Applied Geostatistics in R:1. Naive Bayes Classi-
fier for Lithofacies Modeling in a Sandstone For-
mation
Watheq J. Al-Mudhafar
Craft & Hawkins Department of Petroleum Engineering, Louisiana
State University
August 1, 2015
Naive Bayes Classifier (NBC) is bayesian algorithm that is used to compute the
conditional posterior probabilities of a categorical class variable (Lithofacies)
given independent predictor variables (core and well logs data) using the Bayes
rule.
NBC was adopted here to model the Lithofacies given core analysis and well
logs data from Karpur Dataset:
Install the packages required to implement NBC algorithm with their functions.

## Loading required package: e1071

## Loading required package: MASS
## depth caliper ind.deep ind.med gamma phi.N R.deep R.med SP
## 1 5667.0 8.685 618.005 569.781 98.823 0.410 1.618 1.755 -56.587
## 2 5667.5 8.686 497.547 419.494 90.640 0.307 2.010 2.384 -61.916
## 3 5668.0 8.686 384.935 300.155 78.087 0.203 2.598 3.332 -55.861
## 4 5668.5 8.686 278.324 205.224 66.232 0.119 3.593 4.873 -41.860
## 5 5669.0 8.686 183.743 131.155 59.807 0.069 5.442 7.625 -34.934
## 6 5669.5 8.686 109.512 75.633 57.109 0.048 9.131 13.222 -39.769
## density.corr density phi.core k.core Facies
## 1 -0.033 2.205 33.9000 2442.590 F1
## 2 -0.067 2.040 33.4131 3006.989 F1
## 3 -0.064 1.888 33.1000 3370.000 F1
## 4 -0.053 1.794 34.9000 2270.000 F1
## 5 -0.054 1.758 35.0644 2530.758 F1
## 6 -0.058 1.759 35.3152 2928.314 F1

1
Relationships between Lithofacies and Well Logs & Core Data

depth ind.deep gamma R.deep SP density k.core

2
 Boxplots of the Observed Eight Lithofacies

6000
5900
Depth

5800
5700

F1 F10 F2 F3 F5 F7 F8 F9

Facies

## [1] F10 F3 F3 F1 F1 F1 F1 F1 F1 F1
## Levels: F1 F10 F2 F3 F5 F7 F8 F9

3
 Boxplots of the Predicted Eight Lithofacies

6000
5900
Depth

5800
5700

F1 F10 F2 F3 F5 F7 F8 F9

Facies

##
## pred F1 F10 F2 F3 F5 F7 F8 F9
## F1 107 3 0 0 0 0 0 0
## F10 1 143 0 28 2 0 0 0
## F2 1 1 8 0 0 0 0 0
## F3 2 20 0 26 1 0 0 0
## F5 0 1 0 1 100 0 4 2
## F7 0 2 0 0 0 9 3 0
## F8 0 1 0 0 0 0 171 0
## F9 0 0 0 0 6 0 6 170
## F1 F10 F2 F3 F5 F7 F8
## 0.9727273 0.8218391 0.8000000 0.5306122 0.9259259 0.6428571 0.9941860
## F9
## 0.9340659
## [1] 0.8962149

4
 Posterior Facies Distribution of Facies Type 1

5700
5800
Depth

5900
6000

0.0 0.2 0.4 0.6 0.8 1.0

Posterior Distribution

5
 Posterior Facies Distribution of Facies Type 2

5700
5800
Depth

5900
6000

0.0 0.2 0.4 0.6 0.8 1.0

Posterior Distribution

6
 Posterior Facies Distribution of Facies Type 3

5700
5800
Depth

5900
6000

0.0 0.2 0.4 0.6 0.8 1.0

Posterior Distribution

7
 Posterior Facies Distribution of Facies Type 4

5700
5800
Depth

5900
6000

0.0 0.2 0.4 0.6 0.8 1.0

Posterior Distribution

8
 Posterior Facies Distribution of Facies Type 5

5700
5800
Depth

5900
6000

0.0 0.2 0.4 0.6 0.8 1.0

Posterior Distribution

9
 Posterior Facies Distribution of Facies Type 6

5700
5800
Depth

5900
6000

0.0 0.2 0.4 0.6 0.8 1.0

Posterior Distribution

10
 Posterior Facies Distribution of Facies Type 7

5700
5800
Depth

5900
6000

0.0 0.2 0.4 0.6 0.8 1.0

Posterior Distribution

11
 Posterior Facies Distribution of Facies Type 8

5700
5800
Depth

5900
6000

0.0 0.2 0.4 0.6 0.8 1.0

Posterior Distribution

12
 Posterior Facies Distribution of the Eight Facies

5700
5800
Depth

5900
6000

0.0 0.2 0.4 0.6 0.8 1.0

Posterior Distribution

References
1. Murphy, K. P. (2006). Naive bayes classifiers. University of British
Columbia.
2. Karpur, L., L. Lake, and K. Sepehrnoori. (2000). Probability Logs for
Facies Classification. In Situ 24(1): 57.
3. Al-Mudhafer, W. J. (2014). Multinomial Logistic Regression for Bayesian
Estimation of Vertical Facies Modeling in Heterogeneous Sandstone Reservoirs.
Offshore Technology Conference. doi:10.4043/24732-MS.
4. Al-Mudhafar, W. J. (2015). Integrating Component Analysis & Classifi-
cation Techniques for Comparative Prediction of Continuous & Discrete Litho-
facies Distributions. Offshore Technology Conference. doi:10.4043/25806-MS.
