MRI Equipment and

Accessories
The world’s most extensive range of high quality and innovative
equipment and accessories specifically designed to meet the ever-
changing demands of today’s modern MR environments.

Manufactured by Wardray Premise, Invivo, iRadimed, Lammers Medical

Technology, Metrasens, Magmedix, Aadco Medical, Beekley and
Biodex.

your single source supplier

your single source supplier
Contents
MRI RF Cage Solutions 9

Patient Monitoring, Examination and Dosage Control 15

Patient Monitoring 16
Patient Examination 41
Dosage Control 44

Advanced Clinical Solutions 57

DynaSuite 58
Other 73

Interventional Accessories 75

General Interventional Accessories 76

Paediatric 85

LMT nomag® IC 1.5 / 3.0 86

Other 88

Patient Transportation 89

Wheelchairs and Transport Chairs 96

Spineboards and Accessories 102

Carts For MRI Environments 105

Utility Carts 106

Shelf and Hamper Carts 109
Mobile Carts 113
Procedure Carts 115

Patient Comfort 117

Personal Use Items 118

MRI Compatible Relaxation Systems 120
TESS MRI Down Lighting and Eco Lighting 126

Lighting and Equipment Suspension 133

Lighting 134
Equipment Suspension 137

Safety and Quality Assurance 139

Metal Detection Systems 140

3
Hearing Protection 146
Labels and Signs 151
Phantoms and Accessories 154

Markers and Positioning Aids 159

Skin Markers 160

Foam Positioning Aids 162

Accessories 169

General Support Accessories 170

Cylinders and Regulators 180
Tools and Tool Kits 183

Cleaning 189

Surgery Equipment 199

Suction Devices 200

Electrodes 201
Titanium Surgical Tools 202
Disposable Tools 206

4
Safety Standards
We are proud to supply products from manufacturers who are among the leaders of the MRI industry working to adhere to the new American Society of
Testing and Materials (ASTM) International Standards for MRI Device Marking. These new standards are aimed at eliminating the confusion of the Food and
Drug Administration’s (FDA) previous terms “MR Safe” and “MR Compatible.” When you see an item marked with one of the icons shown below in our
catalogue, it is your guarantee that the appropriate testing has been done and the results of those tests are available to you!
There are now three terms applicable to MRI Device Marking for safety:

MR SAFE as defined by the ASTM International document is applied to an item

that poses no known hazards in all MR environments. MR SAFE items would
include nonconducting, nonmagnetic items such as a plastic Petri dish. The
document further states that an item may be determined to be MR SAFE by
providing a scientifically based rationale rather than test data. Unlike the previous
FDA’s definition of MR Safe, the new MR SAFE may only be applied if the item
is 100% safe, without exception, regardless of MR system field strength or any
environmental or extenuating circumstances. The universal icon to be used for all
MR SAFE products is a green square with white capital letters “MR”, or, a white
square with green border and green capital letters “MR”. Items marked with the
green MR SAFE icon may be taken into, used, or placed anywhere within any MR
environment without risk or potential harm.

MR CONDITIONAL is defined by the ASTM International as an item that has been

demonstrated to pose no known hazards in a specified MR environment with
specified conditions of use. Conditions that may be used to define the specified
MR environment include field strength, spatial gradient, RF fields, specific
absorption rate (SAR) as well as the potential for additional conditions such as
operational conditions for a device. The MR CONDITIONAL label is used to alert
the user that there are certain limitations to the usability of the item, or the testing
that was performed. As an example, an item may have been tested for a 1.5-Tesla
system, but not a 3-Tesla. Items bearing the MR CONDITIONAL icon should
include additional information on the label, as to what the conditionality of use is,
such as a gauss-line restriction or SAR level limitation. The icon designated for
MR CONDITIONAL marking is a yellow equilateral triangle with a black border and
black capital letters “MR” inside.

MR UNSAFE as defined by the ASTM International is any item that is a known

threat or poses a hazard in all MR environments. An example of an MR UNSAFE
item would be a pair of ferromagnetic scissors, or any item constructed of ferrous
metals. The MR UNSAFE icon consists of a white circle with red border and
diagonal strike through and the capital black letters “MR” inside.

If a safety icon isn’t shown does

that mean it can’t be used for MRI?
No, It may still be designated as “MRI Compatible” according
to the old standard. The lack of an icon simply means that the
manufacturer has yet to re-test their products according to the
new standard. We have strongly encouraged all our suppliers to
adopt these new standards and look forward to bringing newly
tested products to our customers in the future.

5
Full Range, Full Service Patient
transport

Safety and
quality
Storage and
assurance
carts

RF MRI room
construction
and turn-key
solutions

Patient
comfort

RF cage
planning and
design
Patient
monitoring
systems
Testing and
compliance
with Australian
standards

Neonatal
incubators

Wide range of
MR compatible
tools and
accessories

Dosage control
systems

6
Imaging Solutions Capability Statement
Imaging Solutions’ commitment to the medical imaging market in
Australia and New Zealand (ANZ) has grown rapidly during the past 5
Product Range and Service Offering
years. During this time, the organisation has evolved significantly and Imaging Solutions offers a broad range of MRI related products and
has pro-actively responded to the challenges of the marketplace and services, from RF cage planning, construction and testing to associated
the demands of our customers. Our decision to enter the MRI market tools and accessories used in the room. We source the world’s market-
was initially a relatively rudimentary one, in so far as we continue to see leading products in each category to deliver quality performance and
Imaging Solutions as a accessories focused supplier. Accordingly, outcomes which you can rely on.
our initial offering focused specifically on marketing packaged MRI
Below is a list of products we offer for the MR environment:
accessories.
• Comfort / environmental systems
More recently and again in response to market and customer demand
for single source supply / turn-key solutions, Imaging Solutions ventured • Storage and carts
into providing the market with high-quality aluminium constructed
modular designed RF cages. This has proved to be enormously effective • Patient transport
in terms of delivering increased value to our customers and providing • RF MRI room construction
the embedded efficiencies a single source transaction model. The MRI
modality market in ANZ is continuing to experience explosive growth and • RF cage planning and design
Imaging Solutions has again responded by expanding our portfolio with
• MR Diagnostics Incubator System nomag® IC
high-end MRI technology products including fluid delivery, MRI patient
monitoring systems and environmental relaxation products. • Patient monitoring systems
The resulting business model developed through this journey has • Dosage / fluid delivery control systems
resulted in the creation of a unique and highly competitive product /
• Other MR compatible tools and accessories
services business platform. Our unique single source supply model
means that with Imaging Solutions, you can start from an empty room
and move through to a turn-key fully operational facility through a single
point of contact (excluding the modality supplier).

World Market Leading Brands

Imaging Solutions prides itself on partnering with only the highest quality
suppliers and manufacturers from around the world to ensure our
customers have the most superior products to choose from.
Below is our world-market-leading MRI supplier partners:

Reference Sites

Gold Coast Medical Imaging, Gold

Coast
Imaging Solutions planned, designed and
constructed an aluminium RF cage at Gold
Coast Medical Imaging’s Southport-based
practice.

Epping Radiology, Melbourne

Installation of Wardray modular RF cage
and complete fit-out for turn-key customer
MIA
Victoria hand-over.

Insight Clinical Imaging, Perth

Supply and installation of Wardray
aluminium modular RF cage.

CitiScan Radiology, Brisbane

Supply and installation of Wardray
aluminium modular RF cage.
Early stage of installation at GCMI
Early stage of installation at GCMI

7
MRI RF Cage Solutions
Quality and reliable RF cages offering outstanding value and
backed by superior knowledge, experience and service.
MRI RF Cage Specifications Our cage is produced from a series of single and multiple extruded
aluminium tube sections locked together with special brackets to form
The MRI cage is an all British shielding structure constructed from a a rigid frame of walls, ceiling and floor. This stands on an insulating
unique modular system using a series of purpose made components membrane with a self levelling compound introduced to infill gaps
produced from the highest quality materials. between the frame and floor.
The self supporting aluminium structure is designed, manufactured and The floor frame is filled with high density boards for a flush finish.
installed under our strict quality control. Each cage is produced to suit Additional support pads for the magnet can be introduced if necessary.
local site conditions. The rigid construction is easily adapted to overcome
late changes in sizes and specification and allows the easy introduction
of additional filters.
The finished product exceeds the attenuation levels required by the
major equipment manufacturers. Our designs are regularly revised and
updated as new scanners are introduced. The standard thickness of the
walls and ceilings is approximately 50mm, excluding any internal finishes.
Floor thickness, excluding the final covering but including the 4mm base
insulation membrane, is approximately 27mm.
The floor can also be strengthened to meet the load bearing
requirements of any size magnet and incorporate under floor cable
ducts. The framework will also support alternative galvanised steel lining
which will provide a degree of magnetic shielding required for some
magnets.

The internal surfaces of the frame are lined with aluminium sheet, locked
into the threaded groove in the extrusion with a face fixed extruded
aluminium cover strip. This unique system gives a double overlap of the
material at each panel joint for the maximum level of performance. Using
a construction, formed from one rigid material eliminates any problems of
structural stressing and flexing through building movement or varying co-
efficients of expansion. It also eliminates the inherent weakness of timber
framework, thinner shielding materials and the problems associated with
some clamping systems.

A typical example of a completed RF Cage.

IMPORTANT: PLEASE NOTE it is acknowledged that an electrolytic
action can occur between aluminium and copper. Where copper based
materials and components are used, we introduce a compatible interface
gasket.

Double Sealed Joint

Our construction ensures easy removal and re-fitting of panels

to allow magnet access in the event of an equipment upgrade.
Sound insulation can be incorporated into the framework of
the walls during assembly

10
Why Choose a
Modular Aluminium Solution?
Aluminium has a proven record on a world wide basis for high
specification RF facilities used by leading telecommunication companies
in sensitive military installations. It is the preferred material for many of
the mobile MRI Units now in regular use and subject to the rigours of
transportation from site to site.
The specification required to meet the necessary conductivity properties
and attenuation levels provides strength, which is put to advantage in
the overall room construction. Subject to reasonable site conditions,
consistent with all installations, the system ensures that there is no
likelihood of degradation, confirmed by over 100 sites completed in the
last 12 years.
As with other shielding materials, such as copper, in adverse conditions
there is a possibility of oxidisation. To simulate these conditions, samples
of our cage construction were submitted for independent testing in a
humidity chamber (98% Rh at 38°C). Results showed neither detectable
signs of corrosion nor increase in resistance at the joints.
• Rigid, robust, free standing cabins.
• Exceeds required attenuation levels of all leading equipment
manufacturers.
• Construction allows easy introduction of additional wave
guides and alterations when equipment is upgraded.

11
Doorsets Special Filters and Fittings
These are constructed with an aluminium facing which can be finished in Air Conditioning Filters
a choice of wood veneers, laminates etc.. and matching timber lippings.
All air conditioning must enter and leave the
Adjustable, purpose made lift off hinges are provided and plated cage through suitably approved RF filters.
beryllium copper finger strips are fitted to the door frame (jams and head)
These are available in stock standard sizes
to minimise wear and tear.
300mm x 300mm and 450mm x 450mm, which
They are also fitted to a removable section on the bottom edge of the should meet most requirements. Non-standard
door to provide contact with the low contour threshold, which are easily sizes are available to special order on request.
replaced in the event of damage or wear.
Galvanic separation is achieved by the inclusion
of a timber frame fitted on the outside of the
cage. A separate equalizing vent filter is fitted
(usually above the door) to alleviate any vacuum
effect within the room.

Medical Gas Filters

Constructed with anti-static connections, they
have been pressure tested for 1 hour at a
maintained pressure of 150psi.

Electrical Filters
The standard single leaf door size gives a clear opening 1200mm wide x
2100mm high. Double doorsets are available on request. Filters are available with 25amp AC rating.
Doors and framework incorporate acoustic seals to jambs, head and They are provided for connection of any
bottom edge of door, to increase the acoustic attenuation. This can be supplementary electrical equipment used within
further increased with the addition of a membrane to the door face as an the room that cannot be routed through the
option. manufacturers’ service panel.
The locking mechanism consists of a single latching point complete with
a Euro-cylinder lock. Lifting the handle engages two further retaining bolts
to ensure maximum contact. An emergency panel 600mm x 600mm is Open Wave Guides
available. This includes an in-built resistance within the hinges to avoid These consist of access tubes in varying
the panel accidentally closing during an escape procedure. diameters and lengths, are easily installed and
preserve the integrity of the shield.
Observation Windows Service Panel Frames and Quench Pipe Filters
These consist of two pieces of glass, each containing a layer of copper These are produced to suit individual
mesh With an anti-reflective coating. They are glazed and laminated to manufacturers’ specifications.
form a complete window unit which is bonded and terminated Within a
welded aluminium frame for fitting into the prepared opening.
The space between the two window sections gives enhanced
attenuation and is designed to eliminate moiré fringes. These are
constructed with an aluminium facing which can be finished in a choice
Magnetic Shielding
of wood veneers, laminates etc. and matching timber lippings. We are able to offer a design and installation service for any Magnetic
Shielding requirement upon receipt of the full manufacturers’
Our standard window size is 1500mm x 900mm, although a single unit is specifications, outlining existing field strengths together with the
available up to a maximum size of 2000mm x 1000mm. proposed room layout.
Below: Larger windows will be produced in separate sections using a
sealing joint.
Enquiry Guide: RF Cages
• If available, please provide a drawing or dimensioned sketch.
• Our standard door size is 1200mm wide x 2100mm high. Does it open
into or out of the room?
• Proposed equipment manufacturer if known and type of equipment,
model number etc.
• Types and quantities of any special filters required.

12
RF Testing
Aware of the advances in technology Wardray Premise have, in
conjunction with leading EMC analysts, developed their own in-
house testing facility. Using highly sophisticated RF test equipment,
our construction methods have been refined to obtain attenuation
levels at the wide range of frequencies now specified by the leading
equipment manufacturers. These levels are far in excess of their current
requirements which leave us well equipped to produce rooms for higher
powered magnets.
In addition to conducting RF tests for our own cages we are always
pleased to carry out independent tests on other sites and in mobile units.
Tests are conducted in accordance with IEEE 299-2006. Further
developments in the testing standards are being investigated which will
be introduced when appropriate. Latest information can be obtained
from our Technical Staff.

Room Fit Out

We will work in close co-operation with site contractors involved in the
installation of air conditioning, power, lighting and internal finishes or as
an alternative can contract to provide a complete installation.

Site Requirements
Site requirements prior to our Installation
1. An enclosed room in clean condition with all other trades completed.
2. Structural floor moisture content not exceeding 5%
3. Structural floor level to a tolerance of ± 2.5mm. If this has not been
achieved, we reserve the right to charge for any waiting time whilst the
work is completed to the correct specification.
4. Temperature to be maintained at a minimum of 15°
5. Relative humidity between 0% and 10% without condensation.

Important Notes
Post-Installation Care to Preserve the Validity of the Guarantee.
The RF cabin must be protected against water ingress, either from
external weather penetration or leakage from internal services. At no time
must any item be fixed to the cage or any penetrations passed into the
room other than as authorised through the manufacturer’s pen panel.
Any proposed works involving the cabin structure must not be
undertaken without first seeking our advice and written consent.

Peace of Mind Guarantee

The main structure is based on the use of high grade aluminium which
will not degrade beyond our stated design limits.

5 A five year guarantee is offered for

attenuation performance, defective materials
anty

and workmanship excluding finger strips

which are liable to damage, wear etc. and
ea will require periodic replacement.
rr

r Wa
Y

As a result of continuing development and improvements we reserve the

right to change the specification without prior notice.

13
Patient Monitoring, Examination
and Dosage Control
Integrated MRI compatible patient monitoring and examination
systems as well as a range of market-leading dosage control
solutions.
Patient Monitoring

Invivo Essential
When quality patient care is simply Light-weight and easy to transport, with a unique wireless design,
Essential features digital technology for exceptional performance on
essential. SpO2 values, low and high perfusion and motion. Artefact suppression
also helps enhance study quality. And with its unrestricted gauss rating,
During MRI sedation studies, providing quality care for your patients Essential can be used virtually anywhere.
throughout the entire process is vital. Easily deliver an improved level of
Essential is precisely what you need from sedation induction through to
care that moves with your patient from sedation to imaging suite and into
recovery – which is exactly what you’d expect from Invivo.
recovery with the very portable Invivo Essential SpO2 monitor.
Essential helps you create a more satisfying patient experience, The value of a deeper understanding.
introduces new opportunities in patient monitoring, and makes better use
of your human and financial resources. Invivo is the worldwide leader in MRI patient gating and monitoring
solutions, with a distinguished history that now includes an
Safer. Smarter. Smaller. environmentally conscious “green” classification.
Creating systems to help monitor patients during the entire sedation
Exceptional clinical performance requires industry leading SpO2
process, Invivo MRI has been there for you for over twenty years. When
technology. Essential delivers. Either as a standalone monitor in basic
quality patient care is simply essential, simply choose Invivo.
clinical situations or combined with multi-parameter systems for
more complex sedation studies, Essential is designed to provide the
monitoring accuracy and stability you need for every patient type, from
neonatal to obese adults.

Quick Connect flexible mounting enables secure and easy attachment to

common transport tables, bed rails, wall channels and roll stands.

16
Quality that’s easy to see, simple to use.
Small and lightweight, Essential fits easily in the palm of your
hand, on a roll stand or patient bed.
The first monitor with an unrestricted gauss rating lets
you focus more on the patient and less on equipment
placement.*
360˚ alarm light alerts staff even when they are away from the
screen or out of earshot.
Wireless SpO2 monitoring uses digital signalling for precise
saturation values and fast acquisition, even for neonatal
patients.
Exclusive SpO2 Perfusion Index for instant feedback on signal
quality, confident assessment and faster setup.
Easy Read 14.5 cm colour touch screen clearly displays
patient vitals up close or across the room.
Express network selection instantly synchronizes with Invivo
wireless monitors or certain MRI scanners, for continuous
patient care.

Simplicity is the shortest path to

department efficiency.
Essential makes transporting patients from preparation to
exam and through recovery without monitoring lapses fast
and easy. The compact wireless monitor with its easy-to-use,
brilliant colour touch screen display can be mounted on an
IV stand, bed rail or a roll stand, or carried in its specially
designed case.
Invivo monitoring systems are designed to anticipate your
needs, delivering information accurately, conveniently,
intuitively. And Invivo wireless monitoring means better patient
comfort, safety and seamless continuity from start to finish.

Product Codes
Essential MRI Patient Monitor IN2-865353
A01 Accessory Kit IN2-865353/A01
A02 No Accessories IN2-865353/A02
S01 Sp02 IN2-865353/S01
S02 No Sp02 IN2-865353/S02

17
Invivo quality: designed
for special environments.
Invivo patient monitoring systems are designed, engineered and manufactured
from the outset to withstand the demands of usage within high magnetic fields. The
Essential monitor is no exception.
As the first monitor with an unrestricted gauss rating, it enables you to focus more
on the patient and less on equipment placement. So you can be more confident of
the safety and security of patient and staff both outside and within the MRI imaging
suite.
All Invivo monitors are built according to the highest standards of quality and the
latest manufacturing processes to deliver long-lasting reliability from the start.

18
When you start with More satisfied patients.
Put patients at ease with a faster exam, free of wires and the discomfort

the patient, you finish of repeated sensor attachments.

Uninterrupted monitoring.
with better patient Reduce the risks associated with unmonitored, sedated patients and
relieve the time pressure on your staff caused by attaching different sets

care. of sensors during the exam process.

When monitoring revolves around the patient, complex sedation studies Better resource management.
are simplified. By easily integrating Essential and Expression monitors Increase staff efficiency by enabling more time for patient interaction. And
into one multi-parameter solution, you work smarter, not harder. With one discover more ways to meet your business objectives by making more
connection to the patient, Invivo’s wireless technology makes it easy to efficient use of your equipment.
monitor and move a patient from induction to imaging and to recovery
without the constraints found during conventional monitoring processes.
With a single wireless module, Essential enables you to track vital
signs continuously throughout the entire sedation process, and also
synchronize with the MRI system for easy peripheral gating.

Invivo Essential Mounting Options

Part Number Description

IN2-989803171711 Essential Carry Case

Protects the Expression for mobile applications. Carry case provides a see
through window to view and control the monitor screen. Case provides storage
for accessories or wireless modules. Includes handle and shoulder strap.

IN2-9898063171681 Essential Flex Mount

Provides quick and easy mounting of the Essential for multiple applications.
The Flex Mount quickly and easily allows the Essential to mount to a vertical
object such as a roll stand to a horizontal object such as a bed rail.

IN2-989803173761 Essential MR Roll Stand

Provides a non ferrous mobile roll stand for Essential to be mounted to. Must
be used in conjunction with the Essential Flex Mount (989803171681)

19
Invivo Expression
Informed Design by Invivo
• Six-colour waveform capability – two ECG, SpO2, EtCO2
and two IBP – provides an easy-to-see overview of patient
status.
• The cleanest and safest ECG information available, thanks
to proprietary Advanced Gradient software, for any clinical
magnet up to and including 3.0 Tesla.
• Wireless SpO2 monitoring uses a digital signal to ensure
precise values for saturation and fast acquisition, even on
paediatrics.
• Precise EtCO2 measurement with waveform fill helps you
make more informed decisions when monitoring respiratory
gas.
• Patient body temperature monitoring allows you to provide
the same standard of care in the MRI suite that you offer
in the OR by allowing rectal, oesophageal or surface
temperature measurements.
• The smart battery management system provides a full eight
hours of life on a single charge for each wireless module.
The monitor displays the remaining battery life for the base
unit, display and each module. A remote battery charger
charges up to four depleted batteries at one time.

Expression’s innovative design allows

you to make informed decisions about a
patient’s condition, safely and efficiently.
• Large, tilting 12-inch colour screen makes patient monitoring effortless with
a complete picture of patient status – including ECG, SpO2, EtCO2, invasive
pressures and Active Trend Arrows – that can easily be viewed from a distance.
• Expression’s 360˚ Alarm Light is positioned on top of the monitor, so you can be
alerted to check the patient’s condition even when you can’t hear the alarm or
when you aren’t in front of the screen.
• Numbers and graphs are colour-coded and easy to read enabling fast decision
making. Open menus don’t block vitals for continuous monitoring of patients.
• Using the innovative, quick-set mount, you can easily remove the display and
place it in a more convenient location in seconds.
• Navigation is “dial-and-select” simple. Just turn the large control knob and click
on the vital sign for more targeted menu options.

Product Codes
Expression MRI Patient Monitor IN2-865214
A01 Accessories Kit IN2-865214/A01
A02 No Accessories IN2-865214/A02
D01 DCU With Printer IN2-865214/D01
D02 DCU Without Printer IN2-865214/D02
D03 No Display - Service 0 IN2-865214/D03
G01 WPU With Agents IN2-865214/G01
G02 WPU With ETC02 IN2-865214/G02
M01 Rolling Pedestal IN2-865214/M01
M02 PCM Horizontal IN2-865214/M02
M03 PCM Vertical IN2-865214/M03
P01 WPU With IBP IN2-865214/P01
T01 WPU With Temperature IN2-865214/T01

20
Electrode Fail Indicator immediately notifies you if an electrode
loses connection with the patient, so you can quickly identify
the source of a lead failure during a scan.

Trend Arrows instantly provide a visual representation of vital

signs trends so you can assess the patient’s history while
also monitoring live readings. This adds a level of safety and
security that other MRI monitors can’t match.

Exclusive SpO2 Perfusion Index provides instant feedback

on the overall quality of your SpO2 signal, for more confident
patient assessment and faster setup time.

21
An MRI exam shouldn’t
be a high-wire act.
Wireless technology speeds workflow
and reduces downtime, while maximizing
patient comfort and safety.
Invivo’s industry-exclusive wireless technology makes it easy to move the patient
from room to room, expediting patient management and workflow in the MRI suite.
Sensor setup is fast and simple in the induction area. Wireless ECG, SpO2 and
respiration mean fewer lines in the exam room. And remote monitoring allows you
to continue to track vital signs in the recovery room without the need for extensive –
and expensive – wireless router networks.
Wireless technology helps increase patient comfort and safety too. Shorter cables
reduce the risk of cable heating. And with their unique one-piece design and large
wet-gel contact area, Quadtrode® electrodes also dissipate heat to help eliminate
burning. Plus Expression is the only monitor to offer complete infection control, with
disposable options for every parameter: MRI internal body temperature sensors, MRI
SpO2 grips, Quadtrode electrodes, blood pressure cuffs and end tidal CO2 sample
lines and cannulas.

Invivo wireless ECG and Quadtrode electrodes are the only

MRI monitor solutions available without any reported FDA
burning reports.

22
Invivo Precess
Invivo has over 20 years of experience developing patient vital signs
monitors designed to increase safety, patient throughput and image
quality. Precess is Invivo’s 5th generation MRI patient monitor and is the
first monitor in the world to feature wireless ECG and wireless SpO2.

Clinicians want more usable space in MRI Suite.

• Easier patient access
• Easier patient transportation to/from MRI
• Greater cable longevity
• More efficient patient workflow
• Reduced risk of damaging equipment during transport

Product Codes
Precess Blue MRI Monitor IN2-865323
A01 Accessories Kit IN2-865323/A01
A02 No Accessories IN2-865323/A02
G01 Anesthetic Agents IN2-865323/G01
G02 EtC02 IN2-865323/G02
P01 IBP IN2-865323/P01
T01 Temperature IN2-865323/T01
Precess Control Room Display IN2-865485
D01 Display With Printer IN2-865485/D01
D02 Display Without Printer IN2-865485/D02

Ideal for intra-operative,

anaesthesia and
sedation applications.

23
Invivo Accessories
The value of purpose-built MRI accessories may not be readily apparent
until an adverse event at your facility. This can be a life changing situation
for the patient, staff and family members. Using Invivo accessories will
help enable MRI departments to adopt practices recommended by
The Joint Commission, American Society of Anesthesiologists (ASA),
National Institutes of Health (NIH) and the Centers for Disease Control
and Prevention (CDC).

ECG Accessories
Part Number Description

IN2-989803152251 Standard ECG Kit

(IN2-94016) Includes ECG Lead Cable (9224), box of 10 Standard Quadtrodes (9303A),
and single tube of Prep Gel (453564120521)

IN2-989803152261 CV ECG Starter Kit

(IN2-94015) Includes CV ECG Lead Cable (9223), box of 10 CV Quadtrodes (9371A) and
single tube of Prep Gel (453564120521)

IN2-989803152441 Neonatal Starter Kit

(IN2-94013) Includes Neonatal ECG Lead Cables (9222), box of 10 Neonatal Quadtrodes
(9372A), single tube of Prep Gel (453564120521), Neonatal NIBP Hose
(989803169421), Neonatal #3 BP Cuff (989803170401), Neonatal #5 BP
Cuff (989803170421), Neonatal Grip Sensors (9399AN), Infant Grip Sensors
(9399AI), and Infant Cannulas (9014 and 9015)

IN2-989803163121 Wireless ECG Module (Generation 2) Additional or Replacement (Must provide

Expression Cart/PMC serial number).

IN2-989803152291 Prep Gel

(IN2-9009) Package of 3 tubes (453564120521). Must be used when applying MRI
electrodes

IN2-989803152301 Standard ECG Lead Cable

(IN2-9224) Compatible with the Standard Quadtrode 9303A or 9303N

IN2-989803152311 Standard Quadtrode (Box of 10)

(IN2-9303A) MRI Electrodes compatible with the 9224 Standard Lead Cable

24
Part Number Description

IN2-989803152321 Standard Quadtrode (Box of 50)

(IN2-9303N) MRI Electrodes compatible with the 9224 Standard Lead Cable

IN2-989803152331 Neonatal ECG Cable

(IN2-9222) Compatible with the Neonatal Quadtrode 9372A

IN2-989803152341 Neonatal Quadtrodes (Box of 10)

(IN2-9372A) MRI Electrodes compatible with the 9222 Neonatal Lead Cable

IN2-989803152351 CV ECG Lead Cable

(IN2-9223) Compatible with the CV Quadtrode 9371A

IN2-989803152361 CV Quadtrode (Box of 10)

(IN2-9371A) MRI Electrodes compatible with the CV Lead Cable 9223, Advanced Filter
Cable 989803170121 and Special Application Cable 452213305301

IN2-989803170121 Advanced Filter ECG Cable

Designed to minimize the gradient artefact on the ECG trace. For use with CV
Quadtrode 9371A

IN2-452213305301 Special Application ECG Lead Cable - Compatible with the CV Quadtrode
9371A- Designed to allow for wide electrode placement

Part Number Description

IN2-989803163121 Wireless ECG Module (Adjustable) Additional or Replacement (Must provide

Precess serial number).
