KS4 – Computer systems Learner Worksheet

Lesson 11 – Logic problems

Three-input logic problems


For each of the problems below, create a logic diagram, truth table, and Boolean
expression. Use your notes and the first example to help you.

Task 1 .

“A picture will be taken if the motion sensor or proximity sensor activates and the light is on.”
Logic circuit

Motion

Proximit Picture

Light

Truth table
Motion Proximity Light OR AND (Picture)

0 0 0 0 0

0 0 1 0 0

0 1 0 1 0

0 1 1 1 1

1 0 0 1 0

1 0 1 1 1

1 1 0 1 0

1 1 1 1 1

Page 1 Last updated: 21/09/2021


KS4 – Computer systems Learner worksheet
Lesson 11 – Logic problems

Boolean expression:

Picture = (motion or proximity) and light

Task 2 .

“The warning siren will sound on if the pressure is too high and the valve is not open, or the
temperature is too high.”
Logic circuit

Pressure

Valve Warning

Temperat

Truth table
Pressure Valve Temperature NOT AND OR

0 0 0 1 0 0

0 0 1 1 0 1

0 1 0 0 0 0

0 1 1 0 0 1

1 0 0 1 1 1

1 0 1 1 1 1

1 1 0 0 0 0

1 1 1 0 0 1

Boolean expression:

Warning siren = (pressure and not valve) or temperature

Page 2 Last updated: 21/09/2021


KS4 – Computer systems Learner worksheet
Lesson 11 – Logic problems

Resources are updated regularly — the latest version is available at: ncce.io/tcc.

This resource is licensed under the Open Government Licence, version 3. For more information on this licence, see
ncce.io/ogl.

Page 3 Last updated: 21/09/2021
