REPUBLIC OF THE PHILIPPINES

LAGUNA STATE POLYTECHNIC UNIVERSITY

PROVINCE OF LAGUNA

AC9: CIRCUITS 1

LABORATORY
ACTIVITY 1
PREPARED BY:
Alcantara, Abegail G.
Avila, Ken Raniel R.
Gorteza, Aura Joi C.
Lacsam, Shaina Martinne E.
Maghirang, Janine Maive
Villafuerte, John Lloyd N.
BSECE 2-B

PRESENTED TO:
Engr. Aldrin S. Bagsic
CONTENTS:
OBJECTIVES

EQUIPMENT

PROCEDURES

CONCLUSION

DOCUMENTATION
OBJECTIVES:
To become familiar with the resistor color code, computation of
tolerances of the resistors, and multimeter

EQUIPMENTS:
Multimeter
Resistors: 100KΩ (TG), 330KΩ (TG), 1MΩ (TS), 100Ω (TS), 1KΩ (TS), 2.2
KΩ (TG), 10KΩ (TS), 68 KΩ (TG)

Where:
TS - Tolerance Silver
TG - Tolerance Gold

PROCEDURE:
1. Write the values of the resistor in the Table number 1 (Lower value to
higher value)
2. Compute and record the tolerance in Table 1.
3. Write the color of the resistor according to its value and record in
Table 1.
4. Measure the value of all resistors using multimeter and record in
Table 1
5. Conclusion for laboratory experiment 1.
6. Take a picture of every value that you can measure in a multimeter
and attach it to your laboratory experiment 1.
TABLE 1:
Resistor’s Resistor’s Actual
Tolerance
Value Color Value

100 KΩ 95 - 105 Br, B, Br 98.2 Ω

1 kΩ 950 - 1050 Br, B, R 0.986 KΩ

2.2 KΩ 2 090 - 2 310 R, R, R 2.152 KΩ

10 KΩ 9 500 - 10 500 Br, B, O 9.87 KΩ

68 KΩ 64 600 - 71 400 B, G, O 67.4 KΩ

100 KΩ 95 000 - 105 000 B, Br, G 98.8 KΩ

330 KΩ 313 500 - 346 500 O, O, O 328.7 KΩ

1 MΩ 950 000 - 1 050 000 Br, B, G 0.969 MΩ

CONCLUSION:

Resistors are passive electronic components that are used to control the
flow of electric current in a circuit. They come in various shapes and
sizes. The color bands on a resistor provide important information about
its characteristics, including its resistance value and tolerance.

In this laboratory activity we’ve identified the resistance value of each

resistor and its tolerance through color coding. Furthermore we’ve
tested each resistor in a multimeter to verify if each resistor’s tolerance
will match it’s actual value.

In summary, resistor color coding is a valuable tool for quickly

identifying the resistance value, tolerance, and expected actual value of
a resistor in electronic circuits. Engineers and electronics experts use
this information to select the appropriate resistors for their applications
and to ensure that the resistors meet the required specifications and
tolerances. While the color code provides a useful starting point, it's
necessary to verify the actual resistance value through measurement,
especially in critical applications where precision is important.
DOCUMENTATION:
