CONTENT
• One Wireless Access Point
• One AC power Adapter for the Wireless Access Point
• One Resource CD
ENGLISH-02
ENGLISH
INTRODUCTION
The COM-817 54Mbps Wireless Access Point is the basic building block
of a wireless LAN infrastructure. It provides connectivity between E
thernet wired networks and radio-equipped wireless notebook systems,
desktop systems, print servers, and other devices.
The COM-817 54Mbps Wireless Access Point acts as a bridge
between the wired LAN and wireless clients. Connecting multiple
COM-817 Access Points via a wired Ethernet backbone can further
lengthen the wireless network coverage.
In the most attentive wireless security, the COM-817 54Mbps Wireless
Access Point provides multiple protection methods. It can be set to turn
off wireless network name (SSID) broadcast so that only
stations that have the SSID can be connected. The AP provides
wireless LAN 64/128/152-bit WEP encryption security, and WPA/WPA2
and WPA-PSK/WPA2-PSK authentication, as well as TKIP/AES
encryption security. It also supports VPN pass-through for sensitive data
secure transmission.
The COM-817 54Mbps Wireless Access Point complies with the IEEE
802.11g/b standards so that the data transmission rate is up to 54Mbps.
It adopts 2x to 3x eXtended RangeTM WLAN transmission technology
so that transmission distance is 2-3 times of traditional IEEE 802.11g/b
solutions.
Transmission range is extended to 4-9 times. It is compatible with all
IEEE 802.11g and IEEE 802.11b products.
ENGLISH-03
ENGLISH
FEATURES
• Complies with IEEE 802.11g, IEEE 802.11b, IEEE 802.3, IEEE
802.3u standards
• Adopts 2x to 3x eXtended RangeTM WLAN transmission
technologies
• Supports 54/48/36/24/18/12/9/6Mbps or 11/5.5/3/2/1Mbps wireless
LAN data transfer rates
• Provides WPA/WPA2 and 64/128/152-bit WEP encryption security
• Built-in DHCP server supporting dynamic IP address distributing
• Supports MAC address filtering
• Supports multiple operating modes (AP/AP Client/Repeater/Bridge/
Multi-Bridge)
• Supports TCP/IP, DHCP, SNMP
• Supports Traffic statistics
• Supports firmware upgrade
• Supports Remote and Web management
ENGLISH-04
ENGLISH
CONTROLS
FRONTAL PANEL
ENGLISH-05
ENGLISH
REAR PANEL
b) Use the Reset button: First, turn off the AP’s power. Second,
press and hold the default reset button then turn on the AP’s
power, until the system LED lights up (about 3 seconds). Last,
release the reset button and wait for the AP to reboot.
AC power socket
ENGLISH-06
ENGLISH
CONNECTING THE AP
SYSTEM REQUIREMENTS
• Broadband Internet Access Service (DSL/Cable/Ethernet)
• DSL/Cable Modem that has an RJ45 connector
• Ethernet broadband router
• TCP/IP protocol must be installed on each PC
• Web browser, such as Microsoft Internet Explorer 5.0 or later,
Firefox
• 802.11g or 802.11b-compliant devices, such as the TL-WN510G
Wireless Adapter
ENGLISH-07
ENGLISH
CONNECTING THE AP
Next figure is an example of an infrastructure network incorporating the
COM-817. An Infrastructure network contains an access point or a
wireless router. For a typical connection of the AP, please do the
following:
ENGLISH-08
ENGLISH
Cable / DSL Modem
COM-817
ENGLISH-09
ENGLISH
TCP/IP CONFIGURATION
After connecting the COM-817 into your network, you should configure
it. The default IP address of the Wireless Access Point is 192.168.1.1,
and the default Subnet Mask is 255.255.255.0. These values can be
seen from the LAN.
They can be changed as you desire, as an example we use the default
values for description in this guide.
Connect the local PCs to the LAN ports on the AP. There are then two
ways to configure the IP address for your PCs:
ENGLISH-10
ENGLISH
Click ‘Start’→’Run’, type cmd in the text box and click Enter button, then
you will see a command prompt, and type ping 192.168.1.1, then press
Enter.
ENGLISH-11
ENGLISH
If the result displayed is similar to that shown in the figure, it means that
your PC has not connected to the AP. Please check it following these
steps:
The LED of LAN port on the AP and LED on your PC’s adapter
should be lit.
ENGLISH-12
ENGLISH
CONFIGURING THE AP
This chapter describes each Web page’s key functions.
Login
With a Web-based (Internet Explorer or Firefox) utility, the Wireless
Access Point is easy to configure and manage. The Web-based utility
can be used on any Windows, Macintosh or UNIX OS with a Web
browser.
Connect to the AP by typing http://192.168.1.1 in the address field of
Web browser.
After a moment, a login window will appear similar to that shown in the
figure. Enter admin for the User Name and Password, both in lower
case letters. Then click the OK button or press the Enter key.
ENGLISH-13
ENGLISH
If the above screen does not prompt, it means that your Web
browser has been set to a proxy. Go to Tools menu>Internet
Options>Connections>LAN Settings, in the screen that appears,
cancel the Using Proxy checkbox, and click OK to finish it.
After your successful login, you can configure and manage the AP.
There are six main menus on the left of the Web-based utility.
Submenus will be available after you click one of the main menus. The
six main menus are: Status, Network, Wireless, DHCP, Wireless
Advanced Settings and System Tools. On the right of the Web-based
utility, there are the detailed explanations and instructions for the
corresponding page. To apply any settings you have altered on the
page, please click the Save button.
ENGLISH-14
ENGLISH
STATUS
The Status page displays the AP’s current status and configuration. All
information is read-only.
1. Network
This field displays the current settings or information of the Network,
including the MAC address, IP address and Subnet Mask.
2. Wireless
This field displays basic information or status of the wireless function,
including Operating Mode, SSID, Channel, Mode, MAC Address and IP
Address.
3. Traffic Statistics
This field displays the AP’s traffic statistics.
4. System Up Time
The time of the AP running from it’s powered on or reset.
ENGLISH-15
ENGLISH
ENGLISH-16
ENGLISH
NETWORK
You can configure the IP parameters of Network on this page.
Type
Choose the type for the IP Address: Static IP, Dynamic IP
(DHCP). If you choose Static IP, you need to configure the IP
Address, Subnet Mask and Gateway.
If you choose Dynamic IP (DHCP), you don’t need to configure
the other information any more.
IP Address
Enter the IP address of your AP in dotted-decimal notation
(factory default: 192.168.1.1).
Subnet Mask
An address code that determines the size of the network.
Normally use 255.255.255.0 as the subnet mask.
ENGLISH-17
ENGLISH
Gateway
Enter the gateway address, it should be in the same subnet
with your IP address.
MAC Address
The physical address of the AP, as seen from the LAN. The
value can’t be changed.
ENGLISH-18
ENGLISH
WIRELESS
There are four submenus under the Wireless menu: Basic Settings,
Security Settings, MAC Filtering and Wireless Statistics. Click any of
them, and you will be able to configure the corresponding function. The
detailed explanations for each submenu are provided below.
ENGLISH-19
ENGLISH
Basic Settings
The basic settings for the wireless network are set on this page:
ENGLISH-20
ENGLISH
Channel
This field determines which operating frequency will be used.
It is not necessary to change the wireless channel unless you
notice interference problems with another nearby access point.
Mode
Select the desired wireless mode. The options are:
• 54Mbps (802.11g) - Both 802.11g and 802.11b
wireless stations can connect to the AP.
• 11Mbps (802.11b) - Only 802.11b wireless stations
can connect to the AP.
Region
Select your region from the pull-down list. This field specifies
the region where the wireless function of the AP can be used.
If your country or region is not listed, please contact your local
government agency for assistance.
The default region is United States. When you select your local
region from the pull-down list, the dialog shown in figure
appears. Click OK.
ENGLISH-21
ENGLISH
Limited by local law regulations, version for North America does
not have region selection option. The wireless basic settings for
this version are shown below.
ENGLISH-22
ENGLISH
Disable Wireless - The wireless of this AP can be enabled or
disabled to allow wireless stations access. If disabled, wireless
stations will not be able to access the AP.
AP provides five operational modes: Access Point, Client,
Repeater, Bridge (point to point), and Bridge (point to
Multi-point).
ENGLISH-24
ENGLISH
2. Verify the wireless security parameters for all access points, if
needed.
3. Verify connectivity across the LANs. A computer on any LAN segment
should be able to connect to the Internet, or share files and printers
with any other PCs or servers which are connected to any of the three
WLAN segments.
ENGLISH-25
ENGLISH
Bridge (Point to Point) - This mode bridges the AP and another
AP also in bridge mode to connect two wired LANs. Please
input the MAC address of the other AP in the field of MAC of
AP.
ENGLISH-26
ENGLISH
• Verify connectivity across LAN 1 and LAN 2. A computer on
either LAN segment should be able to connect to the Internet,
or share files and printers of any other PCs or servers which
are connected to LAN Segment 1 or LAN Segment 2.
ENGLISH-27
ENGLISH
1. Configure the Operating Mode of the COM-817 Access Points.
• Because it is in the central location, set COM-817 (AP1) on
LAN Segment 1 to Point-to-Multi-Point Bridge mode. The MAC
addresses of AP2 and AP3 are required in AP1.
• Set COM-817 (AP2) on LAN Segment 2 to Point-to-Point
Bridge mode with the MAC Address of AP1.
• Set the COM-817 (AP3) on LAN 3 to Point-to-Point Bridge
mode with the MAC Address of AP1.
ENGLISH-28
ENGLISH
You can extend this multi-point bridging by adding additional
COM-817 which are set to Point-to-Point mode for each additional
LAN segment. Furthermore, you can extend the range of the
wireless network with wireless antenna accessories.
SITE SURVEY
After selecting a mode and pressing button Survey, you can view all of
APs around you.
SSID
The SSID of the AP.
BSSID
The BSSID of the AP, usually also the MAC address of the AP.
Signal
The signal received from the AP.
ENGLISH-29
ENGLISH
Channel
The channel the AP works in.
Security
The AP communicates in privacy.
Choose
Choose one AP from list to connect to.
ENGLISH-30
ENGLISH
SECURITY SETTINGS
You can select one of the following security options:
ENGLISH-31
ENGLISH
Disable Security
The wireless security function can be enabled or disabled. If
disabled, the wireless stations will be able to connect to the AP
without encryption. It is strongly recommended that you choose
one of following options to enable security.
WEP
Select 802.11 WEP security.
• Type - You can select one of following types:
1) Automatic - Select Shared Key or Open
System authentication type automatically
based on the wireless station’s capability and
request.
2) Shared Key - Select 802.11 Shared Key
authentication.
3) Open System - Select 802.11 Open
System authentication.
If you do not set the key, the wireless security function is still
disabled even if you have selected Shared Key as Authentication
Type.
ENGLISH-33
ENGLISH
WPA/WPA2
Select WPA/WPA2 based on RADIUS Server.
ENGLISH-34
ENGLISH
WPA-PSK/ WPA2-PSK
Select WPA based on pre-shared passphrase.
Version - You can select one of following versions:
1) Automatic - Select WPA-PSK or WPA2-
PSK automatically based on the wireless
station’s capability and request.
2) WPA-PSK - Pre-shared key of WPA.
3) WPA2-PSK - Pre-shared key of WPA2.
Be sure to click the Save button to save your settings on this page.
The AP will reboot automatically after you click the Save button if
you have select the Reboot checkbox.
ENGLISH-35
ENGLISH
MAC ADDRESS FILTERING
The Wireless MAC Address Filtering feature allows you to control
wireless stations accessing the AP, which depend on the station’s MAC
addresses.
ENGLISH-36
ENGLISH
WEP Key - Specify a unique WEP key (in Hexadecimal format)
to access the AP.
To disable the Wireless MAC Address Filters feature, keep the default
setting, Disable.
To Add a Wireless MAC Address filtering entry, click the Add New…
button. The “Add or Modify Wireless MAC Address Filtering entry” page
will appear, shown in figure:
ENGLISH-37
ENGLISH
To add or modify a MAC Address Filtering entry, follow these
instructions:
1. Enter the appropriate MAC Address into the MAC Address field. The
format of the MAC Address is XX-XX-XX-XX-XX-XX (X is any
hexadecimal digit). For example: 00-0A-EB-B0-00-0B.
2. Enter a simple description of the wireless station in the Description
field. For example: Wireless station A.
3. Privilege - Selects the privileges for this entry, one of Allow / Deny /
64-bit / 128-bit / 152-bit.
4. WEP Key - If you select 64-bit, 128-bit or 152-bit in the Privilege field,
enter any combination of hexadecimal digits (0-9, a-f, A-F) in the
specified length. For example: 2F34D20BE2.
5. Status - Select Enabled or Disabled for this entry on the Status
pull-down list.
6. Click the Save button to save this entry.
ENGLISH-38
ENGLISH
You can click the Enable All button to make all the entries effective, click
the Disable All button to make all the entries ineffective, click the Delete
All button to delete all the entries.
Click the Next button to go to the next page and click the Previous
button to return to the previous page.
For example: If you desire that the wireless station A with MAC address
00-0A-EB-00- 07-BE be able to access the AP, the wireless station B
with MAC address 00-0A-EB- 00-07-5F not be able to access the AP,
and the wireless station C with MAC address 00-0A-EB-00-07-8A
be able to access the AP when its WEP key is 0123456789ABC-
DEF0123456789, while all other wireless stations cannot access the
AP, you should configure the Wireless MAC Address Filtering list
following these steps:
ENGLISH-39
ENGLISH
Enabled in the Status pull-down list. Click the Save and the Return
button.
6. Click the Add New... button and enter the MAC address 00-0A-EB-00-
07-8A in the MAC Address field, enter wireless station C in the
Description field, select 128-bit in the Privilege pull-down list, enter 2F3
4D20BE2E54B326C5476586A in the WEP Key field and select Enabled
in the Status pull-down list. Click the Save and the Return button.
The filtering rules that configured should be similar to the following list:
If you enable the function and select the Deny the stations not
specified by any enabled entries in the list to access for Filtering
Rules, and there are not any enable entries in the list, thus, no
wireless stations can access the AP.
ENGLISH-40
ENGLISH
WIRELESS STATISTICS
This page shows MAC Address, Current Status, Received Packets and
Sent Packets for each connected wireless station.
MAC Address
The connected wireless station’s MAC address
Current Status
The connected wireless station’s running status, one of
STA-AUTH / STA-ASSOC / STA-JOINED / WPA / WPA-PSK /
WPA2 / WPA2-PSK / AP-UP / AP-DOWN / Disconnected
Received Packets
Packets received by the station
Sent Packets
Packets sent by the station
ENGLISH-41
ENGLISH
You cannot change any of the values on this page. To update this page
and to show the current connected wireless stations, click on the
Refresh button.
If the numbers of connected wireless stations go beyond one page, click
the Next button to go to the next page and click the Previous button to
return the previous page.
ENGLISH-42
ENGLISH
DHCP
There are three submenus under the DHCP menu: DHCP Settings,
DHCP Clients List and Address Reservation.
DHCP Settings
The System can be set up as a DHCP (Dynamic Host Configuration
Protocol) server, which provides the TCP/IP configuration for all the PCs
that are connected to the system on the LAN. The DHCP Server can be
configured on the page:
ENGLISH-43
ENGLISH
DHCP Server - Enable or Disable the DHCP server. If you
disable the Server, you must have another DHCP server within
your network or else you must manually configure the
computer.
To use the DHCP server function of the AP, you must configure all
computers on the LAN as “Obtain an IP Address automatically”
mode. This function will take effect until the AP reboots.
ENGLISH-45
ENGLISH
Lease Time - The time of the DHCP client leased. Before the
time is up, DHCP client will request to renew the lease
automatically.
You cannot change any of the values on this page. To update this page
and to show the current attached devices, click on the Refresh button.
ADDRESS RESERVATION
When you specify a reserved IP address for a PC on the LAN, that PC
will always receive the same IP address each time when it accesses the
DHCP server. Reserved IP addresses should be assigned to servers
that require permanent IP settings. This page is used for address
reservation.
ENGLISH-46
ENGLISH
MAC Address - The MAC address of the PC of which you want
to reserve IP address.
To Reserve IP addresses:
1. Enter the MAC address (The format for the MAC Address is
XX-XX-XX-XX-XX-XX.) and IP address in dotted-decimal notation of the
computer you wish to add.
2. Click the Save button when finished.
Click the Next button to go to the next page and Click the Previous
button to return the previous page.
ENGLISH-47
ENGLISH
WIRELESS ADVANCED SETTINGS
You can configure wireless advanced settings on this page.
ENGLISH-48
ENGLISH
SYSTEM TOOLS
There are four submenus under the System Tools menu: Factory
Defaults, Reboot, Password, and Log.
FACTORY DEFAULTS
This page allows you to restore the factory default settings for the AP.
ENGLISH-49
ENGLISH
Click the Restore button to reset all configuration settings to their default
values.
All the settings you have saved will be discarded when the default
settings are restored.
REBOOT
This function allows you to reboot the AP.
ENGLISH-50
ENGLISH
Some settings of the AP will take effect only after rebooting, which
include:
PASSWORD
This page allows you to change the factory default user name and
password of the AP. All users who try to access the AP’s Web-based
utility or Quick Setup will be prompted for the AP’s user name and
password.
ENGLISH-51
ENGLISH
The new user name and password must not exceed 14 characters
in length and must not include any spaces. Enter the new
Password twice to confirm it.
LOG
This page allows you to query the Logs of the AP.
The AP can keep logs of all traffic. You can query the logs to find what
happened to the AP.
ENGLISH-52
ENGLISH
APPENDIX A: FAQ
1. No lights are lit on the access point.
It takes a few seconds for the POWER indicator to light up. Wait a
minute and check the POWER light status.
ENGLISH-53
ENGLISH
3. I cannot access the AP with a wireless capable computer.
There is a configuration problem. Check these items:
1) You may not have restarted the computer with the wireless
adapter to have TCP/IP changes take effect. Restart the
computer.
2) The computer with the wireless adapter may not have the
correct TCP/IP settings to communicate with the network.
Restart the computer and check that TCP/IP is set up properly
for that network. The usual setting for Windows the Network
Properties is set to “Obtain an IP address automatically.”
3) The access point’s default values may not work with your
network. Check the access point default configuration against
the configuration of other devices in your network.
ENGLISH-54
ENGLISH
APPENDIX B: CONFIGURING THE PCS
In this section, we’ll introduce how to install and configure the TCP/IP
correctly in Windows 95/98. First make sure your Ethernet Adapter is
working, refer to the adapter’s manual if needed.
ENGLISH-55
ENGLISH
4) Under Manufacturers on Select Network Protocol page, highlight
Microsoft. Under Network Protocols, highlight TCP/IP. Click OK. TCP/IP
protocol will take effect after reboot.
ENGLISH-56
ENGLISH
2) Double-click the Network icon, highlight the bound TCP/IP tab in
the appearing Network window that appears. An example shown in the
following figure:
ENGLISH-57
ENGLISH
4) Now you have two ways to configure the TCP/IP protocol below:
ENGLISH-58
ENGLISH
b. Do not type anything into the New gateway field on
the Gateway tab.
ENGLISH-59
ENGLISH
c. Choose Disable DNS on the DNS configuration tab,
as shown in the following figure:
ENGLISH-60
ENGLISH
• Setting IP address manually
a. Select Specify an IP address on IP Address tab, as
shown in the following figure. If the AP’s LAN IP
address is 192.168.1.1, type IP address is
192.168.1.x (x is from 2 to 254), and subnet mask is
255.255.255.0.
ENGLISH-61
ENGLISH
b. Type the AP’s LAN IP address (the default IP is
192.168.1.1) into the New gateway field on the
Gateway tab, and click on the Add button, as shown
in the figure:
ENGLISH-62
ENGLISH
c. On the DNS Configuration tab, click Enable DNS
radio, and type your computer name in to the Host
field and a Domain (such as szonline.com) into the
Domain field. In the DNS Server Search Order field
you can type the DNS server IP addresses, which has
been provided by your ISP, and click Add button.
Shown below:
Now, all the configurations are finished, it will take effect after reboot.
ENGLISH-63
ENGLISH
APPENDIX C: SPECIFICATIONS
Frequency band: 2.4~2.4835GHz
Modulation: BPSK, QPSK, CCK, OFDM (BPSK/
QPSK/16-QAM/ 64-QAM)
Range: up to 100m
RF power: 17dBm
Antenna: 3dBi
Standards: IEEE 802.3, 802.3u, 802.11b and 802.11g
Protocols: TCP/IP, DHCP
Ports: One 10/100M Auto-Negotiation LAN RJ45
port supporting Auto MDI/MDIX
Cabling Type: 10BASE-T: UTP category 3, 4, 5 cable
(maximum 100m)
EIA/TIA-568 100Ω STP
(maximum 100m)
100BASE-TX: UTP category 5, 5e cable
(maximum 100m)
EIA/TIA-568 100Ω STP
(maximum 100m)
Radio Data Rate: 54/48/36/24/18/12/9/6Mbps or
11/5.5/3/2/1Mbps
Power Supply: 9V~ 0.8A
Operating Temperature: 32°F~104°F
Operating Humidity: 10% - 95% RH, Non-condensing
Dimensions: 6.2×4.3×1.3in (without antenna)
ENGLISH-64
ENGLISH
AC power adapter
Input: 120V ~ 60Hz 0,15A
Output: 9V~ 800mA
ENGLISH-65
Product: Wireless-G Access point / Repeater
Part number: COM-817
Brand: Steren
WARRANTY
This Steren product is warranted under normal usage against defects in workmanship and
materials to the original purchaser for one year from the date of purchase.
CONDITIONS
1.- This warranty card with all the required information, invoice or purchase ticket, product
box or package, and product, must be presented when warranty service is required.
2.- If the product stills on the warranty time, the company will repair it free of charge.
3.- The repairing time will not exceed 30 natural days, from the day the claim was received.
4.- Steren sell parts, components, consumables and accesories to costumer, as well as
warranty service, at any of the addresses mentioned later.
a) The consumer can also claim the warranty service in the purchase establishment.
b) If you lose the warranty card, we can reissue it, if you show the invoice or purchase ticket.
RETAILER INFORMATION
Name of the retailer
Address
Product
Brand
Part number
Serial number
Date of delivery
In case your product fails or have questions, please contact your nearest dealer. If
you are in Mexico, please give a call to our Call Center.
Call Center
Province: 01 800 500 9000
Antes de utilizar su nuevo Repetidor y Punto de Acceso
inalámbrico lea este instructivo para evitar cualquier mal
funcionamiento. Guárdelo para futuras referencias.
CONTENIDO
• 1 punto de acceso de 54Mbps
ESPAÑOL
• 1 adaptador de corriente para el punto de acceso
• 1 disco de instalación
ESPAÑOL-02
INTRODUCCIÓN
El Punto de Acceso inalámbrico COM-817 es la piedra angular de una
red inalámbrica LAN. Le proporciona conectividad entre redes
alámbricas Ethernet y equipos inalámbricos como computadoras
portátiles, computadoras de escritorio, servidores de impresión, entre
ESPAÑOL
otros equipos.
El COM-817 actúa como un puente entre la red alámbrica LAN y los
clientes inalámbricos. Conectando múltiples COM-817 a través de una
red Ethernet puede ampliar el tamaño de cobertura de una red.
Cuenta con una excelente seguridad, ofreciendo múltiples métodos
de protección. Puede ser configurado para ocultar el nombre de la red
inalámbrica (SSID) de tal forma que solamente estaciones que cuenten
con SSID puedan conectarse. El punto de acceso proporcionar
seguridad encriptada en una red inalámbrica WEP 64/128/152-bits,
así como autentificación WPA/WPA2, WPA-PSK/WPA2-PSK, y TKIP/
AES. Así mismo, soporta VPN para una transmisión de datos segura y
sensitiva.
ESPAÑOL-03
CARACTERÍSTICAS
• Cumple con los estándares IEEE 802.11g, IEEE 802.11b, IEEE
802.3, IEEE 802.3u
• Adopta las tecnologías de transmisión inalámbrica WLAN 2x y 3x
eXtended Range
• Soporta tasas de transferencia de 54/48/36/24/18/12/9/6Mbps o
ESPAÑOL
11/5.5/3/2/1Mbps de forma inalámbrica
• Proporciona seguridad encriptada WPA/WPA2 y 64/128/152-bits
• Servidor DHCP incluido, y soporta distribución de direcciones IP
dinámicas
• Soporta filtración de direcciones MAC
• Soporta modos de operación múltiple ( AP/AP Cliente /Repetidor/
Puente/Multi-puente)
• Soporta TCP/IP, DHCP, SNMP
• Soporta estadísticas de tráfico
• Soporta actualización de Firmware
• Soporta la administración remota y de Web
ESPAÑOL-04
CONTROLES
PANEL FRONTAL
ESPAÑOL
LED Estado Descripción
Apagado Apagado
POWER
Encendido Encendido
Encendido Inicializando
SYSTEM Parpadeo Trabajando adecuadamente
Apagado Hay un error de hardware
No hay equipo conectado al puerto
Apagado
correspondiente
Hay un equipo conectado al puerto
LAN Encendido
correspondiente
Hay un equipo activo conectado al puerto
Parpadeo
correspondiente
Apagado La función inalámbrica está desactivada
WLAN
Parpadeo La función inalámbrica está activada
ESPAÑOL-05
PANEL TRASERO
ESPAÑOL
1.- Antena
REQUERIMIENTOS DE SISTEMA
• Servicio de Internet de banda ancha (DSL / Cable / Ethernet)
• MODEM DSL / Cable con conector RJ45
ESPAÑOL
• Ruteador Ethernet de banda ancha
• Protocolo RCP/IP debe ser instalado en cada computadora
• Navegador de Internet, como Internet Explorer 5.0 o superior,
Firefox entre otros
• Equipos que cumplan con los estándares 802.11g / 802.11b
ESPAÑOL-07
CONECTANDO EL PUNTO DE ACCESO
La siguiente figura es un ejemplo de una red de infraestructura
incorporando el COM-817. Una red de infraestructura contiene un punto
de acceso o un ruteador inalámbrico. Para una conexión típica del
punto de acceso, realice lo siguiente:
ESPAÑOL
1.- Necesita tener acceso a Internet de banda ancha. Consulte con su
proveedor de Cable o DSL para una correcta instalación del MODEM.
2.- Conecte el MODEM de Cable o DSL al ruteador. Rápidamente
instale el ruteador.
3.- Localice un lugar ideal para el punto de acceso. El mejor lugar
normalmente es en el centro del área en donde sus PCs se conectarán
de forma inalámbrica. Recuerde revisar los Requerimientos
ambientales de instalación.
4.- Ajuste la dirección de la antena. Normalmente, completamente
extendida hacia arriba es buena dirección.
5.- Conecte el ruteador Ethernet de banda ancha al COM-817.
Encienda el punto de acceso.
6.- Si está conectando una computadora de escritorio o una
computadora portátil a la red, instale el adaptador inalámbrico en la
computadora.
ESPAÑOL-08
Modem Cable / DSL
ESPAÑOL
Ruteador o Switch COM-817
COM-817
ESPAÑOL-09
CONFIGURACIÓN TCP/IP
Después de conectar el COM-817 en la red, debe configurarla. La
dirección IP predeterminada es 192.168.1.1, y la máscara de subred es
255.255.255.0. Estos valores pueden ser vistos desde la red. Pueden
cambiarse de acuerdo a sus necesidades, como un ejemplo,
utilizaremos los valores predeterminados en este manual.
ESPAÑOL
Conecte las computadores locales de la red en el punto de acceso.
Existen dos formas de configurar la dirección IP de las PCs:
ESPAÑOL-10
Ahora, ejecute el comando PING en la ventana de comandos para
verificar la conexión de red entre la PC y el punto de acceso. El
siguiente ejemplo se ejecutó en Windows 2000.
ESPAÑOL
Enter.
ESPAÑOL-11
ESPAÑOL
Si el resultado desplegado es similar al mostrado en la figura, la
conexión entre la PC y el punto de acceso no ha sido establecida. Por
favor, revise la conexión siguiendo estos pasos:
ESPAÑOL-12
CONFIGURANDO EL PUNTO DE ACCESO
Este capítulo describe cada función Web.
Accesando
Con un navegador de Internet (Internet Explorer o Firefox) el COM-817
puede ser fácilmente configurado y controlado. La utilidad Web puede
ESPAÑOL
ser utilizada en cualquier versión de Windows.
Conecte el punto de acceso tecleando http://192.168.1.1 en el campo
de dirección del navegador de Internet.
ESPAÑOL-13
Si alguna de las pantallas previas no aparece, significa que su
navegador de Internet ha sido configurado como Proxy. Abra el
menú de Herramientas >> Opciones de Internet >> Conexiones
>> Ajustes de red, en la pantalla que aparece desactive la opción
Proxy y presione OK para guardar los cambios.
ESPAÑOL
Después de que haya entrado, podrá configurar y controlar el punto de
acceso. Existen 6 menús principales del lado izquierdo de la utilidad
web. Existen submenús que están disponibles después de seleccionar
el menú principal. Los seis menús principales son: Status, Network,
Wireless, DHCP, Wireless Advanced Settings y System Tools. Del lado
derecho de la utilidad existen explicaciones detalladas e instrucciones
para la página correspondiente. Para aplicar cualquier cambio realiza-
do, deberá presionar el botón de Save.
ESPAÑOL-14
STATUS
La página de Status muestra el estado actual de punto de acceso y la
configuración. Toda la información es de sólo lectura.
1.- Network
Este campo muestra la configuración actual o información de la red,
ESPAÑOL
incluyendo la dirección MAC, la dirección IP y la máscara de subred.
2.- Wireless
Muestra información básica o el estado de la función inalámbrica,
incluyendo el Modo de operación, SSDI, Canales, Modo, dirección MAC
y dirección IP.
ESPAÑOL-15
ESPAÑOL
ESPAÑOL-16
NETWORK
Puede configurar los parámetros IP de la red en está página.
ESPAÑOL
Type
Seleccione el tipo de dirección IP: IP fija, IP dinámica (DHCP).
Si seleccionar IP fija, necesita configurar la dirección IP, la
máscara de subred y la puerta de acceso.
Si selecciona IP Dinámica (DHCP) no necesita configurar otra
información.
IP Address
Introduzca la dirección IP del punto de acceso en formato de
punto decimal (predeterminado de fábrica 192.168.1.1).
Máscara de subred
Es un código de dirección que determina el tamaño de la red.
Normalmente se utiliza 255.255.255.0.
ESPAÑOL-17
Puerta de acceso
Introduzca la dirección de la puerta de acceso. Debe estar en
la misma subred con la dirección IP
MAC Address
Dirección física del punto de acceso, se puede ver desde la
ESPAÑOL
red. El valor no puede ser cambiado
ESPAÑOL-18
WIRELESS
ESPAÑOL
Existen 4 submenús dentro del menú Wireless: Basic Settings, Security
Settings, MAC filtering, Wireless Statistics. Presione cualquier de ellos y
podrá entrar al modo de configuración.
ESPAÑOL-19
Basic Settings
La configuración básica de la red inalámbrica se puede realizar a través
de este menú.
ESPAÑOL
ESPAÑOL-20
Channel
Este campo determina que frecuencia será utilizada. No es
necesario cambiar el canal a menos de que note interferencias
con otro punto de acceso cercano.
Mode
ESPAÑOL
Seleccione el modo de estación inalámbrica. Cuenta con las
siguientes opciones:
- 54Mbps (802.11g): Maneja estaciones inalámbricas
802.11g y 802.11b
- 11Mbps (802.11b): Únicamente se pueden utilizar
estaciones inalámbricas 802.11b
Region
Seleccione una de las regiones de la lista. Especifica la región
donde la función inalámbrica del punto de acceso puede ser
utilizada. Si el país o la región no se encuentra en la lista,
contacte a su gobierno local para asistencia.
La región predeterminada es Estados Unidos. Cuando
selecciona su región local de la lista, aparece una nueva
ventana. Presione OK.
ESPAÑOL-21
Limitado por regulaciones legales locales, la versión de Norte
América no contiene opciones de regiones. La configuración
básica inalámbrica para esta versión se muestra a continuación.
ESPAÑOL
ESPAÑOL-22
Disable Wireless
La función inalámbrica de este punto de acceso puede ser
activada o desactivada para permitir el acceso de estaciones
inalámbricas. Si está desactivado, las estaciones inalámbricas
no estarán disponibles para acceder al punto de acceso.
El punto de acceso provee de 5 modos operacionales: Punto
ESPAÑOL
de Acceso, Cliente, Repetidor, Puente (punto a punto), y
Puente (punto a multi-punto).
Access Point
Este modo permite acceder a las estaciones inalámbricas
incluyendo a los clientes de punto de acceso.
- SSID
Introduzca un valor de hasta 32 caracteres. El
mismo nombre (SSID)debe ser asignado a todos los
equipos inalámbricos en la red. El SSID predetermi
nado es Steren, pero se recomienda que cambie el
nombre de las redes (SSID). Este valor es muy
sensible, por ejemplo STEREN no es lo mismo que
steren.
ESPAÑOL-23
Client
Este modo permite a una o más redes inalámbricas
conectarse con la red central, y crear una red extendida virtual.
De esta manera, cualquier estación de la red remota puede
comunicarse satisfactoriamente con cualquier estación de
la red central, como si todas pertenecieran a la misma red
ESPAÑOL
física. Las estaciones inalámbricas no pueden asociarse a
clientes del punto de acceso.
- SSID
Introduzca el SSID del punto de acceso que desee
acceder. Si selecciona el radio antes del SSID, el
cliente del punto de acceso se conectará al punto de
acceso de acuerdo al SSID.
- Mac of AP
Introduzca la dirección MAC del punto de acceso
que desee. Si selecciona el radio antes de la
dirección MAC, el cliente del punto de acceso se
conectará al punto de acceso de acuerdo a la
dirección MAC.
Repeater
Un repetidor inalámbrico es un punto de acceso con su propio
BSS que retrasa la información a la raíz de un punto de
acceso, al cual es asociado. El repetidor inalámbrico retrasa la
señal entre sus estaciones y la raíz del PA para un rango
ESPAÑOL-24
mayor. Por favor introduzca la dirección MAC de la raíz del PA
en el campo de MAC of AP.
ESPAÑOL
1.- Configure el modo de Operación del COM-817
- Ajuste AP1 en el segmento LAN 1 para acceder al modo.
- Ajuste AP2 al modo de Repetidor con la dirección MAC de su
punto de acceso raíz (AP1)
- Ajuste AP3 al modo de Repetidor con la dirección MAC de su
punto de acceso raíz (AP2)
ESPAÑOL-25
2.- Verifique los parámetros de seguridad de todos los puntos de
acceso, si es necesario.
3.- Verifique la conectividad entre las redes. Una computador de
cualquier segmento de red debe estar disponible para conectarse a
Internet, o compartir archivos e impresoras con cualquier otra PC o
servidor que esté conectados a cualquiera de los tres segmentos de la
ESPAÑOL
red inalámbrica.
ESPAÑOL-26
A continuación se muestra un ejemplo de cómo configurar un Puenteo
punto a punto. Siga las instrucciones:
ESPAÑOL
1.- Configure AP1 en el segmento de red 1 al modo Point-to-Point
Bridge
2.- Configure AP2 en el segmento de red 2 al modo Point-to-Point
Bridge. AP1 debe tener la dirección MAC de AP2 en su campo de MAC
address y AP2 debe tener la dirección MAC de AP1 en su campo de
MAC address.
3.- Configure y verifique los siguientes parámetros para ambos puntos
de acceso:
- Ambos deben utilizar el mismo canal y la misma
configuración de seguridad en caso de utilizarlos
ESPAÑOL-27
- Verifique la conectividad entre la red 1 y la red 2. Una
computadora en cualquier segmentos de red debe estar
disponible para conectarse a Internet, compartir archivos e
imprimir desde cualquier PC o servidor que está conectado al
segmento de red 1 o el segmento de red 2.
ESPAÑOL
Bridge (Point to Multipoint) – este modo puentea el PA y hasta
4 puntos de acceso también en modo de puenteo para
conectar dos o más redes alámbricas. Introduzca la dirección
MAC de los otros puntos de acceso en el campo de MAC of
AP1 hasta MAC of AP4.
ESPAÑOL-28
1.- Configure el modo de operación del COM-817.
- Debido a que se encuentra en un lugar central, configure el
COM-817 (AP1) en el segmento de red 1 al modo de puenteo
punto-a-multipunto. Las direcciones MAC de AP2 y AP3 son
requeridas en AP1.
- Configure el COM-817 (AP2) en el segmento de red 2 al
ESPAÑOL
modo de Point-to-Point Bridge con al dirección MAC de AP1.
- Configure el COM-817 (AP3) en la red 3 al modo de puenteo
punto a punto con la dirección MAC de AP1.
ESPAÑOL-29
segmento de la red puede agregar puntos de acceso
COM-817 que estén configurados en el modo de Punto de
Acceso Inalámbrico a cualquier segmento de red.
ESPAÑOL
cuales tienen que estar configurados en modo Point-to-Point para
cada segmento adicional de la red. Además, puede extender el
rango de la red inalámbrica con antenas.
SITE SURVEY
Después de seleccionar un modo y presionar el botón de Survey, puede
ver todos los puntos de acceso alrededor.
SSID
El SSID del punto de acceso.
BSSID
El BSSID del punto de acceso, usualmente también la MAD
address del punto de acceso
ESPAÑOL-30
Signal
La señal recibida desde el punto de acceso.
Channel
El canal en el que el punto de acceso trabaja.
ESPAÑOL
Security
El punto de acceso se comunica en privado
Choose
Seleccione un punto de acceso de la lista para conectarse
ESPAÑOL-31
PARÁMETROS DE SEGURIDAD
Puede seleccionar una de las siguientes opciones de seguridad:
ESPAÑOL
ESPAÑOL-32
Disable Security
La función de seguridad inalámbrica puede estar activada o
desactivada. Si está desactivada, las estaciones inalámbricas
estarán disponibles para conectarse al punto de acceso sin
encriptación. Se recomiendo que selecciona una de las
siguientes opciones para activar la seguridad.
ESPAÑOL
WEP
Seleccione la seguridad 802.11 WEP
- Type: Puede seleccionar uno de los siguientes tipos:
1) Automático: Seleccione el modo de
autentificación Llave compartida o Sistema
Abierto.
2) Llave compartida: Seleccione la
autentificación de llave compartida 802.11
3) Sistema abierto: Seleccione el modo de
autentificación de sistema abierto 802.11
ESPAÑOL
1) Para encriptación de 64-bits – Puede introducir 10
dígitos hexadecimales (cualquier combinación de 0-9,
a-f, A-F, el cero no está permitido) o 5 caracteres
ASCII.
2) Para encriptación de 128-bits – Puede introducir 26
dígitos hexadecimales (cualquier combinación de 0-9,
a-f, A-F, el cero no está permitido) o 13 caracteres
ASCII.
3) Para encriptación de 152-bits – Puede introducir 32
dígitos hexadecimales (cualquier combinación de 0-9,
a-f, A-F, el cero no está permitido) o 16 caracteres
ASCII.
ESPAÑOL-34
WPA / WPA2
Seleccione la función WPA/WPA2 basados en el servidor
RADIUS
ESPAÑOL
1) Automatic – Permite seleccionar WPA o
WPA2 de forma automática basado en la
capacidad y las peticiones de las estaciones
inalámbricas
2) WPA – Acceso protegido Wi-Fi
3) WPA2 – WPA versión 2
ESPAÑOL-35
WPA-PSK / WPA2-PSK
Seleccione la función WPA basado en una contraseña
pre-compartida
ESPAÑOL
1) Automatic – Permite seleccionar WPA-
PSK o WPA2-PSK de forma automática
basado en la capacidad y las peticiones de
las estaciones inalámbricas
2) WPA-PSK – Llave pre-compartida de
WPA
3) WPA2-PSK – Llave pre-compartida de
WPA2
ESPAÑOL
que desee acceder.
ESPAÑOL-37
Para configurar una entrada, seleccione Enable y siga las
instrucciones:
ESPAÑOL
access, de otra forma seleccione Deny the stations not specified by any
enabled entries in the list to access.
ESPAÑOL-38
Para agregar o modificar una entrada de filtro de dirección MAC,
siga estas instrucciones:
1.- Introduzca la dirección MAC adecuada en el campo MAC Address.
El formato de la MAC address es XX-XX-XX-XX-XX-XX (donde X es
cualquier dígito hexadecimal). Por ejemplo: 00-0A-EB-B0-00-0B.
2.- Introduzca una descripción sencilla de la estación inalámbrica en el
ESPAÑOL
campo Description. Por ejemplo: Estación inalámbrica A.
3.- Privilege – Seleccione los privilegios para esta entrada: Allow / Deny
/ 64-bits, 128-bits, 152-bits.
4.- WEP Key – Si selecciona 64-bits, 12-bits o 152-bits en el campo de
Privilege, introduzca cualquier combinación en formato hexadecimal
(0-9, a-f, A-F) en la longitud requerida. Por ejemplo: 2F34D20BE2.
5.- Status – Seleccione la opción de Enabled o Disabled para esta
entrada en la lista de Status.
6.- Presione Save para guardar los cambios.
ESPAÑOL-39
Puede presionar el botón Enable All para activar todas las entrada,
presione Disable All para desactivar todas las entradas, presione Delete
All para borrar todas las entradas.
ESPAÑOL
Por ejemplo: Si desea que la estación inalámbrica A con dirección MAC
00-0A-EB-00-07-BE esté disponible para acceder al PA, que la estación
inalámbrica B con dirección MAC 00-0A-EB-00-07-5F no esté
disponible para acceder al PA, y la estación inalámbrica C con dirección
MAC 00-0A-EB-00-07-8A esté disponible para acceder al PA y la llave
WEP es 0123456789ABCDEF0123456789, mientras que todas
estaciones inalámbricas restantes no puedan acceder el PA, debe
configurar el Wireless MAC Address Filtering de la siguiente manera:
ESPAÑOL-40
5.- Presione Add New... e introduzca la dirección MAC 00-0A-EB-
00-07-5F en el campo MAC Address, introduzca el nombre Estación
Inalámbrica B en el campo de Description, seleccione Deny en la lista
de Privilege, y seleccione Enabled en la lista de Status. Presione Save
y el botón de Return.
6.- Presione el botón Add New… e introduzca la dirección MAC 00-0A-
ESPAÑOL
EB-00-07-8A en el campo de MAC address, introduzca el nombre
Estación Inalámbrica C en el campo de Description, seleccione 128-
ñbits en la lista Privilege, introduzca 2F34D20BE2E54B326C5476586A
en el campo WEP Key y seleccione Enabled en la lista de Status.
Presione Save y posteriormente Return.
ESPAÑOL-41
Si activa la función y selecciona Deny the stations not specified
by any enabled entries un the list to access en el menu Filtering
Rules, y no hay entradas activas en la lista, entonces ninguna
estación podrá acceder al PA.
ESPAÑOL
ESTADÍSTICAS
Esta página muestra información de la MAC Address, el estado actual,
los paquetes recibidos y enviados de cada estación inalámbrica
conectada
ESPAÑOL-42
Received Packets – Muestra los paquetes recibidos por la
estación
ESPAÑOL
página y mostrar las estaciones conectadas actualmente, presione el
botón Refresh.
Si el número de estaciones conectadas ocupan más de una página,
presione el botón de Next para ver la siguiente página o Previous para
regresar a la página anterior.
ESPAÑOL-43
DHCP
Existen 3 submenús: DHCP Settings, DHCP Clients, y Address
Reservation
ESPAÑOL
DHCP Settings
El sistema puede ser configurado como un servidor DHCP (Dynamic
Host Configuration Protocol), que provee la configuración TCP/IP para
todas las computadoras que estén conectadas al sistema en la red. El
servidor DHCP puede ser configurado en este menú:
ESPAÑOL-44
DHCP Server – Permite activar o desactivar el servidor. Si lo
desactiva, debe tener otro servidor DHCP dentro de esa red y
configurar manualmente la computadora.
ESPAÑOL
la dirección predeterminada inicial.
ESPAÑOL-45
Primary DNS – (Opcional) Introduzca la dirección IP DNS
proporcionada por su proveedor de Internet.
ESPAÑOL
Para utilizar la función de servidor DHCP, debe configurar todas
las computadoras de la red como “Obtain an IP Address
Automatically”. Esta función tomará efecto cuando reinicie el PA.
ESPAÑOL-46
Index - Muestra el índice del cliente DHCP
ESPAÑOL
Assigned IP – La dirección IP que el PA tiene colocado en el
cliente DHCP
ESPAÑOL-47
RESERVACIÓN DE DIRECCIÓN
Cuando especifica una dirección IP reservada para una PC de la red,
esa computadora siempre recibirá la misma dirección IP cada vez
cuando accede al servidor DHCP. Las direcciones IP reservadas deben
estar asignadas a servidores que requieren configuración permanente
IP. Esta página es utilizada para reservar direcciones.
ESPAÑOL
MAC Address – Muestra la MAC address de la computadora
que desea reservar la dirección IP
ESPAÑOL-48
Para reservar una dirección IP
1.- Introduzca la dirección MAC (el formato de la dirección MAC es XX-
XX-XX-XX-XX-XX) y la dirección IP en formato de punto decimal de la
computadora que desee agregar.
2.- Presione el botón de Save cuando termine.
ESPAÑOL
Para modificar una dirección IP reservada
1.- Seleccione la dirección reservada que desee, y modifíquela. Si
desea borrar la entrada, deje todos los campos en blanco.
2.- Presione el botón Save.
ESPAÑOL-49
CONFIGURACIÓN AVANZADA
Mediante esta página podrá realizar configuración avanzada del equipo.
ESPAÑOL
Disable short preamble – El modo 802.11b soporta únicamente
un preámbulo largo y éste parámetro será ignorado.
ESPAÑOL-50
HERRAMIENTAS DE SISTEMA
ESPAÑOL
Existen 4 submenús bajo el menú de herramientas de Sistema: Factory
Defaults, Reboot, Password y Log.
PARÁMETROS DE FÁBRICA
Esta página permite regresar a los parámetros de fábrica del PA.
ESPAÑOL-51
- Valor predeterminado de Nombre de Usuario: admin.
- Valor predeterminado de Contraseña: admin.
- Valor predeterminado de la dirección IP: 192.168.1.1
- Valor predeterminado de la máscara de subred:
255.255.255.0
ESPAÑOL
Todos los parámetros que haya guardado previamente se borrarán
cuando se regrese el sistema a los parámetros de fábrica.
REINICIAR
Esta función reiniciará el PA.
ESPAÑOL-52
Algunos parámetros del PA tomarán efecto únicamente después de
iniciar el punto de acceso, se incluye:
ESPAÑOL
- Función de servidor DHCP
- Asignación de dirección estática del servidor DHCP
- Actualización del firmware (el sistema se reiniciará
automáticamente)
Reinicio de los parámetros de fábrica (el sistema se reiniciará
automáticamente).
CONTRASEÑA
Esta página permite cambiar el nombre de usuario y contraseña
predeterminados. Todos los usuarios que intenten acceder a la utilidad
del PA o la configuración rápida se les requerirá su nombre de usuario y
una contraseña.
ESPAÑOL-53
El nombre de usuario y la contraseña no deben exceder de 14
caracteres de longitud y no deben incluir espacios. Introduzca la
contraseña dos veces para confirmarla.
ESPAÑOL
LOG
Esta página permite ver información del PA.
ESPAÑOL-54
APÉNDICE A: PREGUNTAS FRECUENTES
1.- Las luces indicadores no encienden en el punto de acceso.
Normalmente tarda unos cuantos segundos para que el indicador de
POWER se encienda. Espere un minuto y revise el estado del
indicador.
ESPAÑOL
Si el punto de acceso no enciende:
1.- Asegúrese de que el cable de energía esté conectado al
punto de acceso.
2.- Asegúrese de que el adaptador de corriente esté conectado
a un tomacorriente. Si utiliza una barra de contactos,
asegúrese de que esté encendida.
3.- Asegúrese de que está utilizando el adaptador de corriente
suministrado con el punto de acceso.
ESPAÑOL-55
3.- No puedo acceder al punto de acceso con una computadora
con función inalámbrica.
Podría ser un problema de configuración. Revise estos puntos:
ESPAÑOL
tengan efecto. Reinicie la computadora.
2.- La computadora con el adaptador inalámbrico podrían no
tener la configuración TCP / IP correcta para comunicarse con
la red. Reinicie la computadora y revise que los parámetros
TCP / IP sean los adecuados para esa red. La configuración
normal para Windows es “Obtain an IP address automatically”.
3.- Los valores predeterminados del punto de acceso podrían
no funcionar en su red. Revise la configuración de nueva
cuenta así como la configuración de otros dispositivos en su
red.
ESPAÑOL-56
APÉNDICE B: CONFIGURACIÓN DE PCs
En esta sección se mostrará la forma de instalar y configurar los valores
TCP / IP correctamente en Windows 95/98. Primeramente, asegúrese
de que el adaptador Ethernet esté funcionando, refiérase al manual de
instrucciones del adaptador en caso de ser necesario.
ESPAÑOL
1.- Instalación del componente TCP/IP
1) En la barra de tareas de Windows, presione el botón de Inicio,
seleccione Configuración y presione sobre el Panel de Control.
2) Presione dos veces sobre el ícono de Red, seleccione la opción de
Configuración en la ventana de Red.
3) Presione el botón de Agregar, seleccione Protocolo y presione
nuevamente Add.
ESPAÑOL-57
4) En el menú de Selección de Protocolo de Red, seleccione
Fabricantes, y posteriormente seleccione Microsoft. En el menú de
Protocolos de Red, seleccione TCP / IP. Presione OK. El protocolo TCP
/ IP tomará efecto una vez que reinicie.
ESPAÑOL
2.- Configuración de los valores TCP / IP en la computadora
1) En la barra de tareas de Windows, presione el botón de Inicio,
seleccione Configuración y presione sobre el Panel de Control.
ESPAÑOL-58
2) Presione dos veces sobre el ícono de Red, seleccione la opción TCP
/ IP en la ventana de Red. La siguiente figura podría aparecer:
ESPAÑOL
3.- Presione sobre Propiedades. La ventana de Propiedades TCP / IP
aparecerá.
ESPAÑOL-59
4.- Ahora tendrá dos formas de configurar el protocolo TCP / IP:
ESPAÑOL
ESPAÑOL-60
b) No introduzca ningún dato en el campo Nueva
puerta de enlace.
ESPAÑOL
ESPAÑOL-61
c) Seleccione Desactivar DNS en la barra de
Configuración DNS, como se muestra en la figura:
ESPAÑOL
ESPAÑOL-62
- Asignación de dirección IP de forma manual
a) Seleccione Especificar una dirección IP en la
barra de Dirección IP, como se muestra en la figura.
Si la dirección IP del punto de acceso es 192.168.1.1,
teclee la dirección IP como sigue: 192.168.1.x (donde
x es un valor entre 2 y 254), y la máscara de subred
ESPAÑOL
es 255.255.255.0.
ESPAÑOL-63
b) Introduzca la dirección IP del punto de acceso (el
valor predeterminado es 192.168.1.1) dentro del
campo Nueva Puerta de Enlace en la barra de Puerta
de enlace, presione sobre el botón Agregar como se
muestra en la figura:
ESPAÑOL
ESPAÑOL-64
c) En la barra de Configuración DNS, seleccione
Enable DNS y teclee el nombre de la computadora
en el campo Host y un dominio (como szonline.com)
dentro del campo Domain. En el campo DNS Server
Search Order puede introducir las direcciones IP y del
servidor DNS, las cuales deben ser proporcionadas
ESPAÑOL
por su proveedor de Internet, luego presione el botón
de Agregar.
ESPAÑOL-65
APÉNDICE C: ESPECIFICACIONES
Banda de frecuencia: 2.4~2.4835GHz
Modulación: BPSK, QPSK, CCK, OFDM (BPSK/
QPSK/16-QAM/ 64-QAM)
Cobertura: hasta 100m
Potencia de RF: 17dBm
ESPAÑOL
Antena: 3dBi
Estándares: IEEE 802.3, 802.3u, 802.11b y
802.11g
Protocolos: TCP/IP, DHCP
Puertos: Un puerto 10/100M Auto
negociación, Puerto LAN RJ45 que
soporta Auto MDI / MDIX
Tipo de cable: 10 Base-T: Categoría, 3, 4, 5
UTP (máximo
100m)
EIA/TIA-568
100ohms STP
(máximo 100m)
100 Base-Tx: Categoría 5, 5e
(máximo 100m)
EIA/TIA-568
100ohms STP
(máximo 100m)
Velocidad: 54/48/36/24/18/12/9/6Mbps o
11/5.5/3/2/1Mbps
Entrada: 9V~ 0,8A
ESPAÑOL-66
Temperatura de operación: 0°C a 40°C
Temperatura de almacenaje: -40 a 70 °C
Humedad de operación: 10% -95% de HR, no condensada
Dimensiones: 158×110×32mm (sin antena)
ESPAÑOL
Convertidor de Tensión
Entrada: 120V ~ 60Hz 0,15A
Salida: 9V~ 800mA
ESPAÑOL-67
Producto: Repetidor y Punto de Acceso inalámbrico
Modelo: COM-817
Marca: Steren
PÓLIZA DE GARANTÍA
Esta póliza garantiza el producto por el término de un año en todas sus partes y mano
de obra, contra cualquier defecto de fabricación y funcionamiento, a partir de la fecha de
entrega.
CONDICIONES
1.- Para hacer efectiva la garantía, presente ésta póliza y el producto, en donde fue
adquirido o en Electrónica Steren S.A. de C.V.
2.- Electrónica Steren S.A de C.V. se compromete a reparar el producto en caso de estar
defectuoso sin ningún cargo al consumidor. Los gastos de transportación serán cubiertos
por el proveedor.
3.- El tiempo de reparación en ningún caso será mayor a 30 días, contados a partir de la
recepción del producto en cualquiera de los sitios donde pueda hacerse efectiva la
garantía.
4.- El lugar donde puede adquirir partes, componentes, consumibles y accesorios, así como
hacer válida esta garantía es en cualquiera de las direcciones mencionadas
posteriormente.
El consumidor podrá solicitar que se haga efectiva la garantía ante la propia casa
comercial donde adquirió el producto. Si la presente garantía se extraviara, el consumidor
puede recurrir a su
proveedor para que le expida otra póliza de garantía, previa presentación de la nota de
compra o factura respectiva.
DATOS DEL DISTRIBUIDOR En caso de que su producto
presente alguna falla, acuda
Nombre del Distirbuidor al centro de distribución más
cercano a su domicilio y en caso
Domicilio de tener alguna duda o pregunta
por favor llame a nuestro Centro
Producto de Atención a Clientes, en
donde con gusto le atenderemos
Marca en todo lo relacionado con su
producto Steren.
Modelo
Centro de Atención a Clientes
Número de serie 01 800 500 9000
Fecha de entrega
