CHAPTER 08

LINEAR SLOT DIFFUSERS

EDITION 20.2
 R

LINEAR SLOT DIFFUSER MODEL: ALSD-P

CAT. NO.: AMI-08-01
PLAIN TYPE PAGE NO.: 8.1

Leaders In Air Distribution

SPECIFICATION:
Extruded Aluminium Linear Slot Diffuser with
vertical deflections blades to adjust direction of
air flow. Number of slots available from single
to eight slots in standard widths. Hit and miss
damper available to control volume of supply
air.

DESCRIPTION:
Ø Frame and deflection blades are made of high Ø Total structure is manufactured by mechanical
quality extruded aluminium profiled construction assembly, assuring rigidity and to maintain
with the advantages of corrosion resistance and straight line appearance.
rigidity.
Ø Positive alignment of adjacent sections can be
Ø Each slot consists of two vertical deflectors. made by using alignment strips.
Ø Air distribution can be changed vertically or Ø Suitable for installation for ceiling and sills.
horizontally by means of deflection blades
Ø Standard slot opening width are 16mm, 20mm,
without changing the air flow rate. These blades
25mm and non-standard sizes available as
can be fully adjusted from face opening.
option.
Ø Air flow rate can be adjusted by fixing hit and
Ø Number of slots available: 1, 2, 3, 4, 5, 6, 7, 8.
miss damper at the rear side of the diffuser.
Damper blades are adjusted from the face Ø Length: Up to 3.6 m available in a single piece.
opening.
Ø Optional accessories: Plenum box either un-
Ø Dampers are designed in a unique way that it can lined or internally insulated.
be used as an equalizing grid.

PRODUCT ORDER CHECKLIST:

MODEL SLOTS SLOT OPENING ACCESSORIES FINISH

ALSD-P 1, 2, 3, 16 mm Hit and Miss Powder Coated
4, 5, 6, 20 mm Damper Anodised
7, 8 etc. 25 mm Mill Finish
Wood Finish

*Required: Length, Quantity and RAL Colour Code along with above specifications.

Edition 20.2
Copyright reserved. Specifications subject to change without notice. www.airmaster.co.in
 R

LINEAR SLOT DIFFUSER MODEL: ALSD-P

CAT. NO.: AMI-08-01
PLAIN TYPE PAGE NO.: 8.2

Leaders In Air Distribution

SLOT DIFFUSER DIMENSIONS IN mm:

16 mm Slot Opening:
No. of Slots 1 2 3 4 5 6 7 8

Neck Size in mm 31 60 91 121 152 182 212 242

Duct Size in mm 36 65 96 126 157 187 217 247

Overall Size 58 87 114 144 178 208 238 267

20 mm Slot Opening:
No. of Slots 1 2 3 4 5 6 7 8

Neck Size in mm 35 68 103 137 172 206 240 274

Duct Size in mm 40 73 108 142 177 211 245 279

Overall Size 62 95 130 164 198 232 266 299

25 mm Slot Opening:
No. of Slots 1 2 3 4 5 6 7 8

Neck Size in mm 38 78 118 157 196 236 275 314

Duct Size in mm 43 83 123 162 201 241 280 319

Overall Size 65 105 145 184 223 262 301 339

POSSIBLE AIR DELIVERIES:

Vertical Horizontal Left Horizontal Right

Edition 20.2
Copyright reserved. Specifications subject to change without notice. www.airmaster.co.in
 R

LINEAR SLOT DIFFUSER MODEL: ALSD-P

CAT. NO.: AMI-08-01
PLAIN TYPE PAGE NO.: 8.3

Leaders In Air Distribution

OPTIONAL MITERED CORNERS:

90O Horizontal Variable Angle (90O - 180O)

Standard 90° horizontal Special horizontal mitered

mitered corners available corners selection available
for floor, sill and ceiling for floor, sill and ceiling
applications. applications includes an
angle greater than 90° and
less than 180°.

O O
90 Vertical Outisde 90 Vertical Inside

Vertical outside mitered Vertical inside mitered

corners are available for wall corners are available for wall
application at the junction of application at the junction of
two outside walls with a two inside walls with a
standard angle of 90°. standard angle of 90°.

END FLANGE OPTIONS:

Continuous One Side Flange Both Side Flange

CURVED SLOT DIFFUSER:

Extruded Aluminium Curved Linear Slot
Diffuser can be curved to any architectural
shape of ceiling with a minimum of 2 metre
radius. CAD drawings or templates should be
provided to manufacture. Single or multi radius
curvatures are possible.

Edition 20.2
Copyright reserved. Specifications subject to change without notice. www.airmaster.co.in
 R

LINEAR SLOT DIFFUSER MODEL: ALSD-T

CAT. NO.: AMI-08-02
TEGULAR TYPE PAGE NO.: 8.4

Leaders In Air Distribution

SPECIFICATION:
Extruded Aluminium Linear Slot Diffuser
(Tegular) with vertical deflections blades to
adjust direction of air flow. Hit and miss damper
available to control volume of supply air.
Available in 3 slot as standard to suit grid /
techzone false ceiling systems.

DESCRIPTION:
Ø Frame and deflection blades are made of high
quality extruded aluminium profiled construction
with the advantages of corrosion resistance and
rigidity.
Ø Each slot consists two vertical deflectors.
Ø Air distribution can be changed vertically or
horizontally by means of deflection blades
without changing the air flow rate. These blades
can be fully adjusted from face opening.
Ø Air flow rate can be adjusted by fixing hit and
miss damper at the rear side of the diffuser.
Damper blades are adjusted from the face
opening.
Ø Dampers are designed in a unique way that it can
be used as an equalizing grid.
Ø Total structure is manufactured by mechanical
assembly, assuring rigidity and to maintain
straight line appearance.
Ø Suitable for installation for grid and techzone
ceilings with 150mm centre to centre grid size.
Ø 3 Slot available as standard.
Ø Standard length of 1200mm
Ø Optional accessories: Plenum box either un-
lined or internally insulated.

PRODUCT ORDER CHECKLIST:

MODEL SLOTS SLOT OPENING ACCESSORIES FINISH

ALSD-T 3 25 mm Hit and Miss Powder Coated
Damper Anodised
Mill Finish
2 35 mm
Wood Finish

*Required: Length, Outer Width, Quantity and RAL Colour Code along with above specifications.

Edition 20.2
Copyright reserved. Specifications subject to change without notice. www.airmaster.co.in
 R

LINEAR SLOT DIFFUSER MODEL: ALSD-T

CAT. NO.: AMI-08-02
TEGULAR TYPE PAGE NO.: 8.5

Leaders In Air Distribution

POSSIBLE AIR DELIVERIES:

Vertical Horizontal Left Horizontal Right

END FLANGE OPTIONS:

End Cap Both Side Flange

2 SLOT DIFFUSER TEGULAR TYPE:

Edition 20.2
Copyright reserved. Specifications subject to change without notice. www.airmaster.co.in
 R

LINEAR SLOT DIFFUSER MODEL: ALSD

CAT. NO.: AMI-08
PAGE NO.: 8.6

Leaders In Air Distribution

FIXING DETAILS (FOR PLAIN):

OPTION A OPTION B

FIXING DETAILS (FOR TEGULAR):

Edition 20.2
Copyright reserved. Specifications subject to change without notice. www.airmaster.co.in
 R

LINEAR SLOT DIFFUSER MODEL: ALSD

CAT. NO.: AMI-08
PAGE NO.: 8.7

Leaders In Air Distribution

Table 8.1
Air Flow Data for
Supply Air Linear Slot Diffuser with 16 mm Slot

Edition 20.2
Copyright reserved. Specifications subject to change without notice. www.airmaster.co.in
 R

LINEAR SLOT DIFFUSER MODEL: ALSD

CAT. NO.: AMI-08
PAGE NO.: 8.8

Leaders In Air Distribution

Table 8.1 (Contd.)

Air Flow Data for
Supply Air Linear Slot Diffuser with 16 mm Slot

Edition 20.2
Copyright reserved. Specifications subject to change without notice. www.airmaster.co.in
 R

LINEAR SLOT DIFFUSER MODEL: ALSD

CAT. NO.: AMI-08
PAGE NO.: 8.9

Leaders In Air Distribution

Table 8.2
Air Flow Data for
Return Air Linear Slot Diffuser with 16 mm Slot

Edition 20.2
Copyright reserved. Specifications subject to change without notice. www.airmaster.co.in
 R

LINEAR SLOT DIFFUSER MODEL: ALSD

CAT. NO.: AMI-08
PAGE NO.: 8.10

Leaders In Air Distribution

Table 8.3
Air Flow Data for
Supply Air Linear Slot Diffuser with 20 mm Slot

Edition 20.2
Copyright reserved. Specifications subject to change without notice. www.airmaster.co.in
 R

LINEAR SLOT DIFFUSER MODEL: ALSD

CAT. NO.: AMI-08
PAGE NO.: 8.11

Leaders In Air Distribution

Table 8.3 (Contd.)

Air Flow Data for
Supply Air Linear Slot Diffuser with 20 mm Slot

Edition 20.2
Copyright reserved. Specifications subject to change without notice. www.airmaster.co.in
 R

LINEAR SLOT DIFFUSER MODEL: ALSD

CAT. NO.: AMI-08
PAGE NO.: 8.12

Leaders In Air Distribution

Table 8.4
Air Flow Data for
Return Air Linear Slot Diffuser with 20 mm Slot

Edition 20.2
Copyright reserved. Specifications subject to change without notice. www.airmaster.co.in
 R

LINEAR SLOT DIFFUSER MODEL: ALSD

CAT. NO.: AMI-08
PAGE NO.: 8.13

Leaders In Air Distribution

Table 8.5
Air Flow Data for
Supply Air Linear Slot Diffuser with 25 mm Slot

Edition 20.2
Copyright reserved. Specifications subject to change without notice. www.airmaster.co.in
 R

LINEAR SLOT DIFFUSER MODEL: ALSD

CAT. NO.: AMI-08
PAGE NO.: 8.14

Leaders In Air Distribution

Table 8.5
Air Flow Data for
Supply Air Linear Slot Diffuser with 25 mm Slot

Edition 20.2
Copyright reserved. Specifications subject to change without notice. www.airmaster.co.in
 R

LINEAR SLOT DIFFUSER MODEL: ALSD

CAT. NO.: AMI-08
PAGE NO.: 8.15

Leaders In Air Distribution

Table 8.6
Air Flow Data for
Return Air Linear Slot Diffuser with 25 mm Slot
