& Mooring Chain

General Purpose
07 GenPurp Mooring.qxd 27/1/12 12:48 PM Page 2

General Purpose & Mooring Chain

GRADE L CHAIN
TO AS 2321
Grade L chain is the lowest quality tensile steel chain suitable for
lifting purposes and is manufactured to AS 2321.
Grade L chain is widely used in the marine industry for anchor
and mooring chain.

Grade L Chain - Galvanised

Links Metres
Stock Chain Size WLL
S (mm) R (mm) F (mm) per per
Code (mm) (tonnes)
& Mooring Chain
General Purpose

Metre 100 kg
CGSL06B 6 0.40 6.3 18.8 21.6 53.2 110.0
CGSL08B 8 0.64 8.0 23.8 27.0 42.0 67.8
CGSL10B 10 1.00 10.0 29.8 34.3 33.6 43.2
CGSL13B 13 1.70 13.0 38.8 44.6 25.8 27.8
CGSL16B 16 2.58 16.0 47.8 54.9 20.9 17.5
CGSL20B 20 4.03 20.0 59.2 68.5 16.9 11.1
CGSL22B 22 5.06 22.0 64.9 77.0 15.4 9.2

Grade L Chain - Self Colour

Links Metres
Stock Chain Size WLL
S (mm) R (mm) F (mm) per per
Code (mm) (tonnes)
Metre 100 kg
CBSL06B 6 0.40 6.3 18.8 21.6 53.2 116.0
CBSL08B 8 0.64 8.0 23.8 27.0 42.0 71.4
CBSL10B 10 1.00 10.0 29.8 34.3 33.6 45.4
CBSL13B 13 1.70 13.0 38.8 44.6 25.8 29.6
CBSL16B 16 2.58 16.0 47.8 54.9 20.9 17.8
CBSL20B 20 4.03 20.0 59.2 68.5 16.9 11.3
CBSL22B 22 5.06 22.0 64.9 77.0 15.4 9.5

S R

Link dimensions and metres per 100kg are subject to commercial tolerances

152
07 GenPurp Mooring.qxd 27/1/12 12:48 PM Page 3

General Purpose & Mooring Chain

PROOF COIL CHAIN
Manufactured from low-grade carbon steel, Proof Coil Chain is industries, this versatile range of chain is proof load tested at
available in a variety of link dimensions. Suitable for a wide range manufacture to at least twice the maximum load recommended
of applications across the manufacturing, marine and agricultural for normal use.

Short Link
Featuring the shortest link configuation, Short Proof Coil Chain
is the most flexible mild steel chain available for marine and
general purpose use.
F
S R F Self Colour Galvanised
Chain Size MWL
(mm) (mm) (mm) Metres per Metres per
(mm) (tonnes)
100 kg 100 kg
6 0.40 6.3 18.8 21.6 116.0 110.0
S R 8 0.64 8.0 23.8 27.0 71.4 67.8
10 1.00 10.0 29.8 34.3 45.4 43.2
13 1.70 12.7 38.0 43.0 28.6 27.8

& Mooring Chain

General Purpose
Regular Link
Designed with link dimensions for a wide variety of general
purpose applications.
F
Self Colour Galvanised
Chain Size MWL S R F
Metres per Metres per
(mm) (tonnes) (mm) (mm) (mm)
100 kg 100 kg
3 0.06 3.0 16.6 13.1 602.0 553.0
S R 4 0.11 3.8 19.6 15.8 351.0 345
5 0.19 4.75 23.2 19.1 238.0 225.0
6 0.32 6.0 28.0 24.0 144.1 135.7
8 0.53 7.6 35.8 29.2 90.6 87.7
10 0.86 9.5 43.4 35.5 59.0 57.8
13 1.50 12.0 51.7 44.5 35.5 34.6
16 2.31 16.0 59.6 57.3 19.0 18.6
20 3.67 20.0 73.3 71.0 12.3 12.0
24 5.34 24.0 87.0 84.8 8.6 8.4

Long Link
With the longest link formation in the range, Long Proof Coil
Chain features more generous link dimensions to provide more
metres per 100 kilograms. Ideally suited to agricultural and
barrier applications.
F
Self Colour Galvanised
Chain Size MWL S R F
Metres per Metres per
(mm) (tonnes) (mm) (mm) (mm)
100 kg 100 kg
3 0.05 3.0 23.2 15.4 595.0 581.0
S R 4 0.09 3.8 26.8 18.4 391.0 369.0
5 0.15 4.75 29.8 21.5 226.0 215.0
6 0.26 6.0 36.2 26.0 152.1 148.4
8 0.46 7.6 43.5 31.0 93.4 91.1
10 0.75 9.5 53.1 39.0 61.2 59.7

For Grade 70 load WARNING

binding chain and
components to AS 4344
please refer to Section
12 Load Restraint
• The MWL (Maximum Working Load) stated for Proof Coil Chain is for guidance in the selection of a chain with
sufficient strength for the intended purpose.
• Proof Coil Chain is NOT SUITABLE FOR LIFTING APPLICATIONS.
• Use only load rated products for lifting.

Link dimensions and metres per 100kg are subject to commercial tolerances

153
07 GenPurp Mooring.qxd 27/1/12 12:48 PM Page 4

General Purpose & Mooring Chain

MINING SUSPENSION CHAIN
Mining Suspension Chain is manufactured in Australia from low
grade carbon steel and is available in limited sizing from Regular
or Long Link configurations. Suitable for the suspension of pipes
or ducting, it is proof loaded to at least twice its maximum
working load and suppplied in a galvanised finished in minimum
pallet lots.
MSC Regular Link
Galvanised
Chain Size MWL S R F
F Metres per
(mm) (tonnes) (mm) (mm) (mm)
100 kg
6 0.32 6.0 28.0 24.0 135.7
8 0.53 7.6 35.8 29.2 87.7
10 0.86 9.5 43.4 35.5 57.8
S R

MSC Long Link

Galvanised
Chain Size MWL S R F
Metres per
& Mooring Chain
General Purpose

(mm) (tonnes) (mm) (mm) (mm)

100 kg
10 0.75 9.5 53.1 39.0 59.7

TRAILER SAFETY CHAIN

Trailer safety chain is manufactured in Australia and is processed
F and tested to the strict performance requirements of AS 4177.
Trailer safety chains are manufactured for use with trailers and
caravans of up to 3,500kg aggregate trailer mass and are
available in a range of sizes that are designated according to their
loading capacities.
S R

Self Colour Galvanised

Chain Size MWL S R F
Metres per Metres per
(mm) (tonnes) (mm) (mm) (mm)
100 kg 100 kg
8 1.6 7.6 43.5 31.0 93.4 91.1
10 2.5 9.5 53.1 39.0 61.2 59.7
13 3.5 12.0 51.7 44.5 35.5 34.6

For Grade 70 load WARNING

binding chain and
components to AS 4344
please refer to Section
12 Load Restraint
• The MWL (Maximum Working Load) stated for Trailer Safety Chain is for guidance in the selection of a chain
with sufficient strength for the intended purpose.
• Trailer Safety Chain is NOT SUITABLE FOR LIFTING APPLICATIONS.
• Use only load rated products for lifting.

Link dimensions and metres per 100kg are subject to commercial tolerances

154
07 GenPurp Mooring.qxd 27/1/12 12:48 PM Page 5

General Purpose & Mooring Chain

GALVANISED COMMERCIAL CHAIN
50kg Pail Packs
Inside Outside
Size Pail Pack
Stock Code Length Width Metres
(mm) (kg)
(mm) (mm)
CGH03D 3 16 12 50 262
CGH04D 4 20 15.6 50 175
CGH05D 5 23 19.5 50 107.5
CGH06D 6 27.2 24 50 63
CGH08D 8 32 30 50 39.5
CGH10D 10 40 37 50 25
CGH13D 13 50 46 50 14.5

500kg Bulk Packs

Inside Outside
Size Bulk Pack
Stock Code Length Width Metres
(mm) (kg)
(mm) (mm)
CGH03 3 16 12 500 2617

& Mooring Chain

General Purpose
CGH04 4 20 15.6 500 1748
CGH05 5 23 19.5 500 1073
CGH06 6 27.2 24 500 628
CGH08 8 32 30 500 396
CGH10 10 40 37 500 248
CGH13 13 50 46 500 147
CGH16 16 60 56 500 100

LONG LINK CHAIN

Long link chain has greater length and width dimensions than regular commercial chain, provides
50kg Pail Packs better options for terminating and has more metres per 100kg.

Inside Inside
Size Pail Pack
Stock Code Length Width Metres
(mm) (kg)
(mm) (mm)
CGHL03D 3 22.1 9.7 50 263
CGHL04D 4 25.4 10.6 50 162
CGHL05D 5 29.3 11.8 50 103
CGHL06D 6 34.5 14.1 50 64
CGHL08D 8 41.2 15.9 50 39
CGHL10D 10 49.0 18.7 50 25

500kg Bulk Packs

Inside Inside
Size Bulk Pack
Stock Code Length Width Metres
(mm) (kg)
(mm) (mm)
CGHL03 3 22.1 9.7 500 2630
CGHL04 4 25.4 10.6 500 1615
CGHL05 5 29.3 11.8 500 1030
CGHL06 6 34.5 14.1 500 640
CGHL08 8 41.2 15.9 500 391
CGHL10 10 49.0 18.7 500 251
Link dimensions and metres per kg are subject to commercial tolerances

WARNING
• These products are classified as commercial quality and consequently shall not be used for lifting
purposes.
• Use only load rated products for lifting.

155
07 GenPurp Mooring.qxd 27/1/12 12:48 PM Page 6

General Purpose & Mooring Chain

SPLIT LINKS
Overall Inside
Size Kg per
Stock Code Length Width
(mm) 100 Units
(mm) (mm)
CFLS040 3 19 8.5 0.60
CFLS050 5 25 10.5 1.40
CFLS060 6 38 12.5 3.60
CFLS080 8 38 16 6.00
CFLS100 10 50 19 11.00
CFLS130 13 64 27 25.50

Link dimensions and metres per kg are subject to commercial tolerances

GALVANISED CHAIN SWIVELS

Chain swivels are commonly used in a variety of mooring systems
in marine applications.
& Mooring Chain
General Purpose

Eye & Eye Swivels

Working Dimensions (mm) Weight Ea.
Size
Stock Code Load Limit
(mm) A B C D L R (kg)
(kg)
GSWEE06C 6 386 32 18 19 27 86 74 .10
GSWEE08C 8 567 41 21 25 32 105 90 .18
GSWEE10C 10 1,020 51 24 32 38 127 109 .32
GSWEE13C 13 1,630 63 33 38 51 171 138 .60
GSWEE16C 16 2,360 76 40 44 60 203 167 1.13
GSWEE19C 19 3,270 89 45 51 67 222 183 1.82
GSWEE22C 22 4,540 102 52 57 78 264 213 2.83

Jaw & Eye Swivels

Working Dimensions (mm) Weight Ea.
Size
Stock Code Load Limit
(mm) A B C K L N P R (kg)
(kg)
GSWJE06C 6 386 32 18 19 12 80 22 6 67 0.10
GSWJE08C 8 567 41 21 25 13 95 22 8 74 0.15
GSWJE10C 10 1,020 51 24 32 16 117 27 9 92 0.30
GSWJE13C 13 1,630 63 33 38 19 156 33 13 114 0.61
GSWJE16C 16 2,360 76 40 44 24 187 38 16 135 1.12
GSWJE19C 19 3,270 89 44 51 29 211 44 19 154 1.76
GSWJE22C 22 4,540 102 52 57 30 244 52 22 178 2.66

156
07 GenPurp Mooring.qxd 27/1/12 12:48 PM Page 7

General Purpose & Mooring Chain

STAINLESS STEEL CHAIN
The standard range of Stainless Steel Chain is manufactured from
Type 316 Stainless which is highly resistant to corrosion in acid
and alkaline, as well as salt water and marine environments.
Applications for stainless steel chain include stabilizer chains,
netting ground chain and trawl board chains.
Nobles also have Type 304 Stainless Steel chain available on
request. 304 grade chain is available in 6 - 13mm in regular and
short link. Link dimensions and MWL are identical to 316 grade
but 304 grade chain is supplied unpolished.

Short Link Stainless Steel Chain

Chain Metres
Stock MWL
Size S (mm) R (mm) F (mm) per

& Mooring Chain

General Purpose
Code (tonnes)
(mm) 100kg
CGSS06S 6 0.45 6.3 18.9 21.5 114.4
CGSS08S 8 0.80 8.0 24.0 27.5 70.2
CGSS10S 10 1.25 10.0 30.0 33.5 46.0
CGSS13S 13 2.12 13.0 38.9 45.0 28.2

Regular Link Stainless Steel Chain

Chain Metres
Stock MWL
Size S (mm) R (mm) F (mm) per
Code (tonnes)
(mm) 100kg
CGSS040 4 0.20 4.0 20.1 15.8 317.5
CGSS060 6 0.45 6.3 26.2 23.5 126.3
CGSS080 8 0.80 8.0 32.2 29.5 78.7
CGSS100 10 1.25 10.0 39.2 36.2 50.0
CGSS130 13 2.12 13.0 49.2 46.2 31.5

WARNING
• Stainless Steel chain is not rated for lifting purposes.
• Use only load rated products for lifting.

S R

Link dimensions and metres per 100kg are subject to commercial tolerances

157
07 GenPurp Mooring.qxd 27/1/12 12:48 PM Page 8

General Purpose & Mooring Chain

STUD LINK CHAIN & FITTINGS
Nobles can supply a full range of stud-link chain products and
fittings. Chain specifications include Grade 2, Grade 3 and offshore
mooring chain grade. Stud-link chain is also available with varying
certification depending on requirements or application.

Stud Link Chain (Metric) Proof & Breaking Loads in kN

Anchor Chain for Vessels Offshore Mooring Chain Approx
Grade 2 Grade 3 ORQ Grade 4 GW5 Weight
Chain Proof Break Proof Break Proof Break Proof Break Proof Break of
Size Load Load Load Load Load Load Load Load Load Load Chain
(mm) kN kN kN kN kN kN kN kN kN kN (kgs/m)
16 107 150 6
17.5 127 179 7
19 150 211 211 301 8
& Mooring Chain
General Purpose

20.5 175 244 244 349 249 376 385 490 10

22 200 280 280 401 286 431 442 562 11
24 237 332 332 476 339 511 524 667 13
26 278 389 389 556 397 598 612 779 15
28 321 449 449 642 458 691 707 900 18
30 368 514 514 735 524 790 809 1030 21
32 416 582 582 832 578 880 917 1170 1100 1404 22
34 467 655 655 936 1030 1310 1236 1572 25
36 522 731 731 1049 1150 1460 1380 1752 28
38 580 812 812 1157 822 1245 1280 1630 1536 1956 31
40 640 896 896 1285 1410 1790 1692 2148 35
42 703 980 980 1402 960 1446 1550 1970 1860 2364 38
44 768 1079 1079 1540 1108 1690 1690 2150 2028 2580 41
46 836 1167 1167 1677 1840 2340 2208 2808 45
48 908 1275 1275 1814 1268 1922 2000 2550 2400 3060 49
50 980 1373 1373 1961 1432 2171 2160 2750 2592 3300 55
52 1056 1476 1476 2111 1508 2273 2330 2970 2796 3564 59
54 1134 1585 1585 2268 1620 2441 2500 3180 3000 3816 64
56 1215 1698 1698 2429 1735 2615 2680 3410 3216 4092 69
58 1298 1814 1814 2595 1854 2794 2860 3640 3432 4368 74
60 1383 1933 1933 2766 1976 2978 3040 3870 3648 4644 79
62 1471 2056 2056 2941 2101 3166 3240 4120 3888 4944 84
64 1561 2182 2182 3121 2230 3360 3430 4380 4116 5256 90
66 1653 2311 2311 3306 2361 3559 3640 4630 4368 5556 95
68 1747 2443 2443 3495 2496 3762 3850 4900 4620 5880 101
70 1844 2578 2578 3688 2634 3970 4060 5170 4872 6204 107
73 1993 2786 2786 3986 2847 4291 4390 5580 5268 6696 117
76 2146 3001 3001 4293 3066 4621 4730 6010 5676 7212 126
78 2251 3147 3147 4503 3216 4847 4950 6310 5940 7572 133
81 2412 3373 3373 4825 3446 5194 5320 6760 6384 8112 144
84 2578 3604 3604 5156 3683 5500 5680 7230 6816 8676 155
87 2747 3841 3841 5495 3925 5916 6050 7700 7260 9240 166
90 2921 4084 4084 5842 4173 6289 6440 8190 7728 9828 177
92 3039 4249 4249 6078 4342 6544 6690 8520 8028 10224 185
95 3219 4501 4501 6439 4599 6932 7090 9030 8508 10836 198
97 3342 4671 4671 6683 4774 7195 7360 9370 8832 11244 206
100 3528 4932 4932 7056 5040 7596 7770 9890 9324 11868 219
102 3654 5108 5108 7308 5220 7868 8040 10240 9648 12288 228

158
07 GenPurp Mooring.qxd 27/1/12 12:48 PM Page 9

General Purpose & Mooring Chain

STUD LINK CHAIN & FITTINGS cont.

& Mooring Chain

General Purpose

Details of Stud Link Anchor Chain and Fittings

a = Common link g = Anchor shackle type Kenter
b = Enlarged link h = Anchor shackle, pear shaped
c = End link i = Swivel, normal type
d = Joining shackle type D k = Swivel shackle with bolt
e = Kenter joining shackle l = Swivel shackle with eye
f = Anchor shackle type D m = Hinge link

159
