G-Code and M-Code List for CNC [Easy, With Examples & Tutorials]

Start Here
DON'T DROWN IN THE DETAILS OF GCODE.
GET THE FUNDAMENTALS QUICKLY AND EASILY.

- G-Code Editor and Simulator

- Conversational Wizards for Programming
- Graphical Backplot of Cutting Path Try G-Wizard Editor Now, It's Free!
- Debugger Makes Macro Programming Much Easier
- Translates Cryptic G-Codes to Plain English
Nah! I don't need any GCode Help.

Milling G Code List

Turning G Code List
GCode Simulator
Fanuc Alarm Code List

Complete g code list with m-codes for milling in the Fanuc, LinuxCNC, GRBL, and Haas dialects. We give a quick
de nition for all g code commands along with a link to tutorials and examples of how to use it. Click the g-code link
(if any) to visit a tutorial from our popuplar Online Free G-Code Training that shows examples and teaches how to
program CNC machines using the g-code.

G Codes

Code Category Function Notes

Move in a straight line at rapids

G00 Motion XYZ of endpoint
speed.

Move in a straight line at last

G01 Motion speed commanded by a XYZ of endpoint
(F)eedrate

XYZ of endpoint IJK

Clockwise circular arc at
G02 Motion relative to center R
(F)eedrate
for radius

XYZ of endpoint IJK

Counter-clockwise circular arc
G03 Motion relative to center R
at (F)eedrate
for radius

P for milliseconds X
G04 Motion Dwell: Stop for a speci ed time.
for seconds

G05 Motion FADAL Non-Modal Rapids

G09 Motion Exact stop check

Programmable parameter
G10 Compensation
input

Turn Polar Coordinates OFF,

G15 Coordinate return to Cartesian
Coordinates

G16 Coordinate Turn Polar Coordinates ON

G17 Coordinate Select X-Y plane

G18 Coordinate Select X-Z plane

G19 Coordinate Select Y-Z plane

G20 Coordinate Program coordinates are inches

G21 Coordinate Program coordinates are mm

G27 Motion Reference point return check

G28 Motion Return to home position

Return from the reference

G29 Motion
position

Return to the 2nd, 3rd, and 4th

G30 Motion
reference point

Constant lead threading (like G01

G32 Canned
synchronized with spindle)

Tool cutter compensation o

G40 Compensation
(radius comp.)

Tool cutter compensation left

G41 Compensation
(radius comp.)

Tool cutter compensation right

G42 Compensation
(radius comp.)

Apply tool length

G43 Compensation
compensation (plus)

Apply tool length

G44 Compensation
compensation (minus)

Tool length compensation

G49 Compensation
cancel

G50 Compensation Reset all scale factors to 1.0

G51 Compensation Turn on scale factors

Local workshift for all

G52 Coordinate coordinate systems: add XYZ
o sets

Machine coordinate system

G53 Coordinate
(cancel work o sets)

Work coordinate system (1st

G54 Coordinate
Workpiece)

Work coordinate system (2nd

G55 Coordinate
Workpiece)

Work coordinate system (3rd

G56 Coordinate
Workpiece)

Work coordinate system (4th

G57 Coordinate
Workpiece)

Work coordinate system (5th

G58 Coordinate
Workpiece)

Work coordinate system (6th

G59 Coordinate
Workpiece)

G61 Other Exact stop check mode

G62 Other Automatic corner override

G63 Other Tapping mode

G64 Other Best speed path

G65 Other Custom macro simple call

G68 Coordinate Coordinate System Rotation

Cancel Coordinate System

G69 Coordinate
Rotation

High speed drilling cycle (small

G73 Canned
retract)

G74 Canned Left hand tapping cycle

G76 Canned Fine boring cyle

G80 Canned Cancel canned cycle

G81 Canned Simple drilling cycle

Drilling cycle with dwell

G82 Canned
(counterboring)

G83 Canned Peck drilling cycle (full retract)

G84 Canned Tapping cycle

Boring canned cycle, no dwell,

G85 Canned
feed out

Boring canned cycle, spindle

G86 Canned
stop, rapid out

G87 Canned Back boring canned cycle

Boring canned cycle, spindle stop,

G88 Canned
manual out

Boring canned cycle, dwell, feed

G89 Canned
out

Absolute programming of XYZ

G90 Coordinate
(type B and C systems)

Absolute programming IJK

G90.1 Coordinate
(type B and C systems)

Incremental programming of
G91 Coordinate
XYZ (type B and C systems)

Incremental programming IJK

G91.1 Coordinate
(type B and C systems)

O set coordinate system and

G92 Coordinate
save parameters

G92
Motion Clamp of maximum spindle speed S
(alternate)

Cancel o set and zero

G92.1 Coordinate
parameters

Cancel o set and retain

G92.2 Coordinate
parameters

O set coordinate system with

G92.3 Coordinate
saved parameters

Inverse Time Feed Mode. For

G93 Motion
use with rotary axes

Units per minute feed mode.

G94 Motion
Units in inches or mm.

Units per revolution feed

G95 Motion
mode. Units in inches or mm.

G96 Motion Constant surface speed

G97 Motion Cancel constant surface speed

Return to initial Z plane after

G98 Canned
canned cycle

Return to initial R plane after

G99 Canned
canned cycle

Get a Powerful G-Code Simulator and Editor to Simplify G-Code Work

M Codes
Code Category Function Notes

M00 M-Code Program Stop (non-optional)

M01 M-Code Optional Stop: Operator Selected to Enable

M02 M-Code End of Program

M03 M-Code Spindle ON (CW Rotation)

M04 M-Code Spindle ON (CCW Rotation)

M05 M-Code Spindle Stop

M06 M-Code Tool Change

M07 M-Code Mist Coolant ON

M08 M-Code Flood Coolant ON

M09 M-Code Coolant OFF

M17 M-Code FADAL subroutine return

M29 M-Code Rigid Tapping Mode on Fanuc Controls

M30 M-Code End of Program, Rewind and Reset Modes

M97 M-Code Haas-Style Subprogram Call

M98 M-Code Subprogram Call

M99 M-Code Return from Subprogram

Bonus: Check Out our Other CNC Cookbooks for More In-Depth CNC Information!

If you’re a CNC Beginnner, check out our CNC Beginner’s Cookbook. It’ll get you up to speed with a solid CNC
foundation fast.

We also have Cookbooks for Feeds and Speeds, G-Code Programming, CNC Manufacturing and Shop
Management, DIY CNC, and don’t forget the CNC Cookbook Blog–with over 4 million visitors a year it’s the most
popular CNC blog by far on the web.

More Resources

Mazatrol Training Classes

Fanuc CNC Training Classes

G Code Commands FAQ

How many G codes are there?

There are about 100 g code commands, give or take. There are many dialects of g-code, and some have proprietary
g-codes.

What are G Codes in CNC Machines?

This page lists all the G code commands and tells what they do and also gives a link to tutorials and examples. G
codes are single letter commands that tell the CNC machine what to do. They may command motion (i.e. tell the
machine where to cut) or do things like turn the spindle on or o .

Is learning G-Code hard?

Learning g-code isn’t very hard. We have a complete free online g-code tutorial to teach you as well as a g-code
simulator that makes learning easy.

Why are G Codes used?

G Codes make CNC Machines programmable, which gives them the exible to make almost any part.

What is the di erence between G codes and M codes?

G-Codes are about Geometry while M-Codes are about Machine functions.

Do all CNC machines use G-code?

Not all CNC machine use G-Code. Some may have both g-code and other ways of programming, for example
alternate languages such as Mazak’s Mazatrol or Conversational Programming. Others, may have an alternate
language and no ability to execute g-code at all.
