EcoStruxureTM Power Automation System

EcoSUI – Technical Overview

EcoStruxureTM Power Automation System
Power Solutions Global Training
2021

Confidential Property of Schneider Electric

Internal
Agenda
• EcoSUI history
• EcoSUI Modules and components
• Architectures
• Licensing
• Documentation

Confidential Property of Schneider Electric | Page 2

Internal
 EcoStruxureTM Power Automation System EcoSUI– General Overview

’
EcoSUI is a Digital Control System Gathering Legacy
and Cutting-edge Protocols in One Place

Sized for Small and Large Projects

Focusing on Shortening Engineering Time

&
Satisfying Customer Requirements

Confidential Property of Schneider Electric | Page 3

3
Internal
 EcoStruxureTM Power Automation System EcoSUI– A long Story (1/2)

PSCN (2000 – 2006)

Design of a new and convenient event & trend viewer to replace

original PSCN viewer.
Deployment of it on all PSCN Projects, especially for AVE Project (High
Speed Train between Madrid and Barcelona, 30 Substations)

PACIS (2005 – 2010)

Re-Use of the Alternative PSCN HMI to manage Color Animation of
Railways SLDs on Large Screens of Control Rooms.

Design of a ‘light’ Report Software Generating PDF & CSV periodically

(Archive Poller / Manager)

Confidential Property of Schneider Electric | Page 4

4
Internal
 EcoStruxureTM Power Automation System EcoSUI– A long Story (2/2)

EcoSUI (2010 – 2018)

Re-Use of Source Codes to build a Complete Operator Interface with a

Native IEC61850 Acquisition

Addition of Legacy Protocols: PSCN

Addition of Common Protocols: SNMP, OPC, IEC61850 Ed2, Modbus
TCP

Integrated, deployed and supported by COE Team

Confidential Property of Schneider Electric | Page 5

5
Internal
 EcoStruxureTM Power Automation System EcoSUI– High Performances

EcoSUI has been tested under strong dataflow of 3000 MV/s + 500 xPS/s.
The limiting factor is the size of the hard-disk and the time required to
extract archives.

EcoSUI has been tested with 180 IED 61850 on one Network

Confidential Property of Schneider Electric | Page 6

6
Internal
 EcoStruxureTM Power Automation System EcoSUI– General Overview

EcoSUI is composed of several software ’

HMI (User Interface)

SBUS Server (Multiprotocol Acquisition)
CentralDB (Centralized Configuration, Alarm Management
& Event/MV Archiving)
Gateway (Use of Gateway V5 TBUS Dll to act as Scada Gateway)
Supervisor (Configuration deployment tool)
Reporter (Light Event/MV reporting tool)

Confidential Property of Schneider Electric | Page 7

7
Internal
 EcoStruxureTM Power Automation System EcoSUI– Technical
Characteristics

’
Operating System

• Windows 7 (32/64 bits)

• Windows 10
• Windows 2016 Server

Hardware Specifications

• A500 Computer compatible

• High-End Computer NOT
Mandatory

Confidential Property of Schneider Electric | Page 8

8
Internal
 EcoStruxureTM Power Automation System EcoSUI– Central Database

’
Software

• Based on MySQL Server 5.5

Centralized Database

• Configuration
• Event / MV Archiving
• Alarm List

Redundancy

• On one project, we can have 4 Central DBs

Confidential Property of Schneider Electric | Page 9

9
Internal
 EcoStruxureTM Power Automation System EcoSUI– Local Database One
per computer

Software

• Based on MySQL Server 5.5 as well

Local Database

• Copy of Configuration

Confidential Property of Schneider Electric | Page 10

10
Internal
 EcoStruxureTM Power Automation System EcoSUI– SBUS Server Overview

Features ’
• Data Acquisition (61850 Ed1 & Ed2, SNMP, EFIP, PerfMon, Virtual,
Modbus TCP, …)
• Event/MV Archiving
• Alarm Management
• Data Servicing (Connection to EcoSUI HMI, EcoSUI GTW)
• Printer Management
• Scripting (Python)
• Formula

Special Features (on computers where CentralDBs are located)

• Archive Synchronization
• Alarm Synchronization
• Archive Purging (after x days)
• Printer Management

Confidential Property of Schneider Electric | Page 11

11
Internal
 EcoStruxureTM Power Automation System EcoSUI– SBUS Server Data
Acquisition

« RINGS » ’
• A Ring is a group of equipment with a same protocol
• A SBUS Server can have several rings of different protocol
• A SBUS Server can have several rings of 61850 protocol
• One Ring can be run on 2 different computers (Redundancy)

List of Protocols

• IEC61850
• SNMP
• WINDOWS PERFORMANCE MONITOR COUNTER
• EFIP (PSCN)
• MODBUS TCP
• OPC DA

Confidential Property of Schneider Electric | Page 12

12
Internal
 EcoStruxureTM Power Automation System EcoSUI– SBUS Server Event
and Measured Value Archiving

’
Event/MV Archiving

• For each signal update, event/mv is archived in both Central DBs (if
necessary)
• Buffer of 200000 updates
• For each signal update, event/mv is sent to Printer Managers (if
necessary)

Confidential Property of Schneider Electric | Page 13

13
Internal
 EcoStruxureTM Power Automation System EcoSUI– SBUS Server Alarm
Management

Alarm Management ’

• For each signal update, alarm is Set/Cleared in both Central DBs (if
necessary)
• Buffer of 200000 updates

Confidential Property of Schneider Electric | Page 14

14
Internal
 EcoStruxureTM Power Automation System EcoSUI– SBUS Server Data
Server

Data Server
’

1. Clients (HMI / GTW) connects to all SBUS Servers and register signals
2. SBUS Servers send current values of all registered signals
3. SBUS Servers send updates of registered signals
4. If more than one SBUS Server sends valid values, clients get the value
from the SBUS Server with the highest priority

Confidential Property of Schneider Electric | Page 15

15
Internal
 EcoStruxureTM Power Automation System EcoSUI– SBUS Server Printer
Management

’
Printer Management

• Each SBUS Can be the manager of one Printer

• Each Ring can send logs to 2 printers

Confidential Property of Schneider Electric | Page 16

16
Internal
 EcoStruxureTM Power Automation System EcoSUI– SBUS Server Python
Scripts

Python Scripts

• Each SBUS Server can execute ‘Standalone’ scripts. Ie. Scripts that
will be executed at startup
• xPC signals can be added to virtual rings. A script can be run when a
command is sent from HMI/GTW on these signals

Confidential Property of Schneider Electric | Page 17

17
Internal
 EcoStruxureTM Power Automation System EcoSUI– SBUS Server Formulas

Formulas

• Each SBUS Server can evaluate formulas and feed xPS/MV signals
of Virtual Rings with the result
• Formulas can also send commands on events

Confidential Property of Schneider Electric | Page 18

18
Internal
 EcoStruxureTM Power Automation System EcoSUI– Interaction between
Modules 1/4

Configuration ’
• Each Software (SBUS Server, HMI MCIS, GTW) download at
Startup the latest configuration from CentralDB

Confidential Property of Schneider Electric | Page 19

19
Internal
 EcoStruxureTM Power Automation System EcoSUI– Interaction between
Modules 2/4

’
Alarms

• SBUS Servers Feed CentralDBs with Alarm

Updates.
• HMIs (MCIS) Get the list of Alarms from

• CentralDBs. HMI acknowledge and clear

alarms

Confidential Property of Schneider Electric | Page 20

20
Internal
 EcoStruxureTM Power Automation System EcoSUI– Interaction between
Modules 3/4

Events

• SBUS Servers Feed CentralDBs with

Events/MV Archiving
• HMIs (MCIS) Get Events/MV from CentralDBs.

Confidential Property of Schneider Electric | Page 21

21
Internal
 EcoStruxureTM Power Automation System EcoSUI– Interaction between
Modules 4/4

Live Values ’

• HMI (MCIS) & GTW directly connect to all

SBUS Servers to retrieve live values

Confidential Property of Schneider Electric | Page 22

22
Internal
 EcoStruxureTM Power Automation System EcoSUI– HMI Overview

Features

• Multi-Screen Support
• Multi-Language Support
• Online Configuration
• Replay Feature
• Global Zoom Factor to Fit HMI to different monitor configuration

Confidential Property of Schneider Electric | Page 23

23
Internal
 EcoStruxureTM Power Automation System EcoSUI– EcoGateway Overview

Features

• T101, T104 and OPC Server (non redundant), Modbus TCP, DNP3
serial and IP (Based on Gateway V5)

Confidential Property of Schneider Electric | Page 24

24
Internal
 EcoStruxureTM Power Automation System EcoSUI– EcoGTW Configuration Process

EPAS Gateway
Launch Application
GatewayInterface :

1/ Generate EPAS GTW Files

2/ Start EPAS GTW
• Signal list files

• Protocol
configuration files

Confidential Property of Schneider Electric | Page 25

25
Internal
 EcoStruxureTM Power Automation System EcoSUI– Tools

Troubleshooting

• DbgView (installed automatically)

• C:\MCIS\Debug : archives debug log files of SBUSServers ,
SbusAxs, MCIS HMI, Formulas, …
• MySQL Administrator & MySQL Browser

Confidential Property of Schneider Electric | Page 26

26
Internal
 EcoStruxureTM Power Automation System EcoSUI– Software Installation

’
EcoSUI Installation

• WinPCAP (for IEC61850 Acquisition)

• DotNet 4.0 Full
• IronPython (for Scripting)
• EcoSUI Installation Package

Confidential Property of Schneider Electric | Page 27

27
Internal
 EcoStruxureTM Power Automation System EcoSUI– Database Configuration

’
PACIS

• Import From SCE Generation (ZIP File)

• SignalList Text File (When using SET)

PSCN

• Import BDCF.Zip File

All other Protocols (i.e. SNMP, OPC, Modbus TCP IP )

• SignalList Text File

• CSV Text File

Confidential Property of Schneider Electric | Page 28

28
Internal
 EcoStruxureTM Power Automation System EcoSUI– HMI Mimics (views)
Configuration

’
From VISIO (any Acquisition Protocol)

• Automatic Generation of Views from Visio

PACIS

• Import from SCE Generation (.Zip File)

PSCN

• Import from GOI.Zip file

Confidential Property of Schneider Electric | Page 29

29
Internal
EcoStruxureTM Power Automation System EcoSUI– Global Configuration Process

EcoSUI Suite
Graphical Editor
Formula Editor in MCIS application
in sbusServer
EcoSUI 1
Confpackage
SBusServer HMI (mimics) Supervisor (.zip=)

Database - mySQL
EcoSUI 2
Various acquisition types
.scd Signal list text file
.zip Signal list text file
EcoSUI 3
GEA SNMP,
SCE PERFMON
EPASE FORMULA
Python Scripts Configuration
Electrical configuration
System configuration Graphics deployment
configuration
Acquisition configuration
Confidential Property of Schneider Electric | Page 30
30
Internal
 EcoStruxureTM Power Automation System EcoSUI– Large HSR Architecture
Example

Confidential Property of Schneider Electric | Page 31

31
Internal
 EcoStruxureTM Power Automation System EcoSUI– Large PRP Architecture
Example

Confidential Property of Schneider Electric | Page 32

32
Internal
 EcoStruxureTM Power Automation System EcoSUI– upgrade from non EPAS
system Architecture Example

Confidential Property of Schneider Electric | Page 33

33
Internal
 EcoStruxureTM Power Automation System EcoSUI– Architecture

’
Typical architectures

Confidential Property of Schneider Electric | Page 34

34
Internal
 EcoStruxureTM Power Automation System EcoSUI– Minimal IEC61850
architecture

’
Sbus Server for ring A
Graghical HMI for ring A
Central DB for ring
RCP

PACIS GTW

Ring A : IEC 61850

BCU IED

Confidential Property of Schneider Electric | Page 35

35
Internal
 EcoStruxureTM Power Automation System EcoSUI–Redundant IEC61850
architecture

Sbus Server MAIN for Ring A

Graghical HMI for Ring A
Sbus Server BACKUP for Ring A
Graghical HMI for Ring A
’
Central DB MAIN for Ring A Central DB BACKUP for Ring A

RCP

PACIS GTW

Ring A : IEC 61850

BCU IED

Confidential Property of Schneider Electric | Page 36

36
Internal
 EcoStruxureTM Power Automation System EcoSUI– Multi-Ring IEC61850 architecture
No Redundancy

CONTROL ROOM
Sbus Server for ring A
Graphical HMI for ring A/1/2 ’
RCP Central DB for ring A/1/2
Additional Graphical HMI for ring A/1/2

PACIS GTW For

whole system

Ring A : IEC 61850

BCU IED

Sbus Server for ring 1 RCP Sbus Server for ring 2

PACIS GTW for ring 1

Ring 1 : IEC 61850 Ring 2 : IEC 61850

SUB-STATION 1 SUB-STATION 2
BCU IED BCU IED

Confidential Property of Schneider Electric | Page 37

37
Internal
 EcoStruxureTM Power Automation System EcoSUI– Multi-Ring IEC61850 architecture Redundancy

Sbus Server MAIN for ring A Sbus Server BACKUP for ring A

Central DB Central DB
Graphical HMI for ring A/1/2 Graphical HMI for ring A/1/2
’
MAIN for ring BACKUP for ring
A/1/2 A/1/2 CONTROL ROOM

Ring A

PACIS GTW for

whole system

RCP
BCU IED

Sbus Server MAIN Sbus Server Sbus Server MAIN Sbus Server
for ring 1 BACKUP for ring 2 BACKUP
Graphical HMI for ring 1 Graphical HMI for ring 2
for ring 1 Graphical HMI for ring 2 Graphical HMI
for ring 1 for rin 2

Ring 1 : IEC 61850 Ring 2 : IEC 61850

SUB-STATION 1 SUB-STATION 2
BCU IED BCU IED

Confidential Property of Schneider Electric | Page 38

38
Internal
 EcoStruxureTM Power Automation System EcoSUI– Multi-Ring IEC61850
architecture on same Sbus Server
This architecture allows having several acquisition modules on the LAN in order to increase the number of IED61850 IEDs.

Additional
Graghical HMI
’
for ring A/B/C

1 Sbus Servers MAIN with 3 rings A/B/C 1 Sbus Servers BACKUP with 3 rings A/B/C
Graphical HMI for ring A/B/C Graphical HMI for ring A/B/C
Central DB MAIN for ring A/B/C Central DB BACKUP for ring A/B/C

Ring A : IEC 61850

Ring B : IEC 61850

Ring C : IEC 61850

PACIS GTW IEC 61850 BCU IEC 61850 IED

for ring A

IEC 61850 BCU IEC 61850 IED

IEC 61850 BCU IEC 61850 IED

RCP
PACIS GTW for ring C RCP

Confidential Property of Schneider Electric | Page 39

39
Internal
EcoStruxureTM Power Automation System EcoSUI– Components launch at startup

Depending on which EcoSUI module should run on your computer you have to configure the following
at Windows startup:

Central DB and/or SBUS HMI Workstation only HMI Workstation +

Server Central DB and/or SBUS
Server
EcoSUI SBUS Server required
to run in order to animate EcoSUI SBUS Server required
Central DB datapoint when to run in order to animate
Central DB is stand-alone Central DB datapoint when
Central DB is stand-alone

Consider launching only

Supervisor if need manual
Launch Gateway Interface if EcoGTW action to start software or on
required working laptop

Confidential Property of Schneider Electric | Page 40

40
Internal
 EcoStruxureTM Power Automation System EcoSUI– Licensing

PACiS EcoSUI + WebHMI ’

* Free and time limited for SE DPACs internal used

Substation.Automation.license@schneider-electric.com

Confidential Property of Schneider Electric | Page 41

41
Internal
 EcoStruxureTM Power Automation System EcoSUI– Licensing

Confidential Property of Schneider Electric | Page 42

42
Internal
 EcoStruxureTM Power Automation System EcoSUI– Licensing

Confidential Property of Schneider Electric | Page 43

43
Internal
 EcoStruxureTM Power Automation System EcoSUI– Documentation

Box : Global Technical Support Delivery

’

USER_GUIDES
EcoSUI
EcoGTW
WebHMI

Confidential Property of Schneider Electric | Page 44

44
Internal
 EcoStruxureTM Power Automation System EcoSUI– Documentation

Box :
’

Confidential Property of Schneider Electric | Page 45

45
Internal
 EcoStruxureTM Power Automation System EcoSUI– Documentation

Box :
#TechSupport Delivery /11-DOCUMENTATION / 06-ECOSUI

04 - HOWTO

Confidential Property of Schneider Electric | Page 46

46
Internal
Internal
Internal
