DRAWING 1–550 371 91–E

1/2

55155843E 1/ 4
 DRILLING MODULE

551 558 43
Ref Part No. Description Standard designation Qty

1 550 481 42 CYLINDER FEED ASSEMBLY SEP. PART LIST 1

2 550 404 71 DRIFTER SEP. PART LIST 1
3 550 486 82 ROD CHANGER SEP. PART LIST 1
4 550 451 15 VALVE ASSEMBLY SEP. PART LIST 1
5 550 729 53 SENSOR MOUNTING SEP. PART LIST 1

7 550 451 01 CUTTINGS COLLECTOR SEP. PART LIST 1

9 265 572 92 PRESSURE ACCUMALATOR SEP. PART LIST 1
25 550 987 33 BUMPER 1
26 550 868 36 HOSE GUIDE 1
27 550 348 98 FRONT SUPPORT SEP. PART LIST 1

28 550 594 14 SUPPORTING BLOCK 1

29 550 594 15 SUPPORTING BLOCK 1
30 623 924 18 JAW LEAD PITO 12 JA 14 1
31 623 924 18 JAW LEAD PITO 12 JA 14 1
37 155 750 38 HOSE COVER D=50 L=2000 1

38 807 695 29 STRAP L=400 Black 20

47 330 952 68 HOSE SUPPORT CF180/LF600/LF1500 1
601 390 131 68 PLATE ”R” (30X35) 1
603 390 124 38 PLATE ”3” (30X35) 1
720 550 718 78 HOSE GUIDE 1

722 550 480 89 MOUNTING SEP. PART LIST 1

799 550 458 45 SCREW SET SEP. PART LIST 1
801 550 768 94 HOSING SEP. PART LIST 1
802 550 769 33 HOSING SEP. PART LIST 1
805 550 769 36 LUBRICATION DIAGRAM SEP. PART LIST 1

55155843E 2/ 4
 DIRECTION A

DRAWING 1–550 371 91–E

2/2

DIRECTION B–B

55155843E 3/ 4
 DRILLING MODULE

551 558 43
Ref Part No. Description Standard designation Qty

1 550 481 42 CYLINDER FEED ASSEMBLY SEP. PART LIST 1

2 550 404 71 DRIFTER SEP. PART LIST 1
3 550 486 82 ROD CHANGER SEP. PART LIST 1
4 550 451 15 VALVE ASSEMBLY SEP. PART LIST 1
5 550 729 53 SENSOR MOUNTING SEP. PART LIST 1

7 550 451 01 CUTTINGS COLLECTOR SEP. PART LIST 1

9 265 572 92 PRESSURE ACCUMALATOR SEP. PART LIST 1
25 550 987 33 BUMPER 1
26 550 868 36 HOSE GUIDE 1
27 550 348 98 FRONT SUPPORT SEP. PART LIST 1

28 550 594 14 SUPPORTING BLOCK 1

29 550 594 15 SUPPORTING BLOCK 1
30 623 924 18 JAW LEAD PITO 12 JA 14 1
31 623 924 18 JAW LEAD PITO 12 JA 14 1
37 155 750 38 HOSE COVER D=50 L=2000 1

38 807 695 29 STRAP L=400 Black 20

47 330 952 68 HOSE SUPPORT CF180/LF600/LF1500 1
601 390 131 68 PLATE ”R” (30X35) 1
603 390 124 38 PLATE ”3” (30X35) 1
720 550 718 78 HOSE GUIDE 1

722 550 480 89 MOUNTING SEP. PART LIST 1

799 550 458 45 SCREW SET SEP. PART LIST 1
801 550 768 94 HOSING SEP. PART LIST 1
802 550 769 33 HOSING SEP. PART LIST 1
805 550 769 36 LUBRICATION DIAGRAM SEP. PART LIST 1

55155843E 4/ 4
 SCREW SET

550 458 45
Ref Part No. Description Standard designation Qty

204 800 470 59 HEXAGON HEAD SCREW M12x30 m8.8 SFS 2064 2
263 800 537 39 HEXAGON HEAD SCREW M16x35 m8.8 SFS 4
264 442 218 50 HEXAGON HEAD SCREW M1640 m8.8 SFS 2064 12
276 800 438 39 HEXAGON HEAD BOLT M16X80 m8.8 SFS 2063 4
315 550 934 31 HEXAGON HEAD SCREW M20x50 8.8, special hexagon size 24mm 8

517 801 775 89 LOCK NUT M16 m8 4

553 851 068 09 DOUBLE LOCK WASHER M12 2
555 850 687 49 DOUBLE LOCK WASHER M16 24
556 851 283 39 DOUBLE LOCK WASHER M20 12
600 455 332 90 SCREW N:O 2 X 5 SMS 1549 8

710 801 265 39 HEXAGON HEAD SCREW M20X1,5X55 m8.8 SFS 2066 4

55045845d 1/ 1
(9$2!5,)#2/#+$2),,
 HYDRAULIC ROCK DRILL HL 710S
WATER FLUSHING, HYDRAULIC MOTOR 0MT 200, ROD 2”

550 404 71

SERIAL NUMBER
PAGES 2–3
PAGES 4–5

55040471aa 1/ 5























ÍÍÍÍ
ÍÍÍÍ
 5




55040471aa 2/ 5
 HYDRAULIC ROCK DRILL HL 710S
WATER FLUSHING, HYDRAULIC MOTOR 0MT 200, ROD 2”

550 404 71
Ref Part No. Description Standard designation Qty

2 302 897 41 HOUSING ASSY SEP. PART LIST 1

5 550 348 89 SPACER/ ROCK DRILL SEP. PART LIST 1
6 550 358 76 ROTATION BUSHING INCL. PART 88 1
15 090 475 68 GEAR INCL. PART 89 1
17 152 524 38 STUD BOLT 4

18 154 122 98 PIN D35 L144 1

20 152 525 68 CAP NUT 4
21 154 115 68 COUPLING 1
24 150 689 38 PLATE 2
27 850 687 49 DOUBLE LOCK WASHER M16 2

30 442 735 20 HEXAGON HEAD BOLT (HALF THREAD) M24X140 m8.8 4

31 800 538 69 HEXAGON HEAD SCREW (FULL THREAD) M16X45 m8.8 SFS 2064 6
33 801 777 39 LOCK NUT M24 m8 DIN 985 4
37 522 450 80 O–RING 119,5X3–1 SMS 1586 1
38 802 441 79 O–RING 139,5X3 1

42 800 805 39 O–RING 69,5X3–1 1

43 522 113 40 O–RING 29,2X3–1SMS 1586 1
46 819 539 09 ROD SEAL Ø52 2
50 302 898 73 FLUSHING DEVISE ASSY 2’’ HL700 SEP. PART LIST 1
57 817 097 49 PLUG 210292–8 3/4–16 JIC 2

58 816 909 59 PLUG (1,1/16 12JIC) 2

71 154 127 22 HYDR. MOTOR ASSY SEP. PART LIST 1
72 816 768 29 STRAIGHT THREAD ADAPTER 1,1/16”–12 JIC 2
73 817 098 79 STRAIGHT THREAD ELBOW C40X–S12–1/2” (3/4–16JIC) 1
82 851 284 69 DOUBLE LOCK WASHER M24 4

    
 



           

55040471aa 3/ 5




































ÍÍ
ÍÍÍÍ



ÍÍ








55040471aa 4/ 5
 HYDRAULIC ROCK DRILL HL 710S
WATER FLUSHING, HYDRAULIC MOTOR 0MT 200, ROD 2”

550 404 71
Ref Part No. Description Standard designation Qty

1 303 784 38 BODY INCL. PARTS 39,101–103,105–107 1

3 152 538 58 PLATE 1
4 302 977 58 REAR COVER ASSY 1
8 154 045 68 HIGH PRESSURE ACCUMULATOR SEP. PART LIST 1
9 154 046 98 LOW PRESSURE ACCUMULATOR SEP. PART LIST 1

10 097 055 08 REAR CYLINDER (PKV/IS) 1

11 154 134 58 BEARING D71 d43,5 L107,3 1
12 096 714 18 DISTRIBUTOR (PKV/IS) 1
13 154 200 48 PISTON 575 1
14 097 049 08 FRONT CYLINDER (PKV/IS) 1

16 152 539 88 GASKET PLATE D110 d38 s0,5 1

19 800 545 99 HEXAGON HEAD SCREW (FULL THREAD) M20X60 m8.8 SFS 2064 6
20 152 525 68 CAP NUT 4
27 850 687 49 DOUBLE LOCK WASHER M16 3
29 800 196 59 HEXAGON HEAD SCREW (FULL THREAD) M16X30 3

34 802 198 29 HEXAGON HEAD BOLT (HALF THREAD) 16X70 m8.8 SFS 2063 8
39 819 532 09 O–RING 64,5X3 SMS 1586 1
40 801 518 59 O–RING 84,5X3 4
41 818 735 39 O–RING 32,2X3 1
47 850 814 59 ROD SEAL 47,22x3,53 2

55 816 769 59 STRAIGHT THREAD ADAPTER F40X–S18–1” (1,1/16–12JIC) 1

56 093 298 38 ADAPTER 1,5/16–12JIC 1
60 816 909 59 PLUG (1,1/16 12JIC) 1
61 817 227 39 PLUG 1,5/16–12JIC 1
81 851 283 39 DOUBLE LOCK WASHER M20 6

    #




$


 $

       #!

    $


      $

 
    $


 "! "     ! "%



 ! "         "!

 

  ! "!       !  " !"

  ! " "  " !"

55040471aa 5/ 5
 HOUSING ASSY

302 897 41



 ÂÂÂ
ÂÂÂ


 ÂÂÂ





 20










Ref Part No. Description Standard designation Qty

1 303 785 68 HOUSING 1

2 152 521 58 REAR BUSHING 1
3 152 523 08 BUSHING L=28 1
4 152 522 88 BUSHING L=49 1
5 871 806 69 CYLINDRICAL ROLLER BEARING 1

6 885 525 39 U–SEAL 53–65–6 1

7 886 450 09 FRONT BUSHING 1
8 865 683 09 PLUG SCREW R 1/8” 1
9 857 137 29 PLUG R 1/4” 1
10 812 604 09 PLUG R 3/8” 1

11 812 605 29 PLUG R 1/2” 1

13 801 802 69 BONDED SEAL U 13,7X22X1,5 2
14 801 031 49 BONDED SEAL U 17,4X24X1,5 1
15 800 347 99 BONDED SEAL U 21,5X28,7X2,5 D2=23,15 1
16 448 473 80 SOCKET SETSCREW M10X10 m8.8 DIN 913 1

17 885 556 99 O–RING 10x3 1

18 855 968 89 O–RING 30,2X3 10
19 522 480 00 O–RING 179X3 1
20 885 559 79 O–RING 290x3 1
21 800 118 39 O–RING 79,5X3–1 SMS 1586 2

22 150 693 88 LOCKING SCREW 1

24 448 215 20 SOCKET SETSCREW M8X10 m8.8 DIN 913 1
SEAL KIT FOR ROCK DRILL INCL. PARTS 6, 13–15,17,18,21

30289741 1/ 1
 SPACER ASSY FOR HL 710, 710S
550 348 89

16 17
9
10
7
15 12
3 4
13
8 5

2 6
11

13

14

Ref Part No. Description Standard designation Qty

2 550 049 54 BUSHING 1

3 814 780 09 O–RING 72x3 1
4 150 780 18 GLAND 1
5 801 849 99 SPRING–TYPEE STRAIGHT PIN 16X40 1
6 150 707 38 DOWEL PIN 1

7 810 352 99 PLUG R 3 / 8” 1

8 801 031 49 USIT–SEAL U 17,4X24X1,5 1
9 857 137 29 PLUG R1/4” 1
10 801 802 69 USIT–SEAL U 13,7x22x1,5 1
11 522 077 80 O–RING 19,2x3 1

12 819 533 39 O–RING 24,2X3 1

13 885 557 19 O–RING 28x3 8
14 800 120 29 O–RING 89,5x3 2
15 885 558 49 O–RING 233x3 1
16 817 094 69 STRAIGHT THREAD ADAPTER 1/2 x3/4–16 JIC 1

17 817 097 49 PLUG 3/4–16 JIC 1

55034889 1/ 1
 FLUSHING DEVISE ASSY 2” HL700S WATER FLUSHING
302 898 73

























Ref Part No. Description Standard designation Qty

1 303 786 98 BODY ASSY INCL. PARTS 23–28 1

2 152 526 98 GASKET 1
3 154 129 88 COVER INCL. PART 27 1
4 153 949 08 FLANGE ADAPTER 1
5 154 128 58 SEAL HOUSING 1

6 150 694 08 GASKET 1

7 150 695 38 GASKET 1
8 817 094 69 STRAIGHT THREAD CONNECTOR F40X–S12–1/2”(3/4–16JIC) 1
10 850 687 49 LOCK WASHER M16 5
11 800 196 59 BOLT M16X30 m8.8 SFS 2064 5

12 817 097 49 CAP 210292–8 3/4–16 JIC 1

13 800 118 39 O–RING 79,5X3–1 SMS 1586 3
14 802 441 79 O–RING 139.5X3 SMS 1586 1
15 522 143 70 O–RING 39,2X3–1 SMS 1586 1
16 150 206 78 U–SEAL 5

17 522 113 40 O–RING 29,2X3–1 SMS 1586 1

18 448 215 20 SOCKET SETSCREW M8X10 m8.8 DIN 913 2
19 816 710 69 STRAIGHT THREAD CONNECTOR (1,5/16 12JIC) 1
20 810 395 09 CAP (1,5/16 12JIC) 1
21 150 292 48 COVER 1 1/2”, 1 3/4” 1

22 150 208 28 COVER 2” 1

23 806 448 09 PLUG 1/4 DIN 906 1
24 448 473 80 SOCKET SETSCREW M10X10 m8.8 DIN 913 1
25 801 849 99 SPRING PIN DIN 7343 1
26 865 683 09 PLUG SCREW 138–2 (R1/8”) 2

27 152 266 48 BUSHING BEARING 2” 1

28 152 519 68 SHANK BUSHING 1
886 304 49 SEAL KIT FOR FLUSHING HOUSING INCL. PARTS 2,6,7,13–17

30289873aB 1 / NO TAG
 HYDRAULIC MOTOR ASSY OMT 200
HL700 HL800T

154 127 22






10 Nm pre, 32 Nm final, secure with

glue





   

Ref Part No. Description Standard designation Qty

2 303 789 78 HOUSING HL700 1

3 514 015 60 LOCK NUT SKF KM 11 (M55X2) 1

4 514 411 60 LOCK WASHER SKF MB 11 1

5 855 464 39 SPHERRICAL ROLLER BEARING SKF 22211 CC 1
6 800 957 69 CIRCLIP DIN 472 2
7 550 144 58 COVER 1
8 867 144 89 BOLT M8X25–12.9 13

10 302 889 98 SHAFT HL700 1

11 150 613 08 BUTTON 1
12 883 983 29 SHAFT SEAL 2
13 800 816 79 O–RING 1
14 801 496 49 O–RING 94,5X3–1 SMS 1586 1

16 851 281 89 DOUBLE LOCK WASHER M8 13

30 550 036 49 BOLT 4

PARTS TO BE ORDERED SEPARATELY:

15 871 806 69 CYLINDRICAL ROLLER BEARING 1

867 666 99 SEAL KIT FOR HYDRRAULIC MOTOR
SEAL KIT FOR ROCK DRILL HL700 INCL. PARTS 12–14

15412722aAb 1 / NO TAG
 LOW PRESSURE ACCUMULATOR
4 BAR

154 046 98

 6



Ref Part No. Description Standard designation Qty

1 152 357 98 DIAPHRAGM 1

2 807 590 69 VALVE 1
3 869 733 29 O–RING 14X2 1
4 522 134 90 O–RING 129,5X3 1
5 819 532 09 O–RING 64,5X3 1

PARTS TO BE ORDERED SEPARATELY:

6 085 370 18 RUBBER CAP 1

SEAL KIT FOR ROCK DRILL INCL. PARTS 3,4,5

15404698 1/ 1
 HIGH PRESSURE ACCUMULATOR
80 BAR

154 045 68

 6



Ref Part No. Description Standard designation Qty

1 152 357 98 DIAPHRAGM 1

2 807 590 69 VALVE 1
3 869 733 29 O–RING 14X2 1
4 522 134 90 O–RING 129,5X3 1
5 819 532 09 O–RING 64,5X3 1

PARTS TO BE ORDERED SEPARATELY:

6 085 370 18 RUBBER CAP 1

SEAL KIT FOR ROCK DRILL INCL. PARTS 3,4,5

15404568 1/ 1
   45
2
41

















14



37




 38








15073078c 1/ 2
 SPECIAL TOOLS FOR HL650, HL700, HL700S, HL710, HL710S

150 730 78
Ref Part No. Description Standard designation Qty

1 302 878 58 MOUNTING PLATE HL700, HL 710, HL1000, HL1500 1

2 154 830 38 STAND FOR ROCK DRILL 1
3 836 202 29 WRENCH ADAPTER 1
4 153 936 18 FILL. DEVICE FOR HYDR–ACCUMUL. INCL. PART 41 1
5 096 904 68 STAND FOR ACCUM. COVER 1

6 152 501 38 OPENER FOR ACCUMULATOR 1

8 152 584 98 PUNCH CHUCK 1
9 088 258 18 PUNCH BUSHING, FLUSHING AND FRONT BEARING 1
10 088 256 68 PUNCH BUSHING, FLUSHING AND FRONT BEARING 1
12 152 586 48 PUNCH GEAR HOUS. FRONT BUSHING IN AND OUT 1

13 152 585 18 PUNCH GEAR HOUS. REAR BUSHING IN 1

14 150 736 38 PIN BEARING OF THE GEAR HOUS. 1
15 085 964 88 PUNCH NEEDLE BEARING 1
16 151 738 08 PULLER PISTON, EXTENSION FOR PUNCHES 1
17 092 864 58 PULLER GEAR BOX BUSHINGS 1

18 449 697 70 LIFTING EYE M16 2

21 087 853 38 PUNCH FRONT CYLINDER 1
22 093 149 98 PIN FRONT CYLINDER 1
24 833 710 99 SEALS REMOVING SET SEALS 1
25 093 333 78 TOOL SET: INCL. torque wrench ,sockets 19, 22, 24, 30, 36, 1
hammer, wrench 19, 24, 27, 30, 41 and
torque wrench head 19

26 088 257 98 PULLER SHAFT 1

33 090 845 48 CHECKING GAUGE LP INCL.PART 40 1
34 090 300 38 CHECKING GAUGE HP INCL.PART 40 1
35 087 856 18 THRUST FRONT CYLINDER 1
37 152 583 68 PUNCH BUSHING OF THE GEAR BOX 1

38 152 497 58 PUNCH SEAL OF THE HYDR. MOTOR 1

40 869 598 69 PRESSURE SEAL FOR PARTS 33, 34 2
41 152 280 08 HOSE ASSY FOR FILLING DEVICE 1
42 150 175 88 PUNCH SHANK BEARINGS 1
43 150 738 98 PUNCH FLUSHING HOUSING BUSHING OUT 1

44 152 537 28 PUNCH MOTOR SHAFT SEALS 1

46 150 746 48 GAGE NO–GO GAGE FOR SEAL GROOVE 1
47 550 055 28 RETAINER PLATE FOR GLAND 1
48 550 055 27 PUNCH TOOL FOR RETAINER PLATE 47 1
60 550 342 21 PUNCH FOR SPACER BUSHING 1

PARTS TO BE ORDERED SEPARATELY:

45 150 734 88 SPECIAL TOOL KIT FOR THE SITE INCL. PARTS 3–6, 8–10, 24, 25, 42 1

15073078c 2/ 2
CYLINDER FEED
 DRAWING 1–550 440 92–B

55048142bB 1/ 2
 CYLINDER FEED ASSEMBLY
550 481 42
Ref Part No. Description Standard designation Qty

1 550 431 60 FEED BEAM LF706 1

2 550 593 24 CYLINDER SEP. PART LIST 1
3 550 483 02 CARRIAGE ASSEMBLY SEP. PART LIST 1
4 320 776 08 FRAME STRIP 2
5 330 016 98 SLIDE PIECE 8

6 322 278 48 IDLER WHEEL ASSY. / FRONT SEP. PART LIST 1

8 550 435 31 WIRE ROPE D=12, LF706 4
9 550 011 12 SUPPORT 1
10 321 519 98 HOSE GUIDE 1
11 550 187 80 HOSE SUPPORT d=120 1

12 550 434 43 PLATE LUG 1

13 236 223 18 CATCH 1
14 550 437 79 NUT M16, L=135 2
15 550 437 69 NUT M16, L=95 2
17 550 439 18 PLATE 1

19 321 517 35 BULKHEADPLATE ASSY’ SEP. PART LIST 1

20 208 333 95 BAR M16 L1580 2
21 208 332 65 COVER PIPE 2
22* 322 278 47 IDLER WHEEL ASSY. / REAR SEP. PART LIST 1
23 550 281 31 VALVE ASSEMBLY SEP. PART LIST 1

24 550 288 50 SLIDE PIECE 2

25 550 427 30 RETAINING CENTRALIZER (PITO) SEP. PART LIST 1
26 209 105 78 PLATE LF 1500 2
27 204 279 28 SHAFT BAR 3
28 203 791 58 PIN 1

29 204 551 78 BEARING BUSHING D60 d50 L30 2

30 321 834 51 BULKHEADPLATE ASSY’ SEP. PART LIST 1
33* 550 425 51 SLIDE PLATE L=2780 2
34* 550 425 53 SLIDE PLATE L=3110 2
35 817 095 99 STRAIGHT THREAD ADAPTER 3/4–16JIC 6

36 817 179 09 STRAIGHT THREAD ADAPTER 7/16–20JIC 2

40* 207 256 58 SIGN ”TYPEE” 1
41 455 332 90 SCREW N:O 2 X 5 SMS 1549 1
45 550 441 37 GUIDE WASH MOUNTING SEP. PART LIST 1
46 887 319 09 SCREW M8X150 M8X150 SFS 2063 4

47 550 435 93 LEVER 1

48 550 438 00 LEVER 1
49 550 438 18 SHAFT 20MnCr5G, D40 L=96 2
50 453 689 98 BEARING BUSHING 2
51 344 615 98 BEARING BUSHING D48 d40 L20 4

202 800 824 29 HEXAGON HEAD SCREW M121X25 m8.8 SFS 2064 4
204 800 470 59 HEXAGON HEAD SCREW M12x30 m8.8 SFS 2064 5
263 800 537 39 HEXAGON HEAD SCREW M16x35 m8.8 SFS 12
264 442 218 50 HEXAGON HEAD SCREW M1640 m8.8 SFS 2064 12
271 800 469 99 HEXAGON HEAD BOLT M16X60–8.8 SFS–ISO 4014 2

275 800 540 59 HEXAGON HEAD BOLT M16X25 m8.8 SFS 2063 6
287 800 543 39 HEXAGON HEAD BOLT M16x130m8.8 SFS 2063 24
289 443 005 10 HEXAGON HEAD BOLT M16X150 m8.8 SFS 2063 2
517 801 775 89 LOCK NUT M16 m8 24
517 801 775 89 LOCK NUT M16 m8 6

519 800 485 09 HEXAGON NUT M16 m8 SFS 2067 12

551 851 281 89 DOUBLE LOCK WASHER M8 4
553 851 068 09 DOUBLE LOCK WASHER M12 9
555 850 687 49 DOUBLE LOCK WASHER M16 36
555 850 687 49 DOUBLE LOCK WASHER M16 48

* = PARTS TO BE ORDERED SEPARATELY

55048142bB 2/ 2
 DRAWING 1–550 592 16

MAX 2706
MIN 1611

55059324 1/ 2
 CYLINDER

550 593 24
Ref Part No. Description Standard designation Qty

1 550 572 31 CYLINDER TUBE (L=1471) LF 1600 1

2 550 592 59 PISTON ROD D80/60, LF 1504–LF 1506/LF 706, HL700/HLX5 1
3 550 592 20 FRONT COVER 1
4 264 027 38 PISTON 1
5 264 028 68 LIMIT BUSHING 6’/HL600 L=50 1

6 322 278 47 IDLER WHEEL ASSY. / REAR SEP. PART LIST 1

10 869 129 19 LOCK NUT (M65X2) 1
12 550 593 49 SEAL KIT FOR FEED CYLINDER LF 1600 1
13 879 178 69 STRAIGHT THREAD ADAPTER JIC 3/4 –16 2
14 817 097 49 PLUG 210292–8 3/4–16 JIC 2

15 812 609 39 PLUG R1,1/4” 1

16 800 350 09 USIT–SEAL AQ136–16 1
17 881 142 29 PLUG 138–16 (R1”) 1
18 881 139 09 PLUG R3/8”,E336–3/8” 1

55059324 2/ 2
 CARRIAGE ASSEMBLY

550 483 02

DRAWING 1–302 955–A

Ref Part No. Description Standard designation Qty

1 550 472 07 CARRIAGE HL700S / LF700 1

2 265 683 58 GUIDE L=322 L=322 2
3 447 909 00 SLOTTED COUNTERSUNK FLAT HEAD SCREW AM10X30 ,m5.8 12
4 448 629 50 HEXAGON SOCKET SET SCREW M16X25 m12.9 6
5 302 971 97 SCREW SET 1

10 812 607 89 PLUG 12 2

11 800 348 19 USIT–SEAL U 27,2X36X2 D2=28,9 2

55048302A 1/ 1
 IDLER WHEEL ASSY
FRONT

322 278 48

Ref Part No. Description Standard designation Qty

1 322 277 18 BODY 1

2 330 598 58 IDLER WHEEL D12 2
3 422 292 00 CIRCLIP DIN 472 2
4 550 592 34 ROLLER BEARING D=90,d=50,L=20 4

5 209 484 08 COVER 2

6 446 137 50 HEX.SOCKET HEAD CAP SCREW M8X20 m8.8 SFS 2219 8
7 851 281 89 LOCK WASHER FOR BOLT M8 8
8 572 102 40 GREASE NIPPLE DIN 71412 AR 1/8 3

32227848b 1/ 1
 IDLER WHEEL ASSY
REAR

322 278 47

Ref Part No. Description Standard designation Qty

1 322 277 18 BODY 1

2 330 598 58 IDLER WHEEL D12 2
3 422 292 00 CIRCLIP DIN 472 2
4 550 592 34 ROLLER BEARING D=90,d=50 ,L=20 4

5 209 484 08 COVER 2

6 446 137 50 HEX.SOCKET HEAD CAP SCREW M8X20 m8.8 SFS 2219 8
7 851 281 89 LOCK WASHER FOR BOLT M8 8
8 572 102 40 GREASE NIPPLE DIN 71412 AR 1/8 3

32227847b 1/ 1
 BULKHEADPLATE ASSY

321 517 35

DRAWING 2–321 517–H

REAR

FRONT

FRONT

REAR

Ref Part No. Description Standard designation Qty

1 816 768 29 STRAIGHT THREAD ADAPTER 1,1/16”–12 JIC 1

2 816 768 29 STRAIGHT THREAD ADAPTER 1,1/16”–12 JIC 1
3 816 768 29 STRAIGHT THREAD ADAPTER 1,1/16”–12 JIC 1
4 812 607 89 PLUG 12 1
5 816 760 09 STRAIGHT THREAD ADAPTER 1,5/16–12JIC 2063–12–12 1

6 816 778 39 STRAIGHT THREAD ADAPTER (1,5/16–12JIC) 1

7 208 380 58 ADAPTER R1 1/4”–1 1/16”–12 UNF 1
8 816 769 59 STRAIGHT THREAD ADAPTER F40X–S18–1” (1,1/16–12JIC) 1
9 816 769 59 STRAIGHT THREAD ADAPTER F40X–S18–1” (1,1/16–12JIC) 1
10 816 778 39 STRAIGHT THREAD ADAPTER (1,5/16–12JIC) 1

11 817 095 99 STRAIGHT THREAD ADAPTER 3/4–16JIC 1

12 817 095 99 STRAIGHT THREAD ADAPTER 3/4–16JIC 1
13 817 095 99 STRAIGHT THREAD ADAPTER 3/4–16JIC 1
14 812 607 89 PLUG 12 1
15 817 095 99 STRAIGHT THREAD ADAPTER 3/4–16JIC 1

16 816 778 39 STRAIGHT THREAD ADAPTER (1,5/16–12JIC) 1

17 208 380 58 ADAPTER R1 1/4”–1 1/16”–12 UNF 1
18 816 769 59 STRAIGHT THREAD ADAPTER F40X–S18–1” (1,1/16–12JIC) 1
19 816 769 59 STRAIGHT THREAD ADAPTER F40X–S18–1” (1,1/16–12JIC) 1
20 816 778 39 STRAIGHT THREAD ADAPTER (1,5/16–12JIC) 1

21 800 350 09 USIT–SEAL AQ136–16 2

22 812 607 89 PLUG 12 1
30 321 518 68 PLATE 1
32 812 607 89 PLUG 12 1

32151735cH 1/ 1
 VALVE ASSEMBLY

550 281 31

Ref Part No. Description Standard designation Qty

1 550 281 32 VALVE ASSEMBLY INCL. PARTS 2*, 3*, 4*, 5* 1

2* 550 284 24 PRESSURE COMPENSATED CONTROL VALVE INCL. SEAL KIT 887 285 29 1
3* 886 546 99 SEQUENCE VALVE 210 BAR Q=120 L/MIN P=420 BAR 1
4* 886 059 49 OVERCENTER VALVE 1
5* 816 885 99 QUICK DISCONNECT FITTING 2

6 879 178 69 STRAIGHT THREAD ADAPTER JIC 3/4 –16 2

7 816 769 59 STRAIGHT THREAD ADAPTER F40X–S18–1” (1,1/16–12JIC) 2

55028131 1/ 1
 SPARE PARTS

OTH2





55042730aA 1/ 4
 RETAINING CENTRALIZER (PITO)

550 427 30
Ref Part No. Description Standard designation Qty

1 550 373 96 FRONT PLATE 1

2 550 353 74 LEVER 1
3 550 355 74 LEVER 1
4 550 373 95 LEVER 1
5 550 427 29 CYLINDER SEP. PART LIST 1

6 263 772 28 TAPER PIN D30 L116 3

7 550 374 80 BUSHING Pito 7 4
8 048 176 48 BEARING BUSHING D40 d32 L38 4
9 572 102 40 GREASE NIPPLE AR 1/8 6
10 330 766 28 BEARING BUSHING D38 d30 L39,5 2

30* 051 154 38 JAW 11/4” 2

31* 613 418 58 JAW ROD 1 1/2”, TUBE D 56 2
32* 623 924 18 JAW ROD 1 3/4”, TUBE D 64 2
33* 613 418 58 JAW ROD 1 1/2”, TUBE D 56 2
34* 623 924 18 JAW ROD 1 3/4”, TUBE D 64 2

342 814 044 99 HEXAGON HEAD BOLT (HALF THREAD) M20X220 m8.8 SFS 2063 4
521 817 807 89 LOCK NUT M20 m8 DIN 980 4
556 851 283 39 DOUBLE LOCK WASHER M20 4
710* 801 265 39 HEXAGON HEAD SCREW (FULL THREAD) M20X1,5X55 m8.8 SFS 2066 4
711* 851 283 39 DOUBLE LOCK WASHER M20 4

ALTERNATIVES PARTS FOR DIFFERENT DRILLING CONSUMABLES:

30,31,32,33,34

55042730aA 2/ 4
55042730aA 3/ 4
 RETAINING CENTRALIZER (PITO)

550 427 30
Ref Part No. Description Standard designation Qty

1 550 373 96 FRONT PLATE 1

2 550 353 74 LEVER 1
3 550 355 74 LEVER 1
4 550 373 95 LEVER 1
5 550 427 29 CYLINDER SEP. PART LIST 1

6 263 772 28 TAPER PIN D30 L116 3

7 550 374 80 BUSHING Pito 7 4
8 048 176 48 BEARING BUSHING D40 d32 L38 4
9 572 102 40 GREASE NIPPLE AR 1/8 6
10 330 766 28 BEARING BUSHING D38 d30 L39,5 2

30* 051 154 38 JAW 11/4” 2

31* 613 418 58 JAW ROD 1 1/2”, TUBE D 56 2
32* 623 924 18 JAW ROD 1 3/4”, TUBE D 64 2
33* 613 418 58 JAW ROD 1 1/2”, TUBE D 56 2
34* 623 924 18 JAW ROD 1 3/4”, TUBE D 64 2

342 814 044 99 HEXAGON HEAD BOLT (HALF THREAD) M20X220 m8.8 SFS 2063 4
521 817 807 89 LOCK NUT M20 m8 DIN 980 4
556 851 283 39 DOUBLE LOCK WASHER M20 4
710* 801 265 39 HEXAGON HEAD SCREW (FULL THREAD) M20X1,5X55 m8.8 SFS 2066 4
711* 851 283 39 DOUBLE LOCK WASHER M20 4

ALTERNATIVES PARTS FOR DIFFERENT DRILLING CONSUMABLES:

30,31,32,33,34

55042730aA 4/ 4
 DRAWING 1–550 427 29

51

52

50
51

55042729 1/ 2
 CYLINDER

550 427 29
Ref Part No. Description Standard designation Qty

1 550 376 78 CYLINDER TUBE INCL. PARTS 51,52 1

2 550 379 15 PISTON ROD INCL. PARTS 50,51 1
3 141 152 68 PISTON D=63 1
4 143 425 18 COVER 63/40 1
5 143 427 78 BAND 63/40 1

6 049 734 28 VALVE SEAT 2

7 453 787 68 SPINDLE 1
8 048 286 88 PLUG 2
9 500 777 08 SPRING 8/1,25 2
10 049 735 58 TAPER PIN D20 L21,5 2

11 522 049 00 O–RING 11,3X2,4–1 1

12 522 067 70 O–RING 17,3x2,4–1 SMS 1586 2
13 522 091 30 O–RING 22,2X3–1 SMS 1586 2
14 868 931 19 O–RING 31,5X3 1
15 868 932 49 O–RING 57X3 1

16 807 645 89 U–SEAL 40–112 1

17 868 930 99 ROD GUIDE 40/46X9,6 3
18 806 120 89 WIPER 40–50–7–10 1
19 868 929 29 PISTON SEAL 63/47X19 1
20 872 525 89 LOCK NUT (M30X1,5) 1

21 884 267 39 PRESSURE ACCUMULATOR (0.16l) 1

22 800 916 09 HEXAGON HEAD SCREW M8x25 m8.8 SFS 1
23 801 779 99 LOCK NUT M8 m8 DIN 985 1
24 526 060 10 RUBBER SHEET 28–35020 RUBBER 61 601 0.1
27 816 701 89 STRAIGHT THREAD ADAPTER 40X–S10–1/4”(9/16–18JIC) 3

28 857 302 19 PLUG FNTX–S10 3

30 265 839 28 ADAPTER 1
31 807 590 69 VALVE 1
33 807 135 39 ADAPTER (HYDRAULIC) (R1/4”XR1/2”) 1
50 330 766 28 BEARING BUSHING D38 d30 L39,5 1

51 572 102 40 GREASE NIPPLE AR 1/8 3

52 048 176 48 BEARING BUSHING D40 d32 L38 2

PARTS TO BE ORDERED SEPARATELY:

800 550 074 65 SEAL KIT INCL. PARTS 11–19 1

55042729 2/ 2
 BULKHEADPLATE ASSY’

321 834 51

REAR

FRONT

REAR FRONT

FRONT

REAR

Ref Part No. Description Standard designation Qty

1 816 778 39 STRAIGHT THREAD CONNECTOR 1,5/16–12JIC 1

2 208 380 58 ADAPTER R1 1/4”–1 1/16”–12 UNF 1
3 816 769 59 STRAIGHT THREAD CONNECTOR 1,1/16–12JIC 1
4 816 769 59 STRAIGHT THREAD CONNECTOR 1,1/16–12JIC 1
5 816 778 39 STRAIGHT THREAD CONNECTOR 1,5/16–12JIC 1
6 816 768 29 STRAIGHT THREAD CONNECTOR 1,1/16–12JIC 1
7 816 768 29 STRAIGHT THREAD CONNECTOR 1,1/16–12JIC 1
8 816 768 29 STRAIGHT THREAD CONNECTOR 1,1/16–12JIC 1
9 812 607 89 PLUG R3/4 1
10 816 760 09 STRAIGHT THREAD CONNECTOR 1,5/16–12JIC 1
11 816 778 39 STRAIGHT THREAD CONNECTOR 1,5/16–12JIC 1
12 208 380 58 ADAPTER R1 1/4”–1 1/16”–12 UNF 1
13 816 769 59 STRAIGHT THREAD CONNECTOR 1,1/16–12JIC 1
14 816 769 59 STRAIGHT THREAD CONNECTOR 1,1/16–12JIC 1
15 816 778 39 STRAIGHT THREAD CONNECTOR 1,5/16–12JIC 1

16 817 095 99 STRAIGHT THREAD CONNECTOR 3/4–16JIC 1

17 817 095 99 STRAIGHT THREAD CONNECTOR 3/4–16JIC 1
18 817 095 99 STRAIGHT THREAD CONNECTOR 3/4–16JIC 1
19 812 607 89 PLUG R3/4 1
21 800 350 09 USIT–SEAL U 42,7X53X3 ,D2=44,9 4
22 816 768 29 STRAIGHT THREAD CONNECTOR 1,1/16–12JIC 1
23 879 176 09 STRAIGHT THREAD CONNECTOR 9/16–18JIC 1
34 801 802 69 BONDED SEAL U 13,7X22X1,5 D2=15,4 10
35 812 603 79 PLUG R1/4 10
36 879 177 39 STRAIGHT THREAD CONNECTOR 7/16–20JIC 1

32183451eF 1/ 1
 SPARE PARTS

OTH2





 DRAWING 1–550 441 37–A

SECTION A–A

G
SECTION B–B
DIRECTION A

55044137aA 1/ 2
 GUIDE WASH MOUNTING

550 441 37
Ref Part No. Description Standard designation Qty

1 550 440 56 PLATE 1

2 550 441 02 PLATE 1
3 550 361 76 SEAL 2
4 208 353 08 PLATE 2
5 550 513 16 BUSHING 4

6 550 361 78 NOZZLE 4

7 448 215 20 HEXAGON SOCKET SET SCREW M8X10 m8.8 DIN 913 2
8 550 513 32 BACKING PLATE 2
20 816 711 99 STRAIGHT THREAD ELBOW 9/16/18 2
174 800 192 49 HEXAGON HEAD SCREW M10X30 DIN933 8.8ZN 4

176 800 525 79 HEXAGON HEAD BOLT M10x40 m8.8 SFS2064 4

552 851 282 09 DOUBLE LOCK WASHER M10 8

55044137aA 2/ 2
 DRAWING 1–550 436 18–C 1/2

55048682bCb 1/ 4
 ROD CHANGER

550 486 82
Ref Part No. Description Standard designation Qty

1 550 426 22 REAR FRAME 1

2 550 428 16 FRONT BODY RC700 1
3 550 424 30 DIVIDING PLATE Z=14, RC700 1
4 550 429 90 COVER RC700 1
5 550 430 99 SWING ARM RC700 1

6 550 441 01 SWING ARM RC 700 1

7 550 441 14 PLATE LUG RC 700 2
8 550 441 18 SHAFT RC 700 1
9 550 441 19 SHAFT RC 700 1
10 550 441 61 TUBE 1

11 550 441 65 SLIDE PIECE RC 700 2

12 550 441 76 SWING PIECE RC 700 1
13 550 441 85 WASHER d 17 7
14 572 102 40 GREASE NIPPLE AR 1/8 7
15 851 601 19 MALE CONNECTOR R1/8” 1

16 867 623 79 HYDRAULIC MOTOR 1

17 206 895 18 FLANGE 4
18 207 132 08 FLANGE RC1000 1
19 208 241 18 BUSHING D65 d46 L5 2
20 208 257 98 WASHER 4

21 208 287 18 BUSHING D35 d30 L10 14

22 263 772 28 TAPER PIN D30 L116 6
23 264 742 08 BEARING BUSHING 4–085859 88) 3
24 449 698 00 LIFTING EYE M20 DIN 580 2
25 514 023 10 LOCK NUT (M80X2) 1

26 550 293 45 BEARING BUSHING Flange bearing, D60, d50, L50 6

27 880 678 49 HEXAGON THIN NUT M45X1,5 m8 DIN 936 8
28 886 758 09 DEEP GROOVE BALL BEARING D72 d50 L12 1
29 887 775 59 HEXAGON NUT M30x1.5 m8 DIN 936 4
30 817 095 99 STRAIGHT THREAD ADAPTER 3/4–16JIC 2

31 817 270 99 PLUG 1

32 802 284 39 USIT–SEAL 48,7X59X3 D2=50,8 1
33 883 421 89 V–SEAL (68–73) W=6 6
34 883 420 59 V–SEAL (33–36) W=4 16
35 883 419 99 V–SEAL (105–115) W=7 2

55048682bCb 2/ 4
 DRAWING 1–550 436 18–C 2/2

55048682bCb 3/ 4
 ROD CHANGER

550 486 82
Ref Part No. Description Standard designation Qty

36 206 252 38 KEY RC1600 1

37 514 416 00 LOCK WASHER MB16 1
38 086 028 18 KEY 2
100 550 441 54 PIPE MIDDLE TUBE, SOLO/RC700* 1
101 550 425 54 PLATE Turning plate 2

102 550 436 12 SWING SHAFT 6’, Fixed jaw retainer 1

103 550 440 38 FIXED JAW RETAINER SEP. PART LIST 2
104 550 587 57 CYLINDER SEP. PART LIST 4
105 550 437 55 SHAFT SOLO/RC700* 1
106 550 908 66 GUIDE PLATE 10mm 1

108* 550 424 53 PLATE Turning plate 2

188 800 462 09 HEXAGON HEAD BOLT M10x100m8.8SFS 2063 2
189 802 472 29 HEXAGON HEAD BOLT M10X110 m8.8 SFS 2063 2
202 800 824 29 HEXAGON HEAD SCREW M121X25 m8.8 SFS 2064 11
206 800 531 79 HEXAGON HEAD SCREW M12x40 m8.8 SFS 2064 2

213 800 534 59 HEXAGON HEAD BOLT M12X70 m8.8 SFS 2063 2
262 800 196 59 HEXAGON HEAD SCREW M16X30 m8.8 2
270 801 745 59 HEXAGON HEAD SCREW M16X60 m8.8 SFS 2064 8
271 800 469 99 HEXAGON HEAD BOLT M16X60–8.8 SFS–ISO 4014 8
278 800 541 89 HEXAGON HEAD BOLT M16X85 m8.8 6

281 442 665 20 HEXAGON HEAD BOLT M16X100 m8.8 8

290* 442 916 90 HEXAGON HEAD BOLT M16M160 m8.8 SFS 2063 6
291* 800 544 69 HEXAGON HEAD BOLT M16X180 m8.8 SFS 2063 8
321 800 197 89 HEXAGON HEAD SCREW M20X70 SFS 2064 4
518 811 259 69 LOCK NUT M16 m8 B–lock 14

518 811 259 69 LOCK NUT M16 m8 B–lock 8

519 800 485 09 HEXAGON NUT M16 2
522 801 770 49 HEXAGON NUT M 20 m 8 SFS 2067 4
552 851 282 09 DOUBLE LOCK WASHER M10 4
553 851 068 09 DOUBLE LOCK WASHER M12 15

555 850 687 49 DOUBLE LOCK WASHER M16 24

555 850 687 49 DOUBLE LOCK WASHER M16 28
556 851 283 39 DOUBLE LOCK WASHER M20 4

ALTERNATIVE PARTS FOR DIFFERENT DRILLING CONSUMABLES:

108, 290, 291

55048682bCb 4/ 4
 DRAWING 1–550 440 40–A

55044038aAb 1/ 2
 FIXED JAW RETAINER

550 440 38
Ref Part No. Description Standard designation Qty

1 550 437 51 BODY 1

2 550 436 58 JAW 1
3 263 772 28 TAPER PIN D30 L116 1
4 550 436 26 GUARD 1
5 550 295 57 TAPER PIN D40 L230 1

7 550 295 59 BUSHING D48/40–35 2

8 550 440 09 GUIDE PLATE 1
9 550 440 10 GUIDE PLATE 1
10 550 437 78 BEARING 2
15 572 102 40 GREASE NIPPLE AR 1/8 4

34 550 598 87 WIPER 30X47X8 2

50 550 440 27 WEAR PIECE 1
51 550 586 66 CYLINDER SEP. PART LIST 1
52* 263 581 58 WEAR PIECE, ROD 1 1/4’’ 1 1/4” 1
53* 163 407 08 JAW 1 1/2” 1

54 163 413 08 JAW 1 3/4” 1

55* 262 619 28 JAW PIECE, TUBE 55–64 TUBE 55–64 1
172 800 823 09 HEXAGON HEAD SCREW M10x20m8.8SFS 2064 4
202 800 824 29 HEXAGON HEAD SCREW M121X25 m8.8 SFS 2064 6
204 800 470 59 HEXAGON HEAD SCREW M12x30 m8.8 SFS 2064 12

263 800 537 39 HEXAGON HEAD SCREW M16x35 m8.8 SFS 3

264 442 218 50 HEXAGON HEAD SCREW M1640 m8.8 SFS 2064 2
552 851 282 09 DOUBLE LOCK WASHER M10 4
553 851 068 09 DOUBLE LOCK WASHER M12 12
553 851 068 09 DOUBLE LOCK WASHER M12 6

555 850 687 49 DOUBLE LOCK WASHER M16 5

ALTERNATIVE PARTS FOR DIFFERENT DRILLING CONSUMABLES:

52, 53, 55

55044038aAb 2/ 2
 DRAWING 2–550 586 66

MIN 255
MAX 315

55058666 1/ 2
 CYLINDER

550 586 66
Ref Part No. Description Standard designation Qty

1 550 439 09 CYLINDER TUBE d55 1

2 550 439 21 PISTON ROD D32, INCL. PARTS 30, 31, 32 1
3 550 576 88 PISTON Cylinder D55 d32 1
4 550 576 93 FRONT COVER Cylinder D55 d32 1
5 874 541 09 LOCK NUT (M20X1) 1

6 880 312 49 PISTON SEAL 70 Shore A 1

7 550 586 59 ROD SEAL 32x42x8 1
8 550 586 54 WIPER 32x40x5 1
9 550 586 52 SEAL RING 55x49.9x5.3 1
10 817 741 29 O–RING 23,3X2,4–1 1

11 550 359 72 ROD GUIDE 32/37–9.7 Slydring GR6900320––C380 1

12 550 359 72 ROD GUIDE 32/37–9.7 Slydring GR6900320––C380 1
13 550 359 70 ROD SEAL 32/42.7–4.2 RS1300320–T46N 1
14 880 310 99 ROD GUIDE 55,0 x 50,0 x 9,7 Turcite 47 1
15 880 310 99 ROD GUIDE 55,0 x 50,0 x 9,7 Turcite 47 1

16 141 253 18 BEARING BUSHING D=36/30 L=30 2

17 857 302 19 PLUG FNTX–S10 4
18 801 031 49 USIT–SEAL U 17,4X24X1,5 4
19 856 040 09 STRAIGHT THREAD ADAPTER F40X–S10–3/8 4

PARTS TO BE ORDERED SEPARATELY:

30 883 349 99 PLAIN BEARING 1

31 422 245 40 CIRCLIP 47x1,75 2
32 572 102 40 GREASE NIPPLE AR 1/8 1
800 550 586 76 SEAL KIT FOR CYLINDER 1

55058666 2/ 2
 CYLINDER

550 587 57

DRAWING 3–550 576 85

MIN 340
MAX 445

Ref Part No. Description Standard designation Qty

1 550 576 94 CYLINDER TUBE D55 s105 1

2 321 451 87 PISTON ROD D32 D32 1
3 550 576 88 PISTON D55 d32 1
4 550 576 93 FRONT COVER D55 d32 1
5 874 541 09 LOCK NUT (M20X1) 1

6 880 312 49 PISTON SEAL 70 Shore A 1

7 880 310 99 ROD GUIDE 55,0 x 50,0 x 9,7 Turcite 47 2
8 550 586 59 ROD SEAL 32x42x8 1
9 550 359 70 ROD SEAL 32/42.7–4.2 RS1300320–T46N 1
10 550 359 72 ROD GUIDE 32/37–9.7 Slydring GR6900320––C380 2

11 550 586 54 WIPER 32x40x5 1

12 550 586 52 SEAL RING 55x49.9x5.3 1
13 817 741 29 O–RING 23,3X2,4–1 1
14 883 349 99 PLAIN BEARING (INA GE30DO–2RS) 1
15 422 245 40 CIRCLIP 47x1.75 DIN 472 2

16 856 040 09 STRAIGHT THREAD ADAPTER F40X–S10–3/8 2

17 812 604 09 PLUG R3/8 2
18 801 031 49 USIT–SEAL U 17,4X24X1,5 2
19 857 302 19 PLUG FNTX–S10 2
20 572 102 40 GREASE NIPPLE AR 1/8 2

PARTS TO BE ORDERED SEPARATELY:

800 550 586 76 SEAL KIT FOR CYLINDER 1

55058757a 1/ 1
 SPARE PARTS

OTH2





 DRAWING 1–550 451 15–D

55045115dD 1/ 2
 VALVE ASSEMBLY

550 451 15
Ref Part No. Description Standard designation Qty

1 550 451 58 VALVE BOX 1

2 550 454 86 CONTROL VALVE ASSEMBLY SEP. PART LIST 1
3 550 453 18 SUPPORTING BLOCK 1
10 817 183 59 SWIVEL NUT ELBOW 90 C6X–S12 2
30 321 567 88 OVERCENTER VALVE BLOCK SEP. PART LIST 1

34 561 110 62 SHUTTLE VALVE JIC 6 SEP. PART LIST 1

35 561 110 62 SHUTTLE VALVE JIC 6 SEP. PART LIST 1
40 879 368 09 PRE–WIRED PLUG CABLE 24DC, 3.0m 16
43 801 961 19 PIPE CLAMP 1300–7 1
50 390 509 68 PLATE 1

51 455 332 90 SCREW N:O 2 X 5 SMS 1549 6

61 550 007 24 RUBBER SEAL D=40mm, H=16 hole d=32mm, hole s=8mm 4
62 817 396 09 FILLING CAP PK11 IP65 Ms GL = 6 mm 6
63 810 940 99 FILLING CAP PK21 IP65 Ms GL = 7 mm 1
135 810 913 49 HEXAGON HEAD BOLT M6X75 m8.8 SFS 2063 2

162 442 751 30 HEXAGON HEAD BOLT M8X90 m8.8 SFS 2063 2
172 800 823 09 HEXAGON HEAD SCREW M10x20m8.8SFS 2064 1
200 800 116 89 HEXAGON HEAD SCREW M12X16 m8.8 SFS 2064 4
265 800 538 69 HEXAGON HEAD SCREW M16X45 m8.8 SFS 2064 3
504 801 774 59 LOCK NUT M6 4

506 801 779 99 LOCK NUT M8 m8 DIN 985 2

513 800 821 49 HEXAGON NUT m8 SFS 2067 4
517 801 775 89 LOCK NUT M16 m8 3
550 853 239 79 DOUBLE LOCK WASHER M6 6
551 851 281 89 DOUBLE LOCK WASHER M8 4

552 851 282 09 DOUBLE LOCK WASHER M10 1

555 850 687 49 DOUBLE LOCK WASHER M16 6
572 851 372 29 WASHER D=17/6,4X3 4
601 411 754 20 HEXAGON NUT M6 , A4 4
746 446 703 80 HEXAGON SOCKET HEAD SCREW .A4–80 ISO3506 4

PARTS TO BE ORDERED SEPARATELY:

7 550 401 74 JUNCTION BOX ASSEMBLY SEP. PART LIST 1

11 442 256 30 HEXAGON HEAD SCREW M16X55 m8.8 2
12 850 687 49 DOUBLE LOCK WASHER M16 2
60 887 866 09 RUBBER SEAL 1.5

55045115dD 2/ 2
 DRAWING 2–321 007–F

55045486F 1/ 2
 CONTROL VALVE ASSEMBLY

550 454 86
Ref Part No. Description Standard designation Qty

1 326 135 38 SUBPLATE (CETOP 2) 8 STATIONS 1

2 882 536 49 DIRECTIONAL VALVE SEP. PART LIST 8
3 882 542 49 DOUBLE PILOT OPERATED CHECK VALVE 4
5 882 549 39 PRESSURE REDUCING VALVE 1
6 886 393 09 PRESSURE RELIEF VALVE 4

10 817 094 69 STRAIGHT THREAD ADAPTER 1/2 x3/4–16 JIC 2063–8–8 2

11 800 347 99 USIT–SEAL U 21,5X28,7X2,5 D2=23,15 2
12 814 794 29 ADAPTER (HYDRAULIC) 1260–6 R 3/8 16
13 816 702 09 STRAIGHT THREAD ADAPTER F40X–S10–1/2” 2
14 817 180 79 SWIVEL NUT ELBOW 9/16–18 JIC 2

15 850 778 99 PRESSURE GAUGE CONNECTOR TT4XS10 1/4” 2

16 801 802 69 USIT–SEAL U 13,7X22X1,5 D2=15,4 2
17 816 885 99 QUICK DISCONNECT FITTING 2
18 817 097 49 PLUG 210292–8 3/4–16 JIC 2
22 857 302 19 PLUG FNTX–S10 16

23 865 400 09 ADAPTER (HYDRAULIC) (UK=JIC3/16–18 SK=R3/8”) 16

24 811 555 39 LOCK NUT HD 1270–6 R3/8” 16
31 445 765 80 HEXAGON SOCKET HEAD SCREW M5X40 m8.8 SFS 2219 8
32 853 324 59 HEXAGON SOCKET HEAD SCREW M5X70 m8.8 SFS 12
33 871 242 29 HEXAGON SOCKET HEAD SCREW m12.9 SFS 2219 12

41 455 332 90 SCREW N:O 2 X 5 SMS 1549 4

42 801 031 49 USIT–SEAL U 17,4X24X1,5 16

PARTS TO BE ORDERED SEPARATELY

43 887 292 59 PRE–WIRED PLUG CABLE (MG–CABLE)(OEM) 16

55045486F 2/ 2
 DIRECTIONAL CONTROL VALVE

882 536 49

Ref Part No. Description Standard designation Qty

1 888 009 19 SOLENOID 24 V VICKERS 873706 FOR DG4V–2–10 2

2 888 010 89 SEAL KIT VICKERS 02–156492 FOR DG4V–2–10 1

88253649 1/ 1
 SPARE PARTS

OTH2





 DRAWING 3–550 395 21

1,2

10,11 20,21 30,31

15,16 25,26

25A
26A
1

1
–

–
25K
26K
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
2
3
4
5
6
7
8
9

45,46 35,36

50,51,52,53,54,55,56,57,58,59 60,61

40,41

55040174a 1/ 2
 JUNCTION BOX ASSEMBLY

550 401 74
Ref Part No. Description Standard designation Qty

1 550 396 23 STAINLESS STEEL ENCLOSURE 150x200x80 1

2 550 860 31 WASHER Washer d1=17 d2=30 s=3, Ms, M16 4
2 550 860 37 WASHER Washer d1=8.5, d2=21, s=3, Ms 4
10 550 038 19 METALLIC CABLE GLAND M25x1.5, 13–18mm, IP68, –40 C – 100 C 1
11 550 024 06 METALLIC LOCK–NUT M25x1.5, H=3.5mm 1

15 550 076 08 CABLE ENTRY M25, 4x7mm, –40 C – 100 C IP68 1

16 550 024 06 METALLIC LOCK–NUT M25x1.5, H=3.5mm 1
20 550 076 08 CABLE ENTRY M25, 4x7mm, –40 C – 100 C IP68 1
21 550 024 06 METALLIC LOCK–NUT M25x1.5, H=3.5mm 1
25 550 076 08 CABLE ENTRY M25, 4x7mm, –40 C – 100 C IP68 1

26 550 024 06 METALLIC LOCK–NUT M25x1.5, H=3.5mm 1

30 550 076 08 CABLE ENTRY M25, 4x7mm, –40 C – 100 C IP68 1
31 550 024 06 METALLIC LOCK–NUT M25x1.5, H=3.5mm 1
35 550 024 04 METALLIC LOCKING PLUG M25x1.5, D=28mm, H=4mm, L=8mm, IP68 1
36 550 024 06 METALLIC LOCK–NUT M25x1.5, H=3.5mm 1

40 550 024 04 METALLIC LOCKING PLUG M25x1.5, D=28mm, H=4mm, L=8mm, IP68 1
41 550 024 06 METALLIC LOCK–NUT M25x1.5, H=3.5mm 1
45 550 024 04 METALLIC LOCKING PLUG M25x1.5, D=28mm, H=4mm, L=8mm, IP68 1
46 550 024 06 METALLIC LOCK–NUT M25x1.5, H=3.5mm 1
50 803 123 39 CONTACT RAIL 33/7,5 0.19

51 816 241 89 END CLAMP 2

52 819 899 39 TERMINAL STRIP 23
53 852 885 69 TERMINAL MARKING STRIP ZB6.Lgs:1–10 4
54 852 887 19 TERMINAL MARKING STRIP ZB6.Lgs:21–30 2
55 852 886 99 TERMINAL MARKING STRIP ZB6.Lgs:11–20 2

56 885 927 09 TERMINAL MARKING STRIP ZBM6:SO/CMS/WH 0.04

57 885 928 29 TERMINAL MARKING STRIP ZB6:without marking 3.8
58 819 900 39 TERMINAL STRIP ACCESSORY 5–Mar 1
60 858 964 09 TERMINAL STRIP 2
61 885 928 29 TERMINAL MARKING STRIP ZB6:without marking 0.8

55040174a 2/ 2
 OVERCENTER VALVE BLOCK

321 567 88

Ref Part No. Description Standard designation Qty

1 883 663 29 DOUBLE OVERCENTER VALVE 1

2 856 040 09 STRAIGHT THREAD CONNECTOR F40X–S10–3/8”(9/16–18JIC) 4

32156788 1/ 1
 SHUTTLE VALVE

561 110 62










Ref Part No. Description Standard designation Qty

1 056 923 48 BODY VALVE 1

2 561 104 68 RING 1
3 133 455 18 ADAPTER R1/2” – 9/16”–18 UNF 2
4 816 702 09 STRAIGHT THREAD CONNECTOR F40X–S10–1/2”(9/16–18JIC) 1

5 514 914 80 BALL DIN 5401–10mm III 1

6 522 067 70 O–RING 17,3X2,4–1 SMS 1586 3
8 634 014 00 PLUG D.B.I. NR:30 m=16,5 M=18,0 3

56111062bE 1/ 1
 DRAWING 1–550 451 15–D

55072953D 1/ 2
 SENSOR MOUNTING

550 729 53
Ref Part No. Description Standard designation Qty

15 550 488 56 SENSOR ASSEMBLY SEP. PART LIST 1

175 800 461 79 HEXAGON HEAD SCREW M10x35 m8.8 SFS 2064 2
552 851 282 09 DOUBLE LOCK WASHER M10 2

55072953D 2/ 2
 3–55048856–B

55048856dB 1/ 2
 SENSOR ASSEMBLY

550 488 56
Ref Part No. Description Standard designation Qty

1 550 913 93 SENSOR Inklination /–45 (90) / 360 degr. 1

2 550 487 34 PLATE Inclinometer 1
4 550 770 58 DOUBLE LOCK WASHER M5 4
5 312 743 90 HEXAGON HEAD SCREW M5X12 , A4 4

55048856dB 2/ 2
 DRAW. 1–550 451 01

55045101_a 1/ 2
 CUTTINGS COLLECTOR

550 451 01
Ref Part No. Description Standard designation Qty

1 550 453 37 BODY Cuttings collector 1

2 159 216 68 RING CC600/1000 1
4 550 453 39 COVER RUBBER Cuttings collector 1
5 801 211 89 HEXAGON HEAD BOLT M12X65 4
6 800 531 79 HEXAGON HEAD SCREW M12x40 m8.8 SFS 2064 18

7 800 545 99 HEXAGON HEAD SCREW M20X60 m8.8 SFS 2064 6

9 811 260 29 LOCK NUT M12 m8 BH8 18
10 857 514 39 WASHER 13/35X5 18
11 851 283 39 DOUBLE LOCK WASHER M20 6
12 263 953 98 CONE CC1014/CC611 rod equipment 1

13 264 846 48 CUTTING PROTECTOR MATALA H=56 1

22* 206 186 48 RUBBER PLATE D64–PUTKILLE 5
23 159 220 08 RUBBER SHEET 1 1/4”–––>FOR ROD 5
30 531 103 50 CHAIN 6,5x38 TES 82–35 (1/4”) 0.35
31 850 557 99 WASHER D=35/13 X 5 3

32 800 526 09 HEXAGON HEAD BOLT (HALF THREAD) M10X45 m8.8 SFS 2063 2
34 812 622 69 LOCK NUT M10 m8 DIN 980 1

*=PARTS TO BE ORDERED SEPARATELY

55045101_a 2/ 2
 PRESSURE ACCUMULATOR

265 572 92

Ref Part No. Description Standard designation Qty

1 085 370 18 CAP 1

2 156 959 48 REDUCING PIECE 1
3 807 590 69 VALVE 1
4 808 010 69 O–RING OR 14,00X1,78 SIMRIT 1
5 850 819 99 CU–GASKET 13/26X1,5 1

6 884 268 69 PRESSURE ACCUMULATOR 0531 602 611 1

7 816 702 09 STRAIGHT THREAD CONNECTOR F40X–S10–1/2”(9/16–18JIC) 1
8 810 468 99 BOLT SFS–ISO 4017 M8X40–8.8 1
9 801 779 99 NUT M8 m8 DIN 985 1
10 265 571 68 PRESSURE ACCUMULATOR SUPPORT 1

26557292A 1/ 1
 SPARE PARTS

OTH2





 DRAW. 1–550 348 98

55034898 1/ 2
 FRONT SUPPORT

550 348 98
Ref Part No. Description Standard designation Qty

1 550 349 22 OUTER PIPE 1

2 550 348 99 INNER TUBE 1
3 321 192 66 CYLINDER SEP. PART LIST 1
7 550 355 53 GROUND PIN 1
9 207 096 38 PIN D40 L117 1

10 204 739 28 CLEVIS PIN L=163 1

12 344 668 18 WIPER RUBBER 1
13 344 669 48 SUPPORT PLATE 1
14 262 129 08 WEAR PIECE M100X2–10 D100 8
15 262 130 68 LOCK PIECE M100X2–10 D100 8

16 205 722 38 PLATE 8

17 453 689 98 BEARING BUSHING 2
18 204 279 28 SHAFT BAR 1
19* 572 102 40 GREASE NIPPLE AR 1/8 3
20* 422 080 90 CIRCLIP 40X1,75 DIN 471 2

24 445 784 70 HEXAGON SOCKET HEAD SCREW M8X25 m8.8 SFS 12

35 881 141 09 PLUG (R3/4”) (E336–3/4”) 1
40 881 144 89 PLUG SCREW 138–24 (R1 1/2”) ( E336–1 1/2”) 2
142 808 803 59 HEXAGON HEAD SCREW M8x16m8.8 SFS 16
204 800 470 59 HEXAGON HEAD SCREW M12x30 m8.8 SFS 2064 2

263 800 537 39 HEXAGON HEAD SCREW M16x35 m8.8 SFS 4

553 851 068 09 DOUBLE LOCK WASHER M12 2
555 850 687 49 DOUBLE LOCK WASHER M16 4

55034898 2/ 2
 HYDR.CYLINDER ASSY D80/50

321 192 66






ÍÍÍ
ÄÄ


ÍÍÍÍÍÍ
ÍÍÍÄ
È
ÍÍÍÍ
ÄÈ
È
È







 VBZBV. 2660
VFRC. 4660


Ref Part No. Description Standard designation Qty

001 321 585 48 CYLINDER TUBE D80 INCL. PART 21,22 1

002 321 587 08 PISTON ROD D50 INCL. PART 21,22 1
003 155 044 48 PISTON 1
004 162 395 08 COVER 1
005 869 128 99 LOCK NUT M40X1,5 1

007 817 317 59 PISTON RING 1

008 803 135 09 U–SEAL 50X60X10 1
009 807 823 69 WIPER 50X60X10/7 1
010 522 271 70 O–RING 69,2X5,7–1 1
011 428 702 10 O–RING 49,5X3–1 SMS 1586 1

012 814 797 09 GUIDE RING 1

013 800 118 39 O–RING 79,5X3–1 1
014 812 603 79 PLUG R1/4 2
015 801 802 69 BONDED SEAL U 13,7X22X1,5 D2=15,4 2
016 816 701 89 STRAIGHT THREAD CONNECTOR 9/16–18JIC 2

017 803 264 29 CAP 9/16–18 JIC 2

020 158 729 88 BUSHING 1
021     GREASE NIPPLE 2
022
BEARING BUSHING 1
856 700 69 SEAL KIT

 1/ 1
 SPARE PARTS

OTH2





 SECTION B – B
DIRECTION A

DRAWING 1–550 371 91–D

55048089cD 1/ 2
 MOUNTING
GREASE DISTRIBUTORS, LINCOLN AUTOMATIC

550 480 89
Ref Part No. Description Standard designation Qty

207 800 532 09 HEXAGON HEAD SCREW M12X35 m8.8 SFS 2064 4
553 851 068 09 DOUBLE LOCK WASHER M12 4
600 455 332 90 SCREW N:O 2 X 5 SMS 1549 68
700 851 786 59 DISTRIBUTOR 619–26473–1 2
701 265 038 88 COVER 1

702 550 473 85 COVER PLATE 2

703 445 715 30 HEXAGON SOCKET HEAD SCREW M6X40 m12.9 SFS 10
704 851 787 89 DISTRIBUTOR 1
705 851 788 09 DISTRIBUTOR 1
706 851 788 09 DISTRIBUTOR 1

707 851 788 09 DISTRIBUTOR 1

710 390 130 38 PLATE ”G” 6
711 390 132 98 PLATE 0 (30X35) 1
712 390 122 88 SIGN ”1” (30X35) 6
713 390 123 08 SIGN ”2” (30X35) 1

714 390 124 38 PLATE ”3” (30X35) 1

715 390 125 68 PLATE ”4” (30X35) 1
716 390 133 18 PLATE 9 (30X35) 1

55048089cD 2/ 2
BOOM
 DRAWING 1–550 471 19–C
1/2

55155842C 1/ 4
 BOOM MODULE

551 558 42
Ref Part No. Description Standard designation Qty

1 550 899 64 BOOM ASSEMBLY SEP. PART LIST 1

2 550 803 90 FRONT FRAME ASSEMBLY SEP. PART LIST 1
4 550 865 12 HOSE SUPPORT ASSEMBLY SEP. PART LIST 1
8 550 713 69 LASER EQUIPMENT SEP. PART LIST 2
10 857 801 29 HEAD SCREW M12X40 – 10.9 8

17 345 364 38 COVER ZR/C 1

22 550 867 12 SUPPORT hose guide 2
23 550 867 32 SUPPORT hose guide 1
24 550 868 78 SUPPORT hose support 1
25 550 867 94 HOSE GUIDE 1

27 550 611 39 PLATE 1

28 550 610 63 SUPPORTING BLOCK 1
29 135 058 08 SUPPORTING BLOCK D=120 1
30 135 058 08 SUPPORTING BLOCK D=120 1
31 550 867 04 HOSE SUPPORT ASSEMBLY D120, chain leg 1

32 550 867 04 HOSE SUPPORT ASSEMBLY D120, chain leg 1

33 550 269 34 HOSE SUPPORT ZR30/C 2
34 550 620 51 COVER RUBBER ZR 32, Solo 5 1
35 550 620 50 PLATE ZR 32, Solo 5 2
36 550 620 61 PLATE 2

38 550 868 12 HOSE GUIDE ZR20, SOLO 5 1

39 550 868 13 HOSE GUIDE ZR20, SOLO 5 1
40 550 693 63 HOSE GUIDE ZR 32, Solo 5 1
41 550 867 54 HOSE GUIDE ZR20, SOLO 5 1
42 550 693 60 HOSE GUIDE ZR 32, Solo 5 1

45 550 867 07 SUPPORT hose support 1

46 550 868 35 COVER PLATE ZR 20, Solo 5 1
47 550 867 39 SHAFT hose guide 1
48 550 868 22 HOSE GUIDE ZR20, SOLO 5 1
49 550 867 08 HOSE GUIDE ZR20, SOLO 5 1

50 550 439 52 ROLLER 1

51 550 439 50 ROLLER 2
60 550 038 19 METALLIC CABLE GLAND 2
61 816 768 29 STRAIGHT THREAD ADAPTER 1,1/16”–12 JIC 2
80 857 678 29 HOSE –M–040 d=40 D=45 6bar 4

81 155 749 78 HOSE COVER D=102 L=2000 3

82 807 695 29 STRAP L=400 Black 20
701 550 863 35 SENSOR ASSEMBLY SEP. PART LIST 1
702 550 805 86 MOUNTING SEP. PART LIST 1
799 550 805 02 SCREW SET SEP. PART LIST 1

802 550 846 54 HOSING SEP. PART LIST 1

804 550 805 08 HOSING SEP. PART LIST 1
805 550 805 17 LUBRICATION DIAGRAM SEP. PART LIST 1

55155842C 2/ 4
 DRAWING 1–550 471 19–C
2/2

55155842C 3/ 4
 BOOM MODULE

551 558 42
Ref Part No. Description Standard designation Qty

1 550 899 64 BOOM ASSEMBLY SEP. PART LIST 1

2 550 803 90 FRONT FRAME ASSEMBLY SEP. PART LIST 1
4 550 865 12 HOSE SUPPORT ASSEMBLY SEP. PART LIST 1
8 550 713 69 LASER EQUIPMENT SEP. PART LIST 2
10 857 801 29 HEAD SCREW M12X40 – 10.9 8

17 345 364 38 COVER ZR/C 1

22 550 867 12 SUPPORT hose guide 2
23 550 867 32 SUPPORT hose guide 1
24 550 868 78 SUPPORT hose support 1
25 550 867 94 HOSE GUIDE 1

27 550 611 39 PLATE 1

28 550 610 63 SUPPORTING BLOCK 1
29 135 058 08 SUPPORTING BLOCK D=120 1
30 135 058 08 SUPPORTING BLOCK D=120 1
31 550 867 04 HOSE SUPPORT ASSEMBLY D120, chain leg 1

32 550 867 04 HOSE SUPPORT ASSEMBLY D120, chain leg 1

33 550 269 34 HOSE SUPPORT ZR30/C 2
34 550 620 51 COVER RUBBER ZR 32, Solo 5 1
35 550 620 50 PLATE ZR 32, Solo 5 2
36 550 620 61 PLATE 2

38 550 868 12 HOSE GUIDE ZR20, SOLO 5 1

39 550 868 13 HOSE GUIDE ZR20, SOLO 5 1
40 550 693 63 HOSE GUIDE ZR 32, Solo 5 1
41 550 867 54 HOSE GUIDE ZR20, SOLO 5 1
42 550 693 60 HOSE GUIDE ZR 32, Solo 5 1

45 550 867 07 SUPPORT hose support 1

46 550 868 35 COVER PLATE ZR 20, Solo 5 1
47 550 867 39 SHAFT hose guide 1
48 550 868 22 HOSE GUIDE ZR20, SOLO 5 1
49 550 867 08 HOSE GUIDE ZR20, SOLO 5 1

50 550 439 52 ROLLER 1

51 550 439 50 ROLLER 2
60 550 038 19 METALLIC CABLE GLAND 2
61 816 768 29 STRAIGHT THREAD ADAPTER 1,1/16”–12 JIC 2
80 857 678 29 HOSE –M–040 d=40 D=45 6bar 4

81 155 749 78 HOSE COVER D=102 L=2000 3

82 807 695 29 STRAP L=400 Black 20
701 550 863 35 SENSOR ASSEMBLY SEP. PART LIST 1
702 550 805 86 MOUNTING SEP. PART LIST 1
799 550 805 02 SCREW SET SEP. PART LIST 1

802 550 846 54 HOSING SEP. PART LIST 1

804 550 805 08 HOSING SEP. PART LIST 1
805 550 805 17 LUBRICATION DIAGRAM SEP. PART LIST 1

55155842C 4/ 4
 SCREW SET

550 805 02
Ref Part No. Description Standard designation Qty

173 800 460 49 HEXAGON HEAD SCREW M10X25–8.8 SFS–ISO 4017 8

203 800 465 89 HEXAGON HEAD BOLT M12X25 m8.8 2
204 800 470 59 HEXAGON HEAD SCREW M12x30 m8.8 SFS 2064 10
205 442 776 90 HEXAGON HEAD SCREW M12X35 8.8 SFS 2064 8
206 800 531 79 HEXAGON HEAD SCREW M12x40 m8.8 SFS 2064 14

208 808 997 79 HEXAGON HEAD SCREW M12X0 m8.8 SFS 2064 14
215 800 535 89 HEXAGON HEAD BOLT M12X80 m8.8 SFS 2063 4
260 816 818 09 HEXAGON HEAD SCREW M16X20 m8.8 SFS 2064 6
261 801 093 59 HEXAGON HEAD SCREW M16X25–8.8 1
262 800 196 59 HEXAGON HEAD SCREW M16X30 4

263 800 537 39 HEXAGON HEAD SCREW M16x35 m8.8 SFS 8

264 442 218 50 HEXAGON HEAD SCREW M1640 m8.8 SFS 2064 10
267 863 225 89 HEXAGON HEAD SCREW M16X50–10,9 SFS–ISO 4014 4
272 800 437 09 HEXAGON HEAD BOLT 16X65 m8.8 SFS 2063 2
510 800 820 19 HEXAGON NUT M10 m8 SFS 2067 2

511 412 113 00 LOCK NUT M12 DIN 985–8 NYLOC 4

513 800 821 49 HEXAGON NUT m8 SFS 2067 6
517 801 775 89 LOCK NUT M16 m8 8
519 800 485 09 HEXAGON NUT M16 m8 SFS 2067 2
552 851 282 09 DOUBLE LOCK WASHER M10 16

553 851 068 09 DOUBLE LOCK WASHER M12 40

555 850 687 49 DOUBLE LOCK WASHER M16 31
564 550 130 61 DOUBLE LOCK WASHER M16 sp, 6
596 884 009 89 WASHER M12 DIN 9021 10
597 550 269 68 LARGE PLAIN WASHER M16 SFS 4684 8

55080502a 1/ 1
 SPARE PARTS

OTH2





 DRAWING 1–550 471 17–C
1/2

55089964Cc 1/ 4
 BOOM ASSEMBLY

550 899 64
Ref Part No. Description Standard designation Qty

1 550 411 34 BOOM GUIDE 1

2 550 408 04 OUTER PIPE 1
3 550 404 28 INNER TUBE SEP. PART LIST 1
4 550 469 16 CRADLE 1
6 550 412 97 FLANGE 6x328x328 1

7 208 353 08 PLATE 4

8 550 419 47 FIXING CLIP 1
9 264 016 08 GROUND SPIKE 1
10 550 620 39 PLATE 1
11 332 200 98 COVER 1

12 550 412 55 COVER 1

13 550 412 58 RUBBER SHEET 6x120x120 1
17 207 256 58 SIGN ”TYPEE” 1
20 054 123 08 AXLE D120 L=229 2
21 550 413 18 SHAFT 1

22 550 412 66 FLANGE D200 L10 2

23 045 644 78 PIN D40 L126 2
24 207 096 38 PIN D40 L117 1
27 261 181 28 BEARING BUSHING D138 d120 L87 2
28 453 689 98 BEARING BUSHING 2

29 204 677 88 PIECE 12

30 204 676 58 LOCKING RING 24
31 550 413 45 PLATE 2
34 263 781 08 TAPER PIN SEP. PART LIST 6
35 263 781 08 TAPER PIN SEP. PART LIST 2

36 550 432 69 CLEVIS PIN D40 L163 1

37 207 788 78 CLEVIS PIN D50 L186 1
40 320 776 08 FRAME STRIP 2
41 330 016 98 SLIDE PIECE 8
42 816 647 59 HEXAGON SOCKET SET SCREW M16X25 m12.9 6

50 550 419 78 CYLINDER SEP. PART LIST 2

51 550 419 81 CYLINDER SEP. PART LIST 2
52 550 419 56 CYLINDER SEP. PART LIST 1
53 550 431 62 CYLINDER SEP. PART LIST 1
54 321 192 67 CYLINDER SEP. PART LIST 1

60 345 310 88 RUBBER PLATE 1

61 550 413 25 SEAL BAND 6x28 1
62 550 412 78 GASKET 12x328x328 1
63 550 413 33 STRIP 1
70 422 080 90 CIRCLIP 40X1,75 DIN 471 4

71 422 080 90 CIRCLIP 40X1,75 DIN 471 2

72 049 429 78 ADAPTER R3/8” – 9/16–18 UNF, L=65 2
73 208 033 08 BEARING BUSHING D60 d50 L49 1
74 208 033 08 BEARING BUSHING D60 d50 L49 1
75 453 689 98 BEARING BUSHING 1

55089964Cc 2/ 4
 DRAWING 1–550 471 17–C
2/2

55089964Cc 3/ 4
 BOOM ASSEMBLY

550 899 64
Ref Part No. Description Standard designation Qty

76 613 061 08 BEARING BUSHING 1

77 204 279 28 SHAFT BAR 2
78 207 121 68 ADAPTER R4–JIC6 , L=70 R1/4” –JIC 9/16–18 UNF, L=70 2
79 801 031 49 USIT–SEAL U 17,4X24X1,5 4
80 550 875 45 ADAPTER R3/8” – 9/16”–18 UNF, L=160 2

82 345 313 65 ADAPTER ASSY R1/8” / R1/8” l=158 1

83 851 832 29 EXTENSION PLATE ”R1/8”” L30” 12
84 572 102 40 GREASE NIPPLE AR 1/8 20
85 857 856 09 PLUG R 2” 4
86 802 285 69 USIT–SEAL U 60,7X73X3 D2=62,8 4

87 851 781 19 ELBOW EXTENSION 90 4

88 801 802 69 USIT–SEAL U 13,7X22X1,5 D2=15,4 2
90 345 313 64 ADAPTER ASSY R1/8” / R1/8” l=126 1
99 264 255 66 PROXIMITY SWITCH ASSY SEP. PART LIST 1
123 802 559 29 HEXAGON HEAD SCREW M12X20–8.8 SFS–ISO 4017 8

142 808 803 59 HEXAGON HEAD SCREW M8x16m8.8 SFS 4

144 808 802 29 HEXAGON HEAD SCREW M8X20 m8.8 SFS 2064 72
172 800 823 09 HEXAGON HEAD SCREW M10x20m8.8SFS 2064 2
173 800 460 49 HEXAGON HEAD SCREW M10X25–8.8 SFS–ISO 4017 8
204 800 470 59 HEXAGON HEAD SCREW M12x30 m8.8 SFS 2064 20

263 800 537 39 HEXAGON HEAD SCREW M16x35 m8.8 SFS 4

266 442 219 80 HEXAGON HEAD SCREW M 16X50 m8.8 SFS 2064 8
270 801 745 59 HEXAGON HEAD SCREW M16X60 m8.8 SFS 2064 26
274 802 198 29 HEXAGON HEAD BOLT 16X70 m8.8 SFS 2063 4
285 442 221 70 HEXAGON HEAD BOLT M16X120–8.8 SFS 2063 24

507 800 917 29 HEXAGON NUT M8 m8 SFS 2067 1

518 811 259 69 LOCK NUT M16 m8 B–lock 24
550 853 239 79 DOUBLE LOCK WASHER M6 8
551 851 281 89 DOUBLE LOCK WASHER M8 5
552 851 282 09 DOUBLE LOCK WASHER M10 10

553 851 068 09 DOUBLE LOCK WASHER M12 20

555 850 687 49 DOUBLE LOCK WASHER M16 90
573 421 168 00 WASHER M8 1
600 455 332 90 SCREW N:O 2 X 5 SMS 1549 4

PARTS TO BE ORDERED SEPARATELY:

26 453 689 98 BEARING BUSHING 2

55089964Cc 4/ 4
 DRAWING 1–550 404 28–A

55040428A 1/ 4
 INNER TUBE

550 404 28
Ref Part No. Description Standard designation Qty

1 550 404 23 INNER TUBE 1

2 169 475 78 LEVER 1
4 205 677 98 PLATE 1
10 133 909 18 BEARING BUSHING D=90/80 L=49 1
11 453 689 98 BEARING BUSHING 2

20 550 405 67 BEARING CB–E–0695–25–D–2 1

30 169 916 84 ROTATION UNIT SEP. PART LIST 2
31 550 001 44 FLANGE FITTING 2
40 851 781 19 ELBOW EXTENSION 90 3
41 851 601 19 MALE CONNECTOR R1/8” 6

42 851 605 29 HOSE STUD 0.6 6

43 572 102 40 GREASE NIPPLE AR 1/8 3
44 801 961 19 PIPE CLAMP 1300–7 2
45 851 606 59 HOSE .8,4/4 0
46 813 449 29 ADAPTER (HYDRAULIC) ”R1/4””xR1/8””” 6

47 851 604 09 BUSHING 1–Feb 6

50 800 073 29 SPRING–TYPEE STRAIGHT PIN 6x16 DIN 7343 1
60 857 856 09 PLUG R 2” 2
121 866 024 29 HEXAGON HEAD SCREW M6X12–8.8 SFS–ISO 4017 2
123 802 559 29 HEXAGON HEAD SCREW M12X20–8.8 SFS–ISO 4017 2

208 808 997 79 HEXAGON HEAD SCREW M12X0 m8.8 SFS 2064 16
406 885 612 79 HEXAGON HEAD BOLT M16X110 m8.8 SFS 2063 39
550 853 239 79 DOUBLE LOCK WASHER M6 4
553 851 068 09 DOUBLE LOCK WASHER M12 16
555 850 687 49 DOUBLE LOCK WASHER M16 39

55040428A 2/ 4
 DRAWING 1–550 404 28–A

55040428A 3/ 4
 INNER TUBE

550 404 28
Ref Part No. Description Standard designation Qty

1 550 404 23 INNER TUBE 1

2 169 475 78 LEVER 1
4 205 677 98 PLATE 1
10 133 909 18 BEARING BUSHING D=90/80 L=49 1
11 453 689 98 BEARING BUSHING 2

20 550 405 67 BEARING CB–E–0695–25–D–2 1

30 169 916 84 ROTATION UNIT SEP. PART LIST 2
31 550 001 44 FLANGE FITTING 2
40 851 781 19 ELBOW EXTENSION 90 3
41 851 601 19 MALE CONNECTOR R1/8” 6

42 851 605 29 HOSE STUD 0.6 6

43 572 102 40 GREASE NIPPLE AR 1/8 3
44 801 961 19 PIPE CLAMP 1300–7 2
45 851 606 59 HOSE .8,4/4 0
46 813 449 29 ADAPTER (HYDRAULIC) ”R1/4””xR1/8””” 6

47 851 604 09 BUSHING 1–Feb 6

50 800 073 29 SPRING–TYPEE STRAIGHT PIN 6x16 DIN 7343 1
60 857 856 09 PLUG R 2” 2
121 866 024 29 HEXAGON HEAD SCREW M6X12–8.8 SFS–ISO 4017 2
123 802 559 29 HEXAGON HEAD SCREW M12X20–8.8 SFS–ISO 4017 2

208 808 997 79 HEXAGON HEAD SCREW M12X0 m8.8 SFS 2064 16
406 885 612 79 HEXAGON HEAD BOLT M16X110 m8.8 SFS 2063 39
550 853 239 79 DOUBLE LOCK WASHER M6 4
553 851 068 09 DOUBLE LOCK WASHER M12 16
555 850 687 49 DOUBLE LOCK WASHER M16 39

55040428A 4/ 4
16991684cG 1/ 2
 ROTATION UNIT

169 916 84
Ref Part No. Description Standard designation Qty

1 874 556 59 PLANET GEAR SAE6B 1

5 550 163 53 GEROTOR SEP. PART LIST 1
6 168 566 08 GEAR 154B3711 1
7 206 332 48 FIXING FLANGE 1
8 874 564 09 OVERCENTER VALVE 1
10 446 137 50 HEXAGON SOCKET HEAD SCREW M8X20 m8.8 SFS 2

15 816 702 09 STRAIGHT THREAD ADAPTER F40X–S10–1/2” 2

16 816 701 89 STRAIGHT THREAD ADAPTER 40X–S10–1/4”(9/16–18JIC) 2
19 801 031 49 USIT–SEAL U 17,4X24X1,5 2
20 801 802 69 USIT–SEAL U 13,7X22X1,5 D2=15,4 2
21 812 604 09 PLUG R3/8 2
22 812 603 79 PLUG R 1/4 2

PARTS TO BE ORDERED SEPARATELY

2* 872 408 19 PLANET GEAR SEP. PART LIST 1

3* 874 557 89 BRAKE SEP. PART LIST 1
4* 874 558 09 ASSEMBLY KIT SEP. PART LIST 1
9* 446 177 90 HEXAGON SOCKET HEAD SCREW M8X75 m8.8 SFS 4
12* 522 091 30 O–RING 22,2X3–1 SMS 1586 2
23* 887 484 59 INDICATOR 1
24* 550 543 96 PLUG 1
25* 550 163 55 SEAL KIT SEAL KIT FOR PART 5 1

26* 881 533 59 SEAL KIT SEAL KIT FOR PART 4 1

27* 881 532 29 SEAL KIT SEAL KIT FOR PART 3 1
28* 881 534 89 SEAL KIT SEAL KIT FOR PART 2 1
29* 817 058 39 PRESSURE RELIEF VALVE 2
30* 851 090 09 SEAL KIT SEAL KIT FOR PART 29 2

16991684cG 2/ 2
87240819 1 / NO TAG
 PLANETARY REDUCTION GEAR

872 408 19
Ref Part No. Description Standard designation Qty

550 080 51 REPAIR KIT INCL. PARTS 1.2.4.5.7.8.9.10.11.12.13 1

881 534 89 SEAL KIT INCL. PARTS 3.6 1
1 SCREW 6
2 SUPPORT 1
3 OR 1

4 OUTPUT SHAFT 1
5 KEY 1
6 OIL SEAL 1
7 BEARING 2
8 SUPPORT 1

9 ESCAPE AIR PLUG 1

10 OIL LEVEL PLUG 2
11 MAGNETIC PLUG 1
12 STEEL PLUG 2
13 WASHER 1

14 RING NUT WASHER 1

16 SPRING PIN 4
17 PINION R=3.18:1 1
17 PINION R=3..4:1 1
17 PINION R=4:1 1

17 PINION R=5:1 1
17 PINION R=5.8:1 1
17 PINION R=7:1 1
18 SHIMMING 1
19 OR 2

20 COMPLETE REDUCTION R=3.18:1 1

20 COMPLETE REDUCTION R=3..4:1 1
20 COMPLETE REDUCTION R=4:1 1
20 COMPLETE REDUCTION R=5:1 1
20 COMPLETE REDUCTION R=5.8:1 1

20 COMPLETE REDUCTION R=7:1 1

21 PLANETARY RING 1
26 SCREW 8

87240819 2 / NO TAG
87455789 1 / NO TAG
 BRAKE

874 557 89
Ref Part No. Description Standard designation Qty

881 532 29 SEAL KIT INCL. PARTS 3.13.14.15.16.17.21 1

1 SEEGER 1
2 BEARING 1
3 OIL SEAL 1
4 SUPPORT 1

5 STEEL PLUG 1
6 PLASTIC PLUG 1
7 STEEL PLUG 1
8 STEEL PLUG 4
9 IRON DISC 6

10 SINTERED DISC 7
11 IMPUT SHAFT 1
12 SEEGER 1
13 EXPANSION PLUG 1
14 PARBAK 1

15 OR 1
16 OR 1
17 PARBAK 1
18 BRAKE PISTON 1
19 SPRING FOR RF5 / 130 18

19 SPRING FOR RF5 / 110 15

19 SPRING FOR RF5 / 85 12
19 SPRING FOR RF5 / 65 9
19 SPRING FOR RF5 / 43 6
19 SPRING FOR RF5 / 29 4

19 SPRING FOR RF5 / 21 3

20 SEEGER 1
21 OR 1
22 SUPPORT 1
23 MAGNETIC PLUG 1

24 OIL LEVEL PLUG 2

25 SCREW 8
26 AIR ESCAPE PLUG 1
27 BEARING 1
28 SEEGER 1
29 SEEGER 1

87455789 2 / NO TAG
87455809 1 / NO TAG
 MOUNTING KIT

874 558 09
Ref Part No. Description Standard designation Qty

881 533 59 SEAL KIT INCL. PARTS 1.2 1

1 GASKET 1
2 OIL SEAL 1
3 FLANGE 1
4 ELASTIC WASHER 1

5 SCREW 2
6 SCREW 4
7 COUPLING 1

87455809 2 / NO TAG
 GEROTOR
OMR 315
550 163 53

6 12
4
C–C 15

17

C C

Ref Part No. Description Standard designation Qty

1 550 163 55 SEAL KIT INCL. PARTS 4. 6. 12. 15. 17 1

4 DUST SEAL RING 28.56X35X2.2mm 1

6 SAFT SEAL 28.56X39X4.85mm 1
12 O–RING 90X2mm 3
15 WASHERS 8.4mm 7
17 WASHERS 13.5mm 1

55016353b 1/ 1
 TAPER PIN

263 781 08





Ref Part No. Description Standard designation Qty

1 263 779 18 PIN 1

2 263 780 88 CONICAL BUSHING D55 d37,2 L43 2
3 851 283 39 DOUBLE LOCK WASHER M20 2
4 806 198 69 HEXAGON HEAD SCREW M20X1,5X40 m8.8 SFS 2066 2

26378108a 1/ 1
 CYLINDER

550 419 78











Ä
Í
ÍÍÍ
ÍÍÍ
Ä Ä
ÍÍÍÍ
ÈÈ


ÈÈÄ
Ä



ÍÍ
ÄÄ



 MIN 924

 15 MAX 1471



Ref Part No. Description Standard designation Qty

1 137 876 08 CYLINDER TUBE INCL. PARTS 40,41 1

2 550 419 74 PISTON ROD INCL. PARTS 40,41 1
3 155 004 08 PISTON Piston 1
4 161 412 68 COVER Cover 1
6 869 128 99 LOCK NUT (M40X1,5) 1

8 803 135 09 U–SEAL U–seal 1

9 522 300 00 O–RING 114,3x5,7–1 SMS 1586 1
10 814 797 09 PISTON ROD GUIDE RING Ring 3
11 428 702 10 O–RING 49,5x3–1 SMS 1586 1
12 816 819 39 PISTON SEAL 125x100x25,4 1

13 807 823 69 WIPER 50–60–7–10 1

15 801 031 49 USIT–SEAL U 17,4X24X1,5 2
30 816 713 49 STRAIGHT THREAD ELBOW 9/16/18 2
31 857 302 19 PLUG FNTX–S10 2
32 817 414 09 OVERCENTER VALVE 2

40 133 900 78 BEARING BUSHING D65 d50 L59 2

41 572 102 40 GREASE NIPPLE AR1/8 2

PARTS TO BE ORDERED SEPARATELY:

42 819 440 39 SEAL KIT FOR PART 32 1

43 855 777 09 SEAL KIT FOR CYLINDER INCL. PARTS 8–13,15 1

55041978F 1/ 1
 CYLINDER

550 419 81










ÍÍÍ Ä


Í
ÈÈ
ÍÍÍ
ÍÍÍ
ÄÄ
ÈÈ
ÄÄ
ÈÈ
ÈÈ
ÄÄ
ÍÍ
ÄÄ







 MIN 924

 15 MAX 1359



Ref Part No. Description Standard designation Qty

1 137 876 08 CYLINDER TUBE INCL. PART 40,41 1

2 550 419 74 PISTON ROD INCL. PART 40,41 1
3 155 004 08 PISTON Piston 1
4 161 412 68 COVER Cover 1
6 869 128 99 LOCK NUT (M40X1,5) 1

8 803 135 09 U–SEAL U–seal 1

9 522 300 00 O–RING 114,3x5,7–1 SMS 1586 1
10 814 797 09 PISTON ROD GUIDE RING Ring 3
11 428 702 10 O–RING 49,5x3–1 SMS 1586 1
12 816 819 39 PISTON SEAL 125x100x25,4 1

13 807 823 69 WIPER 50–60–7–10 1

15 801 031 49 USIT–SEAL U 17,4X24X1,5 2
17 550 419 66 LIMIT BUSHING D65 d50 L112 1
30 816 713 49 STRAIGHT THREAD ELBOW 9/16/18 2
31 857 302 19 PLUG FNTX–S10 2

32 817 414 09 OVERCENTER VALVE 2

40 133 900 78 BEARING BUSHING D65 d50 L59 2

41 572 102 40 GREASE NIPPLE AR1/8 2

PARTS TO BE ORDERED SEPARATELY:

42 819 440 39 SEAL KIT FOR PART 32 1

43 855 777 09 SEAL KIT FOR CYLINDER INCL. PARTS 8–13,15 1

55041981F 1/ 1
 CYLINDER

550 419 56












Ref Part No. Description Standard designation Qty

1 320 093 58 CYLINDER TUBE INCL. PARTS 30,31 1

2 320 094 88 PISTON ROD INCL. PARTS 30,31 1
3 162 417 08 COVER 100/50 1
4 155 024 28 PISTON 1
5 514 010 20 LOCK NUT KM 8 1

6 514 408 40 LOCK WASHER MB 8 1

7 817 269 29 PISTON RING 100 X 75 X 22,4 1
8 803 135 09 U–SEAL U–seal 1
9 807 823 69 WIPER 50–60–7–10 1
10 522 235 40 O–RING 89,1X5,7–1 1

11 428 702 10 O–RING 49,5x3–1 SMS 1586 1

12 814 797 09 PISTON ROD GUIDE RING Ring 3
13 800 119 69 O–RING 99,5x3–1, NBR, 70 SHORE A 1
14 817 414 09 OVERCENTER VALVE 2
15 856 040 09 STRAIGHT THREAD ADAPTER F40X–S10–3/8 2

16 857 302 19 PLUG FNTX–S10 2

18 208 615 01 LIMIT BUSHING L=500 D=50/80 1
19 205 350 01 LIMIT BUSHING D=50 L=25 1

30 527 102 40   


31 613 061 08 BEARING BUSHING D48 d40 L49,5 2

PARTS TO BE ORDERED SEPARATELY:

32 819 440 39 SEAL KIT FOR PART 14 1

33 879 187 49 SEAL KIT FOR CYLINDER 1

55041956E 1/ 1
 CYLINDER

550 431 62

SEAL KIT 871 934 69

1 22,23 11 3 5 10 24,21,20 6 9 8 4 19 7 2
20,21
20,21

12
17,18

15,16

Ref Part No. Description Standard designation Qty

1 550 431 61 CYLINDER TUBE INCL. PARTS 20,21 1

2 321 569 38 PISTON ROD D50 INCL. PARTS 20,21 1
3 155 024 28 PISTON 1
4 162 417 08 COVER 100/50 1
5 817 269 29 PISTON RING 100 X 75 X 22,4 1

6 803 135 09 U–SEAL U–seal 1

7 807 823 69 WIPER 50–60–7–10 1
8 814 797 09 PISTON ROD GUIDE RING Ring 3
9 522 235 40 O–RING 89,1X5,7–1 1
10 428 702 10 O–RING 49,5x3–1 SMS 1586 1

11 869 128 99 LOCK NUT (M40X1,5) 1

12 871 693 09 OVERCENTER VALVE 2
15 856 040 09 STRAIGHT THREAD ADAPTER F40X–S10–3/8 2
16 803 264 29 PLUG 210292–6 9/16”–18 JIC 2
17 812 604 09 PLUG R3/8 2
18 801 802 69 USIT–SEAL U 13,7X22X1,5 D2=15,4 2
19 800 119 69 O–RING 99,5x3–1, NBR, 70 SHORE A 1
20 208 033 08 BEARING 2
21 572 102 40 GREASE NIPPLE AR 1/8 2

55043162O 1/ 1
 HYDR.CYLINDER ASSY
D80/50

321 192 67






ÍÍÍÍ
Ä



Í
ÍÍÍÍ
ÍÍÍ
ÄÄ
ÍÍÍÍ
ÈÈ
È
Ä
ÈÈ
Ä
È






 MIN 1800

 MAX 3300

Ref Part No. Description Standard designation Qty

1 321 584 18 CYLINDER TUBE D80 INCL. PARTS 21,22 1

2 321 586 78 PISTON ROD D50 INCL. PARTS 21,22 1
3 155 044 48 PISTON 1
4 162 395 08 COVER 1

5 869 128 99 LOCK NUT (M40X1,5) 1

7 817 317 59 PISTON RING DBM 80/60X22 (5 80–60–15,4–33,8) 1
8 803 135 09 U–SEAL BS 5006 P5008 (NI300) 1
9 807 823 69 WIPER AM 5006 Z5053 (50–60–7–10) 1
10 522 271 70 O–RING 69,2X5,7–1 SMS 1586 1

11 428 702 10 O–RING 49,5X3–1 SMS 1586 1

12 814 797 09 GUIDE RING I/PWR 50/56X13 1
13 800 118 39 O–RING 79,5X3–1 SMS 1586 1
14 812 603 79 PLUG R1/4 2
15 801 802 69 BONDED SEAL U 13,7X22X1,5 D2=15,4 2

16 816 701 89 STRAIGHT THREAD CONNECTOR F40X–S10–1/4”(9/16–18JIC) 2

17 803 264 29 CAP 210292–6 9/16–18 JIC 2
21 572 102 40 GREASE NIPPLE DIN 71412 AR 1/8 2
22 613 061 08 BUSHING D=48/40 L=50 2
856 700 69 SEAL KIT ASSY INCL. PARTS 7–13,15 1


 1/ 1
 PROXIMITY SWITCH ASSY

264 255 66

Ref Part No. Description Standard designation Qty

1 264 256 98 HOLDER 1

2 087 464 68 COVER 1
3 851 210 99 LOCKNUT HD 1270–24 R1,1/2” 2
4 813 840 99 CABLE ENTRY SSTL 17 307 64–6 1

5 522 113 40 O–RING 29,2X3–1 SMS 1586 1

6 880 749 79 PROXIMITY SWITCH 10–30VDC II5446/IIB3010–BPKG/US 1
7 801 870 79 O–RING OR 46,2X3 SIMRIT 2
10 887 262 29 SENSOR CABLE 5M


 1/ 1
55080390a 1/ 2
 FRONT FRAME ASSEMBLY

550 803 90
Ref Part No. Description Standard designation Qty

1 550 803 73 FRONT FRAME Front frame SOLO 5 C, welding 1

2 550 407 06 CROSS PIECE, MACHINING Machining 1
3 550 410 27 SUPPORTING BLOCK Machining 1
4 332 168 38 SHAFT D140 L=565 1
5 054 045 58 SHAFT D120 L=164 2

6 048 464 68 BUSHING D160 d140 L140 2

7 155 344 28 BEARING BUSHING D135/120 L=70 4
8 155 275 58 BEARING BUSHING D138 d120 L80 2
9 263 784 98 TAPER PIN SEP. PART LIST 2
10 264 388 01 TAPER PIN SEP. PART LIST 2

11 263 781 08 TAPER PIN SEP. PART LIST 2

12 345 283 08 FLANGE D200 L=20 2
15 345 200 41 CYLINDER SEP. PART LIST 2
16 325 481 46 CYLINDER SEP. PART LIST 1
17 550 803 68 JACK SEP. PART LIST 1

18 550 801 79 JACK SEP. PART LIST 1

21 800 538 69 HEXAGON HEAD SCREW M16X45 m8.8 SFS 2064 24
22 442 776 90 HEXAGON HEAD SCREW M12X35 8.8 SFS 2064 8
26 850 687 49 DOUBLE LOCK WASHER M16 24
27 851 068 09 DOUBLE LOCK WASHER M12 8

30 572 102 40 GREASE NIPPLE AR 1/8 8

55080390a 2/ 2
 TAPER PIN

263 784 98

Ref Part No. Description Standard designation Qty

1 263 782 38 PIN D70 1

2 263 783 68 CONICAL BUSHING D70 2
3 851 283 39 DOUBLE LOCK WASHER M20 2
4 865 364 39 HEXAGON HEAD SCREW M20X1,5X45 m8.8 SFS 2066 2

26378498a 1/ 1
 TAPER PIN

264 388 01

Ref Part No. Description Standard designation Qty

1 264 390 98 PIN 1

2 263 783 68 CONICAL BUSHING D70 1
3 851 283 39 DOUBLE LOCK WASHER M20 1
4 883 131 09 HEXAGON HEAD SCREW M20x1.5x170–m8.8 SFS–EN 28765 (ISO) 1
5 264 392 48 CONICAL BUSHING PIN D70 1

26438801aA 1/ 1
 HYDR. CYLINDER, 140 / 70

345 200 41

18.19 1 15.17 5 6 7 4 12 3 8 11 10 13 9 2

14.16 MIN 714

MAX 1000 18.19

Ref Part No. Description Standard designation Qty

1 352 210 58 CYLINDER TUBE INCL. PARTS 18.19 1

2 323 348 58 PISTON ROD INCL. PARTS 18.19 1
3 321 369 88 COVER 140 (L=95) 1
4 053 699 68 PISTON 1
5 817 058 39 RELIEF VALVE 2

6 871 374 39 LOCK NUT 1

7 816 976 39 PISTON SEAL 140–115–18,4/36,8) 1
8 874 560 09 U–SEAL 70X80X12 ,PARKER BS 7080 P5008 1
9 801 010 09 WIPER 70X80X10/7 ,PARKER AM 7008 Z5053 1
10 817 054 29 PISTON ROD GUIDE RING 3

11 817 053 09 O–RING 129,54X6,99–1 , 90 SHORE A 1

12 800 805 39 O–RING 69,5X3–1 ,90 SHORE A 1
13 445 827 20 HEXAGON SOCKET HEAD SCREW (FULL THREAD) M12X40 – 8.8 18
14 856 040 09 STRAIGHT THREAD CONNECTOR 9/16–18JIC 2
15 812 604 09 PLUG PIIR.NO 3–090291 4

16 857 302 19 PLUG 9/16–18JIC 2

17 801 031 49 USIT–SEAL U 17,4X24X1,5 ,D2=19,1 4
18 572 102 40 GRESE NIPPLE 2
19 207 973 88 BEARING 2
855 604 39 SEAL KIT HYDR. CYLINDER 1

34520041B 1/ 1
 HYDR.CYLINDER 125/50 ASSY

325 481 46

   12






MIN 653
MAX 883

Ref Part No. Description Standard designation Qty

1 321 767 38 CYLINDER TUBE D125 INCL. PARTS 20,21 1

2 321 769 98 PISTON ROD INCL. PARTS 20,21 1
3 155 004 08 PISTON 1
4 161 412 68 COVER 125/50 1
5 871 693 09 OVERCENTER VALVE 270bar INCL. PARTS 22 2

6 816 819 39 PISTON SEAL 125/100X25 1

7 803 135 09 U–SEAL BS 5006 P5008 1
8 807 823 69 WIPER AM 5006 Z5053 1
9 814 797 09 GUIDE RING I/PWR 50/56X13 3
10 522 300 00 O–RING 114,3X5,7–1 SMS 1586 1

11 428 702 10 O–RING 49,5X3–1 SMS 1586 1

12 869 128 99 LOCK NUT (M40X1,5) 1
13 816 713 49 STRAIGHT THREAD ELBOW C40X–S10–3/8” (9/16–18) 2
14 812 604 09 PLUG 4
15 801 031 49 BONDED SEAL U 17,4X24X1,5 D2=19,1 4

16 857 302 19 FITTING CAP FNTX–S10 (9/16–18JIC) 2

20 572 102 40 GREASE NIPPLE AR1/8 DIN 71412 3
21 133 900 78 BUSHING 2
22 871 694 39 SEAL KIT FOR OVERCENTER VALVE 2
855 777 09 SEAL KIT FOR HYDRAULIC CYLINDER INCL. PARTS 6–11,15 1


 1/ 1
 DRAWING
2 – 550 801 79

55080368 1/ 2
 JACK

550 803 68
Ref Part No. Description Standard designation Qty

1 550 803 69 PLATE LUG 1

2 323 150 98 ARM, MACHINING 1
3 550 414 43 CYLINDER SEP. PART LIST 1
4 331 758 88 SHAFT 1
5 323 153 78 RIBBON 1

6 323 152 48 COVER 1

7 331 751 98 PAW 8
8 331 752 18 CLEVIS PIN D50 L231 2
9 550 088 48 WEAR PLATE D=130, d=62, s=6, HARDOX400 2
10 550 088 37 LOCK SEP. PART LIST 1

11 134 419 08 BEARING BUSHING D70 d60 L39 2

12 133 944 18 BEARING BUSHING 70/60 L=60 2
13 232 101 88 BEARING BUSHING D60 d50 L30 8
14 263 781 08 TAPER PIN SEP. PART LIST 1
15 344 886 38 WASHER 1

16 880 678 49 HEXAGON THIN NUT M45X1,5 m8 DIN 936 2

17 206 895 18 FLANGE 1
18 204 279 28 SHAFT BAR 2
19 572 102 40 GREASE NIPPLE AR 1/8 8
20 800 470 59 HEXAGON HEAD SCREW M12x30 m8.8 SFS 2064 4

21 851 068 09 DOUBLE LOCK WASHER M12 4

22 204 876 08 BUSHING D48 d40 L40 3
23 232 102 08 BEARING BUSHING D60 d50 L40 1
24 442 219 80 HEXAGON HEAD SCREW M 16X50 m8.8 SFS 2064 2
25 850 687 49 DOUBLE LOCK WASHER M16 2

55080368 2/ 2
 CYLINDER

550 414 43

DRAWING 1–328 936–A

40,41 40,41





Ref Part No. Description Standard designation Qty

1 323 160 08 CYLINDER TUBE INCL. PARTS 40,41 1

2 323 159 38 PISTON ROD 50 INCL. PARTS 40,41 1
3 155 004 08 PISTON 1
4 161 412 68 COVER 1
6 869 128 99 LOCK NUT (M40X1,5) 1

8 803 135 09 U–SEAL 1

9 522 300 00 O–RING 114,3x5,7–1 SMS 1586 1
10 814 797 09 PISTON ROD GUIDE RING 3
11 428 702 10 O–RING 49,5x3–1 SMS 1586 1
12 816 819 39 PISTON SEAL 125x100x25,4 1

13 807 823 69 WIPER 50–60–7–10 1

15 801 031 49 USIT–SEAL U 17,4X24X1,5 2
16 205 350 01 LIMIT BUSHING D=50 L=25 1
17 205 348 01 LIMIT BUSHING D125 L=25 1
30 816 713 49 STRAIGHT THREAD ELBOW 9/16/18 2

31 857 302 19 PLUG FNTX–S10 2

32 853 466 79 OVERCENTER VALVE 2
40 572 102 40 GREASE NIPPLE AR 1/8 2
41 133 900 78 BEARING BUSHING D65 d50 L59 2

PARTS TO BE ORDERED SEPARATELY:

42 819 440 39 SEAL KIT FOR PART 32 1

43 819 945 09 SEAL KIT FOR CYLINDER INCL. PARTS 8–13,15 1

55041443aA 1/ 1
 LOCK

550 088 37

DRAWING 3–550 088 37–A

Ref Part No. Description Standard designation Qty

1 550 088 43 FRAME 1

2 331 754 78 ARM 1
3 550 088 46 LOCKING PIN 1
4 623 604 18 JOUSI 22,5/2,5 1
5 814 851 39 HEXAGON SOCKET SET SCREW M8X10 – 8.8, dog point 2

6 572 102 40 GREASE NIPPLE AR 1/8 1

7 804 093 89 O–RING 18,1X1,6–1 SMS 1586 1
8 448 200 80 HEXAGON SOCKET SET SCREW M6X10 – 8.8, flat point 1

55008837aA 1/ 1
 DRAWING
2 – 550 801 79

55080179 1/ 2
 JACK

550 801 79
Ref Part No. Description Standard designation Qty

1 550 801 80 PLATE LUG 1

2 323 150 98 ARM, MACHINING 1
3 550 414 43 CYLINDER SEP. PART LIST 1
4 331 758 88 SHAFT 1
5 323 153 78 RIBBON 1

6 323 152 48 COVER 1

7 331 751 98 PAW 1
8 331 752 18 CLEVIS PIN D50 L231 2
9 550 088 48 WEAR PLATE D=130, d=62, s=6, HARDOX400 2
10 550 088 37 LOCK SEP. PART LIST 1

11 134 419 08 BEARING BUSHING D70 d60 L39 2

12 133 944 18 BEARING BUSHING 70/60 L=60 2
13 232 101 88 BEARING BUSHING D60 d50 L30 8
14 263 781 08 TAPER PIN SEP. PART LIST 1
15 344 886 38 WASHER 1

16 880 678 49 HEXAGON THIN NUT M45X1,5 m8 DIN 936 2

17 206 895 18 FLANGE 1
18 204 279 28 SHAFT BAR 2
19 572 102 40 GREASE NIPPLE AR 1/8 8
20 800 470 59 HEXAGON HEAD SCREW M12x30 m8.8 SFS 2064 4

21 851 068 09 DOUBLE LOCK WASHER M12 4

22 204 876 08 BUSHING D48 d40 L40 3
23 232 102 08 BEARING BUSHING D60 d50 L40 1
24 442 219 80 HEXAGON HEAD SCREW M 16X50 m8.8 SFS 2064 2
25 850 687 49 DOUBLE LOCK WASHER M16 2

55080179 2/ 2
 DRAWING 1–550 865 12–A

55086512aA 1/ 4
 HOSE SUPPORT ASSEMBLY

550 865 12
Ref Part No. Description Standard designation Qty

1 550 865 17 SUPPORTING BLOCK ASSEMBLY SEP. PART LIST 1

2 550 615 79 SUPPORTING BLOCK 1
8 807 695 29 STRAP L=400 2
9 802 284 39 USIT–SEAL 48,7X59X3 D2=50,8 1
10 208 379 98 ADAPTER R1 1/2”–1 5/16”–12 UNF 1

11 816 702 09 STRAIGHT THREAD ADAPTER F40X–S10–1/2” 1

12 816 778 39 STRAIGHT THREAD ADAPTER 1,5/16–12JIC 1
13 817 094 69 STRAIGHT THREAD ADAPTER 1/2 x3/4–16 JIC 2063–8–8 1
14 817 094 69 STRAIGHT THREAD ADAPTER 1/2 x3/4–16 JIC 2063–8–8 1
15 817 094 69 STRAIGHT THREAD ADAPTER 1/2 x3/4–16 JIC 2063–8–8 1

16 817 682 69 STRAIGHT THREAD ADAPTER 7/16–20JIC 1

17 816 769 59 STRAIGHT THREAD ADAPTER F40X–S18–1” (1,1/16–12JIC) 1
18 817 094 69 STRAIGHT THREAD ADAPTER 1/2 x3/4–16 JIC 2063–8–8 1
19 817 094 69 STRAIGHT THREAD ADAPTER 1/2 x3/4–16 JIC 2063–8–8 1
20 817 094 69 STRAIGHT THREAD ADAPTER 1/2 x3/4–16 JIC 2063–8–8 1

21 816 768 29 STRAIGHT THREAD ADAPTER 1,1/16”–12 JIC 1

22 816 768 29 STRAIGHT THREAD ADAPTER 1,1/16”–12 JIC 1
23 882 155 29 STRAIGHT THREAD ADAPTER 1,5/8–12 JIC 1
24 816 769 59 STRAIGHT THREAD ADAPTER F40X–S18–1” (1,1/16–12JIC) 1
26 856 040 09 STRAIGHT THREAD ADAPTER F40X–S10–3/8 1

27 856 040 09 STRAIGHT THREAD ADAPTER F40X–S10–3/8 1

28 816 768 29 STRAIGHT THREAD ADAPTER 1,1/16”–12 JIC 1
29 816 768 29 STRAIGHT THREAD ADAPTER 1,1/16”–12 JIC 1
30 817 227 39 PLUG 1,5/16–12JIC 1
31 857 302 19 PLUG FNTX–S10 1

32 817 227 39 PLUG 1,5/16–12JIC 1

33 817 097 49 PLUG 210292–8 3/4–16 JIC 1
34 817 097 49 PLUG 210292–8 3/4–16 JIC 1
35 817 097 49 PLUG 210292–8 3/4–16 JIC 1
36 817 096 19 PLUG 7/16–20 JIC 1

37 816 909 59 PLUG 1,1/16 12JIC 1

38 817 097 49 PLUG 210292–8 3/4–16 JIC 1
39 817 097 49 PLUG 210292–8 3/4–16 JIC 1
40 817 097 49 PLUG 210292–8 3/4–16 JIC 1
41 816 909 59 PLUG 1,1/16 12JIC 1

42 816 909 59 PLUG 1,1/16 12JIC 1

43 816 909 59 PLUG 1,1/16 12JIC 1
44 816 909 59 PLUG 1,1/16 12JIC 1
45 857 302 19 PLUG FNTX–S10 1
46 857 302 19 PLUG FNTX–S10 1

50 817 094 69 STRAIGHT THREAD ADAPTER 1/2 x3/4–16 JIC 2063–8–8 1

51 817 094 69 STRAIGHT THREAD ADAPTER 1/2 x3/4–16 JIC 2063–8–8 1
52 817 094 69 STRAIGHT THREAD ADAPTER 1/2 x3/4–16 JIC 2063–8–8 1
53 816 778 39 STRAIGHT THREAD ADAPTER 1,5/16–12JIC 1
54 816 702 09 STRAIGHT THREAD ADAPTER F40X–S10–1/2” 1

55086512aA 2/ 4
 DRAWING 1–550 865 12–A

55086512aA 3/ 4
 HOSE SUPPORT ASSEMBLY

550 865 12
Ref Part No. Description Standard designation Qty

55 208 379 98 ADAPTER R1 1/2”–1 5/16”–12 UNF 1

56 817 682 69 STRAIGHT THREAD ADAPTER 7/16–20JIC 1
57 816 769 59 STRAIGHT THREAD ADAPTER F40X–S18–1” (1,1/16–12JIC) 1
58 882 155 29 STRAIGHT THREAD ADAPTER 1,5/8–12 JIC 1
59 816 769 59 STRAIGHT THREAD ADAPTER F40X–S18–1” (1,1/16–12JIC) 1

60 816 768 29 STRAIGHT THREAD ADAPTER 1,1/16”–12 JIC 1

61 816 768 29 STRAIGHT THREAD ADAPTER 1,1/16”–12 JIC 1
62 817 094 69 STRAIGHT THREAD ADAPTER 1/2 x3/4–16 JIC 2063–8–8 1
63 817 094 69 STRAIGHT THREAD ADAPTER 1/2 x3/4–16 JIC 2063–8–8 1
64 817 094 69 STRAIGHT THREAD ADAPTER 1/2 x3/4–16 JIC 2063–8–8 1

65 856 040 09 STRAIGHT THREAD ADAPTER F40X–S10–3/8 1

66 856 040 09 STRAIGHT THREAD ADAPTER F40X–S10–3/8 1
70 817 097 49 PLUG 210292–8 3/4–16 JIC 1
71 817 097 49 PLUG 210292–8 3/4–16 JIC 1
72 817 097 49 PLUG 210292–8 3/4–16 JIC 1

73 817 227 39 PLUG 1,5/16–12JIC 1

74 857 302 19 PLUG S10 1
75 817 227 39 PLUG 1,5/16–12JIC 1
76 817 096 19 PLUG 7/16–20 JIC 1
77 816 909 59 PLUG 1,1/16 12JIC 1

78 816 909 59 PLUG 1,1/16 12JIC 1

79 816 909 59 PLUG 1,1/16 12JIC 1
80 816 909 59 PLUG 1,1/16 12JIC 1
81 816 909 59 PLUG 1,1/16 12JIC 1
82 817 097 49 PLUG 210292–8 3/4–16 JIC 1

83 817 097 49 PLUG 210292–8 3/4–16 JIC 1

84 817 097 49 PLUG 210292–8 3/4–16 JIC 1
85 857 302 19 PLUG FNTX–S10 1
86 857 302 19 PLUG FNTX–S10 1
87 550 038 19 METALLIC CABLE GLAND M25x1.5, 13–18mm 1

88 550 038 19 METALLIC CABLE GLAND M25x1.5, 13–18mm 1

266 442 219 80 HEXAGON HEAD SCREW M 16X50 m8.8 SFS 2064 2
555 850 687 49 DOUBLE LOCK WASHER M16 2

55086512aA 4/ 4
 SUPPORTING BLOCK ASSEMBLY
550 865 17

DRAWING 3–550 865 17

Ref Part No. Description Standard designation Qty

1 206 895 18 FLANGE 1

2 264 743 38 BEARING BUSHING 1
3 550 865 20 BRACKET 1
4 550 267 33 BULKHEAD PLATES 1
5 880 678 49 HEXAGON THIN NUT M45X1,5 m8 DIN 936 2

55086517a 1/ 1
 LASER EQUIPMENT

550 713 69

DRAWING 3–263 859–C

Ref Part No. Description Standard designation Qty

1 550 036 41 LASER EQUIPMENT 24VDC, CLASS 2 LASER 1

2 802 446 09 CABLE GLAND PK9 , SSTL 17 101 09–8 1
3 442 502 60 HEXAGON HEAD SCREW M6X25 – 8.8 4
4 853 239 79 DOUBLE LOCK WASHER M6 4
5 207 595 48 REAR COVER 1

6 207 596 78 SEAL D58 d36 s1 2

7 263 858 08 FRAME 1
8 881 661 59 O–RING 24x5.50 NBR 70 3
9 550 713 68 COVER 1
10 207 597 08 GLAS 1

11 207 604 68 WARNINIG RADIATION HAZARD 1

12 455 332 90 SCREW 2 X 5 SMS 1549 4
13 850 811 79 HEXAGON SOCKET COUNTERSUNK HEAD SCREW M6X16 m8.8 DIN 4

55071369C 1/ 1
 DRAWING 1–550 471 19–C
1/2

55080586aC 1/ 4
 MOUNTING

550 805 86
Ref Part No. Description Standard designation Qty

41 264 547 98 COVER 4

45 265 038 88 COVER 1
51 851 789 39 DISTRIBUTOR 4
52 851 788 09 DISTRIBUTOR 3
55 851 786 59 DISTRIBUTOR 2

65 390 130 38 PLATE 9

66 390 122 88 SIGN 4
67 390 123 08 SIGN 1
68 390 126 98 PLATE 2
69 390 127 18 PLATE 2

70 390 128 48 PLATE 2

71 390 129 78 PLATE 1
208 808 997 79 HEXAGON HEAD SCREW M12X0 m8.8 SFS 2064 12
553 851 068 09 DOUBLE LOCK WASHER M12 12
600 455 332 90 SCREW N:O 2 X 5 SMS 1549 84

709 445 715 30 HEXAGON SOCKET HEAD SCREW M6X40 m12.9 SFS 18

55080586aC 2/ 4
 DRAWING 1–550 471 19–C
2/2

55080586aC 3/ 4
 MOUNTING

550 805 86
Ref Part No. Description Standard designation Qty

41 264 547 98 COVER 4

45 265 038 88 COVER 1
51 851 789 39 DISTRIBUTOR 4
52 851 788 09 DISTRIBUTOR 3
55 851 786 59 DISTRIBUTOR 2

65 390 130 38 PLATE 9

66 390 122 88 SIGN 4
67 390 123 08 SIGN 1
68 390 126 98 PLATE 2
69 390 127 18 PLATE 2

70 390 128 48 PLATE 2

71 390 129 78 PLATE 1
208 808 997 79 HEXAGON HEAD SCREW M12X0 m8.8 SFS 2064 12
553 851 068 09 DOUBLE LOCK WASHER M12 12
600 455 332 90 SCREW N:O 2 X 5 SMS 1549 84

709 445 715 30 HEXAGON SOCKET HEAD SCREW M6X40 m12.9 SFS 18

55080586aC 4/ 4
 SENSOR ASSEMBLY

550 863 35

Ref Part No. Description Standard designation Qty

1 550 863 37 BRACKET Inclinometer 1

10 550 313 94 SENSOR Inklination /–45 (90) / 360 degr. 1
20 885 568 59 SHIELDED CABLE GLAND (13–18) 2
100 550 724 92 HEXAGON SOCKET HEAD SCREW M4x10 ,A4 4

55086335a 1/ 1
