Assessment of Splash and Spray Potential

of Experimental Quiet Pavement Surfaces

Morgan State University

The Pennsylvania State University
University of Maryland
University of Virginia
Virginia Polytechnic Institute & State University
West Virginia University

The Pennsylvania State University

The Thomas D. Larson Pennsylvania Transportation Institute
Transportation Research Building  University Park, PA 16802-4710
Phone: 814-865-1891  Fax: 814-863-3707
www.mautc.psu.edu
1. Report No. 2. Government Accession No. 3. Recipient’s Catalog No.

VT 2012-01

4. Title and Subtitle 5. Report Date 10/22/15

Field Assessment of Splash & Spray
6. Performing Organization Code

7. Author(s) Lijie Tang and Gerardo Flintsch 8. Performing Organization Report No.

9. Performing Organization Name and Address 10. Work Unit No. (TRAIS)
Virginia Tech Transportation Institute
3500 Transportation Research Plaza
Blacksburg, VA 11. Contract or Grant No.
24061 DTRT12-G-UTC03

12. Sponsoring Agency Name and Address 13. Type of Report and Period Covered
US Department of Transportation
Research & Innovative Technology Admin Final
UTC Program, RDT-30
1200 New Jersey Ave., SE 14. Sponsoring Agency Code
Washington, DC 20590

15. Supplementary Notes

16. Abstract
The effects of vehicle splash and spray are well known to motorists who have undertaken journeys in wet
weather conditions. Research suggests that splash and spray contributes to a small, but measureable,
proportion of road traffic accidents and provides considerable nuisance to motorists. Furthermore, splash
and spray from highway pavements can carry a number of pollutants and contaminants that can be
poisonous to plant life and cause the accelerated corrosion of street furniture.
Vehicle and highway engineers are working on several types of solutions to reduce splash and spray,
examples of which include splash and spray reducing devices and/or a permeable surface layer on
pavement. A robust splash and spray measurement device could be used to assess the effectiveness of those
solutions. Furthermore, fluid mechanics computational models are used to simulate the process by which
splash and spray is generated. To calibrate and validate these models, it is necessary to measure the
physical properties of the droplet cloud generated, including the droplet’s size and space density.
This project proposed a methodology to measure splash and spray on in-service pavements and developed a
proof-of-concept system to quantify splash and spray on in-service roads using this methodology. This
effort included developing the system, which involved integrating a light source (beam laser) and a camera,
preparing the image processing software, and subsequent laboratory and road tests to validate the proof-of-
concept.
17. Key Words 18. Distribution Statement

Pavement Surface properties, splash and spray, safety No restrictions. This document is
available from the National Technical
Information Service, Springfield, VA
22161

19. Security Classification 20. Security Classification (of 21. No. of 22. Price
(of this report) this page) Pages

Unclassified Unclassified 12

i
 Field Assessment of Splash and Spray
Final Report

TABLE OF CONTENTS

Acknowledgments ........................................................................................................................... ii
Disclaimer ....................................................................................................................................... ii
Introduction ..................................................................................................................................... 1
Background ..................................................................................................................................... 1
Influential factors......................................................................................................................... 1
Measurement Methods ................................................................................................................ 2
Modeling...................................................................................................................................... 3
Methodology and approach ............................................................................................................. 3
Equipment Development ............................................................................................................. 3
Preliminary Laboratory Testing................................................................................................... 4
Road Testing................................................................................................................................ 5
Results ............................................................................................................................................. 9
Conclusions and recommendations ............................................................................................... 10
References ..................................................................................................................................... 11

ACKNOWLEDGMENTS
The authors would like to thank the Virginia Department of Transportation (VDOT) for
their support in the development of the course. The project was partially funded by the
U.S. Department of Transportation Mid-Atlantic University Transportation Center
(MAUTC).

DISCLAIMER
The contents of this report reflect the views of the authors, who are responsible for the
facts and the accuracy of the information presented herein. This document is
disseminated under the sponsorship of the U.S. Department of Transportation’s
University Transportation Centers Program, in the interest of information exchange. The
U.S. Government assumes no liability for the contents or use thereof.

ii
INTRODUCTION
The effects of vehicle splash and spray are well known to motorists who have undertaken
journeys in wet weather conditions. Research suggests that splash and spray contributes to a
small, but measureable, proportion of road traffic accidents[1] and provides considerable
nuisance to motorists [2]. Furthermore, splash and spray from highway pavements can carry a
number of pollutants and contaminants. When deposited, these contaminants can be poisonous to
plant life and cause the accelerated corrosion of street furniture.
To reduce splash and spray, vehicle and highway engineers are working on several types of
solutions, examples of which include splash and spray reducing devices and a permeable surface
layer on pavement. A robust splash and spray measurement device could be used to assess the
effectiveness of those solutions. Furthermore, fluid mechanics computational models are used to
simulate the generating process of splash spray. To calibrate and validate these models, it is
necessary to measure the physical properties of the droplet cloud generated, including the
droplet’s size and space density.
The objective of the project was to propose a methodology to measure splash and spray on in-
service pavements and develop a proof-of-concept system to quantify splash and spray on in-
service roads using this methodology. The effort included the system’s development, which
involved integrated a light source (beam laser) and a camera, and preparing the image processing
software, along with laboratory and road tests to validate the proof-of-concept.

BACKGROUND
The generation of splash and spray is an extremely complex process and is dependent upon a
number of independent variables. The terms “splash” and “spray” relate to two separate processes.
The definitions of splash and spray are usually given as a function of the droplet sizes produced
or as the process by which they are created, as presented by Pilkington in 1990 [3]:
Splash is defined as, “…the mechanical action of a vehicle’s tire forcing water out of its
path. Splash is generally defined as water drops greater than 1.0 mm (0.04 in.) in
diameter, which follow a ballistic path away from the tire.”
Spray is defined as being formed, “…when water droplets, generally less than 0.5 mm
(0.02 in.) in diameter and suspended in the air, are formed after water has impacted a
smooth surface and been atomized.”
Although splash and spray are separate processes, they are often referred to together because it is
difficult to monitor and measure them individually. Generally, splash and spray are formed on
wet roads by four well-established primary mechanisms: bow splash waves, side splash waves,
tread pickup, and capillary adhesion [4]. In 2005, McCallen et al. [5] designed a tool to illustrate
the spray under controlled conditions. High-speed image capture was used to examine and
analyze the case of the tread pickup source and the interaction between the water and the interface
of two counter rotating tires.

Influential factors
Though no consensus of opinion has been achieved about the relationship between water film
thickness and splash/spray, it is generally concluded that the splash and spray increases with the
thickness of the water film. In addition to the water film thickness, the other main factors that
affect splash and spray include vehicle speed, tire geometry, vehicle aerodynamics, vehicle spray
suppression devices, and wind vector.

1
Water film thickness is usually considered to be a major contributory factor to the generation of
splash and spray. In 1978, Weir et al. [4] studied how the spray was affected by the thickness of
water film, and found that the threshold was 3 mm, a thickness which determines whether tire
tread grooves are filled and the spray reached the maximum strength. In 1985, Koppa [6] et al.
used laser transmitters to measure the spray generated by a truck under three water depth
conditions (0.5 mm, 1.3 mm, and 2.5 mm). It was found that the spray production increased with
a linear relationship to the thickness of water film.
A great deal of research has been carried out to assess the effect of vehicles on the generation of
splash and spray. Among all the vehicular factors, speed is the largest factor of influence. As
early as 1966, Maycock [7] observed that spray density was very small at speeds below 50 km/h
and increased rapidly with speed when speed was above 50 km/h. Similar results have been
reported in the following studies conducted by Chatfield et al. [8] and Resendez et al.[9]. In 1997,
Huebner et al. [10] developed a series of models relating water film thickness to hydroplaning
speed.
Tire-road interaction is another important factor for splash and spray generation, and is affected
by pavement texture and tire properties. In the work presented in 1966 by Maycock [7], a worn
tire produced much more splash than a zig-zag rib and heavy duty block tread patterns. Believing
that tire geometry was related to vehicle hydroplaning speed, Horne et al. [11] conducted
experiments to ascertain a relationship between tire inflation pressure and footprint aspect ratio to
hydroplaning speed for a given water depth. Yager [12] did a similar experiment in Texas and
developed another relationship. Three distinct zones of contact were studied by simulating tire
rolls or slides over a wet road surface in Gough and Moore’s works [13, 14].

Measurement Methods
Many techniques have been developed to quantify splash and spray. The collection method was
developed earliest by fitting devices to the test vehicle itself or to a following vehicle. In 1966,
the device Maycock [7] used involved disposable collectors consisting of several layers of
absorbent paper. The difference in mass before and after testing was used to measure the
generated spray. In 1990, Pilkington [3] used an absorbent screen to collect the droplets. Instead
of using absorbent devices, Ritter attached a collection device to the side of the vehicle close to
the wheels, and part of the spray entered the device, leaving behind a pool of water for
quantification.
The spray can also be quantified by observing the change in the contrast of images during
experiments. The working principle of this method is that the contrast of images will be reduced
if it is viewed through a spray cloud due to the light refraction occurring within the spray particles.
This method has been used by many scholars [16, 16-18]. Another measurement method with the
same principle used by Knight et al. was used [18] in 2005. In this method, a black screen was
fixed to the rear of the vehicle, and the video camera mounted in the following vehicle filmed the
screen to capture the changes in contrast.
In addition to reducing the image contrast, the scattering light induced by a spray cloud can also
reduce the strength of a light passing through the spray. This process is utilized in another
measurement method, which is known as the transmittance analysis method. Ritter [16] employed
this method in 1974 by using a visible-light source from an automobile headlamp. This technique
was developed further by Koppa et al [6] in 1985 using low power laser light sources instead.
Some years later, Manser [15] concluded that the works of Ritter and Koppa provided very
similar results.
Observations, including photographs, video, or direct observation, can also evaluate some
properties of the spray cloud. Although this method has a poor repeatability, it is convenient and

2
can be used for confirming the results gained by other means. In some previous research [3],
observers were used to rate the visibility loss caused by a spray cloud, and the observed results
were compared with those obtained by other methods.
In addition to the methods described above, many other techniques have been developed to
measure the amount of splash and spray. The Doppler technique has been used to determine the
number flux, size distribution, and the velocity of water droplets [19]. Raindrop size, fall velocity,
and intensity have been measured with an optical spectro pluviometer (OSP) [20]. In addition,
Pérez-Jiménez, F., et al., (2011) developed a prototype laser-based system to measure the amount
of splash produced by a tire when it passes over wet pavement [21].

Modeling
Due to the complexity of splash and spray, it cannot be calculated accurately with of all the
fundamental inputs by any of the current models. Most of the existing models are derived from
aerodynamics using Computational Fluid Dynamics (CFD). Commercial software is used to
calculate the air flow around a vehicle and the distribution of water droplets. McCallen [5] used
this method to calculate the spray cloud generated by heavy vehicles. Paschkewitz [22] used the
same method to study the spray dispersion about a simplified trailer wheel assembly. In a
different approach, Resendez et al.’s work [9] presented a splash and spray model as a function of
water film thickness and air/rubber ratio in the vehicle’s tires.

METHODOLOGY AND APPROACH

Generation of splash and spray can be simplified as a process of droplets shooting from the tire to
the air. However, given the nature of the fluid/cloud, it is very hard to distinguish one droplet
from another, let alone to measure a droplet’s speed or size.
The method proposed in this report measures the droplets using a special laser, which operates at
a frequency different from environmental lights, to illuminate the water droplets. Just like the
small particles in the air, the human eye won’t see those particles until one beam of strong
sunlight cuts into the shadow. The laser illuminates the droplets, a camera is used to capture
them, and an image-processing algorithm is employed to find the requested result. The work
included for the proposed method included developing the laser-camera system, mounting the
system in a vehicle, and preparing the image-processing program.

Equipment Development
The prototype system deployed for the experiment is shown in Figure 1. The system consists of
three major parts: the camera; the laser generator; and the frame, which includes two waterproof
box containers for the camera and laser generator. The laser generator produces a laser curtain
that lights up droplets as they cross it, and the camera takes pictures of those droplets.
The working environment for this system is shown in Figure 1 (b). As the camera is intended to
catch the droplets lighted by the laser, the experiment must be performed without other sources of
illumination. This situation is easy to create in the lab, but rather difficult to produce on the road.
To reduce the light disturbance, the field experiment will be conducted at night. A filter that
filters out other light will also be installed on the camera. Before getting on the road, laboratory
tests will be conducted to preliminarily validate the idea.

3
 (a) The system mounted on a Dump Truck

(b) The system mounted on a mid-size SUV

Figure 1: Systems used in the experiment.

Preliminary Laboratory Testing

Laboratory tests were conducted and the results analyzed. Images were collected in the laboratory
and were assumed to be in ‘perfect’ condition, as there was neither vibration nor other light
sources in the laboratory. The collected images were processed with MATLAB using the
procedures visually summarized in Figure 2.
Figure 2 shows the droplets count procedure for the laboratory experiment image, which has a
pure dark background (Figure 2 [a]). On the image, each droplet can be seen as a point spread
function from the center point. The droplets were found by locating all the local peaks on the
image. Figure 2 (c) prints the droplets count over the raw image (background), showing a good fit.
Using this procedure, the splash and spray quantity can be estimated by counting the number of
droplets on each picture in the perfect condition.

4
 (a) Raw Image (b) Processed Image

(c) Droplets Count

Figure 2: Image processing procedure.

Road Testing
After being verified in the laboratory, the prototype system was tested on the road, running at
three different speeds: 30 mph, 45 mph, and 60 mph. For the field experiments, it was inevitable
that the results might be affected by some noise, with vehicle vibration being the most likely
primary source. To address this problem, the laser and camera were installed on the same frame,
and the stiffness of the frame was increased. The environmental light was another potential
expected source of noise. This issue was addressed by conducting the experiment in the evening
to reduce the effect of environmental lights. The beam laser and corresponding filter were also
used in the field experiments. The whole test process was recorded, and one frame of the video is
presented in Figure 3 as an example of the results.

5
 Figure 3: One image taken during the road test.
As Figure 3 shows, when the experiment was moved from the laboratory to the road, the image
was noisier. The vibration of the vehicle caused blurring, the light source in the direction of the
camera formed large light spots, and the water deposited on the camera cover reduced the image
quality. Although the noise could not be totally removed, a filter was used to reduce the strength
of other light sources, and a wiper was used to clean the water from the camera.
Figure 4 shows an example of an image that has been filtered and de-blurred. The filtered image
(Figure 4 [a]) looks very similar to the images obtained in lab tests. The light intensity of each
pixel in the raw image is shown in colors, as illustrated in Figure 4 (b), which shows the
distribution of splash and spray. However, further analysis was necessary to get more accurate
results. A background filter was used to eliminate the background noise by deleting a single pixel
with extraordinary brightness. The resulting the image is shown in Figure 4 (c). In this image, the
number of droplets can be counted by grouping all the pixels that are close to each other with
gradational light intensity into clusters, as shown in Figure 4 (d).
The image was then scanned strip by strip for the change of light intensity, and the final
distribution of droplets is shown in Figure 4 (e). This image scan curve represents the distribution
of light intensity in the image, which means the distribution of splash and spray in the plane. This
curve could serve as the basis for quantifying splash and spray, but more data analysis is needed
to interpret the curve and combine the distribution at different planes.
In addition to the blurring, other images were affected by light sources. It was difficult to analyze
such images because the intensity of the light source was so strong that the data points could not
be recognized. As a result, further procedures were required for processing these images, as
shown in Figure 5.
When there is a light source in the frame, the raw image will be affected with a lighted cluster at
the position of the light source, as shown in Figure 5 (a). In this case, if the image is not treated to
eliminate the effect of the light source, the light distribution will concentrate at the position of the
light source, resulting in the real valuable data points being overwhelmed, as shown in Figure 5
(b).

6
 (a) Raw Image (b) Raw Image shown in color

(c) Filtered image (d) Droplet count

(e) Image scan curve

Figure 4: Processing of blurred images.

7
 (a) Raw Image (b) Raw Image shown in color

100

200

300

400

500

600

700

100 200 300 400 500 600 700 800 900 100

(c) Image scan curve

(d) Processed in MATLAB

100

200

300

400

500

600

700

100 200 300 400 500 600 700 800 900 1000

(e) Droplets Count after Filtering

Figure 5: Processing of the images with surrounding light sources.

8
The problems associated with the light source are also evident in the image scan curve shown in
Figure 5 (c). The light intensity around the light source is increased notably, so the scanned curve
is dominated by the light source and the details of the actual distribution cannot be detected. In
this case, two filters are used: the first eliminates the background noises as shown in Figure 5 (d),
and the second reduces the effect of the light source, as shown in Figure 5 (e). In this way, the
images with a light source can be processed and the droplets on the image can be recognized and
counted.

RESULTS
A total of 874 images were collected in the three road tests. These included 443 images for the 30
mph test, 247 for the 45 mph test, and 184 for the 60 mph test. The number of the droplets on
each image was counted and summarized as shown in Figure 6 for the runs at 30, 45, and 60 mph.
Figure 6 shows that the magnitude of the splash and spray, induced by the moving vehicle, can be
compared using the number of the droplets captured in the images. The splash and spray is
dynamic and complicated, affected by many uncontrollable factors. As a result, the number of
droplets fluctuates significantly, as shown in all three sub-figures of Figure 6, and the splash and
spray quantity changes all the time.
Since the vehicles in the road tests were driven manually, it was impossible to keep the speed
exactly the same throughout the whole process. This was especially true at the beginning and the
end of the tests. Acceleration and deceleration might break the balance between the tires and the
water film and induce more splash and spray. Figure 6 shows that this theory can be validated, as
the largest number of droplets, and therefore the largest splash and spray, can always be found at
the beginning and end of the test. If we remove the beginning and the end of each test, the
measurements are more uniform. Figure 6 also clearly shows that, as expected, the number of
droplets increases as the speed increases. Finally, Figure 6 shows that the number of droplets is
zero at many points during the road tests. This is because some raw images were too noised for
droplets to be identified.

25

20

15

10

0
0 50 100 150 200 250 300 350 400 450

(a) 30 mph

9
 30

25

20

15

10

0
0 50 100 150 200 250
.
(b) 45 mph

30

25

20

15

10

0
0 20 40 60 80 100 120 140 160 180 200

(c) 60 mph
Figure 6: Number of droplets in the three road tests.

CONCLUSIONS AND RECOMMENDATIONS

This report summarized an effort to develop a system to quantify splash and spray on in-service
roads. The effort included the development of a proof-of-concept system featuring the integration
of a light source (beam laser) and a camera, and development of the image processing software.
Laboratory and road tests were used to validate the proof-of-concept.
The testing results suggest that the system can be used to detect and count droplets both in the lab
and in the field. However, more work is needed to further filter the images collected while
measuring under regular road operation conditions to obtain repeatable and reliable results. It is
recommended that the system be improved by acquiring a higher-speed camera and better filters,
as well as by developing better image processing algorithms.

10
REFERENCES
1. National Highway Traffic Safety Administration. (1998). Report to Congress: Update on the
Status of Splash and Spray Suppression Technology for Large Trucks. Washington, DC: U.S.
Department of Transportation.
2. Baughan, C., B. Hedges, and J. Field. (1983). A national survey of lorry nuisance. Transport
and Road Research Laboratory Report (SR 774). Wokingham: Transport and Road Research
Laboratory.
3. Pilkington, G.B. (1990). Splash and Spray - Surface Characteristics of Roadways:
International Research and Technologies. STM STP 1031, American Society for Testing and
Materials, 528-541.
4. Weir, D.H., J.F. Strange, and R.K. Heffley. (1978). Reduction of adverse aerodynamic effects
of large trucks (Technical Report FHWA-RD-79-84). Washington, DC: Federal Highway
Administration.
5. McCallen, R.C. et al. (2005). DOE project on heavy vehicle aerodynamic drag FY 2005
(Report UCRL-TR-217193). Livermore, CA: Lawrence Livermore National Laboratory.
6. Koppa, R.J., et al. (1985). Heavy truck splash and spray testing; Phase II - Volume 1 -
Executive Summary. College Station, TX: Texas Transportation Institute.
7. Maycock, G. (1966). The problem of water thrown up by vehicles on wet roads. Wokingham:
Transport and Road Research Laboratory.
8. Chatfield, A., A. Reynolds, and D. Foot. (1979). Waterspray from heavy goods vehicles: an
assessment of some vehicle modifications (Report No. VSE 513). London: Department of
Transport.
9. Resendez, Y., et al. (2007). Characterizing the splash and spray potential of pavements. US
Department of Transportation, Federal Highway Administration, 11(6).
10. Huebner, R.S., et al. (1997). PAVDRN: Computer model for predicting water film thickness
and potential for hydroplaning on new and reconditioned pavements. Transportation
Research Record: Journal of the Transportation Research Board, 1599(1), 128-131.
11. Home, W.B., T.J. Yager, and D.L. Ivey. (1986). Recent studies to investigate effects of tire
footprint aspect ratio on dynamic hydroplaning speed. The Tire Pavement Interface: A
Symposium. West Conshohocken, PA: ASTM International.
12. Yager, T., et al. (2009). Water accumulations. Influence of roadway surface discontinuities
on safety: State of the art report. Transportation Research Circular, E-C134., 51-60.
13. Gough, V. (1974). A tyre engineer looks critically at current traction physics. In D.F. Hays
and A.L. Brown (Eds.), The Physics of Tire Traction (281-297). New York: Plenum Press.
14. Moore, D.F. (1975). The friction of pneumatic tyres. Amsterdam: Eslevier Scientific
Publishing Company.
15. Manser, M.P., R. Koppa, and P. Mousley. (2003) Evaluation of splash and spray suppression
devices on large trucks during wet weather (Technical Report). Department of Mechanical
Engineering, University of Minnesota.
16. Ritter, T.E. (1974). The Development of Techniques to Measure Vehicle Spray on Wet Roads.
SAE Technical Paper (No. 740526).
17. Baughan, C. and P. Hart. (1988). Water spray from road vehicles: Transmittance analysis
methods. Wokingham: Transport and Road Research Laboratory.

11
18. Knight, I., et al. (2006). Integrated safety guards and spray suppression. Final summary
report. Wokingham: Transport and Road Research Laboratory.
19. Kalantari, D. and C. Tropea. (2006, June). Considerations in Phase-Doppler Measurements
of Spray/Wall Interaction. 13th International Symposium for Applications of Laser
techniques to Fluid Mechanics, Lisbon, Spain.
20. Salles, C. and J. Poesen. (1999). Performance of an optical spectro pluviometer in measuring
basic rain erosivity characteristics. Journal of hydrology, 218(3), 142-156.
21. Pérez-Jiménez, F., et al. (2011). System for measuring splash on wet pavements.
Transportation Research Record: Journal of the Transportation Research Board, 2227(1),
171-179.
22. Paschkewitz, J.S. (2006). Simulation of spray dispersion in a simplified heavy vehicle wake.
Livermore, CA: Lawrence Livermore National Laboratory.

12
