Schlumberger
Copyright Notice
Copyright© 2015 Schlumberger. All rights reserved.
This work contains the confidential and proprietary trade secrets of
Schlumberger and may not be copied or stored in an information
retrieval system, transferred, used, distributed, translated or
retransmitted in any form or by any means, electronic or mechanical, in
whole or in part, without the express written permission of the
copyright owner.
Module 4- Simultaneous seismic inversion and the Inversion property builder .187
Prerequisites ....... ........ .................... .. .... ....................... .......................................................187
Learning objectives ........................................... .... .... ... .......................................................187
Lesson 1 -What is seismic inversion? .................................................... ........................ 188
Applications of simultaneous inversion ..................................................................... 191
Simultaneous inversion workflow .................................. .................... ........................ 192
Input data .... ........................... ....... ................. ............................................................. 192
Output .......................... ... ................... .... ........ ............................................................. 193
Key features ............................... ................................................................................. 193
Simultaneous inversion features and implementation in Petrel ...............................195
Penalty function ................ .. ................ .. ...................................................................... 196
User controls ..................................................................................................... .......... 198
Lesson 2- Inversion preparation: Well tie and wavelet extraction ................................ 202
Seismic trace alignment ......................................... .................................................... 203
Log conditioning/editing ....................................... ............................................ .......... 205
Procedure- Extract a deterministic wavelet.. ......................................................... 206
Predictability displays ............. ............ .............. ..........................................................214
Quantitative Interpretation Table of Contents • 5
General extraction guidelines .................................................................................... 215
Exercise 1 -Extract a deterministic wavelet ..........................................................217
Align seismic volumes with non-rigid matching (NRM) ............................................. 218
Exercise 2 (Optional)- Align data cubes using seismic trace alignment.. .............. 224
Procedure- Condition log data with the Log conditioning tool .............................. 225
Exercise 3 (Optional)- Use the Log conditioning toolbox ....................................... 229
Lesson 3- Low frequency model building and OC with the Inversion property builder .230
Procedure- Convert interpretations to surfaces .....................................................232
Procedure- Populate the model case .....................................................................233
Exercise 1-Create a low frequency model using the Inversion property builder .. 244
Procedure- Use a seismic Inversion OC plot ....... :.................................................245
Exercise 2- Create a seismic inversion QC plot .................................................. ... 248
Lesson 4- Simultaneous inversion and results ..............................................................249
Procedure- Run a Simultaneous inversion .............................................................249
Visualization and quality check of the simultaneous inversion output.. .................... 261
Exercise 1-Set up an inversion case and run a simultaneous inversion ............... 264
Resu Its ........................................................................................................................265
Procedure- Use the Geobody workflow ..................................................................269
Results ........................................................................................................................275
Additional diagnostics ......................................................................... ....................... 279
Lesson 5- Data input for AVOZ inversions .....................................................................284
Review questions ...............................................................................................................287
Summary ............................................................................................................................287
This course teaches you how to use the different workflows in the
Petrel E&P software platform* Quantitative Interpretation (01) suite. It
gives you background information so that you can understand how the
processes work. It also shows you how to run the workflows, what
parameters are used, and how to interpret the output and results.
This course consists of six modules: Rock physics, AVO modeling, AVO
reconnaissance, Simultaneous seismic inversion, Stochastic seismic
inversion, and Lithology classification.
Prerequisites
To complete this course successfully, you must have
• experience working with Petrel
• familiarity with AVO concepts and fluid substitution as used in
E&P subsurface workflows
• completed training courses or have a good working knowledge
of the concepts taught in:
• Petrel Seismic Well Tie or Petrel Geophysics course or
equivalent
• Petrel Property Modeling course, especially familiarity
with geostatistics
Learning objectives
After completing this training, you will know how to:
• run the Rock physics workflows, identify the impact of fluids
on the well elastic paramete~s (computation and crossplots),
and quantify the effects of different fluids and saturation by
using fluid substitution
• run the AVO modeling workflow to generate synthetic
prestack seismic data and extract AVO attributes for use in
calibrating seismic data
• run the AVO Reconnaissance workflow and identify areas of
interest in a seismic data volume based on AVO models
Quantitative Interpretation About this manual• 9
• condition seismic data to use in inversion workflows using
seismic trace alignment
• run the Inversion Property Model Builder to create a low
frequency model for simultaneous inversion
• set up and run a simultaneous seismic inversion
• quality check the output using the inversion diagnostics and
the Seismic Inversion QC Plot tool .
• analyze the results using the Geobody workflow and the results
of rock physics studies
• build a simple pillar grid model and use this model to run a
Stochastic Seismic Inversion
• calculate properties from the results using the workflow editor
• run Reservoir AVO modeling to create synthetic seismic
displays from the output of stochastic inversions for quality
check purposes
• create wedge models
You also become familiar with:
• the concepts of rock physics including elastic moduli, fluid
substitution, and empirical relationships used in rock physics
studies
• AVO concepts and terminology
• different AVO approximations and their limitations and
understand how they are used
• primary and secondary AVO attributes and their uses in
analyzing seismic data
This icon JX>inls you to a tip This icon incicates that the This icon indcates the best
that wiD make your work following information is way to perform a gven
easier. particularly imJX>rtant. task when dfferent Of:XionS
are availalje.
This icon indcates when This icon identities the This icon identities a
you need to proceed with questions at the end of lesson, whch covers a
extreme caution. each lesson. particular topic.
This icon identities the Tlis icon indcates that it's This icon identifies the
steps required to perform a your tum to practice the review questions at the
gven task. procedure. end of each modJie.
This icon identifies any This icon identities any This icon indcates any
prerequisites that are leaning objectives set out ai=Piications, hardNare,
required for the course, or for the course, or for the data sets, or other material
for individual modules. current module. reql.ired for the course.
I I
~
~
~
- i.__- . . ._ r-- -
II
,......- --...,
Petrel Petrel
Petrel Uncertamly Petrel Advanced
Rese!Volr and Advanced Uncertamly
Eng1neenng Oplilllllabon Wells and
(5 day cour~) Fundamentals Oplirmzahon
;::- =::! :=::::~~-=~ :=:.c:::~ - -
Petrel Petrel
ReseiVOir WorkHow
Petrel Well
Engmeenng Editor and
Design
(3 day course) Uncertamly
AnalysiS
~----~ ~ ~ ~ ~-~:~ ..==~
Petrel Petrel Well
Fundamentals Deliverabllity
Petrel
Petrel
Geophysics •
Petrel
Quantitative
INE.r.T blended
GeophysiCS COOI'S99USing
Advanced Interpretation Petrel
Despite good seismic quality and well control, the correct interpretation
requires quantifying the connection between geology and seismic data.
The Rock Physics module establishes this link by computing elastic
parameters. When pore fill and lithology are crossplotted, they can be
differentiated and potential reservoirs can be identified.
In addition, the fluid substitution assesses how changes in the fluid
content affect the seismic response.
Learning objectives
After completing this module, you will know
• the global Quantitative Interpretation (01) workflow
• basic rock physics concepts
• how to set up and run a rock physics study to:
• estimate elastic parameters
• perform fluid substitution modeling
• perform shear property estimation from Pwave velocity
logs
• perform log blocking by using Backus averaging
• how to crossplot results for analysis
El lc: para
Fluid predict & AVO Modelinc AVO Modeling (Module 2}
Utholo,. an on
AVO Reconnaissance (ModuJe 3}
---
_______.,....,
Figure 2 Global Quantitative interpretation workflow using Petrel
cu
u
c
nJ
""C
cu
a.
E
u
~
=
0
u
<t
Gas Sands
Poisson's Ratio
Figure 3 Acoustic impedance versus Poisson's ratio. The trend lines show
where data from specific lithologies tend to cluster
ell
u
c
ns
"'C
ell
a.
E
u
-~
:s
0
u
<(
Gas Sands
Poisson's Ratio
-~~~~~~~~~~~~~~~~~~~
13 -
-
12-
~ 11-=
-~ 6 -
~
-;
s-j
3
0
Poisson rabo_Study 1 (Rock physics]
Figure 5 Acoustic impedance versus Poisson's ratio for actual well data with
points from a known gas sand highlighted in the polygon
The first part of this training class focuses on the Rock Physics process.
This process enables you to compute elastic parameters such as
acoustic impedance (AI), the Vp/Vs ratio, and Poisson's ratio from well
data. These physical rock properties then can be interrogated using
Petrel crossplots to determine which parameters can help identify
reservoirs and hydrocarbon bearing zones. You also look at the impact
of different fluids and saturations through fluid substitution exercises.
Then, you look at the AVO Modeling process. This process provides a
link to the seismic data by modeling the AVO response of your elastic
properties, derived from your seismic data. It uses the results of your
rock physics studies, such as fluid substitution, to characterize the
range of seismic response to different conditions. The objectives are to
24 • Rock physics Quantitative Interpretation
connect the seismic data to the well data and allow you to make
predictions about fluid content and reservoir presence and quality
where there is no well data.
After the AVO modeling process, you use the AVO reconnaissance
workflow. This workflow allows you to combine conventional data
screening for structures and amplitudes with on-the-fly calculation of
AVO attributes. AVO reconnaissance relies on Rock Physics and AVO
modeling processes to characterize what AVO signatures are useful to
identify potential hydrocarbon zones. Combining the search for potential
structures of interest with an analysis of the AVO response allows for a
more efficient screening and ranking of potential prospects.
Finally, you look at two types of inversion; simultaneous inversion
and stochastic inversion. Simultaneous inversion inverts seismic data
to calculate property volumes that contain acoustic and elastic
properties such as acoustic impedance, VpNs ratio, and density. You
then can use these results with the rock physics studies to identify and
map reservoir facies and fluid accumulations.
Stochastic inversion also inverts seismic data. It incorporates
geostatistics to create many alternative scenarios for the subsurface.
Each scenario is consistent with the well and seismic data. These
different scenarios can help you understand the distribution of the
reservoir in a particular formation and get a higher resolution. It also
allows you to calculate the uncertainty in quantities such as the gross
rock volume and reservoir quality.
Reflections
Offset
Figure 6 A simple seismic experiment with one shot and an array of receivers
Density
If you look at a thin section from a porous rock, such as the one shown
in Figure 7, you see that the rock is made up of grains and spaces
between the grains. The grains form the rock matrix, and the spaces
form the porous portion of the rock volume.
Figure 7 A thin section showing the grains of the rock matrix with porous space
between
In the subsurface, the pore space is filled with fluids, usually brine. In
the places of interest to you, the pore fill can be oil or gas. Other rocks,
for example shales, have different structures, but in this course, you are
interested in rocks with pore space to trap oil and gas.
In this formula:
• pb is the bulk density of a volume of the rock (including pores and
pore fill)
• pmis the density of the matrix, the material that forms the grains
• pwand PHcare the respective densities of the water (brine) and
hydrocarbons that fill the pore spaces
• <1> is the porosity or the fractional part of a sample of rock that is
pore space
• Sw is the water saturation in pore space expressed as a fraction
from 0 to 1
The velocity with which the seismic energy travels is more difficult to
calculate. First, you must consider how the energy is traveling.
P and S waves
Two modes in which sound can travel in rigid materials are the
longitudinal or P-wave mode and the S or shear wave mode. These are
known as body waves.
NOTE: Pand S stand for primary and secondary. These terms originated
in earthquake seismology and refer to the order in which the waves
arrive at the detectors.
These two modes are differentiated by the direction of particle motion
in the rock as the wave passes through.
In Pwave mode, the particle motion is along the direction of
propagation. In the shear mode, the motion is perpendicular. Figure 8
shows Pwaves on the left and Swaves on the right.
direction of direction of
particle particle
motion motion
c
0
·usc
•
-..
Cl)
)( ·;c
·=
...
cg w
•
U)
;,;
-
....-------, c.J
(,)
·c
~
·~-·
E
.:0
•
>--
.§--
0
c
0
·;;
(I)
~
=-
E
0
• z
>
0
(..)
Direction of
wave propagation
Compressional
motion
Figure 10 Effects of shear and compressional stresses on the grains and fluids
in a small rock sample
From the illustration, you can see that these two processes are different
mechanically. In Pwave propagation, compressing a volume of rock
involves compressing the grains and the fluids in the pores. It involves
the mechanical properties of both constituent parts of the rock volume.
In S wave propagation, the grains and fluids are not compressed, so
shear waves are subject to a different set of mechanical properties.
There are two parameters that describe how the rock deforms in
response to the shear and compressional stresses shown in Figure 10.
These parameters are examples of what are called elastic moduli. The
amount by which the rock deforms when subject to a shear stress is
characterized by the shear modulus, usually represented by the symbol
Jl.
The amount by which the rock deforms when subjected to a
compressional stress is characterized by the bulk modulus, which
usually is represented by the letter K
v.p =F+ip
p
The Swave velocity is given by:
v.
s
= ~
~p
In these equations:
• K is the bulk modulus of the combined rock and fluid system
• ~is the shear modulus for the combined rock and fluid system
• p is the density
You generally are familiar with typical ranges for velocities. Brine has a
Pwave velocity of around 1,490 m/s. High porosity gas filled sands can
be similar. On the other end of the spectrum, dense anhydrites, highly
cemented rocks, and volcanics can have velocities as high as 6,100 m/s.
Looking at these two formulas, you can see that
• Vp depends on the bulk modulus (and, therefore, on the fluids in
the pore space, because the fluids are compressed along with the
rock frame when a seismic wave passes). It also inversely depends
on the density. Thus, when pore fluid changes, both the density and
the bulk modulus contribute to a change in Vp.
• Vs depends on the shear modulus, which is not influenced by the
pore fluids (because they are not deformed by a shear stress).
Therefore, a change in pore fluids changes only the shear velocity
through its inverse relationship with the density.
• Shear waves travel more slowly than Pwaves.
The magnitude of these fluid-related changes is discussed later.
a= C· e
In this equation:
• a is the applied stress
• Cis a constant of proportion, in reality a tensor
• e is the deformation or strain
When the material being deformed is isotropic, the tensor simplifies
considerably and there are only two independent quantities. Different
convenient moduli can be defined related to these two moduli. Tables
that show the relationships between the constants are available in a
number of publications (for example, Simm and Bacon, 2014, Seismic
Amplitude, An Interpreter's Handbook, p 12).
These elastic constants are of interest to seismologists:
• E=Young's modulus
• Jl =Shear modulus or rigidity
• k =Bulk modulus or incompressibility
• cr = Poisson's ratio
• 'A = Lame's constant
'"....., ,-··········=·~ } DJ
II~-·············<:
Figure 11 Change in length as a result of an applied stress
In this equation:
• a, is the stress expressed as a pressure
• !J.L/L is the fractional change in length
• E is Young's Modulus
The Young's modulus also can be calculated from Vp, Vs and P (inputs
in Petrel) as:
E = (1 + a)2tt
In this equation:
• a is the Poisson's ratio
• Jl is the Shear modulus
Some published values of Young's modulus are
• Quartz: 95.8 GPa
• Dolomite 116.6 GPa
In these values, a giga Pascal (GPa) is equivalent to 10 10 dynes/cm 2.
(Values are from Simm and Bacon, Seismic Amplitude: An
Interpreter's Handbook, 2014.)
In this equation:
• as is the shear strain
• ~ Y/X is the proportional deformation
• Jl is the shear modulus also called the rigidity
The Shear modulus also can be calculated from Vs and p (inputs in
Petrel) as:
f1 = pVsz
In this equation :
• p is the density
• Vs is the S-wave velocity
Figure 12 illustrates these terms.
~y
. . :::·:::~··_··--~---r
as---!-"+
No volume X
change
In this equation:
• Pis the confining pressure
• L1 V/Vis the fractional change in volume
• K is the bulk modulus also referred to as the incompressibility
The Bulk modulus also can be calculated from Vp, Vs and (rho symbol)
(inputs in Petrel) as:
K =pVp2 - (4/ 3)pV/
In this equation:
• p is the density
• Vp is the P-wave velocity
• Vs is the S-wave velocity
As shown in Figure 13, confining pressures result in a shrunken volume.
The fractional change in volume associated with an applied stress is
related through the bulk modulus.
Poisson's ratio
Poisson's ratio is one of the most important physical quantities used in
the 01 workflow, particularly in AVO analysis. You saw that when it is
combined with acoustic impedance, it can be used to discriminate
between reflections caused by different lithologies and fluid contrasts.
If you stretch (or compress) a solid, the length changes. The stretching
(or compression) also tends to change the cross sectional area of the
solid as shown in Figure 14. Poisson's ratio relates these two changes.
... hn~
~·o· ... .. ....... .. .. ... .. ........ ..... .. .. .. .. .. .. .. .. ......~o··. ····r!}·dh
· ...
~:·::~.................................................. _ .. :r.:=·
L
L+.6.L
Figure 14 Changes in length and width are related through Poisson's ratio
In this equation:
• t1UL is the longitudinal strain
• !1h/h is the transverse strain
• cr is Poisson's ratio
Poisson's ratio can be recast in terms of the Pand S wave velocities,
which are more intuitive to seismologists. The relationship is
(?.)' - 2
a= 2[(~) 1] 2 -
Vp/Vs
0 .6
0.5 ,.......
! /
!
-: 0 .3
0 .4
j
v
0
Ill
JA
l. 0.2
I
0.1
j
0
0 2 4 6 8 10 12
Vp/Vs
Figure 15 Graphical depiction of the relationship between the VpNs ratio and
Poisson's ratio
From the graph, you see that Poisson's ratio varies from 0.5 at very high
VpNs to 0 when VpNs is equal to J2.
If you think of how Vp and Vs behave when you introduce gas into a
previously brine-filled porous sand, you expect Vp to decrease in
magnitude because gas is easier to compress than brine, so the rock
has a smaller bulk modulus. Also, you expect that the shear velocity is
little affected. Therefore, VpNs decreases, and, from the graph in
Figure 15, Poisson's ratio can be expected to decrease as well.
Poisson's ratio enters into several of the approximations for amplitude
behavior versus offset that you review later.
Gassmann's equation
Gassmann introduced the most frequently used way to calculate the
new bulk modulus. Gassman published the equations (Gassmann, 1951)
that describe how the Pwave velocity depends on the properties of the
various parts of a mixed system composed of a porous reservoir and
different fluids. Gassmann's formula for the Pwave velocity is a
modified version of the formula for velocity shown earlier and takes this
form:
Y-
p
= F+ ~JL p
You can see that the first term in Gassman's equation really is the bulk
modulus for the saturated rock. What Gassmann has done is to give a
way to compute the bulk modulus from knowledge of the constituent
parts of the fluid filled rock.
Typically, the fluid substitution process consists of several steps:
• If Vp, Vs, and density are known, you can ca lculate the shear
modulus I""'
11, and with that value, you can calculate K
sat
• If you calculate Ksa t' then with a knowledge of both the porosity
and the fluids in the pores and an assumption about the mineral
that makes up the rock frame, you can calculate Kdry also.
• With this result, you can use the formula to calculate the new
velocity that results when a different fluid is substituted into the
pores.
• Values for the fluids (brine, oil, and gas) can come from laboratory
measurements or from empirical equations such as those published
by Batzle &Wang (1992). These equations are implemented in
Petrel.
• If shear velocity information is not available, you might have to
make assumptions to calculate~ -
average. Again, if there are more than two components in the mixture,
additional terms are added to the right side of the equation.
As stated, the Hill average is the arithmetic average of the Reuss and
Voigt averages.
High High
,-_JLD....._______,_) ....0
Ill
a:
-"'c
~
·a
a.
Vs
Figure 16 The effects of different water saturations (that is, gas saturation) on
P and S wave velocities and on Poisson's ratio
Most of the effects are seen over a small range of saturation values
when the gas saturation still is quite small.
Vs changes little, except for a small increase in saturation because of
the inverse relationship with density. The introduction of gas lowers the
Pwave velocity substantially. Most of the decrease occurs with the
initial introduction of gas into the system (hence the difficulty in
determining low saturations from seismic measurements).
If oil is substituted instead of gas, the velocity would decrease as well,
but less so than with the introduction of gas. The oil gravity and the
Gas/Oil Ratio (GOR), or the amount of gas in solution, influences the
result for oil. Some oils with high GORs can produce a significant
velocity decrease. As expected, Poisson's ratio also drops given the
significant change in Vp and the small change in Vs.
In the case shown in Figure 16, Vs was affected only mildly by fluid
content, but shear velocity can be affected by lithology. Vp depends on
both fluid content and lithology. Thus, if you can isolate the Pwave and
S wave responses in a reflection, you have a potential recipe for
42 • Rock physics Quantitative Interpretation
discriminating between fluid and lithology changes. This process gives
you a powerful way to polarize anomalous seismic responses and
improve risk analysis of subsurface opportunities.
Figure 17 Simple seismic experiment with one shot and an array of receivers.
An example of the seismic data that would be recorded is shown in the lower
part of the figure
Reflected S
lncidentP
Figure 18 The different components of the reflected and transmitted wave field
that result from an incident P wave
· PoW!IVCIV8Joci1y MW
.S.W.tve wtocity n.aw
·Oan.tilynew
·I< sat
·P-wwve ~e:oa1y dry
.S·wave veloe>1y dry
·OensMy<Jry
.f<dty
-&\eat mottulua
·OeiiSIIytnlneraJ
·Kmlnet~~l
-tlensaly :fluid
·K fiuid
·Oen !lily fluid II'IOC!IIIe<l
·K nuid modo!od
l
r~
- -- - - - -
Study 1 [Rock physics]
Input Output
V. S·W!Ive velocity ~ [ V. vs
p Density· ~ [ ~1 RHOB
3. Select the well to be used in the study from the Well list or
insert the well to use from the Input pane.
Ix Close I
NOTE: Setting depth ranges is covered later in the course.
4. Select the Operation type from the list.
6. Open the Input tab and use the lists (or the blue arrows ) to
enter the well log curves to be used.
You can use velocity or transit time curves as input.
Input Output
Poensrty: ~~ ~1 RHOB
The settings dialog box for the new Well section window
appears.
2. In the X-section area of the window, select Create new
x-section.
3. In the Template area, select Create new template.
[g Select new well section window settings
n X-section - - - - - - - - - - - - - - -
~) Cre«e newx~ : X~
) Usel!ldstlr~!efnplate :
( ..- OK III(CMcel
4. Click OK.
An empty Well section window opens.
----~-•!!? . "-·.
~::~'G:_~._:_-4.'7;=.. ~~~: -~ ~~;:_;~~~ ......::- ·-~~Adll ~i":"~~.:::.~=~-=~~~ 3~ . ..
~f~~z.-... s...::~~c-:r~~l~"' ~ --.c:u_.~:.:...:~ ~ff~~~~~ .-:
'!:]:;:&J~1~~1:\"!"';~:..~...,:i... ~~-i~1.~.&...J.;J~Z~7~-·,~)-'f'";:"""~1 ~):':~_;,."L~~;-....,;:r.l!,~'!l"~_;..,.~r~"-'i '!J-; '!1§.
..
~t~tf~~!J'"".ai!r_t~~?i-~~ia:~\\M,~~~~,
1000
1200
I I\
~~ ~5·~-11
New QI crossplot
New t.® Collection settings I
window collection lSi Classification data
QI crossplot
X ( ~---------~-----~-~-------~-
y [~----------------------~
Z:
Pointattnbutes - - - - - - - - - -
.., Color --
__. "--- ----------
X: @ Lineor 0 Logorithmic
Y: @ Lineor 0 Logorithmic
Axis ronge
Min. Max.
X: 0.2 ~ 0.5 ~ EJ Lock
Y: 2 ~ 14 ~ 0 Lock
13
12
........
. . .:
"'··...
... ..... ~
~ni
0..
11
·. ...... . •.....'II',·:• ...
-~
'·~
~
w
~
10 .. .... ... . .
.c
Q.
.\ .,:1 .. ..
..><:
u
. : ~.r· ..
. ..-. .. .......
0
~ • ·.c ...
~ .:~,:-..
>.
'0
2
1/)
I
B
lij
'0
Q)
-~
~0
~
Poisson's Ratio
.... .. ~~.
·. :.-::.::.::...
. '·
•
~
·,.~· 'I'"
.. ..
. \i: .•
.,;
. .....
41,- r l -r> T
Oll
'T ' ' ' ' T r' '
0 24 027
QI Crossplot
Class!icatlon
da a
Classification data
4 111.$. ~ Wells
1-
4 ~ Global we/flogs
I> A· Log attributes
0 Rock Physics Input
0 Petrophysical Properties
4
0
~
AI
I. ..
Synthetic
•. [
l
~
r[
f
I
L
I
I-·::\
JJ
,I oo._:; _- _ o~ ~·
10.33- - 0.33~
~0.30 - - 63() ~
6- 0~7 - - ()-2' \.
l
.E. 0.14 - - 0 .1.4 ' ~
r J.o
i
,- 0 . 11
New Ql crossplot N ew
!"@
t: Collection settings I.
window collec ion [Si Classi'ica ion dat a
Ql crossplot
8 tnto-
A Wells . y-
1 [Acoustic mpedence Ptudy 1 [Rock physics]
~ ~ Jupiter-1 1
IZ: [._S.¥;_'1_ _ _ _ _ _ _ _ _ _ _ .~
· Pointllttributes - - - - - - - - - - - [ }
4 ' 6 7 t f H ll U U
~--------------------------
~ Kftuid:
0 Reuss
I~ Use presets T J
Name Mineral fraction Bulk modulus Density
~""--===--=---
fiJ I
~I
6 Gas 35.00% 90.00 %
~I
Oil 0.00 % [tJ 0.00 %
[tJ ..
~ Weter [{] 65.00 % 10.00 %
iiiiiil
Fluid properties 13
I
GIIS gravity (sg 8ir): 0.6000
0 0.6000
Oil gravity (API): -J 300 -[}-- 30.0
GOR (sm'/sm'):
J
-J 100.0
-o 100.0
Salinity {ppm) 3800.0
0 3800.0
LJ Include gas weter mlio 0 Include gas m~ler ratio
Reservoir condrttons
I~
P Pressure: D
--
6000.00 MPll ... 6000.00 MPll ...
T T~pereture: 0 so.oo ·c ... 80.00 'C ...
clicking this button [~] to the right of the We// field in the
upper part of the dialog box.
~ :X
- --- - - - - - - - - -- - - - -
Fluid Substitution 1
Rock physics
(7< Close I
g. When you are finished entering depth ranges, click Close.
78 • Rock physics Quantitative Interpretation
14. When all parameters are set, click Apply.
Entries appear in the Input pane in the Global well logs
folder, in the Rock physics studies folder. The entries also
appear in the Well that contains entries for the fluid
substituted logs.
This figure shows the Global well logs entry.
"' 0 Auid Substitution 1
vP 0 P-wave velocity sat_Auid Substitution 1
V: 0 S·wave velocity sat_Auid Substitution 1
P0 Rho sat_Fkid St.bstitwon 1
This figure shows the Rock physics studies entries.
"' ~ ~ Rock physics studies
~ 0 Bastic Parameter Estimation Stuct1
~ 0 Ruid Substitution 1 .
TIP: You can use settings in the Rock physics dialog box to
adjust the display interactively. In the Rock physics dialog
box, select Edit existing and the study that you want to edit.
The study parameters load into the window. To adjust the
saturation and fluid properties, use the slider bars. The plot
updates interactively.
' ,J EdiiE!XlSttng:
WeU: ~~....:.
[~ ~Jup:......iter_-1_ _ _ _ _ _ _ _ _......)
Operaton type· [ SheM veloctty estil116tion
l iv;,n~P-v.~.-e
l
0ul!l'Jt --------------~ 1
~~ ~
'-1
I I
[ Atp OT ?
Con·p1.~s earV>?Ie I
I
' M10drodc lu-e '
Vs= tvp· ~}!~_(n-/s ) 0
Fil:~~- ~( Y GH ·I
Culof- ----(}-- ~ ~1
11. To create the new shear wave log, click Apply or OK.
~~ 1,'1/ell: § [..._~
.;.__
Ju_pit_e_r-1_ _ _ _ _ _ _ _ _ _ _...,-'1
~: v; vp
~; v. Vs
~~ q 8 RHOB
~( AJ ~~_EP
Para eiers
Blocking f8Ctor
Q 0 100
B. Click Apply or OK
~ S-11.-ave velocity: ~ [ v; vs
Par.:meters --------------------------------u
Blocking factor: ~-------· ----- 0137
o.aa m
V: S-wave velocity: ~ [ v; vs
~( q8 RHOB
¥. Blocking log: ~ (AI Acoos6cimpedance_Sb.Jdy 1[Rock: physics] PAF "' J
Parameters
Summary
In this module, you learned how to run the various operations in the
Rock physics process and display and interactively crossplot results to
visualize the rock physics relationships. You performed these specific
operations:
• Elastic parameter estimation
• Fluid substitution
• Shear velocity calculation
• Log blocking Backus
You also learned about some basic theory regarding elastic moduli,
empirical rock physics relationships, and Gassmann fluid substitution.
Prerequisites
To complete this module successfully, you must have completed the
previous module in the course.
Learning objectives
After completing this module, you will know about:
• different equations that describe the relationships between the
amplitudes of incident and reflected seismic waves including:
• Zoeppritz equations
• approximations that are used currently in Petrel for AVO
modeling and inversion.
• classification of AVO responses into different commonly used
classes
• how to set up and perform an AVO modeling study
• how to create crossplots to analyze the results
• how to create a wedge model
I•i ~
I
~ i
g
VI
~~
5· ffi
GJ
~
0 :3 (6
t- c ~
0.
(') (p
I .__ ~ r- I ~ -[ (')
~
!; ~~
l
&
li: i'
!
1
!
0
3
r:;.) 5 '
....... :E
~
!
~
&.
Ill 0
1- ~
CD
.a; :§
:§ ~
c:
= I
(il ~ (/}
.__
0
8;a
~
1
~ )>
::: lc;
& ;i"'GJ g, 0
! c if~ <D
i5 ~ ~ Ql
{II
Ql
!,ltr.n
liil
..___
-~
~ ~.....-
I
~
fll §,iii
g :2.
:E~
-...
~·
~
tO
J-· I
i
fll
~
:E I
0 DDD
::0
It> p~
:::;.
;§ %
~ s :i
.,
~
'< ~ ~
::;
~
a~ ~~ s
~
~- ~ r.Q
~ "C
,.,""
~
Q;)
~
~
!I>
~ ~
Reflected S
lncidentP
Transmitted P
Transmitted S
Figure 2 An incident P wave and the resulting energy that is reflected and
transmitted. The terminology is the same as in the Zoeppritz equations.
In this equation:
• a = average Vp across the reflecting interface
• ~ = average Vs across the interface
• p = average density contrast across the interface
• 9 =average of the incident and transmitted angles
• d of each of these quantities are the changes in these properties
across the interface
• y = Vp/Vs
The advantage of this approximation is that it also can be represented
in terms of:
Rpp(9) =R(O) + G sin2(9) + F (siri (9)- tari (9))
It is often called the AVO equation where R(O) commonly refers to the
Intercept (Normal Incidence), Gto the Gradient or Slope and Fto the
Curvature (Far offsets).
This approximation also is a widely used result. Whereas the Aki-
Richards formula emphasized the changes in density and Pand S
velocity, Shuey's result emphasizes the angular dependence by dividing
the reflectivity neatly into several terms. These terms become
increasingly important as the incident angle increases.
The first term is a constant term that is the normal incidence reflectivity
when 9 = 0. As the angle increases, the second term starts to become
important. Its coefficient depends on both the contrast in Vp and Vs as
well as the ratio of Vp to Vs and the density.
The third term is small at small angles. As the angle increases, it
becomes significant and controls the shape of the angular re lationship
for large angles. Its coefficient involves only the Pwave velocity
contrast.
In this equation, Pis referred to as the intercept term. From the full
3-term equation, it is equal to the normal incidence Pwave reflectivity.
The term G is called the gradient term. If Vp/Vs is taken as equal to 2,
then with a little algebra, it can be shown that the gradient can be
expressed in terms of the normal incidence Pwave and shear wave
reflectivity, as shown in this equation:
G = Rpp(O)- 2Rss(O)
This approximation is useful and helps you to visualize how the
amplitudes behave in terms of the Pand S wave reflectivities.
The terms Pand Gare examples of what are referred to as Primary AVO
attributes. They are quantities that can be determined directly from
fitting prestack seismic amplitudes to (in this case) the 2-term equation.
Quantities derived by combining primary attributes are called secondary
attributes.
Because the Shuey 2-term equation drops the third term, it should be
used with caution at angles above 30 degrees.
Although the 2-term approximation can be applied over a limited angle
range, it often is used when that limitation is met because of the wide
range of attributes that can be calculated from the primary attributes P
and G. These attributes are discussed later.
PR = w (P+G)
Shales
R
Gas C)
sand . Wet
sand
Gidlow approximation
In 1987, Smith and Gidlow derived an approximation also based on Aki
and Richards results (Smith and Gidlow, 1987). Their interest was in
creating weighted stacks to highlight Pand S wave reflectivity and Vp/
Vs contrast. By making assumptions about what the Vp/VS ratio was,
they were able to highlight the presence of gas by deriving a Fluid
Factor attribute.
This equation is their expression for Rpp in terms of P impedance
contrast, ~1/1, and shear impedance contrast, M/K (refer to the
104 • AVO modeling Quantitative Interpretation
Petrel Help). The approximation is shown in this equation:
tll tJK
2 cos 2 (8) Rpp(8 ) =I +2Ksin2 8 cos 2 e
In this equation:
• 8 is the average angle across the boundary
M
• [ = ZRpp (O) or twice the normal incidence Pwave reflection
coefficient
f1 K
Rpp(8) 1+
= - (1
2
----E- 4 P
tan 2 8) Ill
IP a 15 2
(1
!l/3- · -tan 2 8 - 2 · -
- sin2 8 -
a
(p) 2
sin 2 8 ) -!J.p
p
Rpp(e) .~c cos 2 e = ~ (6P + L\a) + (- 24 (~ L\a + L\{3) - ~ L\p) sin 2 e + ~2 (~ L\p + L\{3) sin 4 e
2 p a y 2 a p 2 p y 2 p {3
When angles are greater than 30 degrees, the observed variation of
amplitude with incident angle is close to a parabola. This approximation
was therefor created:
2 4
Rpp(8) .tt cos 2 8 = a + b sin 8 + c sin 8 (with a constant term
called a, a linear term called b, and a quadractic term called c).
In the first equation:
• e =average incident and transmission angle
• Rpp(8) is the Pwave reflectivity as a function of e
1116 • AVO modeling Quantitative Interpretation
• a, ~.and pare the average Vp, Vs and density above and below
the interface
• ~·s in these quantities are the differences between the values
above and below the interface
• y= VpjVs
This equation leads to three primary attributes, which are the
coefficients a, b, and c in the equation, and secondary attributes that
are derived from combinations of the primary attributes. These
attributes are
t!Jp
Densitv
• contrast: -=
p -2(b +c)
JiJVJ
The P wave o-r Uniaxial compressional m od-ulus contrast: - = 4a + 2(b +c) and M
M
= A+ 2J1
tlVp t::.a
The P ~·vave velocity contrast: - = - = 2(a + b +c)
vP a
If a value is assigned to VpjVs (y), additional secondary attributes can
be calculated:
calibration of the AVO response using the sand and shale properties actually observed is a must for any definitive statements to be made.
0.2
0.1
-0.1
-0.2
Rpp(O)
+
Offset
h Jterr:epl
If the seismic data that you are studying is clean and well behaved with
little organized or systematic noise contamination, then a conventional
least squares fit suffices. In Petrel, this fit is referred to as the
Standard method.
On real data, however, when organized or systematic noise (termed
coherent noise) is present (such as, multiples or other non-random
interference), a better fitting method is required that is not as sensitive
to what might be potentially large outlying amplitudes in the gather.
The Robust method uses a method proposed by Walden (1991) that
uses statistical tests to identify and avoid outlying high amplitudes.
Specifically, the data is divided into offset groups and median values of
the amplitude are calculated for each group. A fit is performed to these
median values and residuals are calculated. Outliers are weighted
down or eliminated and a fit is performed to the remaining values.
Because the median value is less affected by outliers than the average,
this method is less sensitive to outliers than a standard least squares
fit. The Robust method provides better results on real data when noises
are present.
114 • AVO modeling Quantitative Interpretation
Lesson 5- AVO Modeling study
In Module 1, you saw how the elastic parameters were affected by the
presence of hydrocarbons and how crossplots of different parameters
can be used to identify hydrocarbon zones in a well. You then saw how
it is possible to quantify the effects of hydrocarbon saturation on these
parameters by performing fluid substitutions and how different
saturations affected the rock properties.
The next step is to predict how seismic data responds to the presence
of different fluids and saturations. The objectives are to establish the
tie between the AVO response of the seismic and the well data at the
well location and to use modeled seismic responses to calibrate
potential prospects and appraisal well locations.
To accomplish these objectives, you perform AVO modeling to
characterize the AVO response of different saturations and different
fluids: oil, gas, or brine reservoirs in an area. This AVO modeling study
can be performed on both the actual conditions at the well and modeled
cases from fluid substitution.
When creating synthetic gathers, you can compare them to a prestack
seismic dataset you loaded in your project.
Two format of gathers can be imported to Petrel:
• 010 format allowing seismic data to be indexed for a quicker
data index. This format only is supported by the Prestack
Seismic Interpretation (PSI) plugin. This is a separate license
available on the Ocean store.
• SEG-Y format available to be directly imported in Petrel.
Y:
---
077 · 080 : trhSourceYCoordmate ... m
2344
-- 24 16
---
Secondary header range.
10
- -- --
Maximum trace per gather.
Name:
-
PrestackOataSet[SEGY]
-
Value range scan option: Random Scan ....
- -
·20.000.000
- --
15.513.578
-
1., OK
II~ Cancel II
0 Cre8te ~====~============~~~
Avo modeling study 11 ~
• 0 Edit
Input [ 1 Algorithm j
Well: ~~......~:..;_·J_up,:..;_iter_-1_ _ _ _ _ _ _ _ _-J
Wavelet
Wavelet
Scele fllctor·
1 P-wevevelocity - - - - - - - - - - - - - - -
Log: ~.._I\fo...:....p_..:.Vp_ _ _ _ _ _ _ _ _ _ _J
S·wevevelocity - - - - - - - - -- - - - - -
Type: !Log
~==================~
Log. ~~IV:-=-•_
vs_ _ _ _ _ _ _ _ _ _--'
I Density
Type: !Log
Log: ~~~~=a=
RH=OO==================~
[J Auto-update l Canoel j
Log:
• VpNs ratio: Select this type to use a constant VpNs ratio for
the modeling and enter the value for the VpNs ratio.
S-v,-ave velocity - - - - - - - - - - - - - - - - - ---l
Type Log
l09
Synthetic - - - - - - - - - - - - - - - - - - - -
Anglerange - - - - - - - - - - - - - - - - - - -
Startangle : o ! degrees
End angle.
~--·-----~- - ------ 35 : degrees
Angle step
~----- ----- ----- 5 : degrees
Seismic display
Observed gather. ~
10. To run the AVO Modeling, you get the location of the modeled
pre-stack data by clicking D.
120 • AVOmodeling Quantitative Interpretation
11. In the Synthetic section, complete these steps:
a. Edit the Seismic name if desired. This value is the name of
the synthetic that is generated.
b. Select the Algorithm to be used from the values shown in
this figure:
s~~e~ ---------------------------------------
Seismic name: Avo modefing study l synthetic rt.:il
n:r•
Output file: -C-:\,Uset"S
-- ',C_Deslr _ _~
_ ebecql -esldo
-- pi~
-'Y'-
0-model
-- segy
-- o
End angle:
Angle step:
"\fnelet
.[l
Q)
.:1
:~
Ci.
E
<(
1900
~
nr spectn
2100
l~J IJO
'quency (H
ase spectnJ
jj IJO
~quency (H
15. You can customize the Well section window. Click the Well
section window Settings button in the tool bar.
I ~ ~ I SS _ .. ~ ~Jell sectio;!empl .. ~
,.,
I~
· '--~ Avo modeling s1udy 2 S) '
1 B- 0 A Wavelet Vp_edited YP0Vp_edited
'
!--+4
'--01J.,.. Wavelet
Borehole markers ~
' ~ Background
~- L Deviated tracks (0) I[Q]
You can select the tracks to display in the Template objects
area of the dialog box and insert additional tracks. Select the
data to be displayed within a track from available data types
on the Definition tab in the Objects settings area.
AVO
Synthetic - - - - - - - - - - - - - - - - - - - -
Seismic name:
Output file:
Algorithm:
Sample interval:
Well: ~( ~ Jupiter-1
Prest8clc dataset ~ ~ Avo-;odeling study 1 synthetic
Output folder name: Shuey 2-terrn_Avo modeling study 1 synthetic
AVO methods - - - - - - - - - - - - - - - - - - - - -
4. On the Inputs tab, in the Inputs section, verify that the well
(where the result will be stored) and the Prestack dataset (in
this case the synthetic) are correct.
If the attributes are being calculated for the observed seismic,
then the real seismic dataset should be entered as the Prestack
dataset, and the gather closest to the well is selected
Quantitative Interpretation AVO modeling •125
automatically for attribute calculation. Use the blue arrows to
enter a different selection if desired.
The Output folder name is filled in automatically based on the
Algorithm selection (refer to Step 5). You can edit it if another
name is desired.
5. In the AVO methods section, select the algorithm to use to
calculate the attributes and the method to use to fit the data.
a. In the Algorithm field, select the method to use from the
list. This figure shows the available methods.
WO~s ------------------------------------
Algorithm Shuey 2-term
~~mOOe -----------------------------11 1 11
t~ 1~----------~----------_J
~ ·I
Scale factor: 210fgj
Overlap: 0 ....
~
6. Open the Output tab and select the primary and secondary
attributes to be ca lculated.
NOTE: The attributes displayed on this tab change, depending
on the Algorithm that you select.
This figure shows the attributes for the Shuey 2 term algorithm.
Pmre~~~ -------------------------------------
lntercept Intercept
Gr8dient
Second8~ 8tiJ:ibutes
0 Chedt811
0 I
Reftection coefficient difference: RerJEdicn coefficient difference
R.otabon angle: 0 ::
Primcry attributes - - - - - - - - - - - - - - - - - - - - - -
Acoustic imped1snc:e contrast Acoustic impedance contrest
Secondary attributes - - - - - - - - - - - - - - - - - - - - - - -
0 Checkall
This figure shows the attributes for the Pan and Gardner
algorithm.
Primcryattributes - - - - - - - - - - - - - - - - - - - -
Constont term: Const8nt term
Linear term. Lineerterm
Second!lry ettributes
0 Checkall
Vo/Vs ratio.
====================~
20 :
10~
1quency (H
ase spHtru
.tJ
0
. . -';~.:.:- ..
t "" .- :.:.,:
..
[@ Collection settings
New QI crossplot New
window collec ion ~ Classification data
'-------J
QI crossplot
ng study 1
I
~ -------------------------
~ ~Z:============::::l
sitJ1.0)
PO!Pienn~ut~ ---------~
0 Color: ..___ _ _ _ _ _ __
4 Galfler coBections
~ •: Avo modefing study
X @ Linear © l ogarithmic
w
Y: @ Linear 0 Logarithmic
Axis range [J
Min: Max:
X 0! 0.5 : E) l ock
- ---o.i ! -· -
Y: ...
0.1 4 [] lock
[;!]~~ [i
~ Neme Settings Active
~
[1] 0
15% Ges
tl)
~
a.. ••
• • • • •
E
<{
tl)
"0
.@
..
a.
E
<{ .. • • • •
tl)
"0
• •
a. ...
.@ • •
• • •
E
• •
<{
• •
tl)
"0
...
•
~
a.
E
<{
..
010 ! 0 18
1 In situ synthetic
2 In situ I*G
3 90% gas
4 90% gas I*G
5 90% oil
6 90% oiii*G
1 100% brine I*G
8 100% brine I*G
Quantitative Interpretation AVO modeling •145
The models show these responses:
• A strong positive I*G anomaly associated with the top of the pay in
both the in-situ and high (90%) saturation gas cases. In the high
gas saturation case, there also is a positive anomaly at the fluid
level.
• I*G anomalies also are present for the top and base of the hard
overlying unit, but are of opposite sign to the pay.
• There is an I*G response to the brine case, but it is smaller in
amplitude.
• I*G has almost no response in the oil case. However, there still is a
significant amplitude and waveform change going from oil to brine.
50 ID.§._
G:l
-o
::3
..,..,
.~ G.J
0.. c
~
E v
<( ::c
....
....,
G.J
+J
·u;
0
c. ...ccv
nJ
E c.
0 c.
u <(
Grid name:
1/IJell
Markers
~gs -------------------------------------
AJgorithm:
Wavelet
Scale:
Angle range
~ ~--------------------
Sample interval : 4 ms
1
Navelet
PP AVO. Zoeppritz
Select a wavelet: r::J;:l PP AVO. Aki & Richards
~ PPA\'O. Fatti
Scale : PP AVO . Verm & Hilterman
PP AVO. Shuey 2terms
PP AVO. Shuey 3terms
Scale:
Sample interval : 4 ms
You also can display the gathers in the Well section window
and in a Prestack window if the Prestack Seismic Interpretation
(PSI) license is available.
Summary
In this module you learned about:
• different formulations that describe the relationships between
incidents and reflected seismic energy including:
• the exact Zoeppritz equations
• several approximations in current use and used in Petrel
AVO modeling
• classification of AVO responses into different commonly used
classes
• setting up and performing an AVO modeling study
• creating crossplots to analyze the results
• performing wedge modeling
Prerequisites
To complete this module successfully, you must have completed the
previous modules in the course.
Learning objectives ~
~
After completing this module, you will know how to run the AVO
reconnaissance process including how to:
• create a Volume of Interest (VOl) for interactive display and
co-visualization of AVO attributes
• make interactive crossplots of the attributes displayed in the
VOl
AVO RaoonnBlesan<.:e
I Stwey(1) II GldloW(2) II Panand~~~3~~~J
P rlmal'l/' attnbut>ea.r: Primary a11rlbtl1ea· Primacy- at1 rrbutes:
- loter<:ept (I} -A.cou&11C l m~e nce ()Q ntr.a~l -Lil'!e,ar ~arm
..(;f'81dlen i {O~ -Shear Impedance con1ru1 ..QI!l;adrellc term
Quality control
D Ouality co,JitoJ (()atvros
~
c
D Resttll analysts te.atures '+::::
t:
Attribute display using
VOis (4)
6athers disp-lay in
Interpretation window (5)
~
Q)
t.)
c::
ctl
(/)
-!!2
ctl
c::
AVO Cross-plot analysis {6) c::
ct.) c
0
·;::;
~ ~
( '
Geologteal and Geophysicallnterpret!ltlon I ~
:::;,
~
·~
~ a
Inputs to the workflow consist of angle stacks or prestack data.
Attributes are calculated from the data on the fly using several AVO
approximations. Attributes can be co-visualized with the stacked
seismic data using Volumes of Interest (Figure 2). Attributes from a VOl
can be crossplotted for further analysis. You can select among several
different AVO approximations according to which attributes are of
interest.
Figure 2 shows an example where a virtual AVO gradient section is
overlaid using transparency on a stacked section. This functionality
allows the interpreter to connect AVO attributes directly with the
structural and stratigraphic information in the stacked seismic volume.
AVO Reconnaissance I
AVO method: (Shuey 2-term ·I
Input f Outputl
1@ Post-stack () Pre-stack
~
Seismic list
§] Seismic Effective angle :
~
LJ
~
IT'
Method: !standard ·l
Input Ou ~idlow -
o Post-stack Pan and Gardl'er
Pre-staok
4. If you select poststack data, locate the data in the Input pane
and click next to the Seismic list to enter different angle
volumes.
Seismic list:
~. Seismic Effective angle
I~ g; Near_S-20 13.11 :
~ ~ Far_31-46 38.32 :
I
5. If you select prestack data, locate the data in the Input pane in
the Seismic folder and click ¢ to enter the dataset. Select
the trace limits in the Trace section as shown in this figure .
T~re --------------------------------
Minimum:
Maximum:
Step:
The Trace section lists the first and last trace and the
increment. You can adjust these values if you want to limit
which traces are used in the calculations. Limiting traces can
be useful if the angle in the data exceeds the useful range for
the approximation being used, or if there are noises or
acquisition imprints that affect the near or far traces that might
bias the calculation.
--------------------------~
Intercept
Graa~ant
Second8ryettnbutes - - - - - - - - - - - - - - - - - - - - - - 1
[] Check ell
Nl • PRC:
~================~
: Nl • PRC
Rctalicn angle
~========~========
0 :
OK j [1t Cancel J
Secondary si!Jibutes - - - - - - - - - - - - - - - - - - - - -
0 Check all
[] Fiuidmctor:
Vp/Vsrano· 2.0 :
8. Click Apply or OK
.. ..
Volumes of interest
In an exploration context, initial data screening is likely to be done on
stacked data volumes received from a contractor. Stacked data likely
has a higher signal-to-noise ratio than attribute volumes. It also is likely
to be the preferred dataset among members of an exploration team
who are looking for potential leads and prospects.
A useful way to combine working with the stacked data and attributes
at the same time is by creating a Volume of lnterest(VOI). A VOl is a
tool that allows you to define the extent of a volume to be used in the
AVO analysis. The VOl displaying the AVO attributes can be overlaid on
a stacked seismic section in an Interpretation window. You can
visualize the two datasets together to obtain a qualitative
understanding of the relationship between them.
The vertical and horizontal extent of a VOl can be increased or
decreased from the Interpretation window directly. In addition, the
spatial extent (that is, inline and cross line dimensions) can be adjusted
in a 30 window.
112 • AVO reconnaissance Quantitative Interpretation
The VOl can display all of the seismic volumes available within the
same seismic survey. You can change the volume displayed in the VOl
interactively by using the Inspector tool, which is discussed later in
the training.
Figure 3 shows an example of a VOl window that contains the gradient
attribute overlaid on the stacked seismic volume in an Interpretation
window. The VOl can be panned around the section and its size
adjusted to see how the attribute appears at any point of interest.
~ I ~~ [Sfl~
4. Click Create/edit volume of interest in the Tool Palette.
~ Create/edit volume...
-. Qltools X
9. To pan the VOl, make sure that the Tool Palette is active.
a. Click Create/edit volume of interest.
- Tool Palette 0 X
W ~l fit ~ ~ ~
b. Click in the VOl to drag it to another location or click the
sides to resize it.
...---
.
. ......... .......
.. - .. --......:
-~
..
--
3.
-2300
-2400
-2500
Seismic co lroi::m
tl f- orizcrml axis:
Intercept
You can pan the VOl around the section. The crossplot updates
as the VOl changes location.
........
To choose a data volume to display, use the Inspector.
'-::::-----:::::;;;;~~::-. ·~
7. Adjust the transparency and move the window over the section
to observe the response in different locations.
Questions
Do you see any consistent behavior in the attributes on and off
structure consistent with the AVO modeling in Module 2?
~· :
XL 2346
....
-- ~·· · ··-~
.s.- - ~
i.# .. ~..:.; =-=~.....~"! ~
-
~: . 0- · ~
:.:-:- ~
~~
- · :-:-·
Figure 4 Seismic appears with stacked data on the left and the Intercept*
Gradient attribute sections on the right
Summary
In this module, you learned about:
• running the AVO reconnaissance process
• creating VOis for interactive display and co-visualization of
AVO attributes
• making interactive crossplots of the attributes displayed in the
VOl
Prerequisites
To complete this module successfully, you must have completed the
previous modules in the course.
Learning objectives
After completing this module, you will know
• some basic theory regarding Simultaneous inversion and
review in brief some key workflows, such as Wavelet
extraction, Trace Alignment and Log Conditioning
• how to use the Inversion property builder to create a low
frequency model for use in simultaneous inversion
• how to set up and run a Simultaneous inversion
• how to check the quality of the output using the simultaneous
inversion diagnostics and the Inversion QC plot tool
• how to analyze the output using crossplots and geobodies
Quantitative Interpretation Simultaneous seismic inversion and the Petrel Property Model Builder • 187
Lesson 1 -What is seismic inversion?
The class introduction discussed how changes in the acoustic
impedance at layer boundaries in the subsurface created reflections as
seismic energy propagated through the earth. Figure 1 illustrates this
concept. The left side of the figure shows a column of different rock
types. Adjacent to that column is a schematic blocky impedance profile.
Each change in impedance is a source of reflected seismic energy.
On the right is a scaled up view showing perhaps several thousand feet
of the subsurface. The velocity and density logs shown here have many
contrasts each of which can give rise to a reflection. In addition to the
many layers in the logs, what also can be seen is a clear trend in the
log values with depth. While the reflection coefficients only depend on
the local contrast in impedance, the rock properties have absolute
values, and these values vary with depth.
b
synthetics as you did in Module 2.
Reflectivity •
Series Multiply each wavelet S~thebc
by the size ofthe Sewsmogram
reflection coefficient
Zero Phase
Wavelet
~.~.~.~~.~~-~· · -1t~~~~~.~-~
-
Figure 2 Convolutional model for calculating a seismic trace from a wavelet
and a reflection coefficient sequence
.s
-10
il "
·2S
~~--~--------~--~--~----~--~--~
20 JO ~ so 70
Ft~IHZI
Figure 3 Portion of the frequency spectrum occupied by seismic data and the
low and high frequency gaps that are present
Quantitative Interpretation Simultaneous seismic inversion and the Petrel Property Model Builder •189
Lacking high frequencies means that there is a limit to the detail that
you can record and resolve. Therefore, very thin beds are difficult to
resolve and detect. Lacking low frequencies means that you cannot
recover the absolute values of the impedance directly from your data. If
you want to interpret absolute values for subsurface properties, you
must supplement the higher frequency detail of your seismic data with
a model for the low frequency portion of the earth spectrum.
The AVO responses that you worked with earlier told you a lot about
what created the reflections that you observed. However, they were
based on reflections, so they told you only about the contrasts that
caused those reflections. You did not measure absolute values. What
you want to do with inversion is to go beyond the reflectivity contrasts
and use the seismic data along with other data sources to calculate the
absolute properties of the underlying earth model.
To fill the low frequency gap, you use a model for the low frequencies
derived from well data. The higher frequencies come from the seismic
data. You use the convolutional model to make sure that any results
contain the correct high frequency detail by making sure that they
predict the seismic data to within a sufficient tolerance.
Low frequency
model from well
data
Figure 4 Portion of the frequency spectrum that is filled by well data in the low
frequency model
In this module and in Module 5, you look at two types of inversions that
are available in Petrel: simultaneous inversion and stochastic
inversion. In this module, you learn about simultaneous inversion.
In simultaneous inversion, you calculate (or invert for) a single earth
model that contains absolute property values. The low frequency model
provides the guide for the absolute values of the properties. Detail of
190 • Simultaneous seismic inversion and the Petrel Property Model Builder Quantitative Interpretation
the interfaces and smaller scale layers come from the seismic
reflectivity. You do not try to extend the model to thin layers for which
the seismic data has no information.
In stochastic inversion, you add data to your model at a scale beyond
what is contained in the seismic data. Because the seismic data cannot
help you with this, you use statistical models of how the subsurface
varies to create alternative realizations that are consistent with the
well-based low frequency trends and seismic data. In this kind of
inversion, you invert for many possible solutions, not just one solution,
that contains a range of possible properties. Each result should be
consistent with the statistical models, the seismic, and the low
frequency properties from well data.
Quantitative Interpretation Simultaneous seismic inversion and the Petrel Property Model Builder •191
With this in mind, you can apply simultaneous inversion in situations
such as the ones listed here:
• Characterizing and observing the reservoir using integrated
seismic and well data
• Mapping elastic properties (for example, acoustic impedance,
shear impedance, and density) to perform these tasks:
• classify lithology
• estimate porosity or saturation
• predict pore pressure
• perform geomechanical deformation
• Interpreting converted wave data
Input data
The input data consist of:
• seismic data in the form of angle range stacks
• wavelets for each angle range stack
• low frequency models for the inversion parameters (for
example, acoustic impedance, VpNs, and bulk density)
192 • Simultaneous seismic inversion and the Petrel Property Model Builder Quantitative Interpretation
Output
The output depends on the data type:
Key features
Key features of the Petrel Simultaneous inversion are
• Full integration with Petrel data, models, processes,
Workflow editor, and graphics
• Time variant wavelet capabilities
• Global Simultaneous inversion methods using the Aki and
Richards and Fatti approximations
• Acoustic and elastic output volumes include Acoustic
Impedance, Shear Impedance, VpNs ratio, and density.
• Joint PP and PS mode
• Azimuthal Horizontally Transverse Isotropic (HTI) mode, with
output volumes for acoustic impedance, slow and fast shear
impedance, azimuth, and density
• Poststack and prestack 40 modes
• Multi-threading to leverage multi-core, multi-socket CPUs in
modern workstations
Quantitative Interpretation Simultaneous seismic inversion and the Petrel Property Model Builder •193
If a good inversion is to be achieved, data preparation is extremely
important. These steps are important in the data preparation process:
• The seismic data must be processed through a flow that is
suitable for quantitative interpretation. This requirement
implies proper amplitude recovery and preservation and
wavelet deconvolution.
• Logs must be edited and conditioned properly. This task should
be done prior to synthetic generation and wavelet derivation,
but before using the logs in the low frequency model. Good
well ties also must be established.
• The datasets must be aligned. This task can be done through
the Petrel Seismic trace alignment process or other similar
process.
• Wavelets must be derived with care for each input data stack.
• A prior low frequency model must be constructed that includes
the well data and other input (for example, velocity models)
that shape the low frequency behavior of the model.
NOTE: The Seismic trace alignment, Log conditioning, and Wavelet
extraction processes are covered in more detail later.
After the inversion has run, calibration of the inverted properties to
parameters of interest is necessary to make predictions about
parameters such as reservoir porosity, fluid presence and type, and
lithology. These parameters must be based on suitable rock physics and
petrophysical studies so that you can make the relationships for fluid
prediction between parameters, such as acoustic impedance and
porosity or acoustic impedance and VpNs.
194 • Simultaneous seismic inversion and the Petrel Property Model Builder Quantitative Interpretation
Simultaneous inversion features and implementation in
Petrel
Key features of Simultaneous Inversion as implemented in Petrel are:
• It is a globally optimized deterministic inversion that uses a
simulated annealing approach to model perturbations in the
search for a solution. It is a model based inversion that uses a
low frequency prior starting model and outputs absolute elastic
parameters and optionally the forward modeled synthetics,
reflectivity and residuals.
• It simultaneously inverts multiple datasets, for example, angle
stacks, PP-PS data volumes, or 40 data sets.
• It has robust noise reduction that uses trace-to-trace continuity
to reduce sensitivity to noise.
• It can take into consideration time variant absorption effects.
Simultaneous inversion iteratively updates the elastic parameters of a
subsurface model until an objective function is minimized. The objective
function contains terms that measure the misfit with respect to the
seismic data, sample continuity, and other values to be discussed in
this training.
The optimization used in this inversion is a simultaneous inversion,
meaning that it uses all of the seismic input (for example, all the angle
stacks) simultaneously. It does not invert separately for each angle
stack.
It is a global optimization, meaning that the cost function is optimized
for the entire dataset, with no subdivision. This feature is important
because inversion techniques using global optimization can use
complex objective functions with many local minima corresponding to
realistic statistical models for subsurface prediction from seismic data.
The global optimization ensures that the subsurface model does not
become trapped at a model corresponding to one of the many local
minima in the objective function, but that the final optimum model
corresponds with the global minimum. Figure 6 illustrates this concept.
Quantitative Interpretation Simultaneous seismic inversion and the Petrel Property Model Builder • 195
c
0
;:
(.)
c
.2
~
0
•
Global search covering all possible solutions
Figure 6 Potentia/local minima in the cost function highlighted by the red dots.
The inversion seeks to find the global minimum highlighted by the green box.
Penalty function
Inversions such as the simultaneous inversion discussed in this training
operate by trying to minimize a function that measures various
quantities such as the misfit with respect to the seismic, the
smoothness of the model, and the number of reflectors. This function is
termed the cost function or the objective or penalty function.
The cost function for Petrel simultaneous inversion contains these
terms:
• Penalty for differences between the seismic data and the
synthetic seismic determined from the estimated property
models by convolutional forward modeling
• Penalty for horizontal variations in the estimated property
models
• Penalty for deviation of the estimated property models from the
low frequency model
• Penalty for the presence of significant reflectors. Significant
reflectors are places in the estimated property models where
the reflection coefficient exceeds a predefined threshold.
• Penalty for vertical changes in properties between the
significant reflectors.
196 • Simultaneous seismic inversion and the Petrel Property Model Builder Quantitative Interpretation
This term means that the final model must fit the seismic data. It also
means that the model tries to avoid rapid lateral variations in
properties. It tries to keep updates close to the low frequency model,
and it tries to avoid having too many large reflectors with big property
changes between them. Significant reflectors are not forbidden per se,
but the penalty avoids letting the inversion place too many large spikes
in the solution unless needed to fit the seismic data properly.
Expressed as a formula, the objective function is shown in Table 1:
Table 1 Terms for Objective Function
Term lnterpretati on
E = f(SNR) X "L(Si- di)2 Penalty for not fitting the
seismic
Penalty for horizontal
variation
Penalty for deviations from
the low frequency mode
+ R1 (#significant reflectors) Penalty for number of
reflectors that exceed
threshold
Quantitative Interpretation Simultaneous seismic inversion and the Petrel Property Model Builder •197
Table 2 defines the parameters of the objective function.
Table 2 Objective Function Parameter Definitions
Parameter Definition
SNR User-defined signal-to-noise ratio
di Seismic data at sample i
Si Synthetic seismic at sample i
Ra User-defined horizontal standard deviation parameter
ci Continuity at sample i
P. Property value at sample i
pi±1 Property value at the four neighboring samples to
sample i, which might be determined by dip
Rcr User-defined standard deviation between the current
inversion result and the low frequency model
plfm Property value of the low frequency model at sample i
R1 User-defined threshold for significant reflectors
#significant The total number of significant reflectors
reflectors
User controls
The functions before each term in the objective function contain these
user controlled weights:
• The SNR or signal-to-noise ratio term that weights the fit to the
seismic data
• The horizontal standard deviation parameter Ru
• The standard deviation between the current inversion result
and the low frequency model Rcr
• The reflection coefficient threshold for significant reflectors R1.
This threshold controls how many reflectors are counted as
significant for inclusion in the cost function.
198 • Simultaneous seismic inversion and the Petrel Property Model Builder Quantitative Interpretation
SNR parameter: f(SNR) x L:(Si- di)2
To assess the fit between the inversion result and the seismic data, the
inversion result is convolved with the wavelet and compared sample by
sample with the seismic. You want the inversion to calculate the
underlying rock properties, and, as much as possible, avoid modeling
any noise that might be in the seismic data. The SNR parameter
controls how close the match needs to be to allow for the fact that an
exact match requires the inversion to match both signal ~nd noise. If
S/N is set very high (that is, assuming there is very little noise in the
seismic), the inversion tries to match the data in much greater detail
than if it is set at a low value.
The parameter has a usual working range of 1 to 20 with a good default
being 5 +/- 1. It is not measured in db and should be evaluated as a
"relative goodness of fit" parameter and not as an absolute signal to
noise ratio for each stack. It is set separately for each input volume.
Trials with different parameter values are needed to determine a good
value for the dataset at hand.
Quantitative Interpretation Simultaneous seismic inversion and the Petrel Property Model Builder •199
Tie to LFM parameter: f(1/Rcr) x L(Pi- Plfm) 2
The tie to the LFM (Rcr) parameter controls to what degree deviation of
the estimated property model from the LFM is penalized. The greater
the Rcr value, the lesser the penalty, so the further the estimated
acoustic or elastic property model is allowed to deviate from the
associated low frequency model.
A usual working range is 0.01 to 0.20. Lowering the number forces
greater tie to the low-frequency model. In AVO inversion there is a
separate tie to LFM parameter for each of the input domains.
NOTE: The inversion requires that the value of Ra, which controls the
degree of horizontal continuity, must be smaller than the value for Rcr,
which controls the tie to the LFM. This requirement ensures a greater
emphasis in the inversion on horizontal continuity over similarity to the
LFM, and it helps mitigate a tendency toward a single trace inversion in
extreme cases.
Quantitative Interpretation Simultaneous seismic inversion and the Petrel Property Model Builder • 201
Lesson 2 -Inversion preparation: Well tie and
wavelet extraction
In the inversion process, the intermediate results are compared to the
seismic to assess the degree to which the inversion result at that stage
correctly reproduces the input seismic data. This process is done by
convolving a wavelet with the reflectivity sequence computed from the
inversion result. Because there are multiple seismic angle volumes
involved, a wavelet appropriate to each volume must be supplied. In
addition, the well data must be tied carefully to the seismic so that the
LFM is registered correctly and the low frequency model properties are
associated with the correct geologic horizons.
Workflows to perform well ties and wavelet extraction are contained in
the Seismic well calibration group on the Quantitative
Interpretation tab. A complete review of the Seismic well
calibration process is beyond the scope of this course. It is assumed
that people taking this course already are familiar with Seismic well
calibration and its functionality and have completed Petrel training,
such as Seismic Well Tie or Petrel Geophysics, where this material
is covered in detail. For this reason, this training only briefly reviews the
wavelet derivation process recommended for generating wavelets for
inversion purposes.
It is recommended that wavelets be determined by means of the
Deterministic wavelet process. Deterministic wavelet derivation has
several key features that make it the method of choice:
• It determines the amplitude and phase of the wavelet.
• It correctly estimates the amplitude of the wavelet so that the
seismic prediction from the inversion is scaled properly for
comparison to the actual seismic.
• The deterministic process includes a diagnostic that estimates how
well the reflectivity and the underlying seismic reflectivity of the
well match. This diagnostic is useful if the well location is
uncertain or if there are data positioning uncertainties because of
migration errors, which are common in many datasets. The
measure of match between the two reflectivity sequences is
termed Predictability. It helps to select the best location for
wavelet extraction
202 • Simultaneous seismic inversion and the Petrel Property Model Builder Quantitative Interpretation
Seismic trace alignment
Because the inversion develops a model that is consistent with the
event amplitudes in the seismic data, it is critical that seismic events
be aligned properly so that the estimated elastic and acoustic
properties are the result of geologically-based AVO and are not biased
by event misalignment.
Figure 7 shows an example of data that is not aligned properly. Each
panel in the figure is a suite of traces from a different angle volume. In
this example, the data does not invert well because the traces are
aligned poorly and in some cases (as highlighted in the red boxes), the
events on the first trace are almost aligned with troughs on the last
trace.
.. .
._.._.........___..,..----r-- 7:'..,........
,. ~ .... ' ..... ~
Legend: 811111
Cube 1
CumShlftl
matched
~------ CumSMt3
- - - CumShlft4
CumSM tS '
Log conditioning/editing
As with any process that depends on log data (for example, AVO
modeling or Rock physics), the logs must be properly QC'd. Bad data
must be edited and if necessary replaced by data derived from
relationships, such as, Gardners or Greenberg (as described previously)
or from a neural network. It is important to engage the petrophysical
community in this process.
The Log conditioning workflow that is available in the Seismic-well
calibration group allows you to make adjustments to edited logs for
use in inversion and model building. This workflow offers tools to
perform operations such as blocking, depth shifting, interpolation,
smoothing, filtering, and trend calculation. This workflow and its
capabilities are discussed later.
Quantitative Interpretation Simultaneous seismic inversion and the Petrel Property Model Builder • 205
Procedure - Extract a deterministic wavelet
To run a simultaneous inversion, you must have a wavelet for each
angle range stack. In the Wavelet extraction toolbox, the
deterministic method is recommended. The Wavelet extraction
toolbox window is where you indicate the input data to use and set
the Verticalization type if necessary, the Taper parameters, the ion
parameters, and the desired outputs.
1. On the Quantitative Interpretation tab, in the Seismic-
well calibration group, click Wavelet extraction.
-
-t.t~AC»~
~
-
SioNt.,~
--
-
•ooo ....
23.10 ~2361
JS30) ~-
0.544
ooo-
3<!0
.
W.wlotdoooloy ~
s-. ..... 011_......c. ZltZ•o~ 2000 0•
Oporoocns s.t~CftRC 2021J O-
-~
~t1/-...._,.t 1100"""
I
P'-mon~tion · ~~ Power tC1KW:m in dB tC.tl
Phooo_, .. -~ ........
-..~
·1Sl 0
I
, t ~Wtt.;wt I
1 Wavelet list
2 Wavelet extraction settings
3 Wavelet displays
4 Predictability displays
There are several sections to the window. On the far left side is
a list of existing wave lets. By selecting the check box next to
several wavelets, you can make comparative plots of the
wavelets.
206 • Simultaneous seismic inversion and the Petrel Property Model Builder Quantitative Interpretation
NOTE: It might be necessary to expand the display by clicking
the arrow on the far left of the window to expose the
Wavelets list.
Parameters
Length:
Sample rate:
Central frequency:
~ Nome
C [:, Target
D ' Spectra_lnvPS_Full [Anal~ ·I
C Spectra_ISIS_Full 1~ ·I
[£ ~ Ricker l
2] Alr.o-oo!culote
0 Rclsr2
C ~ Rid<er3
~-· k-----------------~
c Rid<er• 128 ms
L lo\. \."Javeiers\._,.Ja~et&_before_~
{l l.\. ':/avelets\\.'Ja.,-e&ets_befofe_l\ 2 m£
C 1.\. \•Jov..le!oi\•Jo....,_befc<e_~ ------
25 Hz
L 1.\. w.v.,le:s\Yiovelels _befc<e_~
E t ;"'"'"""'"'....,_Hnoi_All • O tnvettpolarily
[S \r-lel:elet51Ylavelet5_Ftn~I_Ait
E \'iovell!U\Wovei& _FNI_Aft
Operatioms
Phaoe menipul!ltion l Torne ohtll Honmng file<
-180 180
------------( r-- - -
Rot.te phase 0 00 ffi deg . R:-:-
1 .--; obie
-:-:to
- ....,
---:-ph...,
---,jl WaveleldisplayopticM - - - - - - - - - - - - -
§
Relo'lveemplitude
Phase: 0006 deg I Convert iD:zerophase I Po.....- opednsm m dB ocale
Phase opectnrm in WI"!Piled ongles
Show envelope
Quantitative Interpretation Simultaneous seismic inversion and the Petrel Property Model Builder • 207
2. To run a new extraction, select Create new, the Method
{Deterministic is recommended), and the Algorithm.
The available algorithms are Extended White, ISIS frequency,
and ISIS time.
~ Extended White 1
Method:
-----·-..
Deterministic
-
Algorithm: Extended White
-- ____ _:j
~ Auto-ca lculate
208 • Simultaneous seismic inversion and the Petrel Property Model Builder Quantitative Interpretation
General
Welt
Seismic:
In line window: 10
Xfine window:
- ----
RC calculation method: Aki and Richards PP
Smoothing factor. 0
Filtering options - - - - - - - - - - - - - - 1
lnline radius:
Xline radius:
Square weights:
Quantitative Interpretation Simu~taneous seismic inversion and the Petrel Property Model Builder • 209
5. Open the Taper tab.
This tab allows you to specify the length of the cross
correlation window to be used in the wavelet extraction and
how it is tapered.
NOTE: The actual position of the window is specified on the
Extract tab. You can change the default parameters by
selecting the User defined check box. A white noise level can
be adjusted.
Parameters - - - - - - - - - - - - - - - -
Length of extraction xcor:
Length of extraction xcor taper:
\'1/hite Noise - - - - - - - - - - - - - - - -
Percentage of white noise:
(Reset )
v~e~ -----------------
length of extraction xcor taper Percentage of~ite noise:
IReset I
90ms
length of extraction xcor
248ms
210 • Simultaneous seismic inversion and the Petrel Property Model Builder Quantitative Interpretation
The Length of extraction xcor value and the Length of
extraction xcor taper can have a big effect on the extracted
wavelet. Some examples are shown in this figure.
Extracted Wavelet
Length d extraction xcor: 500 ~of ex!radJon xcor: 500 l..er'4h of ex!radicrl xcor. 200
L~ of e:4radion xcor taper. 250
---- Lefl!jh of elllnlc!ion xcor taper: 100 Length of eltradJcn xc:ortaper. -100
-:-----
----
J
·300 ·200 100 200 300 10
~---
Quantitative Interpretation Simultaneous seismic inversion and the Petrel Property Model Builder • 211
6. Open the Extract tab.
RC window scon - - - - - - - - - - - - -
Start: 2000 ms
End: 2040 ms
Toper - - - - - - - - - - - - - - - -
Taper: None
Length: 10 i @ Percent
~-------------~
()Time
This tab has two main sections. The top section labeled RC
window contains two parameters.
• Start (a): The time at the top of the window from which
the reflection coefficient data is taken for the cross
correlation on the Taper tab. It is used to calculate the
Predictability parameter discussed earlier.
• Length (b): Length of the window. It is shown graphically in
this figure.
T
e
212 • Simultaneous seismic inversion and the Petrel Property Model Builder Quantitative Interpretation
The second section is labeled RC window scan. This section
controls what portion of the seismic trace is matched with the
window already selected on the well log reflectivity to derive
the wavelet and calculate the predictability.
The seismic window is the same length as the reflectivity
window. It starts at a distance controlled by the parameter
Offset to center (d) above or below the reflectivity window.
The window then is progressively shifted up and down relative
to the reflectivity window by half the Length (e) parameter. For
each shift, a new wavelet and the predictabil ity are calculated.
It is possible to edit these parameters graphically in a Well
section window if one is open during the extraction process.
7. Open the Output tab.
This tab allows you to save the Reflectivity, Acoustic
impedance, and seismic Dephase operator if desired.
Click the save icons to the right of the parameters that you
want to save.
General I Verticaftzation I Taper I Extract I Output I' - - - - - - - - - - - ,
Output parameters
RC Reflectivity:
,-----------~
New reflectivity
kl
~
r
L
Quantitative Interpretation Simultaneous seismic inversion and the Petrel Property Model Builder • 213
Predictability displays
The Wavelet section of the Wavelet toolbox dialog box graphically
shows the extracted wavelet with its frequency spectrum and phase. It
is self-explanatory.
The Predictability displays are on the far right side of the window.
Predictability is calculated from this formula.
In this equation:
• Xcor(t) is the cross correlation of the seismic window and the
reflectivity window
• Acor1 (t) is the auto correlation of the reflectivity
• Acor2(t) is the auto correlation of the seismic data
They are weighted automatically by a hard wired cosine weighting
function. The maximum lag in the correlations also is hard wired.
Predictability values can range from 0 to 100, where 1DO is a perfect
match.
A useful characteristic of predictability is that it is a measure of the
similarity of the underlying reflectivity. It is independent of the seismic
wavelet and fairly insensitive to amplitude scaling differences as well
as to wavelet phase uncertainty between the two time series.
Figure 10 shows an example of some predictability displays. There are
several predictability displays available.
,. Maximum predictability (side view)
~
214 • Simultaneous seismic inversion and the Petrel Property Model Builder Quantitative Interpretation
Remember, predictability really is a cube. It (and corresponding
wavelets) is calculated on a grid of inline and crossline locations and
for a series of shifts between the reflectivity and the seismic (the
Extraction tab parameters).
The initial display in the process when first run shows an in line/
cross line slice (left) located at the shift value that gives the maximum
predictability (right). This point is marked by a black X. You can click in
any of the grid cells and the wavelet display updates to show the
wavelet calculated at that location.
Examples of wavelets from different locations in the grid have been
shown on the inline/crossline display on the left.
·~~·
~~ • J
... ~
·w
.....:
A, "
~ J
~~~ ·0 ) ~
..,
Time. (ms) Time (ms)
26 SA
9122/2014
o-~
--~ -
~~r-TI
ffi=-\-1
~
o.o.m...oc
=--- .
!t:!t:j
w.. . --
TCR-
I·-
""""-
._. U..&o'rs..dylltrll!>O'Ot!'TOR
t:....o
><61
Malt .... euiMe...,.,
)
@~
l1
AC-.-..- -6io!'>Y-- - - -
71-"""'""'"..
!«end-"!'
_0(,_, @) IJ,OT 0-..-.... da"""'
Oonocy ~ 'l. AH06 [] ---"'"'""~*~
D S~-.
onglos
~ ll,ors
ill_,_,.,.._
Quantitative Interpretation Simultaneous seismic inversion and the Petrel Property Model Builder • 217
Align seismic volumes with non-rigid matching (NRM)
Seismic volumes must be aligned properly for the inversion program to
invert the data properly. Alignment assures that the seismic events that
represent layer boundaries are all located at the same time. If they are
not, the inversion associates incorrect amplitudes with those
boundaries and calculates incorrect properties for the layers above and
below.
NOTE: After the Seismic trace alignment, the wavelets must be
extracted from the new aligned angle stacks.
This procedure shows you how to run the Seismic trace alignment
process.
NOTE: The test run ran in 25 minutes on the cropped volumes.
1. On the Quantitative Interpretation tab, in the Seismic
conditioning group, click Seismic trace alignment.
~=~ Seismic resampling
Seismic trace fS) S/N es':ir-1a~iol"l
~gnment · Wavele: eq~.oal i;;:a~lo r.
Seismic conditioning
Reference ~ismic:
D Output displaceMents
Qualitycheck - - - - - - - - - - - - - 1
[] Ou!put correlation su~
Surface time: ms
218 • Simultaneous seismic inversion and the Petrel Property Model Builder Quantitative Interpretation
2. On the Settings tab, insert the seismic volumes located in
the Input pane that you want to align.
The volumes can be reordered and deleted, and the pane can
be reset using the buttons to the left. The 20 seismic and 30
cubes can be entered. Data must be in the time domain and in
the same survey.
NOTE: You can remove or change the order of the seismic
volumes in the seismic to be aligned fields, but keep ln mind
that the displacement fields are applied cumulatively based on
the order of the cubes or lines.
3. Select a cube to use as the reference cube from the list in the
Reference seismic field.
4. You can output the displacements, which are the relative shifts
between the data volumes. Select the Output displacements
check box to output these cubes.
They are stored in the same survey as the seismic data.
Quantitative Interpretation Simultaneous seismic inversion and the Petrel Property Model Builder • 219
5. As a check of the results, you also can output correlation
surfaces. These surfaces show the correlation of the datasets
relative to the reference seismic both before and after
alignment. Select the Output correlation surfaces check box
to write this output.
• The Surface time parameter specifies the correlation gate
center.
• The Correlation interval specifies the correlation shift to be
used.
TIP: A good practice is to set these parameters to encompass
the key zone of interest in the data. Correlation surfaces are
stored in an interpretation folder at the bottom of the data tree.
6. Open the Advanced tab. This tab contains parameters that
control filtering and smoothing of the displacement fields.
'I Seismic trace alignment ~ I
~~ A~aooro ~
~ ~-·n_~~~--------------------~
Parameters: - - - - - - - - - - - - - - - - - - - - - - - - - - -
Amplitude level:
220 • Simultaneous seismic inversion and the Petrel Property Model Builder Quantitative Interpretation
Enter values for these parameters:
• High cut frequency and slope: These parameters control
the shape of a bandpass filter to be applied to the
displacement volumes to avoid excessive high frequency
jitter in the displacement values prior to applying them to
the data.
• Amplitude attenuation: The algorithm estimates the time
shift for each sample in each trace. Time shifts estimated
from weak reflectors are honored less than time shifts
coming from strong reflectors. This parameter specifies the
amplitude level where reflectors should be considered to
be weak. It often is preferable to run this method on data
with some sort of AGC applied (for example, a sliding
window AGC of 200 ms). With AGC applied, an Amplitude
attenuation equal to 1.0 usually gives robust estimates.
• Lateral and vertical filter radius: After each iteration, the
intermediate time shifts are filtered using a 30 mean filter.
This parameter specifies the lateral (or vertical) radius of
the mean filter in the inline and the cross line (or vertical)
direction.
• Time Shift Limit: This parameter is the maximum absolute
shift allowed up or down. Twenty milliseconds is a large
shift. Normally, 10 ms is more appropriate; otherwise,
cycle skipping can occur.
• AGC: Trace AGC (automatic gain control) scales the
instantaneous amplitude value with the normalized RMS
amplitude over the specified window. This default should
ALWAYS be changed to represent somewhere between
500-1000 ms.
7. When all parameters have been entered, click Apply or OK to
run the process.
Quantitative Interpretation Simultaneous seismic inversion and the Petrel Property Model Builder • 221
The program creates entries in the tree for the displacements,
the shifted volumes, and the diagnostics. The entries for the
data volumes include the inter-volume shifts, the cumulative
shifts, and the matched volumes. A portion of the tree with the
output data volumes is shown in this figure.
~ tl Mid_18_33 [MATCHED]
lnline 3458
XLine2383
Z=-2600.00
~ fl Far_31-46 [MATCHED]
lnline 3458
Xline2383
Z=-2600.00
,. fl! Near_5-20x Mid_18_33 [NRM]
lnline 3458
Xline 2383
Z=-2600.00
,. tiJ Mid_18_33xFar_3l-46[NRM]
lnline 3458
Xline2383
:J Z=-2600.00
~ ~ Mid_18_33 [Cumulative NRM]
lnline 3458
XLine2383
Z=-2600.00
,. ~ Far_31-46 [Cumulative NRM]
lnline3458
Xline2383
J Z=-2600.00
~ til Mid_18_33 [MATCHED]
In line 3458
Xline 2383
J Z=-2600.00
~ fll Far_31-46 {MATCHED]
lnline 3458
Xline 2383
Z=-2600.00
222 • Simultaneous seismic inversion and the Petrel Property Model Builder Quantitative Interpretation
~ ,. .,. 0 Seismic Trace Alignment Correlations
t> ~ ~ JD Hetp V;oL'51'on filers
~ I!! 0 Correlation Horizon Jupite([Near520 X Jupiter[Mid 1rn
~ t8 0 Survey 1
tl 0 TWT
~! 0 ~er"[Near520]x ~erfMd 1 833)
!>
~
'1) 0
0
...- ·-.
Seismic Trace Ahgnment Correlations
P. ~ ~ JD intetp inclusion £letS
A ~ 0 Correlation HoriZon Jupiter[Near520}xJupiter{Mid1&..1J U'IIA.TCHEDJ
A I:B 0 .Survey 1
tl 0 T'l\/T
{) t 0 .lqjter{Near520] X .ktpiler{Md1833] (MATCHED]
I> " 0 Seismic Trace Alignment Correlations
Quantitative Interpretation Simultaneous seismic inversion and the Petrel Property Model Builder • 223
With correlation surfaces, again the differences between the
input data (top) and data after alignment are subtle because
the data already is well aligned.
Near to Mid correlation surfaces
224 • Simultaneous seismic inversion and the Petrel Property Model Builder Quantitative Interpretation
Procedure - Condition log data with the Log conditioning
tool
Log data that is used in the inversion process must be in good condition
and properly edited so that you can rely on it for use in the inversion
process. Quantitative interpretation offers log conditioning tools that
can help you prepare the logs for use in the inversion process.
NOTE: Log conditioning is part of the Petrel Geoscience core license.
The Ql Extension enables some of the specific operations.
This procedure shows you how to use the Log conditioning tool.
1. Open a Well section window and make it the active
window.
2. On the Quantitative Interpretation tab, in the Seismic-
well calibration group, click Log conditioning.
- ._f.. W~atraction
Seismic If~ too conditionfng I
well t~ J.JI Well tie editing
Sei.smlc-well alibration
Quantitative Interpretation Simultaneous seismic inversion and the Petrel Property Model Builder • 225
3. Click the Selections tool on the left side of the tool bar.
This tool allows you to highlight a region of the log that you
want to work on by drawing a box around it in the Well
section window.
The gray area in the log track in this figure shows the selection
made.
...---- - '- ..... --r - - ..~---- -- ....- ...
·
... ~··
226 • Simultaneous seismic inversion and the Petrel Property Model Builder Quantitative Interpretation
A list of log curves appears below the toolbox.
NOTE: Some processes limit how many logs can be processed
simultaneously.
4. Scroll to the right side of the list of curves to expose the check
boxes.
5. In the Enable column select the Ia u want to condition.
End log Well Enable Delete
16n.06 1888.07 Vs Jupiter-1 til
1710.09 1889.91 Acoustic impedance Jupiter-1 D
2152.29 2328.44 Vp Jupiter-1 0
SSTVD (m) 1433.03 1563.30 RHOS Jupiter-1
m
7. To change the parameters for the process, use the slider bars.
Quantitative Interpretation Simultaneous seismic inversion and the Petrel Property Model Builder •12.7
The Well section window updates interactively to show the
impact of the selections. The log display in this figure shows
where spikes to be eliminated have been identified.
Quantitative Interpretation Simultaneous seismic inversion and the Petrel Property Model Builder • 229
Lesson 3- Low frequency model building and QC
with the Inversion property builder
The low frequency model is used in the inversion process to provide the
low frequency part of the properties of the earth. It fills the region of
the frequency spectrum that lies below the region contained in the
seismic data. Figure 13 shows an example of a low frequency model.
This figure illustrates these components of the model: the surfaces used
to build the LFM model, the wells used, and in the background, the
resulting LFM property model.
This example gives an idea of the scales involved. You can compare the
log scale property values that are highly detailed against the structural
surfaces at a normal seismic interpretation scale and, by comparison,
the low frequency component of the property.
The point is that a model with frequencies from DC to around 8Hz is
very smooth and devoid of most of the detail you are used to seeing in
either seismic or well log displays. However, it does capture the key
trends that allow you to convert relative changes in quantities in the
seismic bandwidth to ·absolute values.
230 • Simultaneous seismic inversion and the Petrel Property Model Builder Quantitative Interpretation
The Inversion property builder is the tool you use to create low
frequency models for simultaneous inversion. The Inversion property
builder can be used to perform these tasks:
• Interpolate well logs into a 2D line or 3D cube, creating a
model suitable to use as the initial model for simultaneous
inversion.
• Extrapolate logs throughout the volume in a horizon consistent
manner. Where multiple logs are present, the log data is
weighted log data. The default weighting is inversely
proportional to the square of the distance from the well.
• Create a Guide model (typically, a velocity cube) to add spatial
information between wells .
• Specify a Depth trend.
There are four basic steps to building a model:
1. If necessary, convert seismic interpretations to surfaces.
2. Populate the model case.
a. Name the model.
b. Provide geometry from the seismic cube and, optionally,
the guide cube.
c. Add Global well log properties.
d. Add wells to use and define the weighting if you are using
multiple wells. ·
e. Add surfaces and set the depositional mode.
f. Decide on advanced parameters for log extrapolation.
3. Check the quality of the input data.
• Blind well test
• Well weightings
4. Run the model.
Quantitative Interpretation Simultaneous seismic inversion and the Petrel Property Model Builder • 231
Procedure - Convert interpretations to surfaces
First, the seismic interpretations must be converted into surfaces, one
of the main components of the LFM.
1. On the Seismic Interpretation tab, in the Utilities group,
click Make surface.
~ :il
:e
Polygon
ru
editing il
Makesumc~
~~: ~
~ ~~
~~=------~
M-. if1lU: ~ ~.-Itfl:_
.~ l_nts_p__, _ ___,! ~ ~ @ lnterp_1
Xmin: 759i4i.7R754 ~
y min: i83S478.2229 ~
X mcn: 764341.53778 'Ndh: 4593.7502450 ~ j91 &pend I
Y max: 7&50003.2229 Heqt: 14525 ~ [liiii stmk I
[{] Rot!tion: §B ·91 .143998
GOO~ ------------------------------
~ Xinc: 18.7500 Yinc: ~ j ~lodes: 24Gx582
Boundary
EJ 1\Aa<e boundar'/ from inplt and extend i 'Aih U nodes.
Note: If togOed on. the boundary in the inpU data wtl not be used.
Iv' ~ II " OK
232 • Simultaneous seismic inversion and the Petrel Property Model Builder Quantitative Interpretation
2. Open the Make surface tab.
3. Locate the horizon to convert in the Input pane and insert
in the Main input field.
~ ' 0 Stochalltic Model Make surface Hints
I> ~ 0 JDiretp inci.iYcn lms ~~--------------------~ n
Quantitative Interpretation Simultaneous seismic inversion and the Petrel Property Model Builder • 233
The Inversion property builder dialog box opens.
This dialog box has several areas for parameter input. It also
has advanced settings. A tab at the top contains hints that
provide background information about the process.
[nversion property builder 1_1Ll
-~
_,
• GkJbalwell logs
"
G
..... 6
'Nell name
--- I Wetght ..._ Inverse dtstance exponent
• Output filter
::::J
-
0 Apply a high cut filter to the output of: 8 Hz with a slope of: 30 dB/oct~:~ve
234 • Simultaneous se1sm1c mvers1on and the Petrel Property Model Bmlder Ouant1tat1ve InterpretatiOn
3. Open the Parameter input tab.
4. The geometry for the model is defined by an existing seismic
volume. In the Geometry models section, select the seismic
volume from the Input pane that represents the geometry to be
used for the model and click to insert it.
A volume can be removed using the button with the red arrow.
The folder symbol next to the blue arrow is used for 20 data
entry, which is covered later in the training.
• Geometry models
Quantitative Interpretation Simultaneous seismic inversion and the Petrel Property Model Builder • 235
This figure illustrates how using a guide model can influence
the model properties. There is a significant difference between
the depth trend of the acoustic impedance property between
the left and right side of the model. The difference in depth
trend across what is a large fault is the result of the
differences in the trend in the guide model.
236 • Simultaneous seismic inversion and the Petrel Property Model Builder Quantitative Interpretation
7. Expand the Wells section of the window and click to enter
the wells that you want to use. Use the blue derrick symbol to
add all wells within a survey area. Wells that lie outside of the
seismic cube can be used as long as the input surfaces extend
through all the well locations.
... Wells r-
!_.,
Q~ ~
Well name I Weight Inverse distance exponent
+li Well-1 Ill 12
8. Specify the Weight to be given to the wells and the Inverse
distance exponent that controls how rapidly the weight
decays away from the well.
The weight applied to each well log is
W=k*(Wu /dn)
In this equation, Wu is the user-supplied Weight entered in
the well table, d is the distance away from the well, and n is
the Inverse distance exponent entered in the well table.
K is a correction factor to correct for cluster effects. You can
enable it on the Advanced tab.
For example, in this figure, without cluster weighting, the four
wells in the top left would receive equal weighting with the
well in the lower right. Because the four wells are close
together, though, their number tends to bias the estimation at
the blue location in the center toward the cluster. The Well
cluster weighting enabled correction attempts to
compensate for this effect.
Quantitative Interpretation Simultaneous seismic inversion and the Petrel Property Model Builder • 237
9. Expand the Layers and horizons section.
10. Select the first surface to add from the Input pane, and click
~ to insert the surface. Repeat for additional surfaces.
NOTE: Surfaces are most easily added in order.
These surfaces define the layers in the model. You can change
the order of surfaces and delete them using the buttons at the
top left of the section.
238 • Simultaneous seismic inversion and the Petrel Property Model Builder Quantitative Interpretation
When a layer is set to Conformable, the log curve is stretched
and squeezed to fill the space between the layers as it is
moved away from the well.
The On lap case is similar to the Offlap case, but it follows the
top horizon. If part of the translated log ends up below the
base horizon, it is truncated. When the translated log does not
fill the zone completely, the first sample in the log curve is
copied downward as a constant value to the bottom boundary.
.. -= II -.
240 • Simultaneous seismic inversion and the Petrel Property Model Builder Quantitative Interpretation
13. Expand the Output Filter section.
This section allows you to filter the model with a high cut filter.
Filtering the model allows you to limit frequency content of the
model to fit the frequency gap between the output of the
Inversion property builder and the low end of the seismic
r·0
~-
spectrum.
---~---··--
Ap~ly es~ igh ~ filter to the output of: 8 Hz with e slope of: 30 dB/octave
~ Apply global 'below TO' extmpolation settings to ell globe I well logs
Overburden [Giobaa - - - - - - - - - - - - - - - - - - - -
~m[~~q----------------------------------------
SutVeywideoptions - - - - - - - - - - - - - - - - - - - -
The check boxes at the top allow you to specify if all logs are
treated the same regarding how their properties are handled.
Clearing these check boxes allows you to specify the settings
for each Global well log individually.
Quantitative Interpretation Simultaneous seismic inversion and the Petrel Property Model Builder • 241
This figure shows examples of some of these methods.
Default - constant User defined Constant
User defined :
firstllast values up 4700, down 7200 Regression extension
uno.5
~7T--r-~---r--,_--
2100
2200
2300
~+---~--H-~---+---
3100 3100
5. All the parameters now are set. Click the Run button to access
options that can help you to assess and check the quality of
the model before running it.
242 • Simultaneous seismic inversion and the Petrel Property Model Builder Quantitative Interpretation
I I
II
L
16. When the parameters are set, click Run> Create model(s).
Quantitative Interpretation Simultaneous seismic inversion and the Petrel Property Model Builder • 243
The completed model appears as an entry in the Input pane,
with subentries for each property.
~ 0 Test Property Model
~ £I 0 Test Property Model AJ
0 ~3498
0 XUne2383
0 Z=-2600.00
~ fill 0 Test Property Model RHOB
0 ln1"1ne 3458
0 XUne 2383
0 Z=-2600.00
~ ill 0 Test Property Model VPVS
0 lnline 3458
0 XUne2383
0 Z-=-2600.00
244 • Simultaneous seismic inversion and the Petrel Property Model Builder Quantitative Interpretation
9. Inspect the output in the 30 window (or Interpretation
window).
Quantitative Interpretation Simultaneous seismic inversion and the Petrel Property Model Builder • 245
The Seismic inversion QC plot dialog box opens.
I
[ttl Seismic irrmsion QC plot ~
!
1.-.ionQC F1 - -
[...Je o...new: lw.a..:tionwmdow J DBp~aJ--.,ror:
!/ OEdittiJOStlng: +
I• L""lld from .....son C4H! . Use defaults 1SMa dbpley Mlling ~I
v
... lrwwsian ,_..
u ...
Cuslom se.-ngs.
Rasle<izetion
_, dl ~ .
Plattyp. Tree:• colors
PnmeoyaJbe Globol-'l log Property lrend cube
I~·
I
O'•'llggle~a ~ -Gray
... w...
0Pcsll:vefill
O~fiO
1-Gray I~
D 1-Groy
H
·'
Wells :
0 v~rl8ble den511y
[il lntecpoletad dens•ty
0 PusiiJve wier ~U
Plot polarity
@NofT111!1
0 Reverse
- - --
QNegatJvecololfiD
... log liltw [J :J Lobe colorfiU
iD Apply lilar.
Numbercftm<:es. : 100 I
LaNcutfilter 0 ~ Hz •rlh e slope of
---
30.00 dB/octave
Decmollon specmg
,, I
Hgh<'.JI r 87 5 ~ Hz wlheslol"!of 3000 dB/oc::bYe
- Clip lunitsilraces)
'4 I
... Crostl«tton [J
... Scale
·~ lnltne () Crossline
@118dr81i~ j
• Track wiclh
~maxJlumiS).
,, I
-
... ElctriiC1ion Q
0 Alcng - bore trojl!doty
·@ VIIItJcalatwellheed~
•l.h
/
lnvenoon QC
inversion QC plot dialog box.
!~ s~ismic inversion QC plot
~
Cn!ate r.ew:
EdrteXJstJng:
IWell section window
+I
~~--b:
Teet p-operty RHOB
- ..,
llfil tmd from ""'STlllm C>S3
@t!oedofaults. Deneily
0 Custcm lllltir.gs
,.. lnversJOn results
t:J ,;
• Rasierizaticn
-~ nl &fl r.
Pnmlll)'albe
~~ TeslpropertyAI I ~llpAI
Globe! well lag
I +I
Propertyhndalbe
J
I '..d.
Plot type
c '.'f<J'Ja 11103
QPo!!ll\'e~
,.Gray
Tracecolol's
i•GtBr
I·'I
j.lI
+rJrestpropertyVPVS I +fHVPVs I..,, I ~ 0 ~tiveliU
I•GtBr ... I
0 Vanable dens y
I
-
+I Testp~RHOB I ti~RHOO 1+1 l rtf
~~~~de'!Sty Plctpoll!rrty
..-Wells
·' - (i il 0 ?os:tM;aJlorfil
Q \aga:Nec.olot J
::::J tecc'Orfill
Q
>;o.·rtnl
0\'HS&
Wells
-
J
-~
~I!Well-1
.-Logfiller
~of!lliCE:s 1100 I
~nsp!IOI'g ll J
0 Apply fillac:
O•o lrlils\tmcm) 14 I
Lawcut~~er
1-'.z
wrtlla~ot.
Wltl': a siopeot.
- -- ~M-·
:JU.OO dll,'ochve
I .. Salle
Ouant1tat1ve Interpretation Srmultaneous sersmrc mversron and the Petrel Property Model Bwlder • 247
9. To create the Well section window display, click Apply or
OK This figure shows an example.
1 AI
2 Rho
3 VpNs
248 • Simultaneous seismic inversion and the Petrel Property Model Builder Quantitative Interpretation
Lesson 4- Simultaneous inversion and results
Now that the seismic volumes are aligned, the logs are conditioned,
and the low frequency model is in place, you are ready to run the
inversion. This lesson contains the procedures that show you how to
set up and run a Simultaneous inversion.
I) Edit trAlstilg:
Method: IPost stack, normal incidence ·acoustic impedance
Surve-1: i 30
20 ~·~---------------------------
Quantitative Interpretation Simultaneous seismic inversion and the Petrel Property Model Builder • 249
3. Select Create new or Edit existing. If creating a new case,
enter a name for the case in the adjacent field. Select an
inversion Method from the list.
IPost st~ck. normal incidence- acoustic impedance
Post stack. normal incidence -acoustic imped~ce
Tme lapse post stack. normal incidence- baseline acoustic impedance and monitor ratio of change
PP AVO. constant coefficients -acoustic impedance and shear imped~
PP AVO. constant coefficients- acoustic i~ and l Ns
lijill\'ltW-'D~t;,l$¥f·%1Mit4,,,J.g.&~DJM·'
; PP AVO Tme l~pse. Aki &Richards- acoustic impedance. VpNs and density baseline and monitor ratio of change
PS AVO . .Aki & Richards - shear impedance and density
w
PP AVO . .Aki & Richards- acoustic impedance. shear impedance and density
PP AVO . Fatti - acoustic impedance and VpNs
PP AVO . Fatti - acoustic imped~nce and shear impedance
• PP AVO . .Aki &Ridlards- acoustic impedance. VpNs. density and angle model update
PP & PS AVO. Aki & Richards - acoustic impedance. shear impedance and density
PP AVOZ. Aki & Richards - acoustic impedance. slow shear impedance. fast shear impedance. azimuth of fast shear impedance. density
250 • Simultaneous seismic inversion and the Petrel Property Model Builder Quantitative Interpretation
6. Enter the value for the SNR parameter.
Remember from the introduction that the cost function contains
a number of terms and that the first term in this formula
measures the match between the seismic data and the seismic
predicted from the inversion model (refer to Table 1).
The SNR parameter controls the weighting of that term and, in
turn, how close the match needs to be. If S/N is set very high
(that is, there is very little noise in the seismic), the inversion
tries to match the data in much greater detail than if it is set at
a low value.
The parameter has a usual working range of 1 to 20 with a
good default being 5 +/- 1. It is not measured in db. It is set
separately for each input volume.
NOTE: Simultaneous inversions run quickly (in a matter of
minutes) on small volume such as the ones used in this class.
So it is possible to run a number of tests on selected
subvolumes to assess the impact of changing this parameter
and to achieve reasonable results.
7. Enter the Min angle and Max angle values for the stacks.
NOTE: If the names of the seismic volumes follow a specific
format convention, these values are populated automatically.
Stack volume names that contain the character'-' with
numbers before and after the character are parsed to strip out
the Min angle and Max angle ranges automatically for
insertion into the table.
The format used is xx.x-xx.x or xx-xx, so a floating point number
can be specified for angle ranges. For situations in which the
file name contains more than one'-' character, it is the LAST
occurrence of the '-' character in the file name that triggers this
behavior.
This figure shows an example of the populated table in this
section.
0
Quantitative Interpretation Simultaneous seismic inversion and the Petrel Property Model Builder • 251
8. Select the check box Use time-varying wavelet.
Selecting this option enables two tabs that allow access to
two processes. One process is a workflow for Frequency
independent attenuation compensation, and the second
process is for Frequency dependent compensation. A third
tab accesses the ac plots generated by these two processes.
9. On the Frequency independent attenuation tab, select Use
frequency independent attenuation and enter the
parameters. This method is aimed at correcting an incorrect
gain function where the effect of transmission losses in the
seismic data is compensated for.
Frequency independent attenuation compares the time-domain
well log reflectivity data with co-located seismic data and
calculates any residual amplitude decay not present in the
earth reflectivity sequence. The type of well log reflectivity you
use must match the seismic data.
For example, for angle-stack seismic data, you should use a
matching angle-dependent reflectivity log curve, and the
reflectivity sequence must be in time.
For shear wave data, you should use a shear reflectivity log
curve. The time-domain well log reflectivity can be output
together with the extracted wavelet from the Seismic-well
Calibration process.
There are different algorithms available to perform the
estimation in the Attenuation approach list. The suggested
option is Constant energy, fixed zero time.
NOTE: For attenuation approaches that are not fixed zero time,
there can be a time-shift on the inversion output compared to
the input data. This shift arises if the energy midpoint of the
input wavelets is not equal to the zero time of the wavelet.
Such a shift occurs even if you do not select either attenuation
method, or you set both to 0 (zero). Therefore, ensure that the
extracted wavelets have energy midpoint at zero.
In the case of multiple input seismic angle stack datasets with
different angle ranges, best practices recommend that you
verify that similar values are estimated for the different angle
stacks in a dataset. A mean or median value can be used as
the user-specified attenuation value.
252 • Simultaneous seismic inversion and the Petrel Property Model Builder Quantitative Interpretation
This figure shows an example of an input parameter set
Frequency independent attenuation.
/ (~ ~ altenuatlonii Frequency dependert altenJation 'j:ocJ
@ Use frequency lndepec~dent attenuation
2000
2080
2160
2240
2320
2400
Vi' 2480
E. 2560
~ 2640
I- 2720
2800
2880
2960
3040
3120
3200~----------~~~----------~~~~------------~~---------------~---------
Quantitative Interpretation Simultaneous seismic inversion and the Petrel Property Model Builder • 253
10. On the Frequency dependent attenuation tab, select Use
frequency dependent attenuation and enter the
parameters.
Frequency dependent attenuation estimates frequency decay
from the seismic data. The method of calculation assumes an
attenuation model where high frequencies from deep reflectors
are increasingly attenuated, resulting in a decrease in mean
frequency of the seismic data with depth.
The result of the model is that the seismic frequency
attenuation of the wavelet in dB is proportional to the product
of the frequency and the depth in TWT, or the estimation of the
attenuation factor (termed RATTA is based on estimating a
linear model between one over mean frequency and depth in
TWT.
Measured Decay (db)= RATTF*frequency*TWT
so that
RATTF =Measured decay/(frequency*TWT)
The factor RATIF is related to the Q factor by this equation:
rr
RATTF = Q
2
-2000 -3200
% oflroces: 1 000
254 • Simultaneous seismic inversion and the Petrel Property Model Builder Quantitative Interpretation
This figure shows an example of the associated OC plot.
I Fraquencyindependentllttenuation I Frequencydependentllttenuation !oc
~----~----------------------------------
0 Frequency independent attenuation @ Frequency dependent lltlenuation
';i
;;;
~2600
,2800 -+----1-----+----+----+--4--H~:...f-.::JIP
Quantitative Interpretation Simultaneous seismic inversion and the Petrel Property Model Builder • 255
This figure shows an example of the impact that attenuation
can have. Proper attenuation compensation resulted in an
improved estimation of the properties deep in the section as
you can see by the improved well tie.
No Attenuation With Attenuation
Extraction window{
P/Svelocity ratio[] I
[lJ to? tl Test property VPVS 0.1 2 - 0.14
Oensity[g/cm3J [[] ~ I Test property RHOB [0.1 2
I
Q14
II
I
Ouant1tat1ve Interpretation Simultaneous se1sm1c mvers1on and the Petrel Property Model Bu1lder • 257
13. Enter the Horizontal continuity weight. Recall that this
weight affects the degree of horizontal continuity in the cost
function (refer to Table 1).
The horizontal continuity (Ra) parameter controls to what
degree horizontal variations in the property models are
penalized. Ra is the standard deviation of neighboring property
traces. The larger the value given to Ra, the smaller the
penalty for lateral changes. Also, the inversion optimization
algorithm imposes less horizontal continuity. A smaller value
increases the penalty for horizontal variations and so imposes
more lateral continuity.
A usual working range is 0.01 to 0.20. Lowering the number
yields an increasing amount of horizontal continuity.
NOTE: The value of Ra must be greater than 0 and smaller
than the value for the tie to the LFM.
14. Enter the lie to LFM weight.
The tie to the LFM (Rcr) parameter controls to what degree
deviation of the estimated property model from the LFM is
penalized (refer to Table 1). The greater the Rcr value, the
lesser the penalty, so the estimated acoustic or elastic property
model is allowed to deviate further from the associated low
frequency model.
A usual working range is 0.01 to 0.20. Lowering the number
increases the similarity to the LFM.
NOTE: The value of Rcr always must be greater than 0 and
larger than Ra. Although the default values are the same in
practice, the Ra values should be different from each property
type.
15. In the Specify the processing volume of interest section,
specify the VOl for the inversion.
There are two options that you can select based on how you
want to specify the VOl.
• To specify the VOl by IL and XL range, select Use inline,
crossline range. Select the ranges by entering values in
the associated fields or using the slider bars.
• To specify the VOl by polygon, select Use polygon and
click to enter the polygon. The time range also can be
adjusted.
258 • Simultaneous seismic inversion and the Petrel Property Model Builder Quantitative Interpretation
This figure shows an example of this section if you select Use
inline, cross/ine range.
~----------------------------------~ ~~
"" Crossline: 2132 slep: 1
o----------------------------------1
2132 2634
~~oo: ~ ~------------------------~
lnline. begin: 3355 Md: 3580 step· '1
Quantitative Interpretation Simultaneous seismic inversion and the Petrel Property Model Builder • 259
The Run time settings verify that the inversion job can run (CPU
cores, memory/RAM, available disk space) when the job starts.
If you run other jobs at the same time as Simultaneous Seismic
Inversion, the processes might exhaust the CPU/RAM
resources or the other process might consume the available
disk space. Best practices recommend not to run other large
CPU, RAM, or disk-consuming jobs at the same time.
It is important to change the working directory to a suitable
location.
16. On the Output tab, select the desired output.
This tab specifies what output is written by the inversion and in
what format.
Select Same as input, SEG- Y, or ZGY as the format and
select the check boxes in the table for the output that you want
to create.
• The Output Property is the main inversion result. It
represents elastic properties in the specified unit as set by the
Petrel templates and in the grid and sample rate of the input
seismic. It is selected by default.
• Reflectivity is the reflectivity of each property calculated
sample by sample.
• For each input seismic dataset, you can select a set of
Synthetics and Residual seismic data sets as output.
Residual= Seismic- Synthetic.
~ lr~-~~d Output
Output form~l @ S~me cs ilput {) SEG·'r ZGY
-~~---Se1-5m-icsl-----~:
Far)l 45
zlck -----R-es_Jdu-~l ----~.R~[ ----Syn__
I
lheli·cs ----li
260 • Simultaneous se1smic invers1on and the Petrel Property Model Bu1lder Ouant1tat1ve Interpretation
17. With all parameters and output now specified, click one of
these buttons.
• Run: If enabled, runs the inversion. If there are problems with
the input, the inversion does not run, but the case can be
saved to the tree.
• Apply: Applies the parameters and saves the case to the tree.
• OK: Saves the case and closes the dialog box.
• Cancel: Cancels changes made since the last time OK or
Apply were clicked. The window closes.
Visualization and quality check of the simultaneous
inversion output
When the inversion has run successfully, the output is stored in the
Input pane below the entry for the Inversion case. Several volumes are
placed in the tree, depending on the output selected. The volumes can
include property volumes, the associated reflectivities, and the
residuals for each of the properties inverted (Figure 15).
Test Property Model Simul Inversion
~ lJ 0 Test Property Model Simul lnvet'$ion
~ ~ 0 Test Property Model Simul Inversion P1mpedance
0 lnfine 3457
0 Xl..ine 2383
0 2=·2&04.00
I> fl 0 Test Property Model SiiU Inversion P-ftpedance Reftec:tivly
I> f!l 0 Test Property Model Simul lnvefflion P/ S velocity ratio
I> ~ 0 Test Property Model Simullnversion P/ S velocity ratio Reflectivity
t> t:J 0 Test Property Model Simul Inversion Density
C> f:l 0 Test Propert'f Model Simul Inversion Density Reflectivit'f
I> ~ 0 Test Property Model Smul lnversion NRM_Nea!Crop_5-20 Residual
I> ~ 0 Test Prcperty Model SinU lnYetsicn NRM_Neaerop_5-20 Synhetic
I> ~ 0 Test Property Model Smullnversion NRM_MidCrop_1S.33 ~idul!l
I> ~0 Test Propert'J Model Smullnversion NRM_MdCrop_1S.33 Synthetic
I> ~0 Test Property Model Simul Inversion NRM_FarCrop_31 -45 Residual
t> ~0 Test Property Model Simul Inversion NRM_FarCrop_3H5 Synthetic
Quantitative Interpretation Simultaneous seismic inversion and the Petrel Property Model Builder • 261
Additional information about the run is captured on the QC tab of the
Inversion case. Double-click the inversion case in the data tree after the run
finishes and select the QC tab in the Settings dialog box.
~-
Settings for 'Inversion'
, ~·-·
- <: _,
- "''~ -- ·-···-~-" ,, .-. - ,- ~ .. - ·-· - l
I Nllme
£1 New NGme Pimpedonce
I [J. New Neme PIS Ylllocity ratio
Cl New N~~tne o-ily
I
~
Slllb91K: I V11lue
Ralauv. mmfit (Ob) ·58+49173
Relative misfit c; En~) 26.0~ -
Relobve runber of Atfledcra ('t. ) ,6.4341507
1
~
Log ~le
This tab contains data about when the inversion was run and the
volume created and written as output. The Statistics section contains
statistics about the fit and the number of (significant) reflectors.
Additional data about the run is written to the Log File displayed in the
lower part of the window.
Observe the output of the Relative number of reflectors from the
inversion case. Bracket the reflection threshold up or down until the
output for Relative number of reflectors is around 0.2 (20%), or until
other factors visible in the output data sets indicate the desired output
quality.
262 • Simultaneous seismic inversion and the Petrel Property Model Builder Quantitative Interpretation
The Relative misfit field is a global measure of the energy in the
residuals. Ideally, this value would be close to zero; however, the
seismic data contains noise and the inversion should leave this noise
behind in the residuals. To judge the Relative misfit parameter, you
must balance the value of the misfit number with a view of what is left
in the residuals. The question to ask is whether there is clear signal in
the residuals, or is just random noise left behind?
The Case tab contains the settings used to run the inversion. These
settings can be edited and the inversion rerun if desired .
• Settings for..,_,.,.
I >----,
j lnpJt Ouq,ut .
II -
Figure 17 The Case tab of the settings for a specific inversion case
Ouant1tat1ve Interpretation Simultaneous se1sm1c mvers1on and the Petrel Property Model Bu1lder • 263
The Run button is located on the Operation tab.
Unlock
Earlier, you learned about the Seismic Inversion OC plot function, which
can be used to inspect the output properties and the logs at the well
locations.
Quantitative Interpretation Simultaneous seismic inversion and the Petrel Property Model Builder • 265
Figure 20 and Figure 21 show the Inversion QC plot of the results. In
Figure 20, the low frequency data at the well location is displayed in
the center tracks of each seismic panel. In Figure 21, the detailed log
curves are displayed.
In each case, the log that appears to the right of the seismic displays
show the low frequency property curve (green), the inversion result
(blue), and the input log curve (red). The inversion clearly has captured
the key features of the seismic reflectivity and has honored the low
frequency trend from the model. Of interest is how well it has captured
the pay section. This section was absent from the low frequency model
and its inclusion in the inversion result is because of the seismic
contribution.
Figure 20 Inversion DC plots of the inverted data. The log tracks embedded in
the seismic show the low frequency model. The log that appears to the right of
the seismic displays show the low frequency property curve (green), the
inversion result (blue), and the input (red)
266 • Simultaneous seismic inversion and the Petrel Property Model Builder Quantitative Interpretation
Figure 21 Inversion DC plots of the inverted data. The log tracks embedded in
the seismic show full bandwidth log data. The log that appears to the right of
the seismic displays are the same as in Figure 20
Quantitative Interpretation Simultaneous seismic inversion and the Petrel Property Model Builder • 267
In the Rock physics section, you created a crossplot of Vp/Vs plotted
against acoustic impedance. This crossplot is reproduced in Figure 22.
This plot shows that the pay section can be identified by where it is
plotted in this space. It is the isolated cloud in the lower left of the plot.
14
I• ft'"•l (Collocticn
r
Ill
Q. 12
~
u..
<
Q.
11
f
c..
10
.><
u
0
!;.
12 16 20 2.4 28 32 36 4.0 0 9
268 • Simultaneous seismic inversion and the Petrel Property Model Builder Quantitative Interpretation
Procedure - Use the Geobody workflow
This procedure shows you how to extract a geobody from a selected
area in a crossplot.
1. On the Home tab, in the Perspective group, select the G&G
Perspective.
2. Activate a 30 window.
3. On the Seismic Interpretation tab, in the Volume
interpretation group, complete these steps:
a. Click Insert and select Box probe.
~-___.interpretatio n
1
Vo lume interpret ation r:;.
Quantitative Interpretation Simultaneous seismic inversion and the Petrel Property Model Builder • 269
4. In the Tool Palette, click the first button on the left to activate
the Manipulate probe function.
-::--= Tool PaJette 0 X
r!/ Manipulate probe
X
270 • Simultaneous seismic inversion and the Petrel Property Model Builder Quantitative Interpretation
5. To contain the seismic volume, use the blue handles to resize
the probe.
6. Access the Settings dialog box for the Box probe by right-
clicking on the Box probe entry in the Input pane.
Quantitative Interpretation Simultaneous seismic inversion and the Petrel Property Model Builder • 271
7. In the Settings dialog box, open the Volumes tab.
;i:J Settings for 'Box probe 1' LJL
8 Info l ~ooo Stmistics I People I Style I Volumes IOpacity I Extraction I
Seismic input
1st cube
~ t; Inversion P-impedonce
2nd cube
I ~
~ ,II; Inversion P/S velocity ~io I I.JW
3rdcube
~I I ·~ .
Co-rendering
Mode
ICROSSPLOT: Color: Color table l Opacity: Crossplot selection · IE:
Threshold
CL-- 7~21505 /~
Geobody masking
Geobody
~I I
Mode
IDisable/None ... ,
I Apply
II ./ OK II ~< Cancel I
B. In the Seismic input section, use the blue arrows to enter the
two volumes you want to crossplot and click Apply.
9. Open the Opacity tab and select Crossp/ot.
272 • Simultaneous seismic inversion and the Petrel Property Model Builder Quantitative Interpretation
The data appears in the crossplot window as shown in this
figure.
stol
AI
Selection -
@ Opacity
~
{) Color
10
~
9 •••
AI • •o
ools -
PoiU
Seal at LOD:
Quantitative Interpretation Simultaneous seismic inversion and the Petrel Property Model Builder • 273
You can display additional volumes or co-visualization.
274 • Simultaneous seismic inversion and the Petrel Property Model Builder Quantitative Interpretation
Results
The result of selecting the region in the polygon in the plot in
"Procedure- Use the Geobody workflow" is shown in Figure 23.
Except for some outliers (acquisition artifacts), the Geobody nicely
isolated the area above the fluid level as seen in your data.
Figure 24 Top down view of the geobody showing the main pay area in the
center and a smaller (unpenetrated} area with similar properties on the left
Quantitative Interpretation Simultaneous seismic inversion and the Petrel Property Model Builder • 275
Figure 25 Geobody overlaid on a time slice through the data near the pay level;
note the excellent structural conformance
Except for the pay in the well, which you know about already, there is a
Geobody to the left of the volume downthrown to the main fault. Is this
a legitimate result and perhaps a new prospect? Figure 26 and Figure
27 show some seismic cuts through this area.
276 • Simultaneous seismic inversion and the Petrel Property Model Builder Quantitative Interpretation
Figure 26 In line sections through the unpenetrated anomaly highlighted in the
Geobody extraction
Quantitative Interpretation Simultaneous seismic inversion and the Petrel Property Model Builder • 277
Figure 27 Crossline sections through the unpenetrated anomaly highlighted in
the Geobody extraction
278 • Simultaneous seismic inversion and the Petrel Property Model Builder Quantitative Interpretation
Additional diagnostics
Additional diagnostics are available to check the quality of the
inversion. Specifically, the inversion outputs synthetic seismic; that is,
the seismic response calculated from the final model corresponding to
the angles associated with the input seismic volumes. It also outputs
the residuals, the difference between the real and synthetic volumes.
You can visualize these outputs in the 3D window and Interpretation
window. Figure 28 through Figure 31 show examples.
Figure 28 Synthetic seismic on the left and the actual seismic on the right;
there is a good match where the lines tie
1 Synthetic
2 Actual
Quantitative Interpretation Simultaneous seismic inversion and the Petrel Property Model Builder • 279
Figure 29 Actual seismic in both traverses, which can be compared to the
synthetic section in Figure 28
280 • Simultaneous seismic inversion and the Petrel Property Model Builder Quantitative Interpretation
Figure 30 Actual seismic on the right and the residual seismic on the left, which
can be compared to Figure 28 and Figure 29
Quantitative Interpretation Simultaneous seismic inversion and the Petrel Property Model Builder • 281
NOTE: The Inversion property builder and Simultaneous
inversion both work with 20 data, Simultaneous inversion
using the 20 output from the Inversion property builder.
In the Inversion property builder, the new column Top
horizon Marker appears with the 20 input and must be
defined.
You can visualize the model properties in the 30 window
(Figure 31 ).
1 AI
2 VpNs
3 Density
Figure 31 20 simultaneous inversion results
282 • Simultaneous seismic inversion and the Petrel Property Model Builder Quantitative Interpretation
The Inversion QC plot tool also works for 20 data as shown
in Figure 32.
Quantitative Interpretation Simultaneous seismic inversion and the Petrel Property Model Builder • 283
Lesson 5- Data input for AVOZ inversions
Data loading for AVOZ follows a similar pattern to loading for 20 data.
Stacks for AVOZ inversions are loaded by highlighting the folder that
contains the data and clicking ¢.
Likewise, you can enter wavelets from a folder (Figure 33).
~ .._.___._._..__
· ..l
...]
,........ ...._ ~
lHR ~'H~Cf9! ..........
IV
l5l ""'
351 ~~
H.}.Ziw~-CICL1$NI. 7
!I_AZl_--~187-lV
H_;IZI___~IB7-ll7
lZ
12 "
;z v:·
+I. •..AZ·--~··-1-217
~~I
181 20.1 H,loi:5_;,,P.02.111·111.7
25.3 lU Mfo'l........_ro_;u=
- II Ol H_IZ<_,I"""'-Ql~:).ll.~
,.,
12
,.,
22 I H_Rl_,...._lnJ5..J»J
. ''"'
Jl
12
:!<.3
c
22
,:-,t ......_~!Ul51
to' I •.t-.-Jil.l53-l!.3
'~i
'
Hfll..-t.np;6._04_:r.:~
H_AU~£M_l!.c
H_Rl__ _ OUZ-'2 ·I
~
~
"'
;)17
lS.3 :l$1 I !Vi:~O<_l1.Q
c • !.: ·-~..IM.l!-<2
"' ';
--
.J
i~IOlft.t
f12
011
You can enter the low frequency models, azimuthal sector values, and
other parameters.
NOTE: For AVOZ cases, the Significant reflector constraint needs
special attention. For AVO and time-lapse data, it is necessary to lower
the number significantly, for example, to 0.00015 for three input seismic
data sets. For AVOZ it must be even smaller.
There also is an extra parameter relating to the threshold for computing
the anisotropy. Figure 34 shows the location of th is parameter and its
explanation.
284 • Simultaneous seismic inversion and the Petrel Property Model Builder Quantitative Interpretation
Figure 34 Minimum anisotropy cutoff parameter
1 Acoustic Impedance
2 Density
3 Fast Shear
4 Slow Shear
Quantitative Interpretation Simultaneous seismic inversion and the Petrel Property Model Builder • 285
Figure 36 3D window display showing the fast to slow shear ratio
Figure 37 3D window display showing the fast to slow shear ratio azimuth
vectors
286 • Simultaneous seismic inversion and the Petrel Property Model Builder Quantitative Interpretation
Review questions
• In what kinds of settings is simultaneous inversion appropriate
to use?
• What information is contained in the low frequency model?
Why is this information important to the inversion process?
• Why are good wavelets and well ties important to getting good
results?
• What kind of wavelet extraction process is recommended for
inversion?
• What is predictability?
• What kind of diagnostics can you visualize to check the quality
of the inversion process?
Summary
In this module, you learned about:
• basic theory regarding Simultaneous inversion and key
workflows, such as Wavelet extraction from Seismic-Well
Ca Iibration
• using the Inversion property builder to create a low
frequency model for use in simultaneous inversion
• setting up and running a Simultaneous inversion
• quality checking the output using the simultaneous inversion
diagnostics and the Inversion QC plot tool
• analyzing the output using crossplots and geobodies
Quantitative Interpretation Simultaneous seismic inversion and the Petrel Property Model Builder • 287
. . 5. - Stochastic
Module .
se1sm1c 1nvers1on
Learning objectives
After completing this module, you will know:
• some of the differences between simultaneous and stochastic
inversions
• how stochastic inversions are used
• how a stochastic inversion works
• how to create a simple model for use in a stochastic inversion
• how to set up and run a Stochastic inversion
• how to check the quality of the output
• how to calculate properties from the inversion output
• how to create a reservoir AVO model from stochastic inversion
output, add random noise to the model, and visualize the
results
1 Seismic volume
2 Reservoir model
Frequency (Hz)
Figure 3 Frequency spectrum and how different data types fill the different
frequency regions
Variograms
It is intuitive that earth properties (for example, lithology, porosity, and
permeability) are more likely to be similar between two points if those
points are close to each other than if they are widely separated. The
degree to which things are dissimilar and the distance over which they
become so is captured in a statistical measure called the variogram.
The parameters used by stochastic inversion to perform the statistical
portion of the inversion property estimation come from a variogram
analysis of local well data.
Figure 4 shows an example of a variogram. On the horizontal axis is the
distance between samples and on the vertical axis is the variance, or
the degree of difference, and, therefore, the variance between
properties. At close distances, the difference usually is small. At large
distances, the difference usually is large. Therefore, the variogram rises
with increasing separation distance from a small value to a large value.
:lO 40 60 80 100
;:; ;:;
-ir Sample Variogram
Sill
~ C)
~
C)
~
~
~·
~ C) C)
~ ,.
C) C)
•
...,
C)
~Nugget ...,
C)
~Range
20 40 60 80 100
Separation Distance
1 lL
y(h) = 2IN(h) " ' (zi - zj) 2
N(h)
In this equation,
• N(h) is the number of samples that are separated by distance h
• Z.I and Z. are samples where i- j=h, which is the separation
J
distance
Variograms have their own special terminology.
• The value for the semivariance as the sample spacing approaches
zero (that is, how much things vary when near each other) is called
the nugget.
• As the distance increases, the semivariance rises until it plateaus.
The plateau value is called the sill.
• The distance at which the semivariance reaches the sill (or for
some analytic variogram models, 95% of the sill) is called the
range.
• A variogram plot from actual data points is called an experimental
or sample variogram.
• The fit of an analytic representation of the variogram to an
experimental variogram is called the variogram model.
There are several common types of variogram models: Gaussian,
exponential, and spherical variograms. The formulas are discussed
shortly, but their key characteristics are shown in the plot in Figure 5.
~ 0
00
0
~
00
~-
~ 0 0
0. 0.
"""
~-
~ 0
:,.
0
:,.
0 0
II,) II,)
0
Range 0
Separation Distance
R i
! i
1:50DCIO
1000 25IIOm
It is important to note that working with fewer wells carries risks that
the results of a stochastic inversion will not model the distribution of
properties correctly within a reservoir. You must be aware of the
uncertainties in the results that are a consequence of being under
constrained.
In stochastic inversion, the key variogram parameters, the sill, nugget,
and range (and major and minor axes in the case where the distribution
is not uniform} are needed for the vertical and lateral dimensions of the
model. This information tells the inversion program how to predict
appropriate statistical variations in the inversion properties that are
tried as possible realizations of the property model.
Later in the training, you learn in more detail how to compute a
variogram in Petrel.
6
= :=== := ~ ~
fj,
*~ ~ ~ +- t---
I
@]Well location
0 Simulated cell
* Un-simulated cell
N =Number of iterations
Synthetic •truth•
- Best fit after N iterations
R=Correlation coefficient between observed and synthetic seismic traces
Figure 8 Process for matching the seismic data in the stochastic inversion
process
~
~
~
Xmin: 759735 .47720 @
Ymin : 7835487.8456 ~
X max: 764347.97747 Wiclh: 4612..5002£54 ~ [BII Expand I
y m&: 7848062.8455 Height: 12574.999906 ~ !mm Stwink 1
[-1 ~ J! ..t OK
h. Click Apply.
The model is stored in the tree in the Models pane.
2. Add horizons.
a. In the Corner point gridding group, click Horizons.
Define model Fa ult model o bj ect ...
Horizons
Horizon type:
- .~
g]B]~~~~Ei] ~ ~ ~ ~[EJ
Use
Horizon Horizon Conform to another .Smooth horizon
Index StatllS Well tops Input #1
name type horizon iteJ"ations -fault
lines
r-
1 Horizon4 Conformable No 1 ../ Done 0 [l] Yes ~ ~ Horizon4
2 Horizon 5 Conformable No 1 ../ Done 0 ~ Yes ~ ~ Horizon5
3 Horiz on 6 Conformable No 1 ../ Done 0 [{] Yes ~ ~ Horizon 6
4 Horizon 6_ Conformable No 1 ./ Done 0 0 Yes ~ ~ Horizon S
3. Create layers
a. In the Corner point gridding group, click Layering.
,-
'fa
~
Define model · f3 ul model object • I Horizons Hori;:on cl ear -up
~J
Well log
lki
Data
S. ""'rai ir.g in age
Ecflt e:osting:
@ OverNrile
Replace and add new
0 Leave an other cells unchanged
Well logs
0
o: Poirts attrble
Sdect log I p AJ
[@ Set!ings
LJ Usebias - - - - - --
l.Jpscaled property: .... ,
(J Zone correction
rupw
0 WeB report
0 Reset output sheet
0 Zone corrected log
0 30 grid z.one log
0 30 gnd well tops
l ..t ~ ll..t oK
liJ Sim ple g rid ·~ F3 It model oper:'ltions Zones Ef1 Grid refinement
""' 5F to b It mod el ~ Edit fa ult mod el Layerin;;~ ~ Do mai <Otl\iersior.
Comer po int gridd ing
1\.lake layers
Reference Restore
Name Color Calculate Zone division
.surface eroded
L] Yes
L] Yes
7.
~· ~· Wdllogs
I ~: I
({') Wel~op attributes
00:
¢0
0 Points attribute
•
[@
0
Settings
Usebias
Upscaled propetty: I
= #if'-ss
..- I
It=
~eDs: 1~10
10
iti~..htey(
Property modeling
I p AJ trend [U]
Status: 1 ts 14>scaled
Trends
~ Variogram
[Q]
-
,_0
-- ¢~
Total sill:
I Ip AI trend (U]
statUs : j £S lijiSciiled
[Q]
Total sill : 1.0
Nugget: 0.0001
8 Neura• net
-----1 dJ User defined algorithm
Variogram
I i
~ il
j §
~ ~-~
3200~--~
2o400~--1~
CI00~~~~~~800~~1CI00~-2~
o400~~~ ~
0 500 1000 1500 2000 2600m
1M "' leeeeeee! . .
1:50000
The center of the map represents zero lag. The lag distance
increases from the center outward. It might be necessary to
adjust the parameters to get a good resu lt. From the map
display, a trend along a line with an axis of 20 to 210 degrees
is apparent. Along this axis, the data is most correlated and
least correlated orthogonal to that axis. These directions can
be used to define the major and minor axes for the horizontal
variogram analysis.
Training image
Velllog Data ~rend
------
Property: ~ VPVS Trend [U]
[](C
::t1 Sear.:m or. r · g;.::;& Uil'1& [@] '~
Direction Azimuth Dip
Number Lag Sea reb Band Tolerance Lao
lags dirtaoc~ .adm. wfdtb antle tofenoce
Vertical t!A
~· s 25 2ti£1 5l) ~s 5li
Major :J 0 s .:S.!: lXoO UJ 1.5 5n
Kinor 173 I) L5l) 1XCI 2::0& .G5 5I:
V~model~
Nugget: ~ ~~ [Q]~
.Structure 1
Type Spr,ericai
·.SUI ~.SC...$9
A f-.
"-.:;....--"
___ ___
------~
:~t::
'---11--'"
12.5 t2.s 11 2.s 1sh 21is
Distance
-2t'C -100 --
•••••••
8£.
• • •••• w
OJ
••••••••
~~~~~~~7~5~~,+,~,~~14r;~
~ ~~,~~~~~2+19~~2Y5~S~~1+91~--~ os
Distance ::!.
S!.
322 • Stochastic seismic inversion Quantitative Interpretation
You can try different variogram types to see if you can improve
the fit. The values for the Sill and Range in the Variogram
model fitting section are recalculated. When a reasonable fit
is achieved, the sill and range parameters can be read for later
entry into the inversion parameter input.
••••••••
Algorithm:
Acoustic Impedance :
Algorithm: IPre-Stack Stochastic Inversion for koustic ~ce. Vp!Vs and Densiy
Select model grid:
Mode!property!Tends - - - - - - - - - - - -
\'pN s: VFVSTrerd
RHOBtrerd
[] HDVA_VelocitLAms
Optimization 'Neight:
[] Average_Velocity [Realized 1
EJ Near_5-20
r:J Mid_18_33 Minimum incidence angle: 5 degrees
[] Far_31_45
[1] NRM_MearCrop_5-20 M~mum incidence angle: 2{) degrees
[1] NRM_MidCrop_18-33
[1] NRM_Far0op_31-45 Incidence angle range: 15.00 degrees
0 Depth_wavelet_cubefjar
[] CC_Cube_50
Eifective incidence angle: 13.11 degrees
D CC_Cube
Seismic wavelet: fE31V-.JP 1_NearRZ_5-20
NOTE: Use the Optimization weight field to control the relative
influence of the current seismic angle stack volume in the
inversion. The weight controls the importance of matching
traces from the current volume in the calculation of the global
objective function. Use the default value if all volumes are of
good quality.
6. Open the Zone Settings tab and complete these steps:
a. Select or clear the Use settings by zone check box. This
option controls whether the parameters on this tab are to be
applied to the whole dataset or if separate parameters are
entered for each zone. You select or clear this option,
depending on how the variogram analysis was done.
326 • Stochastic seismic inversion Quantitative Interpretation
NOTE: Whether you select or clear this option depends on how
similar the statistics and the geology are for the different zones
in the model.
b. In the Variogram model section, take these actions:
• Select the Variogram type from the list. Be consistent with
the variogram analysis that was done.
• Enter the Sill, Nugget, and Vertical range from the
variogram analysis.
• Enter values for the Major range and Minor range based
on experience with other wells or as test values. You can
assess the impact of the test values in trial inversions
until a reasonable result is obtained.
• If structural information is available and was used in the
variogram calculation, enter Dip and Plunge. For a single
well, the Azimuth cannot be determined,
• To align the major and minor axes with the model axes,
click the Align button.
• To force the range parameters to be the same, click the
Isotropic button.
c. In the Correlation matrix section, the model parameters
(in this case AI, VpNs, and density) are correlated to some
degree, which means that the program cannot make
completely random choices for each parameter. The matrix
in the Correlation matrix section informs the inversion to
what degree the model properties are correlated.
Enter values or click the Estimate button to have the
program estimate the values from the data.
To ensure that the estimates are statistically valid, click
the Validate button. If necessary, the program adjusts the
matrix so that it is valid.
d. In the Distribution section, enter appropriate Std
Deviation, Min, and Max values for the properties, or, if
upscaled properties were entered on the Model
properties tab, you can click Estimate to have the
program calculate the entries.
You can adjust the Min and Max values manually after the
program estimates them to prevent non-logical values from
being allowed (for example, Poisson's ration greater than
0.5).
Variogram model· - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
Correlation matrix
Distribution
Optimization Settings
-
Convergence criterion: 0.8
J3. Common
Color. As attribute
Symbol: a SimpUfied sphere
Siize: 5
~fateri:al: """ I
Figure 11 shows the Cost diagnostic. This diagnostic shows the value of
the cost function at each location. The vast majority were above the 0.8
threshold used as the value for this run, which indicates a successful
inversion over most of the area. The inversion had trouble fitting the
data where the dip is steep in the fault zone and where the shallow gas
anomaly interferes with data quality.
Model output
After reviewing the diagnostic output, you should review the output
data.
Figure 14 through Figure 17 are examples of the output for one run with
a particular set of parameter input choices.
In this example, there were not enough wells to assess the spatial
variogram for lateral variation, so an isotropic value of around 2000 m
was chosen as a trial to assess the result (the vertical range was set at
around 50 m). The fine vertical layering is clear, as is a great deal of
lateral continuity in the beds. The hydrocarbon accumulation and flat
spot, however, are not very clear.
Compare this example to the simultaneous inversion shown in Figure
18.
It is possible that the Major range and Minor range of 2000 m was
excessive and did not allow enough flexibility to pick up the pay section.
To test this assumption, a second run was made with a range
parameter of 500 m in the lateral directions and 50 m vertically. The
resu It is quite different.
This result is noisier and with some patchiness, but the flat spot clearly
is visible in this result. It seems to be closer to representing what you
know the subsurface to be and with some further adjustment, what you
would like to see in the result.
AI-PORO
Transform
Hi-Res, Equiprobable
Stochastic Simulations
Depth Volumes
0.8
0.7
(;
~ 0.6
:I
c:r
f 0.5
u.
u
i 0.4 -+- 1 Realization
:;
E 0.3
:I
u
0.2
0.1
r> lj v~
If& Woddlow 1
§) PrabiMiy_CalcdiUin_AI_VPVS T
Dl Probabilty_CalcUation_no_den5ity 0
Dl Porosity Calculation
~ High_Ranking
~ Copy of High-Ranking
§.) Porisity from AJ
~ L1hocube
§.) Woddlow 3
fiTl WO!kflow 2
~l 1Norkflow 4
5. Use the buttons at the top of the dialog box to manipulate the
table. Use the blue arrows in the table to enter rea lizations.
In this workflow, AX is assigned to acoustic impedance, AZ to
VpNs, and AY to density.
Enter the volumes that contain these property rea lizations into
the appropriate column as shown in this figure.
~ Initialize reference list
Calculator Net.ra l
ne!
Property interpr:et.atton
~
~
S,ettings
~·~·---~----~-----·--------------------
[OJ~
JL____ _ _ _ _ _ _ _ ____,~ I
~~ l
[CJ Fromfile: .___ _ _ _ _ _ _ _ ____, []I Run ]
Jlttach new to template:
··lp AITrend(Uj ~ General
;p RHOB trend [U] Filter templates: T-Ftn::tions-.--,
,-I
AVO
AVO li\1 AVO Seismic logs
modeling r@Connaissance Wedge model
Al/0
Algorithm : [ PP AVO. '*i & Richards -acoustic impedance. )/pNs and density • ]
Gridproperties - - - - - - - - - - - - - - - - - -
Selectagrid : ~ '--------------__J
Acoustic impedance:
Vp!Vs:
Density:
Algorithm : IPP AVO. Aid & Richards • acoustic impedance, VpNs and density ... J []
Grid properties
~ lndude elastic properties from grid
~--------------------------~
VpN s:
Density:
Algorithm: IPP AVO, ftki .& Richards- acoustic impedance, Vp/Vs and density •I
Grid properties
[iJ lndude elastic properties from grid
Select a grid: Oass Grid _ _ =>=]
Acoustic impedance: fJ Class Grid SSI_Acoustic lrrpedance_1 [Uj
Vp/Vs: Class Grid SSI_Vp.rVs_1 [U]
Wave!fl. - - - - - - - - - - - - - - - - - - - -
Angle range
Output
@ Pre~ntlcal reflections Post~cal refl ect1cns Both
Algortthm: ( PP AVO. Aki & Richards - acoustlc impedance. VpNs and densly
Glid properties - - - - - - - - - - - - - - - - - - - -
0 lndude elastic properties from grid
End angle: 20 d~
Output
,·::> 0 re"\.'TlliCal reflectiOI"'S Post -critical reftectJor;s Both
~ Ikt\.. JP1_NearRZ_5-20
Noiseamplitude - - - - - - - - - - - - - - - - -
~ -----------------------
~ Combine random noise with inptt data
Summary
In this module, you learned about:
• some of the differences between a simultaneous and
stochastic inversion
• how stochastic inversions are used
• how a stochastic inversion works
• creating a simple model for use in a stochastic inversion
• setting up and running a stochastic inversion
• quality checking the output
• calculating properties from the inversion output
• creating a Reservoir AVO Model from stochastic inversion
output, adding random noise to the model, and visualizing the
results
Prerequisites
To complete this module successfully, you must have completed the
previous modules in the course.
Learning objectives ~
~
After completing this module, you will know how to run the set of
processes performing lithology classification including:
• creating classification log
• lithology analysis
• lithology prediction
Creating c/as.siflc:,ation
data using weH log.s
...
-t
. .. 17 1.7 '""-
·I
f: 14t
0.) ...
- 11
~
... I!
"' - IJ
II
I
a ,.. r.W
I
P~p:pulil)
P
t
· 0 MlrX4111
· ~~ Wtllt
Eil S.11mie
Fillar•foldl!
---~~~~~~·
• 0 Waveltlt
• el Su!factt_lOMtm
1!1 Hori.w"4 • 150ms
.., Horlzon-4
eJ Horl.ron 5 izon 4 Horizon
eJ Honzon6
eJ Horizon 6 •150ms
If Sm111 Polygon
•n ® CI'Oit IIC6ont
II·... 0 WtiH...NAM_NtarCrop_s-20
11-. 0 Wtll·l...NAM..MidCrop_l8·33
' 0 Wtli·I_NAM_FarCrop_31-15 izon 5
' eJ F1HtrJ
• Will conwlallon
X: (PHIE
Y (va.
L ~~~~~----------------------'1
Pooi~ -------------------- 1
[t)Color [sw
~It]
~~
~0
~0
~ qu
) ~
~&•
i ~
~s-c~
Vc~~nt-...
~SJIIOflll'tl.ltl
03
tkDNicWili'ICIIYI
M,.•l!lld!l PH1Efm31m31
Color.
Type· Global wei log (disc.)
Template: - 1111 Generol - . -, re1
.. ·dis - e- - - - - .
He sand
.__ Date.
U ' uNOEF 1· 1 1· 1
Change selected rows
Pat!Bm. ~ Line color. [- ... I
Petrel filename: (obi';ct can1 be saved separately)
Orig. filename: (Made by PetreO I ./ Apply II ./ OK 11 1< Cancel
I . . Apply II
10. Quality check the new lithoclass log in a Well section
window.
Boolean
Cased ,
Ce!l adivity ! Expand (recursive)
Completion~ ~I Sort by names
Connected Insert new cont inuous color -table
• Default disc ]
n;n rl::~~;t:ifir --
Insert new discrete color table
- -- - - - --
U lu NOff
Cell activity I
Oab ult t .,lart:lblo
Dip classmcabon colllt':lenc
Q~lo/ ~--------------~
AVOCiass '1
Material Region
1
Default discrete 1 L_
Unti1!ed 1 l l l'---'---;:::::====~====:::;-.::===::::::;----' 1
I J /IWf ll ll CaAt•l
4. Open the Well log calculator and create your classes using the
Lithoclass template. In this example, we will use these
classes:
Shale= if ( VCL >= 0.3,1 ,0)
Class1_sand =if ( VCL < 0.3 And SW >= 0.8, 2,0)
Class2_sand = if ( VCL < 0.3 And SW < 0.8 And PH IE<= 0.22, 3, 0)
HC_sand =if ( VCL < 0.3 And SW < 0.8 And PH IE> 0.22, 4, 0)
litho
•
~
ana lysis :i-
Litho cfassific .•.
:-TwT0 TWT
:-· '4H~ va.
-c I "' I
I Principal component analysis I [ Correlalion analysis j
I .t Apply II .t OK I[ 1( Cancel I
I
4. On the Settings tab, it is recommended to select Supervised.
Purely statistical facies identification (Unsupervised) also can
be done, but the results will be more reliable if manual
geologic interpretation is provided (such as, existing facies
interpretation) and used as input-output pairs. These data pairs
are used to make a model that estimates the correct output
data when presented with the given input data. The idea is
that the same model can then be applied to similar input data
to compute reasonable output. The error in the network is
assessed by passing the training data's input through the
neural network and comparing it to the original data.
<0 Unsupervised 12
@ Supervised Fccies_interpretation
Training
Error limit 10 %
Cross validation: 50 %
Probability threshold: 0
.. ~ Neural net 1
., :S· Aflribute
;( GR
~ff PHIE
sw
~H VCL
Facies_interpretation
DYII Facies_interpretation [Neural net 1]
.. T Class liNer
:ee: shale
::: Class 1 sand
::: Class 2 sand
••
.,.e; He sand
l Ex lO
-I
'-
'
'
-~
doss2snl
• hcsnl
·I
14><10
-I
12lll0
·I
1Cx10
t
f sexJ0 2
,;:
·l
6Cx10
·l
4Cx10
·l
2Cx10
OCxlO
0
l
<•lx10
l
6Cx10
3
80x10
I
10.10
I
12x10
.
14x1C
t
ICxiO
Hx iO~
Figure 5 Litho Analysis results of the Vp/Vs ratio attribute in 1D plotting mode
o.f1
~· J
o.A
'-,, oJ
' '
o-0
,,.
~ ,
.,. , ""
,....,.
'~
.....
"'').
"'~
..,.-.,
I•"'"'
. Httu.d I
Figure 6 Results in 20 plotting mode
•
•
t
'·
~fin~ QC
!PDF confusion matnx statistics (Facies vs prediction)
.,.. P (Prediction I True)
~
Focies neme shale clllss 1 sand ci8SS2 sand he sand
shale
- f74.33%
- 144.39%
- 03.16% Too.63%
c~ss1 send 20.84% ,44.04% 00.90% 101 .91%
~~fCVPVS 1 10 14 17
~ I P RHOB 1 10 14 17
11. Under Window, on the PDF viewer tab, try the different
plotting mode. Depending on the plotting mode selecting,
different options are enabled.
•
View Cane'a
all align en: •
View
• 'X
3 a::ributes node
• sliM
• sandyshllle
• gnd
• HcS!IId
J J 4
4.0x10 8.0x1.0 1.2x10
1'-ftpedance [kPa.s"m)
He sand
Figure 9 Difference in resolution between the porosity log and the seismic cube
You can apply the classifier to seismic cubes, wells, and pillar grids. The
input data must be collections of rock parameters of the same type.
Template: ~~==~~~~==========~=========-~~
classLogGenDisPetrel_Template
Attribute mapping
Attribute Input
P-impedance +9! Slmlnv 30. P-impedance {Rel!lized} 1 I
P/S velocity ratio +lJ Slmlnv 30. P/S velocity ratio [Rel!lized} 1 I
Density I+ mJ Slmlnv_30. Density [Realized) 1 I
Zone
.
>J0-6(Camo<eiNcf IAnYf X
-
.,_,_
~~
Review questions
• What is the most common way to establish classification and
differentiate facies from well logs?
• What is the main input of the Litho analysis process?
• Why do we use the Bayesian approach?
• Which window do you use to visualize the PDFs? How many
plotting modes are available?
• What is the use of each of the PDF confusion matrix?
• What is the main input of the Litho prediction process? How do
you use the different output cubes?
Summary
In this module, you learned about:
• the different methods to create classification from well logs
• running the Litho analysis process and quality check the results
with the PDF confusion matrix
• running the Litho prediction process and identify potential pay
from the results
These documents and the online help provide significant support for the
tasks detailed in this training.
Bibliography
1. Backus, M 1962. Long-wave elastic anisotropy produced by
horizontal layering: J. Geoph Res., 67, 4427.
2. Batzle, M. and Wang, Z. (1992) Seismic Properties of Pore
Fluids, Geophysics, 57, 1396-1408
3. Castagna, J. P., Batzle, M.L., and Eastwood, R. L. 1985,
Relationships between compressional-wave and shear-wave
velocities in clastic silicate rocks, Geophysics 50, 571-581
4. Greenberg, M. L. and Castagna J. P., 1992, Shear-wave velocity
estimation in porous rocks: Theoretical formulation, preliminary
verification and applications: Geophysical Prospecting, 40,
195-209.
5. Gardner, G.H.F., Gardner, L.W., and Gregory, A.A. 1974,
Formation velocity and density-the diagnostic basics for
stratigraphic traps, Geophysics 39, 770-780.
6. Gassmann, F., 1951,Uber die elastizitat poro sermedien:
Vierteljahrsschrift der Naturforschenden Gesellschaft in Zurich,
96, 1-23.
7. Bill Goodway, Taiwen Chen, Jon Downton, Improved AVO
fluid detection and lithology discrimination using Lame
petrophysical parameters; "A,p", "Jlp", &""-/11 fluid stack",
from Pand S inversions. SEG Technical Program Expanded
Abstracts 1997: 183-186.
8. Zoeppritz, K., 1919, Erdbebenwellen VIII B, On the reflection
and penetration of seismic waves through unstable layers:
Goettinger Nachr., pages 66-84
9. Aki, K. and Richards, P. G., J979, Quantitative Seismology, W.H.
Freeman and to. P 153
10. Castagna, J.P., and Swan, H. W., 1997, Principles of AVO
Crossplotting. The Leading Edge, 16, 337-342
Quantitative Interpretation References • 399
11. Fatti, J.L., Smith, G.C., Vail, P.J., and Levitt, P.R., 1994,
Detection of gas in sandstone reservoirs using
12. AVO analysis: a 3-D seismic case history using the Geostack
technique: Geophysics, 59, 1362-1376.
13. Pan, N. D. and Gardner, G.H.F., 1987, The basic equations of
plane eJastic wave reflection and scattering applied to AVO
analysis. Annual Progress Review 19, Seismic Acoustic
Laboratory, University of Houston.
14. Rutherford, S. R. and Williams, R. H., 1989, Amplitude-versus-
offset variations in gas sands: Geophysics, Soc. of Expl.
Geophys., 54, 680-688.
15. Shuey, R.T., 1985, A simplification of the Zoeppritz equations,
Geophysics 50,609-614.
16. Smith, G.C. and Gidlow, P.M., 1987, Weighted Stacking for
Rock Property Estimation and Detection of Gas, Geophysical
Prospecting 35,993-1014.
17. Gidlow, P. M., Smith, G. C., and Vail, P., 1992, Hydrocarbon
detection using fluid factor traces: Joint SEG/EAEG Summer
Research Workshop, Technical Program and Abstracts, 78-89.
18. Li, Y., Downton, J., Xu, Y., AVO Modeling in Seismic Processing
and Interpretation. Part 1: Fundamentals. CSEG Recorder,
December 2003, 42-52
19. Mahdi H. Almutlaq and Gary F. Margrave, 2010, Tutorial: AVO
inversion CREWES Research Report- Volume 22 (201 0)
20. Ross, C. P., and Kinman, D. L., 1995, Nonbright-spot AVO: two
examples. Geophysics, 60, 1398-1408
21. Verm, R. and Hilterman, F., 1995, Lithology color-coded seismic
sections: The calibration of AVO crossplotting to rock
properties. The Leading Edge No.8 August 1995, 847- 853
22. Walden, A. T., Making AVO sections more robust: Geophysical
Prospecting, European Association of Explorat~on
Geophysicists, val. 39, pp 915-942, October 1991
