Lecture 1: Introduction to Uncertainty

Quantification

Today
What is UQ?
polynomial approximation
parameters estimation

Uncertainty quantification

https://nbviewer.jupyter.org/github/G-Ryzhakov/uq2019/blob/master/lectures/lecture-1.ipynb 1/12
4/15/2021 Jupyter Notebook Viewer

Uncertainty quantification
Numerical simulations assume models of real world; these models pick uncertainties

In input variables: Y = F (X + ε)
In output variables: Y = F (X ) + ε
Models are approximate

Forward and inverse problems

UQ splits into two major branches: forward and inverse problems.

Forward problems
In the forward propagation of uncertainty, we have a known model F for a system of interest.
We model its inputs X as a random variable and wish to understand the output random
variable
Y = F (X )

(also denoted Y |X ) and reads Y given X .

Also, this is related to sensitivity analysis (how random variations in X influence variation in
Y ).

https://nbviewer.jupyter.org/github/G-Ryzhakov/uq2019/blob/master/lectures/lecture-1.ipynb 2/12
4/15/2021 Jupyter Notebook Viewer

Inverse problems
In inverse problems, F is a forward model, but Y is observed data, and we want to find the
input data X

such that F (X ) = Y , i.e. we want X |Y instead of Y |X .

Inverse problems are typically ill-posed in the usual sense, so we need an expert (or prior)
about what a good solution X might be.

Bayesian perspective becomes the method of choice, but this requires the representation of
high-dimensional distributions.
p(Y |X )p(X )
p(X |Y ) = .
p(Y )

Approximation of multivariate functions

If we want to do efficient UQ (not only Monte-Carlo) we need efficient tools for the
approximation of multivariate functions.

Consider orthogonal polynomials {pn }

b

⟨pn , pm ⟩ = pn (x)pm (x)w(x) dx = δ nm hn .

∫
a

−1/2
Chebyshev polynomials of the first kind, (a, b) = (−1, 1) , w(x) = (1 − x
2
)

Hermite polynomials (mathematical or probabilistic), (a, b) = (−∞, +∞) ,

1 2
w(x) = exp(−x /2)
√ 2π

https://nbviewer.jupyter.org/github/G-Ryzhakov/uq2019/blob/master/lectures/lecture-1.ipynb 3/12
4/15/2021 Jupyter Notebook Viewer

In [2]: import numpy as np

import matplotlib.pyplot as plt
from numpy.polynomial import Chebyshev as T
from numpy.polynomial.hermite import hermval
%matplotlib inline

def p_cheb(x, n):

"""
RETURNS T_n(x)
value of not normalized Chebyshev polynomials
$\int \frac1{\sqrt{1-x^2}}T_m(x)T_n(x) dx = \frac\pi2\delta_{nm}$
"""
return T.basis(n)(x)

def p_herm(x, n):

"""
RETURNS H_n(x)
value of non-normalized Probabilistic polynomials
"""
cf = np.zeros(n+1)
cf[n] = 1
return (2**(-float(n)*0.5))*hermval(x/np.sqrt(2.0), cf)

def system_mat(pnts, maxn, poly):

"""
RETURNS system matrix
"""
A = np.empty((pnts.size, maxn), dtype=float)
for i in range(maxn):
A[:, i] = poly(pnts, i)
return A

https://nbviewer.jupyter.org/github/G-Ryzhakov/uq2019/blob/master/lectures/lecture-1.ipynb 4/12
4/15/2021 Jupyter Notebook Viewer

In [3]: x = np.linspace(-1, 1, 1000)

data = []
for i in range(5):
data.append(x)
data.append(p_cheb(x, i))

plt.plot(*data)
plt.legend(["power = {}".format(i) for i in range(len(data))]);

In [4]: def complex_func(x):

return np.sin(2.0*x*np.pi)*np.cos(0.75*(x+0.3)*np.pi)

plt.plot(x, complex_func(x));

Now, let's approximate the function with polynomials taking different maximal power n and the
corresponding number of node points
n

̂
f (x) ≈ f (x) = αi pi (x)
∑
i=0

https://nbviewer.jupyter.org/github/G-Ryzhakov/uq2019/blob/master/lectures/lecture-1.ipynb 5/12
4/15/2021 Jupyter Notebook Viewer

In [5]: n = 6
M = n
nodes = np.linspace(-1, 1, M)
RH = complex_func(nodes)
A = system_mat(nodes, n, p_cheb)
if n == M:
alpha = np.linalg.solve(A, RH)
else:
alpha = np.linalg.lstsq(A, RH)[0]
print("α = {}".format(alpha))

α = [ 0.14310061 -0.43250604 0.20112419 -0.25853987 -0.3442248 0.691

In [7]: def calc_approximant(poly, alpha, x):

"""
RETURNS values of approximant in points x
"""
n = len(alpha)
y = np.zeros_like(x)
for i in range(n):
y[...] += poly(x, i)*alpha[i]

return y

In [8]: y = complex_func(x)
approx_y = calc_approximant(p_cheb, alpha, x)
plt.plot(x, y, x, approx_y, nodes, RH, 'ro');

Approximate value of the error

̂  ̂
ε = ‖f − f ‖ ∞ ≈ max∣ ∣
∣f (x) − f (x)∣
x∈

In [9]: epsilon = np.linalg.norm(y - approx_y, np.inf)

print("ε = {}".format(epsilon))

ε = 1.2986238408482182

If we take another set of polynomials, the result of the approximation will be the same
https://nbviewer.jupyter.org/github/G-Ryzhakov/uq2019/blob/master/lectures/lecture-1.ipynb 6/12
4/15/2021 Jupyter Notebook Viewer
If we take another set of polynomials, the result of the approximation will be the same
(coefficients α will be different of course).

In [10]: A = system_mat(nodes, n, p_herm)

if n == M:
alpha = np.linalg.solve(A, RH)
else:
alpha = np.linalg.lstsq(A, RH)[0]
print("α = {}".format(alpha))

approx_y = calc_apprximant(p_herm, alpha, x)

plt.plot(x, y, x, approx_y, nodes, RH, 'ro')

epsilon = np.linalg.norm(y - approx_y, np.inf)

print("ε = {}".format(epsilon))

α = [ -5.50759675 125.08412934 -13.36674349 95.71226857 -2.75379837

11.05673463]
ε = 1.2986238408482218

Now, what will change if we take another set of node points?

https://nbviewer.jupyter.org/github/G-Ryzhakov/uq2019/blob/master/lectures/lecture-1.ipynb 7/12
4/15/2021 Jupyter Notebook Viewer

In [11]: nodes = np.cos((2.0*np.arange(M) + 1)/M*0.5*np.pi)

RH = complex_func(nodes)
A = system_mat(nodes, n, p_herm)
alpha = np.linalg.solve(A, RH)
print("α = {}".format(alpha))

approx_y = calc_apprximant(p_herm, alpha, x)

plt.plot(x, y, x, approx_y, nodes, RH, 'ro')

epsilon_cheb = np.linalg.norm(y - approx_y, np.inf)

print("ε_cheb = {}".format(epsilon_cheb))

α = [ -8.17756076 69.1215116 -19.61829875 52.92933361 -4.03369459

6.1756528 ]
ε_cheb = 0.8212801266161324

https://nbviewer.jupyter.org/github/G-Ryzhakov/uq2019/blob/master/lectures/lecture-1.ipynb 8/12
4/15/2021 Jupyter Notebook Viewer

In [12]: # All in one. We can play with maximum polynomial power

def plot_approx(f, n, distrib='unif', poly='cheb'):
def make_nodes(n, distrib='unif'):
return {'unif' : lambda : np.linspace(-1, 1, n),
'cheb' : lambda : np.cos((2.0*np.arange(n) + 1.0)/n*0.5

poly_f = {'cheb' : p_cheb, 'herm' : p_herm}[poly[:4].lower()]

#solve
nodes = make_nodes(n, distrib)()
RH = f(nodes)
A = system_mat(nodes, n, p_herm)
alpha = np.linalg.solve(A, RH)

# calc values
x = np.linspace(-1, 1, 2**10)
y = f(x)
approx_y = calc_apprximant(p_herm, alpha, x)

#plot
plt.figure(figsize=(14,6.5))
plt.plot(x, y, x, approx_y, nodes, RH, 'ro')
plt.show()

# calc error
epsilon_cheb = np.linalg.norm(y - approx_y, np.inf)
print("ε = {}".format(epsilon_cheb))

from ipywidgets import interact, fixed, widgets

In [13]: interact(plot_approx,
f=fixed(complex_func),
n=widgets.IntSlider(min=1,max=15,step=1,value=4,continuous_upd
distrib=widgets.ToggleButtons(options=['Uniform', 'Chebyshev r
poly=widgets.ToggleButtons(options=['Chebyshev polynomials', '
);

Random input

Let input x is random with known probability density function ρ .

We want to know statistical properties of the output

mean value
variance
risk estimation

How to find them using polynomial expansion?

Assume the function f is analytical

https://nbviewer.jupyter.org/github/G-Ryzhakov/uq2019/blob/master/lectures/lecture-1.ipynb 9/12
4/15/2021 Jupyter Notebook Viewer

f (x) = αi pi (x).
∑
i=0

The mean value of f is

b ∞ b

𝔼f = f (τ)ρ(τ) dτ = αi pi (τ)ρ(τ) dτ.

∫ ∑∫
a a
i=0

If the set of orthogonal polynomials {pn } have the same weight function as ρ , and the first
polynomial is constant p0 (x) = h0 , then 𝔼f = α0 h0 . Usually, h0 = 1 and we get a simple
relation
𝔼f = α0

The variance is equal to

2
b ∞
2
Var f = 𝔼(f − 𝔼f ) = αi pi (τ) ρ(τ) dτ,
∫
a (∑ )
i=1

note, that the summation begins with 1. Assume we can interchange the sum and the integral,
then
∞ ∞ b ∞

2
Var f = αi pi (τ) αj pj (τ) ρ(τ) dτ = α hi .
i
∑∑∫ ∑
a
i=1 j=1 i=1

The formula is very simple if all the coefficients {hi } are equal to 1:
∞

2
Var f = α .
i
∑
i=1

Let us check the formulas for the mean and variance by calculating them using the Monte-
Carlo method.

Normal distribution

First, consider the case of normal distrubution of the input x ∼  (0, 1) ,

exp(−x /2) , so we take Hermite polynomials.
1 2
ρ(x) =
√ 2π

In [14]: # Scale the function a little

scale = 5.0

big_x = np.random.randn(int(1e6))
big_y = complex_func(big_x/scale)
mean = np.mean(big_y)
var = np.std(big_y)**2
print ("mean = {}, variance = {}".format(mean, var))

mean = -0.16581516100035978, variance = 0.23119787259823302

https://nbviewer.jupyter.org/github/G-Ryzhakov/uq2019/blob/master/lectures/lecture-1.ipynb 10/12
4/15/2021 Jupyter Notebook Viewer

In [16]: def p_herm_snorm(n):

"""
Square norm of "math" Hermite (w = exp(-x^2/2)/sqrt(2*pi))
"""
return np.math.factorial(n)

n = 15
M = n

nodes = np.linspace(-scale, scale, M)

RH = complex_func(nodes/scale)
A = system_mat(nodes, n, p_herm)

if n == M:
alpha = np.linalg.solve(A, RH)
else:
W = np.diag(np.exp( -nodes**2*0.5))
alpha = np.linalg.lstsq(W.dot(A), W.dot(RH))[0]

h = np.array([p_herm_snorm(i) for i in range(len(alpha))])

var = np.sum(alpha[1:]**2*h[1:])

print ("mean = {}, variance = {}".format(alpha[0]*h[0], var))

mean = -0.16556240297459568, variance = 0.2313061711624609

Note, that the precise values are

𝔼f = −0.16556230699 … , Var f = 0.23130350880 …

so, the method based on polynomial expansion is more accurate than Monte-Carlo.

In [17]: ex = 2
x = np.linspace(-scale - ex, scale + ex, 10000)
y = complex_func(x/scale)
approx_y = calc_apprximant(p_herm, alpha, x)
plt.plot(x, y, x, approx_y, nodes, RH, 'ro');

https://nbviewer.jupyter.org/github/G-Ryzhakov/uq2019/blob/master/lectures/lecture-1.ipynb 11/12
4/15/2021 Jupyter Notebook Viewer

Uniform distribution

In tha case of uniform distribution we use Legendre polynomials

1
2
pn (x)pm (x) dx = δ nm
∫ 2n + 1
−1

In [18]: from numpy.polynomial import Legendre

def p_legendre(x, n, interval=(-1.0, 1.0)):
"""
Non-normed Legendre poly.
"""
xn = (interval[0] + interval[1] - 2.0*x)/(interval[0] - interval[1]
return Legendre.basis(n)(xn)

def p_legendre_snorm(n, interval=(-1.0, 1.0)):

"""
RETURNS E[L_n L_n]
"""
return (interval[1] - interval[0])/(2.0*n + 1.0)

In [20]: n = 15
M = n

nodes = np.linspace(-1, 1, M)
RH = complex_func(nodes)
A = system_mat(nodes, n, p_legendre)

if n == M:
alpha = np.linalg.solve(A, RH)
else:
alpha = np.linalg.lstsq(A, RH)[0]

h = np.array([p_legendre_snorm(i) for i in range(len(alpha))])

var = np.sum(alpha[1:]**2*h[1:])

print ("mean = {}, variance = {}".format(alpha[0]*h[0], var))

mean = 0.17164179416392844, variance = 0.4656157485565891

The precise values are

𝔼f = 0.1700970689187 … , Var f = 0.4806857166498 …
