    IP ADDRESS ASSIGNMENT

    HOSTS CIDR SM NET. ADD. DEPT.

    30 /23 254 2 172.16.0.0 Prod 1

    200 /24 255 1 172.16.2.0 Prod 2

    200 /24 255 1 172.16.3.0 Prod 3

    100 /25 128 128 172.16.4.0 Training

    80 /25 128 128 172.16.4.128 Accounting

    50 /26 192 64 172.16.5.0 Office of the Executives

    30 /27 224 32 172.16.5.64 Human Resource

    20 /27 224 32 172.16.5.96 I.T Dept.

    10 /28 240 16 172.16.5.128 Server room

    2 /30 252 4 210.10.0.0 Trunk line to Bldg.B

    PROD 1: 172.16.0.0/23

    Workstation Assignment: 172.16.0.2 ~ 172.16.0.22 (Dynamically)


    Default Gateway: 172.16.0.1
    Expansion IP slots: 172.16.0.23 ~ 172.16.1.254

    PROD 2: 172.16.2.0/24

    Workstation Assignment: 172.16.2.2 ~ 172.16.2.18 (Dynamically)


    Default Gateway: 172.16.2.1
    Expansion IP slots: 172.16.2.19 ~ 172.16.2.254

    PROD 3: 172.16.3.0/24

    Workstation Assignment: 172.16.3.2 ~ 172.16.3.19 (Dynamically)


    Default Gateway: 172.16.3.1
    Expansion IP slots: 172.16.3.20 ~ 172.16.3.254
    TRAINING: 172.16.4.0 /25

    Workstation Assignment: 172.16.4.2 ~ 172.16.4.27 (Dynamically)


    Default Gateway: 172.16.4.1
    Expansion IP slots: 172.16.4.28 ~ 172.16.4.126

    ACCOUNTING: 172.16.4.128/25

    Workstation Assignment: 172.16.4.130 ~ 172.16.4.152 (Dynamically)


    Default Gateway: 172.16.4.129
    Expansion IP slots: 172.16.4.153 ~ 172.16.4.254

    OFFICE OF THE EXECUTIVES: 172.16.5.0/26

    Workstation Assignment: 172.16.5.2 ~ 172.16.5.29 (Dynamically)


    Default Gateway: 172.16.5.1
    Expansion IP slots: 172.16.5.30 ~ 172.16.5.62

    HUMAN RESOURCES: 172.16.5.64 /27

    Workstation Assignment: 172.16.5.66 ~ 172.16.5.86 (Dynamically)


    Default Gateway: 172.16.5.65
    Expansion IP slots: 172.16.5.87 ~ 172.16.5.94

    IT DEPARTMENT: 172.16.5.96/27

    Workstation Assignment: 172.16.5.98 ~ 172.16.5.113 (Dynamically)


    Default Gateway: 172.16.5.97
    Expansion IP slots: 172.16.5.114 ~ 172.16.5.126

    SERVER ROOM: 172.16.5.128/28

    Workstation Assignment: 172.16.5.130 ~ 172.16.5.137 (Dynamically)


    Default Gateway: 172.16.5.129
    Expansion IP slots: 172.16.5.138 ~ 172.16.5.143

    TRUNK LINE TO BLDG. B: 210.10.0.0/30

    IP Assignment: 210.10.0.1 (Static)


    Router Configuration

    MAIN ROUTER Configuration

    ena
    config t
    banner motd #This is a private network! Beware of dogs!#
    hostname MRouter
    enable secret cisco
    int se0/0/0
    ip address 210.10.0.1 255.255.255.252
    clock rate 64000
    no shut
    int fa0/0
    ip address 172.16.5.129 255.255.255.240
    no shut
    int fa0/1
    ip address 172.16.5.145 255.255.255.252
    no shut
    exit
    router rip
    version 2
    network 210.10.0.0
    network 172.16.5.128
    network 172.16.5.145
    exit
    line vty 0 4
    password cisco
    login
    exit
    line console 0
    password password
    exit
    end
    copy run start
    Router 1 Configuration

    ena
    config t
    banner motd #Router 1: Welcome!#
    hostname Router1
    enable secret cisco
    int fa0/1
    ip address 172.16.0.1 255.255.254.0
    no shut
    int eth0/1/0
    ip address 172.16.2.1 255.255.255.0
    no shut
    int fa0/0
    ip address 172.16.5.133 255.255.255.240
    no shut
    exit
    router rip
    version 2
    network 172.16.5.128
    network 172.16.0.0
    network 172.16.2.0
    exit
    line vty 0 4
    password cisco
    login
    exit
    line console 0
    password password
    exit
    end
    copy run start
    Router 2 Configuration

    ena
    config t
    banner motd #Router 2: Welcome!#
    hostname Router2
    enable secret cisco
    int fa0/1
    ip address 172.16.3.1 255.255.255.0
    no shut
    int eth0/1/0
    ip address 172.16.4.1 255.255.255.128
    no shut
    int fa0/0
    ip address 172.16.5.134 255.255.255.240
    no shut
    exit
    router rip
    version 2
    network 172.16.3.0
    network 172.16.4.0
    network 172.16.5.128
    exit
    line vty 0 4
    password cisco
    login
    exit
    line console 0
    password password
    exit
    end
    copy run start
    Router 3 Configuration

    ena
    config t
    banner motd #Router 3: Welcome!#
    hostname Router3
    enable secret cisco
    int fa0/1
    ip address 172.16.4.129 255.255.255.128
    no shut
    int eth0/0/0
    ip address 172.16.5.1 255.255.255.192
    no shut
    int eth0/2/0
    ip address 172.16.5.65 255.255.255.224
    no shut
    int eth0/3/0
    ip address 172.16.5.97 255.255.255.224
    no shut
    int fa0/0
    ip address 172.16.5.135 255.255.255.240
    no shut
    exit
    router rip
    version 2
    network 172.16.5.128
    network 172.16.4.128
    network 172.16.5.0
    network 172.16.5.64
    network 172.16.5.96
    exit
    line vty 0 4
    password cisco
    login
    exit
    line console 0
    password password
    exit
    end
    copy run start
