CCIE Security: 350-018

High Availability Solution

 High Availability Solution

❖ Information about High Availability

This chapter provides an overview of the failover features that enable you to achieve high availability
on the Cisco 5500 series adaptive security appliances.

❖ About Failover and High Availability with Firewall

Failover definition: - Failover is a backup operational mode in which the functions of a system
component (such as a processor, server, network, or database, for example) are assumed by secondary
system components when the primary component becomes unavailable through either failure or
scheduled down time.
This can be operated in a redundant manner or in a standby operational mode upon the failure of a
primary server.

Purpose: - The main purpose of failover is to eliminate, or at least reduce, the impact on users when a
system failure occurs.

❖ There are three scenarios with ASA firewall where Failover can occur
1. Interface level Redundancy.
2. ISP Level Redundancy.
3. Hardware Level Redundancy.
a. Active Standby Failover
b. Active Active Failover

❖ Terms of High Availability

Role: - Active/standby (can change)
Priority: - Primary/ secondary (Fix)

1
1. Interface Level Redundancy= Here we use multiple interfaces where 1 interface is active
and other remains standby. If active goes down standby becomes active.

2
 1. Interface level Redundancy

!ON R1 !ON R2
en en
conf t conf t
int f0/0 int f 0/0
ip add 10.11.11.1 255.255.255.0 ip add 192.1.20.2 255.255.255.0
no sh no sh
exit exit
ip route 0.0.0.0 0.0.0.0 10.11.11.10 ip route 0.0.0.0 0.0.0.0 192.1.20.10
! !
!ON R3
en
conf t
int f0/0
ip add 192.168.30.3 255.255.255.0
no sh
exit
ip route 0.0.0.0 0.0.0.0 192.168.30.10
!

3
!ON ASA VERIFICATION:-
conf t Show interface ip brief
hostname ASA
!1. Bring up the physical interfaces show interface = output
int e0 Interface Ethernet0 "", is up, line protocol is up
no shut Hardware is i82559, BW 100 Mbps, DLY 100 usec
exi Auto-Duplex(Full-duplex), Auto-Speed(100
int e1 Mbps)
no shut Active member of Redundant1
exi MAC address 00ab.bffb.c400, MTU not set
IP address unassigned
!2. Create a Redundant interface 32 packets input, 0 bytes, 0 no buffer
Received 2 broadcasts, 0 runts, 0 giants
interface redundant 1
member-interface e0 Interface Ethernet1 "", is up, line protocol is up
member-interface e1 Hardware is i82559, BW 100 Mbps, DLY 100 usec
nameif inside Auto-Duplex(Full-duplex), Auto-Speed(100
ip add 10.11.11.10 255.255.255.0 Mbps)
exit Standby member of Redundant1
! MAC address 00ab.bffb.c401, MTU not set
redundant-interface redundant 1 active-member e1 IP address unassigned
! 18 packets input, 0 bytes, 0 no buffer
Int e2 Received 2 broadcasts, 0 runts, 0 giants
Nameif outside
Ip add 192.1.20.10 show run interface redundant 1
No sh !
Exit interface Redundant1
! member-interface Ethernet0
Int e3 member-interface Ethernet1
Nameif dmz nameif inside
Security-50 security-level 100
Ip add 192.168.30.10 ip address 10.11.11.10 255.255.255.0
No sh From R1 ping R2
Exit Now shutdown E1 interface of ASA and ping from
! R1 to R2 & do show interface and check above
sho interface outputs
show run interface redundant 1
sho int ip bri

NOTE: If interface E1 goes down E0 becomes Active & when E1 comes up it remains in standby till E0 goes
down

4
 Compression between both interfaces. Here E1 interface is down and E0 is active
ASA(config)# sh interface
Interface Ethernet0 "", is up, line protocol is up
Hardware is i82559, BW 100 Mbps, DLY 100 usec
Auto-Duplex(Full-duplex), Auto-Speed(100 Mbps)
Standby member of Redundant1
MAC address 00ab.bffb.c401, MTU not set
IP address unassigned
1 packets input, 128 bytes, 0 no buffer
Received 3 broadcasts, 0 runts, 0 giants
0 input errors, 0 CRC, 0 frame, 0 overrun, 0 ignored, 0 abort
1 L2 decode drops
0 packets output, 64 bytes, 0 underruns
0 output errors, 0 collisions, 0 interface resets
0 babbles, 0 late collisions, 0 deferred
0 lost carrier, 0 no carrier
input queue (curr/max packets): hardware (0/1) software (0/2)
output queue (curr/max packets): hardware (0/1) software
(0/1)
Interface Ethernet1 "", is up, line protocol is up
Hardware is i82559, BW 100 Mbps, DLY 100 usec
Auto-Duplex(Full-duplex), Auto-Speed(100 Mbps)
Active member of Redundant1
MAC address 00ab.bffb.c400, MTU not set
IP address unassigned
0 packets input, 192 bytes, 0 no buffer
Received 3 broadcasts, 0 runts, 0 giants
0 input errors, 0 CRC, 0 frame, 0 overrun, 0 ignored, 0 abort
3 L2 decode drops
1 packets output, 0 bytes, 0 underruns
0 output errors, 0 collisions, 0 interface resets
0 babbles, 0 late collisions, 0 deferred
0 lost carrier, 0 no carrier
input queue (curr/max packets): hardware (0/1) software (0/2)
output queue (curr/max packets): hardware (0/2) software (0/1)
ASA(config-if)# sh interface
Interface Ethernet0 "", is up, line protocol is up
Hardware is i82559, BW 100 Mbps, DLY 100 usec
Auto-Duplex(Full-duplex), Auto-Speed(100 Mbps)
Active member of Redundant1
MAC address 00ab.bffb.c400, MTU not set
IP address unassigned
1 packets input, 128 bytes, 0 no buffer
Received 3 broadcasts, 0 runts, 0 giants
0 input errors, 0 CRC, 0 frame, 0 overrun, 0 ignored, 0 abort
1 L2 decode drops
1 packets output, 64 bytes, 0 underruns
0 output errors, 0 collisions, 0 interface resets
0 babbles, 0 late collisions, 0 deferred
0 lost carrier, 0 no carrier
input queue (curr/max packets): hardware (0/1) software (0/2)
output queue (curr/max packets): hardware (0/2) software
(0/1)
Interface Ethernet1 "", is administratively down, line protocol is up
Hardware is i82559, BW 100 Mbps, DLY 100 usec
Auto-Duplex(Full-duplex), Auto-Speed(100 Mbps)
Standby member of Redundant1
MAC address 00ab.bffb.c401, MTU not set
IP address unassigned
1 packets input, 192 bytes, 0 no buffer
Received 3 broadcasts, 0 runts, 0 giants
0 input errors, 0 CRC, 0 frame, 0 overrun, 0 ignored, 0 abort
3 L2 decode drops
1 packets output, 0 bytes, 0 underruns
0 output errors, 0 collisions, 0 interface resets
0 babbles, 0 late collisions, 0 deferred
0 lost carrier, 0 no carrier
input queue (curr/max packets): hardware (0/1) software (0/2)
output queue (curr/max packets): hardware (1/2) software
(0/1)
5
Physical Topology

Logical Topology

6
ISP Level Redundancy
!on R1 !ON R2
en EN
conf t conf t
int f 0/0 int f0/0
ip add 10.12.12.1 255.255.255.0 ip add 130.12.12.2 255.255.255.0
no sh no sh
exit exit
ip route 0.0.0.0 0.0.0.0 10.12.12.10 int f 0/1
! ip add 124.4.4.2 255.255.255.0
no sh
exit
ip route 4.2.2.0 255.255.255.0 124.4.4.4
ip route 10.12.12.0 255.255.255.0 130.12.12.10
!
!ON R3 !ON R4
en en
conf t conf t
int f 0/0 int f0/0
ip add 150.10.10.3 255.255.255.0 ip add 124.4.4.4 255.255.255.0
no sh no sh
exit int f0/1
int f0/1 ip add 134.4.4.4 255.255.255.0
ip add 134.4.4.3 255.255.255.0 no sh
no sh exit
exit int loo 1
ip route 4.2.2.0 255.255.255.0 134.4.4.4 ip add 4.2.2.2 255.255.255.0
! exi
!
ip route 130.12.12.0 255.255.255.0 124.4.4.2
ip route 150.10.10.0 255.255.255.0 134.4.4.3
!
!ON ASA Verification:-
int e1 ASA# ping 4.2.2.2
nameif inside
ip add 10.12.12.10 255.255.255.0 Shutdown interface e2 and
no sh ASA# ping 4.2.2.2
exit
int e2 Use traceroute command to check different paths.
nameif outside
ip add 130.12.12.10 255.255.255.0
no sh
exit
int e3
nameif backup
ip add 150.10.10.10 255.255.255.0
no sh
exit
route outside 0 0 130.12.12.2
route backup 0 0 150.10.10.3 2
!
7
 sla monitor 1
type echo protocol ipIcmpEcho 4.2.2.2 interface outside
timeout 3
frequency 5
exit
!
sla monitor schedule 1 life forever start-time now
!
track 2 rtr 1 reachability
route outside 0 0 130.12.12.2 track 2
!
Note:- After using track command firewall will keep on tracking 4.2.2.2 VIA outside interface.
R4 will receive icmp echo packet in every 5 seconds

!R4
R4#debug ip icmp

!ON ASA
Check Route & traffic must be passing through outside interface.

Verification:-
8
!ON R2
now "shut" int f0/1 of R2
Note:- R4 will stop receiving ICMP packets from ASA,

from ASA
ping 4.2.2.2
it should ping with backup route
if backup route is not being installed remove
no route outside 0.0.0.0 0.0.0.0 130.12.12.1 1
Than try. it is due to frequency and time delay
Route is not getting switched instantly.

ASA#show track
ASA#sh sla monitor operational-state 2
