KPI Document - MN Performance

Etisalat Group
Mobile Network Key Performance Indicators
Version: 2.0
Date published: 08-Jul-2013
Presented by: Group Technology/ Mobile Network
Mobile Network KPI Definition
Contents
Mobile Network Key Performance Indicators.......................................................................................... 1
1- Introduction.............................................................................................................................. 5
2- 2G Network............................................................................................................................... 8
2.1 GSM Network............................................................................................................................... 8
2.1.1 Call Setup Success Rate............................................................................................................ 8
2.1.2 Traffic Drop Rate..................................................................................................................... 8
2.1.3 Traffic Congestion Rate............................................................................................................ 8
2.1.4 Signaling Drop Rate................................................................................................................. 9
2.1.5 Signaling Congestion Rate........................................................................................................ 9
2.1.6 Handover Success Rate............................................................................................................ 9
2.1.7 Voice Traffic Volume................................................................................................................ 9
2.2 GPRS.......................................................................................................................................... 10
2.2.1 TBF Establishment Success Rate............................................................................................ 10
2.2.2 TBF Congestion Rate.............................................................................................................. 10
2.2.3 TBF Drop Rate....................................................................................................................... 10
2.2.4 Data Traffic Volume (GB)....................................................................................................... 11
3- 3G Network............................................................................................................................. 12
3.1 Circuit Switched (CS)................................................................................................................. 12
3.1.1 RRC Setup Success Rate......................................................................................................... 12
3.1.2 RRC Congestion Rate............................................................................................................. 12
3.1.3 CS RAB Setup Success Rate.................................................................................................... 12
3.1.4 CS RAB Congestion Rate......................................................................................................... 13
3.1.5 CS Service Drop Rate............................................................................................................. 13
3.1.6 Soft Handover Success Rate................................................................................................... 13
3.1.7 Hard Handover Success Rate.................................................................................................. 13
3.1.8 Inter-RAT Handover Success Rate.......................................................................................... 14
3.1.9 CS Traffic............................................................................................................................... 14
3.2 Packet Switched (PS)................................................................................................................. 14
3.2.1 PS RAB Setup Success Rate.................................................................................................... 14
3.2.2 PS RAB Drop Rate.................................................................................................................. 14
3.2.3 PS Traffic (GB)....................................................................................................................... 15
4- 2G Network Vendor Reference............................................................................................... 16
4.1 GSM Network............................................................................................................................. 16
4.1.1 SDCCH Assignment Attempts................................................................................................. 16
4.1.2 SDCCH Assignment Success................................................................................................... 16
4.1.3 SDCCH Drop Number............................................................................................................. 16
4.1.4 SDCCH Congestion Number................................................................................................... 17
4.1.5 TCH Assignment Attempts..................................................................................................... 17
2
4.1.6 TCH Assignment Success....................................................................................................... 18

4.1.7 TCH Congestion Number........................................................................................................ 18
4.1.8 TCH Drop Number................................................................................................................. 19
4.1.9 Outgoing Handover Attempts................................................................................................. 19
4.1.10 Outgoing Handover Success................................................................................................. 19
4.1.11 Voice Traffic Volume............................................................................................................ 20
4.2 GPRS Network........................................................................................................................... 20
4.2.1 TBF Attempts DL................................................................................................................... 20
4.2.2 TBF Attempts UL................................................................................................................... 21
4.2.3 TBF Success DL..................................................................................................................... 21
4.2.4 TBF Success UL...................................................................................................................... 21
4.2.5 TBF Drop Number DL............................................................................................................ 22
4.2.6 TBF Drop Number UL............................................................................................................ 22
4.2.7 TBF Congestion Number DL................................................................................................... 23
4.2.8 TBF Congestion Number UL................................................................................................... 23
4.2.9 GPRS Data Traffic Volume DL (GB)......................................................................................... 24
4.2.10 GPRS Data Traffic Volume UL (GB).......................................................................................24
4.2.11 EGPRS Data Traffic Volume DL (GB).....................................................................................25
4.2.12 EGPRS Data Traffic Volume UL (GB).....................................................................................25
5- 3G Network Vendor Reference............................................................................................... 27
5.1 Circuit Switched........................................................................................................................ 27
5.1.1 RRC Setup Attempts.............................................................................................................. 27
5.1.2 RRC Setup Success................................................................................................................. 27
5.1.3 RRC Congestion..................................................................................................................... 28
5.1.4 CS RAB Setup Attempts.......................................................................................................... 28
5.1.5 CS RAB Setup Success............................................................................................................ 28
5.1.6 CS RAB Congestion................................................................................................................ 29
5.1.7 CS RAB Drops........................................................................................................................ 29
5.1.8 Soft Handover Attempts......................................................................................................... 29
5.1.9 Soft Handover Success........................................................................................................... 30
5.1.10 Hard Handover Inter-Freq Attempts...................................................................................30
5.1.11 Hard Handover Inter-Freq Success.......................................................................................30
5.1.12 Inter-RAT Handover Attempts............................................................................................. 31
5.1.13 Inter-RAT Handover Success................................................................................................ 31
5.1.14 AMR Traffic Volume (Erlang)............................................................................................... 32
5.1.15 Video-phony Traffic Volume (Erlang)...................................................................................33
5.2 Packet Switched........................................................................................................................ 33
5.2.1 PS RAB Setup Attempts.......................................................................................................... 33
5.2.2 PS RAB Setup Success............................................................................................................ 33
5.2.3 PS RAB Congestion................................................................................................................ 34
5.2.4 PS Drops............................................................................................................................... 34
3
5.2.4 PS Traffic Volume DL R99 (GB).............................................................................................. 35

5.2.5 PS Traffic Volume UL R99 (GB).............................................................................................. 35
5.2.6 PS Traffic Volume HSDPA...................................................................................................... 36
5.2.7 PS Traffic Volume HSUPA....................................................................................................... 36
6- Vendor Counters..................................................................................................................... 37
6.1 Vendor Counters 2G Network................................................................................................... 37
6.1.1 Alcatel-Lucent....................................................................................................................... 37
6.1.2 Ericsson................................................................................................................................ 39
6.1.3 Huawei.................................................................................................................................. 40
6.1.4 NSN....................................................................................................................................... 41
6.1.5 ZTE....................................................................................................................................... 43
6.1.6 NSN - Motorola...................................................................................................................... 49
6.2 Vendor Counters 3G Network................................................................................................... 50
6.2.1 Alcatel-Lucent....................................................................................................................... 50
6.2.2 Ericsson................................................................................................................................ 63
6.2.3 Huawei.................................................................................................................................. 63
6.2.4 NSN....................................................................................................................................... 66
6.2.5 ZTE....................................................................................................................................... 66
4
1- Introduction
A Mobile Network KPI is a measure designed to track a critical performance variable over time and
provide a statistical measure of how well the Mobile Network is doing. The document covers the 2G & 3G
Mobile Network KPI standard formulae definition, KPI definition per vendor and vendor counters
Etisalat OpCos Current Software Releases
2G Networks
2G Networks
opco ALU Ericsson Huawei NSN ZTE
AFG EA R13 V10
AT Benin G11
AT CAR G11
AT CDI G11 R9
AT Gabon G11
AT Niger G11
AT Togo G11
EGY Misr G10 R13 V10
KSA Mobily B12.1 G11 R13 RG20
NIG EMTS B12 R13 RG20
PAK Ufone R9
SL Etisalat B11
TAN Zantel R9
UAE Etisalat B11 G10
3G Networks
3G Networks
opco ALU Ericsson Huawei NSN ZTE
AFG EA R13 UR9.3
AT CDI W11
EGY Misr W10 R13 UR9.3
KSA Mobily UA8.1 W12 R13 RU30
NIG EMTS UA7.1 R13
SL Etisalat UA7.1
TAN Zantel R12
UAE Etisalat R13
5
KPI Formulae Difference in Calculations Main Remarks
Tech KPI Remarks
2G CSSR  SDCCH Access should not be considered due to SDCCH

repetition attempts.
 SDCCH drop rate should include all services as it is not
possible to split it for certain vendors.
 SDCCH & TCH Handovers should not be considered as
attempts for network level KPIs.
 NSN is calculating TCH assignment success from the
terminating end in this case the 3G handover attempts and
success should be included in the attempts to balance the
formulae.
2G HO  HO success rate is calculated as Outgoing HO Success Rate

Success for network level.
Rate
 Success rate is based on inter-cell handovers only which
includes intra & extra BSC i.e. intra-cell handovers are
excluded.
 HO success rate is based on the HO commands and not HO
preparation phase.
2G TCH Drop  2 Formulae are used by vendors:

Rate
a) Abnormal Release/Total Release.
b) Total Drop/Total TCH Assignment
For the second formulae 3G to 2G handovers has to be added as
it not part of the TCH assignment.
2G TBF Drop  ALU calculates the drops as the difference between

Rate establishments and normal releases. This might yield
negative results if PS 3G to 2G Inter-RAT handovers are
ignored.
2G Data  An agreement has to be set for converting bytes to KB, MB,

Traffic GB, TB from bytes either by dividing by 1000 or 1024. EG
recommends by 1000 as it is used by most vendors.
 Data volume should be agreed as either useful RLC blocks
sent or total RLC sent.
 Data volume should be either on RLC or LLC layer.
3G RRC Setup  In case of enabled directed retry to 2G, the formulae should
Success include the attempts and success to 2G.
Rate
6
3G CS Drop  To be counted on cell level and not on RNC level
3G CS & PS  Should include DL & UL power, code and channel element

congestio congestion.
n
3G PS Drop  Cell PCH formulae has to be agreed with all vendors.

a) If the rate is calculated as Abnormal Release/Total
Release, activation of cell PCH reflects as high
percentage of drop rate due to decrease of normal
releases due to transition of idle to cell PCH instead of
normal release.
 It is recommended to calculate the figure as Abnormal
Release/PS RAB Success for network level.
3G Traffic  Cell level and not RNC level

 For R99 all the rates should be considered i.e. 8, 16, 32 .. and
not only the major ones (i.e. 64, 128, 384)
 An agreement has to be set for converting bytes to KB, MB,
GB, TB from bytes either by dividing by 1000 or 1024. EG
recommends by 1000 as it is used by most vendors.
Cell PCH formulae, the denominator on network level has been taken as total PS RAB assigned in
order to avoid the denominator which is total released PS RABs (normal+abnormal).
7
2- 2G Network
2.1 GSM Network
2.1.1 Call Setup Success Rate
KPI Name Call Setup Success Rate

Rate of calls going until TCH successful assignment, that is not interrupted by
Definition
SDCCH DROP neither by Assignment failures
(1 – SDCCH DROP No./SDCCH Seizures) * (TCH Assign Success/TCH Assign
Formulae
Attempts)
Threshold >99%
Unit %
 SDCCH Seizures include LU, if LU is to be excluded then the SDCCH drop
number and SDCCH LU number be subtracted from drops and seizures
respectively. Since the counters for drops for LU is not available for all
vendors then the formulae will include all the SDCCH Seizures reasons.
Comments  It is possible in Ericsson to get the dropped connections during location
area update (CLUNDROP). Also the counter CLUMSESTAB Successful MS
channel establishment on SDCCHs, for location area update.
 TCH Assignment Success & attempts should include 3G to 2G handovers
attempts & success.
2.1.2 Traffic Drop Rate
KPI Name TCH Drop Rate

Rate of TCH dropped (system + radio + handover + pre-emption) over the
Definition
total amount of calls established in the network.
Based on Call Origination: TCH Drop Number/TCH Assignment Success
Formulae Based on Call Termination: Abnormal Release/(Normal Release+Abnormal
Release)
Threshold <1%
Unit %
 In case TCH Drop Formulae is based on TCH origination then 3G to 2G
Comments handovers has to be added as TCH assignment. However, if based on call
termination, it is already considered.
2.1.3 Traffic Congestion Rate
KPI Name TCH Congestion Rate

Rate of RTCH not allocated during normal assignment due to congestion on
Definition
Air interface.
Formulae (TCH Congestion Number / TCH Assignment Attempts)
Threshold <1%
Unit %
 TCH congestion is considering congestion during TCH assignments
phase only. TCH congestion during handover should not be
Comments
considered on network level, however, it might be for used for
optimization purpose on the cell level only.
8
2.1.4 Signaling Drop Rate
KPI Name SDCCH Drop Rate

Rate of dropped SDCCH due to radio link failures (Radiolink Time-out or
Definition
Lapdm timer expiry)
Formulae (SDCCH DROP Number / SDCCH Assignment Success)
Threshold <1%
Unit %
Comments  Includes all services LU, SMS, Call origination …
2.1.5 Signaling Congestion Rate
KPI Name SDCCH Congestion Rate

Rate of SDCCH not allocated during radio link establishment due to
Definition
congestion on Air interface.
Formulae (SDCCH Congestion Number / SDCCH Immediate Assignment Requests)
Threshold <1%
Unit %
 Includes all services LU, SMS, Call origination …
 SDCCH congestion is considering SDCCH congestion during immediate
Comments assignment phase only, SDCCH congestion during handover should not
be considered on network level, however, it might be used for
optimization purpose on the cell level only.
2.1.6 Handover Success Rate
KPI Name Handover Success Rate

Rate of successful outgoing inter-cell and external handovers due to radio
Definition
problems without reversion to old channel.
Formulae (Successful Outgoing Handover / Outgoing Handover Attempts)
Threshold >99%
Unit %
 Handovers include inter-cell handovers only which is intra or inter BSC
Comments
but excludes intra-cell handovers.
2.1.7 Voice Traffic Volume
KPI Name RTCH Erlang

Radio TCH traffic in Erlang (FR & HR, AMR hourly measurement) for
Definition
channels in the GSM & DCS frequency bands.
Formulae TCH Erlang FR + TCH Erlang HR + AMR
Threshold
Unit Number
Comments  Total Mobile Access Traffic
2.2 GPRS
9
2.2.1 TBF Establishment Success Rate
KPI Name TBF Establishment Success Rate

Definition Rate of DL or UL TBF establishment successes per cell.
Formulae Successful Established TBF (DL+UL) / TBF Establishment Attempts (DL+UL)
Threshold >99%
Unit %
 It was not possible to identify the counters for some vendors (Ericsson
Comments
& Motorola)
2.2.2 TBF Congestion Rate
KPI Name TBF Congestion Rate

Definition Rate of DL/UL TBF establishment failures due to congestion per cell.
Formulae TBF Congestion Number (DL+UL) / TBF Establishment Attempts (DL+UL)
Threshold <1%
Unit %
Comments  DL & UL congestion are calculated & evaluated separately.
2.2.3 TBF Drop Rate
KPI Name TBF Drop Rate

Definition Rate of DL or UL TBF drops.
Formulae TBF Drop Number (DL+UL)/TBF Successful Establishment (DL+UL)
Threshold <1%
Unit %
Comments  DL & UL congestion are calculated & evaluated separately.
2.2.4 Data Traffic Volume (GB)
KPI Name Data Traffic (GB)

Definition Data Traffic Volume in GB
Formulae PDCH Data Traffic GPRS + EDGE
Threshold -
Unit Number (GBytes)
 An agreement has to be set for converting bytes to KB, MB, GB, TB from
Comments bytes either by dividing by 1000 or 1024. EG recommends by 1000 as it
is used by most vendors.
10
3- 3G Network
3.1 Circuit Switched (CS)
3.1.1 RRC Setup Success Rate
KPI Name RRC Setup Success Rate

The RRC Connection Attempt for service Procedure is complete when the
RNC receives an RRC CONNECTION REQUEST message from the UE. The
message contains information about one of the following service types
Definition requested by the UE: Conversational Call, Streaming Call, Background Call,
Interactive Call, Originating Subscribed Traffic Call, Emergency Call, High
Priority Signaling, Low Priority Signaling, Cause Unknown, Call Re-
Establishment.
Formulae Number of RRC Connection Request/Number of RRC Connection Attempts
Threshold >99%
Unit %
 2 KPIs can be calculated:
Comments a) RRC setup success rate for all types of requests.

b) RRC setup success rate for CS calls only.
3.1.2 RRC Congestion Rate
KPI Name RRC Congestion Rate

Definition This KPI is used to check the RRC Congestion Ratio in a cluster.
Number of RRC Setup Failures due to Congestion/Number of RRC Setup
Formulae
Attempts
Threshold <1%
Unit %
Comments
3.1.3 CS RAB Setup Success Rate
KPI Name CS RAB Setup Success Rate

This KPI is used to check the RAB Setup Success Ratio of all CS services in an
Definition
RNC or a cluster.
Formulae Number of CS RAB Setup Successes /Number of CS RAB Setup Attempts
Threshold >99%
Unit %
Comments
3.1.4 CS RAB Congestion Rate
KPI Name CS RAB Congestion Rate
11
Definition This KPI is used to check the CS RAB Congestion Ratio in a cluster.
Number of CS RAB Setup Failures due to congestion/Number of CS RAB
Formulae
Setup Attempts
Threshold >99%
Unit %
Comments
3.1.5 CS Service Drop Rate

This KPI provides the ratio of the CS RAB abnormal Releases to the total CS
Definition
RAB Releases (Normal Release + Abnormal Release).
Formulae Number of CS RAB Abnormal Releases/Number of CS RAB Releases
Threshold <1%
Unit %
Comments
3.1.6 Soft Handover Success Rate

This KPI is used to check the soft handover success ratio in an RNC or in
Definition
a Cluster, including softer handover.
Formulae Number of Successful Soft Handover/Number of Soft Handover Attempts
Threshold >99%
Unit %
Comments
3.1.7 Hard Handover Success Rate

Definition Inter-frequency Hard Handover Success Ratio
Number of Successful Inter-Frequency Hard Handover/Number of Inter-
Formulae
Frequency Hard Handover Attempts
Threshold >99%
Unit %
Comments
3.1.8 Inter-RAT Handover Success Rate

Definition Inter-RAT Handover Out Success Ratio i.e. 3G to 2G handovers
12
Formulae CS Successful Inter-RAT Handovers/CS Inter-RAT Handover Attempts

Threshold >99%
Unit %
Comments
3.1.9 CS Traffic

Definition Traffic Erlang for AMR voice & Video-phone traffic
Formulae AMR Voice Erlang + VP traffic
Threshold -
Unit Number (Erlang)
Comments
3.2 Packet Switched (PS)
3.2.1 PS RAB Setup Success Rate
KPI Name PS RAB Setup Success Rate

This KPI provides the ratio of the PS RAB abnormal Releases to the total PS
Definition
Formulae Number of PS RAB Abnormal Releases/Number of PS RAB Releases
Threshold >99%
Unit %
This KPI provides the ratio of the PS RAB abnormal Releases to the total PS
Comments
3.2.2 PS RAB Drop Rate
KPI Name PS RAB Drop Rate

This KPI is used to check the RAB Setup Success Ratio of all PS services in an
Definition
RNC or a cluster.
Formulae Number of PS RAB Setup Successes /Number of PS RAB Setup Attempts
Threshold <1%
Unit %
Comments
3.2.3 PS Traffic (GB)
KPI Name PS RAB Drop Rate
13
Definition Total PS Traffic (R99 & HSPA) in GB

Formulae Data Traffic for R99 DL + R99 UL + HSDPA + HSUPA
Threshold <1%
Unit Number (GB)
Comments
14
4- 2G Network Vendor Reference
4.1 GSM Network
4.1.1 SDCCH Assignment Attempts
KPI Name SDCCH Assignment Attempts

MC04+MC148
ALU
allocation + immediate assignment prep failures.
CCALLS
Ericsson
SDCCH attempts.
CA300J
Huawei
SDCCH requests.
Alloc_SDCCH + Alloc_SDCCH_Fail
Motorola
SDCCH allocations + immediate assignment prep failure
sdcch_seiz_att
attempts
NSN
Mobily using the counter "service.SDCCH_REQ". (Counter not available in the
document).
C900060003+C900060010+C900060038
ZTE
Etisalat Misr to confirm the formulae
4.1.2 SDCCH Assignment Success
KPI Name SDCCH Assignment Success

MC01+MC02
ALU
Imm. Assig. Success MT & MO
CMSESTAB
Ericsson
Signaling link established
K3003
Huawei
Successful Seizures
ALLOC_SDCCH - Chan_Req_Fail_Rol
Motorola
Allocation – mobile timeouts
sdcch_assign
NSN Network level should not consider sdcch_ho_seiz on network level. Mobily to
revise this formulae and confirm.
C900060242+C900060017+C900060235
ZTE
4.1.3 SDCCH Drop Number
KPI Name SDCCH Drop Number

MC07+MC137+MC138
ALU
HO Drop + BSS Fail+ Radio Fail
CNDROP-CNRELCONG
Ericsson
SD drops – drops due to TCH congestion i.e. timeouts due to unavailable TCH
Huawei CM30
15
Total SD drops
RF_LOSSES_SD
Motorola
SD drops due to RF problems. Other causes should be checked & included.
sdcch_radio_fail+ sdcch_rf_old_ho+ sdcch_user_act+ sdcch_bcsu_reset+
sdcch_netw_act+ sdcch_abis_fail_call+ sdcch_abis_fail_old+ sdcch_bts_fail
NSN
+ sdcch_lapd_fail+ sdcch_a_if_fail_call+ sdcch_a_if_fail_old- T3101_EXPIRED
All SDCCH failures.
C901070001 + C901070002 + C901070003 + C901070004 + C901070005 +
C901070007 + C901070008 + C901070009 + C901070010 + C901070011 +
C901070012 + C901070014 + C901070029 + C901070030 + C901070031 +
C901070032 + C901070033 + C901070035 + C901070064 + C901070065 +
ZTE C901070068 + C901070111 + C901070112 + C901070115 + C902000019 +
C902000020 + C902000021 + C902000022 + C902000023 + C902000024 +
C902000031 + C902000032 + C902000033 + C902000041 + C902000044 +
C900060219 + C900060222
4.1.4 SDCCH Congestion Number
KPI Name SDCCH Congestion Number

MC04
ALU
Immediate assignment preparation failures.
CCONGS
Ericsson
SD congestion
K3001
Huawei
Failed SDCCH due to busy SDCCH
Alloc_SDCCH_Fail
Motorola
SDCCH rejection due to congestion
sdcch_busy_att
NSN
SDCCH congestion
C900060005+C900060011+C900060039
ZTE SDCCH congestion + signaling TCH/F for assignment + signaling TCH/H for
assignment Etisalat Misr to confirm the formulae
4.1.5 TCH Assignment Attempts
KPI Name TCH Assignment Attempts

MC140a-(MC142e+MC142f)
TCH assignment request – (Internal Directed Retry + External Directed
ALU Retry)
Etisalat UAE Formulae: MC703+MC812 (TCH Allocation + TCH Failure due to
congestion) – Etisalat UAE formulae to be aligned with other OpCos.
TASSATT
Ericsson
First TCH assignment attempt.
K3010A
TCH Request
 Mobily Formulae considering CA311 which is Assignment Command is
Huawei not in line with ALU formulae counter MC140A which is assignment
request from the MSC.
 However, if we use this counter K3013A the internal and external
directed retry should be subtracted similar to ALU formulae.
16
Ma_cmd_to_ms
Motorola
Assignment commands sent to MS
TCH_REQUESTS_CALL_ATTEMPT
NSN
Channel requests for a call
C900060019+C900060030+C900060042+C900060046
ZTE
Attempts TCH/F + TCH/H (Voice + data)
4.1.6 TCH Assignment Success
KPI Name TCH Assignment Success

MC718
ALU
Normal Assignment Success
TCASSALL
Ericsson
Successful assignment
K3013A
Huawei Successful TCH seizures
same definition as counter CA316 used in Mobily Formulae
Total_Calls
Motorola
First successful TCH assignment procedure
conver_started - msc_i_tch_tch (as per NSN formulae document)
The counter SUCC_TCH_SEIZ_CALL_ATTEMPT is suggested by EG as it is in
line with other vendors.
Successful TCH assignment – Handover controlled by MSC
Mobily Formulae:
NSN
tch_radio_fail - tch_rel_due_rad_fail_ph_2_3 + tch_rf_old_ho+ tch_lapd_fail +
tch_bts_fail+ tch_user_act + tch_bcsu_reset + tch_netw_act + tch_act_fail_call +
tch_abis_fail_old + tch_tr_fail_old+ tch_norm_release
which calculates the TCH assignment form the terminating end (normal +
abnormal release)
C900060036
ZTE
Assignment Success.
4.1.7 TCH Congestion Number
KPI Name TCH Congestion Number

MC812
ALU
Congestion for TCH assignment phase only (does not include HO)
CNRELCONG+CNRELCONGSUB+THNRELCONG+THNRELCONGSUB
Ericsson
Congestion for main & subcells FR & HR
K3011A
Huawei
Failure due to busy TCH
ma_cmd_to_ms_blkd
Motorola
No Radio Resource available in assignment phase
TCH_REQUESTS_CALL_ATTEMPT-SUCC_TCH_SEIZ_CALL_ATTEMPT
NSN
TCH Seizures – TCH success
C900060020+C900060031+C900060043+C900060047
ZTE
Seizures failures FR & HR (voice & data)
4.1.8 TCH Drop Number
17
KPI Name TCH Drop Number

B10: MC621+MC736+MC739+MC14C+MC921C
Drops due to BSS, HO, Radio, transcoder, preemption
B11/12: (MC736+MC993+MC994)+(MC621+MC995+MC996)+(MC14c+MC739)+
ALU
(MC921c)
B11/12 formulae added MC993, MC994, MC995 & MC996 (AMR radio & handover
failures)
TFNDROP+TFNDROPSUB+THNDROP+THNDROPSUB
Ericsson
FR + HR (main + overlaid cells)
CM33
Huawei
Traffic channel drops
RF_LOSSES_TCH_ROLL+INTRA_CELL_HO_LOSTMS+OUT_INTRA_BSS_HO_LOSTMS
+OUT_INTER_BSS_HO_ATMPT-OUT_INTER_BSS_HO_SUC-
Motorola OUT_INTER_BSS_HO_RETURN-OUT_INTER_BSS_CLEARED
RF failures + HO lost intra cell + HO lost intra BSS + inter BSC HO lost (attempt-
succ-return-cleared)
NSN dropped_calls
C900060220 + C900060221 + C900060223 + C900060244 + C901070015
+ C901070017 + C901070018 + C901070019 + C901070021 + C901070022
+ C901070023 + C901070024 + C901070025 + C901070026 + C901070028 +
C901070036 + C901070037 + C901070038 + C901070039 + C901070040
ZTE + C901070041 + C901070042 + C901070043 + C901070044 + C901070045 +
C901070046 + C901070047 + C901070049 + C901070061 + C901070062
+ C901070113 + C901070114 + C901070116 + C901070117 + C901070195 +
C901070213
FR + HR (HO, Radio, LAPD, OMC-R, BTS Failure)
4.1.9 Outgoing Handover Attempts
KPI Name Outgoing Handover Attempts

MC650+MC660
ALU External Ho + internal HO (inter-cell only) attempts (command to be
checked)
HOVERCNT
Ericsson
Handover command
CH311+CH331
Huawei
Internal + external handover command
O_Intra_BS_HO_Atm+O_Inter_BS_HO_Atm
Motorola
Internal + external command
msc_o_ho_cmd+ bsc_o_ho_cmd_assgn+ bts_ho_assgn
NSN
HO command
C900060119+C900060093+C900060095
ZTE
To be checked by Etisalat Misr
4.1.10 Outgoing Handover Success
KPI Name Outgoing Handover Success

MC646+MC656
ALU
External + Internal HO Succ
Ericsson HOVERSUC
18
Successful HO to neighbor cell

CH313+CH333
Huawei
Internal + External Inter-cell HO Succ
o_Intra_bs_Ho_Suc + o_Inter_bs_Ho_Suc
Motorola
Intra-BSS + Inter-BSS HO Succ
msc_o_succ_ho+ bsc_o_succ_ho+ cell_succ_ho
NSN MSC controlled + BSC controlled
Cell_succ_ho should be removed as it is intra-cell HO
C900060096+C900060094+C900060120
ZTE MSC controlled + BSC controlled
C900060120 should be removed as it is intra-cell HO
4.1.11 Voice Traffic Volume
KPI Name Traffic Volume

MC380A+MC380B/3600
ALU
Time FR + HR busy
TFTRALACC+THTRALACC/360
Ericsson
FR + HR Traffic Accumulations
CR355A
Huawei
Traffic volume on TCH
TCH_Usage+TCH_Usg_Ext_Range+TCH_Usage_Inner_Z/3600*1000
Motorola
(Cell + external range + inner zone) traffic volume
((0.5*DTM_duration_sum_HR+ DTM_duration_sum_FR) /100)
/period_duration*60 + (ave_busy_tch/res_av_denom14)
NSN Or
trf_189a + trf_190 + trf_175 + trf_176
FR + HR TCH traffic on normal + extended TRX
(C900060127+ C900060129) / 3600
ZTE
(HR + FR) busy time
4.2 GPRS Network
4.2.1 TBF Attempts DL
KPI Name TBF Attempts DL

B10: P91a+P91b+P91c+P91d+P91e+P91f
B11: P91a+P91b+P91c+P91d+P91e+P91f+P505
ALU
Classified by request type (MPDCH or no MPDCH)
P505 attempt on DCCH for MS operating in DTM mode.
DLTBFEST
Ericsson
Successful establishment + Failures due to several reasons
A9101+A9301
Huawei
GPRS + EGPRS TBF establishment attempts
TBF_DL_ASGN_PACCH+GPRS_DL_ASGN_PCCCH+EGPRS_DL_ASGN_PCCCH
Motorola
GPRS + EGPRS assignments
NBR_OF_DL_TBF
NSN
Number of downlink TBF establishments
ZTE C900040141 + C900040142 + C900040143 + C900040144 + C900040145 +
19
C900040146 + C900040147 + C900040148

GPRS + EGPRS establishment different causes
4.2.2 TBF Attempts UL
KPI Name TBF Attempts UL

B10: P62a+P62b+P62c-P438c
ALU B11: P62a+P62b+P62c-P438c+P507
P507 for DTM Mode
Ericsson N/A
A9001+A9201
Huawei
TBF UL Attempts (GPRS + EGPRS)
UL_GPRS_TBF_ATTEMPTS+UL_EGPRS_TBF_ATTEMPTS
Motorola
GPRS + EGPRS TBF Attempts
NSN NBR_OF_ULTBF
C900040159 + C900040160 + C900040161 + C900040168 + C900040163 +
ZTE C900040164 + C900040165 + C900040166
Different causes for UL TBF attempts
4.2.3 TBF Success DL
KPI Name TBF Success DL

B10: P90a+P90b+P90c+P90d+P90e+P90f
B11: P90a+P90b+P90c+P90d+P90e+P90f+P506
ALU
Classified by request type (MPDCH or no MPDCH)
P506 success on DCCH for MS operating in DTM mode.
MSESTDLTBF
Ericsson
Successful TBF (at least one block sent and acknowledged)
A9102+A9302
Huawei
GPRS + EGPRS Successful TBFs
Motorola N/A
NBR_OF_DL_TBF-
NSN (DL_TBF_Establishment_Failed+DL_EGPRS_TBF_REL_DUE_NO_RESP)
TBF attempts – (GPRS + EGPRS failed no response)
C900040007+C900040015+C900040008+C900040016
ZTE
Signaling + Data (GPRS & EGPRS)
4.2.4 TBF Success UL

B10: P30a+P30b+P30c
ALU B11: P30a+P30b+P30c+P508
P508: DTM transfer
Ericsson N/A
A9002+A9202
Huawei
GPRS + EGPRS TBF Success
20
Motorola N/A
NBR_OF_ULTBF-
NSN
(UL_TBF_Establishment_Failed+UL_EGPRSTBF_REL_DUE_NO_RESP)
C900040025+C900040033+C900040026+C900040034
ZTE
Signaling + Data (GPRS & EGPRS)
4.2.5 TBF Drop Number DL

B10: (P90a+P90b+P90c+P90d+P90e+P90f)-(P146+P98c+P434b+P434d)-P9
B11: (P90a+P90b+P90c+P90d+P90e+P90f+P506)-((P146)+(P98c)+
((P434b)+(P434d))+((P509)))-(P9)
ALU
Establishment – Normal Releases
Establishments might not contain PS 3G to 2G handovers and if the value is
high might produce false negative results.
LDISTFI + LDISRR + LDISOTH
Ericsson LDISRR + LDISOTH
LLC buffer discarded due to radio or others
A9118+A9103
Huawei A9106+A9306
GPRS & EGPRS discarded due to N3105 overflow.
AIR_DL_TBF_FAILURES-AIR_DL_TBF_FAILURES_ET
Motorola
GPRS & EGPRS abnormal release
NBR_OF_DL_TBF
- DL_TBF_Establishment_Failed
- DL_EGPRS_TBF_REL_DUE_NO_RESP
NSN
-decode(AVE_DUR_DL_TBF_SUM,0,0AVE_DUR_DL_TBF_DEN)
DL TBF establishment – establishment failures – release no response –
normal release
C900040010+C900040002
ZTE
GPRS & EGPRS discarded due to N3105 overflow.
4.2.6 TBF Drop Number UL

B10: (P30a+P30b+P30c)-P22-(P147+P98d+P434a+P434c)
B12: (P30a+P30b+P30c+P508)-(P22)-((P147)+(P98d)+((P434a)+(P434c))+
ALU (P510)
TBF establishments – Normal Releases
(P508 UL TBF DTM; P510 releases when MS leaves DTM abnormally
IAULREL+PREJTFI+PREJOTH+PREEMPTULREL+OTHULREL
Ericsson Loss of radio contact or change of RP .. (to be confirmed whether these are
TBF failures during establishment or drops)
A9006+A9007+A9206+A9207
Huawei
GPRS + EGPRS releases due N3101 & N3103
Motorola N/A
NSN NBR_OF_UL_TBF- UL_TBF_Establishment_Failed-
UL_EGPRS_TBF_REL_DUE_NO_RESP-
decode(AVE_DUR_UL_TBF_SUM,0,0,AVE_DUR_UL_TBF_DEN)-
UL_TBF_REL_DUE_TO_FLUSH-UL_TBF_REL_DUE_TO_SUSPEND-
21
UL_TBF_RELEASES_DUE_DTM
UL TBF establishment – establishment failures – release no response –
normal release – suspend – DTM releases
C900040028+C900040020
ZTE
GPRS & EGPRS TBF UL drop due to T3101
4.2.7 TBF Congestion Number DL

B10: P14
B11/12:
ALU ((P105c)+(P105e))+(P14)+(P105g)+((P105i))+((P105k))+((P203))+((P511))
P14 radio congestion only, other counters for GPU, A-interface and other
reasons
FAILDLTBFEST
Ericsson
All TBF establishment failures
A9103+A9303
Huawei
DL GPRS & EGPRS congestion
BLOCKED_DL_TBF
Motorola
NO_RADIO_RES_AVA_DL_TBF
NSN
No radio resource available for DL
ZTE N/A
4.2.8 TBF Congestion Number UL

B10: P27
B11/12: ((P105d)+(P105f))+(P27)+(P105h)+(P105j)+(P105l)+(P204)+
ALU ((P512))
P27 radio congestion only, other counters for GPU, A-interface and other
reasons
PREJTFI+PREJOTH
Ericsson
immediate assignment reject due to TFI + No PDCH & other reason
A9003+A9010+A9203+A9210
Huawei
GPRS & EGPRS establishment failures and release due to no PDCH
CH_REQ_UNSVCD_PCU
Motorola
UL TBF not serviced by PCU
NO_RADIO_RES_AVA_UL_TBF
NSN
No radio resource available for UL
ZTE N/A
4.2.9 GPRS Data Traffic Volume DL (GB)
KPI
GPRS Data Traffic Volume DL
Name
ALU P55a*160 + P55b*240 + P55c*288 + P55d*400 / 8*1024*1024*1024
22
Useful RLC blocks CS1 to CS4

Mobily Formulae: P43 for GPRS/EGPRS
Total LLC Bytes
Division by 1024 or 1000 should be agreed
Ericss DLBGGDATA+DLTHP1GDATA+DLTHP2GDATA+DLTHP3GDATA/((8*1000*1000)
on Accumulated LLC PDU
(L9102*23+L9103*34+L9104*40+L9105*54)/(1024*1024*1024)
Huaw CS1 to CS4 RLC data
ei (TL9123/1000/1000)
Same formulae (one counter i.e. TL9123=CS1*23+CS2*34 ..)
DL_RADIO_BLKS_x_TS_CS_1*22+DL_RADIO_BLKS_x_TS_CS_2*33+DL_RADIO_BLKS_x_TS_CS
Motor _3*39+DL_RADIO_BLKS_x_TS_CS_4*53
ola x=1,2,3,4,5
RLC data layer
sum(a.rlc_data_blocks_ul_cs1 *20 + a.rlc_data_blocks_ul_cs2 *30 + sum over MCS-11
(b.ul_rlc_blocks_in_ack_mode + b.ul_rlc_blocks_in_unack_mode)*36 ;CS3 + sum over MCS-
NSN
12 (b.ul_rlc_blocks_in_ack_mode + b.ul_rlc_blocks_in_unack_mode)*50 ;CS4 )/1024
CS1 to CS4 data volume in RLC layer
C900040060/(1024*1024*1024)
ZTE
DL TBF LLC layer traffic GPRS
4.2.10 GPRS Data Traffic Volume UL (GB)
KPI
GPRS Data Traffic Volume UL
Name
P57a*160 + P57b*240 + P57c*288 + P57d*400 / 8*1024*1024*1024
Useful RLC blocks CS1 to CS4
ALU
Total LLC Bytes
Ericss DLBGGDATA+DLTHP1GDATA+DLTHP2GDATA+DLTHP3GDATA/((8*1000*1000)
L9102*23+L9103*34+L9104*40+L9105*54/1024*1024*1024
Huaw CS1 to CS4 RLC data
ei (TL9123/1000/1000)
Same formulae (one counter i.e. TL9123=CS1*23+CS2*34 ..)
DL_RADIO_BLKS_x_TS_CS_1*22+DL_RADIO_BLKS_x_TS_CS_2*33+DL_RADIO_BLKS_x_TS_CS
Motor
_3*39+DL_RADIO_BLKS_x_TS_CS_4*53
ola
RLC data layer
(rlc_data_blocks_ul_cs1 *20 +rlc_data_blocks_ul_cs2 *30 + sum over MCS-11
(b.ul_rlc_blocks_in_ack_mode + ul_rlc_blocks_in_unack_mode)*36 ;CS3 + sum over MCS-12
NSN
(b.ul_rlc_blocks_in_ack_mode+ul_rlc_blocks_in_unack_mode)*50 ;CS4)/1024
CS1 to CS4 data volume in RLC layer
C900040058/(1024*1024*1024)
ZTE
DL TBF LLC layer traffic GPRS
4.2.11 EGPRS Data Traffic Volume DL (GB)
KPI Name EGPRS Data Traffic Volume DL

ALU P55e*176+P55f*224+P55g*296+P55h*352+ P55i*448 + P55j*592 +
P55k*448 + P55l*544 + P55m*592 / 8*1024*1024*1024
MC1 to MC9 RLC data traffic
23

Total LLC Bytes
DLBGEGDATA+DLTHP1EGDATA+DLTHP2EGDATA+DLTHP3EGDATA/(8*1000*1000)
Ericsson
Accumulated LLC PDU
(L9302*22 + L9303*28 + L9304*37 +L9305*44+ L9306*56 + L9307*74 + L9308*56 +
L9309*68 + L9310*74)/(1024*1024*1024)
Huawei MCS1 to MCS9 RLC data
(TL9338/1000/1000)
Same formulae (one counter i.e. TL9123=MCS1*22+MCS2*24 ..)
DL_RADIO_BLKS_x_TS_MCS_1*22 + DL_RADIO_BLKS_x_TS_MCS_2*28 +
Motorola DL_RADIO_BLKS_x_TS_MCS_7*112 + DL_RADIO_BLKS_x_TS_MCS_8*136 +
DL_RADIO_BLKS_x_TS_MCS_9*148
x=1,2,3,4,5 (No. of TS)
RLC data layer
(sum over MCS-1 (xx)* 22+sum over MCS-2 (xx)* 28+sum over MCS-3 (xx)* 37+
sum over MCS-4 (xx)* 44+sum over MCS-5 (xx)* 56+sum over MCS-6 (xx)* 74+
sum over MCS-7 (xx/2)*112+sum over MCS-8 (xx/2)*136+sum over MCS-9
NSN
(xx/2)*148))) / 1024
where xx = (DL_RLC_BLOCKS_IN_ACK_MODE+ DL_RLC_BLOCKS_IN_UNACK_MODE)
MCS1 to MCS9 data volume in RLC layer
C900040066/(1024*1024*1024)
ZTE
DL TBF LLC layer traffic EGPRS
4.2.12 EGPRS Data Traffic Volume UL (GB)
KPI
EGPRS Data Traffic Volume UL
Name
P57e*176+P57f*224+P57g*296+P57h*352 + P57i*448 + P57j*592 +
P57k*448 + P57l*544 + P57m*592 / 8*1024*1024*1024
ALU Useful RLC blocks MCS1 to MCS9
Total LLC Bytes
Ericss ULBGEGDATA+ULTHP1EGDATA+ULTHP2EGDATA+ULTHP3EGDATA/(8*1000*1000)
L9202*22+L9203*28+L9204*37+L9205*44+L9206*56+L9207*74+L9208*56+L9209*68
+L9210*74/102*1024*1024
Huawe
MCS1 to MCS9 RLC data
i
TL9237/1000/1000
Same formulae (one counter i.e. TL9123=MCS1*22+MCS2*24 ..)
UL_RADIO_BLKS_GMSK_x_TS_MCS_1*22 + UL_RADIO_BLKS_8PSK_x_TS_MCS_2*28 +
UL_RADIO_BLKS_8PSK_x_TS_MCS_3*37 + UL_RADIO_BLKS_8PSK_x_TS_MCS_4*44 +
Motor UL_RADIO_BLKS_8PSK_x_TS_MCS_1*22 + UL_RADIO_BLKS_8PSK_x_TS_MCS_5*56 +
ola UL_RADIO_BLKS_8PSK_x_TS_MCS_6*74 + UL_RADIO_BLKS_8PSK_x_TS_MCS_7*112 +
UL_RADIO_BLKS_8PSK_x_TS_MCS_8*136 + UL_RADIO_BLKS_8PSK_x_TS_MCS_9*148
x=1,2,3,4,5
sum over MCS-1 (xx)* 22+ sum over MCS-2 (xx)* 28+ sum over MCS-3 (xx)* 37+
sum over MCS-4 (xx)* 44+ sum over MCS-5 (xx)* 56+ sum over MCS-6 (xx)* 74+
sum over MCS-7 (xx/2)*112+ sum over MCS-8 (xx/2)*136+ sum over MCS-9 (xx/2)*148))
NSN
) / 1024
where xx = (UL_RLC_BLOCKS_IN_ACK_MODE + UL_RLC_BLOCKS_IN_UNACK_MODE)
MCS1 to MCS9 data volume in RLC layer
24
C900040068/(1024*1024*1024)
ZTE
UL TBF LLC layer traffic EGPRS
25
5- 3G Network Vendor Reference
5.1 Circuit Switched
5.1.1 RRC Setup Attempts
KPI
RRC Setup Attempts
Name
SL:
UC419_0 + U419_1 + U419_2 + U419_3 + U419_4 + UC419_5 + U419_6 + U419_7 + U419_
8 + UC419_9 + U419_14 + U419_16 + U419_17 + U419_19 + UC404_17 + UC404_7
Originating & terminating conversational, background, interactive & streaming + high
ALU priority signaling + emergency + call reestablishment (addition of failed establishment to
be confirmed with SL team)
Mobily: U428
Total RRC establishment connection attempts (excludes repetitions) recommended by
EG
AT CDI: pmTotNoRrcConnectReq
Ericsso Total RRC establishment connection attempts (excludes repetitions)
n Mobily: pmTotNoRrcConnectReq-pmNoLoadSharingRrcConn
Load sharing attempts are not be considered as failures
VS.RRC.AttConnEstab.Sum
Huawei
Total RRC establishment connection attempts (excludes retransmissions from UE)
RRC_CONN_STP_ATT + RRC_CONN_SETUP_COMP_AFT_DIR -
NSN RRC_CON_SETUP_COMP_DIRECTED
Attempts + 3G to 2G DR Attempts – 3G to 2G DR Success
300002
ZTE
Successful RRC attempts
5.1.2 RRC Setup Success
KPI
Na RRC Setup Success
me
SL:
UC403_0 + U403_1 + U403_2 + U403_3 + U403_4 +UC403_5 + U403_6+ U403_7 + U403_8 + U
C403_9 + U403_14 + U403_16 + U403_17 + U403_19 + UC404_7 + UC404_17 - UC439_1 -
UC439_0
priority signaling + emergency + call reestablishment (3G to 2G reselection reload at RRC
ALU level – to be confirmed with SL team)
EG:
U403_0 + U403_1 + U403_2 + U403_3 + U403_4
+ U403_5 + U403_6 + U403_7 + U403_8 + U403_9 + U403_10 + U403_11 + U403_12 + U403_1
3 + U403_14 + U403_15 + U403_16 + U403_17 + U403_18 + U403_19 + U403_20
priority signaling + emergency + call reestablishment + IRAT cell reselection + registrations
Eric pmTotNoRrcConnectReqSuccess
sson Incremented only once even with repeated requests
Hua RRC.SuccConnEstab.Sum
wei Connection setups
NSN RRC_CONN_STP_COMP
26
Completed RRC setup phases

300001
ZTE
Successful RRC establishments
5.1.3 RRC Congestion
KPI Name RRC Congestion

U432_0 + U432_1 + U432_2 + U432_3 + U432_4 + U432_5 + U432_6 + U432_7
+U432_8 + U432_2 + U432_3 + U432_4 + U432_5 + U432_6 + U432_7 + U432_9
ALU
RRC establishment failures due to congestion per type conversation,
streaming, background & interactive for originating and terminating calls.
AT CDI: pmNoRejRrcConnMpLoadC
In case load control featured enabled but failed. AT CDI dividing by RRC
attempts for CS voice only – DR where the counter is incremented for CS, PS &
InterRAT cell change.
Mobily:
Ericsson
pmNoRrcCsReqDeniedAdm+pmNoRrcPsReqDeniedAdm-
pmNoLoadSharingRrcConnCs-pmNoLoadSharingRrcConnPs
Mobily formulae is removing RRC connection diverted through load sharing,
however, the success of the diverted load sharing should be also included in
the formulae
RRC.SuccConnEstab.Sum
Huawei
DL & UL Power, code, channel elements & IuB congestion
RRC_CONN_STP_COMP
NSN
The number of RRC setup failures caused by Admission Control.
ZTE N/A
5.1.4 CS RAB Setup Attempts
KPI Name CS RAB Setup Attempts

EG: UC1620_3+UC1620_2+UC1620_1
CS speech, CS64, streaming
ALU Mobily:
URAB036_C_CsVoice-U2590_0-UIRATDR003_C-UIRATDR006_C
UA8.1
AT CDI & Mobily: pmNoRabEstablishAttemptSpeech
Ericsson
Video calls are not considered in this formulae
VS.RAB.AttEstab.AMR+VS.RAB.AttEstCS.Conv.64+VS.RAB.AttEstabCS.AMRWB12.65
Huawei
CS speech, CS64, wideband AMR
RAB_STP_ATT_CS_VOICE+RAB_STP_ATT_CS_CONV
NSN
CS Voice + CS Data (Video)
300030
ZTE
CS RAB attempts
5.1.5 CS RAB Setup Success
KPI Name CS RAB Setup Success

ALU SL: UC1621_1+UC1621_2+ UC1621_3
CS speech, CS64, streaming
27
Mobily: UTraffic040_C_CsVoice+UIRATDR006_C
CS Voice – Directed Retry
Ericsson pmNoRabEstablishSuccessSpeech
VS.RAB.SuccEstabCS.AMR+VS.RAB.SuccEstCS.Conv.64
Huawei
AMR+Video calls
NSN RAB_ACC_COMP_CS_VOICE+RAB_ACC_COMP_CS_CONV
300029
ZTE
CS RAB setup success
5.1.6 CS RAB Congestion
KPI Name CS RAB Congestion

U2762+U2629_1+U2629_2+U2629_5
ALU
Missing transport network, dl power, code starvation
AT CDI: pmNoRabEstBlockNodeSpeechBest
Ericsson
Mobily: pmNoOfNonHoReqDeniedSpeech
VS.RAB.FailEstabCS.ULPower.Cong + VS. RAB.FailEstabCS.DLPower.Cong +
VS.RAB.FailEstabCS.Code.Cong + VS.RAB.FailEstabCS.ULCE.Cong +
Huawei
VS.RAB.FailEstabCS.DLCE.Cong + VS.RAB.FailEstabCS.DLIUBBand.Cong +
VS.RAB.FailEstabCS.ULIUBBand.Cong
NSN RAB_STP_FAIL_CS_VOICE_AC+RAB_STP_FAIL_CS_CONV_AC
ZTE N/A
5.1.7 CS RAB Drops
KPI Name CS RAB Drops

AT CDI: UC595_0 + UC595_2 + UC595_3 + UC595_4 + UC595_5 + UC595_6
ALU Mobily: U2637
Mobily formulae is calculated from RNC side.
pmNoSystemRabReleaseSpeech + pmNoSystemRabReleaseCs64
Ericsson The counter pmNoSystemRabReleaseSpeech to be checked whether it
includes all AMR.
Huawei VS.RAB.AbnormRel.AMR+VS.RAB.AbnormRel.CS64
RAB_ACT_REL_CS_VOICE_P_EMP + RAB_ACT_FAIL_CS_VOICE_IU +
RAB_ACT_FAIL_CS_VOICE_RADIO + RAB_ACT_FAIL_CS_VOICE_BTS +
RAB_ACT_FAIL_CS_VOICE_IUR + RAB_ACT_FAIL_CS_VOICE_RNC +
RAB_ACT_FAIL_CS_VOICE_UE +RAB_ACT_FAIL_CS_VOICE_TRANS +
NSN RAB_ACT_FAIL_CS_CONV_IU + RAB_ACT_FAIL_CS_CONV_RADIO +
RAB_ACT_FAIL_CS_CONV_BTS + RAB_ACT_FAIL_CS_CONV_RNC+
RAB_ACT_FAIL_CS_CONV_IUR + RAB_ACT_FAIL_CS_CONV_UE +
RAB_ACT_REL_CS_CONV_P_EMP+ RAB_ACT_FAIL_CS_CONV_TRANS
CS Voice + CS Video
ZTE 300240
5.1.8 Soft Handover Attempts
KPI Name Soft Handover Attempts

ALU EG: UA7.1: U415 +U402_0+U402_1
28
Mobily UA8.1: USHO010_C_RLAdd + USHO010_C_RLDel

UA7.1 Successful + Unsuccessful soft handovers
Ericsson pmRlAddSuccessBestCellSpeech
VS.SHO.AttRLAdd+VS.SHO.AttRLDel
Huawei
Soft Handover Additions + Deletions
CELL_ADD_REQ_ON_SHO_FOR_RT + CELL_DEL_REQ_ON_SHO_FOR_RT +
CELL_REPL_REQ_ON_SHO_FOR_RT + CELL_ADD_REQ_ON_SHO_FOR_NRT +
NSN
CELL_DEL_REQ_ON_SHO_FOR_NRT + CELL_REPL_REQ_ON_SHO_FOR_NRT
SHO Additions + Deletions + Replacements for RT + NRT
C300440
ZTE
No. of SHO attempts
5.1.9 Soft Handover Success
KPI Name Soft Handover Success

EG: U415
ALU Mobily: USHO010_C_RLAdd + USHO010_C_RLDel
U415 is the successful SHO
Huawei VS.SHO.SuccRLAdd+VS.SHO.SuccRLDel
SUCC_UPDATES_ON_SHO_FOR_RT+SUCC_UPDATES_ON_SHO_FOR_NRT
NSN
Active set update for RT & NRT
ZTE C300439
5.1.10 Hard Handover Inter-Freq Attempts
KPI Name Hard Handover Attempts

[( U176_0 + U176_1 + U176_2 )+( U122_0 + U122_1
+ U122_2 + U122_3 )+( U174_0 + U174_1 +U174_2 )
+( U131_0 + U131_1 + U131_2 + U131_3 )]
ALU
Specific relocation reasons
UC1831
All inter-frequency relocations
pmAttNonBlindInterFreqHoCsSpeech12
Ericsson
Inter-frequency attempts
Huawei VS.HHO.AttInterFreqOut
Mobily: INTRA_INTER_HHO_ATT_RT + INTRA_INTRA_HHO_ATT_RT +
NSN NTRA_INTER_HHO_ATT_NRT + INTRA_INTRA_HHO_ATT_NRT
For RT & NRT inter-BTS & intra-BTS
C310332621+C310332622+C310332619+C310332620
ZTE
RSCP, EcNo, DL power, UL interference
5.1.11 Hard Handover Inter-Freq Success
KPI Name Hard Handover Success

ALU U177_0 + U177_1 + U177_2 + U124_0 + U124_1 + U124_2 + U124_3+ U175_0
+ U175_1 +U175_2 + U133_0 + U133_1 + U133_2 + U133_3
Specific relocation reasons
29
UC1835
All inter-frequency relocations
Ericsson pmSuccNonBlindInterFreqHoCsSpeech12
Huawei VS.HHO.SuccInterFreqOut
SUCC_INTRA_INTRA_HHO_ATT_RT + SUCC_INTRA_INTER_HHO_ATT_RT +
NSN SUCC_INTRA_INTRA_HHO_ATT_NRT + SUCC_INTRA_INTER_HHO_ATT_NRT
For RT & NRT inter-BTS & intra-BTS
C310332610+C310332611+C310332608+C310332609
ZTE
RSCP, EcNo, DL power, UL interference
5.1.12 Inter-RAT Handover Attempts
KPI Name Inter-RAT Handover Attempts

EG: U164_0+U164_1+U164_2+U164_3+U535_2
Mobily: U154_0+ U196+U156_0+U158_0+U158_1
ALU
EG formulae for handover preperation
Handover commands: Inter-RAT command due to RSCP or EcNo
Ericsson pmNoAttOutIratHoSpeech
Huawei IRATHO.AttOutCS
EG: IS_HHO_ATT_UL_DCH_Q_NRT+IS_HHO_ATT_UE_TRX_PWR_NRT
+IS_HHO_ATT_DL_DPCH_PWR_NRT+IS_HHO_ATT_CPICH_RSCP_NRT
+IS_HHO_ATT_CPICH_ECNO_NRT +IS_HHO_ATT_IM_IMS_NRT
+IS_HHO_ATT_LB_CAPA_DL_NRT +IS_HHO_ATT_LB_CAPA_UL_NRT
+IS_HHO_ATT_LB_PRX_TOT_NRT +IS_HHO_ATT_LB_PTX_TOT_NRT
+IS_HHO_ATT_LB_RES_LIM_NRT +IS_HHO_ATT_LB_RSVR_SC_NRT
+IS_HHO_ATT_SB_NRT +ATT_ISHO_CELL_SHUTDOWN_NRT
+ATT_ISHO_CELL_BLOCK_NRT -IS_HHO_ATT_2ND_BEST_CELL_NRT
-IS_HHO_ATT_3RD_BEST_CELL_NRT
Mobily: IS_HHO_ATT_UL_DCH_Q_RT + IS_HHO_ATT_UE_TRX_PWR_RT +

NSN IS_HHO_ATT_DPCH_PWR_RT + IS_HHO_ATT_CPICH_RSCP_RT +
IS_HHO_ATT_CPICH_ECNO_RT + IS_HHO_ATT_IM_IMS_RT +
IS_HHO_ATT_EMERG_CALL + IS_HHO_ATT_LB_PRX_TOT_RT +
IS_HHO_ATT_LB_PTX_TOT_RT + IS_HHO_ATT_LB_RES_LIM_RT +
IS_HHO_ATT_LB_RSVR_SC_RT + IS_HHO_ATT_SB_RT +
ATT_GANHO_AMR_RT+ IS_HHO_ATT_LB_CAPA_DL_RT +
IS_HHO_ATT_LB_CAPA_UL_RT + IS_HHO_ATT_UL_DCH_WPS_RT+
IS_HHO_ATT_DR_AMR_RT + ATT_ISHO_CELL_SHUTDOWN_RT+
ATT_ISHO_CELL_BLOCK_RT - IS_HHO_ATT_2ND_BEST_CELL_RT-
IS_HHO_ATT_3RD_BEST_CELL_RT
Inter-RAT handovers due to different reasons.

C310352945
ZTE
Inter-RAT handover attempts.
5.1.13 Inter-RAT Handover Success
KPI Name Inter-RAT Handover Success

EG: U167_0+U167_1+U167_2+U167_3+U167_4+U167_5+U1851
ALU Successful 3G to 2G handovers (1851 is 2G to 3G)
Mobily: U1841_0+U1841_1+U1841_2
30
Ericsson pmNoSuccessOutIratHoSpeech
Huawei IRATHO.SuccOutCS
EG: SUCC_IS_HHO_UL_DCH_Q_NRT + SUCC_IS_HHO_UE_TRX_PWR_NRT +
SUCC_IS_HHO_DL_DPCH_PWR_NRT + SUCC_IS_HHO_CPICH_RSCP_NRT +
SUCC_IS_HHO_CPICH_ECNO_NRT + SUCC_IS_HHO_IM_IMS_NRT +
SUCC_IS_HHO_LB_CAPA_DL_NRT + SUCC_IS_HHO_LB_CAPA_UL_NRT +
SUCC_IS_HHO_LB_PRX_TOT_NRT +SUCC_IS_HHO_LB_PTX_TOT_NRT
+SUCC_IS_HHO_LB_RES_LIM_NRT +SUCC_IS_HHO_LB_RSVR_SC_NRT
+SUCC_IS_HHO_SB_NRT +SUCC_ISHO_CELL_SHUTDOWN_NRT
+SUCC_ISHO_CELL_BLOCK_NRT
NSN Mobily: SUCC_IS_HHO_UL_DCH_Q_RT+

SUCC_IS_HHO_UE_TRX_PWR_RT+SUCC_IS_HHO_DL_DPCH_PWR_RT+
SUCC_IS_HHO_CPICH_RSCP_RT+SUCC_IS_HHO_CPICH_ECNO_RT+
SUCC_IS_HHO_IM_IMS_RT + SUCC_IS_HHO_EMERG_CALL +
SUCC_IS_HHO_LB_CAPA_DL_RT+ SUCC_IS_HHO_LB_CAPA_UL_RT+
SUCC_IS_HHO_LB_PRX_TOT_RT + SUCC_IS_HHO_LB_PTX_TOT_RT +
SUCC_IS_HHO_LB_RES_LIM_RT + SUCC_IS_HHO_LB_RSVR_SC_RT +
SUCC_IS_HHO_SB_RT +SUCC_IS_HHO_WPS_RT + SUCC_GANHO_AMR_RT
+SUCC_ISHO_CELL_SHUTDOWN_RT + SUCC_ISHO_CELL_BLOCK_RT
C310352945-C310352946-C310352947-C310352948-C310352949-
ZTE C310352950-C310352951
Attempts-Failures
5.1.14 AMR Traffic Volume (Erlang)
KPI
AMR Traffic Volume (Erlang)
Name
SL: U1566_2/1000/3600
Time the RAB is transmitting data in the DL for CS Voice
ALU
Mobily: (U1666_2_Cum+U1666_3_Cum)/((U1666_2_NbEvt+U1666_3_NbEvt)/2)*24
Mobily formulae includes WB AMR traffic but is on RNC level
Ericss
pmSumBestAmr12200RabEstablish
on
EG: VS.RB.AMRWB.DL.12.65+VS.RB.AMR.DL.12.2+VS.RB.AMR.DL.10.2 +VS.RB.AMR.DL.7.95
+VS.RB.AMR.DL.7.4 +VS.RB.AMR.DL.6.7 +VS.RB.AMR.DL.5.9 +VS.RB.AMR.DL.5.15
+VS.RB.AMR.DL.4.75
UAE: VS.RB.AMR.DL.12.2
Huaw
Mobily: [VS.RB.AMR.DL.4.75.RNC]+[VS.RB.AMR.DL.5.15.RNC]+[VS.RB.AMR.DL.5.9.RNC]
ei
+[VS.RB.AMR.DL.6.7.RNC]+[VS.RB.AMR.DL.7.4.RNC]+[VS.RB.AMR.DL.7.95.RNC]
+[VS.RB.AMR.DL.10.2.RNC]+[VS.RB.AMR.DL.12.2.RNC]+ [VS.RB.AMRWB.DL.12.65]
Mobily formulae is on RNC level & UAE formulae is missing other AMR rates.
Agreement should be made to calculate traffic either on RNC or on cell level.
EG: [AVG_RAB_HLD_TM_CS_VOICE] / sum(PERIOD_DURATION)*100*60
RAB holding time for CS traffic
Mobily: (DUR_FOR_AMR_4_75_UL_IN_SRNC + DUR_FOR_AMR_5_15_UL_IN_SRNC +
NSN DUR_FOR_AMR_5_9_UL_IN_SRNC + DUR_FOR_AMR_6_7_UL_IN_SRNC +
DUR_FOR_AMR_7_4_UL_IN_SRNC + DUR_FOR_AMR_7_95_UL_IN_SRNC +
DUR_FOR_AMR_10_2_UL_IN_SRNC + DUR_FOR_AMR_12_2_UL_IN_SRNC) /(60*100*60)
Calculated on RNC level
ZTE (C310040001+C310040002+C310040003+C310040004+C310040005+C310040006+C31
0040007+C310040008+
C310040009+C310040010+C310040011+C310040012+C310040013+C310040014
31
+C310040015+C310040016+
C310040017+C310040018+C310040019+C310040020+C310040021+C310040022
+C310040075+C310040076+
C310040077+C310040078+C310040079+C310040080+C310040081+C310040082
+C310040083+C310040084+
C310040085+C310040086+C310040087+C310040088+C310040089+C310040090
+C310040091+C310040092+
C310040093+C310040094+C310040095+C310040096)/3600
AMR+WB AMR all rates (cancelled non best cell AMR & CS64, CS32 ..)
5.1.15 Video-phony Traffic Volume (Erlang)
KPI Name AMR Traffic Volume (Erlang)

EG: (U1566_3+U1567_3 )/1000/3600/2
ALU
Mobily: (( U1666_4_Cum )/( U1666_4_NbEvt ))*24
Ericsson pmSumBestCs64RabEstablish
Huawei VS.RB.CS.Conv.DL.64
NSN [RAB_HOLD_TIME_CS_CONV_64]*64/12.2/sum(PERIOD_DURATION)*100*60
(C310040018+C310040092)/3600
ZTE
Cancelled non best cell CS64, only best cell is remaining.
5.2 Packet Switched
5.2.1 PS RAB Setup Attempts
KPI Name PS RAB Setup Attempts

SL: UC1620_0 + UC1620_4 + UC1620_5 + UC1620_6
+ UC1620_7 + UC1620_8 + UC1620_9 + UC1620_12
ALU
DL: Interactive, background & streaming.
Mobily: URAB036_C_Ps-URAB037_C_Ps
pmNoRabEstablishAttemptPacketInteractive
Ericsson
Missig other types
VS.RAB.AttEstabPS.Conv + VS.RAB.AttEstabPS.Inter + VS.RAB.AttEstabPS.Str
Huawei
+ VS.RAB.AttEstabPS.Bkg
RAB_STP_ATT_PS_INTER+RAB_STP_ATT_PS_BACKG
NSN
RAB attempts interactive and background
300036
ZTE
Number of establishment attempts
5.2.2 PS RAB Setup Success
KPI Name PS RAB Setup Success

UC1621_0 + UC1621_4 + UC1621_5 + UC1621_6
ALU + UC1621_7 + UC1621_8 + UC1621_9 + UC1621_12
DL: Interactive, background & streaming.
Ericsson pmNoRabEstablishSuccessPacketInteractive
Huawei VS.RAB.SuccEstabPS.Conv + VS.RAB.SuccEstabPS.Inter +
32
VS.RAB.SuccEstabPS.Str + VS.RAB.SuccEstabPS.Bkg
RAB_ACC_COMP_PS_INTER + RAB_ACC_COMP_PS_BACKG
NSN
RAB success interactive and background
300035
ZTE
Number of establishment success
5.2.3 PS RAB Congestion
KPI Name PS RAB Congestion

SL: U2763+U2631_2+U2631_5
Lack of transport resource + code starvation + RL config. failure
Mobily: U2763+ U2631_1+U2631_2+U2631_5
Lack of transport resource + DL power congestion + code starvation + RL
ALU
config. failure
SL formulae is missing power congestion, formulae not aligned with vendors
to include both DL & UL (should include code, power & channel element
congestion).
Ericsson pmNoRabEstBlkNodePsIntNonHsBest
VS.RAB.FailEstabCS.ULPower.Cong + VS.RAB.FailEstabCS.DLPower.Cong +
VS.RAB.FailEstabCS.Code.Cong + VS.RAB.FailEstabCS.ULCE.Cong +
Huawei VS.RAB.FailEstabCS.DLCE.Cong + VS.RAB.FailEstabCS.DLIUBBand.Cong +
VS.RAB.FailEstabCS.ULIUBBand.Cong
UL & DL Power, code & channel element congestion.
Mobily: RAB_STP_FAIL_PS_STREA_AC+RAB_STP_FAIL_PS_INTER_AC
NSN +RAB_STP_FAIL_PS_BACKG_AC
Failures in setup for streaming, interactive and background.
ZTE N/A
5.2.4 PS Drops
KPI Name PS Drops

SL: UC589_0 + UC589_10 + UC589_11 + UC589_12
+ UC589_13 + UC589_14 + UC589_2 + UC589_3
+ UC589_4 + UC589_5 + UC589_6 + UC589_7 + UC589_8 + UC589_9 + UC589_17
Abnormal Releases for streaming & interactive RAB < 64, 64, 128, 256, 384 &
ALU HSPA
Mobily:
URAB033_C_U_CellDch+URAB033_CR_U_CellFach+URAB033_C_CN_CellDch+U2665
+U1619_7+U1619_6+U1619_5+U1619_4+U1619_9+U1619_8
UL & DL streaming, background & interactive low & high rates.
Ericsson pmNoSystemRabReleasePacket-pmNoSystemRabReleasePacketUra
VS.RAB.AbnormRel.PS-VS.RAB.AbnormRel.PS.PCH-VS.RAB.AbnormRel.PS.D2P-
Huawei
VS.RAB.AbnormRel.PS.F2P
RAB_ACT_FAIL_PS_BACKG_TRANS+RAB_ACT_FAIL_PS_INTER_TRANS
+RAB_ACT_FAIL_PS_INTER_IU+RAB_ACT_FAIL_PS_INTER_RADIO
+RAB_ACT_FAIL_PS_INTER_BTS+RAB_ACT_FAIL_PS_INTER_IUR
+RAB_ACT_FAIL_PS_INTER_RNC+RAB_ACT_FAIL_PS_BACKG_IU
NSN +RAB_ACT_FAIL_PS_BACKG_RADIO+RAB_ACT_FAIL_PS_BACKG_BTS
+RAB_ACT_FAIL_PS_BACKG_IUR+RAB_ACT_FAIL_PS_BACKG_RNC
+RAB_ACT_FAIL_PS_BACKG_UE+RAB_ACT_FAIL_PS_INTER_UE-
RAB_ACT_FAIL_PS_BACKG_PCH-RAB_ACT_FAIL_PS_INT_PCH
33
300243
ZTE
No of PS Drops
5.2.4 PS Traffic Volume DL R99 (GB)
KPI Name PS Traffic Volume DL R99 (GB)

(U1554_14+U1554_6+U1554_16+U1554_8+U1554_13/1024/1024
ALU
DL 64, 128, 384 Streaming, interactive and background.
(pmDlTrafficVolumePs128+pmDlTrafficVolumePs16
Ericsson +pmDlTrafficVolumePs384+pmDlTrafficVolumePs64+pmDlTrafficVolumePsCommon)
/(8*1024*1024)
VS.PS.Bkg.DL.8.Traffic + VS.PS.Bkg.DL.16.Traffic + VS.PS.Bkg.DL.32.Traffic +
VS.PS.Bkg.DL.64.Traffic + VS.PS.Bkg.DL.128.Traffic + VS.PS.Bkg.DL.256.Traffic +
VS.PS.Bkg.DL.384.Traffic + VS.PS.Int.DL.8.Traffic + VS.PS.Int.DL.16.Traffic +
Huawei
VS.PS.Int.DL.32.Traffic + VS.PS.Int.DL.64.Traffic +
VS.PS.Int.DL.128.Traffic + VS.PS.Int.DL.256.Traffic +
VS.PS.Int.DL.384.Traffic/8*1024*1024*1024
EG: (CCH_DATA_FROM_IUB+DCH_DATA_FROM_IUB)/1000*1000
FP Layer
NSN Mobily:
RLC_AM_SDU_DL_PS_VOL_W/1000000+RLC_AM_SDU_UL_PS_VOL_W/1000000
RLC layer
(C310010321+C310010323+C310010325+C310010327)/(1024*1024)
ZTE
Conversational, interactive, background & streaming.
5.2.5 PS Traffic Volume UL R99 (GB)
KPI Name PS Traffic Volume UL R99 (GB)

(U1553_12+U1553_13+U1553_11+U1553_6)/1024/1024
ALU
UL 64, 128, 384 Streaming, interactive and background.
(pmUlTrafficVolumePs128+pmUlTrafficVolumePs16+pmUlTrafficVolumePs384
+pmUlTrafficVolumePs64+pmUlTrafficVolumePs8
Ericsson
+pmUlTrafficVolumePsCommon+pmUlTrafficVolumePsStr128
+pmUlTrafficVolumePsStr16)/(1000*1000*8)
VS.PS.Bkg.UL.8.Traffic + VS.PS.Bkg.UL.16.Traffic + VS.PS.Bkg.UL.32.Traffic +
VS.PS.Bkg.UL.64.Traffic + VS.PS.Bkg.UL.128.Traffic + VS.PS.Bkg.UL.128.Traffic +
VS.PS.Bkg.UL.256.Traffic + VS.PS.Bkg.UL.384.Traffic +
Huawei
VS.PS.Int.UL.8.Traffic + VS.PS.Int.UL.16.Traffic + VS.PS.Int.UL.32.Traffic +
VS.PS.Int.UL.64.Traffic + VS.PS.Int.UL.128.Traffic + VS.PS.Int.UL.128.Traffic +
VS.PS.Int.UL.256.Traffic + VS.PS.Int.UL.384.Traffic/8*1024*1024*1024
(CCH_DATA_TO_IUB_INTERFACE+DCH_DATA_TO_IUB)/1000*1000
FP Layer
NSN
RLC_AM_SDU_DL_PS_VOL_W/1000000+RLC_AM_SDU_UL_PS_VOL_W/1000000
RLC layer
(C310010320+C310010322+C310010324+C310010326)/(1024*1024)
ZTE
Conversational, interactive, background & streaming.
5.2.6 PS Traffic Volume HSDPA
KPI Name PS Traffic Volume HSDPA (GB)
34
SL: (UC1554_5+UC1554_19+UC1554_20)/1024/1024
ALU Sub counters 19 & 20 to be checked by SL team.
Mobily: UTraffic017_C_HSDPA*1.024/1000000
Ericsson pmDlTrafficVolumePsIntHs/8*1000*1000
Huawei VS.HSDPA.MeanChThroughput.TotalBytes/1024*1024*1024
NSN HSDSCH_DATA_FROM_IUB/1000*1000
ZTE (C310010296+C310010297+C310010298+C310010299)/1024
5.2.7 PS Traffic Volume HSUPA
KPI Name PS Traffic Volume HSUPA (GB)

SL: U1555_14/1024/1024
ALU
Mobily: UTraffic018_C_HSUPA*1.024/1000000
Ericsson pmUlTrafficVolumePsIntEul/8*1000*1000
Huawei VS.HSUPA.MeanChThroughput.TotalBytes/1024*1024*1024
NSN EDCH_DATA_TO_IUB/1000*1000
ZTE (C310010292+C310010293+C310010294+C310010295)/(1024*1024)
35
6- Vendor Counters
6.1 Vendor Counters 2G Network
6.1.1 Alcatel-Lucent
Vendor Counter Definition

Alcatel MC01 NB_IMM_ASS_SUCC_MT
Alcatel MC02 NB_IMM_ASS_SUCC_MO
Alcatel MC04 NB_IMM_ASS_PREP_FAIL_CONG
Alcatel MC04 NB_IMM_ASS_PREP_FAIL_CONG
Alcatel MC07 NB_SDCCH_DROP_OUT_HO
Alcatel MC137 NB_SDCCH_DROP_EST_PHAS_BSS_PB
Alcatel MC138 NB_SDCCH_DROP_EST_PHAS_RLF
Alcatel MC148 NB_IMM_ASS_ALLOC
Alcatel MC14C NB_TCH_DROP_EST_PHAS_BSS_PB
Alcatel MC380A TIME_TRX_FR_BUSY
Alcatel MC380B TIME_TRX_HR_BUSY
Alcatel MC621 NB_TCH_DROP_OUT_HO_EXEC_TRX
Alcatel MC646 NB_OUT_EXT_HO_SUCC
Alcatel MC650 NB_OUT_EXT_HO_ATPT
Alcatel MC656 NB_OUT_INT_HO_SUCC
Alcatel MC660 NB_OUT_INT_HO_ATPT
Alcatel MC703 NB_TCH_NOR_ASS_ALLOC_TRX
Alcatel MC718 NB_TCH_NOR_ASS_SUCC_TRX
Alcatel MC736 NB_TCH_DROP_EST_PHAS_RLF_TRX (RSL)
Alcatel MC739 NB_TCH_DROP_EST_PHAS_REM_TRANS_FAIL_TRX (Transcoder)
Alcatel MC812 NB_TCH_NOR_ASS_PREP_FAIL_CONG_R_ABIS
Alcatel MC921C NB_PREEMPTED_CALLS
Alcatel P14 NB_DL_TBF_EST_FAIL_CONG
Alcatel P146 NB_DL_TBF_REL_PREEMPTradio
Alcatel P147 NB_UL_TBF_REL_PREEMPTradio
Alcatel P22 NB_UL_TBF_NORM_REL
Alcatel P27 NB_UL_TBF_EST_FAIL_CONG
Alcatel P30a NB_UL_TBF_EST_SUCC_MSidle_MastChan
Alcatel P30b NB_UL_TBF_EST_SUCC_MStransDL
Alcatel P30c NB_UL_TBF_EST_SUCC_MSidle_NO_MastChan
Alcatel P38b CUMULATED_TIME_PDCH_USED
Alcatel P38c CUMULATED_TIME_PDCH_USED_EGPRS
Alcatel P434a NB_NC2_UL_TBF_RELEASE
Alcatel P434b NB_NC2_DL_TBF_RELEASE
Alcatel P434c NB_NC0_UL_TBF_RELEASE
Alcatel P434d NB_NC0_DL_TBF_RELEASE
Alcatel P438c SIG_BLKS_NC2_UL_PACCH_CCCH_LOAD
Alcatel P43 NB_DL_LLC_BYTES
36
Alcatel P44 NB_UL_LLC_BYTES

Alcatel P55a NB_USEFUL_DL_RLC_BLOCK_PDTCH_CS1
Alcatel P55b NB_USEFUL_DL_RLC_BLOCK_PDTCH_CS2
Alcatel P55c NB_USEFUL_DL_RLC_BLOCK_PDTCH_CS3
Alcatel P55d NB_USEFUL_DL_RLC_BLOCK_PDTCH_CS4
Alcatel P55e NB_USEFUL_DL_RLC_BLOCK_PDTCH_MCS1
Alcatel P55f NB_USEFUL_DL_RLC_BLOCK_PDTCH_MCS2
Alcatel P55g NB_USEFUL_DL_RLC_BLOCK_PDTCH_MCS3
Alcatel P55h NB_USEFUL_DL_RLC_BLOCK_PDTCH_MCS4
Alcatel P55i NB_USEFUL_DL_RLC_BLOCK_PDTCH_MCS5
Alcatel P55j NB_USEFUL_DL_RLC_BLOCK_PDTCH_MCS6
Alcatel P55k NB_USEFUL_DL_RLC_BLOCK_PDTCH_MCS7
Alcatel P55l NB_USEFUL_DL_RLC_BLOCK_PDTCH_MCS8
Alcatel P55m NB_USEFUL_DL_RLC_BLOCK_PDTCH_MCS9
Alcatel P57a NB_USEFUL_UL_RLC_BLOCK_PDTCH_CS1
Alcatel P57b NB_USEFUL_UL_RLC_BLOCK_PDTCH_CS2
Alcatel P57c NB_USEFUL_UL_RLC_BLOCK_PDTCH_CS3
Alcatel P57d NB_USEFUL_UL_RLC_BLOCK_PDTCH_CS4
Alcatel P57e NB_USEFUL_UL_RLC_BLOCK_PDTCH_MCS1
Alcatel P57f NB_USEFUL_UL_RLC_BLOCK_PDTCH_MCS2
Alcatel P57g NB_USEFUL_UL_RLC_BLOCK_PDTCH_MCS3
Alcatel P57h NB_USEFUL_UL_RLC_BLOCK_PDTCH_MCS4
Alcatel P57i NB_USEFUL_UL_RLC_BLOCK_PDTCH_MCS5
Alcatel P57j NB_USEFUL_UL_RLC_BLOCK_PDTCH_MCS6
Alcatel P57k NB_USEFUL_UL_RLC_BLOCK_PDTCH_MCS7
Alcatel P57l NB_USEFUL_UL_RLC_BLOCK_PDTCH_MCS8
Alcatel P57m NB_USEFUL_UL_RLC_BLOCK_PDTCH_MCS9
Alcatel P62a NB_UL_TBF_EST_REQ_MSidle_MastChan
Alcatel P62b NB_UL_TBF_EST_REQ_MStransDL
Alcatel P62c NB_UL_TBF_EST_REQ_MSidle_NO_MastChan
Alcatel P9 NB_DL_TBF_NORM_REL
Alcatel P90a NB_DL_TBF_EST_SUCC_MS_Idle_DRX_MPDCH
Alcatel P90b NB_DL_TBF_EST_SUCC_MS_Transfer_UL
Alcatel P90c NB_DL_TBF_EST_SUCC_MS_IDLE_DRX_NO_MPDCH
Alcatel P90d NB_DL_TBF_EST_SUCC_MS_Non_DRX_MPDCH
Alcatel P90e NB_DL_TBF_EST_SUCC_T3192
Alcatel P90f NB_DL_TBF_EST_SUCC_MS_Non_DRX_NO_MPDCH
Alcatel P91a NB_DL_TBF_EST_REQ_MS_IDLE_DRX_MPDCH
Alcatel P91b NB_DL_TBF_EST_REQ_MS_Transfer_UL
Alcatel P91c NB_DL_TBF_EST_REQ_MS_IDLE_DRX_NO_MPDCH
Alcatel P91d NB_DL_TBF_EST_REQ_MS_Non_DRX_MPDCH
Alcatel P91e NB_DL_TBF_EST_REQ_T3192
Alcatel P91f NB_DL_TBF_EST_REQ_MS_Non_DRX_NO_MPDCH
Alcatel P98c NB_SUSPEND_REQ_FOR_DL_TBF
Alcatel P98d NB_SUSPEND_REQ_FOR_UL_TBF
37
6.1.2 Ericsson

The allocation attempt counters are incremented at every attempt to
Ericsson CCALLS
allocate an SDCCH in a resource type in the cell
Ericsson CCONGS SDCCH Congestion counter
The MS connection establishments on the SDCCH counters are
Ericsson CMSESTAB incremented when a signalling link between the MS and MSC is
established
Ericsson CNDROP SDCCH number of abnormally terminated connections
connection on SDCCH is released due to radio resource congestion,
Ericsson CNRELCONG that is when there is congestion on TCH or congestion on transcoder
resources
connection on SDCCH is released due to radio resource congestion,
Ericsson CNRELCONGSUB that is when there is congestion on TCH or congestion on transcoder
resources for overlaid subscell
Accumulated LLC PDU data volume per TPF for EGPRS, downlink
Ericsson DLBGEGDATA
and QoS class Background PFCs.
Accumulated LLC PDU data volume per TPF for GPRS, downlink and
Ericsson DLBGGDATA
QoS class Background PFCs.
The counter DLTBFEST counts the number of both successful
downlink TBF establishment attempts (either via CCCH or PACCH)
and downlink TBF establishment attempts failed due to one of the
following reasons: No answer from MS, Access Delay > max TA,
Ericsson DLTBFEST Packet CTRL ACK syntax error, Interrupt from RLC, Unspecified
error, Immediate assignment sent timer expired, Channel fault,
Channel preemption, No channels available, Lack of TFIs, Lack of MS
individuals, Congestion in MAC, Congestion due to CP load
regulation.
the number of DL TBF establishment attempts failed due to one or
several of the following reasons: Channel fault, Channel preemption,
Ericsson FAILDLTBFEST
No channels available, Lack of TFIs, Lack of MS individuals,
Congestion in MAC, Congestion due to CP load regulation.
Ericsson HOVERCNT Number of handover commands sent to the neighboring cell
Ericsson HOVERSUC Number of successful handovers to the neighboring cell
incremented per cell for the total number of times when the entire
Ericsson LDISOTH content of the downlink LLC PDU buffer was discarded due to reason
“other”.
Total number of times the entire contents of the downlink LLC PDU
Ericsson LDISRR
buffer were discarded due to radio reasons
Total number of times the entire contents of the downlink LLC PDU
Ericsson LDISTFI
buffer were discarded due to the reason, "No available PDCH or TFI"
Number of successfully established DL TBFs where at least one data
Ericsson MSESTDLTBF
block has been sent and acknowledged.
Total number of rejected access requests for other reasons than "No
PDCH, no USF, no TFI or Abis Overload". Rejected access requests
Ericsson PREJOTH counted by LCLRPARREJ and LCPARREJ are included. Rejected
access requests that occurred during change of TBF mode are not
included.
counts the number of 44.060 PACKET ACCESS REJECT and 44.018
Ericsson PREJTFI IMMEDIATE ASSIGNMENT REJECT sent to the MS during TBF
establishment for the reason "No PDCH, no USF or no TFI".
The assignment attempt counter (TASSATT) is stepped in the target
Ericsson TASSATT
cell for the first assignment attempt (both successful and
38
unsuccessful attempts) to change a connection from a signalling only

connection to a TCH for speech or data
the number of connections established on a TCH used for signalling
Ericsson TCASSALL
connections at immediate assignment
Ericsson TFNDROP TCH Full Rate Dropped connections due to failure
Ericsson TFNDROPSUB TCH Full Rate Dropped connections in overlaid subcell due to failure
Ericsson TFTRALACC Number of FR traffic level accumulations
Ericsson THNDROP TCH Full Rate Dropped connections due to failure
Ericsson THNDROPSUB TCH Half Rate Dropped connections in overlaid subcell due to failure
TCH Half Rate Number of released TCH due to radio resource
Ericsson THNRELCONG
congestion
TCH Half Rate Number of released TCH due to radio resource
Ericsson THNRELCONGSUB
congestion in overlaid subcell
Ericsson THTRALACC Number of HR traffic level accumulations
Accumulated LLC PDU data volume per TPF for EGPRS, uplink and
Ericsson ULBGEGDATA
Accumulated LLC PDU data volume per TPF for GPRS, uplink and
Ericsson ULBGGDATA
6.1.3 Huawei

Huawei CA300J Channel Requests Circuit Service
Huawei K3003 Successful SDCCH Seizures.
Huawei CM30 Call Drops on SDCCH
Huawei K3001 Failed SDCCH Seizures due to Busy SDCCH
Huawei K3010A TCH Seizure Requests Traffic Channel
Huawei K3013A Successful TCH Seizures Traffic Channel
Huawei K3011A Failed TCH Seizures due to Busy TCH Traffic Channel
Huawei CM33 Call Drops on Traffic Channel
Huawei CH311 Number of Outgoing Internal Inter-Cell Handover Commands
Huawei CH331 Outgoing External Inter-Cell Handover Commands
Huawei CH313 Number of Successful Outgoing Internal Inter-Cell Handovers
Huawei CH333 Successful Outgoing External Inter-Cell Handovers
Huawei CR355A Traffic Volume on TCHs
Huawei A9101 Number of Downlink GPRS TBF Establishment Attempts
Huawei A9301 Number of Downlink EGPRS TBF Establishment Attempts
Huawei A9102 Number of Successful Downlink GPRS TBF Establishments
Huawei A9302 Number of Successful Downlink EGPRS TBF Establishments
Huawei A9118 Number of Downlink GPRS Intermit Transfers
Number of Failed Downlink GPRS TBF Establishments due to No
Huawei A9103
Channel
Number of Failed Downlink EGPRS TBF Establishments due to No
Huawei A9303
Channel
Huawei L9102 Total Number of Downlink RLC Data Blocks Using CS1
39
Huawei L9302 Total Number of Downlink EGPRS MCS1 RLC Data Blocks
Huawei L9307 Total Number of Downlink EGPRS MCS6 RLC data blocks
6.1.4 NSN

Number of times when an MS
NSN sdcch_seiz_att
attempts to seize an SDCCH
Number of successful seizures of
NSN sdcch_assign
SDCCH for an immediate assignment
Number of SDCCH transactions ended
NSN sdcch_radio_fail
because of a radio failure.
because of a radio failure on the
NSN sdcch_rf_old_ho source channel during a handover
between SDCCH-SDCCH or SDCCH-
TCH.
Number of SDCCH transactions that
NSN sdcch_user_act
are ended because of user actions.
NSN sdcch_bcsu_reset are ended because of a
BCSU/BCXU restart.

NSN sdcch_netw_act because of a reconfiguration of
the radio network.
are ended because of a failure in the
NSN sdcch_abis_fail_call
Abis interface during a call in
progress
are ended because of a failure in the
NSN sdcch_abis_fail_old Abis interface on the source channel
during SDCCH-SDCCH or SDCCH-TCH
HO.
NSN sdcch_bts_fail
are ended because of a BTS failure.
Number of times when an MS
attempts to seize an SDCCH but the
NSN sdcch_busy_att
attempt is unsuccessful because all
SDCCHs are busy.
NSN sdcch_lapd_fail
are ended because of an LAPD failure.
NSN sdcch_a_if_fail_call Number of SDCCH transactions ended
40
because of a failure in the A interface

during a call attempt.
because of a failure in the A interface
NSN sdcch_a_if_fail_old
on the source channel during an
SDCCH-SDCCH or SDCCH-TCH HO.
NSN T3101_EXPIRED
NSN conver_started
Number of successful incoming TCH
NSN msc_i_tch_tch
to TCH HOs controlled by the MSC.
Number of TCH channel requests for a
NSN TCH_REQUESTS_CALL_ATTEMPT
call
Number of succesful TCH channel
NSN SUCC_TCH_SEIZ_CALL_ATTEMPT
seizures for a call
NSN dropped_calls
Number of handover commands sent
by the BSC in an outgoing
NSN msc_o_ho_cmd
MSCcontrolled handover (SDCCH-
SDCCH, TCH-TCH or SDCCH-TCH HO)
Number of all handover commands
sent by the BSC in an outgoing
NSN bsc_o_ho_cmd_assgn
BSCcontrolled handover (SDCCH-
SDCCH, TCH-TCH or SDCCH-TCH HO).
Number of assignment commands
NSN bts_ho_assgn sent in intra-BTS handovers (SDCCH-
SDCCH, TCH-TCH or SDCCH-TCH).
Number of successful outgoing HOs
NSN msc_o_succ_ho
controlled by the MSC
Number of successful outgoing HOs
NSN bsc_o_succ_ho
controlled by the BSC.
NSN cell_succ_ho Number of successful intra-cell HOs.
NSN DTM_duration_sum_HR
NSN DTM_duration_sum_HR
NSN DTM_duration_sum_FR
NSN ave_busy_tch
NSN res_av_denom14
The number of all downlink TBF
establishments, including both
NSN NBR_OF_DL_TBF acknowledged mode and
unacknowledged mode downlink TBF
establishments.
The number of all UL TBF
establishments, including both
NSN NBR_OF_UL_TBF acknowledged mode and
unacknowledged mode UL TBF
establishments.
The number of downlink GPRS TBF
establishments that have failed due to
NSN DL_TBF_Establishment_Failed
no response from MS. This counter
does not consider EGPRS TBFs.
The number of downlink EGPRS TBF
NSN DL_EGPRS_TBF_REL_DUE_NO_RESP establishments that have failed due to
no response from MS.
NSN UL_TBF_Establishment_Failed The number of uplink GPRS TBF
41
establishments that have failed due to

no response from MS. This counter
does not consider EGPRS TBFs.
The number of uplink EGPRS TBF
NSN UL_EGPRS_TBF_REL_DUE_NO_RESP establishments that have failed due to
no response from MS.
The sum of normally released
NSN AVE_DUR_DL_TBF_SUM
downlink TBF durations
The sum of normally released
NSN AVE_DUR_DL_TBF_DEN
downlink TBFs.
The sum of normally released uplink
NSN AVE_DUR_UL_TBF_SUM
TBF durations.
The sum of normally released uplink
NSN AVE_DUR_UL_TBF_DEN
TBF durations
The number of uplink TBF releases
NSN UL_TBF_REL_DUE_TO_FLUSH
due to flush.
The number of downlink TBF releases
NSN DL_TBF_REL_DUE_TO_FLUSH
because of flush.
The number of uplink TBF releases
NSN UL_TBF_REL_DUE_TO_SUSPEND
because of suspension.
The number of downlink TBF releases
NSN DL_TBF_REL_DUE_TO_SUSPEND
because of suspension.
The number of cases where an
NSN UL_TBF_RELEASES_DUE_DTM ongoing UL TBF needs to be released
due to a DTM procedure.
The number of cases where an
NSN DL_TBF_RELEASES_DUE_DTM ongoing DL TBF needs to be released
due to a DTM procedure.
No radio resources are available for a
NSN NO_RADIO_RES_AVA_DL_TBF
downlink TBF.
The number of valid RLC data blocks
NSN rlc_data_blocks_ul_cs1
in uplink with CS1.
The number of valid RLC data blocks
NSN rlc_data_blocks_ul_cs2
in uplink with CS2.
NSN ul_rlc_blocks_in_ack_mode
NSN ul_rlc_blocks_in_unack_mode
Number of dropped calls after the
NSN DROP_AFTER_TCH_ASSIGN
TCH is assigned.
6.1.5 ZTE
ZTE C900060003 Number of SDCCH seizure attempts for assignment
Number of signaling TCH/F seizure attempts for

ZTE C900060010
assignment
Number of signaling TCH/H seizure attempts for
ZTE C900060038
assignment
ZTE C900060242 Number of SDCCH assignments success
Number of signaling TCH/F assignment success for
ZTE C900060017
assignment
42
ZTE C900060235 Number of signaling TCH/H assignment success

Number of SDCCH drops due to loss of contact with
ZTE C901070001
RANA
ZTE C901070002 Number of SDCCH drops due to radio link failure
ZTE C901070003 Number of SDCCH drops due to LAPD link failure
ZTE C901070004 Number of SDCCH drops due to OMC-R forced release
Number of SDCCH drops due to forced release by

ZTE C901070005
other calls
ZTE C901070007 Number of SDCCH drops due to other failure
Number of signaling TCH/F drops due to loss of
ZTE C901070008
contact with RANA
Number of signaling TCH/F drops due to radio link
ZTE C901070009
failure
Number of signaling TCH/F drops due to LAPD link
ZTE C901070010
failure
Number of signaling TCH/F drops due to OMC-R
ZTE C901070011
forced release
Number of signaling TCH/F drops due to forced
ZTE C901070012
release by other calls
ZTE C901070014 Number of signaling TCH/F drops due to other failure
Number of signaling TCH/H drops due to forced

ZTE C901070029
release by other calls
Number of signaling TCH/H drops due to other
ZTE C901070030
failure
Number of voice TCH/H drops due to loss of contact
ZTE C901070031
with RANA
Number of voice TCH/H drops due to LAPD link
ZTE C901070032
failure
Number of voice TCH/H drops due to OMC-R forced
ZTE C901070033
release
ZTE C901070035 Number of voice TCH/H drops due to other failure
Number of SDCCH drops due to eMLPP forced

ZTE C901070064
handover
Number of signaling TCH/F drops due to eMLPP
ZTE C901070065
forced handover
Number of sigaling TCH/H drops due to eMLPP
ZTE C901070068
forced handover
ZTE C901070111 Number of SDCCH drops due to BTS failure
ZTE C901070112 Number of signaling TCH/F drops due to BTS failure
ZTE C901070115 Number of signaling TCH/H drops due to BTS failure
43
Number of Release Indications due to T200 expired

ZTE C902000019
on SDCCH
Number of Release Indications due to unsolicited DM
ZTE C902000020
response on SDCCH
Number of Release Indications due to sequence error
ZTE C902000021
on SDCCH
ZTE C902000022
on TCH/F (signaling)
ZTE C902000023
response on TCH/F (signaling)
ZTE C902000024
ZTE C902000019
on SDCCH
ZTE C902000020
response on SDCCH
ZTE C902000021
on SDCCH
ZTE C902000022
ZTE C902000023
response on TCH/F (signaling)
ZTE C902000024
ZTE C902000031
on TCH/H (signaling)
ZTE C902000032
response on TCH/H (signaling)
ZTE C902000033
on TCH/H (signaling)
Number of Release Indications without Error Ind on
ZTE C902000041
TCH/F (signaling)
Number of Release Indications without Error Ind on
ZTE C902000044
TCH/H (signaling)
Number of signaling TCH/F drops due to handover
ZTE C900060219
failure..........
Number of signaling TCH/H drops due to handover
ZTE C900060222
failure
ZTE C900060005 Number of SDCCH seizure failure for assignment
Number of signaling TCH/F seizure failure for
ZTE C900060011
assignment
Number of signaling TCH/H seizure failure for
ZTE C900060039
assignment
Number of voice TCH/F seizure attempts for
ZTE C900060019
assignment
44
Number of data TCH/F seizure attempts for

ZTE C900060030
assignment
Number of voice TCH/H seizure attempts for
ZTE C900060042
assignment
Number of data TCH/H seizure attempts for
ZTE C900060046
assignment
ZTE C900060036 Number of data TCH/F assignment success
Number of voice TCH/F seizure failure for
ZTE C900060020
assignment
ZTE C900060031 Number of data TCH/F seizure failure for assignment
Number of voice TCH/H seizure failure for

ZTE C900060043
assignment
ZTE C900060047 Number of data TCH/H seizure failure for assignment
Number of voice TCH/F drops due to handover

ZTE C900060220
failure
ZTE C900060221 Number of data TCH/F drops due to handover failure
ZTE C900060223 Number of data TCH/H drops due to handover failure
Number of voice TCH/F drops due to radio link

ZTE C900060244
failure
Number of voice TCH/F drops due to loss of contact
ZTE C901070015
with RANA
Number of voice TCH/F drops due to LAPD link
ZTE C901070017
failure
Number of voice TCH/F drops due to OMC-R forced
ZTE C901070018
release
Number of voice TCH/F drops due to forced release
ZTE C901070019
by other calls
ZTE C901070021 Number of voice TCH/F drops due to other failure
Number of data TCH/F drops due to loss of contact
ZTE C901070022
with RANA
ZTE C901070023 Number of data TCH/F drops due to radio link failure
ZTE C901070024 Number of data TCH/F drops due to LAPD link failure
Number of data TCH/F drops due to OMC-R forced

ZTE C901070025
release
Number of data TCH/F drops due to forced release by
ZTE C901070026
other calls
ZTE C901070028 Number of data TCH/F drops due to other failure
Number of voice TCH/H drops due to loss of contact
ZTE C901070036
with RANA
ZTE C901070037
45
Number of voice TCH/H drops due to LAPD link

ZTE C901070038
failure
Number of voice TCH/H drops due to OMC-R forced
ZTE C901070039
release
Number of voice TCH/H drops due to forced release
ZTE C901070040
by other calls
ZTE C901070041
ZTE C901070042 Number of voice TCH/H drops due to other failure
Number of data TCH/H drops due to loss of contact

ZTE C901070043
with RA
ZTE C901070044 Number of data TCH/H drops due to radio link failure
ZTE C901070045 Number of data TCH/H drops due to LAPD link failure
Number of data TCH/H drops due to OMC-R forced

ZTE C901070046
release
Number of data TCH/H drops due to forced release by
ZTE C901070047
other
ZTE C901070049 Number of data TCH/H drops due to other failure
ZTE C901070061 Number of TCH/H short messages drops
Number of TCH/F drops due to CS channel is forced
ZTE C901070062
release by PS
ZTE C901070113 Number of voice TCH/F drops due to BTS failure
ZTE C901070114 Number of data TCH/F drops due to BTS failure
ZTE C901070116 Number of voice TCH/H drops due to BTS failure
ZTE C901070117 Number of data TCH/H drops due to BTS failure
Number of Drop Call on TCH/F Due to Ring BTS Turn
ZTE C901070195
Over
Number of Drop Call on TCH/H Due to Ring BTS Turn
ZTE C901070213
Over
ZTE C900060119 Number of Intra-cell handover
Number of BSC-controlled inter-cell outgoing
ZTE C900060093
handover
ZTE C900060095 Number of MSC-controlled outgoing handover
ZTE C900060120 Number of Intra-cell handover success
Number of BSC-controlled inter-cell outgoing
ZTE C900060094
handover success
Number of MSC-controlled outgoing handover
ZTE C900060096
success
ZTE C900060127 TCH/H busy time
ZTE C900060129 TCH/F busy time
Number of GPRS DL TBF establishment requests
ZTE C900040141
before T3192 expiration
Number of GPRS DL TBF establishment using existing
ZTE C900040142
DL TBF resource
46
Number of GPRS DL TBF establishment requests on

ZTE C900040143
PACCH
Number of GPRS DL TBF establishment requests on
ZTE C900040144
CCCH/PCCCH
Number of EGPRS DL TBF establishment requests
ZTE C900040145
before T3192 expiration
Number of EGPRS DL TBF establishment using
ZTE C900040146 existing DL TBF
resource
Number of EGPRS DL TBF establishment requests on
ZTE C900040147
PACCH
Number of EGPRS DL TBF establishment requests on
ZTE C900040148
CCCH/PCCCH
Number of GPRS UL TBF establishments in release
ZTE C900040159
state
Number of GPRS UL TBF establishment with existing
ZTE C900040160
UL resource
Number of GPRS UL TBF establishment requests on
ZTE C900040161
PACCH
Number of GPRS UL TBF establishment requests on
ZTE C900040168
CCCH/PCCCH
Number of EGPRS UL TBF establishments in release
ZTE C900040163
state
Number of EGPRS UL TBF establishment with existing
ZTE C900040164
UL resource
Number of EGPRS UL TBF establishment requests on
ZTE C900040165
PACCH
Number of EGPRS UL TBF establishment requests on
ZTE C900040166
CCCH/PCCCH
ZTE C900040007 Number of GPRS DL signaling TBF establishment
ZTE C900040015 Number of EGPRS DL signaling TBF establishment
ZTE C900040008 Number of GPRS DL data TBF establishment
ZTE C900040016 Number of EGPRS DL data TBF establishment
ZTE C900040025 Number of GPRS UL signaling TBF establishment
ZTE C900040033 Number of EGPRS UL signaling TBF establishment
ZTE C900040026 Number of GPRS UL data TBF establishment
ZTE C900040034 Number of EGPRS UL data TBF establishment
Number of EGPRS DL TBF release due to N3105
ZTE C900040010
overflow
Number of GPRS DL TBF release due to N3105
ZTE C900040002
overflow
Number of EGPRS UL TBF release due to N3101
ZTE C900040028
overflow
Number of GPRS UL TBF release due to N3101
ZTE C900040020
overflow
ZTE C900040060 Bytes of LLC frame on GPRS DL data TBF
47
ZTE C900040058 Bytes of LLC frame on GPRS UL data TBF

ZTE C900040066 Bytes of LLC frame on EGPRS UL data TBF
ZTE C900040068 Bytes of LLC frame on EGPRS DL data TBF
6.1.6 NSN - Motorola

statistic tracks the number of times that an
attempt at SDCCH
Motorola ALLOC_SDCCH_FAIL
seizure was rejected because of SDCCH
congestion
The ALLOC_SDCCH statistic is the sum of the

Motorola Alloc_SDCCH
number of times an SDCCH is successfully seized.
Motorola Chan_Req_Fail_Rol
The statistic pegs the number of calls
Motorola RF_LOSSES_SD terminated on the SDCCH due to RF
problems.
tracks the number of Assignment Commands
Motorola Ma_cmd_to_ms
sent to the MS
pegged only once per connection at the time of
Motorola Total_Calls
the first successful TCH assignment procedure
The pegging of this statistic indicates no
channels were available in the currently
Motorola ma_cmd_to_ms_blkd allocated cell. It is indicated by an Assignment
Failure message with cause: No radio resource
available.
pegs the number of full rate and half rate calls
Motorola RF_LOSSES_TCH_ROLL that were
terminated on TCH due to RF problems.
Number of failed intra-cell handovers that also
Motorola INTRA_CELL_HO_LOSTMS
failed to recover to the original cell.
Number of failed intra-BSS handovers in which
Motorola OUT_INTRA_BSS_HO_LOSTMS
the MS also failed to recover to the original BSS.
Number of assignment commands sent to MS
Motorola OUT_INTER_BSS_HO_ATMPT
during an inter-BSS handover.
Motorola OUT_INTER_BSS_HO_SUC Number of successful inter-BSS handovers.
Number of failed inter-BSS handovers in which
Motorola OUT_INTER_BSS_HO_RETURN
the MS recovered to the original BSS/channel.
Number of outgoing inter-BSS handovers
aborted
due to call clearing in both the MS and NSS.
Motorola OUT_INTER_BSS_CLEARED This scenario corresponds to the receipt of a
Clear Command, SCCP Released, or Release Done
(internal message) during the handover
procedure.
gives an indication of the total amount of traffic
Motorola TCH_Usage/3600*1000
carried by the cell.
48
the number of extended range traffic channels in

Motorola TCH_USAGE_EXT_RANGE/3600*1000
use.
tracks the usage of TCHs belonging to carriers in
Motorola TCH_USAGE_INNER_ZONE/3600*1000
the inner zone of a concentric cell.
measures the number of attempts to establish
Motorola UL_EGPRS_TBF_ATTEMPTS
uplink EGPRS TBF.
measures the number of attempts to establish
Motorola UL_GPRS_TBF_ATTEMPTS
uplink EGPRS TBF.
6.2 Vendor Counters 3G Network
6.2.1 Alcatel-Lucent
Vendor Counter Definition SubCounter

Number of successful RRC ACTIVE SET UPDATE
procedure for which the cell is in the list of the
ALU 415 active set before or after the AS execution.
Incremented once per AS procedure for the cell,
irrelevant of number of cells in the active set.
Number of RAB establishment attempts (per Rabid
and not per procedure). This counter should also Dl and Ul are CS Speech,
ALU 1620_1
be pegged in case of RAB allocation attempts for TC is Conversational
incoming relocations.

and not per procedure). This counter should also Dl and Ul are CSD 64, TC is
ALU 1620_2
be pegged in case of RAB allocation attempts for Conversational
Number of successful RAB establishment per
granted RAB type (per Rabid and not per
Dl and Ul are CS Speech,
ALU 1621_1 procedure). This counter should also be pegged for
TC is Conversational
RAB successfully allocated for incoming
relocations.
Dl and Ul are CSD 64, TC is
Conversational
relocations.
Number of attempted incoming intra UMTS (inter- Sub-Counter #0: Time

ALU 122_0
and intra-PLMN) relocations critical relocation
Sub-Counter #1:
Number of attempted incoming intra UMTS (inter-
ALU 122_1 Relocation desireable for
and intra-PLMN) relocations
radio reasons
49
Number of attempted incoming intra UMTS (inter- Sub-Counter #2: Directed

ALU 122_2
and intra-PLMN) relocations retry
Number of attempted incoming intra UMTS (inter- Sub-Counter #3:

ALU 122_3
and intra-PLMN) relocations Unexpected Cause
Number of successful incoming intra UMTS (inter- Sub-Counter #0: Time

ALU 124_0
and intra-PLMN) relocations critical relocation
Sub-Counter #1:
Number of successful incoming intra UMTS (inter-
ALU 124_1 Relocation desireable for
and intra-PLMN) relocations
radio reasons
Number of successful incoming intra UMTS (inter- Sub-Counter #2: Directed

ALU 124_2
and intra-PLMN) relocations retry
Number of successful incoming intra UMTS (inter- Sub-Counter #3:

ALU 124_3
and intra-PLMN) relocations Unexpected Cause
Number of attempted outgoing relocation to Sub-Counter #0: Inter

ALU 131_0 another RNC in the same PLMN, which is not Frequency Time critical
connected by an Iur link. relocation
Number of attempted outgoing relocation to Sub-Counter #1: Intra

ALU 131_1 another RNC in the same PLMN, which is not Frequency Time critical
connected by an Iur link. relocation
Number of attempted outgoing relocation to

Sub-Counter #2: Service
ALU 131_2 another RNC in the same PLMN, which is not
relocation
connected by an Iur link.
Number of attempted outgoing relocation to Sub-Counter #3: No

ALU 131_3 another RNC in the same PLMN, which is not resource available (CAC
connected by an Iur link. failure) relocation
Sub-Counter #0: Inter

Number of successful Hard Handovers to an RNC
ALU 133_0 Frequency Time critical
in the same PLMN, without an Iur link.
relocation
50
Sub-Counter #1: Intra

ALU 133_1 Frequency Time critical
relocation
Number of successful Hard Handovers to an RNC Sub-Counter #2: Service

ALU 133_2
in the same PLMN, without an Iur link. relocation
Sub-Counter #3: No
ALU 133_3 resource available (CAC
failure) relocation
Number of Kbytes of SDU sent on uplink for each Sub-Counter #11: PS I/B
ALU 1553_11
cell of the active set 64kbps
ALU 1553_12
ALU 1553_13
Number of Kbytes of SDU sent on uplink for each

ALU 1553_6 Sub-Counter #6: PS Str 64
cell of the active set
Number of Kbytes of SDU sent on downlink for Sub-Counter #13: PS I/B

ALU 1554_13
each cell of the active set 64kbps

ALU 1554_14

ALU 1554_16
Number of Kbytes of SDU sent on downlink for

ALU 1554_19 E-Type
each cell of the active set
51
Number of Kbytes of SDU sent on downlink for

ALU 1554_20
each cell of the active set
Number of Kbytes of SDU sent on downlink for Sub-Counter #5: PS

ALU 1554_5
each cell of the active set HSDPA
Number of Kbytes of SDU sent on downlink for Sub-Counter #5: PS

ALU 1554_5
each cell of the active set HSDPA
Number of Kbytes of SDU sent on downlink for Sub-Counter #6: PS Str

ALU 1554_6
each cell of the active set 128
Number of Kbytes of SDU sent on downlink for Sub-Counter #8: PS Str

ALU 1554_8
each cell of the active set 384
ALU 1555_14

and not per procedure). This counter should also
ALU 1620_12
be pegged in case of RAB allocation attempts for

Sub-Counter #4: Dl is any
ALU 1620_4 low rate PS I/B, Ul is any
PS I/B, TC is Interative

ALU 1620_5 low rate PS I/B, Ul is any
PS I/B, TC is Background

ALU 1620_6 high rate PS I/B, Ul is any
PS I/B, TC is Interative

ALU 1620_7 high rate PS I/B, Ul is any
PS I/B, TC is Background
52

ALU 1620_8 low rate Ps Str and Ul is
any PS Str, TC is Streaming

ALU 1620_9 high rate Ps Str and Ul is
any PS Str, TC is Streaming
relocations.
granted RAB type (per Rabid and not per Sub-Counter #4: Dl is any
ALU 1621_4 procedure). This counter should also be pegged for low rate PS I/B, Ul is any
RAB successfully allocated for incoming PS I/B, TC is Interative
relocations.
ALU 1621_5 procedure). This counter should also be pegged for low rate PS I/B, Ul is any
RAB successfully allocated for incoming PS I/B, TC is Background
relocations.
ALU 1621_6 procedure). This counter should also be pegged for high rate PS I/B, Ul is any
RAB successfully allocated for incoming PS I/B, TC is Interative
relocations.
ALU 1621_7 procedure). This counter should also be pegged for high rate PS I/B, Ul is any
RAB successfully allocated for incoming PS I/B, TC is Background
relocations.
ALU 1621_8 procedure). This counter should also be pegged for low rate Ps Str and Ul is
RAB successfully allocated for incoming any PS Str, TC is Streaming
relocations.
ALU 1621_9 procedure). This counter should also be pegged for high rate Ps Str and Ul is
RAB successfully allocated for incoming any PS Str, TC is Streaming
relocations.
Number of hard handovers attempted from this
cell to another inter-frequency cell located either
ALU 174_0 Sub-Counter #0: Rescue
in the same RNC or in a neighbouring RNC (a Iur
link is setup towards the inter-frequency cell).

ALU 174_1 Sub-Counter #1: Service
53
Number of successful hard handovers from this

cell located on the serving RNC to another inter-
ALU 175_0 frequency cell located either in the same RNC or in Sub-Counter #0: Rescue
a neighbouring RNC (a Iur link is setup towards
the inter-frequency cell).
cell located on the serving RNC to another inter-
ALU 175_1 frequency cell located either in the same RNC or in Sub-Counter #1: Service
Number of Hard Handovers attempted to this cell

ALU 176_1 located on Serving RNC from another cell on a Sub-Counter #0: Rescue
different frequency from the same RNC

ALU 176_2 located on Serving RNC from another cell on a Sub-Counter #1: Service
Number of successful Hard Handovers to this cell

Number of successful Hard Handovers to this cell

ALU 177_1 located on Serving RNC from another cell on a Sub-Counter #1: Service
Number of successful Hard Handovers to this cell Sub-Counter #2: No

ALU 177_2 located on Serving RNC from another cell on a resource available (CAC
different frequency from the same RNC failure)
RAB Establishment Failures per failure cause for Sub-Counter #2: Code
ALU 2629_2
the CS domain. starvation
Sub-Counter #5:
Reception of NBAP /
RNSAP RL Reconfiguration
(or RL Setup) Failure with
either of the causes
RAB Establishment Failures per failure cause for
ALU 2629_5 'NodeB resource
the CS domain.
unavailable'(NBAP) or
'Transaction not
supported by Destination
NodeB' (RNSAP). See Note
under 'Triggering Event'
Sub-Counter #0:
ALU 403_0 Number of rrc connection successful Originating Conversational
call
54
Sub-Counter #14:
ALU 403_14 Number of rrc connection successful Originating High Priority
Signalling
Sub-Counter #16: Call re-

ALU 403_16 Number of rrc connection successful
establishment
Sub-Counter #17:
ALU 403_17 Number of rrc connection successful Terminating High Priority
Signalling
Sub-Counter #19:
ALU 403_19 Number of rrc connection successful Terminating- cause
unknown
Sub-Counter #2:
Originating Interactive Call
Sub-Counter #3:
ALU 403_3 Number of rrc connection successful Originating Background
Call
Sub-Counter #4:
ALU 403_4 Number of rrc connection successful Originating Subscribed
Traffic Call
Sub-Counter #5:
ALU 403_5 Number of rrc connection successful Terminating
Conversational call
Sub-Counter #6:
ALU 403_6 Number of rrc connection successful Terminating Streaming
Call
Sub-Counter #7:
ALU 403_7 Number of rrc connection successful Terminating Interactive
Call
Sub-Counter #8:
ALU 403_8 Number of rrc connection successful Terminating Background
Call
55
Sub-Counter #9:
Emergency Call
ALU 404_17 Failed RRC Connection Establishments by Cause.
Sub-Counter #7: CAC

ALU 404_7 Failed RRC Connection Establishments by Cause.
(excluding FACH Ues)
Sub-Counter #0:
Number of first RRC connection requests for a
ALU 419_0 Originating Conversational
given UE on a given cell.
call
Number of first RRC connection requests for a Sub-Counter #1:

ALU 419_1
given UE on a given cell. Originating Streaming Call
Sub-Counter #14:
ALU 419_14 Originating High Priority
Signalling
Number of first RRC connection requests for a Sub-Counter #16: Call re-
ALU 419_16
given UE on a given cell. establishment
Sub-Counter #17:
ALU 419_17 Terminating High Priority
Signalling
Sub-Counter #19:
ALU 419_19 Terminating- cause
unknown

ALU 419_2
given UE on a given cell. Originating Interactive Call
Sub-Counter #3:
ALU 419_3 Originating Background
Call
56
Sub-Counter #4:
ALU 419_4 Originating Subscribed
Traffic Call
Sub-Counter #5:
ALU 419_5 Terminating
Conversational call
Sub-Counter #6:
ALU 419_6 Terminating Streaming
Call
Sub-Counter #7:
ALU 419_7 Terminating Interactive
Call
Sub-Counter #8:
ALU 419_8 Terminating Background
Call

ALU 419_9
given UE on a given cell. Emergency Call
Sub-Counter #0:
Failed RRC Connection Establishments due to
ALU 432_0 Originating Conversational
Congestion per Establishment Cause
Call
Sub-Counter #1:
ALU 432_1 Terminating
Conversational Call
Failed RRC Connection Establishments due to Sub-Counter #2:

ALU 432_2
Congestion per Establishment Cause Originating Streaming Call
Sub-Counter #3:
ALU 432_3 Terminating Streaming
Call
Failed RRC Connection Establishments due to Sub-Counter #4:

ALU 432_4
Congestion per Establishment Cause Originating Interactive Call
57
Sub-Counter #5:
ALU 432_5 Terminating Interactive
Call
Sub-Counter #6:
ALU 432_6 Originating Background
Call
Sub-Counter #7:
ALU 432_7 Terminating Background
Call
Sub-Counter #8:
ALU 432_8 Originating High Priority
Signalling
Sub-Counter #9:
ALU 432_9 Originating Subscribed
traffic Call
Time that RAB is actively transmitting data in the

ALU 1566_2 Sub-Counter #2: CS speech
downlink
Time that RAB is actively transmitting data in the Sub-Counter #3: CS 64

ALU 1566_3
downlink conversational
Time that RAB is actively transmitting data in the Sub-Counter #3: CS 64

ALU 1567_3
uplink conversational

Sub-Counter #2: No
ALU 174_2 resource available (CAC
failure)
cell located on the serving RNC to anotherv inter-
ALU 175_2 frequency cell located either in the same RNC or in

58
RAB Establishment Failures per failure cause for Sub-Counter #2: Code
ALU 2631_2
the PS domain starvation
Sub-Counter #5:
Reception of NBAP /
RNSAP RL Reconfiguration
(or RL Setup) Failure with
either of the causes
RAB Establishment Failures per failure cause for
ALU 2631_5 'NodeB resource
the PS domain
unavailable'(NBAP) or
'Transaction not
supported by Destination
NodeB' (RNSAP). See Note
under 'Triggering Event'
Sub-Counter #0:
ALU 402_0 Number of unsuccessful RRC ACTIVE SET UPDATE RRC_ACTIVE_SET_UPDATE
_FAILURE
ALU 402_1 Number of unsuccessful RRC ACTIVE SET UPDATE Sub-Counter #1: Timeout
Sub-Counter #1:
Originating Streaming Call
With counter 0404 it gives a view of the failure

and success rate of the 3G2G redirection at RRC
establishment request. If no GSM cell verifies the
selection criteria, the UE will re-attempt a new
RACH after the "wait time" timer (UE timer)
elapses. On this new attempt the RNC does not
redirect the call to the 2G and attempts to
Sub-Counter #0:
establish the call on the FDD cell if the Rach comes
ALU 439_0 Emergency call redirection
before the timer rrcCnxRepeatTime elapses. The
feature
counter is incremented when the RNC does not
redirect this new attempt. Repeated "RRC
Connection Request" in the context T300 and
N300 from the same UE (same UE Id and
format)on the same RNC shall be excluded. Note:
rrcCnxRepeatTime is renamed from
emergencyCallRepeatTime
ALU 439_1 With counter 0404 it gives a view of the failure Sub-Counter #1:
and success rate of the 3G2G redirection at Redirection based on cell
RRC establishment request. If no GSM cell verifies load feature
the selection criteria, the UE will re-attempt
a new RACH after the "wait time" timer (UE timer)
elapses. On this new attempt the RNC does
not redirect the call to the 2G and attempts to
establish the call on the FDD cell if the Rach
comes before the timer rrcCnxRepeatTime elapses.
The counter is incremented when the
RNC does not redirect this new attempt. Repeated
59
"RRC Connection Request" in the context T300 and

N300 from the same UE (same UE Id and
format)on the same RNC shall be excluded. Note:
rrcCnxRepeatTime is renamed from
emergencyCallRepeatTime
Number of DlAsConfIds that increments for multi-

Sub-Counter #0: Other
ALU 589_0 service whenever RNC requests Iu release due to
type of Call
abnormal conditions

Sub-Counter #10: PS I/B
128
abnormal conditions

256
abnormal conditions

384
abnormal conditions

abnormal conditions

Sub-Counter #2: PS
Streaming < 64
abnormal conditions

Sub-Counter #3: PS
Streaming 64
abnormal conditions

Sub-Counter #4: PS
Streaming 128
abnormal conditions

Sub-Counter #5: PS
Streaming 256
abnormal conditions

Sub-Counter #6: PS
Streaming 384
abnormal conditions
60

Sub-Counter #7: TRB on
cell FACH
abnormal conditions

Sub-Counter #8: PS I/B <
64
abnormal conditions

ALU 589_9 service whenever RNC requests Iu release due to Sub-Counter #9: PS I/B 64
abnormal conditions
Number of Iu abnormal release request that

Sub-Counter #2: CS speech
ALU 595_2 increments whenever RNC requests Iu release due
NB or LR AMR
to abnormal conditions

Sub-Counter #3: CS speech
WB AMR

ALU 595_4 increments whenever RNC requests Iu release due Sub-Counter #4: CS data

Sub-Counter #5: CS
Streaming 57.6

Sub-Counter #6: CS
Streaming 14.4
6.2.2 Ericsson

Ericsson pmTotNoRrcConnectReq
Ericsson pmTotNoRrcConnectReqSuccess
Ericsson pmNoRejRrcConnMpLoadC
Ericsson pmTotNoRrcConnectReqCs
Ericsson pmTotNoRrcConnectReqCsSucc
Ericsson pmNoRabEstablishAttemptSpeech
Ericsson pmNoRabEstablishSuccessSpeech
Ericsson pmNoRabEstBlockNodeSpeechBest
Ericsson pmNoRabEstablishAttemptPacketInteractive
61
Ericsson pmNoRabEstablishSuccessPacketInteractive
Ericsson pmNoRabEstBlkNodePsIntNonHsBest
Ericsson pmNoSystemRabReleaseSpeech
Ericsson pmNoSystemRabReleasePacket
Ericsson pmNoSystemRabReleasePacketUra
Ericsson pmSumBestAmr12200RabEstablish
Ericsson pmSumBestCs64RabEstablish
Ericsson pmDlTrafficVolumePs128
Ericsson pmDlTrafficVolumePsCommon
Ericsson pmDlTrafficVolumePsIntHs
Ericsson pmRlAddAttemptsBestCellSpeech
Ericsson pmAttNonBlindInterFreqHoCsSpeech12
Ericsson pmSuccNonBlindInterFreqHoCsSpeech12
Ericsson pmNoAttOutIratHoSpeech
Ericsson pmNoSuccessOutIratHoSpeech
6.2.3 Huawei

Huawei VS.RRC.AttConnEstab.Sum Number of Processed RRC Connection Requests for Cell
Huawei RRC.SuccConnEstab.Sum Number of Successful RRC Connection Setups for Cell
Number of RRC Connection Rejects for Cell (UL Power
Huawei VS.RRC.Rej.ULPower.Cong
Congestion)
Number of RRC Connection Rejects for Cell (DL Power
Huawei VS.RRC.Rej.DLPower.Cong
Congestion)
Number of RRC Connection Rejects for Cell (Code Resource
Huawei VS.RRC.Rej.Code.Cong
Congestion)
Number of RRC Connection Rejects for Cell (UL CE Resource
Huawei VS.RRC.Rej.ULCE.Cong
Congestion)
Number of RRC Connection Rejects for Cell (DL CE Resource
Huawei VS.RRC.Rej.DLCE.Cong
Congestion)
Number of RRC Connection Rejects for Cell (UL Iub Bandwidth
Huawei VS.RRC.Rej.ULIUBBand.Cong
Congestion)
Number of RRC Connection Rejects for Cell (DL Iub Bandwidth
Huawei VS.RRC.Rej.DLIUBBand.Cong
Congestion)
Number of Successful RRC Connection Setups for Cell
Huawei RRC.SuccConnEstab.OrgConvCall
(Originating Conversational Call)
Huawei RRC.SuccConnEstab.TmConvCall
(Terminating Conversational Call)
Huawei RRC.SuccConnEstab.OrgSubCall
(Originating Subscribed traffic Call)
62

Huawei RRC.SuccConnEstab.EmgCall
(Emergency Call)
Number of RRC Connection Requests for Cell (Originating
Huawei RRC.AttConnEstab.OrgConvCall
Conversational Call)
Number of RRC Connection Requests for Cell (Terminating
Huawei RRC.AttConnEstab.TmConvCall
Conversational Call)
Number of RRC Connection Requests for Cell (Originating
Huawei RRC.AttConnEstab.OrgSubCall
Subscribed Traffic Call)
Huawei RRC.AttConnEstab.EmgCall Number of RRC Connection Requests for Cell (Emergency Call)
Number of CS AMR Service RAB Establishment Attempts for

Huawei VS.RAB.AttEstab.AMR
Cell
Number of CS Conversational RAB Establishment Attempts for
Huawei VS.RAB.AttEstCS.Conv.64
Cell (Max DL Bit Rate is 64 kbit/s)
Huawei VS.RAB.SuccEstabCS.AMR Number of Successful CS AMR RAB Establishments for Cell
Number of Successful CS RAB Establishments for Cell (Max DL

Huawei VS.RAB.SuccEstCS.Conv.64
Bit Rate is 64 kbit/s)
Number of Failed CS RAB Establishments for Cell (UL Power
Huawei VS.RAB.FailEstabCS.ULPower.Cong
Congestion)
Number of Failed CS RAB Establishments for Cell (DL Power
Huawei VS.RAB.FailEstabCS.DLPower.Cong
Congestion)
Number of Failed CS RAB Establishments for Cell (Code
Huawei VS.RAB.FailEstabCS.Code.Cong
Congestion)
Number of Failed CS RAB Establishments for Cell (UL CE
Huawei VS.RAB.FailEstabCS.ULCE.Cong
Congestion)
Number of Failed CS RAB Establishments for Cell (DL CE
Huawei VS.RAB.FailEstabCS.DLCE.Cong
Congestion)
Number of Failed CS RAB Establishments for Cell (DL Iub
Huawei VS.RAB.FailEstabCS.DLIUBBand.Cong
Bandwidth Congestion)
Number of Failed CS RAB Establishments for Cell (UL Iub
Huawei VS.RAB.FailEstabCS.ULIUBBand.Cong
Number of PS Conversational RAB Establishment Attempts for
Huawei VS.RAB.AttEstabPS.Conv
Cell
Huawei VS.RAB.AttEstabPS.Str Number of PS Streaming RAB Establishment Attempts for Cell
Number of PS Background RAB Establishment Attempts for

Huawei VS.RAB.AttEstabPS.Bkg
Cell
Number of Successful PS Conversational RAB Establishments
Huawei VS.RAB.SuccEstabPS.Conv
for Cell
Number of Successful PS Streaming RAB Establishments for
Huawei VS.RAB.SuccEstabPS.Str
Cell
Number of Successful PS Background RAB Establishments for
Huawei VS.RAB.SuccEstabPS.Bkg
Cell
Number of Failed CS RAB Establishments for Cell (UL Power
Huawei VS.RAB.FailEstabCS.ULPower.Cong
Congestion)
63
Number of Failed CS RAB Establishments for Cell (DL Power

Huawei VS.RAB.FailEstabCS.DLPower.Cong
Congestion)
Number of Failed CS RAB Establishments for Cell (Code
Huawei VS.RAB.FailEstabCS.Code.Cong
Congestion)
Number of Failed CS RAB Establishments for Cell (UL CE
Huawei VS.RAB.FailEstabCS.ULCE.Cong
Congestion)
Number of Failed CS RAB Establishments for Cell (DL CE
Huawei VS.RAB.FailEstabCS.DLCE.Cong
Congestion)
Number of Failed CS RAB Establishments for Cell (DL Iub
Huawei VS.RAB.FailEstabCS.DLIUBBand.Cong
Number of Failed CS RAB Establishments for Cell (UL Iub
Huawei VS.RAB.FailEstabCS.ULIUBBand.Cong
Huawei VS.RAB.AbnormRel.AMR Number of CS AMR RABs Abnormally Released for Cell
Number of CS Conversational 64kbit/s RABs Abnormally
Huawei VS.RAB.AbnormRel.CS64
Released for Cell
Huawei VS.RAB.AbnormRel.PS Number of PS RABs Abnormally Released for Cell
Number of Abnormally Released PS RABs that Are in
Huawei VS.RAB.AbnormRel.PS.PCH
CELL_PCH or URA_PCH State for Cell
Number of RABs Abnormally Released for PS Services during
Huawei VS.RAB.AbnormRel.PS.D2P the State Transition from CELL_DCH to CELL_PCH or URA_PCH
for Cell
Huawei VS.RAB.AbnormRel.PS.F2P Number of call drops During the F2P State Transition for Cell
Huawei VS.RB.AMR.DL.12.2 Number of AMR Users with DL rate of 12.2 Kbit/s for Cell
Average Number of RBs for CS Conversational Services with
Huawei VS.RB.CS.Conv.DL.64
DL Rate of 64 Kbit/s for Cell
Huawei VS.PS.Bkg.DL.8.Traffic DL Traffic Volume of 8 Kbit/s PS Background Services for Cell
Number of Radio Link Addition Attempts in Soft Handover for

Huawei VS.SHO.AttRLAdd
Cell
Number of Radio Link Deletion Attempts in Soft Handover for
Huawei VS.SHO.AttRLDel
Cell
Number of Successful Radio Link Additions in Soft Handover
Huawei VS.SHO.SuccRLAdd
for Cell
Number of Successful Radio Link Deletions in Soft Handover
Huawei VS.SHO.SuccRLDel
for Cell
Number of Outgoing Inter-Frequency Hard Handover
Huawei VS.HHO.AttInterFreqOut
Attempts for Cell
Number of Successful Outgoing Inter-Frequency Hard
Huawei VS.HHO.SuccInterFreqOut
Handovers for Cell
64
Huawei IRATHO.AttOutCS Number of CS Outgoing Inter-RAT Handover Attempts

Number of Successful CS Outgoing Inter-RAT Handovers for
Huawei IRATHO.SuccOutCS
Cell
Number of Normally Released PS RABs that Are in CELL_PCH
Huawei VS.RAB.NormRel.PS.PCH
or URA_PCH State for Cell
Number of Successful State Transfers from CELL_DCH to
Huawei VS.DCCC.D2P.Succ
CELL_PCH for Cell
Number of Successful State Transfers from CELL_FACH to
Huawei VS.DCCC.Succ.F2P
CELL_PCH for Cell
Number of Successful State Transfers from CELL_DCH to
Huawei VS.DCCC.D2P.Succ
CELL_PCH for Cell
Number of Successful State Transfers from CELL_FACH to
Huawei VS.DCCC.Succ.F2P
CELL_PCH for Cell
6.2.4 NSN
6.2.5 ZTE

ZTE 300002 Number of successful RRC connection establishment
ZTE 300001 Number of RRC connection establishment Attempt
ZTE 300029 Number of Successful CS RAB Establishment
ZTE 300030 Number of CS RAB Establishment Attempt
ZTE 300035 Number of Successful PS RABEstablishment
ZTE 300036 Number of PS RABEstablishment Attempt
ZTE 300240 Number of CS CallDrop
ZTE C3231185 Retain.Cell.CsRabRel.Total.AMR12_2
ZTE C3231193 Retain.Cell.CsRabRel.Total.WAMR23_85
65

ZTE C3231202 Retain.Cell.CsRabRel.Total.C_32
ZTE C3231203 Retain.Cell.CsRabRel.Total.C_64K
ZTE C3231204 Retain.Cell.CsRabRel.Total.C_ELSE
ZTE C3231205 Retain.Cell.CsRabRel.Total.S
ZTE C3231206 Retain.Cell.CsRabRel.Total.I
ZTE C3231207 Retain.Cell.CsRabRel.Total.B
ZTE C311866866 Retain.Cell.PsRbRel.C
ZTE C311866868 Retain.Cell.PsRbRel.S_8_8
ZTE C311866876 Retain.Cell.PsRbRel.S_ELSE
ZTE C311866878 Retain.Cell.PsRbRel.I_8_8
ZTE C311866888 Retain.Cell.PsRbRel.I_ELSE
ZTE C311866890 Retain.Cell.PsRbRel.B_8_8
ZTE C311866900 Retain.Cell.PsRbRel.B_ELSE
ZTE C310040001 TV.Cell.BestCell.HoldingTime.AMR12_2
66

ZTE C310040009 TV.Cell.BestCell.HoldingTime.WAMR23_85
ZTE C310040018 TV.Cell.BestCell.HoldingTime.CS64
ZTE C310040019 TV.Cell.BestCell.HoldingTime.CS32
ZTE C310040020 TV.Cell.BestCell.HoldingTime.CS.S
ZTE C310040021 TV.Cell.BestCell.HoldingTime.CS.I
ZTE C310040022 TV.Cell.BestCell.HoldingTime.CS.B
ZTE C310040075 TV.Cell.NonBestCell.HoldingTime.AMR12_2
ZTE C310040083 TV.Cell.NonBestCell.HoldingTime.WAMR23_85
ZTE C310040092 TV.Cell.NonBestCell.HoldingTime.CS64
ZTE C310040093 TV.Cell.NonBestCell.HoldingTime.CS32
ZTE C310040094 TV.Cell.NonBestCell.HoldingTime.CS.S
ZTE C310040095 TV.Cell.NonBestCell.HoldingTime.CS.I
ZTE C310040096 TV.Cell.NonBestCell.HoldingTime.CS.B
ZTE C310010320 TV.Cell.FP.Volume.Ps.C.Ul
ZTE C310010322 TV.Cell.FP.Volume.Ps.S.Ul
ZTE C310010324 TV.Cell.FP.Volume.Ps.I.Ul
ZTE C310010326 TV.Cell.FP.Volume.Ps.B.Ul
ZTE C310010321 TV.Cell.FP.Volume.Ps.C.Dl
ZTE C310010323 TV.Cell.FP.Volume.Ps.S.Dl
ZTE C310010325 TV.Cell.FP.Volume.Ps.I.Dl
ZTE C310010327 TV.Cell.FP.Volume.Ps.B.Dl
ZTE C310010292 TV.Cell.FP.Volume.Iub.Ul.Hsupa.C
67
ZTE C310010293 TV.Cell.FP.Volume.Iub.Ul.Hsupa.S

ZTE C310010294 TV.Cell.FP.Volume.Iub.Ul.Hsupa.I
ZTE C310010295 TV.Cell.FP.Volume.Iub.Ul.Hsupa.B
ZTE C310010296 TV.Cell.FP.Volume.Iub.Dl.Hsdpa.C
ZTE C310010297 TV.Cell.FP.Volume.Iub.Dl.Hsdpa.S
ZTE C310010298 TV.Cell.FP.Volume.Iub.Dl.Hsdpa.I
ZTE C310010299 TV.Cell.FP.Volume.Iub.Dl.Hsdpa.B
ZTE 300439 Number of Successful SHO
ZTE 300440 Number of Attempted SHO
ZTE C310332621 Mob.Cell.CS.InterHard.Succ.Measure.DlPower
ZTE C310332622 Mob.Cell.CS.InterHard.Succ.Measure.UlInterference
ZTE C310332619 Mob.Cell.CS.InterHard.Succ.Measure.RSCP
ZTE C310332620 Mob.Cell.CS.InterHard.Succ.Measure.EcN0
ZTE C310332610 Mob.Cell.CS.InterHard.Att.Measure.DlPower
ZTE C310332611 Mob.Cell.CS.InterHard.Att.Measure.UlInterference
ZTE C310332608 Mob.Cell.CS.InterHard.Att.Measure.RSCP
ZTE C310332609 Mob.Cell.CS.InterHard.Att.Measure.EcN0
ZTE C310332643 Mob.Cell.PS.InterHard.Succ.Measure.DlPower
ZTE C310332644 Mob.Cell.PS.InterHard.Succ.Measure.UlInterference
ZTE C310332645 Mob.Cell.PS.InterHard.Succ.Measure.UlCapacity
ZTE C310332646 Mob.Cell.PS.InterHard.Succ.Measure.DlCapacity
ZTE C310332641 Mob.Cell.PS.InterHard.Succ.Measure.RSCP
ZTE C310332642 Mob.Cell.PS.InterHard.Succ.Measure.EcN0
ZTE C310332632 Mob.Cell.PS.InterHard.Att.Measure.DlPower
ZTE C310332633 Mob.Cell.PS.InterHard.Att.Measure.UlInterference
ZTE C310332634 Mob.Cell.PS.InterHard.Att.Measure.UlCapacity
ZTE C310332635 Mob.Cell.PS.InterHard.Att.Measure.DlCapacity
ZTE C310332630 Mob.Cell.PS.InterHard.Att.Measure.RSCP
ZTE C310332631 Mob.Cell.PS.InterHard.Att.Measure.EcN0
ZTE C310352945 Mob.Cell.Cs.InterRat.Out.Att
ZTE C310352946 Mob.Cell.Cs.InterRat.Out.Fail.Cause.ConfNotSupp
ZTE C310352947 Mob.Cell.Cs.InterRat.Out.Fail.Cause.PhyChFail
ZTE C310352948 Mob.Cell.Cs.InterRat.Out.Fail.Cause.ProtoErr
ZTE C310352949 Mob.Cell.Cs.InterRat.Out.Fail.Cause.InterRatProtoErr
ZTE C310352950 Mob.Cell.Cs.InterRat.Out.Fail.Cause.Misc
ZTE C310352951 Mob.Cell.Cs.InterRat.Out.Fail.Cause.TimeOut
ZTE C310352945 Mob.Cell.Cs.InterRat.Out.Att
ZTE C310352952 Mob.Cell.PS.InterRat.Out.Att
ZTE C310352959 Mob.Cell.PS.InterRat.Cco.Out.Att
ZTE C310352952 Mob.Cell.PS.InterRat.Out.Att
ZTE C310352959 Mob.Cell.PS.InterRat.Cco.Out.Att
ZTE C310352953 Mob.Cell.PS.InterRat.Out.Fail.Cause.ConfNotSupp
ZTE C310352954 Mob.Cell.PS.InterRat.Out.Fail.Cause.PhyChFail
ZTE C310352955 Mob.Cell.PS.InterRat.Out.Fail.Cause.ProtoErr
ZTE C310352956 Mob.Cell.PS.InterRat.Out.Fail.Cause.InterRatProtoErr
ZTE C310352957 Mob.Cell.PS.InterRat.Out.Fail.Cause.Misc
68
ZTE C310352958 Mob.Cell.PS.InterRat.Out.Fail.Cause.TimeOut

ZTE C310352960 Mob.Cell.PS.InterRat.Cco.out.Fail.Cause.ConfNotSupp
ZTE C310352961 Mob.Cell.PS.InterRat.Cco.out.Fail.Cause.PhyChFail
ZTE C310352962 Mob.Cell.PS.InterRat.Cco.out.Fail.Cause.ProtoErr
ZTE C310352963 Mob.Cell.PS.InterRat.Cco.out.Fail.Cause.Misc
ZTE C310352964 Mob.Cell.PS.InterRat.Cco.out.Fail.Cause.TimeOut
69

KPI Document - MN Performance

Uploaded by

Document Information

Copyright

Available Formats

Share this document

Share or Embed Document

Sharing Options

Did you find this document useful?

Is this content inappropriate?

Copyright:

Available Formats

KPI Document - MN Performance

Uploaded by

Copyright:

Available Formats

Etisalat Group

Mobile Network Key Performance Indicators

4.1.6 TCH Assignment Success....................................................................................................... 18

5.2.4 PS Traffic Volume DL R99 (GB).............................................................................................. 35

KPI Formulae Difference in Calculations Main Remarks

Tech KPI Remarks

2G CSSR  SDCCH Access should not be considered due to SDCCH

2G HO  HO success rate is calculated as Outgoing HO Success Rate

2G TCH Drop  2 Formulae are used by vendors:

2G TBF Drop  ALU calculates the drops as the difference between

2G Data  An agreement has to be set for converting bytes to KB, MB,

3G CS Drop  To be counted on cell level and not on RNC level

3G CS & PS  Should include DL & UL power, code and channel element

3G PS Drop  Cell PCH formulae has to be agreed with all vendors.

3G Traffic  Cell level and not RNC level

2.1 GSM Network

2.1.1 Call Setup Success Rate

KPI Name Call Setup Success Rate

2.1.2 Traffic Drop Rate

KPI Name TCH Drop Rate

2.1.3 Traffic Congestion Rate

KPI Name TCH Congestion Rate

2.1.4 Signaling Drop Rate

KPI Name SDCCH Drop Rate

2.1.5 Signaling Congestion Rate

KPI Name SDCCH Congestion Rate

2.1.6 Handover Success Rate

KPI Name Handover Success Rate

2.1.7 Voice Traffic Volume

KPI Name RTCH Erlang

2.2.1 TBF Establishment Success Rate

KPI Name TBF Establishment Success Rate

2.2.2 TBF Congestion Rate

KPI Name TBF Congestion Rate

2.2.3 TBF Drop Rate

KPI Name TBF Drop Rate

2.2.4 Data Traffic Volume (GB)

KPI Name Data Traffic (GB)

3.1 Circuit Switched (CS)

3.1.1 RRC Setup Success Rate

KPI Name RRC Setup Success Rate

Comments a) RRC setup success rate for all types of requests.

3.1.2 RRC Congestion Rate

KPI Name RRC Congestion Rate

3.1.3 CS RAB Setup Success Rate

KPI Name CS RAB Setup Success Rate

3.1.4 CS RAB Congestion Rate

KPI Name CS RAB Congestion Rate

3.1.5 CS Service Drop Rate

KPI Name CS RAB Congestion Rate

3.1.6 Soft Handover Success Rate

KPI Name CS RAB Congestion Rate

3.1.7 Hard Handover Success Rate

KPI Name CS RAB Congestion Rate

3.1.8 Inter-RAT Handover Success Rate

KPI Name CS RAB Congestion Rate

Formulae CS Successful Inter-RAT Handovers/CS Inter-RAT Handover Attempts

KPI Name CS RAB Congestion Rate

3.2 Packet Switched (PS)

3.2.1 PS RAB Setup Success Rate

KPI Name PS RAB Setup Success Rate

3.2.2 PS RAB Drop Rate

KPI Name PS RAB Drop Rate

3.2.3 PS Traffic (GB)
