SS ENERGY SOLUTIONS

SYNCHRONIZE, CONTROL AND

MONITORING SYSTEM
BTK PROJECT 2021-22
 Ref: SS/AGJV/12-1 Date: 08-12-2021

Client: AGJV (Pvt) Ltd

Attn: Manager Project

Dear Sir,

We are pleased to offer you synchronize, control and monitoring system for MAN 9L21/31 power plant. SSES have
hand on expertise and thorough understanding of MAN dedicated control system SaCos One. By utilizing this
expertise, we are capable to design system as customer desire which will ease plant operation. We recently installed
system for same Gen sets in time ceramics Faisalabad. Below is our commercial proposal with technical
specifications.

Generator Control system

GCP equipped with 10” HMI, programmable Logic Controls and Microprocessor based Generator power control
system covering simple to most advanced features in free standing design self-supporting. IP-4X enclosed for indoor
service with hinged front doors for access to control compartment, all to be painted RAL 7035 light gray color.
The cubical shall be floor standing with approximately 2050H x 600W x 600D mm dimensions.

Quantit
S. No y Rate Total
Description
PKR PKR
Supply, Installation and commissioning of
Generator Control, synchronization and Load
sharing panel for MAN 6.6 KV 1880 kw HFO Gen
set equipped with following.
 1-DSE 8610 generator controller
 1-FATEK FBS PLC CPU
1 2,000,00
 1-FATEK FBS PLC IOs 6 12,000,000
0
 1-FATEK 10” HMI
 1-Batteries & battery charger
 Fiber optic cables and converters
 Control cable termination of each Gen set
*Differential Relay is excluded*

GST PKR 17 % 20,40,000/-

Grand Total PKR 14,040,000/
-
Customer Scope:
 Extended Floor foundation or civil work for supplied equipment’s
 230V AC supply shall be provided by customer.
 Work permit shall be arranged by customer.
 Cables & Cable trays/conduit installation as per requirement.

Phone : +92-333-5734388, +92-313-2320846NTN: 4070976-7

Email : info@sses.com.pk
Address: Suite# 15, Mezzanine Floor, Society Apartments, PECHS Block-2, Kashmir Road, Karachi-Pakistan
  Unloading of equipment’s.

Main Features:
 Load Management, Running hours management
 Main Generator Screen, One lined colored graphic display.
 Engine control panel interface via Modbus for Mechanical parameters.
 Display of electrical and mechanical parameters (as given by SaCos).

Electrical Protections:
 Under/Over Voltage
 Over/Under Frequency
 Reverse Power
 Reverse VAR
 Negative Phase sequence control
 Over load protection
 Phase over current protection
 Short circuit protection

Electric Metering on HMI:

 3 Phase ac voltage both Bus and generator
 3 Phase AC current
 Frequency and Power Factor
 REAL (KW), Reactive(KVAR) & Apparent Powers

Mechanical Data, Alarm & Shutdown: on HMI VIA MODBUS:

 As per Engine control system SaCos One.
 Pre lube inter lock.
 Turning gear inter lock.

Other Controls:
 Automatic & Manual Engine start start/stop signal to Gen set & CB via controller
 Automatic synchronizing via active interfaces to engine actuator and AVR.
 Automatic load sharing & VAR sharing.
 Soft loading and unloading against other gen sets.
 Emergency Stop Control.
 Alarm Buzzer & Alarm silencer.
 NGR Control.
Miscellaneous:
 Fan 6”
 MCB`s
 Fiber optic cables and converters

Phone : +92-333-5734388, +92-313-2320846NTN: 4070976-7

Email : info@sses.com.pk
Address: Suite# 15, Mezzanine Floor, Society Apartments, PECHS Block-2, Kashmir Road, Karachi-Pakistan
  Indoor light

Major components list:

Components Brand

Gen Set Controller Deep Sea

PLC FATAK
HMI FATAK
MCB Schneider
Fiber optic cable
Fiber optic converters

Phone : +92-333-5734388, +92-313-2320846NTN: 4070976-7

Email : info@sses.com.pk
Address: Suite# 15, Mezzanine Floor, Society Apartments, PECHS Block-2, Kashmir Road, Karachi-Pakistan
 REMOTE MONITORING & CONTROL SYSTEM

Supervisory control and data acquisition (SCADA) equipped with 3 LED screens 42”, 25” & 25“respectively &
programmable logic controller. This System will give remote access to monitor Gen sets and auxiliaries of power
plant. Software designed for this system shall be compatible against SaCos One, EPC 60B, EPC 50 and other control
systems if any.

S NO. DESCRIPTION QUANTIT UNIT PRICE TOTAL PRICE

Y PKR PKR
Supply, Installation and commissioning of Remote
monitoring system of Gen sets, FCM, Purifier, Boiler,
radiators, compressors and Fuel storage
 1- S7 1500 PLC CPU
1  1- S7 1500 PLC IO`s 1 7,500,000 7,500,000
 1- 42” desktop LED screen
 2- 25” desktop LED screen
 1- Control panel
 Accessories
 Fiber optic cable and converter
 SOFTWARE
 Only Cables termination
GST PKR 17 % 1,275,000/-
Grand Total PKR 8,775,000/-
Customer Scope:
 Desk for Led Screens.
 Foundation or extended floor if required.
 Cables & cable tray/conduit installation as per requirement.
 Unloading of equipment’s
 Work permit
 Supply of 230 VAC

Main Features:
 Complete Power plant process monitoring on one screen, Split overview on 2 screens
 Logging of Alarms, tripping, starting, stopping and running durations of all equipment’s.
 Gen sets and VCB controlling
 Balance of Plant i.e. booster, purifiers, air compressors etc only have monitoring.
 Fuel and lube oil storage monitoring
 All necessary electrical and mechanical metering.

Phone : +92-333-5734388, +92-313-2320846NTN: 4070976-7

Email : info@sses.com.pk
Address: Suite# 15, Mezzanine Floor, Society Apartments, PECHS Block-2, Kashmir Road, Karachi-Pakistan
 List of Components:
Components Brand

PLC Siemens
LED Screens Siemens
MCB Schneider
Fiber optic cable
Fiber optic converter
Accessories

Phone : +92-333-5734388, +92-313-2320846NTN: 4070976-7

Email : info@sses.com.pk
Address: Suite# 15, Mezzanine Floor, Society Apartments, PECHS Block-2, Kashmir Road, Karachi-Pakistan
 Neutral Grounding System
NGS equipped with 2 neutral grounding resistors, one in operation while other one standby. The engagement with
be both i.e motorized and manual control.

S NO DESCRIPTION QUANTITY UNIT PRICE TOTAL PRICE

PKR PKR
Supply, installation and commissioning of (8 in 1 type) NGR
resistance panel for 2.35 MVA, 6.6 kv generators.
 2- 763 ohm Resistor,5A for 10 sec.
1  Link switches rated voltage 15 kv. 2 1,050,000 2,100,000
 NGR protection relay EPM-4C
 Push buttons
 Cubical panel 1000 x 1000 x 2200 mm
 Cable Termination supervision
Supply of HT Contactors
 400 Amp
2  15 kv isolator 6 225,000 1,350,000
 Single pole
 Remote on/ off
Total PKR 3,450,000/-
GST 17 % 586,500/-

Grand total PKR 4,036,500/-

Customer Scope:
 Extended floor or foundation or any civil work.
 Unloading of equipment’s.
 Installation of cable tray conduit etc, cable termination
 Work permit

Main Features:
 763 ohm resistance 5A 10 sec with holding isolation voltage 15 kv.
 Trip function
 Specifications designed for short time high current.
 Self air cooled.
 Copper Bus bar as per load.
 Complete with temperature and humidity sensor.
 Condensation Heater, Indication light, Control push buttons

Phone : +92-333-5734388, +92-313-2320846NTN: 4070976-7

Email : info@sses.com.pk
Address: Suite# 15, Mezzanine Floor, Society Apartments, PECHS Block-2, Kashmir Road, Karachi-Pakistan
 11KV Bus Transformer Synchronizing System
As per approved single line drawing of electrical system, outgoing transformers also required synchronization on
11KV bus.

S NO DESCRIPTION QUANTITY UNIT PRICE TOTAL PRICE

PKR PKR
Supply, installation and commissioning of CRE Synchronizing
Controllers
 Synchronization & Dead Bus Management
1  Adjustable Pulse or latched contact for breaker closing 3 350,000 1,050,000
 Adjustable Pulse or latched contact for breaker closing
 Cubical panel
 Cable Termination supervision
Total PKR 1,050,000/-
GST 17 % 178,500/-

Grand total PKR 1,228,500/-

Customer Scope:
 Extended floor or foundation or any civil work.
 Unloading of equipment’s.
 Installation of cable tray conduit etc, cable termination
 Work permit

Phone : +92-333-5734388, +92-313-2320846NTN: 4070976-7

Email : info@sses.com.pk
Address: Suite# 15, Mezzanine Floor, Society Apartments, PECHS Block-2, Kashmir Road, Karachi-Pakistan
 S NO DESCRIPTION PRICE PKR
1 Generators Control System 12,000,000/-

2 Remote Monitoring & Control System 7,500,000/-

3 Neutral Grounding System 3,450,000/-

4 11KV Bus Transformer Synchronizing System 1,050,000/-

Total Price PKR 24,000,000/-

GST PKR 17 % 4,080,000/-

Grand Total PKR 28,080,000/-

Payment Terms & Condition

 Offer valid for 15 days.

 70% Advance, 20% before delivery and 10% after commissioning.
 All panels delivered within 6~8 weeks after PO & advance payments.
 1 year warranty for complete system.
 Offer is subject to FORCE MAJEURE clause.
 Above prices are exclusive of transportation charges, which will be charged at actual.
 Change in USD exchange rate can affect Cost of Items.

Thanks for your consideration and looking for positive response

Thanks & Regards

Khalid Mazhar
Technical Manager
Khalid.mazhar@sses.com.pk
