0204-125
125 Watts, 28 Volts, Class AB
Defcom 225 - 400 MHz
GENERAL DESCRIPTION CASE OUTLINE
The 0204-125 is a double input matched COMMON EMITTER broadband 55JT- Style 2
transistor specifically intended for use in the 225-400 MHz frequency band. It
may be operated in Class AB or C. Gold metallization and silicon diffused
resistors ensure ruggedness and high reliability.
ABSOLUTE MAXIMUM RATINGS
Maximum Power Dissipation @ 25oC 270 Watts
Maximum Voltage and Current
BVces Collector to Emiter Voltage 65 Volts
BVebo Emitter to Base Voltage 4.0 Volts
Ic Collector Current 16.0 A
Maximum Temperatures
Storage Temperature - 65 to +150 oC
Operating Junction Temperature +200 oC
ELECTRICAL CHARACTERISTICS @ 25 OC
SYMBOL CHARACTERISTICS TEST CONDITIONS MIN TYP MAX UNITS
Pout Power Output F = 400 MHz 125 Watts
Pin Power Input Vcc = 28 Volts 25 Watts
Pg Power Gain 7.0 8.5 dB
ηc Efficiency 60 %
VSWR Load Mismatch Tolerance 5:1
BVebo2 Emitter to Base Breakdown Ie = 10 mA 4.0 Volts
BVces2 Collector to Emitter Breakdown Ic = 100 mA 60 Volts
BVceo2 Collector to Emitter Breakdown Ie = 100 mA 32 Volts
Cob2 Output Capacitance Vcb = 28 V, F = 1 MHz 70 pF
hFE2 DC - Current Gain Vce = 5 V, Ic = 1 A 20 100
θjc
o
Thermal Resistance 0.65 C/W
Note 2: Per side
Issue August 1996
GHz TECHNOLOGY INC. RESERVES THE RIGHT TO MAKE CHANGES WITHOUT FURTHER NOTICE. GHz RECOMMENDS THAT
BEFORE THE PRODUCT(S) DESCRIBED HEREIN ARE WRITTEN INTO SPECIFICATIONS, OR USED IN CRITICAL APPLICATIONS,
THAT THE PERFORMANCE CHARACTERISTICS BE VERIFIED BY CONTACTING THE FACTORY.
GHz Technology Inc. 3000 Oakmead Village Drive, Santa Clara, CA 95051-0808 Tel. 408 / 986-8031 Fax 408 / 986-8120
Downloaded from: http://www.datasheetcatalog.com/
0204-125
Downloaded from: http://www.datasheetcatalog.com/
0204-125
R1 L9
L7
C6
L5
L1
Zo=50W C1 L13
L3
RF INPUT Zo=50W RF
C5 C8 OUT
C3 C4 +
C2 L4 L14
C9 C10 C12
Q1
C11
L2 L6 C7
L8
R2 L12
CAPACITORS INDUCTORS TRANSISTOR
C1,C2=39pF ceramic chip capacitor L1,L2,L3,L4,L5,L6,L7,L8=printed Q1=0204-125
C3=33pF ceramic chip capacitor on the circuit board
C4=56pF ceramic chip capacitor L9,L12=4.7mH RF choke
C5=18pF ceramic chip capacitor L10,L11,L13,L14=0.1mH RF choke
C6,C7,C8=27pF ceramic chip capacitor
C9=0.1mF ceramic capacitor RESISTORS
C10=10mF electrolytic capacitor R1,R2=10 OHM, 1/4 W
C11,C12=.5-10pF Johanson
August 1996
