02/10/2025 15:56 Building a Real-Time Data Visualization Solution with Generative AI | by Yi Ai | Medium

Open in app

Member-only story

Building a Real-Time Data Visualization

Solution with Generative AI
Leveraging OpenAI, LangChain, and Streamlit for Intelligent Data Analysis and
Visualization

13 min read · Nov 22, 2024

Yi Ai Follow

Listen Share More

This article demonstrates how to build a data visualization system that uses
LangChain with LLMs to transform queries into interactive visual insights. The
system integrates OpenAI’s GPT-4o-mini for query interpretation and data

https://yia333.medium.com/building-a-real-time-data-visualization-solution-with-generative-ai-4a560f603696 1/33
02/10/2025 15:56 Building a Real-Time Data Visualization Solution with Generative AI | by Yi Ai | Medium

transformation, BigQuery as a data storage solution, and Streamlit to deliver real-

time visualizations.

What We’re Building

We’ll create a full-stack data analysis system that:

Converts text questions into optimized SQL queries

Executes queries against BigQuery and processes results

Extracts relevant data features (like coordinates for geographic data)

Automatically detect appropriate visualization types based on query results

Transforms data into format-specific visualization structures

Provides real-time, interactive visualizations using Streamlit

Explains insights into natural language

Handles geographic data visualization with interactive maps and chart-based

data visualization using dynamic charts.

Prerequisites
Before we begin, ensure you have the following installed:

Python 3.7 or later

OpenAI API key

Access to a BigQuery dataset

Necessary Python libraries: Install them using the following pip command:

pip install streamlit langchain openai google-cloud-bigquery pandas "langchain-

Architecture Overview
Before diving into the implementation, let’s understand the architecture of our data
visualization agent.

Components
https://yia333.medium.com/building-a-real-time-data-visualization-solution-with-generative-ai-4a560f603696 2/33
02/10/2025 15:56 Building a Real-Time Data Visualization Solution with Generative AI | by Yi Ai | Medium

1. User Interface (Streamlit): Allows users to input queries and display results.

2. Text to SQL: Uses gpt-4o-mini to convert queries to SQL.

3. Query Execution: The SQL query is executed against the database.

4. Coordinate Extractor: Extracts geographical coordinates from the query results

for map visualizations.

5. Visualization Recommender: Uses GPT-4o-mini to suggest the most suitable

visualization based on the query and results.

6. Data Transformer: Uses GPT-4o-mini to transform the SQL query results into a
format suitable for the recommended visualization.

7. Visualization Renderer (Streamlit and Plotly): Renders the recommended

visualization using the transformed data.

Workflow

https://yia333.medium.com/building-a-real-time-data-visualization-solution-with-generative-ai-4a560f603696 3/33
02/10/2025 15:56 Building a Real-Time Data Visualization Solution with Generative AI | by Yi Ai | Medium

https://yia333.medium.com/building-a-real-time-data-visualization-solution-with-generative-ai-4a560f603696 4/33
02/10/2025 15:56 Building a Real-Time Data Visualization Solution with Generative AI | by Yi Ai | Medium

https://yia333.medium.com/building-a-real-time-data-visualization-solution-with-generative-ai-4a560f603696 5/33
02/10/2025 15:56 Building a Real-Time Data Visualization Solution with Generative AI | by Yi Ai | Medium

1. Input: The user enters a question.

2. Text-to-SQL Conversion: Converts the question into an SQL query.

3. Query Execution: The SQL query is executed against the database.

4. Coordinate Extractor: Extracts geographical coordinates from the query results

for map visualizations.

5. Visualization Recommendation: Based on the question, query, and results, the

AI recommends a visualization type.

6. Data Transformation: The query results are transformed to fit the

recommended visualization format.

7. Answer Generation: Generates a textual answer to the user’s question.

8. Result Formatting: The answer, visualization, and geographical data are

compiled into the final result.

9. Output: The user interface displays the answer, visualization, and map (if
applicable).

Setting Up the Database

We’ll use a sample dataset consisting of customer information. Below are the DDL
statements for creating the necessary tables in the BigQuery dataset:

CREATE TABLE `demo_data_set.customer` (

customer_key STRING NOT NULL,
first_name STRING,
last_name STRING,
source_system_name STRING,

https://yia333.medium.com/building-a-real-time-data-visualization-solution-with-generative-ai-4a560f603696 6/33
02/10/2025 15:56 Building a Real-Time Data Visualization Solution with Generative AI | by Yi Ai | Medium

dob DATE,
gender STRING,
create_timestamp TIMESTAMP
);

CREATE TABLE `demo_data_set.customer_address` (

customer_key STRING NOT NULL,
address_key STRING NOT NULL
);

CREATE TABLE `demo_data_set.address` (

address_key STRING NOT NULL,
full_address STRING,
state STRING,
country STRING,
latitude STRING,
longitude STRING
);

Building the Data Visualization Agent

The agent’s workflow involves several steps, from converting user questions into
SQL queries to recommending appropriate visualizations and presenting the final
answer.

Configuring the database connection and LLM

service_account_file = os.environ["GOOGLE_APPLICATION_CREDENTIALS"]
project = os.environ["GOOGLE_PROJECT"]
dataset = os.environ["BIGQUERY_DATASET"]

sql_url = (
f"bigquery://{project}/{dataset}?credentials_path={service_account_file}"
)

db = SQLDatabase.from_uri(sql_url)

model = ChatOpenAI(model="gpt-4o-mini", temperature=0,

max_tokens="10000", timeout=30000, verbose=True)

Text-to-SQL
We start by converting natural language questions into SQL queries using the LLM
model:

https://yia333.medium.com/building-a-real-time-data-visualization-solution-with-generative-ai-4a560f603696 7/33
02/10/2025 15:56 Building a Real-Time Data Visualization Solution with Generative AI | by Yi Ai | Medium

from langchain.chains import create_sql_query_chain

sql_prompt = PromptTemplate.from_template("""
You are a SQL expert with access to a BigQuery dataset containing c
Given an input question, generate a syntactically correct SQL query

Relevant Table Information:

{table_info}

Question: {input}

Guidelines:
1. Ensure that all attribute searches are case-insensitive.
2. ALWAYS add 'LIMIT {top_k}' at the end of the query unless:
- The question explicitly asks for all records
- The query uses GROUP BY and needs to show all groups
- The query is counting records (using COUNT)
- The query calculates aggregates that need all data

Address and Location Queries:

1. For questions about addresses, locations, or properties, always

Double check the user's sql query for common mistakes, including:
- Using NOT IN with NULL values
- Using UNION when UNION ALL should have been used
- Using BETWEEN for exclusive ranges
- Data type mismatch in predicates
- Properly quoting identifiers
- Using the correct number of arguments for functions
- Casting to the correct data type
- Using the proper columns for joins
- Missing LIMIT clause when returning raw records

If there are any of the above mistakes, rewrite the query.

If there are no mistakes, just reproduce the original query with no

Provide only the final SQL query as plain text without any formatti
If the question is not about customers or addresses, respond with "
""")

text_to_sql = create_sql_query_chain(
model, db, sql_prompt)

Executing SQL Queries

Once we have the SQL query, we execute it against the database:

https://yia333.medium.com/building-a-real-time-data-visualization-solution-with-generative-ai-4a560f603696 8/33
02/10/2025 15:56 Building a Real-Time Data Visualization Solution with Generative AI | by Yi Ai | Medium

@RunnableLambda
def execute_query(result, config):
dispatch_custom_event(
"process.execute_query",
{
"status": ""
},
config=config
)
return {
**result,
'result': db.run_no_throw(
command=result["query"], include_columns=True)
}

Extracting Coordinates
If the query results include geographical data, we extract latitude and longitude for
map visualizations:

def extract_coordinates(self, result: dict):

try:
if isinstance(result, dict):
if "result" in result:
result = result["result"]
if isinstance(result, dict) and "result" in result:
result_str = result["result"]
else:
result_str = str(result)
else:
return None
else:
return None

try:
if isinstance(result_str, str):
result_data = eval(result_str)
else:
result_data = result_str
except Exception as e:
print(f"Error evaluating result string: {e}")
return None

if not isinstance(result_data, list):

return None

unique_lat_values = set()

https://yia333.medium.com/building-a-real-time-data-visualization-solution-with-generative-ai-4a560f603696 9/33
02/10/2025 15:56 Building a Real-Time Data Visualization Solution with Generative AI | by Yi Ai | Medium

unique_long_values = set()

for row in result_data:

if isinstance(row, dict):
if 'latitude' in row and row['latitude'] is not None:
try:
unique_lat_values.add(float(row['latitude']))
except (ValueError, TypeError):
pass

if 'longitude' in row and row['longitude'] is not None:

try:
unique_long_values.add(float(row['longitude']))
except (ValueError, TypeError):
pass

if unique_lat_values and unique_long_values:

return {
"latitude": list(unique_lat_values),
"longitude": list(unique_long_values)
}
return None

except Exception as e:
print(f"Error extracting coordinates: {e}")
return None

Recommending Visualizations
We use LLM to recommend the most suitable visualization based on the user’s
question, SQL query, and results:

viz_prompt = PromptTemplate.from_template("""
You are an AI assistant that recommends appropriate data visualizations for cus

Available chart types and their best use cases:

- Bar Graphs (for 3+ categories):

* Comparing distributions across multiple categories
* Customer counts by source system
* Customer demographics across regions/states
* Age group distributions
* Monthly/yearly registration counts

- Horizontal Bar Graphs (for 2-3 categories or large value disparities):

* Binary comparisons (e.g., gender distribution)
* Limited category comparisons (2-3 items)
* Cases with large value differences between categories

https://yia333.medium.com/building-a-real-time-data-visualization-solution-with-generative-ai-4a560f603696 10/33
02/10/2025 15:56 Building a Real-Time Data Visualization Solution with Generative AI | by Yi Ai | Medium

- Line Graphs (for time series only):

* Customer registration trends over time
* Growth patterns by source system
* Any metric tracked over time periods
Note: X-axis MUST represent time (create_timestamp or similar)

- Pie Charts (for proportions, 3-7 categories max):

* Distribution percentages
* Market share analysis
* Proportional comparisons
Note: Total should sum to 100%

- Scatter Plots (for numeric relationships):

* Age vs other numeric metrics
* Timestamp patterns
* Distribution analysis
Note: Both axes must be numeric, non-categorical

Special Cases:
1. Geographic Data:
* If result contains latitude and longitude → No chart (will display map)
* For address/location questions → No chart (will display map)

2. Raw Data:
* Individual customer records → No chart (tabular display)
* Non-aggregated data → No chart (tabular display)

Tables in scope:
- customer: customer_key, first_name, last_name, source_system_name, dob, gende
- customer_address: customer_key, address_key
- address: address_key, full_address, state, country, latitude, longitude

Question: {question}
SQL Query: {query}
SQL Result: {result}

Provide your response in the following format:

Recommended Visualization: [Chart type or "none"]. ONLY use the following names
Reason: [Brief explanation for your recommendation]
""")

@RunnableLambda
def transform_data_for_visualization_chain(args, config):
try:
dispatch_custom_event(
"process.transform_data_for_visualization_chain",
{
"status": ""
},
config=config
)
chart_type = args.get("visualization").get("type")
result = args.get("result")

https://yia333.medium.com/building-a-real-time-data-visualization-solution-with-generative-ai-4a560f603696 11/33
02/10/2025 15:56 Building a Real-Time Data Visualization Solution with Generative AI | by Yi Ai | Medium

if not chart_type or not result:

return {"chart_data": None}

if chart_type == 'bar':
transform_prompt = bar_prompt
elif chart_type == 'horizontal_bar':
transform_prompt = horizontal_bar_prompt
elif chart_type == 'pie':
transform_prompt = pie_prompt
elif chart_type == 'scatter':
transform_prompt = scatter_prompt
elif chart_type == 'line':
transform_prompt = line_prompt
else:
transform_prompt = None

assign_chart_type_and_result = RunnableLambda(
lambda args: {**args, "chart_type": args.get("visualization", {}).g
"type"), "result": args.get("result")}
)

if transform_prompt:
transform_chain = (
assign_chart_type_and_result
| transform_prompt
| model
)
return transform_chain

return {"chart_data": None}

except Exception as e:
print(e)
print(f"Error in transform_data_for_visualization: {e}")
return {"chart_data": None}

viz_prompt
| model
| parse_visualization_response

Transforming Data for Visualization

Depending on the recommended chart type, we transform the data accordingly:

def create_data_transform_prompt(self):

https://yia333.medium.com/building-a-real-time-data-visualization-solution-with-generative-ai-4a560f603696 12/33
02/10/2025 15:56 Building a Real-Time Data Visualization Solution with Generative AI | by Yi Ai | Medium

base_prompt = """You are a data transformation expert. Transform the SQ

SQL Query Result: {result}

Your response must be a valid JSON object containing ONLY the chart_d
"""

chart_prompts = {
"bar": """For a bar chart, return JSON in this EXACT format:
{{
"chart_data": {{
"labels": ["Category1", "Category2", ...],
"values": [
{{
"data": [number1, number2, ...],
"label": "Metric Name"
}}
]
}}
}}

Example with SQL: "SELECT source_system_name, COUNT(*) as count F

{{
"chart_data": {{
"labels": ["System A", "System B", "System C"],
"values": [
{{
"data": [45, 32, 28],
"label": "Customer Count"
}}
]
}}
}}

Example with multiple series:

{{
"chart_data": {{
"labels": ["NSW", "VIC", "QLD"],
"values": [
{{
"data": [500000, 750000, 450000],
"label": "Total Customers"
}},
{{
"data": [35, 30, 28],
"label": "Average Age"
}}
]
}}
}}""",

"horizontal_bar": """For a horizontal bar chart, return JSON in thi

{{

https://yia333.medium.com/building-a-real-time-data-visualization-solution-with-generative-ai-4a560f603696 13/33
02/10/2025 15:56 Building a Real-Time Data Visualization Solution with Generative AI | by Yi Ai | Medium

"chart_data": {{
"labels": ["Category1", "Category2", ...],
"values": [
{{
"data": [number1, number2, ...],
"label": "Metric Name"
}}
]
}}
}}

Example:
{{
"chart_data": {{
"labels": ["Male", "Female"],
"values": [
{{
"data": [75000, 78000],
"label": "Customer Count"
}}
]
}}
}}""",

"line": """For a line chart, return JSON in this EXACT format:

{{
"chart_data": {{
"xValues": ["2023-01", "2023-02", ...],
"yValues": [
{{
"data": [number1, number2, ...],
"label": "Metric Name"
}}
]
}}
}}

Example:
{{
"chart_data": {{
"xValues": ["2023-01", "2023-02", "2023-03", "2023-04"],
"yValues": [
{{
"data": [12500, 13600, 14800, 15200],
"label": "Monthly Registrations"
}}
]
}}
}}

Example with multiple series:

{{
"chart_data": {{

https://yia333.medium.com/building-a-real-time-data-visualization-solution-with-generative-ai-4a560f603696 14/33
02/10/2025 15:56 Building a Real-Time Data Visualization Solution with Generative AI | by Yi Ai | Medium

"xValues": ["2023-01", "2023-02", "2023-03"],

"yValues": [
{{
"data": [5000, 5500, 6000],
"label": "System A Customers"
}},
{{
"data": [4000, 4200, 4500],
"label": "System B Customers"
}}
]
}}
}}""",

"pie": """For a pie chart, return JSON in this EXACT format:

{{
"chart_data": [
{{
"value": number,
"label": "Category Name"
}}
]
}}

Example:
{{
"chart_data": [
{{
"value": 150,
"label": "System A"
}},
{{
"value": 45,
"label": "System B"
}},
{{
"value": 25,
"label": "System C"
}}
]
}}""",

"scatter": """For a scatter plot, return JSON in this EXACT format:

{{
"chart_data": {{
"series": [
{{
"data": [
{{
"x": number,
"y": number,
"id": number
}}

https://yia333.medium.com/building-a-real-time-data-visualization-solution-with-generative-ai-4a560f603696 15/33
02/10/2025 15:56 Building a Real-Time Data Visualization Solution with Generative AI | by Yi Ai | Medium

],
"label": "Series Name"
}}
]
}}
}}

Example:
{{
"chart_data": {{
"series": [
{{
"data": [
{{
"x": -33.865,
"y": 151.209,
"id": 1
}},
{{
"x": -37.813,
"y": 144.963,
"id": 2
}},
{{
"x": -27.470,
"y": 153.021,
"id": 3
}}
],
"label": "Customer Locations"
}}
]
}}
}}

Example with multiple series:

{{
"chart_data": {{
"series": [
{{
"data": [
{{
"x": -33.865,
"y": 151.209,
"id": 1
}},
{{
"x": -37.813,
"y": 144.963,
"id": 2
}}
],
"label": "Male Customers"

https://yia333.medium.com/building-a-real-time-data-visualization-solution-with-generative-ai-4a560f603696 16/33
02/10/2025 15:56 Building a Real-Time Data Visualization Solution with Generative AI | by Yi Ai | Medium

}},
{{
"data": [
{{
"x": -27.470,
"y": 153.021,
"id": 3
}},
{{
"x": -31.950,
"y": 115.860,
"id": 4
}}
],
"label": "Female Customers"
}}
]
}}
}}"""
}

bar_prompt = base_prompt + chart_prompts.get("bar")

horizontal_bar_prompt = base_prompt + \
chart_prompts.get("horizontal_bar")
pie_prompt = base_prompt + chart_prompts.get("pie")
scatter_prompt = base_prompt + chart_prompts.get("scatter")
line_prompt = base_prompt + chart_prompts.get("line")

return (
PromptTemplate.from_template(bar_prompt),
PromptTemplate.from_template(horizontal_bar_prompt),
PromptTemplate.from_template(pie_prompt),
PromptTemplate.from_template(scatter_prompt),
PromptTemplate.from_template(line_prompt)
)

bar_prompt, horizontal_bar_prompt, pie_prompt, scatter_prompt, line_prompt = cr

@RunnableLambda
def transform_data_for_visualization_chain(args, config):
try:
dispatch_custom_event(
"process.transform_data_for_visualization_chain",
{
"status": ""
},
config=config
)
chart_type = args.get("visualization").get("type")
result = args.get("result")

https://yia333.medium.com/building-a-real-time-data-visualization-solution-with-generative-ai-4a560f603696 17/33
02/10/2025 15:56 Building a Real-Time Data Visualization Solution with Generative AI | by Yi Ai | Medium

if not chart_type or not result:

return {"chart_data": None}

if chart_type == 'bar':
transform_prompt = bar_prompt
elif chart_type == 'horizontal_bar':
transform_prompt = horizontal_bar_prompt
elif chart_type == 'pie':
transform_prompt = pie_prompt
elif chart_type == 'scatter':
transform_prompt = scatter_prompt
elif chart_type == 'line':
transform_prompt = line_prompt
else:
transform_prompt = None

assign_chart_type_and_result = RunnableLambda(
lambda args: {**args, "chart_type": args.get("visualization", {}).g
"type"), "result": args.get("result")}
)

if transform_prompt:
transform_chain = (
assign_chart_type_and_result
| transform_prompt
| model
)
return transform_chain

return {"chart_data": None}

except Exception as e:
print(e)
print(f"Error in transform_data_for_visualization: {e}")
return {"chart_data": None}

Generating the Answer

We generate a textual answer to the user’s question using the LLM model:

create_answer_prommpt = PromptTemplate.from_template(
"""Given the following user question, corresponding SQL query, and

Question: {question}
SQL Query: {query}
SQL Result: {result}
Answer: """

https://yia333.medium.com/building-a-real-time-data-visualization-solution-with-generative-ai-4a560f603696 18/33
02/10/2025 15:56 Building a Real-Time Data Visualization Solution with Generative AI | by Yi Ai | Medium

)
create_answer_prommpt | model

Formatting the Final Result

Next, we compile the answer, visualization, and any coordinates into the final
result:

@RunnableLambda
def format_final_result(result, config):
try:
dispatch_custom_event(
"process.format_final_result",
{
"status": ""
},
config=config
)
if isinstance(result, str):
try:
result = json.loads(result)
except json.JSONDecodeError:
result = {"answer": result}

answer = ""
chart_data = None
chart_type = None
coordinates = None

# Extract chart data from AIMessage

if isinstance(result, dict):
coordinates = result.get("coordinates")

# Get chart type from visualization

visualization = result.get('visualization', {})
if isinstance(visualization, dict):
chart_type = visualization.get('type')

chart_data_msg = result.get('chart_data')
if hasattr(chart_data_msg, 'content'):
try:
content = chart_data_msg.content
content = content.replace(
'```json', '').replace('```', '').strip()
parsed_data = json.loads(content)
if isinstance(parsed_data, dict) and 'chart_data' in parsed
chart_data = parsed_data['chart_data']
except json.JSONDecodeError:
https://yia333.medium.com/building-a-real-time-data-visualization-solution-with-generative-ai-4a560f603696 19/33
02/10/2025 15:56 Building a Real-Time Data Visualization Solution with Generative AI | by Yi Ai | Medium

print("Failed to parse chart data JSON")

chart_data = None

answer_msg = result.get('answer')

if hasattr(answer_msg, 'content'):
answer = answer_msg.content
elif isinstance(answer_msg, str):
answer = answer_msg
elif isinstance(answer_msg, dict) and 'content' in answer_msg:
answer = answer_msg['content']
else:
result_data = result.get("result", {})
if isinstance(result_data, dict) and "result" in result_data:
answer = str(result_data["result"])
else:
answer = str(result_data)

response_dict = {
"answer": answer,
"coordinates": coordinates,
"chart_data": chart_data,
"chart_type": chart_type
}
return json.dumps(response_dict)

except Exception as e:
print(f"Error in format_final_result: {e}")
return json.dumps({
"answer": "Error formatting result",
"coordinates": None,
"chart_data": None,
"chart_type": None
})

Full Chain Assembly

We assemble all the steps into a cohesive chain:

chain = (
RunnablePassthrough().assign(query=text_to_sql)
| RunnablePassthrough().assign(
result=execute_query
)
| RunnablePassthrough().assign(
coordinates=lambda x: extract_coordinates(x)
)
| RunnablePassthrough.assign(

https://yia333.medium.com/building-a-real-time-data-visualization-solution-with-generative-ai-4a560f603696 20/33
02/10/2025 15:56 Building a Real-Time Data Visualization Solution with Generative AI | by Yi Ai | Medium

visualization=RunnableLambda(
lambda x: {
"question": x.get("question", ""),
"query": x["query"],
"result": x.get("result", {}).get("result")
}
)
| viz_prompt
| model
| parse_visualization_response
)
| RunnablePassthrough().assign(
chart_data=transform_data_for_visualization_chain
)
| RunnablePassthrough.assign(
answer=create_answer_prommpt | model
)
| format_final_result
| StrOutputParser()
)

Integrating with Streamlit

Streamlit allows us to create an interactive web application to interface with our
agent. It enables users to interact with the visualization agent, execute database
queries, and view dynamic visualizations — all through natural language
conversations.

While I won’t be providing the complete source code for the Streamlit app in this
article, you can find the example code here. In this section, we’ll focus specifically
on how to extend Streamlit with Lanchain Streaming API and custom event handlers
to enhance user interaction and provide real-time feedback.

Extending Streamlit with Custom Event Handlers

When using LangChain’s streaming API, the default StreamlitCallbackHandler can
only display the LLM's status for the first chain (e.g., text-to-SQL step). To display the
LLM's status throughout the entire chain in the Streamlit interface, we need to
create a custom event handler that can receive and handle custom events.

Importing the Correct Streamlit Callback Handler

First, import the StreamlitCallbackHandler from the appropriate module:

https://yia333.medium.com/building-a-real-time-data-visualization-solution-with-generative-ai-4a560f603696 21/33
02/10/2025 15:56 Building a Real-Time Data Visualization Solution with Generative AI | by Yi Ai | Medium

from langchain_community.callbacks.streamlit.streamlit_callback_handler import

Next, create a custom class that inherits from StreamlitCallbackHandler to handle

custom events:

class CustomStreamlitCallbackHandler(StreamlitCallbackHandler):
def on_custom_event(self, name: str, data: dict, **kwargs):
"""Handle custom events, update labels, and mark as complete if specifi
if self._current_thought is not None:
custom_event_label = f"💡{name}"
self._current_thought.container.update(
new_label=custom_event_label)

content = f"**{name}:** {data}"

self._current_thought.container.markdown(content)

is_complete = data.get("is_complete", False)

if is_complete or name == "process.completed":
complete_label = f"✅ Complete, awaiting response"
self._current_thought.complete(final_label=complete_label)
else:
st.write(f"Custom Event Triggered Outside Thought Context: {data}")

def on_llm_end(self, response, **kwargs):

"""Override to ensure the label updates on LLM completion."""
super().on_llm_end(response, **kwargs)
if self._current_thought:
self._current_thought.complete(
final_label="✅ Complete, awaiting response")

def on_tool_end(self, output, **kwargs):

"""Override to ensure the label updates on tool completion."""
super().on_tool_end(output, **kwargs)
if self._current_thought:
self._current_thought.complete(final_label="✅ Tool Complete")

Dispatching Custom Events in LangChain Code

To utilize the custom event handler, dispatch custom events in your LangChain code
where appropriate. For example, in the execute_query step:

https://yia333.medium.com/building-a-real-time-data-visualization-solution-with-generative-ai-4a560f603696 22/33
02/10/2025 15:56 Building a Real-Time Data Visualization Solution with Generative AI | by Yi Ai | Medium

from langchain.callbacks import dispatch_custom_event

@RunnableLambda
def execute_query(query, config):
# Send custom event
dispatch_custom_event(
"process.execute_query",
{"status": "Executing SQL query..."},
config=config
)
try:
result = db.run_query(query)
dispatch_custom_event(
"process.execute_query",
{"status": "SQL query executed successfully.", "is_complete": True}
config=config
)
return result
except Exception as e:
dispatch_custom_event(
"process.execute_query",
{"status": f"Error executing SQL query: {e}", "is_complete": True},
config=config
)
return None

Updating the Streamlit App to Use the Custom Handler

In your Streamlit app, initialize the custom callback handler and pass it to your
LangChain chains:

def process_query(question: str, assistant: DatabaseAssistant) -> Dict[str, Any

try:
chain = assistant.process_query_chain()
return chain.stream(
{"question": question, "top_k": 10},
{"callbacks": [get_streamlit_cb(st.container())]}
)

except Exception as e:
st.error(f"Error processing query: {str(e)}")
return {"answer": "Sorry, I encountered an error processing your query.

with st.chat_message("assistant"):
response = process_query(prompt, assistant)
if response is not None:
https://yia333.medium.com/building-a-real-time-data-visualization-solution-with-generative-ai-4a560f603696 23/33
02/10/2025 15:56 Building a Real-Time Data Visualization Solution with Generative AI | by Yi Ai | Medium

for chunk in response:

handle_stream_response(
chunk, st.session_state.messages)Copy code

By implementing custom event handlers, we can provide real-time status updates

throughout the entire processing chain, enhancing user experience by informing
users about each step.

Running the Application

Now let’s run the app 🥳. You can find the complete working example in my GitHub
repository. To launch the application, navigate to the directory containing your
main.py file and execute the following command:

streamlit run main.py

Check out how the data and charts are generated based on data from the BigQuery
dataset. The application connects to the BigQuery dataset, executes the generated
SQL queries, and displays dynamic visualizations and maps accordingly. The custom
event handlers provide real-time feedback in the Streamlit interface, enhancing the
interactivity and user experience.

Check out the recording below:

https://yia333.medium.com/building-a-real-time-data-visualization-solution-with-generative-ai-4a560f603696 24/33
02/10/2025 15:56 Building a Real-Time Data Visualization Solution with Generative AI | by Yi Ai | Medium

Conclusion
This visualization solution streamlines the data analysis workflow, making it
accessible even to users without extensive technical expertise. You can enhance this
agent further by incorporating additional visualization types, integrating more data
sources, or improving its natural language understanding capabilities. Enjoy
exploring its possibilities!

Genai Generative Ai Tools Langchain Rags Bigquery

https://yia333.medium.com/building-a-real-time-data-visualization-solution-with-generative-ai-4a560f603696 25/33
02/10/2025 15:56 Building a Real-Time Data Visualization Solution with Generative AI | by Yi Ai | Medium

Follow

Written by Yi Ai
719 followers · 49 following

A Technology Enthusiast

Responses (2)

omar abdeddaim

What are your thoughts?

Arlene Watson
May 22

Sorry to be a negative nancy here... just wanted to mention couple caveats not shared on this article.

1. Text-to-SQL is not reliable. Unless your model is trained (ex. fine-tuning, few-shot or RAG), it won't
generate consistent or reliable result… more

1 Reply

Alan Whitehouse
Feb 11 (edited)

Great post. Question, relating to the chart prompts. Is there a library someplace that contains how to best
build/structure prompts for all the different charts that plotly supports? If not, any tips on how to best
structure the prompt for charts… more

Reply

https://yia333.medium.com/building-a-real-time-data-visualization-solution-with-generative-ai-4a560f603696 26/33
02/10/2025 15:56 Building a Real-Time Data Visualization Solution with Generative AI | by Yi Ai | Medium

More from Yi Ai

Yi Ai

Enabling Agent-to-Agent Interactions through MCP

Implementing Agents-as-Tools Pattern Using MCP with Google ADK

Apr 19 10 2

https://yia333.medium.com/building-a-real-time-data-visualization-solution-with-generative-ai-4a560f603696 27/33
02/10/2025 15:56 Building a Real-Time Data Visualization Solution with Generative AI | by Yi Ai | Medium

In GoPenAI by Yi Ai

Exploring Advanced Reasoning Methods for Domain-Specific, Complex

Text-to-SQL
A Comparative Analysis of Direct, CoT, and Agentic Methods Using Gemini 2.5 and GPT-5 Mini
on Extremely Hard Queries

Aug 7 56

In GoPenAI by Yi Ai

Building a PII-Safe Text-to-SQL Agent with Schema-Constrained Output

A practical guide to using Microsoft Presidio and Google ADK for consistent and secure Text-
to-SQL generation

Sep 7 56

https://yia333.medium.com/building-a-real-time-data-visualization-solution-with-generative-ai-4a560f603696 28/33
02/10/2025 15:56 Building a Real-Time Data Visualization Solution with Generative AI | by Yi Ai | Medium

In GoPenAI by Yi Ai

Fine-Tuning a Text-to-SQL LLM for Reasoning Using GRPO

Rewarding the Thought Process Behind Text-to-SQL

Apr 2 163 2

See all from Yi Ai

Recommended from Medium

https://yia333.medium.com/building-a-real-time-data-visualization-solution-with-generative-ai-4a560f603696 29/33
02/10/2025 15:56 Building a Real-Time Data Visualization Solution with Generative AI | by Yi Ai | Medium

Médéric Hurier (Fmind)

Structured LLM Outputs Made Easy: Building a Slack Digest Agent with
Pydantic AI
As developers and AI practitioners, many of us belong to vibrant online communities, like the
MLOps Community on Slack. These platforms are…

Apr 15 53

In Level Up Coding by Fareed Khan

Building 17 Agentic AI Patterns and Their Role in Large-Scale AI Systems

Ensembling, Meta-Control, ToT, Reflexive, PEV and more

https://yia333.medium.com/building-a-real-time-data-visualization-solution-with-generative-ai-4a560f603696 30/33
02/10/2025 15:56 Building a Real-Time Data Visualization Solution with Generative AI | by Yi Ai | Medium

6d ago 1.6K 36

Malini Anbazhagan

I Tried Building an AI Agent for My Data — Here’s What I Built Instead

As a Data Analyst, I’ve always dreamed of taking my workflows to the next level — automating
the boring parts, eliminating repetitive…

Jun 12 22 2

Vivek Singh Pathania

https://yia333.medium.com/building-a-real-time-data-visualization-solution-with-generative-ai-4a560f603696 31/33
02/10/2025 15:56 Building a Real-Time Data Visualization Solution with Generative AI | by Yi Ai | Medium

Build an AI Agent That Turns SQL Databases into Dashboards — No

Queries Needed
This is a hands-on guide to building a secure, no-code, AI-powered dashboard system that
connects directly to your SQL database.

Apr 17 2.8K 35

In Towards AI by Sarah Lea

CSV Plot Agent with LangChain & Streamlit: Your Introduction to Data
Agents
How you can learn the basics of tool-based agents with LangChain, GPT-4o-mini and Streamlit.

Sep 22 122 4

https://yia333.medium.com/building-a-real-time-data-visualization-solution-with-generative-ai-4a560f603696 32/33
02/10/2025 15:56 Building a Real-Time Data Visualization Solution with Generative AI | by Yi Ai | Medium

Dharmendra Pratap Singh

Building Intelligent AI Agents: LangGraph vs CrewAI vs Agent

Development Kit (ADK) — A…
Introduction

3d ago 1

See more recommendations

https://yia333.medium.com/building-a-real-time-data-visualization-solution-with-generative-ai-4a560f603696 33/33
