOM DOOR RHS UNLOADING
24 60107635 ASSEMBLY BOTTOM DOOR LHS UNLOADING
25 60107780 REMOVABLE COVER UPPER
26 60107783 COVER REMOVABLE BOTTOM
27 70010836 EMERGENCY STOP
28 70010837 FOOT PEDAL SYSTEM
29 70010837 FOOT PEDAL SYSTEM
30 70020576 MODULABLE BRACKET
31 80011622 CONNECTION ELEC. DOOR PROTECTION SHEET
32 80011673 PLATE 304 UNLOADING LEFT DOOR LOCK
33 80011681 SEALING 2843 EQ260 CNS S 2000-N - L160
34 80011685 BLACK PVC LIP SEAL TYPE V 10X7 - L510

ED-FLOW - TOUTES / ALL OPTIONS - 2016-09 5 / 27

ED-FLOW - TOUTES / ALL OPTIONS - 2016-09 6 / 27

Label Reference
1 04050005
2 04050006
3 04050007
4 04050008
5 04050009
6 05010027
7 05040001
8 09020002
9 60107640
10 70010824
11 70010825
ED-FLOW - TOUTES / ALL OPTIONS - 2016-09
WASHERS TRIM OPTION
Designation Length Drawing Number
VERTICAL LEFT TRIM FOR ED-FLOW
VERTICAL RIGHT TRIM FOR ED-FLOW
CENTRAL TOP TRIM
FRONT PLATE RIGHT TOP TRIM
FRONT PLATE LEFT TOP TRIM
SCREW TH 5x12
SCREW TRL 4x8
WASHER M 5
CENTRAL LINK PLINTH FOR 2 WASHERS
PLATE PROFILE EXTREMITY CLIP
PLATE PROFILE MIDDLE CLIP
7 / 27
ED-FLOW - TOUTES / ALL OPTIONS - 2016-09 8 / 27
 BASIN
Label Reference Designation Length Drawing Number
1 03170012 TEMPERED GLASS 72X72X5
2 05020003 SCREW TF 3x16
3 05020023 SCREW TFHC M4 X 20
4 05030032 SCREW TC 4x16
5 05080027 SCREW TRHC WITH FLANGE 5x20
6 06030011 NUT HU 14
7 06030020 NUT HU 5
8 06030038 H NUT G1/2'' INOX
9 06030041 SS NUT 7/16 24
10 06050026 SELF-LOCKING NUT M3
11 09020014 WASHER M14
12 09040009 FAN WASHER AZ 5
13 10020027 COLLAR 021.0-706R 17.8 A 21
14 14020050 GYLON 3504 6x14x1.6 SEAL
15 14020060 GYLON 3500 FLAT SEAL 13x18x1.6
16 14020066 GYLON 3504 FLAT SEAL 58x48x4.8
17 14020067 GYLON SEAL FOR ROTATIVE ARM
18 14020071 GYLON SEALING FOR PY SPRINKLERS
19 14020080 PLATE SEALING 14X6X1 DF801
20 14020105 SEAL Ø18-2xØ34x1 - EQ280 - BLACK
21 14020106 SEAL Ø18-2xØ34x1 - EQ280 - BROWN
22 14020107 SEAL Ø18-2xØ34x1 - EQ280 - YELLOW
23 14020108 SEAL Ø18-2xØ34x1 - EQ280 - GREEN
24 14020109 SEAL Ø18-2xØ34x1 - EQ280 - ORANGE
25 14030065 DF801 44x4 O-RING SEAL
26 14030069 13.1x1.6 EPDM O-RING SEAL
27 14030092 DF801 21.30 X 3.60 O-RING SEAL
28 14030110 O-RING SEAL DF801 Ø91X3
29 14050010 CHAMBER SEAL F5
30 14080003 LAMP GASKET
31 17010030 CHAMBER BASE FILTER MIDDLE 270 µm - Ø0.1
32 17010031 CHAMBER BASE FILTER SUPPORT
33 17030021 SHOULDER SCREW FOR CHAMBER FILTER
34 17030028 NUT 304L BASIN FILTER
35 19020081 GLASS FUSE F8AL 250V 5x20mm
36 19030020 IN-LINE FUSE HOLDER 5x20mm - 10A
37 20100169 HAMOGENE BULB
38 21010053 POLYPRO RING Ø58.5XØ49X7.5
39 22030074 2 POINTS CONNECTOR
40 25010053 TORAIDAL TRANSFORMER 230/111.5V 100 VA
41 27050030 RFID READER 40x40 XGCS4901201 (TSX34)
42 28040101 2XPT100 B PROBE LG40 WITH SHIELD
43 31020001 SPRAY HEAD 360° - GETINGE AER
44 31040053 ROTATIVE WASHING BALL CONNECTION
45 33080268 BHU2202 COUPLER
46 33080268 BHU2202 COUPLER
47 33080272 PMC420212 MALE CONNECTION
48 33080273 CHAMBER CONNECTION FOR TRANSPARENT HOSE
49 33080296 SMF0212 FEMALE COUPLER
50 33080326 BHU2204 COUPLER
51 33130078 PVC TIP GUARDS Ø3.5MM
52 38010119 PVDF BODY VALVE 2-2 NC - DN40 G1 1/2
53 38100089 COMPLET HYDRAULIC KIT
54 46020157 TIGHTEN RING FOR O-RING SEAL 24X1
55 46030110 TAG FIXING PLOT
56 46030169 ROLLER FOR ARM SUPPORT
57 46030326 PROTECTIVE CAP
58 60021802 70 DIAM. NUT
59 60107518 CONSOL LAMP
60 70091497 GUIDE PIN
61 70091498 GUIDE PIN
62 70120116 CHAMBER BASE FILTER UPPER
63 70120117 POKA-YOKE FILTER KIT
64 80011605 CONNECTION CONNECTOR ARM SUPPORT
65 80011638 SILICONE HOSE Ø3xØ7 70 Sh +/- 5 - L30
66 80011639 YELLOW SILICON HOSE Ø4xØ8 - L180
67 80011640 BROWN SILICON HOSE Ø4xØ8 - L190
68 80011641 ORANGE SILICON HOSE Ø4xØ8 - L190
69 80011642 GREEN SILICON HOSE Ø4xØ8 - L190
70 80011643 BLACK SILICON HOSE Ø4xØ8 - L190
71 80011644 SILICONE HOSE Ø3xØ7 70 Sh +/- 5 - L140
72 80011644 SILICONE HOSE Ø3xØ7 70 Sh +/- 5 - L140
73 80011690 KIT TRAY GUIDE SUPPORT ASSY

ED-FLOW - TOUTES / ALL OPTIONS - 2016-09 9 / 27

ED-FLOW - TOUTES / ALL OPTIONS - 2016-09 10 / 27
 DOOR FOR VERSION DOUBLE DOOR
Label Reference Designation Length Drawing Number
1 03170011 F5 GLASS DOOR
2 05010006 SCREW TH 6x20
3 05010028 SCREW TH 5x20
4 05010032 SCREW TH 5x8
5 05010078 SHOULDER SCREW M6 X 25 Ø8 X 16
6 05020002 SCREW TF M3x10
7 05030039 SCREW TCL 5x40
8 05030046 SCREW TC M4x18
9 05080017 SCREW TCHC 5x20
10 06030044 HEXAGON THIN NUT M6
11 06050028 SELF-LOCKING NUT M5 A2
12 09020001 WASHER M 4
13 09020002 WASHER M 5
14 09020004 WASHER M 6
15 09030002 LARGE WASHER L 5
16 10020042 COLLAR 056.0-706R 51.5 A 53
17 12010027 TRACTION SPRING Ø13 X 35 X 1.4
18 12020049 GLASS DOOR SPRING F5
19 12030012 SPRING LOCK SCREW NEO MOTOR
20 14020052 BEARING SEAL 3504 14X4.6X0.8
21 20020017 LEVEL SWITCH
22 20020029 OPTIC SENSOR
23 20100163 CONNECTOR FOR OPTIC SENSOR
24 35010055 ASSEMBLY GLASS DOOR JACK
25 35100043 JACK SENSOR
26 46010081 SPACER FOR ROLLER
27 46010083 GLASS DOOR BEARING
28 46030134 SCREW CAP SERIE 006-K1 MS
29 46030135 WASHER SERIE 006-R1 M5
30 46030139 BEARING CLIP IGLIDUR MCM 10 02
31 46030157 NON VIBRATION FASTENING FLEX-LOC
32 46030185 ERTACETAL WASHER Ø13 x Ø5 x 12
33 46040052 GLASS DOOR CABLE
34 46040077 NEO H ENGINE 35N/m 220V 60Hz
35 46040082 TUBULAR MOTOR Ø45-16 TR/MIN 15 NM
36 60021817 ASSEMBLY GLASS DOOR FRAME
37 60107644 DIABOLO FOR DOOR LOCKING DEVICE
38 60107647 LOWER SENSOR SUPPORT - MIRROR
39 60107648 LOWER SENSOR SUPPORT
40 70010885 PLATE PMMA WITH PROTECTION
41 70020560 GLASS DOOR MOTOR ROLL
42 70020572 ASSEMBLY GLASS DOOR ED-FLOW
43 70020573 GLASS DOOR FITTING WITH AXIS
44 70020588 LEFT STRIKER LOCKING KIT
45 70020589 RIGHT STRICKER LOCKING KIT
46 80011691 KIT SENSOR HIGH POSITION - 1
47 80011692 KIT SENSOR HIGH POSITION - 2
48 80011693 KIT NEO ENGINE SUPPORT

ED-FLOW - TOUTES / ALL OPTIONS - 2016-09 11 / 27

ED-FLOW - TOUTES / ALL OPTIONS - 2016-09 12 / 27
 DOOR FOR VERSION SINGLE DOOR
Label Reference Designation Length Drawing Number
1 03170011 F5 GLASS DOOR
2 05010006 SCREW TH 6x20
3 05010028 SCREW TH 5x20
4 05010032 SCREW TH 5x8
5 05010078 SHOULDER SCREW M6 X 25 Ø8 X 16
6 05020002 SCREW TF M3x10
7 05030039 SCREW TCL 5x40
8 05030046 SCREW TC M4x18
9 05080017 SCREW TCHC 5x20
10 06030044 HEXAGON THIN NUT M6
11 06050028 SELF-LOCKING NUT M5 A2
12 09020001 WASHER M 4
13 09020002 WASHER M 5
14 09020004 WASHER M 6
15 09030002 LARGE WASHER L 5
16 10020042 COLLAR 056.0-706R 51.5 A 53
17 12010027 TRACTION SPRING Ø13 X 35 X 1.4
18 12020049 GLASS DOOR SPRING F5
19 12030012 SPRING LOCK SCREW NEO MOTOR
20 14020052 BEARING SEAL 3504 14X4.6X0.8
21 20020017 LEVEL SWITCH
22 20020029 OPTIC SENSOR
23 20100163 CONNECTOR FOR OPTIC SENSOR
24 35010055 ASSEMBLY GLASS DOOR JACK
25 35100043 JACK SENSOR
26 46010081 SPACER FOR ROLLER
27 46010083 GLASS DOOR BEARING
28 46030134 SCREW CAP SERIE 006-K1 MS
29 46030135 WASHER SERIE 006-R1 M5
30 46030139 BEARING CLIP IGLIDUR MCM 10 02
31 46030157 NON VIBRATION FASTENING FLEX-LOC
32 46030185 ERTACETAL WASHER Ø13 x Ø5 x 12
33 46040052 GLASS DOOR CABLE
34 46040077 NEO H ENGINE 35N/m 220V 60Hz
35 46040082 TUBULAR MOTOR Ø45-16 TR/MIN 15 NM
36 60021817 ASSEMBLY GLASS DOOR FRAME
37 60107644 DIABOLO FOR DOOR LOCKING DEVICE
38 60107647 LOWER SENSOR SUPPORT - MIRROR
39 60107648 LOWER SENSOR SUPPORT
40 70010886 OPAQUE PLATE PMMA WITH PROTECTION
41 70020560 GLASS DOOR MOTOR ROLL
42 70020572 ASSEMBLY GLASS DOOR ED-FLOW
43 70020573 GLASS DOOR FITTING WITH AXIS
44 70020588 LEFT STRIKER LOCKING KIT
45 70020589 RIGHT STRICKER LOCKING KIT
46 80011691 KIT SENSOR HIGH POSITION - 1
47 80011692 KIT SENSOR HIGH POSITION - 2
48 80011693 KIT NEO ENGINE SUPPORT

ED-FLOW - TOUTES / ALL OPTIONS - 2016-09 13 / 27

ED-FLOW - TOUTES / ALL OPTIONS - 2016-09 14 / 27
 AIR BREAK TANK
Label Reference Designation Length Drawing Number
1 06030020 NUT HU 5
2 06030045 HEXAGON THIN NUT M5
3 06050028 SELF-LOCKING NUT M5 A2
4 10010004 ADJUSTABLE CLIP 304 50/70
5 10020026 COLLAR 033.1-706R 29.9 A 33.1
6 10020039 COLLAR 062.0-706R
7 10020056 COLLAR Ø31.4 TO 34.6
8 13010083 CAUTION HOT SURFACE LABEL
9 14020081 SEALING DF 801 10X15X2
10 15010003 OVERFLOW EXTENSIBLE HOSE
11 15010045 EMPTYING HOSE 2.50M
12 18020003 GROMMET
13 19020080 F 2A UL FUSE 5x20
14 20030103 RELAY 1 OF 24VDC 7.5A
15 20060012 SAFETY MODULE 3F 24VCC
16 20060033 POWER STATIC RELAY - BI-PHASE 2X35A
17 20100143 1 RT POWER RELAY SUPPORT
18 22040002 JONCTION BLOC
19 22040021 EARTH TERMINAL 12 INPUT
20 22040033 EARTH THERMINAL 21 INPUTS
21 22040113 SPRING PLUG D2.5/5
22 22040114 EXTERNAL FLANGE
23 22040132 FUSE HOLDER TERMINAL BLOCK FUSE 5x20mm
24 22040133 END SECTION COVER M4/8.SF
25 24010001 HEATING ELEMENT 3000 W
26 24100019 FASTENING Ø8.5 FOR HEATER 24010001
27 28010016 LEVEL SWITCH
28 28040049 THREE PHASE SAFETY THERMOSTAT UL 160
29 28040101 2XPT100 B PROBE LG40 WITH SHIELD
30 28050036 CONVERTER SET FOR CONDUCTIV. PROBE K=1.0
31 29020011 2 DIRECTION FLOW REGULATOR
32 32020014 PVDF SEAL - NON RETURN VALVE
33 33050099 T CONNECTOR -TUBE ØINT 4MM
34 33070136 ELBOW CONNECTOR G1/8-TUBE ØINT 4MM
35 33080307 CONNECTOR M5 - TUBE ØINT 4MM
36 34050007 TUBE 4MM Ø INTERNAL BLUE 50
37 34050007 TUBE 4MM Ø INTERNAL BLUE 200
38 34050007 TUBE 4MM Ø INTERNAL BLUE 200
39 34050007 TUBE 4MM Ø INTERNAL BLUE 200
40 34050007 TUBE 4MM Ø INTERNAL BLUE 200
41 34050007 TUBE 4MM Ø INTERNAL BLUE 780
42 34050007 TUBE 4MM Ø INTERNAL BLUE 780
43 34050007 TUBE 4MM Ø INTERNAL BLUE 780
44 34050007 TUBE 4MM Ø INTERNAL BLUE 780
45 34050007 TUBE 4MM Ø INTERNAL BLUE 550
46 34050007 TUBE 4MM Ø INTERNAL BLUE 380
47 34050007 TUBE 4MM Ø INTERNAL BLUE 830
48 34050007 TUBE 4MM Ø INTERNAL BLUE 650
49 34050007 TUBE 4MM Ø INTERNAL BLUE 850
50 34050007 TUBE 4MM Ø INTERNAL BLUE 830
51 34050007 TUBE 4MM Ø INTERNAL BLUE 1030
52 34050007 TUBE 4MM Ø INTERNAL BLUE 650
53 34050007 TUBE 4MM Ø INTERNAL BLUE 510
54 34050007 TUBE 4MM Ø INTERNAL BLUE 630
55 34050007 TUBE 4MM Ø INTERNAL BLUE 1030
56 34050007 TUBE 4MM Ø INTERNAL BLUE 550
57 34050007 TUBE 4MM Ø INTERNAL BLUE 830
58 34050007 TUBE 4MM Ø INTERNAL BLUE 850
59 34050007 TUBE 4MM Ø INTERNAL BLUE 630
60 34050007 TUBE 4MM Ø INTERNAL BLUE 510
61 34050007 TUBE 4MM Ø INTERNAL BLUE 830
62 35100038 4 PORT SOLENOID VALVE MONO 5/2 230V
63 37010230 PNEUMATIC VALVE DN10 - NC
64 38010015 ELECTRICAL VALVE NC L377 - 50/60 Hz
65 46030195 SILENT BLOCK SUPPORT F/F
66 60022006 COVISIL SEAL 14040032 - Lg 235mm
67 60040558 SILICONE HOSE Ø22 X Ø31 - LG 60mm +/-2mm
68 70040365 KIT FOR ED-FLOW EMPTYING PUMP
69 80011653 TRANSPARENT PTFE HOSE Ø4XØ6 - L900
70 80011654 GREY SILICON SEAL 15X7 - L210
71 80011665 HOSE SILICON Ø50x62 - L170 +/-5MM

ED-FLOW - TOUTES / ALL OPTIONS - 2016-09 15 / 27

ED-FLOW - TOUTES / ALL OPTIONS - 2016-09 16 / 27
 TANK CASING
Label Reference Designation Length Drawing Number
1 05010004 SCREW TH 4x10
2 05010008 SCREW TH 6x10
3 05010028 SCREW TH 5x20
4 05020020 STAINLESS STEEL FHC SCREW 6 X 25
5 05020023 SCREW TFHC M4 X 20
6 05030014 SCREW TCL ST 4.2x9.5
7 05040004 SCREW TRL 4x10
8 06010005 WING NUT 4 A4
9 06030024 NUT HU 8 A4
10 08040005 PUMP PIPE GUIDE
11 09020001 WASHER M 4
12 09020002 WASHER M 5
13 09020006 WASHER M 8
14 10030011 PLASTIC COLLAR 4.6x180
15 10030011 PLASTIC COLLAR 4.6x180
16 13010060 STICKER EYE PROTECTION MANDATORY
17 13010061 STICKER HAND PROTECTION MANDATORY
18 13010080 ELECTRICAL WARNING LABEL
19 13010082 PROTECTIVE EARTH GROUND LABEL
20 14020062 GYLON 3500 FLAT SEAL 9.5x4x1.6
21 14020085 SEAL XP40 10X18X2
22 17010047 PRODUCT FILTER
23 18020003 GROMMET
24 18020005 GROMMET
25 20010090 MASTER SWITCH / EMERGENCY OFF SWITCH 32A
26 20010109 STAINLESS STEEL PUSH-BUTTON
27 23080163 HOSE
28 27050039 ED FLOW WEIGHING INTERFACE CARD
29 28010023 WEIGHTING SENSOR
30 28030040 FLOWMETER 8031 TYPE
31 33080327 2P MALE MINIFIT CONNECTOR
32 33080403 HEXAGON MALE HOSE NIPPLE DN09 G1/4 L8MM
33 38010122 SOLENOID VALVE 2/2 TYPE 6013
34 46020021 FRONT PANEL LOCKING
35 46030120 3 L TANK RESERVOIR
36 46030188 SILENT BLOCK SUPPORT MALE-FEMALE
37 46030191 CAP 006 K5 BLUE
38 46030192 CAP 006 K5 RED
39 46030453 KIT BLUE SCREW CAP
40 46030454 KIT RED SCREW CAP
41 46030460 DISINFECTANT A TANK BED PLATE
42 46030461 DISINFECTANT B TANK 2014 BED PLATE
43 46040013 STAINLESS STEEL HANDLE
44 60021845 PRODUCT SUCTION DIPTUBE
45 60022112 NEEDLE WITH LANCET BEVEL POINT
46 60060124 LIQUID ASPIRATION TUBE CLOSURE
47 70040407 AFTER SALES KIT FOR CHEMICAL A
48 70040408 AFTER SALES KIT FOR CHEMICALS B
49 70040409 AFTER SALES KIT FOR CHEMICALS DLC
50 70091550 DOSING PUMP KIT
51 70120118 PRODUCT INTAKE FILTER EF PY

ED-FLOW - TOUTES / ALL OPTIONS - 2016-09 17 / 27

ED-FLOW - TOUTES / ALL OPTIONS - 2016-09 18 / 27
 AUTOMATON VERSION DOUBLE DOOR
Label Reference Designation Length Drawing Number
1 05010027 SCREW TH 5x12
2 05010028 SCREW TH 5x20
3 05010081 SCREW TRHC 5X10 ISO 7380
4 05080026 SCREW TRHC WITH FLANGE 4x20
5 06050027 SELF-LOCKING NUT 4
6 06050028 SELF-LOCKING NUT M5 A2
7 09020001 WASHER M 4
8 09020002 WASHER M 5
9 19020074 FUSE 5X20 1A 250VAC
10 21010046 MINIATURE SUPPORT POST MSPE-3-01
11 21010051 BLACK SPACER NYLON Ø5.2xØ10-6
12 22030087 RFID CONNECTING TE
13 22030088 RFID PINNED CABLE 2M
14 22030089 RFID PINNED CABLE 1M
15 22040123 SCREW TERMINAL STRIP 20 POINTS
16 22040130 BORNIER MINICONNEC
17 22040142 WR-TBL3517 MALE CONNECTOR 5MM HORIZONTAL
18 22050044 RACK 12 POSITIONS
19 22080041 EXTENSION CORD USB2 AA M/F 0.6M
20 22080047 DATA CABLE FOR PRINTER FT 190 II-S3 M0030474
21 22080049 CABLE USB+T - 1.8M
22 22080051 CONNECTOR/CABLE RFID - 1M
23 22080052 CONNECTOR/CABLE RFID - 2M
24 22080053 BOARD CROSS-PLY FUJI/LED - 1100 MM M0021748
25 22080053 BOARD CROSS-PLY FUJI/LED - 1100 MM M0021748
26 22080054 BOARD CROSS-PLY FUJI/LED - 1600 MM M0028131
27 22080054 BOARD CROSS-PLY FUJI/LED - 1600 MM M0028131
28 22080055 TELEFAST CABLE 2X20WIRE 2XHE10 LG2M
29 22080055 TELEFAST CABLE 2X20WIRE 2XHE10 LG2M
30 22080070 RJ45 CABLE ORIENTED UP 3M LENGTH
31 27010077 FLACH MEMORY CARD 1GO
32 27010100 DIGITAL OUTPUT CARD HE10
33 27010111 CPU 340 - 10 MODBUS
34 27010112 DIG 32 INPUTS 24 VDC SINK
35 27010113 DIG 8I / 8Q - 24VDC
36 27010114 DIG 64 OUTPUTS 24 VDC
37 27010115 DIGITAL 16 OUTPUTS CARD
38 27010116 ANA 4 TC/RTD ISOLATED IN
39 27010117 ANA 4 U/I IN ISOLATED HIGH CARD
40 27010126 CIRCUIT CARD FUJITSU DIGITAL INPUT
41 27010138 SDHC CARD 4GO CLASS 4
42 27020013 DUPLICATEUR CIRCUIT RFID M0020920
43 27020014 ELECTRONIC CARD FOR TEMPERATURE PROBE
44 27040035 HIGH POWER SUPPLY 110-230VAC / 24VDC 5A
45 27040036 POWER SUPPLY 100-200 VAC / 24VDC 10A
46 27050030 RFID READER 40x40 XGCS4901201 (TSX34)
47 39010036 PRINTER FT190 II (9-40V)
48 39040075 USERS TAG
49 39040112 PLATE OF PMMA HMI GTO2310 ED FLOW DD M0033326
50 39040113 PLATE OF PMMA PRINTER FT190SP GTO2310 M0033327
51 39040116 HMI GTO 2310 5.7''
52 39040117 HMI TOUCH SCREEN 5.7'' XBTGT2930
53 41020027 THERMIC PAPER FOR AP1200 PRINTER
54 41020031 20 THERMIC PAPER ROLLS FOR AP1200
55 46030134 SCREW CAP SERIE 006-K1 MS
56 46030190 STUD 006 R5
57 60108069 FRONT PANEL STRUCTURE GTO2310 ED FLOW DD M0033325
58 60108070 FRONT PANEL SUPPORT HMI GTO2310 PRINTER M0033324
59 80011630 CONNECTING HARNESS RJ45/M12F - L3000 M0028132

ED-FLOW - TOUTES / ALL OPTIONS - 2016-09 19 / 27

ED-FLOW - TOUTES / ALL OPTIONS - 2016-09 20 / 27
 AUTOMATON VERSION SINGLE DOOR
Label Reference Designation Length Drawing Number
1 05010027 SCREW TH 5x12
2 05010028 SCREW TH 5x20
3 05010081 SCREW TRHC 5X10 ISO 7380
4 05080026 SCREW TRHC WITH FLANGE 4x20
5 06050027 SELF-LOCKING NUT 4
6 06050028 SELF-LOCKING NUT M5 A2
7 09020001 WASHER M 4
8 09020002 WASHER M 5
9 19020074 FUSE 5X20 1A 250VAC
10 21010046 MINIATURE SUPPORT POST MSPE-3-01
11 21010051 BLACK SPACER NYLON Ø5.2xØ10-6
12 22030087 RFID CONNECTING TE
13 22030088 RFID PINNED CABLE 2M
14 22030089 RFID PINNED CABLE 1M
15 22040123 SCREW TERMINAL STRIP 20 POINTS
16 22040130 BORNIER MINICONNEC
17 22040142 WR-TBL3517 MALE CONNECTOR 5MM HORIZONTAL
18 22050044 RACK 12 POSITIONS
19 22080041 EXTENSION CORD USB2 AA M/F 0.6M
20 22080049 CABLE USB+T - 1.8M
21 22080051 CONNECTOR/CABLE RFID - 1M
22 22080053 BOARD CROSS-PLY FUJI/LED - 1100 MM M0021748
23 22080054 BOARD CROSS-PLY FUJI/LED - 1600 MM M0028131
24 22080055 TELEFAST CABLE 2X20WIRE 2XHE10 LG2M
25 22080055 TELEFAST CABLE 2X20WIRE 2XHE10 LG2M
26 22080068 DATA CABLE FOR PRINTER FT190II-S3 M0030475
27 22080070 RJ45 CABLE ORIENTED UP 3M LENGTH
28 27010077 FLACH MEMORY CARD 1GO
29 27010100 DIGITAL OUTPUT CARD HE10
30 27010111 CPU 340 - 10 MODBUS
31 27010112 DIG 32 INPUTS 24 VDC SINK
32 27010113 DIG 8I / 8Q - 24VDC
33 27010114 DIG 64 OUTPUTS 24 VDC
34 27010115 DIGITAL 16 OUTPUTS CARD
35 27010116 ANA 4 TC/RTD ISOLATED IN
36 27010117 ANA 4 U/I IN ISOLATED HIGH CARD
37 27010126 CIRCUIT CARD FUJITSU DIGITAL INPUT
38 27010138 SDHC CARD 4GO CLASS 4
39 27020013 DUPLICATEUR CIRCUIT RFID M0020920
40 27020014 ELECTRONIC CARD FOR TEMPERATURE PROBE
41 27040035 HIGH POWER SUPPLY 110-230VAC / 24VDC 5A
42 27040036 POWER SUPPLY 100-200 VAC / 24VDC 10A
43 27050030 RFID READER 40x40 XGCS4901201 (TSX34)
44 39010036 PRINTER FT190 II (9-40V)
45 39040075 USERS TAG
46 39040114 PLATE OF PMMA HMI GTO2310 AND PRINTER M0033328
47 39040116 HMI GTO 2310 5.7''
48 39040117 HMI TOUCH SCREEN 5.7'' XBTGT2930
49 41020027 THERMIC PAPER FOR AP1200 PRINTER
50 41020031 20 THERMIC PAPER ROLLS FOR AP1200
51 46030134 SCREW CAP SERIE 006-K1 MS
52 46030190 STUD 006 R5
53 60108071 FRONT PANEL STRUCTURE GTO2310 ED FLOW SD M0033330
54 60108072 FRONT PANEL SUPPORT HMI GTO 2310 PRINTER M0033329
55 80011630 CONNECTING HARNESS RJ45/M12F - L3000 M0028132

ED-FLOW - TOUTES / ALL OPTIONS - 2016-09 21 / 27

ED-FLOW - TOUTES / ALL OPTIONS - 2016-09 22 / 27
 HYDRAULIC 1
Label Reference Designation Length Drawing Number
1 05010006 SCREW TH 6x20
2 05010027 SCREW TH 5x12
3 05030030 SCREW TC M3X8
4 05080014 SCREW TCHC 4x6
5 06030020 NUT HU 5
6 06030022 NUT HU 6
7 06050028 SELF-LOCKING NUT M5 A2
8 09040012 FAN WASHER AZ 6
9 10020027 COLLAR 021.0-706R 17.8 A 21
10 10020032 COLLAR 037.6-706R 34.4 A 37.6
11 10020037 COLLAR 056.0-706R 52.8 A 56
12 10020041 COLLAR 64.8 A 68
13 10020042 COLLAR 056.0-706R 51.5 A 53
14 10020054 COLLAR 46.8 A 50
15 10020055 COLLAR 63.3 A 66.5
16 10020056 COLLAR Ø31.4 TO 34.6
17 10030009 TIE-WRAP LG 98
18 14020057 FLAT GASKET 32x27x2 GYLON 3504
19 14020082 SEALING DF801 24-10-2
20 14030068 48x5 O-RING SEAL
21 23010112 PUMP PS18-308 230V 50Hz WITH INLET Ø25MM
22 23010114 PUMP PS18-307 230V 50Hz WITH DRAINING
23 23010125 PUMP PS18-401 230V 60HZ DRAINING OUTLET
24 23010126 PUMP PS18-402 230V 60HZ
25 24010054 ELECTRICAL IMMERSION HEATER 2000W
26 28040100 THERMOSTAT WITH RESTART KNOB 95°C
27 28050026 CONDUCTIVITY PROBE 0 A
28 28100028 HOLDER OF THERMOSTAT BULB
29 33080293 MALE CONNECTOR G1/4 D10 PP
30 33080330 CONNECTION 2'' STAINLESS STEEL F1/2''Ø12
31 34040120 PLAITED TUBE Ø9.5x16.6 165
32 34040120 PLAITED TUBE Ø9.5x16.6 360
33 34040120 PLAITED TUBE Ø9.5x16.6 185
34 34040120 PLAITED TUBE Ø9.5x16.6 185
35 34040120 PLAITED TUBE Ø9.5x16.6 360
36 34040120 PLAITED TUBE Ø9.5x16.6 250
37 34040120 PLAITED TUBE Ø9.5x16.6 370
38 34040120 PLAITED TUBE Ø9.5x16.6 330
39 34040120 PLAITED TUBE Ø9.5x16.6 360
40 34040120 PLAITED TUBE Ø9.5x16.6 1170
41 34040120 PLAITED TUBE Ø9.5x16.6 1170
42 34040152 MODED HOSE Ø23 X 225 MM
43 38010088 D132 SIRAI SOLENOID VALVE
44 38010118 STAINLESS STEEL VALVE 2-2 WAYS NC -
45 38010122 SOLENOID VALVE 2/2 TYPE 6013
46 38100089 COMPLET HYDRAULIC KIT
47 40010103 SILICONE HEAT TRANSFER COMPOUND
48 46030089 PAULSTRADYN SUPPORT 40X40XM6
49 60021855 WASHING COLLECTOR
50 60040558 SILICONE HOSE Ø22 X Ø31 - LG 60mm +/-2mm
51 60040558 SILICONE HOSE Ø22 X Ø31 - LG 60mm +/-2mm
52 70040250 INOX REDUCTOR 25-12
53 80011593 CONNECTION COUPLING ANGLED SS SEAL EQU
54 80011662 HOSE SILICON Ø42xØ54 - L45 +/-2MM
55 80011663 HOSE SILICON Ø38xØ50 - L210 +/-5MM
56 80011664 HOSE SILICON Ø38xØ50 - L120 +/-5MM
57 80011758 HOSE SILICON Ø55xØ64 - L55 +/-2MM

ED-FLOW - TOUTES / ALL OPTIONS - 2016-09 23 / 27

ED-FLOW - TOUTES / ALL OPTIONS - 2016-09 24 / 27
 HYDRAULIC 2
Label Reference Designation Length Drawing Number
1 05010002 SCREW TH 6x30
2 05010025 SCREW TH 4x8
3 05010027 SCREW TH 5x12
4 05010037 SCREW TH 8x16
5 05030011 SCREW TCL ST 5.5x19
6 05040003 SCREW TRL 6x16
7 06020006 CAP NUT 6
8 06030012 NUT HU 10
9 06030022 NUT HU 6
10 06050027 SELF-LOCKING NUT 4
11 06050029 SELF-LOCKING NUT 6
12 06050032 NUT INDESS 8 A4
13 09020001 WASHER M 4
14 09020002 WASHER M 5
15 09040009 FAN WASHER AZ 5
16 10020027 COLLAR 021.0-706R 17.8 A 21
17 10020043 COLLAR 018.5-706R 15.3 A 18.5
18 10030010 TIE-WRAP LG 140
19 10030014 SAFETY RIBBON
20 11040017 PLASTIC FIXING COLLAR 17.7 - 20.2 MM
21 14020007 STANDARD SEAL 20/27
22 14020069 FLAT SEAL 14x6x3.2mm F5
23 14030096 O RING EPDM ID88.5MM Ø3.5MM
24 17010043 INTERNAL 0.1µ WATER FILTER ED FLOW
25 17020050 MICRO MIST SEPARATOR WITH PRE-FILTER
26 18020005 GROMMET
27 18030025 Ø12 CABLE GLAND
28 20070020 HNM LEVEL CONTROL RELAY
29 22040116 DISTRIBUTION BLOCK 80A
30 22060047 TERMINAL Ø5 EXT 86
31 28020099 DIAPHRAGM PRESSURE SWITCHES G 1/8 ''
32 28030021 FLOWMETER FHKU 938 387001
33 28100013 PLUG FOR FLOWMETER 28030010
34 32010042 CHECK VALVE Ø12
35 33030114 PLUG-IN REDUCER Ø6 - TUBE Ø12
36 33050124 UNION TEE Ø12
37 33060016 RIBBED TE FITTING D10
38 33070180 MALE ELBOW Ø12 - 1/4 THREADING
39 33070181 MALE ELBOW Ø12 - 3/8 THREADING
40 33080048 SIMPLE FEMALE CONNECTION 6 1/8'
41 33080307 CONNECTOR M5 - TUBE ØINT 4MM
42 33080309 CONNECTOR G1/4- TUBE ØINT 4MM
43 33080390 DOUBLE HILLOCK M3/8 - M1/4
44 34040120 PLAITED TUBE Ø9.5x16.6 130
45 34040120 PLAITED TUBE Ø9.5x16.6 170
46 34040120 PLAITED TUBE Ø9.5x16.6 170
47 34040120 PLAITED TUBE Ø9.5x16.6 950
48 34040120 PLAITED TUBE Ø9.5x16.6 950
49 34040120 PLAITED TUBE Ø9.5x16.6 900
50 34040120 PLAITED TUBE Ø9.5x16.6 1400
51 34040120 PLAITED TUBE Ø9.5x16.6 1280
52 34050005 TUBE RILSAN T11 NOBEL 2.7X4 800
53 34050007 TUBE 4MM Ø INTERNAL BLUE 130
54 34050007 TUBE 4MM Ø INTERNAL BLUE 1210
55 34050007 TUBE 4MM Ø INTERNAL BLUE 1255
56 34050008 PLASTIC TUBING Ø12xØ8 65
57 34050008 PLASTIC TUBING Ø12xØ8 65
58 34050008 PLASTIC TUBING Ø12xØ8 455
59 34050008 PLASTIC TUBING Ø12xØ8 350
60 34050008 PLASTIC TUBING Ø12xØ8 1450
61 34050008 PLASTIC TUBING Ø12xØ8 5000
62 34050008 PLASTIC TUBING Ø12xØ8 2155
63 37100051 AIR TREATMENT MODULE
64 38010104 ELECTROVALVE AK MULLER 2/2 PA66 NF
65 46010123 FIXED CASTOR Ø65
66 46020015 HINGE
67 46030189 LOW LOAD RUNNER
68 60107806 WASHER WHEEL
69 70030560 COMPLETE WASHER FEET
70 70040306 LEAK RECUPERATION TANK
71 70120120 0.1µM FILTER KIT
72 80011669 CONNECTION WATER SUPPLY - L3500

ED-FLOW - TOUTES / ALL OPTIONS - 2016-09 25 / 27

ED-FLOW - TOUTES / ALL OPTIONS - 2016-09 26 / 27
 PNEUMATIC
Label Reference Designation Length Drawing Number
1 10020028 COLLAR 014.2-706R 11.7 A 14.2
2 10020029 COLLAR 009.0-505R 7.3 A 9
3 10020038 COLLAR 017.0-706R 14.5 A 17
4 10030009 TIE-WRAP LG 98
5 14030019 O-RING SEAL NBR 8x1.9
6 18020005 GROMMET
7 19010003 CIRCUIT BREAKER 1P+N C3 6kA 230V
8 19010062 CIRCUIT BREAKER 1P+N C6 6kA 230V
9 19020005 FUSE 16A 500VAC gG 10X 38
10 19020009 FUSE 8A 500VAC gG 10x38
11 19030001 FUSE DISCONNECTOR TRI 10x38
12 20030003 STANDARD CONTACTOR 25A-220V (2NO)
13 20030108 1 RT POWER RELAY 240V
14 20030111 RELAY 25A-220V (2NO) 60HZ
15 20070025 TIME DELAY RELAY 0.1 TO 10S SPDT
16 20100143 1 RT POWER RELAY SUPPORT
17 23040010 0.5 BAR PUMP
18 28020003 MANURESTAT 16A-220V/ALT 200 BARS
19 28020095 PRESSURE SWITCH 16A - 220V ALT 300 mBAR
20 28020113 CHANNEL CONTROL DEVICE V2
21 29020010 SILENCER - G 1/8
22 29020011 2 DIRECTION FLOW REGULATOR
23 32010003 VALVE 6 - IMMEDIATE ACETAL
24 32010039 CHECK VALVE
25 33050099 T CONNECTOR -TUBE ØINT 4MM
26 33070007 ADJUST MALE STRAIGHT CYL. 6 1/8'
27 33070136 ELBOW CONNECTOR G1/8-TUBE ØINT 4MM
28 33070171 ELBOW FITTING M5
29 33070180 MALE ELBOW Ø12 - 1/4 THREADING
30 33080307 CONNECTOR M5 - TUBE ØINT 4MM
31 33080343 RIBBED FITTITNG G 1/8 Ø4
32 33080388 STRAIGHT RIBBED FITTING G3/8'' D4 PP
33 34040027 SILICONE HOSE Ø4x8 250
34 34040027 SILICONE HOSE Ø4x8 280
35 34050007 TUBE 4MM Ø INTERNAL BLUE 40
36 34050007 TUBE 4MM Ø INTERNAL BLUE 50
37 34050007 TUBE 4MM Ø INTERNAL BLUE 25
38 34050007 TUBE 4MM Ø INTERNAL BLUE 40
39 34050007 TUBE 4MM Ø INTERNAL BLUE 30
40 34050007 TUBE 4MM Ø INTERNAL BLUE 30
41 34050007 TUBE 4MM Ø INTERNAL BLUE 90
42 34050007 TUBE 4MM Ø INTERNAL BLUE 90
43 34050007 TUBE 4MM Ø INTERNAL BLUE 160
44 34050007 TUBE 4MM Ø INTERNAL BLUE 170
45 34050007 TUBE 4MM Ø INTERNAL BLUE 1210
46 34050007 TUBE 4MM Ø INTERNAL BLUE 1255
47 34050008 PLASTIC TUBING Ø12xØ8 1450
48 34050008 PLASTIC TUBING Ø12xØ8 2155
49 38010094 ELECTRICAL VALVE 2/2 NC UL 24VCC
50 38010095 ELECTRICAL VALVE 3/2 NO UL 230V 50Hz
51 38010096 ELECTROVALVE ELEMENT 24VCC
52 38010100 ELECTROVALVE 2/2 NF WITH BALANCING
53 38010116 ELECTROVALVE TYP 0125 2/2 NC
54 39060005 Ø22 INTERMITTENT BUZZER 24VAC/VDC
55 70040208 MANIFOLD SENSOR KIT
56 70091474 ASSEMBLIED MICRO FLOWMETER PROBE
57 80011646 SILICONE TUBE Ø6.3xØ13.2 - L250
58 80011646 SILICONE TUBE Ø6.3xØ13.2 - L250
59 80011646 SILICONE TUBE Ø6.3xØ13.2 - L250
60 80011646 SILICONE TUBE Ø6.3xØ13.2 - L250
61 80011646 SILICONE TUBE Ø6.3xØ13.2 - L250
62 80011647 SILICONE HOSE Ø3xØ7 70 Sh +/- 5 - L120
63 80011649 SILICONE HOSE Ø3xØ7 70 Sh +/- 5 - L360

ED-FLOW - TOUTES / ALL OPTIONS - 2016-09 27 / 27
