. .BOLT
BOLT R-SPEC ·
. 2017-2018
Service Manual
EAS20002
XVS95CH/XVS95CHC
SERVICE MANUAL
©2016 by Yamaha Motor Corporation, U.S.A.
First edition, June 2016
All rights reserved.
Any reproduction or unauthorized use
without the written permission of
Yamaha Motor Corporation, U.S.A.
is expressly prohibited.
Printed in U.S.A.
P/N LIT-11616-30-16
EAS20003
IMPORTANT
This manual was produced by the Yamaha Motor Company, Ltd. primarily for use by Yamaha dealers
and their qualified mechanics. It is not possible to include all the knowledge of a mechanic in one man-
ual. Therefore, anyone who uses this book to perform maintenance and repairs on Yamaha vehicles
should have a basic understanding of mechanics and the techniques to repair these types of vehicles.
Repair and maintenance work attempted by anyone without this knowledge is likely to render the vehi-
cle unsafe and unfit for use.
This model has been designed and manufactured to perform within certain specifications in regard to
performance and emissions. Proper service with the correct tools is necessary to ensure that the vehi-
cle will operate as designed. If there is any question about a service procedure, it is imperative that you
contact a Yamaha dealer for any service information changes that apply to this model. This policy is
intended to provide the customer with the most satisfaction from his vehicle and to conform to federal
environmental quality objectives.
Yamaha Motor Company, Ltd. is continually striving to improve all of its models. Modifications and sig-
nificant changes in specifications or procedures will be forwarded to all authorized Yamaha dealers and
will appear in future editions of this manual where applicable.
TIP ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
• This Service Manual contains information regarding periodic maintenance to the emission control sys-
tem. Please read this material carefully.
• Designs and specifications are subject to change without notice.
EAS30001
-
GENERATOR ANO STARTER CLUTCH
3 -+- ~
,,_.
•o.......·,·
(oil, . . _ _ ....,
.-....,.
-°"""
-
C HKKINO THl STAR'TtR C:UJTC:H
1.
:;;
....;;;
...;;;.,.;;,.......;;;;;;,....
;;,;;;.;;
..;;
...;;l'tP..:ted;;;; • 51:.W,et d.«ft rOIM
hCIMOI N .._. ct..«h. ~ , e a , - Repll,ot.
, • .,....,,. ... .,.._..~•C*'lllet9do.,er
111eg,w• .,, "'*""
2. °"""
• klttor ctACfl ldla gears
• s.., Cl.ilC:tl geat'
~ ' w Nr _.Aclplacelhe
dl'lcMPlrti.f>
°"""
--·
3.
• Sllttltt Cl,tdl Ol'I"• ~ n g -.itt-=-
~- AeplacellelW!ler
4 . O'lecl!.
• s.tetd-*:tl ~
5-43
EAS20005
SYMBOLS
The following symbols are used in this manual for easier understanding.
TIP ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
~ ~ Lithium-soap-based grease
~~
Tightening torque
C) Engine speed
~ Silicone grease
-'
~ Electrical data
A Apply locking agent (LOCTITE®).
TABLE OF CONTENTS
GENERAL INFORMATION
SPECIFICATIONS
CHASSIS
ENGINE
FUEL SYSTEM
ELECTRICAL SYSTEM
TROUBLESHOOTING
GENERAL INFORMATION
IDENTIFICATION .......... ......... .......... ......... ......... .......... ........ .......... ......... ........ 1-1
VEHICLE IDENTIFICATION NUMBER ..... ......... ......... .......... ......... ......... .. 1-1
MODEL LABEL ........ ......... .......... ......... ......... .......... ........ .......... ......... ........ 1-1
FEATURES .......... .......... ......... .......... ......... ......... .......... ........ .......... ......... ........ 1-2
INSTRUMENT FUNCTIONS ..... .......... ......... ........ .......... ......... .......... ........ 1-2
IM PORTA NT INFORMATION ......... .......... ......... .......... ........ ......... .......... ........ 1-4
PREPARATION FOR REMOVAL AND DISASSEMBLY ......... ......... ......... 1-4
REPLACEMENT PARTS .......... ......... ........ .......... ......... .......... ......... ......... . 1-4
GASKETS, OIL SEALS AND 0-RINGS ....... ......... ......... ......... ......... ......... 1-4
LOCK WASHERS/PLATES AND COTTER PINS ......... .......... ......... ......... 1-4
BEARINGS AND OIL SEALS ... .......... ........ .......... ......... ......... .......... ......... 1-5
CIRCLIPS ...... ......... .......... ......... ......... ........ .......... ......... ......... ......... .......... 1-5
RUBB ER PARTS .... ......... ......... .......... ........ ......... ......... ......... ........... ........ . 1-5
BASIC SERVICE INFORMATION .. .... ...... .... .... ..... .... .......... ..... .... .... ...... .... ..... 1-6
QUICK FASTEN ERS ........ ......... .......... ......... ........ .......... ......... .......... ........ 1-6
ELECTRICAL SYSTEM ... ......... ......... ......... ......... .......... ......... ......... ......... . 1-7
SPECIAL TOOLS .......... ......... ......... .......... ......... .......... ........ .......... ......... ...... 1-1 1
IDENTIFICATION
EAS20007
IDENTIFICATION
EAS30002
EAS30003
MODEL LABEL
The model label "1" is affixed to the frame under
the rider seat. This information will be needed to
order spare parts.
1-1
FEATURES
EAS20008
Speedometer
FEATURES The Speedometer shows the vehicle's traveling
EAS30682
speed.
INSTRUMENT FUNCTIONS
Odometer, tripmeters, fuel reserve tripmeter
Multi-function meter unit and clock
n 1 n
u ...
11.!uPHI r----------,
u 2 I"' 1
,,. ••
•• i.i i.i
N ,e,
'° N
The multi-function meter unit is equipped with • The odometer w ill lock at 999999.
the following: • The tripmeters will reset and continue counting
• a speedometer after 999.9 is reached.
• an odometer
Push the "SELECT" switch to change the display
• two tripmeters
between the odometer "ODO", tripmeters 1 and
• a fuel reserve tripmeter 2 "TR IP 1" and "T RIP 2", and the clock in the fol-
• a clock
lowing order:
• a self-diagnosis device
ODO~ TRIP 1 ~ TRIP 2 ~clock~ ODO
TIP ~~~~~~~~~~~~~~~~ If the fuel level warning light comes on , the dis-
• The key must be turned to "ON" before you can play will change to the fuel reserve tripmeter
use the "SELECT" and "RESET" switches. ''TRIP F" and start counting the distance traveled
• To switch between m iles and kilometers, push from that point. In this case, push the "SELECT''
the "SELECT'' switch for three seconds. switch to change the display in the following or-
der:
TRIP F ~ T RIP 1 ~ T RIP 2 ~clock~ ODO~
TRIP F
To reset a tripmeter, use the "SELECT'' switch to
change the display to the desired tripmeter and
then push the "RESET" switch for one second .
The fuel reserve tripmeter can be reset manual-
ly, or after refueling and traveling 5 km (3 mi) it
will reset automatically and disappear from the
(,)
display.
1. "SELECT" switch
2. "RESET" switch
1-2
FEATURES
•• Iii)
N 0
1. Clock
1. Push the "SELECT' and "RESET" switches
for three seconds. The hour digits will start
flashing.
2. Use the "SELECT' switch to set the hours.
3. Push the "RESET" switch. The minute digits
will start flashing.
4. Use the "SELECT' switch to set the minutes.
5. Push the "RESET" switch for two seconds to
confirm settings and start the clock.
Self-diagnosis device
i---.
I
D. ~
•• Iii)
NOTICE
- - - - - - - - - - - - -
1f the display indicates an fault code, the ve-
hicle should be checked as soon as possible
in order to avoid engine damage.
1-3
IMPORTANT INFORMATION
EAS20009
IMPORTANT INFORMATION
EAS30006
EAS30008
1. Oil
2. Lip
3. Spring
4. Grease
EAS30009
REPLACEMENT PARTS
Use only genuine Yamaha parts for all replace-
ments. Use oil and grease recommended by
Yamaha for all lubrication jobs. Other brands
may be similar in function and appearance, but 1
inferior in quality.
1-4
IMPORTANT INFORMATION
EAS30010 EAS30012
ECA13300
NOTICE
-------------
Do not spin the bearing with compressed air
because this will damage the bearing surfac-
es.
EAS30011
CIRCLIPS
Before reassembly, check all circlips carefully
and replace damaged or distorted circlips. Al-
ways replace piston pin clips after one use.
When installing a circlip "1", make sure the
sharp-edged corner "2" is positioned opposite
the thrust "3" that the circlip receives.
1
3
2
1-5
BASIC SERVICE INFORMATION
EAS20010
EAS30013
QUICK FASTENERS
"-·-: ~
. •.v , I ... -·""' ~
Rivet type
1. Remove:
• Quick fastener .
TIP ~~~~~~~~~~~~~~
,.,
.. ......, .
.. I
'
2. Install:
• Quick fastener
TIP ~~~~~~~~~~~~~~~
1IT..
ill
1-6
BASIC SERVICE INFORMATION
ECA16760
EAS30014
NOTICE
ELECTRICAL SYSTEM --------------
Be sure to connect the battery leads to the
Electrical parts handling correct battery terminals. Reversing the bat-
ECA16600 tery lead connections could damage the
NOTICE electrical components.
- - - - - - - - - - - - - -
Never disconnect a battery lead while the en-
gine is running; otherwise, the electrical
components could be damaged. "+"
ECA16n1
NOTICE
--------------
When connecting the battery leads to the
ECA16751 battery, be sure to connect the positive bat-
NOTICE tery lead first, then the negative battery lead.
--------------
When disconnecting the battery leads from If the negative battery lead is connected first
the battery, be sure to disconnect the nega- and a tool or similar item contacts the vehi-
tive battery lead first, then the positive bat- cle while the positive battery lead is being
tery lead. If the positive battery lead is connected, a spark could be generated,
disconnected first and a tool or similar item which is extremely dangerous.
contacts the vehicle, a spark could be gener-
ated, which is extremely dangerous.
e
e
ECA16610
NOTICE
--------------
TIP ~~~~~~~~~~~~~~
Turn the main switch to " OFF" before dis-
connecting or connecting an electrical com-
If a battery lead is difficult to disconnect due to
ponent.
rust on the battery terminal, remove the rust us-
ing hot water.
1-7
BASIC SERVICE INFORMATION
..
ECA16620
ECA16630 ECA14371
NOTICE NOTICE
--------------
EIectricaI components are very sensitive to
--------------
Never insert the tester probes into the cou-
and can be damaged by static electricity. pler terminal slots. Always insert the probes
Therefore, never touch the terminals and be from the opposite end "a" of the coupler, tak-
sure to keep the contacts clean. ing care not to loosen or damage the leads.
ECA16640
TIP ~~~~~~~~~~~~~~
NOTICE
When resetting the ECU by turning the main --------------
switch to "O FF", be sure to wait approximately 5 For waterproof couplers, never insert the
seconds before turning the main switch back to tester probes directly into the coupler. When
"ON". performing any checks using a waterproof
coupler, use the specified test harness or a
suitable commercially available test har-
ness.
1-8
BASIC SERVICE INFORMATION
2. Check:
Checking the connections
• Lead
Check the leads, couplers, and connectors for
• Coupler
stains, rust, moisture, etc.
• Connector
1. Disconnect:
Moisture~ Dry with an air blower.
• Lead
Rust/stains ~ Connect and disconnect sev-
• Coupler
eral times.
• Connector
ECA16780
NOTICE
- - - - - - - - - - - - - -
• When disconnecting a coupler, release the
coupler lock, hold both sections of the cou-
pler securely, and then disconnect the cou-
pler.
• There are many types of coupler locks;
therefore, be sure to check the type of cou-
pler lock before disconnecting the coupler.
3. Connect:
• Lead
• Coupler
• Connector
TIP - - - - - - - - - - - - - - - ~
• When connecting a coupler or connector, push
both sections of the coupler or connector to-
gether until they are connected securely.
• Make sure all connections are tight.
ECA16790
NOTICE
--------------
When disconnecting a connector, do not pull
the leads. Hold both sections of the connec-
tor securely, and then disconnect the con-
nector.
1-9
BASIC SERVICE INFORMATION
• :
Digital circuit tester (CD732)
90890-03243
Model 88 Multimeter with ta-
chometer
YU-A1927
: TIP ~~~~~~~~~~~~~~
~
I
,~
" "
I
7
(00~
• 'i
D
<==Ql
·1 )
till -
- i@J,;.o
\ - )
D
<==Ql
5. Check:
• Resistance
1-10
SPECIAL TOOLS
EAS20012
SPECIAL TOOLS
The following special tools are necessary for complete and accurate tune-up and assembly. Use only
the appropriate special tools as this will help prevent damage caused by the use of inappropriate tools
or improvised techniques. Special tools, part numbers or both may differ depending on the country.
When placing an order, refer to the list provided below to avoid any mistakes.
TIP ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
• For U.S.A. and Canada, use part numbers starting with "YM-", "YU-", or "ACC-".
• For others, use part numbers starting with "90890-".
Reference
Tool name/Tool No. Illustration
pages
Digital circuit tester (CD732) 1-10 , 1-10 ' 5-65 '
90890-03243 6-12, 7-73 ' 7-74 '
Model 88 Multimeter with tachometer 7-75, 7-75 ' 7-79 '
YU-A1927 7-80, 7-80 ' 7-80 '
7-82, 7-82 ' 7-82 '
7-83, 7-83 ' 7-84 '
7-84, 7-85 ' 7-86 '
7-87, 7-87
Yamaha diagnostic tool USB (US) 3-4 , 7-31
90890-03251
O YAMAMA
YU-44456
1-11
SPECIAL TOOLS
Reference
Tool name/Tool No. Illustration
pages
Spoke nipple wrench (8-9) 3-15
90890-01522
Spoke nipple wrench (8-9)
YM-01522
YM-A9409-7/ YM-A5142-4
1-12
SPECIAL TOOLS
Reference
Tool name/Tool No. Illustration
pages
Compression gauge 90890-03081
5-1
90890-03081
Engine compression tester
YU-33223
YU-33223
Extension 5-1
90890-04136
Weight 5-21
90890-01084
90890-01084
Weight
YU-01083-3
YU-01083-3
1-13
SPECIAL TOOLS
Reference
Tool name/Tool No. Illustration
pages
Valve spring compressor attachment 5-31 5-36
90890-01243 '
Valve spring compressor adapter (26 mm)
YM-01253- 1
YU-01304
1-14
SPECIAL TOOLS
Reference
Tool name/Tool No. Illustration
pages
Universal clutch holder 5-55 5-58
90890-04086 90890-04086 M8 XP1.25 '
119
Universal clutch holder
YM-91042
YM-9 1042
1-15
SPECIFICATIONS
GENERAL SPECIFICATIONS ........ .......... ......... .......... ........ ......... .......... ........ 2-1
ENGINE SPECIFICATIONS .. ......... .......... ........ .......... ......... ......... .......... ......... 2-2
CHASSIS SPECIFICATIONS ......... .......... ........ .......... ......... ......... .......... ......... 2-6
ELECTRICAL SPECIFICATIONS .. .......... ........ ......... .......... ......... .......... ......... 2-9
TIGHTENING TORQUES ....... ......... .......... ......... .......... ........ ......... .......... ...... 2-11
GENERAL TIGHTENING TORQUE SPECIFICATIONS .......... ......... ...... 2-11
ENGINE TIGHTENING TORQUES ..... ......... .......... ........ .......... ......... ...... 2-12
CHASSIS TIGHTENING TORQUES .. ......... ......... ........ ........... .......... ...... 2-13
LUBRICATION POINTS AND LUBRICANT TYPES ........... .......... ......... ...... 2-15
ENGINE ......... .......... ......... ......... .......... ......... .......... ........ .......... ......... ...... 2-15
CHASSIS ....... ........ .......... ......... ......... ......... ......... ........... ......... .......... ...... 2-16
LUBRICATION SYSTEM CHART AND DIAGRAMS ........... .......... ......... ...... 2-17
ENGINE OIL LUBRICATION CHART ........ .......... .......... .......... ......... ...... 2-17
LUBRICATION DIAGRAMS ....... ......... .......... ......... ........ .......... ......... ...... 2-19
CABLE ROUTING ......... ......... ......... .......... ......... .......... ........ .......... ......... ...... 2-25
GENERAL SPECIFICATIONS
EAS20013
GENERAL SPECIFICATIONS
Model
Model BP61 (XVS95CH , USA) (for models with spoke
wheels and rear suspensions not equipped with
gas cylinders)
BS51 (XVS95CH , USA) (for models with cast
wheels and rear suspensions equipped with gas
cylinders)
BP62 (XVS95CHC, California) (for models with
spoke wheels and rear suspensions not
equipped with gas cylinders)
BS52 (XVS95CHC, California) (for models with
cast wheels and rear suspensions equipped
with gas cylinders)
Dimensions
Overall length 2290 mm (90.2 in)
Overall width 830 mm (32.7 in)
Overall height 1120 mm (44.1 in)
Seat height 690 mm (27.2 in)
Wheelbase 1570 mm (61 .8 in)
Ground clearance 130 mm (5.12 in)
Minimum turning radius 3.3 m (10.83 ft)
Weight
Curb weight 246 kg (542 lb)
Loading
Maximum load 207 kg (456 lb)
Riding capacity 1 person
2-1
ENGINE SPECIFICATIONS
EAS20014
ENGINE SPECIFICATIONS
Engine
Combustion cycle 4-stroke
Cooling system Air cooled
Valve train SOHC
Displacement 942 cm 3
Cylinder arrangement V-type
Number of cylinders 2-cylinder
Bore x stroke 85.0 x 83.0 mm (3.35 x 3.27 in)
Compression ratio 9.0 : 1
Compression pressure 1218-1568 kPa/400 r/min (12.2- 15.7
kgf/cm 2/400 r/min, 173.2-223.0 psi/400 r/min)
Starting system Electric starter
Fuel
Recommended fuel Regular unleaded gasoline (Gasohol [E1 OJ
acceptable)
Fuel tank capacity 13 L (3.4 US gal, 2.9 Imp.gal)
Fuel reserve amount 2.8 L (0.74 US gal, 0.62 Imp.gal)
Engine oil
Recommended brand YAMALUBE
SAE viscosity grades 1OW-40, 1OW-50, 15W-40, 20W-40 or 20W-50
Recommended engine oil grade API service SG type or higher, JASO standard
MA
Lubrication system Wet sump
Engine oil quantity
Oil change 3.70 L (3.91 US qt, 3.26 Imp.qt)
W ith oil filter removal 4.00 L (4.23 US qt, 3.52 Imp.qt)
Quantity (disassembled) 4.30 L (4.55 US qt, 3.78 Imp.qt)
Oil filter
Oil filter type Cartridge
Oil pump
Inner-rotor-to-outer-rotor-tip clearance 0.000-0.1 20 mm (0.0000-0.0047 in)
Limit 0.20 mm (0.0079 in)
Outer-rotor-to-oil-pump-housing clearance 0.09-0.1 9 mm (0.0035-0.0075 in)
Limit 0.26 mm (0.0102 in)
Bypass valve opening pressure 80.0-120.0 kPa (0.80-1 .20 kgf/cm 2 , 11.6- 17.4
psi)
Relief valve operating pressure 391 .0-489.0 kPa (3.91-4.89 kgf/cm 2 , 56.7- 70.9
psi)
Spark plug(s)
Manufacturer/model NGK/CPR7EA-9
Spark plug gap 0.8-0.9 mm (0.031-0.035 in)
Cylinder head
Warpage limit 0.03 mm (0.0012 in)
2-2
ENGINE SPECIFICATIONS
Camshaft
Camshaft lobe dimensions
Lobe height (Intake) 42.470-42.570 mm (1 .6720-1 .6760 in)
Limit 42.370 mm (1 .6681 in)
Lobe height (Exhaust) 42.1 38-42.238 mm (1.6590-1.6629 in)
Limit 42.038 mm (1 .6550 in)
Camshaft runout limit 0.030 mm (0.0012 in)
Valve spring
Free length (intake) 42.43 mm (1 .67 in)
Limit 40.31 mm (1 .59 in)
Free length (exhaust) 42.43 mm (1 .67 in)
Limit 40.31 mm (1 .59 in)
Spring tilt (intake) 1.9 mm (0.07 in)
Spring tilt (exhaust) 1.9 mm (0.07 in)
Cylinder
Bore 85.000-85.01 O mm (3.3465-3.3468 in)
Out of round limit 0.050 mm (0.0020 in)
Piston
Piston-to-cylinder clearance 0.030-0.055 mm (0.0012-0.0022 in)
Diameter 84.955-84.970 mm (3.3447-3.3453 in)
Measuring point (from piston skirt bottom) 8.0 mm (0.31 in)
2-3
ENGINE SPECIFICATIONS
Piston ring
Top ring
Ring type Barrel
End gap limit 0.60 mm (0.0236 in)
Ring side clearance 0.040-0.080 mm (0.0016-0.0032 in)
Side clearance limit 0.1 00 mm (0.0039 in)
2nd ring
Ring type Taper
End gap limit 0.80 mm (0.0315 in)
Ring side clearance 0.030-0.070 mm (0.0012-0.0028 in)
Side clearance limit 0.1 00 mm (0.0039 in)
Connecting rod
Oil clearance 0.023-0.046 mm (0.0009-0.0018 in)
Bearing color code
4 Black
5 Brown
6 Green
Crankshaft
Runout limit 0.020 mm (0.0008 in)
Crankshaft journal diameter 49.968-49.980 mm (1 .9672-1 .9677 in)
Crankshaft journal bearing inside diameter 50.010-50.028 mm (1 .9689-1 .9696 in)
Journal oil clearance 0.030-0.060 mm (0.0012-0.0024 in)
Clutch
Clutch type Wet, multiple-disc
Clutch lever free play 5.0-10.0 mm (0.20-0.39 in)
Friction plate 1 thickness 2.90-3.1 O mm (0.11 4-0.1 22 in)
Wear limit 2.80 mm (0.11 O in)
Plate quantity 2 pcs
Friction plate 2 thickness 2.92-3.08 mm (0.11 5-0.1 21 in)
Wear limit 2.82 mm (0.111 in)
Plate quantity 7 pcs
Clutch plate thickness 1.90-2.1 O mm (0.075-0.083 in)
Plate quantity 8 pcs
Warpage limit 0.20 mm (0.008 in)
Clutch spring height 7.40 mm (0.29 in)
Minimum height 7.03 mm (0.28 in)
Spring quantity 1 pc
Drivetrain
Primary reduction ratio 1.674 (72/43)
Transmission type Constant mesh 5-speed
Gear ratio
1st 3.067 (46/15)
2nd 2.063 (33/16)
2-4
ENGINE SPECIFICATIONS
Shifting mechanism
Installed shift rod length 93.7-97.7 mm (3.69-3.85 in)
Air filter
A ir filter element O il-coated paper element
Fuel pump
Pump type Electrical
Maximum consumption amperage 2.0 A
Throttle body
ID mark 1TP1 01 (XVS95CH)
1TP2 11 (XVS95CHC)
Fuel injector
Resistance 12.0 Q
Idling condition
Engine idling speed 950-1050 r/min
Engine oil temperature 60-70 °C (140-158 °F)
Intake vacuum 34.7-40.0 kPa (260-300 mm Hg, 10.2-11.8
inHg)
Fuel line pressure (at idle) 220-300 kPa (2.2-3.0 kgf/cm 2 , 31 .9-43.5 psi)
Throttle grip free play 4.0-6.0 mm (0.16-0.24 in)
2-5
CHASSIS SPECIFICATIONS
EAS20015
CHASSIS SPECIFICATIONS
Chassis
Frame type Double cradle
Caster angle 29.0 °
Trail 130 mm (5.1 in)
Front wheel
Wheel type Cast wheel (for cast wheel models)
Spoke wheel (for spoke wheel models)
Rim size 19M/C x MT2.50 (for cast wheel models)
19 x 2.50 (for spoke wheel models)
Rim material Aluminum
Wheel travel 120 mm (4.7 in)
Radial wheel runout limit 1.0 mm (0.04 in) (for cast wheel models)
2.0 mm (0.08 in) (for spoke wheel models)
Lateral wheel runout limit 0.5 mm (0.02 in) (for cast wheel models)
2.0 mm (0.08 in) (for spoke wheel models)
Wheel axle bending limit 0.25 mm (0.01 in)
Rear wheel
Wheel type Cast wheel (for cast wheel models)
Spoke wheel (for spoke wheel models)
Rim size 16M/C x MT3.50
Rim material Aluminum
Wheel travel 70 mm (2.8 in)
Radial wheel runout limit 1.0 mm (0.04 in) (for cast wheel models)
2.0 mm (0.08 in) (for spoke wheel models)
Lateral wheel runout limit 0.5 mm (0.02 in) (for cast wheel models)
2.0 mm (0.08 in) (for spoke wheel models)
Wheel axle bending limit 0.25 mm (0.01 in)
Front tire
Type Tubeless (for cast wheel models)
With tube (for spoke wheel models)
Size 100/90-19M/C 57H
Manufacturer/model BRIDGESTONE/EXEDRA G721 F (for cast
wheel models)
BRIDGESTONE/EXEDRA G721 L (for spoke
wheel models)
Rear tire
Type Tubeless (for cast wheel models)
With tube (for spoke wheel models)
Size 150/80B16M/C 71 H
Manufacturer/model BRIDGESTONE/EXEDRA G722 F (for cast
wheel models)
BRIDGESTONE/EXEDRA G722 L (for spoke
wheel models)
2-6
CHASSIS SPECIFICATIONS
Front brake
Type Hydraulic single disc brake
Disc outside diameter x thickness 298.0 x 5.0 mm (11 .73 x 0.20 in)
Brake disc thickness limit 4.5 mm (0.1 8 in)
Brake disc runout limit (as measured on wheel) 0.1 5 mm (0.0059 in)
Brake pad lining thickness 6.0 mm (0.24 in)
Limit 0.8 mm (0.03 in)
Master cylinder inside diameter 12.70 mm (0.50 in)
Caliper cylinder inside diameter (Left) 30.1 6 mm (1 .1 9 in)
33.34 mm (1 .31 in)
Specified brake fluid DOT4
Rear brake
Type Hydraulic single disc brake
Disc outside diameter x thickness 298.0 x 6.0 mm (11 .73 x 0.24 in)
Brake disc thickness limit 5.5 mm (0.22 in)
Brake disc runout limit (as measured on wheel) 0.1 5 mm (0.0059 in)
Brake pad lining thickness 5.8 mm (0.23 in)
Limit 0.8 mm (0.03 in)
Master cylinder inside diameter 12.7 mm (0.50 in)
Caliper cylinder inside diameter 41 .30 mm (1 .63 in)
Specified brake fluid DOT4
Front suspension
Type Telescopic fork
Spring Coil spring
Shock absorber Hydraulic damper
Fork spring free length 322.2 mm (12.69 in)
Limit 315.7 mm (12.43 in)
Inner tube bending limit 0.2 mm (0.01 in)
Recommended oil Yamaha Suspension Oil G 1O
Quantity (left) 547.0 cm3 (18.49 US oz, 19.29 Imp.oz)
Quantity (right) 547.0 cm3 (18.49 US oz, 19.29 Imp.oz)
Level (left) 116 mm (4.6 in)
Level (right) 116 mm (4.6 in)
Rear suspension
Type Swingarm
Spring Coil spring
Shock absorber Gas-hydraulic damper (for models equipped
with gas cylinders)
Hydraulic damper (for models not equipped with
gas cylinders)
Spring preload
Adjusting system Mechanical adjustable type
Unit for adjustment Cam position
Adjustment value (Soft) 1 (for models not equipped with gas cylinders)
O notches out (for models equipped with gas
cylinders)
2-7
CHASSIS SPECIFICATIONS
Adjustment value (STD) 2 (for models not equipped with gas cylinders)
1 notch out (for models equipped with gas
cylinders)
Adjustment value (Hard) 5 (for models not equipped with gas cylinders)
4 notches out (for models equipped with gas
cylinders)
Drive belt
Drive belt slack 6.0-8.0 mm (0.24-0.31 in)
Drive belt slack (on a suitable stand) 7.0-9.0 mm (0.28-0.35 in)
2-8
ELECTRICAL SPECIFICATIONS
EAS20016
ELECTRICAL SPECIFICATIONS
Voltage
System voltage 12 V
Ignition system
Ignition system TCI
Advancer type Digital
Ignition timing (B.T .D.C.) 5.0 °/1000 r/min
Ignition coil
Minimum ignition spark gap 6.0 mm (0.24 in)
Primary coil resistance 2.1 6-2.64 Q
Secondary coil resistance 8.64-12.96 kQ
Charging system
Charging system AC magneto
Standard output 14.0 V , 32.8 A at 5000 r/min
Standard output 14.0 V , 460 W at 5000 r/min
Stator coil resistance 0.1 28-0.1 92 Q (B-B)
Rectifier/regulator
Regulator type Three-phase
Regulated voltage (DC) 14.3-14.7 V
Rectifier capacity (DC) 50.0 A
Battery
Model YTZ14S
Voltage, capacity 12 V , 11.2 Ah (1 O HR)
Headlight
Bulb type Halogen bulb
Indicator light
Neutral indicator light LED
High beam indicator light LED
Oil level warning light LED
Turn signal indicator light LED
2-9
ELECTRICAL SPECIFICATIONS
Starter motor
Power output 0.80 kW
Armature coil resistance 0.0050-0.0150 Q
Brush overall length 12.0 mm (0.47 in)
Limit 6.50 mm (0.26 in)
Brush spring force 6.02-6.51 N (614-664 gf, 21 .69-23.45 oz)
Mica undercut (depth) 0.70 mm (0.03 in)
Fuse(s)
Main fuse 40.0 A
Headlight fuse 20.0 A
Taillight fuse 7.5 A
Signaling system fuse 7.5 A
Ignition fuse 15.0 A
Fuel injection system fuse 10.0 A
Backup fuse 7.5 A
2-10
TIGHTENING TORQUES
EAS20017
TIGHTENING TORQUES
EAS30015
0
A
2-11
TIGHTENING TORQUES
EAS30016
Drive pulley nut M22 1 140 N-m (14 kgf-m, 100 lb-ft) -G
Stake.
TIP ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
2-12
TIGHTENING TORQUES
2,14
© 3
a,5
TIP ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
12
~ 13 14
11 ~\y~--
10 ° I
~
®
))~ 1
( 2
'' ~
3
7 4
b,6 5
EAS30017
2-13
TIGHTENING TORQUES
Thread
Item Q'ty Tightening torque Remarks
size
Steering stem nut M22 1 110 N-m (11 kgf-m, 80 lb-ft)
Lower ring nut (initial tightening
M25 1 52 N-m (5.2 kgf-m, 38 lb-ft) See TIP
torque)
Lower ring nut (final tightening
M25 1 18 N-m (1.8 kgf-m, 13 lb·ft) See TIP
torque)
TIP ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
~ ~
~ (
;:;:::_c=> -
=
2 1
~/ ~
TIP
Lower ring nut
1. First, tighten the lower ring nut to approximately 52 N-m (5.2 kgf-m, 38 lb-ft) with a torque wrench,
then loosen the lower ring nut completely.
2. Retighten the lower ring nut to 18 N-m (1 .8 kgf-m , 13 lb-ft) with a torque wrench.
2-14
LUBRICATION POINTS AND LUBRICANT TYPES
EAS20018
ENGINE
Lubrication point Lubricant
Oil seals (lip) -..-a
0 -rings
Bearings
-...
---41@
Cylinder head bolts, nuts and washers -1@
Connecting rods (small end and big end) - 1@
Crankshaft journals -1@
Pistons (outer surface) -1@
Piston pins (outer surface) -1@
Camshaft cam lobes and camshaft journals -1@
Valve stems (intake and exhaust) -1@
Valve stem ends (intake and exhaust) -1@
Rocker arm shafts - 1@
Oil strainer -1@
Oil filter cartridge union bolt -1@
Crankcase stud bolts -1@
Starter clutch idle gear 1 shaft -1@
Starter clutch idle gear 1 - 1@
Starter clutch gear (inner and outer surfaces) -1@
Starter clutch and metal-to-metal moving parts -1@
Starter clutch idle gear 2 shaft -1@
Starter clutch idle gear 2 -1@
Primary driven gear (inner surface) and collar - 1@
Clutch pull rod
Oil pump drive sprocket (inner surface)
-...
-1@
Clutch thrust washers -1@
Clutch boss nut and washer - 1@
Transmission gears (wheel and pinion) and collar -1@
Shift forks and shift fork guide bars -1@
Shift drum -1@
Shift shaft and shift -1@
Yamaha bond No.1215
Crankcase (mating surface) (Three Bond
No.1215®)
Yamaha bond No.1215
Crankshaft position sensor lead grommet (Three Bond
No.1215®)
Yamaha bond No.1215
Crankcase breather pipe (Three Bond
No.1215®)
2-15
LUBRICATION POINTS AND LUBRICANT TYPES
EAS30019
CHASSIS
Lubrication point Lubricant
Steering bearings and upper bearing race cover (lip) -..-a
Lower bearing steering seal (lip) ---..1
Front wheel oil seals (lip) ...., I
Rear wheel oil seal (lip)
Rear wheel drive hub (mating surface)
---..-.
....,I
Brake pedal shaft (pivoting point) -..-a
Shift pedal (pivoting point) ---..1
Sidestand (pivoting point) and metal-to-metal moving parts -..-a
Footrest assembly (pivoting point)
Throttle grip tube guide (inner surface) and throttle cables
---..-.
....,I
Brake lever (pivoting point) and metal-to-metal moving parts -Ǥ>I
Brake master cylinder push rod (contact surface) -Ǥ>I
Clutch lever (pivoting point) and metal-to-metal moving parts
Swingarm pivot bearings (inner surface)
......
---..1
Swingarm pivot oil seals (lip) -..-a
Pivot shaft (outer surface) ---..i
Rear wheel axle (outer surface) ....,I
Engine mounting bolt (front lower side) (thread part) ---..-.
2-16
LUBRICATION SYSTEM CHART AND DIAGRAMS
EAS20019
13
11 - ~ ...r
12
~
---,_ u----,_
-
rr-11
-~
• • ~-
l l
-....
F
''
1.
' '
'' '
:;:::,.;
' '
' '
I'
''
' '
"' 9 '' ~ ~
' " ' '
' ' ' '
' ' ' '
' ' ' '
I ' J
'
'
'
'
'
~ ~
'
'
8 10
'
'
' '
'
t 7
'
'
-~
~ =11
'
5 . - - - - ' -I.!.I 6
I
~ 4
'----------,
2
\3
2-17
LUBRICATION SYSTEM CHART AND DIAGRAMS
1. Oil strainer
2. Oil pump assembly
3. Oil delivery pipe 2
4. Relief valve assembly
5. Drive axle
6. Oil filter cartridge
7. Main axle
8. Main gallery
9. Crankshaft
10. Clutch cover
11 . Valve stem end (intake side)
12. Rear cylinder camshaft
13. Front cylinder camshaft
2-18
LUBRICATION SYSTEM CHART AND DIAGRAMS
EAS30021
LUBRICATION DIAGRAMS
2 1
2-19
LUBRICATION SYSTEM CHART AND DIAGRAMS
2-20
LUBRICATION SYSTEM CHART AND DIAGRAMS
-
- -
~
'
I I '
I
' - I
-
-I c '-
.,
- c
"'
0"
_ II'=='! - /·
" I
·~
, ~ .., ,, ~
0
I '"" 9 , , .,...-' V
, ~~:,,,• ~- -. . __,,~ ~
"
I
~ ==i:L:JPr=ct=Oll-----,
I
r---~-- ~ - ~' • ~
Jj__lt_th_,___ir,_,..L--------,------, ~
-
~ - -'--IJJL+-UW I,., ,
r----. r. f~ '• • '
- 1 ----- - '-1.
----- ------ --· - 1e-' ,~" ,.
'<t:·-
- ,, • '
- --·rr. . ====== ..... ·--- l --
~
,-. - l :
I
'
I
'
! '
•
-
~
I
t t
1. Camshaft
2. Crankshaft
2-21
LUBRICATION SYSTEM CHART AND DIAGRAMS
@
I
1
1. Oil drain bolt
2. Crankshaft
2-22
LUBRICATION SYSTEM CHART AND DIAGRAMS
1
I
I I 1111 I
' ~
., r I
I I
-- L
I I
2
- '-r !Gt
/ )
110 q
J
-11
r I
-
I
lI
- II II II ~ II
~
3
u-
l I
- J.e ( J -- -'
r l
- - 'I -
- r
/ -
I
_,
I
'
II I 11 11
- I
,-
/ -
it' I
ll
\
n ••
/
.....,
r
\V:
'-,
" I
-
Jqu r
II II ~~
r
J~')
- / ' 1
=
' ' II
' '
" II " l J
LJ 1
~
- )
/ I
L
\! - ,,.-
(~ -
~
,,.- 0 I Ill ''
"' ~
~
'-, l ([])'
,I
Jj'f
I II I
,_
I
_(
-- 1 I ll
~ ' Il
~ - - r
-
. ''
'
'
I 4
- ~
_/
- ~
~
I
/
r ~
" ~ r
0 I
/' ~ V
5
2-23
LUBRICATION SYSTEM CHART AND DIAGRAMS
1. Drive axle
2. Oil delivery pipe 1
3. Main axle
4. Oil delivery pipe 2
5. Oil pump assembly
6. Oil strainer
2-24
CABLE ROUTING
EAS20021
CABLE ROUTING
Handlebar (top and front view)
4 1 Q] 7
~rr""cl-----1----®
~(\T--t--rN
0
2-25
CABLE ROUTING
1. Clutch cable
2. Throttle cable (accelerator cable)
3. Throttle cable (decelerator cable)
4. Front brake hose
5. Handlebar switch lead (right)
6. Handlebar switch lead (left)
7. Intake air temperature sensor
8. Intake air temperature sensor lead
9. Wire harness
1o. Headlight stay
A. Route the clutch cable, throttle cable (accelerator
cable), and throttle cable (decelerator cable)
through the cable guide.
B. Align the holder with the brake hose union bolt and
face the catch of the holder rearward.
C. Fasten the right handlebar switch lead with the
plastic band. Align the plastic band with the middle
of the front brake master cylinder.
D. Fasten the handlebar switch lead with the plastic
band at the bend in the handlebar.
E. Fasten the left handlebar switch lead with the
plastic band. Align the plastic band with the
locknut.
F. Point the end of the plastic band downward.
G. Face the buckle of the plastic band forward.
H. Route the right handlebar switch lead under the
handlebar.
I. Route the left handlebar switch lead under the
handlebar.
J. Route the clutch cable to the front of the front
brake hose.
K. Insert the projection on the right handlebar switch
lead holder into the hole in the cable guide.
L. Route the front brake hose and right handlebar
switch lead through the cable guide.
M. Route the left handlebar switch lead to the rear of
the right handlebar switch lead and wire harness.
N. Insert the projection on the wire harness holder
into the hole in the headlight stay.
0 . Route the front brake hose to the rear of the
throttle cables and clutch cable.
2-26
CABLE ROUTING
Headlight
1
[
9 '' I
\ '
C \ '
' '
~,/
'-\_/
2-27
CABLE ROUTING
2-28
CABLE ROUTING
I ::1-@ F
2 ~
AJ
AE
---• AA AB
2-29
CABLE ROUTING
1. Clutch cable U. Route the left handlebar switch lead through the
2. Joint coupler guide on the meter bracket. Make sure that there is
3. Throttle cable (accelerator cable) no slack in the handlebar switch lead between the
steering head and the plastic band installed on the
4. Throttle cable (decelerator cable)
handlebar.
5. Wire harness
V. Route the front left turn signal light lead over the
6. Handlebar switch lead (left) guide on the meter bracket.
7. Front cylinder spark plug lead W. Route the right handlebar switch lead through the
8. Front cylinder ignition coil lead guide on the meter bracket. Make sure that there is
9. Rear cylinder ignition coil lead no slack in the handlebar switch lead between the
10. Rear cylinder spark plug lead steering head and the plastic band installed on the
handlebar.
11 . Handlebar switch lead (right)
X. Route the front right turn signal light lead to the
12. Meter assembly lead front of the right handlebar switch lead, and then
13. Handlebar switch coupler (left) connect the lead to the front turn signal light.
A. Route the clutch cable to the inside of the fuel tank Y. Route the meter assembly lead to the front of the
bracket. meter bracket.
B. Route the clutch cable through the guide on the Z. Route the front turn signal light lead to the front of
frame. the left handlebar switch lead, and then connect
C. Route the wire harness through the guide on the the lead to the front turn signal light.
frame. AA. Install the joint coupler by sliding it onto the engine
D. Cover the throttle position sensor coupler with the bracket from below.
coupler cover. AB. Connect the wire harness to the left handlebar
E. Insert the projection on the joint coupler into the switch, and then install the coupler onto the tab on
hole in the frame. the engine bracket (front upper side).
F. Route the clutch cable through the guide. AC. Secure the holder by inserting the projection on
G. Insert the projection on the right handlebar switch the holder into the hole in the bracket, and then
lead holder into the hole in the cable guide. fasten the front cylinder spark plug lead with the
H. Insert the projection on the wire harness holder holder.
into the hole in the cable guide. AD.To the left handlebar switch
I. Route the wire harness through the guide. AE. Install the left handlebar switch coupler onto the
J. Insert the projection on the left handlebar switch tab on the intake air pressure sensor bracket.
lead holder into the hole in the cable guide. AF. To the wire harness
K. Route the throttle cables through the guide. AG. To the main portion of the wire harness
L. Route the left handlebar switch lead to the inside AH. Fasten the wire harness by sliding the plastic
of the wire harness and main switch. holder on the wire harness onto the stud on the
M. Insert the projections on the wire harness holders intake air pressure sensor bracket.
into the holes in the frame. Al. To the horn
N. Fasten the front cylinder spark plug lead with the AJ. Fasten the spark plug lead with the holder.
holder. Point the open ends of the holder rearward. AK.Upward
0 . Install the ignition coil connectors so that the front AL. Route the rear cylinder spark plug lead through the
cylinder ignition coil leads are routed downward. guide.
P Install the ignition coil connectors so that the rear
cylinder ignition coil leads are routed upward.
Q . Align the paint mark on the throttle cable with the
throttle cable holder.
R. Make sure that the rear cylinder spark plug lead is
not pinched between the rear cylinder head and
the rear cylinder head cover.
S. Secure the plastic band by inserting the projection
on the band into the hole in the frame, and then
fasten the clutch cable and wire harness with the
band, making sure to point the end of the band
downward.
T. Fasten the wire harness and clutch cable with the
plastic band. Position the buckle of the plastic band
toward the frame so that it does not protrude to the
outside of the wire harness, and place the end of
the band between the frame and the rear cylinder
ignition coil.
2-30
CABLE ROUTING
K
10
7
5
0
2-31
CABLE ROUTING
2-32
CABLE ROUTING
6~
0
7
2-33
CABLE ROUTING
1. Clutch cable
2. Wire harness
3. Crankshaft position sensor lead
4. Oil level switch lead
5. Neutral switch lead
6. Starter motor lead
7. Rear brake hose
8. 0 2 sensor
9. Rear brake light switch lead
1o. 0 2 sensor lead
11 . Brake fluid reservoir hose
A. Insert the projection on the wire harness holder
into the hole in the frame.
B. After connecting the crankshaft position sensor
coupler, oil level switch coupler, and neutral switch
coupler, cover the couplers with the coupler cover.
C. To the speed sensor
D. To the starter relay
E. Route the starter motor lead to the front of the
frame cross member.
F Route the starter motor lead and rear brake light
switch lead under the engine bracket (rear lower
side).
G. Route the rear brake light switch lead under the
mounting position for the starter motor lead on the
engine bracket (rear lower side).
H. Insert the projection on the starter motor lead
holder into the hole in the engine bracket (rear
lower side).
I. After connecting the rear brake light switch coupler
and 0 2 sensor coupler, cover the couplers with the
coupler cover.
J. Insert the projection on the wire harness holder
into the hole in the battery box bracket.
K. Point the end of the plastic band downward.
2-34
CABLE ROUTING
~
!"-J
··- ··:--·--- -·-·-
1!1-··-t··-··-··-· -~ ·
------ .. ..··-·
·1=!1
I
·t
' ' t .t !
·---------------
··-··i-·-·-·- ----- .. ---
--·-· : ::
,·•
---,-"
i. :I
i :
D
E
y:.:..:": ': ,
I: '(,
'I .,
\.
-:~-S.·,
..
2-35
CABLE ROUTING
2-36
CABLE ROUTING
1 2
.,;;;..-··- ..
'-!/ ~'=:~
I
'
I
r··-··
, ··- ··-··- ··-··-··-··~
0 ,,
''\
I
'
'
''
:\ ''\
\. I' '
' : '\ '\
·-··---~ .. ., I '\ '\ .
. J ' _J
j.-·1· -· --··---··-·· ··-··-J·~·p··"\·
· •,
f ··--t·--- - ·-··-··- ··- ··-··-··- ----·;-,·:-,.'·
y '. -c." ~ .c;s-;:..::,1-' ' i
v.:". ~,,~,;~~.:...7,·(c~~~,,,.r,1,,v·
- ... . ...........__... . ,
/
' 1-........ .... _ r , •
! ·,--...F),---
i ·---·· rT /) / 1 £3)
'='
• I
'
I : JI ........---:;1...
~ ~
I >----1 3
¢===;,
! I
i
'
I
'
/ :C--:;t-(Q
.I
i
'
I
:
I ..1·
I /fAI
/1_'9,
I
'
/
,,.• • I
..,/r.:.:.. ,--
N'/\
' . ~- _.,_. ;,"">,y
I ( . ·">
/ : ! . --~·
I: 'V ,fo[{I!
. (1 ~~\
. .
I .. .·; '..-lo"-·\\:-- -~·.Y". .....-.
:
I:
l ·- \ _) \i ( h-<.:'
{(""\1\:~
I '-":I'\\
-~ . . i· 'f'
• (
/ :~ ·. \ ~-s,. . . .../1 ,,
i :::/,P.:~
: ... ""~,\
_/(,('))
I \., .
\ '., --~~.>~;,--
,, .... "- ··.:.~ -~
( ,~~;, '
,. : .. ~ -
'· ·,·--___;-··
l ,)2) ' ---··
,,
2-37
CABLE ROUTING
2-38
CABLE ROUTING
3 4
D 5
7 IE)
1
,
I 8
QJ 11 '
•'
10 [§)
2-39
CABLE ROUTING
2-40
CABLE ROUTING
-.- --_n-·
---
2-41
CABLE ROUTING
2-42
CABLE ROUTING
5 1
18 8
, ',
)
.~
1> X3
@:l
J
L 1
2-43
CABLE ROUTING
1. Stator coil lead T. Point the end of the plastic locking tie inward.
2. Neutral switch lead U. Position the buckle of the plastic locking tie on top
3. Oil level switch lead of the frame, with the end pointing outward, and
4. Wire harness then cut off the excess end of the tie to 1-5 mm
5. Negative battery lead (0.04-0.20 in).
6. Sub-wire harness (rear turn signal light, license V. Install the ground lead terminal so that the crimped
plate light) section of the terminal that secures the lead is
facing inward. Install the ground lead terminal and
7. Headlight relay
the drive pulley housing using the same bolt.
8. Starter relay
W. Side of the drive pulley housing
9. Fuse box
X. Install the ground lead terminal so that the
10. Main fuse lead indicated section of the terminal is positioned to
11 . Positive battery lead the front of the side of the drive pulley housing.
12. Sidestand switch coupler
13. Sidestand switch lead
14. Crankshaft position sensor lead
15. Turn signal relay
16. Relay unit
17. Lean angle sensor lead
18. Starter motor lead
19. Main fuse
20. Sub-wire harness coupler (negative battery)
21 . Yamaha diagnostic tool coupler
22. Speed sensor lead
23. Ground lead
A. After connecting the couplers, cover the couplers
with the coupler cover, and then place the couplers
in the air duct.
B. Insert the projections on the wire harness holders
into the holes in the frame.
C. Do not face the catch of the holder downward.
D. Insert the projection on the sub-wire harness
holder into the hole in the battery box.
E. Insert the projection on the wire harness holder
into the hole in the battery box.
F. Route the main fuse lead under the fuse box.
G. Route the positive battery lead under the fuse box.
H. To the starter motor
I. Route the oil level switch lead to the inside of the
frame.
J. Route the sidestand switch lead to the inside of the
frame.
K. After connecting the sidestand switch coupler,
insert the projection on the coupler cover into the
hole in the frame.
L. Fasten the oil level switch lead and sidestand
switch lead with the holder. Position the holder
between the sidestand switch coupler and the
sidestand switch lead holder.
M. Install the sidestand switch lead holder at the
location shown.
N. Fasten the oil level switch lead to the frame with a
plastic locking tie.
0 . Point the end of the plastic locking tie downward.
P. Insert the projection on the wire harness holder
into the hole in the battery box.
Q . Insert the projection on the positive battery lead
holder into the hole in the battery box.
R. After connecting the positive battery lead and
starter motor lead, install the starter relay cover.
S. Insert the projection on the ground lead holder into
the hole in the battery box.
2-44
CABLE ROUTING
0 IJ 0
J
@
0
11
1
G
7
2-45
CABLE ROUTING
2-46
CABLE ROUTING
1 2
I
I' l
{
I ,
2-47
CABLE ROUTING
2-48
CABLE ROUTING
,,
/'-, -
I
'
'
\-- --
\ ---
'
\
''
i---
:~
I
I/Tft£___r_:::.,.,..._ _ -f E
J
Nk--~--IF
5 [§] 2
::----~o
2-49
CABLE ROUTING
2-50
CABLE ROUTING
Fuel tank breather hose (left and rear view) (except for California)
'
'
\ I
' '
' '
"' I 1
•' I'
h
..
I,
I' I,
''
,, :_i,__r, :
,,_1!J,r : f',
..
I' I,
\
''
\
~ c.· r--.J-. -·--; ..
I' I,
\ n.:·~ - .. :
..
--- __ .. -- ..•
\ '., I
I' I, I'
'ffil '' '
'I ~--'
- ,! .- --
'-\ '' I• '
i \~[ru L• .---
'
:, '
'
I
'
2-51
CABLE ROUTING
2-52
CABLE ROUTING
'
'\
\
\ I
2
,,
/ '
1
I
~
3
'\
'
'\ I '
' '\
2-53
CABLE ROUTING
2-54
CABLE ROUTING
3 '
\
2 ',,..
B ',,.,
' ,,.,
- ' ' ,,.,
5 B
2-55
CABLE ROUTING
2-56
CABLE ROUTING
'
'
0 '
,'"1 '
~
I :
''
Lj ~
I
2-57
CABLE ROUTING
2-58
CABLE ROUTING
-' -
---
C
2-59
CABLE ROUTING
2-60
CABLE ROUTING
2-61
PERIODIC CHECKS AND ADJUSTMENTS
PERIODIC MAINTENANCE .. ......... .......... ........ .......... ......... ......... .......... ......... 3-1
INTRODUCTION .... ......... .......... ......... ........ ......... ......... .......... ......... ......... . 3-1
PERIODIC MAINTENANCE CHART FOR THE EMISSION CONTROL
SYSTEM .. ..... ......... ......... ......... ......... ......... .......... ......... ......... ......... .......... 3-1
GENERAL MAINTENANCE AND LUBR ICATION CHART .... .......... ......... 3-1
CHECKING THE VEH ICLE USING THE YAMAHA DIAGNOSTIC
TOOL .. .......... ......... .......... ......... ......... .......... ........ .......... ......... ......... ......... 3-4
CHECKING THE FUEL LINE .... .......... ......... ........ ......... ......... .......... ......... 3-4
CHECKING THE SPARK PLUGS ....... .......... .......... ......... ....... ......... ......... 3-4
ADJUSTING THE VALVE CLEARANCE ..... ........ .......... ......... ......... ......... 3-5
CHECKING THE CRANKCASE BREATHER HOSE .... ......... ......... ......... . 3-7
SYNCHRONIZING THE THROTTLE BODIES ...... ......... ......... ......... ......... 3-8
CHECKING THE EXHAUST SYSTEM ....... ......... ......... .......... ......... ......... . 3-9
CHECKING THE CAN ISTER (for California) ...... .......... ......... .......... ....... 3-10
REPLACING TH E AIR FILTER ELEM ENT .. .......... ........ ......... .......... ...... 3-1 O
CHECKING TH E CLUTCH OPERATION ..... .......... ........ .......... ......... ...... 3-11
ADJUSTING THE CLUTCH LEVER FR EE PLAY .. ......... .......... ......... ..... 3-11
CHECKING TH E BRAKE OPERATION ........ ......... ......... ......... ......... ...... 3-11
CHECKING TH E BRAKE FLUID LEVEL ....... .......... ........ ......... .......... ..... 3-12
CHECKING TH E FRONT BRAKE PADS ..... ......... ......... .......... .......... ..... 3-12
CHECKING THE REAR BRAKE PADS ....... ......... ......... .......... .......... ..... 3-12
BLEEDING THE HYDRAULIC BRAKE SYSTEM .......... .......... ......... ...... 3-13
CHECKING TH E FRONT BRAKE HOSE .... .......... ......... .......... .......... ..... 3-14
CHECKING THE REAR BRAKE HOSES .... ......... .......... .......... .......... ..... 3-14
CHECKING TH E WHEELS ....... .......... .......... ......... ......... ......... .......... ..... 3-14
CHECKING AND TIGHTENING THE SPOKES
(for spoke wheel models) ......... ......... ........ .......... ......... ......... ......... ........ 3-14
CHECKING TH E TIRES ........... ......... ......... ......... .......... ......... ......... ........ 3-15
CHECKING TH E WHEEL BEAR INGS ....... ......... ......... ........... .......... ...... 3-17
CHECKING TH E SWINGARM PIVOT SHAFT BEARINGS .... ......... ....... 3-17
CHECKING TH E DRIVE BELT .......... ........ .......... .......... .......... .......... ..... 3-17
ADJUSTING THE DRIVE BELT SLACK ....... ......... ........ .......... ......... ...... 3-17
CHECKING AND ADJUSTING TH E STEERING HEAD .......... .......... ..... 3-19
LUBRICATING TH E STEERING BEARINGS ...... .......... ......... ......... ....... 3-20
CHECKING TH E CHASSIS FASTENERS ........... ......... .......... .......... ...... 3-20
LUBRICATING TH E BRAKE LEV ER ......... ......... ......... ........... .......... ...... 3-20
LUBRICATING TH E BRAKE PEDAL .......... ......... ........ ........... .......... ...... 3-20
LUBRICATING TH E CLUTCH LEVER ....... ......... ......... ........... .......... ...... 3-20
LUBRICATING TH E SHIFT PEDAL .... .......... ......... ........ .......... ......... ...... 3-20
CHECKING TH E SIDESTAND .......... ........ .......... ......... ......... ......... ......... 3-20
LUBRICATING TH E SIDESTAND ........ ......... ......... ......... ......... .......... ..... 3-20
CHECKING TH E SIDESTAND SWITCH ...... ........ ......... ......... .......... ....... 3-21
CHECKING TH E FRONT FORK ........ .......... ........ ......... .......... ......... ....... 3-21
CHECKING THE REAR SHOCK ABSORBER ASSEMBLIES .......... ...... 3-21
ADJUSTING TH E REAR SHOCK ABSORBER ASSEMBLIES
(for models not equipped with gas cylinders) ...... ......... .......... ......... ....... 3-21
ADJUSTING TH E REAR SHOCK ABSORBER ASSEMBLIES
(for models equipped with gas cylinders) ... ......... ......... .......... ......... ....... 3-22
CHECKING THE ENGINE OIL LEVEL ........ ......... ......... .......... .......... ...... 3-22
CHANGING THE ENGINE OIL .......... .......... ........ ......... .......... ......... ....... 3-23
CHECKING THE BRAKE LIGHT SWITCH ... ......... ......... ......... .......... ..... 3-25
ADJUSTING THE REAR BRAKE LIGHT SWITCH ........ .......... ......... ...... 3-25
CHECKING AND LUBRICATING THE CABLES ... ......... .......... ......... ..... 3-25
CHECKING THE THROTTLE GRIP OPERATION ....... .......... ......... ....... 3-25
LUBRICATING THE THROTTLE GRIP HOUSING AND CABLE ..... ...... 3-26
CHECKING THE SWITCHES, LIGHTS AND SIGNALS .......... .......... ..... 3-27
ADJUSTING THE HEADLIGHT BEAM ...... ......... ......... ........... .......... ...... 3-27
REPLACING THE HEADLIGHT BULB ......... .......... ........ ......... .......... ...... 3-27
PERIODIC MAINTENANCE
EAS20022
PERIODIC MAINTENANCE
EAS30022
INTRODUCTION
This chapter includes all information necessary to perform recommended checks and adjustments. If
followed , these preventive maintenance procedures will ensure more reliable vehicle operation , a lon-
ger service life and reduce the need for costly overhaul work. This information applies to vehicles al-
ready in service as well as to new vehicles that are being prepared for sale. All service technicians
should be familiar with this entire chapter.
EAS30614
• From 24000 mi (37000 km) or 36 months, repeat the maintenance intervals starting from 8000 mi
(13000 km) or 12 months.
• Items marked with an asterisk require special tools, data and technical skills, have a Yamaha dealer
perform the service.
6 • Exhaust system • Replace gasket(s) if neces- ..J ..J ..J ..J ..J ..J
sary.
Evaporative emis-
sion control sys- • Check control system for
7 • damage. ..J ..J
tern (for California
• Replace if necessary.
only)
EAS30615
• From 24000 mi (37000 km) or 36 months, repeat the maintenance intervals starting from 8000 mi
(13000 km) or 12 months.
• Items marked with an asterisk require special tools, data and technical skills, have a Yamaha dealer
perform the service.
3-1
PERIODIC MAINTENANCE
2
tern check
• Check operation.
3 * Clutch
• Adjust or replace cable.
• Check operation, fluid level,
" ..J
" ..J
" ..J
Every 4 years
" ..J
8
* Wheels (cast)
age.
• Check runout, spoke tight-
..J
" ..J
" ..J
damage.
9 * Tires • Replace if necessary.
• Check air pressure.
• Correct if necessary.
..J
" ..J ..J ..J
11 *
Swingarm pivot
bearings
cessive play.
• Moderately repack with lithi-
..J
" ..J
um-soap-based grease.
• Check belt condition.
• Replace if damaged.
12 * Drive belt
•
•
Check belt tension.
Adjust if necessary. " Every 2500 mi (4000 km)
um-soap-based grease.
• Check all chassis fitti ng and
14 * Chassis fasteners
15
shaft
Brake pedal pivot
• Apply silicone grease lightly.
• Apply lithium-soap-based
..J
" ..J ..J ..J
16
shaft
Clutch lever pivot
grease lightly.
• Apply lithium-soap-based
..J
" ..J
" ..J
17
shaft
Shift pedal pivot
grease lightly.
• Apply lithium-soap-based
..J
" ..J ..J ..J
18
shaft grease lightly.
• Check operation.
..J
" ..J ..J ..J
20 * Sidestand switch
if necessary.
" ..J
" ..J
" ..J
3-2
PERIODIC MAINTENANCE
TIP ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
• Air filter
• This model's air filter is equipped with a disposable oil-coated paper element, which must not be
cleaned with compressed air to avoid damaging it.
• The air filter element needs to be replaced more frequently when riding in unusually wet or dusty
areas.
• Hydraulic brake service
• After disassembling the brake master cylinders and calipers, always change the fluid. Regularly
check the brake fluid levels and fill the reservoirs as required.
• Every two years replace the internal components of the brake master cylinders and calipers, and
change the brake fluid.
• Replace the brake hoses every four years and if cracked or damaged.
3-3
PERIODIC MAINTENANCE
EAS32024 EAS30619
NOTICE - -------------
Make sure the fuel tank breather/overflow
hose is routed correctly.
3. Check:
• Fault codes 3. Install:
TIP~~~~~~~~~~~~~~ • Fuel tank
Use the "Diagnosis of malfunction" function of Refer to "FUEL TANK" on page 6-1 .
the Yamaha diagnostic tool to check the fault EAS30620
codes. For information about using the Yamaha CHECKING THE SPARK PLUGS
diagnostic tool, refer to the operation manual The following procedure applies to all of the
that is included with the tool. spark plugs.
1. Remove:
Fault code number is displayed~ Check and
• Rear cylinder right cover
repair the probable cause of the malfunction. Refer to "ENGINE REMOVAL" on page 5-2.
Refer to "TROUBLESHOOTING DETAILS"
2. Disconnect:
on page 7-3 1.
• Spark plug cap
4. Perform: 3. Remove:
• Dynamic inspection
• Spark plug
TIP - - - - - - - - - - - - - - - ~
Use the "Dynamic inspection" function of the
Yamaha diagnostic tool version 3.0 and after to
ECA13320
NOTICE - -------------
Before removing the spark plugs, blow away
perform the dynamic inspection. For information any dirt accumulated in the spark plug wells
about using the Yamaha diagnostic tool, refer to with compressed air to prevent it from falling
the operation manual that is included with the into the cylinders.
tool. 4. Check:
5. Install: • Spark plug type
• Seat Incorrect ~ Change.
Refer to "GENERAL CHASSIS (1)" on page
4-1. Manufacturer/model
NGK/CPR?EA-9
3-4
PERIODIC MAINTENANCE
5. Check: 1. Remove:
• Electrode • Fuel tank
Damage/wear ~ Replace the spark plug. Refer to "FUEL TANK" on page 6-1 .
• Insulator • Front cylinder cover (left)
Abnormal color ~ Replace the spark plug. • Front cylinder cover (right)
Normal color is medium-to-light tan . • Rear cylinder cover (left)
6. C lean : • Rear cylinder cover (right)
• Spark plug Refer to "ENGINE REMOVAL" on page 5-2.
(with a spark plug cleaner or wire brush) 2. Disconnect:
7. Measure: • Throttle position sensor coupler
• Spark plug gap "a" • Fuel hose (fuel filter to inlet pipe assembly)
(with a w ire thickness gauge) Refer to "THROTTLE BODIES" on page 6-8.
Out of specification ~ Regap. 3. Remove:
• Fuel filter
Spark plug gap Refer to "THROTTLE BODIES" on page 6-8.
0.8-0.9 mm (0.031-0.035 in) • Rear cylinder head guard
• Rear cylinder cover bracket (left)
Refer to "ENGINE REMOVAL" on page 5-2.
4. Disconnect:
• Crankcase breather hose
Refer to "GENERAL CHASSIS (3)" on page
4-6.
.- 'I
' 5. Remove:
• Hose holder
Refer to "FUEL TANK" on page 6-1 .
6. Disconnect:
• Spark plug caps
8. Install :
Refer to "ENGINE REMOVAL" on page 5-2.
• Spark plug
7. Remove:
Spark plug • Spark plugs
13 N-m (1.3 kgf-m, 9.4 lb-ft) Refer to "CAMSHAFTS" on page 5-16.
8. Remove:
TIP ~~~~~~~~~~~~~~ • Damper cover
• Generator cover damper
Before installing the spark plug , clean the spark
• Timing mark accessing screw
plug and gasket surface.
• Crankshaft end accessing screw
9. Connect: Refer to "GENERATOR AND STARTER
• Spark plug cap CLUTCH" on page 5-43.
1a.Install: 9. Remove:
• Rear cylinder right cover • Front cylinder tappet covers "1"
Refer to "ENGINE REMOVAL" on page 5-2.
EAS30622
3-5
PERIODIC MAINTENANCE
TTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTT
TTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTT Rear cylinder
Front cylinder a. Turn the crankshaft counterclockwise from
a. Turn the crankshaft counterclockwise. the front cylinder piston TDC by 300 degrees.
b. When the rear cylinder piston is at TDC on
the compression stroke, align the TDC mark
"c" on the generator rotor with the slot "d" in
the generator cover.
TIP ~~~~~~~~~~~~~~
Thickness gauge
90890-03180
Feeler gauge set
YU-26900-9
3-6
PERIODIC MAINTENANCE
12.Adjust: 13.lnstall:
• Valve clearance • Rear cylinder tappet covers
TTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTT • Fuel filter bracket
a. Loosen the locknuts "1". • Front cylinder tappet covers
14.lnstall:
• Crankshaft end accessing screw
(along with the 0-ring l~M\i)
A. / • Timing mark accessing screw
b. Insert a thickness gauge "2" between the end (along with the 0-ring 1~@1 1)
of the adjusting screw "3" and the valve tip. • Generator cover damper
• Damper cover
Thickness gauge Refer to "GENERATOR AND STARTER
90890-03180
CLUTCH" on page 5-43.
Feeler gauge set
YU-26900-9 Damper cover bolt
7 N-m (0.7 kgf-m, 5.1 lb-ft)
c. Turn the adjusting screw in direction "a" or "b"
with the hexagon wrench "4" until the speci- 15.lnstall:
fied valve clearance is obtained. • All removed parts
TIP ~~~~~~~~~~~~~~
Direction "a"
Valve clearance is increased. For installation, reverse the removal procedure.
Direction "b"
Valve clearance is decreased. EAS30800
NOTICE
Locknut (rocker arm adjusting -------------
screw) Make sure the crankcase breather hose is
27 N-m (2. 7 kgf-m, 20 lb-ft) routed correctly.
3-7
PERIODIC MAINTENANCE
• Cap "2"
~7-
~7
~
~
~
~~
3. Install: ~~
• Fuel tank 5. Install:
Refer to "FUEL TANK" on page 6-1 . • Hose "1" (Parts No.: SJW-24311-00)
• Air duct • 3-way joint "2" (Parts No.: 90413-05014)
Refer to "BELT DRIVE" on page 4-69. • Vacuum gauge hose #1 "3"
• Air filter case • Vacuum gauge hose #2 "4"
Refer to "GENERAL CHASSIS (3)" on page • Intake air pressure sensor hose "5"
4-6. • Vacuum gauge "6"
EAS30797
• Digital tachometer
SYNCHRONIZING THE THROTTLE BODIES
Vacuum gauge
TIP ~~~~~~~~~~~~~~ 90890-03094
Before synchronizing the throttle bodies, check Vacuummate
the following items: YU-44456
• Valve clearance Digital tachometer
• Spark plugs 90890-06760
• Air filter element Digital tachometer
YU-39951-B
• Throttle body joints
• Fuel hoses
• Exhaust system
• Canister purge hoses (for California)
• Breather hoses
1. Stand the vehicle on a level surface.
TIP ~~~~~~~~~~~~~~~~
3-8
PERIODIC MAINTENANCE
TIP ~~~~~~~~~~~~~~
0
••••••••••••••••••••••••••••••••
8. Measure:
1~ • Engine idling speed
Out of specification ~ Adjust.
Make sure that the vacuum pressure is within
specification .
9. Stop the engine and remove the measuring
equipment.
1a.Connect:
• Intake air pressure sensor hose
• Cap
11.lnstall:
• Air filter case
Refer to "GENERAL CHASSIS (3)" on page
4-6.
12.Adjust:
• Throttle grip free play
Refer to "CHECKING TH E THROTTLE GRIP
OPERATION" on page 3-25.
EAS30625
3-9
PERIODIC MAINTENANCE
' '
!-), E~
12 ~ 85 3. Check:
g 10 ,~ • Air filter element
11 ___..,., Damage~ Replace.
TIP _ _ _ _ _ _ _ _ _ _ _ _ _ __
EAS30626
CHECKING THE CANISTER (for California) • Replace the air filter element every 37000 km
1. Check: (24000 mi) of operation .
• Canister "1" • The air filter needs more frequent service if you
• Canister purge hose "2" are riding in unusually wet or dusty areas.
• Fuel tank breather/overflow hose "3" 4. Install:
Cracks/damage~ Replace. • Air filter element
~ o~ ~~~~_J~=::.C • Air filter case cover
0 3 - ~ .,:!:
,,. -2
T"B,>- ,' ,, , Air filter case cover bolt
2.0 N-m (0.20 kgf-m, 1.4 lb-ft)
ECA20710 -
NOTICE
-------------
Never operate the engine without the air filter
element installed. Unfiltered air will cause
1 rapid wear of engine parts and may damage
EAS30628
the engine. Operating the engine without the
REPLACING THE AIR FILTER ELEMENT air filter element will also affect throttle body
1. Remove: synchronization, leading to poor engine per-
• Air filter case cover "1" formance and possible overheating.
TIP _ _ _ _ _ _ _ _ _ _ _ _ _ __
3-10
PERIODIC MAINTENANCE
EAS31565
TTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTT
Clutch lever side
a. Loosen the locknut "1"
b. Turn the adjusting bolt "2" in direction "b" or
"c" until the specified clutch lever free play is c. Tighten the locknut to specification .
obtained .
Clutch cable locknut
Direction "b" 7 N-m (0.7 kgf-m, 5.1 lb-ft)
Clutch lever free play is increased.
Direction "c"
Clutch lever free play is decreased EAS30801
3-11
PERIODIC MAINTENANCE
EAS30634
3-12
PERIODIC MAINTENANCE
2. Bleed :
• Hydraulic brake system
0
TTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTT
a. Fill the brake master cylinder reservoir or
brake fluid reservoir to the proper level with
the specified brake fluid.
a a
0 0 00( b. Install the diaphragm (brake master cylinder
~ reservoir or brake fluid reservoir).
c. Connect a clear plastic hose "1" tightly to the
bleed screw "2".
EAS30637
A WARNING
Bleed the hydraulic brake system whenever:
• the system is disassembled.
• a brake hose is loosened, disconnected or
replaced.
• the brake fluid level is very low.
• brake operation is faulty.
ffil /
TIP ~~~~~~~~~~~~~~~~
3-13
PERIODIC MAINTENANCE
A WARNING
After bleeding the hydraulic brake system,
check the brake operation.
••••••••••••••••••••••••••••••••
3. Install:
2. Check:
• Brake hose clamp
• Brake fluid reservoir cover
Loose ~ Tighten the clamp bolt.
Brake fluid reservoir cover bolt 3. Hold the vehicle upright and apply the brake
2.8 N-m (0.28 kgf-m, 2.0 lb-ft) several times.
LOCTITE® 4. Check:
• Brake hoses
EAS30635 Brake fluid leakage ~ Replace the damaged
CHECKING THE FRONT BRAKE HOSE hose.
1. Check: Refer to "REAR BRAKE" on page 4-35.
• Brake hose "1"
EAS31428
Cracks/damage/wear~ Replace.
CHECKING THE WHEELS
The following procedure applies to both of the
wheels.
1. Check:
• Wheel
Damage/out-of-round ~ Replace.
EWA13260
AwARNING
Never attempt to make any repairs to the
wheel.
• Brake hoses "1" A tight spoke will emit a clear, ringing tone; a
Cracks/damage/wear~ Replace. loose spoke will sound flat.
3-14
PERIODIC MAINTENANCE
EWA13181
2. Tighten:
• Spoke AwARNING
(with a spoke nipple wrench "1") • The tire pressure should only be checked
TIP ~~~~~~~~~~~~~~ and regulated when the tire temperature
equals the ambient air temperature.
Be sure to tighten the spokes before and after
break-in . • The tire pressure and the suspension must
be adjusted according to the total weight
(including cargo, rider, passenger and ac-
Spoke nipple wrench (8-9) cessories) and the anticipated riding
90890-01522
speed.
Spoke nipple wrench (8-9)
YM-01522 • Operation of an overloaded vehicle could
cause tire damage, an accident or an injury.
NEVER OVERLOAD THE VEHICLE.
Spoke (front)
3.0 N-m (0.30 kgf -m, 2.2 lb-ft) Tire air pressure (measured on
Spoke (rear) cold tires)
4.0 N-m (0.40 kgf -m, 2.9 lb-ft) Front
225 kPa (2.25 kgf/cm 2 , 33 psi)
Rear
250 kPa (2.50 kgf/cm 2 , 36 psi)
1 Maximum load
207 kg (456 lb)
* Total weight of rider, cargo and accesso-
ries
EWA13190
AwARNING
It is dangerous to ride with a worn-out tire.
EAS31429
When the tire tread reaches the wear limit, re-
CHECKING THE TIRES place the tire immediately.
The following procedure applies to both of the 2. Check:
tires. • Tire surfaces
1. Check: Damage/wear ~ Replace the tire.
• Tire pressure
Out of specification ~ Regulate.
3-15
PERIODIC MAINTENANCE
Front tire
Type
Tubeless (for cast wheel mod-
els)
With tube (for spoke wheel
3 models)
Size
100/90-19M/C 57H
Manufacturer/model
BRIDGESTONE/EXEDRA G721
1. Tire tread depth F (for cast wheel models)
2. Side wall BRIDGESTONE/EXEDRA G721
3. Wear indicator L (for spoke wheel models)
3-16
PERIODIC MAINTENANCE
EAS30641
& WARNING
Securely support the vehicle so that there is
no danger of it falling over.
TIP _ _ _ _ _ _ _ _ _ _ _ _ _ __
Place the vehicle on the sidestand or on a suit-
able stand so that the rear wheel is elevated.
3-17
PERIODIC MAINTENANCE
Direction "a"
Drive belt slack (on a suitable Drive belt is tightened.
stand) Direction "b"
7.0-9.0 mm (0.28-0.35 in) Drive belt is loosened.
TIP ~~~~~~~~~~~~~~
Belt tension gauge
90890-03170 Using the alignment marks "4" on each side of
Rear drive belt tension gauge the swingarm, make sure that both belt pullers
YM-03170 are in the same position for proper wheel align-
ment.
TIP ~~~~~~~~~~~~~~
Measure the drive belt slack when the drive belt
has been pushed with 45 N (4.5 kgf, 10 lbf) of
pressure using the belt tension gauge "1".
I
0
3-18
PERIODIC MAINTENANCE
EAS30645
A WARNING
Do not overtighten the lower ring nut.
Install the upper ring nut and lower ring nut with
their sharp-edged sides "a" facing each other.
g. Finger tighten the upper ring nut "2", and then
align the slots of both ring nuts. If necessary,
3 hold the lower ring nut and tighten the upper
ring nut until their slots are aligned.
h. Install the lock washer "1".
b. Tighten the lower ring nut "4" to specification
TIP~~~~~~~~~~~~~~~~
with a steering nut wrench "5".
Make sure the lock washer tabs "b" sit correctly
Steering nut wrench in the ring nut slots "c".
90890-01403
Exhaust flange nut wrench
YU-A9472
3-19
PERIODIC MAINTENANCE
2 Recommended lubricant
l Lithium-soap-based grease
a
EAS30650
3 AwARNING
Securely support the vehicle so that there is
no danger of it falling over.
••••••••••••••••••••••••••••••••
5. Install:
TIP ~~~~~~~~~~~~~~~~
EAS31567
2. Check:
LUBRICATING THE STEERING BEARINGS • Sidestand vertical movement "A"
Lubricate the steering bearings. Free play is noticeable ~ Replace the defec-
tive part(s) .
Recommended lubricant • Sidestand axial movement "B"
l
Lithium-soap-based grease Unsmooth operation ~ Replace the defec-
tive part(s) .
EAS31802
TTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTT
CHECKING THE CHASSIS FASTENERS a. Tighten the sidestand nut "1" to specification.
Make sure that all nuts, bolts, and screws are
properly tightened. Sidestand nut
Refer to "CHASSIS TIGHTENING TORQUES" 64 N-m (6.4 kgf-m, 46 lb-ft)
on page 2-13. LOCTITE®
EAS30804
b. Check the sidestand vertical movement "A"
LUBRICATING THE BRAKE LEVER
by moving the sidestand up and down.
Lubricate the pivoting point and metal-to-metal
c. Check the sidestand axial movement "B" by
moving parts of the brake lever.
moving the sidestand up and down.
EAS31568
Recommended lubricant
Lithium-soap-based grease
EAS30805
3-20
PERIODIC MAINTENANCE
EAS30652
Refer to "SWINGARM AND REAR SHOCK
CHECKING THE SIDESTAND SWITCH
ABSORBER ASSEMBLIES" on page 4-65.
Refer to "ELECTRICAL COMPONENTS" on
page 7-67. EAS30655
4. Check: NOTICE
• Front fork operation
-------------
Never go beyond the maximum or minimum
Push down hard on the handlebar several adjustment positions.
times and check if the front fork rebounds
smoothly. 1. Adjust:
Rough movement ~ Repair. • Spring preload
Refer to "FRONT FORK" on page 4-52. TIP _ _ _ _ _ _ _ _ _ _ _ _ _ _ _~
Adjust the spring preload with the special
wrench and extension bar included in the own-
er's tool kit 2.
TTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTT
a. Turn the adjusting ring "1" in direction "a" or
"b".
b. Align the desired position on the adjusting
ring with the stopper "2".
Direction "a"
EAS30808 Spring preload is increased (suspen-
CHECKINGTHEREARSHOCKABSORBER sion is harder).
ASSEMBLIES Direction "b"
1. Check: Spring preload is decreased (suspen-
• Damper rod sion is softer).
• O il leakage
• Gas leakage (for models equipped with gas
Adjusting positions
cylinders)
Standard
• Spring 2
Refer to "CHECKING TH E REAR SHOCK Minimum (soft)
ABSORBER ASSEMBLIES" on page 4-67. 1
2. Check: Maximum (hard)
• Operation 5
Pump the rear shock absorber assemblies up
and down several times.
Unsmooth operation ~ Replace rear shock
absorber assembly.
3-21
PERIODIC MAINTENANCE
Adjusting positions
Standard
1 notch out*
Minimum (soft)
O notches out*
Maximum (hard)
4 notches out*
* : from the fully turned-in position
2
EAS31610
- ~ 1 ,--,
ADJUSTING THE REAR SHOCK ABSORBER ' '\ ,,. '1 ,."
I
I ,.
I II ~
' 1 , ..I
I J I
'
I
I
'
I
I
'
... , i I
'
cylinders)
The following procedure applies to both of the
rear shock absorber assemblies.
EWA17520
A WARNING
• Securely support the vehicle so that there
is no danger of it falling over.
EAS30656
• Always adjust both rear shock absorber as-
CHECKING THE ENGINE OIL LEVEL
semblies evenly. Uneven adjustment can
1. Stand the vehicle on a level surface.
result in poor handling and loss of stability.
TIP ~----------------------------~
• Place the vehicle on the suitable stand.
Spring preload
ECA13590
• Make sure that the vehicle is upright.
NOTICE--~~~~~~~~~~~ 2. Let the engine idle for a few minutes, and
Never go beyond the maximum or minimum then turn it off.
adjustment positions. 3. Remove:
1. Adjust: • Dipstick "1"
4. Check:
• Spring preload
• Engine oil level
TIP ------------------------------~ The engine oil level should be between the
Adjust the spring preload with the special minimum level mark "a" and maximum level
wrench and extension bar included in the own- mark "b".
er's tool kit 2. Below the minimum level mark ~ Add the
TTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTT recommended engine oil to the proper level.
a. Turn the adjusting ring "1" in direction "a" or TIP ~----------------------------~
"b".
• Before checking the engine oil level, wait a few
b. Align the desired position on the adjusting minutes until the oil has settled .
ring with the stopper "2". • Do not screw the dipstick in when inspecting
the oil level.
Direction "a"
Spring preload is increased (suspen-
sion is harder).
Direction "b"
Spring preload is decreased (suspen-
sion is softer).
3-22
PERIODIC MAINTENANCE
EAS30657
Recommended brand
YAMALUBE
SAE viscosity grades
1OW-40, 1OW-50, 1SW-40, 20W-
40 or 20W-50
Recommended engine oil grade
API service SG type or higher,
JASO standard MA
i SAE
.. .
10..W -50
. . .
1.5W-<IO
. .
.. ..
E 20W-40'.
j SAF 20~-5~
I I I I I I I I
-20 -10 0 10 20 30 40 5o ·c
ECA13361
NOTICE
-------------
• Engine oil also lubricates the clutch and the 4. Drain:
wrong oil types or additives could cause • Engine oil
clutch slippage. Therefore, do not add any (completely from the crankcase)
chemical additives or use engine oils with a 5. If the oil filter cartridge is also to be replaced,
grade of "CD" or higher and do not use oils perform the following procedure.
labeled "ENERGY CONSERVING 11". TTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTT
a. Remove the oil filter cartridge "1" with an oil
• Do not allow foreign materials to enter the
filter wrench "2".
crankcase.
5. Start the engine, warm it up for several min- Oil filter wrench
utes, and then turn it off. 90890-01426
6. Check the engine oil level again . Oil filter wrench
TIP _ _ _ _ _ _ _ _ _ _ _ _ _ _ __ YU-38411
Before checking the engine oil level, wait a few
minutes until the oil has settled.
7. Install:
• Dipstick
3-23
PERIODIC MAINTENANCE
••••••••••••••••••••••••••••••••
6. Install :
1
(along with the 0-ring ilf:S\i) b. Start the engine and keep it idling until engine
9. Check: oil starts to seep from the oil check bolts. If no
• Engine oil level engine oil comes out after one minute, turn
Refer to "C HECKING T HE ENGIN E O IL the engine off so that it will not seize.
LEVEL" on page 3-22. c. Check the engine oil passages, the oil filter
cartridge and the oil pump for damage or
leakage. Refer to "O IL PUMP" on page 5-74.
3-24
PERIODIC MAINTENANCE
••••••••••••••••••••••••••••••••
15.lnstall:
• Rear cylinder cover bracket (right)
• Rear cylinder cover (right)
EAS30660
Rear cylinder cover bracket bolt
(right) CHECKING AND LUBRICATING THE
20 N-m (2.0 kgf-m, 14 lb-ft) CABLES
Rear cylinder cover bolt (right) The following procedure applies to all of the in-
8 N-m (0.8 kgf-m, 5.8 lb-ft) ner and outer cables.
EWA13270
3-25
PERIODIC MAINTENANCE
TIP ~~~~~~~~~~~~~~
Throttle grip free play If the specified throttle grip free play cannot be
4.0-6.0 mm (0.16-0.24 in) obtained on the throttle body side of the cable,
use the adjusting nut on the handlebar side.
'
r1 ~I -- TTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTT
\ Handlebar side
.A
)
0 a. Loosen the locknut "1" .
b. Turn the adjusting nut "2" indirection "a" or "b"
ED II I a until the specified throttle grip free play is ob-
I
) tained.
ED c.../
l Direction "a"
4. Remove: Throttle grip free play is increased.
Direction "b"
• Fuel tank
Throttle grip free play is decreased.
Refer to "FUEL TANK" on page 6-1 .
5. Adjust:
c. Tighten the locknut.
• Throttle grip free play
TIP ~~~~~~~~~~~~~~~~
TTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTT 2
Throttle body side
a. Loosen the locknut "1" on the accelerator ca-
ble.
b. Turn the adjusting nut "2" in direction "a" or "b"
until the specified throttle grip free play is ob-
••••••••••••••••••••••••••••••••
6. Install:
tained . • Fuel tank
Refer to "FUEL TANK" on page 6-1 .
Direction "a"
Throttle grip free play is increased. EAS31575
3-26
PERIODIC MAINTENANCE
EAS30663
Direction "a"
Headlight beam is raised.
Direction "b"
Headlight beam is lowered.
2. Disconnect:
• Headlight coupler "2"
Q 3. Remove:
• Headlight bulb cover "3"
••••••••••••••••••••••••••••••••
2. Adjust:
• Headlight beam (horizontally)
TTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTT
a. Turn the adjusting screw "1" with a screw
driver in direction "a" or "b".
Direction "a"
Headlight beam moves to the left.
Direction "b"
Headlight beam moves to the right.
3-27
PERIODIC MAINTENANCE
EWA13320
A WARNING
Since the headlight bulb gets extremely hot,
keep flammable products and your hands
away from the bulb until it has cooled down.
6. Install :
• Headlight bulb il@:i
Secure the new headlight bulb with the head-
light bulb holder.
ECA13690
NOTICE
-------------
Avoid touching the glass part of the head-
light bulb to keep it free from oil, otherwise
the transparency of the glass, the life of the
bulb and the luminous flux will be adversely
affected. If the headlight bulb gets soiled,
thoroughly clean it with a cloth moistened
with alcohol or lacquer thinner.
7. Attach:
• Headlight bulb holder
8. Install :
• Bulb cover
TIP - - - - - - - - - - - - - - -
When installing the headlight bulb cover, make
sure the "TOP" mark "1" faces upwards.
9. Connect:
• Headlight coupler
1a.Install:
• Headlight lens unit
3-28
PERIODIC MAINTENANCE
3-29
CHASSIS
GENERAL CHASSIS (1) ........ ......... .......... ......... .......... ........ ......... .......... ........ 4-1
INSTALLING THE RIDER SEAT ......... ......... ........ .......... ......... .......... ........ 4-2
GENERAL CHASSIS (2) ........ ......... .......... ......... .......... ........ ......... .......... ........ 4-3
INSTALLING THE TOOL BOX .......... ........ ......... .......... ......... ......... ......... .. 4-5
GENERAL CHASSIS (3) ........ ......... .......... ......... .......... ........ ......... .......... ........ 4-6
FRONT WHEEL ... .......... ......... .......... ......... ......... .......... ........ .......... ......... ...... 4-1 O
REMOVING THE FRONT WHEEL ...... ......... ......... ......... ......... .......... ...... 4-12
DISASSEMBLING THE FRONT WHEEL .... ......... ......... ........... .......... ..... 4-12
CHECKING THE FRONT WHEEL ...... .......... ......... ........ .......... ......... ...... 4-12
ASSEMBLING THE FRONT WHEEL ......... .......... ......... .......... .......... ...... 4-13
ADJUSTING THE FRONT WHEEL STATIC BALANCE ......... .......... ...... 4-13
INSTALLING THE FRONT WHEEL (FRONT BRAKE DISC) ... .......... ..... 4-14
REARWHEEL .... .......... ......... .......... ......... ........ .......... ......... .......... ......... ....... 4-16
REMOVING THE REAR WHEEL (DISC) ..... ........ ......... .......... ......... ....... 4-20
DISASSEMBLING THE REAR WHEEL ...... ......... .......... .......... .......... ..... 4-20
CHECKING THE REAR WHEEL ......... .......... ......... ......... ......... ......... ...... 4-20
CHECKING THE REAR BRAKE CALIPER BRACKET ... ......... .......... ..... 4-20
CHECKING THE REAR WHEEL DRIVE HUB ....... ......... .......... ......... ..... 4-20
CHECKING AND REPLACING THE REAR WHEEL PULLEY .......... ..... 4-21
ASSEMBLING THE REAR WHEEL .... ......... .......... ........ .......... ......... ...... 4-21
ADJUSTING THE REAR WHEEL STATIC BALANCE ... ......... .......... ...... 4-21
INSTALLING THE REAR WHEEL (REAR BRAKE DISC) ...... ......... ....... 4-21
FRONT BRAKE ... .......... ......... .......... ......... ......... .......... ........ .......... ......... ...... 4-23
INTRODUCTION ..... ......... .......... ......... .......... .......... ........ .......... ......... ..... 4-28
CHECKING THE FRONT BRAKE DISC ..... ......... ......... ........... .......... ..... 4-28
REPLACING THE FRONT BRAKE PADS ... ........ .......... ......... .......... ...... 4-29
REMOVING THE FRONT BRAKE CALI PER ...... .......... ......... .......... ....... 4-30
DISASSEMBLING THE FRONT BRAKE CALIPER ...... .......... ......... ....... 4-30
CHECKING THE FRONT BRAKE CALIPERS ....... ......... ......... .......... ..... 4-30
ASSEMBLING THE FRONT BRAKE CALIPER .... .......... ......... .......... ..... 4-31
INSTALLING THE FRONT BRAKE CALIPER ...... ......... .......... ......... ...... 4-31
REMOVING THE FRONT BRAKE MASTER CYLINDER ...... .......... ....... 4-32
CHECKING THE FRONT BRAKE MASTER CYLINDER .. ......... ......... .... 4-32
ASSEMBLING THE FRONT BRAKE MASTER CYLINDER .... .......... ..... 4-33
INSTALLING THE FRONT BRAKE MASTER CYLINDER ....... ......... ...... 4-33
REAR BRAKE .... .......... ......... .......... ......... ........ .......... ......... .......... ......... ....... 4-35
INTRODUCTION ..... ......... .......... ......... .......... .......... ........ .......... ......... ..... 4-41
CHECKING THE REAR BRAKE DISC ....... ......... .......... .......... .......... ...... 4-41
REPLACING THE REAR BRAKE PADS ..... ......... .......... .......... .......... ..... 4-41
REMOVING THE REAR BRAKE CALIPER ........ .......... ......... .......... ....... 4-42
DISASSEMBLING THE REAR BRAKE CALIPER ........... ......... ......... ..... 4-42
CHECKING THE REAR BRAKE CALIPER .......... ......... ........... .......... ..... 4-43
ASSEMBLING THE REAR BRAKE CALIPER ....... ......... .......... ......... ..... 4-43
INSTALLING THE REAR BRAKE CALIPER ........ .......... ......... .......... ...... 4-43
REMOVING THE REAR BRAKE MASTER CYLINDER ......... .......... ...... 4-44
CHECKING THE REAR BRAKE MASTER CYLINDER .. ......... .......... ..... 4-45
ASSEMBLING THE REAR BRAKE MASTER CYLINDER ...... ......... ....... 4-45
INSTALLING THE REAR BRAKE MASTER CYLINDER .......... ......... ..... 4-45
HANDLEBAR ..... .......... ......... .......... ......... ........ .......... ......... .......... ......... ....... 4-47
REMOVING THE HANDLEBAR ........ ......... ......... ........... ......... .......... ...... 4-49
CHECKING THE HANDLEBAR ......... ......... ......... .......... ......... .......... ...... 4-49
INSTALLING THE HANDLEBAR ........ .......... ......... ........ .......... ......... ...... 4-49
FRONT FORK ..... .......... ......... .......... ......... ........ .......... ......... .......... ......... ....... 4-52
REMOVING THE FRONT FORK LEGS ........ ......... ......... ......... .......... ..... 4-55
DISASSEMBLING THE FRONT FORK LEGS ...... ........ ........... .......... ..... 4-55
CHECKING THE FRONT FORK LEGS ....... .......... ......... ......... .......... ..... 4-56
ASSEMBLING THE FRONT FORK LEGS ... ........ .......... ......... .......... ...... 4-56
INSTALLING THE FRONT FORK LEGS ..... .......... ........ .......... ......... ...... 4-59
STEERING HEAD .......... ......... .......... ......... ......... .......... ........ .......... ......... ...... 4-61
REMOVING THE LOWER BRACKET .......... ........ .......... ......... ......... ....... 4-63
CHECKING THE STEERING HEAD .......... ......... .......... .......... ......... ....... 4-63
INSTALLING THE STEERING HEAD ........ ......... .......... ......... .......... ....... 4-63
SWINGARM AND REAR SHOCK ABSORBER ASSEMBLIES ... .......... ...... 4-65
REMOVING THE SWINGARM AND REAR SHOCK ABSORBER
ASS EM BLI ES ......... ......... ......... .......... ......... ......... ......... ......... .......... ...... 4-66
CHECKING THE SWINGARM .. ......... .......... ........ .......... .......... ......... ...... 4-66
HANDLING THE REAR SHOCK ABSORBER AND GAS CYLINDER
(for models equipped with gas cylinders) .... ........ ......... .......... ......... ....... 4-66
DISPOSING OF A REAR SHOCK ABSORBER
(for models equipped with gas cylinders) .... ........ ......... .......... ......... ....... 4-67
CHECKING THE REAR SHOCK ABSORBER ASSEMBLIES .......... ...... 4-67
INSTALLING THE SWINGARM AND REAR SHOCK ABSORBER
ASSEMBLIES ......... ......... ......... .......... ......... ......... ......... ......... .......... ...... 4-67
BELT DRIVE ......... .......... .......... .......... ........... .......... .......... .......... .......... ........ 4-69
REMOVING THE DRIVE BELT AND DRIVE PULLEY .. .......... ......... ...... 4-70
CHECKING THE DRIVE BELT .......... .......... ........ .......... .......... .......... ..... 4-70
INSTALLING THE DRIVE BELT AND DRIVE PULLEY ........... .......... ..... 4-70
GENERAL CHASSIS (1)
EAS20026
3
/
~ _.. ..
_.....
...... . - ..
---
-
1
7 N·m 0.7 k f·m, 5.1 lb.ft
8
7
6
-
B
7 N·m (0.7 kgf·m, 5.1 lb·ft) 2.8 N·m (0.28 kgf·m, 2.0 lb·ft)
4-1
GENERAL CHASSIS (1)
EAS31125
TIP ~~~~~~~~~~~~~~
4-2
GENERAL CHASSIS (2)
EAS20155
-~-
,J
.~ C· ~~
~-
8
'
· , · '-.._
8
(
"
10 g
4-3
GENERAL CHASSIS (2)
19
14 15
r 18
11
12 13
<$QI 11 (
"
@
~-
~ ~or~ J\@
~ 'h"<j ~~k::._,/"""'-'
~~---
14 /---/---
15 20 13~
11 Relay unit 1
12 Turn signal relay 1
13 Headlight relay 1
14 Fuse box 1
15 Main fuse 1
16 Starter relay coupler 1 Disconnect.
17 Starter relay cover 1
18 Starter motor lead 1 Disconnect.
19 Positive battery lead (starter relay) 1 Disconnect.
20 Starter relay 1
4-4
GENERAL CHASSIS (2)
EAS31576
~. - a
' '
l ~ \\~
I
(o
4-5
GENERAL CHASSIS (3)
EAS20156
1 0
(4)
4-6
GENERAL CHASSIS (3)
4-7
GENERAL CHASSIS (3)
14
65 N·m (6.5 kgf·m, 47 lb·ft) 1O N·m (1.0 kgf·m, 7.2 lb·ft) I~!3.8 N·m (0.38 kgf·m, 2.8 lb·ft) I 1:::::::5'
Order Job/Parts to remove Q 'ty Remarks
Disconnect.
11 Rear turn signal light coupler (left) 1 Refer to "CABLE ROUTING" on page 2-25.
Disconnect.
12 Rear turn signal light coupler (right) 1 Refer to "CABLE ROUTING" on page 2-25.
13 Rear turn signal light (left) 1
14 Rear turn signal light (right) 1
15 Sub-wire harness coupler (tail/brake light) 1 Disconnect.
16 Tail/brake light 1
17 Grommet 1
18 Tool box guide 1
19 Battery box 1
20 Lean angle sensor 1
4-8
GENERAL CHASSIS (3)
4-9
FRONT WHEEL
EAS20028
FRONT WHEEL
Removing the front wheel and brake disc
'
I
•
'
,, \. I ~ 4
'
---
<. '
'
''
/
'
' '
,
' ' .. _____ ,, ,
6
23 N·m 2.3 k f·m , 17 lb·ft
4-10
FRONT WHEEL
1~tM1
21~-
'
I
'
I
'
I
'
I
'
------
, /
/
/
,
/,
,,.. ..
,/
, /'
/ 3
/. ,
, , '/ 21~&
11~&
1 Oil seal 2
2 Wheel bearing 2
3 Spacer 1
4-11
FRONT WHEEL
EAS30145
A WARNING
Securely support the vehicle so that there is
no danger of it falling over.
2. Remove:
• Front brake caliper
TIP ~~~~~~~~~~~~~~~~
A WARNING
EAS30146 Do not attempt to straighten a bent wheel ax-
DISASSEMBLING THE FRONT WHEEL le.
1. Remove:
• Oil seals
• Wheel bearings
TTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTT
a. C lean the outside of the front wheel hub.
b. Remove the oil seals "1" with a flathead
screwdriver.
TIP ~~~~~~~~~~~~~~
2. Check:
• Tire
• Front wheel
Damage/wear ~ Replace.
Refer to "CHECKING TH E T IRES" on page
3-15 and "CH ECKING T HE WH EELS" on
0
~~~
(~ page 3-14.
I ~
0 2
'--'I
3. Check (for spoke wheel models) :
• Spoke
Bends/damage ~ Replace.
c. Remove the wheel bearings "3" with a gener- Loose~ Tighten.
al bearing puller. Refer to "CHECKING AND T IGHT ENING
THE SPOKES (for spoke wheel models)" on
page 3-14.
TIP ~~~~~~~~~~~~~~~~
4-12
FRONT WHEEL
TIP ~~~~~~~~~~~~~~
Radial wheel runout limit
Use a socket "4" that matches the diameter of
1.0 mm (0.04 in) (for cast wheel
models) the wheel bearing outer race and oil seal.
2.0 mm (0.08 in) (for spoke
wheel models)
Lateral wheel runout limit +
0.5 mm (0.02 in) (for cast wheel
models)
2.0 mm (0.08 in) (for spoke
wheel models) n=fi=i--- 3
'1
2
EAS30152
EAS30151
~
• O il seals i~tii
TTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTT
a. Install the new wheel bearings and oil seals in X,
the reverse order of disassembly.
ECA18 110
NOTICE
c. Turn the front wheel 90° so that the "X1" mark
--------------
Do not contact the wheel bearing inner race
is positioned as shown .
d. Release the front wheel.
"1 " or balls "2". Contact should be made
only with the outer race "3". e. When the wheel stops, put an "X2" mark at
the bottom of the wheel.
4-13
FRONT WHEEL
TTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTT
a. Turn the front wheel and make sure it stays at
each position shown .
X
X,
•
X X
•••••••••••••••••••••••••••••••• ••••••••••••••••••••••••••••••••
3. Adjust: EAS30932
TIP ~~~~~~~~~~~~~~~~
X •
2. Check:
• Front brake disc
Refer to "CHECKING THE FRONT BRAKE
DISC" on page 4-28.
c. If the heavy spot does not stay in that posi- 3. Lubricate:
tion , install a heavier weight. • Oil seal lips
d. Repeat steps (b) and (c) until the front wheel
is balanced. Recommended lubricant
I
••••••••••••••••••••••••••••••••
4. Check:
Lithium-soap-based grease
4-14
FRONT WHEEL
4. Tighten:
• Front wheel axle
• Front wheel axle pinch bolt
NOTICE
-------------
Before tightening the wheel axle, push down
hard on the handlebars several times and
check if the front fork rebounds smoothly.
TTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTT
a. Insert the front wheel axle from the right side
and tighten it to 59 N-m (5.9 kgf-m , 43 lb-ft) .
b. In the order pinch bolt "1" ~ pinch bolt "2" ~
pinch bolt "1", tighten each bolt to 20 N-m (2.0
kgf-m , 14 lb-ft) without performing temporary
tightening .
/',
-
)
(
= j
••••••••••••••••••••••••••••••••
5. Install :
• Front brake caliper
AwARNING
Make sure the brake hose is routed properly.
4-15
REAR WHEEL
EAS20029
REAR WHEEL
Removing the rear wheel
'------------~
4-16
REAR WHEEL
10
'------------ ~
9 Rear wheel 1
10 Collar (left) 1
11 Collar (right) 1
12 Rear brake caliper bracket 1
4-17
REAR WHEEL
Removing the rear brake disc and rear wheel drive hub
2
(6) ~
I
I
I
I
1 I
I
I
I '
I I
(., I
I
' ' I '
' ' I
' ' I
' ' I
1'',,,,
12 ' I
I
I
I
I 11
' I
'
4-18
REAR WHEEL
1~f4jj2
31~&
4
I
I '
,I
.-
'I ;,'
I
'I ,/ '
/
I
_..
'
'
'I ,~
/
' -- ,
'
' ''
11~-
/
I
'
\
1 Bearing 1
2 Oil seal 1
3 Bearing 1
4 Spacer 1
4-19
REAR WHEEL
EAS30156
• Oil seals
REMOVING THE REAR WHEEL (DISC)
Refer to "CH ECKING TH E FRONT WH EEL"
1. Stand the vehicle on a level surface.
EWA13 120
on page 4-1 2 .
A WARNING 2. Check:
Securely support the vehicle so that there is • Tire
• Rear wheel
no danger of it falling over.
Damage/wear ~ Replace.
TIP ~~~~~~~~~~~~~~~ Refer to "CHECKING THE T IRES" on page
Place the vehicle on a suitable stand so that the 3-15 and "CH ECKING TH E WHEELS" on
rear wheel is elevated . page 3-14.
3. Check (for spoke wheel models) :
2. Remove:
• Spoke
• Rear brake caliper Bends/damage ~ Replace.
TIP ~~~~~~~~~~~~~~ Loose~ Tighten .
Do not depress the brake pedal when removing Refer to "CHECKING AND T IGHTENING
the brake caliper. THE SPOKES (for spoke wheel models)" on
3. Loosen: page 3-14.
TIP ~~~~~~~~~~~~~~
• Drive belt adjusting locknuts "1"
• Drive belt adjusting bolts "2" After tightening the spokes, measure the wheel
I(__) runout.
1 4. Measure:
• Radial wheel runout
• Lateral wheel runout
Refer to "CH ECKING TH E FRONT WH EEL"
on page 4-1 2 .
4-20
REAR WHEEL
EAS30162
1. Adjust:
CHECKING AND REPLACING THE REAR
• Rear wheel static balance
WHEEL PULLEY
Refer to "ADJUSTING TH E FRONT WH EEL
1. Check:
STATIC BALANCE" on page 4-1 3.
• Rear wheel pulley
Surface plating has come off ~ Replace the EAS30911
EAS30163
4-21
REAR WHEEL
1~ ,
5. Adjust:
• Drive belt slack
Refer to "ADJUSTING THE DRIVE BELT
SLACK" on page 3-1 7.
6. Tighten:
• Rear wheel axle nut
7. Install:
• Rear brake caliper
A WARNING
Make sure the brake hose is routed properly.
4-22
FRONT BRAKE
EAS20030
FRONT BRAKE
Removing the front brake pads
4
27 N·m (2.7 kgf·m, 20 lb·ft)
4 3 5
4-23
FRONT BRAKE
1 4
~ 12
5
i§Mfig
8
Drain.
Brake fluid Refer to "BLEEDING THE HYDRAULIC
BRAKE SYSTEM" on page 3-13.
1 Rearview mirror (right) 1
2 Brake master cylinder reservoir cap 1
Brake master cylinder reservoir diaphragm hold-
3
er
1
4-24
FRONT BRAKE
11~-
4-25
FRONT BRAKE
Drain.
Brake fluid Refer to "BLEEDING THE HYDRAULIC
BRAKE SYSTEM" on page 3-13.
1 Front brake hose union bolt 1
2 Brake hose gasket 2
3 Front brake hose 1
4 Front brake caliper bracket bolt 2
5 Front brake caliper 1
4-26
FRONT BRAKE
10
·~-8
·~-9
~
7
~
27 N·m (2.7 kgf·m, 20 lb·ft)
3 2
81~-
7 91~ffl,Q
4-27
FRONT BRAKE
EAS30168
TTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTT
INTRODUCTION a. Place the vehicle on a suitable stand so that
EWA14 10 1
the front wheel is elevated .
AwARNING
b. Before measuring the front brake disc deflec-
Disc brake components rarely require disas- tion, turn the handlebar to the left or right to
sembly. Therefore, always follow these pre- ensure that the front wheel is stationary.
ventive measures: c. Remove the brake caliper.
• Never disassemble brake components un- d. Hold the dial gauge at a right angle against
less absolutely necessary. the brake disc surface.
• If any connection on the hydraulic brake e. Measure the deflection 1.5 mm (0.06 in) be-
system is disconnected, the entire brake
low the edge of the brake disc.
system must be disassembled, drained,
cleaned, properly filled, and bled after reas- ••••••••••••••••••••••••••••••••
4. Measure:
sembly.
• Brake disc thickness
• Never use solvents on internal brake com-
Measure the brake disc thickness at a few dif-
ponents.
ferent locations.
• Use only clean or new brake fluid for clean-
Out of specification ~ Replace.
ing brake components.
• Brake fluid may damage painted surfaces Brake disc thickness limit
and plastic parts. Therefore, always clean 4.5 mm (0.18 in)
up any spilt brake fluid immediately.
• Avoid brake fluid coming into contact with
the eyes as it can cause serious injury.
FIRST AID FOR BRAKE FLUID ENTERING
THE EYES:
• Flush with water for 15 minutes and get im-
mediate medical attention.
EAS30169
9i .
. \ n-0)
TIP ~~~~~~~~~~~~~~~
4-28
FRONT BRAKE
TIP ~~~~~~~~~~~~~~
NOTICE
- - - - - - - - - - - - -
• Do not allow grease to contact the brake
pads.
• Remove any excess grease.
4. Install:
• Front brake caliper bolts
2. Install : 5. Check:
• Brake pad supports • Brake fluid level
• Brake pad spring Below the minimum level mark "a" ~ Add the
• Brake pad shims specified brake fluid to the proper level.
(onto the brake pads) Refer to "CHECKING THE BRAKE FLUID
• Brake pads LEVEL" on page 3-12.
4-29
FRONT BRAKE
3
1 2
6. Check: TTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTT
• Brake lever operation a. Blow compressed air into the brake hose joint
Soft or spongy feeling ~ Bleed the brake sys- opening "a" to force out the piston from the
tem. brake caliper.
EWA13S60
Refer to "BLEEDING TH E HYDRAULIC
BRAKE SYSTEM" on page 3-13.
& WARNING
• Cover the brake caliper pistons with a rag.
EAS30724
Be careful not to get injured when the pis-
REMOVING THE FRONT BRAKE CALIPER tons are expelled from the brake caliper.
TIP ~~~~~~~~~~~~~~ • Never try to pry out the brake caliper pis-
Before removing the brake caliper, drain the tons.
brake fluid from the entire brake system.
1. Remove:
• Front brake hose union bolt "1"
• Brake hose gaskets
• Front brake hose "2"
4-30
FRONT BRAKE
AwARNING NOTICE
-------------
Whenever a brake caliper is disassembled, When installing the brake hose onto the
replace the brake caliper piston dust seals brake caliper "1 " , make sure the brake pipe
and brake caliper piston seals. "a" touches the projection "b" on the brake
caliper.
,
1
,,
,'
,
A
2
I
2. Check:
• Brake caliper bracket 2. Remove:
Cracks/damage~ Replace. • Front brake caliper
3. Install:
EAS30174
• Brake pad supports
ASSEMBLING THE FRONT BRAKE CALIPER
EWA16560
• Brake pad spring
AwARNING • Brake pad shims
• Before installation, all internal brake com- (onto the brake pads)
ponents should be cleaned and lubricated • Brake pads
with clean or new brake fluid. • Front brake caliper
• Never use solvents on internal brake com- Front brake caliper bolt
ponents as they will cause the brake caliper 27 N-m (2.7 kgf-m, 20 lb-ft)
piston dust seals and brake caliper piston Front brake caliper bracket bolt
seals to swell and distort. 40 N-m (4.0 kgf-m, 29 lb-ft)
• Whenever a brake caliper is disassembled,
replace the brake caliper piston dust seals Refer to "REPLACING TH E FRONT BRAKE
and brake caliper piston seals. PADS" on page 4-29.
4. Fill:
Specified brake fluid • Brake master cylinder reservoir
D0T4 (with the specified amount of the specified
brake fluid)
EAS30934
4-31
FRONT BRAKE
EWA13540 EAS30179
deteriorate, causing leakage and poor Before removing the front brake master cylinder,
brake performance. drain the brake fluid from the entire brake sys-
• Refill with the same type of brake fluid that tem.
is already in the system. Mixing brake fluids
1. Remove:
may result in a harmful chemical reaction,
• Front brake hose union bolt "1"
leading to poor brake performance.
• Brake hose gaskets "2"
• When refilling, be careful that water does
• Front brake hose "3"
not enter the brake master cylinder reser-
TIP _ _ _ _ _ _ _ _ _ _ _ _ _ _ _~
voir. Water will significantly lower the boil-
ing point of the brake fluid and could cause To collect any remaining brake fluid, place a
vapor lock. container under the master cylinder and the end
ECA13540
of the brake hose.
NOTICE
-------------
Bra ke fluid may damage painted surfaces ®
and plastic parts. Therefore, always clean up
any spilt brake fluid immediately.
5. Bleed:
• Brake system
Refer to "BLEEDING THE HYDRAULIC
BRAKE SYSTEM" on page 3-13.
6. Check:
• Brake fluid level
EAS30725
Below the minimum level mark "a" ~ Add the
CHECKINGTHEFRONTBRAKEMASTER
specified brake fluid to the proper level.
CYLINDER
Refer to "CHECKING THE BRAKE FLUID
1. Check:
LEVEL" on page 3-12.
• Brake master cylinder
Damage/scratches/wear~ Replace.
• Brake fluid delivery passages
(brake master cylinder body)
Obstruction~ Blow out with compressed air.
2. Check:
• Brake master cylinder kit
Damage/scratches/wear ~ Replace.
3. Check:
• Brake master cylinder reservoir
Cracks/damage ~ Replace.
7. Check:
• Brake master cylinder reservoir diaphragm
• Brake lever operation
Damage/wear ~ Replace.
Soft or spongy feeling ~ Bleed the brake sys-
4. Check:
tem.
• Brake hose
Refer to "BLEEDING THE HYDRAULIC
Cracks/damage/wear~ Replace.
BRAKE SYSTEM" on page 3-13.
4-32
FRONT BRAKE
EAS3018 1
TIP ~~~~~~~~~~~~~~
ASSEMBLING THE FRONT BRAKE MASTER
CYLINDER • Install the brake hose to the front brake master
EWA13520 cylinder within the angle shown in the illustra-
AwARNING tion.
• Before installation, all internal brake com- • While holding the brake hose, tighten the union
ponents should be cleaned and lubricated bolt.
with clean or new brake fluid. • Turn the handlebar to the left and right to make
• Never use solvents on internal brake com- sure the brake hose does not touch other parts
ponents. (e.g., wire harness, cables, and leads). Correct
if necessary.
Specified brake fluid
DOT4
EAS30182
• First, tighten the upper bolt, then the lower bolt. AwARNING
• Use only the designated brake fluid. Other
brake fluids may cause the rubber seals to
deteriorate, causing leakage and poor
brake performance.
• Refill with the same type of brake fluid that
is already in the system. Mixing brake fluids
may result in a harmful chemical reaction,
leading to poor brake performance.
• When refilling, be careful that water does
not enter the brake master cylinder reser-
2. Install: voir. Water will significantly lower the boil-
ing point of the brake fluid and could cause
• Brake hose gaskets ilt¥i
vapor lock.
• Front brake hose "1"
ECA13540
• Front brake hose union bolt "2"
NOTICE
-------------
Front brake hose union bolt Bra ke fluid may damage painted surfaces
30 N-m (3.0 kgf-m, 22 lb-ft) and plastic parts. Therefore, always clean up
EWA13531
any spilt brake fluid immediately.
AwARNING 4. Bleed :
Proper brake hose routing is essential to in- • Brake system
sure safe vehicle operation. Refer to "BLEEDING THE HYDRAULIC
BRAKE SYSTEM" on page 3-13.
Refer to "CABLE ROUTING" on page 2-25.
4-33
FRONT BRAKE
5. Check:
• Brake fluid level
Below the minimum level mark "a" ~ Add the
specified brake fluid to the proper level.
Refer to "CHECKING THE BRAKE FLUID
LEVEL" on page 3-12.
6. Check:
• Brake lever operation
Soft or spongy feeling ~ Bleed the brake sys-
tem.
Refer to "BLEEDING THE HYDRAULIC
BRAKE SYSTEM" on page 3-13.
4-34
REAR BRAKE
EAS20031
REAR BRAKE
Removing the rear brake pads
5
4
4 0
0
5
,
4-35
REAR BRAKE
,•
Drain.
Brake fluid Refer to "BLEEDING THE HYDRAULIC
BRAKE SYSTEM" on page 3-13.
4-36
REAR BRAKE
,•
4-37
REAR BRAKE
21~-
3
~ ---4·~-
------ I'
,' ~
5
-
~
4-38
REAR BRAKE
--' 0
4 0
3
Drain.
Brake fluid Refer to "BLEEDING THE HYDRAULIC
BRAKE SYSTEM" on page 3-13.
1 Rear brake hose union bolt 1
2 Brake hose gasket 2
3 Rear brake hose 1
4 Rear brake caliper bolt 2
5 Rear brake caliper 1
4-39
REAR BRAKE
7
8
·~-3
4
7
4-40
REAR BRAKE
EAS30183
4-41
REAR BRAKE
TTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTT
a. Connect a clear plastic hose "1" tightly to the
bleed screw "2". Put the other end of the hose
into an open container.
b. Loosen the bleed screw and push the brake
caliper piston into the brake caliper with your
fingers.
7. Check:
1 • Brake pedal operation
Soft or spongy feeling~ Bleed the brake sys-
tem.
Refer to "BLEEDING THE HYDRAULIC
BRAKE SYSTEM" on page 3-13.
EAS30186
c. Tighten the bleed screw to specification.
REMOVING THE REAR BRAKE CALIPER
Rear brake caliper bleed screw TIP ~~~~~~~~~~~~~~
6 N-m (0.6 kgf-m, 4.3 lb-ft) Before removing the brake caliper, drain the
brake fluid from the entire brake system.
d. Install new brake pad springs, brake pad
shims, and brake pads. 1. Remove:
• Rear brake hose union bolt "1"
••••••••••••••••••••••••••••••••
4. Lubricate:
• Brake hose gaskets "2"
• Rear brake hose "3"
• Rear brake caliper bolt
TIP _ _ _ _ _ _ _ _ _ _ _ _ _ _ _~
Recommended lubricant Put the end of the brake hose into a container
Silicone grease and pump out the brake fluid carefully.
ECA14 1SO
NOTICE
-------------
• Do not allow grease to contact the brake
pads.
• Remove any excess grease.
5. Install :
• Rear brake caliper bolt 2
4-42
REAR BRAKE
EWA135SO
A WARNING
• Cover the brake caliper piston with a rag.
Be careful not to get injured when the pis-
1
ton is expelled from the brake caliper.
• Never try to pry out the brake caliper pis-
ton.
EAS30189
A WARNING
• Before installation, all internal brake com-
ponents should be cleaned and lubricated
with clean or new brake fluid.
• Never use solvents on internal brake com-
b. Remove the brake caliper piston dust seal
ponents as they will cause the brake caliper
and brake caliper piston seal.
piston dust seal and brake caliper piston
••••••••••••••••••••••••••••••••
EAS30188
seal to swell and distort.
• Whenever a brake caliper is disassembled,
CHECKINGTHEREARBRAKECALIPER replace the brake caliper piston dust seal
Recommended brake component replacement and brake caliper piston seal.
schedule
Brake pads If necessary Specified brake fluid
Piston dust seal Every two years D0T4
Piston seal Every two years EAS30190
Brake hose Every four years INSTALLING THE REAR BRAKE CALIPER
Every two years and 1. Install:
Brake fluid whenever the brake is • Rear brake caliper "1"
disassembled (temporarily)
4-43
REAR BRAKE
5. Bleed :
• Brake system
Refer to "BLEEDING T HE HYDRAULIC
BRAKE SYSTEM" on page 3-13.
6. Check:
• Brake fluid level
Below the minimum level mark "a" ~ Add the
specified brake fluid to the proper level.
Refer to "CHECKING THE BRAKE FLUID
LEVEL" on page 3-12.
2. Remove:
• Rear brake caliper
3. Install:
• Brake pad shims
(onto the brake pads)
• Brake pads
• Brake pad springs
• Rear brake caliper
Refer to "REPLACING THE REAR BRAKE
PADS" on page 4-4 1.
7. Check:
Rear brake caliper bolt • Brake pedal operation
27 N-m (2. 7 kgf-m, 20 lb-ft) Soft or spongy feeling ~ Bleed the brake sys-
tem.
4. Fill :
Refer to "BLEEDING T HE HYDRAULIC
• Brake fluid reservoir
BRAKE SYSTEM" on page 3-13.
(with the specified amount of the specified
brake fluid) EAS30193
NOTICE
-------------
Bra ke fluid may damage painted surfaces
and plastic parts. Therefore, always clean up
any spilt brake fluid immediately.
---1
3
---~1
2
4-44
REAR BRAKE
EAS30194 EAS30196
CHECKING THE REAR BRAKE MASTER INSTALLING THE REAR BRAKE MASTER
CYLINDER CYLINDER
1. Check: 1. Install:
• Brake master cylinder • Rear brake light switch "1"
Damage/scratches/wear ~ Replace. TIP ~~~~~~~~~~~~~~~~
• Brake fluid delivery passages • The rear brake light switch installation length
(brake master cylinder body) "a" should be 8.5 mm (0.33 in).
Obstruction~ Blow out with compressed air. • Install the rear brake light switch spring "2" as
2. Check: shown in the illustration.
• Brake master cylinder kit
Damage/scratches/wear ~ Replace.
3. Check:
• Brake fluid reservoir
Cracks/damage~ Replace.
• Brake fluid reservoir diaphragm
Cracks/damage ~ Replace.
4. Check:
• Brake hoses
Cracks/damage/wear~ Replace. 2
EAS30195
2. Install:
ASSEMBLINGTHEREARBRAKEMASTER
CYLINDER • Brake hose gaskets "1" ilf:il1i
EWA13520 • Rear brake hose "2"
& WARNING • Rear brake hose union bolt "3"
• Before installation, all internal brake com-
Rear brake hose union bolt
ponents should be cleaned and lubricated
30 N-m (3.0 kgf -m, 22 lb-ft)
with clean or new brake fluid.
• Never use solvents on internal brake com- EWA13531
----~
C)
---1
2 3
1 iltM
3. Install:
• Rear brake hose holder "1"
4-45
REAR BRAKE
TIP ~~~~~~~~~~~~~~
7. Check:
• Brake pedal operation
Soft or spongy feeling~ Bleed the brake sys-
tem.
Refer to "BLEEDING THE HYDRAULIC
BRAKE SYSTEM" on page 3-13.
4. Fill: 8. Adjust:
• Brake fluid reservoir • Rear brake light operation timing
(with the specified amount of the specified Refer to "ADJUSTING THE REAR BRAKE
brake fluid) LIGHT SWITCH" on page 3-25.
A WARNING
• Use only the designated brake fluid. Other
brake fluids may cause the rubber seals to
deteriorate, causing leakage and poor
brake performance.
• Refill with the same type of brake fluid that
is already in the system. Mixing brake fluids
may result in a harmful chemical reaction,
leading to poor brake performance.
• When refilling, be careful that water does
not enter the brake fluid reservoir. Water
will significantly lower the boiling point of
the brake fluid and could cause vapor lock.
ECA13540
NOTICE
-------------
Bra ke fluid may damage painted surfaces
and plastic parts. Therefore, always clean up
any spilt brake fluid immediately.
5. Bleed:
• Brake system
Refer to "BLEEDING TH E HYDRAULIC
BRAKE SYSTEM" on page 3-13.
6. Check:
• Brake fluid level
Below the minimum level mark "a" ~ Add the
specified brake fluid to the proper level.
4-46
HANDLEBAR
EAS20033
HANDLEBAR
Removing the handlebar
3.8 N·m (0.38 kgf·m, 2.8 lb·ft)
12
-
B ~- 9
10
1 Rearview mirror 2
2 Front brake light switch connector 2 Disconnect.
3 Front brake master cylinder holder 1
4 Front brake master cylinder assembly 1
5 Handlebar switch (right) 1
6 Throttle cable 2 Disconnect.
7 Throttle grip 1
8 Clutch switch coupler 1 Disconnect.
9 Handlebar switch (left) 1
10 Handlebar grip 1
11 Clutch cable 1 Disconnect.
12 Clutch lever 1
4-47
HANDLEBAR
..
~ 28 N·m (2.8 kgf·m, 20 lb·ft)
18
. 1O N·m (1.0 kgf·m, 7.2 lb·ft)
-
B
13 Clutch switch 1
14 Clutch lever holder 1
15 Meter assembly bracket 1
16 Meter assembly coupler 1 Disconnect.
17 Meter assembly 1
18 Upper handlebar holder 2
19 Handlebar 1
20 Lower handlebar holder 2
21 Cable guide 1
4-48
HANDLEBAR
EAS30203
TIP ~~~~~~~~~~~~~~
REMOVING THE HANDLEBAR
1. Stand the vehicle on a level surface. Align the end of the upper handlebar holder with
EWA13 120 the punch mark "a" on the handlebar.
AwARNING
Securely support the vehicle so that there is
no danger of it falling over.
2. Remove:
• Handlebar grip "1"
TIP - - - - - - - - - - - - - - - ~
Blow compressed air between the handlebar
and the handlebar grip, and gradually push the
grip off the handlebar.
3. Install:
• Meter assembly bracket "1"
TIP - - - - - - - - - - - - - - - ~
1 Make sure that the leads are routed properly
through the guide. Refer to "CABLE ROUTING"
on page 2-25.
EAS30204
AwARNING
Do not attempt to straighten a bent handle-
bar as this may dangerously weaken it.
EAS30205
NOTICE
-------------
First, tighten the bolts on the front side of the
handlebar holder, and then on the rear side.
a
4-49
HANDLEBAR
2 a
••••••••••••••••••••••••••••••••
8. Install:
• Throttle cables "1"
(to the right handlebar switch "2")
6. Install:
• Handlebar switch (left) "1" Throttle cable bracket screw
3.8 N-m (0.38 kgf-m, 2.8 lb-ft)
Handlebar switch screw (left)
3.5 N-m (0.35 kgf-m, 2.5 lb-ft)
TIP ~~~~~~~~~~~~~~~~
9. Install:
• Handlebar switch (right) "1"
7. Install: TIP~~~~~~~~~~~~~~~~
• Handlebar grip "1" Align the projection "a" on the right handlebar
TTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTT switch with the hole "b" in the handlebar.
a. Apply a thin coat of rubber adhesive onto the
left end of the handlebar.
b. Slide the handlebar grip over the left end of
the handlebar.
c. Wipe off any excess rubber adhesive with a
clean rag .
EWA13700 1
& WARNING
Do not touch the handlebar grip until the rub- 1
ber adhesive has fully dried.
4-50
HANDLEBAR
1a.Install:
• Front brake master cylinder "1"
• Front brake master cylinder holder "2"
TIP ~~~~~~~~~~~~~~
11.Adjust:
• Clutch lever free play
Refer to "ADJUSTING TH E CLUTCH LEVER
FREE PLAY" on page 3-11.
12.Adjust:
• Throttle grip free play
Refer to "CH ECKING TH E THROTTLE GRIP
OPERATION" on page 3-25.
4-51
FRONT FORK
EAS20034
FRONT FORK
Removing the front fork legs
'
-'
' '
''
'
''
'' '
13 ' '
'
'' ' ''
'
' ''
8 '
'
9 '' ' '
'
7 N·m (0.7 kgf·m, 5.1 lb·ft) '
' ''
'
-----------
23 N·m 2.3 k f·m, 17 lb·ft 16 N·m 1.6 k f·m , 12 lb·ft '
'' '
'
'
'
'' '
'
'
''
. 23 N·m (2.3 kgf·m, 17 lb·ft) '
~ 1 ,,' ,''
3 ~- '--.....J :
1.5 N·m (0.15 kgf·m, 1.1 lb·ft) ----, ''
4-52
FRONT FORK
2~
·~ta3--~~
14
6-~
1
12~ ,
13--@
L___
:""-- 10 ·~ta
9
B ~ 30 N·m (3.0 kgf·m, 22 lb·ft)
1 Protector 1
2 Front fork cap bolt 1
3 0-ring 1
4 Spacer 1
5 Spring seat 1
6 Fork spring 1
7 Dust seal 1
8 Oil seal clip 1
9 Front fork damper rod bolt 1
10 Copper washer 1
11 Damper rod 1
12 Damper rod ring 1
13 Rebound spring 1
14 Inner tube 1
15 Oil seal 1
4-53
FRONT FORK
20
16 Washer 1
17 Outer tube bushing 1
18 Inner tube bushing 1
19 Oil flow stopper 1
20 Outer tube 1
4-54
FRONT FORK
EAS30206
AwARNING
Securely support the vehicle so that there is
no danger of it falling over.
TIP - - - - - - - - - - - - - - - ~
Place the vehicle on a suitable stand so that the 3. Remove:
front wheel is elevated . • Front fork damper rod bolt "1"
• Copper washer
2. Loosen:
TIP ~~~~~~~~~~~~~~
• Front fork cap bolt
• Upper bracket pinch bolt While holding the damper rod with the damper
• Lower bracket pinch bolts rod holder "2" and T-handle "3", loosen the front
EWA18000 fork damper rod bolt.
AwARNING
Before loosening the lower bracket pinch Damper rod holder (022)
bolts, support the front fork leg. 90890-01365
T-handle
EAS30207 90890-01326
DISASSEMBLINGTHEFRONTFORKLEGS T-handle 3/8 " drive 60 cm long
The following procedure applies to both of the YM-01326
front fork legs.
1. Drain :
• Fork oil
TIP _ _ _ _ _ _ _ _ _ _ _ _ _ _ _~ 2
Stroke the outer tube several times while drain-
ing the fork oil. ---------
3
4. Remove:
• Inner tube
TTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTT
4-55
FRONT FORK
ECA14200
NOTICE
.. - - - - - - - - - - - - - -
• The front fork leg has a built-in damper ad-
justing rod and a very sophisticated inter-
nal construction, which are particularly
sensitive to foreign material.
• When disassembling and assembling the
front fork leg, do not allow any foreign ma-
terial to enter the front fork.
Fl
EAS30209
AwARNING TIP _ _ _ _ _ _ _ _ _ _ _ _ _ _ _~
Do not attempt to straighten a bent inner • When assembling the front fork leg, be sure to
tube as this may dangerously weaken it. replace the following parts:
2. Measure: - Inner tube bushing
• Fork spring free length "a" -Outer tube bushing
Out of specification ~ Replace. -Oil seal
- Dust seal
Fork spring free length • Before assembling the front fork leg , make
322.2 mm (12.69 in) sure all of the components are clean .
Limit
315.7 mm (12.43 in) 1. Install:
• Inner tube bushing "1" i~Mi
• Damper rod "2"
• Damper rod ring
---...__ a • Rebound spring
• Oil flow stopper "3"
ECA22740
NOTICE ~~~~~~~~~~~~
Allow the damper rod to slide slowly down
the inner tube until it protrudes from the bot-
tom of the inner tube. Be careful not to dam-
age the inner tube.
3. Check:
• Damper rod
Damage/wear ~ Replace.
Obstruction ~ Blow out all of the oil passag-
es with compressed air. 3
• Oil flow stopper
Damage ~ Replace. 4
2 1 •~•
4. Inner tube
4-56
FRONT FORK
2. Lubricate:
• Inner tube's outer surface Fork seal driver weight
90890-01367
Recommended oil Replacement hammer
I YM-A9409-7
Yamaha Suspension Oil G1 O
Fork seal driver attachment (041)
3. Install: 90890-01381
• Inner tube Replacement 41 mm
(in the outer tube) YM-A5142-2
4. Install:
• Copper washer i~Mi
• Front fork damper rod bolt
5. Tighten:
• Front fork damper rod bolt "1" 3
IUI
2 I
--r=:: ,
Front fork damper rod bolt .. - --
30 N-m (3.0 kgf-m, 22 lb-ft) ,------,\
LOCTITE® 1~tM1
TIP _ _ _ _ _ _ _ _ _ _ _ _ _ _ _~
7. Install:
While holding the damper rod assembly with the
damper rod holder "2" and T-handle "3", tighten • Oil seal "1" i~M
the front fork damper rod bolt. (with the fork seal driver attachment "2" and
fork seal driver weight "3")
ECA14220
4-57
FRONT FORK
2
w
l
·~tMJ1
1O.Fill:
• Front fork leg
(with the specified amount of the recom-
mended fork oil)
3
IJ
Quantity (left)
2 547.0 cm 3 (18.49 US oz, 19.29
,:=:-=::~
·~-1 ____-f-<:::: .
I
Imp.oz)
Quantity (right)
547.0 cm 3 (18.49 US oz, 19.29
Imp.oz)
8. Install: Recommended oil
• Oil seal clip "1" i~M Yamaha Suspension Oil G1 O
TIP ~~~~~~~~~~~~~~~~
11.Measure:
Adjust the oil seal clip so that it fits into the outer • Front fork leg oil level "a"
tube's groove. (from the top of the inner tube, with the outer
tube fully compressed and without the fork
spring)
Out of specification ~ Correct.
Level (left)
I
116 mm (4.6 in)
Level (right)
116 mm (4.6 in)
TIP ~~~~~~~~~~~~~~~~
p ';
'i
~+' "
12.lnstall:
• Fork spring
• Spring seat
• Spacer
4-58
FRONT FORK
Make sure the inner tube end is flush with the top
of the upper bracket.
@)
EAS30210
4-59
FRONT FORK
EWA13680
A WARNING
Make sure the brake hoses are routed prop-
erly.
4-60
STEERING HEAD
EAS20035
STEERING HEAD
Removing the upper bracket and lower bracket
'
3
~ 4
-~
'
'
4-61
STEERING HEAD
17
14
'
16 ~
15 ----,
' 17 --@)
-~
18 '
4-62
STEERING HEAD
EAS30213
b. Remove the bearing race from the lower
REMOVING THE LOWER BRACKET
bracket with a floor chisel "2" and hammer.
1. Stand the vehicle on a level surface.
EWA13 120
c. Install a new dust seal and new bearing rac-
A WARNING es.
Securely support the vehicle so that there is
no danger of it falling over.
ECA14270
NOTICE - --------------
1f the bearing race is not installed properly,
2. Remove: the steering head pipe could be damaged.
• Upper ring nut
TIP ~~~~~~~~~~~~~~
• Rubber washer
• Lower ring nut "1" • Always replace the bearings and bearing races
• Lower bracket as a set.
EWA13730 • Whenever the steering head is disassembled ,
A WARNING replace the dust seal.
Securely support the lower bracket so that
there is no danger of it falling.
TIP ~~~~~~~~~~~~~~
EAS30214
••••••••••••••••••••••••••••••••
4. Check:
CHECKING THE STEERING HEAD • Upper bracket
1. Wash : • Lower bracket
• Bearings (along with the steering stem)
• Bearing races Bends/cracks/damage ~ Replace.
Recommended cleaning solvent EAS30216
I
Kerosene INSTALLING THE STEERING HEAD
1. Lubricate:
2. Check: • Upper bearing
• Bearings • Lower bearing
• Bearing races • Bearing races
Damage/pitting ~ Replace.
3. Replace: Recommended lubricant
• Bearings Lithium-soap-based grease
• Bearing races
TTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTT 2. Install:
a. Remove the bearing races from the steering • Lower bracket
head pipe with a long rod "1" and hammer. • Lower bracket cap
4-63
STEERING HEAD
Face the hole "a" in the lower bracket cap rear- Align the projection "a" on the front brake hose
ward. holder with the hole "b" in the lower bracket.
3. Install:
• Lower ring nut "1"
• Rubber washer "2"
• Upper ring nut "3"
• Lock washer "4"
Refer to "CHECKING AND ADJUSTING
THE STEERING HEAD" on page 3- 19.
4. Install:
• Upper bracket
• Washer
• Steering stem nut
TIP ~~~~~~~~~~~~~~~
7. Install:
• Front brake hose holder "1"
• Headlight bracket
4-64
SWINGARM AND REAR SHOCK ABSORBER ASSEMBLIES
EAS20197
4
6
91~-
4-65
SWINGARM AND REAR SHOCK ABSORBER ASSEMBLIES
EAS31596 EAS31307
& WARNING
This rear shock absorber and gas cylinder
contain highly compressed nitrogen gas. Be-
fore handling the rear shock absorber or gas
cylinder, read and make sure you under-
stand the following information. The manu-
facturer cannot be held responsible for
4-66
SWINGARM AND REAR SHOCK ABSORBER ASSEMBLIES
TIP ~~~~~~~~~~~~~~
CHECKINGTHEREARSHOCKABSORBER 5 1 3 2 2 1 3 5
ASSEMBLIES 6 6
1. Check:
• Rear shock absorber rod
Bends/damage ~ Replace the rear shock
l
absorber assembly.
• Rear shock absorber 4 4
O il leaks ~ Replace the rear shock absorber
assembly. (for models not equipped with gas
- -a a-i-,,, -
A. Left side
cylinders) B. Right side
Gas leaks/oil leaks ~ Replace the rear shock
3. Install:
absorber assembly. (for models equipped
• Pivot shaft nut
w ith gas cylinders)
4-67
SWINGARM AND REAR SHOCK ABSORBER ASSEMBLIES
4. Install:
• Rear shock absorber assembly "1"
TIP ~~~~~~~~~~~~~~
Make sure that the slot "a" in the rear shock ab-
sorber assembly faces inward. (for models not
equipped with gas cylinders)
1
u
5. Tighten:
• Rear shock absorber assembly upper bolt
6. Tighten:
• Rear shock absorber assembly lower nut
7. Adjust:
• Drive belt slack
Refer to "ADJUSTING TH E DR IVE BELT
SLACK" on page 3-1 7.
4-68
BELT DRIVE
EAS20039
BELT DRIVE
Removing the drive belt
6
,a
(3) 0 Ou"'i
8 N·m (0.8 kgf·m, 5.8 lb·ft) ~ 140 N·m (14 kgf·m, 100 lb·ft)
4-69
BELT DRIVE
EAS30235
NOTICE
-
-- - - - - - - - - - - - -
PULLEY • To protect the drive belt from damage, han-
1. Straighten the drive pulley nut ribs "a". dle it with care.
• The drive belt can not be bent smaller than
125 mm (4.92 in) "a".
• The removed drive belt can not be twisted
inside out.
a
2. Loosen:
• Drive pulley nut
TIP ~~~~~~~~~~~~~~
drive belt from the rear wheel pulley. Refer to INSTALLING THE DRIVE BELT AND DRIVE
"ADJUSTING THE DRIVE BELT SLACK" on PULLEY
page 3- 17. 1. Install:
• Drive belt
ECA22720
EAS30236
2. Install:
• Washer
• Drive pulley nut ilt¥i
TIP - - - - - - - - - - - - - - - ~
Install the washer with its "OUT' mark facing out-
ward .
••••••••••••••••••••••••••••••••
2. Check: 3. Tighten:
• Drive belt • Drive pulley nut
4-70
BELT DRIVE
TIP ~~~~~~~~~~~~~~
4. Adjust:
• Drive belt slack
Refer to "ADJUSTING THE DRIVE BELT
SLACK" on page 3-1 7.
4-71
ENGINE
ENGINE INSPECTION .. ......... ......... .......... ......... .......... ........ ......... .......... ........ 5-1
MEASURE THE COMPRESSION PRESSURE ... ........ ........... ......... ......... 5-1
ENGINE REMOVAL ..... ......... ......... .......... ........ .......... ......... ......... .......... ......... 5-2
INSTALLING THE EXHAUST PIPE ... .......... ........ ......... ......... .......... ....... 5-12
INSTALLING THE MUFFLER ... ......... .......... ........ .......... ......... ......... ....... 5-12
INSTALLING THE SHIFT ARM ......... ........ .......... ......... ......... ......... ......... 5-13
ADJUSTING THE SHIFT PEDAL ........ ......... .......... ........ ......... .......... ...... 5-13
INSTALLING THE HORN .......... ......... .......... ........ ......... .......... ......... ....... 5-14
REMOVING THE ENGINE ........ ......... .......... ........ ......... ......... .......... ....... 5-14
INSTALLING THE ENGINE ........ ......... ......... ........ .......... ......... ......... ....... 5-14
CAMSHAFTS .. .... .......... ......... .......... ......... ........ .......... ......... .......... ......... ....... 5-16
REMOVING THE CAMSHAFTS AND ROCKER ARMS .......... ......... ...... 5-20
CHECKING THE CAMSHAFTS ......... ........ .......... .......... ......... .......... ...... 5-21
CHECKING THE CAMSHAFT SPROCKETS ..... .......... ......... .......... ....... 5-22
CHECKING THE ROCKER ARMS AND ROCKER ARM SHAFTS ........ 5-22
CHECKING THE TIMING CHAIN TENSIONERS .......... .......... .......... ..... 5-22
INSTALLING THE ROCKER ARMS AND CAMSHAFTS ........ .......... ...... 5-23
INSTALLING THE CYLINDER HEAD COVERS .......... .......... ......... ........ 5-25
CYLINDER HEADS ....... .......... .......... ........... .......... .......... .......... .......... ......... 5-27
REMOVING THE CYLINDER HEADS .......... ......... ......... .......... ......... ..... 5-28
CHECKING THE CYLINDER HEADS ........ ......... .......... ......... .......... ....... 5-28
INSTALLING THE CYLINDER HEADS ...... ......... .......... ......... ......... ........ 5-28
VALVES AND VALVE SPRINGS ..... .......... .......... .......... .......... .......... .......... . 5-30
REMOVING THE VALVES ......... .......... .......... ......... .......... ........ .......... .... 5-31
CHECKING THE VALVES AND VALVE GUIDES .......... ......... ......... ...... 5-31
CHECKING THE VALVE SEATS ........ .......... ......... ......... .......... ......... ..... 5-33
CHECKING THE VALVE SPRINGS ... .......... .......... ........ .......... ......... ...... 5-34
INSTALLING THE VALVES ....... ......... ......... .......... ........ .......... ......... ...... 5-35
CYLINDER AND PISTONS ... ......... .......... ........ .......... ......... ......... .......... ....... 5-37
REMOVING THE PISTONS ........ ......... ......... ......... ........ ......... ......... ....... 5-38
CHECKING THE CYLINDERS AND PISTONS ..... ........ .......... .......... ..... 5-38
CHECKING THE PISTON RINGS ....... ......... ........ .......... ......... .......... ...... 5-39
CHECKING THE PISTON PINS ......... .......... ........ ......... .......... ......... ....... 5-40
INSTALLING THE PISTONS AND CYLINDERS ... ........ .......... .......... ..... 5-40
GENERATOR AND STARTER CLUTCH ......... .......... ......... .......... .......... ...... 5-43
REMOVING THE GENERATOR ......... ......... .......... ........ ......... .......... ...... 5-46
REMOVING THE STARTER CLUTCH ........ ........ ......... .......... ......... ....... 5-46
CHECKING THE STARTER CLUTCH ....... ......... .......... ......... .......... ....... 5-46
INSTALLING THE STARTER CLUTCH ....... ........ .......... ......... ......... ....... 5-47
INSTALLING THE GENERATOR ....... .......... ........ .......... ......... ......... ....... 5-47
INSTALLING THE GENERATOR COVER .... ......... ......... ......... .......... ..... 5-48
CLUTCH .... ......... .......... .... ..... .... ...... .... ..... .... ..... ......... ......... .......... ......... .... ... 5-49
REMOVING T HE PR IMARY DRIVE G EAR ......... ......... ......... .......... ....... 5-55
REMOVING TH E CLUTCH ......... ......... .......... ......... .......... ........ .......... .... 5-55
CHECKING TH E FRICTION PLATES ....... .......... .......... ......... .......... ....... 5-55
CH ECKING TH E CLUTCH PLATES .......... ......... .......... ......... .......... ....... 5-56
CHECKING TH E CLUTCH S PRI NG PLATE ........ ......... .......... .......... ...... 5-56
CHECKING TH E CLUTCH HOUSING ...... .......... .......... ......... .......... ....... 5-56
CH ECKING TH E CLUTCH BOSS ....... ......... .......... ........ .......... .......... ..... 5-57
CHECKING TH E PRESSU RE PLATE ....... .......... ......... .......... ......... ....... 5-57
CHECKING TH E PRI MARY DR IVE GEAR .. .......... ........ .......... .......... ..... 5-57
CH ECKING TH E PRIMARY DR IVEN GEAR ...... .......... .......... .......... ...... 5-57
CHECKING TH E PULL LEVER SHAFT AND PULL ROD ...... ......... ....... 5-57
CHECKING TH E OIL PUM P DRIVE S PROCKET AND O IL PUM P
DRIVE CHAIN ....... .......... ......... ......... .......... ........ .......... ......... .......... ...... 5-57
INSTALLING THE CLUTCH ....... ......... ......... .......... ........ .......... ......... ...... 5-57
INSTALLING THE PRIMARY DRIVE GEAR ........ ......... .......... ......... ....... 5-60
SHIFT SHAFT ..... .......... .... ..... .... ...... .... ..... .... .... .......... ......... .......... ......... .... ... 5-6 1
CHECKING TH E SH IFT SHAFT ......... ......... .......... ........ .......... .......... ..... 5-62
CHECKING TH E STOP PER LEVER ......... ......... ......... ........... .......... ...... 5-62
INSTALLING THE SHIFT SHAFT ....... ......... .......... ........ ......... .......... ...... 5-62
ELECTRIC STARTER .. ......... ......... .......... ........ .......... ......... .......... ......... ....... 5-63
CHECKING TH E STARTER MOTOR ........ .......... .......... ......... .......... ...... 5-65
ASS EMBLING TH E STARTER MOTOR ...... .......... ........ ......... .......... ...... 5-66
CR.ANKCASE ..... .......... ......... .......... ......... ........ .......... ......... .......... ......... ....... 5-67
DISASSEMBLING THE CRANKCASE ........ ......... ........ ........... .......... ...... 5-71
CHECKING TH E CRANKCASE ......... ........ .......... ......... .......... ......... ....... 5-71
CH ECKi NG TH E SEARi NGS AND 0 1L SEAL ...... .......... ......... ......... ...... 5-7 1
CHECKING TH E OIL DELIVERY PIPES ..... ......... ......... ......... .......... ...... 5-71
CHECKING TH E T IMING CHAINS .... .......... ........ .......... .......... ......... ...... 5-71
CHECKING TH E OIL PUMP DR IVEN S PROCKET ...... .......... .......... ...... 5-71
INSTALLING THE B EAR ING RETAIN ERS .. ......... ......... .......... .......... ..... 5-71
ASSEMBLING TH E CRANKCASE ..... .......... ........ .......... .......... ......... ...... 5-72
OIL PUMP ... ......... .......... ......... .... ...... .... ..... .... ..... .......... .... .... .......... ......... ...... 5-74
CHECKING TH E OIL PUMP ..... ......... .......... ........ .......... ......... ......... ....... 5-75
CHECKING TH E RELIEF VALVE ...... .......... .......... ........ .......... ......... ...... 5-75
CHECKING TH E OIL STRAINER ...... .......... ........ .......... ......... .......... ...... 5-75
ASS EMBLING TH E OIL PUMP ......... ......... ......... ......... .......... ......... ........ 5-75
INSTALLING THE OIL PUMP ASSEMBLY ... ........... .......... .......... .......... . 5-76
CR.ANKSHAFT ... .......... ......... .......... ......... ........ .......... ......... .......... ......... ....... 5-77
REMOVING TH E CONN ECTING RODS ..... .......... ........ ......... .......... ...... 5-78
CHECKING TH E CRANKSHAFT AND CONN ECTING RODS .......... ..... 5-78
INSTALLING THE CONN ECTING RODS .... .......... ........ .......... .......... ..... 5-80
INSTALLING THE CRANKSHAFT ASSEMBLY .... .......... ......... .......... ..... 5-81
TRANSMISSION .. .......... ......... .......... ......... ......... .......... ........ .......... ......... ...... 5-82
CHECKING THE SHIFT FORKS ........ .......... ........ .......... .......... ......... ...... 5-87
CHECKING THE SHIFT DRUM ASSEMBLY ......... .......... .......... .......... ... 5-87
CHECKING THE TRANSMISSION .... .......... ........ .......... ......... .......... ...... 5-87
ASSEMBLING THE MAIN AXLE AND DRIVE AXLE .... .......... .......... ...... 5-88
INSTALLING THE SHIFT FORKS AND SHIFT DRUM ASSEMBLY ...... 5-88
ENGINE INSPECTION
EAS20041
ENGINE INSPECTION
EAS30249
7. Measure:
MEASURE THE COMPRESSION PRESSURE
• Compression pressure
The following procedure applies to all of the cyl-
Out of specification~ Refer to steps (c) and
inders.
(d) .
TIP _ _ _ _ _ _ _ _ _ _ _ _ _ _ __
Insufficient compression pressure will result in a Compression pressure
loss of performance. 1218-1568 kPa/400 r/min (12.2-
15.7 kgf/cm 2/400 r/min, 173.2-
1. Measure: 223.0 psi/ 400 r/min)
• Valve clearance
Out of specification ~ Adjust. TTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTT
Refer to "ADJUSTING TH E VALVE CLEAR- a. Set the main switch to "ON".
ANCE" on page 3-5. b. W ith the throttle wide open, crank the engine
2. Start the engine, warm it up for several m in- until the reading on the compression gauge
utes, and then turn it off. stabilizes.
3. Remove: TIP _ _ _ _ _ _ _ _ _ _ _ _ _ _ __
• Rear cylinder cover (right) The difference in compression pressure be-
Refer to "ENGINE REMOVAL" on page 5-2. tween cylinders should not exceed 100 kPa (1.0
4. Disconnect: kgf/cm 2 , 14.5 psi).
• Spark plug caps
5. Remove: c. If the compression pressure is above the
maximum specification, check the cylinder
• Spark plug
ECA13340 head , valve surfaces and piston crown for
NOTICE carbon deposits.
-------------
Before removing the spark plugs, use com- Carbon deposits ~ Eliminate.
pressed air to blow away any dirt accumulat- d. If the compression pressure is below the min-
ed in the spark plug wells to prevent it from imum specification, pour a teaspoonful of en-
falling into the cylinders. gine oil into the spark plug bore and measure
again.
6. Install : Refer to the following table.
• Compression gauge "1"
Compression pressure (with oil applied into the
• Extension "2" cylinder)
Compression gauge Reading Diagnosis
90890-03081 Piston ring(s) wear or
Higher than without oil
Engine compression tester damage ~ Replace.
YU-33223 Piston, valves or cylin-
Extension der head gasket possi-
90890-04136 Same as without oil
bly defective ~
Replace.
J ••••••••••••••••••••••••••••••••
8. Install:
• Spark plug
Spark plug
13 N-m (1.3 kgf-m, 9.4 lb-ft)
9. Connect:
• Spark plug caps
1a.Install:
• Rear cylinder cover (right)
Refer to "ENGIN E REMOVAL" on page 5-2.
5-1
ENGINE REMOVAL
EAS20042
ENGINE REMOVAL
Removing the muffler and exhaust pipe
I
(5) -@ 45 N·m (4.5 kgf·m, 33 lb·ft)
B , . ,. . ._ _
20 N·m (2.0 kgf·m, 14 lb·ft)
,/
2 Muffler 1
3 Clamp 1
4 Gasket 1
5 Exhaust pipe protector 1 1
6 Exhaust pipe 1
7 Gasket 2
8 Exhaust pipe joint cover 1
5-2
ENGINE REMOVAL
,-,) 16
5-3
ENGINE REMOVAL
I
(5) -@ 45 N·m (4.5 kgf·m, 33 lb·ft)
B , . ,. . _ _
20 N·m (2.0 kgf·m, 14 lb·ft)
,/
18 0 2 sensor 1
19 Muffler bracket 1
5-4
ENGINE REMOVAL
?
I 3
11
24 N·m 2.4 k f·m , 17 lb·ft
5-5
ENGINE REMOVAL
?
I
13 Damper 1
14 Dowel pin 2
15 Sidestand switch coupler 1 Disconnect.
16 Sidestand 1
17 Shift pedal 1
18 Shift arm 1
19 Shift rod 1
5-6
ENGINE REMOVAL
2
2
-,
'
I
LJ
5-7
ENGINE REMOVAL
7
-,
'
I
LJ
5-8
ENGINE REMOVAL
5
~ 88 N·m 8.8 k f·m , 64 lb·ft
\ 6
Drain.
Engine oil Refer to "CHANGING THE ENGINE OIL'.' on
page 3-23.
1 Engine mounting nut (front lower side) 1
2 Engine mounting nut (rear lower side) 1
3 Engine mounting nut (front upper side) 1
4 Engine mounting nut (rear upper side) 1
5 Engine mounting bolt (front lower side) 1
6 Engine bracket bolt (front lower side) 2
5-9
ENGINE REMOVAL
\
9
9
5-10
ENGINE REMOVAL
-
88 N·m 8.8 k f·m , 64 lb·ft B
88 N·m (8.8 kgf·m, 64 lb·ft)
15 Lock washer 1
16 Engine mounting bolt (rear upper side) 1
17 Engine bracket bolt (rear upper side) 2
18 Engine bracket (rear upper side) 1
19 Engine 1
5-11
ENGINE REMOVAL
EAS31587
d. Crimp the exhaust pipe protector 2 bracket
INSTALLING THE EXHAUST PIPE
band using the boots band installation tool
1. Install:
"4".
• Exhaust pipe joint
• Exhaust pipe joint cover Boots band installation tool
90890-01526
Exhaust pipe joint nut Boots band installation tool
15 N-m (1.5 kgf-m, 11 lb-ft) YM-01526
Exhaust pipe joint cover bolt
7 N-m (0. 7 kgf-m, 5.1 lb-ft)
TIP ~~~~~~~~~~~~~~~~
EAS31588
~ -
1. Install:
• Gasket "1" ilM
a r{t (to muffler)
TIP ~~~~~~~~~~~~~~~~
Install the gasket with the chamfer "a", located
on an inner rim of the gasket, and the chamfer
"b", located on an outer rim of the gasket, as
shown .
5-12
ENGINE REMOVAL
C 1 l~fMJ
L
a b
2. Install: EAS31870
1
3. Install:
• Muffler assembly
• Muffler bracket
Muffler bolt
35 N-m (3.5 kgf-m, 25 lb-ft) 2. Adjust:
Muffler bracket bolt • Installed shift rod length
53 N-m (5.3 kgf-m, 38 lb-ft) TTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTT
a. Loosen both locknuts "1".
ECA22700
4. Tighten: ---.
NOTICE
• Clamp bolt - - - - - - - - - - - - -
The shift rod locknut (shift arm side) has left-
Clamp bolt hand threads.
12 N-m (1.2 kgf-m, 8. 7 lb-ft) b. Turn the shift rod "2" in direction "a" or "b" to
EAS31589
obtain the correct shift rod length.
INSTALLING THE SHIFT ARM TIP - - - - - - - - - - - - - - -
1. Install: Make sure that the engaged thread length on
• Shift arm "1" both ends of the shift rod is 4 ridges or more.
5-13
ENGINE REMOVAL
5-14
ENGINE REMOVAL
3. Tighten:
• Engine mounting nut (rear upper side) "16"
• Engine mounting nut (front upper side) "17"
• Engine mounting nut (rear lower side) "18"
• Engine mounting nut (front lower side) "19"
B 16
2. Tighten:
• Engine bracket bolts (rear upper side) "3"
• Engine bracket nuts (front upper side) "9"
• Engine bracket bolts (rear lower side) "11 "
• Engine bracket bolts (front lower side) "14"
5-15
CAMSHAFTS
EAS20043
CAMSHAFTS
Removing the cylinder head covers
1O N·m (1.0 kgf·m, 7.2 lb·ft) N 1O N·m (1.0 kgf·m, 7.2 lb·ft) I
1O N·m (1.0 kgf·m, 7.2 lb·ft)
(5)
(5)
bi- (5)
,
1O N·m 1.0 k f·m, 7.2 lb·ft
5-16
CAMSHAFTS
(5)
1
6
1/ 71~-
l'l·~"'f:i"'*·• 2
i~f:ifi 5
(5)
4
I ·~- 2 1
,
~ 1O N·m (1.0 kgf·m, 7.2 lb·ft)
1 Tappet cover 4
2 0-ring 4
3 Fuel filter bracket 1
4 Front cylinder side cover 1
5 Front cylinder side cover gasket 1
6 Rear cylinder side cover 1
7 Rear cylinder side cover gasket 1
5-17
CAMSHAFTS
er-
/
1O N·m (1.0 kgf·m, 7.2 lb·ft) 13 N·m 1.3 k f·m , 9.4 lb.ft
5-18
CAMSHAFTS
51~-
5-19
CAMSHAFTS
EAS31592
TTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTT
Front cylinder
a. Turn the crankshaft counterclockwise. 3. Remove:
b. When the front cylinder piston is at TDC on • Front cylinder camshaft sprocket
the compression stroke, align the TDC mark TIP ~~~~~~~~~~~~~~~~
"a" on the generator rotor with the slot "b" in • While holding the camshaft sprocket with the
the generator cover. rotor holding tool "1", loosen the camshaft
TIP ~~~~~~~~~~~~~~~~ sprocket bolt "2".
To position the front cylinder piston at TDC on • To prevent the timing chain from falling into the
the compression stroke, align the "I" mark "c" on crankcase, fasten it with a wire.
the camshaft sprocket with the arrow mark "d"
on the front cylinder head. Rotor holding tool
90890-01235
Universal magneto and rotor
b a holder
YU-01235
4. Remove:
• Camshaft retainer
• Front cylinder camshaft
5. Remove:
• Intake rocker arm shaft
• Exhaust rocker arm shaft
••••••••••••••••••••••••••••••••
2. Remove:
•
•
Intake rocker arm
Exhaust rocker arm
• Front cylinder tim ing chain tensioner "1" TIP~~~~~~~~~~~~~~~~
Remove the rocker arm shafts with the slide
hammer bolt "1" and weight "2".
5-20
CAMSHAFTS
••••••••••••••••••••••••••••••••
7. Remove:
• Rear cylinder timing chain tensioner
• Rear cylinder camshaft sprocket
• Camshaft retainer
• Rear cylinder camshaft
• Intake rocker arm shaft
• Exhaust rocker arm shaft
• Intake rocker arm
6. Align: • Exhaust rocker arm
• "I" mark on the rear cylinder camshaft sprock-
TIP~~~~~~~~~~~~~~
et
(with the arrow mark on the rear cylinder Remove the parts using the same procedure as
head) for the front cylinder camshaft and rocker arm.
EAS30257
TTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTT
Rear cylinder CHECKING THE CAMSHAFTS
a. Turn the crankshaft counterclockwise from 1. Check:
the front cylinder piston TDC by 300 degrees. • Camshaft lobes
b. When the rear cylinder piston is at TDC on Blue discoloration/pitting/scratches ~ Re-
the compression stroke, align the TDC mark place the camshaft.
"a" on the generator rotor with the slot "b" in 2. Measure:
the generator cover. • Camshaft lobe dimensions "a"
TIP ~~~~~~~~~~~~~~
Out of specification ~ Replace the camshaft.
To position the rear cylinder piston at TDC on Camshaft lobe dimensions
the compression stroke, align the "I" mark "c" on Lobe height (Intake)
the camshaft sprocket with the arrow mark "d" 42.470--42.570 mm (1.6720-
on the rear cylinder head. 1.6760 in)
Limit
b 42.370 mm (1.6681 in)
a Lobe height (Exhaust)
42.138-42.238 mm (1.6590-
1.6629 in)
Limit
42.038 mm (1.6550 in)
5-21
CAMSHAFTS
3. Check:
• Camshaft oil passage
Obstruction ~ Blow out with compressed air.
EAS30936
n ----'------,
a 1
.
11.981-11.991 mm (0.4717-
0.4721 in)
b ·-.......;"
' '
:
'
j,--.....,
Limit
11.941 mm (0.4701 in)
' '
'
a. 1/4 tooth
b. Correct
1. Timing chain roller
2. Camshaft sprocket
EAS30259
The following procedure applies to all of the CHECKING THE TIMING CHAIN
rocker arms and rocker arm shafts. TENSIONERS
1. Check: The following procedure applies to all of the tim-
• Rocker arm ing chain tensioners.
• Rocker arm roller 1. Check:
Damage/wear ~ Replace. • Timing chain tensioner
2. Check: Cracks/damage ~ Replace.
• Rocker arm shaft 2. Check:
Blue discoloration/excessive wear/pit- • One-way cam operation
ting/scratches ~ Replace or check the lubri- Rough movement ~ Replace the timing
cation system . chain tensioner assembly.
3. Measure: 3. Check:
• Rocker arm inside diameter • Timing chain tensioner cap bolt "1"
Out of specification ~ Replace. • Copper washer "2"
• Timing chain tensioner spring "3"
• One-way cam "4"
5-22
CAMSHAFTS
5 3 2 1
= :o
5. Install:
• Front cylinder camshaft sprocket
4
TTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTT
EAS31594
Front cylinder
INSTALLING THE ROCKER ARMS AND a. Turn the crankshaft counterclockwise.
CAMSHAFTS b. When the front cylinder piston is at TDC on
The following procedure applies to all of the the compression stroke, align the TDC mark
rocker arms and camshafts. "a" on the generator rotor with the slot "b" in
1. Lubricate: the generator cover.
• Rocker arm shafts
b
Recommended lubricant
I Engine oil
2. Install:
• Rocker arms
• Rocker arm shafts
3. Lubricate:
• Camshaft
c. Install the timing chain "1" onto the front cylin-
....,.1 Recommended lubricant
der camshaft sprocket "2", then install the
Camshaft
Molybdenum disulfide oil camshaft sprocket onto the camshaft, and
Camshaft bearing then finger tighten the camshaft sprocket bolt
Engine oil "3".
ECA13740
NOTICE
4. Install:
• Camshaft "1"
--------------
Do not turn the crankshaft when installing
• Camshaft retainer "2" the camshaft(s) to avoid damage or improper
valve timing.
Camshaft retainer bolt
TIP _ _ _ _ _ _ _ _ _ _ _ _ _ _ _~
1 O N-m (1.0 kgf-m, 7.2 lb-ft)
• To position the front cylinder piston at TDC on
TIP _ _ _ _ _ _ _ _ _ _ _ _ _ _ _~ the compression stroke, align the "I" mark "c"
The front cylinder camshaft is identified by the on the camshaft sprocket with the arrow mark
punch mark "a". The rear cylinder camshaft does "d" on the front cylinder head.
not have a punch mark. • When installing the front cylinder camshaft
sprocket, be sure to keep the timing chain as
tight as possible on the exhaust side.
5-23
CAMSHAFTS
TTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTT
Rear cylinder
a. Turn the crankshaft counterclockwise from
..1--- 2 the front cylinder piston TDC by 300 degrees.
b. When the rear cylinder piston is at TDC on
the compression stroke, align the TDC mark
"a" on the generator rotor with the slot "b" in
the generator cover.
1
b a
7. Install:
• Front cylinder timing chain tensioner gasket
"1"l~tii
• Front cylinder timing chain tensioner "2"
TIP _ _ _ _ _ _ _ _ _ _ _ _ __
To push in the timing chain tensioner rod, re-
lease the lock by pushing in the one-way cam
"6". c. Install the timing chain "1" onto the rear cylin-
der camshaft sprocket "2", then install the
Timing chain tensioner bolt camshaft sprocket onto the camshaft, and
1 O N-m (1.0 kgf-m, 7.2 lb-ft) then finger tighten the camshaft sprocket bolt
"3".
8. Install:
• Timing chain tensioner spring "5"
5-24
CAMSHAFTS
ECA13740
11.lnstall:
NOTICE
-------------- • Rear cylinder timing chain tensioner gasket
Do not turn the crankshaft when installing
"1" 11(¥11
the camshaft(s) to avoid damage or improper • Rear cylinder timing chain tensioner "2"
valve timing.
TIP ~~~~~~~~~~~~~~
TIP ~~~~~~~~~~~~~~ To push in the timing chain tensioner rod, re-
• To position the rear cylinder piston at TDC on lease the lock by pushing in the one-way cam
the compression stroke, align the "I" mark "c" "6".
on the camshaft sprocket with the arrow mark
"d" on the rear cylinder head . Timing chain tensioner bolt
• When installing the rear cylinder camshaft 10 N-m (1.0 kgf-m, 7.2 lb-ft)
sprocket, be sure to keep the timing chain as
tight as possible on the intake side. 12.lnstall:
• Timing chain tensioner spring "5"
• Copper washer "4" iltii
3 • Timing chain tensioner cap bolt "3"
0
1 2 5 4 3
\__,_, 1
d. Remove the wire from the timing chain .
•••••••••••••••••••••••••••••••• ©V
1a.Tighten:
• Rear cylinder camshaft sprocket bolt "1"
TIP ~~~~~~~~~~~~~~
5-25
CAMSHAFTS
2. Install:
• Front cylinder side cover
• Tappet covers
5-26
CYLINDER HEADS
EAS20044
CYLINDER HEADS
Removing the cylinder heads
1st 15 N·m (1.5 kgf·m, 11 lb·ft) 1st 15 N·m (1.5 kgf·m, 11 lb·ft)
2nd 25 N·m 2.5 k f·m, 18 lb·ft 2nd 25 N·m 2.5 k f·m , 18 lb·ft
~ 13 N·m (1.3 kgf·m, 9.4 lb·ft)
Final 65 N·m (6.5 kgf·m, 47 lb·ft) Final 65 N·m (6.5 kgf·m, 47 lb·ft)
6
10
81~- ) '
·~- 8
5-27
CYLINDER HEADS
EAS30276
REMOVING THE CYLINDER HEADS
1. Remove:
• Cylinder head bolts
• Cylinder head nuts
TIP ~~~~~~~~~~~~~~
Warpage limit
0.03 mm (0.0012 in)
TTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTT
a. Place a straightedge "1" and a thickness
gauge "2" across the cylinder head .
5-28
CYLINDER HEADS
TIP ~~~~~~~~~~~~~~
5-29
VALVES AND VALVE SPRINGS
EAS20045
81~-
·~- 8
5-30
VALVES AND VALVE SPRINGS
EAS30283
1. Check:
• Valve sealing
Leakage at the valve seat ~ Check the valve 3. Remove:
face, valve seat, and valve seat width. • Upper spring seat "1"
Refer to "CHECKING TH E VALVE SEATS" • Valve spring "2"
on page 5-33. • Valve "3"
TTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTT • Valve stem seal "4"
a. Pour a clean solvent "a" into the intake and • Lower spring seat "5"
exhaust ports. TIP ~~~~~~~~~~~~~~
b. Check that the valves properly seal. Identify the position of each part very carefully so
TIP ~~~~~~~~~~~~~~~~ that it can be reinstalled in its original place.
There should be no leakage at the valve seat "1".
i----
--- ---- '
2
3
EAS30284
5-31
VALVES AND VALVE SPRINGS
C
a. Valve guide position
TIP ~~~~~~~~~~~~~~
2. Replace:
After replacing the valve guide, reface the valve
• Valve guide
seat.
TIP ~~~~~~~~~~~~~~
To ease valve guide removal and installation,
Valve guide remover (06)
and to maintain the correct fit, heat the cylinder 90890-04064
head to 100 °c (212 °F) in an oven . Valve guide remover (6.0 mm)
TTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTT YM-04064-A
a. Remove the valve guide with the valve guide Valve guide installer (06)
remover "1". 90890-04065
Valve guide installer (6.0 mm)
YM-04065-A
Valve guide reamer (06)
90890-04066
Valve guide reamer (6.0 mm)
YM-04066
••••••••••••••••••••••••••••••••
3. Eliminate:
• Carbon deposits
(from the valve face and valve seat)
5-32
VALVES AND VALVE SPRINGS
4. Check:
• Valve face
Pitting/wear~ Grind the valve face.
• Valve stem end
Mushroom shape or diameter larger than the
body of the valve stem~ Replace the valve. a
5. Measure:
• Valve stem runout
Out of specification ~ Replace the valve.
TIP ~~~~~~~~~~~~~~
TTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTT
• When installing a new valve, always replace
a. Apply blue layout fluid "b" onto the valve face.
the valve guide.
• If the valve is removed or replaced, always re-
place the valve stem seal.
EAS30285
Where the valve seat and valve face contacted
CHECKING THE VALVE SEATS one another, the blue layout fluid will have been
The following procedure applies to all of the removed.
valves and valve seats.
1. Eliminate: •4.•••••••••••••••••••••••••••••••
Lap:
• Carbon deposits
• Valve face
(from the valve face and valve seat)
• Valve seat
2. Check:
TIP ~~~~~~~~~~~~~~
• Valve seat
Pitting/wear ~ Replace the cylinder head. After replacing the cylinder head or replacing the
3. Measure: valve and valve guide, the valve seat and valve
• Valve seat width "a" face should be lapped.
Out of specification ~ Replace the cylinder TTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTT
head. a. Apply a coarse lapping compound "a" to the
valve face.
Valve seat contact width (intake) ECA13790
5-33
VALVES AND VALVE SPRINGS
b. Apply molybdenum disulfide oil onto the h. Install the valve into the cylinder head.
valve stem. 1. Press the valve through the valve guide and
onto the valve seat to make a clear impres-
sion.
J. Measure the valve seat width "c" again. If the
valve seat width is out of specification , reface
and lap the valve seat.
5-34
VALVES AND VALVE SPRINGS
3. Lubricate:
Recommended lubricant
l
Engine oil
1--...t 2
2. Measure:
• Valve spring tilt "a"
O ut of specification ~ Replace the valve
spnng .
---J
3
5
2. Lubricate:
• Valve stem "1"
• Valve stem seal "2"
(with the recommended lubricant)
a. Larger pitch
Recommended lubricant b. Smaller pitch
Molybdenum disulfide oil
5-35
VALVES AND VALVE SPRINGS
5. Install:
• Valve cotters
TIP ~~~~~~~~~~~~~~
NOTICE
-------------
Hitting the valve tip with excessive force
could damage the valve.
5-36
CYLINDER AND PISTONS
EAS20046
,
9
9
' i@f:ii 6
8
-
·~· 4 m
8 7
\ 6 l@f:ij
5
i@f:ii
7
6 5
3 l@f:ij
5-37
CYLINDER AND PISTONS
EAS30289
NOTICE
-------------
I
Do not use a hammer to drive the piston pin
out.
TIP - - - - - - - - - - - - - - - ~
• Before removing the circlips, cover the crank-
case opening with a clean rag to prevent the
EAS30291
circlips from falling into the crankcase.
CHECKING THE CYLINDERS AND PISTONS
• Before removing the piston pin, deburr the cir-
The following procedure applies to all of the cyl-
clips' groove and the piston's pin bore area. If
inders and pistons.
both areas are deburred and the piston pin is
still difficult to remove, remove it with the piston 1. Check:
• Piston wall
pin puller set "4".
• Cylinder wall
Vertical scratches ~ Rebore or replace the
Piston pin puller set cylinder, and replace the piston and piston
90890-01304
rings as a set.
Piston pin puller
YU-01304 2. Measure:
• Piston-to-cylinder clearance
TTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTT
a. Measure the cylinder bore with the cylinder
bore gauge.
TIP - - - - - - - - - - - - - - - ~
Measure the cylinder bore by taking side-to-side
and front-to-back measurements of the cylinder.
Bore
85.000-85.01 O mm (3.3465-
3.3468 in)
Out of round limit
0.050 mm (0.0020 in)
4
2. Remove:
• Top ring
• 2nd ring
• O il ring
5-38
CYLINDER AND PISTONS
b ••••••••••••••••••••••••••••••••
EAS30292
b I
0 ...............
Side clearance limit
0.100 mm (0.0039 in)
5-39
CYLINDER AND PISTONS
//---
Piston ring
Top ring
End gap limit
0.60 mm (0.0236 in)
2nd ring
End gap limit
0.80 mm (0.0315 in) b
EAS30293
5-40
CYLINDER AND PISTONS
4. Offset:
• Piston ring end gaps
[Al
90°
e,d
goo
2. Install:
• Piston "1"
• Piston pin "2" ac
45° '
• Circlips "3" m1lll!!fij"'(,• i
a. Top ring
TIP ~~~~~~~~~~~~~~~~
b. Upper oil ring rail
• Apply engine oil onto the piston pin. c. Oil ring expander
• Make sure the arrow mark "a" on the piston fac- d. Lower oil ring rail
es towards the front side of the cylinder. e. 2nd ring
• Before installing the circlips, cover the crank- A. forward
case opening with a clean rag to prevent the
clips from falling into the crankcase. 5. Install:
• Install the circlips so that the clip ends are 3 • Rear cylinder gasket "1"
mm (0.12 in) "b" or more from the cutout in the • Front cylinder gasket "2"
piston. 1 2
• Reinstall each piston into its original cylinder.
i,-..........,.
00 00
0
1
2 0
0
Qo 0
A. Intake side
31~(@ 31~· B. Exhaust side
6. Install:
• Cylinder "1"
TIP ~~~~~~~~~~~~~~
I
I
~
• Pass the timing chain and timing chain guide
~
~ -)) , b through the timing chain cavity.
-- J ' -
I
3. Lubricate:
• Piston
• Piston rings
5-41
CYLINDER AND PISTONS
5-42
GENERATOR AND STARTER CLUTCH
EAS20140
,a
(12)
(6)
3 5 '
Drain.
Engine oil Refer to "CHANGING THE ENGINE OIL'.' on
page 3-23.
Sidestand/Drive pulley cover Refer to "BELT DRIVE" on page 4-69.
1 Rectifier/regulator coupler 1 Disconnect.
2 Crankshaft position sensor coupler 1 Disconnect.
3 Damper cover 1
4 Generator cover damper 1
5 Crankshaft end accessing screw 1
5-43
GENERATOR AND STARTER CLUTCH
·~t@Jg
,a
,
(12)
(6)
5-44
GENERATOR AND STARTER CLUTCH
6
8
@
-
Gl
~ 90 N·m (9.0 kgf·m, 65 lb·ft)
1 Generator rotor 1
2 Starter clutch 1
3 Woodruff key 1
4 Starter clutch gear 1
5 Starter clutch idle gear 2 shaft 1
6 Starter clutch idle gear 2 1
7 Starter clutch idle gear 1 shaft 1
8 Starter clutch idle gear 1 1
5-45
GENERATOR AND STARTER CLUTCH
EAS30867
Sheave holder
90890-01701
Primary clutch holder
YS-01880-A
3
2. Remove:
• Generator rotor "1"
(with the flywheel puller "2")
• Woodruff key
ECA13880
NOTICE
-------------
To protect the end of the crankshaft, place an
appropriate sized socket between the fly-
wheel puller set center bolt and the crank-
EAS30869
shaft.
CHECKING THE STARTER CLUTCH
TIP _ _ _ _ _ _ _ _ _ _ _ _ __ 1. Check:
• Install the flywheel puller bolts to the threaded • Starter clutch rollers
holes of the starter clutch. Damage/wear ~ Replace.
• Make sure the flywheel puller is centered over 2. Check:
the generator rotor. • Starter clutch idle gears
• Starter clutch gear
Burrs/chips/roughness/wear~ Replace the
Flywheel puller
90890-01362 defective part(s).
Heavy duty puller 3. Check:
YU-33270-B • Starter clutch gear's contacting surfaces
Damage/pitting/wear ~ Replace the starter
clutch gear.
4. Check:
• Starter clutch operation
5-46
GENERATOR AND STARTER CLUTCH
EAS30872
TTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTT
a. Install the starter clutch gear "1" onto the gen- INSTALLING THE GENERATOR
erator rotor "2" and hold the generator rotor. 1. Install:
b. When turning the starter clutch gear clock- • Generator rotor
w ise "A", the starter clutch and the starter • Washer
clutch gear should engage, otherwise the • Generator rotor bolt
starter clutch is faulty and must be replaced. TIP ~~~~~~~~~~~~~~
c. When turning the starter clutch gear counter- • Clean the tapered portion of the crankshaft and
clockwise "B", it should turn freely, otherwise the generator rotor hub.
the starter clutch is faulty and must be re- • When installing the generator rotor, make sure
placed . the woodruff key is properly seated in the key-
way of the crankshaft.
• Lubricate the generator rotor bolt threads and
washer mating surfaces w ith engine oil.
2. Tighten:
• Generator rotor bolt "1"
TIP ~~~~~~~~~~~~~~~~
While holding the generator rotor "2" w ith the
EAS30871 sheave holder "3", tighten the generator rotor
INSTALLING THE STARTER CLUTCH bolt.
1. Install:
• Starter clutch
Sheave holder
• Starter clutch bolts "1"
90890-01701
Starter clutch bolt Primary clutch holder
24 N·m (2.4 kgf.m, 17 lb·ft) YS-01880-A
LOCTITE®
TIP ~~~~~~~~~~~~~~
Sheave holder
90890-01701
Primary clutch holder
YS-01880-A
3. Apply:
• Sealant
3 (onto the crankshaft position sensor lead
grommet)
5-47
GENERATOR AND STARTER CLUTCH
EAS31600
TIP~~~~~~~~~~~~~~
a,5
5-48
CLUTCH
EAS20055
CLUTCH
Removing the primary drive gear
-
12 N·m (1.2 kgf·m, 8.7 lb·ft) 12 N·m (1.2 kgf·m, 8.7 lb·ft)
B
Order Job/Parts to remove Q 'ty Remarks
Drain.
Engine oil Refer to "CHANGING THE ENGINE OIL'.' on
page 3-23.
Sidestand Refer to "BELT DRIVE" on page 4-69.
Exhaust pipe Refer to "ENGINE REMOVAL.'.' on page 5-2.
5-49
CLUTCH
,q 0,~
1O N·m (1.0 kgf·m, 7.2 lb·ft)
4.0 N·m 0.40 k f·m, 2.9 lb·ft
~ ~:::::,,,._
6
4
3
2 4.0 N·m 0.40 k f·m, 2.9 lb.ft
i~tWii 1 " - ~
~ 7 "'
r~l12 N•m (1.2 kgf•m, 8.7 lb·ft) I~ 12 N·m (1.2 kgf·m, 8.7 lb·ft)
1 Circlip 1
2 Pull lever 1
3 Pull lever spring 1
4 Clutch plastic cover 1 1
5 Clutch plastic cover 2 1
6 Clutch cover 1
7 Clutch cable holder 1
Starter motor lead and rear brake light switch
8 1
lead holder
5-50
CLUTCH
i~tMI 9
'\
r~l12 N•m (1.2 kgf•m, 8.7 lb·ft) I~ 12 N·m (1.2 kgf·m, 8.7 lb·ft)
5-51
CLUTCH
~11~f:i\j
a @
---
0 J=="ico3::o:::-- ~
~ ' ~\::::::::g~~o,;:d.-..,
,,/
1 Circlip 1
2 Pull lever shaft 1
3 Oil seal 1
4 Bearing 1
5 Bearing 1
6 Oil seal retainer 1
7 Oil seal 1
5-52
CLUTCH
9 '
125 N·m (12.5 kgf·m, 90 lb·ft)
8 9
8 9 7
8 8
9 '
8 9
8
7 5 '
6
-
m
~ 8 N·m 0.8 k f·m, 5.8 lb·ft
5-53
CLUTCH
18 17
16
,
15
19
14
11 . g washer
Conical spnn 1
12 Clutch boss 1
13 Thrust washer 1 1
14 Clutch housing 1
15 Bearing 1
16 Collar . 1
17 Oil pump d n·ve chain 1
18 . sprocket
Oil pump drive 1
19 Thrust washer 2 1
5-54
CLUTCH
EAS30347
TIP ~~~~~~~~~~~~~~
REMOVING THE PRIMARY DRIVE GEAR
1. Straighten the lock washer tab. While holding the clutch boss "2" w ith the univer-
2. Remove: sal clutch holder "3", loosen the clutch boss nut.
• Primary drive gear nut "1"
• Lock washer "2" Universal clutch holder
TIP ~~~~~~~~~~~~~~ 90890-04086
Universal clutch holder
• While holding the generator rotor "3" with the
YM-91042
sheave holder "4", loosen the primary drive
gear nut.
• Do not allow the sheave holder to touch the
projection on the generator rotor.
Sheave holder
90890-01701
Primary clutch holder
YS-01880-A
3. Remove:
• Clutch boss nut "1"
• Conical spring washer "2"
• Clutch boss "3"
EAS30348
2. Loosen:
• Clutch boss nut "1"
5-55
CLUTCH
EAS30350
A. Friction plate 1
B. Friction plate 2
EAS30349
5-56
CLUTCH
EAS30357
2. Check:
• Pull rod bearing
Damage/wear~ Replace.
EAS31601
5-57
CLUTCH
TIP ~~~~~~~~~~~~~~
4. Lubricate:
• Friction plates
• Clutch plates
(with the recommended lubricant)
Recommended lubricant
I
Engine oil
5. Install:
• Friction plates 2
• Clutch plates
• Friction plates 1
TIP ~~~~~~~~~~~~~~
5-58
CLUTCH
TIP ~~~~~~~~~~~~~~
TIP ~~~~~~~~~~~~~~
7. Install : ?-AP3
• O il seals "1", "2" il@1i 7
b,6 5 4
(to the clutch cover)
9. Install:
Installed depth "a" • Pull lever spring "1"
1.0-1.5 mm (0.04-0.06 in) • Pull lever "2"
Installed depth "b" • Washer
0-0.5 mm (0-0.02 in)
• Circlip 1~t4W
-- a
.- - -.
TIP ~~~~~~~~~~~~~~
10.Adjust:
• Clutch lever free play
8. Install : Refer to "ADJUSTING THE CLUTCH LEVER
• Clutch cover FREE PLAY" on page 3-11 .
• Clutch cable holder
5-59
CLUTCH
EAS30362
TIP ~~~~~~~~~~~~~~
Sheave holder
90890-01701
Primary clutch holder
YS-01880-A
5-60
SHIFT SHAFT
EAS20057
SHIFT SHAFT
Removing the s hift s haft and stopper lever
8
5
6
7
- '
B
Order Job/Parts to remove Q'ty Remarks
Drive pulley cover/Shift arm Refer to "BELT DRIVE" on page 4-69.
Clutch cover/Clutch housing Refer to "CLUTCH" on page 5-49.
1 Shift shaft 1
2 Stopper lever spring 1
3 Circlip 1
4 Stopper lever 1
5 Collar 1
6 Shift shaft spring 1
7 Shift shaft spring stopper 1
8 Oil seal 1
9 Bearing 1
5-61
SHIFT SHAFT
EAS303n
' 1•
r- '
0
1
2. Install:
• Stopper lever "1"
• Stopper lever spring "2"
• Shift shaft "3"
TIP~~~~~~~~~~~~~~
5-62
ELECTRIC STARTER
EAS20052
ELECTRIC STARTER
Removing the starter motor
5-63
ELECTRIC STARTER
'
'
51~-
,
4
5 N·m (0.5 kgf·m, 3.6 lb·ft)
3
2
i~tMs 1 i~t=iVI
1 0-ring 1
2 Starter motor front cover 1
3 Armature assembly 1
4 Starter motor yoke 1
5 Gasket 2
6 Starter motor rear cover 1
7 Brush set 1
8 0-ring 1
5-64
ELECTRIC STARTER
EAS30325
• • • •
12.0 mm (0.47 in)
I Limit
6.50 mm (0.26 in)
3. Measure: a
• Armature assembly resistances (commutator
and insulation)
Out of specification ~ Replace the starter
motor. 5. Measure:
TTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTT
• Brush spring force
a. Measure the armature assembly resistances
with the digital circuit tester. Out of specification ~ Replace the brush set.
6. Check:
• Gear teeth
Damage/wear ~ Replace the starter motor.
5-65
ELECTRIC STARTER
7. Check:
• Bearing
Damage/wear ~ Replace the starter motor.
EAS30326
b b
5-66
CRANKCASE
EAS20059
CRANKCASE
Removing the oil delivery pipes and timing chains
1 O N·m (1.0 kgf·m, 7.2 lb·ft)
. 17 N·m (1.7 kgf·m, 12 lb·ft)
5-67
CRANKCASE
5
4
5
5-68
CRANKCASE
71§t4W
6
1O N·m (1.0 kgf·m, 7.2 lb·ft)
10
5-69
CRANKCASE
a
12 N·m (1.2 kgf·m, 8.7 lb·ft)
5-70
CRANKCASE
EAS30389 EAS30390
NOTICE
-------------
Tap on one side of the crankcase with a soft-
EAS31602
5-71
CRANKCASE
- ~
• M10 x 110 mm bolts
EAS30397
0
i Q • M6 x 80 mm bolts
Im
0
3. Install:
• Crankcase (left)
(onto the right crankcase)
TIP ~~~~~~~~~~~~~~~
5-72
CRANKCASE
5. Apply:
• Engine oil
(onto the crankshaft pin bearings and oil de-
livery holes)
6. Check:
• Crankshaft and transmission operation
Rough movement ~ Repair.
5-73
OIL PUMP
EAS20054
OIL PUMP
Removing the oil pump assembly
/
;'
''
/
/
' ' 24 N·m (2.4 kgf·m, 17 lb·ft)
' '
''
''
' '
5
''
''
' '
' '
'
4 'I
'' '' 5
' ' 9
' '
'' 8 6
''
'
' '
'
'' I
'' I
' ' I
'
24 N·m 2.4 kgf·m, 17 lb·ft
5-74
OIL PUMP
EAS30337 EAS30338
Inner-rotor-to-outer-rotor-tip
clearance 1
0.000-0.120 mm (0.0000-0.0047
in)
Limit
0.20 mm (0.0079 in)
Outer-rotor-to-oil-pump-housing
clearance EAS30340
1. Inner rotor
2. Outer rotor EAS30342
2. Install:
• Pin "1"
• Oil pump inner rotor "2"
• Oil pump outer rotor "3"
• Dowel pin
I.)
• Oil pump housing "4"
5-75
OIL PUMP
TIP _ _ _ _ _ _ _ _ _ _ _ _ __
When installing the inner rotor, align the pin in
the impeller shaft with the grooves "a" in the in-
ner rotor.
4
3
2
a
3. Check:
• Oil pump operation
Refer to "CHECKING TH E OIL PUMP" on
page 5-75.
EAS31604
ECA13890
NOTICE
-------------
Aft er tightening the bolts, make sure the oil
pump turns smoothly.
> .......?
5-76
CRANKSHAFT
EAS20061
CRANKSHAFT
Removing the crankshaft
4
5
-
' I Gl
3
2
Crankcase Separate.
Refer to "CRANKCASE" on page 5-67.
1 Crankshaft 1
2 Connecting rod cap 2
3 Big end lower bearing 2
4 Connecting rod 2
5 Big end upper bearing 2
5-77
CRANKSHAFT
EAS304 15
The following procedure applies to all of the
REMOVING THE CONNECTING RODS
connecting rods.
1. Remove: ECA13930 - - - ,
Runout limit
0.020 mm (0.0008 in) I
c. Put a piece of Plastigauge® "1" on the crank-
shaft pin.
2. Check:
• Crankshaft journal surfaces
• Crankshaft pin surfaces
• Bearing surfaces d. Assemble the connecting rod halves.
Scratches/wear ~ Replace the crankshaft. TIP ~~~~~~~~~~~~~~
3. Measure:
• Do not move the connecting rod or crankshaft
• Crankshaft-pin-to-big-end-bearing clearance until the clearance measurement has been
Out of specification ~ Replace the big end completed .
bearings.
• Lubricate the bolts threads and nut seats with
molybdenum disulfide grease.
Oil clearance
0.023-0.046 mm (0.0009-0.0018 • Make sure the projection "c" on the connecting
in) rod faces towards the left side of the crank-
shaft.
5-78
CRANKSHAFT
C'L)IJ--___,
0
e. Tighten the connecting rod bolts.
Refer to "INSTALLING THE CONNECTING 0
RODS" on page 5-80.
f. Remove the connecting rod and big end
bearings.
_-.:_5..I. . . -_ ____J
5. Measure:
• Crankshaft journal diameter "a"
Out of specification ~ Replace the crank-
shaft.
TIP ~~~~~~~~~~~~~~~
Measure the diameter of each crankshaft journal
at two places .
••••••••••••••••••••••••••••••••
4. Select: Crankshaft journal diameter
49.968-49.980 mm (1.9672-
• Big end bearings (P1 - P2 )
1.9677 in)
TIP ~~~~~~~~~~~~~~~-
c.,
c.., -
5-79
CRANKSHAFT
6. Measure:
• Crankshaft journal bearing inside diameter Recommended lubricant
l
"a" Engine oil
Out of specification ~ Replace the crank-
3. Install:
case assembly.
• Big end bearings
TIP ~~~~~~~~~~~~~~
• Connecting rods
Measure the inside diameter of each crankshaft • Connecting rod caps
journal bearing at two places. (onto the crankshaft pin)
TIP ~~~~~~~~~~~~~~
Crankshaft journal bearing inside • Align the projections "a" on the big end bear-
diameter ings with the notches "b" in the connecting rods
50.010-50.028 mm (1.9689-
and connecting rod caps.
1.9696 in)
• Be sure to reinstall each big end bearing in its
original place.
• Make sure the projection "c" on each connect-
ing rod faces towards the left side of the crank-
shaft.
• Make sure the characters "d" on both the con-
necting rod and connecting rod cap are
aligned .
G a
b a
7. Calculate:
• Crankshaft-journal-to-crankshaft-journal-
bearing clearance
Out of specification ~ Replace the crank-
shaft and crankcase as a set.
TIP ~~~~~~~~~~~~~~~~
f
Calculate the clearance by subtracting the
crankshaft journal diameter from the crankshaft
journal bearing inside diameter.
EAS30426
(with the recommended lubricant) Tighten the connecting rod bolts using the fol-
lowing procedure.
5-80
CRANKSHAFT
NOTICE - -------------
To avoid scratching the crankshaft and to
Connecting rod bolt (1st) ease the installation procedure, lubricate
15 N-m (1.5 kgf-m, 11 lb-ft) each bearing with engine oil.
EWA12900
& WARNING
When the bolts are tightened more than the
specified angle, do not loosen the bolt and
then retighten it.
Replace the bolt with a new one and perform
the procedure again.
ECA183SO
NOTICE
-------------
• Do not use a torque wrench to tighten the
bolt to the specified angle.
• Tighten the bolt until it is at the specified
angle.
EAS30428
5-81
TRANSMISSION
EAS20062
TRANSMISSION
Removing the transmission, shift drum assembly, and shift forks
''
'
I
I
._I
' '
''
4 ''
' ' ' 'I
I
V I
I
4 ' '
' I
I
I
/', ~I
6
2 1
Separate.
Crankcase Refer to "CRANKCASE" on page 5-67.
1 Long shift fork guide bar 1
2 Short shift fork guide bar 1
3 Shift drum assembly 1
4 Shift fork 1 2
5 Shift fork 2 1
6 Main axle assembly 1
7 Drive axle assembly 1
5-82
TRANSMISSION
'
'
1@t411a
7
6
4
3
1 i@tM
Order Job/Parts to remove Q'ty Remarks
1 Circlip 1
2 2nd pinion gear 1
3 Toothed lock washer 1
4 Toothed lock washer retainer 1
5 4th pinion gear 1
6 Collar 1
7 Toothed washer 1
8 Circlip 1
9 3rd pinion gear 1
5-83
TRANSMISSION
14
13
'
12
' '
, ---/
<: .--,
'
1@ '
11
10
\ ' ' 01
,
'
I I ,e ' ~
,
10 Circlip 1
11 Toothed washer 1
12 5th pinion gear 1
13 Collar 1
14 Main axle/1st pinion gear 1
5-84
TRANSMISSION
1 2
'
5
6 3
7 '
__ ,/ 4
'
~
' \
' _/
l' 8
'J 9 '
i,IJ,
' I
I .,-...f
\' ,~
·\_ - ,,
,
--
'
' >
'
'
'
'
'
'
1 Washer 1
2 1st wheel gear 1
3 Collar 1
4 5th wheel gear 1
5 Circlip 1
6 Toothed washer 1
7 3rd wheel gear 1
8 Collar 1
9 Toothed lock washer 1
5-85
TRANSMISSION
'
'
.---,
'
'
10
\' ,~·\_ -
--
12
'
' >
13
16 15
I '
'
'
'
'
'
5-86
TRANSMISSION
EAS30431 EAS30432
2. Check:
• Shift fork guide bar
Roll the shift fork guide bar on a flat surface.
Bends ~ Replace. EAS30433
EWA12840
CHECKING THE TRANSMISSION
A WARNING 1. Measure:
Do not attempt to straighten a bent shift fork • Main axle runout
guide bar. (with a centering device and dial gauge "1")
Out of specification ~ Replace the main axle.
3. Check:
• Shift fork movement
(along the shift fork guide bar)
Rough movement ~ Replace the shift forks
and shift fork guide bar as a set. 2. Measure:
• Drive axle runout
(with a centering device and dial gauge "1")
Out of specification~ Replace the drive axle.
5-87
TRANSMISSION
- a
1 '-. l
1•~•
~
1
•
•
•
•
•
•
•
--.""<:-............
.. r. v , ' ~ "
.. /
b. l1
b
3. Check: 2. Install:
• Transmission gears • Toothed lock washer retainer "1"
Blue discoloration/pitting/ wear ~ Replace • Toothed lock washer "2"
the defective gear(s) . TIP ~~~~~~~~~~~~~~
• Transmission gear dogs • W ith the toothed lock washer retainer in the
Cracks/damage/rounded edges~ Replace groove "a" in the drive axle, align the projection
the defective gear(s) . "b" on the retainer with an axle spline "c", and
then install the toothed lock washer.
0 X • Be sure to align the projection on the toothed
~~
lock washer that is between the alignment
marks "d" with the alignment mark "e" on the
retainer.
4. Check: a
• Transmission gear engagement
(each pinion gear to its respective wheel
gear)
Incorrect~ Reassemble the transmission
axle assemblies.
5. Check: EAS30437
5-88
TRANSMISSION
2. Check:
• Transmission
Rough movement ~ Repair.
TIP ~~~~~~~~~~~~~~
5-89
FUEL SYSTEM
FUEL TANK ......... .......... ......... .......... ......... ......... .......... ........ .......... ......... ........ 6-1
REMOVING THE FUEL TANK .. ......... ........ ......... ......... .......... ......... ......... . 6-5
REMOVING THE FUEL PUMP .......... ........ ......... .......... ......... .......... ......... 6-5
CHECKING THE FUEL PUMP BODY ...... .......... ......... ......... ......... ......... ... 6-5
CHECKING THE ROLLOVER VALVE ...... ......... ......... ......... .......... ......... .. 6-5
INSTALLING THE FUEL TANK DAMPER ........... ......... ......... .......... ......... 6-6
INSTALLING THE FUEL PUMP ........ ......... ......... ......... ......... .......... ......... . 6-6
INSTALLING THE FUEL SENDER .... .......... ........ ......... ......... ......... .......... 6-7
THROTTLE BODIES .... ......... ......... .......... ........ .......... ......... ......... .......... ......... 6-8
CHECKING THE INJECTORS .......... ......... ......... .......... .......... ......... ....... 6-11
INSTALLING THE INJECTORS ........ ......... ......... .......... ......... .......... ....... 6-11
CHECKING THE THROTTLE BODIES ........ ........ .......... ......... .......... ...... 6-11
CHECKING THE INTAKE MANIFOLD JOINTS ... ........... ......... .......... ..... 6-11
CHECKING THE PRESSURE REGULATOR OPERATION ... .......... ...... 6-11
ADJUSTING THE THROTTLE POSITION SENSOR ..... ......... ......... ....... 6-12
REMOVING THE INTAKE MANIFOLD ASSEMBLY ...... ......... .......... ...... 6-13
INSTALLING THE INTAKE MANIFOLD ASSEMBLY ..... ......... .......... ..... 6-13
FUEL TANK
EAS20067
FUEL TANK
Removing the fuel tank
-- --
..... -- ...,
-- ' .
,,,
'
' '
'
6-1
FUEL TANK
-- --
..... -- ...,
-- ' .
,,,
16
'
' '
'
12
11
6-2
FUEL TANK
'
4
7 N•m ()
9 Rollover valve 1
10 Fuel tank breather/overflow hose holder 1 Except for Californ ia
6-3
FUEL TANK
, ~ - 13
,)
12
/ j--14
'
11 - -,
7 N•m ()
6-4
FUEL TANK
EAS30450
~ WARNING
Cover fuel hose connections with a cloth
when disconnecting them. Residual pres-
sure in the fuel lines could cause fuel to
spurt out when removing the hoses.
TIP - - - - - - - - - - - - - - - ~
• To disconnect the fuel hose from the fuel pump
or fuel filter, slide the fuel hose connector cover
"1" on the end of the hose in the direction of the A. Connection to fuel pump and fuel filter
arrow shown, press the two buttons "2" on the B. Connection between fuel hoses
sides of the connector, and then disconnect
2. Remove:
the hose.
• Fuel pump cover
• To disconnect the fuel hose (fuel pump to fuel
hose) from the fuel hose (fuel hose to fuel fil- TIP ~~~~~~~~~~~~~~
ter), slide the fuel hose connector lock "3" in the When removing the fuel pump cover, remove
direction of the arrow shown using a slotted the cover from the fuel hose end of the fuel pump
head screwdriver, and then disconnect the first.
hose. 3. Remove:
• Disconnect the fuel hose from the fuel pump
• Fuel pump
and fuel filter manually without using any tools. ECA22660
EAS30454
6-5
FUEL TANK
NOTICE - -------------
Do not touch the filter portion of the fuel
pump.
TIP ~~~~~~~~~~~~~~
-
. - -. .....
' '' ,,
'
''
\\,,,.-,,- - b
a
FWD
2. Install:
~ • Fuel hoses
ECA22680
NOTICE - -------------
When installing a fuel hose, make sure that it
is securely connected, and that the fuel hose
connector cover or fuel hose connector lock
3 is in the correct position, otherwise the fuel
hose will not be properly installed.
EAS30456 TIP _ _ _ _ _ _ _ _ _ _ _ _ _ _ _~
INSTALLING THE FUEL PUMP
• Connect the fuel hoses until a distinct "click" is
1. Install:
heard .
• Fuel pump
• To connect a fuel hose, slide the fuel hose con-
• Gasket m1@ll!!t4!11114,•; nector cover "1" or fuel hose connector lock "2"
in the direction of the arrow.
Fuel pump bolt
4.0 N-m (0.40 kgf-m, 2.9 lb-ft)
6-6
FUEL TANK
TIP ~~~~~~~~~~~~~~
Position the fuel sender coupler "1" between the
guides "a" on the fuel tank bracket "2".
6-7
THROTTLE BODIES
EAS20070
THROTTLE BODIES
Removing the throttle body
'
/
5
6-8
THROTTLE BODIES
9 6
\
'
8
6-9
THROTTLE BODIES
1O N·m (1.0 kgf·m, 7.2 lb·ft) ~ 1O N·m (1.0 kgf·m, 7.2 lb·ft)
a .~ '
3
3.5 N·m 0.35 k f·m , 2.5 lb·ft
1 Pressure regulator 1
2 Inlet pipe assembly 1
3 Injector 2
4 Intake manifold 1
6-10
THROTTLE BODIES
EAS304n EAS30479
tery terminal before checking the injectors. CHECKING THE PRESSURE REGULATOR
ECA18430
OPERATION
NOTICE 1. Check:
-------------
• Always use new 0-rings.
• Fuel pressure
TTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTT
• When checking the injectors, do not allow a. Disconnect the fuel hose (fuel pump to fuel
any foreign material to enter or adhere to hose) "1" from the fuel hose (fuel hose to fuel
the injectors, fuel rail, or 0-rings. filter) .
• Be careful not to twist or pinch the 0-rings EWA16640
6-11
THROTTLE BODIES
6-12
THROTTLE BODIES
TIP ~~~~~~~~~~~~~~
Throttle position sensor screw
3.5 N-m (0.35 kgf-m, 2.5 lb-ft) Be sure to fit the projection "b" on the intake
manifold assembly between the projections "c"
on the rear cylinder intake manifold joint.
joint bolt
1 O N-m (1.0 kgf-m, 7.2 lb-ft)
TIP~~~~~~~~~~~~~~
Install the front cylinder intake manifold joint with
its projection "a" facing up as shown in the illus-
tration .
6-13
ELECTRICAL SYSTEM
IGNITION SYSTEM ...... ......... ........ ........ ......... ........ ......... ......... ....... ......... ....... 7- 1
CIRCU IT DIAGRAM ......... .......... ......... ......... ........ ......... .......... ......... ......... 7-1
ENGINE STOPPI NG DUE TO SIDESTAND OPERATION ... .......... ......... . 7-3
TROUBLESHOOTING ... .......... ......... ........ .......... ......... .......... ......... ......... . 7-4
ELECTRIC STARTING SYSTEM .... ......... ....... ......... ......... ........ ......... ....... ...... 7-7
CIRCU IT DIAGRAM ......... .......... ......... ......... ........ ......... .......... ......... ......... 7-7
START ING CIRCUIT CUT-O FF SYSTEM OPERATION ......... ........ ......... 7-9
TROUBLESHOOTING ... .......... ......... ......... ......... .......... ......... ......... ........ 7- 1O
CHARGING SYSTEM ... ......... ......... .......... ........ .......... ......... .......... ......... ....... 7-13
CIRCU IT DIAGRAM .......... .......... ......... .......... .......... ......... ......... ......... .... 7-13
TROUBLESHOOTING ... .......... ......... ......... ......... .......... ......... ......... ........ 7- 15
LIGHTING SYSTEM ..... ......... .......... ......... ........ .......... ......... .......... ......... ....... 7-17
CIRCU IT DIAGRAM .......... .......... ......... .......... .......... ......... ......... ......... .... 7-17
TROUBLESHOOTING ... .......... ......... ......... ......... .......... ......... ......... ........ 7- 19
SIGNALING SYSTEM .. ......... ......... .......... ........ .......... ......... .......... ......... ....... 7-2 1
CIRCU IT DIAG RAM .......... .......... ......... .......... .......... ......... ......... ......... .... 7-21
TROUBLESHOOTING ... .......... ......... ......... ......... .......... ......... ......... ........ 7-23
FUEL INJECTION SYSTEM .. ......... .......... ........ .......... ......... ......... .......... ....... 7-27
CIRCU IT DIAGRAM .......... .......... ......... .......... ......... .......... ......... ......... .... 7-27
ECU SELF-DIAGNOSTIC FUNCTION ....... .......... ......... ......... .......... ....... 7-29
TROUBLESHOOTING METHOD ........ ......... .......... ......... ......... .......... ..... 7-30
YAMAHA DIAGNOSTIC TOOL ......... ......... ......... .......... ......... ......... ........ 7-3 1
TROUBLESHOOTING DETAILS ....... .......... ........ .......... ......... ......... ....... 7-3 1
FU EL PUMP SYSTEM .. ......... ......... .......... ........ .......... ......... .......... ......... ....... 7-63
CIRCU IT DIAGRAM .......... .......... ......... .......... ......... .......... ......... ......... .... 7-63
TROUBLESHOOTING ... .......... ......... ......... ......... .......... ......... ......... ........ 7-65
ELECTRICAL COMPONENTS ........ .......... ......... .......... ........ ......... .......... ...... 7-67
CHECKING THE SWITCHES .. .......... ........ .......... ......... .......... .......... ...... 7-71
CHECKING THE BULBS AND BULB SOCKETS .. ......... ......... .......... ..... 7-74
CHECKING THE FUSES ......... .......... ......... ......... .......... ......... .......... ...... 7-75
CHECKING AND CHARGING THE BATTERY .... .......... .......... .......... ..... 7-76
CHECKING THE RELAYS ........ .......... ......... .......... ......... ......... .......... ..... 7-79
CHECKING THE TURN SIGNAL RELAY .. ......... ............ ......... .......... ..... 7-80
CHECKING THE RELAY UNIT (DIODE) ..... .......... ........ .......... .......... ..... 7-80
CHECKING THE IGNITION SPARK GAP ... ......... ........... ......... .......... ..... 7-81
CHECKING THE SPARK PLUG CAPS ..... ......... ........ ............. .......... ...... 7-81
CHECKING THE IGNITION COILS .... .......... ........ .......... .......... ......... ...... 7-82
CHECKING THE CRANKSHAFT POSITION SENSOR ........... ......... ...... 7-82
CHECKING THE LEAN ANGLE SENSOR ... ........ .......... .......... ......... ...... 7-83
CHECKING THE STARTER MOTOR OPERATION ..... .......... .......... ...... 7-83
CHECKING THE STATOR COIL ........ ......... .......... ........ .......... ......... ...... 7-84
CHECKING THE RECTIFIER/REGULATOR ....... ......... .......... ......... ....... 7-84
CHECKING THE OIL LEVEL SWITCH ....... ......... ......... .......... .......... ...... 7-85
CHECKING THE FUEL SENDER ....... .......... ......... ......... ......... .......... ..... 7-85
CHECKING THE FUEL LEVEL WARNING LIGHT ......... ......... ......... ...... 7-85
CHECKING THE OIL LEVEL WARNING LIGHT .. .......... ......... .......... ..... 7-86
CHECKING THE ENGINE TEMPERATURE SENSOR ........... .......... ..... 7-86
CHECKING THE INTAKE AIR TEMPERATURE SENSOR ..... ......... ...... 7-86
CHECKING THE FUEL INJECTORS ......... ......... .......... ......... .......... ....... 7-87
IGNITION SYSTEM
EAS20072
IGNITION SYSTEM
EAS30490
CIRCUIT DIAGRAM
aG iii @ ~ te>·~
~ ~ ~ · :iii
i(BI < 0 < -m ~ 11•3 @:i>•3
.
• >
• 11
-~Ill!
••
·-----,
' -
:® /"';.
'--11-- •
•
' ! 1-. -
• --------------------,
--i
00
.,,, -
•
'
:
'
'
.
:@ ,....._._.._,@, ® @ ® @ ® :
@
"'11"1""'11421 -,j , :
~'
''
f !
-1 • '®-- - - - - - - - - - - - - -•,-
>
- • 6 -'
'' -
'- - ---~• _I
l--
,® ~
'
' r •'
·-
~
'- •
-- ••
--
• •• JU'ftf+-t-t-',.U..------1-.U. . _. .
c·--~
-
'•
eiijI• •
'
'
:~:
l
'
' @'
... ,--- -,
~
•• ~1 •
-
.f?.-s -
1111-...J Ill :
'
• ® - ® I:•
-~11-11--r--ntttttt11nH8!~
lf;i --, I ~1~ :. ""I'~
'® ~ '
rtt-t- -....
' ~ .
i-=--,, .-11., ;; ••• , , : ·" ., : ---,I
~
t!!!J
,i ,- ""' I I ·· · · IIII11III, I
I
I
I
'
'
I
I I
'ti-.. ' co '
~•-'=- =-·
~ I
I
1
I
,-->.J->-
'
:@ ~:
'
. Q'
,' _- ..'
•
••
•
.i
!
--J II
I
lf l
.'
""'·
1
r- N
"-
·---- ---1~ ----'
~-
-
'
·-
:~
/-- --====-- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - _ ,
7-1
IGNITION SYSTEM
3. Main switch
4. Main fuse
5. Battery
6. Engine ground
7. Fuel injection system fuse
1O.Joint connector
13. Ignition fuse
16.Joint coupler
17. Relay unit
20.Sidestand switch
21.Neutral switch
26.Crankshaft position sensor
27.Lean angle sensor
32. ECU (Engine Control Unit)
33. Front cylinder ignition coil
34.Spark plug
35. Rear cylinder ignition coil
67. Handlebar switch (right)
69. Engine stop switch
A. Wire harness
B. Sub-wire harness (negative battery)
C. Sub-wire harness (neutral switch)
7-2
IGNITION SYSTEM
EAS30491
2
I
e (t)
--- 1
I
,,
3
1
4
--3+
_,_ J,
-- 8
) 5
J
10
6
11 )9 I+
' •
7
... ... 1-
1. Battery
2. Main fuse
3. Main switch
4. Ignition fuse
5. Engine stop switch
6. Ignition coil
7. Spark plug
8. ECU (Engine Control Unit)
9. Sidestand switch
10. Relay unit (diode)
11 . Neutral switch
7-3
IGNITION SYSTEM
EAS30492
TROUBLESHOOTING
The ignition system fails to operate (no spark or intermittent spark) .
TIP ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
OKt
OKt
OKt
NG j,
OKt
OKt
OKt
7-4
IGNITION SYSTEM
OKt
OKt
OKt
OKt
OKt
OKt
OKt
7-5
IGNITION SYSTEM
7-6
ELECTRIC STARTING SYSTEM
EAS20073
CIRCUIT DIAGRAM
·-----,
.
• > ' 11 •
' -
:® r;·
'--11-- •
of
•- ! ''
! 1-.., - --i
--------------------,
00
••
••
Kill
'
,
•
:@
:
'
'
. ,....._._.._,@,
@
® @
"'11"1""'11421
® @
-,j
® :
,
~ '
:
' ----,
-- -tit. • '@·· - - - - - - - - - - - - -•,-
>
- • 6 .'
' .
.... . '' ,,..
,®
l.. ~
'
• (~ •'
', .
,
•
.• • • ' IiUf
c·--~
-----,
'•
~ - - -,
eiij
' - -
'
'
:~ :
l
'
' @'
\i. ' -
. •• ~1 •
'
.i
!
--J II
I
lf l
.'
""'·
1
r- N
"-
, ____ ---1~ ----'
.,
/
7-7
ELECTRIC STARTING SYSTEM
3. Main switch
4. Main fuse
5. Battery
6. Engine ground
8. Starter relay
9. Starter motor
13. Ignition fuse
16.Joint coupler
17. Relay unit
18. Starting circuit cut-off relay
20.Sidestand switch
21.Neutral switch
56.Clutch switch
67. Handlebar switch (right)
69. Engine stop switch
70.Start switch
A. Wire harness
B. Sub-wire harness (negative battery)
C. Sub-wire harness (neutral switch)
7-8
ELECTRIC STARTING SYSTEM
EAS30494
13'/
/
....1...
-
- ".
I
II
_ 11
-
e (ti
--- - 1
3
:> 4
I .A
7 7 ..._ '11
I "" V l,
r
5
!
6 C
[
7_, I '
.' ' -7
A
•
" 8
a
-' ~7
b 1 112
9
10
I
a. WHEN THE TRANSMISSION IS IN 8. Clutch switch
NEUTRAL 9. Sidestand switch
b. WHEN THE SIDESTAND IS UP AND THE 10. Neutral switch
CLUTCH LEVER IS PULLED TO THE 11 . Starter relay
HANDLEBAR
12. Start switch
1 . Battery
13. Starter motor
2. Main fuse
3. Main switch
4. Ignition fuse
5. Engine stop switch
6. Relay unit (starting circuit cut-off relay)
7. Relay unit (diode)
7-9
ELECTRIC STARTING SYSTEM
EAS30495
TROUBLESHOOTING
The starter motor fails to turn.
TIP ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
OKt
OKt
NG j,
OKt
OKt
6. Check the relay unit (diode). NG~
Refer to "CHECKING THE RELAY Replace the relay unit.
UNIT (DIODE)" on page 7-80.
OKt
OKt
7-10
ELECTRIC STARTING SYSTEM
OKt
OKt
OKt
OKt
OKt
OKt
OKt
7-11
ELECTRIC STARTING SYSTEM
7-12
CHARGING SYSTEM
EAS20074
CHARGING SYSTEM
EAS30496
CIRCUIT DIAGRAM
·-----,
.
• > ' 11 •
' -
:® r;·
'--11-- •
of
•- ! ''
! 1-. -
• --------------------,
--i
00
••
••
Kill
'
•
•
:
'
'
.
:@ ,....._._.._,@, ® @ ® @ ® :
.. ,- : '
' ---- ,
-- -tit. • '@·· - - - - - - - - - - - - -•,- -
> • 6
.'
' .
,,..
.... . ''
:®·
. :~ :
• • i • ' i~!f ~
•• • ' 'it-Hl-t-'.-1-1--------1-~U. ..... '
•
•
C
ij ·
'· --
,• • ljt• ..
:~ ....~
:
I
U).,+t-t-.--1-t-th
.. - •
g•'
eiij
'
' ' ''
. ' - - l
' '
' ' '
,--
~ - -, :~: @'
\i.
. •• ~1 •
- - - _... '
etl1t·-tt-+- -HH·-,rrt·~ - .- .- ."";·~·~·
+1-+------,f+--. - ---+++++++++-f+---+f-++Hf+-++f-' ' @'
. ,, '
• :@, '
' fl·:ffl--, al!,
f•-s
•
•
'
- --- ' '
.'
.
•
® ' ''
. ®
. !
•) .!... ""'·. '
, ____ ---1~ ----'
'
'® '
'
ll
.,
/-- -·------·
-----------------------------------------~
7-13
CHARGING SYSTEM
1. AC magneto
2. Rectifier/regulator
4. Main fuse
5. Battery
A. Wire harness
B. Sub-wire harness (negative battery)
7-14
CHARGING SYSTEM
EAS30497
TROUBLESHOOTING
The battery is not being charged.
TIP ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
OKt
OKt
OKt
OKt
OKt
7-15
CHARGING SYSTEM
7-16
LIGHTING SYSTEM
EAS20075
LIGHTING SYSTEM
EAS30498
CIRCUIT DIAGRAM
.
.
• •• •• •
•
-~Ill! .. •
·-----,
' - •
:® ~ · ' •
'-- 11- - • ! ' - . -, --------------- ~-,
.,,,
'
•
•
:@
:
'
'
. @:
, :
~ '
''
f !
-1 • '®-- - - - - - - - - - - - - - ii--
• • 6
-'
''
'- - ---'i'i _I .
I •
•
ij ·
'· --
.. • ljt• .. I
!'1(3\
!'c,I
' -- ...
l'l
W.,tt-1-·--1-t-th
, . •
' g•'
'
~ffl·.
'
'
•(@
1
I
I
I
' '
@'
''
.... ,--- -,
~ 1- -
••
j
~1 •
- - - _... '
L+-1-1-l:~l
-
l -e"Jj;,..lt·••+t-+------++--
"'tt-t- ----....~--++...~
_-_-_-._,.-y-·,._
.'
. - - - - - l-H-H-H-H-+---l+--++HH-++11-' '
'
@'
.f.... . ~-~-: '
'
'
fl·:ffl-
-
-, al!,
• ' -' •
® ' ''
®
--~- -11--11--r------imttmi-1
©r 1
rtt-ll::1±±=1~~ :
'® '
rtt----ir-~ •1'1 -, r=+-•
: ·" ., : ---,I
I I ' I
I
I·~· ·
I I ' I
I I ~ I 1 ,-->.J->-
~
'
'
.. ' .. ~•-'=-=-·
.m,:E1;·:
:@ ~:
' Q,
' -
,_ ..
..
••
.• - l!J1'@ I
~' --...... , -
''& '
II 1A
''o'
. N
•)
l
-'
1/cw)
"'
.. .""'·
I
7-17
LIGHTING SYSTEM
3. Main switch
4. Main fuse
5. Battery
7. Fuel injection system fuse
11.Signaling system fuse
12. Tail/brake light fuse
13. Ignition fuse
15. Headlight fuse
16.Joint coupler
32. ECU (Engine Control Unit)
40.Meter assembly
42.Multi-function meter
46.Meter light
47.High beam indicator light
51. Headlight relay
52. Handlebar switch (left)
53.Dimmer switch
57.Auxiliary light (OPTION)
59. Headlight
60. Front turn signal/position light (left)
61. Front turn signal/position light (right)
64.License plate light
65.Tail/brake light assembly
66. Tail/brake light
A. Wire harness
B. Sub-wire harness (negative battery)
E. Sub-wire harness (rear turn signal light,
license plate light)
F. Sub-wire harness (tail/brake light)
7-18
LIGHTING SYSTEM
EAS30499
TROUBLESHOOTING
Any of the following fail to light: headlight, high beam indicator light, taillight, license plate light, position
light, meter light or auxiliary light (OPTION) .
TIP ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
OKt
OKt
OKt
OKt
OKt
OKt
7-19
LIGHTING SYSTEM
OKt
Replace the ECU, meter assembly or
tail/brake light assembly.
7-20
SIGNALING SYSTEM
EAS20076
SIGNALING SYSTEM
EAS30500
CIRCUIT DIAGRAM
' :@
.,,, - :
'
• '
f r
• ' - - - - - - - - - -•,- - -'
'' -1 :a
-:-----: . ••
''
'- -
.
---'i"! _I
-
.;.®>. '' •-tp-:l
~ ------ -'
•
I ~:~
'~ .:-Y: , !:
L
~
l--
,® ~
'
.. - - # • r- '
'
'
@, --' .. • •• j~!f
.
---
-----,
~""....., '
-'""- - - - ..'
-
I •
•
• • ljt• .. I
~ :
-..-
le/ ,•
w. •
11
'•
eiij
' - -
'
'
:~:
l
'
' @'
-
.... ,--- -,
~
•• ~1 •
- - - _... '
-- etllt' tt-+--- -----l+-· -- - -,-r-·
~- ~ . !.
• :@ ,
f•-s • --- - .
• '
-®
II
7-21
SIGNALING SYSTEM
3. Main switch
4. Main fuse
5. Battery
6. Engine ground
7. Fuel injection system fuse
11.Signaling system fuse
13. Ignition fuse
14.Backup fuse
16.Joint coupler
17. Relay unit
21.Neutral switch
22.Speed sensor
32. ECU (Engine Control Unit)
39.0il level switch
40.Meter assembly
41. Neutral indicator light
42.Multi-function meter
44. Oil level warning light
45. Fuel level warning light
48. Turn signal indicator light
49. Fuel sender
SO.Turn signal relay
52. Handlebar switch (left)
54.Turn signal switch
55. Horn switch
58.Horn
60. Front turn signal/position light (left)
61.Front turn signal/position light (right)
62. Rear turn signal light (left)
63. Rear turn signal light (right)
65.Tail/brake light assembly
66. Tail/brake light
68. Front brake light switch
73. Rear brake light switch
A. Wire harness
B. Sub-wire harness (negative battery)
C. Sub-wire harness (neutral switch)
E. Sub-wire harness (rear turn signal light,
license plate light)
F. Sub-wire harness (tail/brake light)
7-22
SIGNALING SYSTEM
EAS30501
TROUBLESHOOTING
• Any of the following fail to light: turn signal light, brake light or an indicator light.
• The horn fails to sound.
• The fuel meter fails to come on.
• The speedometer fails to operate.
TIP ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
OKt
OKt
OKt
OKt
OKt
7-23
SIGNALING SYSTEM
OKt
OKt
OKt
OKt
The turn signal light. turn signal indicator light or both fail to blink.
OKt
OKt
7-24
SIGNALING SYSTEM
OKt
OKt
OKt
OKt
OKt
OKt
OKt
7-25
SIGNALING SYSTEM
OKt
Replace the meter assembly.
OKt
2. Check the entire signaling system NG~
w1nng . Properly connect or replace the wire har-
Refer to "CIRCU IT DIAGRAM" on ness.
page 7-21 .
OKt
Replace the ECU or meter assembly.
7-26
FUEL INJECTION SYSTEM
EAS20078
CIRCUIT DIAGRAM
a(:] a @ :. ~ ~ ~~ i ~i~
i(BI < 0 < t) ~ 11•3 @:i>•3
.
r.::··@li,,. @I l • (l)t • >
• >
... ••
•
•
I I
'a'
• •
'! 10'
" • •
,---- 1 -
!' '
,--:_--,
!® _, ' -~Ill! '
•
' ! ' .. . .
:@
.
•
----------------~-,
@:
:
··} t ·[I·. r
.,,,
-1
,
•
•
:
'
'
' .. - - - - - - - -•,- -
,
- '
.'
'' ® > • 6
'' .
'- -
.
---'i'i _I
•
L ..
. ,®
,-
'·
~
'
•'
•
',, •
., ••
.
-
~ tH·---i-,
11 I II
'•
~~
··''
'
'®
'
'
' @'
.... ,--- -,
~ 1- -
••
I
~1 •
I '
• •
•
•f•- ®
•
- ® ':
•
-~
©.. , ~ , -1 --r---tmlittt11rtr=tt-i88==~1
I -~
~ :,
'® '
rtt-t- -....
' r==+-•
i~-=--,, Sll$1iS551'iS
: ·" ., : ---,I
I :· · · I 111111 11:
.rL~~·~;;'·-~: -
,i,- - I I I ' I
I
t!!!J 'ti-.. ' co '
I
I
I
I~
'
I
I
1 ,-->.J->-
:~~.~:
.
~I
: . ... l!ttt!
I~ I I
~•-'=- =-·
~-,
·"'=:- ' .o;~
'I\'~ :~.: -ii'.©~
' '
m+- . f';:==.i
:@ ~:
'
,' _- ..'
Q' •
••
•
I -·......- + - - - - 1 - h
l- ~ti~:--!
®J-:(~- ; :~ i
II
1(00:ij l ~-~-
'....... , :~
/-- -====-- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - . . J
7-27
FUEL INJECTION SYSTEM
3. Main switch
4. Main fuse
5. Battery
6. Engine ground
7. Fuel injection system fuse
1O.Joint connector
11.Signaling system fuse
13. Ignition fuse
14.Backup fuse
16.Joint coupler
17. Relay unit
18. Starting circuit cut-off relay
19.Fuel pump relay
20.Sidestand switch
21.Neutral switch
22.Speed sensor
23.02 sensor
24.Engine temperature sensor
25. Intake air temperature sensor
26.Crankshaft position sensor
27.Lean angle sensor
28.Throttle position sensor
29. Intake air pressure sensor
30. ISC (Idle Speed Control) unit
31. Yamaha diagnostic tool coupler
32. ECU (Engine Control Unit)
33. Front cylinder ignition coil
34.Spark plug
35. Rear cylinder ignition coil
36. Front cylinder injector
37. Rear cylinder injector
38.Fuel pump
40.Meter assembly
42.Multi-function meter
43. Engine trouble warning light
51. Headlight relay
56.Clutch switch
67. Handlebar switch (right)
69. Engine stop switch
A. Wire harness
B. Sub-wire harness (negative battery)
C. Sub-wire harness (neutral switch)
D. Sub-wire harness (intake air temperature
sensor)
7-28
FUEL INJECTION SYSTEM
EAS30505
Engine trouble warning light indication and fuel injection system operation
Warning light indication ECU operation Fuel injection operation Vehicle operation
Warning provided when
Flashing* Operation stopped Cannot be operated
unable to start engine
Operated with substitute
Can or cannot be operat-
characteristics in accor-
Remains on Malfunction detected ed depending on the fault
dance with the descrip-
code
tion of the malfunction
* The warning light flashes when any one of the conditions listed below is present and the start switch
is pushed :
Lean angle sensor
12: Crankshaft position sensor 41:
(open or short-circuit)
Blue/black ECU lead ECU internal malfunction
19: 50:
(broken or disconnected) (memory check error)
Lean angle sensor
30:
(latch up detected)
7-29
FUEL INJECTION SYSTEM
EAS30506
The engine operation is not normal, but the
TROUBLESHOOTING METHOD
engine trouble warning light does not come
on.
The engine operation is not normal and the
1. Check the operation of the following sensors
engine trouble warning light comes on.
and actuators in the diagnostic mode.
1. Check:
• Fault code number 01: Throttle position sensor signal (throttle an-
gle)
TTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTT
30: Front cylinder ignition coil
a. Check the fault code number displayed on
31 : Rear cylinder ignition coil
the multi-function meter display. 36: Front cylinder injector
b. Identify the faulty system w ith the fault code 37: Rear cylinder injector
number.
c. Identify the probable cause of the malfunc- If a malfunction is detected in the sensors or
tion . actuators, repair or replace all faulty parts.
If no malfunction is detected in the sensors
••••••••••••••••••••••••••••••••
2. Check and repair the probable cause of the and actuators, check and repair the inner
malfunction. parts of the engine.
7-30
FUEL INJECTION SYSTEM
EAS30951
TIP~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
When the Yamaha diagnostic tool is connected to the vehicle, the operation of the multi-function meter
and indicators will be different from the normal operation.
EAS30508
TROUBLESHOOTING DETAILS
This section describes the measures per fault code number displayed on the multi-function meter dis-
play. Check and service the items or components that are the probable cause of the malfunction fol-
lowing the order given.
After the check and service of the malfunctioning part has been completed , reset the multi-function me-
ter display according to the reinstatement method .
Fault code No.:
Code number displayed on the multi-function meter when the engine failed to work normally. Refer to
"SELF-DIAGNOSTIC FUNCTION TABLE" on page 8-5.
Diagnostic code No.:
Diagnostic code number to be used when the diagnostic mode is operated. Refer to "SELF-DIAGNOS-
TIC FUNCTION AND DIAGNOSTIC COD E TABLE" on page 8-5.
7-31
FUEL INJECTION SYSTEM
5 Defective crankshaft position Check the crankshaft position Crank the engine.
sensor. sensor. Fault code number is not dis-
Refer to "CHECKING THE played ~ Service is finished.
CRANKSHAFT POSITION Fault code number is displayed
SENSOR" on page 7-82. ~ Go to item 6.
Replace if defective.
6 Malfunction in ECU. Replace the ECU.
If fault code numbers "13" and "14" are both indicated , take the actions specified for fault code number
"13" first.
7-32
FUEL INJECTION SYSTEM
7-33
FUEL INJECTION SYSTEM
If fault code numbers "13" and "14" are both indicated , take the actions specified for fault code number
"13" first.
7-34
FUEL INJECTION SYSTEM
7-35
FUEL INJECTION SYSTEM
5 Defective throttle position sen- Check throttle position sensor Turn the main switch to "ON".
sor. signal. Fault code number is not dis-
Execute the diagnostic mode. played ~ Service is finished.
(Code No. 01) Fault code number is displayed
When the throttle valves are ful- ~ Go to item 6.
ly closed:
A value of 14-20 is indicated.
When throttle valves are fully
open:
A value of 92-102 is indicated.
An indicated value is out of the
specified range ~ Replace the
throttle position sensor.
6 Malfunction in ECU. Replace the ECU.
7-36
FUEL INJECTION SYSTEM
3 Connection of main switch cou- Improperly connected ~ Con- Turn the main switch to "ON",
pier. nect the coupler securely or re- and then extend and retract the
Check the locking condition of place the wire harness. sidestand.
the coupler. Fault code number is not dis-
Disconnect the coupler and played ~ Service is finished.
check the pins (bent or broken Fault code number is displayed
terminals and locking condition ~ Go to item 4.
of the pins).
4 Connection of relay unit cou- Improperly connected ~ Con- Turn the main switch to "ON",
pier. nect the coupler securely or re- and then extend and retract the
Check the locking condition of place the wire harness. sidestand.
the coupler. Fault code number is not dis-
Disconnect the coupler and played ~ Service is finished.
check the pins (bent or broken Fault code number is displayed
terminals and locking condition ~ Go to item 5.
of the pins).
5 Wire harness continuity. Open or short circuit ~ Replace Turn the main switch to "ON",
the wire harness. and then extend and retract the
Between main switch coupler sidestand.
and relay unit coupler. Fault code number is not dis-
blue/yellow- blue/yellow played ~ Service is finished.
Between main switch coupler Fault code number is displayed
and joint connector. ~ Go to item 6.
blue/black- blue/black
Between joint connector and
ECU coupler.
blue/black- blue/black
6 Defective sidestand switch. Execute the diagnostic mode. Turn the main switch to "ON",
(Code No. 20) and then extend and retract the
Shift the transmission into gear. sidestand.
Sidestand retracted: "ON" Fault code number is not dis-
Sidestand extended: "OFF" played ~ Service is finished.
Replace if defective. Fault code number is displayed
~ Goto item 7.
7 Malfunction in ECU. Replace the ECU.
7-37
FUEL INJECTION SYSTEM
7-38
FUEL INJECTION SYSTEM
Item 0 2 sensor: no normal signals are recei ved from the 0 2 sensor.
2 Connection of 0 2 sensor cou- Improperly connected ~ Con- Start the engine, warm it up,
pier. nect the coupler securely or re- and then race it, or execute the
Check the locking condition of place the wire harness. diagnostic mode. (Code No. 63)
the coupler. Fault code number is not dis-
Disconnect the coupler and played ~ Service is finished.
check the pins (bent or broken Fault code number is displayed
terminals and locking condition ~ Go to item 3.
of the pins).
3 Connection of ECU coupler. Improperly connected ~ Con- Start the engine, warm it up,
Check the locking condition of nect the coupler securely or re- and then race it, or execute the
the coupler. place the wire harness. diagnostic mode. (Code No. 63)
Disconnect the coupler and Fault code number is not dis-
check the pins (bent or broken played ~ Service is finished.
terminals and locking condition Fault code number is displayed
of the pins). ~ Go to item 4.
7-39
FUEL INJECTION SYSTEM
4 Wire harness continuity. Open or short circuit ~ Replace Start the engine, warm it up,
the wire harness. and then race it, or execute the
Between 0 2 sensor coupler and diagnostic mode. (Code No. 63)
ECU coupler. Fault code number is not dis-
gray/white-gray/white played ~ Service is finished.
gray/green-gray/green Fault code number is displayed
Between 0 2 sensor coupler and ~ Go to item 5.
joint coupler.
red/white-red/white
black/blue- black/blue
Between joint coupler and ECU
coupler.
black/blue- black/blue
red/white-red/white
5 Check fuel pressure. Refer to "CHECKING THE Start the engine, warm it up,
PRESSURE REGULATOR OP- and then race it, or execute the
ERATION" on page 6-11 . diagnostic mode. (Code No. 63)
Fault code number is not dis-
played ~ Service is finished.
Fault code number is displayed
~ Go to item 6.
6 Defective 0 2 sensor. Check the 0 2 sensor. Start the engine, warm it up,
Replace if defective. and then race it, or execute the
Refer to "ENGINE REMOVAL'.' diagnostic mode. (Code No. 63)
on page 5-2. Fault code number is not dis-
played ~ Service is finished.
Fault code number is displayed
~ Goto item 7.
7 Malfunction in ECU. Replace the ECU.
If fault code numbers "28" and "37" are both indicated , take the actions specified for fault code number
"28" first.
7-40
FUEL INJECTION SYSTEM
5 Defective engine temperature Execute the diagnostic mode. Turn the main switch to "ON".
sensor. (Code No. 11) Fault code number is not dis-
When engine is cold: played ~ Service is finished.
Displayed temperature is close Fault code number is displayed
to the ambient temperature. ~ Go to item 6.
The displayed temperature is
not close to the ambient tem-
perature ~ Check the engine
temperature sensor.
Replace if defective.
Refer to "CHECKING THE EN-
GINE TEMPERATURE SEN-
SOR" on page 7-86.
6 Malfunction in ECU. Replace the ECU.
7-41
FUEL INJECTION SYSTEM
2 Installed condition of lean an- Check the installed direction Turn the main switch to "ON",
gle sensor. and condition of the sensor. then to "OFF", and then back to
"ON".
Fault code number is not dis-
played ~ Service is finished.
Fault code number is displayed
~ Go to item 3.
3 Defective lean angle sensor. Execute the diagnostic mode. Turn the main switch to "ON",
(Code No. 08) then to "OFF", and then back to
An indicated value is out of the "ON".
specified range ~ Replace the Fault code number is not dis-
lean angle sensor. played ~ Service is finished.
Fault code number is displayed
~ Go to item 4.
7-42
FUEL INJECTION SYSTEM
4 Installed condition of front cylin- Improperly installed ignition coil Start the engine and let it idle
der ignition coil. ~ Reinstall or replace the igni- for approximately 5 seconds.
Check for looseness or pinch- tion coil. Fault code number is not dis-
,ng. played ~ Service is finished.
Fault code number is displayed
~ Go to item 5.
5 Defective front cylinder ignition Measure the primary coil resis- Start the engine and let it idle
coil. tance of the front cylinder igni- for approximately 5 seconds.
tion coil. Fault code number is not dis-
Replace if out of specification. played ~ Service is finished.
Refer to "CHECKING THE IG- Fault code number is displayed
NITION COILS" on page 7-82. ~ Go to item 6.
7-43
FUEL INJECTION SYSTEM
4 Installed condition of rear cylin- Improperly installed ignition coil Start the engine and let it idle
der ignition coil. ~ Reinstall or replace the igni- for approximately 5 seconds.
Check for looseness or pinch- tion coil. Fault code number is not dis-
,ng. played ~ Service is finished.
Fault code number is displayed
~ Go to item 5.
5 Defective rear cylinder ignition Measure the primary coil resis- Start the engine and let it idle
coil. tance of the rear cylinder igni- for approximately 5 seconds.
tion coil. Fault code number is not dis-
Replace if out of specification. played ~ Service is finished.
Refer to "CHECKING THE IG- Fault code number is displayed
NITION COILS" on page 7-82. ~ Go to item 6.
7-44
FUEL INJECTION SYSTEM
7-45
FUEL INJECTION SYSTEM
7-46
FUEL INJECTION SYSTEM
7-47
FUEL INJECTION SYSTEM
7-48
FUEL INJECTION SYSTEM
3 Wire harness continuity. Open or short circuit ~ Replace Turn the main switch to "ON",
the wire harness. then to "OFF", and then back to
Between lean angle sensor "ON".
coupler and ECU coupler. Fault code number is not dis-
yellow/green- yellow/green played ~ Service is finished.
Between lean angle sensor Fault code number is displayed
coupler and joint coupler. ~ Go to item 4.
blue-blue
black/blue- black/blue
Between joint coupler and ECU
coupler.
blue-blue
black/blue- black/blue
4 Defective lean angle sensor. Execute the diagnostic mode. Turn the main switch to "ON",
(Code No. 08) then to "OFF", and then back to
An indicated value is out of the "ON".
specified range ~ Replace the Fault code number is not dis-
lean angle sensor. played ~ Service is finished.
Fault code number is displayed
~ Go to item 5.
7-49
FUEL INJECTION SYSTEM
If fault code numbers "37" and "42" are both indicated , take the actions specified for fault code number
"42" first.
7-50
FUEL INJECTION SYSTEM
7-51
FUEL INJECTION SYSTEM
7-52
FUEL INJECTION SYSTEM
7-53
FUEL INJECTION SYSTEM
7-54
FUEL INJECTION SYSTEM
7-55
FUEL INJECTION SYSTEM
7-56
FUEL INJECTION SYSTEM
5 Defective relay unit. Execute the diagnostic mode. Start the engine and let it idle
(Code No. 09) for approximately 5 seconds.
Fuel system voltage is below 3 Fault code number is not dis-
V ~ Replace the relay unit. played ~ Service is finished.
Fault code number is displayed
~ Go to item 6.
7-57
FUEL INJECTION SYSTEM
If fault code numbers "37" and "46" are both indicated , take the actions specified for fault code number
"46" first.
7-58
FUEL INJECTION SYSTEM
4 Defective meter assembly. Replace the meter assembly. Turn the main switch to "ON".
Fault code number is not dis-
played ~ Service is finished.
Fault code number is displayed
~ Go to item 5.
7-59
FUEL INJECTION SYSTEM
4 Defective meter assembly. Replace the meter assembly. Turn the main switch to "ON".
Fault code number is not dis-
played ~ Service is finished.
Fault code number is displayed
~ Go to item 5.
7-60
FUEL INJECTION SYSTEM
4 Defective meter assembly. Replace the meter assembly. Turn the main switch to "ON".
Fault code number is not dis-
played ~ Service is finished.
Fault code number is displayed
~ Go to item 5.
7-61
FUEL INJECTION SYSTEM
7-62
FUEL PUMP SYSTEM
EAS20081
CIRCUIT DIAGRAM
.
(l)t ••• •
,--:_--, ffl •
' • --------------------, 00
!® ,./ '
iI
~Ill! ,illl
'
•
•
! ' -.
:@
' ,
'
'
-·
@:
,
-
:
'
'
''
' -1 • '®-- -------- •a-- • 6
-'
'':__, .., -
'
J
' . ""' ._,,..
~ ~ - - - - -'
. l--~ ,® ''
• ·-~ .
,-
• .... Rl
:: •i'lft"t-t-t~~i-1--.----------,---L-JJ~-~~
:· : ~ €: :~___ i
~ ::
~ :·
:1';··:1··
I
: -
I! ,t, -'
O
! •
1 "' ill H
I
•
~
!: I •
•
ij
I .;c ,._ I 6
,• • ljt,. .. I
'' -'
:~ ..1:
•... - _,
..
• •
'•
eiij
:~:
I - -
'
'
l
'
' @'
". '
~
-
- - -,
---~
•• '--l
'
•
- - - -,·-r-·•·- ---++++++++++--1-1-+1-1-l+-+I--IJ ' @'
. Slit' = -, • '
• •
:@, '
'
'
fl·:ffl-
-
-, al!,
f•-
• .® '
- - - - I
.'
® ' ''
•
1i '
'
.++-+-- •:...,®~.
:, .., : 1
I I I I
I I ~ ' I I
0 : ~ I I ..-->.J->-
i!;)•-'=-=-·
0 ' '
'
I
- .'J :
'""' ~ '
:\c/Q:
' -
,_ .. ..
l
.j
• ! •-'
-Ir-- •N
'
'
- '"' .. ""'· '
I••• - - - -I ) ---- '
7-63
FUEL PUMP SYSTEM
3. Main switch
4. Main fuse
5. Battery
7. Fuel injection system fuse
13. Ignition fuse
16.Joint coupler
17. Relay unit
19.Fuel pump relay
32. ECU (Engine Control Unit)
38.Fuel pump
67. Handlebar switch (right)
69. Engine stop switch
A. Wire harness
B. Sub-wire harness (negative battery)
7-64
FUEL PUMP SYSTEM
EAS30514
TROUBLESHOOTING
The fuel pump fails to operate.
TIP ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
OKt
OKt
OKt
OKt
OKt
OKt
OKt
7-65
FUEL PUMP SYSTEM
7-66
ELECTRICAL COMPONENTS
EAS20089
ELECTRICAL COMPONENTS
13
8
12 -- --
9
11
10
7-67
ELECTRICAL COMPONENTS
7-68
ELECTRICAL COMPONENTS
2 3 4
20 6
19
9
18
10
17
7-69
ELECTRICAL COMPONENTS
1. Main switch
2. Throttle position sensor
3. Relay unit
4. Battery
5. Lean angle sensor
6. Headlight relay
7. Starter relay
8. Fuel injection system fuse
9. Main fuse
10. Fuse box
11. Ignition fuse
12. Signaling system fuse
13. Tail/brake light fuse
14. Backup fuse
15. Headlight fuse
16. Spare fuse
17. Rectifier/regulator
18. Sidestand switch
19. Rear brake light switch
20.Fuelsender
7-70
ELECTRICAL COMPONENTS
EAS30549
r-------------------
J 'J:
12
-
Br p
13
--l- --
C:::0-
11 --------'
----
¢>
Dg ltN; Ch YIR B
(L)
N
(R)
Q
:m
I
10 - I
DQ
----;o 0 L G G Y/R
p e, B IJ'( Ch
- - - - - - - - - - - ...J
'D
~ B/Y L IX 0 BINI
------------------- J
,- - - ..........
-------------
I
2
,---------,
:9 --r-------, I
- -8 ) • B
~
~
(.l'-
e -", 'l-,--,-,r-T 0
--- 0 '
~ I
8!1'/ Br
j._ j._
---------
L- -------- I
~
3 4
--------
----
-
YIG BIY
) -(' ----
-
p B/Y
)
i--r-ei
~
RESET SELECT
8
I 5 6
BIR
---- I.AV 8
:i :
'
I Sb
I
~ ---------------
-
~ )
:1 :
''
''
'' --
''
''
''
:7
- - - - ,
-------r--· :
~--------
________ J
~:
L ------ --- I
'----------
7-71
ELECTRICAL COMPONENTS
1. Main switch
2. Front brake light switch
3. Reset switch
4. Select switch
5. Engine stop switch
6. Start switch
7. Rear brake light switch
8. Neutral switch
9. Sidestand switch
10. Dimmer switch
11. Turn signal switch
12. Horn switch
13. Clutch switch
7-72
ELECTRICAL COMPONENTS
Check each switch for continuity with the digital circuit tester. If the continuity reading is incorrect, check
the wiring connections and if necessary, replace the switch.
ECA14371
NOTICE
--------------------------------
Never insert the tester probes into the coupler terminal slots. Always insert the probes from the
opposite end "a" of the coupler, taking care not to loosen or damage the leads.
TIP - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - ~
When checking for continuity, switch back and forth between the switch positions a few times.
The switches and their term inal connections are illustrated as in the following example of the main
switch.
The switch positions "a" are shown in the far left column and the switch lead colors "b" are shown in the
top row.
The continuity (i.e., a closed circuit) between switch terminals at a given switch position is indicated by
'' 0 - 0 ''.
There is continuity between the red and brown leads, and between the blue/yellow and blue leads when
the switch is set to "ON".
b
(
•
'
------ R Br UY L
a{ ON
OFF
0- f..(") 0 -0
- - L
A-
UY
-
-: R
Br
7-73
ELECTRICAL COMPONENTS
EAS30550
Checking the condition of the bulbs
CHECKING THE BULBS AND BULB
The following procedure applies to all of the
SOCKETS
bulbs.
TIP - - - - - - - - - - - - - - - ~ 1. Remove:
Do not check any of the lights that use LEDs. • Bulb
EWA13320
Check each bulb and bulb socket for damage or & WARNING
wear, proper connections, and also for continuity
Since the headlight bulb gets extremely hot,
between the terminals.
keep flammable products and your hands
Damage/wear ~ Repair or replace the bulb,
away from the bulb until it has cooled down.
bulb socket or both.
Improperly connected ~ Properly connect.
No continuity ~ Repair or replace the bulb, bulb
ECA14381
NOTICE - -------------
• Be sure to hold the socket firmly when re-
socket or both .
moving the bulb. Never pull the lead, other-
Types of bulbs wise it may be pulled out of the terminal in
The bulbs used on this vehicle are shown in the the coupler.
following illustration. • Avoid touching the glass part of a headlight
• Bulbs "a" are used for the headlights and usu- bulb to keep it free from oil, otherwise the
ally use a bulb holder that must be detached transparency of the glass, the life of the
before removing the bulb. The majority of bulb, and the luminous flux will be adverse-
these types of bulbs can be removed from their ly affected. If the headlight bulb gets soiled,
respective sockets by turning them counter- thoroughly clean it with a cloth moistened
clockwise. with alcohol or lacquer thinner.
• Bulbs "b" is used for turn signal and tail/brake 2. Check:
lights and can be removed from the socket by • Bulb (for continuity)
pushing and turning the bulb counterclockwise. (with the digital circuit tester)
• Bulbs "c" are used for license plate lights and No continuity ~ Replace.
can be removed from their respective sockets
by carefully pulling them out. Digital circuit tester (CD732)
90890-03243
Model 88 Multimeter with ta-
a b chometer
YU-A1927
TTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTT
a. Connect the positive tester probe to terminal
"1" and the negative tester probe to terminal
"2", and check the continuity.
b. Connect the positive tester probe to terminal
"1" and the negative tester probe to terminal
"3", and check the continuity.
c. If either of the readings indicates no continui-
ty, replace the bulb .
••••••••••••••••••••••••••••••••
C
--
7-74
ELECTRICAL COMPONENTS
Checking the condition of the bulb sockets b. If there is no continuity, replace the fuse.
The following procedure applies to all of the bulb
sockets.
••••••••••••••••••••••••••••••••
3. Replace:
1. Check: • Blown fuse
• Bulb socket (for continuity) TTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTT
(with the digital circuit tester) a. Set the main switch to "O FF".
No continuity ~ Replace. b. Install a new fuse of the correct amperage
rating.
Digital circuit tester (CD732) c. Set on the switches to verify if the electrical
90890-03243 circuit is operational.
Model 88 Multimeter with ta-
d. If the fuse immediately blows again , check
chometer
the electrical circuit.
YU-A1927
Amperage
Fuses Q'ty
TIP ~~~~~~~~~~~~~~ rating
Check each bulb socket for continuity in the Main 40A 1
same manner as described in the bulb section ; Headlight 20A 1
however, note the following.
Ignition 15 A 1
TTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTT Fuel injection system 10 A 1
a. Install a good bulb into the bulb socket.
Signaling system 7.5 A 1
b. Connect the digital circuit tester probes to the
respective leads of the bulb socket. Taillight 7.5 A 1
c. Check the bulb socket for continuity. If any of Backup 7.5 A 1
the readings indicates no continuity, replace Spare 20A 1
the bulb socket.
Spare 15 A 1
Spare 10 A 1
EAS30551
es.
ECA13680
& WARNING
NOTICE Never use a fuse with an amperage rating
--------------
To avoid a short circuit, always set the main other than that specified. Improvising or us-
switch to "OFF" when checking or replacing ing a fuse with the wrong amperage rating
may cause extensive damage to the electri-
a fuse.
cal system, cause the lighting and ignition
1. Remove: systems to malfunction and could possibly
• Side cover (left) cause a fire.
Refer to "GENERAL CHASSIS (1)" on page
4-1. ••••••••••••••••••••••••••••••••
4. Install:
• Tool box
Refer to "GENERAL CHASSIS (2)" on page • Tool box
4-3. Refer to "GENERAL C HASSIS (2)" on page
2. Check: 4-3.
• Fuse • Side cover (left)
TTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTT Refer to "GENERAL CHASSIS (1)" on page
a. Connect the digital circuit tester to the fuse 4-1.
and check the continuity.
7-75
ELECTRICAL COMPONENTS
EAS30552
specific gravity of the electrolyte. Therefore, the
CHECKING AND CHARGING THE BATTERY
EWA 13290
charge of the battery has to be checked by mea-
AwARNING suring the voltage at the battery terminals.
Batteries generate explosive hydrogen gas 1. Remove:
and contain electrolyte which is made of poi- • Side cover (left)
sonous and highly caustic sulfuric acid. • Rider seat
Therefore, always follow these preventive • Battery cover
measures: Refer to "GENERAL CHASSIS (1)" on page
• Wear protective eye gear when handling or 4-1 .
working near batteries. • ECU bracket
• Charge batteries in a well-ventilated area. Refer to "GENERAL CHASSIS (2)" on page
• Keep batteries away from fire, sparks or 4-3.
open flames (e.g., welding equipment, 2. Disconnect:
lighted cigarettes). • Battery leads
• DO NOT SMOKE when charging or han- (from the battery terminals)
dling batteries. ECA 13640
NOTICE
• KEEP BATTERIES AND ELECTROLYTE
OUT OF REACH OF CHILDREN.
-------------
First, disconnect the negative battery lead
• Avoid bodily contact with electrolyte as it "1 ", and then positive battery lead "2" .
can cause severe burns or permanent eye
. .
1n1ury.
FIRST AID IN CASE OF BODILY CONTACT:
EXTERNAL
•Skin-Wash with water.
• Eyes - Flush with water for 15 minutes and
get immediate medical attention.
INTERNAL
• Drink large quantities of water or milk fol-
lowed with milk of magnesia, beaten egg or
vegetable oil. Get immediate medical atten- 3. Remove:
tion. • Battery
ECA13661
4. Check:
NOTICE
-------------
• This is a VRLA (Valve Regulated Lead Acid)
• Battery charge
TTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTT
battery. Never remove the sealing caps be- a. Connect a digital circuit tester to the battery
cause the balance between cells will not be terminals.
maintained and battery performance will • Positive tester probe ~
deteriorate. positive battery terminal
• Charging time, charging amperage and • Negative tester probe ~
negative battery terminal
charging voltage for a VRLA (Valve Regu-
lated Lead Acid) battery are different from TIP ~~~~~~~~~~~~~~
those of conventional batteries. The VRLA
• The charge state of an VALA (Valve Regulated
(Valve Regulated Lead Acid) battery should
Lead Acid) battery can be checked by measur-
be charged according to the appropriate
ing its open-circuit voltage (i.e., the voltage
charging method. If the battery is over-
when the positive battery terminal is discon-
charged, the electrolyte level will drop con-
nected).
siderably. Therefore, take special care
• No charging is necessary when the open-cir-
when charging the battery.
cuit voltage equals or exceeds 12.8 V.
TIP _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ ~
7-76
ELECTRICAL COMPONENTS
7-77
ELECTRICAL COMPONENTS
TIP ~~~~~~~~~~~~~~ c. Make sure that the current is higher than the
Voltage should be measured 30 minutes after standard charging current written on the bat-
the engine is stopped. tery.
TIP ~~~~~~~~~~~~~~
b. Connect a charger and ammeter to the bat-
If the current is lower than the standard charging
tery and start charging.
current written on the battery, this type of battery
TIP _ _ _ _ _ _ _ _ _ _ _ _ _ _ _~
charger cannot charge the VALA (Valve Regu-
Set the charging voltage to 16-17 V. If the set- lated Lead Acid) battery. A variable voltage
ting is lower, charging will be insufficient. If too charger is recommended.
high , the battery will be overcharged .
d. Charge the battery until the battery's
c. Make sure that the current is higher than the charging voltage is 15 V.
standard charging current written on the bat- TIP _ _ _ _ _ _ _ _ _ _ _ _ _ _ _~
tery.
Set the charging time to 20 hours (maximum) .
TIP - - - - - - - - - - - - - - - ~
If the current is lower than the standard charging e. Measure the battery open-circuit voltage after
current written on the battery, set the charging leaving the battery unused for more than 30
voltage adjusting dial to 20-24 V and monitor minutes.
the amperage for 3-5 minutes to check the bat- 12.8 V or more --- Charging is complete.
tery. 12.7 V or less --- Recharging is required.
Under 12.0 V --- Replace the battery.
• Standard charging current is reached
Battery is good.
• Standard charging current is not reached
••••••••••••••••••••••••••••••••
6. Install:
Replace the battery. • Battery
7. Connect:
d. Adjust the voltage so that the current is at the
• Battery leads
standard charging level.
(to the battery terminals)
e. Set the time according to the charging time
suitable for the open-circuit voltage. TIP - - - - - - - - - - - - - - - ~
f. If charging requires more than 5 hours, it is Route the positive battery lead under the nega-
advisable to check the charging current after tive battery lead , making sure not to route it on
a lapse of 5 hours. If there is any change in top of the relay unit.
the amperage, readjust the voltage to obtain ECA13630
TTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTT
Charging method using a constant volt-
age charger
a. Measure the open-circuit voltage prior to
charging.
8. Check:
TIP ~~~~~~~~~~~~~~
• Battery terminals
Voltage should be measured 30 minutes after Dirt~ Clean w ith a w ire brush .
the engine is stopped. Loose connection~ Connect properly.
b. Connect a charger and ammeter to the bat- 9. Lubricate:
tery and start charging. • Battery terminals
7-78
ELECTRICAL COMPONENTS
\~ ~
E
4 1 2 3 + I I-
1a.Install:
• ECU bracket
I I I
]
Refer to "GENERAL CHASSIS (2)" on page
4-3.
• Battery cover
• Rider seat
• Side cover (left)
Refer to "GENERAL CHASSIS (1 )" on page
1. Positive battery terminal
4-1 .
2. Negative battery terminal
EAS30553 3. Positive tester probe
CHECKING THE RELAYS 4. Negative tester probe
Check each relay for continuity w ith the digital
circuit tester. If the continuity reading is incor-
Result
rect, replace the relay.
Continuity
(between "3" and "4")
Digital circuit tester (CD732)
90890-03243
Model 88 Multimeter with ta- Relay unit (fuel pump relay)
chometer
YU-A1927
3 2 1 4
1. Disconnect the relay from the wire harness.
~
2. Connect the digital circuit tester and battery
(12 V) to the relay terminal as shown .
- :/ I
] \~ t + I I-
Starter relay
L -
~
1 I 2
Result
Continuity
(between "3" and "4")
4
Result 2 1
Continuity
(between "3" and "4")
7-79
ELECTRICAL COMPONENTS
TTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTT 1
a. Connect the digital circuit tester to the turn
signal relay terminal as shown.
~1 I I J----- 1
Digital circuit tester (CD732)
90890-03243
Model 88 Multimeter with ta-
chometer
YU-A1927
7-80
ELECTRICAL COMPONENTS
7-81
ELECTRICAL COMPONENTS
Resistance
7 .50-12.50 kQ
D
<== Ql
TTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTT
a. Remove the spark plug cap from the spark
plug lead .
b. Connect the digital circuit tester to the spark
plug cap as shown .
1
Digital circuit tester (CD732)
90890-03243 c. Measure the primary coil resistance.
Model 88 Multimeter with ta-
chometer ••••••••••••••••••••••••••••••••
2. Check:
YU-A1927
• Secondary coil resistance
Out of specification ~ Replace.
D
<== Ql
Secondary coil resistance
8.64-12.96 kQ
TTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTT
a. Disconnect the spark plug cap from the igni-
tion coil.
b. Connect the digital circuit tester to the ignition
coil as shown .
c. Measure the spark plug cap resistance. Digital circuit tester (CD732)
90890-03243
•••••••••••••••••••••••••••••••• Model 88 Multimeter with ta-
EAS30558
chometer
CHECKING THE IGNITION COILS YU-A1927
The following procedure applies to all of the igni-
tion coils. • Positive tester probe ~
1. Check: black/red "1"
• Primary coil resistance • Negative tester probe ~
Out of specification ~ Replace. spark plug lead "2"
TTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTT
2
D
<== Ql
a. Disconnect the ignition coil connectors from
the ignition coil terminals.
b. Connect the digital circuit tester to the ignition 0
coil as shown.
1
Digital circuit tester (CD732)
90890-03243
Model 88 Multimeter with ta- c. Measure the secondary coil resistance.
chometer
YU-A1927
••••••••••••••••••••••••••••••••
EAS30560
7-82
ELECTRICAL COMPONENTS
2. Check: TTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTT
• Crankshaft position sensor resistance a. Connect the test harness-lean angle sensor
Out of specification ~ Replace the crank- (6P) "1" to the lean angle sensor and wire
shaft position sensor/stator assembly. harness as shown.
b. Connect the digital circuit tester to the test
Crankshaft position sensor resis- harness-lean angle sensor (6P).
tance
248-372 Q Digital circuit tester (CD732)
90890-03243
TTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTT Model 88 Multimeter with ta-
a. Connect the digital circuit tester to the crank- chometer
shaft position sensor coupler as shown. YU-A1927
Test harness- lean angle sensor
Digital circuit tester (CD732) (6P)
90890-03243 90890-03209
Model 88 Multimeter with ta- Test harness- lean angle sensor
chometer (6P)
YU-A1927 YU-03209
2- B Gy+-- 1
b. Measure the crankshaft position sensor re- c. Turn the main switch to "ON".
sistance. d. Turn the lean angle sensor to 45°.
••••••••••••••••••••••••••••••••
EAS30561
e. Measure the lean angle sensor output volt-
age.
CHECKING THE LEAN ANGLE SENSOR
1. Remove:
••••••••••••••••••••••••••••••••
EAS30562
7-83
ELECTRICAL COMPONENTS
EWA13810
• Positive tester probe ~
A WARNING black "2"
• A wire that is used as a jumper lead must • Negative tester probe ~
have at least the same capacity of the bat- black "3"
tery lead, otherwise the jumper lead may
burn.
• This check is likely to produce sparks,
therefore, make sure no flammable gas or
fluid is in the vicinity.
3
I
2 ri D
! - - - f_________ ~
I
.---..___.:....+-0 U>i-------, I
I
1 2 3
1 ;
+ b. Measure the stator coil resistance.
M
••••••••••••••••••••••••••••••••
-- -- EAS30680
7-84
ELECTRICAL COMPONENTS
2
0
1
1
c. Start the engine and operate it run at approx- b. Measure the oil level switch resistance.
imately 5000 r/min.
d. Measure the charging voltage. EAS30573
••••••••••••••••••••••••••••••••
EAS30796
CHECKING THE FUEL SENDER
1. Disconnect:
CHECKING THE OIL LEVEL SWITCH • Fuel sender coupler
1. Drain: (from the wire harness)
• Engine oil 2. Remove:
2. Remove: • Fuel sender
• O il level switch (from the fuel tank)
(from the crankcase) 3. Connect:
3. Check: • Fuel sender coupler
• O il level switch resistance 4. Turn the main switch to "ON".
Out of specification ~ Replace the oil level 5. Check:
switch. • Fuel level warning light
Out of specification ~ Replace the fuel send-
Oil level switch er.
Oil level switch resistance (maxi-
Fuel sender is exposed to the atmosphere as
mum level position) shown in "A"
484.0-536.0 Q ~ Fuel level warning light comes on.
Oil level switch resistance (mini- Fuel sender is immersed in fuel as shown in "B"
mum level position) ~ Fuel level warning light goes off.
114.0-126.0 Q
TTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTT
a. Connect the digital circuit tester to the oil level
switch terminal as shown.
7-85
ELECTRICAL COMPONENTS
Warning light does not come on ~ Replace • Never subject the engine temperature sen-
the meter assembly. sor to strong shocks. If the engine tempera-
Warning light flashes eight times, then goes ture sensor is dropped, replace it.
off for three seconds in a repeated cycle (mal-
2. Check:
function detected in fuel sender or thermistor) • Engine temperature sensor resistance
~ Replace the fuel sender.
Out of specification ~ Replace.
....
r1 ,.
a
2510-2780 Q at 20 °C (2510-
2780 Q at 68 °F)
Engine temperature sensor resis-
c,,, •• ii' tance
210-221 n at 100 ° C (210-221 n
at 212 °F)
1
TTTTTTTTTTTTTTTTTTTTTTTTTTTTTTTT
EAS30575 a. Connect the digital circuit tester to the engine
CHECKING THE OIL LEVEL WARNING temperature sensor as shown.
LIGHT
This model is equipped with a self-diagnosis de- Digital circuit tester (CD732)
vice for the oil level detection circuit. 90890-03243
1. Check: Model 88 Multimeter with ta-
• O il level warning light "1" chometer
(Turn the main switch to "ON".) YU-A1927
Warning light comes on for a few seconds,
then goes off~ Warning light is OK. • Positive tester probe ~
black/blue "1"
Warning light does not come on ~ Replace
• Negative tester probe ~
the meter assembly. brown "2"
Warning light flashes ten times, then goes off
for 3 seconds in a repeated cycle (malfunc-
tion detected in oil level switch) ~ Replace
the oil level switch.
n
l.1.,.
.. C
EAs30s12
••••••••••••••••••••••••••••••••
3. Install
CHECKING THE ENGINE TEMPERATURE • Engine temperature sensor
SENSOR
1. Remove: EAS30594
7-86
ELECTRICAL COMPONENTS
~
"1" in a container filled with water "2".
TIP - - - - - - - - - - - - - - - ~
Make sure that the intake air temperature sensor
terminals do not get wet.
c. Place a thermometer "3" in the water.
3
- 1
i=] c. Measure the fuel injector resistance.
••••••••••••••••••••••••••••••••
t9
(00~
1 7
1" ,,
- I I
-
'I J -- -2
~
,.
.o
' -
7-87
TROUBLESHOOTING
TROUBLESHOOTING .. ......... ......... .......... ........ .......... ......... ......... .......... ......... 8-1
GENERAL IN FORMATION ....... .......... ......... .......... ........ ......... .......... ........ 8-1
STARTING FAILURES .... .......... ......... ........ .......... ......... .......... ......... ......... 8-1
INCORRECT ENGINE IDLING SPEED ...... ......... ........ ........... ......... ......... 8-1
POOR MEDIUM-AND-HIGH-SPEED PERFORMANCE ........ ......... .......... 8-2
FAULTY GEAR SHIFTING ....... ......... ......... ......... ......... ......... .......... ......... . 8-2
SHIFT PEDAL DOES NOT MOVE ...... ......... ........ .......... ......... ......... ......... 8-2
JUMPS OUT OF GEAR .. .......... ......... ........ .......... ......... .......... ......... ......... . 8-2
FAULTY CLUTCH .. ......... ......... ......... ........ ......... .......... ......... ......... ......... .. 8-2
OVERHEATING ..... ......... ......... .......... ........ .......... ......... ......... .......... ......... 8-2
POOR BRAKING PERFORMANCE .... .......... ......... ........ .......... ......... ........ 8-3
FAULTY FRONT FORK LEGS ........... ........ ......... ......... ......... .......... ......... . 8-3
UNSTABLE HANDLING .. ......... .......... ........ ......... .......... ......... .......... ......... 8-3
FAULTY LIGHTING OR SIGNALING SYSTEM ... .......... ......... ......... ......... 8-3
EAS20090
Electrical system
TROUBLESHOOTING 1. Battery
EAS30599
• Discharged battery
GENERAL INFORMATION • Faulty battery
TIP ~~~~~~~~~~~~~~~~ 2. Fuse(s)
• Blown, damaged or incorrect fuse
The following guide for troubleshooting does not
• Improperly installed fuse
cover all the possible causes of trouble. It should
3. Spark plug(s)
be helpful, however, as a guide to basic trouble-
• Incorrect spark plug gap
shooting. Refer to the relative procedure in this
• Incorrect spark plug heat range
manual for checks, adjustments, and replace-
• Fouled spark plug
ment of parts.
• Worn or damaged electrode
• Worn or damaged insulator
EAS30600
8-1
TROUBLESHOOTING
EAS30605
Electrical system
JUMPS OUT OF GEAR
1. Battery
• Discharged battery
Shift shaft
• Faulty battery
• Incorrect shift pedal position
2. Spark plug(s)
• Improperly returned stopper lever
• Incorrect spark plug gap
• Incorrect spark plug heat range Shift forks
• Fouled spark plug • Worn shift fork
• Worn or damaged electrode
• Worn or damaged insulator Shift drum
• Faulty spark plug cap • Incorrect axial play
3. Ignition coil(s) • Worn shift drum groove
• Broken or shorted primary or secondary coils
• Faulty spark plug lead Transmission
• Cracked or broken ignition coil • Worn gear dog
4. Ignition system
EAS30849
• Faulty ECU
FAULTY CLUTCH
• Faulty crankshaft position sensor
• Broken generator rotor Woodruff key
Clutch slips
EAS30602 1. Clutch
POOR MEDIUM-AND-HIGH-SPEED • Improperly assembled clutch
PERFORMANCE • Improperly adjusted clutch cable
Refer to "STARTIN G FAILURES" on page 8-1 . • Loose or fatigued clutch spring
• Worn friction plate
Engine • Worn clutch plate
1. Air filter 2. Engine oil
• Clogged air filter element • Incorrect oil level
• Incorrect oil viscosity (low)
Fuel system • Deteriorated oil
1. Fuel pump
• Faulty fuel pump Clutch drags
EAS30603
1. Clutch
FAULTY GEAR SHIFTING • Unevenly tensioned clutch springs
• Warped pressure plate
Shifting is difficult • Bent clutch plate
Refer to "Clutch drags". • Swollen friction plate
• Bent clutch pull rod
EAS30604
8-2
TROUBLESHOOTING
UNSTABLE HANDLING
Fuel system 1. Handlebar
1. Throttle body(-ies)
• Bent or improperly installed handlebar
• Damaged or loose throttle body joint 2. Steering head components
2. Air filter
• Improperly installed upper bracket
• C logged air filter element • Improperly installed lower bracket
(improperly tightened ring nut)
Chassis
• Bent steering stem
1. Brake(s)
• Damaged ball bearing or bearing race
• Dragging brake
3. Front fork leg(s)
• Uneven oil levels (both front fork legs)
Electrical system
• Unevenly tensioned fork spring (both front
1. Spark plug(s)
fork legs)
• Incorrect spark plug gap
• Broken fork spring
• Incorrect spark plug heat range
• Bent or damaged inner tube
2. Ignition system
• Bent or damaged outer tube
• Faulty ECU
4. Swingarm
EAS30609 • Worn bearing or bushing
POOR BRAKING PERFORMANCE • Bent or damaged swingarm
• Worn brake pad 5. Rear shock absorber assembly
• Worn brake disc • Faulty rear shock absorber spring
• Air in hydraulic brake system • Leaking oil
• Leaking brake fluid 6. Tire(s)
• Faulty brake caliper kit • Uneven tire pressures (front and rear)
• Faulty brake caliper seal • Incorrect tire pressure
• Loose union bolt • Uneven tire wear
• Damaged brake hose 7. Wheel(s)
• Oil or grease on the brake disc • Incorrect wheel balance
• Oil or grease on the brake pad • Broken or loose spoke (for spoke wheel mod-
• Incorrect brake fluid level els)
EAS30610
• Deformed cast wheel (for cast wheel models)
FAULTY FRONT FORK LEGS • Damaged wheel bearing
• Bent or loose wheel axle
Leaking oil • Excessive wheel runout
• Bent, damaged or rusty inner tube 8. Frame
• Cracked or damaged outer tube • Bent frame
• Improperly installed oil seal • Damaged steering head pipe
• Damaged oil seal lip • Improperly installed bearing race
• Incorrect oil level (high)
EAS30612
• Loose damper rod assembly bolt FAULTY LIGHTING OR SIGNALING SYSTEM
• Damaged damper rod assembly bolt copper
washer Headlight does not come on
• Cracked or damaged cap bolt 0-ring • Wrong headlight bulb
• Too many electrical accessories
Malfunction • Hard charging
• Bent or damaged inner tube • Incorrect connection
• Bent or damaged outer tube • Improperly grounded circuit
• Damaged fork spring • Poor contacts (main switch)
• Worn or damaged outer tube bushing • Burnt-out headlight bulb
• Bent or damaged damper rod
• Incorrect oil viscosity
8-3
TROUBLESHOOTING
8-4
SELF-DIAGNOSTIC FUNCTION AND DIAGNOSTIC CODE TABLE
EAS20116
EAS31056
8-5
SELF-DIAGNOSTIC FUNCTION AND DIAGNOSTIC CODE TABLE
EAS31057
The diagnostic code numbers cannot be displayed on the multi-function meter. To display the diagnos-
tic code numbers, use the Yamaha diagnostic tool.
Diagnostic
Item Display Procedure
code No.
01 Throttle position sensor sig-
nal
• Fully closed position 14-20 Check with throttle valves ful-
ly closed.
• Fully open position 92- 102 Check with throttle valves ful-
ly open.
03 Intake air pressure Displays the intake air pres- Operate the throttle while
sure. pushing the start switch "@)".
(If the display value changes,
the performance is OK.)
05 Intake air temperature Displays the intake air tern- Compare the actually mea-
perature. sured air temperature with
the display value.
07 Vehicle speed pulses 0- 999 Check that the number in-
creases when the rear wheel
is rotated. The number is cu-
mulative and does not reset
each time the wheel is
stopped.
08 Lean angle sensor Lean angle sensor output Remove the lean angle sen-
voltage sor and incline it more than
0.4-1.4 45 degrees.
• Upright
• Overturned 3.7-4.4
09 Set the engine stop switch to
"o", and then compare the
actually measured battery
Fuel system voltage (battery
Approximately 12.0 voltage with the meter dis-
voltage)
play value. (If the actually
measured battery voltage is
low, recharge the battery.)
11 Compare the actually mea-
Displays the engine tempera-
Engine temperature sured engine temperature
ture.
with the display value.
20 Sidestand switch Extend and retract the side-
stand (with the transmission
• Stand retracted ON
in gear).
• Stand extended OFF
8-6
SELF-DIAGNOSTIC FUNCTION AND DIAGNOSTIC CODE TABLE
Diagnostic
Item Display Procedure
code No.
21 Neutral switch and clutch Operate the transmission,
switch clutch lever, and sidestand.
• Transmission is in neutral ON
• Transm ission is in gear or OFF
the clutch lever released
• Clutch lever is squeezed ON
with the transmission in
gear and when the side-
stand is retracted
• Clutch lever is squeezed OFF
with the transmission in
gear and when the side-
stand is extended
60 EEPROM fault code display
• No history 00 -
• No malfunctions detected
(If the self-diagnosis fault
code 44 is indicated, the
ECU is defective.)
• History exists 01 or 02 (Cylinder fault code) -
• (If both cylinders are defec-
tive, the display alternates
every two seconds.)
61 Malfunction history code dis-
play
• No history 00 -
• History exists Fault codes 12-70 -
• (If more than one code
number is detected, the
display alternates every
two seconds to show all the
detected code numbers.
When all code numbers are
shown, the display repeats
the same process.)
62 Malfunction history code era-
sure
• No history 00 -
• History exists • Displays the total number To erase the history, set the
of malfunctions, including engine stop switch from "~"
the current malfunction, to"o ".
that have occurred since
the history was last erased.
(For example, if there have
been three malfunctions,
"03" is displayed.)
63 Malfunction code reinstate-
ment (for fault code No. 24
only)
• No malfunction code 00 -
• Malfunction code exists Fault code 24 To reinstate, set the engine
stop switch from "~" to "o ".
8-7
SELF-DIAGNOSTIC FUNCTION AND DIAGNOSTIC CODE TABLE
Diagnostic
Item Display Procedure
code No.
70 Control number 0-254 [-] -
EAS31058
8-8
SELF-DIAGNOSTIC FUNCTION AND DIAGNOSTIC CODE TABLE
Diagnostic
Item Actuation Procedure
code No.
Fully closes the ISC valve,
and then opens the valve.
This operation is performed 3
times and takes approxi-
The ISC unit vibrates when
54 ISC valve mately 4 seconds each time.
the ISC valve operates.
The "CHECK" indicator on
the Yamaha diagnostic tool
screen come on during the
operation.
8-9
SELF-DIAGNOSTIC FUNCTION AND DIAGNOSTIC CODE TABLE
8-10
EAS20091
58. Horn EAS30613
lGy)
,--------, ("
811�';;::l::=::l:===========t:========= ���Ill- - - - - - -- -
I
i A---��--.
Ii
� 1\l
-------
'.-------�--t--'
I �
:I @:�
B ' ® f4jl- R -rA-R�
' -R R I� I
R ! �L - -b- -!== 'f "':bNI - •- &
l6/. .,. .- - - - - -+ •
=l-..
--•-
••••
L L
Ml - 1i'1
©- I
r-,
•i ;@ : i : I • @
::: -
:::: :::::::::::_ _
' ,.. u•,� J , "' _ ::::::
;: ' :
,,
:::::: :
<- ..
k·--
-· ...
.L�
.l• ®'
_l!_ > ,
:
. �1m� '9'II
m�:
�@--0,:
II 6 II II�
I' B l!l!J,
,?,.,.q,,.,'
-� -+--H>-++-- -------+++-+e71�
tR) -
,...... ·I,.. ............................ ,
:®
' B
ON
•I Inff I
� (A)•'
�
I
''
·�
'
·-----
' ---- ------ .. :·--@·--:
. �-Cl<O-��-
'
� - - - -
- 1- -�. , ' -
�
M"i-++f-- - - - - - +t
- l+-1-t-l--M�
(Ob)
(BJ
:@--:
' ''
·' -----, •••• --8'. '
"'3l8
'' @: ' -
- -8'.
-lh\ ...
''
@) L ,
··-..- -
- - -...
-M
.:.
''
'' @
l ··-
-o,- -
-
-8'.
-8'.
e,--
-8'.
•R :;
'
"' --- --..
-8'.
''
@ m -H--HH--11+++- -
'
: �: '- - -- - .J
�
l®�"iA �H
'"t-r---1:::====::t:==::1:t:==t:1�==::1:==-�, �IJ�}-: ---------� ., •------- e
G\
-l-<'.rG\- -
mlP
(0fi) (@ ,l,
lffe
@
··:r.i:] Ii��--�a--@--;--I
,---- �
--- I 0, ----------- m;! -------- l !
.--�--''.'l_ �
:@1�: i:;,,;;-� --;, @i' ® @ p @
.j '
. ' I•',--------
Q IIf I -
.·- - \Q9/(8J I •'8) ,• ' R( )
I
I •
I
�t.�-�- .t _ -- -: !r--®-__::@"-!�>__:
+- t
I,
l"""i'CL
© - @
SY
--l�
-
-+,
8
-.- c-.
@
- - (8)
---
0
l @
-----
- - -
(Gy)
l
8
'' '' ,.- · -1$)
. .
9!
io®(� <wi11:@ �:)"°(?@ � : 1 ��0 � (@ '' :@ :':@) :
1
* * '
..
I (;'\,,, II :) I 8
:@
' :@
''
'' ' .
''
: �
• VO B
'.1----E� I (B)
II -:r-- •• (Oy) II
111 1
(GV) ,·.·
8
(8) ••1
8 ''------
18) ' ',_ J�L-- • "J
11 1
•- - - - - - - - - - - .J- -- -i ---- -· - - - - - - -1 - - -I.._ -- ---
B
'
� �
t
11
:@--:
8, . t
.-@-•�·
J
i===::::::::::::::::::::::::_ - �
__- _ _ _ _ _
_
.. 8 --------------------------�
• - ------------
�
mm
(0) (O)
® ~
'
- G
L~M-=------------_J
'&- - - - - - - --
L. ~\..
;®~~--.
v,s.- ----R t•
rl~=ti) ' (Db)
,~
•111- '- - - 1 - J '
&1.- c,.,________j~
L. .-&G;- --------------1-
,.. ff~...
'"
8 Gy " o h, ' 1...
o-
o- '
'
ll[!" I)( 8 G lv4tlv1S W,fl lffl V~J
' - - . ~-- ~
-, .lr_;wr/
B•G
~
'
(0)
"
'
,- - - - -, "" 1;m~w::1:&t1~:t:~~tt1
® : :~ - (0)
w
,_ - - - .J
", y
._u
L.
I '
~
'
G '
................ '
,.... - '
'
:@
''
''
lUPl '
'
'
'
'
'
'
'
'
-- -+-lf+-l-___J(B>
Ct! lff 6 81
i.ll~Y X
at
L i/t'
' J.,.
'
'
·-- _______ _! '
'
'
'
'
'
'
'
""'
'
'
'
' A.@ '
'' '
V '
~ '
' '
'
f~~n-===r================ ~
' en 0rg::m.
t! @
,-~- :~-:~: : j:,·.:
l
~:_J_j
_~_:_~_1_4~;_~__
'
' vllfv1GlP111 w G • '" IX I
(Gy>
: ~
- - - - - =t .J
:,afM
]
XVS95CH/XVS95CHC 2017-2018
WIRING DIAGRAM
-IWIWIWIWl-------·�-T--TWIWl"-I W•-•w•w•-
,
·@1·!-------,
@;)
•
•
(Gy) : '
•
II
m .I
. . . . . . . . --; ---I
® i-a�i--.--a·�-
' ;�: · · ·o--- ,o-1
1\!!/, II
P""",J
0' :,,g. Cv: -- -
iB)
@) � 1 OO��@ll:l�I I�
��--- ---�
I
1· • •
'
::•® :.,.::
0"::fiP
•• �
: ®
• ,.!a,'.-' 8. "-{JJ.-:oo�
."" ""_ t.-c-�----=· ,.-..� :,---,---,----__�·-,___-- -·
___.__..__......._-.._ .-· .-.,.-.,--.-.-.
i•i
mcm
--a,.
' -'
' ' (8)
:• (•t•,:
l
o
@ : j----
®(
:�-� ----�=- ij-r.r�T-:
'• lB) '
(R) ••••- I
-
I
• @:
� ----'
(R )
''.-
'
' � "''"-'-'--'
. j,,j,.,,,.. ''I
""
,---------,
...,,
,_____
: @)
� --------_,
::®t
---j:: --+H++-----+Hi-+-...o@t (O b)
� -- - f.!
= (8)
=
:@··:''
'
1··<u5:
-
-
'
- -
''
- -
:© - -
- :a .-. . . .. . ·---···---···� .
:® -
- -
- ••
- -.. •• •
'
-'
'
----- i
'
:,_ - �: .-------. � ;
-- - J :®r:i : Iii].
I I
• •• •:
,_ --=-=-- •i
�!-
iB)
,---------- ----------- ------- @ -�--·
:@,. [�f�1
' 1
lB} ' ! @�;.·:c:·'.j:tE:i,J' ., I�
t• !• • • • • • • •
! m
®2 "� �:. iB) : _ @__, � @
- -
a
'
I �
'' ::�
@ '-'--""r' ��
I
I '-"
'----------· - - - - - - - - - - - -I - - - - - - - - - - - - - - - - - - - - - - - - - - - -
1
•
------
(0) (6) I
I
'- - -a- - - - J '
� ..... .
iB)
@)�a *
:@ea -�-:,--· @ '® <@
* * '' ----- t 1- - -I .•
- - iB- -) - (Oy)
1 ·�
�! � ::@ *l :*
. :@.
- : (@ '' :@) ' ::..@)
(Gy) i8) (Gy)
- @
: w::(§ '' '' ..
:• De
I)4..
'''' : '' ' 'I - - - �
- ,• i8)
..
: :: '
'' '' iGy) '' 'I � --(B)- --''''• --I
-----�
(Gy)
'' I,______
i8) ' '. J'l>'t •• '
'- - -
l - - - - - - - - � - -- -4 -- ;t------ � �
------
'
raa .....-1 WOW I__..._.._ _ .--.___..,.-.__.. WI W .--- I W i W i WI w-a w-.-- .--.-......_.__.. _........_.. W IIW I W I _ . . . __ .--.___..,.-T__.. WI W .---.._ I W II WI w_.
I
•
I
• I®] L!]
I
•
I !Al [ID
•
.--------. I
•
l\f]
I
• ®
•
• !Al IQ]
l ~X -=a'.~..~ - - ~. -
•- •- • -....-.,--...-
- --=-.~1.w.1 : - ~~
-------·--·--·---
-
~ ~ -.- - ~ ~ I W i "W
·- . - -· -...-.,.w.,.-.-.----..-....-...--,.--1.w.-.-
- - -
i ~.--1.w.1 : -~
- ·- -. - .-
......
-
-=a: ®ii..
·- ------ (@• )) l•f«>J
®
• !Al [QJ
;~ - - - -, •
·~ '
G (Gy)
iii
!Al
(8)
•(8)
If]
G ;i@------~
': ~ - ;
(GV'.l
9 (8)
~(8)
''E9 • A F
' --
'
:& (Db)
·- -- - ,
•
I
... ·- •.:- ... - •• • ... . . .. -.. .. . .,....... •
-=-..-
··-····
··-····
-~;mz 2za1
··-····
-·-···· (B)
....;=c.,-,
(8)
I
®: , _ - - - .J (8)
/AN,. - - - - - - - - - - - .
•
~: @ : I
-e- - - - - - -
• • • •
- • ~
--~ ©
@) ~
0 ®> ,1:
''
'
4) ''
mii'
-------- @
!®1 (0 j
- (Gy)
--- ~
,.
:@
~ @ I
· ---------
(Oy) I
@)
, ___________ J (Gy)
-------
•
·!•f• I
,
r.r.Te1
~
