    product by 2022

    HINGES
    35 DSO

    Description
    Ÿ Slide on hinge
    Ÿ Opening angle 95°
    Ÿ Diameter of hinge cup 35mm
    Ÿ Depth of hinge cup 11,3mm
    Ÿ Cup distance 3mm - 7mm
    Ÿ Door thickness 14mm - 23mm
    Ÿ Material iron
    Ÿ Finish nickel plated
    Ÿ Unit pcs

    Order Code 35DSO L (Full overlay) 35DSO ST (Half overlay) 35DSO T (Inset)

    35 JSC

    Description
    Ÿ Soft clip on hinge
    Ÿ Opening angle 95°
    Ÿ Diameter of hinge cup 35mm
    Ÿ Cup distance 3mm - 7mm
    Ÿ Door thickness 14mm - 23mm
    Ÿ Material iron
    Ÿ Finish nickel plated
    Ÿ Unit pcs

    Order Code 35JSC L (Full overlay) 35JSC ST (Half overlay) 35JSC T (Inset)

    page 1
    SLIDE
    JS2C

    CLUTCH PIN

    Description
    Ÿ Undermount full extension soft slide
    Ÿ Load capacity 30kg
    Ÿ 0 - 4mm height adjust
    Ÿ Max. drawer side thickness 16mm
    Ÿ Unit set

    Order Code Size

    JS2 300C Length 300mm

    JS2 350C Length 350mm

    JS2 400C Length 400mm

    JS2 450C Length 450mm

    JS2 500C Length 500mm

    page 2
    SLIDE
    JS1P

    LOCKING PIN

    Description
    Ÿ Undermount single extension soft slide
    Ÿ Load capacity 30kg
    Ÿ 0 - 4mm height adjust
    Ÿ Max. drawer side thickness 16mm
    Ÿ Unit set

    Order Code Size

    JS1 300P Length 300mm

    JS1 350P Length 350mm

    JS1 400P Length 400mm

    JS1 450P Length 450mm

    JS1 500P Length 500mm

    page 3
    SLIDE
    EB235

    Description
    Ÿ Sidemount full extension regular slide
    Ÿ Load capacity 25kg
    Ÿ Colour black
    Ÿ Rail thickness 13mm
    Ÿ Unit set

    Order Code Size

    EB2 3525 Length 250mm

    EB2 3530 Length 300mm

    EB2 3535 Length 350mm

    EB2 3540 Length 400mm

    EB2 3545 Length 450mm

    EB2 3550 Length 500mm

    EB2 3555 Length 550mm

    page 4
    SLIDE
    EB245

    Description
    Ÿ Sidemount full extension regular slide
    Ÿ Load capacity 35kg
    Ÿ Colour black
    Ÿ Rail thickness 13mm
    Ÿ Unit set

    Order Code Size

    EB2 4520 Length 200mm

    EB2 4525 Length 250mm

    EB2 4530 Length 300mm

    EB2 4535 Length 350mm

    EB2 4540 Length 400mm

    EB2 4545 Length 450mm

    EB2 4550 Length 500mm

    EB2 4555 Length 550mm

    EB2 4560 Length 600mm

    EB2 4565 Length 650mm

    EB2 4570 Length 700mm

    page 5
    SLIDE
    ECO BC

    Description
    Ÿ Load capacity 25kg
    Ÿ Colour cream
    Ÿ Rail thickness 12mm
    Ÿ Unit set

    Order Code Size

    ECO BC250 Length 250mm

    ECO BC300 Length 300mm

    ECO BC350 Length 350mm

    ECO BC400 Length 400mm

    ECO BC450 Length 450mm

    ECO BC500 Length 500mm

    ECO BC550 Length 550mm

    ECO BC600 Length 600mm

    page 6
    SLIDE
    ECO BB

    Description
    Ÿ Load capacity 25kg
    Ÿ Colour black
    Ÿ Rail thickness 12mm
    Ÿ Unit set

    Order Code Size

    ECO BB250 Length 250mm

    ECO BB300 Length 300mm

    ECO BB350 Length 350mm

    ECO BB400 Length 400mm

    ECO BB450 Length 450mm

    ECO BB500 Length 500mm

    ECO BB550 Length 550mm

    ECO BB600 Length 600mm

    page 7
