Peter KlassenFLO-LOCK
Flo-Lock Grooving/Threading Insert Identification Chart
FL G P 3 M 125 R C CB GP3 A
type of insert additional info
chipbreaker style
FL Flo-Lock D Deep Grooving
hand of insert Threading:
F Fine Pitch
FCB Ultra Fine grade
K Fine Pos Rake L Left CB Fine
P Positive Rake R Right HCB General Purpose
T Double Ended edge prep
Grooving:
insert size CB General Purpose
insert style insert groove width
Size Inch Metric
A Acme 2 .150 3,81 Inch/Metric sizes
3 .195 4,95 Example:
B Blank
4 .255 6,48 Inch: .125 = 125
D API Thread
5 .380 9,65 Metric: 1,50 = 150
FLO-LOCK
F Face grooving
G Grooving 6 .383 9,73
coarse
J UNJ Thread
R Full Radius Used to indicate coarse
metric size pitch threaders only
T 60˚ Thread
U Undercut Used to indicate
V Poly Vee metric groovers
Flo-Lock Cross Reference Chart
STYLE TOOL-FLO KENNAMETAL® SANDVIK®* VALENITE®* HORIZON®* RTW®*
ACME FLA NA TLA VLA HA PA
ACME STUBF FLAS NAS TLAS VAS HAS PAS
API-NON TOPPING FLD ND TLD # # #
API-TOPPING FLDC NDC TLDC # HDC PDC
DEEP GROOVING FLGD NGD # # HGD #
FACE GROOVING FLF NF TLF # HF #
GROOVING FLG NG TLG VLG HG PG
GROOVING-POSITIVE FLGP NGP TLGP VLGD HGD PGD
UNJ FLJ NJ TLJ # HJ #
UNJ-FINE PITCH FLJF NJF TLJF # HJF #
UNJ-FINE PITCH-POSITIVE FLJK NJK TLJK # # #
UNJ-POSITIVE FLJP NJP TLJP # # #
PROFILING - LH FLPL NPL # # # #
PROFILING - RH FLPR NPR # # # #
GROOVING - FLR FLR NR TLR VLR HR PR
GROOVING - FLR POS. FLRP NRP TLRP VLRD HRP PRP
60˚ V FLT NT TLT VLT HT PT
AMERICAN STANDARD BUTTRESS FLTB NTB TLTB # HTB #
UN - UNIFIED FLTC NTC TLTC VLTC HTC PTC
60˚ V - FINE PITCH FLTF NTF TLTF VLTF HTF PTF
60˚ V - FINE PITCH POSITIVE FLTK NTK TLTK VLTK HTK PTK
60˚ V - POSITIVE FLTP NTP TLTP VLTP HTP PTP
POLY-V GROOVING FLV NV TLV # HV #
*Top Clamp change is required when converting from SANDVIK®
90
FLO-LOCK
GROOVING-CHIP-FLO
FLG-CB d design! E
w/patented chipbreaker Exclusive patente 3˚
T
W
Features:
AlTiN Coated
• Patented chipbreaker - Patent No. 6,146,064
RTyp. GAGE
RH Shown
TiN Coated
B DIA.
Uncoated
• Maximum chip control A
• Industry standard widths
w
E Gage
GP50
AC22
AC50
GP3
AC3
C25
Description EDP Code Inch Metric R Inch Metric T A B Dia.
C3
FLG-2047R-CB 562647PR .047 1,20 .002/.005 .050 1,27 .150 .219 .2700 .1875 ● ● ● ● ●
FLG-2047L-CB 562647PL .047 1,20 .002/.005 .050 1,27 .150 .219 .2700 .1875 ● ● ● ● ●
FLG-2062R-CB 562662PR .062 1,57 .005/.010 .110 2,79 .150 .219 .2700 .1875 ● ● ● ● ● ●
FLG-2062L-CB 562662PL .062 1,57 .005/.010 .110 2,79 .150 .219 .2700 .1875 ● ● ● ● ● ●
FLG-2078R-CB 562678PR .078 1,98 .005/.010 .110 2,79 .150 .219 .2700 .1875 ● ● ● ●
FLG-2078L-CB 562678PL .078 1,98 .005/.010 .110 2,79 .150 .219 .2700 .1875 ● ● ● ●
FLG-2094R-CB 562694PR .094 2,39 .005/.010 .110 2,79 .150 .219 .2700 .1875 ● ● ● ● ●
FLG-2094L-CB 562694PL .094 2,39 .005/.010 .110 2,79 .150 .219 .2700 .1875 ● ● ● ● ●
FLG-2125R-CB 562825PR .125 3,18 .005/.010 .110 2,79 .150 .219 .2700 .1875 ● ● ● ● ●
FLG-2125L-CB 562825PL .125 3,18 .005/.010 .110 2,79 .150 .219 .2700 .1875 ● ● ● ● ●
FLG-3031R-CB 563631PR .031 0,79 .002/.005 .050 1,27 .195 .344 .4050 .3750 ● ● ● ● ●
FLG-3031L-CB 563631PL .031 0,79 .002/.005 .050 1,27 .195 .344 .4050 .3750 ● ● ● ● ●
FLO-LOCK
FLG-3047R-CB 563647PR .047 1,19 .005/.010 .075 1,90 .195 .344 .4050 .3750 ● ● ● ● ●
FLG-3047L-CB 563647PL .047 1,19 .005/.010 .075 1,90 .195 .344 .4050 .3750 ● ● ● ● ●
FLG-3062R-CB 563662PR .062 1,57 .005/.010 .120 3,05 .195 .344 .4050 .3750 ● ● ● ● ●
FLG-3062L-CB 563662PL .062 1,57 .005/.010 .120 3,05 .195 .344 .4050 .3750 ● ● ● ● ●
FLG-3072R-CB 563672PR .072 1,83 .005/.010 .120 3,05 .195 .344 .4050 .3750 ● ● ● ●
FLG-3072L-CB 563672PL .072 1,83 .005/.010 .120 3,05 .195 .344 .4050 .3750 ● ● ● ●
FLG-3078R-CB 563678PR .078 1,98 .005/.010 .120 3,05 .195 .344 .4050 .3750 ● ● ● ●
FLG-3078L-CB 563678PL .078 1,98 .005/.010 .120 3,05 .195 .344 .4050 .3750 ● ● ● ●
FLG-3088R-CB 563688PR .088 2,24 .005/.010 .180 4,57 .195 .344 .4050 .3750 ● ● ● ●
FLG-3088L-CB 563688PL .088 2,24 .005/.010 .180 4,57 .195 .344 .4050 .3750 ● ● ● ●
FLG-3094R-CB 563694PR .094 2,39 .005/.010 .180 4,57 .195 .344 .4050 .3750 ● ● ● ● ● ●
FLG-3094L-CB 563694PL .094 2,39 .005/.010 .180 4,57 .195 .344 .4050 .3750 ● ● ● ● ● ●
FLG-3097R-CB 563697PR .097 2,46 .005/.010 .180 4,57 .195 .344 .4050 .3750 ● ● ● ● ●
FLG-3097L-CB 563697PL .097 2,46 .005/.010 .180 4,57 .195 .344 .4050 .3750 ● ● ● ● ●
FLG-3125R-CB 563825PR .125 3,18 .005/.010 .180 4,57 .195 .344 .4050 .3750 ● ● ● ● ●
FLG-3125L-CB 563825PL .125 3,18 .005/.010 .180 4,57 .195 .344 .4050 .3750 ● ● ● ● ●
FLG-3189R-CB 563889PR .189 4,80 .020/.025 .180 4,57 .195 .344 .4050 .3750 ●● ● ● ● ●
FLG-3189L-CB 563889PL .189 4,80 .020/.025 .180 4,57 .195 .344 .4050 .3750 ●● ● ● ● ●
FLG-4125R-CB 564825PR .125 3,18 .005/.010 .250 6,35 .255 .453 .6360 .3750 ● ● ● ●
FLG-4125L-CB 564825PL .125 3,18 .005/.010 .250 6,35 .255 .453 .6360 .3750 ● ● ● ●
FLG-4189R-CB 564889PR .189 4,80 .020/.025 .250 6,35 .255 .453 .6360 .3750 ● ● ● ● ●
FLG-4189L-CB 564889PL .189 4,80 .020/.025 .250 6,35 .255 .453 .6360 .3750 ● ● ● ● ●
FLG-4250R-CB 574050PR .250 6,35 .020/.025 .250 6,35 .255 .453 .6360 .3750 ● ● ● ● ●
FLG-4250L-CB 574050PL .250 6,35 .020/.025 .250 6,35 .255 .453 .6360 .3750 ● ● ● ● ●
In an effort to improve our stock standard grade offering, Cast Iron ▲ ●
there are periodic changes. ● High performance choice in optimal conditions. Non-Ferrous ▲ ●
Please see current price list for up to date grade offering. ▲ Recommended grade under general conditions. Stainless/High Temp ▲ ●
Steel ▲ ●
91
FLO-LOCK
GROOVING-CHIP-FLO
FLG-CB - METRIC E
nted d esign! 3˚
w/patented chipbreaker sive pate
Exclu W
T
RTyp.
RH Shown
GAGE
B DIA.
AlTiN Coated
Features:
TiN Coated
A
• Patented chipbreaker - Patent No. 6,146,064
• Maximum chip control
• Industry standard widths
W E Gage
GP50
AC22
AC50
GP3
AC3
Description EDP Code Metric Inch R Metric Inch T A B Dia.
FLG-2M100R-CB 562M100PR 1,00 .039 .002/.005 1,90 .050 .150 .219 .2700 .1875 ● ● ● ●
FLG-2M100L-CB 562M100PL 1,00 .039 .002/.005 1,90 .050 .150 .219 .270 .1875 ● ● ● ●
FLG-2M150R-CB 562M150PR 1,50 .059 .005/.010 2,79 .110 .150 .219 .2700 .1875 ● ● ● ●
FLG-2M150L-CB 562M150PL 1,50 .059 .005/.010 2,79 .110 .150 .219 .2700 .1875 ● ● ● ●
FLG-2M170R-CB 562M170PR 1,70 .067 .005/.010 2,79 .110 .150 .219 .2700 .1875 ● ● ● ● ●
FLG-2M170L-CB 562M170PL 1,70 .067 .005/.010 2,79 .110 .150 .219 .2700 .1875 ● ● ● ● ●
FLG-2M195R-CB 562M195PR 1,95 .077 .005/.010 2,79 .110 .150 .219 .2700 .1875 ● ● ● ●
FLG-2M195L-CB 562M195PL 1,95 .077 .005/.010 2,79 .110 .150 .219 .2700 .1875 ● ● ● ●
FLG-2M200R-CB 562M200PR 2,00 .079 .005/.010 2,79 .110 .150 .219 .2700 .1875 ● ● ● ●
FLG-2M200L-CB 562M200PL 2,00 .079 .005/.010 2,79 .110 .150 .219 .2700 .1875 ● ● ● ●
FLG-2M220R-CB 562M220PR 2,20 .087 .005/.010 2,79 .110 .150 .219 .2700 .1875 ● ● ● ●
FLG-2M220L-CB 562M220PL 2,20 .087 .005/.010 2,79 .110 .150 .219 .2700 .1875
FLO-LOCK
● ● ● ●
FLG-2M225R-CB 562M225PR 2,25 .089 .005/.010 2,79 .110 .150 .219 .2700 .1875 ● ● ● ●
FLG-2M225L-CB 562M225PL 2,25 .089 .005/.010 2,79 .110 .150 .219 .2700 .1875 ● ● ● ●
FLG-2M250R-CB 562M250PR 2,50 .098 .005/.010 2,79 .110 .150 .219 .2700 .1875 ● ● ● ● ●
FLG-2M250L-CB 562M250PL 2,50 .098 .005/.010 2,79 .110 .150 .219 .2700 .1875 ● ● ● ● ●
FLG-2M300R-CB 562M300PR 3,00 .118 .005/.010 2,79 .110 .150 .219 .2700 .1875 ● ● ● ●
FLG-2M300L-CB 562M300PL 3,00 .118 .005/.010 2,79 .110 .150 .219 .2700 .1875 ● ● ● ●
FLG-2M325R-CB 562M325PR 3,25 .128 .005/.010 2,79 .110 .150 .219 .2700 .1875 ● ● ● ●
FLG-2M325L-CB 562M325PL 3,25 .128 .005/.010 2,79 .110 .150 .219 .2700 .1875 ● ● ● ●
FLG-3M100R-CB 563M100PR 1,00 .039 .005/.010 1,90 .050 .195 .344 .4050 .3750 ● ● ● ●
FLG-3M100L-CB 563M100PL 1,00 .039 .005/.010 1,90 .050 .195 .344 .4050 .3750 ● ● ● ●
FLG-3M120R-CB 563M120PR 1,20 .047 .005/.010 1,90 .075 .195 .344 .4050 .3750 ● ● ● ●
FLG-3M120L-CB 563M120PL 1,20 .047 .005/.010 1,90 .075 .195 .344 .4050 .3750 ● ● ● ●
FLG-3M150R-CB 563M150PR 1,50 .059 .005/.010 3,05 .120 .195 .344 .4050 .3750 ● ● ● ●
FLG-3M150L-CB 563M150PL 1,50 .059 .005/.010 3,05 .120 .195 .344 .4050 .3750 ● ● ● ●
FLG-3M170R-CB 563M170PR 1,70 .067 .005/.010 3,05 .120 .195 .344 .4050 .3750 ● ● ● ● ●
FLG-3M170L-CB 563M170PL 1,70 .067 .005/.010 3,05 .120 .195 .344 .4050 .3750 ● ● ● ● ●
FLG-3M175R-CB 563M175PR 1,75 .069 .005/.010 3,05 .120 .195 .344 .4050 .3750 ● ● ● ●
FLG-3M175L-CB 563M175PL 1,75 .069 .005/.010 3,05 .120 .195 .344 .4050 .3750 ● ● ● ●
FLG-3M200R-CB 563M200PR 2,00 .079 .005/.010 3,05 .120 .195 .344 .4050 .3750 ● ● ● ●
FLG-3M200L-CB 563M200PL 2,00 .079 .005/.010 3,05 .120 .195 .344 .4050 .3750 ● ● ● ●
FLG-3M220R-CB 563M220PR 2,20 .087 .005/.010 4,57 .180 .195 .344 .4050 .3750 ● ● ● ●
FLG-3M220L-CB 563M220PL 2,20 .087 .005/.010 4,57 .180 .195 .344 .4050 .3750 ● ● ● ●
FLG-3M225R-CB 563M225PR 2,25 .089 .005/.010 4,57 .180 .195 .344 .4050 .3750 ● ● ● ●
FLG-3M225L-CB 563M225PL 2,25 .089 .005/.010 4,57 .180 .195 .344 .4050 .3750 ● ● ● ●
FLG-3M250R-CB 563M250PR 2,50 .098 .005/.010 4,57 .180 .195 .344 .4050 .3750 ● ● ● ● ●
FLG-3M250L-CB 563M250PL 2,50 .098 .005/.010 4,57 .180 .195 .344 .4050 .3750 ● ● ● ● ●
FLG-3M300R-CB 563M300PR 3,00 .118 .005/.010 4,57 .180 .195 .344 .4050 .3750 ● ● ● ●
FLG-3M300L-CB 563M300PL 3,00 .118 .005/.010 4,57 .180 .195 .344 .4050 .3750 ● ● ● ●
FLG-3M320R-CB 563M320PR 3,20 .126 .005/.010 4,57 .180 .195 .344 .4050 .3750 ● ● ● ●
FLG-3M320L-CB 563M320PL 3,20 .126 .005/.010 4,57 .180 .195 .344 .4050 .3750 ● ● ● ●
FLG-3M325R-CB 563M325PR 3,25 .128 .005/.010 4,57 .180 .195 .344 .4050 .3750 ● ● ● ●
FLG-3M325L-CB 563M325PL 3,25 .128 .005/.010 4,57 .180 .195 .344 .4050 .3750 ● ● ● ●
FLG-3M400R-CB 563M400PR 4,00 .157 .010/.015 6,35 .180 .195 .344 .4050 .3750 ● ● ● ●
FLG-3M400L-CB 563M400PL 4,00 .157 .010/.015 6,35 .180 .195 .344 .4050 .3750 ● ● ● ●
FLG-4M320R-CB 564M320PR 3,20 .126 .005/.010 6,35 .250 .255 .453 .6360 .3750 ● ● ● ●
FLG-4M320L-CB 564M320PL 3,20 .126 .005/.010 6,35 .250 .255 .453 .6360 .3750 ● ● ● ●
In an effort to improve our stock standard grade offering, Cast Iron ▲ ●
there are periodic changes.
● High performance choice in optimal conditions. Non-Ferrous ▲ ●
Please see current price list for up to date grade offering. ▲ Recommended grade under general conditions. Stainless/High Temp ▲ ●
Steel ▲ ●
92
FLO-LOCK
GROOVING
FLG
E
FLG 3˚
W T
AlTiN Coated
RTyp.
GAGE
TiN Coated
B DIA.
Uncoated
A
RH Shown
W E
GP50
AC22
AC50
Gage
GP3
AC3
C25
Description EDP Code Inch Metric R Inch Metric T A B Dia.
C3
FLG-2031R 562631R .031 0,79 .002/.005 .050 1,27 .150 .219 .2700 .1875 ● ● ● ● ●
FLG-2031L 562631L .031 0,79 .002/.005 .050 1,27 .150 .219 .2700 .1875 ● ● ● ● ●
FLG-2041R 562641R .041 1,04 .002/.005 .050 1,27 .150 .219 .2700 .1875 ● ● ● ● ●
FLG-2041L 562641L .041 1,04 .002/.005 .050 1,27 .150 .219 .2700 .1875 ● ● ● ● ●
FLG-2047R 562647R .047 1,19 .002/.005 .050 1,27 .150 .219 .2700 .1875 ● ● ● ● ●
FLG-2047L 562647L .047 1,19 .002/.005 .050 1,27 .150 .219 .2700 .1875 ● ● ● ● ●
FLG-2058R 562658R .058 1,47 .005/.010 .050 1,27 .150 .219 .2700 .1875 ● ● ● ●
FLG-2058L 562658L .058 1,47 .005/.010 .050 1,27 .150 .219 .2700 .1875 ● ● ● ●
FLG-2062R 562662R .062 1,57 .005/.010 .110 2,79 .150 .219 .2700 .1875 ● ● ● ● ●
FLG-2062L 562662L .062 1,57 .005/.010 .110 2,79 .150 .219 .2700 .1875 ● ● ● ● ●
FLG-2094R 562694R .094 2,39 .005/.010 .110 2,79 .150 .219 .2700 .1875 ● ● ● ● ●
FLG-2094L 562694L .094 2,39 .005/.010 .110 2,79 .150 .219 .2700 .1875 ● ● ● ● ●
FLG-2125R 562825R .125 3,18 .005/.010 .110 2,79 .150 .219 .2700 .1875 ● ● ● ● ●
FLG-2125L 562825L .125 3,18 .005/.010 .110 2,79 .150 .219 .2700 .1875 ● ● ● ● ●
FLO-LOCK
FLG-3031R 563631R .031 0,79 .002/.005 .050 1,27 .195 .344 .4050 .3750 ● ● ● ● ●
FLG-3031L 563631L .031 0,79 .002/.005 .050 1,27 .195 .344 .4050 .3750 ● ● ● ● ●
FLG-3047R 563647R .047 1,19 .005/.010 .075 1,90 .195 .344 .4050 .3750 ● ● ● ● ●
FLG-3047L 563647L .047 1,19 .005/.010 .075 1,90 .195 .344 .4050 .3750 ● ● ● ● ●
FLG-3062R 563662R .062 1,57 .005/.010 .120 3,05 .195 .344 .4050 .3750 ● ● ● ● ●
FLG-3062L 563662L .062 1,57 .005/.010 .120 3,05 .195 .344 .4050 .3750 ● ● ● ● ●
FLG-3072R 563672R .072 1,83 .005/.010 .120 3,05 .195 .344 .4050 .3750 ● ● ● ●
FLG-3072L 563672L .072 1,83 .005/.010 .120 3,05 .195 .344 .4050 .3750 ● ● ● ●
FLG-3078R 563678R .078 1,98 .005/.010 .120 3,05 .195 .344 .4050 .3750 ● ● ● ●
FLG-3078L 563678L .078 1,98 .005/.010 .120 3,05 .195 .344 .4050 .3750 ● ● ● ●
FLG-3088R 563688R .088 2,24 .005/.010 .180 4,57 .195 .344 .4050 .3750 ● ● ● ●
FLG-3088L 563688L .088 2,24 .005/.010 .180 4,57 .195 .344 .4050 .3750 ● ● ● ●
FLG-3094R 563694R .094 2,39 .005/.010 .180 4,57 .195 .344 .4050 .3750 ● ● ● ● ●
FLG-3094L 563694L .094 2,39 .005/.010 .180 4,57 .195 .344 .4050 .3750 ● ● ● ● ●
FLG-3097R 563697R .097 2,46 .010/.015 .180 4,57 .195 .344 .4050 .3750 ● ● ● ● ●
FLG-3097L 563697L .097 2,46 .010/.015 .180 4,57 .195 .344 .4050 .3750 ● ● ● ● ●
FLG-3105R 563805R .105 2,67 .005/.010 .180 4,57 .195 .344 .4050 .3750 ● ● ● ●
FLG-3105L 563805L .105 2,67 .005/.010 .180 4,57 .195 .344 .4050 .3750 ● ● ● ●
FLG-3110R 563810R .110 2,79 .005/.010 .180 4,57 .195 .344 .4050 .3750 ● ● ● ●
FLG-3110L 563810L .110 2,79 .005/.010 .180 4,57 .195 .344 .4050 .3750 ● ● ● ●
FLG-3122R 563822R .122 3,10 .005/.010 .180 4,57 .195 .344 .4050 .3750 ● ● ● ● ●
FLG-3122L 563822L .122 3,10 .005/.010 .180 4,57 .195 .344 .4050 .3750 ● ● ● ● ●
FLG-3125R 563825R .125 3,18 .005/.010 .180 4,57 .195 .344 .4050 .3750 ● ● ● ● ●
FLG-3125L 563825L .125 3,18 .005/.010 .180 4,57 .195 .344 .4050 .3750 ● ● ● ● ●
FLG-3142R 563842R .142 3,61 .005/.010 .180 4,57 .195 .344 .4050 .3750 ● ● ● ●
FLG-3142L 563842L .142 3,61 .005/.010 .180 4,57 .195 .344 .4050 .3750 ● ● ● ●
FLG-3156R 563856R .156 3,96 .005/.010 .180 4,57 .195 .344 .4050 .3750 ● ● ● ●
FLG-3156L 563856L .156 3,96 .005/.010 .180 4,57 .195 .344 .4050 .3750 ● ● ● ●
FLG-3178R 563878R .178 4,52 .005/.010 .180 4,57 .195 .344 .4050 .3750 ● ● ● ●
FLG-3178L 563878L .178 4,52 .005/.010 .180 4,57 .195 .344 .4050 .3750 ● ● ● ●
FLG-3185R 563885R .185 4,70 .020/.025 .180 4,57 .195 .344 .4050 .3750 ● ● ● ●
FLG-3185L 563885L .185 4,70 .020/.025 .180 4,57 .195 .344 .4050 .3750 ● ● ● ●
FLG-3189R 563889R .189 4,80 .020/.025 .180 4,57 .195 .344 .4050 .3750 ● ● ● ● ● ●
FLG-3189L 563889L .189 4,80 .020/.025 .180 4,57 .195 .344 .4050 .3750 ● ● ● ● ● ●
FLG-3250R 573050R .250 6,35 .020/.025 .180 4,57 .250 .344 .4050 .3750 ●
FLG-3250L 573050L .250 6,35 .020/.025 .180 4,57 .250 .344 .4050 .3750 ●
In an effort to improve our stock standard grade offering, Cast Iron ▲ ●
there are periodic changes.
● High performance choice in optimal conditions. Non-Ferrous ▲ ●
Please see current price list for up to date grade offering. ▲ Recommended grade under general conditions. Stainless/High Temp ▲ ●
Steel ▲ ●
93
FLO-LOCK
E
3˚
GROOVING W T
AlTiN Coated
FLG
TiN Coated
RTyp.
GAGE
Uncoated
B DIA.
RH Shown
W
E Gage
GP50
AC50
GP3
GP5
AC3
EDP Code Inch Metric R Inch Metric T A B Dia.
C3
Description
FLG-4125R 564825R .125 3,18 .005/.010 .290 7,37 .255 .453 .6360 .3750 ● ● ● ●
FLG-4125L 564825L .125 3,18 .005/.010 .290 7,37 .255 .453 .6360 .3750 ● ● ● ●
FLG-4189R 564889R .189 4,80 .020/.025 .250 6,35 .255 .453 .6360 .3750 ● ● ● ●
FLG-4189L 564889L .189 4,80 .020/.025 .250 6,35 .255 .453 .6360 .3750 ● ● ● ●
FLG-4213R 574013R .213 5,41 .005/.010 .250 6,35 .255 .453 .6360 .3750 ● ●
FLG-4213L 574013L .213 5,41 .005/.010 .250 6,35 .255 .453 .6360 .3750 ● ●
FLG-4219R 574019R .219 5,56 .020/.025 .250 6,35 .255 .453 .6360 .3750 ● ●
FLG-4219L 574019L .219 5,56 .020/.025 .250 6,35 .255 .453 .6360 .3750 ● ●
FLG-4250R 574050R .250 6,35 .020/.025 .250 6,35 .255 .453 .6360 .3750 ● ● ● ● ●
FLG-4250L 574050L .250 6,35 .020/.025 .250 6,35 .255 .453 .6360 .3750 ● ● ● ● ●
FLG-4312R 574212R .312 7,92 .030/.035 .250 6,35 .312 .453 .6360 .3750 ●
FLG-4312L 574212L .312 7,92 .030/.035 .250 6,35 .312 .453 .6360 .3750 ●
FLG-5250R 575050R .250 6,35 .020/.025 .375 9,53 .380 .688 .9520 .5000 ●
FLG-5250L 575050L .250 6,35 .020/.025 .375 9,53 .380 .688 .9520 .5000 ●
FLG-5281R 575081R .281 7,14 .030/.035 .375 9,53 .380 .688 .9520 .5000 ●
FLG-5281L 575081L .281 7,14 .030/.035 .375 9,53 .380 .688 .9520 .5000 ●
FLG-5312R 575212R .312 7,92 .030/.035 .375 9,53 .380 .688 .9520 .5000 ●
FLO-LOCK
FLG-5312L 575212L .312 7,92 .030/.035 .375 9,53 .380 .688 .9520 .5000 ●
FLG-5344R 575244R .344 8,74 .030/.035 .375 9,53 .380 .688 .9520 .5000 ●
FLG-5344L 575244L .344 8,74 .030/.035 .375 9,53 .380 .688 .9520 .5000 ●
FLG-5375R 575275R .375 9,53 .030/.035 .375 9,53 .380 .688 .9520 .5000 ●
FLG-5375L 575275L .375 9,53 .030/.035 .375 9,53 .380 .688 .9520 .5000 ●
FLG-6281R 576081R .281 7,14 .030/.035 .250 6,35 .383 .453 .6360 .3750 ●
FLG-6281L 576081L .281 7,14 .030/.035 .250 6,35 .383 .453 .6360 .3750 ●
FLG-6312R 576212R .312 7,92 .030/.035 .250 6,35 .383 .453 .6360 .3750 ●
FLG-6312L 576212L .312 7,92 .030/.035 .250 6,35 .383 .453 .6360 .3750 ●
FLG-6375R 576275R .375 9,53 .030/.035 .250 6,35 .383 .453 .6360 .3750 ●
FLG-6375L 576275L .375 9,53 .030/.035 .250 6,35 .383 .453 .6360 .3750 ●
E
3˚
GROOVING W T
GPM6 TiN Coated Cermet
AlTiN Coated
FLGP
GP50 TiN Coated
RTyp.
Uncoated
GAGE
5˚ B DIA.
w/positive rake RH Shown
A
AC50
W
E Gage
GP3
AC3
Description EDP Code Inch Metric R Inch Metric T A B Dia.
C3
FLGP-2031R 572431R .031 0,79 .002/.005 .050 1,27 .150 .219 .2700 .1875 ● ● ● ● ●
FLGP-2031L 572431L .031 0,79 .002/.005 .050 1,27 .150 .219 .2700 .1875 ● ● ● ● ●
FLGP-2062R 572462R .062 1,57 .005/.010 .110 2,79 .150 .219 .2700 .1875 ● ● ● ● ●
FLGP-2062L 572462L .062 1,57 .005/.010 .110 2,79 .150 .219 .2700 .1875 ● ● ● ● ●
FLGP-2125R 572625R .125 3,18 .005/.010 .110 2,79 .150 .219 .2700 .1875 ● ● ● ● ●
FLGP-2125L 572625L .125 3,18 .005/.010 .110 2,79 .150 .219 .2700 .1875 ● ● ● ● ●
FLGP-3047R 573447R .047 1,19 .005/.010 .075 1,90 .195 .344 .4050 .3750 ● ● ● ● ● ●
FLGP-3047L 573447L .047 1,19 .005/.010 .075 1,05 .195 .344 .4050 .3750 ● ● ● ● ● ●
FLGP-3062R 573462R .062 1,57 .005/.010 .120 3,05 .195 .344 .4050 .3750 ● ● ● ● ●
FLGP-3062L 573462L .062 1,57 .005/.010 .120 3,05 .195 .344 .4050 .3750 ● ● ● ● ●
FLGP-3088R 573488R .088 2,24 .005/.010 .180 4,57 .195 .344 .4050 .3750 ● ● ● ●
FLGP-3088L 573488L .088 2,24 .005/.010 .180 4,57 .195 .344 .4050 .3750 ● ● ● ●
FLGP-3094R 573494R .094 2,39 .005/.010 .180 4,57 .195 .344 .4050 .3750 ● ● ● ● ● ●
FLGP-3094L 573494L .094 2,39 .005/.010 .180 4,57 .195 .344 .4050 .3750 ● ● ● ● ● ●
FLGP-3125R 573625R .125 3,18 .005/.010 .180 4,57 .195 .344 .4050 .3750 ● ● ● ● ● ●
FLGP-3125L 573625L .125 3,18 .005/.010 .180 4,57 .195 .344 .4050 .3750 ● ● ● ● ● ●
FLGP-3156R 573656R .156 3,96 .005/.010 .180 4,57 .195 .344 .4050 .3750 ● ● ● ● ●
FLGP-3156L 573656L .156 3,96 .005/.010 .180 4,57 .195 .344 .4050 .3750 ● ● ● ● ●
FLGP-3189R 573689R .189 4,80 .020/.025 .180 4,57 .195 .344 .4050 .3750 ● ● ● ● ● ●
FLGP-3189L 573689L .189 4,80 .020/.025 .180 4,57 .195 .344 .4050 .3750 ● ● ● ● ● ●
FLGP-4125R 574625R .125 3,18 .005/.010 .250 6,35 .255 .453 .6360 .3750 ● ● ● ●
FLGP-4125L 574625L .125 3,18 .005/.010 .250 6,35 .255 .453 .6360 .3750 ● ● ● ●
FLGP-4189R 574689R .189 4,80 .020/.025 .250 6,35 .255 .453 .6360 .3750 ● ● ● ●
FLGP-4189L 574689L .189 4,80 .020/.025 .250 6,35 .255 .453 .6360 .3750 ● ● ● ●
FLGP-4250R 574850R .250 6,35 .020/.025 .250 6,35 .255 .453 .6360 .3750 ● ● ● ●
FLGP-4250L 574850L .250 6,35 .020/.025 .250 6,35 .255 .453 .6360 .3750 ● ● ● ●
In an effort to improve our stock standard grade offering, Cast Iron ▲ ●
there are periodic changes.
● High performance choice in optimal conditions. Non-Ferrous ▲ ●
Please see current price list for up to date grade offering. ▲ Recommended grade under general conditions. Stainless/High Temp ▲ ●
94 Steel ▲ ▲ ●
FLO-LOCK
GROOVING - CHIP-FLO 3˚
E
FLR-CB Features:
AlTiN Coated
W T
w/full nose radius
TiN Coated
• Patented chipbreaker
Uncoated
GAGE
RTyp. B DIA.
! Patent No. 6,146,064
d design
RH Shown
• Maximum chip control
A
e patente
Exclusiv • Industry standard widths
GP50
AC50
W R E Gage
GP3
AC3
Description
C3
EDP Code Inch Metric Inch Metric Inch Metric T A B Dia.
FLR-3031R-CB 593031PR .062 1,57 .031 0,78 .125 3,18 .195 .344 .4033 .3750 ● ● ● ● ●
FLR-3031L-CB 593031PL .062 1,57 .031 0,78 .125 3,18 .195 .344 .4033 .3750 ● ● ● ● ●
FLR-3047R-CB 593047PR .094 2,39 .047 1,19 .180 4,57 .195 .344 .4025 .3750 ● ● ● ● ●
FLR-3047L-CB 593047PL .094 2,39 .047 1,19 .180 4,57 .195 .344 .4025 .3750 ● ● ● ● ●
FLR-3062R-CB 593062PR .125 3,18 .062 1,57 .180 4,57 .195 .344 .4017 .3750 ● ● ● ● ●
FLR-3062L-CB 593062PL .125 3,18 .062 1,57 .180 4,57 .195 .344 .4017 .3750 ● ● ● ● ●
E
3˚
GROOVING T
AlTiN Coated
W
FLR
TiN Coated
Uncoated
R GAGE
RH Shown
w/full nose radius B DIA.
W R E
GP50
AC50
Gage
GP3
AC3
Description
C3
EDP Code Inch Metric Inch Metric Inch Metric T A B Dia.
FLO-LOCK
FLR-2031R 592031R .062 1,57 .031 0,78 .110 2,79 .150 .219 .2683 .1875 ● ● ● ●
FLR-2031L 592031L .062 1,57 .031 0,78 .110 2,79 .150 .219 .2683 .1875 ● ● ● ●
FLR-2047R 592047R .094 2,39 .047 1,19 .110 2,79 .150 .219 .2675 .1875 ● ● ● ●
FLR-2047L 592047L .094 2,39 .047 1,19 .110 2,79 .150 .219 .2675 .1875 ● ● ● ●
FLR-2062R 592062R .125 3,18 .062 1,57 .110 2,79 .150 .219 .2667 .1875 ● ● ● ●
FLR-2062L 592062L .125 3,18 .062 1,57 .110 2,79 .150 .219 .2667 .1875 ● ● ● ●
FLR-3031R 593031R .062 1,57 .031 0,78 .125 3,18 .195 .344 .4033 .3750 ● ● ● ● ●
FLR-3031L 593031L .062 1,57 .031 0,78 .125 3,18 .195 .344 .4033 .3750 ● ● ● ● ●
FLR-3047R 593047R .094 2,39 .047 1,19 .180 4,57 .195 .344 .4025 .3750 ● ● ● ● ●
FLR-3047L 593047L .094 2,39 .047 1,19 .180 4,57 .195 .344 .4025 .3750 ● ● ● ● ●
FLR-3062R 593062R .125 3,18 .062 1,57 .180 4,57 .195 .344 .4017 .3750 ● ● ● ● ●
FLR-3062L 593062L .125 3,18 .062 1,57 .180 4,57 .195 .344 .4017 .3750 ● ● ● ● ●
FLR-3078R 593078R .156 3,96 .078 1,98 .180 4,57 .195 .344 .4008 .3750 ● ● ● ●
FLR-3078L 593078L .156 3,96 .078 1,98 .180 4,57 .195 .344 .4008 .3750 ● ● ● ●
FLR-3094R 593094R .189 4,80 .094 2,39 .180 4,57 .195 .344 .4000 .3750 ● ● ● ●
FLR-3094L 593094L .189 4,80 .094 2,39 .180 4,57 .195 .344 .4000 .3750 ● ● ● ●
FLR-4062R (Same E dim. as FLRD) 594062R .125 3,18 .062 1,57 .250 6,35 .255 .453 .6327 .3750 ● ● ● ● ●
FLR-4062L (Same E dim. as FLRD) 594062L .125 3,18 .062 1,57 .250 6,35 .255 .453 .6327 .3750 ● ● ● ● ●
FLR-4094R 594094R .189 4,80 .094 2,39 .250 6,35 .255 .453 .6310 .3750 ● ● ● ● ●
FLR-4094L 594094L .189 4,80 .094 2,39 .250 6,35 .255 .453 .6310 .3750 ● ● ● ● ●
FLR-4125R 594225R .250 6,35 .125 3,18 .250 6,35 .255 .453 .6293 .3750 ● ● ● ● ●
FLR-4125L 594225L .250 6,35 .125 3,18 .250 6,35 .255 .453 .6293 .3750 ● ● ● ● ●
E
GROOVING
3˚
AlTiN Coated
W T
TiN Coated
FLRP R RH Shown Uncoated
w/full nose radius and positive rake
GAGE
B DIA.
5˚
W R E Gage
GP50
AC50
GP3
AC3
Description EDP Code Inch Metric Inch Metric Inch Metric T A B Dia.
C3
FLRP-3031R 593831R .062 1,57 .031 0,78 .125 0,79 .195 .344 .4033 .3750 ● ● ● ● ●
FLRP-3031L 593831L .062 1,57 .031 0,78 .125 0,79 .195 .344 .4033 .3750 ● ● ● ● ●
FLRP-3047R 593847R .094 2,39 .047 1,19 .180 4,57 .195 .344 .4025 .3750 ● ● ● ● ●
FLRP-3047L 593847L .094 2,39 .047 1,19 .180 4,57 .195 .344 .4025 .3750 ● ● ● ● ●
FLRP-3062R 593862R .125 3,18 .062 1,57 .180 4,57 .195 .344 .4017 .3750 ● ● ● ● ●
FLRP-3062L 593862L .125 3,18 .062 1,57 .180 4,57 .195 .344 .4017 .3750 ● ● ● ● ●
FLRP-3078R 593878R .156 3,96 .078 1,98 .180 4,57 .195 .344 .4008 .3750 ● ● ● ●
FLRP-3078L 593878L .156 3,96 .078 1,98 .180 4,57 .195 .344 .4008 .3750 ● ● ● ●
FLRP-3094R 593894R .189 4,80 .094 2,39 .180 4,57 .195 .344 .4000 .3750 ● ● ● ● ●
FLRP-3094L 593894L .189 4,80 .094 2,39 .180 4,57 .195 .344 .4000 .3750 ● ● ● ● ●
FLRP-4062R 594862R .125 3,18 .062 1,57 .250 6,35 .255 .453 .6327 .3750 ● ● ● ●
FLRP-4062L 594862L .125 3,18 .062 1,57 .250 6,35 .255 .453 .6327 .3750 ● ● ● ●
FLRP-4094R 594894R .189 4,80 .094 2,39 .250 6,35 .255 .453 .6310 .3750 ● ● ● ●
FLRP-4094L 594894L .189 4,80 .094 2,39 .250 6,35 .255 .453 .6310 .3750 ● ● ● ●
FLRP-4125R 604025R .250 6,35 .125 3,18 .250 6,35 .255 .453 .6293 .3750 ● ● ● ●
FLRP-4125L 604025L .250 6,35 .125 3,18 .250 6,35 .255 .453 .6293 .3750 ● ● ● ●
In an effort to improve our stock standard grade offering, Cast Iron ▲ ●
there are periodic changes.
● High performance choice in optimal conditions. Non-Ferrous ▲ ●
Please see current price list for up to date grade offering. ▲ Recommended grade under general conditions. Stainless/High Temp ▲ ●
Steel ▲ ●
95
FLO-LOCK
FACE GROOVING - CHIP-FLO
FLF-CB
E
ign! 12 3˚
e pate nted des
Exclusiv W T
AlTiN Coated
Features:
TiN Coated
Uncoated
• Patented chipbreaker - Patent No. 6,146,064
R Typ.
GAGE
B RH Shown DIA.
• Maximum chip control A
• Industry standard widths
W Gage
GP50
AC50
GP3
AC3
Description
C3
EDP Code Inch Metric R E T A B Dia.
FLF-3125R-CB 563025PR .125 3,18 .005/.010 .180 .195 .344 .4050 .3750 ● ● ●
FLF-3125L-CB 563025PL .125 3,18 .005/.010 .180 .195 .344 .4050 .3750 ● ● ●
FLF-3156R-CB 563056PR .156 3,96 .005/.010 .180 .195 .344 .4050 .3750 ● ● ●
FLF-3156L-CB 563056PL .156 3,96 .005/.010 .180 .195 .344 .4050 .3750 ● ● ●
FLF-3188R-CB 563088PR .188 4,77 .020/.025 .180 .195 .344 .4050 .3750 ● ● ●
FLF-3188L-CB 563088PL .188 4,77 .020/.025 .180 .195 .344 .4050 .3750 ● ● ●
FACE GROOVING 12 3˚
FLF W T
AlTiN Coated
TiN Coated
RTyp. GAGE
RH Shown
Uncoated
DIA.
B
FLO-LOCK
W Gage
GP50
AC50
GP3
AC3
C3
Description EDP Code Inch Metric R E T A B Dia.
FLF-3125R 563025R .125 3,18 .005/.010 .180 .195 .344 .4050 .3750 ● ● ●
FLF-3125L 563025L .125 3,18 .005/.010 .180 .195 .344 .4050 .3750 ● ● ●
FLF-3156R 563056R .156 3,96 .005/.010 .180 .195 .344 .4050 .3750 ● ● ●
FLF-3156L 563025L .156 3,96 .005/.010 .180 .195 .344 .4050 .3750 ● ● ●
FLF-3188R 563088R .188 4,77 .020/.025 .180 .195 .344 .4050 .3750 ● ●
FLF-3188L 563088L .188 4,77 .020/.025 .180 .195 .344 .4050 .3750 ● ●
FLF-4250R 564250R .250 6,35 .020/.025 .250 .255 .453 .6360 .3750 ● ● ●
FLF-4250L 564250L .250 6,35 .020/.025 .250 .255 .453 .6360 .3750 ● ● ●
FLF-6218R 566218R .218 5,54 .030/.035 .250 .383 .453 .6360 .3750
FLF-6218L 566218L .218 5,54 .030/.035 .250 .383 .453 .6360 .3750
FLF-6250R 566250R .250 6,35 .030/.035 .250 .383 .453 .6360 .3750
FLF-6250L 566250L .250 6,35 .030/.035 .250 .383 .453 .6360 .3750
FLF-6375R 566475R .375 9,53 .030/.035 .250 .383 .453 .6360 .3750
FLF-6375L 566475L .375 9,53 .030/.035 .250 .383 .453 .6360 .3750
DEEP GROOVING - CHIP-FLO
FLGD-CB design!
E
T
atented
Single ended Ex clusive p W
Features: B
GAGE
DIA.
• Patented chipbreaker - Patent No. 6,146,064
AlTiN Coated
TiN Coated
• Maximum chip control
Uncoated
A
RH Shown
• Industry standard widths
W Gage
GP50
AC50
GP3
AC3
C3
Description EDP Code Inch Metric R E T A B Dia.
FLGD-3062R-CB (FLG-3062R-CB)* 563662PR .062 1,57 .005/.010 .120 .195 .344 .5050 .3750 ● ● ● ● ●
FLGD-3062L-CB (FLG-3062L-CB)* 563662PL .062 1,57 .005/.010 .120 .195 .344 .5050 .3750 ● ● ● ● ●
FLGD-3094R-CB 6335094PR .094 2,39 .005/.010 .250 .195 .344 .5050 .3750 ● ● ● ●
FLGD-3094L-CB 6335094PL .094 2,39 .005/.010 .250 .195 .344 .5050 .3750 ● ● ● ●
FLGD-3125R-CB 6335125PR .125 3,18 .005/.010 .250 .195 .344 .5050 .3750 ● ● ● ●
FLGD-3125L-CB 6335125PL .125 3,18 .005/.010 .250 .195 .344 .5050 .3750 ● ● ● ●
FLGD-3189R-CB 6335189PR .189 4,80 .020/.025 .250 .195 .344 .5050 .3750 ● ● ● ●
FLGD-3189L-CB 6335189PL .189 4,80 .020/.025 .250 .195 .344 .5050 .3750 ● ● ● ●
FLGD-4189R-CB 6345189PR .189 4,80 .020/.025 .375 .255 .453 .7610 .3750 ● ● ● ●
FLGD-4189L-CB 6345189PL .189 4,80 .020/.025 .375 .255 .453 .7610 .3750 ● ● ● ●
FLGD-4250R-CB 6345250PR .250 6,35 .020/.025 .500 .255 .453 .8860 .3750 ● ● ● ●
FLGD-4250L-CB 6345250PL .250 6,35 .020/.025 .500 .255 .453 .8860 .3750 ● ● ● ●
*Inserts are double ended.
In an effort to improve our stock standard grade offering, Cast Iron ▲ ●
there are periodic changes.
● High performance choice in optimal conditions. Non-Ferrous ▲ ●
Please see current price list for up to date grade offering. ▲ Recommended grade under general conditions. Stainless/High Temp ▲ ●
Steel ▲ ●
96
FLO-LOCK
E
T
AlTiN Coated
DEEP GROOVING
W
TiN Coated
Uncoated
R
FLGD B
GAGE
DIA.
Single ended RH Shown
A
W Gage
GP50
AC50
GP3
AC3
Description
C3
EDP Code Inch Metric R E T A B Dia.
FLGD-3062R (.120 DOC)* 563662R .062 1,57 .005/.010 .145 .195 .344 .5050 .3750 ● ● ● ● ●
FLGD-3062L (.120 DOC)* 563662L .062 1,57 .005/.010 .145 .195 .344 .5050 .3750 ● ● ● ● ●
FLGD-3094R 6334094R .094 2,39 .005/.010 .250 .195 .344 .5050 .3750 ● ●
FLGD-3094L 6334094L .094 2,39 .005/.010 .250 .195 .344 .5050 .3750 ● ●
FLGD-3125R 6334125R .125 3,18 .005/.010 .250 .195 .344 .5050 .3750 ● ●
FLGD-3125L 6334125L .125 3,18 .005/.010 .250 .195 .344 .5050 .3750 ● ●
FLGD-3189R 6334189R .189 4,8 .020/.025 .250 .195 .344 .5050 .3750 ● ●
FLGD-3189L 6334189L .189 4,8 .020/.025 .250 .195 .344 .5050 .3750 ● ●
FLGD-4125R (FLG-4125R)* 564825R .125 3,18 .005/.010 .290 .255 .453 .6360 .3750 ● ●
FLGD-4125L (FLG-4125L)* 564825L .125 3,18 .005/.010 .290 .255 .453 .6360 .3750 ● ●
FLGD-4189R 6344189R .189 4,8 .020/.025 .375 .255 .453 .7610 .3750 ● ● ●
FLGD-4189L 6344189L .189 4,8 .020/.025 .375 .255 .453 .7610 .3750 ● ● ●
FLGD-4250R 6344250R .250 6,35 .020/.025 .500 .255 .453 .8860 .3750 ● ●
FLGD-4250L 6344250L .250 6,35 .020/.025 .500 .255 .453 .8860 .3750 ● ●
*Inserts are double ended.
E
T
DEEP GROOVING - FNR W
AC50 AlTiN Coated
FLRD
TiN Coated
R
Uncoated
GAGE
Full nose radius - Single ended
FLO-LOCK
B DIA.
A
RH Shown
W Gage
GP50
GP3
AC3
C3
Description EDP Code Inch Metric R E T A B Dia.
FLRD-3031R (FLR-3031R)* 593031R .062 1,57 .031 .125 .195 .344 .4033 .3750 ● ● ● ● ●
FLRD-3031L (FLR-3031L)* 593031L .062 1,57 .031 .125 .195 .344 .4033 .3750 ● ● ● ● ●
FLRD-3062R 6336062R .125 3,19 .062 .250 .195 .344 .5016 .3750 ● ● ● ●
FLRD-3062L 6336062L .125 3,19 .062 .250 .195 .344 .5016 .3750 ● ● ● ●
FLRD-3094R 6336094R .189 4,8 .094 .250 .195 .344 .5016 .3750 ● ● ● ●
FLRD-3094L 6336094L .189 4,8 .094 .250 .195 .344 .5016 .3750 ● ● ● ●
FLRD-4094R 6346094R .189 4,8 .094 .500 .255 .453 .8860 .3750 ● ● ● ●
FLRD-4094L 6346094L .189 4,8 .094 .500 .255 .453 .8860 .3750 ● ● ● ●
FLRD-4125R 6346125R .250 6,35 .125 .500 .255 .453 .8860 .3750 ● ● ● ●
FLRD-4125L 6346125L .250 6,35 .125 .500 .255 .453 .8860 .3750 ● ● ● ●
*Inserts are double ended.
INTERNAL DEEP FACE
GROOVING - CHIP-FLO
E
T
12
W
FLFD-I-CB Features:
AlTiN Coated
R
• Patented chipbreaker
TiN Coated
Single ended
Uncoated
GAGE
B DIA.
esign! Patent No. 6,146,064
e pa tented d • Maximum chip control
RH Shown
Exclusiv
A
• Industry
standard widths W Gage
GP50
AC50
GP3
AC3
C3
Description EDP Code Inch Metric R E T A B Dia.
FLFD-3125R-I-CB 6338125PRI .125 3,18 .005/.010 .250 .195 .344 .5050 .3750 ● ● ● ●
FLFD-3125L-I-CB 6338125PLI .125 3,18 .005/.010 .250 .195 .344 .5050 .3750 ● ● ● ●
FLFD-3189R-I-CB 6338189PRI .189 4,80 .020/.025 .250 .195 .344 .5050 .3750 ● ● ● ●
FLFD-3189L-I-CB 6338189PLI .189 4,80 .020/.025 .250 .195 .344 .5050 .3750 ● ● ● ●
DEEP FACE GROOVING 12 E
T
CHIP-FLO Features: W
FLFD-CB • Patented chipbreaker
AC50 AlTiN Coated
R
TiN Coated
GAGE
B DIA.
Uncoated
Single ended Patent No. 6,146,064
ign! • Maximum chip control
nted des
A RH Shown
e pate • Industry standard widths
Exclusiv W Gage
GP50
GP3
AC3
C3
Description EDP Code Inch Metric R E T A B Dia.
FLFD-3125R-CB 6338125PR .125 3,18 .005/.010 .250 .195 .344 .5050 .3750 ● ● ● ●
FLFD-3125L-CB 6338125PL .125 3,18 .005/.010 .250 .195 .344 .5050 .3750 ● ● ● ●
FLFD-3189R-CB 6338189PR .189 4,80 .020/.025 .250 .195 .344 .5050 .3750 ● ● ● ●
FLFD-3189L-CB 6338189PL .189 4,80 .020/.025 .250 .195 .344 .5050 .3750 ● ● ● ●
In an effort to improve our stock standard grade offering, Cast Iron ▲ ●
there are periodic changes.
● High performance choice in optimal conditions. Non-Ferrous ▲ ●
Please see current price list for up to date grade offering. ▲ Recommended grade under general conditions. Stainless/High Temp ▲ ●
Steel ▲ ●
97
FLO-LOCK
DEEP GROOVING E
T
FLGT ge des ign!
sive 2 ed
W
Exclu
AlTiN Coated
Double ended R
TiN Coated
Uncoated
GAGE
B DIA.
Fits FLSLT/RT Holders. See page 110
RH Shown
A
W Gage
GP50
AC50
GP3
AC3
Description EDP Code Inch Metric R E T A B Dia.
C3
FLGT-3094R 6332094R .094 2,39 .005/.010 .275 .195 .344 .855 .3750 ● ● ● ●
FLGT-3094L 6332094L .094 2,39 .005/.010 .275 .195 .344 .855 .3750 ● ● ● ●
FLGT-3125R 6332125R .125 3,18 .005/.010 .437 .195 .344 .855 .3750 ● ● ● ●
FLGT-3125L 6332125L .125 3,18 .005/.010 .437 .195 .344 .855 .3750 ● ● ● ●
FLGT-3189R 6332189R .189 4,8 .020/.025 .437 .195 .344 .855 .3750 ● ● ● ●
FLGT-3189L 6332189L .189 4,8 .020/.025 .437 .195 .344 .855 .3750 ● ● ● ●
FLGT-4125R 6342125R .125 3,18 .005/.010 .550 .255 .453 1.136 .3750 ● ● ● ●
FLGT-4125L 6342125L .125 3,18 .005/.010 .550 .255 .453 1.136 .3750 ● ● ● ●
FLGT-4189R 6342189R .189 4,8 .020/.025 .550 .255 .453 1.136 .3750 ● ● ● ●
FLGT-4189L 6342189L .189 4,8 .020/.025 .550 .255 .453 1.136 .3750 ● ● ● ●
FLGT-4250R 6342250R .250 6,35 .020/.025 .550 .255 .453 1.136 .3750 ● ● ● ●
FLGT-4250L 6342250L .250 6,35 .020/.025 .550 .255 .453 1.136 .3750 ● ● ● ●
DEEP FACE GROOVING
FLFT
FLO-LOCK
esign!
Double ended e 2 edge d 12 E
Exclusiv
T
W
AC50 AlTiN Coated
GAGE
TiN Coated
Fits FLSLT/RT Holders. See page 110 B DIA.
Uncoated
A
RH Shown
W Gage
GP50
GP3
AC3
C3
Description EDP Code Inch Metric R E T A B Dia.
FLFT-3125R 6339125R .125 3,18 .005/.010 .375 .195 .344 .885 .3750 ● ● ● ●
FLFT-3125L 6339125L .125 3,18 .005/.010 .375 .195 .344 .885 .3750 ● ● ● ●
FLFT-4189R 6349189R .189 4,8 .020/.025 .550 .255 .453 1.136 .3750 ● ● ● ●
FLFT-4189L 6349189L .189 4,8 .020/.025 .550 .255 .453 1.136 .3750 ● ● ● ●
FLFT-4250R 6349250R .250 6,35 .020/.025 .550 .255 .453 1.136 .3750 ● ●
FLFT-4250L 6349250L .250 6,35 .020/.025 .550 .255 .453 1.136 .3750 ● ●
DEEP GROOVING - FNR
FLRT desig n!
E
T
Double ended e 2 edge
Exclusiv
W
AlTiN Coated
R
TiN Coated
GAGE
Uncoated
B DIA.
Fits FLSLT/RT Holders. See page 110
A RH Shown
W Gage
GP50
AC50
GP3
AC3
C3
Description EDP Code Inch Metric R E T A B Dia.
FLRT-3062R 6337062R .125 3,18 .062 .437 .195 .344 .855 .3750 ● ●
FLRT-3062L 6337062L .125 3,18 .062 .437 .195 .344 .855 .3750 ● ●
FLRT-3094R 6337094R .189 4,80 .094 .437 .195 .344 .855 .3750 ● ●
FLRT-3094L 6337094L .189 4,80 .094 .437 .195 .344 .855 .3750 ● ●
FLRT-4062R 6347062R .125 3,18 .062 .550 .255 .453 1.136 .3750 ● ●
FLRT-4062L 6347062L .125 3,18 .062 .550 .255 .453 1.136 .3750 ● ●
FLRT-4094R 6347094R .189 4,8 .094 .550 .255 .453 1.136 .3750 ● ●
FLRT-4094L 6347094L .189 4,8 .094 .550 .255 .453 1.136 .3750 ● ●
FLRT-4125R 6347125R .250 6,35 .125 .550 .255 .453 1.136 .3750 ● ●
FLRT-4125L 6347125L .250 6,35 .125 .550 .255 .453 1.136 .3750 ● ●
In an effort to improve our stock standard grade offering, Cast Iron ▲ ●
there are periodic changes.
● High performance choice in optimal conditions. Non-Ferrous ▲ ●
Please see current price list for up to date grade offering. ▲ Recommended grade under general conditions. Stainless/High Temp ▲ ●
Steel ▲ ●
98
FLO-LOCK
Recommended Feed rate - inch/rev (mm/rev)
Insert Rake Configuration
Flo-Lock Series Kits
Workpiece FLG-Neutral FLG-CB THREADING KITS SAVE!
V-THREADING V-THREADING Buy in Kits
Group KIT #1A KIT #1B
Kit Contents Kit Contents
1 FLSR-163D 1 FLSR-163D
Free Machining 4 FLT-3R-HCB GP50 4 FLT-3R-HCB GP3
.004-.010 .005-.014 1 S-412 SCREW 1 S-412 SCREW
Carbon Steels
Plain Carbon
Steels
.004-.010 .005-.014 GROOVING KITS
W.125 GROOVING W.125 GROOVING
Alloy Steels
190-330 HB
.004-.010 .005-.014
KIT #2A KIT #2B
Kit Contents Kit Contents
Alloy Steels .003-.009 .005-.012
330-450 HB 1 FLSR-163D 1 FLSR-163D
4 FLG-3125R-CB GP50 4 FLG-3125R-CB GP3
Martensitic/Ferritic 1 S-412 SCREW 1 S-412 SCREW
Stainless Steel .004-.010 .005-.014
400 Series W.094 GROOVING W.094 GROOVING
Austenitic Stainless
300 Series
.003-.006 .004-.008 KIT #3A KIT #3B
Kit Contents Kit Contents
Gray Cast Iron
.004-.010 --- 1 FLSR-163D 1 FLSR-163D
190-330 HB 4 FLG-3094R-CB GP3
4 FLG-3094R-CB GP50
Gray Cast Iron 1 S-412 SCREW 1 S-412 SCREW
.003-.009 ---
330-450 HB
W.062 GROOVING W.062 GROOVING
Alloy / Ductile Irons .004-.010 .005-.014
KIT #4A KIT #4B
Free Machining Kit Contents Kit Contents
.005-.012 .006-.016
Aluminum Alloys 1 FLSR-163D 1 FLSR-163D
High-Silicon 4 FLG-3062R-CB GP50 4 FLG-3062R-CB GP3
.003-.006 --- 1 S-412 SCREW 1 S-412 SCREW
Aluminum Alloys
FLO-LOCK
Copper / Zinc / Brass .005-.012 .006-.016 W.047 GROOVING W.047 GROOVING
KIT #5A KIT #5B
Non-Metallics .005-.012 --- Kit Contents Kit Contents
1 FLSR-163D 1 FLSR-163D
High Temperature 4 FLG-3047R-CB GP3
.003-.006 .004-.007 4 FLG-3047R-CB GP50
Alloys 200-260 HB 1 S-412 SCREW 1 S-412 SCREW
High Temperature
.003-.006 .004-.007
Alloys 260-450 HB DEEP GROOVING KITS
Titanium Alloys W.125 GROOVING W.094 GROOVING
.003-.006 .004-.008
(Ti 6Al-4V) KIT #6 KIT #7
Hardened Materials Kit Contents Kit Contents
.0015-.005 ---
48-65 HRC 1 FLSR-163D 1 FLSR-163D
4 FLGD-3125R-CB AC3 4 FLGD-3094R-CB AC3
1 S-412 SCREW 1 S-412 SCREW
Recommended SFM for Grooving Applications
Uncoated
Coated
Cermet
Coated
Workpiece
AlTiN
CBN
PVD
PCD
PVD
TiN
TiN
Group
C3 GP22 GP3 GP4 GP50 AC22 AC3 AC50 GPM6 CB200 CB400 PC33
Free Machining
--- 150-300 200-400 60-175 200-600 200-400 250-450 400-800 600-1500 --- --- ---
Carbon Steels
Plain Carbon
--- 150-300 200-400 60-175 200-600 200-400 250-450 450-800 600-1200 --- --- ---
Steels
Alloy Steels
--- 150-300 200-400 60-150 200-500 200-350 250-400 400-800 500-1100 --- --- ---
190-330 HB
Alloy Steels
--- 150-300 200-350 60-150 200-450 200-350 250-400 400-750 600-800 --- --- ---
330-450 HB
Martensitic/Ferritic
Stainless Steel --- 150-300 200-400 60-150 200-500 200-400 250-450 350-700 500-800 --- --- ---
400 Series
Austenitic Stainless
300 Series 200-400 150-400 200-500 60-150 --- 300-600 250-700 --- 500-1000 --- --- ---
Gray Cast Iron
190-330 HB 100-375 150-400 200-600 60-150 --- 300-600 250-700 --- 400-1100 1400-2500 --- ---
Gray Cast Iron
100-350 150-350 200-500 60-150 --- 200-550 250-600 --- 350-950 1200-1800 --- ---
330-450 HB
Alloy / Ductile Irons 100-350 150-300 200-400 60-150 200-500 250-450 200-450 300-700 350-950 --- --- ---
Free Machining
500-2000 150-2000 300-2000 60-150 --- 600-2200 600-2500 --- --- --- --- 1000-8000
Aluminum Alloys
High-Silicon
--- --- --- --- --- --- --- --- --- --- --- 1000-5000
Aluminum Alloys
Copper / Zinc / Brass 200-700 150-700 200-900 --- --- 300-900 400-1000 --- --- --- --- 1000-4000
Non-Metallics 400-1400 150-1500 300-1500 --- --- 350-1200 400-1500 --- --- --- --- 1000-4500
High Temperature
80-130 100-175 100-200 50-80 --- 80-200 100-250 --- --- 300-600 --- ---
Alloys 200-260 HB
High Temperature
50-100 80-150 100-175 50-80 --- 80-175 100-200 --- --- 250-450 --- ---
Alloys 260-450 HB
Titanium Alloys
100-200 100-250 150-300 50-80 --- 80-300 100-300 --- --- --- --- ---
(Ti 6Al-4V)
Hardened Materials
48-65 HRC --- --- --- --- --- --- 80-150 --- --- 150-350 200-550 ---
Bold print items denote the top choices for the materials listed, provided it can be machined within the SFM stated under the appropriate machining conditions. For the best performance in
optimal machining conditions, select the grade that will provide you with the highest allowable SFM.
99
FLO-LOCK
ACME THREADING 3°
FLA E T
AlTiN Coated
TiN Coated
W
Uncoated
GAGE RH Shown
For Flo-Lock acme thread limits see pg. 111,112. B DIA.
A
Gage
GP50
AC50
GP3
AC3
Description
C3
EDP Code TPI W T E A B Dia.
FLA-3R16 553016R 16 .0206 .195 .149 .344 .4026 .3750 ● ●
FLA-3L16 553016L 16 .0206 .195 .149 .344 .4026 .3750 ● ●
FLA-3R14 553014R 14 .0239 .195 .149 .344 .4026 .3750 ● ●
FLA-3L14 553014L 14 .0239 .195 .149 .344 .4026 .3750 ● ●
FLA-3R12 553012R 12 .0283 .195 .149 .344 .4026 .3750 ● ●
FLA-3L12 553012L 12 .0283 .195 .149 .344 .4026 .3750 ● ●
FLA-3R10 553010R 10 .0319 .195 .149 .344 .4026 .3750 ● ● ●
FLA-3L10 553010L 10 .0319 .195 .149 .344 .4026 .3750 ● ● ●
FLA-3R8 553008R 8 .0411 .195 .149 .344 .4026 .3750 ● ● ● ●
FLA-3L8 553008L 8 .0411 .195 .149 .344 .4026 .3750 ● ● ● ●
FLA-3R6 553006R 6 .0566 .195 .149 .344 .4026 .3750 ● ● ● ● ●
FLA-3L6 553006L 6 .0566 .195 .149 .344 .4026 .3750 ● ● ● ● ●
FLA-3R5 553005R 5 .0689 .195 .149 .344 .4026 .3750 ● ● ● ● ●
FLA-3L5 553005L 5 .0689 .195 .149 .344 .4026 .3750 ● ● ● ● ●
FLA-3R4 553004R 4 .0875 .195 .133 .344 .4018 .3750 ● ● ● ● ●
FLA-3L4 553004L 4 .0875 .195 .133 .344 .4018 .3750 ● ● ● ● ●
FLA-4R8 554008R 8 .0411 .255 .202 .453 .6332 .3750 ● ●
FLA-4L8 554008L 8 .0411 .255 .202 .453 .6332 .3750 ● ●
FLO-LOCK
FLA-4R6 554006R 6 .0566 .255 .202 .453 .6332 .3750 ● ●
FLA-4L6 554006L 6 .0566 .255 .202 .453 .6332 .3750 ● ●
FLA-4R5 554005R 5 .0689 .255 .202 .453 .6332 .3750 ● ●
FLA-4L5 554005L 5 .0689 .255 .202 .453 .6332 .3750 ● ●
FLA-4R4 554004R 4 .0875 .255 .202 .453 .6332 .3750 ● ● ● ●
FLA-4L4 554004L 4 .0875 .255 .202 .453 .6332 .3750 ● ● ● ●
FLA-6R3 556003R 3 .1184 .383 .283 .453 .6308 .3750 ●
FLA-6L3 556003L 3 .1184 .383 .283 .453 .6308 .3750 ●
FLA-6R2.5 5560025R 2.5 .1431 .383 .283 .453 .6308 .3750 ●
FLA–6L2.5 5560025L 2.5 .1431 .383 .283 .453 .6308 .3750 ●
FLA-6R2 556002R 2 .1802 .383 .283 .453 .6308 .3750 ●
FLA-6L2 556002L 2 .1802 .383 .283 .453 .6308 .3750 ●
ACME STUB THREADING 3˚
FLAS E W T
AlTiN Coated
TiN Coated
Uncoated
GAGE RH Shown
B DIA.
Gage
GP50
AC50
GP3
AC3
C3
Description EDP Code TPI W T E A B Dia.
FLAS-3R16 553216R 16 .0238 .195 .149 .344 .4026 .375
● ● ●
FLAS-3L16 553216L 16 .0238 .195 .149 .344 .4026 .375 ● ● ●
FLAS-3R14 553214R 14 .0276 .195 .149 .344 .4026 .375 ● ●
FLAS-3L14 553214L 14 .0276 .195 .149 .344 .4026 .375 ● ●
FLAS-3R12 553212R 12 .0326 .195 .149 .344 .4026 .375 ●
FLAS-3L12 553212L 12 .0326 .195 .149 .344 .4026 .375 ●
FLAS-3R10 553210R 10 .0370 .195 .149 .344 .4026 .375 ● ● ●
FLAS-3L10 553210L 10 .0370 .195 .149 .344 .4026 .375 ● ● ●
FLAS-3R8 553208R 8 .0476 .195 .149 .344 .4026 .375 ● ● ● ●
FLAS-3L8 553208L 8 .0476 .195 .149 .344 .4026 .375 ● ● ● ●
FLAS-3R6 553206R 6 .0652 .195 .149 .344 .4026 .375 ● ● ● ●
FLAS-3L6 553206L 6 .0652 .195 .149 .344 .4026 .375 ● ● ● ●
FLAS-3R5 553205R 5 .0793 .195 .149 .344 .4026 .375 ● ● ● ●
FLAS-3L5 553205L 5 .0793 .195 .149 .344 .4026 .375
● ● ● ●
FLAS-3R4 553204R 4 .1004 .195 .149 .344 .4026 .375
● ● ● ●
FLAS-3L4 553204L 4 .1004 .195 .149 .344 .4026 .375 ● ● ● ●
FLAS-4R3 554203R 3 .1356 .255 .202 .453 .6332 .375 ● ●
FLAS-4L3 554203L 3 .1356 .255 .202 .453 .6332 .375 ● ●
FLAS-6R2 556202R 2 .2060 .383 .283 .453 .6308 .375 ●
FLAS-6L2 556202L 2 .2060 .383 .283 .453 .6308 .375 ●
In an effort to improve our stock standard grade offering, Cast Iron ▲ ●
● High performance choice in optimal conditions.
there are periodic changes. Non-Ferrous ▲ ●
Please see current price list for up to date grade offering. ▲ Recommended grade under general conditions. Stainless/High Temp ▲ ●
Steel ▲ ●
100
FLO-LOCK
PARTIAL TOPPING 3°
ACME THREADING E T
AlTiN Coated
FLA-PT (with corner radii)
TiN Coated
W
Uncoated
GAGE
For Flo-Lock acme thread limits see pg. 111,112. B DIA.
A RH Shown
Gage
GP50
AC50
GP3
AC3
Description
C3
EDP Code TPI W T E A B Dia.
FLA-3R16-PT 553016PTR 16 .0206 .195 .149 .344 .4026 .3750 ● ●
FLA-3L16-PT 553016PTL 16 .0206 .195 .149 .344 .4026 .3750 ● ●
FLA-3R14-PT 553014PTR 14 .0239 .195 .149 .344 .4026 .3750 ● ●
FLA-3L14-PT 553014PTL 14 .0239 .195 .149 .344 .4026 .3750 ● ●
FLA-3R12-PT 553012PTR 12 .0283 .195 .149 .344 .4026 .3750 ● ●
FLA-3L12-PT 553012PTL 12 .0283 .195 .149 .344 .4026 .3750 ● ●
FLA-3R10-PT 553010PTR 10 .0319 .195 .149 .344 .4026 .3750 ● ● ●
FLA-3L10-PT 553010PTL 10 .0319 .195 .149 .344 .4026 .3750 ● ● ●
FLA-3R8-PT 553008PTR 8 .0411 .195 .149 .344 .4026 .3750 ● ● ● ●
FLA-3L8-PT 553008PTL 8 .0411 .195 .149 .344 .4026 .3750 ● ● ● ●
FLA-3R6-PT 553006PTR 6 .0566 .195 .149 .344 .4026 .3750 ● ● ● ● ●
FLA-3L6-PT 553006PTL 6 .0566 .195 .149 .344 .4026 .3750 ● ● ● ● ●
FLA-3R5-PT 553005PTR 5 .0689 .195 .149 .344 .4026 .3750 ● ● ● ● ●
FLA-3L5-PT 553005PTL 5 .0689 .195 .149 .344 .4026 .3750 ● ● ● ● ●
FLA-3R4-PT 553004PTR 4 .0875 .195 .133 .344 .4018 .3750 ● ● ● ● ●
FLA-3L4-PT 553004PTL 4 .0875 .195 .133 .344 .4018 .3750 ● ● ● ● ●
FLO-LOCK
FLA-4R8-PT 554008PTR 8 .0411 .255 .202 .453 .6332 .3750 ● ●
FLA-4L8-PT 554008PTL 8 .0411 .255 .202 .453 .6332 .3750 ● ●
FLA-4R6-PT 554006PTR 6 .0566 .255 .202 .453 .6332 .3750 ● ●
FLA-4L6-PT 554006PTL 6 .0566 .255 .202 .453 .6332 .3750 ● ●
FLA-4R5-PT 554005PTR 5 .0689 .255 .202 .453 .6332 .3750 ● ●
FLA-4L5-PT 554005PTL 5 .0689 .255 .202 .453 .6332 .3750 ● ●
FLA-4R4-PT 554004PTR 4 .0875 .255 .202 .453 .6332 .3750 ● ● ● ●
FLA-4L4-PT 554004PTL 4 .0875 .255 .202 .453 .6332 .3750 ● ● ● ●
FLA-6R3-PT 556003PTR 3 .1184 .383 .283 .453 .6308 .3750 ●
FLA-6L3-PT 556003PTL 3 .1184 .383 .283 .453 .6308 .3750 ●
FLA-6R2.5-PT 556025PTR 2.5 .1431 .383 .283 .453 .6308 .3750 ●
FLA–6L2.5-PT 556025PTL 2.5 .1431 .383 .283 .453 .6308 .3750 ●
FLA-6R2-PT 556002PTR 2 .1802 .383 .283 .453 .6308 .3750 ●
FLA-6L2-PT 556002PTL 2 .1802 .383 .283 .453 .6308 .3750 ●
PARTIAL TOPPING 3°
ACME STUB THREADING
AlTiN Coated
E T
TiN Coated
Uncoated
FLAS-PT (with corner radii) W
B
GAGE
DIA.
A
RH Shown
Gage
GP50
AC50
GP3
AC3
C3
Description EDP Code TPI W T E A B Dia.
FLAS-3R16-PT 553216PTR 16 .0238 .195 .149 .344 .4026 .375
● ● ●
FLAS-3L16-PT 553216PTL 16 .0238 .195 .149 .344 .4026 .375 ● ● ●
FLAS-3R14-PT 553214PTR 14 .0276 .195 .149 .344 .4026 .375 ● ●
FLAS-3L14-PT 553214PTL 14 .0276 .195 .149 .344 .4026 .375 ● ●
FLAS-3R12-PT 553212PTR 12 .0326 .195 .149 .344 .4026 .375 ●
FLAS-3L12-PT 553212PTL 12 .0326 .195 .149 .344 .4026 .375 ●
FLAS-3R10-PT 553210PTR 10 .0370 .195 .149 .344 .4026 .375 ● ● ●
FLAS-3L10-PT 553210PTL 10 .0370 .195 .149 .344 .4026 .375 ● ● ●
FLAS-3R8-PT 553208PTR 8 .0476 .195 .149 .344 .4026 .375 ● ● ● ●
FLAS-3L8-PT 553208PTL 8 .0476 .195 .149 .344 .4026 .375 ● ● ● ●
FLAS-3R6-PT 553206PTR 6 .0652 .195 .149 .344 .4026 .375 ● ● ● ●
FLAS-3L6-PT 553206PTL 6 .0652 .195 .149 .344 .4026 .375 ● ● ● ●
FLAS-3R5-PT 553205PTR 5 .0793 .195 .149 .344 .4026 .375 ● ● ● ●
FLAS-3L5-PT 553205PTL 5 .0793 .195 .149 .344 .4026 .375
● ● ● ●
FLAS-3R4-PT 553204PTR 4 .1004 .195 .149 .344 .4026 .375
● ● ● ●
FLAS-3L4-PT 553204PTL 4 .1004 .195 .149 .344 .4026 .375 ● ● ● ●
FLAS-4R3-PT 554203PTR 3 .1356 .255 .202 .453 .6332 .375 ● ●
FLAS-4L3-PT 554203PTL 3 .1356 .255 .202 .453 .6332 .375 ● ●
FLAS-6R2-PT 556202PTR 2 .2060 .383 .283 .453 .6308 .375 ●
FLAS-6L2-PT 556202PTL 2 .2060 .383 .283 .453 .6308 .375 ●
In an effort to improve our stock standard grade offering, Cast Iron ▲ ●
● High performance choice in optimal conditions.
there are periodic changes. Non-Ferrous ▲ ●
Please see current price list for up to date grade offering. ▲ Recommended grade under general conditions. Stainless/High Temp ▲ ●
Steel ▲ ●
101
FLO-LOCK
AMERICAN STANDARD BUTTRESS 45˚
7˚ LEAD
3˚
AlTiN Coated
E T
FLTB
TiN Coated
Uncoated
7˚
R GAGE
B DIA.
For ASB specifications and application see pg. 111. A
RH Shown
GP50
AC50
Gage
GP3
AC3
C3
Description EDP Code TPI R T E A B Dia.
FLTB-2RA 602801R 16-20 .002/.004 .150 .126 .219 .2688 .1875 ● ● ● ●
FLTB-2LA 602801L 16-20 .002/.004 .150 .126 .219 .2688 .1875 ● ● ● ●
FLTB-3RA 603801R 8-16 .005/.008 .195 .164 .344 .4034 .3750 ● ● ● ●
FLTB-3LA 603801L 8-16 .005/.008 .195 .164 .344 .4034 .3750 ● ● ● ●
FLTB-4RA 604801R 4-6 .008/.012 .255 .206 .453 .6334 .3750 ● ● ● ●
FLTB-4LA 604801L 4-6 .008/.012 .255 .206 .453 .6334 .3750 ● ● ● ●
AMERICAN STANDARD BUTTRESS 7˚
45˚ LEAD E T
AlTiN Coated
FLTB R
TiN Coated
3˚
Uncoated
45˚
GAGE
B DIA.
RH Shown
FLO-LOCK
For ASB specifications and application see pg. 111. A
Gage
GP50
AC50
GP3
AC3
EDP Code TPI R T E A B Dia.
C3
Description
FLTB-2RB 602802R 16-20 .002/.004 .150 .010 .219 .2627 .1875 ● ● ● ●
FLTB-2LB 602802L 16-20 .002/.004 .150 .010 .219 .2627 .1875 ● ● ● ●
FLTB-3RB 603802R 8-16 .005/.008 .195 .012 .344 .3954 .3750 ● ● ● ●
FLTB-3LB 603802L 8-16 .005/.008 .195 .012 .344 .3954 .3750 ● ● ● ●
FLTB-4RB 604802R 4-6 .008/.012 .255 .016 .453 .6235 .3750 ● ● ● ●
FLTB-4LB 604802L 4-6 .008/.012 .255 .016 .453 .6235 .3750 ● ● ● ●
API BUTTRESS
AlTiN Coated
T
TiN Coated
THREADING
Uncoated
GAGE
FLDC B DIA.
A RH EXT Shown
GP50
AC50
Gage
GP3
AC3
C3
Description EDP Code TPI TPF T A B Dia.
FLDC-3-5B75E 553616E 5 3/4 .250 .344 .4026 .3750 ●
FLDC-3-5B75I 553616I 5 3/4 .250 .344 .4026 .3750 ●
FLDC-3-5B1E 553617E 5 1 .250 .344 .4026 .3750 ●
FLDC-3-5B1I 553617I 5 1 .250 .344 .4026 .3750 ●
FLDC-4-5B75E 554616E 5 3/4 .255 .453 .6320 .3750 ●
FLDC-4-5B75I 554616I 5 3/4 .255 .453 .6320 .3750 ●
FLDC-4-5B1E 554617E 5 1 .255 .453 .6320 .3750 ●
FLDC-4-5B1I 554617I 5 1 .255 .453 .6320 .3750 ●
E
API THREADING 60˚ T AlTiN Coated
NON TOPPING
3˚
TiN Coated
Uncoated
R. GAGE
B DIA. RH Shown
FLD A
Gage
GP50
AC50
GP3
AC3
C3
Description EDP Code TPI R E T A B Dia.
FLD-3038R 553438R 4 .033/.038 .082 .195 .344 .3991 .3750
●
FLD-3038L 553438L 4 .033/.038 .082 .195 .344 .3991 .3750 ●
FLD-3040R 553440R 5 .015/.020 .082 .195 .344 .3991 .3750 ●
FLD-3040L 553440L 5 .015/.020 .082 .195 .344 .3991 .3750 ●
FLD-4038R 554438R 4 .033/.038 .128 .255 .453 .6293 .3750 ●
FLD-4038L 554438L 4 .033/.038 .128 .255 .453 .6293 .3750 ●
FLD-4040R 554440R 5 .015/.020 .128 .255 .453 .6293 .3750 ●
FLD-4040L 554440L 5 .015/.020 .128 .255 .453 .6293 .3750
●
FLD-4050R 554450R 4 .020/.025 .128 .255 .453 .6293 .3750 ● ●
FLD-4050L 554450L 4 .020/.025 .128 .255 .453 .6293 .3750
● ●
In an effort to improve our stock standard grade offering, Cast Iron ▲ ●
● High performance choice in optimal conditions. Non-Ferrous ▲ ●
there are periodic changes.
Please see current price list for up to date grade offering. ▲ Recommended grade under general conditions. Stainless/High Temp ▲ ●
Steel ▲
102
FLO-LOCK
E
API ROTARY SHOULDER
AlTiN Coated
TiN Coated
60˚ T
CONNECTION THREADING 3˚
B
GAGE
FLDC
DIA.
RH EXT Shown
A
Gage Conn. No.
GP50
AC22
AC50
GP3
AC3
Description EDP Code TPI TPF E T A B Dia. or Size
FLDC-3-530E 553613E 5 3 .147 .250 .344 .4026 .3750 3-1/2 FH, 2-3/8-4-1/2 Reg. ●
FLDC-3-530I 553613I 5 3 .147 .250 .344 .4026 .3750 3-1/2 FH, 2-3/8-4-1/2 Reg. ●
FLDC-4-425E 554609E 4 2 .183 .312 .453 .6320 .3750 5-1/2 FH, 6-5/8 FH & Reg. ● ● ●
FLDC-4-425I 554609I 4 2 .183 .312 .453 .6320 .3750 5-1/2 FH, 6-5/8 FH & Reg. ● ● ●
FLDC-4-428E 554610E 4 2 .183 .312 .453 .6320 .3750 NC23-NC50, 2-3/8-5-1/2IF ● ● ●
FLDC-4-428I 554610I 4 2 .183 .312 .453 .6320 .3750 NC23-NC50, 2-3/8-5-1/2IF ● ● ●
FLDC-4-435E 554611E 4 3 .183 .312 .453 .6320 .3750 5-1/2, 7-5/8, 8-5/8 Reg. ●
FLDC-4-435I 554611I 4 3 .183 .312 .453 .6320 .3750 5-1/2, 7-5/8, 8-5/8 Reg. ●
FLDC-4-438E 554612E 4 3 .183 .312 .453 .6320 .3750 NC56 - NC71 ●
FLDC-4-438I 554612I 4 3 .183 .312 .453 .6320 .3750 NC56 - NC71 ●
E
API ROUND THREADING T
AlTiN Coated
60˚
TiN Coated
FLDC
Uncoated
GAGE
B DIA.
A RH Shown
Gage
GP50
AC50
GP3
AC3
C3
Description EDP Code TPI TPF E T A B Dia.
FLO-LOCK
FLDC-3-8RDR75 553632R 8 3/4 .195 .125 .344 .4010 .3750 ● ● ●
FLDC-3-8RDL75 553632L 8 3/4 .195 .125 .344 .4010 .3750 ● ● ●
FLDC-3-10RDR75 553634R 10 3/4 .195 .125 .344 .4010 .3750 ● ● ●
FLDC-3-10RDL75 553634L 10 3/4 .195 .125 .344 .4010 .3750 ● ● ●
E
FLDC
AlTiN Coated
60˚ T
TiN Coated
with chipbreaker
Uncoated
3˚
ign!
nted des
GAGE
e pate
B DIA.
Exclusiv A
RH Shown
Gage
GP50
AC50
GP3
AC3
C3
Description EDP Code TPI TPF E T A B Dia.
FLDC-3-8RDR75-CB 553632PR 8 3/4 .195 .125 .344 .4010 .3750 ● ● ●
FLDC-3-8RDL75-CB 553632PL 8 3/4 .195 .125 .344 .4010 .3750 ● ● ●
E
FLDC
AlTiN Coated
60˚
TiN Coated
T
Multi-tooth
Uncoated
GAGE
B DIA.
RH Shown
A
Gage
GP50
AC50
GP3
AC3
Description EDP Code TPI TPF E T A B Dia.
FLDC-6-8RDR75M 556633R 8 3/4 .070 .383 .453 .6360 C3
.3750
FLDC-6-10RDR75M 556635R 10 3/4 .134 .383 .453 .6360 .3750
E
NPT THREADING 60˚ T
AlTiN Coated
TiN Coated
Uncoated
FLDC 3˚
GAGE
B DIA.
A
RH Shown
Gage
GP50
AC50
GP3
AC3
C3
Description EDP Code TPI TPF E T A B Dia.
FLDC-38VR-75 553608R 8 3/4 .100 .195 .344 .4000 .3750
● ● ●
FLDC-38VL-75 553608L 8 3/4 .100 .195 .344 .4000 .3750 ● ● ●
FLDC-3115VR-75 553611R 11.5 3/4 .144 .195 .344 .4000 .3750 ● ● ●
FLDC-3115VL-75 553611L 11.5 3/4 .144 .195 .344 .4000 .3750 ● ● ●
FLDC-314VR-75 553614R 14 3/4 .148 .195 .344 .4023 .3750 ● ● ●
FLDC-314VL-75 553614L 14 3/4 .148 .195 .344 .4023 .3750
● ● ●
FLDC-318VR-75 553618R 18 3/4 .154 .195 .344 .4023 .3750 ● ● ●
FLDC-318VL-75 553618L 18 3/4 .154 .195 .344 .4023 .3750 ● ● ●
FLDC-327VR-75 553627R 27 3/4 .162 .195 .344 .4023 .3750 ● ● ●
FLDC-327VL-75 553627L 27 3/4 .162 .195 .344 .4023 .3750
● ● ●
In an effort to improve our stock standard grade offering, Cast Iron ●
there are periodic changes.
● High performance choice in optimal conditions. Non-Ferrous ●
Please see current price list for up to date grade offering. ▲ Recommended grade under general conditions. Stainless/High Temp ●
Steel ▲ ●
103
FLO-LOCK
NPT THREADING 60˚
E
T
FLDC
AlTiN Coated
TiN Coated
Uncoated
Multi-tooth B
GAGE
DIA.
RH Shown
Gage
GP50
AC50
GP3
AC3
C3
Description EDP Code TPI TPF E T A B Dia.
FLDC-3-8 NPT-2E 553708E 8 3/4 .058 .250 .344 .4050 .3750 ● ● ●
FLDC -3-8 NPT-2I 553708I 8 3/4 .058 .250 .344 .4050 .3750 ● ● ●
FLDC-3-11.5 NPT-2E 553711E 11.5 3/4 .048 .250 .344 .4050 .3750 ● ●
FLDC-3-11.5 NPT-2I 553711I 11.5 3/4 .048 .250 .344 .4050 .3750 ● ●
UNJ THREADING
E
60˚ T
FLJ
AlTiN Coated
TiN Coated
3˚
Uncoated
R
GAGE RH Shown
B DIA.
Gage
GP50
AC50
GP3
AC3
C3
Description EDP Code TPI R E T A B Dia.
FLJ-3010R16 583216R 16 .0094/.0104 .098 .195 .344 .3999 .3750
● ● ●
FLJ-3010L16 583216L 16 .0094/.0104 .098 .195 .344 .3999 .3750 ● ● ●
FLJ-3014R12 583212R 12 .0125/.0135 .098 .195 .344 .3999 .3750 ● ● ●
FLO-LOCK
FLJ-3014L12 583212L 12 .0125/.0135 .098 .195 .344 .3999 .3750
● ● ●
FLJ-3020R8 583208R 8 .0188/.0198 .098 .195 .344 .3999 .3750 ● ● ●
FLJ-3020L8 583208L 8 .0188/.0198 .098 .195 .344 .3999 .3750 ● ● ●
UNJ THREADING 60˚ T
AlTiN Coated
FLJP 3˚
TiN Coated
R
Uncoated
RH Shown
Positive rake 5˚
B
GAGE
DIA.
Gage
GP50
AC50
GP3
AC3
C3
Description EDP Code TPI R E T A B Dia.
FLJP-3010R16 583816R 16 .0094/.0104 .098 .195 .344 .3999 .3750
● ● ●
FLJP-3010L16 583816L 16 .0094/.0104 .098 .195 .344 .3999 .3750 ● ● ●
FLJP-3014R12 583812R 12 .0125/.0135 .098 .195 .344 .3999 .3750 ● ● ●
FLJP-3014L12 583812L 12 .0125/.0135 .098 .195 .344 .3999 .3750
● ● ●
FLJP-3020R8 583808R 8 .0188/.0198 .098 .195 .344 .3999 .3750 ● ● ●
FLJP-3020L8 583808L 8 .0188/.0198 .098 .195 .344 .3999 .3750 ● ● ●
UNJ FINE PITCH THREADING E
FLJF 60˚ T
AlTiN Coated
For cutting close to shoulder
TiN Coated
3˚
Uncoated
R GAGE RH Shown
B DIA.
Gage
GP50
AC50
GP3
AC3
C3
Description EDP Code TPI R E T A B Dia.
FLJF-3005R32 583432R 32 .0047/.0057 .141 .195 .344 .4022 .3750
● ● ●
FLJF-3005L32 583432L 32 .0047/.0057 .141 .195 .344 .4022 .3750 ● ● ●
FLJF-3006R28 583428R 28 .0054/.0064 .141 .195 .344 .4022 .3750 ● ● ●
FLJF-3006L28 583428L 28 .0054/.0064 .141 .195 .344 .4022 .3750
● ● ●
FLJF-3007R24 583424R 24 .0063/.0073 .141 .195 .344 .4022 .3750 ● ● ●
FLJF-3007L24 583424L 24 .0063/.0073 .141 .195 .344 .4022 .3750
● ● ●
FLJF-3008R20 583420R 20 .0075/.0085 .141 .195 .344 .4022 .3750 ● ● ●
FLJF-3008L20 583420L 20 .0075/.0085 .141 .195 .344 .4022 .3750
● ● ●
FLJF-3009R18 583418R 18 .0083/.0093 .141 .195 .344 .4022 .3750 ● ● ●
FLJF-3009L18 583418L 18 .0083/.0093 .141 .195 .344 .4022 .3750
● ● ●
FLJF-3010R16 583416R 16 .0094/.0104 .141 .195 .344 .4022 .3750 ● ● ●
FLJF-3010L16 583416L 16 .0094/.0104 .141 .195 .344 .4022 .3750
● ● ●
FLJF-3012R14 583414R 14 .0107/.0117 .141 .195 .344 .4022 .3750 ● ● ●
FLJF-3012L14 583414L 14 .0107/.0117 .141 .195 .344 .4022 .3750 ● ● ●
In an effort to improve our stock standard grade offering, Cast Iron ▲ ●
there are periodic changes.
● High performance choice in optimal conditions. Non-Ferrous ▲ ●
Please see current price list for up to date grade offering. ▲ Recommended grade under general conditions. Stainless/High Temp ▲ ●
Steel ▲
104
FLO-LOCK
UNJ FINE PITCH E
AC50 AlTiN Coated
60˚ T
THREADING
TiN Coated
Uncoated
3˚
R
RH Shown
FLJK 5˚
B
GAGE
DIA.
Positive rake A
Gage
GP50
GP3
AC3
C3
Description EDP Code TPI R E T A B Dia.
FLJK-3005R32 583632R 32 .0047/.0057 .141 .195 .344 .4022 .3750
● ● ● ●
FLJK-3005L32 583632L 32 .0047/.0057 .141 .195 .344 .4022 .3750 ● ● ● ●
FLJK-3006R28 583628R 28 .0054/.0064 .141 .195 .344 .4022 .3750 ● ● ●
FLJK-3006L28 583628L 28 .0054/.0064 .141 .195 .344 .4022 .3750
● ● ●
FLJK-3007R24 583624R 24 .0063/.0073 .141 .195 .344 .4022 .3750 ● ● ●
FLJK-3007L24 583624L 24 .0063/.0073 .141 .195 .344 .4022 .3750
● ● ●
FLJK-3008R20 583620R 20 .0075/.0085 .141 .195 .344 .4022 .3750 ● ● ●
FLJK-3008L20 583620L 20 .0075/.0085 .141 .195 .344 .4022 .3750
● ● ●
FLJK-3009R18 583618R 18 .0083/.0093 .141 .195 .344 .4022 .3750 ● ● ●
FLJK-3009L18 583618L 18 .0083/.0093 .141 .195 .344 .4022 .3750
● ● ●
FLJK-3010R16 583616R 16 .0094/.0104 .141 .195 .344 .4022 .3750 ● ● ●
FLJK-3010L16 583616L 16 .0094/.0104 .141 .195 .344 .4022 .3750
● ● ●
FLJK-3012R14 583614R 14 .0107/.0117 .141 .195 .344 .4022 .3750 ● ● ●
FLJK-3012L14 583614L 14 .0107/.0117 .141 .195 .344 .4022 .3750 ● ● ●
UN THREADING E H
AlTiN Coated
TiN Coated
60˚ T
Uncoated
FLTC R
3˚
GAGE
RH EXT Shown
Crest topping B DIA.
A Gage
GP50
AC50
FLO-LOCK
GP3
AC3
C3
Description EDP Code TPI R E H T A B Dia.
FLTC-3R7E 613007R 7 .017 .107 .108 .195 .344 .4004 .3750
● ● ●
FLTC-3L7E 613007L 7 .017 .107 .108 .195 .344 .4004 .3750 ● ● ●
FLTC-3R7I 613207R 7 .009 .107 .092 .195 .344 .4004 .3750 ● ● ●
FLTC-3L7I 613207L 7 .009 .107 .092 .195 .344 .4004 .3750
● ● ●
FLTC-3R8E 613008R 8 .015 .107 .094 .195 .344 .4004 .3750 ● ● ●
FLTC-3L8E 613008L 8 .015 .107 .094 .195 .344 .4004 .3750
● ● ●
FLTC-3R8I 613208R 8 .007 .107 .081 195 .344 .4004 .3750 ● ● ●
FLTC-3L8I 613208L 8 .007 .107 .081 .195 .344 .4004 .3750
● ● ●
FLTC-3R9E 613009R 9 .013 .107 .084 .195 .344 .4004 .3750 ● ● ●
FLTC-3L9E 613009L 9 .013 .107 .084 .195 .344 .4004 .3750
● ● ●
FLTC-3R9I 613209R 9 .006 .107 .072 .195 .344 .4004 .3750 ● ● ●
FLTC-3L9I 613209L 9 .006 .107 .072 .195 .344 .4004 .3750
● ● ●
FLTC-3R10E 613010R 10 .012 .107 .076 .195 .344 .4004 .3750 ● ● ●
FLTC-3L10E 613010L 10 .012 .107 .076 .195 .344 .4004 .3750 ● ● ●
FLTC-3R10I 613210R 10 .005 .107 .065 .195 .344 .4004 .3750 ● ● ●
FLTC-3L10I 613210L 10 .005 .107 .065 .195 .344 .4004 .3750
● ● ●
FLTC-3R11E 613011R 11 .011 .107 .069 .195 .344 .4004 .3750 ● ● ●
FLTC-3L11E 613011L 11 .011 .107 .069 .195 .344 .4004 .3750
● ● ●
FLTC-3R11I 613211R 11 .005 .107 .059 .195 .344 .4004 .3750 ● ● ●
FLTC-3L11I 613211L 11 .005 .107 .059 .195 .344 .4004 .3750
● ● ●
FLTC-3R12E 613012R 12 .010 .148 .051 .195 .344 .4025 .3750 ● ● ●
FLTC-3L12E 613012L 12 .010 .148 .051 .195 .344 .4025 .3750
● ● ●
FLTC-3R12I 613212R 12 .004 .148 .048 .195 .344 .4025 .3750 ● ● ●
FLTC-3L12I 613212L 12 .004 .148 .048 .195 .344 .4025 .3750
● ● ●
FLTC-3R14E 613014R 14 .009 .148 .054 .195 .344 .4025 .3750 ● ● ●
FLTC-3L14E 613014L 14 .009 .148 .054 .195 .344 .4025 .3750
● ● ●
FLTC-3R14I 613214R 14 .003 .148 .044 .195 .344 .4025 .3750 ● ● ●
FLTC-3L14I 613214L 14 .003 .148 .044 .195 .344 .4025 .3750
● ● ●
FLTC-3R16E 613016R 16 .008 .148 .046 .195 .344 .4025 .3750 ● ● ●
FLTC-3L16E 613016L 16 .008 .148 .046 .195 .344 .4025 .3750
● ● ●
FLTC-3R16I 613216R 16 .003 .148 .040 .195 .344 .4025 .3750 ● ● ●
FLTC-3L16I 613216L 16 .003 .148 .040 .195 .344 .4025 .3750
● ● ●
FLTC-3R18E 613018R 18 .007 .148 .041 .195 .344 .4025 .3750 ● ● ●
FLTC-3L18E 613018L 18 .007 .148 .041 .195 .344 .4025 .3750
● ● ●
FLTC-3R18I 613218R 18 .003 .148 .036 .195 .344 .4025 .3750 ● ● ●
FLTC-3L18I 613218L 18 .003 .148 .036 .195 .344 .4025 .3750
● ● ●
FLTC-3R20E 613020R 20 .006 .148 .037 .195 .344 .4025 .3750 ● ● ●
FLTC-3L20E 613020L 20 .006 .148 .037 .195 .344 .4025 .3750 ● ●
FLTC-3R20I 613220R 20 .003 .148 .031 .195 .344 .4025 .3750 ● ●
FLTC-3L20I 613220L 20 .003 .148 .031 .195 .344 .4025 .3750 ●
FLTC-3R24E 613024R 24 .005 .148 .031 .195 .344 .4025 .3750 ● ●
FLTC-3L24E 613024L 24 .005 .148 .031 .195 .344 .4025 .3750
● ●
FLTC-3R24I 613224R 24 .003 .148 .026 .195 .344 .4025 .3750 ●
FLTC-3L24I 613224L 24 .003 .148 .026 .195 .344 .4025 .3750
FLTC-3R28* 613028R 28 .003 .148 .023 .195 .344 .4025 .3750 ● ●
FLTC-3L28* 613028L 28 .003 .148 .023 .195 .344 .4025 .3750 ●
FLTC-3R32* 613032R 32 .003 .148 .021 .195 .344 .4025 .3750 ●
FLTC-3L32* 613032L 32 .003 .148 .021 .195 .344 .4025 .3750
*Will work for either internal or external.
In an effort to improve our stock standard grade offering, Cast Iron ▲ ●
● High performance choice in optimal conditions. Non-Ferrous ▲ ●
there are periodic changes.
Please see current price list for up to date grade offering. ▲ Recommended grade under general conditions. Stainless/High Temp ▲ ●
Steel ▲ ●
105
FLO-LOCK
E
60˚ V-THREADING
AlTiN Coated
TiN Coated
T
Uncoated
60˚
FLTF R
3˚
GAGE
RH Shown
B
Fine pitch
DIA.
A
For 60˚V-thread limits see pg. 112.
GP520
TPI Gage
GP50
AC50
GP3
GP4
AC3
C25
Description EDP Code Int Ext R E T A B Dia.
FLTF-2R 612400R 12-24 14-44 .002/.004 .110 .150 .219 .2679 .1875 ● ● ● ● ●
FLTF-2L 612400L 12-24 14-44 .002/.004 .110 .150 .219 .2679 .1875 ● ● ● ● ●
FLTF-3R 613400R 9-24 10-44 .002/.004 .141 .195 .344 .4022 .3750 ● ● ● ● ●
FLTF-3L 613400L 9-24 10-44 .002/.004 .141 .195 .344 .4022 .3750 ● ● ● ● ●
FLTF-4R 614400R 9-24 10-44 .002/.004 .201 .255 .453 .6322 .3750 ● ● ● ● ●
FLTF-4L 614400L 9-24 10-44 .002/.004 .201 .255 .453 .6322 .3750 ● ● ● ● ●
60˚ V-THREADING
AlTiN Coated
60˚ T
TiN Coated
FLTK
Uncoated
3˚
R
B
GAGE
RH Shown
Positive rake 5˚
DIA.
GP520
TPI Gage
GP50
AC50
GP3
GP4
AC3
C25
Description EDP Code Int Ext R E T A B Dia.
FLTK-2R 612600R 12-24 14-44 .002/.004 .110 .150 .219 .2679 .1875 ● ● ● ● ●
FLTK-2L 612600L 12-24 14-44 .002/.004 .110 .150 .219 .2679 .1875 ● ● ● ● ●
FLO-LOCK
FLTK-3R 613600R 9-24 10-44 .002/.004 .141 .195 .344 .4022 .3750 ● ● ● ● ●
FLTK-3L 613600L 9-24 10-44 .002/.004 .141 .195 .344 .4022 .3750 ● ● ● ● ●
FLTK-4R 614600R 9-24 10-44 .002/.004 .201 .255 .453 .6322 .3750 ● ● ● ● ●
FLTK-4L 614600L 9-24 10-44 .002/.004 .201 .255 .453 .6322 .3750 ● ● ● ● ●
60˚ V-THREADING - CHIP-FLO
FLT-CB nted des
ign!
e pate
Features: Exclusiv E
AlTiN Coated
• Patented chipbreaker - Patent No. 6,146,064
TiN Coated
60˚ T
Uncoated
• Maximum chip control
3˚
R
B
GAGE
DIA.
RH Shown
• Fewer scarred threads A
• For coarse and fine pitches
GP520
GP22
GP50
AC22
AC50
TPI Gage
GP4
AC3
C25
C3
Description EDP Code Int Ext R E T A B Dia.
FLT-3R-HCB 603600HCR 5-12 6-20 .005/.008 .098 .195 .344 .3999 .3750 ● ● ● ● ● ● ●
FLT-3L-HCB 603600HCL 5-12 6-20 .005/.008 .098 .195 .344 .3999 .3750 ● ●● ● ● ● ●
FLT-3RC-HCB 603612HCR 5-6 6-11 .012/.015 .098 .195 .344 .3999 .3750 ● ● ● ● ●
FLT-3LC-HCB 603612HCL 5-6 6-11 .012/.015 .098 .195 .344 .3999 .3750 ● ● ● ● ●
FLT-3R-CB 603600CR 8-12 8-20 .005/.008 .098 .195 .344 .3999 .3750 ● ●● ● ● ● ●
FLT-3L-CB 603600CL 8-12 8-20 .005/.008 .098 .195 .344 .3999 .3750 ● ●● ● ● ● ●
FLT-3R-FCB 603600FCR 7-20 8-36 .003/.005 .098 .195 .344 .3999 .3750 ● ●● ● ● ● ●
FLT-3L-FCB 603600FCL 7-20 8-36 .003/.005 .098 .195 .344 .3999 .3750 ● ●● ● ● ● ●
FLT-4R-HCB 604600HCR 4-12 4-20 .005/.008 .128 .255 .453 .6298 .3750 ●● ● ● ● ● ●
FLT-4L-HCB 604600HCL 4-12 4-20 .005/.008 .128 .255 .453 .6298 .3750 ●● ● ● ● ● ●
60˚ V-THREADING E
FLT
AlTiN Coated
60˚ T
TiN Coated
Uncoated
3˚
R
GAGE RH Shown
For 60˚V-thread limits see pg. 112. B DIA.
A
GP520
GP50
AC22
AC50
TPI Gage
GP3
GP4
AC3
C25
Description EDP Code Int Ext R E T A B Dia.
FLT-2R 602600R 7-20 8-36 .003/.005 .075 .150 .219 .2661 .1875 ● ● ● ● ● ● ●
FLT-2L 602600L 7-20 8-36 .003/.005 .075 .150 .219 .2661 .1875 ● ● ● ● ● ● ●
FLT-3R 603600R 5-12 6-20 .005/.008 .098 .195 .344 .3999 .3750 ● ● ● ● ● ● ● ●
FLT-3L 603600L 5-12 6-20 .005/.008 .098 .195 .344 .3999 .3750 ● ● ● ● ● ● ● ●
FLT-3010R 603610R 5-12 6-18 .009/.011 .098 .195 .344 .3999 .3750 ● ● ● ●
FLT-3010L 603610L 5-12 6-18 .009/.011 .098 .195 .344 .3999 .3750 ● ● ● ●
FLT-4R 604600R 4-12 4-20 .005/.008 .128 .255 .453 .6298 .3750 ● ● ● ● ●
FLT-4L 604600L 4-12 4-20 .005/.008 .128 .255 .453 .6298 .3750 ● ● ● ● ●
In an effort to improve our stock standard grade offering, Cast Iron ▲ ●
there are periodic changes.
● High performance choice in optimal conditions. Non-Ferrous ▲ ●
Please see current price list for up to date grade offering. ▲ Recommended grade under general conditions. Stainless/High Temp ▲ ●
Steel
106
▲ ▲ ●
FLO-LOCK
60˚ V-THREADING
E
AC50 AlTiN Coated
60˚ T
TiN Coated
FLTP
C25 Uncoated
3˚
R
RH Shown
Positive rake 5˚
B
GAGE
DIA.
For 60˚V-thread limits see pg.
112. A
TPI Gage
GP50
GP3
AC3
Description EDP Code Int Ext R E T A B Dia.
FLTP-2R 612800R 7-20 8-36 .003/.005 .075 .150 .219 .2661 .1875 ● ● ● ● ●
FLTP-2L 612800L 7-20 8-36 .003/.005 .075 .150 .219 .2661 .1875 ● ● ● ● ●
FLTP-3R 613800R 5-12 6-20 .005/.008 .098 .195 .344 .3999 .3750 ● ● ● ● ●
FLTP-3L 613800L 5-12 6-20 .005/.008 .098 .195 .344 .3999 .3750 ● ● ● ● ●
FLTP-4R 614800R 4-12 4-20 .005/.008 .128 .255 .453 .6293 .3750 ● ● ● ● ●
FLTP-4L 614800L 4-12 4-20 .005/.008 .128 .255 .453 .6293 .3750 ● ● ● ● ●
AlTiN Coated
W
UNDERCUTTING
T
TiN Coated
Uncoated
R E
FLU B
GAGE
DIA.
RH Shown
For use in FLRR/L holders
A
W Gage
GP50
AC50
GP3
AC3
C3
Description EDP Code Inch Metric R E T A B Dia.
FLU-3094R 623094R .094 2,39 .020 .125 .195 .344 .4050 .3750 ● ● ●
FLU-3094L 623094L .094 2,39 .020 .125 .195 .344 .4050 .3750 ● ● ●
FLU-3125R 623125R .125 3,18 .047 .188 .195 .344 .4050 .3750 ● ●
FLU-3125L 623125L .125 3,18 .047 .188 .195 .344 .4050 .3750 ● ●
FLU-3156R 623156R .156 3,96 .047 .188 .195 .344 .4050 .3750 ● ●
FLU-3156L 623156L .156 3,96 .047 .188 .195 .344 .4050 .3750 ●
FLO-LOCK
●
E H
AlTiN Coated
POLY-V
TiN Coated
40˚ T
C25 Uncoated
FLV R 3˚
R1 GAGE
RH Shown
B DIA.
A
Gage
GP50
AC50
GP3
AC3
Description EDP Code R R1 E T H A B Dia.
FLV-3RJ 623800R .012 .008 .125 .195 .087 .344 .4013 .3750 ● ● ● ●
FLV-3LJ 623800L .012 .008 .125 .195 .087 .344 .4013 .3750 ● ● ● ●
FLV-4RL 624800R .012 .015 .118 .255 .201 .453 .6288 .3750 ● ● ●
FLV-4LL 624800L .012 .015 .118 .255 .201 .453 .6288 .3750 ● ● ●
In an effort to improve our stock standard grade offering, Cast Iron ▲ ●
there are periodic changes.
● High performance choice in optimal conditions. Non-Ferrous ▲ ●
Please see current price list for up to date grade offering. ▲ Recommended grade under general conditions. Stainless/High Temp ▲ ●
EXTERNAL HOLDER
Steel ▲ ●
(INCH) D
FLSR/L F
3°
A B
Threading and Grooving C C
RH SHOWN
Most holders
available with coolant port (ie: Add CP to end of description) Seat Clamp
Description EDP Code Insert A B C D F* Seat Screw Clamp Screw
FLSR-62 93400608C FL_-2R 3/8 3/8 2-1/2 .14 .562 - - TF-74 S-310
FLSL-62 93300608C FL_-2L 3/8 3/8 2-1/2 .14 .562 - - TF-75 S-310
FLSR-82V 93400808V FL_-2R 1/2 1/2 3-1/2 .14 .750 - - TF-74 S-310
FLSL-82V 93300808V FL_-2L 1/2 1/2 3-1/2 .14 .750 - - TF-75 S-310
FLSR-102B 93401008B FL_-2R 5/8 5/8 4-1/2 .14 1.000 - - TF-74 S-310
FLSR-122B 93401208B FL_-2R 3/4 3/4 4-1/2 .14 1.000 - - TF-74 S-310
FLSL-122B 93301208B FL_-2L 3/4 3/4 4-1/2 .14 1.000 - - TF-75 S-310
FLSR-162C 93401608C FL_-2R 1 1.000 5 .14 1.250 - - TF-74 S-310
FLSL-162C 93301608C FL_-2L 1 1.000 5 .14 1.250 - - TF-75 S-310
FLSR-123B 93401216B FL_-3R 3/4 3/4 4-1/2 .21 1.000 - - TF-72 S-412
FLSL-123B 93301216B FL_-3L 3/4 3/4 4-1/2 .21 1.000 - - TF-73 S-412
FLSR-163C 93401616C FL_-3R 1 1 5 .21 1.250 - - TF-72 S-412
FLSL-163C 93301616C FL_-3L 1 1 5 .21 1.250 - - TF-73 S-412
FLSR-163D 93401616D FL_-3R 1 1 6 .21 1.250 - - TF-72 S-412
FLSL-163D 93301616D FL_-3L 1 1 6 .21 1.250 - - TF-73 S-412
FLSR-203D 93402016D FL_-3R 1-1/4 1-1/4 6 .21 1.500 - - TF-72 S-412
FLSL-203D 93302016D FL_-3L 1-1/4 1-1/4 6 .21 1.500 - - TF-73 S-412
FLSR-164D 93401620D FL_-4R 1 1 6 .29 1.250 SM-420 SL-344 TF-72 S-412
FLSL-164D 93301620D FL_-4L 1 1 6 .29 1.250 SM-420 SL-344 TF-73 S-412
FLSR-204D 93402020D FL_-4R 1-1/4 1-1/4 6 .29 1.500 SM-420 SL-344 TF-72 S-412
FLSL-204D 93302020D FL_-4L 1-1/4 1-1/4 6 .29 1.500 SM-420 SL-344 TF-73 S-412
FLSR-205D 93402024D FL_-5R 1-1/4 1-1/4 6 .40 1.500 - - TF-80 S-352
FLSL-205D 93302024D FL_-5L 1-1/4 1-1/4 6 .40 1.500 - - TF-81 S-352
FLSR-206D 93402028D FL_-6R 1-1/4 1-1/4 6 .29 1.500 SM-416 S-111 TF-120 S-412
FLSL-206D 93302028D FL_-6L 1-1/4 1-1/4 6 .29 1.500 SM-416 S-111 TF-121 S-412
* “F” Dim. over sharp point of grooving insert.
107
FLO-LOCK
EXTERNAL HOLDER
(METRIC) D
FLSR/L F
3°
A B
Threading and Grooving C C RH SHOWN
Most holders
available with coolant port (ie: Add CP to end of description) Seat Clamp
Description EDP Code Insert A B C D F* Seat Screw Clamp Screw
FLSR-2020M2 93412008 FL_-2R 20,0 20,0 125,0 3,0 25,0 - - TF-74 S-310
FLSL-2020M2 93312008 FL_-2L 20,0 20,0 125,0 3,0 25,0 - - TF-75 S-310
FLSR-2525M2 93412508 FL_-2R 25,0 25,0 150,0 3,0 32,0 - - TF-74 S-310
FLSL-2525M2 93312508 FL_-2L 25,0 25,0 150,0 3,0 32,0 - - TF-75 S-310
FLSR-2020M3 93412016 FL_-3R 20,0 20,0 125,0 5,0 32,0 - - TF-72 S-412
FLSL-2020M3 93312016 FL_-3L 20,0 20,0 125,0 5,0 32,0 - - TF-73 S-412
FLSR-2525M3 93412516 FL_-3R 25,0 25,0 150,0 5,0 32,0 - - TF-72 S-412
FLSL-2525M3 93312516 FL_-3L 25,0 25,0 150,0 5,0 32,0 - - TF-73 S-412
* “F” Dim. over sharp point of grooving insert.
EXTERNAL HOLDER
(INCH) 3°
FLER/L F A B
Threading and Grooving H
RH SHOWN
FLO-LOCK
D
C C
RH SHOWN
Most holders available with coolant port (ie: Add CP to end of description)
Clamp
Description EDP Code Insert A B C D F* H Clamp Screw
FLER-82V 93100808V FL_-2L 1/2 1/2 3-1/2 .14 .750 1 TF-75 S-310
FLER-122B 93101208B FL_-2L 3/4 3/4 4-1/2 .14 1.000 1 TF-75 S-310
FLEL-122B 93001208B FL_-2R 3/4 3/4 4-1/2 .14 1.000 1 TF-74 S-310
FLER-162C 93101608C FL_-2L 1 1 5 .14 1.250 1 TF-75 S-310
FLEL-162C 93001608C FL_-2R 1 1 5 .14 1.250 1 TF-74 S-310
FLER-123B 93101216B FL_-3L 3/4 3/4 4-1/2 .21 1.125 2 TF-73 S-412
FLEL-123B 93001216B FL_-3R 3/4 3/4 4-1/2 .21 1.125 2 TF-72 S-412
FLER-163D 93101616D FL_-3L 1 1 6.000 .21 1.250 2 TF-73 S-412
FLEL-163D 93001616D FL_-3R 1 1 6.000 .21 1.250 2 TF-72 S-412
FLER-203D 93102016D FL_-3L 1-1/4 1-1/4 6.000 .21 1.500 2 TF-73 S-412
FLEL-203D 93002016D FL_-3R 1-1/4 1-1/4 6.000 .21 1.500 2 TF-72 S-412
FLER-164D 93101620D FL_-4L 1 1 6.000 .29 1.375 2 TF-73 S-412
FLEL-164D 93001620D FL_-4R 1 1 6.000 .29 1.375 2 TF-72 S-412
FLER-204D 93102020D FL_-4L 1-1/4 1-1/4 6.000 .29 1.625 2 TF-73 S-412
FLEL-204D 93002020D FL_-4R 1-1/4 1-1/4 6.000 .29 1.625 2 TF-72 S-412
FLER-205D 93102024D FL_-5L 1-1/4 1-1/4 6.000 .29 2.000 2 TF-81 S-352
FLEL-205D 93002024D FL_-5R 1-1/4 1-1/4 6.000 .29 2.000 2 TF-80 S-352
FLER-206D 93102028D FL_-6L 1-1/4 1-1/4 6.000 .29 1.625 2 TF-121 S-412
FLEL-206D 93002028D FL_-6R 1-1/4 1-1/4 6.000 .29 1.625 2 TF-120 S-412
* C&F measured over sharp point of grooving insert
EXTERNAL HOLDER
(INCH) r Swiss
machine
s
FLASR/L Design fo D
Threading and Grooving B
F A
3˚
RH SHOWN
C C
Most holders available with coolant port (ie: Add CP to end of description)
Clamp
Description EDP Code Insert A B C D F Clamp Screw
FLASR-062D 92900608D FL_-2R 3/8 3/8 6 .138 .375 TF-182 S-310
FLASL-062D 92650608D FL_-2L 3/8 3/8 6 .138 .375 TF-183 S-310
FLASR-082D 92900808D FL_-2R 1/2 1/2 6 .138 .500 TF-182 S-310
FLASL-082D 92650808D FL_-2L 1/2 1/2 6 .138 .500 TF-183 S-310
FLASR-102B 92901008B FL_-2R 5/8 5/8 4-1/2 .138 .625 TF-184 S-412
FLASR-83D 92900816D FL_-3R 1/2 1/2 6 .210 .614 TF-184 S-412
FLASL-83D 92900816D FL_-3L 1/2 1/2 6 .210 .614 TF-184 S-412
FLASR-103B 92901016B FL_-3R 5/8 5/8 4-1/2 .210 .625 TF-184 S-412
FLASL-103B 92891016B FL_-3L 5/8 5/8 4-1/2 .210 .625 TF-185 S-412
* “F” Dim. over sharp point of grooving insert.
108
FLO-LOCK
EXTERNAL HOLDER (METRIC)
D
FLASR/L s machin
es F A B
r Swis 3˚
Threading and Grooving Design fo C C
RH SHOWN
Most holders available with coolant port (ie: Add CP to end of description)
Clamp
Description EDP Code Insert A B C D F Clamp Screw
FLASR-1010M2 92711008 FL_-2R 10,0 10,0 150,0 3,51 10,0 TF-182 S-310
FLASL-1010M2 92661008 FL_-2L 10,0 10,0 150,0 3,51 10,0 TF-183 S-310
FLASR-1212M2 92711208 FL_-2R 12,0 12,0 150,0 3,51 12,0 TF-182 S-310
FLASL-1212M2 92661208 FL_-2L 12,0 12,0 150,0
45˚ 3,51 12,0 TF-183 S-310
FLASR-1616M2 92711608 FL_-2R 16,0 16,0 150,0 3,51 16,0 TF-184 S-412
A
FLASR-1616M3 92711616 FL_-3R 16,0 16,0 F
125,0 5,31 16,0 TF-184 S-412
FLASL-1616M3 92661616 FL_-3L 16,0 16,0 125,0
E
5,31 16,0 TF-185 S-412
EXTERNAL HOLDER (INCH) 45˚ C
FLRR/L F A
B
Undercutting E
RH SHOWN
C
Most holders available with coolant port
(ie: Add CP to end of description) Clamp
Description EDP Code Insert A B C E F Clamp Screw
B
FLRR-123B 93201216B FLU-3L 3/4 3/4 4-1/2 1-1/4 1.000 TF-73 S-412
FLRL-123B 93181216B FLU-3R 3/4 3/4 4-1/2 1-1/4 1.000 TF-72 S-412
FLRR-163D 93201616D FLU-3L 1 1 6 1-1/4 1.250 TF-73 S-412
FLRL-163D 93181616D FLU-3R 1 1 6 1-1/4 1.250 TF-72 S-412
FLRR-203D 93202016D FLU-3L 1-1/4 1-1/4 6 1-1/4 1.500 TF-73 S-412
FLO-LOCK
FLRL-203D 93182016D FLU-3R 1-1/4 1-1/4 6 1-1/4 1.500 TF-72 S-412
INTERNAL HOLDER (INCH) 3˚
A-FLER/L D
CM
-73
Threading and Grooving F
RH SHOWN
Coolant
hole Stock
C
Min. Clamp
Description EDP Code Status Insert Bore D C F Clamp Screw
A08-FLER2 96500808 ● FL-2L .730 .500 8 .437 TF-147 S-39
A08-FLEL2 96400808 ● FL-2R .730 .500 8 .437 TF-146 S-39
A10-FLER2 96501008 ● FL-2L 1.000 .625 10 .500 TF-75 S-310
A12-FLER2 96501208 ● FL-2L 1.125 .750 10 .562 TF-75 S-310
A12-FLEL2 96401208 ● FL-2R 1.125 .750 10 .562 TF-74 S-310
A16-FLER2 96501608 ● FL-2L 1.375 1.000 12 .688 TF-75 S-310
A16-FLEL2 96401608 ● FL-2R 1.375 1.000 12 .688 TF-74 S-310
A16-FLER3 96501616 ● FL-3L 1.375 1.000 12 .688 TF-73 S-412
A16-FLEL3 96401616 ● FL-3R 1.375 1.000 12 .688 TF-72 S-412
A20-FLER3 96502016 ❍ FL-3L 1.750 1.250 14 .875 TF-73 S-412
A20-FLEL3 96402016 ❍ FL-3R 1.750 1.250 14 .875 TF-72 S-412
A24-FLER3 96502416 ● FL-3L 2.000 1.500 14 1.000 TF-73 S-412
A24-FLEL3 96402416 ● FL-3R 2.000 1.500 14 1.000 TF-72 S-412
A28-FLER3 96502816 ❍ FL-3L 2.250 1.750 14 1.125 TF-73 S-412
A32-FLER3 96503216 ● FL-3L 2.500 2.000 16 1.250 TF-73 S-412
A32-FLEL3 96403216 ● FL-3R 2.500 2.000 16 1.250 TF-72 S-412
A28-FLER4 96502820 ● FL-4L 2.250 1.750 14 1.250 TF-73 S-412
A28-FLEL4 96402820 ● FL-4R 2.250 1.750 14 1.250 TF-72 S-412
A32-FLER4 96503220 ● FL-4L 2.750 2.000 16 1.296 TF-73 S-412
A32-FLEL4 96403220 ● FL-4R 2.750 2.000 16 1.296 TF-72 S-412
A32-FLER5 96503224 ● FL-5L 2.812 2.000 16 1.406 CM-81 S-352
A32-FLER6 96503228 ● FL-6L 2.750 2.000 16 1.375 CM-121 S-412
“F” and “C” Dim. over sharp point of grooving insert.
INTERNAL HOLDER (METRIC) 3˚
A_M-FLER/L
Threading and Grooving D
CM
-73
F RH SHOWN
Coolant
hole Stock C
Min. Clamp
Description EDP Code Status Insert Bore D C F Clamp Screw
A16M-FLER2 96441608 ● FL-2L 25,4 16,0 250,0 12,65 TF-75 S-310
A20M-FLER2 96442008 ● FL-2L 28,6 20,0 250,0 13,8 TF-75 S-310
A25M-FLER2 96442508 ● FL-2L 34,9 25,0 300,0 17,7 TF-75 S-310
A25M-FLEL2 96432508 ● FL-2R 34,9 25,0 300,0 17,7 TF-74 S-310
A25M-FLER3 96442516 ● FL-3L 34,9 25,0 300,0 17,7 TF-73 S-412
A25M-FLEL3 96432516 ● FL-3R 34,9 25,0 300,0 17,7 TF-72 S-412
A32M-FLER3 96443216 ❍ FL-3L 44,45 32,0 350,0 22,1 TF-73 S-412
A32M-FLEL3 96433216 ❍ FL-3R 44,45 32,0 350,0 22,1 TF-72 S-412
A40M-FLER3 96444016 ● FL-3L 50,8 40,0 350,0 24,45 TF-73 S-412
A40M-FLEL3 96434016 ● FL-3R 50,8 40,0 350,0 24,45 TF-72 S-412
A50M-FLER4 96445020 ● FL-4L 63,5 50,0 400,0 35,3 TF-72 S-412
A50M-FLEL4 96435020 ● FL-4R 63,5 50,0 400,0 35,3 TF-72 S-412
109
“F” and “C” Dim. over sharp point of grooving insert.
FLO-LOCK
EXTERNAL HOLDER D
FLSR/LT F A
3°
For double ended FLGT/FLRT inserts
sign!
-FLO de
C
Inch TO O L
e
Exclusiv B B RH SHOWN
Most holders available with coolant port
(ie: Add CP to end of description)
C
Clamp
Description EDP Code Insert A B C D F Clamp Screw
FLSRT-163D 93431616D FLGT-3R 1.000 1.000 6.000 .440 1.250 TF-72 S-412
FLSLT-163D 93421616D FLGT-3L 1.000 1.000 6.000 .440 1.250 TF-73 S-412
FLSRT-203D 93432016D FLGT-3R 1.250 1.250 6.000 .440 1.500 TF-72 S-412
FLSLT-203D 93422016D FLGT-3L 1.250 1.250 6.000 .440 1.500 TF-73 S-412
FLSRT-164D 93431620D FLGT-4R 1.000 1.000 6.000 .560 1.250 TF-72 S-412
FLSLT-164D 93421620D FLGT-4L 1.000 1.000 6.000 .560 1.250 TF-73 S-412
FLSRT-204D 93432020D FLGT-4R 1.250 1.250 6.000 .560 1.500 TF-72 S-412
FLSLT-204D 93422020D FLGT-4L 1.250 1.250 6.000 .560 1.500 TF-73 S-412
METRIC
Clamp
Description EDP Code Insert A B C D F Clamp Screw
FLSRT-2525M3 934325M16 FLGT/RT-3R 25,0 25,0 152,4 11,2 32,0 TF-72 S-412
FLSLT-2525M3 934225M16 FLGT/RT-3L 25,0 25,0 152,4 11,2 32,0 TF-73 S-412
FLSRT-3232M3 934332M16 FLGT/RT-3R 32,0 32,0 152,4 11,2 40,0 TF-72 S-412
FLSLT-3232M3 934232M16 FLGT/RT-3L 32,0 32,0 152,4 11,2 40,0 TF-73 S-412
FLSRT-2525M4 934325M20 FLGT/RT-4R 25,0 25,0 152,4 14,2 32,0 TF-72 S-412
FLO-LOCK
FLSLT-2525M4 934225M20 FLGT/RT-4L 25,0 25,0 152,4 14,2 32,0 TF-73 S-412
FLSRT-3232M4 934332M20 FLGT/RT-4R 32,0 32,0 152,4 14,2 40,0 TF-72 S-412
FLSLT-3232M4 934232M20 FLGT/RT-4L 32,0 32,0 152,4 14,2 40,0 TF-73 S-412
3°
FLER/LT A
For double ended FLGT/FLRT inserts F
sign!
-FLO de
D
e TO O L C
Exclusiv RH SHOWN
Most holders available with coolant port B
(ie: Add CP to end of description)
H
Clamp
C
Description EDP Code Insert A B C D F Clamp Screw
FLERT-163D 93111616D FLGT-3L 1.000 1.000 6.000 .440 1.582 TF-72 S-412
FLELT-163D 93011616D FLGT-3R 1.000 1.000 6.000 .440 1.582 TF-73 S-412
FLERT-203D 93112016D FLGT-3L 1.250 1.250 6.000 .440 1.832 TF-72 S-412
FLELT-203D 93012016D FLGT-3R 1.250 1.250 6.000 .440 1.832 TF-73 S-412
FLERT-164D 93111620D FLGT-4L 1.000 1.000 6.000 .560 1.582 TF-72 S-412
FLELT-164D 93011620D FLGT-4R 1.000 1.000 6.000 .560 1.582 TF-73 S-412
FLERT-204D 93112020D FLGT-4L 1.250 1.250 6.000 .560 1.832 TF-72 S-412
FLELT-204D 93012020D FLGT-4R 1.250 1.250 6.000 .560 1.832 TF-73 S-412
INTERNAL BAR OOL-FL
O design
!
A_FLER/LT Ex clusive T 3˚
For double ended FLGT/FLRT inserts
D
Inch
CM
-7
3
RH SHOWN
Most holders available with coolant port C
(ie: Add CP to end of description) Min. Clamp
Description EDP Code Insert D C F Bore Clamp Screw
A20-FLERT3 96552016 FLGT/RT-3L 1.250 18.000 1.082 1.807 TF-72 S-412
A20-FLELT3 96452016 FLGT/RT-3R 1.250 18.000 1.082 1.807 TF-73 S-412
A24-FLERT3 96552416 FLGT/RT-3L 1.500 18.000 1.207 2.057 TF-72 S-412
A24-FLELT3 96452416 FLGT/RT-3R 1.500 18.000 1.207 2.057 TF-73 S-412
A28-FLERT4 96552820 FLGT/RT-4L 1.750 18.000 1.500 2.475 TF-72 S-412
A28-FLELT4 96452820 FLGT/RT-4R 1.750 18.000 1.500 2.475 TF-73 S-412
METRIC
Min. Clamp
Description EDP Code Insert D C F Bore Clamp Screw
A32M-FLERT3 96442016 FLGT/RT-3L 32,0 457,2 27,48 46,0 TF-72 S-412
A32M-FLELT3 96432016 FLGT/RT-3R 32,0 457,2 27,48 46,0 TF-73 S-412
A40M-FLERT3 96442416 FLGT/RT-3L 40,0 457,2 31,60 54,15 TF-72 S-412
A40M-FLELT3 96432416 FLGT/RT-3R 40,0 457,2 31,60 54,15 TF-73 S-412
A50M-FLERT4 96442820 FLGT/RT-4L 50,0 457,2 40,87 68,43 TF-72 S-412
A50M-FLELT4 96432820 FLGT/RT-4R 50,0 457,2 40,87 68,43 TF-73 S-412
110
FLO-LOCK
3
INTERCHANGEABLE HEADS
H-FLER D
RH SHOWN
Threading and Grooving F
PARTS
Min. Clamp
Description EDP Code Insert D C C F Bore Clamp Screw
H20-FLER3W 93502016W FL-3L 1-1/4 1.625 .875 1.750 TF-73 S-412
H24-FLER3W 93502416W FL-3L 1-1/2 1.625 1.000 2.000 TF-73 S-412
H28-FLER3W 93502816W FL-3L 1-3/4 1.625 1.125 2.250 TF-73 S-412
H32-FLER3W 93503216W FL-3L 2 1.625 1.250 2.500 TF-73 S-412
H40-FLER3W 93504016W FL-3L 2-1/2 1.625 1.500 3.000 TF-73 S-412
H28-FLER4W 93502820W FL-4L 1-3/4 1.625 1.250 2.500 TF-73 S-412
H32-FLER4W 93503220W FL-4L 2 1.625 1.375 2.750 TF-73 S-412
H36-FLER4W 93503620W FL-4L 2-1/4 1.625 1.500 3.000 TF-73 S-412
H40-FLER4W 93504020W FL-4L 2-1/2 1.625 1.625 3.250 TF-73 S-412
H28-FLER6W 93502828W FL-6L 1-3/4 1.625 1.250 2.500 TF-121 S-412
H32-FLER6W 93503228W FL-6L 2 1.625 1.375 2.750 TF-121 S-412
H40-FLER6W 93504028W FL-6L 2-1/2 1.625 1.625 3.250 TF-121 S-412
*Left hand quoted on request 3˚
HS-FLEL/R*
D d RH SHOWN
F
PARTS
Min. Clamp
C
Description EDP Code Insert d C F Bore (D) Clamp Screw
HS32-FLER3W 9IHS65032M16 FL-3L 1.25 1.34 0.866 1.730 TF-73 S-412
FLO-LOCK
HS40-FLER3W 9IHS65040M16 FL-3L 1.57 1.58 1.102 2.210 TF-73 S-412
HS50-FLER3W 9IHS65050M16 FL-3L 1.97 1.65 1.380 2.760 TF-73 S-412
HS60-FLER3W 9IHS65060M16 FL-3L 2.36 1.75 1.740 3.480 TF-73 S-412
HS50-FLER4W 9IHS65050M20 FL-4L 1.97 1.65 1.380 2.760 TF-73 S-412
HS60-FLER4W 9IHS65060M20 FL-4L 2.36 1.75 1.740 3.480 TF-73 S-412
*Left hand quoted on request.
American Standard Buttress Thread Designations
● When only the designation BUTT is used, the thread is a “pull” type buttress (external thread pulls) with the clearance flank (45˚) leading and the
pressure flank (7˚) following.
● When the designation PUSH-BUTT is used, the thread is a push type buttress (external thread pushes) with the load flank (7˚) leading and the 45˚
clearance flank following.
● Whenever possible this description should be confirmed by a simplified view showing thread angles on the drawing of the product that has the
buttress thread.
● Always remember that the position of your holder and direction of your feed will determine the lead angle on the insert.
external buttress (45˚ lead) thread internal buttress (45˚ lead) thread
AMERICAN STANDARD BUTTRESS
Counterclockwise
rotation
Counterclockwise
rotation
1/2 d playAPI NC
nut
P
0,0627 P
0,1632 P
45˚ clearance flank of this
buttress thread becomes
SPECIFICATIONS
the leading angle in this
application.
0,3 P
RH bar 0,3 P
A_ -FLER 0,8906 P
0,3 P
feed
45˚ clearance angle of this LH insert
buttress thread becomes 45˚ Lead
the leading angle in this FLTB-2LB 1/2 d2 play
chuck 7˚
application. chuck FLTB-3LB 45˚
FLTB-4LB
RH insert 0,0826 P 0,1632 P
45˚ Lead screw
FLTB-2RB
1/2 d1 play
FLTB-3RB LH holder 45˚
FLTB-4RB Use: fittings and pipe couplings
FLEL
feed RH holder For insert with this form see pages
FLSR
Feed direction towards the chuck
External RH Thread • counterclockwise rotation Internal RH Thread External LH Thread Internal LH Thread • clockwise rotation
• counterclockwise rotation
• right hand toolholder • left hand bar
• right hand bar
• right hand insert • right hand insert
• left hand insert
• clockwise rotation
• left hand toolholder
• left hand insert
Feed direction towards the tailstock
External LH Thread • counterclockwise rotation Internal LH Thread External RH Thread Internal RH Thread
• clockwise rotation • clockwise rotation
• right hand toolholder
• left hand toolholder • left hand bar
• right hand insert
• left hand insert • right hand insert
• counterclockwise rotation
• right hand bar
• left hand insert
111
FLO-LOCK
Threading Limits with Standard Flo-Lock Inserts
The following charts list the largest pitch that can be applied on internal applications for Acme and V-Threading Flo-Lock inserts in sizes 2,3, 4 and 6.
For Buttress threads, please see previous page.
Acme Threading Limits
60˚ V-Threading Limits
FLA-2 internal threading limitations
FLT-2 Inserts internal threading limitations nominal minimum minor
nominal threads per inch thread size diameter
minimum minor
threads per inch thread size diameter 6 2-1/2 2.333
6 1-7/8 1.695 8 2-1/4 2.125
7 1-3/4 1.595 10 2 1.900
8 1-5/8 1.490 12 1-3/4 1.667
9 1-9/16 1.442 14 1-5/8 1.554
10 1-1/2 1.392 16* 1-1/2 1.438
11 1-7/16 1.339
*16 pitch acme threads and finer can be cut provided the minor diameter is 1.438 or
12 1-3/8 1.285 larger.
13 1-5/16 1.229
14 1-1/4 1.173
16 1-1/4 1.182
18 1-1/8 1.065
20 1-1/8 1.071
24 1-1/16 1.017
* 24 TPI and finer can be cut with a #2 series inseret provided thart the minor diameter
is 1.000 or larger.
A secondary clearance can be ground
FLO-LOCK
on the leading edge of the form of the
insert to provide sufficient helical clear-
ance for machining courser threads
and multiple start threads.
minor diameter major diameter Modified standard inserts may be produced for special
(minimum bore) (nominal thread size) threads or ones not listed on the charts shown. Quoted
upon request.
FLA-3, 4 & 6 internal threading limitations
nominal minimum minor
threads per inch thread size diameter
2** 5 4.500
threads 2-1/2** 4-1/2 4.100
per inch 3** 4 3.665
4 3-1/2 3.250
5 3 2.800
6 2-1/2 2.333
8 2-1/4 2.125
10 2 1.900
12 1-3/4 1.667
14 1-5/8 1.554
FLT-3 & 4 Inserts internal threading limitations 16* 1-1/2 1.438
nominal minimum minor
threads per inch thread size diameter *16 pitch acme threads and finer can be cut provided the minor diameter is 1.438 or larger.
**FLA-6 only.
4** 3 2.729
4-1/2** 2-7/8 2.634 NOTE: Positive rake acme inserts are recommended for stainless steels and high-temp
alloy applications. Quoted upon request.
5 2-3/4 2.534
6 2-1/2 2.320
7 2-1/4 2.095
8 2 1.865
9 1-15/16 1.817
10 1-7/8 1.767
11 1-13/16 1.714
90˚
12 1-3/4 1.660
13 1-5/8 1.542
14 1-9/16 1.485 3˚
16* 1-7/16 1.370 back clearance
*16 pitch V threads and finer can be cut provided the minor diameter is 1.370 or larger.
**FLT-4 only.
NOTE: Tool holders are designed to locate the insert at a 3˚
angle to provide back clearance down the side.
FLTB-2A & 2B internal threading limitations FLTB-3A & 4A internal threading limitations FLTB-3B & 4B internal threading limitations
nominal minimum minor nominal minimum minor nominal minimum minor
threads per inch thread size threads per inch thread size diameter threads per inch thread size diameter
diameter
8 1-3/4 1.600 4* 2-1/2 2.200 4 *2-7/8 2.575
10 1-5/8 1.505 5 2-1/4 2.010 5 2-3/4 2.510
12 1-1/2 1.400 6 2 1.800 6 2-3/8 2.175
16 1-1/4 1.175 8 1-3/4 1.600 8 2-1/8 1.975
20 1-1/16 1.002 10 1-5/8 1.505 10 1-7/8 1.755
12** 1-1/2 1.400 12 1-5/8 1.525
* FLTB-4A insert only 16 1-1/2 1.407
** Sixteen or 20 threads per inch can be cut providing minor diameter is 1.375 or larger. 20 1-7/16 1.378
112 * FLTB-4B insert only
You might also like
- P 0002 Ph01 d01 01c001 Fsa SDR Civ 100300 (00) Potable Water Network Site Layout Master Plan (Zone 1) 5No ratings yetP 0002 Ph01 d01 01c001 Fsa SDR Civ 100300 (00) Potable Water Network Site Layout Master Plan (Zone 1) 51 page
- Brosur Tokico Dan Data Sheet-D7a93-3206 339No ratings yetBrosur Tokico Dan Data Sheet-D7a93-3206 3396 pages
- SEAL IDENTIFICATION CHART G2 - Baum HydraulicsNo ratings yetSEAL IDENTIFICATION CHART G2 - Baum Hydraulics37 pages
- Coroturn® 107 Positive Basic-Shape InsertsNo ratings yetCoroturn® 107 Positive Basic-Shape Inserts16 pages
- Threading Inserts and Toolholders GuideNo ratings yetThreading Inserts and Toolholders Guide48 pages
- Comprehensive Fittings and Sealants GuideNo ratings yetComprehensive Fittings and Sealants Guide282 pages
- Monogram Aerospace Fasteners: A Trimas Company L G S R RadNo ratings yetMonogram Aerospace Fasteners: A Trimas Company L G S R Rad2 pages
- Beneficio de Minerales: Equipos y MotoresNo ratings yetBeneficio de Minerales: Equipos y Motores83 pages
- Iso Cartridges - Sigma Toolings, Fine Boring Tools, Cutting Tools ManufacturerNo ratings yetIso Cartridges - Sigma Toolings, Fine Boring Tools, Cutting Tools Manufacturer9 pages
- Threading Catalog: CAT2016THD FRONTCOVER - Indd 1 8/24/16 10:37 AMNo ratings yetThreading Catalog: CAT2016THD FRONTCOVER - Indd 1 8/24/16 10:37 AM156 pages
- Fanuc LATHE CNC Program Manual Gcodetraining 58877% (13)Fanuc LATHE CNC Program Manual Gcodetraining 588104 pages
- Compact Limit Switches for Safety ApplicationsNo ratings yetCompact Limit Switches for Safety Applications3 pages
- Fishing & Cable Pulling: Ultra Tugger 2 Cable Puller CR25 Cable Roller Guide Ultr Tug Light Base SheaveNo ratings yetFishing & Cable Pulling: Ultra Tugger 2 Cable Puller CR25 Cable Roller Guide Ultr Tug Light Base Sheave48 pages
- Bench Top Dial Hardness Tester User ManualNo ratings yetBench Top Dial Hardness Tester User Manual20 pages
- Doosan Lathe Programming, Canned CyclesNo ratings yetDoosan Lathe Programming, Canned Cycles28 pages
- Plastic Raw Material MIS: Date 18-Apr-2022No ratings yetPlastic Raw Material MIS: Date 18-Apr-20223 pages
- Basic Rates (SH: 25.0 Conservation of Heritage Buildings) : Code Description Unit Rate NoNo ratings yetBasic Rates (SH: 25.0 Conservation of Heritage Buildings) : Code Description Unit Rate No48 pages
- Technical Bid Evaluation Sheet New Oil Transfer Pumps (P-1250)100% (2)Technical Bid Evaluation Sheet New Oil Transfer Pumps (P-1250)2 pages
- Standard Triangulation Language (STL) FileNo ratings yetStandard Triangulation Language (STL) File26 pages
- Technical Report on GA-100W Shadow BlockNo ratings yetTechnical Report on GA-100W Shadow Block1 page
- OceanStor Dorado Spare Parts Catalog 2021No ratings yetOceanStor Dorado Spare Parts Catalog 20219 pages
- Monoi: Heat-Shrinkable MV Indoor TerminationNo ratings yetMonoi: Heat-Shrinkable MV Indoor Termination1 page
