V8000 SERIES
TECHNICAL MANUAL
VERSION
FEBRUARY 2002
CONTENTS
CHAPTER 1: MAINTENANCE
1. Preface ...................................................................................................................... 1-2
CAUTION ................................................................................................................... 1-3
WARNING ................................................................................................................. 1-4
2. Work Precautions ..................................................................................................... 1-5
3. JIGs ........................................................................................................................... 1-8
4. Installation Procedure ............................................................................................ 1-11
5. Leveling the Machine on the Floor ......................................................................... 1-15
6. Exterior Cover Removal ......................................................................................... 1-19
[Contents - 1]
Next Page
CONTENTS
Page Before
[Contents - 2]
Next Page
CONTENTS
Page Before
[Contents - 3]
Next Page
CONTENTS
Page Before
[Contents - 4]
Next Page
CONTENTS
Page Before
[Contents - 5]
Next Page
CONTENTS
Page Before
[Contents - 6]
Next Page
CONTENTS
Page Before
[Contents - 7]
Next Page
CONTENTS
Page Before
[Contents - 8]
Next Page
CONTENTS
D01 D02 D03 D04 D05 D07 D09 D10 D11 D13 D16 D17
D18 D19 D20 D22 D23 D24 D25 D26 D27 D28 D29 D30
E01 E02 E03
F01 F02 F03 F04 F05 F06 F10 F14 F23 F25 F27 F28
F30 F32 F35 F36 F37
G001 G002 G004 G008 G016
4. Errors Requiring Special Action .......................................................................... 16-36
Page Before
[Contents - 9]
Next Page
CONTENTS
Page Before
[Contents - 10]
CHAPTER 1: MAINTENANCE
Contents
[1 - 1]
CHAPTER 1. MAINTENANCE
1. Preface
This manual provides Technical Service Information for model V8000 series.
This manual also provides procedures for removing and installing major components. Following these
procedures will minimize machine malfunctions. The information will also increase technical represen-
tatives' awareness and experience regarding repairs necessary to insure end-user satisfaction.
[1 - 2]
CHAPTER 1. MAINTENANCE
CAUTION
- Never fail to follow the following instructions when you discard the used
lithium battery.
[1 - 3]
CHAPTER 1. MAINTENANCE
!! WARNING !!
I. To avoid injuries:
Be sure to disconnect the electrical power before disassembling, assembling,or when
making adjustments on the machine.
2. WARNING:
The back light tube of LCD of the Control Panel on this Model,
contains mercury which must be recycled or disposed of as hazardous waste.
FIRST
THEN
[1 - 4]
CHAPTER 1. MAINTENANCE
2. Work Precautions
Inspection
If you discover any defects or problems during an inspection, fix the problems or if necessary take
steps such as replacing a part.
Removal
Check the problem area. At the same time, examine the cause of the problem and determine
whether the part needs to be removed or disassembled. Next proceed according to the proce-
dures presented in the Technical Manual. In cases where, for example, it is necessary to disas-
semble areas with large numbers of parts, parts which are similar to each other, or parts which are
the same on the left and right, sort the parts so that you do not mix them up during reassembly.
(1) Carefully sort the removed parts.
(2) Distinguish between parts which are being replaced and those which will be reused.
(3) When replacing screws, etc., be sure to use the
specified sizes.
Assembly and Installation
Unless specified otherwise, perform the removal proce-
dures in reverse during assembly and installation. In
cases where protrusions or holes are provided to assist
in positioning parts, use them for accurate positioning
and securing.
(Protrusions and holes for positioning parts Half
pierce section)
Tools
Using tools other than those specified can lead to injury
or damage screws and parts. Have all the tools neces-
sary for the work available.
[1 - 5]
CHAPTER 1. MAINTENANCE
Sensor types
• Photo-electric sensors may be broadly
divided into the following four types: in-
terrupt types (U-shaped), actuator types,
reflective types, and transmittive types.
• Magnetic sensors use Hall ICs, which re-
act to the magnetic force in magnets.
• Always turn off the power before plugging
or unplugging sensor connectors.
Switch types
• Microswitches may be divided between nor-
mally open (NO) types and normally closed
(NC) types.
With an NO connection, an internal con-
tact is connected when the switch actua-
tor is pressed.
With an NC connection, an internal con-
tact is disconnected when the switch ac-
tuator is pressed.
• Magnetic lead switches are switches in
which an internal contact is connected
in reaction to the magnetic force of a
magnet.
[1 - 6]
CHAPTER 1. MAINTENANCE
Installation location
• Do not install the machine in any of the following locations.
(1) Those subject to direct sunlight or any bright location such as by a window (If you must
install in such a location, put a curtain or the like over the window.)
(2) Those where the temperature changes drastically
(3) Those that are too hot, cold, humid, or dry
RECOMMENDED:
Temperature range: 15° centigrade - 30° centigrade
Humidity range: 40% - 70% No condensation allowed
(4) Those with radiant heat sources and any locations in the direct path of air from air condition-
ers, heaters
(5) Any poorly ventilated location
(6) Dusty atmosphere
(7) Any tilted location
(Levelness of the floor: Within 2 degrees incline, and within 3mm difference in floor height.)
Electrical connection
• Plug the plug securely into the socket so that there is no problem with the contact in the power
supply plug section.
• Do not use any triplets or extension cords.
• Do not allow any other machine to stand on or crush the power cord.
Ground connection
• Always ground this machine to prevent electrical shock in the unlikely event of electrical
leakage.
[1 - 7]
CHAPTER 1. MAINTENANCE
3. JIGs
S0101 S0102
016-16141-003
022-18401-000
8 mm dia. x 160 mm shaft (JIG)
14 mm diameter long-shaft (JIG)
(2 pieces required)
S0103 S0104
022-18402-006 022-76001-003
8 mm diameter long-shaft (JIG) Squeegee Gap Adjustment Shaft (JIG)
S0105 S0106
015-36311-005 022-16714-000
Squeegee Gap Gauge (JIG) Drum Manual Rotation Knob
[1 - 8]
CHAPTER 1. MAINTENANCE
S0108
S0107
022-76002-000
Drum Joint Alignment Lock (JIG)
022-76003-006
Drum Stand (JIG)
P0109
018-16255-208
Blance Weight; FB
Three pieces of the part is formed into
one unit, with one of the weight facing
the other way
P0110
030-90010-050
LED Unit
S0111
Instructions for using the “LED Unit”
1. Remove the Rear Cover.
2. Plug the connector of the LED Unit into connector “CN20” of the MCTL PCB.
3. Choose the display sheet for V8000 on the LED Unit.
4. Look at the LED display of the LED Unit to check the condition of the machine.
[1 - 9]
CHAPTER 1. MAINTENANCE
022-75000-054
Leveling jig
P0128
[1 - 10]
CHAPTER 1. MAINTENANCE
Front door R
Front door R
Rail
[1 - 11]
CHAPTER 1. MAINTENANCE
Side cover
[1 - 12]
CHAPTER 1. MAINTENANCE
[1 - 13]
CHAPTER 1. MAINTENANCE
Blind seal
18. Lock the casters.
[1 - 14]
CHAPTER 1. MAINTENANCE
Leveling jig
P0129
TOUCH
P0130
[1 - 15]
CHAPTER 1. MAINTENANCE
(4) Look at the scale straight at right angle and read the line on the scale to which the string points to.
Note: Incorrect reading of the scale will be made if the scale is viewed at an angle. The view must be
made at 90 degrees against the scale.
P0132 P0133
< String in front of the scale > < String at back of the scale >
< The string should hang free from the plate and scale, eigher in front or back of the scale >
Operation panel
Operation panel
P0134
P0135
[1 - 16]
CHAPTER 1. MAINTENANCE
(6) Lift the Operation Panel gently upwards a little and slide it towards the front to allow the top thin
surface of the machine frame to appear.
(7) Remove the Leveling jig from the rear machine frame and mount it on the front machine frame in the
same manner as done on the rear machine frame.
(8) Read the scale at the bottom of the jig in the same way as done for the rear of the machine.
(9) The difference in the scale reading between the rear and front should be within 0.5 mm.
P0136
P0137
[1 - 17]
CHAPTER 1. MAINTENANCE
(10) If the difference is more than 0.5 mm between the front and rear, attach two Height adjusters under
the front of the machine, firmly against the bracket of the two casters on the machine. The Height
adjusters need not be placed on the rear of the machine.
(11) Rotate either one of both of the Height adjusters to raise the machine until the rear and front of the
machine is leveled (the difference in the scale reading is within 0.5 mm between the front and rear).
The Height adjuster is raised or lowered by turning the bottom nut.
(12) After adjusting the levelness, lock the position by turning and bringing the center nut tightly against
the top nut.
S0113
Caster
Height adjuster
Height adjuster
Caster
S0114
[1 - 18]
CHAPTER 1. MAINTENANCE
Rear cover
P0112
[1 - 19]
CHAPTER 1. MAINTENANCE
P0113
P0114
P0115 P0116
[1 - 20]
CHAPTER 1. MAINTENANCE
P0117
P0118
[1 - 21]
CHAPTER 1. MAINTENANCE
FB left cover
P0119
[1 - 22]
CHAPTER 1. MAINTENANCE
F cover R
Rear right cover
P0120
[1 - 23]
CHAPTER 1. MAINTENANCE
To remove the FB right cover, remove the FB lock plate front and FB safety SW Assy, slide the scanner
table in the reverse direction, and remove the hidden screws.
P0121 P0122
P0123
To remove the FB right and FB front covers, slide the scanner table, insert a screwdriver through the hole
marked by the arrow in the picture, and remove the screws.
P0125
P0124
[1 - 24]
CHAPTER 1. MAINTENANCE
P0126
FB front cover
P0127
[1 - 25]
CHAPTER 2: MACHINE OVERVIEW
Contents
[2 - 1]
CHAPTER 2. MACHINE OVERVIEW
1. Features
Simultaneously prints two colors at speeds up to 120 sheets per minute.
The RISO V8000 uses its screen printing system to achieve both speed and economy in printing.
The two print drums print simultaneously for easy two-color printing at speeds of 120 sheets per
minute. Per page printing costs are even lower with greater print quantities. The cost of printing 1,000
copies is 173 yen, or approximately 0.17 yen per print.
High print quality with 600 dpi high resolution and V-Press
The machine incorporates a “V-Press” configuration, with two print drums arranged in a V-shape
relative to the paper drum, for outstanding print quality and precise print positioning. Pressure is
applied from each print drum to the paper drum, which retains precise, positive control of paper
position to the ejection stage by gripping the ends of the paper, ensuring the precise print positioning
required for two-color printing. The machine incorporates Riso Kagaku’s extensive experience with
high-quality image output, with variable pressure print drums capable of fine control of ink density and
600 dpi resolution.
[2 - 2]
CHAPTER 2. MACHINE OVERVIEW
Specifications
Processing Automatic digital scanning/thermal screening, high-speed twin-cylinder (drum) dual-color
printing system
Initial Imaging Time Letter or A4 original : approx. 90 sec.
Print Speed 5 selectable levels (60 to 120 copies/min.)
Scanning Resolution 600 x 600 dpi
Original Input Type Bound document or sheets
Original Size - For the Stage Glass
2" x 31/2" (50 x 90 mm) to 115/8" x 17" (Ledger, A3, or 297 x 432 mm)
- In the optional AF Unit
4" x 57/8" (A6 or 100 x 148 mm) to 115/8" x 17" (Ledger, A3, or 297 x 432 mm)
Output Paper Size 3 /2" x 51/2" (90 x 140 mm) to 133/8" x 173/8" (340 x 440 mm)
1
[2 - 3]
CHAPTER 2. MACHINE OVERVIEW
3. Product Configuration
1. Main unit
RISO V8000
2. Accessories
• Operating instruction manual x1
• Printer driver CD-ROM x1
• Power cable x1
3. Optional items
• AF unit VI
• Digitizer V
• Digitizer V; AF
• Inkless print drum (with case)
• Card counter IV
• Job separator IV
• RISORINC-NET-B
4. Consumable items
• RISO master V type (1 roll, approx. 200 masters)
• RISO ink V type (black)
• RISO ink V type (color)
[2 - 4]
CHAPTER 2. MACHINE OVERVIEW
S0201
[2 - 5]
CHAPTER 2. MACHINE OVERVIEW
MEMO
[2 - 6]
CHAPTER 3: MAIN DRIVE SECTION
Contents
[3 - 1]
CHAPTER 3. MAIN DRIVE SECTION
Mechanism
1. Main Drive Section Rotating Mechanism
The print drum and paper drum are rotated for normal use by the main motor. The main motor limit
sensor (encoder sensor) detects the main motor speed and the amount of rotation and verifies stable
motor operations.
The free rotation of the main motor can be controlled using the switch on the mechanical control PCB.
The main pulse motor is used when ultra-low-speed rotation of the print drum or paper drum is required,
for applications such as corrections for master loading or the print drum stop position, in which case the
main clutch is applied. When the main motor is used to drive the print drum or paper drum, the main
clutch is released to remove the load from the main pulse motor.
The following parts are driven by the main motor via gears and cams.
Paper drum: Paper drum rotation and opening/closing of sheet gripper
Print drum: Print drum rotation, and vertical movement and rotation of inner pressure
roller
First paper feed section: Rotation of pickup roller and scraper, and air pump operation
Second paper feed section: Rotation of timing roller, vertical movement of guide roller, and vertical
movement of paper feed variable guide.
Intermediate gear
Guide gear
[3 - 2]
CHAPTER 3. MAIN DRIVE SECTION
P0302
Main motor
P0303
[3 - 3]
CHAPTER 3. MAIN DRIVE SECTION
The following will stop when any one of above safety switch activates.
- Clamp slide motors 1 & 2
- Clamp opening and closing motors 1 & 2
- Master tail clamp fan
- Print positioning pulse motor
- Master compression motor
- Disposal plate motor
- Paper ejection motor
- Pinch pulse motor
- Master making unit slide motor
- Main motor
- Pinch roller release motor (This motor stops only with the activation of Paper ejection unit safety switch).
P0304 P0305
Master disposal box 1 safety switch Master disposal box 2 safety switch
[3 - 4]
CHAPTER 3. MAIN DRIVE SECTION
P0306
P0324
P0307 P0308
Front door safety switch (Right) Front door safety switch (Left)
[3 - 5]
CHAPTER 3. MAIN DRIVE SECTION
[3 - 6]
CHAPTER 3. MAIN DRIVE SECTION
Disassembly
1. Removing the Main Cover Ass’y
(1) Remove the reuse band on the position T sensor wire harness and disconnect the position T sensor
connector.
(2) Detach the wire harness from the wire saddle.
(3) Remove the eight mounting screws (M4 x 8), then remove the main cover ass’y.
Position T sensor
P0309
[3 - 7]
CHAPTER 3. MAIN DRIVE SECTION
SH-PCB + graphic
board
P0310 P0311
Blind plate
Sector gear
P0312
[3 - 8]
CHAPTER 3. MAIN DRIVE SECTION
Reinforcing plate
P0313
Guide gear
Guide lever spring
P0314
Intermediate gear
Guide gear
P0315
[3 - 9]
CHAPTER 3. MAIN DRIVE SECTION
Paper drum gear Position of the air pump when fixing the pump gear in position.
P0317
Intermediate gear
S0316
P0318
P0320
P0319
Guide gear
Parallel pin
P0322
P0321
Pump gear
[Work Precautions]
• The connector on the motor power supply cable is fitted with a lock. This should be released before
disconnecting.
• The main motor is extremely heavy. Work carefully to prevent injuries.
Signal cable
P0323
[3 - 11]
CHAPTER 3. MAIN DRIVE SECTION
MEMO
[3 - 12]
CHAPTER 4: FIRST PAPER FEED SECTION
Contents
[4 - 1]
CHAPTER 4. FIRST PAPER FEED SECTION
Mechanism
1. Paper Feed Tray Mechanism
Dampers are fitted to both sides of the paper feed tray to ensure that it opens gently. The paper feed tray
set sensor checks that the paper feed tray is in place.
The horizontal print position is adjusted using the print drum so the paper feed tray does not move
sideways.
The paper detection sensor (reflective type) checks that paper is loaded in the paper feed tray.
The final sheet in the paper feed tray is susceptible to multiple paper feeding. The L.O. sheet is used to
prevent such occurrences.
The size of the paper loaded in the paper feed tray is detected by the paper width potentiometer and paper
size sensor.
The paper width potentiometer senses the paper width, while the paper size sensor determines the
paper orientation (portrait or landscape).
The gap between the front and rear pinch rollers on the pinch unit is adjusted automatically to suit the
paper width detected.
The correspondence between the measured size and determined size is shown in the table on next
page.
P0429
[4 - 2]
CHAPTER 4. FIRST PAPER FEED SECTION
< Damper on the operator side of the paper feed tray >
Damper
P0430
292 - 302 A3
252 - 262 B4
205 - 215 A4
177 - 187 B5
95 - 105 Postcard
[4 - 3]
CHAPTER 4. FIRST PAPER FEED SECTION
P0432
3. First Paper Feed Mechanism
The paper feed through the first and second paper feed sections is checked by the first paper sensor,
second paper sensor, and multiple paper feed sensor. The first paper sensor is located before the
second paper feed roller, while the second paper sensor and multiple paper feed sensor are located after
the second paper feed roller.
Paper is fed through the first paper feed section by the rotation of the scraper and pickup roller. The drive
side of the paper feed clutch rotates continuously while the main motor rotates, but the actual rotation of
the scraper and pickup roller is controlled by switching the paper feed clutch on and off.
The paper feed clutch is switched on at an angle of 150° from the paper drum position T.
The paper feed clutch is switched off when the paper drum has rotated 18° after paper has been detected
by the first paper sensor.
The leading edge of the paper strikes the second paper feed roller here, and stops with the paper flexed.
A one-way core is fitted to the scraper and pickup roller so that they spin, keeping the first paper feed
section from acting as a brake once the paper has been transferred beyond the second paper feed
section.
[4 - 4]
CHAPTER 4. FIRST PAPER FEED SECTION
Stripper pad
Stripper spring
Stripper-pad-angle
adjust knob
Stripper-pressure
Stripper pressure adjustment
adjust knob
S0401
[4 - 5]
CHAPTER 4. FIRST PAPER FEED SECTION
Disassembly
1. Removing the Paper Feed Cover
(1) Completely lowerhepaper feed tray.
(2) Remove the four mounting screws (M4 x 8), disconnect the connector on the paper feed tray safety
switch wire harness, and remove the paper feed cover.
* Note the position of the pressure adjust lever. Avoid applying excessive force.
P0402
P0403
[4 - 6]
CHAPTER 4. FIRST PAPER FEED SECTION
Nozzle Hose
P0404
Hose band
Pump unit
P0405
[4 - 7]
CHAPTER 4. FIRST PAPER FEED SECTION
P0406
[4 - 8]
CHAPTER 4. FIRST PAPER FEED SECTION
P0407 P0408
P0409
[4 - 9]
CHAPTER 4. FIRST PAPER FEED SECTION
P0410
Reuse band
Wire cover
Ground lead
P0411 P0412
P0413
[4 - 10]
CHAPTER 4. FIRST PAPER FEED SECTION
P0414
[4 - 11]
CHAPTER 4. FIRST PAPER FEED SECTION
P0415
[4 - 12]
CHAPTER 4. FIRST PAPER FEED SECTION
P0416
P0417
P0418 P0419
P0420
[4 - 13]
CHAPTER 4. FIRST PAPER FEED SECTION
P0421
[4 - 14]
CHAPTER 4. FIRST PAPER FEED SECTION
P0422
Shaft (center)
Shafts (front/rear)
Fence blocks
P0424
[4 - 15]
CHAPTER 4. FIRST PAPER FEED SECTION
P0425
Elevator motor
[4 - 16]
CHAPTER 4. FIRST PAPER FEED SECTION
P0427
P0426
P0428
[4 - 17]
CHAPTER 4. FIRST PAPER FEED SECTION
[Precautions on Reassembly]
• Insert the stripper unit onto the paper-guide plate while pressing the stripper pad ass’y down.
• Adjust the stripper angle and pressure if necessary.
• Adjust the Multiple Feed Switch position if necessary.
Paper-guide plate
Stripper-pad ass’y
[4 - 18]
CHAPTER 4. FIRST PAPER FEED SECTION
Stripper-pad ass’y
Stripper pad
Stripper-pad base
Stripper-pad cover
S0430
[4 - 19]
CHAPTER 4. FIRST PAPER FEED SECTION
Adjustment
1. Paper Width Potentiometer Adjustment
Check and adjustment procedure
(1) Position the paper guide fences at 100 mm and run test mode No. 450 (Paper size VR adjust
100 mm).
(2) Position the paper guide fences at 300 mm and run test mode No. 451 (Paper size VR adjust
300 mm).
(3) With the paper guide fences still at 300 mm, run test mode No. 471 (Paper width metric data),
confirming that the figure displayed is 3000 ± 10.
Symptoms
Incorrect adjustment will not allow the size of the paper in the paper feed tray to be correctly identified,
causing the machine not to function properly.
Symptoms
Positioning the elevator upper limit sensor too high increases paper feed pressure, increasing the
potential for multiple paper feeds.
Positioning the upper limit sensor too low will result in reduced paper feed pressure, increasing the
potential for paper misfeeds.
[4 - 20]
CHAPTER 4. FIRST PAPER FEED SECTION
Paper limit detection plate Insert the shaft into this hole
P0431
[4 - 21]
CHAPTER 4. FIRST PAPER FEED SECTION
4. Stripper Adjustment
[Standard machines]
Procedure
(1) Use the pressure-adjust lever to set the most suitable paper type prior to printing.
(2) If multiple feeding or misfeeding occurs, adjust the stripper-pad angle and stripper pressure.
1) Multiple feeding
• Turn the stripper-pad-angle adjust knob clockwise to increase the stripper-pad angle (raise the pad
to vertical).
• Turn the stripper-pressure adjust knob clockwise to increase the stripper pressure.
2) Misfeeding
• Turn the stripper-pad-angle adjust knob [A] counterclockwise to reduce the stripper-pad angle
(lower the pad to horizontal).
• Turn the stripper-pressure adjust knob [B] counterclockwise to reduce the stripper pressure.
Standard
Adjustable from
(24 degrees)
stripper-pad-angle 14 degrees to
adjust knob 28 degrees
Stronger
Standard
Weaker
stripper-pressure
adjust knob
Strong Weak
S0432
[4 - 22]
CHAPTER 4. FIRST PAPER FEED SECTION
Fig. a
0.8mm
to
1.2mm
ON/OFF
Fig. b
S0433
Closer
Adjusting
Screw
Further
< Viewed from bottom >
Adjusting Screw
Multiple Paper Feed Switch
Fig. c
S0434
[4 - 23]
CHAPTER 4. FIRST PAPER FEED SECTION
MEMO
[4 - 24]
CHAPTER 5: SECOND PAPER FEED SECTION
Contents
[5 - 1]
CHAPTER 5. SECOND PAPER FEED SECTION
Mechanism
1. Second Paper Feed Mechanism
The second paper feed mechanism is operated by the rotating timing roller (the guide roller rotates due to
drag torque). Rotary drive is provided by the sector gear, which in turn is driven by the timing cam.
The timing roller incorporates a one-way core that permits it to rotate when the timing gear rotates
clockwise, but not when the timing gear rotates counterclockwise. A load is applied on the timing roller by
the timing clutch and timing brake to ensure that it stops immediately when not being driven.
The timing clutch is activated at 195° from position T on the paper drum, and is deactivated at 358°.
The guide roller gear cam brings the guide roller into contact with the timing roller during the first paper
feed operation, then moves the guide roller away at the same time that the timing roller stops rotating.
Paper feed status within the second paper feed section is monitored by the 2nd paper sensor and the
multiple paper feed detection sensor.
The multiple paper feed detection sensor checks whether multiple paper feeding has occurred by
measuring the light transmissivity of the paper. Printing stops if a multiple paper feed occurs.
Light transmissivity is measured 200 times within the 35 mm to 157 mm range at the leading edge of the
paper, and a multiple paper feed is determined to have occurred if the measured value falls outside a
range equal to 75% to 150% of the mean value set by Test mode No.457.
Multiple paper feed detection is also enabled for printing with the “Test print” key.
[5 - 2]
CHAPTER 5. SECOND PAPER FEED SECTION
Disassembly
1. Removing the Paper Pass Guide
(1) Open the front door and pull out the 1st print drum.
(2) Remove the second paper feed upper cover. (Four M4 x 8 screws)
(3) Remove the 2nd paper feed sensor bracket. (M4 x 8 screw)
(4) Remove the two mounting screws (M4 x 6) and remove the paper pass guide.
P0501
P0502
[5 - 3]
CHAPTER 5. SECOND PAPER FEED SECTION
Timing clutch
P0504
Braking unit
P0506
[5 - 4]
CHAPTER 5. SECOND PAPER FEED SECTION
P0507
P0508
[5 - 5]
CHAPTER 5. SECOND PAPER FEED SECTION
P0509
Guide roller ass’y springs
P0511
[5 - 6]
CHAPTER 5. SECOND PAPER FEED SECTION
(13) Disconnect the wire harness connector, detach from the wire saddles, and remove the guide plate
lower ass’y. (Four M4 x 8 screws)
(14) Detach the E-rings and metals on both sides and remove the guide roller ass’y with the two springs
still attached.
P0512
Wire saddles
(5 locations)
P0513
[5 - 7]
CHAPTER 5. SECOND PAPER FEED SECTION
4. Removing the 1st Paper Feed Sensor, 2nd Paper Feed Sensor,
and Multiple Paper Feed Detection Sensor
P0515
P0516
P0517
[5 - 8]
CHAPTER 5. SECOND PAPER FEED SECTION
P0518
P0519
[5 - 9]
CHAPTER 5. SECOND PAPER FEED SECTION
Adjustment
1. Gap Between Timing Roller and Guide Roller
Check and adjustment procedure
(1) Rotate the paper drum until the cam on the guide roller gear is positioned as shown in the
diagram.
(2) Check that the gap between the guide roller and the timing roller is 1.0 mm ± 0.25 mm.
(3) If the gap size falls outside these specified values, loosen the guide lever ass’y lock screw and
adjust.
(One graduation on the section marked “A” on the sketch below corresponds to a gap variation
of 1 mm.)
* If the gap is too largely off from above value, it is recommended that the graduation scale, pointed
out as “A” on sketch below, is adjusted to the center line. This will bring the gap close to 1 mm.
* Make sure to readjust the “Gap between paper pass guide and lower paper guide” (given on next
page) after adjusting the gap between the timing roller and guide roller.
Timing roller
m
m
S0520 25
0.
±
m
m
0
1.
Timing roller
Guide roller
Guide roller
A
S0521
[5 - 10]
CHAPTER 5. SECOND PAPER FEED SECTION
S0522
mm
1.0 mm ± 0.5
S0523
[5 - 11]
CHAPTER 5. SECOND PAPER FEED SECTION
mm
8.5
9.5
to
A
One graduation
Paper Drum = 2° on paper drum
Printing paper = 3.7 mm on paper drum circumference
Increase feed amount
Timing roller
S0524 P0525
[5 - 12]
CHAPTER 5. SECOND PAPER FEED SECTION
Within 0.5 mm
10th Print
30th Print
30th Print
10th Print
6th Print
7th Print
8th Print
9th Print
9th Print
8th Print
7th Print
6th Print
l
Rear Front
S0526 S0527
[5 - 13]
CHAPTER 5. SECOND PAPER FEED SECTION
MEMO
[5 - 14]
CHAPTER 6: PAPER DRUM SECTION
Contents
[6 - 1]
CHAPTER 6. PAPER DRUM SECTION
Mechanism
1. Paper Drum Mechanism
For normal rotation, the paper drum is driven by the main motor; for master loading and super low speed
rotation, it is driven by the main pulse motor.
The position of the paper drum is determined by the position T sensor. The precise position of the paper
drum is confirmed by the main motor limit sensor using the position from position T sensor as a datum
position.
In standby mode after printing is complete, the stop position for the paper drum is 150° from position T.
[6 - 2]
CHAPTER 6. PAPER DRUM SECTION
Disassembly
1. Removing the Paper Drum
(1) Pull out 1st and 2nd print drums.
(2) Detach the lock ring and remove the handle.
(3) Remove the following covers.
• Front doors (left/right)
• Front cover (lower) plate
fo rcing
Rein
• Rear cover
Machine front view
• Reinforcing plate (seven M4 x 8 screws) P0649
(4) Remove the paper pass guide (see Chapter 5: Second Paper Feed Section).
(5) Pull out the paper ejection unit.
(6) Take the following steps to ensure safety and to prevent damage to components.
• Rotate the paper drum by hand to the position shown in the photograph. (Photograph 1)
• Secure the grippers and gripper cover with adhesive tape to keep them from opening. (Photograph
2)
• Secure the paper ejection separators with adhesive tape in the lowered position. (Photograph 3)
• Affix adhesive tape around the edges of the opening in the front frame plate (2nd print drum side).
(Photograph 4)
[6 - 3]
CHAPTER 6. PAPER DRUM SECTION
(7) Rotate the paper drum to insert 8 mm diameter shaft (JIG) into the main cover alignment hole and
rear paper drum gear, and lock the paper drum gear in position.
(8) Remove the paper drum lock screw (M6 x 20) in the center of the paper drum gear.
(9) Remove the gripper cover cam. (Two M4 x 14 screws)
(10) Remove the three mounting screws (M4 x 8) on shaft bearing ass’y F.
(11) Pull the paper drum forward, then disengage the paper drum shaft from the paper drum gear. Tilt the
paper drum while providing support from below, and remove by pulling through the opening in the
frame plate.
P0605
P0606 P0607
Insert a hand through this opening to
support the paper drum.
P0608 P0609
[6 - 4]
CHAPTER 6. PAPER DRUM SECTION
Coupling
P0610 P0611
[6 - 5]
CHAPTER 6. PAPER DRUM SECTION
Link spring
P0612
P0614
Gripper plate F ass’y
[6 - 6]
CHAPTER 6. PAPER DRUM SECTION
Cover stay
P0615
P0616 Gripper
Gripper cover ass’y
Gripper
A A
B B
Gripper cover ass’y
A A
B B
Gripper sheet
S0618
[6 - 7]
CHAPTER 6. PAPER DRUM SECTION
(8) Remove the 3 mm Allen wrench, which was inserted through the Link cover F ass’y by step (5).
(9) Install the gripper cover timing plate ass’y.
(10) Install the gripper cover spring and link spring.
P0619
P0620
[6 - 8]
CHAPTER 6. PAPER DRUM SECTION
P0621
3 mm Allen wrench
Adhesive tape
P0622
[6 - 9]
CHAPTER 6. PAPER DRUM SECTION
Cover stay
P0623
Link cover R
BB roller
P0624
[6 - 10]
CHAPTER 6. PAPER DRUM SECTION
(6) Remove E-ring and one screw (M3x6) to detach paper drum timing gear R ass’y from the rear of
the paper drum.
(7) Detach gripper cover shaft by removing metal shaft bearings from the front and rear of the paper
drum.
(8) Remove nine pieces of gripper springs.
(9) Remove gripper spring hook plate (four M4x8 screws).
Gripper gear
P0625
P0626 P0627
[6 - 11]
CHAPTER 6. PAPER DRUM SECTION
(10) Remove the screws holding the gripper shaft reinforcing arm. (two M4x12 screws)
(11) Remove gripper gear from the gripper shaft unit. (M3x6 screw)
(12) Remove metal shaft bearing from the rear of the gripper shaft unit.
(13) Remove E-ring and metal shaft bearing from the front of the gripper shaft unit.
(14) Squeeze the gripper collar (rubber) on the rear side of the gripper shaft unit lightly, and detach
the gripper shaft unit. (Refer to the photograph on top of next page.)
P0628
Gripper gear
P0629
[6 - 12]
CHAPTER 6. PAPER DRUM SECTION
P0631
[6 - 13]
CHAPTER 6. PAPER DRUM SECTION
(3) Mount the gripper cover shaft, together with the metal bearings on the front and rear.
The side with stepped down diameter should be for the rear side.
(4) Fix the gripper shaft reinforcing arm in position by two screws.
The top surface of the reinforcing arm should be flat with the reinforcing base, as shown
by “A” on the sketch below. The surface indicated by “B” on the sketch should also align
with each other, though may need to slide the reinforcing arm a little bit to allow smooth
movement of the gripper shaft unit and gripper cover shaft.
(5) The final position of the gripper shaft will be readjusted, if required, after running B4 size thin
papers or recycled papers. If paper wrinkle appears, especially on the tail end of the paper, the
gripper shaft reinforcing arm will need to be moved in the direction shown by the arrow mark
indicated under the alphabet “B” on the sketch.
Gripper gear
P0632
B A
S0633
[6 - 14]
CHAPTER 6. PAPER DRUM SECTION
(6) Fit the 8 mm diameter long-shaft (JIG) through the gripper plate R ass’y, paper drum side plate
(R), paper drum side pate (F), and gripper plate F ass’y.
(7) Attach paper drum timing gear R ass’y on the paper drum.
Use an available 3 mm diameter rod or 2.5 mm Allen wrench to align the elongated hole on the
paper drum timing gear R ass’y and round hole on the gripper gear to achieve correct
positioning.
Gripper gear
Allen wrench
(2.5 mm)
P0636
Gripper gear
P0637
[6 - 15]
CHAPTER 6. PAPER DRUM SECTION
(8) Mount the gripper spring hook plate, and hook the nine gripper springs.
(9) Insert the shaft of the gripper ass’y and cover stay through the holes on the gripper plate ass’y F
& R, and attach screws on both ends of the cover stay.
The shaft on the cover stay with a flat cut should go on the rear of the paper drum.
(13) Hook the paper lifter spring and link spring on the paper drum.
(14) Mount link cover R, BB roller (flat surface to face outside), and paper lifter timing plate ass’y on
the paper drum.
(15) Mount link cover F, gripper cover timing plate ass’y , and gripper cover spring on the paper drum.
Adhesive tape
P0638
P0639
[6 - 16]
CHAPTER 6. PAPER DRUM SECTION
P0640
Gripper shaft unit
Gripper base
P0641 P0642
P0643
[6 - 17]
CHAPTER 6. PAPER DRUM SECTION
P0644
P0645
[6 - 18]
CHAPTER 6. PAPER DRUM SECTION
Adjustment
1. Position T Sensor Adjustment
(1) Start up Test mode.
(2) Rotate the paper drum to position T and insert 8 mm diameter long-shaft (JIG) through the front
frame plate, paper drum, and rear frame plate, in this sequence.
(3) Run Test mode No. 503 (Position T sensor).
(4) Loosen the lock screw (M3 x 6), move the position T sensor bracket position up (in direction of arrow
in photograph), and secure at the point at which the buzzer sound changes from long beeps to short
beeps.
(5) Remove the 8 mm diameter long-shaft (JIG) and exit from the Test mode.
Paper drum
P0646 P0647
P0648
[6 - 19]
CHAPTER 6. PAPER DRUM SECTION
MEMO
[6 - 20]
CHAPTER 7: PAPER EJECTION SECTION
Contents
[7 - 1]
CHAPTER 7. PAPER EJECTION SECTION
Mechanism
1. Paper Ejection Mechanism
The paper transferred from the paper drum is ejected to the paper receiving tray, as described below.
(1) The leading edge of the paper is released from the paper drum grippers while pinched between the
paper drum and the first pinch roller.
(2) The paper is guided to the paper ejection roller by the paper ejection separators.
(3) The paper is gripped between the second pinch roller and the paper ejection roller, and is guided by
the paper ejection wings before ejected onto the paper receiving tray.
The paper ejection unit safety SW confirms that the paper ejection unit is in place on the machine. The
main motor is disabled if the paper ejection unit is not in place.
Power is supplied to the paper ejection unit via the drawer connector, and the contacts of this connector
are used to determine whether the paper ejection unit is in place. (The paper ejection unit set signal is
OFF when not in place.)
The paper ejection sensor checks that the printed paper is ejected properly.
The paper ejection roller is driven by the paper ejection motor, and the rotation of the paper ejection motor
is monitored by the paper ejection limit sensor (encoder sensor).
The paper ejection wings can be manually adjusted up or down to suit the paper ejected. (Raise for
normal paper, lower for thick paper or post card.)
[7 - 2]
CHAPTER 7. PAPER EJECTION SECTION
[7 - 3]
CHAPTER 7. PAPER EJECTION SECTION
Disassembly
1. Removing the Paper Receiving Tray
(1) Remove the receiving tray lock plates on both sides. (M3 x 6 screw on each side)
(2) Remove the paper receiving tray from the paper receiving tray support ass’y .
P0701
P0702
[7 - 4]
CHAPTER 7. PAPER EJECTION SECTION
P0703
P0704
[7 - 5]
CHAPTER 7. PAPER EJECTION SECTION
P0705
Paper ejection cover ass’y
P0706 P0707
[7 - 6]
CHAPTER 7. PAPER EJECTION SECTION
P0708
P0709
Paper ejection roller unit
P0710
P0711
Pinch pulse motor timing belt
[7 - 7]
CHAPTER 7. PAPER EJECTION SECTION
P0712
P0713 P0714
Pinch roller Spacer
[7 - 8]
CHAPTER 7. PAPER EJECTION SECTION
Pinch cover
P0715
Connectors Connectors
P0716 P0717
P0718
[7 - 9]
CHAPTER 7. PAPER EJECTION SECTION
P0719
Pinch HP sensor
P0720
[7 - 10]
CHAPTER 7. PAPER EJECTION SECTION
Connector
Connector
P0723
P0722
Paper ejection unit safety SW
Paper ejection unit safety SW bracket
attachment spring
[7 - 11]
CHAPTER 7. PAPER EJECTION SECTION
P0724
P0725
P0726 P0727
Pinch roller release ass’y & pinch release shaft ass’y Pinch roller release motor
[7 - 12]
CHAPTER 7. PAPER EJECTION SECTION
P0728
[7 - 13]
CHAPTER 7. PAPER EJECTION SECTION
Adjustment
1. Pinch Roller Position Adjustment
(1) Apply a marking agent to the pinch rollers and feed paper between them.
(2) Measure the width of the marks for the front and rear rollers, confirming that this is 3 mm ± 0.5 mm.
(3) If the pinch roller mark width falls outside the specifications, correct by running Test mode No. 489
(Front Pinch Roller Position Adjustment) for the front rollers and Test mode No. 490 (Rear Pinch
Roller Position Adjustment) for the rear rollers.
Range: -100 to +100 (-10.0 mm to +10.0 mm)
Units: 5 (0.5 mm)
Default: 0 mm
Positive values move the rollers toward the center of the paper, while negative values move them
toward the edge of the paper.
P0729
Adjuster screw
Adjuster plate
P0730 P0731
[7 - 14]
CHAPTER 8: PRINT DRUM SECTION
Contents
[8 - 1]
CHAPTER 8. PRINT DRUM SECTION
Mechanism
1. Print Drum Layout and Angle
The two interchangeable print drums have the identical construction. When mounted in the machine, the
drum closest to the paper feed side is called the 1st print drum, while the one at the paper ejection side is
called the 2nd print drum.
The two print drums are arranged in a V-shape at an angle of 45° on either side of the center of the paper
drum. This enables simultaneous printing of two colors onto a single sheet of paper.
With the print drums mounted in the machine, the print drum position in which the clamp plate base is
located at the top of the print drum is called position A, while the position for removing the print drum is
called position B.
As described above, the two print drums are arranged in a V-shape at 45° to the paper drum to print two
colors simultaneously onto a single sheet of paper. The two print drums are therefore mechanically out of
phase by 90° during printing.
Position A sensors are positioned at the front and rear of the print drums. When the print drum is used as
the 1st print drum, sensor No.1 (rear sensor) is used, and when the print drum is used as the 2nd print
drum, sensor No.2 (front sensor) is used.
When the print drums are completely removed (and placed for example on the floor), the clamp plates for
both the 1st and 2nd print drums move to their topmost positions. The position B lock confirmation
sensor, located next to the rear position A sensor and blocked by the position A sensor detection plate,
confirms that the print drum is at position B for print drum removal.
When the print drums are reinserted into the machine, it is the paper drum position which determines the
position B on the machine drive unit, enabling the print drum to engage with the machine drive unit.
[8 - 2]
CHAPTER 8. PRINT DRUM SECTION
P08002
P08001
[8 - 3]
CHAPTER 8. PRINT DRUM SECTION
[8 - 4]
CHAPTER 8. PRINT DRUM SECTION
[8 - 5]
CHAPTER 8. PRINT DRUM SECTION
Disassembly
1. Removing the Screen Ass’y
(1) Remove the side frame R and side frame L. (Five M4 x 8 screws on each)
(2) Remove the two screen springs.
(3) Remove the front and rear E-rings and washers. (Refer to the photograph below.)
(4) Remove the front and rear stepped screws. Remove the clamp plate base ass’y from hanger E on
the screen ass’y. (Refer to the photograph on the bottom and on the next page.)
(5) Remove the two mounting screws on the hanger TA (M4 x 8), and remove the screen ass’y. (Refer
to the photograph on next page.)
Side frame L
P08003
Side frame R
P08005
[8 - 6]
CHAPTER 8. PRINT DRUM SECTION
Hanger E
P08006
Screen ass’y
P08007
Hanger TA
[8 - 7]
CHAPTER 8. PRINT DRUM SECTION
Screws to remove
Hook
Print drum cover
P08008 P08009
Connector
Connector (2 places)
P08010
[8 - 8]
CHAPTER 8. PRINT DRUM SECTION
P08011
P08013
[8 - 9]
CHAPTER 8. PRINT DRUM SECTION
P08015
Flange
P08016
Dome sheet
Connector
P08017
[8 - 10]
CHAPTER 8. PRINT DRUM SECTION
[Precautions on Reassembly]
· Align the shaft pin with the slot in the clutch shaft.
· Engage the slot in the inner pressure clutch bracket with the protrusion on the bottle guide.
Connector
P08018
P08019 P08020
[8 - 11]
CHAPTER 8. PRINT DRUM SECTION
P08021
P08022
Horizontal pulse motor ass’y
[8 - 12]
CHAPTER 8. PRINT DRUM SECTION
P08023
P08024
[8 - 13]
CHAPTER 8. PRINT DRUM SECTION
P08025
slide
P08026 P08027
[8 - 14]
CHAPTER 8. PRINT DRUM SECTION
Connector
P08028
P08029
[8 - 15]
CHAPTER 8. PRINT DRUM SECTION
P08030
P08031
[8 - 16]
CHAPTER 8. PRINT DRUM SECTION
Bottle guide A
P08032
Connector
P08033 P08034
Ink sensor PCB ass’y
[Precautions on Reassembly]
Engage the protrusions on ink sensor PCB bracket A with the slots in ink sensor PCB
bracket B.
Protrusions on ink sensor PCB bracket A Slots in ink sensor PCB bracket B
P08035 P08036
Ink sensor PCB bracket A Ink sensor PCB bracket B
[8 - 17]
CHAPTER 8. PRINT DRUM SECTION
P08037 P08038
P08039
[8 - 18]
CHAPTER 8. PRINT DRUM SECTION
Wire saddles
P08040
Connectors
[8 - 19]
CHAPTER 8. PRINT DRUM SECTION
(4) Loosen two set screws and remove the spur gear from the inner pressure roller drive shaft.
(5) Remove two E-rings and detach the bearing.
Spur gear
P08041
E-ring (2 pcs)
P08042
Bearing
P08043
P08044
[8 - 20]
CHAPTER 8. PRINT DRUM SECTION
(6) Detach the E-ring on the flange drive gear shaft and loosen the two set screws on flange drive gear F.
Disconnect the connector on the inner pressure limit sensor (encoder sensor), confirming that the
inner pressure detection plate is positioned in between the sensor. Then remove the two mounting
screws (M4 x 8) on the print drum flange F ass’y and slide the print drum flange F ass’y and flange
drive gear F to remove.
P08046
P08045
Connector
P08047
P08048
[8 - 21]
CHAPTER 8. PRINT DRUM SECTION
(7) Detach the E-rings and remove the link plate and link ass’y.
E-rings
P08049
From steps (8) to (15), which continues, are all on the rear (drive) side of the machine.
(8) Remove C-ring and detach print drum rear frame ass’y.
C-ring
P08050 P08051
[8 - 22]
CHAPTER 8. PRINT DRUM SECTION
(9) Loosen two set screws and remove the spur gear.
(10) Remove E-ring, two screws (M3x8), and detach one-way hinge.
(11) Remove the bearing.
Spur gear
P08052
One-way hinge
P08053
P08054
P08055
[8 - 23]
CHAPTER 8. PRINT DRUM SECTION
(12) Unplug two sensor connectors and remove one detachable wire harness band.
(13) Remove two mounting screws (M4 x 8) on the print drum flange R ass’y and slide the print drum
flange R ass’y together with flange drive gear shaft attached to remove.
Connectors
P08056
P08057
P08058
[8 - 24]
CHAPTER 8. PRINT DRUM SECTION
(14) Detach the E-rings and remove the link plate and link ass’y.
P08059
E-rings
[8 - 25]
CHAPTER 8. PRINT DRUM SECTION
(15) Detach ink shaft drive plate by removing screw (M4x8), and remove metal bearing with flange, spur
gear, and then pull out the ink drive shaft.
* Do not misplace the metal bearing between the spur gear and the O-ring.
P08060 P08061
P08062 P08063
P08064
[8 - 26]
CHAPTER 8. PRINT DRUM SECTION
(16) Detach inner pressure roller springs (one each on FRONT and REAR) and remove mounting screw
(M4x8) on each side. Detach pin C on the inner pressure roller unit from the slot in the inner
pressure roller support plate and remove the inner pressure roller unit.
<Refer to page No. 8-28 for the assembly instructions>
Pin C
Mounting screw
P08066
< FRONT >
P08067
[8 - 27]
CHAPTER 8. PRINT DRUM SECTION
P08068
P08069
Pin C
P08070
[8 - 28]
CHAPTER 8. PRINT DRUM SECTION
(2) Insert ink drive shaft, and mount spur gear and ink drive shaft plate.
Firmly push the metal bearing and O-ring on the ink drive shaft with the spur gear for firm
insertion of the O-ring.
(3) Mount link plate and link ass’y on both end of the print drum.
Refer to the photographs on pages 8-22 and 8-25 for correct gear positions.
(7) Align the position of print drum flanges R and F by inserting 8 mm diameter long-shaft (JIG)
through the holes on the two flanges.
P08072
P08071
P08073
[8 - 29]
CHAPTER 8. PRINT DRUM SECTION
(8) Attach E-ring on the flange drive gear shaft, and then pull the flange drive gear F against the
bearing and tighten the two set screws on the gear.
(9) Install bearing, one-way hinge, E-ring, and spur gear on the rear side of the inner pressure roller
drive shaft.
Push the spur gear against the E-ring when tightening the set screws.
(10) Install bearing, E-ring (2 pcs), and spur gear on the front side of the inner pressure roller.
Push the spur gear against the E-ring when tightening the set screws.
· Bottle guide B
· Inner pressure clutch
· Wire holding plate
· Ink volume detection sensor (send) ass’y
· Ink volume detection sensor (receive) ass’y
· Dome sheet
· Clamp plate base ass’y
· Screen ass’y
· Side frames L and R
· Print drum cover
P08074
Bottle guide A
[8 - 30]
CHAPTER 8. PRINT DRUM SECTION
Cap screws
P08076
Engagement pin
[8 - 31]
CHAPTER 8. PRINT DRUM SECTION
P08077
Slit on back of Engagement pin
Engagement pin
P08078
P08079
P08080
[8 - 32]
CHAPTER 8. PRINT DRUM SECTION
P08081
[8 - 33]
CHAPTER 8. PRINT DRUM SECTION
slide
P08082
P08083
[8 - 34]
CHAPTER 8. PRINT DRUM SECTION
P08084
[8 - 35]
CHAPTER 8. PRINT DRUM SECTION
Removing the Drive transmit release sensor and Horizontal centering HP sensor
(3) Unplug the connectors and remove the two sensors.
P08085
P08087
[8 - 36]
CHAPTER 8. PRINT DRUM SECTION
Flange gear
P08088
P08089
[8 - 37]
CHAPTER 8. PRINT DRUM SECTION
P08090 P08091
Print drum No.2 Print drum No.1
P08092
[8 - 38]
CHAPTER 8. PRINT DRUM SECTION
P08093
P08094
P08095
[8 - 39]
CHAPTER 8. PRINT DRUM SECTION
Adjustment
1. Inner Pressure Roller Gap Adjustment
Check and Adjustment Procedure
(1) Remove side frame L and screen ass’y.
(2) Release the position B lock and rotate to move the clamp plate base ass’y to bottom.
(3) Attach squeegee gap adjustment shaft (JIG) and drum manual rotation knob.
(4) Hook two squeegee gap gauges (JIG) on the squeegee gap adjustment shaft (JIG), and hook
the weight (JIG) on the squeegee gap gauges.
(5) Rotate the print drum through a half revolution using the drum manual rotation knob.
(6) Check the ink scooped on the squeegee gap gauges, referring to the sketch on next page. If the
amount is incorrect and requires adjustment, loosen the two lock screws (refer to photograph
on next page) and turn the gap adjustment knob to adjust. (Rotating upward reduces the gap,
while rotating downward increases the gap.)
(7) After adjusting, firmly retighten the two lock screws.
(8) Run an actual print test (Test chart No. 11, print speed: 3, print density: 1, A3 size standard
printing paper) to check the density balance.
Precautions on Adjustment
· One revolution of the gap adjustment shaft alters the gap by approximately 0.025 mm.
· Adjust the gap by first increasing, then decreasing the gap to compensate for the play.
· Adjust at room temperature of between 20°C to 28°C
· After the adjustment, do not touch the gap adjustment knob or the worm gears.
P08096
Drum manual rotation knob Weight (JIG)
[8 - 40]
CHAPTER 8. PRINT DRUM SECTION
P08097
Squeegee gap adjustment shaft (JIG) Gap adjustment knob Weight (JIG)
S08099
Too little
P08100
[8 - 41]
CHAPTER 8. PRINT DRUM SECTION
(3) After adjusting, check the print density by the check procedure given below.
Checking Procedure
Test chart No. 11, print speed: 3, print density: 1, and standard A3 size white printing paper.
Increase the Teflon tape thickness if the master elongates upwards on the print drum.
If master elongation is 1.0 mm, change the tape thickness by 0.08 mm.
If master elongation is 1.5 mm, change the tape thickness by 0.13 mm.
If master elongation is 2.0 mm, change the tape thickness by 0.18 mm.
[8 - 42]
CHAPTER 8. PRINT DRUM SECTION
If the master has shifted, adjust by moving the drum positioning block R horizontally.
If the master has shifted to the front, move drum positioning block R to the right.
If it has shifted to the rear, move drum positioning block R to the left.
The adjustment amounts for drum positioning block R are shown below, depending on the amount of
master shift.
If the master has shifted 0.5 mm, move the drum positioning block R horizontally 0.1 mm.
If the master has shifted 1.0 mm, move the drum positioning block R horizontally 0.2 mm.
If the master has shifted 1.5 mm, move the drum positioning block R horizontally 0.3 mm.
If the master has shifted 2.0 mm, move the drum positioning block R horizontally 0.4 mm.
If creases are observed on the top of the screen, above the ink opening holes, move the drum
positioning block R horizontally 0.07 mm.
CAUTION
P08101
P08102
[8 - 43]
CHAPTER 8. PRINT DRUM SECTION
MEMO
[8 - 44]
CHAPTER 9: VERTICAL PRINT POSITION SECTION
Contents
[9 - 1]
CHAPTER 9. VERTICAL PRINT POSITION SECTION
Mechanism
1. Vertical Print Position Mechanism
Both the 1st and 2nd print drums are equipped with separate vertical print position mechanisms that are
incorporated into the drum drive units.
The two print drum drive units are identical, but phase with respect to the paper drum differs when
mounted in the machine.
The print drum drive unit incorporates a planetary gear mechanism. The vertical print position is
controlled by the print positioning pulse motor, while the datum position is checked by the vertical
centering sensor.
The initial vertical print position (home position) is the position in which the vertical centering sensor
switches from ON to OFF as the print positioning pulse motor rotates in the direction to bring the image
down.
If the vertical print position key is pressed while the machine is in idle, the panel display changes, but the
motor still does not rotate. The actual print position does not change until the START button is pressed
for the print operation.
If “0” is selected by test mode No. 091, the print position changes only at the start of the printing.
If “1” is selected by test mode No. 091, the print position changes simultaneously during the printing.
The print positions is altered in increments of ±0.1 mm by a press of the print positioning key, and can be
varied continuously by keeping the key depressed.
Vertical print positioning is performed under the following circumstances:
1. When the vertical print positioning key is pressed during printing.
2. During print preparation movement (moves to home position and then to the memorized position).
3. When the machine power is turned ON.
P0912
[9 - 2]
CHAPTER 9. VERTICAL PRINT POSITION SECTION
P0913
< Print drum drive unit >
< View with the Print drum drive cover removed >
P0914
[9 - 3]
CHAPTER 9. VERTICAL PRINT POSITION SECTION
Disassembly
1. Removing the Print Drum Drive Unit (same for 1st and 2nd print drum)
Refer to next page for PRECAUTIONS before disassembly.
(1) Remove the main cover ass’y.
(2) Disconnect the two connectors, remove the fourmounting screws (M4 x 8), and remove the print drum
drive unit.
P0901
P0902 P0903
2nd print drum drive unit 1st print drum drive unit
[9 - 4]
CHAPTER 9. VERTICAL PRINT POSITION SECTION
[Work Precautions]
• Reassembling the print drum drive unit requires a jig to align the phase. Do not disassemble past
the point shown in the photograph below.
P 0904 P0905
P0906 P0907
[9 - 5]
CHAPTER 9. VERTICAL PRINT POSITION SECTION
P0908 P0909
P0910 P0911
[9 - 6]
CHAPTER 9. VERTICAL PRINT POSITION SECTION
Adjustment
1. Adjusting the Datum Print Position (Phase Between Print Drum
and Paper Drum)
This adjustment is to input the memory of the print position on each print drum for maximum of six print
drum positions (print drum positions 1 and 2 location for each machine, for maximum of three machines).
Preparations before the adjustment
(1) If there are more than one machine (maximum 3 machines) at an installation site, start up test
mode No. 686 and register each machine with numbers starting with “0”.
For maximum of three machines, the machines will be registered as “0”, “1”, and “3”.
If there is only one machine, the default setting for that machine is “0” from the start, so there
is no need to run test mode No.686.
(2) If the vertical center position adjustment on the machine (test mode No.680) is changed from
the default setting of “0” to another setting in the past, return the test mode No. 680 setting back
to “0” on all the machines to which the datum print position adjustment on the print drum(s) is to
be made.
Checking and Adjustment Procedure
(3) Install the print drum(s) to be adjusted. Two print drums at one time or only one print drum at
one time can be installed for the adjustment.
(4) Make confidential master on the print drum(s).
(5) Using a scale, preferably of a flexible material, make a mark on the master on the print drum(s)
at a point 85 mm from the tip of the clamp plate.
(6) Run prints (print speed: 3, print position: center) and check that the line(s) is printed 10 mm ± 1
mm from the leading edge of the print paper.
(7) If the line(s) is not printed within the given distance from the leading edge of the paper, rum test
mode No.681 (vertical center position adjustment on the print drum) for the print drum(s) on
which the line was not printed within the given distance.
Increasing the value by test mode No.681 will bring the image up.
(8) Above adjustment should be made on all print drums for all the possible print drum positions
the print drums will be inserted in all the machines at one installation site (maximum three
machines).
Symptoms if incorrectly adjusted
The print position may vary on each print drum when the print drum position is changed for that print
drum on the machine(s).
[9 - 7]
CHAPTER 9. VERTICAL PRINT POSITION SECTION
MEMO
[9 - 8]
CHAPTER 10: CLAMP UNIT
Contents
[10 - 1]
CHAPTER 10. CLAMP UNIT
Mechanism
1. Mechanism Outline
Identically constructed clamp units are provided on the 1st and 2nd print drums.
The clamp units are composed of the back and forth motion part and the opening and closing movement
part.
The backward and forth motion is driven by the clamp slide motor.
The position of the clamp is checked by the clamp slide HP sensor and clamp slide return sensor.
The opening and closing action is driven by the clamp opening and closing motor, and the position for the
clamp opening and closing is checked by the clamp plate HP sensor, clamp plate loading position
sensor, and angular sensor.
[10 - 2]
CHAPTER 10. CLAMP UNIT
[10 - 3]
CHAPTER 10. CLAMP UNIT
Position A of the tail clamp plate for the master removal (same for print drums No. 1 & No. 2)
(1) With the main motor, the print drum rotates at 30 rpm and stops when position A sensor
detection changes from OFF to ON.
(2) Main clutch is engaged to rotate the print drum in the reverse direction by the maim pulse motor.
(3) The main pulse motor stops when position A sensor detection changes from ON to OFF.
(4) 300 msec later, the main pulse motor rotates in the forward direction.
(5) When position A sensor detection changes from OFF to ON, the main pulse motor stops and
the main clutch is disengaged.
Position A of the top clamp plate for the master removal (same for print drums No. 1 & No. 2)
(1) Main clutch engages and main pulse motor rotates in the forward direction.
(2) The main pulse motor stops 800 msec after position A sensor detection changes from ON to
OFF.
(3) 300 msec later, the main pulse motor rotates the print drum in reverse direction.
(4) Main pulse motor stops and main clutch disengages at 5 mm circumference rotation of the print
drum from the time the position A sensor detection changes from OFF to ON.
Position A of the top clamp plate for the master loading (same for print drums No. 1 & No. 2)
(1) With the main motor, the print drum rotates at 30 rpm and stops when position A sensor
detection changes from OFF to ON.
(2) Main clutch is engaged to rotate the print drum in the forward direction by the maim pulse motor.
(3) The main pulse motor stops 800 msec after position A sensor detection changes from ON to
OFF.
(4) 300 msec later, the main pulse motor rotates the print drum in reverse direction.
(5) Main pulse motor stops and main clutch disengages at 5 mm circumference rotation of the print
drum from the time the position A sensor detection changes from OFF to ON.
Position A of the tail clamp plate after the master loading (for print drum No. 1 only)
(1) With the main motor, the print drum rotates at 30 rpm and decelerates to 10 rpm from paper
drum at T position.
(2) The main motor stops when the paper drum comes to 45 degrees from the T position.
(3) 100 msec later, the main clutch engages and the main pulse motor rotates the print drum in
forward direction.
(4) Main pulse motor stops and main clutch disengages when the position A sensor detection
changes from OFF to ON.
Position A of the tail clamp plate after the master loading (for print drum No. 2 only)
(1) With the main motor, the print drum rotates at 30 rpm and decelerates to 10 rpm after the paper
drum rotates 180 degrees from the T position.
(2) The main motor stops when the paper drum comes to 225 degrees from the T position.
(3) 100 msec later, the main clutch engages and the main pulse motor rotates the print drum in
forward direction.
(4) Main pulse motor stops and main clutch disengages when the position A sensor detection
changes from OFF to ON.
[10 - 4]
CHAPTER 10. CLAMP UNIT
5. Angular Sensors
The clamp plate position on the print drum is checked during the clamp opening and closing movement
by three sensors, 0 angular sensor, 180 angular sensor, and angular safety sensor.
(1) 0 angular sensor
Detects top clamp plate closed position.
Detects tail clamp plate opened position.
(2) 180 angular sensor
Detects top clamp plate opened position.
Detects tail clamp plate closed position.
(3) Angular safety sensor
Checks whether the top clamp plate is in opened position when the tail clamp plate is going to
open. The tail clamp plate will not open if the top clamp plate is detected opened.
[10 - 5]
CHAPTER 10. CLAMP UNIT
[10 - 6]
CHAPTER 10. CLAMP UNIT
Disassembly
1. Removing the Clamp Unit (Same for 1st and 2nd)
(1) Remove the rear cover.
(2) Unplug three connectors and dismount detachable wire harness band.
(3) Remove three mounting screws (M4 x 8), and remove the clamp unit.
P1005 P1006
1st Clamp unit 2nd Clamp unit
(for print drum No. 1) (for print drum No. 2)
P1008
P1007
0 Angular sensor
[10 - 7]
CHAPTER 10. CLAMP UNIT
P1010
CLAMP UNIT
(Rear View)
[10 - 8]
CHAPTER 11: MASTER DISPOSAL SECTION
Contents
[11 - 1]
CHAPTER 11. MASTER DISPOSAL SECTION
Mechanism
1. Master Disposal Mechanism
The master disposal unit consists of the master disposal vertical transport section, which passes the
master from the print drum to the master disposal unit, and the compression section, which compresses
the disposed master inside the master disposal box.
The 1st and 2nd master disposal units are used for the 1st and 2nd print drums and differ in the
construction of their vertical transport sections.
The 1st master disposal unit has four master tail clamp fans which operate to assist the master end
clamping action on the 1st print drum.
A master disposal fan is also situated inside the master making unit, and the master making unit moves
to each print drum during master disposal (master making) to assist in the master disposal operation.
[11 - 2]
CHAPTER 11. MASTER DISPOSAL SECTION
[11 - 3]
CHAPTER 11. MASTER DISPOSAL SECTION
Disassembly
Refer to page 11-18 for removing
1. Removing the 1st Master Disposal Unit 2nd Master Disposal Unit.
P1101
[11 - 4]
CHAPTER 11. MASTER DISPOSAL SECTION
P1104 P1105
3. Removing the Master Tail Clamp Fan (1st Master Disposal Unit
Only)
(1) Disconnect the connector, remove the two mounting screws (M3 x 20) on each fan, and remove the
fan.
Enlarged View
P1106
P1107
[11 - 5]
CHAPTER 11. MASTER DISPOSAL SECTION
[ The procedure is common for both the 1st and 2nd master removal unit ]
(1) Disconnect the connector, remove the mounting screw (M4 x 5), and remove the master disposal
motor limit sensor together with its bracket.
P1108
(1) Remove the mounting screw (M4 x 6), lift up the master compression sensor ass’y, disconnect the
connector, and remove the master compression limit sensor and master compression HP sensor.
P1109
[11 - 6]
CHAPTER 11. MASTER DISPOSAL SECTION
(1) Remove the mounting screw on the master disposal limit sensor ass’y.
(2) Remove the mounting screw on the master compression sensor ass’y.
(3) Disconnect the connector on the master disposal motor, cut the wire harness band, remove the three
mounting screws (M4 x 6), and remove the master disposal motor cover.
(4) Remove the master disposal motor ass’y. (Three M4 x 6 screws)
(5) Remove the three mounting screws (M3 x 5), then remove the master disposal motor.
Connector
Master disposal limit sensor ass’y
P1111
P1113
< Master disposal motor ass’y >
[11 - 7]
CHAPTER 11. MASTER DISPOSAL SECTION
P1114
(1) Remove the vertical transport roller holder ass’y. (Two M4 x 6 screws)
(2) Disconnect the connector, remove the mounting screw (M3 x 6), and remove the master disposal jam
sensor together with the bracket.
< 1st Master Removal Unit > P1115 < 2nd Master Removal Unit > P1116
[11 - 8]
CHAPTER 11. MASTER DISPOSAL SECTION
(1) Cut the wire harness band, disconnect the connector, remove the two mounting screws (M4 x 6), and
remove the disposal plate motor ass’y.
(2) Remove the disposal plate motor. (Two M2.6 x 5 screws)
P1117
[11 - 9]
CHAPTER 11. MASTER DISPOSAL SECTION
10. Removing the Vertical Transport Roller G and Master Disposal Belt
(1st Master Disposal Unit) Refer to page 11-19 for removing these
parts from the 2nd Master Disposal Unit.
(1) Remove the vertical transport roller holder.
(2) Remove the master disposal jam sensor ass’y.
(3) Remove the disposal plate motor.
(4) Detach the E-ring and bearing on one side of the guiding roller, slide out the roller, and remove.
(5) Loosen the set screw on gear Z24 and remove from vertical transport roller G.
* The gear on the “Gear Z24” should face inside and the boss with the set screw faces outside.
(6) Pull out and remove vertical transport roller G from the keyhole shaped hole in the frame plate.
(7) Remove the master disposal belt from vertical transport roller G.
Guiding roller
P1119
P1120
[11 - 10]
CHAPTER 11. MASTER DISPOSAL SECTION
(1) Remove the master disposal motor ass’y together with the master disposal motor cover. (Five M4 x 6
screws)
(2) Detach the E-ring and remove the intermediate gear. (Front)
(3) Detach the E-ring and remove the spur gear (sharrow boss faces inwards). (Front)
(4) Remove the disposal plate sensor ass’y. (M4 x 6 screw)
(5) Loosen the set screw on the rear gear Z21 and remove from vertical transport roller J.
(6) Remove the four mounting screws (M4 x 6) on the master disposal guide lower ass’y and slide the
ass’y back a little.
(7) Detach the E-rings and metals on both sides and remove vertical transport roller J.
P1121 P1122
Master disposal motor ass’y Intermediate gear Disposal plate sensor ass’y
Slide
Slide
back
back
P1123 P1124
[11 - 11]
CHAPTER 11. MASTER DISPOSAL SECTION
Disposal plate
P1125 P1126
[11 - 12]
CHAPTER 11. MASTER DISPOSAL SECTION
Intermediate gear
Spur gear
P1127
[11 - 13]
CHAPTER 11. MASTER DISPOSAL SECTION
P1129
[11 - 14]
CHAPTER 11. MASTER DISPOSAL SECTION
P1130 P1131
P1132 P1133
[11 - 15]
CHAPTER 11. MASTER DISPOSAL SECTION
P1134 P1135
[11 - 16]
CHAPTER 11. MASTER DISPOSAL SECTION
Safety SW cover
P1136
Safety SW ass’y
P1137
Connectors
P1138
[11 - 17]
CHAPTER 11. MASTER DISPOSAL SECTION
P1139
[11 - 18]
CHAPTER 11. MASTER DISPOSAL SECTION
Gear Z21
Vertical transport roller G
Guide roller
P1140
Intermediate gear
Guiding roller
Master disposal
guide lower II ass’y
P1141
[11 - 19]
CHAPTER 11. MASTER DISPOSAL SECTION
MEMO
[11 - 20]
CHAPTER 12: FB ORIGINAL SCANNING SECTION
Contents
[12 - 1]
CHAPTER 12. FB ORIGINAL SCANNING SECTION
Mechanism
1. Scanner Table Opening and Closing Mechanism
The scanner table can be opened by gripping the scanner table slide lever.
The flat bed set SW confirms that the scanner table is in position.
The flat bed set switch also acts as an interlock SW. When the scanner table is opened, the switch cuts
power to the main motor, clamp motor, master loading fan, print positioning pulse motor, master
compression motor, disposal plate motor, paper ejection motor, pinch pulse motor, master making unit
shifting motor, and TPH power supply.
P1201
P1202
[12 - 2]
CHAPTER 12. FB ORIGINAL SCANNING SECTION
MEMO
[12 - 3]
CHAPTER 12. FB ORIGINAL SCANNING SECTION
2. Scanning Mechanism
The FB read pulse motor drives the front and rear wire-spool pulleys via the two-stage reduction pulleys
linked by the timing belt.
The front and rear wire-spool pulleys are configured symmetrically.
One end of the wire is secured to the frame via the spring, and is attached to the lamp carriage via sliding
pulley 2 mounted on the mirror carriage. It is wound approximately 7 times around the wire-spool pulley
from the opposite side via fixed pulley 2 secured to the frame. It is then attached to the frame via fixed
pulley 1 mounted on the frame, and sliding pulley 1 mounted on the mirror carriage].
The mirror carriage and lamp carriage are able to move horizontally along the rails attached to the
respective sliders.
The mirror carriage carries two mirrors (mirror 2 and mirror 3), and the lamp carriage carries the original
illumination lamp (and lamp inverter) and mirror 1.
The mechanism uses a “full/half-rate mirror scanning” system, in which the mirror carriage moves 1/2 L
mm as the lamp carriage moves L mm in the same direction. This means that when the FB read pulse
motor is activated, the original can be scanned while a constant distance is maintained between the
original and the center of the lens mounted on the frame. The image of the original on the scanner table
illuminated by the lamp is reflected via mirrors 1, 2, and 3, and is then focused onto the CCD by the lens
in the lens ass’y.
P1203
Wire-spool pulley
Lens ass’y
P1204
[12 - 4]
CHAPTER 12. FB ORIGINAL SCANNING SECTION
Drive-system diagram
FB read pulse motor
S1205
Optical-system diagram
S1206
Mirror 2
Mirror 3
[12 - 5]
CHAPTER 12. FB ORIGINAL SCANNING SECTION
3. Flatbed Initialization
Initialization is performed in the following situations to place the flatbed in standby mode:
• When the power is switched on
• When “All reset” is performed
Initialization operation
The FB/AF HP sensor is checked, and if it is OFF (open), the FB read pulse motor is activated in the
return direction until the light path is blocked, to move the lamp carriage to the left in the photograph.
Once the FB/AF HP sensor turns ON (blocked), it is moved a further set distance before the operation
ends (this is the “standby position”).
The detection plate on the FB/AF HP sensor is attached to the lamp carriage.
No movement is made if the FB/AF HP sensor is ON from the start.
The flatbed is moved to the shading position after moving to the standby position. Then, the lamp
illuminates, and peak detection is performed as part of the shading compensation operation. The lamp
finally turns off, and the flatbed is returned to the standby position.
FB/AF HP sensor
Lamp carriage
P1207
P1208
[12 - 6]
CHAPTER 12. FB ORIGINAL SCANNING SECTION
[12 - 7]
CHAPTER 12. FB ORIGINAL SCANNING SECTION
Disassembly
1. Removing the Scanner Unit
(1) Move the carriage to the lock position using Test mode No. 154 (Scanner Lock Mode). Slide the
scanner table, then secure the mirror carriage with the scanner unit securing screw.
(2) Switch OFF power and remove the covers.
(3) Remove the 6 screws (M4 x 8), disconnect the connector, and remove the operation panel unit.
(4) Remove the screw (M4 x 6), disconnect the connector, and remove the stage cover sensor ass’y.
(5) Remove the four screws (M4 x 6) securing the scanner unit to the hinge bracket.
(6) Remove the four scanner unit screws (M4 x 6), disconnect the bottom connector, and raise and
remove the scanner unit.
(The scanner unit is heavy precision component. Handle with care.)
[12 - 8]
CHAPTER 12. FB ORIGINAL SCANNING SECTION
P1209
[12 - 9]
CHAPTER 12. FB ORIGINAL SCANNING SECTION
Top L stay
Scanner frame
P1210
Scanner frame
Lamp
Lamp carriage
P1211
[12 - 10]
CHAPTER 12. FB ORIGINAL SCANNING SECTION
Adjustment
1. FB Read Pulse-Motor Speed Adjustment
Checks and procedure
(1) Place A3-size papers on the paper-feed tray, place test chart No. 11 on the stage glass, and make
one-to-one size image master and make prints.
(2) Lay the print on top of the original to confirm that the image elongation and shrinkage is within ±1.0%
at the 350-mm line.
(3) If the elongation and shrinkage is outside the specified parameters, adjust them using test mode
No. 182 (FB scanning-speed adjustment).
* Prior to this adjustment, first adjust the image elongation and shrinkage in master making area
(refer to page 14-23).
[12 - 11]
CHAPTER 12. FB ORIGINAL SCANNING SECTION
[12 - 12]
CHAPTER 13: AF SCANNING SECTION
Contents
[13 - 1]
CHAPTER 13. AF SCANNING SECTION
Mechanism
1. AF Original Set Mechanism
When the original is placed along the original guide fence and pushed against the original stopper, the AF
original detection sensor is activated (light path open) and the display on the panel changes to “Ready to
make master.”
Following a preset interval, the AF read pulse motor reverses to lower the original pickup roller in the
direction indicated by the arrow, and withdraw the original stopper upward. (The one-way clutch
incorporated between the original registration roller gear and the original registration roller shaft prevents
the original registration roller from rotating during this process.)
Once the original pickup roller has descended to push against the original, the original pickup roller and
original stripper roller rotate in the original transport direction, and a single original is fed forward by the
action of the original stripper roller and original stripper pad. This activates the AF original registration
sensor (light path blocked), and the edge of the original is stopped by the stationary original registration
roller.
Once a preset interval has elapsed following activation of the AF original registration sensor, the AF read
pulse motor operates in the forward direction.
This raises the original pickup roller while rotating the original registration roller, the two original read
rollers 1 & 2, and the original ejection roller, all of which are linked by the timing belt, in the feed direction.
The original stops briefly after it has been moved 90 mm from the original set position.
The lamp illuminates when the AF original det. sensor is activated, and the lamp carriage in the scanner
unit performs shading compensation and moves to the AF scanning position before waiting in standby.
If the START key is not pressed within 60 seconds, the lamp turns off and the lamp carriage returns to the
standby position. If the START key is subsequently pressed, shading compensation is repeated (auto
base control is also performed if the original scanning density is set to “Auto”) and scanning starts.
If the START key is pressed within 60 seconds, scanning starts immediately, provided that the original
scanning density is not set to “Auto.” If the original scanning density is set to “Auto,” the lamp carriage
returns to the standby position, shading compensation is repeated, and auto base control is performed
before scanning is begun.
S1301
[13 - 2]
CHAPTER 13. AF SCANNING SECTION
Original
registration sensor
S1302
Original feed
P1303
[13 - 3]
CHAPTER 13. AF SCANNING SECTION
AF white roller
[13 - 4]
CHAPTER 13. AF SCANNING SECTION
P1305
AF white roller
Original IN sensor
[13 - 5]
CHAPTER 13. AF SCANNING SECTION
AF cover
P1306
P1307
[13 - 6]
CHAPTER 13. AF SCANNING SECTION
(3) Detach plastic lock rings from both ends of the shaft, slide the metal bushings toward the center, and
then remove the original pick up roller ass’y towards the front by sliding the rear drive gear of the
original pickup roller out through from the hole on the AF frame plate.
Metal bushing Platic lock ring Platic lock ring Metal bushing
P1308 P1309
P1310
[13 - 7]
CHAPTER 13. AF SCANNING SECTION
P1312
P1313
< Original pickup roller ass’y >
[13 - 8]
CHAPTER 13. AF SCANNING SECTION
[Precautions on Reassembly]
• When engaging the parallel pin with the K-holder F frame, insert it into the shallower groove on the
K-holder F frame.
• Note the direction of the original stripper roller. It must be inserted with the gear end at the front.
P1314
E-ring
K-holder F frame
Parallel pin
P1315
[13 - 9]
CHAPTER 13. AF SCANNING SECTION
[Precaution on Reassembly]
After placing a new original IN sensor, adjust the sensor sensitivity by using test mode No. 752.
Original IN sensor
P1316
[13 - 10]
CHAPTER 13. AF SCANNING SECTION
Open lever
P1317
Wire harness bracket ass’y
P1318
Tension spring
P1319
[13 - 11]
CHAPTER 13. AF SCANNING SECTION
AF control PCB
P1320
P1321
< AF Drive unit >
[13 - 12]
CHAPTER 13. AF SCANNING SECTION
(5) Unplug the connectors of the AF cover set switch and AF read pulse motor, and remove one screw
(M3 x 6) to detach the ground wire..
(6) Detach the detachable wire harness band (referred on the photograph) and free the wire harness
from three plastic hooks, and let the wire harness free.
(7) Remove one screw (M4 x 6) and detach the ground wire of the wire harness bracket ass’y.
(8) Remove one screw (M4 x 6) and detach the wire harness bracket ass’y.
(9) Remove the open lever with the open lever spring attached.
(10) Remove four screws (M4 x 6) and remove the motor bracket ass’y.
(11) Loosen the screw on the idler ass’y and remove the idler spring.
(12) Remove white plastic clip and remove the spur gear, and then remove E-ring to detach the gear ass’y
located under the spur gear. The timing belt-1 comes off.
[Precaution on Reassembly]
The gear ass’y contains one-way clutch. The surface with the boss should face outward.
Ground wire
Detachable wire harness band
P1322
Spur gear
Timing belt-1
Gear ass’y
P1323
[13 - 13]
CHAPTER 13. AF SCANNING SECTION
P1324
[13 - 14]
CHAPTER 13. AF SCANNING SECTION
Timing pulley
P1327
[13 - 15]
CHAPTER 13. AF SCANNING SECTION
[Precaution on Reassembly]
The timing-pulley ass’y contains one-way clutch. Make sure to install it back in the correct direction.
P1330
Plastic lock ring Parallel pin Metal bushing E-ring Dial E-ring
[13 - 16]
CHAPTER 13. AF SCANNING SECTION
Timing pulley
P1333
Plastic lock ring Parallel pin Metal bushing Plastic lock ring
[13 - 17]
CHAPTER 13. AF SCANNING SECTION
Timing pulley
P1334 P1335
< REAR > < FRONT >
P1336
Plastic lock ring Parallel pin Metal bushing Plastic lock ring
[13 - 18]
CHAPTER 13. AF SCANNING SECTION
Adjustment
1. AF Scanning-Start Position Adjustment
Checks and adjustment procedure
(1) Place A3 size printing paper on the paper feed tray. Make 1 to 1
size master using test chart No.11 through the AF unit., and
make prints.
(2) Examine the prints to confirm that the scanning start position is
at 5 mm ± 2 mm on the top vertical scale on the test chart No.11
printed image.
(3) If the AF scanning start position does not fall within above
specification, make an adjustment using test mode No. 783
(AF Scan Start Position Adjustment).
[13 - 19]
CHAPTER 13. AF SCANNING SECTION
[13 - 20]
CHAPTER 14: MASTER MAKING SECTION
Contents
[14 - 1]
CHAPTER 14. MASTER MAKING SECTION
Mechanism
1. Basic Construction of the Master Making Section
The flat bed set SW checks that the scanner table is in position, functioning as an interlock SW.
The master making unit sensor checks that the master making unit is in place. The master positioning
operation is performed once the master making unit is in position.
The master volume detection sensor checks the amount remaining on the master roll.
The master end sensor detects when the master roll is finished.
The master detection sensor checks that a master is present in the master making unit.
The master positioning sensor checks that a master is present in the standby position.
Manual master cutting is performed with the master cut SW.
* Master cut SW conditions: The scanner table must be open, the 2nd print drum must be removed, and
the master detection sensor must be on.
5. Master Loading
The master is fed by the write pulse motor and master loading motor in the master making section.
Master loading relies on a “simultaneous loading” system, which simultaneously makes the master and
loads the master around the print drum.
For master loading, the print drum is rotated at super-low speed by the main pulse motor.
[14 - 2]
CHAPTER 14. MASTER MAKING SECTION
Master Cutting
The master cutting starts when the print drum is at the 298.8° position.
The print drum rotates during master cutting.
The switch is depressed after the cutter motor starts rotating, and the motor stops again when the
switch is no longer depressed.
Initialization Movement
The cutter is initialized when the power is switched on, during “All Reset”, and when master making
begins.
Initialization is not performed if the cutter is at the home position (cutter home position switch is not
depressed) at the start of the operation.
If the cutter home position switch is depressed, the cutter motor rotates until the switch is no longer
depressed.
[14 - 3]
CHAPTER 14. MASTER MAKING SECTION
Disassembly
1. Removing the Master Volume Detection Sensor (Receive/Send)
(1) Open the scanner table.
(2) Open the master making unit and remove the master roll.
(3) Remove the volume detection sensor (receive) bracket and volume detection sensor (send) bracket.
(One M3 x 6 screw each)
(4) Remove the mounting screw (M3 x 6) on the master volume detection sensors (receive) and (send),
disconnect the connectors, and remove the sensors.
Scanner table
P1401
P1402
[14 - 4]
CHAPTER 14. MASTER MAKING SECTION
P1403
P1404
Tension roller
[14 - 5]
CHAPTER 14. MASTER MAKING SECTION
P1405
P1406 P1407
Connector
P1408
[14 - 6]
CHAPTER 14. MASTER MAKING SECTION
P1409
P1410 P1411
Boss on side of master making unit Slot on end of master making unit lower cover ass’y
[14 - 7]
CHAPTER 14. MASTER MAKING SECTION
P1413
P1412
Master end sensor
Master end sensor cover
Connectors
P1415
[14 - 8]
CHAPTER 14. MASTER MAKING SECTION
Spring
P1416
P1417
[14 - 9]
CHAPTER 14. MASTER MAKING SECTION
P1418 P1419
P1420 P1421
[14 - 10]
CHAPTER 14. MASTER MAKING SECTION
PCB cover
P1422
Connectors
P1423
Wire holder
P1424
[14 - 11]
CHAPTER 14. MASTER MAKING SECTION
(9) Remove the screws (four M4 x 8 screws each) retaining the master making unit to the master making
rails on the front and rear.
(10) Move the master making unit and remove position sensor bracket 2. (M4 x 8 screw)
(11) Move the master making unit toward the master holder until a hand can be inserted. Lift up the
master holder side slightly and move toward the paper ejection side to allow removal of the spur
gear on the master making unit shaft. Now remove the master making unit.
P1425
P1426
< FRONT >
P1427
< REAR >
[14 - 12]
CHAPTER 14. MASTER MAKING SECTION
P1428
P1429
[14 - 13]
CHAPTER 14. MASTER MAKING SECTION
P1430
Cutter guide
P1431 P1432
Write roller
P1433
[14 - 14]
CHAPTER 14. MASTER MAKING SECTION
Pulley
Bearing
P1435
[14 - 15]
CHAPTER 14. MASTER MAKING SECTION
P1436
P1437
[14 - 16]
CHAPTER 14. MASTER MAKING SECTION
Master loading roller ass’y Intermediate gear Master loading roller ass’y
P1438 P1439
Master Making Unit Master Making Unit
< REAR VIEW > < FRONT VIEW >
P1440
Master Loading Roller Ass’y
[14 - 17]
CHAPTER 14. MASTER MAKING SECTION
P1441
[14 - 18]
CHAPTER 14. MASTER MAKING SECTION
P1442
P1443
P1444
[14 - 19]
CHAPTER 14. MASTER MAKING SECTION
Cutter unit
P1445 P1446
P1447
[14 - 20]
CHAPTER 14. MASTER MAKING SECTION
Adjustment
1. Master Leading Clamp Range Adjustment
Checking and Adjustment Procedure
(1) Make marking on the clamped master at the tip end of the closed top clamp plate.
(2) Measure the distance from the mark to the top of the master, confirming that this is 17 mm ± 2 mm.
(3) If the measured value falls outside the specifications, run Test mode No. 283 (Master Clamp Range
Adjustment) and make the necessary adjustments.
Increasing the value by the test mode increases the master top clamping area.
Symptoms
If incorrectly adjusted, the master may start slipping out of the clamp plate or master skewing on the
print drum may occur during the printing. Master removal error may also occur.
Symptoms
If incorrectly adjusted, the master may skew on the print drum during the printing.
[14 - 21]
CHAPTER 14. MASTER MAKING SECTION
S1448
Checking and Adjustment Procedure for 2nd Print Drum Write Start Position relative to the 1st Print
Drum Position
Once the 1st print drum has been adjusted, make master on both the 1st and 2nd print drums using
test mode No. 51. Make few prints using two colors. (Print speed: 3, print density: 3, print position
adjustment: center)
Check that the difference between the first printed line at the top of the print on the 1st print drum and
2nd print drum is within 0.5 mm.
If the difference falls outside the range of specifications, run Test mode No. 281 (Write Start Position
Adjustment) and adjust the difference between 1st and 2nd print drums by adjusting only the write
start position for the 2nd print drum.
Symptoms
Incorrect adjustment leads to print positioning offset between the two print drums.
S1449
[14 - 22]
CHAPTER 14. MASTER MAKING SECTION
Checking and Adjustment Procedure for 2nd Print Drum Image Elongation and Shrinkage relative to
the 1st Print Drum Setting
Once the 1st print drum has been adjusted, make a master on the 2nd print drum using test mode
No. 51 and make few prints using two colors. (Print speed: 3, print density: 3, print position
adjustment: center)
Align the 1st print drum image and the 2nd print drum image at the top (if offset, adjust using the
vertical print position keys). Confirm that the difference between the 1st and 2nd print drums is within
0.5 mm at the 5th or 6th horizontal line from the bottom.
If the measured value falls outside the above range, run Test mode No. 287 (master-making speed
adjustment) on the 2nd print drum and adjust the difference between the 1st and 2nd print drums.
in ype
(Print speed: 3, print density: 3, print position adjustment: center)
k
M a ot
Fold the printed paper at a 45 degrees line so that the printed lines will be 90 degrees against each
s
r ot
other. The elongation or shrinkage should be within 0.3 %. (Example: For the length of 300mm, the
a
te pr rse
elongation or shrinkage should be within 0.9 mm.)
s
If the measured value falls outside the above range, run Test mode No. 292 (main pulse motor
a on e
speed for master making) and adjust image elongation on the 1st print drum.
M
e nly e O v
Increasing the test mode setting elongates the image, while the opposite will shrink the image.
typ o th
Checking and Adjustment Procedure for 2nd Print Drum Image Elongation and Shrinkage relative to
d r
Old talle es fo
the 1st Print Drum Setting
Once the 1st print drum has been adjusted, make a master on the 2nd print drum using test mode
ins chin
No. 51and make few prints using two colors. (Print speed: 3, print density: 3, print position
adjustment: center)
Align the 1st print drum image and the 2nd print drum image at the top (if offset, adjust using the
ma rket.
vertical print position keys). Confirm that the difference between the 1st and 2nd print drums is within
0.5 mm at the 5th or 6th horizontal line from the top.
ma
If the measured value falls outside the above range, run Test mode No. 292 (main pulse motor
speed for master making) on the 2nd print drum and adjust the difference between the 1st and 2nd
print drums.
[14 - 23]
CHAPTER 14. MASTER MAKING SECTION
A (A < B) B C (C > D) D
S1450 S1451
Print A Print B
E (E = F) F
S1452
ADJUSTED
[14 - 24]
CHAPTER 15: TIMING CHARTS
Contents
[15 - 1]
CHAPTER 16: PANEL MESSAGES
Contents
[16 - 1]
CHAPTER 16. PANEL MESSAGES
2) Error type
The order of error priority is as specified below.
3) Error point
The error-point classifications are as specified below. If the power was turned off, during an error that
would be backed up had been displayed, “999” will be displayed as an error point when the machine
is turned on.
[16 - 2]
CHAPTER 16. PANEL MESSAGES
LIST OF ERROR TYPES
[16 - 3]
CHAPTER 16. PANEL MESSAGES
LIST OF ERROR TYPES
[16 - 4]
CHAPTER 16. PANEL MESSAGES
DETAILED LIST OF PANEL MESSAGES
[16 - 5]
CHAPTER 16. PANEL MESSAGES
DETAILED LIST OF PANEL MESSAGES
Clamp slide HP sensor does not switch from OFF → ON and the slide return sensor does
508
not switch OFF within 2 s when positioning the clamp at the home position.
Clamp slide HP sensor does not switch from ON → OFF within 1 s when positioning the
509
clamp at the home position.
Clamp slide HP sensor does not switch from OFF → ON and the slide return sensor does
510
not go ON within 2 s when resetting the clamp.
Clamp slide HP sensor does not switch from ON → OFF within 1 s when resetting the
511
clamp.
512 Overload current detection (It is not monitored between 100ms after motor ON)
The master-making unit is in the incorrect position when starting positioning the clamp unit
513
at the forth position.
The machine type communication error is occurred when positioning the clamp unit at the
562
forth position.
The machine type communication error is occurred when positioning the clamp unit at the
563
back position.
[16 - 6]
CHAPTER 16. PANEL MESSAGES
DETAILED LIST OF PANEL MESSAGES
[16 - 7]
CHAPTER 16. PANEL MESSAGES
DETAILED LIST OF PANEL MESSAGES
[16 - 8]
CHAPTER 16. PANEL MESSAGES
DETAILED LIST OF PANEL MESSAGES
[16 - 9]
CHAPTER 16. PANEL MESSAGES
DETAILED LIST OF PANEL MESSAGES
[16 - 10]
CHAPTER 16. PANEL MESSAGES
DETAILED LIST OF PANEL MESSAGES
[16 - 11]
CHAPTER 16. PANEL MESSAGES
DETAILED LIST OF PANEL MESSAGES
Clamp slide HP sensor does not switch from OFF → ON and the slide return sensor does
508
not switch OFF within 2 s during the clamp slide HP resetting (forward) operation.
Clamp slide HP sensor does not switch from ON → OFF within 1 s during the clamp slide
509
HP resetting (forward) operation.
Clamp slide HP sensor does not switch from OFF → ON and the slide return sensor does
510
not go ON within 2 s during the clamp slide resetting operation.
Clamp slide HP sensor does not switch from ON → OFF within 1 s during the clamp slide
511
resetting operation.
512 Overload current detection (It is not monitored between 100ms after motor ON)
The master-making unit is in the incorrect position when starting positioning the clamp unit
513
at the forth position.
The machine type communication error is occurred when positioning the clamp unit at the
562
forth position.
The machine type communication error is occurred when positioning the clamp unit at the
563
back position.
[16 - 12]
CHAPTER 16. PANEL MESSAGES
DETAILED LIST OF PANEL MESSAGES
[16 - 13]
CHAPTER 16. PANEL MESSAGES
DETAILED LIST OF PANEL MESSAGES
[16 - 14]
CHAPTER 16. PANEL MESSAGES
DETAILED LIST OF PANEL MESSAGES
Error type T38 [1st clamp opening and closing motor lock]
T38-***
Panel display !!System Error!!
Call Service
Reset method To be reset by Technician only
Error point Error conditions
542 0 angular sensor does not go ON within 3s when opening the end clamp.
544 180 angular sensor does not go ON within 3s when opening the top clamp.
Clamp plate loading position sensor does not go ON within 1.5s when half-closing the top
546
clamp.
548 0 angular sensor does not go ON within 1.5s when closing the top clamp.
550 Clamp plate home position sensor does not go ON within 1.5s when half-closing the end clamp.
552 180 angular sensor does not go ON within 1.5s when closing the end clamp.
554 Overload current detection
Clamp plate home position sensor is ON at the start of the open and close returning operation
555 and clamp plate home position sensor dose not go OFF within 3s during the rotation of the motor
toward 180 angular.
Clamp plate home position sensor dose not switch from OFF to ON within 3s during the rotation
556
of the motor toward 0 angular when the open and close returning.
Clamp plate home position sensor dose not switch from ON to OFF within 3s during the rotation
557 of the motor toward 180 angular after the clamp plate home position sensor switching from ON
to OFF when the open and close returning.
[16 - 15]
CHAPTER 16. PANEL MESSAGES
DETAILED LIST OF PANEL MESSAGES
[16 - 16]
CHAPTER 16. PANEL MESSAGES
DETAILED LIST OF PANEL MESSAGES
Error type T45 [2nd clamp opening and closing motor lock]
T45-***
Panel display !!System Error!!
Call Service
Reset method To be reset by Technician only
Error point Error conditions
542 0 angular sensor does not go ON within 3s when opening the end clamp.
544 180 angular sensor does not go ON within 3s when opening the top clamp.
Clamp plate loading position sensor does not go ON within 1.5s when half-closing the top
546
clamp.
548 0 angular sensor does not go ON within 1.5s when closing the top clamp.
Clamp plate home position sensor does not go ON within 1.5s when half-closing the end
550
clamp.
552 180 angular sensor does not go ON within 1.5s when closing the end clamp.
554 Overload current detection
Clamp plate home position sensor is ON at the start of the open and close returning
555 operation and clamp plate home position sensor dose not go OFF within 3s during the
rotation of the motor toward 180 angular.
Clamp plate home position sensor dose not switch from OFF to ON within 3s during the
556
rotation of the motor toward 0 angular when the open and close returning.
Clamp plate home position sensor dose not switch from ON to OFF within 3s during the
557 rotation of the motor toward 180 angular after the clamp plate home position sensor
switching from ON to OFF when the open and close returning.
[16 - 17]
CHAPTER 16. PANEL MESSAGES
DETAILED LIST OF PANEL MESSAGES
Error type T48 [1st inner pressure error (when the print drive is engaged) ]
T48-***
Panel display !!System Error!!
Call Service
Reset method To be reset by Technician only
Error point Error conditions
The print drum was installed in the condition of the inner pressure roller was at the pressure
558
position. (Inner pressure detection sensor was ON)
Error type T49 [2nd inner pressure error (when the print drive is engaged) ]
T49-***
Panel display !!System Error!!
Call Service
Reset method To be reset by Technician only
Error point Error conditions
The print drum was installed in the condition of the inner pressure roller was at the pressure
558
position. (Inner pressure detection sensor was ON)
[16 - 18]
CHAPTER 16. PANEL MESSAGES
DETAILED LIST OF PANEL MESSAGES
[16 - 19]
CHAPTER 16. PANEL MESSAGES
DETAILED LIST OF PANEL MESSAGES
[16 - 20]
CHAPTER 16. PANEL MESSAGES
DETAILED LIST OF PANEL MESSAGES
[16 - 21]
CHAPTER 16. PANEL MESSAGES
DETAILED LIST OF PANEL MESSAGES
Error type A29 [1st print drum clamp plate status error]
A29-***
Panel display
Pull Out Print Drum 1 and Check Clamp Plate Position
Pull out 1st Print Drum. (1st Print Drum set sensor switches OFF and 1st Print Drum
Reset method
connection signal switches OFF)
Error point Error conditions
564 Angular safety sensor was ON when the end clamp was opened.
Error type A30 [2nd print drum clamp plate status error]
A30-***
Panel display
Pull Out Print Drum 2 and Check Clamp Plate Position
Pull out print 2nd print drum. (2nd print drum set sensor switches OFF and print 2nd print
Reset method
drum connection signal switches OFF)
Error point Error conditions
564 Angular safety sensor was ON when the end clamp was opened.
The 1st print drum set sensor detects the 1st print drum. (The 1st print drum set sensor, the
Reset method
1st print drum connection signal, and the 1st print drum lock position sensor all go ON.)
[16 - 22]
CHAPTER 16. PANEL MESSAGES
DETAILED LIST OF PANEL MESSAGES
[16 - 23]
CHAPTER 16. PANEL MESSAGES
DETAILED LIST OF PANEL MESSAGES
Refer to below for the meaning of the four phrases as used on this page.
slack jam: 1st paper sensor does not switch ON during paper drum angle 180-236 degrees.
paper feed jam: 2nd paper sensor does not switch ON during paper drum angle 270-310 degrees.
Paper jam below the
paper ejection sensor does not switch ON during paper drum angle 530-580 degrees.
paper drum:
Paper ejection jam: paper ejection sensor was ON at drum angle 840 degrees.
[16 - 24]
CHAPTER 16. PANEL MESSAGES
DETAILED LIST OF PANEL MESSAGES
Option errors
Error type B01 [Keycard counter]
B01-***
Panel display
Insert Card in Key/Card Counter
Reset method Insert card
Error point Error conditions
027 No card
[16 - 25]
CHAPTER 16. PANEL MESSAGES
DETAILED LIST OF PANEL MESSAGES
[16 - 26]
CHAPTER 16. PANEL MESSAGES
DETAILED LIST OF PANEL MESSAGES
[16 - 27]
CHAPTER 16. PANEL MESSAGES
DETAILED LIST OF PANEL MESSAGES
[16 - 28]
CHAPTER 16. PANEL MESSAGES
DETAILED LIST OF PANEL MESSAGES
[16 - 29]
CHAPTER 16. PANEL MESSAGES
DETAILED LIST OF PANEL MESSAGES
[16 - 30]
CHAPTER 16. PANEL MESSAGES
DETAILED LIST OF PANEL MESSAGES
[16 - 31]
CHAPTER 16. PANEL MESSAGES
DETAILED LIST OF PANEL MESSAGES
Warnings (Miscellaneous)
Error type F01 [No master on 1st print drum]
No Master on Print Drum
Panel display
Make a New Master
Reset method Switch to master making mode to clear.
Error point Error conditions
050 No master on the print drum at the start of printing
[16 - 32]
CHAPTER 16. PANEL MESSAGES
DETAILED LIST OF PANEL MESSAGES
[16 - 33]
CHAPTER 16. PANEL MESSAGES
DETAILED LIST OF PANEL MESSAGES
[16 - 34]
CHAPTER 16. PANEL MESSAGES
DETAILED LIST OF PANEL MESSAGES
[16 - 35]
CHAPTER 16. PANEL MESSAGES
ERRORS REQUIRING SPECIAL ACTION
[16 - 36]
CHAPTER 17: TEST MODE
Contents
[17 - 1]
CHAPTER 17. TEST MODE
PROCEDURES
1. Procedures
1) Start-up Procedure
Switch on power while simultaneously pressing the “←” and “→” print positioning keys on the panel. This
initiates test mode in standby mode.
2) Operating Procedure
Test mode numbers can be entered (selected) via “Key entry” or “Menu selection.”
a) Key entry procedure
(1) In standby mode, enter the number of the test mode to be run using the numeric keys. If you
make a mistake during entry, you can perform entry once again by pressing the “C” key.
(2) Press the “Start” key to initiate Test mode operations.
(3) Press the “Stop” or “Start” key to end Test mode and return to standby or operation standby
modes.
* After setting data, press the “Start” key to confirm the modified data and return to standby mode.
Press the “Stop” key to cancel settings before returning to standby mode.
b) Menu selection method
(1) While in standby mode, select the unit containing the test item to be run from the Test mode
menu.
• Press the unit name on the LCD screen. (Unit name is highlighted.)
• The Test mode sub-menu appears.
(2) Select the test item to be run from the Test mode sub-menu.
• Press the test item on the LCD screen. (Test item is highlighted.)
(3) Press the “Start” key to initiate Test mode operations.
(4) Press the “Stop” or “Start” key to end the Test mode operation and return to standby mode or
operation standby mode.
* After setting data, press the “Start” key to confirm the modified data and return to standby mode.
Press the “Stop” key to cancel the settings before returning to standby mode.
3) Ending procedure
To exit the Test mode, press the “Reset” key for at least 1 second during test mode standby mode or test
mode operation standby mode.
[17 - 2]
CHAPTER 17. TEST MODE
INDIVIDUAL TEST PROCEDURES
[17 - 3]
CHAPTER 17. TEST MODE
SYSTEM/CNTRL PANEL TEST MODE
[17 - 4]
CHAPTER 17. TEST MODE
SYSTEM/CNTRL PANEL TEST MODE
[17 - 5]
CHAPTER 17. TEST MODE
SYSTEM/CNTRL PANEL TEST MODE
[17 - 6]
CHAPTER 17. TEST MODE
PROCESS/SCANNING TEST MODE
[17 - 7]
CHAPTER 17. TEST MODE
PROCESS/SCANNING TEST MODE
[17 - 8]
CHAPTER 17. TEST MODE
PROCESS/SCANNING TEST MODE
[17 - 9]
CHAPTER 17. TEST MODE
MASTER MAKING TEST MODE
[17 - 10]
CHAPTER 17. TEST MODE
MASTER MAKING TEST MODE
Description Adjusts the master-making area (adjusts master making signal ON time).
Range: -100 to +100 (-10.0 mm to +10.0 mm)
* (+ increases length)
Setting
Units: 1 (0.1 mm)
Default: 0 mm
283 Master Clamp Range Adjustment O
Adjusts the master clamp range when loading the master (distance from
Description
master positioning sensor).
Range: -1000 to +1000 (-10.0 mm to +10.0 mm)
* (+ increases clamp range)
Setting
Units: 1 (0.01 mm)
Default: 0 mm
284 Master Cut Position Adjustment O
Description Adjusts the length of one master (rear clamp amount).
Range: -1000 to +500 (-10.00 mm to +5.00 mm)
* (+ increases master length)
Setting
Units: 1 (0.01 mm)
Default: -800 (-8.00 mm)
285 Master Image Front Margin Adjust
Adjusts the master margin (mask amount in image processing) at the right
Description
(front) of the copy.
Range: -40 to +40 (-4.0 mm to +4.0 mm)
* (+ increases margin)
Setting
Units: 1 (0.1 mm)
Default: 0 mm
286 Master Image Rear Margin Adjust
Adjusts the master margin (mask amount in image processing) at the left
Description
(rear) of the copy.
Range: -40 to +40 (-4.0 mm to +4.0 mm)
* (+ increases margin)
Setting
Units: 1 (0.1 mm)
Default: 0 mm
287 Master-Making Speed Adjustment (New Master Making Unit Only) O
Adjusts image elongation and shrinkage during master making by varying the
Description
speed of the write pulse motor.
Range: -100 to +100
* (+ shrinks)
Setting
Units: 1 (0.125 mm)
Default: 0 mm
288 TPH Resistance Value Entry
Description Sets the TPH resistance value.
Range: 1200 to 5300 (1200 Ω to 5300 Ω )
Setting Units: 1 (1 Ω )
Default: 1200 Ω
[17 - 11]
CHAPTER 17. TEST MODE
MASTER MAKING TEST MODE
[17 - 12]
CHAPTER 17. TEST MODE
MASTER MAKING TEST MODE
[17 - 13]
CHAPTER 17. TEST MODE
MASTER DISPOSAL TEST MODE
[17 - 14]
CHAPTER 17. TEST MODE
MASTER DISPOSAL TEST MODE
[17 - 15]
CHAPTER 17. TEST MODE
PAPER FEED/EJECT TEST MODE
[17 - 16]
CHAPTER 17. TEST MODE
PAPER FEED/EJECT TEST MODE
[17 - 17]
CHAPTER 17. TEST MODE
PAPER FEED/EJECT TEST MODE
[17 - 18]
CHAPTER 17. TEST MODE
PAPER FEED/EJECT TEST MODE
[17 - 19]
CHAPTER 17. TEST MODE
PRINT DRUM TEST MODE
[17 - 20]
CHAPTER 17. TEST MODE
PRINT DRUM TEST MODE
Prints 250 sheets or until the STOP key is pressed at fixed printing speed of 5 and
printing density of 3.
No inking action and deactivation of ink sensor.
Make sure to make master by test mode No.50 before activating test mode No.558
[17 - 21]
CHAPTER 17. TEST MODE
PRINT DRUM TEST MODE
Range: 1 to 60 (1 to 60 s)
Setting Units: 1 (1 s)
Default: 40 s
[17 - 22]
CHAPTER 17. TEST MODE
PRINT DRUM TEST MODE
[17 - 23]
CHAPTER 17. TEST MODE
PRINT DRUM TEST MODE
Sets the m otor rotation tim e adjus tm ent tim er for clos ing the m as ter top clam p.
Des cription (The rotation tim e is extended for the open/clos e m otor clos ing the m as ter top
clam p during m as ter loading to prevent lifting of the clam p plate.)
[17 - 24]
CHAPTER 17. TEST MODE
PRINTING TEST MODE
[17 - 25]
CHAPTER 17. TEST MODE
PRINTING TEST MODE
[17 - 26]
CHAPTER 17. TEST MODE
ACCESSORIES 1 TEST MODE
[17 - 27]
CHAPTER 17. TEST MODE
ACCESSORIES 1 TEST MODE
[17 - 28]
CHAPTER 17. TEST MODE
ACCESSORIES 1 TEST MODE
[17 - 29]
CHAPTER 17. TEST MODE
FACTORY MODE TEST MODE
[17 - 30]
CHAPTER 18: FUNCTIONS
Contents
[18 - 1]
CHAPTER 18. FUNCTIONS
1. Configuration
The function setting sub-screen contains the following items:
(1) Selections
(2) Memory
(3) Programs
(4) Other settings (Functions list/Properties)
[18 - 2]
CHAPTER 18. FUNCTIONS
Refer to the “USERS GUIDE” for the Functions that can be viewed and set on the sub-screen, and also
of the Items that can be saved in memory.
Refer to the “USERS GUIDE” for the details. (Jump to Users Guide)
[18 - 3]
CHAPTER 18. FUNCTIONS
MEMO
[18 - 4]
CHAPTER 19: OTHER PRECAUTIONS
Contents
[19 - 1]
CHAPTER 19. OTHER PRECAUTIONS
P1901 P1902
2. Battery Replacement
Replace the battery on the SH-PCB or MCTL PCB with power switched on.
* To prevent data loss, always replace with the power switched on.
[19 - 2]
CHAPTER 19. OTHER PRECAUTIONS
P1903 P1904
DIMM
P1906
P1905
BATTERY
P1907
[19 - 3]
CHAPTER 19. OTHER PRECAUTIONS
[19 - 4]
CHAPTER 20: PRINTED CIRCUIT BOARDS
Contents
[20 - 1]
1.
CN2
MAIN DRUM PCB 1
CN1
MOTOR (on drum No.1)
CN1
ELEVATOR CN7
MOTOR CN10 MAIN DRIVE CN5 CN2
DRUM PCB 2
CN4 PCB CN1
(on drum No.2)
CN9
CN1 SIDE DRIVE
CN10
CN3
CN2
CN3
CN10
CN13
CN7 CN17 PCB 1
CN1 POWER MCTL PCB CN2
CN8 CN18
POWER SW CN9 SUPPLY (Mechanical CN4
CN6
PCB Control PCB)
CN1 SIDE DRIVE
PCB 2
CN7
CN9
CN20
CN11
CHAPTER 20. PRINTED CIRCUIT BOARDS
SCANNER CN1
[20 - 2]
UNIT
CN8
LED UNIT
CN2
RIPU PCB (Service LED PCB)
CN5
Connection Diagram Between Boards
(Image PCB)
CN1
CN2
DIGITIZER
CN4
CPU PCB
TPH POWER CN1 CN3 CN2
CN3 CN4
SUPPLY PCB SH-PCB NET-B PCB
CN2 CN5
Master Making CN1 CN10
CN1
TPH CN1 PCB
CN1
2. PCBs
Br 1
CN11 CN4 1
-S +S
Rd 2 2
G6 N.C.
Or 3 3
G6 -S
Yw 4
G6
Gr 5
G6
Bl 6
G6
Vt 7
G6
Gy 8
G6 Cooling
Wh 9
G6
Fan
Bk 10
TPH Power PCB G6
Br 11
CN2 TPH
Rd 12 CN5
TPH
Or 13 1
TPH G4
Yw 14 2
TPH 24V-A
Gr 15
MCTL PCB
4 AC OUT(N) Rd 4 4 Br 1 G4
AC IN(L) 13 Or 13
5 5 Rd 2 G4
AC IN(N) 14 Yw 14
6 6 G4
15 Gr 15
24V-A
16 Bl 16
24V-A
17 Vt 17
24V-B
18 Gy 18
1 AC(L) Bk 1 1 24V-B
19 Wh 19
Power 2 AC(N) Wh 2 2 24V-C
20 Bk 20
Inlet 3 FG(E) 3 3 24V-C
24V-D
21 Br 21
22 Rd 22
Gr/Yw 24V-D
FG
CN8 1 Br 1 CN18
24V P.F(OUT)
2 Rd 2
N.C.
CN10 1 Br 1
CN10 TPH-CTRL(IN)
3 Or 3
G1 4 Yw 4
2 Rd 2 DADAT SIGNAL (IN)
5.1V-1 5 Gr 5
3 Or 3 DACLK SIGNAL (IN)
G4 6 Bl 6
4 Yw 4 DALAT SIGNAL (IN)
G4 7 Vt 7
5 Gr 5 G1
G4
6 Bl 6
G4
7 Vt 7
G4
8 Gy 8
G4
9 Wh 9
24V-A
CN6
1 Br 1 CN4
10 Bk 10 G1
Main Drive PCB
24V-A 2 Rd 2
11 Br 11 G1
24V-B 3 Or 3
12 Rd 12 5.1V-1
24V-B 4 Yw 4
13 Or 13 5.1V-1
24V-C 5 Gr 5
14 Yw 14 G4
24V-C 6 Bl 6
SH-PCB
15 Gr 15 G4
G2 7 Vt 7
16 Bl 16 24V-D
18V-1 8 Gy 8
17 Vt 17 24V-D
G3 9 Wh 9
18 Gy 18 G1
18V-2 10 Bk 10
G1
11 Br 11
5.1V-2
12 Rd 12
5.1V-2
CN4 1 Or 1
CN3 STAND-BY
13 Or 13
24V-IN 14 Yw 14
2 Or 2 AUTO POWER-OFF
N.C. 15 Gr 15
3 Or 3 N.C.
TPHRL_OUT 16 16
100V-P.F
17 Vt
G1
18 Gy
CN2 G1
CN9 19 Wh
1 Bl 1 G1
G5 20 Bk
2 Bl 2 5.1V-1
3 Bl 3
G5
5.1V-1
21 Br 1 CN8
G5 22 Rd 2
4 Rd 4 5.1V-1
RIPU PCB
(Image PCB)
36V 23 Or 3
5 Rd 5 G4
36V 24 Yw 4
6 Rd 6 G4
36V 25 Gr 5
24V-E
26 Bl 6
24V-E
7
8
9
10
[20 - 3]
CHAPTER 20. PRINTED CIRCUIT BOARDS
[20 - 4]
CHAPTER 20. PRINTED CIRCUIT BOARDS
2-2-1. SH-PCB
D-SUB 37pin
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
1
2
3
4
5
6
7
8
9
Bk
Bk
Bk
Bk
Bk
Bk
Bk
Bk
Bk
Bk
Bk
Bk
Bk
Bk
Bk
Bk
Bk
Bk
Bk
Bk
Bk
Bk
Bk
Bk
Bk
Bk
Bk
Bk
Bk
Bk
Bk
Bk
Bk
Bk
Bk
Bk
Bk
Bk
10
11
12
13
14
15
16
17
18
19
20
40
39
38
37
36
35
34
33
32
31
30
29
28
27
26
25
24
23
22
21
1
2
3
4
5
6
7
8
9
PWR GND
HSYNC+
CRRDY+
RDCLK+
VSYNC+
RHE+
STRDY+
PWR
BUSY+
CMD+
DCLK+
CONN
HE+
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
GND
GND
CN9
HSYNC-
RDCLK-
VSYNC-
STATUS+
RHE-
CMD-
DCLK-
SDATA+
CRRDY-
V
HE-
PDATA+
STRDY-
BUSY-
STATUS-
SDATA-
PDATA-
13 Vt 1
CN1 CN10 A1 Or B1
CN9 12 Vt 2
RXD J5V
A2 Or B2
CN1
/CTS D0
11 Vt 3 A3 Gy B3
GND J5V
10 Vt 4 A4 Gy B4
TXD D1
9 Vt 5 A5 Wh B5
/RTS J5V
8 Vt 6 A6 Wh B6
(Mechanical Control PCB)
GND D2
7 Vt 7 A7 Yw B7
/RTS 5V
6 Vt 8 A8 Yw B8
GND D3
5 Vt 9 A9 Pk B9
INTO 5V
4 Vt 10 A10 Pk B10
N.C. D4
3 Vt 11 A11 Or B11
MCTL PCB
INT IO 5V
2 Vt 12 A12 Or B12
GND D5
1 Vt 13 A13 Gy B13
GND 5V
A14 Gy B14
D6
26 Vt 14 A15 Wh B15
T-POSITION 5V
25 Vt 15 A16 Wh B16
PAPER SENSOR D7
19 A3
N.C. B10 Pk A10
18 GND
RTS_NIC B11 Or A11
17 A4
TXD_NIC B12 Or A12
1 Vt 16 GND
CN2 3 Vt 15
STB-A
/RD
B13 Gy A13
PAD0 B14 Gy A14
5 Vt 14 GND
PAD1 B15 Wh A15
7 Vt 13 /WR
PAD2 B16 Wh A16
9 Vt 12 GND
PAD3 B17 Yw A17
11 Vt 11 TXD
PAD4 B18 Yw A18
13 Vt 10 GND
PAD5 B19 Pk A19
15 Vt 9 R_LED
PAD6 B20 Pk A20
17 Vt 8 /RESET
PAD7
19 Vt 7
ACK-A
21 Vt 6
23 Vt 5
BSY-A CN4 1 Br 1
25 Vt 4
PE-A GND
2 Rd 2
CN6
SLCT-A GND
27 Vt 3 3 Or 3
ATFD-A 5V
NET-B PCB
29 Vt 2 4 Yw 4
MRST 5V
31 Vt 1 5 Gr 5
5V P GND
6 Bl 6
P GND
32 Vt 38 7 Vt 7
5V 24V
30 Vt 37 8 Gy 8
SLCTIN-A 24V
28 Vt 36 9 Wh 9
FLT-A GND
26 Vt 35 10 Bk 10
INIT-A GND
24 Vt 34 11 Br 11
NICCOM J5V
22 Vt 33 12 Rd 12
GND J5V
20 Vt 32 13 Or 13
GND P_ON
18 Vt 31 14 Yw 14
GND AUTO SHUT OFF
16 Vt 30 15 Gr 15
GND N.C.
14 Vt 29 16 Bl 16
GND NMI
12 Vt 28
GND
10 Vt 27
GND
8 Vt 26
GND
6 Vt 25
GND RIPU3 (Image) PCB
4 Vt 24
2 Vt 23
GND CN6 CN1
GND Board to Board
22
RXD_NIC
21
CTS_NIC
20
N.C.
SLCTIN-B
CN11
ATFD-B
CN2
SLCT-B
ACK-B
STB-B
BSY-B
PBD0
PBD1
PBD2
PBD3
PBD4
PBD5
PBD6
PBD7
FLT-B
INT-B
PE-B
/CTS
/RTS
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
DCD
RXD
DSR
DTR
TXD
N.C.
N.C.
N.C.
N.C.
PLH
RI
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
1
2
3
4
5
6
7
8
9
1
2
3
4
5
6
7
8
9
[20 - 5]
CHAPTER 20. PRINTED CIRCUIT BOARDS
A1
CN5 CN2 A1 Br 1 1 Br A1
A2
/LST GNDA
A2 Wh 2 2 Wh A2
CN1
/OPT_HE DNDB
A3 A3 Rd 3 3 Rd A3
DGCLK DNDB
A4 A4 Wh 4 4 Wh A4
SK-SIG GND
A5 A5 Or 5 5 Or A5
STMPDAT1 GND
A6 A6 Wh 6 6 Wh A6
/SAREA VD0
A7 A7 Yw 7 7 Yw A7
/WHITE VD1
A8 A8 Wh 8 8 Wh A8
/NEGA VD2
A9 A9 Gr 9 9 Gr A9
/CHARA VD3
A10 A10 Wh 10 10 Wh A10
/CTS VD4
A11 A11 Bl 11 11 Bl A11
/RTS VD5
A12 A12 Wh 12 12 Wh A12
/RE_RES VD6
A13 A13 Vt 13 13 Vt A13
RDCK VD7
A14 A14 Wh 14 14 Wh A14
D0 DCLK
A15 A15 Gy 15 15 Gy A15
D2 /LST
A16 A16 Wh 16 16 Wh A16
GND /INT_S2M
A17 A17 17 17 Pk A17
Scanner Unit
Pk
D4 RXD
A18 A18 Wh 18 18 Wh A18
D6 TXD
A19 A19 Bk 19 19 Bk A19
GND /RTS
A20 A20 Wh 20 20 Wh A20
/RESET /RESET
A21
GND
A22 B1 Br 21 21 Br B1
GND 24VA
A23 B2 Wh 22 22 Wh B2
GND 24VB
A24 B3 Rd 23 23 Rd B3
GND 24VB
A25 B4 Wh 24 24 Wh B4
GND24 VCC
To DIGITIZER B5 Or 25 25 Or B5
VCC
(OPTION) B1 B6 Wh 26 26 Wh B6
GND GND
B2 B7 Yw 27 27 Or B7
GND GND
B3 B8 Wh 28 28 Wh B8
GND GND
B4 B9 Gr 29 29 Gr B9
GND GND
B5 B10 Wh 30 30 Wh B10
GND GND
B6 B11 Bl 31 31 Bl B11
/DGT_VSYNC GND
B7 B12 Wh 32 32 Wh B12
/BLACK GND
B8 B13 Vt 33 33 Vt B13
/PHOTO GND
B9 B14 Wh 34 34 Wh B14
/AMI GND
B10 B15 Gy 35 35 Gy B15
RXD GND
B11 B16 Wh 36 36 Wh B16
TXD /CTS
B12 B17 Pk 37 37 Pk B17
/LCDSET GND
B13 B18 Wh 38 38 Wh B18
GND SCLK
B14 B19 Bk 39 39 Bk B19
(Image PCB)
D1 TRIG
B15 B20 Wh 40 40 Wh B20
RIPU PCB
D3 /INT_M2S
B16
GND
B17
D5
B18
D7
B19
GND
B20
/DG_EXIST
B21
B22
+5V CN4 1 Bl 1
B23
+5V TPH2
2 Bl 2
CN3
+5V TPH3
B24 3 Bl 3
+5V TPH4
B25 4 Bl 4
+24V THERM
5 Bl 5
TPH0
6 Bl 6
TPH1
7 Bl 7
/STB1
CN7 8 Bl 8
TPHCLK1
Master Making PCB
1 9 Bl 9
GND /LATCH1
2 10 Bl 10
GND DI1
3 11 Bl 11
/CC_CLK GND
4 12 Bl 12
/CC_LST GND
5 13 Bl 13
/CC_DATA GND
6 14 Bl 14
/CARD_REQ VCC
7 15 Rd 15
RXD VCC
8 16 Rd 16
To KEY/CARD TXD VCC
9 17 Rd 17
COUNTER /CUNT_OP /STB2
10 18 Rd 18
(OPTION) /CUNT_SET TPHCLK2
11 19 Rd 19
/MASTER COUNT /LATCH2
12 20 Rd 20
/COPY COUNT DI2
13 21 Rd 21
/CARD_ACK /STB3
14 22 Rd 22
+5V TPHCLK3
15 23 Rd 23
+5V /LATCH3
16 24 Rd 24
/CC CONNECTIVITY DI3
17 25 Rd 25
/CC CONNECTIVITY GND /STB4
26 Rd 26
TPHCLK4
27 Rd 27
/LATCH4
28 Rd 28
DI4
CN8
Power Supply PCB
1 Vt 17
SH-PCB G1
2 Gy 18
CN6
CN6 CN1 G1
3 Wh 19
Board to Board G1
4 Bk 20
5.1V-1
5 Br 21
5.1V-1
6 Rd 22
5.1V-1
7 Or 23
G4
8 Yw 24
G4
9 Gr 25
24V-E
10 Bl 26
24V-E
[20 - 6]
CHAPTER 20. PRINTED CIRCUIT BOARDS
1
CN6 Yw 12 1 Yw 2 1
GND
MULTIPLE PAPER FEED SWITCH
2 Yw 11 2 Yw 1 2 SW MULTIPLE PAPER FEED SWITCH
3 Yw 10 3 Yw 2
1st PAPER FEED SENSOR(SEND) GND 4 Yw 9 4 Yw 1 SEN 1st PAPER FEED SENSOR (SEND)
1st PAPER FEED SENSOR(SEND) Vcc 5 Yw 8 5 Yw 3
1st PAPER FEED SENSOR(RCV) GND 6 Yw 7 6 Yw 2
1st PAPER FEED SENSOR (RECIEVE) 7 Yw 6 7 Yw 1
SEN 1st PAPER FEED SENSOR (RECIEVE)
1st PAPER FEED SENSOR (RCV) Vcc 8 Yw 5 8 Yw 2
2nd PAPER FEED SENSOR(SEND) GND 9 Yw 4 9 Yw 1 SEN 2nd PAPER FEED SENSOR (SEND)
2nd PAPER FEED SENSOR(SEND) Vcc 10 Yw 3 10 Yw 3
MULTI-PAPER FEED DET. SENSOR (RCV) GND 11 Yw 2 11 Yw 2
MULTI-PAPER FEED DET. SENSOR (RCV)
12 Yw 1 12 Yw 1 SEN MULTIPLE PAPER FEED DETECTION SENSOR (RECEIVE)
MULTI-PAPER FEED DET. SENSOR (RCV) Vcc
A10 A1
CN5 A1 Yw A9 A2 Yw 3
GND
A2 Yw A8 A3 Yw 2
PAPER FEED PRESSURE SENSOR (THICK)
A3 Yw A7 A4 Yw 1 SEN PAPER FEED PRESSURE SENSOR (THICK)
VCC
A4 Yw A6 A5 Yw 3
GND
A5 Yw A5 A6 Yw 2
PAPER FEED PRESSURE SENSOR (THIN) (Not Used)
A6 Yw A4 A7 Yw 1
VCC
A7 Yw A3 A8 Yw 3
GND
A8 Yw A2 A9 Yw 2
ELEVATOR UPPER LIMIT SENSOR (A)
A9 Yw A1 A10 Yw 1
SEN ELEVATOR UPPER LIMIT SENSOR (A)
VCC
A10 Yw B10 B1 Yw 3
GND
A11 Yw B9 B2 Yw 2
ELEVATOR UPPER LIMIT SENSOR (B)
A12 Yw B8 B3 Yw 1
SEN ELEVATOR UPPER LIMIT SENSOR (B)
VCC
A13 Yw B7 B4 Yw 3
2nd PAPER FEED SENSOR (RCV) GND
A14 Yw B6 B5 Yw 2
2nd PAPER FEED SENSOR (RCV)
A15 Yw B5 B6 Yw 1 SEN 2nd PAPER FEED SENSOR (RECEIVE)
2nd PAPER FEED SENSOR (RCV) Vcc
A16 Yw B4 B7 Yw 2 1 Wh
GND
PAPER FEED TRAY BUTTON
A17 Yw B3 B8 Yw 1 2 Wh SW PAPER FEED TRAY BUTTON
MULTI-PAPER FEED DET. SENSOR (SEND) A18 Yw B2 B9 Yw 2
MULTI-PAPER FEED DET. SENSOR (SEND)Vcc
A19 Yw B1 B10 Yw 1 SEN MULTIPLE PAPER FEED DETECTION SENSOR (SEND)
B1 Yw 9 1 Bl 9 1 Br 3
GND
B2 Yw 8 2 Bl 8 2 Rd 2
PAPER DETECTION SENSOR
B3 Yw 7 3 Bl 7 3 Or 1
SEN PAPER DETECTION SENSOR
VCC
B4 Yw 6 4 Bl 6 4 Yw 3
GND
B5 Yw 5 5 Bl 5 5 Gr 2
PAPER SIZE DETECTION SENSOR
B6 Yw 4 6 Bl 4 6 Bl 1
SEN PAPER SIZE DETECTION SENSOR
VCC
B7 Yw 3 7 Bl 3 7 Vt 3 3
GNDA
B8 Yw 2 8 Bl 2 8 Gy 2 2
PAPER WIDTH POTENTIOMETER B9 Yw 1 9 Rd 1 9 Wh 1 1
VR PAPER WIDTH POTENTIOMETER
AVCC
B10 Yw
GND
B11 Yw
PAPER VOLUME DET. SENSOR (A)
B12 Yw 10 1 Vt 3
VCC
B13 Yw 9 2 Vt 2
GND
B14 Yw 8 3 Vt 1 SEN PAPER VOLUME DETECTION SENSOR (A)
PAPER VOLUME DET. SENSOR (B)
B15 Yw 7 4 Vt 3
VCC
B16 Yw 6 5 Vt 2
GND
B17 Yw 5 6 Vt 1 SEN PAPER VOLUME DETECTION SENSOR (B)
ELEVATOR LOWER LIMIT SENSOR
B18 Yw 4 7 Vt 3
VCC
B19 3 8 Vt 2
N.C.
2 9 Vt 1
SEN ELEVATOR LOWER LIMIT SENSOR
(Mechanical Control PCB)
1 10
CN7
15 Bl 1
WAISCK4
14 Bl 2
CN1
Master Making PCB
GND
13 Bl 3
MCTL PCB
WAISDT4
12 Bl 4
GND
11 Bl 5
WAILAT4
10 Bl 6
AVCC
9 Bl 7
WRITE ROLLER THERMISTAT
8 Bl 8
AGND
7 Bl 9
VCC
6 Bl 10
VCC
5 Bl 11
24VD
4 Bl 12
24GND
3 Bl 13
24GND
2 Bl 14
N.C.
1 Bl 15
24VR1
CN16 1 Vt 2 2
PAPER EJECTION SENSOR (SEND) GND
PAPER EJECTION SENSOR (SEND) Vcc 2 Vt 1 1 SEN PAPER EJECTION SENSOR (SEND)
3 Vt 2 1
PAPER EJECTION MOTOR
24V-B
4 Vt 1 2 M PAPER EJECTION MOTOR
5 Vt 3
GND
6 Vt 2
PAPER EJECTION ENCODER INPUT
7 Vt 1 SEN PAPER EJECTION LIMIT SENSOR
VCC (Encoder Sensor)
1 1 Or 1 1 Bk
1
CN19 Or
2 2 2 2
SW MASTER DISPOSAL BOX 1 SAFETY SWITCH
24VC OUT 3 3 Or 3 3 Wh
2
N.C.
3 Rd 1 1 Or 1 1 Bk
MASTER DIS.- BOX 1 SAFETY-SW IN
MASTER DIS.-BOX 2 SAFETY-SW OUT 4 Or 2 2 2 2
SW MASTER DISPOSAL BOX 2 SAFETY SWITCH
5 3 3 Or 3 3 Wh
N.C.
MASTER DIS.- BOX 2 SAFETY-SW IN 6 Rd
1 1 Bk
7 Or
PAPER FEED TRAY SAFETY-SW OUT 2 2
N.C.
8
3 3 Wh SW PAPER FEED TRAY SAFETY SWITCH
9 Rd
PAPER FEED TRAY SAFETY-SW IN
10 Or 1 1 Bk
PAPER EJEC.-UNIT SAFETY SW OUT
11 2 2
N.C. To PAPER EJECTION UNIT DRAWER SWITCH
PAPER EJEC.-UNIT SAFETY SW IN 12 Rd 3 3 Wh
[20 - 7]
CHAPTER 20. PRINTED CIRCUIT BOARDS
DRAWER CONNECTOR
CN15
A1 Yw A12 A1 Yw 6
PINCH PM_F_A
A2 Yw A11 A2 Yw 5
PINCH PM_F_B
A3 Yw A10 A3 Yw 4
COMA
COMB A5
A4 Yw A9 A4 Yw 3 M PINCH PULSE MOTOR (F)
Yw A8 A5 Yw 2
PINCH PM_F_/A
A6 Yw A7 A6 Yw 1
PINCH PM_F_/B A7 Yw A6 A7 Yw 3
GND
A8 Yw A5 A8 Yw 2
PINCH HP (F)
A9 Yw A4 A9 Yw 1
SEN PINCH HP SENSOR (F)
VCC
A10 Yw A3 A10 Yw 3
GND
A11 Yw A2 A11 Yw 2
PINCH ROLLER RELEASE SENSOR
A12 Yw A1 A12 Yw 1
SEN PINCH ROLLER RELEASE SENSOR
VCC
B1 Yw B12 B1 Yw 3
GND
B2 Yw B11 B2 Yw 2
PAPER EJECTION SENSOR
B3 Yw B10 B3 Yw 1
SEN PAPER EJECTION SENSOR (RECEIVE)
VCC
B4 Yw B9 B4 Yw 3
GND
B5 Yw B8 B5 Yw 2
PINCH HP (R)
B6 Yw B7 B6 Yw 1 SEN PINCH HP SENSOR (R)
VCC B7 Yw B6 B7 Yw 6
PINCH PM_R_A B8 Yw B5 B8 Yw 5
PINCH PM_R_B
B9 Yw B4 B9 Yw 4
COMA
COMB
B10 Yw B3 B10 Yw 3 M PINCH PULSE MOROT (R)
PINCH PM_R_/A B11 Yw B2 B11 Yw 2
B12 Yw B1 B12 Yw 1
PINCH PM_R_/B
1
CN14 Br 2 2 Br 2 1
PINCH ROLLER RELEASE MOTOR OUT2 2
PINCH ROLLER RELEASE MOTOR OUT1
Br 3 3 Br 1 2 M PINCH ROLLER RELEASE MOTOR
1 1 Bk 1 1 Bk 1 1 Bk
2 2 2 2
SW PAPER EJECTION UNIT SAFETY SWITCH
CN19 3 3 Wh 4 4 Wh 3 3 Wh
PAPER EJECTION UNIT SAFETY SW OUT 10 Or
DRAWER CONNECTOR
N.C. 11
12 Rd 1 1 Wh 1 1 Wh 1
PAPER EJECTION UNIT SAFETY SW IN
2 2 Br 2 2 Br 2
CN2
Mechanical Contorl PCB
3 3 Br 3 3 Br 3
4 4 Br 4 4 Br 4
CN13
WAISDT1D A3 Yw A18 A3 Yw A8 A3 Yw A8 A3 Yw 8
A4 Yw A17 A4 Yw A7 A4 Yw A7 A4 Yw 7
GND
A5 Yw A16 A5 Yw A6 A5 Yw A6 A5 Yw 6
WAIENA-1D
A6 Yw A15 A6 Yw A5 A6 Yw A5 A6 Yw 5
TDATA1D
A7 Yw A14 A7 Yw A4 A7 Yw A4 A7 Yw 4
EEPROMDO1D
A8 Yw A13 A8 Yw A3 A8 Yw A3 A8 Yw 3
EEPROMDI1D
A9 Yw A12 A9 Yw A2 A9 Yw A2 A9 Yw 2
EEPROMCS1D
A10 Yw A11 A10 Yw A1 A10 Yw A1 A10 Yw 1
EEPROMSK1D
A11 Yw A10 A11 Yw B10 B1 Yw B10 B1 Yw 20
CNTSCK7-1D
A12 Yw A9 A12 Yw B9 B2 Yw B9 B2 Yw 19
GND
CNTDAT7-1D A13 Yw A8 A13 Yw B8 B3 Yw B8 B3 Yw 18
A14 Yw A7 A14 Yw B7 B4 Yw B7 B4 Yw 17
GND
A15 Yw A6 A15 Yw B6 B5 Yw B6 B5 Yw 16
CNTLAT7-1D
D-SET-1D A16 Yw A5 A16 Yw B5 B6 Yw B5 B6 Yw 15
A17 Yw A4 A17 Yw B4 B7 Yw B4 B7 Yw 14
/POSITION-A SENSOR alpha 1
A18 Yw A3 A18 Yw B3 B8 Yw B3 B8 Yw 13
/POSITION-A SENSOR beta 1
A19 Yw A2 A19 Yw B2 B9 Yw B2 B9 Yw 12
PRESSURE HP SENSOR 1
A20 Yw A1 A20 Yw B1 B10 Yw B1 B10 Yw 11
PRESSURE LIMIT SENSOR 1
(Encoder Sensor)
DRAWER CONNECTOR
B1 Yw B20 B1 Yw A10 A1 Yw 10 CN1
WAISCK2D
B2 Yw B19 B2 Yw A9 A2 Yw 9
GND
B3 Yw B18 B3 Yw A8 A3 Yw 8
WAISDT2D
B4 Yw B17 B4 Yw A7 A4 Yw 7
GND
B5 Yw B16 B5 Yw A6 A5 Yw 6
PRINT DRUM PCB (2)
WAIENA-2D
B6 Yw B15 B6 Yw A5 A6 Yw 5
TDATA2D
B7 Yw B14 B7 Yw A4 A7 Yw 4
EEPROMDO2D B8 Yw B13 B8 Yw A3 A8 Yw 3
EEPROMDI2D
B9 Yw B12 B9 Yw A2 A9 Yw 2
EEPROMCS2D B10 Yw B11 B10 Yw A1 A10 Yw 1
EEPROMSK2D
B11 Yw B10 B11 Yw B10 B1 Yw 20
CNTSCK8-2D
B12 Yw B9 B12 Yw B9 B2 Yw 19
GND
B13 Yw B8 B13 Yw B8 B3 Yw 18
CNTDAT8-2D
B14 Yw B7 B14 Yw B7 B4 Yw 17
GND
B15 Yw B6 B15 Yw B6 B5 Yw 16
CNTLAT8-2D
B16 Yw B5 B16 Yw B5 B6 Yw 15
D-SET-2D
B17 Yw B4 B17 Yw B4 B7 Yw 14
/POSITION-A SENSOR alpha 2
B18 Yw B3 B18 Yw B3 B8 Yw 13
/POSITION-A SENSOR beta 2
PRESSURE HP SENSOR 2 B19 Yw B2 B19 Yw B2 B9 Yw 12
PRESSURE LIMIT SENSOR 2 B20 Yw B1 B20 Yw B1 B10 Yw 11
CN10 1 Br 1 1 Br
24VB-D1
3 Rd 2 2 Rd
GND E
5 Or 3 3 Or
5V-D1
7 Yw 4 4 Yw
GND E
2 Gr 5 5 Gr 1 1 Wh 1
24VD-D2
4 Bl 6 6 Bl 2 2 Br 2
CN2
GND E
6 Vt 7 7 Vt 3 3 Br 3
5V-D2
8 Gy 8 8 Gy 4 4 Br 4
GND E
[20 - 8]
CHAPTER 20. PRINTED CIRCUIT BOARDS
2 Vt 12 12 Rd 9
RTS 24VR1
1 Vt 13 13 Or 10
TXD0 24GND
14 Yw 11
24GND
26 Vt 14 15 12
PFAIL (output) N.C.
25 Vt 15 16 Bl 13
PRINT SIGNAL (interrupt output) 24VB
24 Vt 16
N.C.
23 Vt 17
spare I/O4
22 Vt 18
21 Vt 19
spare I/O3 CN4 1 Br 1
CN1
4 Yw 4
VCC
5 Gr 5
VCC CN8
GNDE GND
11 Br 11 6 Bl 6
GNDE 5V
12 Rd 12 7 BlGr 7
GNDE 24VD
13 Or 13 8 Gy 8
GNDE /BUSY
14 Yw 14 9 Wh 9
GNDE TAPE JAM
15 Gr 15 10 Bk 10
24VA TAPE DETECTION
16 Bl 16 11 Pk 11
24VA SORTER DETECTIOIN
17 Vt 17 12 Lbl 12
24VB
18 Gy 18 C4
24VB
19 Wh 19 C3
24VC
20
21
Bk
Br
20
21
24VC CN11 1 Bk 1 1 Rd 1 1 Bk
C2
C1
24VD GND
22 Rd 22 2 2 2 2 2 A7
To AF UNIT CONNECTOR
24VD N.C.
3 Yw 3 3 Rd 3 3 Yw A6
+24VA
A5
Gr
A4
1 Br 1
CN18 A3
CN8 2 Rd 2
PFAIL CN12 1 Vt 10 1 Rd 10 1 Vt A2
N.C. GND
3 Or 3 GND 2 Vt 9 2 Rd 9 2 Vt A1
TPH-CTL
4 Yw 4 3 Vt 8 3 Rd 8 3 Vt B8
DADAT +5V
5 Gr 5 4 Vt 7 4 Rd 7 4 Vt B7
DACLK +5V
6 Bl 6 5 Vt 6 5 Rd 6 5 Vt B6
DALAT TXD
7 Vt 7 RXD 6 Vt 5 6 Rd 5 6 Vt B5
GND
7 Vt 4 7 Rd 4 7 Vt B4
RTS
AF START INT 8 Vt 3 8 Rd 3 8 Vt B3
9 Vt 2 9 Rd 2 9 Vt B2
1 Rd 1
CN20 AF CTS
10 Vt 1 10 Rd 1 10 Vt B1
GND AF SET
2 Gy 2
GND
3 Gr 3
GND
4 Gy 4
SENDAT1 CN3
LED UNIT CONNECTOR
[20 - 9]
CHAPTER 20. PRINTED CIRCUIT BOARDS
CN6 1 Br 4 1
Rd 1
CN1 SGND
2 Rd 3 2
MAIN MTR_+ TERMINAL MAIN MTR FG SENSOR (A)
MAIN MOTOR M
2
N.C. MAIN MTR FG SENSOR (B)
3 Or 2 3 SEN MAIN MTR FG SENSOR
Bl 3 4 Yw 1 4
MAIN MTR_- TERMINAL 5V-1
5 Gr
24VB
6 2 1
N.C.
MAIN MTR CLUTCH OUT
7 Vt 1 2 CLU MAIM MTR CLUTCH
8
1 Rd 1
CN4 N.C. 9 Wh 6 1
CN3 2 2
TPH RELAY IN MAIN PULSE MTR A
10 Bk 5 2
N.C. MAIN PULSE MTR B
3 Bl 3 11 4 3
TPH RELAY OUT N.C.
N.C.
12 3 4 M MAIN PUSE MTR
MAIN PULSE MTR/A 13 Or 2 5
14 Yw 1 6
1 Br 1
CN9 MAIN PULSE MTR/B
CN2 2 Rd 2
MAIN MTR FGB
MAIN MTR FGA
3 Or 3
4 Yw 4
MAIN MTR BRK CN7 1 Br 4
MAIN MTR EMERGENCY STOP 24VA
5 Gr 5 2 Rd 3
POWER SUPPLY PCB
CN2 1
N.C.
2 Or 1 1 Bk
FRONT DOOR 1 SAFETY SW IN
3 2 2
N.C.
4 Or 3 3 Wh SW FRONT DOOR 1 SAFETY SW
FRONT DOOR 1 SAFETY SW OUT
5 Or 1 1 Bk
FRONT DOOR 2 SAFETY SW IN
6 2 2
N.C.
7 Or 3 3 Wh SW FRONT DOOR 2 SAFETY SW
FRONT DOOR 2 SAFETY SW OUT
8
N.C.
CN3 1 Or 1 1 Or 1 1 Bk
24VC
2 2 2 2 2
N.C.
3 Rd 3 3 Rd 3 3 Wh
SW FEED TRAY UPPER SAFETY SW
FEED TRAY UPPER SAFETY SW OUT
4 Or 1 1
FEED TRAY LOWER SAFETY SW IN
5 2 2
N.C.
6 Rd 3 3 Or
FEED TRAY LOWER SAFETY SW OUT
MAIN DRIVE PCB
CN5 1 Br 1 1 Br
MAIN MTR FGB
2 Rd 2 2 Rd
CN3
MAIN MTR FGA
3 Or 3 3 Or
MAIN MTR BRAKE
4 Yw 4 4 Yw
MAIN MTR EMRGNCY STOP
5 Gr 5 5 Gr 5
(Mechanical Control PCB)
10 Bk 10 10 Bk 10
CNTSCK3
11 Br 11 11 Br 11
CNTLAT3
12 Rd 12 12 Rd 12
CNTDAT3
13 Or 13 13 Or 13
CNTSCK9
CNTLAT9 14 Yw 14 14 Yw 14
15 Gr 15 15 Gr 15
CNTDAT9
16 Bl 16 16 Bl 16
OE/CNTENA
17 Vt 17 17 VT 17
BRAKE CONTROL
18 Gy 18 18 Gy 18
N.C.
19 19 19 19
N.C.
N.C. 20 20 20 20
21 Br 21 21 Br 21
PAPER EJECTION UNIT SAFETY SW OUT
22 22 22 22
N.C.
23 23 23 23
N.C. 24 Yw 24 24 Yw 24
DOOR2 SAFETY SW OUT 25 25 25
N.C. 26 26 26
N.C.
27 Vt 27 27 Vt 4
24VA
28 Gy 28 28 Gy 3
PAPER FEED CLUTCH OUT 2 CLU PAPER FEED CLUTCH
1
[20 - 10]
CHAPTER 20. PRINTED CIRCUIT BOARDS
POSITION-T SENSOR
CN5 1 Vt 16 1 Vt 2 1
24V
OUT
2 Vt 15 2 Vt 1 2 M MASTER DISPOSAL MOTOR (1)
3 Vt 14 3 Vt 3
GND
4 Vt 13 4 Vt 2
SEN
5 Vt 12 5 Vt 1 SEN MASTER DISPOSAL LIMIT SENSOR (1)
SEN
5V (encoder sensor)
6 Vt 11 6 Vt 3
5V
7 Vt 10 7 Vt 2
GND
8 Vt 9 8 Vt 1 SEN DISPOSAL BOX EMPTY DET. SENSOR SEND (1)
3
2
1
LED
9 Vt 8 9 Vt 3
GND
Rd
10 Vt 7 10 Vt 2
Or
Br
SEN
11 Vt 6 11 Vt 1
SEN MASTER COMPRESSION HP SENSOR (1)
5V
12 Vt 5 12 Vt 3
GND
13 Vt 4 13 Vt 2
CN2 1 SEN
14 Vt 3 14 Vt 1
SEN MASTER COMPRESSION LIMIT SENSOR (1)
2 5V
15 Vt 2 15 Vt 2 1
(Mechanical Control PCB
3 CN1 OUT2
4 Yw 1 OUT1
16 Vt 1 16 Vt 1 2 M DISPOSAL PLATE MOTOR (1)
WAISCK0 17 Vt 32 17 Vt 2 1
5 Gr 2 OUT2
6 Bl 3
GND
OUT1
18 Vt 31 18 Vt 1 2 M MASTER COMPRESSION MOTOR (1)
WAISDT0 19 Vt 30 19 Vt 3
7 Vt 4 GND
MCTL PCB
VCC 20 Vt 29 20 Vt 2
8 GY 5
WAILAT0
SEN
21 Vt 28 21 Vt 1 SEN MASTER DISPOSAL JAM SENSOR (1)
9 Wh 6 5V
MASTER REMOVAL FG SENSOR 1 22 Vt 27 22 Vt 3
10 Bk 7 GND
MASTER REMOVAL PWM1 23 Vt 26 23 Vt 2
11 Br 8
24VR1
SEN
24 Vt 25 24 Vt 1 SEN DISPOSAL PLATE HP SENSOR (1)
12 RD 9 5V
24VR1 25 Vt 24 25 Vt 3
13 Or 10 GND
24GND 26 Vt 23 26 Vt 2
14 Yw 11
24GND
SEN
27 Vt 22 27 Vt 1 SEN DISPOSAL PLATE LIMIT SENSOR (1)
15 12 5V
N.C. 28 Vt 21 28 Vt 4
16 Bl 13 VOUT
24VB 29 Vt 20 29 Vt 3
GND
LED
30 Vt 19 30 Vt 2 SEN DISPOSAL BOX EMPTY DET. SENSOR RCV. (1)
31 Vt 18 31 Vt 1
5V
32 Vt 17 32
N.C.
1
CN2
2
N.C. CN6 1 Vt 8 1 Vt 2 1
N.C. OUT2
Vt 3
OUT2 OUT1
2 Vt 7 2 Vt 1 2 M CLAMP OPENING & CLOSING MOTOR (1)
Vt 4 3 Vt 6 3 Vt 3
OUT1 GND
4 Vt 5 4 Vt 2
SEN SEN CLAMP PLATE HP SENSOR (1)
2
1
5 Vt 4 5 Vt 1
5V
6 Vt 3 6 Vt 3
GND
7 Vt 2 7 Vt 2
1
2
SEN
8 Vt 1 8 Vt 1
SEN CLAMP PLATE LOADING POSITION SENSOR (1)
5V
9 Vt 5 1 Vt 5
GND
10 Vt 4 2 Vt 4
ANZEN
11 Vt 3 3 Vt 3
0DO
12 Vt 2 4 Vt 2
SEN ANGULAR SENSOR (1)
180DO
13 Vt 1 5 Vt 1
5V
14 Vt 8 1 Vt 2 1
M
OUT2
OUT1
15 Vt 7 2 Vt 1 2 M CLAMP SLIDE MOTOR (1)
16 Vt 6 3 Vt 3
GND
PRINT DRUM LOCKING MOTOR (1)
17 Vt 5 4 Vt 2
SEN
18 Vt 4 5 Vt 1 SEN CLAMP SLIDE HP SENSOR (1)
5V
SIDE DRIVE PCB (1)
19 Vt 3 6 Vt 3
GND
20 Vt 2 7 Vt 2
SEN
21 Vt 1 8 Vt 1 SEN CLAMP RETURM SLIDE SENSOR (1)
5V
22
N.C.
23
N.C.
24
N.C.
25
N.C.
26
N.C.
CN3 1 Vt 8 1 Vt 2 1 Vt
24V
OUT
2 Vt 7 2 Vt 1 2 Vt FAN MASTER TAIL CLAMP FAN a (1)
3 Vt 6 3 Vt 2 1 Vt
24V
OUT
4 Vt 5 4 Vt 1 2 Vt FAN MASTER TAIL CLAMP FAN b (1)
5 Vt 4 5 Vt 2 1 Vt
24V
OUT
6 Vt 3 6 Vt 1 2 Vt FAN MASTER TAIL CLAMP FAN c (1)
7 Vt 2 7 Vt 2 1 Vt
24V
OUT
8 Vt 1 8 Vt 1 2 Vt FAN MASTER TAIL CLAMP FAN d (1)
9 Vt 6
A
10 Vt 5
B
11 Vt 4
COM_A
COM_B
12 Vt 3 M PRINT POSITIONING PULSE MOTOR (1)
13 Vt 2
/A
14 Vt 1
/B
15 Vt 6 1 Vt 3
GND
16 Vt 5 2 Vt 2
SEN
17 Vt 4 3 Vt 1
SEN PRINT DRUM LOCK POSITION SENSOR (1)
5V
18 Vt 3 4 Vt 3
GND
19 Vt 2 5 Vt 2
SEN
20 Vt 1 6 Vt 1
SEN PRINT DRUM LOCK CAM SENSOR (1)
5V
21 Vt 3
GND
22 Vt 2
SEN
23 Vt 1 SEN PRINT DRUM SET SENSOR (1)
5V
24 Vt 3
GND
25 Vt 2
SEN
26 Vt 1 SEN VERTICAL CENTERING SENSOR (1)
5V
27
N.C.
28
N.C.
[20 - 11]
CHAPTER 20. PRINTED CIRCUIT BOARDS
1 Br 1
CN1 CN5 1 Vt 16 1 Vt 2 1
CN4 2 Rd 2
WAISCK2 24V
2 Vt 15 2 Vt 1 2 M MASTER DISPOSAL MOTOR (2)
GND OUT
3 Or 3 3 Vt 14 3 Vt 3
(Mechanical Control PCB)
WAISDT2 GND
4 Yw 4 4 Vt 13 4 Vt 2
5 Gr 5
VCC SEN
5 Vt 12 5 Vt 1 SEN MASTER DISPOSAL LIMIT SENSOR (2)
MCTL PCB
22 Vt 27 22 Vt 3
GND
23 Vt 26 23 Vt 2
SEN
24 Vt 25 24 Vt 1 SEN DISPOSAL PLATE HP SENSOR (2)
1
2
5V
25 Vt 24 25 Vt 3
GND
26 Vt 23 26 Vt 2
SEN
27 Vt 22 27 Vt 1 SEN DISPOAL PLATE LIMIT SENSOR (2)
5V
28 Vt 21 28 Vt 4
VOUT
29 Vt 20 29 Vt 3
2
1
GND
LED
30 Vt 19 30 Vt 2 SEN DISPOSAL BOX EMPTY DET. SENSOR RCV. (2)
LMP
31 Vt 18 31 Vt 1
M
5V
32 Vt 17 32
N.C.
SERVICING LAMP
PRINT DRUM
LOCKING MOTOR (2)
CN6 1 Vt 8 1 Vt 2 1
OUT2
OUT1
2 Vt 7 2 Vt 1 2 M CLAMP OPENING & CLOSING MOTOR (2)
3 Vt 6 3 Vt 3
GND
4 Vt 5 4 Vt 2
SEN
5 Vt 4 5 Vt 1 SEN CLAMP PLATE HP SENSOR (2)
5V
6 Vt 3 6 Vt 3
GND
7 Vt 2 7 Vt 2
SEN
8 Vt 1 8 Vt 1
SEN CLAMP PLATE LOADING POSITION SENSOR (2)
5V
CN4 9 Vt 5 1 Vt 5
GND
Vt 1 10 Vt 4 2 Vt 4
5V ANZEN
Vt 2 11 Vt 3 3 Vt 3
Vt 3
SEN 0DO
12 Vt 2 4 Vt 2
SEN ANGULAR SENSOR (2)
GND 180DO
Vt 4 13 Vt 1 5 Vt 1
5V 5V
Vt 5 14 Vt 8 1 Vt 2 1
SEN OUT2
Vt 6
GND OUT1
15 Vt 7 2 Vt 1 2 M CLAMP SLIDE MOTOR (2)
16 Vt 6 3 Vt 3
GND
3
2
1
3
2
1
17 Vt 5 4 Vt 2
SEN
18 Vt 4 5 Vt 1 SEN CLAMP SLIDE HP SENSOR (2)
5V
SIDE DRIVE PCB (2)
19 Vt 3 6 Vt 3
1
2
3
1
2
3
GND
20 Vt 2 7 Vt 2
SEN
21 Vt 1 8 Vt 1 SEN CLAMP RUTUN SLIDE SENSOR (2)
5V
22
N.C.
23
N.C.
24
N.C.
25
N.C.
SEN
SEN
26
N.C.
MASTER LOADING SENSOR (1)
CN3 1 Vt 8 1 Vt 2 1 Vt
24V
OUT
2 Vt 7 2 Vt 1 2 Vt FAN MASTER TAIL CLAMP FAN a (2)
3 Vt 6 3 Vt 2 1 Vt
24V
OUT
4 Vt 5 4 Vt 1 2 Vt FAN MASTER TAIL CLAMP FAN b (2)
5 Vt 4 5 Vt 2 1 Vt
24V
OUT
6 Vt 3 6 Vt 1 2 Vt FAN MASTER TAIL CLAMP FAN c (2)
7 Vt 2 7 Vt 2 1 Vt
24V
OUT
8 Vt 1 8 Vt 1 2 Vt FAN MASTER TAIL CLAMP FAM d (2)
9 Vt 6
A
10 Vt 5
B
11 Vt 4
COM_A
COM_B
12 Vt 3 M PRINT POSITIONING PULSE MOTOR (2)
13 Vt 2
/A
14 Vt 1
/B
15 Vt 6 1 Vt 3
GND
16 Vt 5 2 Vt 2
SEN
17 Vt 4 3 Vt 1
SEN PRINT DRUM LOCK POSITION SENSOR (2)
5V
18 Vt 3 4 Vt 3
GND
19 Vt 2 5 Vt 2
SEN
20 Vt 1 6 Vt 1
SEN PRINT DRUM LOCK CAM SENSOR (2)
5V
21 Vt 3
GND
22 Vt 2
SEN
23 Vt 1 SEN PRINT DRUM SET SENSOR (2)
5V
24 Vt 3
GND
25 Vt 2
SEN
26 Vt 1 SEN VERTICAL CENTERING SENSOR (2)
5V
27
N.C.
28
N.C.
[20 - 12]
CHAPTER 20. PRINTED CIRCUIT BOARDS
15 Bl 1
CN1 CN4 1 Vt 6 1
CN7 14 Bl 2
WAISCK4 A
2 Vt 5 2
GND B
13 Bl 3 3 Vt 4 3
WAISDT4 A COM
(Mechanical Control PCB)
12 Bl 4
GND B COM
4 Vt 3 4 M MASTER MAKING UNIT SHIFT MOTOR
11 Bl 5 5 Vt 2 5
WAILAT4 /A
10 Bl 6 6 Vt 1 6
AVCC /B
MCTL PCB
9 Bl 7
WRITE ROLLER THERMISTAT
8 Bl 8
AGND
7 Bl 9
6 Bl 10
VCC CN6 1 Vt 6 1
VCC A
5 Bl 11 2 Vt 5 2
24VD B
4 Bl 12 3 Vt 4 3
24GND A COM
3 Bl 13
24GND B COM
4 Vt 3 4 M WRITE PULSE MOTOR
2 Bl 14 5 Vt 2 5
N.C. /A
1 Bl 15 6 Vt 1 6
24VR1 /B
7 Vt 4 1
OUT2
OUT1
8 Vt 3 2 M CUTTER MOTOR
9 Vt 2 3
OUT
SGND
10 Vt 1 4 SW CUTTER HP SWITCH
1 Bl 1
CN3
CN4 2 Bl 2
TPH2
TPH4 CN2
3 Bl 3
TPH3 A1
4 Bl 4 N.C.
THERM A2 Vt 8 1 Vt 2 1
5 Bl 5 OUT2
6 Bl 6
TPH0
OUT1
A3 Vt 7 2 Vt 1 2 M THERMAL PRESSURE MOTOR
TPH1 A4 Vt 6 3 Vt 3
7 Bl 7 GND
Master Making PCB
/STB1 A5 Vt 5 4 Vt 2
8 Bl 8
TPHCLK1
OUT
A6 Vt 4 5 Vt 1
SEN THERMAL PRESSURE SENSOR
9 Bl 9 VCC
/LATCH1 A7 Vt 3 6 Vt 3 1
10 Bl 10 GND
DI1 A8 Vt 2 7 Vt 2 2
11 Bl 11
GND
OUT
A9 Vt 1 8 Vt 1 3 SEN MASTER END SENSOR (RECEIVE)
12 Bl 12 VCC
GND A10 Vt 3
13 Bl 13 GND
GND A11 Vt 2
14 Bl 14 OUT SEN MASTER MAKING UNIT SENSOR
(Image PCB)
VCC A12 Vt 1
RIPU PCB
15 Rd 15 VCC
VCC A13 Vt 3
16 Rd 16 5V
VCC A14 Vt 2
17 Rd 17
/STB2
GND
A15 Vt 1
SEN MASTER VOLUME DETECTION SENSOR (SEND)
18 Rd 18 LED
TPHCLK2 A16 Vt 4
19 Rd 19 OUT
/LATCH2 A17 Vt 3
20 Rd 20 GND
21 Rd 21
DI2
LED
A18 Vt 2 SEN MASTER VOLUME DETECTION SENSOR (RECEIVE)
/STB3 A19 Vt 1
22 Rd 22 5V
TPHCLK3
23 Rd 23
/LATCH3 B1 Vt 17 1 Vt 2 1
24 Rd 24 24V
25 Rd 25
DI3
OUT
B2 Vt 16 2 Vt 1 2 FAN MASTER DISPOSAL FAN A
/STB4 B3 Vt 15 3 Vt 2 1
26 Rd 26 24V
27 Rd 27
TPHCLK4
OUT
B4 Vt 14 4 Vt 1 2 FAN MASTER DISPOSAL FAN B
/LATCH4 B5 Vt 13 5 Vt 2 1
28 Rd 28 24V
DI4
OUT
B6 Vt 12 6 Vt 1 2 FAN MASTER DISPOSAL FAN C
B7 Vt 11 7 Vt 2 1
24V
OUT
B8 Vt 10 8 Vt 1 2 FAN MASTER DISPOSAL FAN D
B9 Vt 9 9 Vt 3 1
GND
B10 Vt 8 10 Vt 2 2
1 Br 1
CN5 OUT
B11 Vt 7 11 Vt 1 3 SEN MASTER DETECTION SENSOR
CN1 2 Rd 2
TPH2 VCC
B12 Vt 6 12 Vt 3
MASTER END SENSOR (SEND)
TPH4 GND
3 Or 3 B13 Vt 5 13 Vt 2
4 Yw 4
TPH3 THRM
B14 Vt 4 14 Vt 1
SEN WRITE ROLLER TEMP. SENSOR
THERM VCC
5 Gr 5 B15 Vt 3 15 Vt 3
TPH0 GND
6 Bl 6 B16 Vt 2 16 Vt 2
7 Vt 7
TPH1 OUT
B17 Vt 1 17 Vt 1
SEN MASTER POSITIONING SENSOR
/STB1 VCC
8 Gy 8 B18 Vt
TPHCLK1 OUT
9 Wh 9 B19 Vt 2 1
/LATCH1 24V
10 Bk 10
DI1
1 2 SW MASTER CUT SWITCH
11 Br 11
GND
12 Rd 12
GND
13 Or 13
14 Yw 14
GND CN7 1 Vt 2 1
TPH
VCC OUT1
15 Gr 15
VCC OUT2
2 Vt 1 2 M MASTER LOADING MOTOR
16 Bl 16
VCC
17 Vt 17
/STB2
18 Gy 18
TPHCLK2
19 Wh 19
/LATCH2
20 Bk 20
DI2
21 Br 21
/STB3
22 Rd 22
TPHCLK3
23 Or 23
/LATCH3
24 Yw 24
DI3
25 Gr 25
/STB4
26 Bl 26
TPHCLK4
27 Vt 27
/LATCH4
28 Gy 28
DI4
[20 - 13]
CHAPTER 20. PRINTED CIRCUIT BOARDS
CN1 1 Br 1
1 Br 1 1 Br 1 1 Rd 1 1 Br 1
CN2 GNDH
2 Rd 2
CN2
CN11 2 Rd 2 2 Rd 2 2 Rd 2 2 Rd 2
-S GNDH
3 Or 3
G6 GNDH
3 Or 3 3 Or 3 3 Rd 3 3 Or 3 4 Yw 4
G6 GNDH
4 Yw 4 4 Yw 4 4 Rd 4 4 Yw 4 5 Gr 5
G6 GNDH
5 Gr 5 5 Gr 5 5 Rd 5 5 Gr 5 6 Bl 6
G6 GNDH
7 Vt 7 7 Vt 7 7 Rd 7 7 Vt 7 8 Gy 8
G6 GNDH
8 Gy 8 8 Gy 8 8 Rd 8 8 Gy 8 9 Wh 9
G6 GNDH
9 Wh 9 9 Wh 9 9 Rd 9 9 Wh 9 10 Bk 10
G6 GNDH
TPH
10 Bk 10 10 Bk 10 10 Rd 10 10 Bk 10 11 Br 11
G6 VH
11 Br 11 11 Br 11 11 Rd 11 11 Br 11 12 Rd 12
TPH VH
12 Rd 12 12 Rd 12 12 Rd 12 12 Rd 12 13 Or 13
TPH VH
13 Or 13 13 Or 13 13 Rd 13 13 Or 13 14 Yw 14
TPH VH
14 Yw 14 14 Yw 14 14 Rd 14 14 Yw 14 15 Gr 15
TPH VH
15 Gr 15 15 Gr 15 15 Rd 15 15 Gr 15 16 Bl 16
TPH VH
16 Bl 16 16 Bl 16 16 Rd 16 16 Bl 16 17 Vt 17
TPH VH
17 Vt 17 17 Vt 17 17 Rd 17 17 Vt 17 18 Gy 18
TPH VH
18 Gy 18 18 Gy 18 18 Rd 18 18 Gy 18 19 Wh 19
TPH VH
19 Wh 19 19 Wh 19 19 Rd 19 19 Wh 19 20 Bk 20
TPH VH
20 Bk 20 20 Bk 20 20 Rd 20 20 Bk 20 21
+S N.C.
22
N.C.
[20 - 14]
CHAPTER 20. PRINTED CIRCUIT BOARDS
Yw 1
CN1 CN4 1 Vt 7
EEPROMSK1D BOTTLE SET SW e
Yw 2 2 Vt 6
Yw 3
EEPROMCS1D BOTTLE SET SW d
3 Vt 5
Ink cartridge SW PCB (H) for black
EEPROMDI1D BOTTLE SET SW c
Yw 4 4 Vt 4
Yw 5
EEPROMDO1D BOTTLE SET SW b
5 Vt 3
OR
TDATA1D BOTTLE SET SW a
Yw 6 6 Vt 2
Yw 7
WAIENA-1D 5V
7 Vt 1
Ink cartridge SW PCB (MC) for color
GND GND
Yw 8
WAISDT1D
MCTL PCB Yw 9 8 Vt 3
(Mechanical
GND GND
Yw 10 9 Vt 2
Control PCB) Yw 11
WAISCK1D INNER PRES. DET. SENSOR
10 Vt 1 SEN INNER PRESSURE DETECTION SENSOR
PRESSURE LIMIT SENSOR 1 5V
CN13 Yw 12 11 Vt 2
PRESSURE HP SENSOR 1 24V
Yw 13
/POSITION-A SENSOR beta1 OUT
12 Vt 1 M INKING MOTOR
Yw 14 13 Vt 2
/POSITION-A SENSOR alpha1 OUT2
Yw 15
D-SET-1D OUT1
14 Vt 1 M PRESSURE CONTROL MOTOR
Yw 16 15 Vt 6
CNTLAT7-1D A
Yw 17 16 Vt 5
GND B
Yw 18 17 Vt 4
CNTDAT7-1D COM_A
Yw 19
GND COM_B
18 Vt 3 M HORIZONTAL PULSE MOTOR
Yw 20 19 Vt 2
Drum PCB 1
CNTSCK7-1D /A
20 Vt 1
/B
CN7 1 Vt 3 1 Vt 3
GND
2 Vt 2 2 Vt 2
POSITION-B LOCK LEVER SENSOR
3 Vt 1 3 Vt 1 SEN POSITION-B LOCK LEVER SENSOR
VCC
CN3 1 Vt 3
GND
2 Vt 2
PRESSURE LIMIT SENSOR 3 Vt 1 SEN PRESSURE LIMIT SENSOR
5V
4 Vt 3
GND
5 Vt 2
POSITION-A SENSOR (No.2)
6 Vt 1
SEN POSITION-A SENSOR (No.2)
5V
CN5 1 Vt 3
GND
2 Vt 2
HORIZONTAL CENTERING HP SENSOR
3 Vt 1
SEN HORIZONTAL CENTERING HP SENSOR
5V
4 Vt 3
GND
5 Vt 2
DRIVE TRANSMIT RELEASE SENSOR 6 Vt 1 SEN DRIVE TRANSMIT RELEASE SENSOR
5V
7 Vt 3
GND
8 Vt 2
INK VOLUME DETECTION SENSOR (RECEIVE)
9 Vt 1 SEN INK VOLUME DETECTION SENSOR (RECEIVE)
5V
10 Vt 2
24V
OUT
11 Vt 1 CLU INNER PRESSURE CLUTCH
[20 - 15]
CHAPTER 20. PRINTED CIRCUIT BOARDS
Yw 1
CN1 CN4 1 Vt 7
EEPROMSK2D BOTTLE SET SW e
Yw 2 2 Vt 6 Ink cartridge SW PCB (H) for black
EEPROMCS2D BOTTLE SET SW d
Yw 3 3 Vt 5
EEPROMDI2D BOTTLE SET SW c
Yw 4 4 Vt 4
EEPROMDO2D BOTTLE SET SW b OR
Yw 5 5 Vt 3
TDATA2D BOTTLE SET SW a
Yw 6 6 Vt 2
WAIENA-2D 5V Ink cartridge SW PCB (MC) for color
Yw 7 7 Vt 1
GND GND
Yw 8
WAISDT2D
Yw 9 8 Vt 3
MCTL PCB GND GND
Yw 10 9 Vt 2
(Mechanical
Yw 11
WAISCK2D INNER PRES. DET. SENSOR
10 Vt 1 SEN INNER PRESSURE DETECTION SENSOR
Control PCB) PRESSURE LIMIT SENSOR 2 5V
Yw 12 11 Vt 2
CN13 PRESSURE HP SENSOR 2 24V
Yw 13
/POSITION-A SENSOR beta2 OUT
12 Vt 1 M INKING MOTOR
Yw 14 13 Vt 2
/POSITION-A SENSOR alpha2 OUT2
Yw 15
D-SET-2D OUT1
14 Vt 1 M PRESSURE CONTROL MOTOR
Yw 16 15 Vt 6
CNTLAT8-2D A
Yw 17 16 Vt 5
GND B
Yw 18 17 Vt 4
CNTDAT8-2D COM_A
Yw 19
GND COM_B
18 Vt 3 M HORIZONTAL PULSE MOTOR
Yw 20 19 Vt 2
CNTSCK8-2D /A
20 Vt 1
Drum PCB 2
/B
CN2 21 Vt 6
LED 10%
Wh 1 22 Vt 5
MCTL PCB 24VB-D2 5V
Br 2 23 Vt 4
(Mechanical GND E LED 30% INK VOLUME DETECTION
Control PCB) Br 3
5V-D1 5V
24 Vt 3 SEN SENSOR (SEND) ASS'Y
Br 4 25 Vt 2
CN10 GND E LED 50%
26 Vt 1
5V
27 Vt 5 1 Br 1
5V
28 Vt 4 2 Rd 2
TDATA
29 Vt 3 3 Or 3
INK
30 Vt 2 4 Yw 4 SEN INK SENSOR
OVER
31 Vt 1 5 Gr 5
GND
32 Vt 9 1 Vt 3
GND
33 Vt 8 2 Vt 2
PRESSURE HP SENSOR
34 Vt 7 3 Vt 1 SEN PRESSURE HP SENSOR
5V
35 Vt 6 4 Vt 3
GND
36 Vt 5 5 Vt 2
POSITION-A SENSOR (No.1)
37 Vt 4 6 Vt 1
SEN POSITION-A SENSOR (No.1)
5V
38 Vt 3 7 Vt 3
GND
39 Vt 2 8 Vt 2
POSITION-B LOCK CONFIRMATION SENSOR
40 Vt 1 9 Vt 1
SEN POSITION-B LOCK CONFIRMATION SENSOR
5V
CN7 1 Vt 3 1 Vt 3
GND
2 Vt 2 2 Vt 2
POSITION-B LOCK LEVER SENSOR
3 Vt 1 3 Vt 1 SEN POSITION-B LOCK LEVER SENSOR
VCC
CN3 1 Vt 3
GND
2 Vt 2
PRESSURE LIMIT SENSOR
3 Vt 1 SEN PRESSURE LIMIT SENSOR
5V
4 Vt 3
GND
5 Vt 2
POSITION-A SENSOR (No.2)
6 Vt 1
SEN POSITION-A SENSOR (No.2)
5V
CN5 1 Vt 3
GND
2 Vt 2
HORIZONTAL CENTERING HP SENSOR
3 Vt 1
SEN HORIZONTAL CENTERING HP SENSOR
5V
4 Vt 3
GND
5 Vt 2
DRIVE TRANSMIT RELEASE SENSOR 6 Vt 1 SEN DRIVE TRANSMIT RELEASE SENSOR
5V
7 Vt 3
GND
8 Vt 2
INK VOLUME DETECTION SENSOR (RECEIVE) 9 Vt 1 SEN INK VOLUME DETECTION SENSOR (RECEIVE)
5V
10 Vt 2
24V
OUT
11 Vt 1 CLU INNER PRESSURE CLUTCH
[20 - 16]
CHAPTER 20. PRINTED CIRCUIT BOARDS
COM3C
CN1
CN1
CN2
KOUT4
P-KEY
P-LED
GNDA
GNDA
LED2
LED1
KIN3
KIN2
KIN4
KIN1
GND
N.C.
N.C.
H.V
P1
P2
P3
10
11
12
1
2
3
4
5
6
7
8
9
1
2
3
1
2
3
4
10
11
12
1
2
3
4
5
6
7
8
9
1
2
3
COM3C
KOUT4
LED2
LED1
GNDA
GNDA
KIN3
KIN2
KIN4
KIN1
CN8
CN6
P-KEY
P1
P2
P3
P-LED
B1 Or A1
CN1
CN10 B2 Or A2
/CS
GND
B3 Gy A3
A0
B4 Gy A4
B5 Wh A5
GND CN5 1
A1 S
B6 Wh A6 2
LCD
GND CP1
B7 Yw A7 3
A2 CP2
B8 Yw A8 4
GND N.C.
B9 Pk A9 5
A3 DISPOF
B10 Pk A10 6
GND CD0
B11 Or A11 7
A4 CD1
B12 Or A12 8
GND CD2
B13 Gy A13 9
/RD CD3
B14 Gy A14 10
GND VDD
Panel Control PCB
B15 Wh A15 11
/WR VSS
B16 Wh A16 12
GND VEE
B17 Yw A17
RXD
B18 Yw A18
GND
SH-PCB
B19 Pk A19
P-LED
B20 Pk A20
/SYSRST
A1 Or B1
VCC
A2 Or B2
D0
A3 Gy B3
VCC
Touch Panel
A4 Gy B4
D1
A5 Wh B5
A6 Wh B6
VCC CN7 1
D2 Y2
A7 Yw B7 2
VCC X2
A8 Yw B8 3
D3 Y1
A9 Pk B9 4
VCC X1
A10 Pk B10
D4
A11 Or B11
VCC
A12 Or B12
D5
A13 Gy B13
VCC
A14 Gy B14
D6
A15 Wh B15
VCC
A16 Wh B16
D7
A17 Yw B17
VCC
A18 Yw B18
TXD
A19 Pk B19
P-KEY
A20 Pk B20
RSTSG
CN3
CN2
KOUT0
KOUT1
KOUT2
KOUT3
KOUT4
KOUT5
KOUT6
COM0
COM1
COM2
COM3
SOUT
LACH
LED1
LED2
GND
GND
KIN5
KIN4
KIN3
KIN2
KIN1
KIN0
GND
D2-4
D2-3
D2-2
D2-1
VCC
SCK
10
11
12
10
11
12
13
14
15
16
17
18
1
2
3
4
5
6
7
8
9
1
2
3
4
5
6
7
8
9
10
11
12
10
11
12
13
14
15
16
17
18
1
2
3
4
5
6
7
8
9
1
2
3
4
5
6
7
8
9
COM0
COM1
COM2
COM3
GND
GND
KOUT0
KOUT1
KOUT2
KOUT3
KOUT4
KOUT5
KOUT6
LED1
LED2
GND
SOUT
KIN5
KIN4
KIN3
KIN2
KIN1
KIN0
CN3
CN2
SCK
LACH
VCC
D2-4
D2-3
D2-2
D2-1
[20 - 17]
CHAPTER 20. PRINTED CIRCUIT BOARDS
MEMO
[20 - 18]
INDEX
[A]
AF Horizontal-Scanning Position (adjustment) ............................................................... 13-19
AF Original IN Sensor Sensitivity (adjustment) ................................................................ 13-20
AF Original Scanning Mechanism (mechanism) .............................................................. 13-4
AF Original Scanning Mechanism [with Auto Base Control] (mechanism) ...................... 13-4
AF Original Set (mechanism) ............................................................................................. 13-2
AF Read Pulse Motor (removal) ....................................................................................... 13-11
AF Read Pulse-Motor Speed (adjustment) ...................................................................... 13-19
AF Scanning-Start Position (adjustment) ........................................................................ 13-19
Air Pump Unit (removal) ....................................................................................................... 4-7
Angular Sensor PCB (removal) .......................................................................................... 10-7
Angular Sensors (mechanism) ......................................................................................... 10-5
Automatic Multiple Paper Feed (adjustment) .................................................................... 5-13
[B]
Battery Replacement .......................................................................................................... 19-2
Book-Mode Pre-Scan (mechanism) .................................................................................. 12-7
Book-Mode Scanning (mechanism) .................................................................................. 12-7
[C]
CAUTION .............................................................................................................................. 1-3
Center Gear (removal) ....................................................................................................... 4-14
Clamp Plate Base Ass’y (removal) .................................................................................... 8-18
Clamp Plate HP Sensor (removal) .................................................................................... 10-8
Clamp Plate Loading Position Sensor (removal) ............................................................. 10-8
Clamp Plate Movement (mechanism) ............................................................................... 10-6
Clamp Slide HP Sensor (removal) .................................................................................... 10-8
Clamp Slide Sensor (removal) .......................................................................................... 10-8
Clamp Unit (mechanism) .................................................................................................. 10-2
Clamp Unit (removal) ......................................................................................................... 10-7
Clamp Unit Engaged and Disengaged Position (mechanism) ........................................ 10-5
Clamp Unit Initial Position (mechanism) .......................................................................... 10-5
[D]
Disposal Box Empty Detection Sensor (removal) .............................................................. 11-5
Disposal Box Full Detection (mechanism) ......................................................................... 11-2
Disposal Box Safety SW (removal) .................................................................................. 11-17
Disposal Compress Action (mechanism) .......................................................................... 11-3
Disposal Plate (removal) ................................................................................................. 11-12
Disposal Plate HP Sensor (removal) ................................................................................. 11-8
Disposal Plate Limit Sensor (removal) .............................................................................. 11-8
Disposal Plate Motor (removal) .......................................................................................... 11-9
Disposal Plate Shaft (removal) ........................................................................................ 11-13
Drive Transmit Release Sensor (removal) ........................................................................ 8-36
i
[E]
Elevator Lower Limit Sensor (removal) ............................................................................. 4-17
Elevator Motor (removal) .................................................................................................... 4-16
Elevator Upper Limit Sensor A Position (adjustment) ....................................................... 4-20
Engagement Pin (removal) ................................................................................................ 8-31
Error Code display ............................................................................................................. 16-2
Error Point display .............................................................................................................. 16-2
Error Type display ............................................................................................................... 16-2
Errors Requiring Special Action ....................................................................................... 16-36
Exterior Cover Removal ...................................................................................................... 1-19
[F]
Factory Mode Test Mode ................................................................................................... 17-30
FB Horizontal-Scan Position (adjustment) ...................................................................... 12-12
FB Original Scanning Movement [Book Mode OFF] (mechanism) .................................... 12-7
FB Scan Start-Position (adjustment) ............................................................................... 12-11
First Paper Feed (mechanism) ............................................................................................ 4-4
First Paper Feed Sensor (removal) ..................................................................................... 5-8
Flatbed Initialization (mechanism) ..................................................................................... 12-6
[G]
Gap Between Paper Pass Guide and Lower Paper Guide (adjustment) .......................... 5-11
Gap Between Timing Roller and Guide Roller (adjustment) ............................................ 5-10
Gripper (removal) ............................................................................................................... 6-17
Gripper Cover Ass’y (removal) ............................................................................................. 6-6
Gripper Open/Close (mechanism) ...................................................................................... 6-2
Gripper Shaft Unit (removal) .............................................................................................. 6-10
Guide Gear (removal) ........................................................................................................... 3-8
Guide Roller Ass’y (removal) ............................................................................................... 5-5
[H]
Horizontal Centering HP Sensor (removal) ....................................................................... 8-36
Horizontal Printing Position (adjustment) ........................................................................ 14-24
Horizontal Pulse Motor Ass’y (removal) ............................................................................. 8-12
[I]
Image Elongation and Shrinkage [AF read pulse motor] (adjustment) .......................... 13-19
Image Elongation and Shrinkage [FB Read Pulse-Motor speed] (adjustment) ............. 12-11
Image Elongation and Shrinkage [Write roller speed] (adjustment) .............................. 14-23
Ink Cartridge Set (mechanism) ............................................................................................ 8-4
Ink Pump Ass’y (removal) .................................................................................................. 8-13
Ink Sensor PCB (removal) ................................................................................................. 8-16
Ink Supply System (mechanism) ......................................................................................... 8-4
Ink Volume Detection Sensor [Receive] (removal) .............................................................. 8-9
Ink Volume Detection Sensor [Receive] Ass’y (removal) ..................................................... 8-8
Inner Pressure (mechanism) .............................................................................................. 8-4
Inner Pressure Clutch (removal) ......................................................................................... 8-11
Inner Pressure Detection Sensor (removal) ...................................................................... 8-35
Inner Pressure Roller Gap Adjustment (adjustment) ....................................................... 8-40
ii
Inner Pressure Roller Unit (removal) ................................................................................. 8-19
Installation Procedure ......................................................................................................... 1-11
[J]
JIGs ....................................................................................................................................... 1-8
[L]
Leveling the Machine on the Floor ..................................................................................... 1-15
Low Temperature Printing Speed Limit ............................................................................... 3-6
[M]
Machine Features ................................................................................................................. 2-2
Machine Specifications ........................................................................................................ 2-3
Main Cover Ass’y [main drive] (removal) .............................................................................. 3-7
Main Drive Section (mechanism) ......................................................................................... 3-2
Main Motor Safety (mechanism) .......................................................................................... 3-4
Main Motor Unit (removal) ................................................................................................... 3-11
Master Compression HP Sensor (removal) ....................................................................... 11-6
Master Compression Limit Sensor (removal) .................................................................... 11-6
Master Compression Motor (removal) ............................................................................. 11-14
Master Compression Plate (removal) ............................................................................. 11-15
Master Cutting (mechanism) ............................................................................................. 14-3
Master Detection Sensor (removal) ................................................................................... 14-6
Master Disposal (mechanism) ........................................................................................... 11-2
Master Disposal Belt [1st Master Disposal Unit] (removal) ............................................ 11-10
Master Disposal Belt [2nd Master Disposal Unit] (removal) ........................................... 11-19
Master Disposal Fan (removal) ....................................................................................... 14-19
Master Disposal Jam Sensor (removal) ............................................................................. 11-8
Master Disposal Motor (removal) ........................................................................................ 11-7
Master Disposal Motor Limit Sensor (removal) .................................................................. 11-6
Master Disposal Unit [1st unit] (removal) ............................................................................. 11-4
Master Disposal Unit [2nd unit] (removal) ......................................................................... 11-18
Master Disposal Vertical Transport (mechanism) .............................................................. 11-3
Master Elongation (adjustment) ........................................................................................ 8-42
Master End Sensor (removal) ............................................................................................ 14-8
Master Leading Clamp Range (adjustment) ................................................................... 14-21
Master Loading (mechanism) ........................................................................................... 14-2
Master Loading Motor (removal) ...................................................................................... 14-18
Master Loading Roller Ass’y (removal) ............................................................................ 14-16
Master Making (mechanism) ............................................................................................. 14-2
Master Making Unit (removal) .......................................................................................... 14-10
Master Making Unit Lower Cover (removal) ....................................................................... 14-7
Master Making Unit Shifting (mechanism) ......................................................................... 14-2
Master on Drum (Before Printing) Check (mechanism) ...................................................... 8-3
Master on Drum [Before Master Removal] Check (mechanism) ....................................... 11-2
Master Positioning Sensor (removal) .............................................................................. 14-17
Master Set (mechanism) .................................................................................................... 14-2
Master Shift Adjustment (adjustment) ............................................................................... 8-43
Master Tail Clamp Fan (removal) ........................................................................................ 11-5
Master Tail Clamp Range (adjustment) .......................................................................... 14-21
iii
Master Volume Detection Sensor (removal) ...................................................................... 14-4
MCTL PCB Replacement ................................................................................................... 19-4
Multiple Paper Feed Detection Sensor (removal) ............................................................... 5-8
Multiple Paper Feed Switch (adjustment) .......................................................................... 4-23
[O]
Original IN Sensor (removal) ........................................................................................... 13-10
Original Pickup Roller (removal) ........................................................................................ 13-8
Original Pickup Roller Ass’y (removal) .............................................................................. 13-6
Original Stripper Roller (removal) ...................................................................................... 13-9
[P]
Panel Messages ................................................................................................................ 16-1
Paper Detection Sensor (removal) .................................................................................... 4-12
Paper Drum (mechanism) ................................................................................................... 6-2
Paper Drum (removal) ......................................................................................................... 6-3
Paper Drum Rotation Position (mechanism) ...................................................................... 3-6
Paper Ejection (mechanism) ............................................................................................... 7-2
Paper Ejection Cover Ass’y (removal) ................................................................................. 7-6
Paper Ejection Limit Sensor (removal) ................................................................................ 7-8
Paper Ejection Motor (removal) ............................................................................................ 7-7
Paper Ejection Pinch Unit (removal) .................................................................................... 7-5
Paper Ejection Roller Unit (removal) ................................................................................... 7-7
Paper Ejection Sensor [Receive] (removal) ........................................................................ 7-11
Paper Ejection Sensor [Send] (removal) ............................................................................. 7-6
Paper Ejection Separator Gap (adjustment) ..................................................................... 7-14
Paper Ejection Unit Safety SW (removal) ............................................................................ 7-11
Paper Feed Cover (removal) ................................................................................................ 4-6
Paper Feed Intermediate Gear (removal) ............................................................................ 3-8
Paper Feed Pressure Adjustment Unit (removal) ............................................................... 4-9
Paper Feed Sensor (removal) ............................................................................................. 5-8
Paper Feed Tray (mechanism) ............................................................................................ 4-2
Paper Feed Tray Elevation (mechanism) ............................................................................ 4-4
Paper Feed Tray Unit (removal) ......................................................................................... 4-10
Paper Guide Fence (removal) ............................................................................................. 4-11
Paper Lifter (removal) ......................................................................................................... 6-18
Paper Limit Detection Plate Attachment (adjustment) ...................................................... 4-21
Paper Pass Guide (mechanism) ......................................................................................... 5-2
Paper Pass Guide (removal) ............................................................................................... 5-3
Paper Receiving Tray (mechanism) .................................................................................... 7-3
Paper Receiving Tray (removal) ........................................................................................... 7-4
Paper Receiving Tray Support Ass’y (removal) ................................................................... 7-5
Paper Size Detection Sensor (removal) ............................................................................ 4-12
Paper Strip (mechanism) ..................................................................................................... 4-5
Paper Volume Detection Sensor (removal) ....................................................................... 4-17
Paper Width Potentiometer (adjustment) .......................................................................... 4-20
Paper Width Potentiometer (removal) ............................................................................... 4-12
Pickup Roller (removal) ........................................................................................................ 4-8
Pickup Roller Shaft Ass’y (removal) ..................................................................................... 4-9
Pinch HP Sensors F & R (removal) ................................................................................... 7-10
iv
Pinch Pulse Motors F & R (removal) .................................................................................. 7-10
Pinch Roller (mechanism) ................................................................................................... 7-2
Pinch Roller Ass’y Home Position and Movement (mechanism) ....................................... 7-3
Pinch Roller Position (adjustment) .................................................................................... 7-14
Pinch Roller Positioning (mechanism) ............................................................................... 7-2
Pinch Roller Release Motor (removal) ............................................................................... 7-12
Pinch Roller Release Sensor (removal) ............................................................................ 7-13
Pinch Rollers (removal) ....................................................................................................... 7-8
Pinch Slide Ass’y (removal) ................................................................................................. 7-9
Position A Sensor [No.1] (removal) .................................................................................... 8-33
Position A Sensor [No.2] (removal) .................................................................................... 8-36
Position B Lock Confirmation Sensor (removal) ............................................................... 8-33
Position T Sensor (adjustment) ......................................................................................... 6-19
Preface ................................................................................................................................. 1-2
Pressure Control Motor (removal) ..................................................................................... 8-14
Pressure HP Sensor (removal) ......................................................................................... 8-34
Pressure Limit Sensor (removal) ...................................................................................... 8-37
Print Density (adjustment) ................................................................................................. 8-42
Print Drum Drive Unit (removal) ........................................................................................... 9-4
Print Drum Horizontal Movement (mechanism) .................................................................. 8-2
Print Drum Layout and Angle ............................................................................................... 8-2
Print Drum Lock (mechanism) ............................................................................................. 8-5
Print Drum Locking Unit (removal) ..................................................................................... 8-38
Print Drum PCB Replacement ........................................................................................... 19-4
Print Drum Position-A Movement (mechanism) ................................................................ 10-4
Print Drum Removal/Insertion (mechanism) ...................................................................... 8-3
Print Drum Retaining Joint (mechanism) ............................................................................ 8-2
Print Drum Set Sensor (removal) ....................................................................................... 8-39
Print Image Adjustment Procedure .................................................................................... 19-4
Print Position Datum (adjustment) ...................................................................................... 9-7
Print Positioning Pulse Motor (removal) .............................................................................. 9-6
Printed Circuit Boards ........................................................................................................ 20-1
Pump Gear (removal) ........................................................................................................... 3-8
[R]
Removing the Cutter Unit (removal) ................................................................................ 14-20
Removing the Ink Volume Detection Sensor [Send] Ass’y (removal) ............................... 8-10
[S]
Scanner Lamp (removal) ................................................................................................. 12-10
Scanner Table Opening and Closing (mechanism) ......................................................... 12-2
Scanner Unit (removal) ...................................................................................................... 12-8
Scanning (mechanism) ..................................................................................................... 12-4
Schematic Cross-Sectional View ........................................................................................ 2-5
Scraper (removal) ................................................................................................................. 4-8
Screen Ass’y (removal) ........................................................................................................ 8-6
Second Paper Feed (mechanism) ...................................................................................... 5-2
Second Paper Feed Sensor (removal) ................................................................................ 5-8
Second Paper Feeding (adjustment) ................................................................................ 5-12
SH-PCB (Main PCB) Replacement .................................................................................... 19-3
v
Software Download Instructions ........................................................................................ 19-2
Stage Glass (removal) ....................................................................................................... 12-9
Stripper (adjustment) ......................................................................................................... 4-22
Stripper Unit (removal) ....................................................................................................... 4-18
Stripper-Pad Ass’y (removal) ............................................................................................. 4-19
[T]
Tension Roller (removal) .................................................................................................... 14-5
Test Mode (factory mode) ................................................................................................. 17-30
Test Mode ........................................................................................................................... 17-1
Thermal Pressure Motor Ass’y (removal) .......................................................................... 14-9
Timing Roller Ass’y (removal) .............................................................................................. 5-4
TPH Ass’y (removal) ........................................................................................................... 14-8
TPH Elevation (mechanism) .............................................................................................. 14-2
[V]
Vertical Position Variation Check [Print Registration] (adjustment) .................................. 5-13
Vertical Print Position (mechanism) .................................................................................... 9-2
Vertical Transport Roller G [1st Master Disposal Unit] (removal) ................................... 11-10
Vertical Transport Roller G [2nd Master Disposal Unit] (removal) .................................... 11-19
Vertical Transport Roller J [1st Master Disposal Unit] (removal) ..................................... 11-11
Vertical Transport Roller J [2nd Master Disposal Unit] (removal) ................................... 11-19
[W]
WARNING ............................................................................................................................. 1-4
Work Precautions ................................................................................................................. 1-5
Write Roller (removal) ...................................................................................................... 14-14
Write Roller Temperature Sensor (removal) .................................................................... 14-19
Write Start Position (adjustment) ..................................................................................... 14-22
vi
Jump to OPTIONS INSTALLATION INSTRUCTIONS documents
Auto Document Feeder AF
Digitizer & Auto Document Feeder AF
Digitizer
Job Separator
Key Card Counter
NET B
Inkless Drum
