MAIN ASSEMBLY

SOLO 5

550 798 65

DRAWING 1–550 371 95–B

Ref Part No. Description Standard designation Qty

2 550 798 58 CARRIER MODULE SEP. PART LIST 1

3 550 798 59 BOOM MODULE SEP. PART LIST 1
4 550 798 60 DRILLING MODULE SEP. PART LIST 1
6 550 798 61 FINISHING MODULE SEP. PART LIST 1
7 550 798 62 ELECTRIC MODULE SEP. PART LIST 1

799 550 583 12 SCREW SET SEP. PART LIST 1

900 550 798 63 SEPARATE PARTS 1

55079865aB 1/ 1
 SCREW SET

550 583 12
Ref Part No. Description Standard designation Qty

354 442 936 00 HEXAGON HEAD SCREW M24X60 – 8.8 9

357 442 325 00 HEXAGON HEAD BOLT M24X80 8.8 9
557 851 284 69 DOUBLE LOCK WASHER M24 36

55058312b 1/ 1
 DRAWING 1–550 371 92

55079861e 1/ 4
 FINISHING MODULE

550 798 61
Ref Part No. Description Standard designation Qty

40 550 550 51 SIGN TYPE 1

42 205 398 58 SIGN “AIR INTAKE” 1
43 205 399 88 SIGN WATER IN 1
44 157 217 78 SIGN ”EXTRA FLOW” 1
45 132 727 18 SIGN OILER DRAINAGE 3

46 550 439 49 SIGN TYRE PRESSURE 10 BAR 4

47 390 100 08 SIGN LIFTING 4
48 132 730 38 SIGN ”WELDING INSTRUCTIONS” 1
49 390 039 58 SYMBOL ”HYDR.OIL TEMPERATURE” 1
50 004 508 08 SIGN ”ROTATION DIRECTION” 1

51 390 009 28 SIGN 13X48 1

52 390 075 88 SIGN AIR PRESSURE 1
53 390 098 88 SIGN AIR FILTER 1
54 390 064 48 SIGN 70X70 1
55 550 509 86 SIGN 1

56 550 511 35 SIGN 1

58 390 097 58 SIGN ENGINE STOPPING INSTR. 1
59 550 309 34 SIGN PARKING BRAKE PRESSURE 2
60 881 715 49 TOP COAT PAINT . 30
61 881 716 79 OIL 250

62 818 519 79 FUEL 80

71 136 219 68 SIGN 2
72 207 333 88 SIGN DANGER AREA DRILLING 4
73 207 343 98 SIGN BOOM 2
74 207 353 08 SIGN HYDRAULICS 3

75 207 273 98 SIGN SLIP RING UNIT 1

76 207 283 08 SIGN HAZARDOUS VOLTAGE 1
77 207 303 58 SIGN CRUSHING HAZARD 2
78 207 363 08 SIGN SLIPPING HAZARD 2
79 207 323 78 SIGN 1

81 550 890 52 SIGN “SEAT BELT” 1

82 208 264 18 SIGN PRESSURE ACCUMULATOR 3
84 207 313 68 SIGN AIR/OIL INJECT. HAZARD 4
85 207 383 28 SIGN SAFETY 1
86 207 393 38 SIGN SAFETY 1

87 207 373 18 SIGN ROLL OVER HAZARD 1

88 207 263 88 SIGN ’’TIPPING HAZARD’’ 1
89 550 645 89 INSTRUCTION PLATE 1
90 550 309 35 SIGN VENTING OF WATER PUMP 1
91 550 028 46 SIGN PATENT NAMEPLATE 1

102 738 332 56 FILTER ELEMENT FC1096Q010BS 1

103 815 584 79 FILTER ELEMENT 1
820 550 514 38 SIGN SET INCL. PARTS 40–54, 58, 59, 71, 90 AND 91 1
821 550 672 01 CAUTION BOARD SET INCL. PARTS 72–89 1
822 550 879 59 DECAL SET 1

824 888 028 09 SIGNS ANSUL 55–9094–56 1

830 550 490 33 LIFTING INSTRUCTION 1
840 887 636 19 KEY 03–253 5536 1
899 550 458 40 SCREW SET SEP. PART LIST 1

55079861e 2/ 4
 DRAWING 1–550 371 92

55079861e 3/ 4
 FINISHING MODULE

550 798 61
Ref Part No. Description Standard designation Qty

40 550 550 51 SIGN TYPE 1

42 205 398 58 SIGN “AIR INTAKE” 1
43 205 399 88 SIGN WATER IN 1
44 157 217 78 SIGN ”EXTRA FLOW” 1
45 132 727 18 SIGN OILER DRAINAGE 3

46 550 439 49 SIGN TYRE PRESSURE 10 BAR 4

47 390 100 08 SIGN LIFTING 4
48 132 730 38 SIGN ”WELDING INSTRUCTIONS” 1
49 390 039 58 SYMBOL ”HYDR.OIL TEMPERATURE” 1
50 004 508 08 SIGN ”ROTATION DIRECTION” 1

51 390 009 28 SIGN 13X48 1

52 390 075 88 SIGN AIR PRESSURE 1
53 390 098 88 SIGN AIR FILTER 1
54 390 064 48 SIGN 70X70 1
55 550 509 86 SIGN 1

56 550 511 35 SIGN 1

58 390 097 58 SIGN ENGINE STOPPING INSTR. 1
59 550 309 34 SIGN PARKING BRAKE PRESSURE 2
60 881 715 49 TOP COAT PAINT . 30
61 881 716 79 OIL 250

62 818 519 79 FUEL 80

71 136 219 68 SIGN 2
72 207 333 88 SIGN DANGER AREA DRILLING 4
73 207 343 98 SIGN BOOM 2
74 207 353 08 SIGN HYDRAULICS 3

75 207 273 98 SIGN SLIP RING UNIT 1

76 207 283 08 SIGN HAZARDOUS VOLTAGE 1
77 207 303 58 SIGN CRUSHING HAZARD 2
78 207 363 08 SIGN SLIPPING HAZARD 2
79 207 323 78 SIGN 1

81 550 890 52 SIGN “SEAT BELT” 1

82 208 264 18 SIGN PRESSURE ACCUMULATOR 3
84 207 313 68 SIGN AIR/OIL INJECT. HAZARD 4
85 207 383 28 SIGN SAFETY 1
86 207 393 38 SIGN SAFETY 1

87 207 373 18 SIGN ROLL OVER HAZARD 1

88 207 263 88 SIGN ’’TIPPING HAZARD’’ 1
89 550 645 89 INSTRUCTION PLATE 1
90 550 309 35 SIGN VENTING OF WATER PUMP 1
91 550 028 46 SIGN PATENT NAMEPLATE 1

102 738 332 56 FILTER ELEMENT FC1096Q010BS 1

103 815 584 79 FILTER ELEMENT 1
820 550 514 38 SIGN SET INCL. PARTS 40–54, 58, 59, 71, 90 AND 91 1
821 550 672 01 CAUTION BOARD SET INCL. PARTS 72–89 1
822 550 879 59 DECAL SET 1

824 888 028 09 SIGNS ANSUL 55–9094–56 1

830 550 490 33 LIFTING INSTRUCTION 1
840 887 636 19 KEY 03–253 5536 1
899 550 458 40 SCREW SET SEP. PART LIST 1

55079861e 4/ 4
 SCREW SET

550 458 40
Ref Part No. Description Standard designation Qty

120 800 953 59 HEXAGON HEAD SCREW M4X16 m8.8 SFS 2064 2
505 801 772 09 HEXAGON NUT M4 m8 SFS 2067 2
600 455 332 90 SCREW N:O 2 X 5 SMS 1549 228
601 806 263 29 POP–RIVET 3,2X8 114

55045840b 1/ 1
