Code: EC23APC201

R23
[Link] I Year II Semester Regular/Supplementary Examinations July 2024
NETWORK ANALYSIS
(Electronics & Communication Engineering)
Time: 3 hrs. Max Marks: 70
Answer all the questions
****
PART-A
(Answer the following: 10 X 02 = 20 Marks)

1. Answer the following 10x02=20 Marks


a) What is a dual network? 2M
b) State reciprocity theorem. 2M
c) Define the time constant of RL & RC circuits? 2M
d) Define transient state. 2M
e) Define Impedance and Admittance? 2M
f) A voltage of 100 V is applied to a capacitor of 12 μF. The current is 0.5 A. What must
be the frequency of supply?
g) Define coefficient of coupling and write its expression?
h) What is meant by quality factor?
i) Express Z–parameters in terms of the Y–parameters.
j) Write short notes on two port network.
PART-B
(Answer all the questions: 05 X 10 = 50 Marks)
UNIT-I
2. State and explain Maximum power transfer theorem with example. 10 M

OR
3. a) State and explain about super position theorem 5M

b) Using node analysis, find the current flowing through the resistors. 5M

UNIT-II
4. Explain in detail about DC transient Response for R-L series circuit. 10M
OR
5. 10 M
A dc voltage of 100V is applied in the circuit shown in figure below and the switch is
kept open. The switch K is closed at t = 0. Find the complete expression for the
current.

Page 1 of 2
UNIT-III
6. A coil of resistance 5Ω and inductance 120 mH in series with a 100μF capacitor is 10 M
connected to a 300 V, 50 Hz supply. Calculate: (i) The current flowing in the circuit.
(b) The phase difference between the supply voltage and current. (iii) The voltage
across the coil.(iv) Real and reactive power

OR
7. Distinguish between reactance, impedance, admittance,Power factor and susceptance. 10 M
UNIT-IV
8. a) Distinguish between self-inductance and mutual inductance. 5M

b) If the two identical coils have an equivalent inductance of 0.08 H in series aiding 5M
and0.035 H in series opposing, what are the values of L1, L2, M and K.
OR

9 Derive the expression for resonant frequency for a tank circuit. 10 M

UNIT-V

10 Derive the relation between Z parameter in terms of ABCD parameter. 10 M

OR

11 Find the hybrid parameters for the two-port network shown in Fig. below 10 M

*****

Page 2 of 2
