2 Channel CAN BUS FD Shield for Raspberry Pi
On this page
2 Channel CAN BUS
FD Shield for
Raspberry Pi
This is a CAN BUS shield for Raspberry
Pi(hereinafter referred to as 2 channel pi hat), 2
channel CAN BUS I/O, support CAN FD. CAN
FD support much faster transmission speed(up
to 8Mbps)
Also it have two On-board 120Ω terminating
resistors which are controlled by the switches.
Versions Declare
There are 3 versions of the CAN BUS shield
for Raspberry Pi. All 3 versions work perfectly
on Raspberry Pi platform, and may skip this
section if you're using RPi platform.
The CAN BUS shield now also supports the
Nvidia Jetson Nano platform, and different
versions of the CAN BUS Shield do affect the
functionality, please check the table below
carefully if you're using with Jetson Nano
Platform.
Product RPi J
Chip
Name State
2-Channel
CAN-
Two Si
BUS(FD) MCP2517FD
Channels Ch
Shield for RPi
(MCP2517FD)
2-Channel
CAN-
BUS(FD) Two
MCP2518FD Tw
Shield for Channels
Raspberry Pi
(MCP2518FD)
As you can see, there are two versions of chips
used in the 2-Channel CAN-BUS(FD) Shield for
RPi (MCP2517FD) and both channels work on
RPi but only single channel (CAN0) works on
the Jetson Nano Platform!
Features
High-speed transfer rate: 8Mbps@10m
20AWG shielded cable / 1Mbps@40m
20AWG shielded cable
Stable power supply, selectable Raspberry
Pi power supply or DC power supply
Compatible with Raspberry Pi 2, Raspberry
Pi 3, Raspberry Pi 3, Raspberry Pi 4 and
Raspberry Pi Zero
One-button configuration of 120Ω
terminating resistor
Support CAN FD
Hardware Overview
Figure 1. Hardware
overview(MCP2517)
Figure 2. Hardware
overview(MCP2517)
Figure 3. Block Diagram(MCP2517)
Figure 4. Hardware
overview(MCP2518FD)
Mounting Guide
Figure 4. Mounting Guide
CAUTION
You can see that we used nylon columns
during assembly to avoid short-circuiting
between the metal terminals under the
CAN BUS port and the HDMI interface on
the Raspberry Pi. So please be sure to
assemble the nylon column as shown.
Specification
Parameter Value
12V~24V DC
Power Input Raspberry Pi GPIO
5V
CAN FD Controller MCP2517FD
CAN FD
MCP2557FD
Transceiver
CAN FD Channel 2
8Mbps@10m 20AWG
shielded cable
Transfer Rate
1Mbps@40m 20AWG
shielded cable
Communication
SPI
Interface with Pi
Grove Interface Grove I2C x2
Platforms Supported
Raspberry
Arduino
Pi
Getting Started
Materials required
2-
CAN-
Channel
Raspberry Arduino BUS
CAN-
pi Board Shield
BUS(FD)
V2
Shield
Get Get
Get ONE Get ONE
ONE ONE
Now Now
Now Now
Also we need to two male to male jumper and
power cables to power those boards.
Hardware Connection
Step 1. Follow the Mounting Guide to Plug
the 2-Channel CAN-BUS(FD) Shield into
Raspberry.
Step 2. Plug the CAN BUS Shield V2 into
the Seeeduino(or Arduino) Board
Step 3. Use the jumpers to connect the
CAN terminal of both shield.
2-Channel CAN- CAN-BUS
BUS(FD) Shield Shield V2
CAN_0_L CANL
CAN_0_H CANH
TIP
You can find the silkscreen at the b
Step 4. Power the Raspberry Pi and
Seeeduino.
Software
Install CAN-HAT
Step 1. Open config.txt file
sudo nano /boot/config.txt
Step 2. Add the following line at the end of
the file
dtoverlay=seeed-can-fd-hat-v2
Step 3. Press Ctrl + x, press y and press
Enter to save the file
Step 4. Reboot Raspberry Pi
sudo reboot
Step 5. Check the kernel log to see if
CAN-BUS HAT was initialized successfully.
You will also see can0 and can1 appear in
the list of ifconfig results
pi@raspberrypi:~ $ dmesg | grep spi
[ 6.178008] mcp25xxfd spi0.0 can0: MCP2
[ 6.218466] mcp25xxfd spi0.1 (unnamed n
pi@raspberrypi:~ $ ifconfig -a
can0: flags=128<NOARP> mtu 16
unspec 00-00-00-00-00-00-00-00-00-
RX packets 0 bytes 0 (0.0 B)
RX errors 0 dropped 0 overruns 0
TX packets 0 bytes 0 (0.0 B)
TX errors 0 dropped 0 overruns 0
device interrupt 166
can1: flags=128<NOARP> mtu 16
unspec 00-00-00-00-00-00-00-00-00-
RX packets 0 bytes 0 (0.0 B)
RX errors 0 dropped 0 overruns 0
TX packets 0 bytes 0 (0.0 B)
TX errors 0 dropped 0 overruns 0
device interrupt 167
eth0: flags=4163<UP,BROADCAST,RUNNING,MULT
inet 10.0.0.13 netmask 255.255.25
inet6 fe80::44cc:eeb8:47a0:7fce p
ether b8:27:eb:25:d4:e0 txqueuele
RX packets 299 bytes 27437 (26.7
RX errors 0 dropped 0 overruns 0
TX packets 172 bytes 25974 (25.3
TX errors 0 dropped 0 overruns 0
lo: flags=73<UP,LOOPBACK,RUNNING> mtu 655
inet 127.0.0.1 netmask 255.0.0.0
inet6 ::1 prefixlen 128 scopeid
loop txqueuelen 1000 (Local Loop
RX packets 0 bytes 0 (0.0 B)
RX errors 0 dropped 0 overruns 0
TX packets 0 bytes 0 (0.0 B)
TX errors 0 dropped 0 overruns 0
wlan0: flags=4098<BROADCAST,MULTICAST> mt
ether b8:27:eb:70:81:b5 txqueuele
RX packets 0 bytes 0 (0.0 B)
RX errors 0 dropped 0 overruns 0
TX packets 0 bytes 0 (0.0 B)
TX errors 0 dropped 0 overruns 0
Step 6. Set the can fd protocol, and the
dbitrate can be set to 8M speed. Refer to
the kernel documentation for more usage
sudo ip link set can0 up type can bitr
sudo ip link set can1 up type can bitr
sudo ifconfig can0 txqueuelen 65536
sudo ifconfig can1 txqueuelen 65536
Step 7. Open two terminal windows and
enter the following commands in the
Windows to test can fd protocol.
#send data
cangen can0 -mv
#dump data
candump can0
You can test the CAN-BUS by connecting
two channels by itself using jumpers: 0_L
<===> 1_L, 0_H <===> 1_H.
Communicate with Arduino CAN BUS
Shield
In this demo, we only use one of the two
channels.
For Arduino CAN BUS Shield, we provide the
Arduino Code, if you don't know how to use
Arduino, please check here.
For 2 channel pi hat, there are two ways to
send & receive, you can use both can-
util/cangen and python code.
CAN BUS Shield send and CAN HAT receive
Arduino Code for CAN BUS Shield:
// demo: CAN-BUS Shield, send data
// loovee@seeed.cc
#include <mcp_can.h>
#include <SPI.h>
// the cs pin of the version after v1.
// v0.9b and v1.0 is default D10
const int SPI_CS_PIN = 9;
MCP_CAN CAN(SPI_CS_PIN);
void setup()
{
Serial.begin(115200);
while (CAN_OK != CAN.begin(CAN_500
{
Serial.println("CAN BUS Shield
Serial.println(" Init CAN BUS
delay(100);
}
Serial.println("CAN BUS Shield ini
}
unsigned char stmp[8] = {0, 0, 0, 0, 0
void loop()
{
//send data: id = 0x00, standrad
stmp[7] = stmp[7]+1;
if(stmp[7] == 100)
{
stmp[7] = 0;
stmp[6] = stmp[6] + 1;
if(stmp[6] == 100)
{
stmp[6] = 0;
stmp[5] = stmp[6] + 1;
}
}
CAN.sendMsgBuf(0x00, 0, 8, stmp);
delay(100);
}
// END FILE
Respberry pi setting and and you can use can-
util to receive
#set 500k baudrate
pi@raspberrypi:~ $ sudo ip link set ca
pi@raspberrypi:~ $ ip -details link sh
3: can0: <NOARP,UP,LOWER_UP,ECHO> mtu
link/can promiscuity 0
can state ERROR-ACTIVE (berr-count
bitrate 500000 sample-point 0.875
tq 25 prop-seg 34 phase-seg1 35 pha
mcp25xxfd: tseg1 2..256 tseg2 1..12
mcp25xxfd: dtseg1 1..32 dtseg2 1..1
clock 40000000numtxqueues 1 numrxqu
#receive
pi@raspberrypi:~ $ candump can0
can0 000 [8] 00 00 00 00 00 00 0
can0 000 [8] 00 00 00 00 00 00 0
can0 000 [8] 00 00 00 00 00 00 0
can0 000 [8] 00 00 00 00 00 00 0
can0 000 [8] 00 00 00 00 00 00 0
can0 000 [8] 00 00 00 00 00 00 0
can0 000 [8] 00 00 00 00 00 00 0
can0 000 [8] 00 00 00 00 00 00 0
can0 000 [8] 00 00 00 00 00 00 0
can0 000 [8] 00 00 00 00 00 00 0
can0 000 [8] 00 00 00 00 00 00 0
can0 000 [8] 00 00 00 00 00 00 0
can0 000 [8] 00 00 00 00 00 00 0
can0 000 [8] 00 00 00 00 00 00 0
can0 000 [8] 00 00 00 00 00 00 0
can0 000 [8] 00 00 00 00 00 00 0
can0 000 [8] 00 00 00 00 00 00 0
can0 000 [8] 00 00 00 00 00 00 0
can0 000 [8] 00 00 00 00 00 00 0
can0 000 [8] 00 00 00 00 00 00 0
can0 000 [8] 00 00 00 00 00 00 0
can0 000 [8] 00 00 00 00 00 00 0
can0 000 [8] 00 00 00 00 00 00 0
can0 000 [8] 00 00 00 00 00 00 0
can0 000 [8] 00 00 00 00 00 00 0
Or you can use python code to get the CAN
data. To use python to receive CAN data, you
should install python-can at first.
# install python-can
sudo pip3 install python-can
Open a new python file and copy the following
code, save as can_test.py:
import can
can_interface = 'can0'
bus = can.interface.Bus(can_interface,
while True:
message = bus.recv(1.0) # Timeout
if message is None:
print('Timeout occurred, n
print(message)
Run the Python code and the results are as
follows :
0 00 00 00 00 00 0e 63 Channel: can0
0 00 00 00 00 00 0f 00 Channel: can0
0 00 00 00 00 00 0f 01 Channel: can0
0 00 00 00 00 00 0f 02 Channel: can0
0 00 00 00 00 00 0f 03 Channel: can0
0 00 00 00 00 00 0f 04 Channel: can0
0 00 00 00 00 00 0f 05 Channel: can0
0 00 00 00 00 00 0f 06 Channel: can0
0 00 00 00 00 00 0f 07 Channel: can0
0 00 00 00 00 00 0f 08 Channel: can0
0 00 00 00 00 00 0f 09 Channel: can0
0 00 00 00 00 00 0f 0a Channel: can0
CAN BUS Shield receive and CAN HAT send #
For Raspberry Pi, you can use cangen to send
random package:
pi@raspberrypi:~ $ cangen can0 -v
can0 442#14.C4.1A.1A.C2.25.79.25
can0 748#4E.C7.8B.0B.6E.B9.15.77
can0 1E4#64.D4.62.22.2F.A6.BF
can0 1DD#69.6F.61.33.1F.59.E4.7C
can0 63D#
can0 764#2C.C1.E3
can0 68B#11.9C.63.6D.EA.E9.4B
can0 329#DA.06.2C.34.6C
can0 7DD#2E.F5.E0.2A.26.77.58.38
can0 1BE#94.30.6E.2F.A2.7B.E3.1D
can0 654#D1.21.A3.58.31.E8.51.5F
can0 706#51.41.36.5C.43.8D.AE.5D
can0 34A#89.F2.DE.33.AE.52.38.6C
can0 6AC#C1.35.83.41.37
can0 38C#22.AF
can0 208#22.8E.97.58.E5.69.F7.2C
For Arduino, you can use the following code to
recieve CAN data.
// demo: CAN-BUS Shield, receive data
// when in interrupt mode, the data co
// loovee, 2014-6-13
#include <SPI.h>
#include "mcp_can.h"
// the cs pin of the version after v1.
// v0.9b and v1.0 is default D10
const int SPI_CS_PIN = 9;
MCP_CAN CAN(SPI_CS_PIN);
unsigned char flagRecv = 0;
unsigned char len = 0;
unsigned char buf[8];
char str[20];
void setup()
{
Serial.begin(115200);
while (CAN_OK != CAN.begin(CAN_500
{
Serial.println("CAN BUS Shield
Serial.println(" Init CAN BUS
delay(100);
}
Serial.println("CAN BUS Shield ini
attachInterrupt(0, MCP2515_ISR, FA
}
void MCP2515_ISR()
{
flagRecv = 1;
}
void loop()
{
if(flagRecv)
{
flagRecv = 0;
// iterate over all pending me
// If either the bus is satura
// both RX buffers may be in u
// message does not clear the
while (CAN_MSGAVAIL == CAN.che
{
// read data, len: data l
CAN.readMsgBuf(&len, buf);
// print the data
for(int i = 0; i<len; i++)
{
Serial.print(buf[i]);S
}
Serial.println();
}
}
}
Open the Serial Monitor of Arduino IDE by
